検索 › 比較 › KA3 × KA4

KA3 × KA4

共通 2,427 / 合計 3,862 · Jaccard 62.8%

KA3 Honda LEGEND — 3,195 中 2,427 共有

KA4 Honda LEGEND — 3,094 中 2,427 共有

2,427 件

Accelerator pedal (LH) 11 / 15

#	OEM	KA3	KA4
1	16418-PH7-660	Clamp comp. c - THROTTLE CABLE	Clamp comp. c - THROTTLE CABLE
3	17805-SE0-000	Pad - ACCELERATOR STOPPER	Pad - ACCELERATOR STOPPER
4	17814-SD4-670	Spring - ACCELERATOR PEDAL	Spring - ACCELERATOR PEDAL
4	17814-SD4-770	Spring - ACCELERATOR PEDAL	Spring - ACCELERATOR PEDAL
5	17822-SD4-010	Washer - ACCELERATOR ARM	Washer - ACCELERATOR ARM
6	17855-SD4-010	Bush - WIRE END (BLACK)	Bush - WIRE END (BLACK)
8	17910-SD4-673	Wire - THROTTLE	Wire - THROTTLE
10	17936-SD4-003	Clip - THROTTLE WIRE	Clip - THROTTLE WIRE
11	24360-PL5-013	Cable comp - THROTTLE (AT)	Cable comp - THROTTLE (AT)
12	90551-SD4-010	Washer - PLAIN, 13MM	Washer - PLAIN, 13MM
13	90651-SA6-671	Clip - WIRE	Clip - WIRE

Accumulator (A.L.B.) 2 / 25

#	OEM	KA3	KA4
1	46462-SE0-000	Bolt - OIL	Bolt - OIL
2	46472-568-000	Packing - OIL BOLT	Packing - OIL BOLT

Air cleaner 25 / 25

#	OEM	KA3	KA4
1	17210-PH7-000	Cover comp. - AIR CLEANER	Cover comp. - AIR CLEANER
2	17211-PH7-020	Stay - AIR CLEANER	Stay - AIR CLEANER
3	17212-PH7-000	Rubber a - AIR CLEANER MOUNTING	Rubber a - AIR CLEANER MOUNTING
4	17213-PH7-020	Rubber b - AIR CLEANER CASE MOUNTING	Rubber b - AIR CLEANER CASE MOUNTING
5	17214-PH7-000	Rubber c - AIR CLEANER CASE MOUNTING	Rubber c - AIR CLEANER CASE MOUNTING
6	17216-PH7-000	Collar - AIR CLEANER	Collar - AIR CLEANER
7	17220-PH7-751	Element comp - AIR CLEANER (TOYO)	Element comp - AIR CLEANER (TOYO)
8	17221-PH7-000	Rubber - AIR CLEANER COVER	Rubber - AIR CLEANER COVER
9	17222-PH7-000	Plate - ELEMENT SETTING	Plate - ELEMENT SETTING
10	17224-PL2-010	Tube comp - AIR FLOW	Tube comp - AIR FLOW
11	17225-PH7-300	Joint - AIR FLOW TUBE	Joint - AIR FLOW TUBE
12	17241-PL2-010	Case comp. - AIR CLEANER	Case comp. - AIR CLEANER
13	17242-PL2-300	Tube a - AIR INTAKE	Tube a - AIR INTAKE
14	17244-PH7-320	Tube b - AIR INTAKE	Tube b - AIR INTAKE
15	17245-PL2-000	Tube c - AIR VALVE	Tube c - AIR VALVE
16	17246-PH7-310	Joint - AIR INTAKE PIPE	Joint - AIR INTAKE PIPE
17	17257-PL2-000	Stay - TUBE CLAMP (A)	Stay - TUBE CLAMP (A)
18	17313-PH7-013	Clamp a - AIR INTAKE TUBE	Clamp a - AIR INTAKE TUBE
19	17314-PH7-003	Clamp b - AIR INTAKE TUBE	Clamp b - AIR INTAKE TUBE
20	17315-PH7-003	Clip - AIR FLOW TUBE	Clip - AIR FLOW TUBE
21	17315-PP8-003	Band c - AIR FLOW TUBE	Band c - AIR FLOW TUBE
22	17363-PH7-000	Clamp - EGR CONTROL TUBE	Clamp - EGR CONTROL TUBE
23	90091-PE2-000	Bolt-washer - 5X25	Bolt-washer - 5X25
24	90010-PL2-000	Bolt-washer - 6X28	Bolt-washer - 6X28
25	91405-PH7-003	Clamp - TUBE (D15)	Clamp - TUBE (D15)

Air conditioner (COMPRESSOR) 18 / 24

#	OEM	KA3	KA4
3	38811-671-003	Circlip a - EXTERNAL	Circlip a - EXTERNAL
4	38812-671-003	Ring a - SNAP	Ring a - SNAP
5	38813-671-003	Washer a - PLATE	Washer a - PLATE
5	38814-671-003	Washer b - PLATE	Washer b - PLATE
5	38815-671-003	Washer c - PLATE	Washer c - PLATE
6	38816-689-003	Clip - LEAD WIRE	Clip - LEAD WIRE
7	38834-PD2-003	Seal assy - SHAFT	Seal assy - SHAFT
8	38836-PD2-003	Key	Key
9	38844-PD2-003	Ring - SNAP	Ring - SNAP
14	38942-PH3-003	Pulley comp - IDLE	Pulley comp - IDLE
15	38944-PH3-003	Collar - IDLE PULLEY (DENSO)	Collar - IDLE PULLEY (DENSO)
16	38945-PH3-003	Cover - BEARING	Cover - BEARING
17	38946-PH3-003	Shaft comp. - IDLE (DENSO)	Shaft comp. - IDLE (DENSO)
18	38947-PL2-000	Nut - IDLE PULLEY	Nut - IDLE PULLEY
19	90043-PH7-000	Bolt - ADJUSTING, 8X65	Bolt - ADJUSTING, 8X65
20	90053-PL2-003	Bolt - FLANGE, 10X40	Bolt - FLANGE, 10X40
21	90054-PL2-003	Bolt - FLANGE, 10X55	Bolt - FLANGE, 10X55
22	38827-PH7-003	Screw-washer - 5X8	Screw-washer - 5X8

Air conditioner (CONDENSER) 10 / 10

#	OEM	KA3	KA4
1	38611-PL2-003	Fan comp - COOLING (DENSO)	Fan comp - COOLING (DENSO)
2	38613-PH7-013	Resistor assy - DENSO	Resistor assy - DENSO
3	38615-PL2-003	Shroud comp - DENSO	Shroud comp - DENSO
4	38616-PH7-003	Motor - COOLING FAN (DENSO)	Motor - COOLING FAN (DENSO)
5	38619-PH7-003	Protector - FAN MOTOR	Protector - FAN MOTOR
6	80100-SD4-003	Condenser assy	Condenser assy
7	80107-SD4-003	Mount - CONDENSER UPPER	Mount - CONDENSER UPPER
8	80175-SD4-000	Rubber - CONDENSER MOUNTING	Rubber - CONDENSER MOUNTING
9	90042-PA6-003	Bolt-washer - 6X10 (DENSO)	Bolt-washer - 6X10 (DENSO)
10	90091-PC1-000	Bolt-washer - 6X16	Bolt-washer - 6X16

Air conditioner (HOSES/PIPES; LH) 23 / 27

#	OEM	KA3	KA4
1	38641-671-013	Valve - SAFETY	Valve - SAFETY
2	38646-SA5-003	O-ring - 8MM	O-ring - 8MM
3	38647-692-660	O-ring - 1/2"	O-ring - 1/2"
4	38648-692-660	O-ring - 5/8"	O-ring - 5/8"
5	38673-SB0-000	Clamp - SUCTION PIPE	Clamp - SUCTION PIPE
8	39798-SE0-003	Relay assy - POWER (4P) (058700-1170) (DENSO)	Relay assy - POWER (4P) (058700-1170) (DENSO)
8	80490-SM4-A01	Relay assy - POWER (DENSO)	Relay assy - POWER (DENSO)
11	80316-SD4-013	Pipe - DISCHARGE	Pipe - DISCHARGE
12	80323-SD4-A04	Pipe a - RECEIVER	Pipe a - RECEIVER
13	80325-SD4-003	Pipe a - CONDENSER	Pipe a - CONDENSER
14	80340-SD4-013	Tank assy. - RECEIVER	Tank assy. - RECEIVER
15	80350-SD4-000	Clamp - DISCHARGE HOSE	Clamp - DISCHARGE HOSE
16	80352-SD4-000	Clamp - DISCHARGE PIPE	Clamp - DISCHARGE PIPE
17	80360-SD4-003	Clamp - DISCHARGE HOSE	Clamp - DISCHARGE HOSE
18	80361-SD4-A00	Bracket - SUCTION PIPE	Bracket - SUCTION PIPE
19	80365-SD4-013	Stay - DISCHARGE PIPE	Stay - DISCHARGE PIPE
20	80370-SD4-000	Clamp - RECEIVER PIPE	Clamp - RECEIVER PIPE
21	80380-SE0-000	Grommet - SUCTION PIPE	Grommet - SUCTION PIPE
22	80381-SE0-000	Grommet - LIQUID PIPE	Grommet - LIQUID PIPE
23	80440-SD4-023	Switch - PRESSURE	Switch - PRESSURE
24	90141-SD4-000	Screw - TAPPING, 6X16	Screw - TAPPING, 6X16
25	91619-SA5-000	Grommet - SCREW, 6MM	Grommet - SCREW, 6MM
26	91640-SD4-003	Cap - VALVE	Cap - VALVE

Air conditioner (SENSOR; LH) 1 / 12

#	OEM	KA3	KA4
2	39397-SA5-003	Bulb - NEO WEDGE (14V 100MA)	Bulb - NEO WEDGE (14V 100MA)

Air conditioner (UNIT; LH) 16 / 19

#	OEM	KA3	KA4
1	39246-671-003	Clamp - CASE HOLD	Clamp - CASE HOLD
3	80201-SD4-A01	Case - UPPER	Case - UPPER
4	80202-SD4-A02	Case - LOWER	Case - LOWER
5	80205-SD4-003	Insulator - PIPING	Insulator - PIPING
6	80206-SD4-003	Holder	Holder
7	80207-SD4-003	Holder - PIPING	Holder - PIPING
8	80208-SD4-003	Seal a	Seal a
9	80209-SD4-003	Seal b	Seal b
10	80210-SD4-A02	Evaporator assy.	Evaporator assy.
11	80216-SD4-003	Tube - LIQUID	Tube - LIQUID
12	80220-SD4-003	Valve - EXPANSION	Valve - EXPANSION
13	80335-SD4-A00	Hose - DRAIN	Hose - DRAIN
14	80382-SD4-000	Grommet - DRAIN HOSE	Grommet - DRAIN HOSE
17	90137-SD4-000	Bolt-washer - 6X20	Bolt-washer - 6X20
18	90155-SE0-003	Screw - TAPPING, 6X20	Screw - TAPPING, 6X20
19	91549-SE0-003	Holder - DRAIN HOSE	Holder - DRAIN HOSE

Alternator 25 / 26

#	OEM	KA3	KA4
1	31100-PH7-024	Alternator assy - CJK46) (DENSO	Alternator assy - CJK46) (DENSO
2	31101-PH7-004	Rotor assy.	Rotor assy.
3	31105-PD1-034	Holder assy. - ALTERNATOR BRUSH	Holder assy. - ALTERNATOR BRUSH
3	31105-PZ1-003	Holder assy. - BRUSH	Holder assy. - BRUSH
4	31109-PH7-004	Frame assy - DRIVE END	Frame assy - DRIVE END
5	31111-PD1-014	Bearing - RR. GENERATOR	Bearing - RR. GENERATOR
7	31116-PE0-013	Plate - RETAINER	Plate - RETAINER
8	31118-PD1-004	Bush - INSULATION	Bush - INSULATION
9	31119-PH1-004	Bush - INSULATION	Bush - INSULATION
10	31121-PH7-004	Frame - RR. END	Frame - RR. END
11	31127-PD2-014	Rectifier assy.	Rectifier assy.
12	31129-PD1-014	Spring - BRUSH (###)	Spring - BRUSH (###)
13	31135-PD2-004	Cover - RR. END (###)	Cover - RR. END (###)
14	31138-PD1-004	Cover - BEARING	Cover - BEARING
15	31141-PL2-004	Pulley - ###	Pulley - ###
16	31142-PD1-004	Nut - PULLEY LOCK	Nut - PULLEY LOCK
17	31143-PH1-004	Clip - CORD (###)	Clip - CORD (###)
18	31144-PD1-004	Brush	Brush
18	31144-P01-003	Brush	Brush
19	31145-PD1-004	Bolt - STUD, 6X68	Bolt - STUD, 6X68
20	31146-PD1-004	Screw-washer - 4X19	Screw-washer - 4X19
21	31148-PD1-004	Screw-washer - 4X25	Screw-washer - 4X25
22	31149-PD1-004	Screw-washer - 4X8 (###)	Screw-washer - 4X8 (###)
23	31150-PD6-024	Regulator assy	Regulator assy
24	90231-PD1-014	Nut-washer - 5MM	Nut-washer - 5MM

Alternator bracket 12 / 12

#	OEM	KA3	KA4
1	31110-PH7-013	Belt - ALTERNATOR (BANDO)	Belt - ALTERNATOR (BANDO)
2	31112-PL2-020	Bracket - ALTERNATOR	Bracket - ALTERNATOR
3	31113-PL2-000	Plate - ADJUSTING	Plate - ADJUSTING
4	31114-PL2-000	Bolt - TENSIONER	Bolt - TENSIONER
5	31117-PL2-000	Hanger - ENGINE	Hanger - ENGINE
6	31118-PL2-000	Plate - SUPPORT	Plate - SUPPORT
7	31125-PH7-000	Cover comp. - BELT	Cover comp. - BELT
8	31127-PH7-662	Plate - CAUTION	Plate - CAUTION
9	32113-PH7-010	Holder - WIRE HARNESS COVER	Holder - WIRE HARNESS COVER
10	90016-PA9-000	Bolt - FLANGE, 10X90	Bolt - FLANGE, 10X90
11	90043-PH7-000	Bolt - ADJUSTING, 8X65	Bolt - ADJUSTING, 8X65
12	90044-PH7-000	Bolt - ALTERNATOR SPECIAL	Bolt - ALTERNATOR SPECIAL

Antenna/speaker 2 / 19

#	OEM	KA3	KA4
25	39170-SD4-A00	Valve - RR. MOTOR ANTENNA DRAIN	Valve - RR. MOTOR ANTENNA DRAIN
27	90662-693-003	Grommet - SCREW, 4MM (BLUE)	Grommet - SCREW, 4MM (BLUE)

Atf cooler 24 / 25

#	OEM	KA3	KA4
1	25500-PG4-614	Cooler kit - ATF	Cooler kit - ATF
2	25510-PG4-613	Cooler comp - ATF	Cooler comp - ATF
3	25511-PG4-611	Hose a - OIL COOLER	Hose a - OIL COOLER
4	25512-PG4-611	Hose b - OIL COOLER	Hose b - OIL COOLER
5	25513-PG4-611	Hose c - OIL COOLER	Hose c - OIL COOLER
6	25514-PG4-612	Hose d - OIL COOLER	Hose d - OIL COOLER
7	25515-PG4-610	Band - ATF HOSE	Band - ATF HOSE
8	25516-PL5-E00	Hose e - OIL COOLER	Hose e - OIL COOLER
9	25517-PG4-610	Insulator - ATF COOLER	Insulator - ATF COOLER
10	25520-PG4-611	Guide comp. a - AIR	Guide comp. a - AIR
11	25521-PL5-E00	Guide b - AIR	Guide b - AIR
13	25540-PG4-613	Stay a - ATF COOLER	Stay a - ATF COOLER
14	25541-PG4-610	Stay b - ATF COOLER	Stay b - ATF COOLER
15	25543-PL5-E00	Stay - COUPLER	Stay - COUPLER
16	25545-PL5-E00	Protector a	Protector a
17	25546-PL5-E00	Protector b	Protector b
18	25547-PG4-610	Clamp - RECEIVER PIPE	Clamp - RECEIVER PIPE
19	25548-PG4-610	Cover - CONNECTOR	Cover - CONNECTOR
20	32175-647-920	Clip - WIRE HARNESS	Clip - WIRE HARNESS
20	30701-883-000	Clip, high tension cord (8mm)	Clip, high tension cord (8mm)
21	53735-SE0-961	Clip - POWER STEERING SUCTION TUBE	Clip - POWER STEERING SUCTION TUBE
22	90438-671-000	Washer - SPECIAL, 6MM	Washer - SPECIAL, 6MM
23	90635-671-000	Clip - OIL HOSE	Clip - OIL HOSE
24	90676-SA8-003	Band - WIRE HARNESS, 150MM (BLUE)	Band - WIRE HARNESS, 150MM (BLUE)

Auto radio 5 / 5

#	OEM	KA3	KA4
1	39100-SD4-Y01	Tuner assy - AUTO RADIO (FM/MW/SW+CASSETTE) (PIONEER)	Tuner assy - AUTO RADIO (FM/MW/SW+CASSETTE) (PIONEER)
12	39102-SA6-681	Knob - PIONEER	Knob - PIONEER
25	39110-671-661	Fuse - 3A	Fuse - 3A
27	39114-SA6-681	Knob - SWITCH (PIONEER)	Knob - SWITCH (PIONEER)
28	39116-SA6-681	Knob - FADER (PIONEER)	Knob - FADER (PIONEER)

Body structure components (1) 1 / 1

#	OEM	KA3	KA4
23	90127-SB6-000	Bolt - HOOD, 6X16	Bolt - HOOD, 6X16

Body structure components (3) 9 / 10

#	OEM	KA3	KA4
28	70494-SE0-000	Spring - FUEL LID OPENER	Spring - FUEL LID OPENER
30	74422-SE0-000	Cushion - FUEL FILLER LID	Cushion - FUEL FILLER LID
31	74559-SG0-010	Cover - FUEL PIPE	Cover - FUEL PIPE
34	90114-SE0-000	Screw - TAPPING, 5X20	Screw - TAPPING, 5X20
35	90147-634-003	Bolt - FENDER, 6X18	Bolt - FENDER, 6X18
36	90302-SG0-003	Nut - SEAL-WASHER, 6MM	Nut - SEAL-WASHER, 6MM
39	90136-SD4-003	Clip - MUDGUARD	Clip - MUDGUARD
40	90682-SB0-003	Grommet - SCREW, 5MM	Grommet - SCREW, 5MM
41	90107-SD4-J10	Bolt assy - SKIRT, 6X35	Bolt assy - SKIRT, 6X35

Brake & clutch pedal (LH) 32 / 33

#	OEM	KA3	KA4
2	36760-SE0-003	Switch assy - CLUTCH(TEC)	Switch assy - CLUTCH(TEC)
3	46504-SD4-300	Bush - PEDAL	Bush - PEDAL
4	46504-679-300	Bush - PEDAL	Bush - PEDAL
5	46505-SA5-000	Pad - PEDAL STOPPER	Pad - PEDAL STOPPER
6	46510-SG0-A00	Pedal - BRAKE	Pedal - BRAKE
7	46510-SG0-A82	Pedal - BRAKE	Pedal - BRAKE
8	46520-SD4-670	Holder - BRACKET	Holder - BRACKET
8	46520-SG0-A00	Holder - BRACKET	Holder - BRACKET
9	46530-SD4-670	Spring - PEDAL RETURN	Spring - PEDAL RETURN
10	46535-692-000	Collar - PEDAL	Collar - PEDAL
11	46536-SD4-670	Plate a	Plate a
11	46536-SG0-A00	Plate a	Plate a
12	46537-SD4-670	Plate b	Plate b
13	46538-SD4-670	Collar - BRACKET HOLDER	Collar - BRACKET HOLDER
14	46545-SA5-000	Cover, Pedal	Cover, Pedal
15	46545-SE0-980	Cover - BRAKE PEDAL	Cover - BRAKE PEDAL
16	46590-SD4-672	Bracket - BRAKE PEDAL	Bracket - BRAKE PEDAL
16	46590-SG0-A00	Bracket - BRAKE PEDAL	Bracket - BRAKE PEDAL
17	46910-SG0-A00	Pedal - CLUTCH	Pedal - CLUTCH
18	46911-SD4-003	Bush - PEDAL PIN	Bush - PEDAL PIN
19	46936-SD4-000	Collar - CLUTCH PEDAL	Collar - CLUTCH PEDAL
20	46980-SD4-930	Spring - CLUTCH ASSISTANT	Spring - CLUTCH ASSISTANT
21	46981-SD4-930	Bush a - CLUTCH ASSISTANT	Bush a - CLUTCH ASSISTANT
22	46982-SD4-930	Bush b - CLUTCH ASSISTANT	Bush b - CLUTCH ASSISTANT
23	46987-SD4-670	Collar - CLUTCH MOUNTING	Collar - CLUTCH MOUNTING
24	46988-SD4-670	Rubber - CLUTCH MOUNTING	Rubber - CLUTCH MOUNTING
25	46990-SD4-671	Bracket - CLUTCH PEDAL	Bracket - CLUTCH PEDAL
26	46991-SG0-A00	Cover - FOOTREST	Cover - FOOTREST
27	46992-SG0-A00	Pad - FOOTREST	Pad - FOOTREST
28	75891-611-000	Cover - DOOR SWITCH	Cover - DOOR SWITCH
29	90125-SD4-670	Bolt - FLANGE, 8X83	Bolt - FLANGE, 8X83
30	90325-SD4-670	Nut - SELF-LOCK, 8MM	Nut - SELF-LOCK, 8MM

Brake line 28 / 41

#	OEM	KA3	KA4
1	17712-SA0-000	Grommet - FUEL PIPE	Grommet - FUEL PIPE
3	46331-SD4-000	Pipe comp. e - R. BRAKE	Pipe comp. e - R. BRAKE
6	46361-SD4-000	Pipe comp. e - L. BRAKE	Pipe comp. e - L. BRAKE
16	46380-SB0-000	Grommet a - BRAKE PIPE (BLACK)	Grommet a - BRAKE PIPE (BLACK)
17	46382-SA0-300	Grommet a - BRAKE PIPE	Grommet a - BRAKE PIPE
18	46391-692-003	Clip s - BRAKE PIPE	Clip s - BRAKE PIPE
19	46392-SB0-010	Clip d - BRAKE PIPE (BLACK)	Clip d - BRAKE PIPE (BLACK)
20	46392-SB2-014	Clip b - BRAKE PIPE	Clip b - BRAKE PIPE
21	46392-SD4-010	Clip - BRAKE PIPE	Clip - BRAKE PIPE
22	46392-SF0-000	Clip - BRAKE PIPE	Clip - BRAKE PIPE
23	46392-692-003	Clip d - BRAKE PIPE (WHITE)	Clip d - BRAKE PIPE (WHITE)
24	46394-SB0-682	Clip b	Clip b
25	46410-SD4-903	Hose assy - R. FR. BRAKE (MEIJI)	Hose assy - R. FR. BRAKE (MEIJI)
26	46411-SD4-903	Hose assy - L. FR. BRAKE (MEIJI)	Hose assy - L. FR. BRAKE (MEIJI)
27	46428-SD4-014	Bracket - R. FR. BRAKE	Bracket - R. FR. BRAKE
28	46429-SD4-014	Bracket - L. FR. BRAKE	Bracket - L. FR. BRAKE
30	46431-SE0-935	Hose b - RR. BRAKE (MEIJI)	Hose b - RR. BRAKE (MEIJI)
30	46431-SE0-934	Hose b - RR. BRAKE (NICHIRIN)	Hose b - RR. BRAKE (NICHIRIN)
31	46435-SG0-000	Bracket - R. RR. BRAKE HOSE	Bracket - R. RR. BRAKE HOSE
32	46436-SG0-000	Bracket - L. RR. BRAKE HOSE	Bracket - L. RR. BRAKE HOSE
33	46438-SG0-010	Bracket - R. RR. BRAKE HOSE	Bracket - R. RR. BRAKE HOSE
34	46439-SG0-010	Bracket - L. RR. BRAKE HOSE	Bracket - L. RR. BRAKE HOSE
35	46462-SE0-000	Bolt - OIL	Bolt - OIL
37	46472-568-000	Packing - OIL BOLT	Packing - OIL BOLT
38	90105-SB0-003	Bolt-washer - 8X16	Bolt-washer - 8X16
40	90105-SD9-003	Bolt-washer - 8X20	Bolt-washer - 8X20
41	90651-538-000	Clip - BRAKE HOSE	Clip - BRAKE HOSE
42	90677-SB0-003	Clip - PIPE PROTECTOR	Clip - PIPE PROTECTOR

Brake master cylinder (A.L.B.) 7 / 13

#	OEM	KA3	KA4
4	57562-SF1-003	Circlip	Circlip
6	46660-SD4-013	Tank - RESERVE	Tank - RESERVE
7	46662-SD4-033	Cap comp. - RESERVE TANK	Cap comp. - RESERVE TANK
8	46666-SD4-013	Filter - BRAKE RESERVOIR	Filter - BRAKE RESERVOIR
9	46669-692-003	Seal - RESERVE TANK	Seal - RESERVE TANK
10	46671-SD4-003	O-ring - 49.7X2.4	O-ring - 49.7X2.4
11	57173-SB0-801	O-ring - CONNECTOR	O-ring - CONNECTOR

Bumper 17 / 51

#	OEM	KA3	KA4
1	60821-SE0-A00	Hook - TIE DOWN	Hook - TIE DOWN
48	90101-SE0-010	Bolt assy. b - BUMPER	Bolt assy. b - BUMPER
49	90102-SE0-010	Bolt assy. c - BUMPER	Bolt assy. c - BUMPER
55	90110-SE0-003	Bolt c - BUMPER	Bolt c - BUMPER
56	90114-SE0-000	Screw - TAPPING, 5X20	Screw - TAPPING, 5X20
59	90111-SM4-003	Bolt - BUMPER	Bolt - BUMPER
60	90190-SG0-010	Bolt assy - RR. BUMPER CORNER	Bolt assy - RR. BUMPER CORNER
61	90192-SG0-003	Bolt - BUMPER CORNER	Bolt - BUMPER CORNER
63	90302-SB3-010	Nut - SPRING, 4MM	Nut - SPRING, 4MM
64	90303-SA5-003	Nut - FR. COMBINATION LIGHT	Nut - FR. COMBINATION LIGHT
66	90321-SE1-000	Nut - CLIP (AIR SPOILER)	Nut - CLIP (AIR SPOILER)
67	90540-SA7-000	Washer - BUMPER	Washer - BUMPER
70	90673-SB2-000	Nut - CLIP, 6MM	Nut - CLIP, 6MM
71	90675-SA5-003	Nut - CLIP, 6MM	Nut - CLIP, 6MM
72	90675-SB0-003	Clip - FR. COWL	Clip - FR. COWL
72	91501-S04-003	Clip - INNER FENDER	Clip - INNER FENDER
73	90682-SB0-003	Grommet - SCREW, 5MM	Grommet - SCREW, 5MM

Camshaft/timing belt 17 / 17

#	OEM	KA3	KA4
1	14100-PL2-000	Camshaft - FR.	Camshaft - FR.
2	14200-PL2-000	Camshaft - RR.	Camshaft - RR.
3	14260-PL2-003	Pulley - FR. TIMING BELT DRIVEN	Pulley - FR. TIMING BELT DRIVEN
4	14270-PH7-003	Pulley - RR. TIMING BELT DRIVEN	Pulley - RR. TIMING BELT DRIVEN
5	14400-PH7-014	Belt - TIMING (UNITTA)	Belt - TIMING (UNITTA)
6	14510-PH7-003	Adjuster comp - TIMING BELT (KOYO)	Adjuster comp - TIMING BELT (KOYO)
6	14510-PH7-004	Adjuster comp - TIMING BELT (NIPPON SEIKO)	Adjuster comp - TIMING BELT (NIPPON SEIKO)
7	14516-PH7-000	Spring - TIMING BELT ADJUSTER	Spring - TIMING BELT ADJUSTER
8	32123-PH7-000	Clamp - TDC SENSOR WIRE HARNESS	Clamp - TDC SENSOR WIRE HARNESS
9	37840-PL2-016	Sensor assy - CYLINDER	Sensor assy - CYLINDER
10	90016-PH7-000	Bolt - TIMING BELT ADJUSTING	Bolt - TIMING BELT ADJUSTING
11	90021-PL2-000	Bolt - FLANGE, 6X20	Bolt - FLANGE, 6X20
12	90031-PH7-000	Bolt - FLANGE, 8X20	Bolt - FLANGE, 8X20
13	90401-634-000	Rubber - TIMING BELT ADJUSTER	Rubber - TIMING BELT ADJUSTER
14	90501-MB7-610	Washer - 10.3X25	Washer - 10.3X25
15	91213-PH7-004	Oil seal - 35X50X8 (ARAI)	Oil seal - 35X50X8 (ARAI)
15	91213-PL2-003	Oil seal - 35X50X8 (NOK)	Oil seal - 35X50X8 (NOK)

Change lever 30 / 30

#	OEM	KA3	KA4
1	54101-SD4-673	Lever - CHANGE	Lever - CHANGE
2	54102-SD4-013	Knob comp. - CHANGE LEVER	Knob comp. - CHANGE LEVER
3	54105-692-010	Washer - THRUST	Washer - THRUST
4	54106-SG0-A01	Holder - CHANGE BOOT	Holder - CHANGE BOOT
5	54107-SA0-010	Bush, RR. JOINT	Bush, RR. JOINT
6	54108-692-000	Boot - CHANGE LEVER	Boot - CHANGE LEVER
7	54110-SD4-003	Seat - CHANGE LEVER BALL	Seat - CHANGE LEVER BALL
8	54114-SB2-000	Collar - PIPE MOUNTING	Collar - PIPE MOUNTING
9	54114-SD4-000	Seal b - CHANGE DUST	Seal b - CHANGE DUST
10	54115-SD4-020	Seal a - CHANGE DUST	Seal a - CHANGE DUST
11	54117-SD4-000	Collar - RR. JOINT	Collar - RR. JOINT
12	54119-SD4-003	Stopper - CHANGE BALL	Stopper - CHANGE BALL
13	54146-SD4-000	Spacer - BALL SEAT	Spacer - BALL SEAT
14	54201-SD4-020	Rod comp - CHANGE	Rod comp - CHANGE
15	54225-SD4-300	Bush - JOINT A	Bush - JOINT A
16	54226-SA0-300	Bush - JOINT A OUTER	Bush - JOINT A OUTER
17	54301-SD4-030	Extension - CHANGE	Extension - CHANGE
18	54303-SA5-000	Rubber - EXTENSION END	Rubber - EXTENSION END
19	54304-689-000	Washer a - EXTENSION END	Washer a - EXTENSION END
20	54305-SA0-000	Washer b - EXTENSION END	Washer b - EXTENSION END
21	54306-SB2-000	Rubber - EXTENSION MOUNTING	Rubber - EXTENSION MOUNTING
22	54307-SE0-000	Stopper - EXTENSION MOUNTING	Stopper - EXTENSION MOUNTING
23	54318-SD4-020	Seal - CHANGE BOOT	Seal - CHANGE BOOT
24	90103-689-000	Screw - TAPPING	Screw - TAPPING
25	90114-SD4-000	Bolt-washer - 8X73	Bolt-washer - 8X73
26	90115-659-003	Nut - SELF-LOCK, 8MM (CLINCH)	Nut - SELF-LOCK, 8MM (CLINCH)
27	90681-693-000	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
28	91301-671-671	O-ring - 1.9X11	O-ring - 1.9X11
28	91303-HA0-004	O-ring, 11x1.9 (nok)	O-ring, 11x1.9 (nok)
29	91351-SD4-000	O-ring - 40X3MM	O-ring - 40X3MM

Clutch 40 / 40

#	OEM	KA3	KA4
1	22500-PL5-J00	Clutch assy. - LOW	Clutch assy. - LOW
2	22510-PL5-J00	Guide comp - LOW CLUTCH	Guide comp - LOW CLUTCH
3	22520-PF4-010	Piston comp - LOW CLUTCH	Piston comp - LOW CLUTCH
4	22530-PF4-000	Piston comp - CLUTCH	Piston comp - CLUTCH
5	22530-PL5-000	Piston comp - THIRD CLUTCH	Piston comp - THIRD CLUTCH
6	22537-PG4-013	Spring - SECOND CLUTCH DISK	Spring - SECOND CLUTCH DISK
7	22538-PG4-003	Spring - LOW CLUTCH DISK	Spring - LOW CLUTCH DISK
8	22540-PG4-000	Piston comp - SECOND CLUTCH	Piston comp - SECOND CLUTCH
9	22541-PG4-004	Spring - SECOND CLUTCH RETURN	Spring - SECOND CLUTCH RETURN
10	22542-PA9-000	Seat - CLUTCH SPRING	Seat - CLUTCH SPRING
11	22542-PC9-003	Spring - LOW CLUTCH RETURN (SANKO)	Spring - LOW CLUTCH RETURN (SANKO)
11	22542-PC9-004	Spring - LOW CLUTCH RETURN (NHK SPRING)	Spring - LOW CLUTCH RETURN (NHK SPRING)
12	22542-PG4-000	Seat - SECOND RETURN SPRING	Seat - SECOND RETURN SPRING
13	22543-PF4-000	Plate - CLUTCH (116MM)	Plate - CLUTCH (116MM)
14	22544-PF4-010	Disk - CLUTCH	Disk - CLUTCH
15	22556-PF4-000	Plate - CLUTCH END (6) (2.6MM)	Plate - CLUTCH END (6) (2.6MM)
15	22551-PF4-000	Plate - CLUTCH END (1) (2.1MM)	Plate - CLUTCH END (1) (2.1MM)
15	22558-PF4-000	Plate - CLUTCH END (8) (2.8MM)	Plate - CLUTCH END (8) (2.8MM)
15	22553-PF4-000	Plate - CLUTCH END (3) (2.3MM)	Plate - CLUTCH END (3) (2.3MM)
15	22560-PF4-000	Plate - CLUTCH END (10) (3.0MM)	Plate - CLUTCH END (10) (3.0MM)
15	22555-PF4-000	Plate - CLUTCH END (5) (2.5MM)	Plate - CLUTCH END (5) (2.5MM)
15	22557-PF4-000	Plate - CLUTCH END (7) (2.7MM)	Plate - CLUTCH END (7) (2.7MM)
15	22552-PF4-000	Plate - CLUTCH END (2) (2.2MM)	Plate - CLUTCH END (2) (2.2MM)
15	22559-PF4-000	Plate - CLUTCH END (9) (2.9MM)	Plate - CLUTCH END (9) (2.9MM)
15	22554-PF4-000	Plate - CLUTCH END (4) (2.4MM)	Plate - CLUTCH END (4) (2.4MM)
16	22563-PF4-000	Plate - CLUTCH END (13) (3.3MM)	Plate - CLUTCH END (13) (3.3MM)
16	22562-PF4-000	Plate - CLUTCH END (12) (3.2MM)	Plate - CLUTCH END (12) (3.2MM)
16	22564-PF4-000	Plate - CLUTCH END (14) (3.4MM)	Plate - CLUTCH END (14) (3.4MM)
16	22561-PF4-000	Plate - CLUTCH END (11) (3.1MM)	Plate - CLUTCH END (11) (3.1MM)
17	22600-PG4-050	Clutch assy. - SECOND	Clutch assy. - SECOND
18	22610-PG4-010	Guide comp - CLUTCH (2-4)	Guide comp - CLUTCH (2-4)
19	22650-PL5-000	Clutch assy. - THIRD	Clutch assy. - THIRD
20	22661-PL5-000	Guide - THIRD CLUTCH	Guide - THIRD CLUTCH
21	90603-PA9-000	Circlip - EXTERNAL, 40MM	Circlip - EXTERNAL, 40MM
22	90603-PG4-000	Circlip - EXTERNAL, 43MM	Circlip - EXTERNAL, 43MM
23	90605-PF4-000	Ring - SNAP, 125MM	Ring - SNAP, 125MM
24	91302-PA9-004	O-ring - 39.8X2.2 (NOK)	O-ring - 39.8X2.2 (NOK)
24	91302-PA9-003	O-ring, 39.8X2.2 (ARAI)	O-ring, 39.8X2.2 (ARAI)
25	91302-PG4-003	O-ring - 42.8X2.2 (ARAI)	O-ring - 42.8X2.2 (ARAI)
26	91303-PF4-004	O-ring - 110X2.2 (NOK)	O-ring - 110X2.2 (NOK)

Clutch housing 13 / 13

#	OEM	KA3	KA4
1	21000-PG2-A20	Case comp. - CLUTCH	Case comp. - CLUTCH
2	21101-PG2-000	Plate - NEEDLE BEARING SETTING	Plate - NEEDLE BEARING SETTING
3	21103-PG2-000	Plate c - OIL GUIDE	Plate c - OIL GUIDE
4	21120-PG2-003	Magnet - TRANSMISSION	Magnet - TRANSMISSION
5	90030-PG2-000	Bolt - SPECIAL, 6MM	Bolt - SPECIAL, 6MM
6	90705-PG2-000	Dowel pin - 14X20	Dowel pin - 14X20
7	91002-PG1-018	Bearing - BALL, 63/28C (TOYO)	Bearing - BALL, 63/28C (TOYO)
8	91103-PG2-008	Bearing - NEEDLE, 33X62X22 (TOYO)	Bearing - NEEDLE, 33X62X22 (TOYO)
8	91103-PG2-004	Bearing - NEEDLE, 33X62X22 (KOYO)	Bearing - NEEDLE, 33X62X22 (KOYO)
9	91206-PG2-005	Oil seal - 40X56X9 (NOK)	Oil seal - 40X56X9 (NOK)
10	91215-PG2-005	Oil seal - 16X27X16 (NOK)	Oil seal - 16X27X16 (NOK)
11	91216-PG1-003	Oil seal - 28X43X7 (ARAI)	Oil seal - 28X43X7 (ARAI)
11	91216-PG1-005	Oil seal - 28X43X7 (NOK)	Oil seal - 28X43X7 (NOK)

Clutch master cylinder (LH) 34 / 34

#	OEM	KA3	KA4
1	43352-567-000	Screw - BLEEDER	Screw - BLEEDER
2	43353-548-003	Cap - BLEEDER SCREW	Cap - BLEEDER SCREW
3	46164-632-000	Float	Float
4	46182-500-013	Circlip	Circlip
5	46184-611-000	Dust seal - MASTER CYLINDER	Dust seal - MASTER CYLINDER
6	46472-568-000	Packing - OIL BOLT	Packing - OIL BOLT
7	46912-SD4-000	Pin - CLUTCH PEDAL	Pin - CLUTCH PEDAL
8	46920-SD4-A01	Cylinder assy. - CLUTCH MASTER (NISSIN)	Cylinder assy. - CLUTCH MASTER (NISSIN)
9	46921-SD4-980	Plate - MASTER CYLINDER HOLE	Plate - MASTER CYLINDER HOLE
10	46922-SD4-980	Plate b - MASTER CYLINDER HOLE	Plate b - MASTER CYLINDER HOLE
11	46926-SF1-003	Piston assy.	Piston assy.
12	46928-SD4-000	Seal - CLUTCH MASTER CYLINDER	Seal - CLUTCH MASTER CYLINDER
13	46929-SD4-A00	Packing - OIL BOLT	Packing - OIL BOLT
14	46930-SD4-901	Cylinder assy. - SLAVE	Cylinder assy. - SLAVE
15	46932-SD4-901	Piston - SLAVE CYLINDER	Piston - SLAVE CYLINDER
16	46933-SD4-901	Cup a - PISTON	Cup a - PISTON
17	46934-SD4-901	Cup b - PISTON	Cup b - PISTON
18	46935-SD4-003	Spring - SLAVE CYLINDER	Spring - SLAVE CYLINDER
19	46937-SD4-003	Boot - SLAVE CYLINDER	Boot - SLAVE CYLINDER
20	46938-SD4-003	Rod - PUSH	Rod - PUSH
21	46950-SD4-023	Rod assy - PUSH	Rod assy - PUSH
22	46952-SD4-003	Joint - TUBE	Joint - TUBE
23	46953-SD4-003	Packing	Packing
24	46960-SD4-A00	Pipe assy. - CLUTCH	Pipe assy. - CLUTCH
24	46960-SD4-A01	Pipe assy.,clutch	Pipe assy.,clutch
25	46963-SD4-020	Bolt - CLUTCH OIL	Bolt - CLUTCH OIL
26	46966-SD4-670	Holder - TANK	Holder - TANK
27	46970-SG0-A01	Pipe comp - CLUTCH	Pipe comp - CLUTCH
28	46971-SD4-671	Tube - CLUTCH FLUID	Tube - CLUTCH FLUID
29	46972-SD4-003	Tank - CLUTCH FLUID	Tank - CLUTCH FLUID
30	46973-SD4-003	Cap comp. - RESERVE TANK	Cap comp. - RESERVE TANK
31	46975-SD4-003	Seal - RESERVE TANK	Seal - RESERVE TANK
32	46993-SG0-A02	Damper assy. - CLUTCH (NISSIN)	Damper assy. - CLUTCH (NISSIN)
34	91592-SG0-003	Clamp	Clamp

Clutch release 5 / 5

#	OEM	KA3	KA4
1	22810-PG2-004	Bearing - CLUTCH RELEASE (KOYO)	Bearing - CLUTCH RELEASE (KOYO)
1	22810-PG2-008	Bearing - CLUTCH RELEASE (TOYO)	Bearing - CLUTCH RELEASE (TOYO)
2	22820-PG2-A01	Fork comp - CLUTCH RELEASE	Fork comp - CLUTCH RELEASE
3	22825-PG2-010	Bolt - RELEASE FORK	Bolt - RELEASE FORK
4	22841-PG2-000	Boot - RELEASE FORK	Boot - RELEASE FORK

Clutch/flywheel 6 / 6

#	OEM	KA3	KA4
1	21350-PH7-010	Cover - CLUTCH CASE	Cover - CLUTCH CASE
2	22100-PL2-G10	Flywheel comp.	Flywheel comp.
3	22200-PL2-G10	Disk comp - FRICTION	Disk comp - FRICTION
4	22300-PL2-G10	Disk comp - PRESSURE	Disk comp - PRESSURE
5	90011-PH3-000	Bolt - FLANGE, 12MM	Bolt - FLANGE, 12MM
6	90034-689-000	Bolt - TWELVE POINT, 8MM (TOKAI TRW)	Bolt - TWELVE POINT, 8MM (TOKAI TRW)

Combination meter 11 / 11

#	OEM	KA3	KA4
2	39700-SG0-004	Clock assy - DIGITAL (NS)	Clock assy - DIGITAL (NS)
2	39700-SG0-003	Clock assy - DIGITAL (JECO)	Clock assy - DIGITAL (JECO)
3	75522-634-000	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
3	90866-SA0-000	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
4	78410-SD4-A01	Cable assy - SPEEDOMETER	Cable assy - SPEEDOMETER
7	78411-SD4-033	Cable assy - SPEEDOMETER	Cable assy - SPEEDOMETER
8	78412-SD4-A02	Cable assy - SPEEDOMETER (GR)	Cable assy - SPEEDOMETER (GR)
9	78413-SD4-023	Cable - INNER	Cable - INNER
10	90101-SA4-000	Screw - TAPPING, 4X12	Screw - TAPPING, 4X12
11	90105-SA7-000	Screw-washer - 4X16	Screw-washer - 4X16
12	90690-SB0-003	Clip - CABLE (WHITE)	Clip - CABLE (WHITE)

Combination meter (COMPONENTS) 22 / 29

#	OEM	KA3	KA4
1	35505-SA5-003	Socket assy, BULB(14V 1.4W) (NS)(BASE:BLACK)	Socket assy, BULB(14V 1.4W) (NS)(BASE:BLACK)
2	35506-SA5-003	Bulb - 14V 1.4W	Bulb - 14V 1.4W
3	37102-SE3-003	Socket assy - BULB (T-10) (NS)	Socket assy - BULB (T-10) (NS)
4	37105-SF0-003	Socket assy - BULB (14V) (BASE:BLACK)	Socket assy - BULB (14V) (BASE:BLACK)
5	37106-SA0-023	Knob - TRIP	Knob - TRIP
6	37114-671-004	Grommet - TRIP KNOB (DENSO)	Grommet - TRIP KNOB (DENSO)
7	37115-SA0-601	Packing - NS	Packing - NS
8	37237-SE3-003	Bulb - T-10) (BASE:BROWN	Bulb - T-10) (BASE:BROWN
9	78108-SD4-013	Panel comp - PRINT	Panel comp - PRINT
10	78110-SD4-Y02	Case assy.	Case assy.
11	78120-SD4-Y03	Speedometer assy	Speedometer assy
13	78130-SD4-043	Meter assy - FUEL & TEMPERATURE	Meter assy - FUEL & TEMPERATURE
13	78130-SD4-954	Meter assy - FUEL & TEMPERATURE	Meter assy - FUEL & TEMPERATURE
14	78136-SD4-003	Stay	Stay
15	78140-SD4-Y02	Amplifier assy	Amplifier assy
17	78155-SD4-003	Visor assy - METER	Visor assy - METER
18	78166-SD4-003	Illumination assy.	Illumination assy.
21	78183-SG0-A01	Socket assy - BULB (T7)	Socket assy - BULB (T7)
24	90131-SD2-003	Screw-washer - 4X12 (NS)	Screw-washer - 4X12 (NS)
25	90132-SD2-003	Screw-washer - 3X13 (NS)	Screw-washer - 3X13 (NS)
26	90132-SG0-A01	Screw-washer - 3X40	Screw-washer - 3X40
27	90133-SG0-A01	Screw - TAPPING, 4X36	Screw - TAPPING, 4X36

Console 34 / 37

#	OEM	KA3	KA4
2	35505-692-003	Bulb - 14V 1.4W	Bulb - 14V 1.4W
4	66418-SA5-000	Stopper - GLOVE BOX LID	Stopper - GLOVE BOX LID
6	77135-SG0-E01	Bracket - RADIO	Bracket - RADIO
9	77292-SG0-A00	Bracket - CENTER CONSOLE	Bracket - CENTER CONSOLE
10	77295-SG0-G10	Panel assy. - CONSOLE	Panel assy. - CONSOLE
11	77296-SG0-G10	Panel - CONSOLE	Panel - CONSOLE
12	77297-SG0-A00	Clip	Clip
13	77298-SG0-A00	Clip	Clip
15	77721-SG0-000	Protector - CIGARETTE LIGHTER	Protector - CIGARETTE LIGHTER
16	77730-SG0-013	Ashtray comp. - FR. OUTER	Ashtray comp. - FR. OUTER
17	77780-SG0-E01	Pocket assy - FR. CONSOLE	Pocket assy - FR. CONSOLE
18	77781-SG0-E00	Bracket - CASSETTE BOX ASSY.	Bracket - CASSETTE BOX ASSY.
19	77783-SG0-003	Damper - AIR	Damper - AIR
20	77785-SG0-A02	Pocket assy - CONSOLE INNER	Pocket assy - CONSOLE INNER
21	77786-SG0-A02	Panel - CONSOLE POCKET	Panel - CONSOLE POCKET
22	77787-SG0-A02	Pocket comp. - CONSOLE INNER	Pocket comp. - CONSOLE INNER
23	77795-SG0-G01	Outer - CONSOLE POCKET	Outer - CONSOLE POCKET
26	83408-SD4-000	Bracket - RR. CONSOLE	Bracket - RR. CONSOLE
28	83412-SG0-A01	Plate - BOOT SETTING	Plate - BOOT SETTING
30	83414-SG0-000	Cover - PLATE SET	Cover - PLATE SET
32	83418-SD4-000	Insulator - R. CONSOLE	Insulator - R. CONSOLE
33	83419-SD4-000	Insulator - L. CONSOLE	Insulator - L. CONSOLE
34	83420-SD4-N20	Plate	Plate
36	83437-SD4-000	Spring - ARMREST STOPPER	Spring - ARMREST STOPPER
39	90101-SA4-000	Screw - TAPPING, 4X12	Screw - TAPPING, 4X12
40	90102-SA4-000	Screw - TAPPING, 4X16	Screw - TAPPING, 4X16
41	90113-SA7-003	Clamp - CABLE, 10MM (BLACK)	Clamp - CABLE, 10MM (BLACK)
42	90144-SG0-000	Screw - TAPPING, 3X12	Screw - TAPPING, 3X12
43	90302-SB3-010	Nut - SPRING, 4MM	Nut - SPRING, 4MM
44	90302-SD4-900	Nut - SPRING, 4MM	Nut - SPRING, 4MM
45	90666-SD4-003	Clip - FITTING	Clip - FITTING
46	90681-693-000	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
50	39610-SD4-405	Knob comp. - CIGARETTE LIGHTER	Knob comp. - CIGARETTE LIGHTER
51	39620-SD4-309	Socket assy - CIGARETTE LIGHTER	Socket assy - CIGARETTE LIGHTER

Control box cover (B,F,G,S,W,X,Y) 13 / 16

#	OEM	KA3	KA4
1	32134-PH7-662	Stay - CONTROL BOX COUPLER	Stay - CONTROL BOX COUPLER
2	36017-PM3-004	Bolt - MOUNTING	Bolt - MOUNTING
3	36019-PH7-662	Cover - LOWER	Cover - LOWER
4	36020-PH7-661	Cover - UPPER	Cover - UPPER
5	36022-PL2-752	Label - CONTROL BOX	Label - CONTROL BOX
6	36023-PH7-661	Clamp - COVER	Clamp - COVER
7	36024-PL2-751	Holder - TUBE	Holder - TUBE
9	36034-PL2-661	Stay comp	Stay comp
10	36035-PL2-662	Base	Base
11	36037-PL2-751	Bracket - IGNITION TIMING ADJUSTER	Bracket - IGNITION TIMING ADJUSTER
14	36053-PM6-A01	Rubber - MOUNTING, 20MM	Rubber - MOUNTING, 20MM
15	36057-PH7-004	Screw - TAPPING, 4X25	Screw - TAPPING, 4X25
19	90041-PH2-004	Screw-washer - 5X8	Screw-washer - 5X8

Control box tubing (B,F,G,S,W,X,Y) 21 / 26

#	OEM	KA3	KA4
1	17205-PC6-000	Clamp - TUBE, 7.5X2	Clamp - TUBE, 7.5X2
2	17290-PH7-752	Valve assy. - CONTROL	Valve assy. - CONTROL
3	17361-PC6-000	Clamp - TUBE, 7.5X3	Clamp - TUBE, 7.5X3
4	36010-PA6-004	Joint - THREE WAY	Joint - THREE WAY
5	36010-PE0-004	Joint - THREE WAY	Joint - THREE WAY
6	36013-PE0-004	Holder - SOLENOID, 3.5MM	Holder - SOLENOID, 3.5MM
7	36013-PG7-661	Holder - SOLENOID, 3.5MM	Holder - SOLENOID, 3.5MM
8	36017-PG7-004	Washer - FREQUENCY SOLENOID VALVE	Washer - FREQUENCY SOLENOID VALVE
9	36032-PL2-004	Clamp assy - TUBE	Clamp assy - TUBE
10	36034-PM6-901	Plug - SEALING	Plug - SEALING
11	36036-PL2-661	Tube - CVC VALVE	Tube - CVC VALVE
12	36041-PL2-751	Cord assy	Cord assy
16	36100-PG7-004	Filter assy - AIR	Filter assy - AIR
17	36134-PL2-661	Chamber comp - VACUUM	Chamber comp - VACUUM
18	36138-PE0-004	Filter assy - SOLENOID VALVE	Filter assy - SOLENOID VALVE
19	36161-PH2-004	Valve assy. - IGNITION SOLENOID (#150-B)	Valve assy. - IGNITION SOLENOID (#150-B)
20	36166-PE7-662	Valve assy. - PURGE CUT SOLENOID	Valve assy. - PURGE CUT SOLENOID
21	36190-PL2-005	Valve assy. b - FREQUENCY SOLENOID	Valve assy. b - FREQUENCY SOLENOID
22	36194-PD2-661	Filter assy - AIR	Filter assy - AIR
25	37830-PL2-662	Sensor assy - MAP	Sensor assy - MAP
26	37860-PL2-662	Adjuster - IGNITION TIMING	Adjuster - IGNITION TIMING

Control lever/ control wire 22 / 22

#	OEM	KA3	KA4
1	24412-PL5-000	Lever - CONTROL	Lever - CONTROL
2	24414-PA9-010	Pin - CONTROL	Pin - CONTROL
3	24415-PA9-000	Roller - CONTROL LEVER	Roller - CONTROL LEVER
4	24901-PG4-020	Holder - CONTROL CABLE	Holder - CONTROL CABLE
5	25610-PL5-Z01	Gauge comp. - OIL LEVEL (ATF)	Gauge comp. - OIL LEVEL (ATF)
6	25613-PL5-000	Pipe - OIL LEVEL GAUGE (ATF)	Pipe - OIL LEVEL GAUGE (ATF)
7	25910-PL5-A00	Pipe comp - OIL HOSE (A)	Pipe comp - OIL HOSE (A)
8	25920-PL5-020	Pipe comp - OIL HOSE (B)	Pipe comp - OIL HOSE (B)
9	25950-PL5-000	Bolt comp - JOINT	Bolt comp - JOINT
10	25951-639-000	Bolt - JOINT	Bolt - JOINT
11	27494-PG4-000	Lever - THROTTLE CONTROL	Lever - THROTTLE CONTROL
12	27495-PG4-010	Spring - THROTTLE LEVER	Spring - THROTTLE LEVER
13	27496-PL5-010	Stay - THROTTLE CABLE	Stay - THROTTLE CABLE
14	27921-PL5-A00	Stay - PICK UP COUPLER	Stay - PICK UP COUPLER
15	54315-SD4-982	Wire - CONTROL	Wire - CONTROL
16	54341-SA0-980	Boot - CONTROL WIRE	Boot - CONTROL WIRE
17	90001-PA9-000	Bolt - HEX., 6MM	Bolt - HEX., 6MM
18	90010-PA9-000	Bolt - SPECIAL, 5X12	Bolt - SPECIAL, 5X12
19	90433-639-000	Washer - LOCK, 6MM	Washer - LOCK, 6MM
20	90436-PA9-000	Washer - LOCK, 5MM	Washer - LOCK, 5MM
21	90437-PG4-000	Washer - TONGUED, 6MM	Washer - TONGUED, 6MM
22	91307-425-003	O-ring - 21.5X3.2	O-ring - 21.5X3.2

Control unit (1) 15 / 20

#	OEM	KA3	KA4
1	32168-SG0-000	Bracket - FAN RELAY	Bracket - FAN RELAY
2	35150-SD2-003	Controller - ILLUMINATION	Controller - ILLUMINATION
4	37120-SD4-003	Buzzer - SPEED ALARM	Buzzer - SPEED ALARM
5	37836-PH7-003	Sensor comp - PA	Sensor comp - PA
9	38290-SD4-942	Relay assy - INTERMITTENT WIPER (RISE UP CONTROL)	Relay assy - INTERMITTENT WIPER (RISE UP CONTROL)
10	38300-SB0-013	Relay assy - TURN SIGNAL & HAZARD (MITSUBA)	Relay assy - TURN SIGNAL & HAZARD (MITSUBA)
10	38300-SB0-004	Relay assy - TURN SIGNAL & HAZARD (DENSO)	Relay assy - TURN SIGNAL & HAZARD (DENSO)
13	38380-SD4-A01	Control unit - AUTO DOOR LOCK	Control unit - AUTO DOOR LOCK
15	38600-SD4-Y03	Control unit - INTEGRATED	Control unit - INTEGRATED
16	38611-SD4-G00	Bracket - INTEGRATED UNIT	Bracket - INTEGRATED UNIT
20	39400-SD4-003	Relay assy - MAIN (PGM-FI)	Relay assy - MAIN (PGM-FI)
22	39792-SE0-003	Relay assy - POWER(4P)(DENSO) (056700-7410)	Relay assy - POWER(4P)(DENSO) (056700-7410)
23	39795-SB2-003	Relay assy - POWER (4P) (MITSUBA) (RC-2201)	Relay assy - POWER (4P) (MITSUBA) (RC-2201)
24	90101-SA4-000	Screw - TAPPING, 4X12	Screw - TAPPING, 4X12
26	90676-SA7-003	Grommet - SCREW, 5MM (BLACK)	Grommet - SCREW, 5MM (BLACK)

Control unit (2) 11 / 20

#	OEM	KA3	KA4
2	37735-PH7-023	Control unit - RADIATOR FAN	Control unit - RADIATOR FAN
3	37736-PH7-661	Stay - FR. FAN CONTROL UNIT	Stay - FR. FAN CONTROL UNIT
4	37737-PH7-662	Stay - RR. FAN CONTROL UNIT	Stay - RR. FAN CONTROL UNIT
11	37915-PH7-752	Resistor assy - K-5	Resistor assy - K-5
11	37917-PH7-752	Resistor assy - K-7	Resistor assy - K-7
11	37912-PH7-752	Resistor assy - K-2	Resistor assy - K-2
11	37914-PH7-752	Resistor assy - K-4	Resistor assy - K-4
11	37916-PH7-752	Resistor assy - K-6	Resistor assy - K-6
11	37911-PH7-752	Resistor assy - K-1	Resistor assy - K-1
11	37913-PH7-752	Resistor assy - K-3	Resistor assy - K-3
12	62316-679-003	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM

Control unit (A.L.B.) 1 / 15

#	OEM	KA3	KA4
3	39795-SB2-003	Relay assy - POWER (4P) (MITSUBA) (RC-2201)	Relay assy - POWER (4P) (MITSUBA) (RC-2201)

Countershaft 33 / 33

#	OEM	KA3	KA4
1	23220-PL5-J10	Countershaft comp.	Countershaft comp.
2	23421-PL5-J00	Gear - COUNTERSHAFT LOW	Gear - COUNTERSHAFT LOW
3	23423-PL5-J00	Clutch assy. - ONE WAY	Clutch assy. - ONE WAY
4	23427-PL5-J00	Gear - PARKING	Gear - PARKING
5	23441-PL5-610	Gear - COUNTERSHAFT SECOND	Gear - COUNTERSHAFT SECOND
6	23451-PL5-N00	Gear - COUNTERSHAFT THIRD	Gear - COUNTERSHAFT THIRD
7	23471-PL5-E10	Gear - COUNTERSHAFT FOURTH	Gear - COUNTERSHAFT FOURTH
8	23531-PL5-J01	Gear - COUNTERSHAFT REVERSE	Gear - COUNTERSHAFT REVERSE
9	23541-PF4-000	Gear - REVERSE IDLE	Gear - REVERSE IDLE
10	23542-PH0-020	Shaft - REVERSE IDLE GEAR	Shaft - REVERSE IDLE GEAR
11	23543-PH0-000	Spring a - IDLE GEAR SHAFT	Spring a - IDLE GEAR SHAFT
12	23565-PL5-Z03	Selector - REVERSE GEAR	Selector - REVERSE GEAR
13	23566-PL5-J00	Hub - SELECTOR	Hub - SELECTOR
14	90202-PL5-Z01	Nut - FLANGE, 25MM	Nut - FLANGE, 25MM
15	90411-PL5-000	Collar - DISTANCE, 38X44X28.5	Collar - DISTANCE, 38X44X28.5
16	90507-PL5-000	Collar - DISTANCE, 35MM (47.75)	Collar - DISTANCE, 35MM (47.75)
16	90502-PL5-000	Collar - DISTANCE, 35MM (47.50)	Collar - DISTANCE, 35MM (47.50)
16	90504-PL5-000	Collar - DISTANCE, 35MM (47.60)	Collar - DISTANCE, 35MM (47.60)
16	90510-PL5-000	Collar - DISTANCE, 35MM (47.90)	Collar - DISTANCE, 35MM (47.90)
16	90506-PL5-000	Collar - DISTANCE, 35MM (47.70)	Collar - DISTANCE, 35MM (47.70)
16	90501-PL5-000	Collar - DISTANCE, 35MM (47.45)	Collar - DISTANCE, 35MM (47.45)
16	90508-PL5-000	Collar - DISTANCE, 35MM (47.80)	Collar - DISTANCE, 35MM (47.80)
16	90503-PL5-000	Collar - DISTANCE, 35MM (47.55)	Collar - DISTANCE, 35MM (47.55)
16	90509-PL5-000	Collar - DISTANCE, 35MM (47.85)	Collar - DISTANCE, 35MM (47.85)
16	90505-PL5-000	Collar - DISTANCE, 35MM (47.65)	Collar - DISTANCE, 35MM (47.65)
17	90509-PL5-J00	Collar - LOW GEAR	Collar - LOW GEAR
18	91011-PG4-003	Bearing - NEEDLE, 32X38X20 (NTN)	Bearing - NEEDLE, 32X38X20 (NTN)
19	91024-PL5-J01	Bearing - NEEDLE, 33X39X14	Bearing - NEEDLE, 33X39X14
20	91025-PJ2-003	Bearing - NEEDLE, 14X18X15 (NTN)	Bearing - NEEDLE, 14X18X15 (NTN)
20	91025-639-004	Bearing - NEEDLE, 14X18X15 (KOYO)	Bearing - NEEDLE, 14X18X15 (KOYO)
21	91028-PL5-003	Bearing - THRUST NEEDLE, 44X49X24	Bearing - THRUST NEEDLE, 44X49X24
22	91031-PL5-003	Bearing - THRUST NEEDLE, 50X66X2.5	Bearing - THRUST NEEDLE, 50X66X2.5
23	91307-PL5-003	O-ring - 34.2X1.9	O-ring - 34.2X1.9

Countershaft/gear 39 / 39

#	OEM	KA3	KA4
1	23220-PG2-960	Countershaft comp.	Countershaft comp.
2	23421-PG1-000	Gear - COUNTERSHAFT LOW	Gear - COUNTERSHAFT LOW
3	23431-PG2-010	Gear - COUNTERSHAFT SECOND	Gear - COUNTERSHAFT SECOND
4	23461-PG2-950	Gear - COUNTERSHAFT FIFTH	Gear - COUNTERSHAFT FIFTH
5	23471-PG2-000	Gear - COUNTERSHAFT THIRD	Gear - COUNTERSHAFT THIRD
6	23481-PG2-000	Gear - COUNTERSHAFT FOURTH	Gear - COUNTERSHAFT FOURTH
7	23521-PG2-305	Sleeve set - SYNCHRONIZER (1-2)	Sleeve set - SYNCHRONIZER (1-2)
8	23914-PG2-000	Collar d - DISTANCE, 36X44X29 (-0.01/-0.03)	Collar d - DISTANCE, 36X44X29 (-0.01/-0.03)
8	23912-PG2-000	Collar b - DISTANCE, 36X44X29 (+0.03/+0.01)	Collar b - DISTANCE, 36X44X29 (+0.03/+0.01)
8	23915-PG2-000	Collar e - DISTANCE, 36X44X29 (-0.03/-0.05)	Collar e - DISTANCE, 36X44X29 (-0.03/-0.05)
8	23911-PG2-000	Collar a - DISTANCE, 36X44X29 (+0.05/+0.03)	Collar a - DISTANCE, 36X44X29 (+0.05/+0.03)
8	23913-PG2-000	Collar c - DISTANCE, 36X44X29 (+0.01/-0.01)	Collar c - DISTANCE, 36X44X29 (+0.01/-0.01)
9	23921-PK5-900	Washer a - 40X54X1.95	Washer a - 40X54X1.95
9	23932-PK5-900	Washer l - 40X54X2.06	Washer l - 40X54X2.06
9	23927-PK5-900	Washer g - 40X54X2.01	Washer g - 40X54X2.01
9	23925-PK5-900	Washer e - 40X54X1.99	Washer e - 40X54X1.99
9	23933-PK5-900	Washer m - 40X54X2.07	Washer m - 40X54X2.07
9	23928-PK5-900	Washer h - 40X54X2.02	Washer h - 40X54X2.02
9	23924-PK5-900	Washer d - 40X54X1.98	Washer d - 40X54X1.98
9	23934-PK5-900	Washer n - 40X54X2.08	Washer n - 40X54X2.08
9	23929-PK5-900	Washer i - 40X54X2.03	Washer i - 40X54X2.03
9	23923-PK5-900	Washer c - 40X54X1.97	Washer c - 40X54X1.97
9	23935-PK5-900	Washer o - 40X54X2.09	Washer o - 40X54X2.09
9	23930-PK5-900	Washer j - 40X54X2.04	Washer j - 40X54X2.04
9	23936-PK5-900	Washer p - 40X54X2.10	Washer p - 40X54X2.10
9	23922-PK5-900	Washer b - 40X54X1.96	Washer b - 40X54X1.96
9	23931-PK5-900	Washer k - 40X54X2.05	Washer k - 40X54X2.05
9	23926-PK5-900	Washer f - 40X54X2.00	Washer f - 40X54X2.00
10	23926-PG1-010	Washer - SPRING, 23MM	Washer - SPRING, 23MM
11	90201-PG1-000	Nut - HEX., 23MM (L)	Nut - HEX., 23MM (L)
12	90602-PG1-770	Ring - SNAP, 56MM	Ring - SNAP, 56MM
13	91003-PG2-008	Bearing - SPECIAL BALL (NTN)	Bearing - SPECIAL BALL (NTN)
14	91102-PG2-008	Bearing - NEEDLE, 25X56.4X19	Bearing - NEEDLE, 25X56.4X19
15	91105-PG1-008	Bearing - NEEDLE, 40X46X29 (NTN)	Bearing - NEEDLE, 40X46X29 (NTN)
15	91105-PK5-008	Bearing - NEEDLE, 40X46X29 (NTN)	Bearing - NEEDLE, 40X46X29 (NTN)
15	91105-PG2-004	Bearing - NEEDLE, 40X46X29 (KOYO)	Bearing - NEEDLE, 40X46X29 (KOYO)
16	91106-PG1-008	Bearing - NEEDLE, 44X50X29 (NTN)	Bearing - NEEDLE, 44X50X29 (NTN)
16	91106-PK5-008	Bearing - NEEDLE, 44X50X29 (NTN)	Bearing - NEEDLE, 44X50X29 (NTN)
16	91106-PG2-004	Bearing - NEEDLE, 44X50X29 (KOYO)	Bearing - NEEDLE, 44X50X29 (KOYO)

Crankshaft/pulley 28 / 30

Cylinder block/oil pan 32 / 32

#	OEM	KA3	KA4
1	11000-PL2-J00	Block assy - CYLINDER	Block assy - CYLINDER
2	11105-PH3-000	Cap - SEALING, 35MM	Cap - SEALING, 35MM
3	11116-PH7-000	Orifice - OIL CONTROL	Orifice - OIL CONTROL
4	11126-PK1-003	Bolt - SEALING, 22MM	Bolt - SEALING, 22MM
5	11130-PH7-010	Bridge comp - BEARING CAP	Bridge comp - BEARING CAP
6	11200-PH7-010	Pan comp - OIL	Pan comp - OIL
7	11220-PH7-010	Cover comp. - BEARING CAP	Cover comp. - BEARING CAP
8	11251-PH7-000	Packing - OIL PAN	Packing - OIL PAN
9	11301-PH7-010	Case - OIL SEAL	Case - OIL SEAL
10	11711-PL2-000	Plate comp. a - BREATHER COVER	Plate comp. a - BREATHER COVER
11	11712-PL2-000	Plate comp. b - BREATHER COVER	Plate comp. b - BREATHER COVER
12	90004-PL2-J01	Bolt - FLANGE, 11X136.5	Bolt - FLANGE, 11X136.5
13	90009-PH1-000	Bolt - DRAIN PLUG, 14MM	Bolt - DRAIN PLUG, 14MM
14	90009-PH7-003	Bolt - FLANGE, 9X86	Bolt - FLANGE, 9X86
15	90013-PH7-003	Bolt-washer - 10X56	Bolt-washer - 10X56
16	90014-PH7-003	Bolt-washer - 10X41	Bolt-washer - 10X41
17	90029-PH7-004	Bolt - PLUG, 10MM (SATO RASHI)	Bolt - PLUG, 10MM (SATO RASHI)
17	90029-PH7-003	Bolt - PLUG, 10MM (SAGA)	Bolt - PLUG, 10MM (SAGA)
18	90030-PH7-000	Bolt - BREATHING	Bolt - BREATHING
19	90040-PH7-000	Bolt - BREATHING	Bolt - BREATHING
20	90041-PA5-000	Bolt - STUD, 6X28	Bolt - STUD, 6X28
21	90481-463-000	Washer - 10.2MM	Washer - 10.2MM
22	90701-679-000	Dowel pin - 8X10	Dowel pin - 8X10
23	90715-PH7-000	Dowel pin - 13X37	Dowel pin - 13X37
24	91214-PL2-003	Oil seal	Oil seal
24	91214-PL2-004	Oil seal - 80X98X10 (ARAI)	Oil seal - 80X98X10 (ARAI)
24	91214-PNA-014	Oil seal - 80X98X10 (ARAI)	Oil seal - 80X98X10 (ARAI)
25	91301-PH3-003	O-ring - 28.7X3.5	O-ring - 28.7X3.5
26	91305-PH7-003	O-ring - 12.5X2.4	O-ring - 12.5X2.4
27	91323-PH7-004	Packing - BEARING CAP BRIDGE (NOK)	Packing - BEARING CAP BRIDGE (NOK)
27	91323-PH7-003	Packing - BEARING CAP BRIDGE (ARAI)	Packing - BEARING CAP BRIDGE (ARAI)
34	90052-PH7-000	Bolt - FLANGE, 6X22	Bolt - FLANGE, 6X22

Cylinder head (FRONT) 23 / 23

#	OEM	KA3	KA4
1	12100-PL2-750	Head assy - FR. CYLINDER	Head assy - FR. CYLINDER
2	12204-PH7-305	Guide - IN. VALVE	Guide - IN. VALVE
3	12205-PH7-305	Guide - EX. VALVE	Guide - EX. VALVE
4	12206-PH7-300	Bolt - SEALING, 16MM	Bolt - SEALING, 16MM
5	12207-PC6-300	Washer - SEALING, 16MM	Washer - SEALING, 16MM
6	12210-PD2-004	Seal a - VALVE STEM (NOK)	Seal a - VALVE STEM (NOK)
6	12210-PD2-003	Seal a - VALVE STEM (ARAI)	Seal a - VALVE STEM (ARAI)
7	12211-PH7-004	Seal b - VALVE STEM (NOK)	Seal b - VALVE STEM (NOK)
7	12211-PH7-003	Seal b - VALVE STEM (ARAI)	Seal b - VALVE STEM (ARAI)
8	12236-PH7-000	Pipe comp - CAM HOLDER	Pipe comp - CAM HOLDER
9	12251-PL2-003	Gasket - CYLINDER HEAD (ISHINO GASKET)	Gasket - CYLINDER HEAD (ISHINO GASKET)
10	12331-PH7-003	Cover - CYLINDER HEAD SIDE	Cover - CYLINDER HEAD SIDE
11	12332-PH7-003	Packing - CYLINDER HEAD SIDE COVER	Packing - CYLINDER HEAD SIDE COVER
12	90001-PH7-000	Bolt - STUD, 8X49	Bolt - STUD, 8X49
13	90002-PG6-000	Bolt - FLANGE, 6X40	Bolt - FLANGE, 6X40
14	90005-PH7-003	Bolt-washer - 11X164	Bolt-washer - 11X164
15	90008-PH7-010	Bolt - FLANGE, 8X41	Bolt - FLANGE, 8X41
16	90020-PH3-000	Bolt - STUD, 8X46	Bolt - STUD, 8X46
17	90039-PH7-010	Bolt - FLANGE, 8X63	Bolt - FLANGE, 8X63
18	90707-PH7-000	Dowel pin - 10X12	Dowel pin - 10X12
19	90719-PH7-000	Dowel pin - 13X37	Dowel pin - 13X37
20	91308-PH9-000	O-ring - 8.8X1.9	O-ring - 8.8X1.9
20	91302-GE0-000	O-ring (8.8x1.9)	O-ring (8.8x1.9)

Cylinder head (REAR) 21 / 21

#	OEM	KA3	KA4
1	12204-PH7-305	Guide - IN. VALVE	Guide - IN. VALVE
2	12205-PH7-305	Guide - EX. VALVE	Guide - EX. VALVE
3	12210-PD2-003	Seal a - VALVE STEM (ARAI)	Seal a - VALVE STEM (ARAI)
3	12210-PD2-004	Seal a - VALVE STEM (NOK)	Seal a - VALVE STEM (NOK)
4	12211-PH7-004	Seal b - VALVE STEM (NOK)	Seal b - VALVE STEM (NOK)
4	12211-PH7-003	Seal b - VALVE STEM (ARAI)	Seal b - VALVE STEM (ARAI)
5	12236-PH7-000	Pipe comp - CAM HOLDER	Pipe comp - CAM HOLDER
6	12251-PL2-003	Gasket - CYLINDER HEAD (ISHINO GASKET)	Gasket - CYLINDER HEAD (ISHINO GASKET)
7	12266-PH7-003	Plug - CYLINDER HEAD	Plug - CYLINDER HEAD
8	12300-PL2-750	Head assy - RR. CYLINDER	Head assy - RR. CYLINDER
9	12331-PH7-003	Cover - CYLINDER HEAD SIDE	Cover - CYLINDER HEAD SIDE
10	12332-PH7-003	Packing - CYLINDER HEAD SIDE COVER	Packing - CYLINDER HEAD SIDE COVER
11	90001-PH7-000	Bolt - STUD, 8X49	Bolt - STUD, 8X49
12	90005-PH7-003	Bolt-washer - 11X164	Bolt-washer - 11X164
13	90008-PH7-010	Bolt - FLANGE, 8X41	Bolt - FLANGE, 8X41
14	90020-PH3-000	Bolt - STUD, 8X46	Bolt - STUD, 8X46
15	90039-PH7-010	Bolt - FLANGE, 8X63	Bolt - FLANGE, 8X63
16	90707-PH7-000	Dowel pin - 10X12	Dowel pin - 10X12
17	90719-PH7-000	Dowel pin - 13X37	Dowel pin - 13X37
18	91308-PH9-000	O-ring - 8.8X1.9	O-ring - 8.8X1.9
18	91302-GE0-000	O-ring (8.8x1.9)	O-ring (8.8x1.9)

Cylinder head cover 15 / 15

#	OEM	KA3	KA4
1	12207-PC6-300	Washer - SEALING, 16MM	Washer - SEALING, 16MM
2	12310-PH7-000	Cover comp. - FR. CYLINDER HEAD	Cover comp. - FR. CYLINDER HEAD
3	12320-PH7-660	Cover assy. - RR. CYLINDER HEAD	Cover assy. - RR. CYLINDER HEAD
4	12341-PH7-000	Gasket - CYLINDER HEAD COVER	Gasket - CYLINDER HEAD COVER
4	12341-P0G-A00	Packing - CYLINDER HEAD COVER	Packing - CYLINDER HEAD COVER
5	12415-PH7-003	Packing - BREATHER CHAMBER COVER	Packing - BREATHER CHAMBER COVER
6	12416-PH7-000	Cover comp. - FR. BREATHER CHAMBER	Cover comp. - FR. BREATHER CHAMBER
7	15610-PC6-000	Cap assy. - OIL FILLER	Cap assy. - OIL FILLER
8	15613-PC6-000	Packing, Oil Filler	Packing, Oil Filler
9	17130-PH7-003	Valve assy. - PCV	Valve assy. - PCV
10	90019-PH7-000	Bolt - CYLINDER HEAD COVER	Bolt - CYLINDER HEAD COVER
11	90035-PH7-000	Bolt - SPECIAL, 6X32	Bolt - SPECIAL, 6X32
12	90541-PH7-000	Washer - MOUNTING RUBBER	Washer - MOUNTING RUBBER
13	90542-PH7-000	Rubber - MOUNTING	Rubber - MOUNTING
14	91301-706-000	O-ring - 12X2.5	O-ring - 12X2.5

Differential gear 59 / 61

#	OEM	KA3	KA4
2	41233-PG2-960	Gear - FINAL DRIVEN	Gear - FINAL DRIVEN
2	41233-PL5-000	Gear - FINAL DRIVEN	Gear - FINAL DRIVEN
3	41310-PG2-A10	Case comp. - DIFFERENTIAL	Case comp. - DIFFERENTIAL
3	41310-PL5-J00	Case comp. - DIFFERENTIAL	Case comp. - DIFFERENTIAL
4	41321-PG2-A10	Shaft - PINION	Shaft - PINION
6	41357-PG1-000	Washer g - DIFFERENTIAL PINION THRUST(1.0MM)	Washer g - DIFFERENTIAL PINION THRUST(1.0MM)
6	41352-PG1-000	Washer b - DIFFERENTIAL PINION THRUST(0.75MM)	Washer b - DIFFERENTIAL PINION THRUST(0.75MM)
6	41354-PG1-000	Washer d - DIFFERENTIAL PINION THRUST(0.85MM)	Washer d - DIFFERENTIAL PINION THRUST(0.85MM)
6	41356-PG1-000	Washer f - DIFFERENTIAL PINION THRUST(0.95MM)	Washer f - DIFFERENTIAL PINION THRUST(0.95MM)
6	41351-PG1-000	Washer a - DIFFERENTIAL PINION THRUST(0.7MM)	Washer a - DIFFERENTIAL PINION THRUST(0.7MM)
6	41358-PG1-000	Washer h - DIFFERENTIAL PINION THRUST(1.05MM)	Washer h - DIFFERENTIAL PINION THRUST(1.05MM)
6	41353-PG1-000	Washer c - DIFFERENTIAL PINION THRUST(0.8MM)	Washer c - DIFFERENTIAL PINION THRUST(0.8MM)
6	41355-PG1-000	Washer e - DIFFERENTIAL PINION THRUST(0.9MM)	Washer e - DIFFERENTIAL PINION THRUST(0.9MM)
7	41371-PG2-000	Washer - THRUST, 37X55X1.5	Washer - THRUST, 37X55X1.5
8	41380-PG2-A10	Shim - 75MM	Shim - 75MM
8	41388-PG4-000	Shim h - 80MM (1.25)	Shim h - 80MM (1.25)
8	41383-PG4-000	Shim c - 80MM (1.00)	Shim c - 80MM (1.00)
8	41395-PG4-000	Shim o - 80MM (2.35)	Shim o - 80MM (2.35)
8	41390-PG4-000	Shim j - 80MM (1.35)	Shim j - 80MM (1.35)
8	41385-PG4-000	Shim e - 80MM (1.10)	Shim e - 80MM (1.10)
8	41397-PG4-000	Shim q - 80MM (2.45)	Shim q - 80MM (2.45)
8	41392-PG4-000	Shim l - 80MM (2.20)	Shim l - 80MM (2.20)
8	41387-PG4-000	Shim g - 80MM (1.20)	Shim g - 80MM (1.20)
8	41382-PG4-000	Shim b - 80MM (0.95)	Shim b - 80MM (0.95)
8	41394-PG4-000	Shim n - 80MM (2.30)	Shim n - 80MM (2.30)
8	41389-PG4-000	Shim i - 80MM (1.30)	Shim i - 80MM (1.30)
8	41384-PG4-000	Shim d - 80MM (1.05)	Shim d - 80MM (1.05)
8	41396-PG4-000	Shim p - 80MM (2.40)	Shim p - 80MM (2.40)
8	41391-PG4-000	Shim k - 80MM (2.15)	Shim k - 80MM (2.15)
8	41386-PG4-000	Shim f - 80MM (1.15)	Shim f - 80MM (1.15)
8	41381-PG4-000	Shim a - 80MM (0.90)	Shim a - 80MM (0.90)
8	41393-PG4-000	Shim m - 80MM (2.25)	Shim m - 80MM (2.25)
9	41387-PG2-030	Shim g - 68MM (2.08)	Shim g - 68MM (2.08)
9	41382-PG2-030	Shim b - 68MM (1.93)	Shim b - 68MM (1.93)
9	41399-PG2-000	Shim s - 68MM (2.44)	Shim s - 68MM (2.44)
9	41394-PG2-000	Shim n - 68MM (2.29)	Shim n - 68MM (2.29)
9	41389-PG2-020	Shim i - 68MM (2.14)	Shim i - 68MM (2.14)
9	41384-PG2-030	Shim d - 68MM (1.99)	Shim d - 68MM (1.99)
9	41396-PG2-000	Shim p - 68MM (2.35)	Shim p - 68MM (2.35)
9	41391-PG2-010	Shim k - 68MM (2.20)	Shim k - 68MM (2.20)
9	41386-PG2-030	Shim f - 68MM (2.05)	Shim f - 68MM (2.05)
9	41381-PG2-020	Shim a - 68MM (1.90)	Shim a - 68MM (1.90)
9	41398-PG2-000	Shim r - 68MM (2.41)	Shim r - 68MM (2.41)
9	41393-PG2-000	Shim m - 68MM (2.26)	Shim m - 68MM (2.26)
9	41388-PG2-020	Shim h - 68MM (2.11)	Shim h - 68MM (2.11)
9	41383-PG2-030	Shim c - 68MM (1.96)	Shim c - 68MM (1.96)
9	41400-PG2-000	Shim t - 68MM (2.47)	Shim t - 68MM (2.47)
9	41395-PG2-000	Shim o - 68MM (2.32)	Shim o - 68MM (2.32)
9	41390-PG2-020	Shim j - 68MM (2.17)	Shim j - 68MM (2.17)
9	41385-PG2-030	Shim e - 68MM (2.02)	Shim e - 68MM (2.02)
9	41397-PG2-000	Shim q - 68MM (2.38)	Shim q - 68MM (2.38)
9	41392-PG2-010	Shim l - 68MM (2.23)	Shim l - 68MM (2.23)
9	90007-PL5-000	Bolt - HEX., 10MM	Bolt - HEX., 10MM
10	90017-PG2-000	Bolt - SPECIAL, 11MM	Bolt - SPECIAL, 11MM
10	91006-PG4-003	Bearing - SPECIAL TAPER, 40X80X19.75	Bearing - SPECIAL TAPER, 40X80X19.75
11	91005-PG2-008	Bearing - TAPER, 40X75X21 (NTN)	Bearing - TAPER, 40X75X21 (NTN)
11	91005-PG2-004	Bearing - TAPER, 40X75X21 (KOYO)	Bearing - TAPER, 40X75X21 (KOYO)
12	91006-PG2-004	Bearing - TAPER, 40X68X19 (KOYO)	Bearing - TAPER, 40X68X19 (KOYO)
12	91006-PG2-008	Bearing - TAPER, 40X68X19 (TOYO)	Bearing - TAPER, 40X68X19 (TOYO)

Distributor 9 / 9

#	OEM	KA3	KA4
1	30100-PL2-016	Distributor assy - TD-01T) (TEC	Distributor assy - TD-01T) (TEC
2	30101-PL2-016	Housing comp	Housing comp
3	30102-PL2-016	Cap assy.	Cap assy.
4	30103-PL2-006	Head - ROTOR	Head - ROTOR
5	30110-PH7-006	O-ring - 24.4X3.1 (TEC)	O-ring - 24.4X3.1 (TEC)
6	30110-PL2-006	O-ring - CAP	O-ring - CAP
7	30113-PG6-006	Coupling set - TEC	Coupling set - TEC
8	30135-PL2-006	Screw-washer - 5X10	Screw-washer - 5X10
9	30136-PL2-006	Stay - HIGH TENSION CORD CLAMP	Stay - HIGH TENSION CORD CLAMP

Door sash molding 1 / 26

#	OEM	KA3	KA4
20	90661-SD4-003	Clip - DRIP SEAL END	Clip - DRIP SEAL END

Driveshaft 10 / 16

#	OEM	KA3	KA4
2	44310-SD4-300	Joint comp - INBOARD	Joint comp - INBOARD
3	44310-SD4-900	Joint comp - INBOARD	Joint comp - INBOARD
4	44319-SD4-010	Set ring - 30X2.2	Set ring - 30X2.2
5	44323-SD4-901	Boot - OUTBOARD	Boot - OUTBOARD
6	44325-SD4-901	Boot - INBOARD	Boot - INBOARD
7	44327-SB0-300	Band - OUTBOARD BOOT	Band - OUTBOARD BOOT
9	44329-SC2-300	Band - SHAFT BOOT	Band - SHAFT BOOT
10	44336-SD4-300	Ring a - STOPPER	Ring a - STOPPER
11	44338-SD4-300	Circlip - 28MM	Circlip - 28MM
15	90305-SD4-003	Nut - SPINDLE (24MM)	Nut - SPINDLE (24MM)

Duct 17 / 19

#	OEM	KA3	KA4
1	62316-679-003	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
2	66871-611-000	Nut - CENTER PANEL	Nut - CENTER PANEL
3	75450-SD4-020	Outlet assy - RR. AIR	Outlet assy - RR. AIR
4	77471-SD4-A00	Duct - DRIVER SIDE DEFROSTER	Duct - DRIVER SIDE DEFROSTER
5	77472-SD4-A00	Duct - PASSENGER SIDE DEFROSTER	Duct - PASSENGER SIDE DEFROSTER
6	77476-SD4-A02	Duct - DRIVER JOINT HEATER	Duct - DRIVER JOINT HEATER
7	79145-SD4-010	Joint - RR. HEATER DUCT	Joint - RR. HEATER DUCT
8	79146-SD4-000	Clip - RR. HEATER DUCT	Clip - RR. HEATER DUCT
10	79825-SD4-A03	Duct - HEATER ASSIST	Duct - HEATER ASSIST
11	79831-SD4-A02	Outlet - HEATER DRIVER	Outlet - HEATER DRIVER
12	79832-SD4-A02	Duct - HEATER DRIVER	Duct - HEATER DRIVER
13	83331-SD4-671	Duct - RR. HEATER	Duct - RR. HEATER
14	83335-SG0-000	Duct - RR. PARTITION	Duct - RR. PARTITION
17	90102-SA4-000	Screw - TAPPING, 4X16	Screw - TAPPING, 4X16
18	90107-SA5-000	Screw - TAPPING, 4X12	Screw - TAPPING, 4X12
19	90672-SC7-003	Grommet - TAPPING SCREW, 4MM	Grommet - TAPPING SCREW, 4MM
20	90675-SG0-003	Clip - RR. DUCT	Clip - RR. DUCT

Egr valve 9 / 10

#	OEM	KA3	KA4
1	12104-PH7-003	Pipe comp - EGR	Pipe comp - EGR
2	12105-PH7-000	Gasket - EGR PIPE	Gasket - EGR PIPE
5	18710-PL2-751	Valve assy. - EGR	Valve assy. - EGR
6	18712-PH7-000	Passage - EGR	Passage - EGR
7	18713-PH7-000	Gasket - EGR PASSAGE	Gasket - EGR PASSAGE
9	18715-PB2-000	GASKET, EGR VALVE (ISHINO GASKET)	GASKET, EGR VALVE (ISHINO GASKET)
12	19506-PH7-003	Clamp comp - WATER HOSE	Clamp comp - WATER HOSE
14	90006-PH7-000	Bolt - STUD, 6X31	Bolt - STUD, 6X31
15	90050-PH7-000	Bolt-washer - 6X20	Bolt-washer - 6X20

Emblem 7 / 24

#	OEM	KA3	KA4
1	17273-PH7-750	Plate - CAUTION (FRENCH-ENGLISH)	Plate - CAUTION (FRENCH-ENGLISH)
3	19017-PL2-660	Mark - SUB FAN CAUTION	Mark - SUB FAN CAUTION
4	19043-PH7-752	Mark - RADIATOR CAUTION	Mark - RADIATOR CAUTION
5	31511-SB2-671	Mark - BATTERY CAUTION (MAINTENANCE FREE)	Mark - BATTERY CAUTION (MAINTENANCE FREE)
11	75711-SD4-050	Emblem - RR. (HONDA)	Emblem - RR. (HONDA)
26	87351-SA0-003	Clip - TUBULAR	Clip - TUBULAR
26	91512-SR3-004	Clip - TUBULAR	Clip - TUBULAR

Engine mounts 18 / 18

#	OEM	KA3	KA4
1	50800-SD4-010	Mounting assy. - FR. ENGINE	Mounting assy. - FR. ENGINE
2	50810-SD4-000	Mounting assy. - RR. ENGINE	Mounting assy. - RR. ENGINE
3	50813-SK2-000	Stopper - FR. REBOUND	Stopper - FR. REBOUND
4	50815-SD4-000	Rubber - WIND STOPPER INSULATOR (MT)	Rubber - WIND STOPPER INSULATOR (MT)
4	50815-SD4-980	Rubber - WIND STOPPER INSULATOR (AT)	Rubber - WIND STOPPER INSULATOR (AT)
6	50820-SD4-000	Bracket - WIND STOPPER	Bracket - WIND STOPPER
7	50824-SD4-010	Mounting assy. - ENGINE SIDE	Mounting assy. - ENGINE SIDE
8	50825-SK2-020	Bracket - FR. ENGINE MOUNTING (MT)	Bracket - FR. ENGINE MOUNTING (MT)
8	50825-SK2-981	Bracket - FR. ENGINE MOUNTING (AT)	Bracket - FR. ENGINE MOUNTING (AT)
9	50827-SK2-010	Bracket - RR. ENGINE MOUNTING (MT)	Bracket - RR. ENGINE MOUNTING (MT)
9	50827-SG0-981	Bracket - RR. ENGINE MOUNTING (AT)	Bracket - RR. ENGINE MOUNTING (AT)
10	50840-SD4-000	Nut - YOKE, 10MM	Nut - YOKE, 10MM
11	90116-SD4-010	Bolt - SIDE MOUNTING, 12MM	Bolt - SIDE MOUNTING, 12MM
12	90122-SD4-900	Bolt - FLANGE, 10X105	Bolt - FLANGE, 10X105
13	90175-SK2-000	Bolt - FLANGE, 10X50	Bolt - FLANGE, 10X50
14	90176-SK2-000	Bolt - FLANGE, 10X32	Bolt - FLANGE, 10X32
15	90372-SK2-000	Nut - FLANGE, 10MM	Nut - FLANGE, 10MM
16	90504-SE0-000	Washer - PLAIN, 10MM	Washer - PLAIN, 10MM

Engine wire harness 28 / 28

#	OEM	KA3	KA4
1	32110-PL2-Y00	Harness - ENGINE WIRE	Harness - ENGINE WIRE
1	32110-PL2-Y10	Harness - ENGINE WIRE	Harness - ENGINE WIRE
2	32114-PH7-000	Clamp - ENGINE WIRE HARNESS	Clamp - ENGINE WIRE HARNESS
3	32115-PH7-010	Clamp - FR. ENGINE WIRE HARNESS	Clamp - FR. ENGINE WIRE HARNESS
4	32116-PH7-010	Clamp - RR. ENGINE WIRE HARNESS	Clamp - RR. ENGINE WIRE HARNESS
5	32117-PL2-000	Clamp - ENGINE WIRE HARNESS	Clamp - ENGINE WIRE HARNESS
6	32118-PL2-000	Clamp - ENGINE WIRE HARNESS	Clamp - ENGINE WIRE HARNESS
7	32126-PH7-310	Holder - FR. WIRE HARNESS LOWER	Holder - FR. WIRE HARNESS LOWER
8	32127-PH7-310	Holder - FR. WIRE HARNESS UPPER	Holder - FR. WIRE HARNESS UPPER
9	32128-PH7-310	Holder - RR. WIRE HARNESS LOWER	Holder - RR. WIRE HARNESS LOWER
10	32129-PH7-310	Holder - RR. WIRE HARNESS UPPER	Holder - RR. WIRE HARNESS UPPER
11	32132-PH7-000	Clamp a - OIL PRESSURE WIRE HARNESS	Clamp a - OIL PRESSURE WIRE HARNESS
12	32133-PH7-000	Clamp b - OIL PRESSURE WIRE HARNESS	Clamp b - OIL PRESSURE WIRE HARNESS
13	32136-PL2-000	Clamp - ENGINE WIRE HARNESS (AIR CLEANER)	Clamp - ENGINE WIRE HARNESS (AIR CLEANER)
14	32137-PH7-000	Clamp - POWER STEERING SWITCH WIRE HARNESS	Clamp - POWER STEERING SWITCH WIRE HARNESS
15	32610-SD3-600	Cable - SUB EARTH	Cable - SUB EARTH
16	37750-PH2-014	Thermo unit - DENSO	Thermo unit - DENSO
17	37770-PH7-662	Sensor - THERMO (A-105)	Sensor - THERMO (A-105)
19	37870-PD6-003	Sensor assy - WATER TEMP	Sensor assy - WATER TEMP
20	37872-PD6-000	Cover - TW SENSOR	Cover - TW SENSOR
21	90023-PE0-000	Bolt - FLANGE, 6X10	Bolt - FLANGE, 6X10
22	90122-PH7-000	Bolt - FLANGE, 12X95	Bolt - FLANGE, 12X95
22	90122-PH7-900	Bolt - FLANGE, 12X135	Bolt - FLANGE, 12X135
23	90123-PG4-000	Bolt - FLANGE, 12X85	Bolt - FLANGE, 12X85
24	90855-SA5-300	Protector - CORD	Protector - CORD
25	91307-PH7-660	O-ring (13.5X1.4)	O-ring (13.5X1.4)
26	91506-PH7-003	Clip - WIRE HARNESS (BLACK)	Clip - WIRE HARNESS (BLACK)
31	90121-PG4-000	Bolt - FLANGE, 12X70	Bolt - FLANGE, 12X70

Exhaust manifold 11 / 11

#	OEM	KA3	KA4
1	18100-PL2-640	Manifold assy - FR. EX.	Manifold assy - FR. EX.
2	18110-PL2-640	Manifold assy - RR. EX.	Manifold assy - RR. EX.
3	18115-PH7-003	Gasket - EX. MANIFOLD	Gasket - EX. MANIFOLD
4	18120-PH7-642	Cover - FR. EX. MANIFOLD	Cover - FR. EX. MANIFOLD
5	18130-PH7-640	Cover - RR. EX. MANIFOLD	Cover - RR. EX. MANIFOLD
9	90015-PH7-000	Bolt-washer - 8X14	Bolt-washer - 8X14
9	90015-PT0-J00	Bolt-washer - 8X14	Bolt-washer - 8X14
10	90065-PC1-300	Bolt - STUD, 10X34.5	Bolt - STUD, 10X34.5
11	90212-PD2-003	Nut - SELF-LOCK, 8MM	Nut - SELF-LOCK, 8MM
11	90212-RCA-A01	Nut - SELF-LOCK, 8MM	Nut - SELF-LOCK, 8MM
12	90402-PL2-000	Washer - SPECIAL, 8.5X16.5X2.7	Washer - SPECIAL, 8.5X16.5X2.7

Exhaust pipe 14 / 18

#	OEM	KA3	KA4
5	18210-SD4-J02	Pipe a - EX.	Pipe a - EX.
6	18212-SA7-003	Gasket - EX. PIPE (ISHINO)	Gasket - EX. PIPE (ISHINO)
6	18212-SA7-004	Gasket - EX. PIPE (NIPPON LEAKLESS)	Gasket - EX. PIPE (NIPPON LEAKLESS)
7	18212-671-003	Gasket - EX. PIPE(ISHINO) (59.5MM-60.5MM)	Gasket - EX. PIPE(ISHINO) (59.5MM-60.5MM)
9	18215-671-000	Rubber - SILENCER MOUNTING (74X53X22)	Rubber - SILENCER MOUNTING (74X53X22)
14	18282-SD4-010	Bracket b - FLEXIBLE MOUNTING	Bracket b - FLEXIBLE MOUNTING
15	18303-SF1-S01	Gasket - SILENCER	Gasket - SILENCER
18	18328-SG0-000	Bracket - SILENCER MOUNTING	Bracket - SILENCER MOUNTING
19	18393-SH3-S00	Gasket - PRE-CHAMBER (52.5MM-53.5MM)	Gasket - PRE-CHAMBER (52.5MM-53.5MM)
21	74651-SG0-010	Plate - TANK HEAT BAFFLE	Plate - TANK HEAT BAFFLE
22	74655-SG0-010	Plate - SILENCER HEAT BAFFLE	Plate - SILENCER HEAT BAFFLE
23	90115-659-003	Nut - SELF-LOCK, 8MM (CLINCH)	Nut - SELF-LOCK, 8MM (CLINCH)
24	90212-SA5-003	Nut - SELF-LOCK, 10MM	Nut - SELF-LOCK, 10MM
25	90212-671-005	Nut - SELF-LOCK, 10MM	Nut - SELF-LOCK, 10MM

Floor mat 6 / 12

#	OEM	KA3	KA4
1	72849-SA5-000	Insulator b - SIDE SILL HOLD	Insulator b - SIDE SILL HOLD
2	74251-SD4-671	Insulator - DASHBOARD LOWER OUTER	Insulator - DASHBOARD LOWER OUTER
4	74615-SD4-000	Panel - FR. FLOOR SIDE RR. UPPER	Panel - FR. FLOOR SIDE RR. UPPER
10	84541-SD4-010	Insulator - SPARE TIRE	Insulator - SPARE TIRE
13	90676-SB2-003	Clip - DASHBOARD INSULATOR	Clip - DASHBOARD INSULATOR
14	91530-SD4-003	Clip - DASHBOARD INSULATOR OUTER	Clip - DASHBOARD INSULATOR OUTER

Front beam/torque rod 22 / 22

#	OEM	KA3	KA4
1	50100-SG0-010	Beam - CENTER	Beam - CENTER
2	50200-SD4-676	Beam - RR.	Beam - RR.
3	50230-SG0-010	Insulator a - SUB FRAME MOUNTING	Insulator a - SUB FRAME MOUNTING
4	50231-SE0-010	Insulator b - SUB FRAME MOUNTING	Insulator b - SUB FRAME MOUNTING
5	50232-SD4-000	Washer - SUB FRAME (A)	Washer - SUB FRAME (A)
6	50235-SG0-000	Insulator c - SUB FRAME MOUNTING	Insulator c - SUB FRAME MOUNTING
7	50236-SD4-000	Insulator d - SUB FRAME MOUNTING	Insulator d - SUB FRAME MOUNTING
8	50250-SD4-030	Beam - FR.	Beam - FR.
9	50834-SA0-010	Insulator a - TORQUE ROD	Insulator a - TORQUE ROD
10	50835-SD4-000	Rod - TORQUE	Rod - TORQUE
11	50836-SD4-000	Insulator b - TORQUE ROD	Insulator b - TORQUE ROD
11	50836-SA0-981	Insulator b - TORQUE ROD	Insulator b - TORQUE ROD
12	50837-692-010	Washer - TORQUE ROD	Washer - TORQUE ROD
13	50839-SD4-000	Nut - YOKE, 12MM	Nut - YOKE, 12MM
14	50841-SD4-000	Bracket - L. TORQUE ROD	Bracket - L. TORQUE ROD
15	50842-SD4-010	Bracket - R. TORQUE ROD	Bracket - R. TORQUE ROD
16	90121-SD4-013	Bolt - FLANGE, 12X109	Bolt - FLANGE, 12X109
17	90124-SE0-000	Bolt-washer - LOCK, 10X21	Bolt-washer - LOCK, 10X21
18	90127-SD4-000	Bolt - FLANGE, 10X60	Bolt - FLANGE, 10X60
19	90131-SA5-000	Bolt - TORQUE ROD, 12X66 (NTN)	Bolt - TORQUE ROD, 12X66 (NTN)
20	90162-SD4-000	Bolt - TORQUE ROD, 12X81	Bolt - TORQUE ROD, 12X81
21	91613-SE0-003	Grommet - SUB FRAME, 15MM	Grommet - SUB FRAME, 15MM

Front brake caliper 16 / 19

#	OEM	KA3	KA4
1	43352-692-003	Screw - BLEEDER	Screw - BLEEDER
2	43353-SA0-003	Cap - BLEEDER SCREW	Cap - BLEEDER SCREW
2	43353-SD5-003	Cap - BLEEDER SCREW	Cap - BLEEDER SCREW
6	45214-SD4-003	Boot - PISTON	Boot - PISTON
6	45214-SM4-003	Boot - PISTON	Boot - PISTON
7	45216-SG0-003	Piston	Piston
8	45217-SD4-003	Seal - PISTON	Seal - PISTON
9	45225-SD4-003	Shim a - INNER	Shim a - INNER
10	45226-SD4-013	Shim b - INNER	Shim b - INNER
11	45227-SG0-013	Spring - PAD	Spring - PAD
12	45228-SD4-003	Shim - BRAKE PAD	Shim - BRAKE PAD
14	45234-SD4-003	Boot - PIN	Boot - PIN
15	45235-SD4-023	Pin	Pin
16	45237-SD4-003	Retainer	Retainer
17	45240-SA7-003	Bolt - FLANGE, 8X22	Bolt - FLANGE, 8X22
18	90107-663-670	Bolt - CALIPER MOUNTING	Bolt - CALIPER MOUNTING

Front combination light 6 / 21

#	OEM	KA3	KA4
6	33305-SE3-J01	Tube	Tube
7	33307-SD4-013	Packing - B	Packing - B
9	33308-SG0-A01	Cover	Cover
12	34908-634-611	Bulb - 12V 21W) (ECE) (STANLEY	Bulb - 12V 21W) (ECE) (STANLEY
24	90140-SD4-013	Screw - TAPPING, 4X40	Screw - TAPPING, 4X40
25	90303-SA5-003	Nut - FR. COMBINATION LIGHT	Nut - FR. COMBINATION LIGHT

Front door lining 13 / 36

#	OEM	KA3	KA4
2	34257-SD4-000	Plate - COURTESY LIGHT	Plate - COURTESY LIGHT
3	34258-SD4-003	Lens - DAIICHI	Lens - DAIICHI
3	34258-SD4-004	Lens - IMASEN	Lens - IMASEN
4	34295-SD4-004	Bulb - 12V 5W) (IMASEN	Bulb - 12V 5W) (IMASEN
4	34295-SA5-003	Bulb - 12V 3.4W) (DAIICHI	Bulb - 12V 3.4W) (DAIICHI
5	35156-SD4-003	Bulb - NEO WEDGE (A) (14V 1.12W)	Bulb - NEO WEDGE (A) (14V 1.12W)
6	35158-SD4-003	Bulb - 14V 0.84W	Bulb - 14V 0.84W
6	35851-SP1-901	Bulb b - NEO WEDGE(14V 100MA)	Bulb b - NEO WEDGE(14V 100MA)
8	35751-SD4-000	Bracket - FR. POWER WINDOW SWITCH	Bracket - FR. POWER WINDOW SWITCH
47	90101-SA4-000	Screw - TAPPING, 4X12	Screw - TAPPING, 4X12
48	90102-SA4-000	Screw - TAPPING, 4X16	Screw - TAPPING, 4X16
54	90664-671-003	Clip - CANOE	Clip - CANOE
59	91530-SE0-003	Clip A - DOOR WEATHERSTRIP	Clip A - DOOR WEATHERSTRIP

Front door locks 8 / 33

#	OEM	KA3	KA4
11	72105-SG0-003	Striker - DOOR LOCK (BLACK)	Striker - DOOR LOCK (BLACK)
12	72106-SG0-000	Bolt - LOCK STRIKER (BLACK)	Bolt - LOCK STRIKER (BLACK)
30	72141-SD4-004	Bush - R. JOINT	Bush - R. JOINT
37	72149-SF1-003	Clip - CYLINDER ROD	Clip - CYLINDER ROD
50	72181-SD4-004	Bush - L. JOINT	Bush - L. JOINT
51	72185-SD4-013	Cylinder - L. DOOR	Cylinder - L. DOOR
55	75551-693-003	Holder - DOOR LOCK ROD	Holder - DOOR LOCK ROD
62	90662-SB2-003	Grommet - SCREW, 5MM	Grommet - SCREW, 5MM

Front door panels 4 / 7

#	OEM	KA3	KA4
15	72331-SD4-000	Stopper - DOOR	Stopper - DOOR
17	75760-SB2-003	Pin - DOOR CHECKER	Pin - DOOR CHECKER
19	75891-611-000	Cover - DOOR SWITCH	Cover - DOOR SWITCH
21	90101-SE3-003	Bolt-washer - 8X23.5	Bolt-washer - 8X23.5

Front door windows 3 / 31

#	OEM	KA3	KA4
3	72212-SH3-003	Spring - SPIRAL	Spring - SPIRAL
30	90120-SE3-003	Bolt - FLANGE, 6X12	Bolt - FLANGE, 6X12
35	90115-SG0-003	Bolt - FLANGE, 6MM	Bolt - FLANGE, 6MM

Front fenders 17 / 27

#	OEM	KA3	KA4
6	74111-SG0-010	Shield - FR. SPLASH	Shield - FR. SPLASH
7	74112-SD4-000	Cover - FR. SPLASH SHIELD	Cover - FR. SPLASH SHIELD
15	90100-SE0-010	Bolt assy. a - BUMPER	Bolt assy. a - BUMPER
16	90103-SE3-003	Bolt a - BUMPER	Bolt a - BUMPER
17	90108-SF1-000	Bolt-washer - 6X15	Bolt-washer - 6X15
18	90114-SE0-000	Screw - TAPPING, 5X20	Screw - TAPPING, 5X20
19	90119-SE0-000	Bolt - FLANGE, 6MM	Bolt - FLANGE, 6MM
21	90146-SA7-000	Bolt-washer - 6X16 (DACRO COATING)	Bolt-washer - 6X16 (DACRO COATING)
22	90540-SA7-000	Washer - BUMPER	Washer - BUMPER
23	90657-SB0-003	Clip, SPLASH SHIELD	Clip, SPLASH SHIELD
24	90673-SB2-000	Nut - CLIP, 6MM	Nut - CLIP, 6MM
25	90675-SB0-003	Clip - FR. COWL	Clip - FR. COWL
25	91501-S04-003	Clip - INNER FENDER	Clip - INNER FENDER
26	91619-SA5-000	Grommet - SCREW, 6MM	Grommet - SCREW, 6MM
27	91532-SG0-003	Clip - FAIRING	Clip - FAIRING
28	91533-SG0-000	Clip b - FAIRING	Clip b - FAIRING
29	91620-SA5-000	Plug - CONSOLE	Plug - CONSOLE

Front grille 1 / 6

#	OEM	KA3	KA4
6	90682-SB0-003	Grommet - SCREW, 5MM	Grommet - SCREW, 5MM

Front lower arm/ front stabilizer 20 / 27

#	OEM	KA3	KA4
2	51308-SG0-020	Bracket - FR. STABILIZER	Bracket - FR. STABILIZER
7	51352-SD4-003	Rod - R. FR. RADIUS	Rod - R. FR. RADIUS
9	51362-SD4-003	Rod - L. FR. RADIUS	Rod - L. FR. RADIUS
10	51380-SG0-023	Bush b assy. - FR. RADIUS ROD (RR.) (HOKUSHIN)	Bush b assy. - FR. RADIUS ROD (RR.) (HOKUSHIN)
11	51390-SG0-013	Bush a assy. - FR. RADIUS ROD (FR.) (HOKUSHIN)	Bush a assy. - FR. RADIUS ROD (FR.) (HOKUSHIN)
12	51393-SK2-000	Bush - FR. LOWER ARM	Bush - FR. LOWER ARM
13	51397-SB0-010	Adjuster - FR. RADIUS ROD	Adjuster - FR. RADIUS ROD
14	51398-SB0-000	Washer comp - FR. RADIUS ROD	Washer comp - FR. RADIUS ROD
15	51398-SG0-020	Collar - FR. RADIUS ROD	Collar - FR. RADIUS ROD
16	51810-SD4-013	Bush - SHOCK ABSORBER FORK	Bush - SHOCK ABSORBER FORK
17	51811-SD4-020	Fork - R. FR. SHOCK ABSORBER	Fork - R. FR. SHOCK ABSORBER
18	51821-SD4-020	Fork - L. FR. SHOCK ABSORBER	Fork - L. FR. SHOCK ABSORBER
19	90020-SD4-000	Bolt - SELF-LOCK, 12X87	Bolt - SELF-LOCK, 12X87
20	90117-SM4-003	Bolt - FR. SHOCK ABSORBER LOCK (10X44)	Bolt - FR. SHOCK ABSORBER LOCK (10X44)
21	90121-SB0-013	Bolt - SHOCK ABSORBER FORK (12X108)	Bolt - SHOCK ABSORBER FORK (12X108)
22	90178-SH3-004	Bolt - FR. RADIUS ROD (12X35)	Bolt - FR. RADIUS ROD (12X35)
23	90215-SB0-003	Nut - SELF-LOCK, 12MM (SATO RASHI) (CLINCH)	Nut - SELF-LOCK, 12MM (SATO RASHI) (CLINCH)
24	90361-SD4-000	Nut - SELF-LOCK, 12MM	Nut - SELF-LOCK, 12MM
25	90362-SG0-013	Nut - TRAILING ARM, 12MM	Nut - TRAILING ARM, 12MM
25	90215-SMA-003	Nut	Nut

Front seat components (1) 4 / 23

#	OEM	KA3	KA4
1	32558-SD4-A10	Harness - L. FR. SEAT WIRE	Harness - L. FR. SEAT WIRE
36	90101-SA4-000	Screw - TAPPING, 4X12	Screw - TAPPING, 4X12
37	90123-SD4-J01	Bolt-washer - 10X28	Bolt-washer - 10X28
45	90672-SA0-003	Strap - CABLE, 118MM(BLACK)	Strap - CABLE, 118MM(BLACK)

Front seat components (3) 5 / 7

#	OEM	KA3	KA4
1	77208-SA5-003	Bush - NYLON (TS TECH)	Bush - NYLON (TS TECH)
2	77209-SB0-003	Washer - NYLON	Washer - NYLON
3	77517-SA5-014	Cap - SLIDE ADJUSTER	Cap - SLIDE ADJUSTER
29	90108-SA5-003	Bolt-washer - 8X19	Bolt-washer - 8X19
30	90123-SD4-J01	Bolt-washer - 10X28	Bolt-washer - 10X28

Front shock absorber 21 / 21

#	OEM	KA3	KA4
1	51401-SD4-Y01	Spring - FR. (MITSUBISHI SEIKO)	Spring - FR. (MITSUBISHI SEIKO)
1	51401-SD4-Y02	Spring - FR. (SHOWA)	Spring - FR. (SHOWA)
2	51601-SG0-Y03	Absorber assy - R. FR. SHOCK	Absorber assy - R. FR. SHOCK
3	51602-SG0-Y02	Absorber assy - L. FR. SHOCK	Absorber assy - L. FR. SHOCK
4	51605-SD4-044	Absorber unit - R. FR. SHOCK (SHOWA)	Absorber unit - R. FR. SHOCK (SHOWA)
5	51606-SD4-024	Absorber unit - L. FR. SHOCK (SHOWA)	Absorber unit - L. FR. SHOCK (SHOWA)
6	51621-SD4-000	Washer - FR. SHOCK ABSORBER MOUNTING	Washer - FR. SHOCK ABSORBER MOUNTING
7	51631-SB0-004	Rubber - SHOCK ABSORBER MOUNTING (YAMASHITA)	Rubber - SHOCK ABSORBER MOUNTING (YAMASHITA)
7	51631-S7S-J01	RUBBER DAMPER M	RUBBER DAMPER M
8	51675-SB0-004	Base - FR. SHOCK ABSORBER MOUNTING (SHOWA)	Base - FR. SHOCK ABSORBER MOUNTING (SHOWA)
9	51676-SB0-003	Seal - FR. SHOCK ABSORBER MOUNTING (TOKICO)	Seal - FR. SHOCK ABSORBER MOUNTING (TOKICO)
10	51685-SH3-014	Plate - DUST COVER(SHOWA)	Plate - DUST COVER(SHOWA)
11	51686-SD4-004	Rubber - SHOCK ABSORBER MOUNTING	Rubber - SHOCK ABSORBER MOUNTING
12	51687-SD4-024	Cover - SLEEVE DUST	Cover - SLEEVE DUST
13	51689-SH3-004	Plate - BUMP STOP (SHOWA)	Plate - BUMP STOP (SHOWA)
14	51723-SD4-003	Rubber - BUMP STOPPER	Rubber - BUMP STOPPER
15	51728-SB0-004	Collar - SHOCK ABSORBER MOUNTING (SHOWA)	Collar - SHOCK ABSORBER MOUNTING (SHOWA)
16	51932-SB0-000	Cap - SHOCK ABSORBER MOUNT	Cap - SHOCK ABSORBER MOUNT
17	90364-SG0-004	Nut - SELF-LOCK, 10MM (SHOWA) (NYLON)	Nut - SELF-LOCK, 10MM (SHOWA) (NYLON)
18	90214-SE0-000	Nut - HEX., 10MM	Nut - HEX., 10MM
19	90414-SB0-000	Washer - SPRING, 10MM	Washer - SPRING, 10MM

Front windshield wiper (LH) 23 / 27

#	OEM	KA3	KA4
1	32167-SD4-000	Bracket - WIPER COUPLER	Bracket - WIPER COUPLER
2	38461-SB0-003	Nut - WIPER ARM CAP, 10MM	Nut - WIPER ARM CAP, 10MM
3	74217-SD4-000	Cover - PIVOT (PASSENGER SIDE)	Cover - PIVOT (PASSENGER SIDE)
5	76505-SD4-S02	Motor comp - FR. WIPER	Motor comp - FR. WIPER
6	76513-SD4-013	Seal b	Seal b
7	76514-SD4-003	Cover - WATER SEAL	Cover - WATER SEAL
8	76516-SE0-003	Rubber - BRACKETLESS MOUNTING	Rubber - BRACKETLESS MOUNTING
9	76517-SE0-003	Collar - BRACKETLESS	Collar - BRACKETLESS
10	76520-SD4-672	Link a assy. - L.	Link a assy. - L.
14	76532-SD4-003	Cover - JOINT	Cover - JOINT
16	76540-SD4-673	Rod a assy. - L.	Rod a assy. - L.
18	76550-SD4-674	Rod b assy. - L.	Rod b assy. - L.
20	76561-SD4-003	Cap - PIVOT	Cap - PIVOT
22	76600-SD4-673	Arm - WINDSHIELD WIPER (DRIVER SIDE)	Arm - WINDSHIELD WIPER (DRIVER SIDE)
23	76610-SD4-672	Arm - WINDSHIELD WIPER (PASSENGER SIDE)	Arm - WINDSHIELD WIPER (PASSENGER SIDE)
24	76620-SD4-672	Blade - WINDSHIELD WIPER (DRIVER SIDE)	Blade - WINDSHIELD WIPER (DRIVER SIDE)
25	76630-SD4-672	Blade - WINDSHIELD WIPER (PASSENGER SIDE)	Blade - WINDSHIELD WIPER (PASSENGER SIDE)
26	76622-SD4-003	Rubber - BLADE (500MM)	Rubber - BLADE (500MM)
27	76632-SD4-003	Rubber - BLADE (475MM)	Rubber - BLADE (475MM)
28	76665-SD4-000	Stopper assy - ARM	Stopper assy - ARM
29	76701-SE1-003	Rubber - MOUNTING	Rubber - MOUNTING
30	76702-SE1-003	Collar	Collar
31	90126-SE0-000	Bolt-washer - 6X25 (DACRO COATING)	Bolt-washer - 6X25 (DACRO COATING)

Fuel Pump 14 / 20

#	OEM	KA3	KA4
1	17574-SE0-000	Packing - BASE	Packing - BASE
2	17704-SD4-010	Hose a - FUEL TANK RETURN	Hose a - FUEL TANK RETURN
5	17708-SG0-S31	Pump unit - FUEL	Pump unit - FUEL
11	74661-SG0-000	Cap - FUEL MAINTENANCE HOLE	Cap - FUEL MAINTENANCE HOLE
12	90020-PD6-000	Bolt - SEALING, 12MM	Bolt - SEALING, 12MM
13	90428-PD6-003	Washer - SEALING, 12MM	Washer - SEALING, 12MM
14	90663-SB2-003	Grommet - SCREW, 6MM	Grommet - SCREW, 6MM
15	90671-SB2-000	Bolt - FR. FENDER (DACRO COATING)	Bolt - FR. FENDER (DACRO COATING)
16	90676-SA7-003	Grommet - SCREW, 5MM (BLACK)	Grommet - SCREW, 5MM (BLACK)
17	91406-SA7-931	Clamp - FUEL HOSE, 15.5MM	Clamp - FUEL HOSE, 15.5MM
17	91406-SL0-931	Clamp - FUEL HOSE, 15.5MM	Clamp - FUEL HOSE, 15.5MM
20	90164-SD4-000	Bolt-washer - 6X16	Bolt-washer - 6X16
22	90167-SD4-000	Screw - TAPPING, 5X12	Screw - TAPPING, 5X12
24	90103-SB0-010	Nut - FLANGE, 5MM	Nut - FLANGE, 5MM

Fuel injector 36 / 36

#	OEM	KA3	KA4
1	06164-PH6-000	Packing set - INJECTOR	Packing set - INJECTOR
2	16414-PH7-000	Clamp a - THROTTLE CABLE	Clamp a - THROTTLE CABLE
3	16472-PH7-003	Seal ring - INJECTOR (OTSUKA)	Seal ring - INJECTOR (OTSUKA)
3	16472-P0H-A01	Seal ring - INJECTOR (NOK)	Seal ring - INJECTOR (NOK)
4	16473-PD6-000	Cushion ring - INJECTOR (OTSUKA)	Cushion ring - INJECTOR (OTSUKA)
4	16473-P10-A01	Cushion ring - INJECTOR (NOK)	Cushion ring - INJECTOR (NOK)
5	16474-PH7-000	Insulator - INJECTOR	Insulator - INJECTOR
6	16610-PL2-000	Pipe comp - FR. FUEL	Pipe comp - FR. FUEL
7	16620-PH7-000	Pipe comp - RR. FUEL	Pipe comp - RR. FUEL
8	16638-PH7-000	Insulator - FUEL PIPE	Insulator - FUEL PIPE
9	16722-PL2-014	Hose comp. c - FUEL FEED	Hose comp. c - FUEL FEED
10	16723-PL2-004	Hose comp. d - FUEL FEED	Hose comp. d - FUEL FEED
11	16740-PH7-005	Regulator assy - PRESSURE	Regulator assy - PRESSURE
12	16741-PG7-005	O-ring - PRESSURE REGULATOR	O-ring - PRESSURE REGULATOR
13	16743-PH7-004	Rubber - FUEL HOSE MOUNTING	Rubber - FUEL HOSE MOUNTING
14	16744-PH7-004	Collar - FUEL HOSE MOUNTING	Collar - FUEL HOSE MOUNTING
15	16745-PH7-004	Washer - FUEL HOSE MOUNTING	Washer - FUEL HOSE MOUNTING
16	16746-PH7-010	Clamp a - FUEL HOSE	Clamp a - FUEL HOSE
17	16747-PL2-000	Clamp b - FUEL HOSE	Clamp b - FUEL HOSE
19	16751-PH7-661	Stay - FUEL HOSE CLAMP	Stay - FUEL HOSE CLAMP
20	16752-PH7-013	Clamp c - FUEL HOSE	Clamp c - FUEL HOSE
21	17164-PL2-000	Emblem - PULSER CONTROL VALVE (V6 2700 24-VALVE PGM-FI)	Emblem - PULSER CONTROL VALVE (V6 2700 24-VALVE PGM-FI)
22	17165-PL2-000	Cover comp. - PULSER CONTROL VALVE	Cover comp. - PULSER CONTROL VALVE
23	17167-PL2-000	Gasket a - PULSER CONTROL VALVE COVER	Gasket a - PULSER CONTROL VALVE COVER
24	17168-PL2-000	Gasket b - PULSER CONTROL VALVE COVER	Gasket b - PULSER CONTROL VALVE COVER
25	17701-SA7-930	Rubber - FUEL PIPE INSULATOR	Rubber - FUEL PIPE INSULATOR
26	17723-SD4-A30	Hose - PRESSURE REGULATOR RETURN	Hose - PRESSURE REGULATOR RETURN
27	90026-PH7-000	Bolt - STUD, 6X64	Bolt - STUD, 6X64
28	90026-PL2-000	Bolt - STUD, 6X88	Bolt - STUD, 6X88
29	90037-PL2-000	Bolt - FLANGE, 6X20	Bolt - FLANGE, 6X20
30	90201-PD1-000	Nut a - SEALING, 12MM	Nut a - SEALING, 12MM
31	90428-PD6-003	Washer - SEALING, 12MM	Washer - SEALING, 12MM
32	91301-PD6-003	O-ring - 7.3X2.2 (ARAI)	O-ring - 7.3X2.2 (ARAI)
32	91301-P2F-A01	O-ring - 7.3X2.2 (NOK)	O-ring - 7.3X2.2 (NOK)
33	91406-SA7-931	Clamp - FUEL HOSE, 15.5MM	Clamp - FUEL HOSE, 15.5MM
33	91406-SL0-931	Clamp - FUEL HOSE, 15.5MM	Clamp - FUEL HOSE, 15.5MM

Fuel pipe 29 / 31

#	OEM	KA3	KA4
1	16010-SD4-A50	Strainer set - FUEL	Strainer set - FUEL
4	16918-SD4-672	Bracket - FUEL STRAINER	Bracket - FUEL STRAINER
6	16919-SD4-030	Band - FUEL STRAINER	Band - FUEL STRAINER
8	17300-SD4-A32	Canister assy	Canister assy
9	17358-SD4-020	Bracket - CANISTER	Bracket - CANISTER
10	17556-SD4-003	Clip - FUEL PIPE	Clip - FUEL PIPE
11	17701-SD4-010	Rubber a - FUEL PIPE INSULATOR	Rubber a - FUEL PIPE INSULATOR
12	17701-SE0-000	Rubber - FUEL PIPE INSULATOR	Rubber - FUEL PIPE INSULATOR
13	17713-SD4-003	Clamp - FUEL VENT PIPE	Clamp - FUEL VENT PIPE
14	17725-SG0-000	Hose assy - PURGE	Hose assy - PURGE
16	17742-SD4-Z02	Joint - CANISTER DRAIN TUBE	Joint - CANISTER DRAIN TUBE
17	17742-SF1-A01	Joint - DRAIN TUBE	Joint - DRAIN TUBE
19	17751-SD4-010	Bracket - FUEL PIPE	Bracket - FUEL PIPE
20	17752-SD4-030	Protector - FUEL PIPE	Protector - FUEL PIPE
21	38608-692-000	Rubber - MOUNTING	Rubber - MOUNTING
22	38609-692-000	Collar - DISTANCE	Collar - DISTANCE
23	90008-PD6-010	Bolt - BANJO, 12MM	Bolt - BANJO, 12MM
23	90008-PP4-E02	Bolt - BANJO, 12MM	Bolt - BANJO, 12MM
24	90009-PE2-010	Bolt - SEALING, 6MM	Bolt - SEALING, 6MM
24	90009-RMX-010	Bolt,sealing 6mm	Bolt,sealing 6mm
25	90091-PC1-000	Bolt-washer - 6X16	Bolt-washer - 6X16
26	90146-SA7-000	Bolt-washer - 6X16 (DACRO COATING)	Bolt-washer - 6X16 (DACRO COATING)
27	90428-PD6-003	Washer - SEALING, 12MM	Washer - SEALING, 12MM
28	90430-PD6-003	Washer - SEALING, 6MM	Washer - SEALING, 6MM
29	90680-SG0-300	Clamp e - FUEL PIPE	Clamp e - FUEL PIPE
30	90685-SD4-310	Clamp a - FUEL PIPE	Clamp a - FUEL PIPE
31	90686-SD4-310	Clamp b - FUEL PIPE	Clamp b - FUEL PIPE
32	90687-SD4-310	Clamp c - FUEL PIPE	Clamp c - FUEL PIPE
33	90688-SD4-310	Clamp d - FUEL PIPE	Clamp d - FUEL PIPE

Fuel tank 20 / 27

#	OEM	KA3	KA4
1	17371-SF1-A01	Valve - TWO WAY	Valve - TWO WAY
4	17521-SG0-020	Band - R. FUEL TANK MOUNTING	Band - R. FUEL TANK MOUNTING
5	17522-SG0-020	Band - L. FUEL TANK MOUNTING	Band - L. FUEL TANK MOUNTING
6	17525-SG0-000	Bolt - FUEL TANK MOUNTING	Bolt - FUEL TANK MOUNTING
7	17570-SD4-010	Valve - FUEL CUT	Valve - FUEL CUT
8	17575-SE0-000	Packing - FUEL CUT VALVE	Packing - FUEL CUT VALVE
10	17652-SA5-000	Clip - FILLER TUBE	Clip - FILLER TUBE
11	17653-SG0-000	Tube - BREATHER	Tube - BREATHER
13	17662-SG0-000	Packing - FUEL FILLER	Packing - FUEL FILLER
14	17664-SE0-010	Bush - FILLER PIPE MOUNT	Bush - FILLER PIPE MOUNT
15	17665-SE0-010	Collar - FILLER PIPE MOUNT	Collar - FILLER PIPE MOUNT
16	17669-SM4-W00	Label - FUEL FILLER CAUTION (SUPER PREMIUM GASOLINE)	Label - FUEL FILLER CAUTION (SUPER PREMIUM GASOLINE)
17	17670-SA5-013	Cap comp. - FUEL FILLER	Cap comp. - FUEL FILLER
18	17682-679-013	Packing - FUEL FILLER CAP	Packing - FUEL FILLER CAP
21	37801-SE3-000	Packing - BASE	Packing - BASE
22	37802-SE0-000	Retainer - FUEL UNIT	Retainer - FUEL UNIT
23	74423-SD4-000	Holder - FUEL CAP	Holder - FUEL CAP
25	90163-SD4-000	Bolt - FILLER PIPE MOUNTING	Bolt - FILLER PIPE MOUNTING
26	90103-SB0-010	Nut - FLANGE, 5MM	Nut - FLANGE, 5MM
28	90700-SB0-003	Clip - AIR BLEED TUBE	Clip - AIR BLEED TUBE

Fuse box/horn 5 / 6

#	OEM	KA3	KA4
1	30700-SD4-A02	Resistor assy.	Resistor assy.
2	32166-SD4-000	Holder - COUPLER	Holder - COUPLER
3	38100-SD4-Y01	Horn assy - LOW	Horn assy - LOW
4	38150-SD4-Y01	Horn assy - HIGH (MITSUBA)	Horn assy - HIGH (MITSUBA)
8	38235-SA5-003	Puller - FUSE (SUMITOMO)	Puller - FUSE (SUMITOMO)

Gasket kit/engine assy./ transmission assy. 3 / 3

KA3 Gasket kit/engine assy./ transmission assy.

#	OEM	KA3	KA4
4	10002-PL2-761	Engine assy - BLOCK	Engine assy - BLOCK
5	10003-PL2-750	General assy. - CYLINDER HEAD	General assy. - CYLINDER HEAD
6	20021-PL5-E20	Transmission assy.	Transmission assy.

Glove box 23 / 23

#	OEM	KA3	KA4
1	34254-SD2-013	Lamp assy. - GLOVE BOX	Lamp assy. - GLOVE BOX
2	34295-SA5-003	Bulb - 12V 3.4W) (DAIICHI	Bulb - 12V 3.4W) (DAIICHI
3	35810-SD4-A01	Switch - TRUNK OPENER MAIN	Switch - TRUNK OPENER MAIN
4	62316-679-003	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
5	66405-SD4-000	Stay - GLOVE BOX HINGE	Stay - GLOVE BOX HINGE
6	66406-SA5-000	Plate - GLOVE BOX STOPPER ARM	Plate - GLOVE BOX STOPPER ARM
7	66407-SA5-000	Arm - GLOVE BOX STOPPER	Arm - GLOVE BOX STOPPER
8	66417-SA0-000	Rubber - GLOVE BOX STOPPER	Rubber - GLOVE BOX STOPPER
9	66456-SA5-000	Spring - GLOVE BOX ARM	Spring - GLOVE BOX ARM
10	77123-SD4-000	Bracket - GLOVE BOX STOPPER	Bracket - GLOVE BOX STOPPER
11	77144-SD4-A00	Frame - GLOVE BOX	Frame - GLOVE BOX
13	77506-SD4-003	Stopper - GLOVE BOX	Stopper - GLOVE BOX
18	77535-SD4-000	Label - TRUNK MAIN SWITCH	Label - TRUNK MAIN SWITCH
19	77540-SD4-010	Striker assy - GLOVE BOX	Striker assy - GLOVE BOX
21	77581-SD4-A00	Cover - GLOVE BOX UPPER	Cover - GLOVE BOX UPPER
22	77591-SD4-000	Clip - R. GLOVE BOX UPPER COVER	Clip - R. GLOVE BOX UPPER COVER
23	77592-SD4-000	Clip - L. GLOVE BOX UPPER COVER	Clip - L. GLOVE BOX UPPER COVER
24	90101-SA4-000	Screw - TAPPING, 4X12	Screw - TAPPING, 4X12
25	90101-692-000	Screw - GLOVE BOX	Screw - GLOVE BOX
26	90102-SA4-000	Screw - TAPPING, 4X16	Screw - TAPPING, 4X16
27	90107-SB2-003	Screw - TAPPING, 4X10	Screw - TAPPING, 4X10
28	90302-SA4-003	Nut - SPRING, 4MM	Nut - SPRING, 4MM
29	90616-SB0-000	Clip c - WIRE HARNESS	Clip c - WIRE HARNESS

Grommet 24 / 29

#	OEM	KA3	KA4
1	61109-623-670	Grommet - FR. FENDER	Grommet - FR. FENDER
2	70226-611-000	Plug - SETTING HOLE	Plug - SETTING HOLE
3	72206-SA5-000	Cap - FLOOR HOLE, 53MM	Cap - FLOOR HOLE, 53MM
4	74532-SD4-000	Separator - ROOF RAIL SIDE	Separator - ROOF RAIL SIDE
7	74552-SD4-000	Seal - COATING HOLE	Seal - COATING HOLE
8	82871-671-000	Grommet - DRAIN HOLE, 25MM	Grommet - DRAIN HOLE, 25MM
9	85268-SA0-000	Protection - TAILGATE, 20MM (CIRCLE)	Protection - TAILGATE, 20MM (CIRCLE)
10	90682-693-000	Plug - HOLE, 12.5MM	Plug - HOLE, 12.5MM
11	90801-SB0-000	Plug - CHANGE REINFORCEMENT	Plug - CHANGE REINFORCEMENT
12	90810-SG0-000	Grommet - TIE DOWN	Grommet - TIE DOWN
14	90852-SA5-000	Plug - HOLE, 10MM	Plug - HOLE, 10MM
15	90852-671-003	Plug - HOLE	Plug - HOLE
16	90856-SA0-000	Plug - COATING HOLE, 25MM	Plug - COATING HOLE, 25MM
18	90871-SG0-010	Valve - RR. DRAIN, 20MM	Valve - RR. DRAIN, 20MM
19	90872-SA5-000	Valve - DRAIN	Valve - DRAIN
20	91451-688-000	Grommet - TRUNK LID	Grommet - TRUNK LID
22	91602-SD4-000	Grommet - 32MM	Grommet - 32MM
23	91603-SD4-000	Grommet - WAX HOLE, 25MM	Grommet - WAX HOLE, 25MM
26	91606-SE0-000	Seal - 20X20	Seal - 20X20
28	91611-SG0-003	Plug - FLOOR HOLE, 25MM	Plug - FLOOR HOLE, 25MM
30	91613-SG0-003	Plug - FLOOR HOLE, 50MM	Plug - FLOOR HOLE, 50MM
31	91614-SA5-000	Grommet - HEATER LEVER HOLE (20MM)	Grommet - HEATER LEVER HOLE (20MM)
33	91617-SB6-000	Grommet - WASHER HOSE, 32MM	Grommet - WASHER HOSE, 32MM
34	91624-SE0-000	Seal - DASHBOARD UPPER	Seal - DASHBOARD UPPER

Half shaft 12 / 18

#	OEM	KA3	KA4
1	44500-SD4-J00	Shaft assy - HALF	Shaft assy - HALF
2	44510-SD4-900	Shaft comp. - HALF	Shaft comp. - HALF
3	44511-SD4-000	Support - HALF SHAFT BEARING	Support - HALF SHAFT BEARING
4	44517-SD4-030	Cover - HEAT	Cover - HEAT
4	44517-SD4-902	Cover - HEAT	Cover - HEAT
5	90102-SD4-000	Bolt - BEARING SUPPORT, 8X1.25	Bolt - BEARING SUPPORT, 8X1.25
7	91057-SD9-008	Bearing - HALF SHAFT (TOYO SEIKO)	Bearing - HALF SHAFT (TOYO SEIKO)
7	91057-SD2-004	Bearing - HALF SHAFT (KOYO SEIKO)	Bearing - HALF SHAFT (KOYO SEIKO)
8	91260-SD9-023	Seal - HALF SHAFT OUTER (NOK)	Seal - HALF SHAFT OUTER (NOK)
8	91260-SD9-014	Seal - HALF SHAFT OUTER (ARAI)	Seal - HALF SHAFT OUTER (ARAI)
9	91262-SE0-003	Seal - HALF SHAFT INNER (NOK)	Seal - HALF SHAFT INNER (NOK)
9	91262-SE0-004	Seal - HALF SHAFT INNER (ARAI)	Seal - HALF SHAFT INNER (ARAI)

Headlight 4 / 13

#	OEM	KA3	KA4
5	33106-SB2-731	Screw - TAPPING, 6X20	Screw - TAPPING, 6X20
7	33115-692-741	Bulb - HEADLIGHT (12V 60/55W) (PHILIPS) (HALOGEN)	Bulb - HEADLIGHT (12V 60/55W) (PHILIPS) (HALOGEN)
17	90182-SB6-000	Bolt-washer - 6X16	Bolt-washer - 6X16
18	90676-SA7-003	Grommet - SCREW, 5MM (BLACK)	Grommet - SCREW, 5MM (BLACK)

Heater blower 18 / 25

#	OEM	KA3	KA4
1	39223-692-003	Pivot - ADJUSTABLE	Pivot - ADJUSTABLE
2	39242-671-670	Fan - HEATER	Fan - HEATER
3	39246-671-003	Clamp - CASE HOLD	Clamp - CASE HOLD
4	39797-SE0-003	Relay assy - POWER (4P) (DENSO) (056700-7330)	Relay assy - POWER (4P) (DENSO) (056700-7330)
4	39797-SE0-004	Relay assy - POWER (4P) (MITSUBA) (RC-2201)	Relay assy - POWER (4P) (MITSUBA) (RC-2201)
5	79191-SD4-003	Washer - LINK	Washer - LINK
6	79197-SD4-003	Screw-washer - 3X8	Screw-washer - 3X8
8	79310-SD4-013	Motor assy.	Motor assy.
9	79315-SD4-003	Packing	Packing
10	79330-SD4-003	Transistor assy	Transistor assy
12	79351-SD4-003	Packing	Packing
14	79353-SD4-003	Lever b	Lever b
18	79356-SD4-A02	Rod b - FRESH AIR	Rod b - FRESH AIR
22	79359-SD4-A01	Plate - HARNESS	Plate - HARNESS
24	80789-SH3-003	Holder - ROD	Holder - ROD
25	90137-SD4-000	Bolt-washer - 6X20	Bolt-washer - 6X20
26	90307-SA0-003	Nut - FLANGE, 5MM	Nut - FLANGE, 5MM
27	90501-671-003	Washer - SPECIAL	Washer - SPECIAL

Heater unit 25 / 32

#	OEM	KA3	KA4
1	39246-671-003	Clamp - CASE HOLD	Clamp - CASE HOLD
3	79110-SD4-A02	Core comp - HEATER	Core comp - HEATER
4	79135-SD4-013	Select assy. - VACUUM	Select assy. - VACUUM
5	79136-SD4-003	Joint - VACUUM TUBE	Joint - VACUUM TUBE
6	79137-SD4-003	Tube a - VACUUM	Tube a - VACUUM
7	79138-SD4-003	Tube b - VACUUM	Tube b - VACUUM
9	79160-SE0-003	Holder a - PIPE	Holder a - PIPE
10	79161-SE0-003	Holder b - PIPE	Holder b - PIPE
11	79162-SE0-003	Holder - HEATER CORE	Holder - HEATER CORE
13	79171-SD4-A01	Lever - VENT	Lever - VENT
14	79172-SD4-003	Lever - ROOM	Lever - ROOM
15	79173-SD4-A02	Plate - ROOM	Plate - ROOM
16	79174-SD4-A41	Adjuster - DEFROSTER LEVER	Adjuster - DEFROSTER LEVER
17	79180-SD4-A02	Plate - AIR MODE	Plate - AIR MODE
20	79185-SD4-A01	Plate - COOL AIR	Plate - COOL AIR
21	79186-SD4-A02	Lever - COOL AIR	Lever - COOL AIR
22	79187-SD4-003	Rod - COOL AIR	Rod - COOL AIR
23	79191-SD4-003	Washer - LINK	Washer - LINK
24	79192-SD4-003	Bush - 6.7MM	Bush - 6.7MM
25	79193-SD4-003	Bush - 5MM	Bush - 5MM
26	79196-SD4-003	Bush - 7MM	Bush - 7MM
30	80789-SH3-003	Holder - ROD	Holder - ROD
31	90113-SA7-003	Clamp - CABLE, 10MM (BLACK)	Clamp - CABLE, 10MM (BLACK)
32	90137-SD4-000	Bolt-washer - 6X20	Bolt-washer - 6X20
33	90651-692-731	Nut - NYLON, 3MM	Nut - NYLON, 3MM

High tension cord/ spark plug 24 / 24

#	OEM	KA3	KA4
1	32701-PL2-900	Cord comp - RESISTANCE (NO.1)	Cord comp - RESISTANCE (NO.1)
2	32702-PL2-900	Cord comp - RESISTANCE (NO.2)	Cord comp - RESISTANCE (NO.2)
3	32703-PL2-900	Cord comp - RESISTANCE (NO.3)	Cord comp - RESISTANCE (NO.3)
4	32704-PL2-900	Cord comp - RESISTANCE (NO.4)	Cord comp - RESISTANCE (NO.4)
5	32705-PL2-900	Cord comp - RESISTANCE (NO.5)	Cord comp - RESISTANCE (NO.5)
6	32706-PL2-900	Cord comp - RESISTANCE (NO.6)	Cord comp - RESISTANCE (NO.6)
7	32720-PL2-900	Cord comp - RR. HIGH TENSION (###)	Cord comp - RR. HIGH TENSION (###)
8	32722-PL2-900	Cord comp - FR. HIGH TENSION	Cord comp - FR. HIGH TENSION
9	32723-PL2-900	Cord comp - IGNITION CENTER	Cord comp - IGNITION CENTER
10	32762-PL2-010	Clamp f - HIGH TENSION & FUEL	Clamp f - HIGH TENSION & FUEL
11	32763-PH7-000	Clamp - HIGH TENSION CORD	Clamp - HIGH TENSION CORD
12	32764-PH7-003	Clamp - HIGH TENSION CORD	Clamp - HIGH TENSION CORD
13	32765-PA6-000	Clamp - HIGH TENSION CORD	Clamp - HIGH TENSION CORD
13	32768-PJ7-000	Clamp - CENTER CORD	Clamp - CENTER CORD
14	32766-PH7-000	Clamp a - DISTRIBUTOR CORD	Clamp a - DISTRIBUTOR CORD
15	32766-PL2-003	Clamp - HIGH TENSION CENTER CORD	Clamp - HIGH TENSION CENTER CORD
16	32767-PL2-000	Protector - HIGH TENSION CORD	Protector - HIGH TENSION CORD
17	32768-PH7-000	Stay - HIGH TENSION CORD CLAMP	Stay - HIGH TENSION CORD CLAMP
18	32769-PH7-000	Clamp b - HIGH TENSION CORD	Clamp b - HIGH TENSION CORD
19	32778-PH7-000	Clamp - RR. HIGH TENSION CORD	Clamp - RR. HIGH TENSION CORD
20	32779-PH7-000	Clamp - FR. HIGH TENSION CORD	Clamp - FR. HIGH TENSION CORD
21	90003-PL2-000	Bolt-washer - 8X28	Bolt-washer - 8X28
24	32720-PL2-405	Cord comp - RR. HIGH TENSION	Cord comp - RR. HIGH TENSION
25	32722-PL2-405	Cord comp - FR. HIGH TENSION	Cord comp - FR. HIGH TENSION

Hood 26 / 33

#	OEM	KA3	KA4
4	60686-SB0-003	Clip - HOOD WIRE	Clip - HOOD WIRE
6	74120-SD4-013	Lock assy - HOOD	Lock assy - HOOD
7	74125-SD4-003	Spring - HOOD LOCK	Spring - HOOD LOCK
8	74131-SD4-003	Wire comp - HOOD	Wire comp - HOOD
12	74142-SD4-000	Rubber - R. FR. HOOD SEAL	Rubber - R. FR. HOOD SEAL
13	74143-SD4-670	Rubber - RR. HOOD SEAL	Rubber - RR. HOOD SEAL
14	74144-SD4-000	Cover - R. HOOD HINGE	Cover - R. HOOD HINGE
17	74175-SD4-000	Cushion - HOOD	Cushion - HOOD
19	74180-SD4-003	Striker assy - HOOD	Striker assy - HOOD
20	74194-SD4-000	Cover - L. HOOD HINGE	Cover - L. HOOD HINGE
23	74211-SD4-670	Garnish a - COWL TOP	Garnish a - COWL TOP
24	74212-SD4-670	Garnish b - COWL TOP (DRIVER SIDE)	Garnish b - COWL TOP (DRIVER SIDE)
25	74213-SD4-670	Garnish c - COWL TOP (PASSENGER SIDE)	Garnish c - COWL TOP (PASSENGER SIDE)
26	74216-SD4-670	Cover - WIPER PIVOT (DRIVER SIDE)	Cover - WIPER PIVOT (DRIVER SIDE)
27	90106-SD4-000	Bolt-washer - 8X16	Bolt-washer - 8X16
28	90146-SA7-000	Bolt-washer - 6X16 (DACRO COATING)	Bolt-washer - 6X16 (DACRO COATING)
31	90521-SD4-003	Clip - HOOD SEAL	Clip - HOOD SEAL
34	90664-671-003	Clip - CANOE	Clip - CANOE
35	90687-SB0-013	Clip - AIRSCOOP GRILLE (BLACK)	Clip - AIRSCOOP GRILLE (BLACK)
36	90692-SD4-003	Clip b - OPENER CABLE	Clip b - OPENER CABLE
37	90751-SE0-003	Boot - COWL TOP CLIP	Boot - COWL TOP CLIP
38	91501-SF1-003	Clip - HOOD INSULATOR	Clip - HOOD INSULATOR
38	90700-SB2-003	Clip - HOOD INSULATOR	Clip - HOOD INSULATOR
39	91558-SE3-003	Clip - HOOD WIRE	Clip - HOOD WIRE
40	91605-SD4-000	Grommet - HOOD HINGE	Grommet - HOOD HINGE
41	91610-SD4-000	Plug - HOLE, 28MM	Plug - HOLE, 28MM

Ignition coil/battery 17 / 17

#	OEM	KA3	KA4
1	30120-PL2-014	Igniter unit - MNE-311)(OKI	Igniter unit - MNE-311)(OKI
2	30500-PH6-900	Coil assy - IGNITION	Coil assy - IGNITION
3	30501-PH6-900	Bracket - IGNITION COIL	Bracket - IGNITION COIL
4	30501-PL2-000	Bracket - IGNITION COIL	Bracket - IGNITION COIL
5	30510-PH7-003	Condenser comp.	Condenser comp.
6	30520-PH6-902	Coil comp - IGNITION (TEC) (TC-09A)	Coil comp - IGNITION (TEC) (TC-09A)
7	30520-PH7-016	Coil assy - IGNITION (TC-04A) (TEC)	Coil assy - IGNITION (TC-04A) (TEC)
8	31500-SG0-E06	Battery assy - 80D26L-MF) (PANASONIC	Battery assy - 80D26L-MF) (PANASONIC
8	31500-SG0-E07	Battery assy - 80D26L-MF) (YUASA	Battery assy - 80D26L-MF) (YUASA
9	31512-SD4-020	Plate - BATTERY SETTING	Plate - BATTERY SETTING
10	31513-SA5-670	Bolt - BATTERY SETTING, 225MM	Bolt - BATTERY SETTING, 225MM
11	31513-SA7-811	Bolt - BATTERY SETTING, 215MM	Bolt - BATTERY SETTING, 215MM
12	31521-SD4-000	Box assy - BATTERY	Box assy - BATTERY
12	31521-SD4-010	Box assy - BATTERY	Box assy - BATTERY
13	31542-SE3-902	Plug - VENT (MF) (YUASA)	Plug - VENT (MF) (YUASA)
13	31542-SA5-665	Plug - VENT (MF) (PANASONIC)	Plug - VENT (MF) (PANASONIC)
16	90520-PH6-000	Collar - IGNITION COIL	Collar - IGNITION COIL

Install pipe/tubing 8 / 10

#	OEM	KA3	KA4
1	17205-PC6-000	Clamp - TUBE, 7.5X2	Clamp - TUBE, 7.5X2
2	17267-PH7-010	Clamp a - CANISTER TUBE	Clamp a - CANISTER TUBE
3	17364-PL2-000	Clamp - TWO WAY	Clamp - TWO WAY
4	17370-PD2-013	Thermovalve - 65-C	Thermovalve - 65-C
5	17440-PL2-620	Pipe assy. - INSTALL	Pipe assy. - INSTALL
7	36061-671-000	Clamp a - TUBE	Clamp a - TUBE
8	36135-PJ0-661	Valve - DASHPOT CHECK	Valve - DASHPOT CHECK
10	36517-PL2-000	Tube - AUTO CRUISE	Tube - AUTO CRUISE

Instrument panel (LH) 25 / 25

#	OEM	KA3	KA4
1	37271-SA0-000	Nut - FLOATING, 5MM	Nut - FLOATING, 5MM
2	62316-679-003	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
3	75522-611-000	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
5	77131-SD4-000	Frame - METER	Frame - METER
6	77133-SD4-000	Frame - POCKET	Frame - POCKET
7	77410-SD4-A00	Duct assy - CENTER	Duct assy - CENTER
8	77421-SD4-A00	Duct - DRIVER SIDE AIR CONDITIONER	Duct - DRIVER SIDE AIR CONDITIONER
9	77431-SD4-A00	Duct - PASSENGER SIDE AIR CONDITIONER	Duct - PASSENGER SIDE AIR CONDITIONER
10	77660-SD4-A00	Valve assy. - DRIVER VENTILATION	Valve assy. - DRIVER VENTILATION
11	77663-SD4-000	Lever - R. VENT	Lever - R. VENT
12	77664-SD4-000	Link - R. VENT	Link - R. VENT
13	77665-SD4-000	Link - L. VENT	Link - L. VENT
14	77666-SD4-000	Link b - R. VENTILATION	Link b - R. VENTILATION
15	77667-SD4-000	Bush - VENTILATION VALVE	Bush - VENTILATION VALVE
16	77668-SD4-000	Rod	Rod
17	77671-SD4-300	Clip - R. INSTRUMENT PANEL	Clip - R. INSTRUMENT PANEL
18	77671-SE3-003	Washer - LINK	Washer - LINK
19	77680-SD4-A00	Valve assy. - PASSENGER VENTILATION	Valve assy. - PASSENGER VENTILATION
20	77683-SD4-000	Lever - L. VENT	Lever - L. VENT
21	77686-SD4-000	Link b - L. VENTILATION	Link b - L. VENTILATION
22	77691-SD4-300	Clip - L. INSTRUMENT PANEL	Clip - L. INSTRUMENT PANEL
23	90101-SA4-000	Screw - TAPPING, 4X12	Screw - TAPPING, 4X12
24	90102-SA4-000	Screw - TAPPING, 4X16	Screw - TAPPING, 4X16
25	90601-SB3-003	Linkage - BUSHING	Linkage - BUSHING
26	90659-SA5-003	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM

Instrument panel lower (LH) 20 / 21

#	OEM	KA3	KA4
1	34259-SD4-013	Lamp assy. - FUSE BOX	Lamp assy. - FUSE BOX
2	34295-SA5-003	Bulb - 12V 3.4W) (DAIICHI	Bulb - 12V 3.4W) (DAIICHI
3	34504-SD4-003	Bulb assy - FOOT ILLUMINATION (14V 14W)	Bulb assy - FOOT ILLUMINATION (14V 14W)
4	35505-692-003	Bulb - 14V 1.4W	Bulb - 14V 1.4W
6	66418-SA5-000	Stopper - GLOVE BOX LID	Stopper - GLOVE BOX LID
7	66418-579-000	Stopper - GLOVE BOX LID	Stopper - GLOVE BOX LID
8	66418-688-000	Stopper - GLOVE BOX LID	Stopper - GLOVE BOX LID
10	66856-SA0-660	Lock - FUSE PANEL	Lock - FUSE PANEL
11	66857-SA0-660	Spring - FUSE PANEL	Spring - FUSE PANEL
12	66871-611-000	Nut - CENTER PANEL	Nut - CENTER PANEL
14	77215-SD4-A00	Clip - LOWER COVER	Clip - LOWER COVER
17	77392-SD4-A00	Cover - PASSENGER UNDER	Cover - PASSENGER UNDER
19	77761-SD4-000	Spring - COIN POCKET	Spring - COIN POCKET
20	77762-SD4-000	Label - FUSE	Label - FUSE
21	77763-SD4-000	Label - COIN	Label - COIN
22	77766-SD4-000	Bush - FUSE LID	Bush - FUSE LID
23	90101-SA4-000	Screw - TAPPING, 4X12	Screw - TAPPING, 4X12
24	90102-SA4-000	Screw - TAPPING, 4X16	Screw - TAPPING, 4X16
25	90601-836-000	E-ring - 4MM	E-ring - 4MM
26	90677-SD4-003	Clip - DASHBOARD INSULATOR UNDER COVER	Clip - DASHBOARD INSULATOR UNDER COVER

Instrument panel upper (LH) 15 / 16

#	OEM	KA3	KA4
1	39383-SA5-000	Clamp - CONTROL CABLE	Clamp - CONTROL CABLE
2	62316-679-003	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
4	77183-SD4-000	Bracket a - R. VISOR SWITCH	Bracket a - R. VISOR SWITCH
5	77184-SD4-000	Bracket a - L. VISOR SWITCH	Bracket a - L. VISOR SWITCH
6	77187-SD4-901	Bracket b - R. VISOR SWITCH	Bracket b - R. VISOR SWITCH
9	77206-SD4-000	Hook - METER VISOR	Hook - METER VISOR
13	77470-SD4-000	Seal assy - SIDE	Seal assy - SIDE
18	77629-SD4-000	Cable	Cable
20	90101-SA4-000	Screw - TAPPING, 4X12	Screw - TAPPING, 4X12
21	90102-SA4-000	Screw - TAPPING, 4X16	Screw - TAPPING, 4X16
22	90102-SG0-000	Screw - TAPPING (PO) 4X16	Screw - TAPPING (PO) 4X16
23	90108-SD4-000	Washer - PLAIN, 4MM	Washer - PLAIN, 4MM
24	90133-SD4-000	Screw - TRUSS	Screw - TRUSS
25	90666-SD4-003	Clip - FITTING	Clip - FITTING
26	91547-SE0-000	Washer - LINK	Washer - LINK

Instrument stays (LH) 11 / 11

#	OEM	KA3	KA4
3	62316-679-003	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
4	77121-SD4-A00	Bracket - GLOVE BOX SIDE	Bracket - GLOVE BOX SIDE
5	77142-SD4-A00	Bracket - INSTRUMENT DRIVER LOWER	Bracket - INSTRUMENT DRIVER LOWER
6	77145-SD4-010	Bracket - INSTRUMENT PANEL CENTER	Bracket - INSTRUMENT PANEL CENTER
7	77160-SD4-A02	Frame comp - INSTRUMENT CENTER	Frame comp - INSTRUMENT CENTER
8	77192-SG0-A00	Bracket - R. INSTRUMENT SIDE	Bracket - R. INSTRUMENT SIDE
9	77193-SG0-A00	Bracket - L. INSTRUMENT SIDE	Bracket - L. INSTRUMENT SIDE
10	90102-SA4-000	Screw - TAPPING, 4X16	Screw - TAPPING, 4X16
11	90128-SA7-000	Bolt-washer - 6X25	Bolt-washer - 6X25
12	90659-SA5-003	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
13	90670-SG0-003	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM

Intake manifold 12 / 12

#	OEM	KA3	KA4
1	17100-PL2-000	Manifold - INTAKE	Manifold - INTAKE
2	17105-PL2-003	Gasket - INTAKE MANIFOLD	Gasket - INTAKE MANIFOLD
3	17110-PL2-010	Chamber comp - MANIFOLD	Chamber comp - MANIFOLD
4	17120-PL2-005	Body assy - BYPASS VALVE	Body assy - BYPASS VALVE
5	17121-PL2-000	Gasket - BYPASS VALVE	Gasket - BYPASS VALVE
6	17127-PH7-660	Stay a - MASTER POWER TUBE	Stay a - MASTER POWER TUBE
7	17129-PL2-005	Diaphragm assy.	Diaphragm assy.
8	18767-PL2-000	Plate - AIR SUCTION VALVE	Plate - AIR SUCTION VALVE
9	18768-PL2-000	Packing b - AIR SUCTION VALVE	Packing b - AIR SUCTION VALVE
10	37880-PE2-013	Sensor assy - AIR TEMP	Sensor assy - AIR TEMP
11	91303-PD1-910	O-ring - 7.5X1.5	O-ring - 7.5X1.5
11	91303-PK2-005	O-ring (7.5X1.5)	O-ring (7.5X1.5)

Interior light 5 / 6

#	OEM	KA3	KA4
2	34253-671-003	Bulb - 12V 8W)(DAIICHI	Bulb - 12V 8W)(DAIICHI
2	04110-SWA-305	BULB T10X318W	BULB T10X318W
3	34260-SE3-003	Light assy - TRUNK ROOM	Light assy - TRUNK ROOM
4	34295-SA5-003	Bulb - 12V 3.4W) (DAIICHI	Bulb - 12V 3.4W) (DAIICHI
5	34295-SD4-003	Bulb - 12V 5W.K	Bulb - 12V 5W.K

Knuckle 17 / 19

#	OEM	KA3	KA4
1	44300-SG0-004	Bearing assy - FR. HUB (KOYO SEIKO)	Bearing assy - FR. HUB (KOYO SEIKO)
2	44600-SG0-000	Hub assy - FR.	Hub assy - FR.
3	45251-SG0-J00	Disk - FR. BRAKE	Disk - FR. BRAKE
4	45255-SG0-020	Guard - FR. SPLASH	Guard - FR. SPLASH
7	51220-SD4-023	Joint comp - LOWER BALL (MUSASHI)	Joint comp - LOWER BALL (MUSASHI)
8	51225-SD4-003	Boot - LOWER BALL DUST	Boot - LOWER BALL DUST
9	51450-SG0-003	Arm assy. - R. FR. UPPER	Arm assy. - R. FR. UPPER
10	51460-SG0-003	Arm assy. - L. FR. UPPER	Arm assy. - L. FR. UPPER
11	53546-SA0-003	Boot - TIE ROD END (MUSASHI)	Boot - TIE ROD END (MUSASHI)
12	53548-SA0-003	Circlip - MUSASHI	Circlip - MUSASHI
13	53548-SD4-003	Circlip - LOWER BALL (MUSASHI)	Circlip - LOWER BALL (MUSASHI)
14	90113-SD4-900	Bolt - WHEEL	Bolt - WHEEL
15	90215-SB0-003	Nut - SELF-LOCK, 12MM (SATO RASHI) (CLINCH)	Nut - SELF-LOCK, 12MM (SATO RASHI) (CLINCH)
16	90305-SD4-003	Nut - SPINDLE (24MM)	Nut - SPINDLE (24MM)
17	90307-SD4-010	Nut - CASTLE, 14MM	Nut - CASTLE, 14MM
18	90321-SE0-000	Nut - UPPER BALL PIN, 10MM	Nut - UPPER BALL PIN, 10MM
19	90681-SG0-000	Circlip - INTERNAL, 84MM	Circlip - INTERNAL, 84MM

Left side cover 33 / 33

#	OEM	KA3	KA4
1	21240-PL5-A00	Cover comp. - L. SIDE	Cover comp. - L. SIDE
2	21244-PF4-010	Spring - LOW ACCUMULATOR ONE WAY BALL	Spring - LOW ACCUMULATOR ONE WAY BALL
3	21812-PL5-S00	Gasket - L. SIDE COVER	Gasket - L. SIDE COVER
4	22710-PF4-010	Pipe a - FEED	Pipe a - FEED
5	22713-PC9-010	Guide a - FEED PIPE	Guide a - FEED PIPE
6	22721-PA9-003	Flange - FEED PIPE	Flange - FEED PIPE
7	22722-PG4-000	Pipe c - FEED	Pipe c - FEED
8	27561-PG4-000	Piston - LOW ACCUMULATOR	Piston - LOW ACCUMULATOR
9	27562-PL5-000	Spring a - LOW ACCUMULATOR	Spring a - LOW ACCUMULATOR
10	27563-PG4-000	Cover - LOW ACCUMULATOR	Cover - LOW ACCUMULATOR
11	27564-PL5-000	Spring b - LOW ACCUMULATOR	Spring b - LOW ACCUMULATOR
12	28810-PL5-A02	Pick up assy. - MAIN (KEIHIN)	Pick up assy. - MAIN (KEIHIN)
12	28810-PL5-A01	Pick up assy. - MAIN (TEC)	Pick up assy. - MAIN (TEC)
13	28820-PL5-A02	Pick up assy. - COUNTER (KEIHIN)	Pick up assy. - COUNTER (KEIHIN)
13	28820-PL5-A01	Pick up assy. - COUNTER (TEC)	Pick up assy. - COUNTER (TEC)
14	90024-PF4-020	Bolt - LOW ACCUMULATOR SEALING	Bolt - LOW ACCUMULATOR SEALING
15	90024-612-000	Bolt - SEALING, 8MM	Bolt - SEALING, 8MM
16	90471-580-000	Packing - 8MM	Packing - 8MM
17	90507-PA9-000	Collar - 8X11	Collar - 8X11
18	90601-PC9-860	Circlip - INTERNAL, 38MM	Circlip - INTERNAL, 38MM
19	90703-PA9-003	Roller - 2X19.8	Roller - 2X19.8
20	91301-PC9-003	O-ring - 7.7X2.3 (ARAI)	O-ring - 7.7X2.3 (ARAI)
20	91301-PC9-004	O-ring - 7.7X2.3 (NOK)	O-ring - 7.7X2.3 (NOK)
21	91305-PC9-004	O-ring - 34X1.9 (NOK)	O-ring - 34X1.9 (NOK)
21	91305-PC9-003	O-ring - 34X1.9 (ARAI)	O-ring - 34X1.9 (ARAI)
22	91308-PA9-004	O-ring - 19.8X1.9 (NOK)	O-ring - 19.8X1.9 (NOK)
22	91308-PA9-003	O-ring - 19.8X1.9 (ARAI)	O-ring - 19.8X1.9 (ARAI)
23	91309-PX4-003	O-ring - 16X2.1 (NOK)	O-ring - 16X2.1 (NOK)
24	91311-PA9-004	O-ring - 7.7X1.9 (NOK)	O-ring - 7.7X1.9 (NOK)
24	91311-PA9-003	O-ring - 7.7X1.9 (ARAI)	O-ring - 7.7X1.9 (ARAI)
25	91314-PC9-004	O-ring - 8.5X1.9 (NOK)	O-ring - 8.5X1.9 (NOK)
25	91314-PC9-003	O-ring - 8.5X1.9 (ARAI)	O-ring - 8.5X1.9 (ARAI)
26	91344-PN1-003	O-ring - 30.7X2.4 (NOK)	O-ring - 30.7X2.4 (NOK)

Main valve body/governor 21 / 21

#	OEM	KA3	KA4
1	22741-PG4-010	Pipe - LOW CLUTCH	Pipe - LOW CLUTCH
2	24461-PA9-010	Spring - ROLLER	Spring - ROLLER
3	24471-PN6-000	Roller - 6X16	Roller - 6X16
4	25145-PA9-010	Shaft - OIL PUMP GEAR	Shaft - OIL PUMP GEAR
5	27105-PL5-Z03	Body sub assy. - MAIN VALVE	Body sub assy. - MAIN VALVE
6	27112-PL5-Z00	Plate - MAIN SEPARATING	Plate - MAIN SEPARATING
7	27115-PL5-A00	Holder - MAIN SEPARATOR PLATE	Holder - MAIN SEPARATOR PLATE
8	27116-PL5-A00	Pin - OIL STOPPER	Pin - OIL STOPPER
9	27255-PC9-710	Spring - TORQUE CONVERTER CHECK VALVE	Spring - TORQUE CONVERTER CHECK VALVE
10	27256-PA9-000	Valve - RELIEF	Valve - RELIEF
11	27256-639-000	Valve - TORQUE CONVERTER CHECK	Valve - TORQUE CONVERTER CHECK
12	27257-PG4-000	Spring - RELIEF VALVE	Spring - RELIEF VALVE
13	27258-680-900	Seat - RELIEF VALVE SPRING	Seat - RELIEF VALVE SPRING
18	27415-PC9-010	Valve - ORIFICE CONTROL	Valve - ORIFICE CONTROL
19	27418-PF4-000	Spring - ORIFICE CONTROL VALVE	Spring - ORIFICE CONTROL VALVE
20	27419-PC9-010	SEAT, VALVE SPRING	SEAT, VALVE SPRING
21	27421-PL5-Z00	Valve - MANUAL	Valve - MANUAL
22	27544-PL5-Z01	Seat - SHIFT (3-4)	Seat - SHIFT (3-4)
23	27750-PL5-J01	Filter - SECONDARY BODY	Filter - SECONDARY BODY
24	90007-PA9-000	Bolt - FLANGE, 6X30	Bolt - FLANGE, 6X30
28	91101-PF4-003	Roller - 3.5X21.8	Roller - 3.5X21.8

Mainshaft 39 / 39

#	OEM	KA3	KA4
1	22814-PF4-003	Ring - SEALING, 35MM	Ring - SEALING, 35MM
2	23210-PL5-E02	Mainshaft comp.	Mainshaft comp.
3	23411-PL5-J00	Gear - MAINSHAFT LOW	Gear - MAINSHAFT LOW
4	23431-PL5-610	Gear - MAINSHAFT SECOND	Gear - MAINSHAFT SECOND
5	23461-PL5-E00	Gear - MAINSHAFT FOURTH	Gear - MAINSHAFT FOURTH
6	90201-PL5-Z00	Nut - FLANGE, 19MM	Nut - FLANGE, 19MM
7	90406-PF4-000	Washer - THRUST, 31X42X1.5	Washer - THRUST, 31X42X1.5
8	90407-PC9-000	Washer - THRUST, 26X53X3	Washer - THRUST, 26X53X3
9	90420-PG4-000	Washer - 26X45X3.8	Washer - 26X45X3.8
10	90422-PA9-000	Washer - THRUST, 26MM	Washer - THRUST, 26MM
11	90445-PG4-010	Washer - THRUST, 36.5X55X4.20	Washer - THRUST, 36.5X55X4.20
11	90447-PG4-010	Washer - THRUST, 36.5X55X4.30	Washer - THRUST, 36.5X55X4.30
11	90442-PG4-010	Washer - THRUST, 36.5X55X4.05	Washer - THRUST, 36.5X55X4.05
11	90449-PG4-010	Washer - THRUST, 36.5X55X4.40	Washer - THRUST, 36.5X55X4.40
11	90444-PG4-010	Washer - THRUST, 36.5X55X4.15	Washer - THRUST, 36.5X55X4.15
11	90446-PG4-010	Washer - THRUST, 36.5X55X4.25	Washer - THRUST, 36.5X55X4.25
11	90441-PG4-010	Washer - THRUST, 36.5X55X4.00	Washer - THRUST, 36.5X55X4.00
11	90448-PG4-010	Washer - THRUST, 36.5X55X4.35	Washer - THRUST, 36.5X55X4.35
11	90443-PG4-010	Washer - THRUST, 36.5X55X4.10	Washer - THRUST, 36.5X55X4.10
12	90502-PC9-000	Collar - MAINSHAFT FOURTH GEAR	Collar - MAINSHAFT FOURTH GEAR
14	90508-PF4-000	Collar - 26MM	Collar - 26MM
15	90603-PF4-003	Circlip - EXTERNAL, 23MM	Circlip - EXTERNAL, 23MM
16	90613-PA9-000	Ring - SNAP, 26MM	Ring - SNAP, 26MM
17	91011-PG4-003	Bearing - NEEDLE, 32X38X20 (NTN)	Bearing - NEEDLE, 32X38X20 (NTN)
17	91011-PA9-004	Bearing - NEEDLE, 32X38X20 (KOYO)	Bearing - NEEDLE, 32X38X20 (KOYO)
18	91012-PN6-701	Bearing - NEEDLE, 31X36X18.5	Bearing - NEEDLE, 31X36X18.5
19	91017-PL5-Z01	Bearing - NEEDLE, 23X29X25	Bearing - NEEDLE, 23X29X25
20	91018-PA9-003	Bearing - THRUST NEEDLE, 32X44X2 (NTN)	Bearing - THRUST NEEDLE, 32X44X2 (NTN)
20	91018-P56-003	Bearing - THRUST NEEDLE, 32X44X2 (NTN)	Bearing - THRUST NEEDLE, 32X44X2 (NTN)
21	91019-PG4-003	Bearing - THRUST NEEDLE, 31X47X2	Bearing - THRUST NEEDLE, 31X47X2
22	91023-PG4-013	Bearing - THRUST NEEDLE, 36X56X2.5 (NTN)	Bearing - THRUST NEEDLE, 36X56X2.5 (NTN)
23	91031-PC9-003	Bearing - THRUST NEEDLE, 39X54X2 (NTN)	Bearing - THRUST NEEDLE, 39X54X2 (NTN)
23	91031-PC9-006	Bearing - THRUST NEEDLE, 39X54X2 (NIPPON SEIKO)	Bearing - THRUST NEEDLE, 39X54X2 (NIPPON SEIKO)
23	91031-PC9-005	Bearing - THRUST NEEDLE, 39X54X2 (KOYO)	Bearing - THRUST NEEDLE, 39X54X2 (KOYO)
24	91101-PL5-003	Bearing - THRUST NEEDLE, 36X42X18.5	Bearing - THRUST NEEDLE, 36X42X18.5
25	91307-PA9-004	O-ring - 31.2X1.9 (NOK)	O-ring - 31.2X1.9 (NOK)
25	91307-PA9-003	O-ring 31.2X1.9 (ARAI)	O-ring 31.2X1.9 (ARAI)
26	91308-PA9-004	O-ring - 19.8X1.9 (NOK)	O-ring - 19.8X1.9 (NOK)
26	91308-PA9-003	O-ring - 19.8X1.9 (ARAI)	O-ring - 19.8X1.9 (ARAI)

Mainshaft/gears 14 / 14

#	OEM	KA3	KA4
1	23210-PG2-A30	Mainshaft comp.	Mainshaft comp.
2	23261-PG2-000	Shaft - REVERSE IDLE GEAR	Shaft - REVERSE IDLE GEAR
3	23441-PG2-010	Gear - MAINSHAFT THIRD	Gear - MAINSHAFT THIRD
4	23451-PG2-010	Gear - MAINSHAFT FOURTH	Gear - MAINSHAFT FOURTH
5	23540-PG2-020	Gear comp - REVERSE IDLE	Gear comp - REVERSE IDLE
6	23543-PG2-000	Washer - 20X30X4	Washer - 20X30X4
7	23581-PG2-E00	Gear - MAINSHAFT FIFTH	Gear - MAINSHAFT FIFTH
8	23623-PG2-305	Sleeve set - SYNCHRONIZER (3-4)	Sleeve set - SYNCHRONIZER (3-4)
9	23626-PG2-325	Sleeve set - SYNCHRONIZER (5)	Sleeve set - SYNCHRONIZER (5)
10	23915-PG1-770	Collar - DISTANCE, 31X38X56	Collar - DISTANCE, 31X38X56
11	23927-PG2-A00	Washer - SPRING, 28MM	Washer - SPRING, 28MM
12	91104-PG1-771	Bearing - NEEDLE, 38X43X26 (NTN)	Bearing - NEEDLE, 38X43X26 (NTN)
12	91104-PK5-008	Bearing - NEEDLE, 38X43X26 (NTN)	Bearing - NEEDLE, 38X43X26 (NTN)
12	91104-PG2-004	Bearing - NEEDLE, 38X43X26 (KOYO)	Bearing - NEEDLE, 38X43X26 (KOYO)

Master power 9 / 9

#	OEM	KA3	KA4
1	46191-634-000	Gasket - MASTER CYLINDER BRACKET	Gasket - MASTER CYLINDER BRACKET
2	46192-SD2-003	Spacer	Spacer
3	46193-SD2-003	Seal - MASTER POWER	Seal - MASTER POWER
4	46400-SD4-A31	Power assy. - MASTER (8"+9")	Power assy. - MASTER (8"+9")
5	46401-SA5-013	Valve assy. - CHECK	Valve assy. - CHECK
6	46404-SG0-A00	Tube a - MASTER POWER	Tube a - MASTER POWER
9	46405-SD4-670	Tube b - MASTER POWER	Tube b - MASTER POWER
11	46512-SB2-000	Pin - PEDAL	Pin - PEDAL
12	53729-671-003	Clamp d - 15.5MM	Clamp d - 15.5MM

Mirror/sunvisor 6 / 17

#	OEM	KA3	KA4
24	83248-SG0-003	Spacer - GRAB RAIL	Spacer - GRAB RAIL
28	88145-SD2-003	Base	Base
29	88147-SA5-003	Washer - TOOTHED (MATSUYAMA)	Washer - TOOTHED (MATSUYAMA)
30	88148-SA5-003	Bolt - LOCK, 6X7 (MATSUYAMA)	Bolt - LOCK, 6X7 (MATSUYAMA)
34	90681-693-000	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
35	90133-SG0-003	Bolt-washer - 5X30	Bolt-washer - 5X30

Modulator (A.L.B.) 2 / 31

#	OEM	KA3	KA4
2	46472-568-000	Packing - OIL BOLT	Packing - OIL BOLT
3	46669-692-003	Seal - RESERVE TANK	Seal - RESERVE TANK

Oil cooler hose 20 / 20

#	OEM	KA3	KA4
1	19313-PL2-000	Clamp b - WATER HOSE (D13.5)	Clamp b - WATER HOSE (D13.5)
2	19422-PH7-010	Hose - IN. OIL COOLER	Hose - IN. OIL COOLER
3	19423-PH7-010	Hose - OIL COOLER OUTLET	Hose - OIL COOLER OUTLET
4	19424-PL2-000	Hose - OIL COOLER PIPE	Hose - OIL COOLER PIPE
5	19425-PH7-000	Joint - OIL COOLER CONNECTING	Joint - OIL COOLER CONNECTING
6	19426-PL2-000	Pipe - OIL COOLER OUTLET	Pipe - OIL COOLER OUTLET
7	19427-PH7-004	Clamp - OIL COOLER HOSE	Clamp - OIL COOLER HOSE
8	19512-PC6-003	Clip - HOSE, 18.7MM	Clip - HOSE, 18.7MM
9	19522-PL2-010	Hose a - WATER	Hose a - WATER
10	19523-PL2-000	Hose b - WATER	Hose b - WATER
11	19524-PH7-000	Hose c - WATER	Hose c - WATER
12	19525-PL2-000	Hose d - WATER	Hose d - WATER
13	19526-PL2-010	Hose e - WATER	Hose e - WATER
14	19527-PL2-000	Hose f - WATER	Hose f - WATER
15	91405-PK1-003	Clip, WATER HOSE, 24MM	Clip, WATER HOSE, 24MM
15	19513-PE0-003	Clamp - WATER HOSE (21.7MM) (CHUO SPRING)	Clamp - WATER HOSE (21.7MM) (CHUO SPRING)
16	79720-SD4-000	Hose - WATER IN.	Hose - WATER IN.
17	91311-PH7-004	O-ring - 13.8X2.4 (ARAI)	O-ring - 13.8X2.4 (ARAI)
17	91311-PH7-003	O-ring - 13.8X2.4 (NOK)	O-ring - 13.8X2.4 (NOK)
18	91405-PD1-004	Clamp - TUBE(D12)	Clamp - TUBE(D12)

Oil cooler/oil filter 25 / 26

#	OEM	KA3	KA4
1	11110-PL2-000	Pipe comp - OIL LEVEL	Pipe comp - OIL LEVEL
2	15301-PL2-000	Base - OIL FILTER	Base - OIL FILTER
3	15400-PL2-305	Cartridge - OIL FILTER (TOYO ROKI)	Cartridge - OIL FILTER (TOYO ROKI)
3	15400-PL2-306	OIL FILTER (TOYO ROKI)	OIL FILTER (TOYO ROKI)
4	15500-PH7-004	Cooler - ENGINE OIL (DENSO)	Cooler - ENGINE OIL (DENSO)
5	15550-PH7-000	Bolt assy - OIL COOLER CENTER	Bolt assy - OIL COOLER CENTER
6	15650-PL2-004	Gauge comp. - OIL LEVEL (ARS)	Gauge comp. - OIL LEVEL (ARS)
7	15705-PL2-000	Tube a - PCV	Tube a - PCV
8	17135-PL2-010	Pipe assy. - BREATHER	Pipe assy. - BREATHER
9	17153-PH7-000	Tube - BREATHER PIPE	Tube - BREATHER PIPE
10	37240-657-013	Switch - OIL PRESSURE (DENSO)	Switch - OIL PRESSURE (DENSO)
10	37240-P13-013	Switch assy - OIL PRESSURE (DENSO)	Switch assy - OIL PRESSURE (DENSO)
10	37240-PA6-004	Switch - OIL PRESSURE (TEC)	Switch - OIL PRESSURE (TEC)
11	90002-PA6-003	Bolt-washer - 4X8 (DENSO)	Bolt-washer - 4X8 (DENSO)
12	90015-PL2-000	Holder - OIL FILTER	Holder - OIL FILTER
14	91308-PH9-000	O-ring - 8.8X1.9	O-ring - 8.8X1.9
14	91302-GE0-000	O-ring (8.8x1.9)	O-ring (8.8x1.9)
15	91316-PE7-730	O-ring - 62.4X3.1	O-ring - 62.4X3.1
16	91318-PH7-004	O-ring - OIL FILTER CASE (NOK)	O-ring - OIL FILTER CASE (NOK)
16	91318-PY3-000	Packing - OIL PUMP	Packing - OIL PUMP
16	91318-PH7-003	O-ring - OIL FILTER CASE (ARAI)	O-ring - OIL FILTER CASE (ARAI)
17	91327-PH7-003	O-ring - 29X2.4 (NOK)	O-ring - 29X2.4 (NOK)
17	91327-PH7-004	O-ring - 29X2.4 (ARAI)	O-ring - 29X2.4 (ARAI)
18	91405-679-004	Clamp - TUBE (D17)	Clamp - TUBE (D17)
18	91405-PM5-004	Clamp - TUBE (D17)	Clamp - TUBE (D17)

Oil pump 23 / 23

#	OEM	KA3	KA4
1	15100-PH6-003	Pump assy. - OIL	Pump assy. - OIL
2	15110-PH6-003	Body - OIL PUMP	Body - OIL PUMP
3	15112-PH7-013	Cover - OIL PUMP	Cover - OIL PUMP
4	15131-PH6-003	Rotor - PUMP INNER	Rotor - PUMP INNER
5	15132-PH6-003	Rotor - PUMP OUTER	Rotor - PUMP OUTER
6	15141-PH7-000	Joint - OIL PASS PIPE	Joint - OIL PASS PIPE
7	15143-PH7-000	Pipe - OIL PASS	Pipe - OIL PASS
8	15220-PH7-000	Strainer comp. - OIL	Strainer comp. - OIL
9	15231-PH7-003	Valve - RELIEF	Valve - RELIEF
10	15232-PH7-013	Spring - RELIEF VALVE	Spring - RELIEF VALVE
11	15233-PC6-000	Bolt - SEALING, 18MM	Bolt - SEALING, 18MM
12	15233-PH7-013	Seat - RELIEF VALVE SPRING	Seat - RELIEF VALVE SPRING
13	15234-PH7-003	O-ring - SPRING SEAT	O-ring - SPRING SEAT
14	15302-PH7-003	Washer - SEALING, 18MM	Washer - SEALING, 18MM
17	90041-PA5-000	Bolt - STUD, 6X28	Bolt - STUD, 6X28
19	91212-PH7-013	Oil seal - 41X56X8	Oil seal - 41X56X8
20	91308-PH7-003	O-ring - OIL JOINT	O-ring - OIL JOINT
21	91309-PH7-000	O-ring - 17.4X3.5	O-ring - 17.4X3.5
22	91310-PH7-000	O-ring - 19.8X2.4	O-ring - 19.8X2.4
29	90051-PH7-000	Bolt - FLANGE, 6X18	Bolt - FLANGE, 6X18
31	90052-PH7-000	Bolt - FLANGE, 6X22	Bolt - FLANGE, 6X22
33	90053-PH7-000	Bolt - FLANGE, 8X65	Bolt - FLANGE, 8X65
33	90042-PR7-A00	Bolt - FLANGE, 8X65	Bolt - FLANGE, 8X65

Opening trim 8 / 14

#	OEM	KA3	KA4
2	66856-SA0-660	Lock - FUSE PANEL	Lock - FUSE PANEL
3	66857-SA0-660	Spring - FUSE PANEL	Spring - FUSE PANEL
24	90137-SD2-000	Screw - TAPPING, 4X12 (SUS)	Screw - TAPPING, 4X12 (SUS)
25	90601-836-000	E-ring - 4MM	E-ring - 4MM
27	90609-SG0-003	Clip - PILLAR GARNISH	Clip - PILLAR GARNISH
29	90667-693-920	Clip - ROOF SIDE	Clip - ROOF SIDE
30	90672-671-811	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
31	90681-693-000	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM

P.s. gear box (LH) 9 / 10

#	OEM	KA3	KA4
1	53435-SD4-951	Cushion a - POWER STEERING GEAR BOX	Cushion a - POWER STEERING GEAR BOX
2	53436-SD4-950	Cushion b - POWER STEERING GEAR BOX	Cushion b - POWER STEERING GEAR BOX
3	53437-SK2-A51	Bracket a - STEERING GEAR BOX	Bracket a - STEERING GEAR BOX
4	53438-SD4-951	Bracket b - STEERING GEAR BOX	Bracket b - STEERING GEAR BOX
5	53501-SD4-000	Grommet a - STEERING	Grommet a - STEERING
6	53502-SD4-000	Grommet b - STEERING	Grommet b - STEERING
8	53692-SK2-A53	Guard - SPLASH	Guard - SPLASH
9	53760-SA5-950	Rubber - GEAR BOX SEAL	Rubber - GEAR BOX SEAL
10	90171-SD4-010	Bolt-washer - 10X34	Bolt-washer - 10X34

P.s. gear box components (LH) 56 / 61

#	OEM	KA3	KA4
1	53412-634-000	O-ring - RACK GUIDE (YAMADA)	O-ring - RACK GUIDE (YAMADA)
2	53413-SD4-970	Spring - RACK GUIDE PRESSURE	Spring - RACK GUIDE PRESSURE
3	53414-634-010	Screw - RACK GUIDE	Screw - RACK GUIDE
3	53414-634-020	Screw	Screw
4	53416-SD4-953	Guide - STEERING RACK	Guide - STEERING RACK
5	53426-SE0-951	Dust seal - STEERING PINION	Dust seal - STEERING PINION
6	53458-SE0-003	Nut - RACK SCREW LOCK	Nut - RACK SCREW LOCK
6	53458-S01-A51	Nut - LOCK	Nut - LOCK
7	53608-SD4-A61	Housing sub assy. - STEERING GEAR BOX (###)	Housing sub assy. - STEERING GEAR BOX (###)
8	53611-SD4-952	Cylinder comp	Cylinder comp
10	53613-SD4-954	Retainer - PACKING	Retainer - PACKING
11	53614-SD4-951	Cap - CYLINDER	Cap - CYLINDER
12	53615-SD4-950	Washer - RETAINER	Washer - RETAINER
13	53617-SA5-951	Port - ORIFICE	Port - ORIFICE
14	53622-SD4-A51	Pinion - STEERING	Pinion - STEERING
15	53625-SE0-950	Cap - GEAR BOX HOUSING	Cap - GEAR BOX HOUSING
17	53629-SD4-952	Ring - PISTON SEAL	Ring - PISTON SEAL
18	53630-SD4-950	Spring - CYLINDER	Spring - CYLINDER
19	53631-SD4-951	Bush a - STEERING RACK	Bush a - STEERING RACK
20	53632-SF1-951	Bushing b - STEERING RACK	Bushing b - STEERING RACK
21	53633-SD4-953	Packing - CYLINDER END (NOK)	Packing - CYLINDER END (NOK)
21	53633-SK7-951	Packing - CYLINDER END (NOK)	Packing - CYLINDER END (NOK)
22	53634-SF1-950	Clip - BUSH STOPPER	Clip - BUSH STOPPER
24	53643-SD4-A61	Port comp. - VALVE	Port comp. - VALVE
25	53645-SD4-A60	Cap a - VALVE BODY	Cap a - VALVE BODY
26	53652-SE0-950	Spool comp. c - CUT-OFF (-0.010 / -0.005)	Spool comp. c - CUT-OFF (-0.010 / -0.005)
26	53651-SE0-950	Spool comp. b - CUT-OFF (-0.005 / 0)	Spool comp. b - CUT-OFF (-0.005 / 0)
26	53650-SE0-950	Spool comp. a - CUT-OFF (0 / +0.005)	Spool comp. a - CUT-OFF (0 / +0.005)
27	53653-SE0-950	Spring - CUT-OFF	Spring - CUT-OFF
29	53659-SA5-671	Orifice - DAMPING	Orifice - DAMPING
30	53660-SA5-952	Seal - PORT	Seal - PORT
32	90684-SD4-950	Ring - SNAP, 31MM	Ring - SNAP, 31MM
33	90693-SE0-951	Circlip - INTERNAL, 28MM	Circlip - INTERNAL, 28MM
34	90697-SE0-951	Circlip - EXTERNAL, 30MM	Circlip - EXTERNAL, 30MM
35	91052-SD4-J62	Bearing - 6906Z	Bearing - 6906Z
36	91053-SD4-J61	Bearing - 6001Z	Bearing - 6001Z
37	91103-429-000	Dowel pin - 8X10	Dowel pin - 8X10
38	91154-SA5-952	Roller - 3.5X29.8	Roller - 3.5X29.8
39	91202-SD4-951	Ring - BACK UP	Ring - BACK UP
40	91350-671-004	O-ring - 3.4MM (NOK)	O-ring - 3.4MM (NOK)
40	91350-671-003	O-ring - 3.4MM (ARAI)	O-ring - 3.4MM (ARAI)
40	91305-MCJ-751	O-ring (3.2x1.1)	O-ring (3.2x1.1)
41	91352-SA5-952	O-ring - 7.8X1.9 (NOK)	O-ring - 7.8X1.9 (NOK)
41	91352-SA5-951	O-ring - 7.8X1.9(ARAI)	O-ring - 7.8X1.9(ARAI)
42	91353-SA5-951	O-ring - 11X1.9 (ARAI)	O-ring - 11X1.9 (ARAI)
43	91354-SD4-952	O-ring - 27.5X2 (ARAI)	O-ring - 27.5X2 (ARAI)
43	91354-SD4-951	O-ring - 27.5X2 (NOK)	O-ring - 27.5X2 (NOK)
44	91355-SD4-954	O-ring - 37X1.5 (ARAI)	O-ring - 37X1.5 (ARAI)
44	91355-SD4-953	O-ring - 37X1.5 (NOK)	O-ring - 37X1.5 (NOK)
45	91356-SD4-953	O-ring - 31.5X2.4 (NOK)	O-ring - 31.5X2.4 (NOK)
46	91360-SD4-952	O-ring - 50X2.4 (ARAI)	O-ring - 50X2.4 (ARAI)
46	91360-SD4-951	O-ring - 50X2.4 (NOK)	O-ring - 50X2.4 (NOK)
47	91361-SA5-952	O-ring - 46X1.5 (NOK)	O-ring - 46X1.5 (NOK)
47	91361-SA5-951	O-ring - 46X1.5 (ARAI)	O-ring - 46X1.5 (ARAI)
48	91362-SE0-952	O-ring - 45.5X2 (NOK)	O-ring - 45.5X2 (NOK)
48	91362-SE0-951	O-ring - 45.5X2 (ARAI)	O-ring - 45.5X2 (ARAI)

P.s. line (LH) 40 / 43

#	OEM	KA3	KA4
1	19105-PH7-000	Bracket comp. - RESERVE TANK	Bracket comp. - RESERVE TANK
2	53748-671-000	Rubber - MOUNTING	Rubber - MOUNTING
3	46217-579-000	Clip - TUBE	Clip - TUBE
4	53697-SD4-951	Cap - OIL TANK	Cap - OIL TANK
5	53701-SD4-953	Tank comp. - POWER STEERING OIL	Tank comp. - POWER STEERING OIL
6	53710-SD4-952	Bracket assy - OIL TANK	Bracket assy - OIL TANK
7	53711-SD4-950	Bracket - OIL TANK	Bracket - OIL TANK
8	53713-SD4-673	Hose comp. - FEED	Hose comp. - FEED
9	53720-SD4-A63	Hose - RETURN	Hose - RETURN
10	53721-SD4-A61	Stay - RETURN HOSE	Stay - RETURN HOSE
11	53724-SD4-A62	Pipe comp - RETURN, 6MM	Pipe comp - RETURN, 6MM
12	53725-SE0-951	Hose - SPEED SENSOR INLET	Hose - SPEED SENSOR INLET
13	53726-SD4-A62	Pipe comp - SENSOR	Pipe comp - SENSOR
14	53727-SD4-950	Tube - SPEED SENSOR RETURN	Tube - SPEED SENSOR RETURN
14	53727-SD4-980	Tube - SPEED SENSOR RETURN	Tube - SPEED SENSOR RETURN
16	53729-671-003	Clamp d - 15.5MM	Clamp d - 15.5MM
17	53731-SD4-954	Tube - SUCTION	Tube - SUCTION
18	53732-SD4-954	Hose - SENSOR RETURN	Hose - SENSOR RETURN
19	53733-SD4-953	Hose - RETURN	Hose - RETURN
20	53734-SD4-950	Tube - SENSOR JOINT	Tube - SENSOR JOINT
21	53735-SD4-950	Tube - RETURN JOINT	Tube - RETURN JOINT
22	53736-SD4-953	Holder b - POWER STEERING PIPE	Holder b - POWER STEERING PIPE
23	53737-SD4-952	Hose comp. - RETURN	Hose comp. - RETURN
24	53740-SE0-953	Clip - SENSOR HOSE	Clip - SENSOR HOSE
25	53746-SD4-953	Stay a - POWER STEERING CLIP	Stay a - POWER STEERING CLIP
27	53753-SD4-A61	Clip - RETURN PIPE	Clip - RETURN PIPE
28	53765-SD4-952	Cooler - POWER STEERING OIL	Cooler - POWER STEERING OIL
30	53773-SD4-953	Clamp - SUCTION	Clamp - SUCTION
31	53776-SD4-951	Clip A - POWER STEERING HOSE	Clip A - POWER STEERING HOSE
32	53777-SD4-954	Connector - THREE WAY	Connector - THREE WAY
33	53778-SD4-952	Clip b - POWER STEERING HOSE	Clip b - POWER STEERING HOSE
34	53781-SE0-952	Clip - RETURN HOSE	Clip - RETURN HOSE
35	56490-PH6-003	Switch assy - POWER STEERING PRESSURE	Switch assy - POWER STEERING PRESSURE
36	56492-PH7-010	Cord comp - PRESSURE SWITCH	Cord comp - PRESSURE SWITCH
37	90370-SD4-950	Nut - FLANGE, 6MM	Nut - FLANGE, 6MM
38	90854-671-000	Collar - OIL PUMP	Collar - OIL PUMP
39	91304-PA6-003	O-ring - 7.8X1.9	O-ring - 7.8X1.9
40	91314-PE0-000	O-ring - 19.8X1.9	O-ring - 19.8X1.9
41	91370-SB3-950	O-ring - 8.8X1.9	O-ring - 8.8X1.9
43	91462-SA5-950	Clamp d - 19MM	Clamp d - 19MM

P.s. pump components 16 / 16

#	OEM	KA3	KA4
1	56110-PH7-040	Pump sub assy - POWER STEERING	Pump sub assy - POWER STEERING
2	56250-PH7-000	Cover comp. - OIL PUMP FR. (###)	Cover comp. - OIL PUMP FR. (###)
3	56350-PC1-010	Spool assy. - A) (-0.005 / 0) (###	Spool assy. - A) (-0.005 / 0) (###
3	56360-PC1-010	Spool assy. - B) (0 / +0.006) (###	Spool assy. - B) (0 / +0.006) (###
4	56385-PC1-000	Spring - SPOOL (###)	Spring - SPOOL (###)
5	56480-PC1-040	Pulley assy - POWER STEERING PUMP	Pulley assy - POWER STEERING PUMP
6	90001-PC1-000	Bolt - FLANGE, 6X78	Bolt - FLANGE, 6X78
7	90004-PE0-000	Bolt - SPECIAL, 8X18	Bolt - SPECIAL, 8X18
8	90701-679-000	Dowel pin - 8X10	Dowel pin - 8X10
9	91201-PE0-003	Oil seal - 16X30X7 (NOK)	Oil seal - 16X30X7 (NOK)
9	91201-PE0-004	Oil seal - 16X30X7 (ARAI)	Oil seal - 16X30X7 (ARAI)
10	91303-PH1-003	Seal - HOUSING (NOK)	Seal - HOUSING (NOK)
10	91303-PH1-004	Seal - HOUSING (ARAI)	Seal - HOUSING (ARAI)
11	91307-PH1-004	Seal - PLUNGER	Seal - PLUNGER
12	91322-PH1-003	O-ring - 18.3X1.9 (NOK)	O-ring - 18.3X1.9 (NOK)
12	91322-PH1-004	O-ring - 18.3X1.9 (ARAI)	O-ring - 18.3X1.9 (ARAI)

P.s. pump/speed sensor 8 / 8

#	OEM	KA3	KA4
1	23814-689-000	Seal - GEAR HOLDER	Seal - GEAR HOLDER
2	56500-PH6-010	Sensor assy - POWER STEERING	Sensor assy - POWER STEERING
2	56500-PH6-901	Sensor assy - POWER STEERING	Sensor assy - POWER STEERING
3	56992-PL2-003	Belt - POWER STEERING PUMP	Belt - POWER STEERING PUMP
4	56995-PH7-000	Bolt - PLATE BASED	Bolt - PLATE BASED
5	90204-PH7-000	Nut - SPECIAL	Nut - SPECIAL
6	90637-689-000	Clip - SPEEDOMETER CABLE	Clip - SPEEDOMETER CABLE
7	91313-611-010	O-ring - 23.5X2	O-ring - 23.5X2

Parking brake 14 / 18

#	OEM	KA3	KA4
1	43471-SD2-930	Pin - BRAKE WIRE END	Pin - BRAKE WIRE END
3	47122-SD4-672	Cover - PARKING BRAKE	Cover - PARKING BRAKE
4	47142-671-010	Knob - PARKING BRAKE PUSH ROD	Knob - PARKING BRAKE PUSH ROD
5	47143-SD4-300	Spring - PUSH ROD	Spring - PUSH ROD
6	47190-SD4-010	Packing - PARKING BRAKE COVER	Packing - PARKING BRAKE COVER
7	47342-SA5-013	Switch - PARKING BRAKE	Switch - PARKING BRAKE
8	47360-SD4-000	Equalizer	Equalizer
10	47513-SD4-000	Holder - WIRE GUIDE	Holder - WIRE GUIDE
13	47538-SD4-003	Nut - ADJUSTING	Nut - ADJUSTING
14	47572-SD4-000	Base - WIRE GUIDE	Base - WIRE GUIDE
15	47574-SD4-000	Spring - RETURN	Spring - RETURN
17	90115-SB2-003	Nut - SELF-LOCK, 8MM	Nut - SELF-LOCK, 8MM
18	90681-693-000	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
19	90705-SD2-931	Pin - SNAP, 6MM	Pin - SNAP, 6MM

Piston/connecting rod 25 / 25

#	OEM	KA3	KA4
1	13031-PL2-751	Ring set - PISTON (OS 0.50)	Ring set - PISTON (OS 0.50)
1	13021-PL2-752	Ring set - PISTON (OS 0.25)	Ring set - PISTON (OS 0.25)
1	13011-PL2-751	Ring set - PISTON (STD.)	Ring set - PISTON (STD.)
1	13031-PL2-752	Ring set - PISTON (OS 0.50)	Ring set - PISTON (OS 0.50)
1	13021-PL2-751	Ring set - PISTON (OS 0.25)	Ring set - PISTON (OS 0.25)
1	13011-PL2-752	Ring set - PISTON (STD.)	Ring set - PISTON (STD.)
2	13102-PL2-750	Piston b - STD	Piston b - STD
2	13103-PL2-750	Piston - OS 0.25	Piston - OS 0.25
2	13104-PL2-750	Piston - OS 0.50	Piston - OS 0.50
2	13101-PL2-750	Piston a - STD	Piston a - STD
3	13112-PH7-000	Pin - PISTON	Pin - PISTON
4	13204-PY3-013	Bolt - CONNECTING ROD	Bolt - CONNECTING ROD
4	13204-PH7-003	Bolt - CONNECTING ROD	Bolt - CONNECTING ROD
5	13205-PH7-000	Nut - CONNECTING ROD	Nut - CONNECTING ROD
6	13210-PH7-000	Rod comp - CONNECTING	Rod comp - CONNECTING
7	13215-PH7-013	Bearing e - CONNECTING ROD (PINK) (DAIDO)	Bearing e - CONNECTING ROD (PINK) (DAIDO)
7	13212-PH7-014	Bearing b - CONNECTING ROD (BROWN) (TAIHO)	Bearing b - CONNECTING ROD (BROWN) (TAIHO)
7	13213-PH7-014	Bearing c - CONNECTING ROD (GREEN) (TAIHO)	Bearing c - CONNECTING ROD (GREEN) (TAIHO)
7	13211-PH7-013	BEARING A - CONNECTING ROD (BLACK) (DAIDO)	BEARING A - CONNECTING ROD (BLACK) (DAIDO)
7	13214-PH7-014	Bearing d - CONNECTING ROD (YELLOW) (TAIHO)	Bearing d - CONNECTING ROD (YELLOW) (TAIHO)
7	13212-PH7-013	Bearing b - CONNECTING ROD (BROWN) (DAIDO)	Bearing b - CONNECTING ROD (BROWN) (DAIDO)
7	13215-PH7-014	Bearing e - CONNECTING ROD (PINK) (TAIHO)	Bearing e - CONNECTING ROD (PINK) (TAIHO)
7	13213-PH7-013	Bearing c - CONNECTING ROD (GREEN) (DAIDO)	Bearing c - CONNECTING ROD (GREEN) (DAIDO)
7	13214-PH7-013	Bearing d - CONNECTING ROD (YELLOW) (DAIDO)	Bearing d - CONNECTING ROD (YELLOW) (DAIDO)
7	13211-PH7-014	BEARING A - CONNECTING ROD (BLACK) (TAIHO)	BEARING A - CONNECTING ROD (BLACK) (TAIHO)

Radiator 15 / 15

#	OEM	KA3	KA4
1	19010-PH7-662	Radiator comp - DENSO	Radiator comp - DENSO
1	19010-PH7-672	Radiator comp - DENSO	Radiator comp - DENSO
2	19011-671-000	Bolt - DRAIN (DENSO)	Bolt - DRAIN (DENSO)
3	19012-671-300	Packing - DRAIN (DENSO)	Packing - DRAIN (DENSO)
4	19015-PP8-901	Shroud comp - DENSO	Shroud comp - DENSO
6	19020-PH7-661	Fan - COOLING (DENSO)	Fan - COOLING (DENSO)
7	19030-PH7-662	Motor - COOLING FAN (DENSO)	Motor - COOLING FAN (DENSO)
8	19045-PT0-003	Cap comp - DENSO	Cap comp - DENSO
8	19045-PT0-004	Cap comp - TOYO	Cap comp - TOYO
9	19050-PH7-662	Resistor assy - DENSO	Resistor assy - DENSO
10	32175-647-920	Clip - WIRE HARNESS	Clip - WIRE HARNESS
10	30701-883-000	Clip, high tension cord (8mm)	Clip, high tension cord (8mm)
11	90041-PE0-003	Screw-washer - 4X10 (DENSO)	Screw-washer - 4X10 (DENSO)
12	90042-PC1-003	Bolt-washer - 6X14 (DENSO)	Bolt-washer - 6X14 (DENSO)
13	90043-PD2-003	Nut - HEX., 5MM (DENSO)	Nut - HEX., 5MM (DENSO)

Radiator hose/ reserve tank 27 / 27

#	OEM	KA3	KA4
1	19022-PL2-000	Seal comp - R. RADIATOR SIDE	Seal comp - R. RADIATOR SIDE
2	19023-PH7-020	Seal comp - L. RADIATOR SIDE	Seal comp - L. RADIATOR SIDE
3	19101-PH7-000	Tank - RESERVE	Tank - RESERVE
4	19102-PA0-020	Cap - RESERVE TANK	Cap - RESERVE TANK
5	19103-PH7-000	Hose - RESERVE TANK	Hose - RESERVE TANK
6	19104-PH7-000	Tube - RESERVE TANK	Tube - RESERVE TANK
8	19106-PA0-020	Joint - RESERVE TANK	Joint - RESERVE TANK
9	19107-PA0-000	Clip - RESERVE TANK JOINT	Clip - RESERVE TANK JOINT
10	19108-PH7-003	Clamp - RESERVE TANK TUBE	Clamp - RESERVE TANK TUBE
11	19109-PL2-000	Skirt - TANK CAP	Skirt - TANK CAP
12	19501-PH7-000	Hose - WATER UPPER	Hose - WATER UPPER
13	19502-PH7-000	Hose - WATER LOWER	Hose - WATER LOWER
14	19511-PH7-003	Clip, HOSE(36.5MM) (CHUO SPRING)	Clip, HOSE(36.5MM) (CHUO SPRING)
15	19511-PK1-003	Clip - WATER HOSE	Clip - WATER HOSE
16	21216-PL2-000	Clamp - OIL COOLER HOSE	Clamp - OIL COOLER HOSE
17	25210-PL2-J10	Pipe comp - OIL HOSE (C)	Pipe comp - OIL HOSE (C)
18	25213-PL2-J00	Hose - OIL COOLER, 260MM	Hose - OIL COOLER, 260MM
19	25214-PL2-J00	Hose comp. - OIL COOLER, 450MM	Hose comp. - OIL COOLER, 450MM
20	25215-PH7-000	Hose - OIL COOLER, 200MM	Hose - OIL COOLER, 200MM
21	37760-PH7-003	Sensor assy - RADIATOR FAN CONTROL (MATSUSHITA)	Sensor assy - RADIATOR FAN CONTROL (MATSUSHITA)
22	74171-SD4-000	Cushion - RADIATOR MOUNTING UPPER	Cushion - RADIATOR MOUNTING UPPER
23	74172-SD4-020	Cushion - RADIATOR MOUNTING LOWER	Cushion - RADIATOR MOUNTING LOWER
24	90146-SA7-000	Bolt-washer - 6X16 (DACRO COATING)	Bolt-washer - 6X16 (DACRO COATING)
25	90635-671-000	Clip - OIL HOSE	Clip - OIL HOSE
26	90657-SB0-003	Clip, SPLASH SHIELD	Clip, SPLASH SHIELD
27	91307-611-000	O-ring (13.5X1.4)	O-ring (13.5X1.4)
27	91307-PH7-660	O-ring (13.5X1.4)	O-ring (13.5X1.4)

Rear axle 20 / 24

#	OEM	KA3	KA4
2	42324-SD4-020	Washer - RR. HUB	Washer - RR. HUB
3	42326-SG0-000	Cap - HUB UNIT	Cap - HUB UNIT
4	42510-SD4-930	Disk - RR. BRAKE	Disk - RR. BRAKE
7	43255-SG0-020	Protector - R. RR. CALIPER	Protector - R. RR. CALIPER
8	43256-SG0-020	Protector - L. RR. CALIPER	Protector - L. RR. CALIPER
9	51251-SB0-010	Cap - STABILIZER END	Cap - STABILIZER END
10	52111-SG0-300	Knuckle comp - R. RR.	Knuckle comp - R. RR.
11	52116-SG0-300	Knuckle comp - L. RR.	Knuckle comp - L. RR.
12	52202-SG0-000	Ring - SPINDLE	Ring - SPINDLE
13	52212-SG0-020	Bracket - R. RR. KNUCKLE	Bracket - R. RR. KNUCKLE
14	52217-SG0-020	Bracket - L. RR. KNUCKLE	Bracket - L. RR. KNUCKLE
15	52390-SG0-043	Arm comp - RR. UPPER	Arm comp - RR. UPPER
16	52622-SE0-000	Bush - RR. SHOCK ABSORBER LOWER	Bush - RR. SHOCK ABSORBER LOWER
16	52622-SE0-013	Bush - RR. SHOCK ABSORBER LOWER	Bush - RR. SHOCK ABSORBER LOWER
17	90025-SG0-000	Bolt - FLANGE, 10X45	Bolt - FLANGE, 10X45
18	90113-SD4-900	Bolt - WHEEL	Bolt - WHEEL
19	90171-SG0-003	Bolt a - TRAILING ARM (12X54)	Bolt a - TRAILING ARM (12X54)
20	90172-SG0-003	Bolt b - TRAILING ARM (12X42)	Bolt b - TRAILING ARM (12X42)
21	90305-SD4-003	Nut - SPINDLE (24MM)	Nut - SPINDLE (24MM)
22	90321-SE0-000	Nut - UPPER BALL PIN, 10MM	Nut - UPPER BALL PIN, 10MM

Rear brake caliper 39 / 39

#	OEM	KA3	KA4
1	43022-SG0-020	Pad set - RR.	Pad set - RR.
2	43209-371-006	Seal - PISTON (38MM)	Seal - PISTON (38MM)
3	43210-SG0-033	Caliper assy - R. RR. (NISSIN) (11CLP-14S)	Caliper assy - R. RR. (NISSIN) (11CLP-14S)
4	43214-SG0-003	Cover - PISTON DUST	Cover - PISTON DUST
5	43215-SG0-003	Piston assy.	Piston assy.
6	43218-SD2-931	Cup	Cup
7	43223-SD2-932	BEARING A	BEARING A
8	43224-SD2-931	Spring b - ADJUSTING	Spring b - ADJUSTING
9	43224-SG0-003	Shim - BRAKE PAD OUTER	Shim - BRAKE PAD OUTER
10	43225-SG0-003	Shim - BRAKE PAD INNER	Shim - BRAKE PAD INNER
11	43227-SG0-013	Spring - PAD	Spring - PAD
12	43228-SD2-933	Shaft a	Shaft a
13	43229-SD2-931	Rod	Rod
14	43230-SG0-033	Caliper assy - L. RR. (NISSIN) (11CLP-14S)	Caliper assy - L. RR. (NISSIN) (11CLP-14S)
15	43232-SD2-931	O-ring	O-ring
16	43233-SD2-931	Piston comp - SLEEVE	Piston comp - SLEEVE
17	43234-SD2-931	Cover - DUST	Cover - DUST
17	43234-S04-003	Cover - DUST	Cover - DUST
18	43235-SD2-931	Pin a	Pin a
19	43236-SD2-931	Spacer	Spacer
19	43236-S04-003	Spacer	Spacer
20	43238-SG0-003	Ring - RETAINING	Ring - RETAINING
21	43241-SG0-003	Guide - SPRING	Guide - SPRING
22	43242-SD2-933	Cover - SHAFT	Cover - SHAFT
23	43243-SD2-931	Nut - PARKING	Nut - PARKING
24	43244-SG0-003	Retainer	Retainer
25	43245-SE0-931	Lever	Lever
26	43246-SE0-931	Spring - R. RETURN	Spring - R. RETURN
27	43247-SE0-931	Arm - R.	Arm - R.
28	43248-SD2-933	Shaft b	Shaft b
29	43249-SG0-003	Bolt - ADJUSTING (###)	Bolt - ADJUSTING (###)
30	43262-SD2-931	Pin b	Pin b
30	43262-S84-A51	Pin b	Pin b
31	43266-SE0-931	Spring - L. RETURN	Spring - L. RETURN
32	43267-SE0-931	Arm - L.	Arm - L.
33	43352-692-003	Screw - BLEEDER	Screw - BLEEDER
34	43353-SA0-003	Cap - BLEEDER SCREW	Cap - BLEEDER SCREW
34	43353-SD5-003	Cap - BLEEDER SCREW	Cap - BLEEDER SCREW
35	45240-SC2-003	Bolt - FLANGE, 8X22	Bolt - FLANGE, 8X22

Rear lower arm/ rear stabilizer 33 / 46

#	OEM	KA3	KA4
3	52306-SE0-030	Link - RR. STABILIZER	Link - RR. STABILIZER
4	52308-SE0-000	Bracket - RR. STABILIZER BUSH	Bracket - RR. STABILIZER BUSH
5	52309-SE0-000	Washer - RR. STABILIZER END	Washer - RR. STABILIZER END
6	52310-SE0-003	Shaft - STABILIZER LINK	Shaft - STABILIZER LINK
7	52312-SE0-000	Collar - STABILIZER INNER BUSH END	Collar - STABILIZER INNER BUSH END
9	52316-SA5-000	Bush - STABILIZER END	Bush - STABILIZER END
10	52317-SE0-000	Bracket - R. RR. STABILIZER BUSH	Bracket - R. RR. STABILIZER BUSH
11	52318-SE0-000	Bracket - L. RR. STABILIZER BUSH	Bracket - L. RR. STABILIZER BUSH
12	52350-SG0-040	Arm comp. a - R. RR. LOWER	Arm comp. a - R. RR. LOWER
13	52355-SG0-040	Arm comp. b - RR. LOWER	Arm comp. b - RR. LOWER
14	52360-SG0-020	Arm comp. a - L. RR. LOWER	Arm comp. a - L. RR. LOWER
15	52364-634-020	Washer - LOWER ARM	Washer - LOWER ARM
16	52365-SE0-003	Bush - RR. LOWER ARM (SUMITOMO)	Bush - RR. LOWER ARM (SUMITOMO)
16	52365-SE0-004	Bush - RR. LOWER ARM (HOKUSHIN)	Bush - RR. LOWER ARM (HOKUSHIN)
17	52365-SG0-020	Bush comp - RR. LOWER ARM	Bush comp - RR. LOWER ARM
18	52366-SG0-000	Bolt - KNUCKLE	Bolt - KNUCKLE
22	52387-SE0-023	Bolt - LOWER ARM ADJUSTING	Bolt - LOWER ARM ADJUSTING
23	52388-SE0-030	Plate - CAM	Plate - CAM
27	90022-SE0-010	Bolt - TRAILING BRACKET, 12X60	Bolt - TRAILING BRACKET, 12X60
27	90173-SM4-000	Bolt - FLANGE, 12X60	Bolt - FLANGE, 12X60
28	90023-SE0-020	Bolt - TRAILING BRACKET, 12X30	Bolt - TRAILING BRACKET, 12X30
29	90028-SE0-000	Bolt - TRAILING ARM, 8X16	Bolt - TRAILING ARM, 8X16
30	90115-659-003	Nut - SELF-LOCK, 8MM (CLINCH)	Nut - SELF-LOCK, 8MM (CLINCH)
31	90119-SM4-003	Bolt - RR. LOWER ARM, 12X66	Bolt - RR. LOWER ARM, 12X66
33	90176-SM4-000	Bolt - FLANGE, 12X95	Bolt - FLANGE, 12X95
34	90212-SA7-010	Nut - SELF-LOCK, 10MM	Nut - SELF-LOCK, 10MM
35	90215-SB0-003	Nut - SELF-LOCK, 12MM (SATO RASHI) (CLINCH)	Nut - SELF-LOCK, 12MM (SATO RASHI) (CLINCH)
36	90216-SE0-010	Nut	Nut
36	90216-SE0-305	NUT, LWR ARM	NUT, LWR ARM
37	90362-SG0-013	Nut - TRAILING ARM, 12MM	Nut - TRAILING ARM, 12MM
37	90215-SMA-003	Nut	Nut
38	90438-SE0-000	Washer - TRAILING, 12MM	Washer - TRAILING, 12MM
40	91613-SE0-003	Grommet - SUB FRAME, 15MM	Grommet - SUB FRAME, 15MM

Rear seat 2 / 4

#	OEM	KA3	KA4
1	78113-SB0-003	Rubber - RR. CUSHION SETTING (TS TECH)	Rubber - RR. CUSHION SETTING (TS TECH)
15	90003-692-000	Bolt - FLANGE, 6X16	Bolt - FLANGE, 6X16

Rear shock absorber 14 / 17

#	OEM	KA3	KA4
3	52611-SD4-Z03	Absorber unit - RR. SHOCK (SHOWA)	Absorber unit - RR. SHOCK (SHOWA)
5	52621-SB2-004	Washer - RR. SHOCK ABSORBER MOUNTING (SHOWA)	Washer - RR. SHOCK ABSORBER MOUNTING (SHOWA)
6	52675-SE0-013	Base - RR. SHOCK ABSORBER MOUNTING	Base - RR. SHOCK ABSORBER MOUNTING
7	52676-SE0-003	Seal - RR. SHOCK ABSORBER MOUNTING	Seal - RR. SHOCK ABSORBER MOUNTING
8	52686-SG0-004	Rubber - RR. SPRING MOUNTING	Rubber - RR. SPRING MOUNTING
9	52687-SG0-034	Cover comp. - RR. SLEEVE DUST	Cover comp. - RR. SLEEVE DUST
10	52688-SE0-003	Plate - RR. BUMP STOP	Plate - RR. BUMP STOP
11	52690-SG0-000	Plate - BUMP STOP	Plate - BUMP STOP
12	51722-SF1-014	Rubber - BUMP STOPPER (POLYURETHAN KASEI)	Rubber - BUMP STOPPER (POLYURETHAN KASEI)
13	52725-SB2-003	Rubber - RR. SHOCK ABSORBER MOUNTING (YAMASHITA)	Rubber - RR. SHOCK ABSORBER MOUNTING (YAMASHITA)
14	52728-SB2-004	Collar - RR. SHOCK ABSORBER MOUNTING(SHOWA)	Collar - RR. SHOCK ABSORBER MOUNTING(SHOWA)
15	52748-SE0-000	Rubber - RR. SPRING SEAT	Rubber - RR. SPRING SEAT
16	90021-SE0-000	Bolt - SHOCK ABSORBER, 10X64	Bolt - SHOCK ABSORBER, 10X64
17	90364-SG0-004	Nut - SELF-LOCK, 10MM (SHOWA) (NYLON)	Nut - SELF-LOCK, 10MM (SHOWA) (NYLON)

Rear side lining 1 / 14

#	OEM	KA3	KA4
20	90102-SA4-000	Screw - TAPPING, 4X16	Screw - TAPPING, 4X16

Rear tray/ trunk side garnish 9 / 15

#	OEM	KA3	KA4
3	66856-SA0-660	Lock - FUSE PANEL	Lock - FUSE PANEL
4	66857-SA0-660	Spring - FUSE PANEL	Spring - FUSE PANEL
5	74825-692-000	Nut - SPIRE	Nut - SPIRE
7	83863-SA4-000	Cap - TIRE LID	Cap - TIRE LID
10	84509-SD4-000	Seal - RR. TRAY	Seal - RR. TRAY
21	90163-SA5-000	Screw-washer - 4X16	Screw-washer - 4X16
22	90662-693-003	Grommet - SCREW, 4MM (BLUE)	Grommet - SCREW, 4MM (BLUE)
24	90667-693-920	Clip - ROOF SIDE	Clip - ROOF SIDE
27	90681-693-000	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM

Regulator/ lock up valve 29 / 29

#	OEM	KA3	KA4
1	25155-PL5-010	Shaft assy - STATOR	Shaft assy - STATOR
2	27200-PL5-E00	Regulator assy	Regulator assy
3	27221-PC9-000	Valve - REGULATOR	Valve - REGULATOR
4	27231-PL5-004	Spring a - REGULATOR VALVE	Spring a - REGULATOR VALVE
5	27232-PF4-000	Spring b - REGULATOR VALVE	Spring b - REGULATOR VALVE
6	27233-PA9-000	Spring - REACTION STATOR	Spring - REACTION STATOR
7	27246-PN6-800	Cap - REGULATOR SPRING	Cap - REGULATOR SPRING
8	27256-PA9-000	Valve - RELIEF	Valve - RELIEF
9	27258-680-900	Seat - RELIEF VALVE SPRING	Seat - RELIEF VALVE SPRING
10	27259-PL5-000	Spring - COOLER CHECK VALVE	Spring - COOLER CHECK VALVE
11	27610-PL5-010	Body comp - LOCK UP VALVE	Body comp - LOCK UP VALVE
12	27612-PL5-010	Plate - LOCK UP SEPARATING	Plate - LOCK UP SEPARATING
13	27621-PL5-010	Valve - LOCK UP SHIFT	Valve - LOCK UP SHIFT
14	27623-PL5-000	Spring - LOCK UP SHIFT VALVE	Spring - LOCK UP SHIFT VALVE
15	27626-PL5-000	Valve b - LOCK UP TIMING	Valve b - LOCK UP TIMING
16	27627-PL5-000	Spring b - LOCK UP TIMING	Spring b - LOCK UP TIMING
17	27645-PL5-000	Cap - LOCK UP CONTROL	Cap - LOCK UP CONTROL
18	27646-PL5-010	Sleeve - LOCK UP CONTROL	Sleeve - LOCK UP CONTROL
19	27728-PF4-000	Cap - REVERSE CONTROL VALVE	Cap - REVERSE CONTROL VALVE
20	90001-PL5-000	Bolt - FLANGE, 6X93	Bolt - FLANGE, 6X93
21	90004-PC9-000	Bolt - FLANGE, 6X90	Bolt - FLANGE, 6X90
22	90009-PC9-810	Bolt - FLANGE, 6X103	Bolt - FLANGE, 6X103
23	90024-612-000	Bolt - SEALING, 8MM	Bolt - SEALING, 8MM
24	90089-PC9-000	Bolt - STOPPER, 6MM	Bolt - STOPPER, 6MM
25	90471-580-000	Packing - 8MM	Packing - 8MM
26	90701-639-000	Dowel pin - 8X55	Dowel pin - 8X55
27	91101-PF4-003	Roller - 3.5X21.8	Roller - 3.5X21.8
28	91102-PF4-000	Roller - 3.5X19.8	Roller - 3.5X19.8
29	91316-PF4-003	O-ring - 31X1.7 (ARAI)	O-ring - 31X1.7 (ARAI)

Resonator chamber 19 / 19

#	OEM	KA3	KA4
1	16137-657-670	Joint - THREE WAY	Joint - THREE WAY
2	17212-PE2-000	Rubber a - AIR CLEANER CASE MOUNTING	Rubber a - AIR CLEANER CASE MOUNTING
3	17231-PL2-000	Chamber comp - RESONATOR	Chamber comp - RESONATOR
4	17233-PL2-300	Joint comp - RESONATOR	Joint comp - RESONATOR
5	17237-PL2-003	Diaphragm comp - VALVE CONTROL	Diaphragm comp - VALVE CONTROL
6	17239-PL2-000	Pipe comp - RESONATOR CONTROL	Pipe comp - RESONATOR CONTROL
7	17249-PH7-000	Screen comp. - RESONATOR	Screen comp. - RESONATOR
8	17255-PL2-000	Collar - RESONATOR	Collar - RESONATOR
9	17256-PL2-000	Stay - SOLENOID VALVE	Stay - SOLENOID VALVE
10	17258-PL2-003	Clip - RESONATOR CONTROL PIPE	Clip - RESONATOR CONTROL PIPE
11	17259-PL2-000	Pipe - ELBOW	Pipe - ELBOW
12	36138-PL2-003	Filter assy - SOLENOID VALVE	Filter assy - SOLENOID VALVE
13	36145-PA6-661	Valve - CHECK	Valve - CHECK
13	36145-PM4-004	Valve - CHECK	Valve - CHECK
14	36270-PL2-003	Valve assy. - RESONATOR CONTROL SOLENOID	Valve assy. - RESONATOR CONTROL SOLENOID
15	36625-PC6-003	Tank comp. - VACUUM	Tank comp. - VACUUM
16	36626-PL2-000	Stay - VACUUM TANK	Stay - VACUUM TANK
17	90010-PL2-000	Bolt-washer - 6X28	Bolt-washer - 6X28
18	90011-PL2-000	Screw-washer - 5X8	Screw-washer - 5X8

Roof lining 1 / 2

#	OEM	KA3	KA4
5	90672-671-003	Clip - TRIM	Clip - TRIM

Secondary body 29 / 29

#	OEM	KA3	KA4
1	27263-PA9-000	Seat Valve Sping 1.0mm - VALVE SPRING, 1.0MM	Seat Valve Sping 1.0mm - VALVE SPRING, 1.0MM
2	27415-PC9-010	Valve - ORIFICE CONTROL	Valve - ORIFICE CONTROL
3	27415-PL5-Z00	Valve - FOURTH ORIFICE CONTROL	Valve - FOURTH ORIFICE CONTROL
4	27415-PL5-000	Valve - SECOND ORIFICE CONTROL	Valve - SECOND ORIFICE CONTROL
5	27417-PL5-000	Spring - SECOND ORIFICE CONTROL VALVE	Spring - SECOND ORIFICE CONTROL VALVE
7	27543-PL5-J11	Cap - SHIFT (3-4)	Cap - SHIFT (3-4)
8	27544-PL5-Z01	Seat - SHIFT (3-4)	Seat - SHIFT (3-4)
9	27628-PK4-000	Cap - LOCK UP TIMING	Cap - LOCK UP TIMING
10	27646-PG4-000	Sleeve - 12.5MM	Sleeve - 12.5MM
11	27653-PF4-000	Cap - CLUTCH PRESSURE CONTROL VALVE	Cap - CLUTCH PRESSURE CONTROL VALVE
12	27653-PL5-J00	Cap - MODULATOR VALVE	Cap - MODULATOR VALVE
13	27655-PC9-950	Valve - CLUTCH PRESSURE CONTROL	Valve - CLUTCH PRESSURE CONTROL
14	27656-PC9-000	Spring a - CLUTCH PRESSURE CONTROL VALVE	Spring a - CLUTCH PRESSURE CONTROL VALVE
14	27657-PC9-000	Spring b - CLUTCH PRESSURE CONTROL VALVE	Spring b - CLUTCH PRESSURE CONTROL VALVE
15	27656-PC9-950	Spring a - CLUTCH PRESSURE CONTROL VALVE (5.6-5.7)	Spring a - CLUTCH PRESSURE CONTROL VALVE (5.6-5.7)
15	27657-PC9-950	Spring b - CLUTCH PRESSURE CONTROL VALVE (5.5-5.6)	Spring b - CLUTCH PRESSURE CONTROL VALVE (5.5-5.6)
16	27700-PL5-Z10	Body assy - SECONDARY	Body assy - SECONDARY
17	27711-PL5-Z10	Body - SECONDARY	Body - SECONDARY
18	27712-PL5-J11	Plate - SECONDARY SEPARATING	Plate - SECONDARY SEPARATING
19	27750-PL5-J01	Filter - SECONDARY BODY	Filter - SECONDARY BODY
20	27721-PL5-Z01	Valve - KICK DOWN (4-3)	Valve - KICK DOWN (4-3)
21	27722-PL5-Z00	Spring - KICK DOWN VALVE (4-3) (###)	Spring - KICK DOWN VALVE (4-3) (###)
22	27724-PG4-000	Cap - KICK DOWN VALVE	Cap - KICK DOWN VALVE
23	27731-PL5-Z10	Valve - SERVO CONTROL (###)	Valve - SERVO CONTROL (###)
24	27732-PL5-Z10	Spring - SERVO CONTROL VALVE (###)	Spring - SERVO CONTROL VALVE (###)
25	27417-PL5-Z00	Spring - FOURTH ORIFICE CONTROL VALVE	Spring - FOURTH ORIFICE CONTROL VALVE
26	27753-PL5-J00	Spring - ORIFICE CONTROL (2-1)	Spring - ORIFICE CONTROL (2-1)
27	91101-PF4-003	Roller - 3.5X21.8	Roller - 3.5X21.8
28	91704-PF4-000	Dowel pin - 8X40	Dowel pin - 8X40

Select lever (LH) 20 / 27

#	OEM	KA3	KA4
1	30158-700-010	E-clip - 3MM	E-clip - 3MM
2	35505-692-003	Bulb - 14V 1.4W	Bulb - 14V 1.4W
3	35700-SD4-A02	Switch assy - INHIBITOR & BACK UP LIGHT	Switch assy - INHIBITOR & BACK UP LIGHT
6	37700-SD4-981	Lamp assy. - INDICATOR (AT)	Lamp assy. - INDICATOR (AT)
7	54026-SJ4-980	Collar - LOCK PIN	Collar - LOCK PIN
8	54027-SD4-A81	Guide - WIRE HARNESS	Guide - WIRE HARNESS
11	54113-SE0-981	Collar - LOCK PIN	Collar - LOCK PIN
12	54114-SE0-980	Collar - LOCK PIN	Collar - LOCK PIN
13	54117-SB0-980	Spring - LOCK PIN	Spring - LOCK PIN
14	54118-SD4-980	Spring - DETENT	Spring - DETENT
15	54119-SE0-J80	Pin - LOCK	Pin - LOCK
16	54123-SE0-980	Collar - SELECT LEVER	Collar - SELECT LEVER
17	54206-SG0-A80	Outer - SELECT LEVER	Outer - SELECT LEVER
26	54138-SF1-980	Ring - SPRING	Ring - SPRING
27	54142-SA5-980	Bush - GUIDE	Bush - GUIDE
28	54147-SD4-980	Guide - DETENT	Guide - DETENT
30	54211-SG0-A81	Lamp - L. INDICATOR	Lamp - L. INDICATOR
32	54222-SD4-982	Cover - SELECT LEVER	Cover - SELECT LEVER
33	54361-689-981	Pipe - CONTROL WIRE ADJUSTING	Pipe - CONTROL WIRE ADJUSTING
34	54710-SD4-A80	Escutcheon - CONSOLE	Escutcheon - CONSOLE

Select lever control 15 / 16

#	OEM	KA3	KA4
1	35721-SD4-A80	Tube assy - SELECT	Tube assy - SELECT
2	54116-SD4-980	Washer - FLOATING (WHITE)	Washer - FLOATING (WHITE)
3	54121-SD4-980	Rubber - FLOATING (BLACK)	Rubber - FLOATING (BLACK)
4	54201-SG0-A81	Bracket - SELECT LEVER	Bracket - SELECT LEVER
5	54202-SG0-A81	Bracket - CONTROL	Bracket - CONTROL
6	54217-SD4-980	Collar a - FLOATING	Collar a - FLOATING
8	54220-SD4-A80	Plate - FLOATING	Plate - FLOATING
10	54317-SD4-982	Holder - CONTROL WIRE	Holder - CONTROL WIRE
11	54318-SD4-A80	Seal - CONTROL	Seal - CONTROL
12	54363-SE0-980	Pin - CONTROL WIRE ADJUSTER	Pin - CONTROL WIRE ADJUSTER
15	90308-SA0-981	Nut - SELF-LOCK, 6MM	Nut - SELF-LOCK, 6MM
16	90551-SD4-980	Washer - PLAIN, 6MM	Washer - PLAIN, 6MM
17	90651-SB2-003	Clip - WIRE HARNESS, 13MM (GRAY)	Clip - WIRE HARNESS, 13MM (GRAY)
18	90673-SA7-003	Band - TUBE	Band - TUBE
19	90681-693-000	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM

Servo body/modulator 30 / 30

#	OEM	KA3	KA4
1	22743-PG4-000	Pipe - THIRD CLUTCH	Pipe - THIRD CLUTCH
2	22744-PG4-000	Pipe - TOP CLUTCH	Pipe - TOP CLUTCH
3	24271-PL5-Z00	Shaft a - SHIFT FORK	Shaft a - SHIFT FORK
3	24272-PL5-Z00	Shaft b - SHIFT FORK	Shaft b - SHIFT FORK
3	24273-PL5-Z00	Shaft c - SHIFT FORK	Shaft c - SHIFT FORK
4	24530-PN1-000	Sleeve comp. - SERVO DETENT	Sleeve comp. - SERVO DETENT
5	25422-PN6-801	Magnet comp. - TRANSMISSION	Magnet comp. - TRANSMISSION
6	27405-PL5-Z05	Body sub assy. - SERVO	Body sub assy. - SERVO
7	27412-PL5-Z02	Plate - SERVO SEPARATING	Plate - SERVO SEPARATING
8	27413-PL5-Z03	Cover - THROTTLE	Cover - THROTTLE
11	27572-PL5-010	Piston - SECOND ACCUMULATOR	Piston - SECOND ACCUMULATOR
12	27574-PG4-000	Piston - THIRD ACCUMULATOR	Piston - THIRD ACCUMULATOR
13	27576-PL5-Z00	Piston - TOP ACCUMULATOR	Piston - TOP ACCUMULATOR
14	27577-PL5-Z01	Spring - TOP ACCUMULATOR	Spring - TOP ACCUMULATOR
15	27580-PL5-Z01	Cover - ACCUMULATOR	Cover - ACCUMULATOR
17	27582-PG4-040	Spring - SECOND ACCUMULATOR	Spring - SECOND ACCUMULATOR
18	27583-PL5-N00	Spring - THIRD ACCUMULATOR	Spring - THIRD ACCUMULATOR
20	90002-PL5-Z00	Bolt - FLANGE, 6X167	Bolt - FLANGE, 6X167
22	90003-PL5-Z00	Bolt - FLANGE, 6X157	Bolt - FLANGE, 6X157
23	90003-PL5-000	Bolt - FLANGE, 6X110	Bolt - FLANGE, 6X110
24	90004-PC9-000	Bolt - FLANGE, 6X90	Bolt - FLANGE, 6X90
27	90012-PL5-000	Bolt - FLANGE, 6X123	Bolt - FLANGE, 6X123
28	91326-PL5-003	O-ring - 26X2.4(NOK)	O-ring - 26X2.4(NOK)
29	91331-PC9-004	O-ring - 21.2X2.4 (NOK)	O-ring - 21.2X2.4 (NOK)
29	91331-PC9-003	O-ring	O-ring
30	91318-PA9-004	O-ring - 23.5X2.1 (NOK)	O-ring - 23.5X2.1 (NOK)
30	91318-PA9-003	O-ring - 23.5X2.1 (ARAI)	O-ring - 23.5X2.1 (ARAI)
31	91344-PC9-003	O-ring - 29X2.4 (ARAI)	O-ring - 29X2.4 (ARAI)
31	91344-PC9-004	O-ring - 29X2.4 (NOK)	O-ring - 29X2.4 (NOK)
32	91344-580-000	O-ring - 31X2.7 (ARAI)	O-ring - 31X2.7 (ARAI)

Shift fork/fork shaft 6 / 6

#	OEM	KA3	KA4
1	24200-PG2-020	Fork comp - FIFTH GEARSHIFT	Fork comp - FIFTH GEARSHIFT
2	24210-PG2-A13	Fork comp - GEARSHIFT (3-4)	Fork comp - GEARSHIFT (3-4)
3	24220-PG2-A10	Fork comp - GEARSHIFT (1-2)	Fork comp - GEARSHIFT (1-2)
4	24243-PG2-000	Piece - FIFTH & REVERSE SHIFT	Piece - FIFTH & REVERSE SHIFT
5	24261-PG2-A12	Shaft - FORK (1-2)	Shaft - FORK (1-2)
6	24271-PG2-A12	Shaft - FIFTH & REVERSE FORK SHIFT	Shaft - FIFTH & REVERSE FORK SHIFT

Shift rod/shift holder 15 / 16

#	OEM	KA3	KA4
1	24230-PG2-000	Holder comp - REVERSE SHIFT	Holder comp - REVERSE SHIFT
2	24311-PG2-010	Rod - GEARSHIFT	Rod - GEARSHIFT
3	24312-PG2-320	Joint end - CHANGE	Joint end - CHANGE
4	24313-PG2-010	Clip - CHANGE JOINT PIN	Clip - CHANGE JOINT PIN
5	24316-PG2-000	Boot - SHIFT ROD	Boot - SHIFT ROD
6	24351-PG1-000	Shaft - SHIFT PIECE	Shaft - SHIFT PIECE
7	24400-PG2-A11	Holder assy. - CHANGE	Holder assy. - CHANGE
8	24411-PG2-000	Piece - GEARSHIFT	Piece - GEARSHIFT
9	24432-PG2-A11	Interlock comp.	Interlock comp.
10	24440-PG2-A10	Piece comp. - GEARSHIFT	Piece comp. - GEARSHIFT
12	24519-PB6-000	Screw - BALL SPRING SETTING	Screw - BALL SPRING SETTING
13	90028-PB6-010	Bolt - SPECIAL, 6X22.5	Bolt - SPECIAL, 6X22.5
14	90028-PG2-000	Bolt - SPECIAL, 8X53	Bolt - SPECIAL, 8X53
15	90029-PG2-010	Bolt - SPECIAL, 8X27	Bolt - SPECIAL, 8X27
16	90412-679-000	Washer - CONICAL SPRING, 8MM	Washer - CONICAL SPRING, 8MM

Side protector 2 / 16

#	OEM	KA3	KA4
13	75807-671-010	Nut - SIDE PROTECTOR (BLACK)	Nut - SIDE PROTECTOR (BLACK)
14	90114-SE0-000	Screw - TAPPING, 5X20	Screw - TAPPING, 5X20

Sliding roof (1) 1 / 19

#	OEM	KA3	KA4
21	90102-SA4-000	Screw - TAPPING, 4X16	Screw - TAPPING, 4X16

Starter motor (2) 15 / 16

#	OEM	KA3	KA4
1	31200-PH7-006	Motor assy. - STARTER (MITSUBA) (SM-302-19 1.4KW)	Motor assy. - STARTER (MITSUBA) (SM-302-19 1.4KW)
2	31202-PC2-681	Bolt - THROUGH (###)	Bolt - THROUGH (###)
3	31203-PH7-006	Cover - GEAR (MITSUBA)	Cover - GEAR (MITSUBA)
4	31204-PH7-016	Gear assy. - PINION (MITSUBA)	Gear assy. - PINION (MITSUBA)
6	31207-PH3-954	Armature assy - ###	Armature assy - ###
6	31207-PH3-953	Armature comp.	Armature comp.
8	31209-PH7-006	Bracket - RR. UNIT (###)	Bracket - RR. UNIT (###)
9	31210-PH7-016	Switch assy - MAGNETIC	Switch assy - MAGNETIC
10	31211-PC2-006	Ring - SQUARE (MITSUBA)	Ring - SQUARE (MITSUBA)
11	31217-PC2-006	Screw-washer - 4X28 (MITSUBA)	Screw-washer - 4X28 (MITSUBA)
12	31229-PH7-026	Case comp. - FR. (###)	Case comp. - FR. (###)
12	31229-PH7-016	Case comp. - FR.	Case comp. - FR.
14	31251-PD2-026	Tube - LABYRINTH	Tube - LABYRINTH
15	31252-PD2-006	Rubber - BUSH (MITSUBA)	Rubber - BUSH (MITSUBA)
17	31260-PH7-006	Stator set	Stator set

Steering column (LH) 20 / 20

#	OEM	KA3	KA4
1	35453-SD4-003	Switch assy - RISE UP CONTROL	Switch assy - RISE UP CONTROL
2	53200-SD4-A04	Column assy - STEERING	Column assy - STEERING
3	53216-SD4-670	Holder b - STEERING COLUMN	Holder b - STEERING COLUMN
4	53217-SB0-000	Collar - STEERING RETAINER	Collar - STEERING RETAINER
5	53231-SB2-000	Label - IGNITION SWITCH	Label - IGNITION SWITCH
6	53320-SD4-A01	Cover - STEERING JOINT	Cover - STEERING JOINT
8	53323-SF4-003	Joint comp. b - STEERING	Joint comp. b - STEERING
9	53325-SD4-000	Clip A - JOINT COVER	Clip A - JOINT COVER
10	53326-SB0-000	Clip b - JOINT COVER	Clip b - JOINT COVER
11	53332-SD4-A01	Plate - JOINT COVER	Plate - JOINT COVER
14	77352-SD4-000	Blind - COLUMN	Blind - COLUMN
15	77354-SD4-000	Label - TILT STEERING	Label - TILT STEERING
18	77371-SF1-000	Ring - COLUMN COVER	Ring - COLUMN COVER
20	90101-SA4-000	Screw - TAPPING, 4X12	Screw - TAPPING, 4X12
21	90102-SA4-000	Screw - TAPPING, 4X16	Screw - TAPPING, 4X16
22	90135-SB0-003	Bolt - STEERING YOKE, 8X28 (NIPPON SEIKO)	Bolt - STEERING YOKE, 8X28 (NIPPON SEIKO)
23	90313-567-000	Nut - SPEED, 3MM	Nut - SPEED, 3MM
24	90471-SB0-000	Washer - PLAIN, 8MM	Washer - PLAIN, 8MM
25	90511-671-003	Washer - TOOTHED LOCK	Washer - TOOTHED LOCK
26	90676-SE0-003	Clip - JOINT COVER PLATE	Clip - JOINT COVER PLATE

Steering wheel (1) 4 / 5

#	OEM	KA3	KA4
2	53153-SA0-004	Washer - TS TECH	Washer - TS TECH
3	78508-SD4-003	Cord a - HORN (TS TECH)	Cord a - HORN (TS TECH)
7	78531-SD4-003	Emblem - STEERING WHEEL (TS TECH)	Emblem - STEERING WHEEL (TS TECH)
8	90380-SB2-003	Nut - SELF-LOCK (OHASHI)	Nut - SELF-LOCK (OHASHI)

Switch (1) 9 / 11

#	OEM	KA3	KA4
1	35151-SD4-A01	Volume assy - ILLUMINATION CONTROL	Volume assy - ILLUMINATION CONTROL
2	35158-SD4-003	Bulb - 14V 0.84W	Bulb - 14V 0.84W
2	35851-SP1-901	Bulb b - NEO WEDGE(14V 100MA)	Bulb b - NEO WEDGE(14V 100MA)
5	35159-SD4-003	Bulb - 14V 0.56W	Bulb - 14V 0.56W
7	35190-SD4-004	Switch assy - REMOTE CONTROL MIRROR	Switch assy - REMOTE CONTROL MIRROR
9	35500-SD4-G03	Switch assy - RR. DEFOGGER	Switch assy - RR. DEFOGGER
12	35510-SD4-A03	Switch assy - HAZARD (LH)	Switch assy - HAZARD (LH)
26	90101-SA4-000	Screw - TAPPING, 4X12	Screw - TAPPING, 4X12
27	90666-SD4-003	Clip - FITTING	Clip - FITTING

Switch (2) 18 / 23

#	OEM	KA3	KA4
2	35100-SD4-G03	Lock assy - STEERING	Lock assy - STEERING
3	35102-SG0-003	Bolt - BREAK HEAD	Bolt - BREAK HEAD
3	35102-SV4-003	Bolt - BREAK HEAD	Bolt - BREAK HEAD
4	35103-SE3-003	Screw - RECESSED, 3X8	Screw - RECESSED, 3X8
5	35105-SD4-003	Ring - ILLUMINATION	Ring - ILLUMINATION
6	35106-SD4-013	Cover - ILLUMINATION RING	Cover - ILLUMINATION RING
7	35107-SD4-013	Cap - ILLUMINATION RING	Cap - ILLUMINATION RING
12	35130-SD4-A01	Switch comp - STEERING	Switch comp - STEERING
13	35131-SA5-621	Cylinder comp - STEERING	Cylinder comp - STEERING
17	35400-SG0-023	Switch assy - DOOR	Switch assy - DOOR
18	35409-SG0-901	Screw - FLANGE, 6X12	Screw - FLANGE, 6X12
19	35417-SE3-003	Cover - DOOR SWITCH	Cover - DOOR SWITCH
19	35410-692-003	Cover - DOOR SWITCH	Cover - DOOR SWITCH
20	35450-SD4-A02	Switch assy - WIPER (A)	Switch assy - WIPER (A)
21	35505-692-003	Bulb - 14V 1.4W	Bulb - 14V 1.4W
22	53271-SF1-003	Cam - TURN SIGNAL SWITCH CANCEL	Cam - TURN SIGNAL SWITCH CANCEL
25	90674-WA8-003	Band - CABLE, 120MM (BLACK)	Band - CABLE, 120MM (BLACK)
26	90690-SA0-003	Strap - WIRE HARNESS, 25MM (BLACK)	Strap - WIRE HARNESS, 25MM (BLACK)

Taillight 6 / 19

#	OEM	KA3	KA4
20	34908-634-611	Bulb - 12V 21W) (ECE) (STANLEY	Bulb - 12V 21W) (ECE) (STANLEY
21	34909-505-003	Bulb - 12V8W	Bulb - 12V8W
21	34904-634-611	BULB (12V 5W) (ECE) - (12V, 5W) ECE	BULB (12V 5W) (ECE) - (12V, 5W) ECE
23	37540-SE0-Q01	Sensor - STOP LAMP FAILURE	Sensor - STOP LAMP FAILURE
24	37540-SE3-A01	Sensor - STOP LAMP FAILURE	Sensor - STOP LAMP FAILURE
26	90672-SA0-003	Strap - CABLE, 118MM(BLACK)	Strap - CABLE, 118MM(BLACK)

Throttle body 23 / 24

#	OEM	KA3	KA4
1	16016-PH3-005	Screw set	Screw set
2	16075-PE2-005	O-ring - 31.2X1.9	O-ring - 31.2X1.9
3	16111-PL2-005	Diaphragm assy. - DASHPOT	Diaphragm assy. - DASHPOT
4	16119-PH7-005	Binder	Binder
5	16176-PL2-003	Rubber - THROTTLE BODY MOUNTING	Rubber - THROTTLE BODY MOUNTING
6	16400-PL2-Y01	Throttle Body Assy - GH01A	Throttle Body Assy - GH01A
6	16400-PL2-901	Throttle Body Assy - GH01B	Throttle Body Assy - GH01B
7	16411-PL2-010	Stay - THROTTLE WIRE	Stay - THROTTLE WIRE
8	16412-PL2-300	Stay - THROTTLE BODY	Stay - THROTTLE BODY
9	16413-PE2-000	Collar - MOUNTING	Collar - MOUNTING
11	16416-PH7-660	Clamp comp. b - THROTTLE CABLE	Clamp comp. b - THROTTLE CABLE
13	16500-PH7-005	Valve assy. - FAST IDLE (08A)	Valve assy. - FAST IDLE (08A)
13	16500-PL2-901	Valve assy. - FAST IDLE (10A)	Valve assy. - FAST IDLE (10A)
14	17136-PH7-000	Stay comp - BREATHER PIPE	Stay comp - BREATHER PIPE
15	17207-PC6-000	Rubber - AIR CLEANER CASE MOUNTING	Rubber - AIR CLEANER CASE MOUNTING
16	17208-PC6-000	Washer - PLAIN	Washer - PLAIN
17	30168-PL2-000	Cord - CONDENSER EARTH	Cord - CONDENSER EARTH
18	36450-PL2-003	Valve assy. - EIC	Valve assy. - EIC
19	36454-PS4-003	Filter comp - ELECTRONIC AIR CONTROL VALVE (TOYO ROKI)	Filter comp - ELECTRONIC AIR CONTROL VALVE (TOYO ROKI)
20	36455-PR4-A01	Packing - ELECTRONIC AIR CONTROL VALVE (DENSO)	Packing - ELECTRONIC AIR CONTROL VALVE (DENSO)
20	36455-PT3-A01	Packing, ELECTRONIC AIR CONTROL VALVE (DENSO)	Packing, ELECTRONIC AIR CONTROL VALVE (DENSO)
21	36456-PH7-000	Packing - COVER	Packing - COVER
22	91304-PE2-005	O-ring - 15.8X1.9	O-ring - 15.8X1.9

Throttle valve shaft 20 / 20

#	OEM	KA3	KA4
1	24111-PL5-Z01	Fork - REVERSE SHIFT	Fork - REVERSE SHIFT
2	24282-634-000	Bolt - SHAFT FORK SETTING	Bolt - SHAFT FORK SETTING
3	24411-PG4-300	Shaft - CONTROL	Shaft - CONTROL
4	24421-PL5-300	Lever - MANUAL VALVE	Lever - MANUAL VALVE
5	24423-PA9-000	Pin - MANUAL VALVE	Pin - MANUAL VALVE
6	24425-639-000	Roller - MANUAL VALVE	Roller - MANUAL VALVE
7	24532-PN6-003	Lever - PARKING BRAKE	Lever - PARKING BRAKE
8	24535-PG4-000	Spring - PARKING BRAKE	Spring - PARKING BRAKE
9	24537-PA9-003	Stopper - PARKING BRAKE (1)	Stopper - PARKING BRAKE (1)
9	24539-PA9-003	Stopper - PARKING BRAKE (3)	Stopper - PARKING BRAKE (3)
9	24538-PA9-003	Stopper - PARKING BRAKE (2)	Stopper - PARKING BRAKE (2)
10	24552-PL5-J00	Spring - PARKING BRAKE PAWL	Spring - PARKING BRAKE PAWL
11	24553-PN6-000	Roller - PARKING BRAKE	Roller - PARKING BRAKE
12	24555-PN6-000	Pin - ROLLER, 6MM	Pin - ROLLER, 6MM
13	24561-PL5-010	Pawl - PARKING BRAKE	Pawl - PARKING BRAKE
14	24562-PL5-J00	Shaft - PARKING BRAKE	Shaft - PARKING BRAKE
15	27490-PL5-J00	Shaft comp. - THROTTLE VALVE	Shaft comp. - THROTTLE VALVE
16	90433-639-000	Washer - LOCK, 6MM	Washer - LOCK, 6MM
17	90607-081-000	Circlip - 7MM	Circlip - 7MM
18	90701-639-000	Dowel pin - 8X55	Dowel pin - 8X55

Tie rod 16 / 16

#	OEM	KA3	KA4
1	53411-SD4-952	Tube - AIR TRANSFER	Tube - AIR TRANSFER
2	53434-SD9-000	Clip - TIE ROD	Clip - TIE ROD
2	53434-S04-J51	CLIP, TIE ROD	CLIP, TIE ROD
3	53448-SB0-950	Clip - TRANSFER TUBE	Clip - TRANSFER TUBE
4	53449-SE0-000	Band - BELLOWS	Band - BELLOWS
5	53459-SD4-670	Stay - TRANSFER TUBE	Stay - TRANSFER TUBE
6	53521-SD4-023	End comp - FR. RACK	End comp - FR. RACK
7	53534-SD4-000	Dust seal comp. - TIE ROD	Dust seal comp. - TIE ROD
8	53534-SD4-950	Dust seal comp. - TIE ROD	Dust seal comp. - TIE ROD
9	53535-SB3-010	Washer - TIE ROD STOPPER	Washer - TIE ROD STOPPER
10	53536-SB2-000	Washer - TIE ROD LOCK	Washer - TIE ROD LOCK
11	53540-SD4-003	End comp - R. TIE ROD	End comp - R. TIE ROD
12	53546-SD4-003	Boot - TIE ROD END (MUSASHI)	Boot - TIE ROD END (MUSASHI)
13	90683-SF1-003	Circlip - FR. UPPER (MUSASHI)	Circlip - FR. UPPER (MUSASHI)
14	53560-SD4-003	End comp - L. TIE ROD	End comp - L. TIE ROD
15	90320-601-000	Nut - CASTLE, 10MM	Nut - CASTLE, 10MM

Timing belt cover 19 / 19

#	OEM	KA3	KA4
1	11810-PH7-010	Cover comp. - TIMING BELT	Cover comp. - TIMING BELT
2	11820-PH7-010	Cover comp. - FR. TIMING BELT UPPER	Cover comp. - FR. TIMING BELT UPPER
3	11825-PH7-000	Grommet - TIMING BELT COVER HOLE	Grommet - TIMING BELT COVER HOLE
4	11830-PH7-000	Cover comp. - RR. TIMING BELT UPPER	Cover comp. - RR. TIMING BELT UPPER
5	11841-PH7-000	Packing a - TIMING BELT COVER	Packing a - TIMING BELT COVER
6	11843-PH7-000	Packing - FR. TIMING BELT UPPER COVER	Packing - FR. TIMING BELT UPPER COVER
7	11844-PH7-000	Packing - RR. TIMING BELT UPPER COVER	Packing - RR. TIMING BELT UPPER COVER
8	11845-PH7-000	Packing - RR. TIMING BELT BACK PLATE	Packing - RR. TIMING BELT BACK PLATE
9	11846-PH7-000	Packing - TIMING BELT PLATE	Packing - TIMING BELT PLATE
10	11847-PH7-000	Packing - FR. TIMING BELT PLATE	Packing - FR. TIMING BELT PLATE
11	11848-PH7-010	Packing - FR. TIMING BELT BACK PLATE	Packing - FR. TIMING BELT BACK PLATE
12	11849-PH7-000	Packing - RR. TIMING BELT PLATE	Packing - RR. TIMING BELT PLATE
13	11860-PH7-020	Plate - FR. TIMING BELT COVER	Plate - FR. TIMING BELT COVER
14	11870-PH7-000	Plate - RR. TIMING BELT COVER	Plate - RR. TIMING BELT COVER
15	32119-PH7-000	Clamp a - ENGINE WIRE HARNESS	Clamp a - ENGINE WIRE HARNESS
16	32125-PH7-000	Clamp b - ENGINE WIRE HARNESS	Clamp b - ENGINE WIRE HARNESS
17	90047-PH7-000	Bolt-washer - 6X22	Bolt-washer - 6X22
18	90423-PH7-000	Rubber - TIMING BELT PLATE MOUNTING	Rubber - TIMING BELT PLATE MOUNTING
19	91312-PH7-000	O-ring - 8.8X1.5	O-ring - 8.8X1.5

Tire/wheel disk 7 / 34

#	OEM	KA3	KA4
1	42700-SD4-681	Disk - WHEEL (15X5 1/2JJ) (KANAI)(FROSTED BLACK)	Disk - WHEEL (15X5 1/2JJ) (KANAI)(FROSTED BLACK)
6	42753-SE0-A02	Valve - RIM (SCHRADER)	Valve - RIM (SCHRADER)
6	42753-SB8-661	Valve - RIM (SCHRADER)	Valve - RIM (SCHRADER)
6	42753-671-003	Valve - RIM (TAIHEIYO)	Valve - RIM (TAIHEIYO)
11	74654-SE0-A00	Bolt - ANCHOR	Bolt - ANCHOR
12	74665-SE0-A00	Adapter - ANCHOR BOLT	Adapter - ANCHOR BOLT
13	90304-SA5-013	Nut - WHEEL (CHROME PLATED) (FUSE RASHI)	Nut - WHEEL (CHROME PLATED) (FUSE RASHI)

Tools/jack 5 / 10

#	OEM	KA3	KA4
3	84650-SD4-003	Jack assy - PANTOGRAPH	Jack assy - PANTOGRAPH
7	89216-SJ6-000	Wrench - SPARK PLUG	Wrench - SPARK PLUG
10	89600-SE3-Y01	Extinguisher - FIRE	Extinguisher - FIRE
12	90156-SE3-003	Blind - FASTENER	Blind - FASTENER
13	90676-SA7-003	Grommet - SCREW, 5MM (BLACK)	Grommet - SCREW, 5MM (BLACK)

Torque converter 6 / 6

#	OEM	KA3	KA4
1	21350-PH7-010	Cover - CLUTCH CASE	Cover - CLUTCH CASE
2	26000-PL5-J01	Converter assy - TORQUE	Converter assy - TORQUE
3	26251-PH7-010	Plate - DRIVE	Plate - DRIVE
4	90023-PA9-000	Bolt - SPECIAL	Bolt - SPECIAL
5	90429-PC6-900	Washer - 40X86X2	Washer - 40X86X2
6	91302-639-000	O-ring - 32X1.9	O-ring - 32X1.9

Torque converter housing 19 / 19

#	OEM	KA3	KA4
1	21110-PL5-050	Case comp. - TORQUE CONVERTER	Case comp. - TORQUE CONVERTER
2	21220-PL5-Z00	Plate comp - BAFFLE	Plate comp - BAFFLE
3	23225-PF0-850	Plate - OIL GUIDE	Plate - OIL GUIDE
4	25420-PL5-000	Strainer - TRANSMISSION	Strainer - TRANSMISSION
5	28200-PL5-033	Solenoid assy. - SHIFT	Solenoid assy. - SHIFT
6	28220-PL5-003	Filter assy - SHIFT SOLENOID	Filter assy - SHIFT SOLENOID
7	28300-PL5-033	Solenoid assy. - LOCK UP	Solenoid assy. - LOCK UP
8	28320-PL5-003	Filter assy - LOCK UP SOLENOID	Filter assy - LOCK UP SOLENOID
9	90024-612-000	Bolt - SEALING, 8MM	Bolt - SEALING, 8MM
10	90471-580-000	Packing - 8MM	Packing - 8MM
11	90705-PA9-000	Dowel pin - 14X25	Dowel pin - 14X25
12	90705-PF4-000	Dowel pin - 14X20	Dowel pin - 14X20
13	91001-591-004	Bearing - BALL, 16008 (KOYO)	Bearing - BALL, 16008 (KOYO)
13	91001-PX4-004	Bearing - BALL, 40X68X9 (KOYO)	Bearing - BALL, 40X68X9 (KOYO)
14	91102-PL5-003	Bearing - NEEDLE, 38.5X67X19	Bearing - NEEDLE, 38.5X67X19
15	91206-PG2-005	Oil seal - 40X56X9 (NOK)	Oil seal - 40X56X9 (NOK)
16	91207-PG4-005	Oil seal - 44X68X8	Oil seal - 44X68X8
17	91209-612-000	Oil seal - 12X22X7	Oil seal - 12X22X7
17	91209-612-003	Oil seal - 12X22X7 (ARAI)	Oil seal - 12X22X7 (ARAI)

Transmission housing 78 / 79

#	OEM	KA3	KA4
1	21104-PG1-770	Plate m - OIL GUIDE	Plate m - OIL GUIDE
1	21211-PL5-A00	Case - TRANSMISSION	Case - TRANSMISSION
2	21200-PG2-A10	Case comp. - TRANSMISSION	Case comp. - TRANSMISSION
2	21215-PG4-010	Holder - REVERSE IDLE SHAFT	Holder - REVERSE IDLE SHAFT
3	21232-PG2-030	Hanger - TRANSMISSION	Hanger - TRANSMISSION
3	21232-PL5-000	Hanger - TRANSMISSION	Hanger - TRANSMISSION
4	21320-PG2-A10	Tube assy - BREATHER	Tube assy - BREATHER
4	21233-PL5-010	Stay - SOLENOID HARNESS CLAMP	Stay - SOLENOID HARNESS CLAMP
5	21321-689-000	Plug - BREATHER TUBE	Plug - BREATHER TUBE
5	21396-611-010	Cap - BREATHER	Cap - BREATHER
6	23970-PK5-000	Shim ad - 78MM (2.07)	Shim ad - 78MM (2.07)
6	23955-PK5-000	Shim o - 78MM (1.62)	Shim o - 78MM (1.62)
6	23966-PK5-000	Shim z - 78MM (1.95)	Shim z - 78MM (1.95)
6	23950-PK5-000	Shim j - 78MM (1.47)	Shim j - 78MM (1.47)
6	23976-PK5-000	Shim aj - 78MM (2.25)	Shim aj - 78MM (2.25)
6	23961-PK5-000	Shim u - 78MM (1.80)	Shim u - 78MM (1.80)
6	23945-PK5-000	Shim e - 78MM (1.32)	Shim e - 78MM (1.32)
6	23943-PK5-000	Shim c - 78MM (1.26)	Shim c - 78MM (1.26)
6	23971-PK5-000	Shim ae - 78MM (2.10)	Shim ae - 78MM (2.10)
6	23956-PK5-000	Shim p - 78MM (1.65)	Shim p - 78MM (1.65)
6	23967-PK5-000	Shim aa - 78MM (1.98)	Shim aa - 78MM (1.98)
6	23951-PK5-000	Shim k - 78MM (1.50)	Shim k - 78MM (1.50)
6	23977-PK5-000	Shim ak - 78MM (2.28)	Shim ak - 78MM (2.28)
6	23962-PK5-000	Shim v - 78MM (1.83)	Shim v - 78MM (1.83)
6	23946-PK5-000	Shim f - 78MM (1.35)	Shim f - 78MM (1.35)
6	23972-PK5-000	Shim af - 78MM (2.13)	Shim af - 78MM (2.13)
6	23957-PK5-000	Shim q - 78MM (1.68)	Shim q - 78MM (1.68)
6	23942-PK5-000	Shim b - 78MM (1.23)	Shim b - 78MM (1.23)
6	23952-PK5-000	Shim l - 78MM (1.53)	Shim l - 78MM (1.53)
6	23968-PK5-000	Shim ab - 78MM (2.01)	Shim ab - 78MM (2.01)
6	23978-PK5-000	Shim al - 78MM (2.31)	Shim al - 78MM (2.31)
6	23963-PK5-000	Shim w - 78MM (1.86)	Shim w - 78MM (1.86)
6	23947-PK5-000	Shim g - 78MM (1.38)	Shim g - 78MM (1.38)
6	23973-PK5-000	Shim ag - 78MM (2.16)	Shim ag - 78MM (2.16)
6	23958-PK5-000	Shim r - 78MM (1.71)	Shim r - 78MM (1.71)
6	23941-PK5-000	Shim a - 78MM (1.20)	Shim a - 78MM (1.20)
6	23953-PK5-000	Shim m - 78MM (1.56)	Shim m - 78MM (1.56)
6	23969-PK5-000	Shim ac - 78MM (2.04)	Shim ac - 78MM (2.04)
6	23979-PK5-000	Shim am - 78MM (2.34)	Shim am - 78MM (2.34)
6	23964-PK5-000	Shim x - 78MM (1.89)	Shim x - 78MM (1.89)
6	23948-PK5-000	Shim h - 78MM (1.41)	Shim h - 78MM (1.41)
6	23948-P16-000	Shim h - 78MM (1.41)	Shim h - 78MM (1.41)
6	23974-PK5-000	Shim ah - 78MM (2.19)	Shim ah - 78MM (2.19)
6	23959-PK5-000	Shim s - 78MM (1.74)	Shim s - 78MM (1.74)
6	23954-PK5-000	Shim n - 78MM (1.59)	Shim n - 78MM (1.59)
6	23980-PK5-000	Shim an - 78MM (2.37)	Shim an - 78MM (2.37)
6	23965-PK5-000	Shim y - 78MM (1.92)	Shim y - 78MM (1.92)
6	23949-PK5-000	Shim i - 78MM (1.44)	Shim i - 78MM (1.44)
6	23975-PK5-000	Shim ai - 78MM (2.22)	Shim ai - 78MM (2.22)
6	23960-PK5-000	Shim t - 78MM (1.77)	Shim t - 78MM (1.77)
6	23944-PK5-000	Shim d - 78MM (1.29)	Shim d - 78MM (1.29)
6	21397-PG4-010	Joint - BREATHER	Joint - BREATHER
7	24452-PG2-020	Spring - FIFTH & REVERSE STOPPER	Spring - FIFTH & REVERSE STOPPER
7	21811-PL5-S00	Gasket - TORQUE CONVERTER CASE	Gasket - TORQUE CONVERTER CASE
8	24519-PG2-000	Screw - BALL SPRING SETTING	Screw - BALL SPRING SETTING
8	23544-PC9-810	Spring b - IDLE GEAR SHAFT	Spring b - IDLE GEAR SHAFT
9	32745-PG2-A10	Clamp - BACK LIGHT HARNESS	Clamp - BACK LIGHT HARNESS
10	35600-PG2-003	Switch assy - BACK UP LIGHT (TEC)	Switch assy - BACK UP LIGHT (TEC)
10	90007-PC9-811	Bolt - REVERSE HOLDER	Bolt - REVERSE HOLDER
11	35620-PG2-A12	Switch assy - NEUTRAL	Switch assy - NEUTRAL
11	90014-PA9-000	Bolt - FLANGE, 10X55	Bolt - FLANGE, 10X55
12	90012-PG1-000	Bolt - SPECIAL, 10X31.5	Bolt - SPECIAL, 10X31.5
12	90015-PA9-000	Bolt - FLANGE, 10X75	Bolt - FLANGE, 10X75
13	90013-PG1-010	Bolt - SPECIAL, 10X42	Bolt - SPECIAL, 10X42
13	90081-PF4-000	Bolt - PLUG, 14MM	Bolt - PLUG, 14MM
14	90013-PG2-000	Bolt - SPECIAL, 10X52 (SH)	Bolt - SPECIAL, 10X52 (SH)
14	90615-PF4-000	Ring - SNAP, 75MM	Ring - SNAP, 75MM
15	90014-PG2-000	Bolt - SPECIAL, 10X102 (SH)	Bolt - SPECIAL, 10X102 (SH)
15	91002-PG4-003	Bearing - BALL, 26X75X18.2 (SPECIAL)	Bearing - BALL, 26X75X18.2 (SPECIAL)
16	90081-PB6-000	Bolt - PLUG, 14MM	Bolt - PLUG, 14MM
16	91002-PL5-J01	Bearing - SPECIAL BALL, 28X75X18.2	Bearing - SPECIAL BALL, 28X75X18.2
17	90081-PG1-305	Bolt - SEALING, 32MM	Bolt - SEALING, 32MM
17	91201-PA9-004	Oil seal - 9X18X7 (ARAI)	Oil seal - 9X18X7 (ARAI)
17	91201-PA9-003	Oil seal - 9X18X7 (NOK)	Oil seal - 9X18X7 (NOK)
18	90083-PG1-305	Bolt - SEALING, 16MM	Bolt - SEALING, 16MM
19	90401-PG1-000	Washer - DRAIN PLUG, 10MM	Washer - DRAIN PLUG, 10MM
21	91004-PG1-771	Bearing - BALL, 28X78 (TOYO)	Bearing - BALL, 28X78 (TOYO)
22	91206-PG2-005	Oil seal - 40X56X9 (NOK)	Oil seal - 40X56X9 (NOK)

Trunk lid 9 / 18

#	OEM	KA3	KA4
4	73219-693-951	Seal - FUEL LID OPENER (GREEN)	Seal - FUEL LID OPENER (GREEN)
6	83418-SG3-003	Cushion - TRUNK HINGE	Cushion - TRUNK HINGE
9	74862-SD4-013	Striker - TRUNK	Striker - TRUNK
12	74870-SD4-003	Solenoid assy. - TRUNK OPENER	Solenoid assy. - TRUNK OPENER
19	83431-SA4-000	Cushion - FR. TRUNK	Cushion - FR. TRUNK
22	90103-SE3-000	Bolt - SPECIAL, 6MM	Bolt - SPECIAL, 6MM
23	90106-SE3-000	Bolt-washer - 6X12	Bolt-washer - 6X12
26	90684-SD4-003	Clip - FUEL LID OPENER	Clip - FUEL LID OPENER
27	91633-SE0-003	Plug - HOLE, 20MM	Plug - HOLE, 20MM

Vacuum tank/tubing 8 / 8

#	OEM	KA3	KA4
1	16137-PA6-004	Joint - THREE WAY	Joint - THREE WAY
2	17205-PC6-000	Clamp - TUBE, 7.5X2	Clamp - TUBE, 7.5X2
3	17267-PL2-661	Clamp - TUBE, 7.5X3	Clamp - TUBE, 7.5X3
4	17269-PH7-000	Clamp - TUBE (24)(BLACK)	Clamp - TUBE (24)(BLACK)
5	17362-PL2-660	Clamp - TORQUE ROD TUBE	Clamp - TORQUE ROD TUBE
8	36145-PA6-661	Valve - CHECK	Valve - CHECK
8	36145-PM4-004	Valve - CHECK	Valve - CHECK
10	39321-SB0-003	Tank comp. - VACUUM	Tank comp. - VACUUM

Valve/rocker arm (FRONT) 36 / 36

#	OEM	KA3	KA4
1	12206-PH7-300	Bolt - SEALING, 16MM	Bolt - SEALING, 16MM
2	12207-PC6-300	Washer - SEALING, 16MM	Washer - SEALING, 16MM
3	12214-PH7-000	Washer - SEALING, 22MM	Washer - SEALING, 22MM
4	12241-PH7-000	Orifice a - CYLINDER HEAD	Orifice a - CYLINDER HEAD
5	12242-PH7-010	Plug - CYLINDER HEAD OIL	Plug - CYLINDER HEAD OIL
6	12245-PH7-000	Valve - OIL RELIEF	Valve - OIL RELIEF
7	12246-PH7-000	Spring - OIL RELIEF VALVE	Spring - OIL RELIEF VALVE
8	12247-PH7-000	Bolt - SEALING, 18MM	Bolt - SEALING, 18MM
9	12248-PH7-000	Washer - RELIEF VALVE	Washer - RELIEF VALVE
10	14440-PH7-010	Rod comp - PUSH	Rod comp - PUSH
11	14540-PL2-000	Lifter assy - VALVE	Lifter assy - VALVE
12	14621-PL2-000	Arm - IN. ROCKER	Arm - IN. ROCKER
13	14623-PL2-000	Arm comp - ROCKER (EX.-IN.)	Arm comp - ROCKER (EX.-IN.)
14	14625-PL2-000	Arm a - EX. ROCKER	Arm a - EX. ROCKER
15	14626-PL2-000	Arm b - EX. ROCKER	Arm b - EX. ROCKER
16	14628-PH7-010	Guide - ROCKER ARM	Guide - ROCKER ARM
17	14631-PH7-000	Shaft - VALVE ROCKER ARM	Shaft - VALVE ROCKER ARM
18	14653-PH7-000	Washer - ROCKER ARM SHAFT WAVE	Washer - ROCKER ARM SHAFT WAVE
19	14711-PH7-750	Valve - IN.	Valve - IN.
20	14721-PH7-751	Valve - EX.	Valve - EX.
21	14745-PH7-000	Screw - TAPPET ADJUSTING	Screw - TAPPET ADJUSTING
22	14751-PL2-014	Spring - IN. VALVE (GREEN) (CHUO SPRING)	Spring - IN. VALVE (GREEN) (CHUO SPRING)
22	14751-PL2-013	Spring - IN. VALVE (GREEN) (NIPPON HATSUJO)	Spring - IN. VALVE (GREEN) (NIPPON HATSUJO)
23	14761-PL2-751	Spring - EX. VALVE INNER (NIPPON HATSUJO)	Spring - EX. VALVE INNER (NIPPON HATSUJO)
23	14761-PL2-752	Spring - EX. VALVE INNER (CHUO SPRING)	Spring - EX. VALVE INNER (CHUO SPRING)
24	14762-PL2-004	Spring - EX. VALVE OUTER (YELLOW) (CHUO SPRING)	Spring - EX. VALVE OUTER (YELLOW) (CHUO SPRING)
24	14762-PL2-003	Spring - EX. VALVE OUTER (YELLOW) (NIPPON HATSUJO)	Spring - EX. VALVE OUTER (YELLOW) (NIPPON HATSUJO)
25	14765-PH3-000	Retainer - VALVE SPRING	Retainer - VALVE SPRING
26	14775-PH3-013	Seat - VALVE SPRING	Seat - VALVE SPRING
27	14781-PL2-004	Cotter - VALVE (SANKO)	Cotter - VALVE (SANKO)
27	14781-PE0-003	Valve Cotter - (FUJI VALVE)	Valve Cotter - (FUJI VALVE)
28	90081-PH7-000	Bolt - SEALING, 22MM	Bolt - SEALING, 22MM
29	90206-657-000	Nut - TAPPET ADJUSTING	Nut - TAPPET ADJUSTING
30	90701-679-000	Dowel pin - 8X10	Dowel pin - 8X10
31	91308-PH9-000	O-ring - 8.8X1.9	O-ring - 8.8X1.9
31	91302-GE0-000	O-ring (8.8x1.9)	O-ring (8.8x1.9)

Valve/rocker arm (REAR) 36 / 36

#	OEM	KA3	KA4
1	12206-PH7-300	Bolt - SEALING, 16MM	Bolt - SEALING, 16MM
2	12207-PC6-300	Washer - SEALING, 16MM	Washer - SEALING, 16MM
3	12214-PH7-000	Washer - SEALING, 22MM	Washer - SEALING, 22MM
4	12241-PH7-000	Orifice a - CYLINDER HEAD	Orifice a - CYLINDER HEAD
5	12242-PH7-010	Plug - CYLINDER HEAD OIL	Plug - CYLINDER HEAD OIL
6	12245-PH7-000	Valve - OIL RELIEF	Valve - OIL RELIEF
7	12246-PH7-000	Spring - OIL RELIEF VALVE	Spring - OIL RELIEF VALVE
8	12247-PH7-000	Bolt - SEALING, 18MM	Bolt - SEALING, 18MM
9	12248-PH7-000	Washer - RELIEF VALVE	Washer - RELIEF VALVE
10	14440-PH7-010	Rod comp - PUSH	Rod comp - PUSH
11	14540-PL2-000	Lifter assy - VALVE	Lifter assy - VALVE
12	14621-PL2-000	Arm - IN. ROCKER	Arm - IN. ROCKER
13	14623-PL2-000	Arm comp - ROCKER (EX.-IN.)	Arm comp - ROCKER (EX.-IN.)
14	14625-PL2-000	Arm a - EX. ROCKER	Arm a - EX. ROCKER
15	14626-PL2-000	Arm b - EX. ROCKER	Arm b - EX. ROCKER
16	14628-PH7-010	Guide - ROCKER ARM	Guide - ROCKER ARM
17	14631-PH7-000	Shaft - VALVE ROCKER ARM	Shaft - VALVE ROCKER ARM
18	14653-PH7-000	Washer - ROCKER ARM SHAFT WAVE	Washer - ROCKER ARM SHAFT WAVE
19	14711-PH7-750	Valve - IN.	Valve - IN.
20	14721-PH7-751	Valve - EX.	Valve - EX.
21	14745-PH7-000	Screw - TAPPET ADJUSTING	Screw - TAPPET ADJUSTING
22	14751-PL2-014	Spring - IN. VALVE (GREEN) (CHUO SPRING)	Spring - IN. VALVE (GREEN) (CHUO SPRING)
22	14751-PL2-013	Spring - IN. VALVE (GREEN) (NIPPON HATSUJO)	Spring - IN. VALVE (GREEN) (NIPPON HATSUJO)
23	14761-PL2-751	Spring - EX. VALVE INNER (NIPPON HATSUJO)	Spring - EX. VALVE INNER (NIPPON HATSUJO)
23	14761-PL2-752	Spring - EX. VALVE INNER (CHUO SPRING)	Spring - EX. VALVE INNER (CHUO SPRING)
24	14762-PL2-004	Spring - EX. VALVE OUTER (YELLOW) (CHUO SPRING)	Spring - EX. VALVE OUTER (YELLOW) (CHUO SPRING)
24	14762-PL2-003	Spring - EX. VALVE OUTER (YELLOW) (NIPPON HATSUJO)	Spring - EX. VALVE OUTER (YELLOW) (NIPPON HATSUJO)
25	14765-PH3-000	Retainer - VALVE SPRING	Retainer - VALVE SPRING
26	14775-PH3-013	Seat - VALVE SPRING	Seat - VALVE SPRING
27	14781-PL2-004	Cotter - VALVE (SANKO)	Cotter - VALVE (SANKO)
27	14781-PE0-003	Valve Cotter - (FUJI VALVE)	Valve Cotter - (FUJI VALVE)
28	90081-PH7-000	Bolt - SEALING, 22MM	Bolt - SEALING, 22MM
29	90206-657-000	Nut - TAPPET ADJUSTING	Nut - TAPPET ADJUSTING
30	90701-679-000	Dowel pin - 8X10	Dowel pin - 8X10
31	91308-PH9-000	O-ring - 8.8X1.9	O-ring - 8.8X1.9
31	91302-GE0-000	O-ring (8.8x1.9)	O-ring (8.8x1.9)

Water pump 14 / 14

#	OEM	KA3	KA4
1	19200-PH7-003	Pump comp - WATER	Pump comp - WATER
2	19222-PH7-003	O-ring - WATER PUMP	O-ring - WATER PUMP
3	19300-PH7-024	Thermostat - NIPPON THERMOSTAT	Thermostat - NIPPON THERMOSTAT
4	19305-PC6-000	Rubber - THERMOSTAT MOUNTING	Rubber - THERMOSTAT MOUNTING
5	19311-PH7-000	Cover - THERMOSTAT	Cover - THERMOSTAT
6	19312-PL2-000	Clamp a - WATER HOSE (D13.5)	Clamp a - WATER HOSE (D13.5)
7	19410-PL2-000	Passage comp. - WATER	Passage comp. - WATER
8	19505-PL2-000	Pipe - CONNECTING	Pipe - CONNECTING
9	19516-PC1-000	Bolt - BREATHING WATER	Bolt - BREATHING WATER
10	90012-PH3-003	Bolt - TIMING BELT ADJUSTER SPRING (SATO RASHI)	Bolt - TIMING BELT ADJUSTER SPRING (SATO RASHI)
11	91313-PH7-003	O-ring - 28.2X2.4	O-ring - 28.2X2.4
12	91314-PH7-003	O-ring 31.2X4.1 (NOK)	O-ring 31.2X4.1 (NOK)
15	90052-PH7-000	Bolt - FLANGE, 6X22	Bolt - FLANGE, 6X22
17	90049-PH7-000	Bolt - FLANGE, 8X25	Bolt - FLANGE, 8X25

Water valve/water hose 12 / 12

#	OEM	KA3	KA4
1	36145-PA6-661	Valve - CHECK	Valve - CHECK
1	36145-PM4-004	Valve - CHECK	Valve - CHECK
3	79700-SD4-013	Valve assy. - WATER	Valve assy. - WATER
4	79721-SD4-000	Hose - WATER VALVE	Hose - WATER VALVE
5	79725-SD4-A00	Hose - WATER OUTLET	Hose - WATER OUTLET
6	79760-SE0-000	Grommet - HEATER PIPE	Grommet - HEATER PIPE
7	79780-SD4-000	Grommet - VACUUM TUBE	Grommet - VACUUM TUBE
8	79785-SD4-A02	Tube assy - WATER VALVE VACUUM	Tube assy - WATER VALVE VACUUM
9	79788-SD4-A00	Tube c - VACUUM	Tube c - VACUUM
10	91405-PK1-003	Clip, WATER HOSE, 24MM	Clip, WATER HOSE, 24MM
10	19513-PE0-003	Clamp - WATER HOSE (21.7MM) (CHUO SPRING)	Clamp - WATER HOSE (21.7MM) (CHUO SPRING)
11	91553-SD4-A00	Joint - VACUUM TUBE	Joint - VACUUM TUBE

Windshield 7 / 32

#	OEM	KA3	KA4
3	73126-SD4-000	Spacer - FR. WINDSHIELD	Spacer - FR. WINDSHIELD
7	73156-SD4-000	Cap - FR. LOWER MOLDING CLIP	Cap - FR. LOWER MOLDING CLIP
23	90116-SD4-003	Screw - TAPPING, 4X16	Screw - TAPPING, 4X16
25	90654-SD4-003	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
26	90655-SD4-003	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
31	91502-SG0-003	Clip - FR. WINDSHIELD UPPER MOLDING	Clip - FR. WINDSHIELD UPPER MOLDING
32	91505-SG0-003	Clip A - FR. WINDSHIELD UPPER MOLDING (ORANGE)	Clip A - FR. WINDSHIELD UPPER MOLDING (ORANGE)

Windshield washer 25 / 25

#	OEM	KA3	KA4
3	38513-SB0-961	Cap - WASHER MOUTH(MITSUBA)	Cap - WASHER MOUTH(MITSUBA)
3	76802-SS0-003	Cap - MOUTH	Cap - MOUTH
4	38562-663-920	Joint b - WASHER TUBE (MITSUBA)	Joint b - WASHER TUBE (MITSUBA)
5	38571-SA5-621	Valve - ONE WAY (MITSUBA)	Valve - ONE WAY (MITSUBA)
7	75522-611-000	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
8	76801-SD4-023	Washer comp - WINDSHIELD (FR.)	Washer comp - WINDSHIELD (FR.)
10	76804-SE0-003	Float - WASHER	Float - WASHER
11	76805-SD4-003	Hose - WASHER	Hose - WASHER
12	76806-SE0-S01	Motor - WASHER (MITSUBA)	Motor - WASHER (MITSUBA)
14	76807-SE0-921	Packing - T-TYPE	Packing - T-TYPE
16	76809-SE0-003	Grommet - WASHER TANK	Grommet - WASHER TANK
18	76810-SG0-A11	Nozzle - R. WINDSHIELD WASHER	Nozzle - R. WINDSHIELD WASHER
19	76812-SG0-003	Mouth assy. - WASHER	Mouth assy. - WASHER
20	76815-SG0-A11	Nozzle - L. WINDSHIELD WASHER	Nozzle - L. WINDSHIELD WASHER
21	76820-SD4-003	Grommet - WASHER TUBE	Grommet - WASHER TUBE
22	76830-SG0-003	Joint y - TUBE	Joint y - TUBE
22	76830-SG0-023	Joint y - TUBE	Joint y - TUBE
24	76838-SD4-003	Clip - WASHER TUBE	Clip - WASHER TUBE
25	76842-SE0-003	Bush - WASHER TANK (MITSUBA)	Bush - WASHER TANK (MITSUBA)
26	76851-SE1-003	Tube a - RR. WASHER	Tube a - RR. WASHER
28	90130-SE0-000	Screw - TAPPING, 6X16 (DACRO COATING)	Screw - TAPPING, 6X16 (DACRO COATING)
29	90652-SB2-023	Clip - TUBE, 7MM	Clip - TUBE, 7MM
30	91512-SE0-003	Clip - WASHER TUBE	Clip - WASHER TUBE
31	91519-SE0-000	Clip - WASHER TUBE	Clip - WASHER TUBE
32	91619-SA5-000	Grommet - SCREW, 6MM	Grommet - SCREW, 6MM

Wire harness (1) 28 / 40

#	OEM	KA3	KA4
2	32152-SD4-000	Separator - WIRE HARNESS (GRAY)	Separator - WIRE HARNESS (GRAY)
3	32160-SD4-000	Bracket - COUPLER HOLDER	Bracket - COUPLER HOLDER
6	32164-SD4-013	Holder - COUPLER	Holder - COUPLER
7	32410-SD4-J11	Cable assy - STARTER	Cable assy - STARTER
7	32410-SG0-J02	Cable assy - STARTER (SUMITOMO)	Cable assy - STARTER (SUMITOMO)
8	32600-SD4-A02	Cable assy - EARTH (FURUKAWA)	Cable assy - EARTH (FURUKAWA)
8	32600-SD4-A01	Cable assy - EARTH (SUMITOMO)	Cable assy - EARTH (SUMITOMO)
9	32601-SK7-900	Bolt - BATTERY TERMINAL	Bolt - BATTERY TERMINAL
10	32601-SA5-003	Bolt - BATTERY TERMINAL (SUMITOMO)	Bolt - BATTERY TERMINAL (SUMITOMO)
11	32602-SK7-900	Nut - BATTERY TERMINAL	Nut - BATTERY TERMINAL
12	32602-SA5-003	Nut - BATTERY TERMINAL (SUMITOMO)	Nut - BATTERY TERMINAL (SUMITOMO)
17	38211-SD2-000	Fuse - BLOCK (30A)	Fuse - BLOCK (30A)
18	38212-SE0-000	Fuse - BLOCK (40A)	Fuse - BLOCK (40A)
19	38215-SE0-000	Fuse - BLOCK (70A)	Fuse - BLOCK (70A)
21	38245-SD4-J00	Bracket - RELAY BOX	Bracket - RELAY BOX
22	39762-SG0-003	Relay assy - POWER (5P) (DENSO) (056700-8160)	Relay assy - POWER (5P) (DENSO) (056700-8160)
23	39792-SE0-004	Relay assy - POWER (4P) (OMRON) (G4R-1A21T-H22)	Relay assy - POWER (4P) (OMRON) (G4R-1A21T-H22)
23	39792-SE0-003	Relay assy - POWER(4P)(DENSO) (056700-7410)	Relay assy - POWER(4P)(DENSO) (056700-7410)
24	39794-SB0-922	Relay assy - POWER (4P) (OMRON) (G2MS-1121T-100R)	Relay assy - POWER (4P) (OMRON) (G2MS-1121T-100R)
24	39794-SE0-003	Relay assy - POWER(4P)(DENSO) (056700-7250)	Relay assy - POWER(4P)(DENSO) (056700-7250)
24	39794-SE0-004	Relay assy - POWER (4P) (MITSUBA) (RC-2203)	Relay assy - POWER (4P) (MITSUBA) (RC-2203)
27	90114-SG0-003	Bolt - 5X13	Bolt - 5X13
28	90149-SE0-003	Bolt - EARTH, 6X16	Bolt - EARTH, 6X16
29	90153-SA5-900	Screw-washer - 5X9	Screw-washer - 5X9
30	90627-SA5-003	Clip - WIRE HARNESS(BLUE) (HARNESS TAPING)(50MM)	Clip - WIRE HARNESS(BLUE) (HARNESS TAPING)(50MM)
35	90669-SD4-003	Strap - CABLE, 180MM (YELLOW)	Strap - CABLE, 180MM (YELLOW)
39	91588-SD4-004	Grommet - CABIN WIRE HARNESS	Grommet - CABIN WIRE HARNESS
40	91637-SF1-003	Cap - 090 2P	Cap - 090 2P

Wire harness (2) 8 / 23

#	OEM	KA3	KA4
8	90148-SE0-003	Bolt - EARTH, 6X16 (WASHER 12.5MM) (ZN)	Bolt - EARTH, 6X16 (WASHER 12.5MM) (ZN)
10	90650-SD4-003	Clip - WIRE HARNESS	Clip - WIRE HARNESS
12	90672-SA0-003	Strap - CABLE, 118MM(BLACK)	Strap - CABLE, 118MM(BLACK)
14	90681-SA9-600	Clip - JOINT	Clip - JOINT
16	91547-SF4-003	Band - WIRE HARNESS (BLUE) (123.5MM)	Band - WIRE HARNESS (BLUE) (123.5MM)
18	91551-SF4-003	Band - WIRE HARNESS(BROWN) (110MM)	Band - WIRE HARNESS(BROWN) (110MM)
20	91559-SE3-003	Clip - WIRE HARNESS (WHITE) (55MM)	Clip - WIRE HARNESS (WHITE) (55MM)
21	91567-SE0-003	Band - WIRE HARNESS(WHITE) (93.5MM)	Band - WIRE HARNESS(WHITE) (93.5MM)

#	OEM	KA3	KA4
2	04110-SWA-305	BULB T10X318W	BULB T10X318W
1	06164-PH6-000	Packing set - INJECTOR	Packing set - INJECTOR
4	10002-PL2-761	Engine assy - BLOCK	Engine assy - BLOCK
5	10003-PL2-750	General assy. - CYLINDER HEAD	General assy. - CYLINDER HEAD
1	11000-PL2-J00	Block assy - CYLINDER	Block assy - CYLINDER
2	11105-PH3-000	Cap - SEALING, 35MM	Cap - SEALING, 35MM
1	11110-PL2-000	Pipe comp - OIL LEVEL	Pipe comp - OIL LEVEL
3	11116-PH7-000	Orifice - OIL CONTROL	Orifice - OIL CONTROL
4	11126-PK1-003	Bolt - SEALING, 22MM	Bolt - SEALING, 22MM
5	11130-PH7-010	Bridge comp - BEARING CAP	Bridge comp - BEARING CAP
6	11200-PH7-010	Pan comp - OIL	Pan comp - OIL
7	11220-PH7-010	Cover comp. - BEARING CAP	Cover comp. - BEARING CAP
8	11251-PH7-000	Packing - OIL PAN	Packing - OIL PAN
9	11301-PH7-010	Case - OIL SEAL	Case - OIL SEAL
10	11711-PL2-000	Plate comp. a - BREATHER COVER	Plate comp. a - BREATHER COVER
11	11712-PL2-000	Plate comp. b - BREATHER COVER	Plate comp. b - BREATHER COVER
1	11810-PH7-010	Cover comp. - TIMING BELT	Cover comp. - TIMING BELT
2	11820-PH7-010	Cover comp. - FR. TIMING BELT UPPER	Cover comp. - FR. TIMING BELT UPPER
3	11825-PH7-000	Grommet - TIMING BELT COVER HOLE	Grommet - TIMING BELT COVER HOLE
4	11830-PH7-000	Cover comp. - RR. TIMING BELT UPPER	Cover comp. - RR. TIMING BELT UPPER
5	11841-PH7-000	Packing a - TIMING BELT COVER	Packing a - TIMING BELT COVER
6	11843-PH7-000	Packing - FR. TIMING BELT UPPER COVER	Packing - FR. TIMING BELT UPPER COVER
7	11844-PH7-000	Packing - RR. TIMING BELT UPPER COVER	Packing - RR. TIMING BELT UPPER COVER
8	11845-PH7-000	Packing - RR. TIMING BELT BACK PLATE	Packing - RR. TIMING BELT BACK PLATE
9	11846-PH7-000	Packing - TIMING BELT PLATE	Packing - TIMING BELT PLATE
10	11847-PH7-000	Packing - FR. TIMING BELT PLATE	Packing - FR. TIMING BELT PLATE
11	11848-PH7-010	Packing - FR. TIMING BELT BACK PLATE	Packing - FR. TIMING BELT BACK PLATE
12	11849-PH7-000	Packing - RR. TIMING BELT PLATE	Packing - RR. TIMING BELT PLATE
13	11860-PH7-020	Plate - FR. TIMING BELT COVER	Plate - FR. TIMING BELT COVER
14	11870-PH7-000	Plate - RR. TIMING BELT COVER	Plate - RR. TIMING BELT COVER
1	12100-PL2-750	Head assy - FR. CYLINDER	Head assy - FR. CYLINDER
1	12104-PH7-003	Pipe comp - EGR	Pipe comp - EGR
2	12105-PH7-000	Gasket - EGR PIPE	Gasket - EGR PIPE
2	12204-PH7-305	Guide - IN. VALVE	Guide - IN. VALVE
3	12205-PH7-305	Guide - EX. VALVE	Guide - EX. VALVE
4	12206-PH7-300	Bolt - SEALING, 16MM	Bolt - SEALING, 16MM
5	12207-PC6-300	Washer - SEALING, 16MM	Washer - SEALING, 16MM
6	12210-PD2-003	Seal a - VALVE STEM (ARAI)	Seal a - VALVE STEM (ARAI)
6	12210-PD2-004	Seal a - VALVE STEM (NOK)	Seal a - VALVE STEM (NOK)
7	12211-PH7-003	Seal b - VALVE STEM (ARAI)	Seal b - VALVE STEM (ARAI)
7	12211-PH7-004	Seal b - VALVE STEM (NOK)	Seal b - VALVE STEM (NOK)
3	12214-PH7-000	Washer - SEALING, 22MM	Washer - SEALING, 22MM
8	12236-PH7-000	Pipe comp - CAM HOLDER	Pipe comp - CAM HOLDER
4	12241-PH7-000	Orifice a - CYLINDER HEAD	Orifice a - CYLINDER HEAD
5	12242-PH7-010	Plug - CYLINDER HEAD OIL	Plug - CYLINDER HEAD OIL
6	12245-PH7-000	Valve - OIL RELIEF	Valve - OIL RELIEF
7	12246-PH7-000	Spring - OIL RELIEF VALVE	Spring - OIL RELIEF VALVE
8	12247-PH7-000	Bolt - SEALING, 18MM	Bolt - SEALING, 18MM
9	12248-PH7-000	Washer - RELIEF VALVE	Washer - RELIEF VALVE
9	12251-PL2-003	Gasket - CYLINDER HEAD (ISHINO GASKET)	Gasket - CYLINDER HEAD (ISHINO GASKET)
7	12266-PH7-003	Plug - CYLINDER HEAD	Plug - CYLINDER HEAD
8	12300-PL2-750	Head assy - RR. CYLINDER	Head assy - RR. CYLINDER
2	12310-PH7-000	Cover comp. - FR. CYLINDER HEAD	Cover comp. - FR. CYLINDER HEAD
3	12320-PH7-660	Cover assy. - RR. CYLINDER HEAD	Cover assy. - RR. CYLINDER HEAD
10	12331-PH7-003	Cover - CYLINDER HEAD SIDE	Cover - CYLINDER HEAD SIDE
11	12332-PH7-003	Packing - CYLINDER HEAD SIDE COVER	Packing - CYLINDER HEAD SIDE COVER
4	12341-P0G-A00	Packing - CYLINDER HEAD COVER	Packing - CYLINDER HEAD COVER
4	12341-PH7-000	Gasket - CYLINDER HEAD COVER	Gasket - CYLINDER HEAD COVER
5	12415-PH7-003	Packing - BREATHER CHAMBER COVER	Packing - BREATHER CHAMBER COVER
6	12416-PH7-000	Cover comp. - FR. BREATHER CHAMBER	Cover comp. - FR. BREATHER CHAMBER
1	13011-PL2-751	Ring set - PISTON (STD.)	Ring set - PISTON (STD.)
1	13011-PL2-752	Ring set - PISTON (STD.)	Ring set - PISTON (STD.)
1	13021-PL2-751	Ring set - PISTON (OS 0.25)	Ring set - PISTON (OS 0.25)
1	13021-PL2-752	Ring set - PISTON (OS 0.25)	Ring set - PISTON (OS 0.25)
1	13031-PL2-751	Ring set - PISTON (OS 0.50)	Ring set - PISTON (OS 0.50)
1	13031-PL2-752	Ring set - PISTON (OS 0.50)	Ring set - PISTON (OS 0.50)
2	13101-PL2-750	Piston a - STD	Piston a - STD
2	13102-PL2-750	Piston b - STD	Piston b - STD
2	13103-PL2-750	Piston - OS 0.25	Piston - OS 0.25
2	13104-PL2-750	Piston - OS 0.50	Piston - OS 0.50
3	13112-PH7-000	Pin - PISTON	Pin - PISTON
4	13204-PH7-003	Bolt - CONNECTING ROD	Bolt - CONNECTING ROD
4	13204-PY3-013	Bolt - CONNECTING ROD	Bolt - CONNECTING ROD
5	13205-PH7-000	Nut - CONNECTING ROD	Nut - CONNECTING ROD
6	13210-PH7-000	Rod comp - CONNECTING	Rod comp - CONNECTING
7	13211-PH7-013	BEARING A - CONNECTING ROD (BLACK) (DAIDO)	BEARING A - CONNECTING ROD (BLACK) (DAIDO)
7	13211-PH7-014	BEARING A - CONNECTING ROD (BLACK) (TAIHO)	BEARING A - CONNECTING ROD (BLACK) (TAIHO)
7	13212-PH7-013	Bearing b - CONNECTING ROD (BROWN) (DAIDO)	Bearing b - CONNECTING ROD (BROWN) (DAIDO)
7	13212-PH7-014	Bearing b - CONNECTING ROD (BROWN) (TAIHO)	Bearing b - CONNECTING ROD (BROWN) (TAIHO)
7	13213-PH7-013	Bearing c - CONNECTING ROD (GREEN) (DAIDO)	Bearing c - CONNECTING ROD (GREEN) (DAIDO)
7	13213-PH7-014	Bearing c - CONNECTING ROD (GREEN) (TAIHO)	Bearing c - CONNECTING ROD (GREEN) (TAIHO)
7	13214-PH7-013	Bearing d - CONNECTING ROD (YELLOW) (DAIDO)	Bearing d - CONNECTING ROD (YELLOW) (DAIDO)
7	13214-PH7-014	Bearing d - CONNECTING ROD (YELLOW) (TAIHO)	Bearing d - CONNECTING ROD (YELLOW) (TAIHO)
7	13215-PH7-013	Bearing e - CONNECTING ROD (PINK) (DAIDO)	Bearing e - CONNECTING ROD (PINK) (DAIDO)
7	13215-PH7-014	Bearing e - CONNECTING ROD (PINK) (TAIHO)	Bearing e - CONNECTING ROD (PINK) (TAIHO)
1	13310-PL2-010	Crankshaft comp.	Crankshaft comp.
2	13321-PL2-J01	BEARING A - MAIN (BLACK) (DAIDO)	BEARING A - MAIN (BLACK) (DAIDO)
2	13321-PL2-J02	BEARING A - MAIN (BLACK) (TAIHO)	BEARING A - MAIN (BLACK) (TAIHO)
2	13322-PL2-J01	Bearing b - MAIN (BROWN) (DAIDO)	Bearing b - MAIN (BROWN) (DAIDO)
2	13322-PL2-J02	Bearing b - MAIN (BROWN) (TAIHO)	Bearing b - MAIN (BROWN) (TAIHO)
2	13323-PL2-J01	Bearing c - MAIN (GREEN) (DAIDO)	Bearing c - MAIN (GREEN) (DAIDO)
2	13323-PL2-J02	Bearing c - MAIN (GREEN) (TAIHO)	Bearing c - MAIN (GREEN) (TAIHO)
2	13324-PL2-J01	Bearing d - MAIN (YELLOW) (DAIDO)	Bearing d - MAIN (YELLOW) (DAIDO)
2	13324-PL2-J02	Bearing d - MAIN (YELLOW) (TAIHO)	Bearing d - MAIN (YELLOW) (TAIHO)
2	13325-PL2-J01	Bearing e - MAIN (PINK) (DAIDO)	Bearing e - MAIN (PINK) (DAIDO)
2	13325-PL2-J02	Bearing e - MAIN (PINK) (TAIHO)	Bearing e - MAIN (PINK) (TAIHO)
3	13331-PH7-003	Washer - THRUST (DAIDO)	Washer - THRUST (DAIDO)
3	13331-PH7-004	Washer - THRUST (TAIHO)	Washer - THRUST (TAIHO)
4	13341-PL2-J01	BEARING A - MAIN LOWER (BLACK) (DAIDO)	BEARING A - MAIN LOWER (BLACK) (DAIDO)
4	13341-PL2-J02	BEARING A - MAIN LOWER (BLACK) (TAIHO)	BEARING A - MAIN LOWER (BLACK) (TAIHO)
4	13342-PL2-J01	Bearing b - MAIN LOWER (BROWN) (DAIDO)	Bearing b - MAIN LOWER (BROWN) (DAIDO)
4	13342-PL2-J02	Bearing b - MAIN LOWER (BROWN) (TAIHO)	Bearing b - MAIN LOWER (BROWN) (TAIHO)
4	13343-PL2-J01	Bearing c - MAIN LOWER (GREEN) (DAIDO)	Bearing c - MAIN LOWER (GREEN) (DAIDO)
4	13343-PL2-J02	Bearing c - MAIN LOWER (GREEN) (TAIHO)	Bearing c - MAIN LOWER (GREEN) (TAIHO)
4	13344-PL2-J01	Bearing d - MAIN LOWER (YELLOW) (DAIDO)	Bearing d - MAIN LOWER (YELLOW) (DAIDO)
4	13344-PL2-J02	Bearing d - MAIN LOWER (YELLOW) (TAIHO)	Bearing d - MAIN LOWER (YELLOW) (TAIHO)
4	13345-PL2-J01	Bearing e - MAIN LOWER (PINK) (DAIDO)	Bearing e - MAIN LOWER (PINK) (DAIDO)
4	13345-PL2-J02	Bearing e - MAIN LOWER (PINK) (TAIHO)	Bearing e - MAIN LOWER (PINK) (TAIHO)
5	13621-PH7-003	Pulley - TIMING BELT DRIVE	Pulley - TIMING BELT DRIVE
6	13622-PH7-000	Plate - TIMING BELT GUIDE	Plate - TIMING BELT GUIDE
1	14100-PL2-000	Camshaft - FR.	Camshaft - FR.
2	14200-PL2-000	Camshaft - RR.	Camshaft - RR.
3	14260-PL2-003	Pulley - FR. TIMING BELT DRIVEN	Pulley - FR. TIMING BELT DRIVEN
4	14270-PH7-003	Pulley - RR. TIMING BELT DRIVEN	Pulley - RR. TIMING BELT DRIVEN
5	14400-PH7-014	Belt - TIMING (UNITTA)	Belt - TIMING (UNITTA)
10	14440-PH7-010	Rod comp - PUSH	Rod comp - PUSH
6	14510-PH7-003	Adjuster comp - TIMING BELT (KOYO)	Adjuster comp - TIMING BELT (KOYO)
6	14510-PH7-004	Adjuster comp - TIMING BELT (NIPPON SEIKO)	Adjuster comp - TIMING BELT (NIPPON SEIKO)
7	14516-PH7-000	Spring - TIMING BELT ADJUSTER	Spring - TIMING BELT ADJUSTER
11	14540-PL2-000	Lifter assy - VALVE	Lifter assy - VALVE
12	14621-PL2-000	Arm - IN. ROCKER	Arm - IN. ROCKER
13	14623-PL2-000	Arm comp - ROCKER (EX.-IN.)	Arm comp - ROCKER (EX.-IN.)
14	14625-PL2-000	Arm a - EX. ROCKER	Arm a - EX. ROCKER
15	14626-PL2-000	Arm b - EX. ROCKER	Arm b - EX. ROCKER
16	14628-PH7-010	Guide - ROCKER ARM	Guide - ROCKER ARM
17	14631-PH7-000	Shaft - VALVE ROCKER ARM	Shaft - VALVE ROCKER ARM
18	14653-PH7-000	Washer - ROCKER ARM SHAFT WAVE	Washer - ROCKER ARM SHAFT WAVE
19	14711-PH7-750	Valve - IN.	Valve - IN.
20	14721-PH7-751	Valve - EX.	Valve - EX.
21	14745-PH7-000	Screw - TAPPET ADJUSTING	Screw - TAPPET ADJUSTING
22	14751-PL2-013	Spring - IN. VALVE (GREEN) (NIPPON HATSUJO)	Spring - IN. VALVE (GREEN) (NIPPON HATSUJO)
22	14751-PL2-014	Spring - IN. VALVE (GREEN) (CHUO SPRING)	Spring - IN. VALVE (GREEN) (CHUO SPRING)
23	14761-PL2-751	Spring - EX. VALVE INNER (NIPPON HATSUJO)	Spring - EX. VALVE INNER (NIPPON HATSUJO)
23	14761-PL2-752	Spring - EX. VALVE INNER (CHUO SPRING)	Spring - EX. VALVE INNER (CHUO SPRING)
24	14762-PL2-003	Spring - EX. VALVE OUTER (YELLOW) (NIPPON HATSUJO)	Spring - EX. VALVE OUTER (YELLOW) (NIPPON HATSUJO)
24	14762-PL2-004	Spring - EX. VALVE OUTER (YELLOW) (CHUO SPRING)	Spring - EX. VALVE OUTER (YELLOW) (CHUO SPRING)
25	14765-PH3-000	Retainer - VALVE SPRING	Retainer - VALVE SPRING
26	14775-PH3-013	Seat - VALVE SPRING	Seat - VALVE SPRING
27	14781-PE0-003	Valve Cotter - (FUJI VALVE)	Valve Cotter - (FUJI VALVE)
27	14781-PL2-004	Cotter - VALVE (SANKO)	Cotter - VALVE (SANKO)
1	15100-PH6-003	Pump assy. - OIL	Pump assy. - OIL
2	15110-PH6-003	Body - OIL PUMP	Body - OIL PUMP
3	15112-PH7-013	Cover - OIL PUMP	Cover - OIL PUMP
4	15131-PH6-003	Rotor - PUMP INNER	Rotor - PUMP INNER
5	15132-PH6-003	Rotor - PUMP OUTER	Rotor - PUMP OUTER
6	15141-PH7-000	Joint - OIL PASS PIPE	Joint - OIL PASS PIPE
7	15143-PH7-000	Pipe - OIL PASS	Pipe - OIL PASS
8	15220-PH7-000	Strainer comp. - OIL	Strainer comp. - OIL
9	15231-PH7-003	Valve - RELIEF	Valve - RELIEF
10	15232-PH7-013	Spring - RELIEF VALVE	Spring - RELIEF VALVE
11	15233-PC6-000	Bolt - SEALING, 18MM	Bolt - SEALING, 18MM
12	15233-PH7-013	Seat - RELIEF VALVE SPRING	Seat - RELIEF VALVE SPRING
13	15234-PH7-003	O-ring - SPRING SEAT	O-ring - SPRING SEAT
2	15301-PL2-000	Base - OIL FILTER	Base - OIL FILTER
14	15302-PH7-003	Washer - SEALING, 18MM	Washer - SEALING, 18MM
3	15400-PL2-305	Cartridge - OIL FILTER (TOYO ROKI)	Cartridge - OIL FILTER (TOYO ROKI)
3	15400-PL2-306	OIL FILTER (TOYO ROKI)	OIL FILTER (TOYO ROKI)
4	15500-PH7-004	Cooler - ENGINE OIL (DENSO)	Cooler - ENGINE OIL (DENSO)
5	15550-PH7-000	Bolt assy - OIL COOLER CENTER	Bolt assy - OIL COOLER CENTER
7	15610-PC6-000	Cap assy. - OIL FILLER	Cap assy. - OIL FILLER
8	15613-PC6-000	Packing, Oil Filler	Packing, Oil Filler
6	15650-PL2-004	Gauge comp. - OIL LEVEL (ARS)	Gauge comp. - OIL LEVEL (ARS)
7	15705-PL2-000	Tube a - PCV	Tube a - PCV
1	16010-SD4-A50	Strainer set - FUEL	Strainer set - FUEL
1	16016-PH3-005	Screw set	Screw set
2	16075-PE2-005	O-ring - 31.2X1.9	O-ring - 31.2X1.9
3	16111-PL2-005	Diaphragm assy. - DASHPOT	Diaphragm assy. - DASHPOT
4	16119-PH7-005	Binder	Binder
1	16137-657-670	Joint - THREE WAY	Joint - THREE WAY
1	16137-PA6-004	Joint - THREE WAY	Joint - THREE WAY
5	16176-PL2-003	Rubber - THROTTLE BODY MOUNTING	Rubber - THROTTLE BODY MOUNTING
6	16400-PL2-901	Throttle Body Assy - GH01B	Throttle Body Assy - GH01B
6	16400-PL2-Y01	Throttle Body Assy - GH01A	Throttle Body Assy - GH01A
7	16411-PL2-010	Stay - THROTTLE WIRE	Stay - THROTTLE WIRE
8	16412-PL2-300	Stay - THROTTLE BODY	Stay - THROTTLE BODY
9	16413-PE2-000	Collar - MOUNTING	Collar - MOUNTING
2	16414-PH7-000	Clamp a - THROTTLE CABLE	Clamp a - THROTTLE CABLE
11	16416-PH7-660	Clamp comp. b - THROTTLE CABLE	Clamp comp. b - THROTTLE CABLE
1	16418-PH7-660	Clamp comp. c - THROTTLE CABLE	Clamp comp. c - THROTTLE CABLE
3	16472-P0H-A01	Seal ring - INJECTOR (NOK)	Seal ring - INJECTOR (NOK)
3	16472-PH7-003	Seal ring - INJECTOR (OTSUKA)	Seal ring - INJECTOR (OTSUKA)
4	16473-P10-A01	Cushion ring - INJECTOR (NOK)	Cushion ring - INJECTOR (NOK)
4	16473-PD6-000	Cushion ring - INJECTOR (OTSUKA)	Cushion ring - INJECTOR (OTSUKA)
5	16474-PH7-000	Insulator - INJECTOR	Insulator - INJECTOR
13	16500-PH7-005	Valve assy. - FAST IDLE (08A)	Valve assy. - FAST IDLE (08A)
13	16500-PL2-901	Valve assy. - FAST IDLE (10A)	Valve assy. - FAST IDLE (10A)
6	16610-PL2-000	Pipe comp - FR. FUEL	Pipe comp - FR. FUEL
7	16620-PH7-000	Pipe comp - RR. FUEL	Pipe comp - RR. FUEL
8	16638-PH7-000	Insulator - FUEL PIPE	Insulator - FUEL PIPE
9	16722-PL2-014	Hose comp. c - FUEL FEED	Hose comp. c - FUEL FEED
10	16723-PL2-004	Hose comp. d - FUEL FEED	Hose comp. d - FUEL FEED
11	16740-PH7-005	Regulator assy - PRESSURE	Regulator assy - PRESSURE
12	16741-PG7-005	O-ring - PRESSURE REGULATOR	O-ring - PRESSURE REGULATOR
13	16743-PH7-004	Rubber - FUEL HOSE MOUNTING	Rubber - FUEL HOSE MOUNTING
14	16744-PH7-004	Collar - FUEL HOSE MOUNTING	Collar - FUEL HOSE MOUNTING
15	16745-PH7-004	Washer - FUEL HOSE MOUNTING	Washer - FUEL HOSE MOUNTING
16	16746-PH7-010	Clamp a - FUEL HOSE	Clamp a - FUEL HOSE
17	16747-PL2-000	Clamp b - FUEL HOSE	Clamp b - FUEL HOSE
19	16751-PH7-661	Stay - FUEL HOSE CLAMP	Stay - FUEL HOSE CLAMP
20	16752-PH7-013	Clamp c - FUEL HOSE	Clamp c - FUEL HOSE
4	16918-SD4-672	Bracket - FUEL STRAINER	Bracket - FUEL STRAINER
6	16919-SD4-030	Band - FUEL STRAINER	Band - FUEL STRAINER
1	17100-PL2-000	Manifold - INTAKE	Manifold - INTAKE
2	17105-PL2-003	Gasket - INTAKE MANIFOLD	Gasket - INTAKE MANIFOLD
3	17110-PL2-010	Chamber comp - MANIFOLD	Chamber comp - MANIFOLD
4	17120-PL2-005	Body assy - BYPASS VALVE	Body assy - BYPASS VALVE
5	17121-PL2-000	Gasket - BYPASS VALVE	Gasket - BYPASS VALVE
6	17127-PH7-660	Stay a - MASTER POWER TUBE	Stay a - MASTER POWER TUBE
7	17129-PL2-005	Diaphragm assy.	Diaphragm assy.
9	17130-PH7-003	Valve assy. - PCV	Valve assy. - PCV
8	17135-PL2-010	Pipe assy. - BREATHER	Pipe assy. - BREATHER
14	17136-PH7-000	Stay comp - BREATHER PIPE	Stay comp - BREATHER PIPE
9	17153-PH7-000	Tube - BREATHER PIPE	Tube - BREATHER PIPE
21	17164-PL2-000	Emblem - PULSER CONTROL VALVE (V6 2700 24-VALVE PGM-FI)	Emblem - PULSER CONTROL VALVE (V6 2700 24-VALVE PGM-FI)
22	17165-PL2-000	Cover comp. - PULSER CONTROL VALVE	Cover comp. - PULSER CONTROL VALVE
23	17167-PL2-000	Gasket a - PULSER CONTROL VALVE COVER	Gasket a - PULSER CONTROL VALVE COVER
24	17168-PL2-000	Gasket b - PULSER CONTROL VALVE COVER	Gasket b - PULSER CONTROL VALVE COVER
1	17205-PC6-000	Clamp - TUBE, 7.5X2	Clamp - TUBE, 7.5X2
15	17207-PC6-000	Rubber - AIR CLEANER CASE MOUNTING	Rubber - AIR CLEANER CASE MOUNTING
16	17208-PC6-000	Washer - PLAIN	Washer - PLAIN
1	17210-PH7-000	Cover comp. - AIR CLEANER	Cover comp. - AIR CLEANER
2	17211-PH7-020	Stay - AIR CLEANER	Stay - AIR CLEANER
2	17212-PE2-000	Rubber a - AIR CLEANER CASE MOUNTING	Rubber a - AIR CLEANER CASE MOUNTING
3	17212-PH7-000	Rubber a - AIR CLEANER MOUNTING	Rubber a - AIR CLEANER MOUNTING
4	17213-PH7-020	Rubber b - AIR CLEANER CASE MOUNTING	Rubber b - AIR CLEANER CASE MOUNTING
5	17214-PH7-000	Rubber c - AIR CLEANER CASE MOUNTING	Rubber c - AIR CLEANER CASE MOUNTING
6	17216-PH7-000	Collar - AIR CLEANER	Collar - AIR CLEANER
7	17220-PH7-751	Element comp - AIR CLEANER (TOYO)	Element comp - AIR CLEANER (TOYO)
8	17221-PH7-000	Rubber - AIR CLEANER COVER	Rubber - AIR CLEANER COVER
9	17222-PH7-000	Plate - ELEMENT SETTING	Plate - ELEMENT SETTING
10	17224-PL2-010	Tube comp - AIR FLOW	Tube comp - AIR FLOW
11	17225-PH7-300	Joint - AIR FLOW TUBE	Joint - AIR FLOW TUBE
3	17231-PL2-000	Chamber comp - RESONATOR	Chamber comp - RESONATOR
4	17233-PL2-300	Joint comp - RESONATOR	Joint comp - RESONATOR
5	17237-PL2-003	Diaphragm comp - VALVE CONTROL	Diaphragm comp - VALVE CONTROL
6	17239-PL2-000	Pipe comp - RESONATOR CONTROL	Pipe comp - RESONATOR CONTROL
12	17241-PL2-010	Case comp. - AIR CLEANER	Case comp. - AIR CLEANER
13	17242-PL2-300	Tube a - AIR INTAKE	Tube a - AIR INTAKE
14	17244-PH7-320	Tube b - AIR INTAKE	Tube b - AIR INTAKE
15	17245-PL2-000	Tube c - AIR VALVE	Tube c - AIR VALVE
16	17246-PH7-310	Joint - AIR INTAKE PIPE	Joint - AIR INTAKE PIPE
7	17249-PH7-000	Screen comp. - RESONATOR	Screen comp. - RESONATOR
8	17255-PL2-000	Collar - RESONATOR	Collar - RESONATOR
9	17256-PL2-000	Stay - SOLENOID VALVE	Stay - SOLENOID VALVE
17	17257-PL2-000	Stay - TUBE CLAMP (A)	Stay - TUBE CLAMP (A)
10	17258-PL2-003	Clip - RESONATOR CONTROL PIPE	Clip - RESONATOR CONTROL PIPE
11	17259-PL2-000	Pipe - ELBOW	Pipe - ELBOW
2	17267-PH7-010	Clamp a - CANISTER TUBE	Clamp a - CANISTER TUBE
3	17267-PL2-661	Clamp - TUBE, 7.5X3	Clamp - TUBE, 7.5X3
4	17269-PH7-000	Clamp - TUBE (24)(BLACK)	Clamp - TUBE (24)(BLACK)
1	17273-PH7-750	Plate - CAUTION (FRENCH-ENGLISH)	Plate - CAUTION (FRENCH-ENGLISH)
2	17290-PH7-752	Valve assy. - CONTROL	Valve assy. - CONTROL
8	17300-SD4-A32	Canister assy	Canister assy
18	17313-PH7-013	Clamp a - AIR INTAKE TUBE	Clamp a - AIR INTAKE TUBE
19	17314-PH7-003	Clamp b - AIR INTAKE TUBE	Clamp b - AIR INTAKE TUBE
20	17315-PH7-003	Clip - AIR FLOW TUBE	Clip - AIR FLOW TUBE
21	17315-PP8-003	Band c - AIR FLOW TUBE	Band c - AIR FLOW TUBE
9	17358-SD4-020	Bracket - CANISTER	Bracket - CANISTER
3	17361-PC6-000	Clamp - TUBE, 7.5X3	Clamp - TUBE, 7.5X3
5	17362-PL2-660	Clamp - TORQUE ROD TUBE	Clamp - TORQUE ROD TUBE
22	17363-PH7-000	Clamp - EGR CONTROL TUBE	Clamp - EGR CONTROL TUBE
3	17364-PL2-000	Clamp - TWO WAY	Clamp - TWO WAY
4	17370-PD2-013	Thermovalve - 65-C	Thermovalve - 65-C
1	17371-SF1-A01	Valve - TWO WAY	Valve - TWO WAY
5	17440-PL2-620	Pipe assy. - INSTALL	Pipe assy. - INSTALL
4	17521-SG0-020	Band - R. FUEL TANK MOUNTING	Band - R. FUEL TANK MOUNTING
5	17522-SG0-020	Band - L. FUEL TANK MOUNTING	Band - L. FUEL TANK MOUNTING
6	17525-SG0-000	Bolt - FUEL TANK MOUNTING	Bolt - FUEL TANK MOUNTING
10	17556-SD4-003	Clip - FUEL PIPE	Clip - FUEL PIPE
7	17570-SD4-010	Valve - FUEL CUT	Valve - FUEL CUT
1	17574-SE0-000	Packing - BASE	Packing - BASE
8	17575-SE0-000	Packing - FUEL CUT VALVE	Packing - FUEL CUT VALVE
10	17652-SA5-000	Clip - FILLER TUBE	Clip - FILLER TUBE
11	17653-SG0-000	Tube - BREATHER	Tube - BREATHER
13	17662-SG0-000	Packing - FUEL FILLER	Packing - FUEL FILLER
14	17664-SE0-010	Bush - FILLER PIPE MOUNT	Bush - FILLER PIPE MOUNT
15	17665-SE0-010	Collar - FILLER PIPE MOUNT	Collar - FILLER PIPE MOUNT
16	17669-SM4-W00	Label - FUEL FILLER CAUTION (SUPER PREMIUM GASOLINE)	Label - FUEL FILLER CAUTION (SUPER PREMIUM GASOLINE)
17	17670-SA5-013	Cap comp. - FUEL FILLER	Cap comp. - FUEL FILLER
18	17682-679-013	Packing - FUEL FILLER CAP	Packing - FUEL FILLER CAP
25	17701-SA7-930	Rubber - FUEL PIPE INSULATOR	Rubber - FUEL PIPE INSULATOR
11	17701-SD4-010	Rubber a - FUEL PIPE INSULATOR	Rubber a - FUEL PIPE INSULATOR
12	17701-SE0-000	Rubber - FUEL PIPE INSULATOR	Rubber - FUEL PIPE INSULATOR
2	17704-SD4-010	Hose a - FUEL TANK RETURN	Hose a - FUEL TANK RETURN
5	17708-SG0-S31	Pump unit - FUEL	Pump unit - FUEL
1	17712-SA0-000	Grommet - FUEL PIPE	Grommet - FUEL PIPE
13	17713-SD4-003	Clamp - FUEL VENT PIPE	Clamp - FUEL VENT PIPE
26	17723-SD4-A30	Hose - PRESSURE REGULATOR RETURN	Hose - PRESSURE REGULATOR RETURN
14	17725-SG0-000	Hose assy - PURGE	Hose assy - PURGE
16	17742-SD4-Z02	Joint - CANISTER DRAIN TUBE	Joint - CANISTER DRAIN TUBE
17	17742-SF1-A01	Joint - DRAIN TUBE	Joint - DRAIN TUBE
19	17751-SD4-010	Bracket - FUEL PIPE	Bracket - FUEL PIPE
20	17752-SD4-030	Protector - FUEL PIPE	Protector - FUEL PIPE
3	17805-SE0-000	Pad - ACCELERATOR STOPPER	Pad - ACCELERATOR STOPPER
4	17814-SD4-670	Spring - ACCELERATOR PEDAL	Spring - ACCELERATOR PEDAL
4	17814-SD4-770	Spring - ACCELERATOR PEDAL	Spring - ACCELERATOR PEDAL
5	17822-SD4-010	Washer - ACCELERATOR ARM	Washer - ACCELERATOR ARM
6	17855-SD4-010	Bush - WIRE END (BLACK)	Bush - WIRE END (BLACK)
8	17910-SD4-673	Wire - THROTTLE	Wire - THROTTLE
10	17936-SD4-003	Clip - THROTTLE WIRE	Clip - THROTTLE WIRE
1	18100-PL2-640	Manifold assy - FR. EX.	Manifold assy - FR. EX.
2	18110-PL2-640	Manifold assy - RR. EX.	Manifold assy - RR. EX.
3	18115-PH7-003	Gasket - EX. MANIFOLD	Gasket - EX. MANIFOLD
4	18120-PH7-642	Cover - FR. EX. MANIFOLD	Cover - FR. EX. MANIFOLD
5	18130-PH7-640	Cover - RR. EX. MANIFOLD	Cover - RR. EX. MANIFOLD
5	18210-SD4-J02	Pipe a - EX.	Pipe a - EX.
7	18212-671-003	Gasket - EX. PIPE(ISHINO) (59.5MM-60.5MM)	Gasket - EX. PIPE(ISHINO) (59.5MM-60.5MM)
6	18212-SA7-003	Gasket - EX. PIPE (ISHINO)	Gasket - EX. PIPE (ISHINO)
6	18212-SA7-004	Gasket - EX. PIPE (NIPPON LEAKLESS)	Gasket - EX. PIPE (NIPPON LEAKLESS)
9	18215-671-000	Rubber - SILENCER MOUNTING (74X53X22)	Rubber - SILENCER MOUNTING (74X53X22)
14	18282-SD4-010	Bracket b - FLEXIBLE MOUNTING	Bracket b - FLEXIBLE MOUNTING
15	18303-SF1-S01	Gasket - SILENCER	Gasket - SILENCER
18	18328-SG0-000	Bracket - SILENCER MOUNTING	Bracket - SILENCER MOUNTING
19	18393-SH3-S00	Gasket - PRE-CHAMBER (52.5MM-53.5MM)	Gasket - PRE-CHAMBER (52.5MM-53.5MM)
5	18710-PL2-751	Valve assy. - EGR	Valve assy. - EGR
6	18712-PH7-000	Passage - EGR	Passage - EGR
7	18713-PH7-000	Gasket - EGR PASSAGE	Gasket - EGR PASSAGE
9	18715-PB2-000	GASKET, EGR VALVE (ISHINO GASKET)	GASKET, EGR VALVE (ISHINO GASKET)
8	18767-PL2-000	Plate - AIR SUCTION VALVE	Plate - AIR SUCTION VALVE
9	18768-PL2-000	Packing b - AIR SUCTION VALVE	Packing b - AIR SUCTION VALVE
1	19010-PH7-662	Radiator comp - DENSO	Radiator comp - DENSO
1	19010-PH7-672	Radiator comp - DENSO	Radiator comp - DENSO
2	19011-671-000	Bolt - DRAIN (DENSO)	Bolt - DRAIN (DENSO)
3	19012-671-300	Packing - DRAIN (DENSO)	Packing - DRAIN (DENSO)
4	19015-PP8-901	Shroud comp - DENSO	Shroud comp - DENSO
3	19017-PL2-660	Mark - SUB FAN CAUTION	Mark - SUB FAN CAUTION
6	19020-PH7-661	Fan - COOLING (DENSO)	Fan - COOLING (DENSO)
1	19022-PL2-000	Seal comp - R. RADIATOR SIDE	Seal comp - R. RADIATOR SIDE
2	19023-PH7-020	Seal comp - L. RADIATOR SIDE	Seal comp - L. RADIATOR SIDE
7	19030-PH7-662	Motor - COOLING FAN (DENSO)	Motor - COOLING FAN (DENSO)
4	19043-PH7-752	Mark - RADIATOR CAUTION	Mark - RADIATOR CAUTION
8	19045-PT0-003	Cap comp - DENSO	Cap comp - DENSO
8	19045-PT0-004	Cap comp - TOYO	Cap comp - TOYO
9	19050-PH7-662	Resistor assy - DENSO	Resistor assy - DENSO
3	19101-PH7-000	Tank - RESERVE	Tank - RESERVE
4	19102-PA0-020	Cap - RESERVE TANK	Cap - RESERVE TANK
5	19103-PH7-000	Hose - RESERVE TANK	Hose - RESERVE TANK
6	19104-PH7-000	Tube - RESERVE TANK	Tube - RESERVE TANK
1	19105-PH7-000	Bracket comp. - RESERVE TANK	Bracket comp. - RESERVE TANK
8	19106-PA0-020	Joint - RESERVE TANK	Joint - RESERVE TANK
9	19107-PA0-000	Clip - RESERVE TANK JOINT	Clip - RESERVE TANK JOINT
10	19108-PH7-003	Clamp - RESERVE TANK TUBE	Clamp - RESERVE TANK TUBE
11	19109-PL2-000	Skirt - TANK CAP	Skirt - TANK CAP
1	19200-PH7-003	Pump comp - WATER	Pump comp - WATER
2	19222-PH7-003	O-ring - WATER PUMP	O-ring - WATER PUMP
3	19300-PH7-024	Thermostat - NIPPON THERMOSTAT	Thermostat - NIPPON THERMOSTAT
4	19305-PC6-000	Rubber - THERMOSTAT MOUNTING	Rubber - THERMOSTAT MOUNTING
5	19311-PH7-000	Cover - THERMOSTAT	Cover - THERMOSTAT
6	19312-PL2-000	Clamp a - WATER HOSE (D13.5)	Clamp a - WATER HOSE (D13.5)
1	19313-PL2-000	Clamp b - WATER HOSE (D13.5)	Clamp b - WATER HOSE (D13.5)
7	19410-PL2-000	Passage comp. - WATER	Passage comp. - WATER
2	19422-PH7-010	Hose - IN. OIL COOLER	Hose - IN. OIL COOLER
3	19423-PH7-010	Hose - OIL COOLER OUTLET	Hose - OIL COOLER OUTLET
4	19424-PL2-000	Hose - OIL COOLER PIPE	Hose - OIL COOLER PIPE
5	19425-PH7-000	Joint - OIL COOLER CONNECTING	Joint - OIL COOLER CONNECTING
6	19426-PL2-000	Pipe - OIL COOLER OUTLET	Pipe - OIL COOLER OUTLET
7	19427-PH7-004	Clamp - OIL COOLER HOSE	Clamp - OIL COOLER HOSE
12	19501-PH7-000	Hose - WATER UPPER	Hose - WATER UPPER
13	19502-PH7-000	Hose - WATER LOWER	Hose - WATER LOWER
8	19505-PL2-000	Pipe - CONNECTING	Pipe - CONNECTING
12	19506-PH7-003	Clamp comp - WATER HOSE	Clamp comp - WATER HOSE
14	19511-PH7-003	Clip, HOSE(36.5MM) (CHUO SPRING)	Clip, HOSE(36.5MM) (CHUO SPRING)
15	19511-PK1-003	Clip - WATER HOSE	Clip - WATER HOSE
8	19512-PC6-003	Clip - HOSE, 18.7MM	Clip - HOSE, 18.7MM
15	19513-PE0-003	Clamp - WATER HOSE (21.7MM) (CHUO SPRING)	Clamp - WATER HOSE (21.7MM) (CHUO SPRING)
9	19516-PC1-000	Bolt - BREATHING WATER	Bolt - BREATHING WATER
9	19522-PL2-010	Hose a - WATER	Hose a - WATER
10	19523-PL2-000	Hose b - WATER	Hose b - WATER
11	19524-PH7-000	Hose c - WATER	Hose c - WATER
12	19525-PL2-000	Hose d - WATER	Hose d - WATER
13	19526-PL2-010	Hose e - WATER	Hose e - WATER
14	19527-PL2-000	Hose f - WATER	Hose f - WATER
6	20021-PL5-E20	Transmission assy.	Transmission assy.
1	21000-PG2-A20	Case comp. - CLUTCH	Case comp. - CLUTCH
2	21101-PG2-000	Plate - NEEDLE BEARING SETTING	Plate - NEEDLE BEARING SETTING
3	21103-PG2-000	Plate c - OIL GUIDE	Plate c - OIL GUIDE
1	21104-PG1-770	Plate m - OIL GUIDE	Plate m - OIL GUIDE
1	21110-PL5-050	Case comp. - TORQUE CONVERTER	Case comp. - TORQUE CONVERTER
4	21120-PG2-003	Magnet - TRANSMISSION	Magnet - TRANSMISSION
2	21200-PG2-A10	Case comp. - TRANSMISSION	Case comp. - TRANSMISSION
1	21211-PL5-A00	Case - TRANSMISSION	Case - TRANSMISSION
2	21215-PG4-010	Holder - REVERSE IDLE SHAFT	Holder - REVERSE IDLE SHAFT
16	21216-PL2-000	Clamp - OIL COOLER HOSE	Clamp - OIL COOLER HOSE
2	21220-PL5-Z00	Plate comp - BAFFLE	Plate comp - BAFFLE
3	21232-PG2-030	Hanger - TRANSMISSION	Hanger - TRANSMISSION
3	21232-PL5-000	Hanger - TRANSMISSION	Hanger - TRANSMISSION
4	21233-PL5-010	Stay - SOLENOID HARNESS CLAMP	Stay - SOLENOID HARNESS CLAMP
1	21240-PL5-A00	Cover comp. - L. SIDE	Cover comp. - L. SIDE
2	21244-PF4-010	Spring - LOW ACCUMULATOR ONE WAY BALL	Spring - LOW ACCUMULATOR ONE WAY BALL
4	21320-PG2-A10	Tube assy - BREATHER	Tube assy - BREATHER
5	21321-689-000	Plug - BREATHER TUBE	Plug - BREATHER TUBE
1	21350-PH7-010	Cover - CLUTCH CASE	Cover - CLUTCH CASE
5	21396-611-010	Cap - BREATHER	Cap - BREATHER
6	21397-PG4-010	Joint - BREATHER	Joint - BREATHER
7	21811-PL5-S00	Gasket - TORQUE CONVERTER CASE	Gasket - TORQUE CONVERTER CASE
3	21812-PL5-S00	Gasket - L. SIDE COVER	Gasket - L. SIDE COVER
2	22100-PL2-G10	Flywheel comp.	Flywheel comp.
3	22200-PL2-G10	Disk comp - FRICTION	Disk comp - FRICTION
4	22300-PL2-G10	Disk comp - PRESSURE	Disk comp - PRESSURE
1	22500-PL5-J00	Clutch assy. - LOW	Clutch assy. - LOW
2	22510-PL5-J00	Guide comp - LOW CLUTCH	Guide comp - LOW CLUTCH
3	22520-PF4-010	Piston comp - LOW CLUTCH	Piston comp - LOW CLUTCH
4	22530-PF4-000	Piston comp - CLUTCH	Piston comp - CLUTCH
5	22530-PL5-000	Piston comp - THIRD CLUTCH	Piston comp - THIRD CLUTCH
6	22537-PG4-013	Spring - SECOND CLUTCH DISK	Spring - SECOND CLUTCH DISK
7	22538-PG4-003	Spring - LOW CLUTCH DISK	Spring - LOW CLUTCH DISK
8	22540-PG4-000	Piston comp - SECOND CLUTCH	Piston comp - SECOND CLUTCH
9	22541-PG4-004	Spring - SECOND CLUTCH RETURN	Spring - SECOND CLUTCH RETURN
10	22542-PA9-000	Seat - CLUTCH SPRING	Seat - CLUTCH SPRING
11	22542-PC9-003	Spring - LOW CLUTCH RETURN (SANKO)	Spring - LOW CLUTCH RETURN (SANKO)
11	22542-PC9-004	Spring - LOW CLUTCH RETURN (NHK SPRING)	Spring - LOW CLUTCH RETURN (NHK SPRING)
12	22542-PG4-000	Seat - SECOND RETURN SPRING	Seat - SECOND RETURN SPRING
13	22543-PF4-000	Plate - CLUTCH (116MM)	Plate - CLUTCH (116MM)
14	22544-PF4-010	Disk - CLUTCH	Disk - CLUTCH
15	22551-PF4-000	Plate - CLUTCH END (1) (2.1MM)	Plate - CLUTCH END (1) (2.1MM)
15	22552-PF4-000	Plate - CLUTCH END (2) (2.2MM)	Plate - CLUTCH END (2) (2.2MM)
15	22553-PF4-000	Plate - CLUTCH END (3) (2.3MM)	Plate - CLUTCH END (3) (2.3MM)
15	22554-PF4-000	Plate - CLUTCH END (4) (2.4MM)	Plate - CLUTCH END (4) (2.4MM)
15	22555-PF4-000	Plate - CLUTCH END (5) (2.5MM)	Plate - CLUTCH END (5) (2.5MM)
15	22556-PF4-000	Plate - CLUTCH END (6) (2.6MM)	Plate - CLUTCH END (6) (2.6MM)
15	22557-PF4-000	Plate - CLUTCH END (7) (2.7MM)	Plate - CLUTCH END (7) (2.7MM)
15	22558-PF4-000	Plate - CLUTCH END (8) (2.8MM)	Plate - CLUTCH END (8) (2.8MM)
15	22559-PF4-000	Plate - CLUTCH END (9) (2.9MM)	Plate - CLUTCH END (9) (2.9MM)
15	22560-PF4-000	Plate - CLUTCH END (10) (3.0MM)	Plate - CLUTCH END (10) (3.0MM)
16	22561-PF4-000	Plate - CLUTCH END (11) (3.1MM)	Plate - CLUTCH END (11) (3.1MM)
16	22562-PF4-000	Plate - CLUTCH END (12) (3.2MM)	Plate - CLUTCH END (12) (3.2MM)
16	22563-PF4-000	Plate - CLUTCH END (13) (3.3MM)	Plate - CLUTCH END (13) (3.3MM)
16	22564-PF4-000	Plate - CLUTCH END (14) (3.4MM)	Plate - CLUTCH END (14) (3.4MM)
17	22600-PG4-050	Clutch assy. - SECOND	Clutch assy. - SECOND
18	22610-PG4-010	Guide comp - CLUTCH (2-4)	Guide comp - CLUTCH (2-4)
19	22650-PL5-000	Clutch assy. - THIRD	Clutch assy. - THIRD
20	22661-PL5-000	Guide - THIRD CLUTCH	Guide - THIRD CLUTCH
4	22710-PF4-010	Pipe a - FEED	Pipe a - FEED
5	22713-PC9-010	Guide a - FEED PIPE	Guide a - FEED PIPE
6	22721-PA9-003	Flange - FEED PIPE	Flange - FEED PIPE
7	22722-PG4-000	Pipe c - FEED	Pipe c - FEED
1	22741-PG4-010	Pipe - LOW CLUTCH	Pipe - LOW CLUTCH
1	22743-PG4-000	Pipe - THIRD CLUTCH	Pipe - THIRD CLUTCH
2	22744-PG4-000	Pipe - TOP CLUTCH	Pipe - TOP CLUTCH
1	22810-PG2-004	Bearing - CLUTCH RELEASE (KOYO)	Bearing - CLUTCH RELEASE (KOYO)
1	22810-PG2-008	Bearing - CLUTCH RELEASE (TOYO)	Bearing - CLUTCH RELEASE (TOYO)
1	22814-PF4-003	Ring - SEALING, 35MM	Ring - SEALING, 35MM
2	22820-PG2-A01	Fork comp - CLUTCH RELEASE	Fork comp - CLUTCH RELEASE
3	22825-PG2-010	Bolt - RELEASE FORK	Bolt - RELEASE FORK
4	22841-PG2-000	Boot - RELEASE FORK	Boot - RELEASE FORK
1	23210-PG2-A30	Mainshaft comp.	Mainshaft comp.
2	23210-PL5-E02	Mainshaft comp.	Mainshaft comp.
1	23220-PG2-960	Countershaft comp.	Countershaft comp.
1	23220-PL5-J10	Countershaft comp.	Countershaft comp.
3	23225-PF0-850	Plate - OIL GUIDE	Plate - OIL GUIDE
2	23261-PG2-000	Shaft - REVERSE IDLE GEAR	Shaft - REVERSE IDLE GEAR
3	23411-PL5-J00	Gear - MAINSHAFT LOW	Gear - MAINSHAFT LOW
2	23421-PG1-000	Gear - COUNTERSHAFT LOW	Gear - COUNTERSHAFT LOW
2	23421-PL5-J00	Gear - COUNTERSHAFT LOW	Gear - COUNTERSHAFT LOW
3	23423-PL5-J00	Clutch assy. - ONE WAY	Clutch assy. - ONE WAY
4	23427-PL5-J00	Gear - PARKING	Gear - PARKING
3	23431-PG2-010	Gear - COUNTERSHAFT SECOND	Gear - COUNTERSHAFT SECOND
4	23431-PL5-610	Gear - MAINSHAFT SECOND	Gear - MAINSHAFT SECOND
3	23441-PG2-010	Gear - MAINSHAFT THIRD	Gear - MAINSHAFT THIRD
5	23441-PL5-610	Gear - COUNTERSHAFT SECOND	Gear - COUNTERSHAFT SECOND
4	23451-PG2-010	Gear - MAINSHAFT FOURTH	Gear - MAINSHAFT FOURTH
6	23451-PL5-N00	Gear - COUNTERSHAFT THIRD	Gear - COUNTERSHAFT THIRD
4	23461-PG2-950	Gear - COUNTERSHAFT FIFTH	Gear - COUNTERSHAFT FIFTH
5	23461-PL5-E00	Gear - MAINSHAFT FOURTH	Gear - MAINSHAFT FOURTH
5	23471-PG2-000	Gear - COUNTERSHAFT THIRD	Gear - COUNTERSHAFT THIRD
7	23471-PL5-E10	Gear - COUNTERSHAFT FOURTH	Gear - COUNTERSHAFT FOURTH
6	23481-PG2-000	Gear - COUNTERSHAFT FOURTH	Gear - COUNTERSHAFT FOURTH
7	23521-PG2-305	Sleeve set - SYNCHRONIZER (1-2)	Sleeve set - SYNCHRONIZER (1-2)
8	23531-PL5-J01	Gear - COUNTERSHAFT REVERSE	Gear - COUNTERSHAFT REVERSE
5	23540-PG2-020	Gear comp - REVERSE IDLE	Gear comp - REVERSE IDLE
9	23541-PF4-000	Gear - REVERSE IDLE	Gear - REVERSE IDLE
10	23542-PH0-020	Shaft - REVERSE IDLE GEAR	Shaft - REVERSE IDLE GEAR
6	23543-PG2-000	Washer - 20X30X4	Washer - 20X30X4
11	23543-PH0-000	Spring a - IDLE GEAR SHAFT	Spring a - IDLE GEAR SHAFT
8	23544-PC9-810	Spring b - IDLE GEAR SHAFT	Spring b - IDLE GEAR SHAFT
12	23565-PL5-Z03	Selector - REVERSE GEAR	Selector - REVERSE GEAR
13	23566-PL5-J00	Hub - SELECTOR	Hub - SELECTOR
7	23581-PG2-E00	Gear - MAINSHAFT FIFTH	Gear - MAINSHAFT FIFTH
8	23623-PG2-305	Sleeve set - SYNCHRONIZER (3-4)	Sleeve set - SYNCHRONIZER (3-4)
9	23626-PG2-325	Sleeve set - SYNCHRONIZER (5)	Sleeve set - SYNCHRONIZER (5)
1	23814-689-000	Seal - GEAR HOLDER	Seal - GEAR HOLDER
8	23911-PG2-000	Collar a - DISTANCE, 36X44X29 (+0.05/+0.03)	Collar a - DISTANCE, 36X44X29 (+0.05/+0.03)
8	23912-PG2-000	Collar b - DISTANCE, 36X44X29 (+0.03/+0.01)	Collar b - DISTANCE, 36X44X29 (+0.03/+0.01)
8	23913-PG2-000	Collar c - DISTANCE, 36X44X29 (+0.01/-0.01)	Collar c - DISTANCE, 36X44X29 (+0.01/-0.01)
8	23914-PG2-000	Collar d - DISTANCE, 36X44X29 (-0.01/-0.03)	Collar d - DISTANCE, 36X44X29 (-0.01/-0.03)
10	23915-PG1-770	Collar - DISTANCE, 31X38X56	Collar - DISTANCE, 31X38X56
8	23915-PG2-000	Collar e - DISTANCE, 36X44X29 (-0.03/-0.05)	Collar e - DISTANCE, 36X44X29 (-0.03/-0.05)
9	23921-PK5-900	Washer a - 40X54X1.95	Washer a - 40X54X1.95
9	23922-PK5-900	Washer b - 40X54X1.96	Washer b - 40X54X1.96
9	23923-PK5-900	Washer c - 40X54X1.97	Washer c - 40X54X1.97
9	23924-PK5-900	Washer d - 40X54X1.98	Washer d - 40X54X1.98
9	23925-PK5-900	Washer e - 40X54X1.99	Washer e - 40X54X1.99
10	23926-PG1-010	Washer - SPRING, 23MM	Washer - SPRING, 23MM
9	23926-PK5-900	Washer f - 40X54X2.00	Washer f - 40X54X2.00
11	23927-PG2-A00	Washer - SPRING, 28MM	Washer - SPRING, 28MM
9	23927-PK5-900	Washer g - 40X54X2.01	Washer g - 40X54X2.01
9	23928-PK5-900	Washer h - 40X54X2.02	Washer h - 40X54X2.02
9	23929-PK5-900	Washer i - 40X54X2.03	Washer i - 40X54X2.03
9	23930-PK5-900	Washer j - 40X54X2.04	Washer j - 40X54X2.04
9	23931-PK5-900	Washer k - 40X54X2.05	Washer k - 40X54X2.05
9	23932-PK5-900	Washer l - 40X54X2.06	Washer l - 40X54X2.06
9	23933-PK5-900	Washer m - 40X54X2.07	Washer m - 40X54X2.07
9	23934-PK5-900	Washer n - 40X54X2.08	Washer n - 40X54X2.08
9	23935-PK5-900	Washer o - 40X54X2.09	Washer o - 40X54X2.09
9	23936-PK5-900	Washer p - 40X54X2.10	Washer p - 40X54X2.10
6	23941-PK5-000	Shim a - 78MM (1.20)	Shim a - 78MM (1.20)
6	23942-PK5-000	Shim b - 78MM (1.23)	Shim b - 78MM (1.23)
6	23943-PK5-000	Shim c - 78MM (1.26)	Shim c - 78MM (1.26)
6	23944-PK5-000	Shim d - 78MM (1.29)	Shim d - 78MM (1.29)
6	23945-PK5-000	Shim e - 78MM (1.32)	Shim e - 78MM (1.32)
6	23946-PK5-000	Shim f - 78MM (1.35)	Shim f - 78MM (1.35)
6	23947-PK5-000	Shim g - 78MM (1.38)	Shim g - 78MM (1.38)
6	23948-P16-000	Shim h - 78MM (1.41)	Shim h - 78MM (1.41)
6	23948-PK5-000	Shim h - 78MM (1.41)	Shim h - 78MM (1.41)
6	23949-PK5-000	Shim i - 78MM (1.44)	Shim i - 78MM (1.44)
6	23950-PK5-000	Shim j - 78MM (1.47)	Shim j - 78MM (1.47)
6	23951-PK5-000	Shim k - 78MM (1.50)	Shim k - 78MM (1.50)
6	23952-PK5-000	Shim l - 78MM (1.53)	Shim l - 78MM (1.53)
6	23953-PK5-000	Shim m - 78MM (1.56)	Shim m - 78MM (1.56)
6	23954-PK5-000	Shim n - 78MM (1.59)	Shim n - 78MM (1.59)
6	23955-PK5-000	Shim o - 78MM (1.62)	Shim o - 78MM (1.62)
6	23956-PK5-000	Shim p - 78MM (1.65)	Shim p - 78MM (1.65)
6	23957-PK5-000	Shim q - 78MM (1.68)	Shim q - 78MM (1.68)
6	23958-PK5-000	Shim r - 78MM (1.71)	Shim r - 78MM (1.71)
6	23959-PK5-000	Shim s - 78MM (1.74)	Shim s - 78MM (1.74)
6	23960-PK5-000	Shim t - 78MM (1.77)	Shim t - 78MM (1.77)
6	23961-PK5-000	Shim u - 78MM (1.80)	Shim u - 78MM (1.80)
6	23962-PK5-000	Shim v - 78MM (1.83)	Shim v - 78MM (1.83)
6	23963-PK5-000	Shim w - 78MM (1.86)	Shim w - 78MM (1.86)
6	23964-PK5-000	Shim x - 78MM (1.89)	Shim x - 78MM (1.89)
6	23965-PK5-000	Shim y - 78MM (1.92)	Shim y - 78MM (1.92)
6	23966-PK5-000	Shim z - 78MM (1.95)	Shim z - 78MM (1.95)
6	23967-PK5-000	Shim aa - 78MM (1.98)	Shim aa - 78MM (1.98)
6	23968-PK5-000	Shim ab - 78MM (2.01)	Shim ab - 78MM (2.01)
6	23969-PK5-000	Shim ac - 78MM (2.04)	Shim ac - 78MM (2.04)
6	23970-PK5-000	Shim ad - 78MM (2.07)	Shim ad - 78MM (2.07)
6	23971-PK5-000	Shim ae - 78MM (2.10)	Shim ae - 78MM (2.10)
6	23972-PK5-000	Shim af - 78MM (2.13)	Shim af - 78MM (2.13)
6	23973-PK5-000	Shim ag - 78MM (2.16)	Shim ag - 78MM (2.16)
6	23974-PK5-000	Shim ah - 78MM (2.19)	Shim ah - 78MM (2.19)
6	23975-PK5-000	Shim ai - 78MM (2.22)	Shim ai - 78MM (2.22)
6	23976-PK5-000	Shim aj - 78MM (2.25)	Shim aj - 78MM (2.25)
6	23977-PK5-000	Shim ak - 78MM (2.28)	Shim ak - 78MM (2.28)
6	23978-PK5-000	Shim al - 78MM (2.31)	Shim al - 78MM (2.31)
6	23979-PK5-000	Shim am - 78MM (2.34)	Shim am - 78MM (2.34)
6	23980-PK5-000	Shim an - 78MM (2.37)	Shim an - 78MM (2.37)
1	24111-PL5-Z01	Fork - REVERSE SHIFT	Fork - REVERSE SHIFT
1	24200-PG2-020	Fork comp - FIFTH GEARSHIFT	Fork comp - FIFTH GEARSHIFT
2	24210-PG2-A13	Fork comp - GEARSHIFT (3-4)	Fork comp - GEARSHIFT (3-4)
3	24220-PG2-A10	Fork comp - GEARSHIFT (1-2)	Fork comp - GEARSHIFT (1-2)
1	24230-PG2-000	Holder comp - REVERSE SHIFT	Holder comp - REVERSE SHIFT
4	24243-PG2-000	Piece - FIFTH & REVERSE SHIFT	Piece - FIFTH & REVERSE SHIFT
5	24261-PG2-A12	Shaft - FORK (1-2)	Shaft - FORK (1-2)
6	24271-PG2-A12	Shaft - FIFTH & REVERSE FORK SHIFT	Shaft - FIFTH & REVERSE FORK SHIFT
3	24271-PL5-Z00	Shaft a - SHIFT FORK	Shaft a - SHIFT FORK
3	24272-PL5-Z00	Shaft b - SHIFT FORK	Shaft b - SHIFT FORK
3	24273-PL5-Z00	Shaft c - SHIFT FORK	Shaft c - SHIFT FORK
2	24282-634-000	Bolt - SHAFT FORK SETTING	Bolt - SHAFT FORK SETTING
2	24311-PG2-010	Rod - GEARSHIFT	Rod - GEARSHIFT
3	24312-PG2-320	Joint end - CHANGE	Joint end - CHANGE
4	24313-PG2-010	Clip - CHANGE JOINT PIN	Clip - CHANGE JOINT PIN
5	24316-PG2-000	Boot - SHIFT ROD	Boot - SHIFT ROD
6	24351-PG1-000	Shaft - SHIFT PIECE	Shaft - SHIFT PIECE
11	24360-PL5-013	Cable comp - THROTTLE (AT)	Cable comp - THROTTLE (AT)
7	24400-PG2-A11	Holder assy. - CHANGE	Holder assy. - CHANGE
8	24411-PG2-000	Piece - GEARSHIFT	Piece - GEARSHIFT
3	24411-PG4-300	Shaft - CONTROL	Shaft - CONTROL
1	24412-PL5-000	Lever - CONTROL	Lever - CONTROL
2	24414-PA9-010	Pin - CONTROL	Pin - CONTROL
3	24415-PA9-000	Roller - CONTROL LEVER	Roller - CONTROL LEVER
4	24421-PL5-300	Lever - MANUAL VALVE	Lever - MANUAL VALVE
5	24423-PA9-000	Pin - MANUAL VALVE	Pin - MANUAL VALVE
6	24425-639-000	Roller - MANUAL VALVE	Roller - MANUAL VALVE
9	24432-PG2-A11	Interlock comp.	Interlock comp.
10	24440-PG2-A10	Piece comp. - GEARSHIFT	Piece comp. - GEARSHIFT
7	24452-PG2-020	Spring - FIFTH & REVERSE STOPPER	Spring - FIFTH & REVERSE STOPPER
2	24461-PA9-010	Spring - ROLLER	Spring - ROLLER
3	24471-PN6-000	Roller - 6X16	Roller - 6X16
12	24519-PB6-000	Screw - BALL SPRING SETTING	Screw - BALL SPRING SETTING
8	24519-PG2-000	Screw - BALL SPRING SETTING	Screw - BALL SPRING SETTING
4	24530-PN1-000	Sleeve comp. - SERVO DETENT	Sleeve comp. - SERVO DETENT
7	24532-PN6-003	Lever - PARKING BRAKE	Lever - PARKING BRAKE
8	24535-PG4-000	Spring - PARKING BRAKE	Spring - PARKING BRAKE
9	24537-PA9-003	Stopper - PARKING BRAKE (1)	Stopper - PARKING BRAKE (1)
9	24538-PA9-003	Stopper - PARKING BRAKE (2)	Stopper - PARKING BRAKE (2)
9	24539-PA9-003	Stopper - PARKING BRAKE (3)	Stopper - PARKING BRAKE (3)
10	24552-PL5-J00	Spring - PARKING BRAKE PAWL	Spring - PARKING BRAKE PAWL
11	24553-PN6-000	Roller - PARKING BRAKE	Roller - PARKING BRAKE
12	24555-PN6-000	Pin - ROLLER, 6MM	Pin - ROLLER, 6MM
13	24561-PL5-010	Pawl - PARKING BRAKE	Pawl - PARKING BRAKE
14	24562-PL5-J00	Shaft - PARKING BRAKE	Shaft - PARKING BRAKE
4	24901-PG4-020	Holder - CONTROL CABLE	Holder - CONTROL CABLE
4	25145-PA9-010	Shaft - OIL PUMP GEAR	Shaft - OIL PUMP GEAR
1	25155-PL5-010	Shaft assy - STATOR	Shaft assy - STATOR
17	25210-PL2-J10	Pipe comp - OIL HOSE (C)	Pipe comp - OIL HOSE (C)
18	25213-PL2-J00	Hose - OIL COOLER, 260MM	Hose - OIL COOLER, 260MM
19	25214-PL2-J00	Hose comp. - OIL COOLER, 450MM	Hose comp. - OIL COOLER, 450MM
20	25215-PH7-000	Hose - OIL COOLER, 200MM	Hose - OIL COOLER, 200MM
4	25420-PL5-000	Strainer - TRANSMISSION	Strainer - TRANSMISSION
5	25422-PN6-801	Magnet comp. - TRANSMISSION	Magnet comp. - TRANSMISSION
1	25500-PG4-614	Cooler kit - ATF	Cooler kit - ATF
2	25510-PG4-613	Cooler comp - ATF	Cooler comp - ATF
3	25511-PG4-611	Hose a - OIL COOLER	Hose a - OIL COOLER
4	25512-PG4-611	Hose b - OIL COOLER	Hose b - OIL COOLER
5	25513-PG4-611	Hose c - OIL COOLER	Hose c - OIL COOLER
6	25514-PG4-612	Hose d - OIL COOLER	Hose d - OIL COOLER
7	25515-PG4-610	Band - ATF HOSE	Band - ATF HOSE
8	25516-PL5-E00	Hose e - OIL COOLER	Hose e - OIL COOLER
9	25517-PG4-610	Insulator - ATF COOLER	Insulator - ATF COOLER
10	25520-PG4-611	Guide comp. a - AIR	Guide comp. a - AIR
11	25521-PL5-E00	Guide b - AIR	Guide b - AIR
13	25540-PG4-613	Stay a - ATF COOLER	Stay a - ATF COOLER
14	25541-PG4-610	Stay b - ATF COOLER	Stay b - ATF COOLER
15	25543-PL5-E00	Stay - COUPLER	Stay - COUPLER
16	25545-PL5-E00	Protector a	Protector a
17	25546-PL5-E00	Protector b	Protector b
18	25547-PG4-610	Clamp - RECEIVER PIPE	Clamp - RECEIVER PIPE
19	25548-PG4-610	Cover - CONNECTOR	Cover - CONNECTOR
5	25610-PL5-Z01	Gauge comp. - OIL LEVEL (ATF)	Gauge comp. - OIL LEVEL (ATF)
6	25613-PL5-000	Pipe - OIL LEVEL GAUGE (ATF)	Pipe - OIL LEVEL GAUGE (ATF)
7	25910-PL5-A00	Pipe comp - OIL HOSE (A)	Pipe comp - OIL HOSE (A)
8	25920-PL5-020	Pipe comp - OIL HOSE (B)	Pipe comp - OIL HOSE (B)
9	25950-PL5-000	Bolt comp - JOINT	Bolt comp - JOINT
10	25951-639-000	Bolt - JOINT	Bolt - JOINT
2	26000-PL5-J01	Converter assy - TORQUE	Converter assy - TORQUE
3	26251-PH7-010	Plate - DRIVE	Plate - DRIVE
5	27105-PL5-Z03	Body sub assy. - MAIN VALVE	Body sub assy. - MAIN VALVE
6	27112-PL5-Z00	Plate - MAIN SEPARATING	Plate - MAIN SEPARATING
7	27115-PL5-A00	Holder - MAIN SEPARATOR PLATE	Holder - MAIN SEPARATOR PLATE
8	27116-PL5-A00	Pin - OIL STOPPER	Pin - OIL STOPPER
2	27200-PL5-E00	Regulator assy	Regulator assy
3	27221-PC9-000	Valve - REGULATOR	Valve - REGULATOR
4	27231-PL5-004	Spring a - REGULATOR VALVE	Spring a - REGULATOR VALVE
5	27232-PF4-000	Spring b - REGULATOR VALVE	Spring b - REGULATOR VALVE
6	27233-PA9-000	Spring - REACTION STATOR	Spring - REACTION STATOR
7	27246-PN6-800	Cap - REGULATOR SPRING	Cap - REGULATOR SPRING
9	27255-PC9-710	Spring - TORQUE CONVERTER CHECK VALVE	Spring - TORQUE CONVERTER CHECK VALVE
11	27256-639-000	Valve - TORQUE CONVERTER CHECK	Valve - TORQUE CONVERTER CHECK
10	27256-PA9-000	Valve - RELIEF	Valve - RELIEF
12	27257-PG4-000	Spring - RELIEF VALVE	Spring - RELIEF VALVE
13	27258-680-900	Seat - RELIEF VALVE SPRING	Seat - RELIEF VALVE SPRING
10	27259-PL5-000	Spring - COOLER CHECK VALVE	Spring - COOLER CHECK VALVE
1	27263-PA9-000	Seat Valve Sping 1.0mm - VALVE SPRING, 1.0MM	Seat Valve Sping 1.0mm - VALVE SPRING, 1.0MM
6	27405-PL5-Z05	Body sub assy. - SERVO	Body sub assy. - SERVO
7	27412-PL5-Z02	Plate - SERVO SEPARATING	Plate - SERVO SEPARATING
8	27413-PL5-Z03	Cover - THROTTLE	Cover - THROTTLE
18	27415-PC9-010	Valve - ORIFICE CONTROL	Valve - ORIFICE CONTROL
4	27415-PL5-000	Valve - SECOND ORIFICE CONTROL	Valve - SECOND ORIFICE CONTROL
3	27415-PL5-Z00	Valve - FOURTH ORIFICE CONTROL	Valve - FOURTH ORIFICE CONTROL
5	27417-PL5-000	Spring - SECOND ORIFICE CONTROL VALVE	Spring - SECOND ORIFICE CONTROL VALVE
25	27417-PL5-Z00	Spring - FOURTH ORIFICE CONTROL VALVE	Spring - FOURTH ORIFICE CONTROL VALVE
19	27418-PF4-000	Spring - ORIFICE CONTROL VALVE	Spring - ORIFICE CONTROL VALVE
20	27419-PC9-010	SEAT, VALVE SPRING	SEAT, VALVE SPRING
21	27421-PL5-Z00	Valve - MANUAL	Valve - MANUAL
15	27490-PL5-J00	Shaft comp. - THROTTLE VALVE	Shaft comp. - THROTTLE VALVE
11	27494-PG4-000	Lever - THROTTLE CONTROL	Lever - THROTTLE CONTROL
12	27495-PG4-010	Spring - THROTTLE LEVER	Spring - THROTTLE LEVER
13	27496-PL5-010	Stay - THROTTLE CABLE	Stay - THROTTLE CABLE
7	27543-PL5-J11	Cap - SHIFT (3-4)	Cap - SHIFT (3-4)
22	27544-PL5-Z01	Seat - SHIFT (3-4)	Seat - SHIFT (3-4)
8	27561-PG4-000	Piston - LOW ACCUMULATOR	Piston - LOW ACCUMULATOR
9	27562-PL5-000	Spring a - LOW ACCUMULATOR	Spring a - LOW ACCUMULATOR
10	27563-PG4-000	Cover - LOW ACCUMULATOR	Cover - LOW ACCUMULATOR
11	27564-PL5-000	Spring b - LOW ACCUMULATOR	Spring b - LOW ACCUMULATOR
11	27572-PL5-010	Piston - SECOND ACCUMULATOR	Piston - SECOND ACCUMULATOR
12	27574-PG4-000	Piston - THIRD ACCUMULATOR	Piston - THIRD ACCUMULATOR
13	27576-PL5-Z00	Piston - TOP ACCUMULATOR	Piston - TOP ACCUMULATOR
14	27577-PL5-Z01	Spring - TOP ACCUMULATOR	Spring - TOP ACCUMULATOR
15	27580-PL5-Z01	Cover - ACCUMULATOR	Cover - ACCUMULATOR
17	27582-PG4-040	Spring - SECOND ACCUMULATOR	Spring - SECOND ACCUMULATOR
18	27583-PL5-N00	Spring - THIRD ACCUMULATOR	Spring - THIRD ACCUMULATOR
11	27610-PL5-010	Body comp - LOCK UP VALVE	Body comp - LOCK UP VALVE
12	27612-PL5-010	Plate - LOCK UP SEPARATING	Plate - LOCK UP SEPARATING
13	27621-PL5-010	Valve - LOCK UP SHIFT	Valve - LOCK UP SHIFT
14	27623-PL5-000	Spring - LOCK UP SHIFT VALVE	Spring - LOCK UP SHIFT VALVE
15	27626-PL5-000	Valve b - LOCK UP TIMING	Valve b - LOCK UP TIMING
16	27627-PL5-000	Spring b - LOCK UP TIMING	Spring b - LOCK UP TIMING
9	27628-PK4-000	Cap - LOCK UP TIMING	Cap - LOCK UP TIMING
17	27645-PL5-000	Cap - LOCK UP CONTROL	Cap - LOCK UP CONTROL
10	27646-PG4-000	Sleeve - 12.5MM	Sleeve - 12.5MM
18	27646-PL5-010	Sleeve - LOCK UP CONTROL	Sleeve - LOCK UP CONTROL
11	27653-PF4-000	Cap - CLUTCH PRESSURE CONTROL VALVE	Cap - CLUTCH PRESSURE CONTROL VALVE
12	27653-PL5-J00	Cap - MODULATOR VALVE	Cap - MODULATOR VALVE
13	27655-PC9-950	Valve - CLUTCH PRESSURE CONTROL	Valve - CLUTCH PRESSURE CONTROL
14	27656-PC9-000	Spring a - CLUTCH PRESSURE CONTROL VALVE	Spring a - CLUTCH PRESSURE CONTROL VALVE
15	27656-PC9-950	Spring a - CLUTCH PRESSURE CONTROL VALVE (5.6-5.7)	Spring a - CLUTCH PRESSURE CONTROL VALVE (5.6-5.7)
14	27657-PC9-000	Spring b - CLUTCH PRESSURE CONTROL VALVE	Spring b - CLUTCH PRESSURE CONTROL VALVE
15	27657-PC9-950	Spring b - CLUTCH PRESSURE CONTROL VALVE (5.5-5.6)	Spring b - CLUTCH PRESSURE CONTROL VALVE (5.5-5.6)
16	27700-PL5-Z10	Body assy - SECONDARY	Body assy - SECONDARY
17	27711-PL5-Z10	Body - SECONDARY	Body - SECONDARY
18	27712-PL5-J11	Plate - SECONDARY SEPARATING	Plate - SECONDARY SEPARATING
20	27721-PL5-Z01	Valve - KICK DOWN (4-3)	Valve - KICK DOWN (4-3)
21	27722-PL5-Z00	Spring - KICK DOWN VALVE (4-3) (###)	Spring - KICK DOWN VALVE (4-3) (###)
22	27724-PG4-000	Cap - KICK DOWN VALVE	Cap - KICK DOWN VALVE
19	27728-PF4-000	Cap - REVERSE CONTROL VALVE	Cap - REVERSE CONTROL VALVE
23	27731-PL5-Z10	Valve - SERVO CONTROL (###)	Valve - SERVO CONTROL (###)
24	27732-PL5-Z10	Spring - SERVO CONTROL VALVE (###)	Spring - SERVO CONTROL VALVE (###)
23	27750-PL5-J01	Filter - SECONDARY BODY	Filter - SECONDARY BODY
26	27753-PL5-J00	Spring - ORIFICE CONTROL (2-1)	Spring - ORIFICE CONTROL (2-1)
14	27921-PL5-A00	Stay - PICK UP COUPLER	Stay - PICK UP COUPLER
5	28200-PL5-033	Solenoid assy. - SHIFT	Solenoid assy. - SHIFT
6	28220-PL5-003	Filter assy - SHIFT SOLENOID	Filter assy - SHIFT SOLENOID
7	28300-PL5-033	Solenoid assy. - LOCK UP	Solenoid assy. - LOCK UP
8	28320-PL5-003	Filter assy - LOCK UP SOLENOID	Filter assy - LOCK UP SOLENOID
12	28810-PL5-A01	Pick up assy. - MAIN (TEC)	Pick up assy. - MAIN (TEC)
12	28810-PL5-A02	Pick up assy. - MAIN (KEIHIN)	Pick up assy. - MAIN (KEIHIN)
13	28820-PL5-A01	Pick up assy. - COUNTER (TEC)	Pick up assy. - COUNTER (TEC)
13	28820-PL5-A02	Pick up assy. - COUNTER (KEIHIN)	Pick up assy. - COUNTER (KEIHIN)
1	30100-PL2-016	Distributor assy - TD-01T) (TEC	Distributor assy - TD-01T) (TEC
2	30101-PL2-016	Housing comp	Housing comp
3	30102-PL2-016	Cap assy.	Cap assy.
4	30103-PL2-006	Head - ROTOR	Head - ROTOR
5	30110-PH7-006	O-ring - 24.4X3.1 (TEC)	O-ring - 24.4X3.1 (TEC)
6	30110-PL2-006	O-ring - CAP	O-ring - CAP
7	30113-PG6-006	Coupling set - TEC	Coupling set - TEC
1	30120-PL2-014	Igniter unit - MNE-311)(OKI	Igniter unit - MNE-311)(OKI
8	30135-PL2-006	Screw-washer - 5X10	Screw-washer - 5X10
9	30136-PL2-006	Stay - HIGH TENSION CORD CLAMP	Stay - HIGH TENSION CORD CLAMP
1	30158-700-010	E-clip - 3MM	E-clip - 3MM
17	30168-PL2-000	Cord - CONDENSER EARTH	Cord - CONDENSER EARTH
2	30500-PH6-900	Coil assy - IGNITION	Coil assy - IGNITION
3	30501-PH6-900	Bracket - IGNITION COIL	Bracket - IGNITION COIL
4	30501-PL2-000	Bracket - IGNITION COIL	Bracket - IGNITION COIL
5	30510-PH7-003	Condenser comp.	Condenser comp.
6	30520-PH6-902	Coil comp - IGNITION (TEC) (TC-09A)	Coil comp - IGNITION (TEC) (TC-09A)
7	30520-PH7-016	Coil assy - IGNITION (TC-04A) (TEC)	Coil assy - IGNITION (TC-04A) (TEC)
1	30700-SD4-A02	Resistor assy.	Resistor assy.
20	30701-883-000	Clip, high tension cord (8mm)	Clip, high tension cord (8mm)
1	31100-PH7-024	Alternator assy - CJK46) (DENSO	Alternator assy - CJK46) (DENSO
2	31101-PH7-004	Rotor assy.	Rotor assy.
3	31105-PD1-034	Holder assy. - ALTERNATOR BRUSH	Holder assy. - ALTERNATOR BRUSH
3	31105-PZ1-003	Holder assy. - BRUSH	Holder assy. - BRUSH
4	31109-PH7-004	Frame assy - DRIVE END	Frame assy - DRIVE END
1	31110-PH7-013	Belt - ALTERNATOR (BANDO)	Belt - ALTERNATOR (BANDO)
5	31111-PD1-014	Bearing - RR. GENERATOR	Bearing - RR. GENERATOR
2	31112-PL2-020	Bracket - ALTERNATOR	Bracket - ALTERNATOR
3	31113-PL2-000	Plate - ADJUSTING	Plate - ADJUSTING
4	31114-PL2-000	Bolt - TENSIONER	Bolt - TENSIONER
7	31116-PE0-013	Plate - RETAINER	Plate - RETAINER
5	31117-PL2-000	Hanger - ENGINE	Hanger - ENGINE
8	31118-PD1-004	Bush - INSULATION	Bush - INSULATION
6	31118-PL2-000	Plate - SUPPORT	Plate - SUPPORT
9	31119-PH1-004	Bush - INSULATION	Bush - INSULATION
10	31121-PH7-004	Frame - RR. END	Frame - RR. END
7	31125-PH7-000	Cover comp. - BELT	Cover comp. - BELT
11	31127-PD2-014	Rectifier assy.	Rectifier assy.
8	31127-PH7-662	Plate - CAUTION	Plate - CAUTION
12	31129-PD1-014	Spring - BRUSH (###)	Spring - BRUSH (###)
13	31135-PD2-004	Cover - RR. END (###)	Cover - RR. END (###)
14	31138-PD1-004	Cover - BEARING	Cover - BEARING
15	31141-PL2-004	Pulley - ###	Pulley - ###
16	31142-PD1-004	Nut - PULLEY LOCK	Nut - PULLEY LOCK
17	31143-PH1-004	Clip - CORD (###)	Clip - CORD (###)
18	31144-P01-003	Brush	Brush
18	31144-PD1-004	Brush	Brush
19	31145-PD1-004	Bolt - STUD, 6X68	Bolt - STUD, 6X68
20	31146-PD1-004	Screw-washer - 4X19	Screw-washer - 4X19
21	31148-PD1-004	Screw-washer - 4X25	Screw-washer - 4X25
22	31149-PD1-004	Screw-washer - 4X8 (###)	Screw-washer - 4X8 (###)
23	31150-PD6-024	Regulator assy	Regulator assy
1	31200-PH7-006	Motor assy. - STARTER (MITSUBA) (SM-302-19 1.4KW)	Motor assy. - STARTER (MITSUBA) (SM-302-19 1.4KW)
2	31202-PC2-681	Bolt - THROUGH (###)	Bolt - THROUGH (###)
3	31203-PH7-006	Cover - GEAR (MITSUBA)	Cover - GEAR (MITSUBA)
4	31204-PH7-016	Gear assy. - PINION (MITSUBA)	Gear assy. - PINION (MITSUBA)
6	31207-PH3-953	Armature comp.	Armature comp.
6	31207-PH3-954	Armature assy - ###	Armature assy - ###
8	31209-PH7-006	Bracket - RR. UNIT (###)	Bracket - RR. UNIT (###)
9	31210-PH7-016	Switch assy - MAGNETIC	Switch assy - MAGNETIC
10	31211-PC2-006	Ring - SQUARE (MITSUBA)	Ring - SQUARE (MITSUBA)
11	31217-PC2-006	Screw-washer - 4X28 (MITSUBA)	Screw-washer - 4X28 (MITSUBA)
12	31229-PH7-016	Case comp. - FR.	Case comp. - FR.
12	31229-PH7-026	Case comp. - FR. (###)	Case comp. - FR. (###)
14	31251-PD2-026	Tube - LABYRINTH	Tube - LABYRINTH
15	31252-PD2-006	Rubber - BUSH (MITSUBA)	Rubber - BUSH (MITSUBA)
17	31260-PH7-006	Stator set	Stator set
8	31500-SG0-E06	Battery assy - 80D26L-MF) (PANASONIC	Battery assy - 80D26L-MF) (PANASONIC
8	31500-SG0-E07	Battery assy - 80D26L-MF) (YUASA	Battery assy - 80D26L-MF) (YUASA
5	31511-SB2-671	Mark - BATTERY CAUTION (MAINTENANCE FREE)	Mark - BATTERY CAUTION (MAINTENANCE FREE)
9	31512-SD4-020	Plate - BATTERY SETTING	Plate - BATTERY SETTING
10	31513-SA5-670	Bolt - BATTERY SETTING, 225MM	Bolt - BATTERY SETTING, 225MM
11	31513-SA7-811	Bolt - BATTERY SETTING, 215MM	Bolt - BATTERY SETTING, 215MM
12	31521-SD4-000	Box assy - BATTERY	Box assy - BATTERY
12	31521-SD4-010	Box assy - BATTERY	Box assy - BATTERY
13	31542-SA5-665	Plug - VENT (MF) (PANASONIC)	Plug - VENT (MF) (PANASONIC)
13	31542-SE3-902	Plug - VENT (MF) (YUASA)	Plug - VENT (MF) (YUASA)
1	32110-PL2-Y00	Harness - ENGINE WIRE	Harness - ENGINE WIRE
1	32110-PL2-Y10	Harness - ENGINE WIRE	Harness - ENGINE WIRE
9	32113-PH7-010	Holder - WIRE HARNESS COVER	Holder - WIRE HARNESS COVER
2	32114-PH7-000	Clamp - ENGINE WIRE HARNESS	Clamp - ENGINE WIRE HARNESS
3	32115-PH7-010	Clamp - FR. ENGINE WIRE HARNESS	Clamp - FR. ENGINE WIRE HARNESS
4	32116-PH7-010	Clamp - RR. ENGINE WIRE HARNESS	Clamp - RR. ENGINE WIRE HARNESS
5	32117-PL2-000	Clamp - ENGINE WIRE HARNESS	Clamp - ENGINE WIRE HARNESS
6	32118-PL2-000	Clamp - ENGINE WIRE HARNESS	Clamp - ENGINE WIRE HARNESS
15	32119-PH7-000	Clamp a - ENGINE WIRE HARNESS	Clamp a - ENGINE WIRE HARNESS
8	32123-PH7-000	Clamp - TDC SENSOR WIRE HARNESS	Clamp - TDC SENSOR WIRE HARNESS
16	32125-PH7-000	Clamp b - ENGINE WIRE HARNESS	Clamp b - ENGINE WIRE HARNESS
7	32126-PH7-310	Holder - FR. WIRE HARNESS LOWER	Holder - FR. WIRE HARNESS LOWER
8	32127-PH7-310	Holder - FR. WIRE HARNESS UPPER	Holder - FR. WIRE HARNESS UPPER
9	32128-PH7-310	Holder - RR. WIRE HARNESS LOWER	Holder - RR. WIRE HARNESS LOWER
10	32129-PH7-310	Holder - RR. WIRE HARNESS UPPER	Holder - RR. WIRE HARNESS UPPER
11	32132-PH7-000	Clamp a - OIL PRESSURE WIRE HARNESS	Clamp a - OIL PRESSURE WIRE HARNESS
12	32133-PH7-000	Clamp b - OIL PRESSURE WIRE HARNESS	Clamp b - OIL PRESSURE WIRE HARNESS
1	32134-PH7-662	Stay - CONTROL BOX COUPLER	Stay - CONTROL BOX COUPLER
13	32136-PL2-000	Clamp - ENGINE WIRE HARNESS (AIR CLEANER)	Clamp - ENGINE WIRE HARNESS (AIR CLEANER)
14	32137-PH7-000	Clamp - POWER STEERING SWITCH WIRE HARNESS	Clamp - POWER STEERING SWITCH WIRE HARNESS
2	32152-SD4-000	Separator - WIRE HARNESS (GRAY)	Separator - WIRE HARNESS (GRAY)
3	32160-SD4-000	Bracket - COUPLER HOLDER	Bracket - COUPLER HOLDER
6	32164-SD4-013	Holder - COUPLER	Holder - COUPLER
2	32166-SD4-000	Holder - COUPLER	Holder - COUPLER
1	32167-SD4-000	Bracket - WIPER COUPLER	Bracket - WIPER COUPLER
1	32168-SG0-000	Bracket - FAN RELAY	Bracket - FAN RELAY
20	32175-647-920	Clip - WIRE HARNESS	Clip - WIRE HARNESS
7	32410-SD4-J11	Cable assy - STARTER	Cable assy - STARTER
7	32410-SG0-J02	Cable assy - STARTER (SUMITOMO)	Cable assy - STARTER (SUMITOMO)
1	32558-SD4-A10	Harness - L. FR. SEAT WIRE	Harness - L. FR. SEAT WIRE
8	32600-SD4-A01	Cable assy - EARTH (SUMITOMO)	Cable assy - EARTH (SUMITOMO)
8	32600-SD4-A02	Cable assy - EARTH (FURUKAWA)	Cable assy - EARTH (FURUKAWA)
10	32601-SA5-003	Bolt - BATTERY TERMINAL (SUMITOMO)	Bolt - BATTERY TERMINAL (SUMITOMO)
9	32601-SK7-900	Bolt - BATTERY TERMINAL	Bolt - BATTERY TERMINAL
12	32602-SA5-003	Nut - BATTERY TERMINAL (SUMITOMO)	Nut - BATTERY TERMINAL (SUMITOMO)
11	32602-SK7-900	Nut - BATTERY TERMINAL	Nut - BATTERY TERMINAL
15	32610-SD3-600	Cable - SUB EARTH	Cable - SUB EARTH
1	32701-PL2-900	Cord comp - RESISTANCE (NO.1)	Cord comp - RESISTANCE (NO.1)
2	32702-PL2-900	Cord comp - RESISTANCE (NO.2)	Cord comp - RESISTANCE (NO.2)
3	32703-PL2-900	Cord comp - RESISTANCE (NO.3)	Cord comp - RESISTANCE (NO.3)
4	32704-PL2-900	Cord comp - RESISTANCE (NO.4)	Cord comp - RESISTANCE (NO.4)
5	32705-PL2-900	Cord comp - RESISTANCE (NO.5)	Cord comp - RESISTANCE (NO.5)
6	32706-PL2-900	Cord comp - RESISTANCE (NO.6)	Cord comp - RESISTANCE (NO.6)
24	32720-PL2-405	Cord comp - RR. HIGH TENSION	Cord comp - RR. HIGH TENSION
7	32720-PL2-900	Cord comp - RR. HIGH TENSION (###)	Cord comp - RR. HIGH TENSION (###)
25	32722-PL2-405	Cord comp - FR. HIGH TENSION	Cord comp - FR. HIGH TENSION
8	32722-PL2-900	Cord comp - FR. HIGH TENSION	Cord comp - FR. HIGH TENSION
9	32723-PL2-900	Cord comp - IGNITION CENTER	Cord comp - IGNITION CENTER
9	32745-PG2-A10	Clamp - BACK LIGHT HARNESS	Clamp - BACK LIGHT HARNESS
10	32762-PL2-010	Clamp f - HIGH TENSION & FUEL	Clamp f - HIGH TENSION & FUEL
11	32763-PH7-000	Clamp - HIGH TENSION CORD	Clamp - HIGH TENSION CORD
12	32764-PH7-003	Clamp - HIGH TENSION CORD	Clamp - HIGH TENSION CORD
13	32765-PA6-000	Clamp - HIGH TENSION CORD	Clamp - HIGH TENSION CORD
14	32766-PH7-000	Clamp a - DISTRIBUTOR CORD	Clamp a - DISTRIBUTOR CORD
15	32766-PL2-003	Clamp - HIGH TENSION CENTER CORD	Clamp - HIGH TENSION CENTER CORD
16	32767-PL2-000	Protector - HIGH TENSION CORD	Protector - HIGH TENSION CORD
17	32768-PH7-000	Stay - HIGH TENSION CORD CLAMP	Stay - HIGH TENSION CORD CLAMP
13	32768-PJ7-000	Clamp - CENTER CORD	Clamp - CENTER CORD
18	32769-PH7-000	Clamp b - HIGH TENSION CORD	Clamp b - HIGH TENSION CORD
19	32778-PH7-000	Clamp - RR. HIGH TENSION CORD	Clamp - RR. HIGH TENSION CORD
20	32779-PH7-000	Clamp - FR. HIGH TENSION CORD	Clamp - FR. HIGH TENSION CORD
5	33106-SB2-731	Screw - TAPPING, 6X20	Screw - TAPPING, 6X20
7	33115-692-741	Bulb - HEADLIGHT (12V 60/55W) (PHILIPS) (HALOGEN)	Bulb - HEADLIGHT (12V 60/55W) (PHILIPS) (HALOGEN)
6	33305-SE3-J01	Tube	Tube
7	33307-SD4-013	Packing - B	Packing - B
9	33308-SG0-A01	Cover	Cover
2	34253-671-003	Bulb - 12V 8W)(DAIICHI	Bulb - 12V 8W)(DAIICHI
1	34254-SD2-013	Lamp assy. - GLOVE BOX	Lamp assy. - GLOVE BOX
2	34257-SD4-000	Plate - COURTESY LIGHT	Plate - COURTESY LIGHT
3	34258-SD4-003	Lens - DAIICHI	Lens - DAIICHI
3	34258-SD4-004	Lens - IMASEN	Lens - IMASEN
1	34259-SD4-013	Lamp assy. - FUSE BOX	Lamp assy. - FUSE BOX
3	34260-SE3-003	Light assy - TRUNK ROOM	Light assy - TRUNK ROOM
4	34295-SA5-003	Bulb - 12V 3.4W) (DAIICHI	Bulb - 12V 3.4W) (DAIICHI
5	34295-SD4-003	Bulb - 12V 5W.K	Bulb - 12V 5W.K
4	34295-SD4-004	Bulb - 12V 5W) (IMASEN	Bulb - 12V 5W) (IMASEN
3	34504-SD4-003	Bulb assy - FOOT ILLUMINATION (14V 14W)	Bulb assy - FOOT ILLUMINATION (14V 14W)
21	34904-634-611	BULB (12V 5W) (ECE) - (12V, 5W) ECE	BULB (12V 5W) (ECE) - (12V, 5W) ECE
12	34908-634-611	Bulb - 12V 21W) (ECE) (STANLEY	Bulb - 12V 21W) (ECE) (STANLEY
21	34909-505-003	Bulb - 12V8W	Bulb - 12V8W
2	35100-SD4-G03	Lock assy - STEERING	Lock assy - STEERING
3	35102-SG0-003	Bolt - BREAK HEAD	Bolt - BREAK HEAD
3	35102-SV4-003	Bolt - BREAK HEAD	Bolt - BREAK HEAD
4	35103-SE3-003	Screw - RECESSED, 3X8	Screw - RECESSED, 3X8
5	35105-SD4-003	Ring - ILLUMINATION	Ring - ILLUMINATION
6	35106-SD4-013	Cover - ILLUMINATION RING	Cover - ILLUMINATION RING
7	35107-SD4-013	Cap - ILLUMINATION RING	Cap - ILLUMINATION RING
12	35130-SD4-A01	Switch comp - STEERING	Switch comp - STEERING
13	35131-SA5-621	Cylinder comp - STEERING	Cylinder comp - STEERING
2	35150-SD2-003	Controller - ILLUMINATION	Controller - ILLUMINATION
1	35151-SD4-A01	Volume assy - ILLUMINATION CONTROL	Volume assy - ILLUMINATION CONTROL
5	35156-SD4-003	Bulb - NEO WEDGE (A) (14V 1.12W)	Bulb - NEO WEDGE (A) (14V 1.12W)
6	35158-SD4-003	Bulb - 14V 0.84W	Bulb - 14V 0.84W
5	35159-SD4-003	Bulb - 14V 0.56W	Bulb - 14V 0.56W
7	35190-SD4-004	Switch assy - REMOTE CONTROL MIRROR	Switch assy - REMOTE CONTROL MIRROR
17	35400-SG0-023	Switch assy - DOOR	Switch assy - DOOR
18	35409-SG0-901	Screw - FLANGE, 6X12	Screw - FLANGE, 6X12
19	35410-692-003	Cover - DOOR SWITCH	Cover - DOOR SWITCH
19	35417-SE3-003	Cover - DOOR SWITCH	Cover - DOOR SWITCH
20	35450-SD4-A02	Switch assy - WIPER (A)	Switch assy - WIPER (A)
1	35453-SD4-003	Switch assy - RISE UP CONTROL	Switch assy - RISE UP CONTROL
9	35500-SD4-G03	Switch assy - RR. DEFOGGER	Switch assy - RR. DEFOGGER
2	35505-692-003	Bulb - 14V 1.4W	Bulb - 14V 1.4W
1	35505-SA5-003	Socket assy, BULB(14V 1.4W) (NS)(BASE:BLACK)	Socket assy, BULB(14V 1.4W) (NS)(BASE:BLACK)
2	35506-SA5-003	Bulb - 14V 1.4W	Bulb - 14V 1.4W
12	35510-SD4-A03	Switch assy - HAZARD (LH)	Switch assy - HAZARD (LH)
10	35600-PG2-003	Switch assy - BACK UP LIGHT (TEC)	Switch assy - BACK UP LIGHT (TEC)
11	35620-PG2-A12	Switch assy - NEUTRAL	Switch assy - NEUTRAL
3	35700-SD4-A02	Switch assy - INHIBITOR & BACK UP LIGHT	Switch assy - INHIBITOR & BACK UP LIGHT
1	35721-SD4-A80	Tube assy - SELECT	Tube assy - SELECT
8	35751-SD4-000	Bracket - FR. POWER WINDOW SWITCH	Bracket - FR. POWER WINDOW SWITCH
3	35810-SD4-A01	Switch - TRUNK OPENER MAIN	Switch - TRUNK OPENER MAIN
6	35851-SP1-901	Bulb b - NEO WEDGE(14V 100MA)	Bulb b - NEO WEDGE(14V 100MA)
4	36010-PA6-004	Joint - THREE WAY	Joint - THREE WAY
5	36010-PE0-004	Joint - THREE WAY	Joint - THREE WAY
6	36013-PE0-004	Holder - SOLENOID, 3.5MM	Holder - SOLENOID, 3.5MM
7	36013-PG7-661	Holder - SOLENOID, 3.5MM	Holder - SOLENOID, 3.5MM
8	36017-PG7-004	Washer - FREQUENCY SOLENOID VALVE	Washer - FREQUENCY SOLENOID VALVE
2	36017-PM3-004	Bolt - MOUNTING	Bolt - MOUNTING
3	36019-PH7-662	Cover - LOWER	Cover - LOWER
4	36020-PH7-661	Cover - UPPER	Cover - UPPER
5	36022-PL2-752	Label - CONTROL BOX	Label - CONTROL BOX
6	36023-PH7-661	Clamp - COVER	Clamp - COVER
7	36024-PL2-751	Holder - TUBE	Holder - TUBE
9	36032-PL2-004	Clamp assy - TUBE	Clamp assy - TUBE
9	36034-PL2-661	Stay comp	Stay comp
10	36034-PM6-901	Plug - SEALING	Plug - SEALING
10	36035-PL2-662	Base	Base
11	36036-PL2-661	Tube - CVC VALVE	Tube - CVC VALVE
11	36037-PL2-751	Bracket - IGNITION TIMING ADJUSTER	Bracket - IGNITION TIMING ADJUSTER
12	36041-PL2-751	Cord assy	Cord assy
14	36053-PM6-A01	Rubber - MOUNTING, 20MM	Rubber - MOUNTING, 20MM
15	36057-PH7-004	Screw - TAPPING, 4X25	Screw - TAPPING, 4X25
7	36061-671-000	Clamp a - TUBE	Clamp a - TUBE
16	36100-PG7-004	Filter assy - AIR	Filter assy - AIR
17	36134-PL2-661	Chamber comp - VACUUM	Chamber comp - VACUUM
8	36135-PJ0-661	Valve - DASHPOT CHECK	Valve - DASHPOT CHECK
18	36138-PE0-004	Filter assy - SOLENOID VALVE	Filter assy - SOLENOID VALVE
12	36138-PL2-003	Filter assy - SOLENOID VALVE	Filter assy - SOLENOID VALVE
13	36145-PA6-661	Valve - CHECK	Valve - CHECK
13	36145-PM4-004	Valve - CHECK	Valve - CHECK
19	36161-PH2-004	Valve assy. - IGNITION SOLENOID (#150-B)	Valve assy. - IGNITION SOLENOID (#150-B)
20	36166-PE7-662	Valve assy. - PURGE CUT SOLENOID	Valve assy. - PURGE CUT SOLENOID
21	36190-PL2-005	Valve assy. b - FREQUENCY SOLENOID	Valve assy. b - FREQUENCY SOLENOID
22	36194-PD2-661	Filter assy - AIR	Filter assy - AIR
14	36270-PL2-003	Valve assy. - RESONATOR CONTROL SOLENOID	Valve assy. - RESONATOR CONTROL SOLENOID
18	36450-PL2-003	Valve assy. - EIC	Valve assy. - EIC
19	36454-PS4-003	Filter comp - ELECTRONIC AIR CONTROL VALVE (TOYO ROKI)	Filter comp - ELECTRONIC AIR CONTROL VALVE (TOYO ROKI)
20	36455-PR4-A01	Packing - ELECTRONIC AIR CONTROL VALVE (DENSO)	Packing - ELECTRONIC AIR CONTROL VALVE (DENSO)
20	36455-PT3-A01	Packing, ELECTRONIC AIR CONTROL VALVE (DENSO)	Packing, ELECTRONIC AIR CONTROL VALVE (DENSO)
21	36456-PH7-000	Packing - COVER	Packing - COVER
10	36517-PL2-000	Tube - AUTO CRUISE	Tube - AUTO CRUISE
15	36625-PC6-003	Tank comp. - VACUUM	Tank comp. - VACUUM
16	36626-PL2-000	Stay - VACUUM TANK	Stay - VACUUM TANK
2	36760-SE0-003	Switch assy - CLUTCH(TEC)	Switch assy - CLUTCH(TEC)
3	37102-SE3-003	Socket assy - BULB (T-10) (NS)	Socket assy - BULB (T-10) (NS)
4	37105-SF0-003	Socket assy - BULB (14V) (BASE:BLACK)	Socket assy - BULB (14V) (BASE:BLACK)
5	37106-SA0-023	Knob - TRIP	Knob - TRIP
6	37114-671-004	Grommet - TRIP KNOB (DENSO)	Grommet - TRIP KNOB (DENSO)
7	37115-SA0-601	Packing - NS	Packing - NS
4	37120-SD4-003	Buzzer - SPEED ALARM	Buzzer - SPEED ALARM
8	37237-SE3-003	Bulb - T-10) (BASE:BROWN	Bulb - T-10) (BASE:BROWN
10	37240-657-013	Switch - OIL PRESSURE (DENSO)	Switch - OIL PRESSURE (DENSO)
10	37240-P13-013	Switch assy - OIL PRESSURE (DENSO)	Switch assy - OIL PRESSURE (DENSO)
10	37240-PA6-004	Switch - OIL PRESSURE (TEC)	Switch - OIL PRESSURE (TEC)
1	37271-SA0-000	Nut - FLOATING, 5MM	Nut - FLOATING, 5MM
23	37540-SE0-Q01	Sensor - STOP LAMP FAILURE	Sensor - STOP LAMP FAILURE
24	37540-SE3-A01	Sensor - STOP LAMP FAILURE	Sensor - STOP LAMP FAILURE
6	37700-SD4-981	Lamp assy. - INDICATOR (AT)	Lamp assy. - INDICATOR (AT)
2	37735-PH7-023	Control unit - RADIATOR FAN	Control unit - RADIATOR FAN
3	37736-PH7-661	Stay - FR. FAN CONTROL UNIT	Stay - FR. FAN CONTROL UNIT
4	37737-PH7-662	Stay - RR. FAN CONTROL UNIT	Stay - RR. FAN CONTROL UNIT
16	37750-PH2-014	Thermo unit - DENSO	Thermo unit - DENSO
21	37760-PH7-003	Sensor assy - RADIATOR FAN CONTROL (MATSUSHITA)	Sensor assy - RADIATOR FAN CONTROL (MATSUSHITA)
17	37770-PH7-662	Sensor - THERMO (A-105)	Sensor - THERMO (A-105)
21	37801-SE3-000	Packing - BASE	Packing - BASE
22	37802-SE0-000	Retainer - FUEL UNIT	Retainer - FUEL UNIT
25	37830-PL2-662	Sensor assy - MAP	Sensor assy - MAP
5	37836-PH7-003	Sensor comp - PA	Sensor comp - PA
9	37840-PL2-016	Sensor assy - CYLINDER	Sensor assy - CYLINDER
26	37860-PL2-662	Adjuster - IGNITION TIMING	Adjuster - IGNITION TIMING
19	37870-PD6-003	Sensor assy - WATER TEMP	Sensor assy - WATER TEMP
20	37872-PD6-000	Cover - TW SENSOR	Cover - TW SENSOR
10	37880-PE2-013	Sensor assy - AIR TEMP	Sensor assy - AIR TEMP
11	37911-PH7-752	Resistor assy - K-1	Resistor assy - K-1
11	37912-PH7-752	Resistor assy - K-2	Resistor assy - K-2
11	37913-PH7-752	Resistor assy - K-3	Resistor assy - K-3
11	37914-PH7-752	Resistor assy - K-4	Resistor assy - K-4
11	37915-PH7-752	Resistor assy - K-5	Resistor assy - K-5
11	37916-PH7-752	Resistor assy - K-6	Resistor assy - K-6
11	37917-PH7-752	Resistor assy - K-7	Resistor assy - K-7
3	38100-SD4-Y01	Horn assy - LOW	Horn assy - LOW
4	38150-SD4-Y01	Horn assy - HIGH (MITSUBA)	Horn assy - HIGH (MITSUBA)
17	38211-SD2-000	Fuse - BLOCK (30A)	Fuse - BLOCK (30A)
18	38212-SE0-000	Fuse - BLOCK (40A)	Fuse - BLOCK (40A)
19	38215-SE0-000	Fuse - BLOCK (70A)	Fuse - BLOCK (70A)
8	38235-SA5-003	Puller - FUSE (SUMITOMO)	Puller - FUSE (SUMITOMO)
21	38245-SD4-J00	Bracket - RELAY BOX	Bracket - RELAY BOX
9	38290-SD4-942	Relay assy - INTERMITTENT WIPER (RISE UP CONTROL)	Relay assy - INTERMITTENT WIPER (RISE UP CONTROL)
10	38300-SB0-004	Relay assy - TURN SIGNAL & HAZARD (DENSO)	Relay assy - TURN SIGNAL & HAZARD (DENSO)
10	38300-SB0-013	Relay assy - TURN SIGNAL & HAZARD (MITSUBA)	Relay assy - TURN SIGNAL & HAZARD (MITSUBA)
13	38380-SD4-A01	Control unit - AUTO DOOR LOCK	Control unit - AUTO DOOR LOCK
2	38461-SB0-003	Nut - WIPER ARM CAP, 10MM	Nut - WIPER ARM CAP, 10MM
3	38513-SB0-961	Cap - WASHER MOUTH(MITSUBA)	Cap - WASHER MOUTH(MITSUBA)
4	38562-663-920	Joint b - WASHER TUBE (MITSUBA)	Joint b - WASHER TUBE (MITSUBA)
5	38571-SA5-621	Valve - ONE WAY (MITSUBA)	Valve - ONE WAY (MITSUBA)
15	38600-SD4-Y03	Control unit - INTEGRATED	Control unit - INTEGRATED
21	38608-692-000	Rubber - MOUNTING	Rubber - MOUNTING
22	38609-692-000	Collar - DISTANCE	Collar - DISTANCE
1	38611-PL2-003	Fan comp - COOLING (DENSO)	Fan comp - COOLING (DENSO)
16	38611-SD4-G00	Bracket - INTEGRATED UNIT	Bracket - INTEGRATED UNIT
2	38613-PH7-013	Resistor assy - DENSO	Resistor assy - DENSO
3	38615-PL2-003	Shroud comp - DENSO	Shroud comp - DENSO
4	38616-PH7-003	Motor - COOLING FAN (DENSO)	Motor - COOLING FAN (DENSO)
5	38619-PH7-003	Protector - FAN MOTOR	Protector - FAN MOTOR
1	38641-671-013	Valve - SAFETY	Valve - SAFETY
2	38646-SA5-003	O-ring - 8MM	O-ring - 8MM
3	38647-692-660	O-ring - 1/2"	O-ring - 1/2"
4	38648-692-660	O-ring - 5/8"	O-ring - 5/8"
5	38673-SB0-000	Clamp - SUCTION PIPE	Clamp - SUCTION PIPE
3	38811-671-003	Circlip a - EXTERNAL	Circlip a - EXTERNAL
4	38812-671-003	Ring a - SNAP	Ring a - SNAP
5	38813-671-003	Washer a - PLATE	Washer a - PLATE
5	38814-671-003	Washer b - PLATE	Washer b - PLATE
5	38815-671-003	Washer c - PLATE	Washer c - PLATE
6	38816-689-003	Clip - LEAD WIRE	Clip - LEAD WIRE
22	38827-PH7-003	Screw-washer - 5X8	Screw-washer - 5X8
7	38834-PD2-003	Seal assy - SHAFT	Seal assy - SHAFT
8	38836-PD2-003	Key	Key
9	38844-PD2-003	Ring - SNAP	Ring - SNAP
14	38942-PH3-003	Pulley comp - IDLE	Pulley comp - IDLE
15	38944-PH3-003	Collar - IDLE PULLEY (DENSO)	Collar - IDLE PULLEY (DENSO)
16	38945-PH3-003	Cover - BEARING	Cover - BEARING
17	38946-PH3-003	Shaft comp. - IDLE (DENSO)	Shaft comp. - IDLE (DENSO)
18	38947-PL2-000	Nut - IDLE PULLEY	Nut - IDLE PULLEY
1	39100-SD4-Y01	Tuner assy - AUTO RADIO (FM/MW/SW+CASSETTE) (PIONEER)	Tuner assy - AUTO RADIO (FM/MW/SW+CASSETTE) (PIONEER)
12	39102-SA6-681	Knob - PIONEER	Knob - PIONEER
25	39110-671-661	Fuse - 3A	Fuse - 3A
27	39114-SA6-681	Knob - SWITCH (PIONEER)	Knob - SWITCH (PIONEER)
28	39116-SA6-681	Knob - FADER (PIONEER)	Knob - FADER (PIONEER)
25	39170-SD4-A00	Valve - RR. MOTOR ANTENNA DRAIN	Valve - RR. MOTOR ANTENNA DRAIN
1	39223-692-003	Pivot - ADJUSTABLE	Pivot - ADJUSTABLE
2	39242-671-670	Fan - HEATER	Fan - HEATER
1	39246-671-003	Clamp - CASE HOLD	Clamp - CASE HOLD
10	39321-SB0-003	Tank comp. - VACUUM	Tank comp. - VACUUM
1	39383-SA5-000	Clamp - CONTROL CABLE	Clamp - CONTROL CABLE
2	39397-SA5-003	Bulb - NEO WEDGE (14V 100MA)	Bulb - NEO WEDGE (14V 100MA)
20	39400-SD4-003	Relay assy - MAIN (PGM-FI)	Relay assy - MAIN (PGM-FI)
50	39610-SD4-405	Knob comp. - CIGARETTE LIGHTER	Knob comp. - CIGARETTE LIGHTER
51	39620-SD4-309	Socket assy - CIGARETTE LIGHTER	Socket assy - CIGARETTE LIGHTER
2	39700-SG0-003	Clock assy - DIGITAL (JECO)	Clock assy - DIGITAL (JECO)
2	39700-SG0-004	Clock assy - DIGITAL (NS)	Clock assy - DIGITAL (NS)
22	39762-SG0-003	Relay assy - POWER (5P) (DENSO) (056700-8160)	Relay assy - POWER (5P) (DENSO) (056700-8160)
22	39792-SE0-003	Relay assy - POWER(4P)(DENSO) (056700-7410)	Relay assy - POWER(4P)(DENSO) (056700-7410)
23	39792-SE0-004	Relay assy - POWER (4P) (OMRON) (G4R-1A21T-H22)	Relay assy - POWER (4P) (OMRON) (G4R-1A21T-H22)
24	39794-SB0-922	Relay assy - POWER (4P) (OMRON) (G2MS-1121T-100R)	Relay assy - POWER (4P) (OMRON) (G2MS-1121T-100R)
24	39794-SE0-003	Relay assy - POWER(4P)(DENSO) (056700-7250)	Relay assy - POWER(4P)(DENSO) (056700-7250)
24	39794-SE0-004	Relay assy - POWER (4P) (MITSUBA) (RC-2203)	Relay assy - POWER (4P) (MITSUBA) (RC-2203)
23	39795-SB2-003	Relay assy - POWER (4P) (MITSUBA) (RC-2201)	Relay assy - POWER (4P) (MITSUBA) (RC-2201)
4	39797-SE0-003	Relay assy - POWER (4P) (DENSO) (056700-7330)	Relay assy - POWER (4P) (DENSO) (056700-7330)
4	39797-SE0-004	Relay assy - POWER (4P) (MITSUBA) (RC-2201)	Relay assy - POWER (4P) (MITSUBA) (RC-2201)
8	39798-SE0-003	Relay assy - POWER (4P) (058700-1170) (DENSO)	Relay assy - POWER (4P) (058700-1170) (DENSO)
2	41233-PG2-960	Gear - FINAL DRIVEN	Gear - FINAL DRIVEN
2	41233-PL5-000	Gear - FINAL DRIVEN	Gear - FINAL DRIVEN
3	41310-PG2-A10	Case comp. - DIFFERENTIAL	Case comp. - DIFFERENTIAL
3	41310-PL5-J00	Case comp. - DIFFERENTIAL	Case comp. - DIFFERENTIAL
4	41321-PG2-A10	Shaft - PINION	Shaft - PINION
6	41351-PG1-000	Washer a - DIFFERENTIAL PINION THRUST(0.7MM)	Washer a - DIFFERENTIAL PINION THRUST(0.7MM)
6	41352-PG1-000	Washer b - DIFFERENTIAL PINION THRUST(0.75MM)	Washer b - DIFFERENTIAL PINION THRUST(0.75MM)
6	41353-PG1-000	Washer c - DIFFERENTIAL PINION THRUST(0.8MM)	Washer c - DIFFERENTIAL PINION THRUST(0.8MM)
6	41354-PG1-000	Washer d - DIFFERENTIAL PINION THRUST(0.85MM)	Washer d - DIFFERENTIAL PINION THRUST(0.85MM)
6	41355-PG1-000	Washer e - DIFFERENTIAL PINION THRUST(0.9MM)	Washer e - DIFFERENTIAL PINION THRUST(0.9MM)
6	41356-PG1-000	Washer f - DIFFERENTIAL PINION THRUST(0.95MM)	Washer f - DIFFERENTIAL PINION THRUST(0.95MM)
6	41357-PG1-000	Washer g - DIFFERENTIAL PINION THRUST(1.0MM)	Washer g - DIFFERENTIAL PINION THRUST(1.0MM)
6	41358-PG1-000	Washer h - DIFFERENTIAL PINION THRUST(1.05MM)	Washer h - DIFFERENTIAL PINION THRUST(1.05MM)
7	41371-PG2-000	Washer - THRUST, 37X55X1.5	Washer - THRUST, 37X55X1.5
8	41380-PG2-A10	Shim - 75MM	Shim - 75MM
9	41381-PG2-020	Shim a - 68MM (1.90)	Shim a - 68MM (1.90)
8	41381-PG4-000	Shim a - 80MM (0.90)	Shim a - 80MM (0.90)
9	41382-PG2-030	Shim b - 68MM (1.93)	Shim b - 68MM (1.93)
8	41382-PG4-000	Shim b - 80MM (0.95)	Shim b - 80MM (0.95)
9	41383-PG2-030	Shim c - 68MM (1.96)	Shim c - 68MM (1.96)
8	41383-PG4-000	Shim c - 80MM (1.00)	Shim c - 80MM (1.00)
9	41384-PG2-030	Shim d - 68MM (1.99)	Shim d - 68MM (1.99)
8	41384-PG4-000	Shim d - 80MM (1.05)	Shim d - 80MM (1.05)
9	41385-PG2-030	Shim e - 68MM (2.02)	Shim e - 68MM (2.02)
8	41385-PG4-000	Shim e - 80MM (1.10)	Shim e - 80MM (1.10)
9	41386-PG2-030	Shim f - 68MM (2.05)	Shim f - 68MM (2.05)
8	41386-PG4-000	Shim f - 80MM (1.15)	Shim f - 80MM (1.15)
9	41387-PG2-030	Shim g - 68MM (2.08)	Shim g - 68MM (2.08)
8	41387-PG4-000	Shim g - 80MM (1.20)	Shim g - 80MM (1.20)
9	41388-PG2-020	Shim h - 68MM (2.11)	Shim h - 68MM (2.11)
8	41388-PG4-000	Shim h - 80MM (1.25)	Shim h - 80MM (1.25)
9	41389-PG2-020	Shim i - 68MM (2.14)	Shim i - 68MM (2.14)
8	41389-PG4-000	Shim i - 80MM (1.30)	Shim i - 80MM (1.30)
9	41390-PG2-020	Shim j - 68MM (2.17)	Shim j - 68MM (2.17)
8	41390-PG4-000	Shim j - 80MM (1.35)	Shim j - 80MM (1.35)
9	41391-PG2-010	Shim k - 68MM (2.20)	Shim k - 68MM (2.20)
8	41391-PG4-000	Shim k - 80MM (2.15)	Shim k - 80MM (2.15)
9	41392-PG2-010	Shim l - 68MM (2.23)	Shim l - 68MM (2.23)
8	41392-PG4-000	Shim l - 80MM (2.20)	Shim l - 80MM (2.20)
9	41393-PG2-000	Shim m - 68MM (2.26)	Shim m - 68MM (2.26)
8	41393-PG4-000	Shim m - 80MM (2.25)	Shim m - 80MM (2.25)
9	41394-PG2-000	Shim n - 68MM (2.29)	Shim n - 68MM (2.29)
8	41394-PG4-000	Shim n - 80MM (2.30)	Shim n - 80MM (2.30)
9	41395-PG2-000	Shim o - 68MM (2.32)	Shim o - 68MM (2.32)
8	41395-PG4-000	Shim o - 80MM (2.35)	Shim o - 80MM (2.35)
9	41396-PG2-000	Shim p - 68MM (2.35)	Shim p - 68MM (2.35)
8	41396-PG4-000	Shim p - 80MM (2.40)	Shim p - 80MM (2.40)
9	41397-PG2-000	Shim q - 68MM (2.38)	Shim q - 68MM (2.38)
8	41397-PG4-000	Shim q - 80MM (2.45)	Shim q - 80MM (2.45)
9	41398-PG2-000	Shim r - 68MM (2.41)	Shim r - 68MM (2.41)
9	41399-PG2-000	Shim s - 68MM (2.44)	Shim s - 68MM (2.44)
9	41400-PG2-000	Shim t - 68MM (2.47)	Shim t - 68MM (2.47)
2	42324-SD4-020	Washer - RR. HUB	Washer - RR. HUB
3	42326-SG0-000	Cap - HUB UNIT	Cap - HUB UNIT
4	42510-SD4-930	Disk - RR. BRAKE	Disk - RR. BRAKE
1	42700-SD4-681	Disk - WHEEL (15X5 1/2JJ) (KANAI)(FROSTED BLACK)	Disk - WHEEL (15X5 1/2JJ) (KANAI)(FROSTED BLACK)
6	42753-671-003	Valve - RIM (TAIHEIYO)	Valve - RIM (TAIHEIYO)
6	42753-SB8-661	Valve - RIM (SCHRADER)	Valve - RIM (SCHRADER)
6	42753-SE0-A02	Valve - RIM (SCHRADER)	Valve - RIM (SCHRADER)
1	43022-SG0-020	Pad set - RR.	Pad set - RR.
2	43209-371-006	Seal - PISTON (38MM)	Seal - PISTON (38MM)
3	43210-SG0-033	Caliper assy - R. RR. (NISSIN) (11CLP-14S)	Caliper assy - R. RR. (NISSIN) (11CLP-14S)
4	43214-SG0-003	Cover - PISTON DUST	Cover - PISTON DUST
5	43215-SG0-003	Piston assy.	Piston assy.
6	43218-SD2-931	Cup	Cup
7	43223-SD2-932	BEARING A	BEARING A
8	43224-SD2-931	Spring b - ADJUSTING	Spring b - ADJUSTING
9	43224-SG0-003	Shim - BRAKE PAD OUTER	Shim - BRAKE PAD OUTER
10	43225-SG0-003	Shim - BRAKE PAD INNER	Shim - BRAKE PAD INNER
11	43227-SG0-013	Spring - PAD	Spring - PAD
12	43228-SD2-933	Shaft a	Shaft a
13	43229-SD2-931	Rod	Rod
14	43230-SG0-033	Caliper assy - L. RR. (NISSIN) (11CLP-14S)	Caliper assy - L. RR. (NISSIN) (11CLP-14S)
15	43232-SD2-931	O-ring	O-ring
16	43233-SD2-931	Piston comp - SLEEVE	Piston comp - SLEEVE
17	43234-S04-003	Cover - DUST	Cover - DUST
17	43234-SD2-931	Cover - DUST	Cover - DUST
18	43235-SD2-931	Pin a	Pin a
19	43236-S04-003	Spacer	Spacer
19	43236-SD2-931	Spacer	Spacer
20	43238-SG0-003	Ring - RETAINING	Ring - RETAINING
21	43241-SG0-003	Guide - SPRING	Guide - SPRING
22	43242-SD2-933	Cover - SHAFT	Cover - SHAFT
23	43243-SD2-931	Nut - PARKING	Nut - PARKING
24	43244-SG0-003	Retainer	Retainer
25	43245-SE0-931	Lever	Lever
26	43246-SE0-931	Spring - R. RETURN	Spring - R. RETURN
27	43247-SE0-931	Arm - R.	Arm - R.
28	43248-SD2-933	Shaft b	Shaft b
29	43249-SG0-003	Bolt - ADJUSTING (###)	Bolt - ADJUSTING (###)
7	43255-SG0-020	Protector - R. RR. CALIPER	Protector - R. RR. CALIPER
8	43256-SG0-020	Protector - L. RR. CALIPER	Protector - L. RR. CALIPER
30	43262-S84-A51	Pin b	Pin b
30	43262-SD2-931	Pin b	Pin b
31	43266-SE0-931	Spring - L. RETURN	Spring - L. RETURN
32	43267-SE0-931	Arm - L.	Arm - L.
1	43352-567-000	Screw - BLEEDER	Screw - BLEEDER
1	43352-692-003	Screw - BLEEDER	Screw - BLEEDER
2	43353-548-003	Cap - BLEEDER SCREW	Cap - BLEEDER SCREW
2	43353-SA0-003	Cap - BLEEDER SCREW	Cap - BLEEDER SCREW
2	43353-SD5-003	Cap - BLEEDER SCREW	Cap - BLEEDER SCREW
1	43471-SD2-930	Pin - BRAKE WIRE END	Pin - BRAKE WIRE END
1	44300-SG0-004	Bearing assy - FR. HUB (KOYO SEIKO)	Bearing assy - FR. HUB (KOYO SEIKO)
2	44310-SD4-300	Joint comp - INBOARD	Joint comp - INBOARD
3	44310-SD4-900	Joint comp - INBOARD	Joint comp - INBOARD
4	44319-SD4-010	Set ring - 30X2.2	Set ring - 30X2.2
5	44323-SD4-901	Boot - OUTBOARD	Boot - OUTBOARD
6	44325-SD4-901	Boot - INBOARD	Boot - INBOARD
7	44327-SB0-300	Band - OUTBOARD BOOT	Band - OUTBOARD BOOT
9	44329-SC2-300	Band - SHAFT BOOT	Band - SHAFT BOOT
10	44336-SD4-300	Ring a - STOPPER	Ring a - STOPPER
11	44338-SD4-300	Circlip - 28MM	Circlip - 28MM
1	44500-SD4-J00	Shaft assy - HALF	Shaft assy - HALF
2	44510-SD4-900	Shaft comp. - HALF	Shaft comp. - HALF
3	44511-SD4-000	Support - HALF SHAFT BEARING	Support - HALF SHAFT BEARING
4	44517-SD4-030	Cover - HEAT	Cover - HEAT
4	44517-SD4-902	Cover - HEAT	Cover - HEAT
2	44600-SG0-000	Hub assy - FR.	Hub assy - FR.
6	45214-SD4-003	Boot - PISTON	Boot - PISTON
6	45214-SM4-003	Boot - PISTON	Boot - PISTON
7	45216-SG0-003	Piston	Piston
8	45217-SD4-003	Seal - PISTON	Seal - PISTON
9	45225-SD4-003	Shim a - INNER	Shim a - INNER
10	45226-SD4-013	Shim b - INNER	Shim b - INNER
11	45227-SG0-013	Spring - PAD	Spring - PAD
12	45228-SD4-003	Shim - BRAKE PAD	Shim - BRAKE PAD
14	45234-SD4-003	Boot - PIN	Boot - PIN
15	45235-SD4-023	Pin	Pin
16	45237-SD4-003	Retainer	Retainer
17	45240-SA7-003	Bolt - FLANGE, 8X22	Bolt - FLANGE, 8X22
35	45240-SC2-003	Bolt - FLANGE, 8X22	Bolt - FLANGE, 8X22
3	45251-SG0-J00	Disk - FR. BRAKE	Disk - FR. BRAKE
4	45255-SG0-020	Guard - FR. SPLASH	Guard - FR. SPLASH
3	46164-632-000	Float	Float
4	46182-500-013	Circlip	Circlip
5	46184-611-000	Dust seal - MASTER CYLINDER	Dust seal - MASTER CYLINDER
1	46191-634-000	Gasket - MASTER CYLINDER BRACKET	Gasket - MASTER CYLINDER BRACKET
2	46192-SD2-003	Spacer	Spacer
3	46193-SD2-003	Seal - MASTER POWER	Seal - MASTER POWER
3	46217-579-000	Clip - TUBE	Clip - TUBE
3	46331-SD4-000	Pipe comp. e - R. BRAKE	Pipe comp. e - R. BRAKE
6	46361-SD4-000	Pipe comp. e - L. BRAKE	Pipe comp. e - L. BRAKE
16	46380-SB0-000	Grommet a - BRAKE PIPE (BLACK)	Grommet a - BRAKE PIPE (BLACK)
17	46382-SA0-300	Grommet a - BRAKE PIPE	Grommet a - BRAKE PIPE
18	46391-692-003	Clip s - BRAKE PIPE	Clip s - BRAKE PIPE
23	46392-692-003	Clip d - BRAKE PIPE (WHITE)	Clip d - BRAKE PIPE (WHITE)
19	46392-SB0-010	Clip d - BRAKE PIPE (BLACK)	Clip d - BRAKE PIPE (BLACK)
20	46392-SB2-014	Clip b - BRAKE PIPE	Clip b - BRAKE PIPE
21	46392-SD4-010	Clip - BRAKE PIPE	Clip - BRAKE PIPE
22	46392-SF0-000	Clip - BRAKE PIPE	Clip - BRAKE PIPE
24	46394-SB0-682	Clip b	Clip b
4	46400-SD4-A31	Power assy. - MASTER (8"+9")	Power assy. - MASTER (8"+9")
5	46401-SA5-013	Valve assy. - CHECK	Valve assy. - CHECK
6	46404-SG0-A00	Tube a - MASTER POWER	Tube a - MASTER POWER
9	46405-SD4-670	Tube b - MASTER POWER	Tube b - MASTER POWER
25	46410-SD4-903	Hose assy - R. FR. BRAKE (MEIJI)	Hose assy - R. FR. BRAKE (MEIJI)
26	46411-SD4-903	Hose assy - L. FR. BRAKE (MEIJI)	Hose assy - L. FR. BRAKE (MEIJI)
27	46428-SD4-014	Bracket - R. FR. BRAKE	Bracket - R. FR. BRAKE
28	46429-SD4-014	Bracket - L. FR. BRAKE	Bracket - L. FR. BRAKE
30	46431-SE0-934	Hose b - RR. BRAKE (NICHIRIN)	Hose b - RR. BRAKE (NICHIRIN)
30	46431-SE0-935	Hose b - RR. BRAKE (MEIJI)	Hose b - RR. BRAKE (MEIJI)
31	46435-SG0-000	Bracket - R. RR. BRAKE HOSE	Bracket - R. RR. BRAKE HOSE
32	46436-SG0-000	Bracket - L. RR. BRAKE HOSE	Bracket - L. RR. BRAKE HOSE
33	46438-SG0-010	Bracket - R. RR. BRAKE HOSE	Bracket - R. RR. BRAKE HOSE
34	46439-SG0-010	Bracket - L. RR. BRAKE HOSE	Bracket - L. RR. BRAKE HOSE
1	46462-SE0-000	Bolt - OIL	Bolt - OIL
2	46472-568-000	Packing - OIL BOLT	Packing - OIL BOLT
4	46504-679-300	Bush - PEDAL	Bush - PEDAL
3	46504-SD4-300	Bush - PEDAL	Bush - PEDAL
5	46505-SA5-000	Pad - PEDAL STOPPER	Pad - PEDAL STOPPER
6	46510-SG0-A00	Pedal - BRAKE	Pedal - BRAKE
7	46510-SG0-A82	Pedal - BRAKE	Pedal - BRAKE
11	46512-SB2-000	Pin - PEDAL	Pin - PEDAL
8	46520-SD4-670	Holder - BRACKET	Holder - BRACKET
8	46520-SG0-A00	Holder - BRACKET	Holder - BRACKET
9	46530-SD4-670	Spring - PEDAL RETURN	Spring - PEDAL RETURN
10	46535-692-000	Collar - PEDAL	Collar - PEDAL
11	46536-SD4-670	Plate a	Plate a
11	46536-SG0-A00	Plate a	Plate a
12	46537-SD4-670	Plate b	Plate b
13	46538-SD4-670	Collar - BRACKET HOLDER	Collar - BRACKET HOLDER
14	46545-SA5-000	Cover, Pedal	Cover, Pedal
15	46545-SE0-980	Cover - BRAKE PEDAL	Cover - BRAKE PEDAL
16	46590-SD4-672	Bracket - BRAKE PEDAL	Bracket - BRAKE PEDAL
16	46590-SG0-A00	Bracket - BRAKE PEDAL	Bracket - BRAKE PEDAL
6	46660-SD4-013	Tank - RESERVE	Tank - RESERVE
7	46662-SD4-033	Cap comp. - RESERVE TANK	Cap comp. - RESERVE TANK
8	46666-SD4-013	Filter - BRAKE RESERVOIR	Filter - BRAKE RESERVOIR
9	46669-692-003	Seal - RESERVE TANK	Seal - RESERVE TANK
10	46671-SD4-003	O-ring - 49.7X2.4	O-ring - 49.7X2.4
17	46910-SG0-A00	Pedal - CLUTCH	Pedal - CLUTCH
18	46911-SD4-003	Bush - PEDAL PIN	Bush - PEDAL PIN
7	46912-SD4-000	Pin - CLUTCH PEDAL	Pin - CLUTCH PEDAL
8	46920-SD4-A01	Cylinder assy. - CLUTCH MASTER (NISSIN)	Cylinder assy. - CLUTCH MASTER (NISSIN)
9	46921-SD4-980	Plate - MASTER CYLINDER HOLE	Plate - MASTER CYLINDER HOLE
10	46922-SD4-980	Plate b - MASTER CYLINDER HOLE	Plate b - MASTER CYLINDER HOLE
11	46926-SF1-003	Piston assy.	Piston assy.
12	46928-SD4-000	Seal - CLUTCH MASTER CYLINDER	Seal - CLUTCH MASTER CYLINDER
13	46929-SD4-A00	Packing - OIL BOLT	Packing - OIL BOLT
14	46930-SD4-901	Cylinder assy. - SLAVE	Cylinder assy. - SLAVE
15	46932-SD4-901	Piston - SLAVE CYLINDER	Piston - SLAVE CYLINDER
16	46933-SD4-901	Cup a - PISTON	Cup a - PISTON
17	46934-SD4-901	Cup b - PISTON	Cup b - PISTON
18	46935-SD4-003	Spring - SLAVE CYLINDER	Spring - SLAVE CYLINDER
19	46936-SD4-000	Collar - CLUTCH PEDAL	Collar - CLUTCH PEDAL
19	46937-SD4-003	Boot - SLAVE CYLINDER	Boot - SLAVE CYLINDER
20	46938-SD4-003	Rod - PUSH	Rod - PUSH
21	46950-SD4-023	Rod assy - PUSH	Rod assy - PUSH
22	46952-SD4-003	Joint - TUBE	Joint - TUBE
23	46953-SD4-003	Packing	Packing
24	46960-SD4-A00	Pipe assy. - CLUTCH	Pipe assy. - CLUTCH
24	46960-SD4-A01	Pipe assy.,clutch	Pipe assy.,clutch
25	46963-SD4-020	Bolt - CLUTCH OIL	Bolt - CLUTCH OIL
26	46966-SD4-670	Holder - TANK	Holder - TANK
27	46970-SG0-A01	Pipe comp - CLUTCH	Pipe comp - CLUTCH
28	46971-SD4-671	Tube - CLUTCH FLUID	Tube - CLUTCH FLUID
29	46972-SD4-003	Tank - CLUTCH FLUID	Tank - CLUTCH FLUID
30	46973-SD4-003	Cap comp. - RESERVE TANK	Cap comp. - RESERVE TANK
31	46975-SD4-003	Seal - RESERVE TANK	Seal - RESERVE TANK
20	46980-SD4-930	Spring - CLUTCH ASSISTANT	Spring - CLUTCH ASSISTANT
21	46981-SD4-930	Bush a - CLUTCH ASSISTANT	Bush a - CLUTCH ASSISTANT
22	46982-SD4-930	Bush b - CLUTCH ASSISTANT	Bush b - CLUTCH ASSISTANT
23	46987-SD4-670	Collar - CLUTCH MOUNTING	Collar - CLUTCH MOUNTING
24	46988-SD4-670	Rubber - CLUTCH MOUNTING	Rubber - CLUTCH MOUNTING
25	46990-SD4-671	Bracket - CLUTCH PEDAL	Bracket - CLUTCH PEDAL
26	46991-SG0-A00	Cover - FOOTREST	Cover - FOOTREST
27	46992-SG0-A00	Pad - FOOTREST	Pad - FOOTREST
32	46993-SG0-A02	Damper assy. - CLUTCH (NISSIN)	Damper assy. - CLUTCH (NISSIN)
3	47122-SD4-672	Cover - PARKING BRAKE	Cover - PARKING BRAKE
4	47142-671-010	Knob - PARKING BRAKE PUSH ROD	Knob - PARKING BRAKE PUSH ROD
5	47143-SD4-300	Spring - PUSH ROD	Spring - PUSH ROD
6	47190-SD4-010	Packing - PARKING BRAKE COVER	Packing - PARKING BRAKE COVER
7	47342-SA5-013	Switch - PARKING BRAKE	Switch - PARKING BRAKE
8	47360-SD4-000	Equalizer	Equalizer
10	47513-SD4-000	Holder - WIRE GUIDE	Holder - WIRE GUIDE
13	47538-SD4-003	Nut - ADJUSTING	Nut - ADJUSTING
14	47572-SD4-000	Base - WIRE GUIDE	Base - WIRE GUIDE
15	47574-SD4-000	Spring - RETURN	Spring - RETURN
1	50100-SG0-010	Beam - CENTER	Beam - CENTER
2	50200-SD4-676	Beam - RR.	Beam - RR.
3	50230-SG0-010	Insulator a - SUB FRAME MOUNTING	Insulator a - SUB FRAME MOUNTING
4	50231-SE0-010	Insulator b - SUB FRAME MOUNTING	Insulator b - SUB FRAME MOUNTING
5	50232-SD4-000	Washer - SUB FRAME (A)	Washer - SUB FRAME (A)
6	50235-SG0-000	Insulator c - SUB FRAME MOUNTING	Insulator c - SUB FRAME MOUNTING
7	50236-SD4-000	Insulator d - SUB FRAME MOUNTING	Insulator d - SUB FRAME MOUNTING
8	50250-SD4-030	Beam - FR.	Beam - FR.
1	50800-SD4-010	Mounting assy. - FR. ENGINE	Mounting assy. - FR. ENGINE
2	50810-SD4-000	Mounting assy. - RR. ENGINE	Mounting assy. - RR. ENGINE
3	50813-SK2-000	Stopper - FR. REBOUND	Stopper - FR. REBOUND
4	50815-SD4-000	Rubber - WIND STOPPER INSULATOR (MT)	Rubber - WIND STOPPER INSULATOR (MT)
4	50815-SD4-980	Rubber - WIND STOPPER INSULATOR (AT)	Rubber - WIND STOPPER INSULATOR (AT)
6	50820-SD4-000	Bracket - WIND STOPPER	Bracket - WIND STOPPER
7	50824-SD4-010	Mounting assy. - ENGINE SIDE	Mounting assy. - ENGINE SIDE
8	50825-SK2-020	Bracket - FR. ENGINE MOUNTING (MT)	Bracket - FR. ENGINE MOUNTING (MT)
8	50825-SK2-981	Bracket - FR. ENGINE MOUNTING (AT)	Bracket - FR. ENGINE MOUNTING (AT)
9	50827-SG0-981	Bracket - RR. ENGINE MOUNTING (AT)	Bracket - RR. ENGINE MOUNTING (AT)
9	50827-SK2-010	Bracket - RR. ENGINE MOUNTING (MT)	Bracket - RR. ENGINE MOUNTING (MT)
9	50834-SA0-010	Insulator a - TORQUE ROD	Insulator a - TORQUE ROD
10	50835-SD4-000	Rod - TORQUE	Rod - TORQUE
11	50836-SA0-981	Insulator b - TORQUE ROD	Insulator b - TORQUE ROD
11	50836-SD4-000	Insulator b - TORQUE ROD	Insulator b - TORQUE ROD
12	50837-692-010	Washer - TORQUE ROD	Washer - TORQUE ROD
13	50839-SD4-000	Nut - YOKE, 12MM	Nut - YOKE, 12MM
10	50840-SD4-000	Nut - YOKE, 10MM	Nut - YOKE, 10MM
14	50841-SD4-000	Bracket - L. TORQUE ROD	Bracket - L. TORQUE ROD
15	50842-SD4-010	Bracket - R. TORQUE ROD	Bracket - R. TORQUE ROD
7	51220-SD4-023	Joint comp - LOWER BALL (MUSASHI)	Joint comp - LOWER BALL (MUSASHI)
8	51225-SD4-003	Boot - LOWER BALL DUST	Boot - LOWER BALL DUST
9	51251-SB0-010	Cap - STABILIZER END	Cap - STABILIZER END
2	51308-SG0-020	Bracket - FR. STABILIZER	Bracket - FR. STABILIZER
7	51352-SD4-003	Rod - R. FR. RADIUS	Rod - R. FR. RADIUS
9	51362-SD4-003	Rod - L. FR. RADIUS	Rod - L. FR. RADIUS
10	51380-SG0-023	Bush b assy. - FR. RADIUS ROD (RR.) (HOKUSHIN)	Bush b assy. - FR. RADIUS ROD (RR.) (HOKUSHIN)
11	51390-SG0-013	Bush a assy. - FR. RADIUS ROD (FR.) (HOKUSHIN)	Bush a assy. - FR. RADIUS ROD (FR.) (HOKUSHIN)
12	51393-SK2-000	Bush - FR. LOWER ARM	Bush - FR. LOWER ARM
13	51397-SB0-010	Adjuster - FR. RADIUS ROD	Adjuster - FR. RADIUS ROD
14	51398-SB0-000	Washer comp - FR. RADIUS ROD	Washer comp - FR. RADIUS ROD
15	51398-SG0-020	Collar - FR. RADIUS ROD	Collar - FR. RADIUS ROD
1	51401-SD4-Y01	Spring - FR. (MITSUBISHI SEIKO)	Spring - FR. (MITSUBISHI SEIKO)
1	51401-SD4-Y02	Spring - FR. (SHOWA)	Spring - FR. (SHOWA)
9	51450-SG0-003	Arm assy. - R. FR. UPPER	Arm assy. - R. FR. UPPER
10	51460-SG0-003	Arm assy. - L. FR. UPPER	Arm assy. - L. FR. UPPER
2	51601-SG0-Y03	Absorber assy - R. FR. SHOCK	Absorber assy - R. FR. SHOCK
3	51602-SG0-Y02	Absorber assy - L. FR. SHOCK	Absorber assy - L. FR. SHOCK
4	51605-SD4-044	Absorber unit - R. FR. SHOCK (SHOWA)	Absorber unit - R. FR. SHOCK (SHOWA)
5	51606-SD4-024	Absorber unit - L. FR. SHOCK (SHOWA)	Absorber unit - L. FR. SHOCK (SHOWA)
6	51621-SD4-000	Washer - FR. SHOCK ABSORBER MOUNTING	Washer - FR. SHOCK ABSORBER MOUNTING
7	51631-S7S-J01	RUBBER DAMPER M	RUBBER DAMPER M
7	51631-SB0-004	Rubber - SHOCK ABSORBER MOUNTING (YAMASHITA)	Rubber - SHOCK ABSORBER MOUNTING (YAMASHITA)
8	51675-SB0-004	Base - FR. SHOCK ABSORBER MOUNTING (SHOWA)	Base - FR. SHOCK ABSORBER MOUNTING (SHOWA)
9	51676-SB0-003	Seal - FR. SHOCK ABSORBER MOUNTING (TOKICO)	Seal - FR. SHOCK ABSORBER MOUNTING (TOKICO)
10	51685-SH3-014	Plate - DUST COVER(SHOWA)	Plate - DUST COVER(SHOWA)
11	51686-SD4-004	Rubber - SHOCK ABSORBER MOUNTING	Rubber - SHOCK ABSORBER MOUNTING
12	51687-SD4-024	Cover - SLEEVE DUST	Cover - SLEEVE DUST
13	51689-SH3-004	Plate - BUMP STOP (SHOWA)	Plate - BUMP STOP (SHOWA)
12	51722-SF1-014	Rubber - BUMP STOPPER (POLYURETHAN KASEI)	Rubber - BUMP STOPPER (POLYURETHAN KASEI)
14	51723-SD4-003	Rubber - BUMP STOPPER	Rubber - BUMP STOPPER
15	51728-SB0-004	Collar - SHOCK ABSORBER MOUNTING (SHOWA)	Collar - SHOCK ABSORBER MOUNTING (SHOWA)
16	51810-SD4-013	Bush - SHOCK ABSORBER FORK	Bush - SHOCK ABSORBER FORK
17	51811-SD4-020	Fork - R. FR. SHOCK ABSORBER	Fork - R. FR. SHOCK ABSORBER
18	51821-SD4-020	Fork - L. FR. SHOCK ABSORBER	Fork - L. FR. SHOCK ABSORBER
16	51932-SB0-000	Cap - SHOCK ABSORBER MOUNT	Cap - SHOCK ABSORBER MOUNT
10	52111-SG0-300	Knuckle comp - R. RR.	Knuckle comp - R. RR.
11	52116-SG0-300	Knuckle comp - L. RR.	Knuckle comp - L. RR.
12	52202-SG0-000	Ring - SPINDLE	Ring - SPINDLE
13	52212-SG0-020	Bracket - R. RR. KNUCKLE	Bracket - R. RR. KNUCKLE
14	52217-SG0-020	Bracket - L. RR. KNUCKLE	Bracket - L. RR. KNUCKLE
3	52306-SE0-030	Link - RR. STABILIZER	Link - RR. STABILIZER
4	52308-SE0-000	Bracket - RR. STABILIZER BUSH	Bracket - RR. STABILIZER BUSH
5	52309-SE0-000	Washer - RR. STABILIZER END	Washer - RR. STABILIZER END
6	52310-SE0-003	Shaft - STABILIZER LINK	Shaft - STABILIZER LINK
7	52312-SE0-000	Collar - STABILIZER INNER BUSH END	Collar - STABILIZER INNER BUSH END
9	52316-SA5-000	Bush - STABILIZER END	Bush - STABILIZER END
10	52317-SE0-000	Bracket - R. RR. STABILIZER BUSH	Bracket - R. RR. STABILIZER BUSH
11	52318-SE0-000	Bracket - L. RR. STABILIZER BUSH	Bracket - L. RR. STABILIZER BUSH
12	52350-SG0-040	Arm comp. a - R. RR. LOWER	Arm comp. a - R. RR. LOWER
13	52355-SG0-040	Arm comp. b - RR. LOWER	Arm comp. b - RR. LOWER
14	52360-SG0-020	Arm comp. a - L. RR. LOWER	Arm comp. a - L. RR. LOWER
15	52364-634-020	Washer - LOWER ARM	Washer - LOWER ARM
16	52365-SE0-003	Bush - RR. LOWER ARM (SUMITOMO)	Bush - RR. LOWER ARM (SUMITOMO)
16	52365-SE0-004	Bush - RR. LOWER ARM (HOKUSHIN)	Bush - RR. LOWER ARM (HOKUSHIN)
17	52365-SG0-020	Bush comp - RR. LOWER ARM	Bush comp - RR. LOWER ARM
18	52366-SG0-000	Bolt - KNUCKLE	Bolt - KNUCKLE
22	52387-SE0-023	Bolt - LOWER ARM ADJUSTING	Bolt - LOWER ARM ADJUSTING
23	52388-SE0-030	Plate - CAM	Plate - CAM
15	52390-SG0-043	Arm comp - RR. UPPER	Arm comp - RR. UPPER
3	52611-SD4-Z03	Absorber unit - RR. SHOCK (SHOWA)	Absorber unit - RR. SHOCK (SHOWA)
5	52621-SB2-004	Washer - RR. SHOCK ABSORBER MOUNTING (SHOWA)	Washer - RR. SHOCK ABSORBER MOUNTING (SHOWA)
16	52622-SE0-000	Bush - RR. SHOCK ABSORBER LOWER	Bush - RR. SHOCK ABSORBER LOWER
16	52622-SE0-013	Bush - RR. SHOCK ABSORBER LOWER	Bush - RR. SHOCK ABSORBER LOWER
6	52675-SE0-013	Base - RR. SHOCK ABSORBER MOUNTING	Base - RR. SHOCK ABSORBER MOUNTING
7	52676-SE0-003	Seal - RR. SHOCK ABSORBER MOUNTING	Seal - RR. SHOCK ABSORBER MOUNTING
8	52686-SG0-004	Rubber - RR. SPRING MOUNTING	Rubber - RR. SPRING MOUNTING
9	52687-SG0-034	Cover comp. - RR. SLEEVE DUST	Cover comp. - RR. SLEEVE DUST
10	52688-SE0-003	Plate - RR. BUMP STOP	Plate - RR. BUMP STOP
11	52690-SG0-000	Plate - BUMP STOP	Plate - BUMP STOP
13	52725-SB2-003	Rubber - RR. SHOCK ABSORBER MOUNTING (YAMASHITA)	Rubber - RR. SHOCK ABSORBER MOUNTING (YAMASHITA)
14	52728-SB2-004	Collar - RR. SHOCK ABSORBER MOUNTING(SHOWA)	Collar - RR. SHOCK ABSORBER MOUNTING(SHOWA)
15	52748-SE0-000	Rubber - RR. SPRING SEAT	Rubber - RR. SPRING SEAT
2	53153-SA0-004	Washer - TS TECH	Washer - TS TECH
2	53200-SD4-A04	Column assy - STEERING	Column assy - STEERING
3	53216-SD4-670	Holder b - STEERING COLUMN	Holder b - STEERING COLUMN
4	53217-SB0-000	Collar - STEERING RETAINER	Collar - STEERING RETAINER
5	53231-SB2-000	Label - IGNITION SWITCH	Label - IGNITION SWITCH
22	53271-SF1-003	Cam - TURN SIGNAL SWITCH CANCEL	Cam - TURN SIGNAL SWITCH CANCEL
6	53320-SD4-A01	Cover - STEERING JOINT	Cover - STEERING JOINT
8	53323-SF4-003	Joint comp. b - STEERING	Joint comp. b - STEERING
9	53325-SD4-000	Clip A - JOINT COVER	Clip A - JOINT COVER
10	53326-SB0-000	Clip b - JOINT COVER	Clip b - JOINT COVER
11	53332-SD4-A01	Plate - JOINT COVER	Plate - JOINT COVER
1	53411-SD4-952	Tube - AIR TRANSFER	Tube - AIR TRANSFER
1	53412-634-000	O-ring - RACK GUIDE (YAMADA)	O-ring - RACK GUIDE (YAMADA)
2	53413-SD4-970	Spring - RACK GUIDE PRESSURE	Spring - RACK GUIDE PRESSURE
3	53414-634-010	Screw - RACK GUIDE	Screw - RACK GUIDE
3	53414-634-020	Screw	Screw
4	53416-SD4-953	Guide - STEERING RACK	Guide - STEERING RACK
5	53426-SE0-951	Dust seal - STEERING PINION	Dust seal - STEERING PINION
2	53434-S04-J51	CLIP, TIE ROD	CLIP, TIE ROD
2	53434-SD9-000	Clip - TIE ROD	Clip - TIE ROD
1	53435-SD4-951	Cushion a - POWER STEERING GEAR BOX	Cushion a - POWER STEERING GEAR BOX
2	53436-SD4-950	Cushion b - POWER STEERING GEAR BOX	Cushion b - POWER STEERING GEAR BOX
3	53437-SK2-A51	Bracket a - STEERING GEAR BOX	Bracket a - STEERING GEAR BOX
4	53438-SD4-951	Bracket b - STEERING GEAR BOX	Bracket b - STEERING GEAR BOX
3	53448-SB0-950	Clip - TRANSFER TUBE	Clip - TRANSFER TUBE
4	53449-SE0-000	Band - BELLOWS	Band - BELLOWS
6	53458-S01-A51	Nut - LOCK	Nut - LOCK
6	53458-SE0-003	Nut - RACK SCREW LOCK	Nut - RACK SCREW LOCK
5	53459-SD4-670	Stay - TRANSFER TUBE	Stay - TRANSFER TUBE
5	53501-SD4-000	Grommet a - STEERING	Grommet a - STEERING
6	53502-SD4-000	Grommet b - STEERING	Grommet b - STEERING
6	53521-SD4-023	End comp - FR. RACK	End comp - FR. RACK
7	53534-SD4-000	Dust seal comp. - TIE ROD	Dust seal comp. - TIE ROD
8	53534-SD4-950	Dust seal comp. - TIE ROD	Dust seal comp. - TIE ROD
9	53535-SB3-010	Washer - TIE ROD STOPPER	Washer - TIE ROD STOPPER
10	53536-SB2-000	Washer - TIE ROD LOCK	Washer - TIE ROD LOCK
11	53540-SD4-003	End comp - R. TIE ROD	End comp - R. TIE ROD
11	53546-SA0-003	Boot - TIE ROD END (MUSASHI)	Boot - TIE ROD END (MUSASHI)
12	53546-SD4-003	Boot - TIE ROD END (MUSASHI)	Boot - TIE ROD END (MUSASHI)
12	53548-SA0-003	Circlip - MUSASHI	Circlip - MUSASHI
13	53548-SD4-003	Circlip - LOWER BALL (MUSASHI)	Circlip - LOWER BALL (MUSASHI)
14	53560-SD4-003	End comp - L. TIE ROD	End comp - L. TIE ROD
7	53608-SD4-A61	Housing sub assy. - STEERING GEAR BOX (###)	Housing sub assy. - STEERING GEAR BOX (###)
8	53611-SD4-952	Cylinder comp	Cylinder comp
10	53613-SD4-954	Retainer - PACKING	Retainer - PACKING
11	53614-SD4-951	Cap - CYLINDER	Cap - CYLINDER
12	53615-SD4-950	Washer - RETAINER	Washer - RETAINER
13	53617-SA5-951	Port - ORIFICE	Port - ORIFICE
14	53622-SD4-A51	Pinion - STEERING	Pinion - STEERING
15	53625-SE0-950	Cap - GEAR BOX HOUSING	Cap - GEAR BOX HOUSING
17	53629-SD4-952	Ring - PISTON SEAL	Ring - PISTON SEAL
18	53630-SD4-950	Spring - CYLINDER	Spring - CYLINDER
19	53631-SD4-951	Bush a - STEERING RACK	Bush a - STEERING RACK
20	53632-SF1-951	Bushing b - STEERING RACK	Bushing b - STEERING RACK
21	53633-SD4-953	Packing - CYLINDER END (NOK)	Packing - CYLINDER END (NOK)
21	53633-SK7-951	Packing - CYLINDER END (NOK)	Packing - CYLINDER END (NOK)
22	53634-SF1-950	Clip - BUSH STOPPER	Clip - BUSH STOPPER
24	53643-SD4-A61	Port comp. - VALVE	Port comp. - VALVE
25	53645-SD4-A60	Cap a - VALVE BODY	Cap a - VALVE BODY
26	53650-SE0-950	Spool comp. a - CUT-OFF (0 / +0.005)	Spool comp. a - CUT-OFF (0 / +0.005)
26	53651-SE0-950	Spool comp. b - CUT-OFF (-0.005 / 0)	Spool comp. b - CUT-OFF (-0.005 / 0)
26	53652-SE0-950	Spool comp. c - CUT-OFF (-0.010 / -0.005)	Spool comp. c - CUT-OFF (-0.010 / -0.005)
27	53653-SE0-950	Spring - CUT-OFF	Spring - CUT-OFF
29	53659-SA5-671	Orifice - DAMPING	Orifice - DAMPING
30	53660-SA5-952	Seal - PORT	Seal - PORT
8	53692-SK2-A53	Guard - SPLASH	Guard - SPLASH
4	53697-SD4-951	Cap - OIL TANK	Cap - OIL TANK
5	53701-SD4-953	Tank comp. - POWER STEERING OIL	Tank comp. - POWER STEERING OIL
6	53710-SD4-952	Bracket assy - OIL TANK	Bracket assy - OIL TANK
7	53711-SD4-950	Bracket - OIL TANK	Bracket - OIL TANK
8	53713-SD4-673	Hose comp. - FEED	Hose comp. - FEED
9	53720-SD4-A63	Hose - RETURN	Hose - RETURN
10	53721-SD4-A61	Stay - RETURN HOSE	Stay - RETURN HOSE
11	53724-SD4-A62	Pipe comp - RETURN, 6MM	Pipe comp - RETURN, 6MM
12	53725-SE0-951	Hose - SPEED SENSOR INLET	Hose - SPEED SENSOR INLET
13	53726-SD4-A62	Pipe comp - SENSOR	Pipe comp - SENSOR
14	53727-SD4-950	Tube - SPEED SENSOR RETURN	Tube - SPEED SENSOR RETURN
14	53727-SD4-980	Tube - SPEED SENSOR RETURN	Tube - SPEED SENSOR RETURN
12	53729-671-003	Clamp d - 15.5MM	Clamp d - 15.5MM
17	53731-SD4-954	Tube - SUCTION	Tube - SUCTION
18	53732-SD4-954	Hose - SENSOR RETURN	Hose - SENSOR RETURN
19	53733-SD4-953	Hose - RETURN	Hose - RETURN
20	53734-SD4-950	Tube - SENSOR JOINT	Tube - SENSOR JOINT
21	53735-SD4-950	Tube - RETURN JOINT	Tube - RETURN JOINT
21	53735-SE0-961	Clip - POWER STEERING SUCTION TUBE	Clip - POWER STEERING SUCTION TUBE
22	53736-SD4-953	Holder b - POWER STEERING PIPE	Holder b - POWER STEERING PIPE
23	53737-SD4-952	Hose comp. - RETURN	Hose comp. - RETURN
24	53740-SE0-953	Clip - SENSOR HOSE	Clip - SENSOR HOSE
25	53746-SD4-953	Stay a - POWER STEERING CLIP	Stay a - POWER STEERING CLIP
2	53748-671-000	Rubber - MOUNTING	Rubber - MOUNTING
27	53753-SD4-A61	Clip - RETURN PIPE	Clip - RETURN PIPE
9	53760-SA5-950	Rubber - GEAR BOX SEAL	Rubber - GEAR BOX SEAL
28	53765-SD4-952	Cooler - POWER STEERING OIL	Cooler - POWER STEERING OIL
30	53773-SD4-953	Clamp - SUCTION	Clamp - SUCTION
31	53776-SD4-951	Clip A - POWER STEERING HOSE	Clip A - POWER STEERING HOSE
32	53777-SD4-954	Connector - THREE WAY	Connector - THREE WAY
33	53778-SD4-952	Clip b - POWER STEERING HOSE	Clip b - POWER STEERING HOSE
34	53781-SE0-952	Clip - RETURN HOSE	Clip - RETURN HOSE
7	54026-SJ4-980	Collar - LOCK PIN	Collar - LOCK PIN
8	54027-SD4-A81	Guide - WIRE HARNESS	Guide - WIRE HARNESS
1	54101-SD4-673	Lever - CHANGE	Lever - CHANGE
2	54102-SD4-013	Knob comp. - CHANGE LEVER	Knob comp. - CHANGE LEVER
3	54105-692-010	Washer - THRUST	Washer - THRUST
4	54106-SG0-A01	Holder - CHANGE BOOT	Holder - CHANGE BOOT
5	54107-SA0-010	Bush, RR. JOINT	Bush, RR. JOINT
6	54108-692-000	Boot - CHANGE LEVER	Boot - CHANGE LEVER
7	54110-SD4-003	Seat - CHANGE LEVER BALL	Seat - CHANGE LEVER BALL
11	54113-SE0-981	Collar - LOCK PIN	Collar - LOCK PIN
8	54114-SB2-000	Collar - PIPE MOUNTING	Collar - PIPE MOUNTING
9	54114-SD4-000	Seal b - CHANGE DUST	Seal b - CHANGE DUST
12	54114-SE0-980	Collar - LOCK PIN	Collar - LOCK PIN
10	54115-SD4-020	Seal a - CHANGE DUST	Seal a - CHANGE DUST
2	54116-SD4-980	Washer - FLOATING (WHITE)	Washer - FLOATING (WHITE)
13	54117-SB0-980	Spring - LOCK PIN	Spring - LOCK PIN
11	54117-SD4-000	Collar - RR. JOINT	Collar - RR. JOINT
14	54118-SD4-980	Spring - DETENT	Spring - DETENT
12	54119-SD4-003	Stopper - CHANGE BALL	Stopper - CHANGE BALL
15	54119-SE0-J80	Pin - LOCK	Pin - LOCK
3	54121-SD4-980	Rubber - FLOATING (BLACK)	Rubber - FLOATING (BLACK)
16	54123-SE0-980	Collar - SELECT LEVER	Collar - SELECT LEVER
26	54138-SF1-980	Ring - SPRING	Ring - SPRING
27	54142-SA5-980	Bush - GUIDE	Bush - GUIDE
13	54146-SD4-000	Spacer - BALL SEAT	Spacer - BALL SEAT
28	54147-SD4-980	Guide - DETENT	Guide - DETENT
14	54201-SD4-020	Rod comp - CHANGE	Rod comp - CHANGE
4	54201-SG0-A81	Bracket - SELECT LEVER	Bracket - SELECT LEVER
5	54202-SG0-A81	Bracket - CONTROL	Bracket - CONTROL
17	54206-SG0-A80	Outer - SELECT LEVER	Outer - SELECT LEVER
30	54211-SG0-A81	Lamp - L. INDICATOR	Lamp - L. INDICATOR
6	54217-SD4-980	Collar a - FLOATING	Collar a - FLOATING
8	54220-SD4-A80	Plate - FLOATING	Plate - FLOATING
32	54222-SD4-982	Cover - SELECT LEVER	Cover - SELECT LEVER
15	54225-SD4-300	Bush - JOINT A	Bush - JOINT A
16	54226-SA0-300	Bush - JOINT A OUTER	Bush - JOINT A OUTER
17	54301-SD4-030	Extension - CHANGE	Extension - CHANGE
18	54303-SA5-000	Rubber - EXTENSION END	Rubber - EXTENSION END
19	54304-689-000	Washer a - EXTENSION END	Washer a - EXTENSION END
20	54305-SA0-000	Washer b - EXTENSION END	Washer b - EXTENSION END
21	54306-SB2-000	Rubber - EXTENSION MOUNTING	Rubber - EXTENSION MOUNTING
22	54307-SE0-000	Stopper - EXTENSION MOUNTING	Stopper - EXTENSION MOUNTING
15	54315-SD4-982	Wire - CONTROL	Wire - CONTROL
10	54317-SD4-982	Holder - CONTROL WIRE	Holder - CONTROL WIRE
23	54318-SD4-020	Seal - CHANGE BOOT	Seal - CHANGE BOOT
11	54318-SD4-A80	Seal - CONTROL	Seal - CONTROL
16	54341-SA0-980	Boot - CONTROL WIRE	Boot - CONTROL WIRE
33	54361-689-981	Pipe - CONTROL WIRE ADJUSTING	Pipe - CONTROL WIRE ADJUSTING
12	54363-SE0-980	Pin - CONTROL WIRE ADJUSTER	Pin - CONTROL WIRE ADJUSTER
34	54710-SD4-A80	Escutcheon - CONSOLE	Escutcheon - CONSOLE
1	56110-PH7-040	Pump sub assy - POWER STEERING	Pump sub assy - POWER STEERING
2	56250-PH7-000	Cover comp. - OIL PUMP FR. (###)	Cover comp. - OIL PUMP FR. (###)
3	56350-PC1-010	Spool assy. - A) (-0.005 / 0) (###	Spool assy. - A) (-0.005 / 0) (###
3	56360-PC1-010	Spool assy. - B) (0 / +0.006) (###	Spool assy. - B) (0 / +0.006) (###
4	56385-PC1-000	Spring - SPOOL (###)	Spring - SPOOL (###)
5	56480-PC1-040	Pulley assy - POWER STEERING PUMP	Pulley assy - POWER STEERING PUMP
35	56490-PH6-003	Switch assy - POWER STEERING PRESSURE	Switch assy - POWER STEERING PRESSURE
36	56492-PH7-010	Cord comp - PRESSURE SWITCH	Cord comp - PRESSURE SWITCH
2	56500-PH6-010	Sensor assy - POWER STEERING	Sensor assy - POWER STEERING
2	56500-PH6-901	Sensor assy - POWER STEERING	Sensor assy - POWER STEERING
3	56992-PL2-003	Belt - POWER STEERING PUMP	Belt - POWER STEERING PUMP
4	56995-PH7-000	Bolt - PLATE BASED	Bolt - PLATE BASED
11	57173-SB0-801	O-ring - CONNECTOR	O-ring - CONNECTOR
4	57562-SF1-003	Circlip	Circlip
4	60686-SB0-003	Clip - HOOD WIRE	Clip - HOOD WIRE
1	60821-SE0-A00	Hook - TIE DOWN	Hook - TIE DOWN
1	61109-623-670	Grommet - FR. FENDER	Grommet - FR. FENDER
12	62316-679-003	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
5	66405-SD4-000	Stay - GLOVE BOX HINGE	Stay - GLOVE BOX HINGE
6	66406-SA5-000	Plate - GLOVE BOX STOPPER ARM	Plate - GLOVE BOX STOPPER ARM
7	66407-SA5-000	Arm - GLOVE BOX STOPPER	Arm - GLOVE BOX STOPPER
8	66417-SA0-000	Rubber - GLOVE BOX STOPPER	Rubber - GLOVE BOX STOPPER
7	66418-579-000	Stopper - GLOVE BOX LID	Stopper - GLOVE BOX LID
8	66418-688-000	Stopper - GLOVE BOX LID	Stopper - GLOVE BOX LID
4	66418-SA5-000	Stopper - GLOVE BOX LID	Stopper - GLOVE BOX LID
9	66456-SA5-000	Spring - GLOVE BOX ARM	Spring - GLOVE BOX ARM
10	66856-SA0-660	Lock - FUSE PANEL	Lock - FUSE PANEL
11	66857-SA0-660	Spring - FUSE PANEL	Spring - FUSE PANEL
2	66871-611-000	Nut - CENTER PANEL	Nut - CENTER PANEL
2	70226-611-000	Plug - SETTING HOLE	Plug - SETTING HOLE
28	70494-SE0-000	Spring - FUEL LID OPENER	Spring - FUEL LID OPENER
11	72105-SG0-003	Striker - DOOR LOCK (BLACK)	Striker - DOOR LOCK (BLACK)
12	72106-SG0-000	Bolt - LOCK STRIKER (BLACK)	Bolt - LOCK STRIKER (BLACK)
30	72141-SD4-004	Bush - R. JOINT	Bush - R. JOINT
37	72149-SF1-003	Clip - CYLINDER ROD	Clip - CYLINDER ROD
50	72181-SD4-004	Bush - L. JOINT	Bush - L. JOINT
51	72185-SD4-013	Cylinder - L. DOOR	Cylinder - L. DOOR
3	72206-SA5-000	Cap - FLOOR HOLE, 53MM	Cap - FLOOR HOLE, 53MM
3	72212-SH3-003	Spring - SPIRAL	Spring - SPIRAL
15	72331-SD4-000	Stopper - DOOR	Stopper - DOOR
1	72849-SA5-000	Insulator b - SIDE SILL HOLD	Insulator b - SIDE SILL HOLD
3	73126-SD4-000	Spacer - FR. WINDSHIELD	Spacer - FR. WINDSHIELD
7	73156-SD4-000	Cap - FR. LOWER MOLDING CLIP	Cap - FR. LOWER MOLDING CLIP
4	73219-693-951	Seal - FUEL LID OPENER (GREEN)	Seal - FUEL LID OPENER (GREEN)
6	74111-SG0-010	Shield - FR. SPLASH	Shield - FR. SPLASH
7	74112-SD4-000	Cover - FR. SPLASH SHIELD	Cover - FR. SPLASH SHIELD
6	74120-SD4-013	Lock assy - HOOD	Lock assy - HOOD
7	74125-SD4-003	Spring - HOOD LOCK	Spring - HOOD LOCK
8	74131-SD4-003	Wire comp - HOOD	Wire comp - HOOD
12	74142-SD4-000	Rubber - R. FR. HOOD SEAL	Rubber - R. FR. HOOD SEAL
13	74143-SD4-670	Rubber - RR. HOOD SEAL	Rubber - RR. HOOD SEAL
14	74144-SD4-000	Cover - R. HOOD HINGE	Cover - R. HOOD HINGE
22	74171-SD4-000	Cushion - RADIATOR MOUNTING UPPER	Cushion - RADIATOR MOUNTING UPPER
23	74172-SD4-020	Cushion - RADIATOR MOUNTING LOWER	Cushion - RADIATOR MOUNTING LOWER
17	74175-SD4-000	Cushion - HOOD	Cushion - HOOD
19	74180-SD4-003	Striker assy - HOOD	Striker assy - HOOD
20	74194-SD4-000	Cover - L. HOOD HINGE	Cover - L. HOOD HINGE
23	74211-SD4-670	Garnish a - COWL TOP	Garnish a - COWL TOP
24	74212-SD4-670	Garnish b - COWL TOP (DRIVER SIDE)	Garnish b - COWL TOP (DRIVER SIDE)
25	74213-SD4-670	Garnish c - COWL TOP (PASSENGER SIDE)	Garnish c - COWL TOP (PASSENGER SIDE)
26	74216-SD4-670	Cover - WIPER PIVOT (DRIVER SIDE)	Cover - WIPER PIVOT (DRIVER SIDE)
3	74217-SD4-000	Cover - PIVOT (PASSENGER SIDE)	Cover - PIVOT (PASSENGER SIDE)
2	74251-SD4-671	Insulator - DASHBOARD LOWER OUTER	Insulator - DASHBOARD LOWER OUTER
30	74422-SE0-000	Cushion - FUEL FILLER LID	Cushion - FUEL FILLER LID
23	74423-SD4-000	Holder - FUEL CAP	Holder - FUEL CAP
4	74532-SD4-000	Separator - ROOF RAIL SIDE	Separator - ROOF RAIL SIDE
7	74552-SD4-000	Seal - COATING HOLE	Seal - COATING HOLE
31	74559-SG0-010	Cover - FUEL PIPE	Cover - FUEL PIPE
4	74615-SD4-000	Panel - FR. FLOOR SIDE RR. UPPER	Panel - FR. FLOOR SIDE RR. UPPER
21	74651-SG0-010	Plate - TANK HEAT BAFFLE	Plate - TANK HEAT BAFFLE
11	74654-SE0-A00	Bolt - ANCHOR	Bolt - ANCHOR
22	74655-SG0-010	Plate - SILENCER HEAT BAFFLE	Plate - SILENCER HEAT BAFFLE
11	74661-SG0-000	Cap - FUEL MAINTENANCE HOLE	Cap - FUEL MAINTENANCE HOLE
12	74665-SE0-A00	Adapter - ANCHOR BOLT	Adapter - ANCHOR BOLT
5	74825-692-000	Nut - SPIRE	Nut - SPIRE
9	74862-SD4-013	Striker - TRUNK	Striker - TRUNK
12	74870-SD4-003	Solenoid assy. - TRUNK OPENER	Solenoid assy. - TRUNK OPENER
3	75450-SD4-020	Outlet assy - RR. AIR	Outlet assy - RR. AIR
3	75522-611-000	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
3	75522-634-000	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
55	75551-693-003	Holder - DOOR LOCK ROD	Holder - DOOR LOCK ROD
11	75711-SD4-050	Emblem - RR. (HONDA)	Emblem - RR. (HONDA)
17	75760-SB2-003	Pin - DOOR CHECKER	Pin - DOOR CHECKER
13	75807-671-010	Nut - SIDE PROTECTOR (BLACK)	Nut - SIDE PROTECTOR (BLACK)
28	75891-611-000	Cover - DOOR SWITCH	Cover - DOOR SWITCH
5	76505-SD4-S02	Motor comp - FR. WIPER	Motor comp - FR. WIPER
6	76513-SD4-013	Seal b	Seal b
7	76514-SD4-003	Cover - WATER SEAL	Cover - WATER SEAL
8	76516-SE0-003	Rubber - BRACKETLESS MOUNTING	Rubber - BRACKETLESS MOUNTING
9	76517-SE0-003	Collar - BRACKETLESS	Collar - BRACKETLESS
10	76520-SD4-672	Link a assy. - L.	Link a assy. - L.
14	76532-SD4-003	Cover - JOINT	Cover - JOINT
16	76540-SD4-673	Rod a assy. - L.	Rod a assy. - L.
18	76550-SD4-674	Rod b assy. - L.	Rod b assy. - L.
20	76561-SD4-003	Cap - PIVOT	Cap - PIVOT
22	76600-SD4-673	Arm - WINDSHIELD WIPER (DRIVER SIDE)	Arm - WINDSHIELD WIPER (DRIVER SIDE)
23	76610-SD4-672	Arm - WINDSHIELD WIPER (PASSENGER SIDE)	Arm - WINDSHIELD WIPER (PASSENGER SIDE)
24	76620-SD4-672	Blade - WINDSHIELD WIPER (DRIVER SIDE)	Blade - WINDSHIELD WIPER (DRIVER SIDE)
26	76622-SD4-003	Rubber - BLADE (500MM)	Rubber - BLADE (500MM)
25	76630-SD4-672	Blade - WINDSHIELD WIPER (PASSENGER SIDE)	Blade - WINDSHIELD WIPER (PASSENGER SIDE)
27	76632-SD4-003	Rubber - BLADE (475MM)	Rubber - BLADE (475MM)
28	76665-SD4-000	Stopper assy - ARM	Stopper assy - ARM
29	76701-SE1-003	Rubber - MOUNTING	Rubber - MOUNTING
30	76702-SE1-003	Collar	Collar
8	76801-SD4-023	Washer comp - WINDSHIELD (FR.)	Washer comp - WINDSHIELD (FR.)
3	76802-SS0-003	Cap - MOUTH	Cap - MOUTH
10	76804-SE0-003	Float - WASHER	Float - WASHER
11	76805-SD4-003	Hose - WASHER	Hose - WASHER
12	76806-SE0-S01	Motor - WASHER (MITSUBA)	Motor - WASHER (MITSUBA)
14	76807-SE0-921	Packing - T-TYPE	Packing - T-TYPE
16	76809-SE0-003	Grommet - WASHER TANK	Grommet - WASHER TANK
18	76810-SG0-A11	Nozzle - R. WINDSHIELD WASHER	Nozzle - R. WINDSHIELD WASHER
19	76812-SG0-003	Mouth assy. - WASHER	Mouth assy. - WASHER
20	76815-SG0-A11	Nozzle - L. WINDSHIELD WASHER	Nozzle - L. WINDSHIELD WASHER
21	76820-SD4-003	Grommet - WASHER TUBE	Grommet - WASHER TUBE
22	76830-SG0-003	Joint y - TUBE	Joint y - TUBE
22	76830-SG0-023	Joint y - TUBE	Joint y - TUBE
24	76838-SD4-003	Clip - WASHER TUBE	Clip - WASHER TUBE
25	76842-SE0-003	Bush - WASHER TANK (MITSUBA)	Bush - WASHER TANK (MITSUBA)
26	76851-SE1-003	Tube a - RR. WASHER	Tube a - RR. WASHER
4	77121-SD4-A00	Bracket - GLOVE BOX SIDE	Bracket - GLOVE BOX SIDE
10	77123-SD4-000	Bracket - GLOVE BOX STOPPER	Bracket - GLOVE BOX STOPPER
5	77131-SD4-000	Frame - METER	Frame - METER
6	77133-SD4-000	Frame - POCKET	Frame - POCKET
6	77135-SG0-E01	Bracket - RADIO	Bracket - RADIO
5	77142-SD4-A00	Bracket - INSTRUMENT DRIVER LOWER	Bracket - INSTRUMENT DRIVER LOWER
11	77144-SD4-A00	Frame - GLOVE BOX	Frame - GLOVE BOX
6	77145-SD4-010	Bracket - INSTRUMENT PANEL CENTER	Bracket - INSTRUMENT PANEL CENTER
7	77160-SD4-A02	Frame comp - INSTRUMENT CENTER	Frame comp - INSTRUMENT CENTER
4	77183-SD4-000	Bracket a - R. VISOR SWITCH	Bracket a - R. VISOR SWITCH
5	77184-SD4-000	Bracket a - L. VISOR SWITCH	Bracket a - L. VISOR SWITCH
6	77187-SD4-901	Bracket b - R. VISOR SWITCH	Bracket b - R. VISOR SWITCH
8	77192-SG0-A00	Bracket - R. INSTRUMENT SIDE	Bracket - R. INSTRUMENT SIDE
9	77193-SG0-A00	Bracket - L. INSTRUMENT SIDE	Bracket - L. INSTRUMENT SIDE
9	77206-SD4-000	Hook - METER VISOR	Hook - METER VISOR
1	77208-SA5-003	Bush - NYLON (TS TECH)	Bush - NYLON (TS TECH)
2	77209-SB0-003	Washer - NYLON	Washer - NYLON
14	77215-SD4-A00	Clip - LOWER COVER	Clip - LOWER COVER
9	77292-SG0-A00	Bracket - CENTER CONSOLE	Bracket - CENTER CONSOLE
10	77295-SG0-G10	Panel assy. - CONSOLE	Panel assy. - CONSOLE
11	77296-SG0-G10	Panel - CONSOLE	Panel - CONSOLE
12	77297-SG0-A00	Clip	Clip
13	77298-SG0-A00	Clip	Clip
14	77352-SD4-000	Blind - COLUMN	Blind - COLUMN
15	77354-SD4-000	Label - TILT STEERING	Label - TILT STEERING
18	77371-SF1-000	Ring - COLUMN COVER	Ring - COLUMN COVER
17	77392-SD4-A00	Cover - PASSENGER UNDER	Cover - PASSENGER UNDER
7	77410-SD4-A00	Duct assy - CENTER	Duct assy - CENTER
8	77421-SD4-A00	Duct - DRIVER SIDE AIR CONDITIONER	Duct - DRIVER SIDE AIR CONDITIONER
9	77431-SD4-A00	Duct - PASSENGER SIDE AIR CONDITIONER	Duct - PASSENGER SIDE AIR CONDITIONER
13	77470-SD4-000	Seal assy - SIDE	Seal assy - SIDE
4	77471-SD4-A00	Duct - DRIVER SIDE DEFROSTER	Duct - DRIVER SIDE DEFROSTER
5	77472-SD4-A00	Duct - PASSENGER SIDE DEFROSTER	Duct - PASSENGER SIDE DEFROSTER
6	77476-SD4-A02	Duct - DRIVER JOINT HEATER	Duct - DRIVER JOINT HEATER
13	77506-SD4-003	Stopper - GLOVE BOX	Stopper - GLOVE BOX
3	77517-SA5-014	Cap - SLIDE ADJUSTER	Cap - SLIDE ADJUSTER
18	77535-SD4-000	Label - TRUNK MAIN SWITCH	Label - TRUNK MAIN SWITCH
19	77540-SD4-010	Striker assy - GLOVE BOX	Striker assy - GLOVE BOX
21	77581-SD4-A00	Cover - GLOVE BOX UPPER	Cover - GLOVE BOX UPPER
22	77591-SD4-000	Clip - R. GLOVE BOX UPPER COVER	Clip - R. GLOVE BOX UPPER COVER
23	77592-SD4-000	Clip - L. GLOVE BOX UPPER COVER	Clip - L. GLOVE BOX UPPER COVER
18	77629-SD4-000	Cable	Cable
10	77660-SD4-A00	Valve assy. - DRIVER VENTILATION	Valve assy. - DRIVER VENTILATION
11	77663-SD4-000	Lever - R. VENT	Lever - R. VENT
12	77664-SD4-000	Link - R. VENT	Link - R. VENT
13	77665-SD4-000	Link - L. VENT	Link - L. VENT
14	77666-SD4-000	Link b - R. VENTILATION	Link b - R. VENTILATION
15	77667-SD4-000	Bush - VENTILATION VALVE	Bush - VENTILATION VALVE
16	77668-SD4-000	Rod	Rod
17	77671-SD4-300	Clip - R. INSTRUMENT PANEL	Clip - R. INSTRUMENT PANEL
18	77671-SE3-003	Washer - LINK	Washer - LINK
19	77680-SD4-A00	Valve assy. - PASSENGER VENTILATION	Valve assy. - PASSENGER VENTILATION
20	77683-SD4-000	Lever - L. VENT	Lever - L. VENT
21	77686-SD4-000	Link b - L. VENTILATION	Link b - L. VENTILATION
22	77691-SD4-300	Clip - L. INSTRUMENT PANEL	Clip - L. INSTRUMENT PANEL
15	77721-SG0-000	Protector - CIGARETTE LIGHTER	Protector - CIGARETTE LIGHTER
16	77730-SG0-013	Ashtray comp. - FR. OUTER	Ashtray comp. - FR. OUTER
19	77761-SD4-000	Spring - COIN POCKET	Spring - COIN POCKET
20	77762-SD4-000	Label - FUSE	Label - FUSE
21	77763-SD4-000	Label - COIN	Label - COIN
22	77766-SD4-000	Bush - FUSE LID	Bush - FUSE LID
17	77780-SG0-E01	Pocket assy - FR. CONSOLE	Pocket assy - FR. CONSOLE
18	77781-SG0-E00	Bracket - CASSETTE BOX ASSY.	Bracket - CASSETTE BOX ASSY.
19	77783-SG0-003	Damper - AIR	Damper - AIR
20	77785-SG0-A02	Pocket assy - CONSOLE INNER	Pocket assy - CONSOLE INNER
21	77786-SG0-A02	Panel - CONSOLE POCKET	Panel - CONSOLE POCKET
22	77787-SG0-A02	Pocket comp. - CONSOLE INNER	Pocket comp. - CONSOLE INNER
23	77795-SG0-G01	Outer - CONSOLE POCKET	Outer - CONSOLE POCKET
9	78108-SD4-013	Panel comp - PRINT	Panel comp - PRINT
10	78110-SD4-Y02	Case assy.	Case assy.
1	78113-SB0-003	Rubber - RR. CUSHION SETTING (TS TECH)	Rubber - RR. CUSHION SETTING (TS TECH)
11	78120-SD4-Y03	Speedometer assy	Speedometer assy
13	78130-SD4-043	Meter assy - FUEL & TEMPERATURE	Meter assy - FUEL & TEMPERATURE
13	78130-SD4-954	Meter assy - FUEL & TEMPERATURE	Meter assy - FUEL & TEMPERATURE
14	78136-SD4-003	Stay	Stay
15	78140-SD4-Y02	Amplifier assy	Amplifier assy
17	78155-SD4-003	Visor assy - METER	Visor assy - METER
18	78166-SD4-003	Illumination assy.	Illumination assy.
21	78183-SG0-A01	Socket assy - BULB (T7)	Socket assy - BULB (T7)
4	78410-SD4-A01	Cable assy - SPEEDOMETER	Cable assy - SPEEDOMETER
7	78411-SD4-033	Cable assy - SPEEDOMETER	Cable assy - SPEEDOMETER
8	78412-SD4-A02	Cable assy - SPEEDOMETER (GR)	Cable assy - SPEEDOMETER (GR)
9	78413-SD4-023	Cable - INNER	Cable - INNER
3	78508-SD4-003	Cord a - HORN (TS TECH)	Cord a - HORN (TS TECH)
7	78531-SD4-003	Emblem - STEERING WHEEL (TS TECH)	Emblem - STEERING WHEEL (TS TECH)
3	79110-SD4-A02	Core comp - HEATER	Core comp - HEATER
4	79135-SD4-013	Select assy. - VACUUM	Select assy. - VACUUM
5	79136-SD4-003	Joint - VACUUM TUBE	Joint - VACUUM TUBE
6	79137-SD4-003	Tube a - VACUUM	Tube a - VACUUM
7	79138-SD4-003	Tube b - VACUUM	Tube b - VACUUM
7	79145-SD4-010	Joint - RR. HEATER DUCT	Joint - RR. HEATER DUCT
8	79146-SD4-000	Clip - RR. HEATER DUCT	Clip - RR. HEATER DUCT
9	79160-SE0-003	Holder a - PIPE	Holder a - PIPE
10	79161-SE0-003	Holder b - PIPE	Holder b - PIPE
11	79162-SE0-003	Holder - HEATER CORE	Holder - HEATER CORE
13	79171-SD4-A01	Lever - VENT	Lever - VENT
14	79172-SD4-003	Lever - ROOM	Lever - ROOM
15	79173-SD4-A02	Plate - ROOM	Plate - ROOM
16	79174-SD4-A41	Adjuster - DEFROSTER LEVER	Adjuster - DEFROSTER LEVER
17	79180-SD4-A02	Plate - AIR MODE	Plate - AIR MODE
20	79185-SD4-A01	Plate - COOL AIR	Plate - COOL AIR
21	79186-SD4-A02	Lever - COOL AIR	Lever - COOL AIR
22	79187-SD4-003	Rod - COOL AIR	Rod - COOL AIR
5	79191-SD4-003	Washer - LINK	Washer - LINK
24	79192-SD4-003	Bush - 6.7MM	Bush - 6.7MM
25	79193-SD4-003	Bush - 5MM	Bush - 5MM
26	79196-SD4-003	Bush - 7MM	Bush - 7MM
6	79197-SD4-003	Screw-washer - 3X8	Screw-washer - 3X8
8	79310-SD4-013	Motor assy.	Motor assy.
9	79315-SD4-003	Packing	Packing
10	79330-SD4-003	Transistor assy	Transistor assy
12	79351-SD4-003	Packing	Packing
14	79353-SD4-003	Lever b	Lever b
18	79356-SD4-A02	Rod b - FRESH AIR	Rod b - FRESH AIR
22	79359-SD4-A01	Plate - HARNESS	Plate - HARNESS
3	79700-SD4-013	Valve assy. - WATER	Valve assy. - WATER
16	79720-SD4-000	Hose - WATER IN.	Hose - WATER IN.
4	79721-SD4-000	Hose - WATER VALVE	Hose - WATER VALVE
5	79725-SD4-A00	Hose - WATER OUTLET	Hose - WATER OUTLET
6	79760-SE0-000	Grommet - HEATER PIPE	Grommet - HEATER PIPE
7	79780-SD4-000	Grommet - VACUUM TUBE	Grommet - VACUUM TUBE
8	79785-SD4-A02	Tube assy - WATER VALVE VACUUM	Tube assy - WATER VALVE VACUUM
9	79788-SD4-A00	Tube c - VACUUM	Tube c - VACUUM
10	79825-SD4-A03	Duct - HEATER ASSIST	Duct - HEATER ASSIST
11	79831-SD4-A02	Outlet - HEATER DRIVER	Outlet - HEATER DRIVER
12	79832-SD4-A02	Duct - HEATER DRIVER	Duct - HEATER DRIVER
6	80100-SD4-003	Condenser assy	Condenser assy
7	80107-SD4-003	Mount - CONDENSER UPPER	Mount - CONDENSER UPPER
8	80175-SD4-000	Rubber - CONDENSER MOUNTING	Rubber - CONDENSER MOUNTING
3	80201-SD4-A01	Case - UPPER	Case - UPPER
4	80202-SD4-A02	Case - LOWER	Case - LOWER
5	80205-SD4-003	Insulator - PIPING	Insulator - PIPING
6	80206-SD4-003	Holder	Holder
7	80207-SD4-003	Holder - PIPING	Holder - PIPING
8	80208-SD4-003	Seal a	Seal a
9	80209-SD4-003	Seal b	Seal b
10	80210-SD4-A02	Evaporator assy.	Evaporator assy.
11	80216-SD4-003	Tube - LIQUID	Tube - LIQUID
12	80220-SD4-003	Valve - EXPANSION	Valve - EXPANSION
11	80316-SD4-013	Pipe - DISCHARGE	Pipe - DISCHARGE
12	80323-SD4-A04	Pipe a - RECEIVER	Pipe a - RECEIVER
13	80325-SD4-003	Pipe a - CONDENSER	Pipe a - CONDENSER
13	80335-SD4-A00	Hose - DRAIN	Hose - DRAIN
14	80340-SD4-013	Tank assy. - RECEIVER	Tank assy. - RECEIVER
15	80350-SD4-000	Clamp - DISCHARGE HOSE	Clamp - DISCHARGE HOSE
16	80352-SD4-000	Clamp - DISCHARGE PIPE	Clamp - DISCHARGE PIPE
17	80360-SD4-003	Clamp - DISCHARGE HOSE	Clamp - DISCHARGE HOSE
18	80361-SD4-A00	Bracket - SUCTION PIPE	Bracket - SUCTION PIPE
19	80365-SD4-013	Stay - DISCHARGE PIPE	Stay - DISCHARGE PIPE
20	80370-SD4-000	Clamp - RECEIVER PIPE	Clamp - RECEIVER PIPE
21	80380-SE0-000	Grommet - SUCTION PIPE	Grommet - SUCTION PIPE
22	80381-SE0-000	Grommet - LIQUID PIPE	Grommet - LIQUID PIPE
14	80382-SD4-000	Grommet - DRAIN HOSE	Grommet - DRAIN HOSE
23	80440-SD4-023	Switch - PRESSURE	Switch - PRESSURE
8	80490-SM4-A01	Relay assy - POWER (DENSO)	Relay assy - POWER (DENSO)
24	80789-SH3-003	Holder - ROD	Holder - ROD
8	82871-671-000	Grommet - DRAIN HOLE, 25MM	Grommet - DRAIN HOLE, 25MM
24	83248-SG0-003	Spacer - GRAB RAIL	Spacer - GRAB RAIL
13	83331-SD4-671	Duct - RR. HEATER	Duct - RR. HEATER
14	83335-SG0-000	Duct - RR. PARTITION	Duct - RR. PARTITION
26	83408-SD4-000	Bracket - RR. CONSOLE	Bracket - RR. CONSOLE
28	83412-SG0-A01	Plate - BOOT SETTING	Plate - BOOT SETTING
30	83414-SG0-000	Cover - PLATE SET	Cover - PLATE SET
32	83418-SD4-000	Insulator - R. CONSOLE	Insulator - R. CONSOLE
6	83418-SG3-003	Cushion - TRUNK HINGE	Cushion - TRUNK HINGE
33	83419-SD4-000	Insulator - L. CONSOLE	Insulator - L. CONSOLE
34	83420-SD4-N20	Plate	Plate
19	83431-SA4-000	Cushion - FR. TRUNK	Cushion - FR. TRUNK
36	83437-SD4-000	Spring - ARMREST STOPPER	Spring - ARMREST STOPPER
7	83863-SA4-000	Cap - TIRE LID	Cap - TIRE LID
10	84509-SD4-000	Seal - RR. TRAY	Seal - RR. TRAY
10	84541-SD4-010	Insulator - SPARE TIRE	Insulator - SPARE TIRE
3	84650-SD4-003	Jack assy - PANTOGRAPH	Jack assy - PANTOGRAPH
9	85268-SA0-000	Protection - TAILGATE, 20MM (CIRCLE)	Protection - TAILGATE, 20MM (CIRCLE)
26	87351-SA0-003	Clip - TUBULAR	Clip - TUBULAR
28	88145-SD2-003	Base	Base
29	88147-SA5-003	Washer - TOOTHED (MATSUYAMA)	Washer - TOOTHED (MATSUYAMA)
30	88148-SA5-003	Bolt - LOCK, 6X7 (MATSUYAMA)	Bolt - LOCK, 6X7 (MATSUYAMA)
7	89216-SJ6-000	Wrench - SPARK PLUG	Wrench - SPARK PLUG
10	89600-SE3-Y01	Extinguisher - FIRE	Extinguisher - FIRE
17	90001-PA9-000	Bolt - HEX., 6MM	Bolt - HEX., 6MM
6	90001-PC1-000	Bolt - FLANGE, 6X78	Bolt - FLANGE, 6X78
12	90001-PH7-000	Bolt - STUD, 8X49	Bolt - STUD, 8X49
20	90001-PL5-000	Bolt - FLANGE, 6X93	Bolt - FLANGE, 6X93
11	90002-PA6-003	Bolt-washer - 4X8 (DENSO)	Bolt-washer - 4X8 (DENSO)
13	90002-PG6-000	Bolt - FLANGE, 6X40	Bolt - FLANGE, 6X40
20	90002-PL5-Z00	Bolt - FLANGE, 6X167	Bolt - FLANGE, 6X167
15	90003-692-000	Bolt - FLANGE, 6X16	Bolt - FLANGE, 6X16
21	90003-PL2-000	Bolt-washer - 8X28	Bolt-washer - 8X28
23	90003-PL5-000	Bolt - FLANGE, 6X110	Bolt - FLANGE, 6X110
22	90003-PL5-Z00	Bolt - FLANGE, 6X157	Bolt - FLANGE, 6X157
21	90004-PC9-000	Bolt - FLANGE, 6X90	Bolt - FLANGE, 6X90
7	90004-PE0-000	Bolt - SPECIAL, 8X18	Bolt - SPECIAL, 8X18
12	90004-PL2-J01	Bolt - FLANGE, 11X136.5	Bolt - FLANGE, 11X136.5
14	90005-PH7-003	Bolt-washer - 11X164	Bolt-washer - 11X164
14	90006-PH7-000	Bolt - STUD, 6X31	Bolt - STUD, 6X31
24	90007-PA9-000	Bolt - FLANGE, 6X30	Bolt - FLANGE, 6X30
10	90007-PC9-811	Bolt - REVERSE HOLDER	Bolt - REVERSE HOLDER
9	90007-PL5-000	Bolt - HEX., 10MM	Bolt - HEX., 10MM
23	90008-PD6-010	Bolt - BANJO, 12MM	Bolt - BANJO, 12MM
15	90008-PH7-010	Bolt - FLANGE, 8X41	Bolt - FLANGE, 8X41
23	90008-PP4-E02	Bolt - BANJO, 12MM	Bolt - BANJO, 12MM
22	90009-PC9-810	Bolt - FLANGE, 6X103	Bolt - FLANGE, 6X103
24	90009-PE2-010	Bolt - SEALING, 6MM	Bolt - SEALING, 6MM
13	90009-PH1-000	Bolt - DRAIN PLUG, 14MM	Bolt - DRAIN PLUG, 14MM
14	90009-PH7-003	Bolt - FLANGE, 9X86	Bolt - FLANGE, 9X86
24	90009-RMX-010	Bolt,sealing 6mm	Bolt,sealing 6mm
18	90010-PA9-000	Bolt - SPECIAL, 5X12	Bolt - SPECIAL, 5X12
24	90010-PL2-000	Bolt-washer - 6X28	Bolt-washer - 6X28
5	90011-PH3-000	Bolt - FLANGE, 12MM	Bolt - FLANGE, 12MM
18	90011-PL2-000	Screw-washer - 5X8	Screw-washer - 5X8
12	90012-PG1-000	Bolt - SPECIAL, 10X31.5	Bolt - SPECIAL, 10X31.5
10	90012-PH3-003	Bolt - TIMING BELT ADJUSTER SPRING (SATO RASHI)	Bolt - TIMING BELT ADJUSTER SPRING (SATO RASHI)
27	90012-PL5-000	Bolt - FLANGE, 6X123	Bolt - FLANGE, 6X123
13	90013-PG1-010	Bolt - SPECIAL, 10X42	Bolt - SPECIAL, 10X42
14	90013-PG2-000	Bolt - SPECIAL, 10X52 (SH)	Bolt - SPECIAL, 10X52 (SH)
15	90013-PH7-003	Bolt-washer - 10X56	Bolt-washer - 10X56
11	90014-PA9-000	Bolt - FLANGE, 10X55	Bolt - FLANGE, 10X55
15	90014-PG2-000	Bolt - SPECIAL, 10X102 (SH)	Bolt - SPECIAL, 10X102 (SH)
16	90014-PH7-003	Bolt-washer - 10X41	Bolt-washer - 10X41
12	90015-PA9-000	Bolt - FLANGE, 10X75	Bolt - FLANGE, 10X75
9	90015-PH7-000	Bolt-washer - 8X14	Bolt-washer - 8X14
12	90015-PL2-000	Holder - OIL FILTER	Holder - OIL FILTER
9	90015-PT0-J00	Bolt-washer - 8X14	Bolt-washer - 8X14
10	90016-PA9-000	Bolt - FLANGE, 10X90	Bolt - FLANGE, 10X90
10	90016-PH7-000	Bolt - TIMING BELT ADJUSTING	Bolt - TIMING BELT ADJUSTING
10	90017-PG2-000	Bolt - SPECIAL, 11MM	Bolt - SPECIAL, 11MM
8	90017-PL2-003	Bolt - SPECIAL, 14MM	Bolt - SPECIAL, 14MM
10	90019-PH7-000	Bolt - CYLINDER HEAD COVER	Bolt - CYLINDER HEAD COVER
12	90020-PD6-000	Bolt - SEALING, 12MM	Bolt - SEALING, 12MM
16	90020-PH3-000	Bolt - STUD, 8X46	Bolt - STUD, 8X46
19	90020-SD4-000	Bolt - SELF-LOCK, 12X87	Bolt - SELF-LOCK, 12X87
11	90021-PL2-000	Bolt - FLANGE, 6X20	Bolt - FLANGE, 6X20
16	90021-SE0-000	Bolt - SHOCK ABSORBER, 10X64	Bolt - SHOCK ABSORBER, 10X64
27	90022-SE0-010	Bolt - TRAILING BRACKET, 12X60	Bolt - TRAILING BRACKET, 12X60
4	90023-PA9-000	Bolt - SPECIAL	Bolt - SPECIAL
21	90023-PE0-000	Bolt - FLANGE, 6X10	Bolt - FLANGE, 6X10
28	90023-SE0-020	Bolt - TRAILING BRACKET, 12X30	Bolt - TRAILING BRACKET, 12X30
15	90024-612-000	Bolt - SEALING, 8MM	Bolt - SEALING, 8MM
14	90024-PF4-020	Bolt - LOW ACCUMULATOR SEALING	Bolt - LOW ACCUMULATOR SEALING
17	90025-SG0-000	Bolt - FLANGE, 10X45	Bolt - FLANGE, 10X45
27	90026-PH7-000	Bolt - STUD, 6X64	Bolt - STUD, 6X64
28	90026-PL2-000	Bolt - STUD, 6X88	Bolt - STUD, 6X88
13	90028-PB6-010	Bolt - SPECIAL, 6X22.5	Bolt - SPECIAL, 6X22.5
14	90028-PG2-000	Bolt - SPECIAL, 8X53	Bolt - SPECIAL, 8X53
29	90028-SE0-000	Bolt - TRAILING ARM, 8X16	Bolt - TRAILING ARM, 8X16
15	90029-PG2-010	Bolt - SPECIAL, 8X27	Bolt - SPECIAL, 8X27
17	90029-PH7-003	Bolt - PLUG, 10MM (SAGA)	Bolt - PLUG, 10MM (SAGA)
17	90029-PH7-004	Bolt - PLUG, 10MM (SATO RASHI)	Bolt - PLUG, 10MM (SATO RASHI)
5	90030-PG2-000	Bolt - SPECIAL, 6MM	Bolt - SPECIAL, 6MM
18	90030-PH7-000	Bolt - BREATHING	Bolt - BREATHING
12	90031-PH7-000	Bolt - FLANGE, 8X20	Bolt - FLANGE, 8X20
6	90034-689-000	Bolt - TWELVE POINT, 8MM (TOKAI TRW)	Bolt - TWELVE POINT, 8MM (TOKAI TRW)
11	90035-PH7-000	Bolt - SPECIAL, 6X32	Bolt - SPECIAL, 6X32
29	90037-PL2-000	Bolt - FLANGE, 6X20	Bolt - FLANGE, 6X20
17	90039-PH7-010	Bolt - FLANGE, 8X63	Bolt - FLANGE, 8X63
19	90040-PH7-000	Bolt - BREATHING	Bolt - BREATHING
20	90041-PA5-000	Bolt - STUD, 6X28	Bolt - STUD, 6X28
11	90041-PE0-003	Screw-washer - 4X10 (DENSO)	Screw-washer - 4X10 (DENSO)
19	90041-PH2-004	Screw-washer - 5X8	Screw-washer - 5X8
9	90042-PA6-003	Bolt-washer - 6X10 (DENSO)	Bolt-washer - 6X10 (DENSO)
12	90042-PC1-003	Bolt-washer - 6X14 (DENSO)	Bolt-washer - 6X14 (DENSO)
33	90042-PR7-A00	Bolt - FLANGE, 8X65	Bolt - FLANGE, 8X65
13	90043-PD2-003	Nut - HEX., 5MM (DENSO)	Nut - HEX., 5MM (DENSO)
19	90043-PH7-000	Bolt - ADJUSTING, 8X65	Bolt - ADJUSTING, 8X65
12	90044-PH7-000	Bolt - ALTERNATOR SPECIAL	Bolt - ALTERNATOR SPECIAL
17	90047-PH7-000	Bolt-washer - 6X22	Bolt-washer - 6X22
17	90049-PH7-000	Bolt - FLANGE, 8X25	Bolt - FLANGE, 8X25
15	90050-PH7-000	Bolt-washer - 6X20	Bolt-washer - 6X20
29	90051-PH7-000	Bolt - FLANGE, 6X18	Bolt - FLANGE, 6X18
34	90052-PH7-000	Bolt - FLANGE, 6X22	Bolt - FLANGE, 6X22
33	90053-PH7-000	Bolt - FLANGE, 8X65	Bolt - FLANGE, 8X65
20	90053-PL2-003	Bolt - FLANGE, 10X40	Bolt - FLANGE, 10X40
21	90054-PL2-003	Bolt - FLANGE, 10X55	Bolt - FLANGE, 10X55
10	90065-PC1-300	Bolt - STUD, 10X34.5	Bolt - STUD, 10X34.5
16	90081-PB6-000	Bolt - PLUG, 14MM	Bolt - PLUG, 14MM
13	90081-PF4-000	Bolt - PLUG, 14MM	Bolt - PLUG, 14MM
17	90081-PG1-305	Bolt - SEALING, 32MM	Bolt - SEALING, 32MM
28	90081-PH7-000	Bolt - SEALING, 22MM	Bolt - SEALING, 22MM
18	90083-PG1-305	Bolt - SEALING, 16MM	Bolt - SEALING, 16MM
24	90089-PC9-000	Bolt - STOPPER, 6MM	Bolt - STOPPER, 6MM
10	90091-PC1-000	Bolt-washer - 6X16	Bolt-washer - 6X16
23	90091-PE2-000	Bolt-washer - 5X25	Bolt-washer - 5X25
15	90100-SE0-010	Bolt assy. a - BUMPER	Bolt assy. a - BUMPER
25	90101-692-000	Screw - GLOVE BOX	Screw - GLOVE BOX
10	90101-SA4-000	Screw - TAPPING, 4X12	Screw - TAPPING, 4X12
48	90101-SE0-010	Bolt assy. b - BUMPER	Bolt assy. b - BUMPER
21	90101-SE3-003	Bolt-washer - 8X23.5	Bolt-washer - 8X23.5
40	90102-SA4-000	Screw - TAPPING, 4X16	Screw - TAPPING, 4X16
5	90102-SD4-000	Bolt - BEARING SUPPORT, 8X1.25	Bolt - BEARING SUPPORT, 8X1.25
49	90102-SE0-010	Bolt assy. c - BUMPER	Bolt assy. c - BUMPER
22	90102-SG0-000	Screw - TAPPING (PO) 4X16	Screw - TAPPING (PO) 4X16
24	90103-689-000	Screw - TAPPING	Screw - TAPPING
24	90103-SB0-010	Nut - FLANGE, 5MM	Nut - FLANGE, 5MM
22	90103-SE3-000	Bolt - SPECIAL, 6MM	Bolt - SPECIAL, 6MM
16	90103-SE3-003	Bolt a - BUMPER	Bolt a - BUMPER
11	90105-SA7-000	Screw-washer - 4X16	Screw-washer - 4X16
38	90105-SB0-003	Bolt-washer - 8X16	Bolt-washer - 8X16
40	90105-SD9-003	Bolt-washer - 8X20	Bolt-washer - 8X20
27	90106-SD4-000	Bolt-washer - 8X16	Bolt-washer - 8X16
23	90106-SE3-000	Bolt-washer - 6X12	Bolt-washer - 6X12
18	90107-663-670	Bolt - CALIPER MOUNTING	Bolt - CALIPER MOUNTING
18	90107-SA5-000	Screw - TAPPING, 4X12	Screw - TAPPING, 4X12
27	90107-SB2-003	Screw - TAPPING, 4X10	Screw - TAPPING, 4X10
41	90107-SD4-J10	Bolt assy - SKIRT, 6X35	Bolt assy - SKIRT, 6X35
29	90108-SA5-003	Bolt-washer - 8X19	Bolt-washer - 8X19
23	90108-SD4-000	Washer - PLAIN, 4MM	Washer - PLAIN, 4MM
17	90108-SF1-000	Bolt-washer - 6X15	Bolt-washer - 6X15
55	90110-SE0-003	Bolt c - BUMPER	Bolt c - BUMPER
59	90111-SM4-003	Bolt - BUMPER	Bolt - BUMPER
41	90113-SA7-003	Clamp - CABLE, 10MM (BLACK)	Clamp - CABLE, 10MM (BLACK)
14	90113-SD4-900	Bolt - WHEEL	Bolt - WHEEL
25	90114-SD4-000	Bolt-washer - 8X73	Bolt-washer - 8X73
34	90114-SE0-000	Screw - TAPPING, 5X20	Screw - TAPPING, 5X20
27	90114-SG0-003	Bolt - 5X13	Bolt - 5X13
26	90115-659-003	Nut - SELF-LOCK, 8MM (CLINCH)	Nut - SELF-LOCK, 8MM (CLINCH)
17	90115-SB2-003	Nut - SELF-LOCK, 8MM	Nut - SELF-LOCK, 8MM
35	90115-SG0-003	Bolt - FLANGE, 6MM	Bolt - FLANGE, 6MM
23	90116-SD4-003	Screw - TAPPING, 4X16	Screw - TAPPING, 4X16
11	90116-SD4-010	Bolt - SIDE MOUNTING, 12MM	Bolt - SIDE MOUNTING, 12MM
20	90117-SM4-003	Bolt - FR. SHOCK ABSORBER LOCK (10X44)	Bolt - FR. SHOCK ABSORBER LOCK (10X44)
19	90119-SE0-000	Bolt - FLANGE, 6MM	Bolt - FLANGE, 6MM
31	90119-SM4-003	Bolt - RR. LOWER ARM, 12X66	Bolt - RR. LOWER ARM, 12X66
30	90120-SE3-003	Bolt - FLANGE, 6X12	Bolt - FLANGE, 6X12
31	90121-PG4-000	Bolt - FLANGE, 12X70	Bolt - FLANGE, 12X70
21	90121-SB0-013	Bolt - SHOCK ABSORBER FORK (12X108)	Bolt - SHOCK ABSORBER FORK (12X108)
16	90121-SD4-013	Bolt - FLANGE, 12X109	Bolt - FLANGE, 12X109
22	90122-PH7-000	Bolt - FLANGE, 12X95	Bolt - FLANGE, 12X95
22	90122-PH7-900	Bolt - FLANGE, 12X135	Bolt - FLANGE, 12X135
12	90122-SD4-900	Bolt - FLANGE, 10X105	Bolt - FLANGE, 10X105
23	90123-PG4-000	Bolt - FLANGE, 12X85	Bolt - FLANGE, 12X85
37	90123-SD4-J01	Bolt-washer - 10X28	Bolt-washer - 10X28
17	90124-SE0-000	Bolt-washer - LOCK, 10X21	Bolt-washer - LOCK, 10X21
29	90125-SD4-670	Bolt - FLANGE, 8X83	Bolt - FLANGE, 8X83
31	90126-SE0-000	Bolt-washer - 6X25 (DACRO COATING)	Bolt-washer - 6X25 (DACRO COATING)
23	90127-SB6-000	Bolt - HOOD, 6X16	Bolt - HOOD, 6X16
18	90127-SD4-000	Bolt - FLANGE, 10X60	Bolt - FLANGE, 10X60
11	90128-SA7-000	Bolt-washer - 6X25	Bolt-washer - 6X25
28	90130-SE0-000	Screw - TAPPING, 6X16 (DACRO COATING)	Screw - TAPPING, 6X16 (DACRO COATING)
19	90131-SA5-000	Bolt - TORQUE ROD, 12X66 (NTN)	Bolt - TORQUE ROD, 12X66 (NTN)
24	90131-SD2-003	Screw-washer - 4X12 (NS)	Screw-washer - 4X12 (NS)
25	90132-SD2-003	Screw-washer - 3X13 (NS)	Screw-washer - 3X13 (NS)
26	90132-SG0-A01	Screw-washer - 3X40	Screw-washer - 3X40
24	90133-SD4-000	Screw - TRUSS	Screw - TRUSS
35	90133-SG0-003	Bolt-washer - 5X30	Bolt-washer - 5X30
27	90133-SG0-A01	Screw - TAPPING, 4X36	Screw - TAPPING, 4X36
22	90135-SB0-003	Bolt - STEERING YOKE, 8X28 (NIPPON SEIKO)	Bolt - STEERING YOKE, 8X28 (NIPPON SEIKO)
39	90136-SD4-003	Clip - MUDGUARD	Clip - MUDGUARD
24	90137-SD2-000	Screw - TAPPING, 4X12 (SUS)	Screw - TAPPING, 4X12 (SUS)
17	90137-SD4-000	Bolt-washer - 6X20	Bolt-washer - 6X20
24	90140-SD4-013	Screw - TAPPING, 4X40	Screw - TAPPING, 4X40
24	90141-SD4-000	Screw - TAPPING, 6X16	Screw - TAPPING, 6X16
42	90144-SG0-000	Screw - TAPPING, 3X12	Screw - TAPPING, 3X12
21	90146-SA7-000	Bolt-washer - 6X16 (DACRO COATING)	Bolt-washer - 6X16 (DACRO COATING)
35	90147-634-003	Bolt - FENDER, 6X18	Bolt - FENDER, 6X18
8	90148-SE0-003	Bolt - EARTH, 6X16 (WASHER 12.5MM) (ZN)	Bolt - EARTH, 6X16 (WASHER 12.5MM) (ZN)
28	90149-SE0-003	Bolt - EARTH, 6X16	Bolt - EARTH, 6X16
29	90153-SA5-900	Screw-washer - 5X9	Screw-washer - 5X9
18	90155-SE0-003	Screw - TAPPING, 6X20	Screw - TAPPING, 6X20
12	90156-SE3-003	Blind - FASTENER	Blind - FASTENER
20	90162-SD4-000	Bolt - TORQUE ROD, 12X81	Bolt - TORQUE ROD, 12X81
21	90163-SA5-000	Screw-washer - 4X16	Screw-washer - 4X16
25	90163-SD4-000	Bolt - FILLER PIPE MOUNTING	Bolt - FILLER PIPE MOUNTING
20	90164-SD4-000	Bolt-washer - 6X16	Bolt-washer - 6X16
22	90167-SD4-000	Screw - TAPPING, 5X12	Screw - TAPPING, 5X12
10	90171-SD4-010	Bolt-washer - 10X34	Bolt-washer - 10X34
19	90171-SG0-003	Bolt a - TRAILING ARM (12X54)	Bolt a - TRAILING ARM (12X54)
20	90172-SG0-003	Bolt b - TRAILING ARM (12X42)	Bolt b - TRAILING ARM (12X42)
27	90173-SM4-000	Bolt - FLANGE, 12X60	Bolt - FLANGE, 12X60
13	90175-SK2-000	Bolt - FLANGE, 10X50	Bolt - FLANGE, 10X50
14	90176-SK2-000	Bolt - FLANGE, 10X32	Bolt - FLANGE, 10X32
33	90176-SM4-000	Bolt - FLANGE, 12X95	Bolt - FLANGE, 12X95
22	90178-SH3-004	Bolt - FR. RADIUS ROD (12X35)	Bolt - FR. RADIUS ROD (12X35)
17	90182-SB6-000	Bolt-washer - 6X16	Bolt-washer - 6X16
60	90190-SG0-010	Bolt assy - RR. BUMPER CORNER	Bolt assy - RR. BUMPER CORNER
61	90192-SG0-003	Bolt - BUMPER CORNER	Bolt - BUMPER CORNER
30	90201-PD1-000	Nut a - SEALING, 12MM	Nut a - SEALING, 12MM
11	90201-PG1-000	Nut - HEX., 23MM (L)	Nut - HEX., 23MM (L)
6	90201-PL5-Z00	Nut - FLANGE, 19MM	Nut - FLANGE, 19MM
14	90202-PL5-Z01	Nut - FLANGE, 25MM	Nut - FLANGE, 25MM
5	90204-PH7-000	Nut - SPECIAL	Nut - SPECIAL
29	90206-657-000	Nut - TAPPET ADJUSTING	Nut - TAPPET ADJUSTING
25	90212-671-005	Nut - SELF-LOCK, 10MM	Nut - SELF-LOCK, 10MM
11	90212-PD2-003	Nut - SELF-LOCK, 8MM	Nut - SELF-LOCK, 8MM
11	90212-RCA-A01	Nut - SELF-LOCK, 8MM	Nut - SELF-LOCK, 8MM
24	90212-SA5-003	Nut - SELF-LOCK, 10MM	Nut - SELF-LOCK, 10MM
34	90212-SA7-010	Nut - SELF-LOCK, 10MM	Nut - SELF-LOCK, 10MM
18	90214-SE0-000	Nut - HEX., 10MM	Nut - HEX., 10MM
23	90215-SB0-003	Nut - SELF-LOCK, 12MM (SATO RASHI) (CLINCH)	Nut - SELF-LOCK, 12MM (SATO RASHI) (CLINCH)
25	90215-SMA-003	Nut	Nut
36	90216-SE0-010	Nut	Nut
36	90216-SE0-305	NUT, LWR ARM	NUT, LWR ARM
24	90231-PD1-014	Nut-washer - 5MM	Nut-washer - 5MM
28	90302-SA4-003	Nut - SPRING, 4MM	Nut - SPRING, 4MM
63	90302-SB3-010	Nut - SPRING, 4MM	Nut - SPRING, 4MM
44	90302-SD4-900	Nut - SPRING, 4MM	Nut - SPRING, 4MM
36	90302-SG0-003	Nut - SEAL-WASHER, 6MM	Nut - SEAL-WASHER, 6MM
64	90303-SA5-003	Nut - FR. COMBINATION LIGHT	Nut - FR. COMBINATION LIGHT
13	90304-SA5-013	Nut - WHEEL (CHROME PLATED) (FUSE RASHI)	Nut - WHEEL (CHROME PLATED) (FUSE RASHI)
15	90305-SD4-003	Nut - SPINDLE (24MM)	Nut - SPINDLE (24MM)
26	90307-SA0-003	Nut - FLANGE, 5MM	Nut - FLANGE, 5MM
17	90307-SD4-010	Nut - CASTLE, 14MM	Nut - CASTLE, 14MM
15	90308-SA0-981	Nut - SELF-LOCK, 6MM	Nut - SELF-LOCK, 6MM
23	90313-567-000	Nut - SPEED, 3MM	Nut - SPEED, 3MM
15	90320-601-000	Nut - CASTLE, 10MM	Nut - CASTLE, 10MM
18	90321-SE0-000	Nut - UPPER BALL PIN, 10MM	Nut - UPPER BALL PIN, 10MM
66	90321-SE1-000	Nut - CLIP (AIR SPOILER)	Nut - CLIP (AIR SPOILER)
30	90325-SD4-670	Nut - SELF-LOCK, 8MM	Nut - SELF-LOCK, 8MM
24	90361-SD4-000	Nut - SELF-LOCK, 12MM	Nut - SELF-LOCK, 12MM
25	90362-SG0-013	Nut - TRAILING ARM, 12MM	Nut - TRAILING ARM, 12MM
17	90364-SG0-004	Nut - SELF-LOCK, 10MM (SHOWA) (NYLON)	Nut - SELF-LOCK, 10MM (SHOWA) (NYLON)
37	90370-SD4-950	Nut - FLANGE, 6MM	Nut - FLANGE, 6MM
15	90372-SK2-000	Nut - FLANGE, 10MM	Nut - FLANGE, 10MM
8	90380-SB2-003	Nut - SELF-LOCK (OHASHI)	Nut - SELF-LOCK (OHASHI)
13	90401-634-000	Rubber - TIMING BELT ADJUSTER	Rubber - TIMING BELT ADJUSTER
19	90401-PG1-000	Washer - DRAIN PLUG, 10MM	Washer - DRAIN PLUG, 10MM
9	90402-PH1-000	Washer - 14.5X36X8	Washer - 14.5X36X8
12	90402-PL2-000	Washer - SPECIAL, 8.5X16.5X2.7	Washer - SPECIAL, 8.5X16.5X2.7
7	90406-PF4-000	Washer - THRUST, 31X42X1.5	Washer - THRUST, 31X42X1.5
8	90407-PC9-000	Washer - THRUST, 26X53X3	Washer - THRUST, 26X53X3
15	90411-PL5-000	Collar - DISTANCE, 38X44X28.5	Collar - DISTANCE, 38X44X28.5
16	90412-679-000	Washer - CONICAL SPRING, 8MM	Washer - CONICAL SPRING, 8MM
19	90414-SB0-000	Washer - SPRING, 10MM	Washer - SPRING, 10MM
9	90420-PG4-000	Washer - 26X45X3.8	Washer - 26X45X3.8
10	90422-PA9-000	Washer - THRUST, 26MM	Washer - THRUST, 26MM
18	90423-PH7-000	Rubber - TIMING BELT PLATE MOUNTING	Rubber - TIMING BELT PLATE MOUNTING
13	90428-PD6-003	Washer - SEALING, 12MM	Washer - SEALING, 12MM
5	90429-PC6-900	Washer - 40X86X2	Washer - 40X86X2
28	90430-PD6-003	Washer - SEALING, 6MM	Washer - SEALING, 6MM
19	90433-639-000	Washer - LOCK, 6MM	Washer - LOCK, 6MM
20	90436-PA9-000	Washer - LOCK, 5MM	Washer - LOCK, 5MM
21	90437-PG4-000	Washer - TONGUED, 6MM	Washer - TONGUED, 6MM
22	90438-671-000	Washer - SPECIAL, 6MM	Washer - SPECIAL, 6MM
38	90438-SE0-000	Washer - TRAILING, 12MM	Washer - TRAILING, 12MM
11	90441-PG4-010	Washer - THRUST, 36.5X55X4.00	Washer - THRUST, 36.5X55X4.00
11	90442-PG4-010	Washer - THRUST, 36.5X55X4.05	Washer - THRUST, 36.5X55X4.05
11	90443-PG4-010	Washer - THRUST, 36.5X55X4.10	Washer - THRUST, 36.5X55X4.10
11	90444-PG4-010	Washer - THRUST, 36.5X55X4.15	Washer - THRUST, 36.5X55X4.15
11	90445-PG4-010	Washer - THRUST, 36.5X55X4.20	Washer - THRUST, 36.5X55X4.20
11	90446-PG4-010	Washer - THRUST, 36.5X55X4.25	Washer - THRUST, 36.5X55X4.25
11	90447-PG4-010	Washer - THRUST, 36.5X55X4.30	Washer - THRUST, 36.5X55X4.30
11	90448-PG4-010	Washer - THRUST, 36.5X55X4.35	Washer - THRUST, 36.5X55X4.35
11	90449-PG4-010	Washer - THRUST, 36.5X55X4.40	Washer - THRUST, 36.5X55X4.40
16	90471-580-000	Packing - 8MM	Packing - 8MM
24	90471-SB0-000	Washer - PLAIN, 8MM	Washer - PLAIN, 8MM
21	90481-463-000	Washer - 10.2MM	Washer - 10.2MM
27	90501-671-003	Washer - SPECIAL	Washer - SPECIAL
14	90501-MB7-610	Washer - 10.3X25	Washer - 10.3X25
16	90501-PL5-000	Collar - DISTANCE, 35MM (47.45)	Collar - DISTANCE, 35MM (47.45)
12	90502-PC9-000	Collar - MAINSHAFT FOURTH GEAR	Collar - MAINSHAFT FOURTH GEAR
16	90502-PL5-000	Collar - DISTANCE, 35MM (47.50)	Collar - DISTANCE, 35MM (47.50)
16	90503-PL5-000	Collar - DISTANCE, 35MM (47.55)	Collar - DISTANCE, 35MM (47.55)
16	90504-PL5-000	Collar - DISTANCE, 35MM (47.60)	Collar - DISTANCE, 35MM (47.60)
16	90504-SE0-000	Washer - PLAIN, 10MM	Washer - PLAIN, 10MM
16	90505-PL5-000	Collar - DISTANCE, 35MM (47.65)	Collar - DISTANCE, 35MM (47.65)
16	90506-PL5-000	Collar - DISTANCE, 35MM (47.70)	Collar - DISTANCE, 35MM (47.70)
17	90507-PA9-000	Collar - 8X11	Collar - 8X11
16	90507-PL5-000	Collar - DISTANCE, 35MM (47.75)	Collar - DISTANCE, 35MM (47.75)
14	90508-PF4-000	Collar - 26MM	Collar - 26MM
16	90508-PL5-000	Collar - DISTANCE, 35MM (47.80)	Collar - DISTANCE, 35MM (47.80)
16	90509-PL5-000	Collar - DISTANCE, 35MM (47.85)	Collar - DISTANCE, 35MM (47.85)
17	90509-PL5-J00	Collar - LOW GEAR	Collar - LOW GEAR
16	90510-PL5-000	Collar - DISTANCE, 35MM (47.90)	Collar - DISTANCE, 35MM (47.90)
25	90511-671-003	Washer - TOOTHED LOCK	Washer - TOOTHED LOCK
16	90520-PH6-000	Collar - IGNITION COIL	Collar - IGNITION COIL
31	90521-SD4-003	Clip - HOOD SEAL	Clip - HOOD SEAL
67	90540-SA7-000	Washer - BUMPER	Washer - BUMPER
12	90541-PH7-000	Washer - MOUNTING RUBBER	Washer - MOUNTING RUBBER
13	90542-PH7-000	Rubber - MOUNTING	Rubber - MOUNTING
12	90551-SD4-010	Washer - PLAIN, 13MM	Washer - PLAIN, 13MM
16	90551-SD4-980	Washer - PLAIN, 6MM	Washer - PLAIN, 6MM
25	90601-836-000	E-ring - 4MM	E-ring - 4MM
18	90601-PC9-860	Circlip - INTERNAL, 38MM	Circlip - INTERNAL, 38MM
25	90601-SB3-003	Linkage - BUSHING	Linkage - BUSHING
12	90602-PG1-770	Ring - SNAP, 56MM	Ring - SNAP, 56MM
21	90603-PA9-000	Circlip - EXTERNAL, 40MM	Circlip - EXTERNAL, 40MM
15	90603-PF4-003	Circlip - EXTERNAL, 23MM	Circlip - EXTERNAL, 23MM
22	90603-PG4-000	Circlip - EXTERNAL, 43MM	Circlip - EXTERNAL, 43MM
23	90605-PF4-000	Ring - SNAP, 125MM	Ring - SNAP, 125MM
17	90607-081-000	Circlip - 7MM	Circlip - 7MM
27	90609-SG0-003	Clip - PILLAR GARNISH	Clip - PILLAR GARNISH
16	90613-PA9-000	Ring - SNAP, 26MM	Ring - SNAP, 26MM
14	90615-PF4-000	Ring - SNAP, 75MM	Ring - SNAP, 75MM
29	90616-SB0-000	Clip c - WIRE HARNESS	Clip c - WIRE HARNESS
30	90627-SA5-003	Clip - WIRE HARNESS(BLUE) (HARNESS TAPING)(50MM)	Clip - WIRE HARNESS(BLUE) (HARNESS TAPING)(50MM)
23	90635-671-000	Clip - OIL HOSE	Clip - OIL HOSE
6	90637-689-000	Clip - SPEEDOMETER CABLE	Clip - SPEEDOMETER CABLE
10	90650-SD4-003	Clip - WIRE HARNESS	Clip - WIRE HARNESS
41	90651-538-000	Clip - BRAKE HOSE	Clip - BRAKE HOSE
33	90651-692-731	Nut - NYLON, 3MM	Nut - NYLON, 3MM
13	90651-SA6-671	Clip - WIRE	Clip - WIRE
17	90651-SB2-003	Clip - WIRE HARNESS, 13MM (GRAY)	Clip - WIRE HARNESS, 13MM (GRAY)
29	90652-SB2-023	Clip - TUBE, 7MM	Clip - TUBE, 7MM
25	90654-SD4-003	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
26	90655-SD4-003	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
23	90657-SB0-003	Clip, SPLASH SHIELD	Clip, SPLASH SHIELD
26	90659-SA5-003	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
20	90661-SD4-003	Clip - DRIP SEAL END	Clip - DRIP SEAL END
27	90662-693-003	Grommet - SCREW, 4MM (BLUE)	Grommet - SCREW, 4MM (BLUE)
62	90662-SB2-003	Grommet - SCREW, 5MM	Grommet - SCREW, 5MM
14	90663-SB2-003	Grommet - SCREW, 6MM	Grommet - SCREW, 6MM
54	90664-671-003	Clip - CANOE	Clip - CANOE
45	90666-SD4-003	Clip - FITTING	Clip - FITTING
29	90667-693-920	Clip - ROOF SIDE	Clip - ROOF SIDE
35	90669-SD4-003	Strap - CABLE, 180MM (YELLOW)	Strap - CABLE, 180MM (YELLOW)
13	90670-SG0-003	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
15	90671-SB2-000	Bolt - FR. FENDER (DACRO COATING)	Bolt - FR. FENDER (DACRO COATING)
5	90672-671-003	Clip - TRIM	Clip - TRIM
30	90672-671-811	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
45	90672-SA0-003	Strap - CABLE, 118MM(BLACK)	Strap - CABLE, 118MM(BLACK)
19	90672-SC7-003	Grommet - TAPPING SCREW, 4MM	Grommet - TAPPING SCREW, 4MM
18	90673-SA7-003	Band - TUBE	Band - TUBE
70	90673-SB2-000	Nut - CLIP, 6MM	Nut - CLIP, 6MM
25	90674-WA8-003	Band - CABLE, 120MM (BLACK)	Band - CABLE, 120MM (BLACK)
71	90675-SA5-003	Nut - CLIP, 6MM	Nut - CLIP, 6MM
72	90675-SB0-003	Clip - FR. COWL	Clip - FR. COWL
20	90675-SG0-003	Clip - RR. DUCT	Clip - RR. DUCT
26	90676-SA7-003	Grommet - SCREW, 5MM (BLACK)	Grommet - SCREW, 5MM (BLACK)
24	90676-SA8-003	Band - WIRE HARNESS, 150MM (BLUE)	Band - WIRE HARNESS, 150MM (BLUE)
13	90676-SB2-003	Clip - DASHBOARD INSULATOR	Clip - DASHBOARD INSULATOR
26	90676-SE0-003	Clip - JOINT COVER PLATE	Clip - JOINT COVER PLATE
42	90677-SB0-003	Clip - PIPE PROTECTOR	Clip - PIPE PROTECTOR
26	90677-SD4-003	Clip - DASHBOARD INSULATOR UNDER COVER	Clip - DASHBOARD INSULATOR UNDER COVER
29	90680-SG0-300	Clamp e - FUEL PIPE	Clamp e - FUEL PIPE
27	90681-693-000	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
14	90681-SA9-600	Clip - JOINT	Clip - JOINT
19	90681-SG0-000	Circlip - INTERNAL, 84MM	Circlip - INTERNAL, 84MM
10	90682-693-000	Plug - HOLE, 12.5MM	Plug - HOLE, 12.5MM
40	90682-SB0-003	Grommet - SCREW, 5MM	Grommet - SCREW, 5MM
13	90683-SF1-003	Circlip - FR. UPPER (MUSASHI)	Circlip - FR. UPPER (MUSASHI)
26	90684-SD4-003	Clip - FUEL LID OPENER	Clip - FUEL LID OPENER
32	90684-SD4-950	Ring - SNAP, 31MM	Ring - SNAP, 31MM
30	90685-SD4-310	Clamp a - FUEL PIPE	Clamp a - FUEL PIPE
31	90686-SD4-310	Clamp b - FUEL PIPE	Clamp b - FUEL PIPE
35	90687-SB0-013	Clip - AIRSCOOP GRILLE (BLACK)	Clip - AIRSCOOP GRILLE (BLACK)
32	90687-SD4-310	Clamp c - FUEL PIPE	Clamp c - FUEL PIPE
33	90688-SD4-310	Clamp d - FUEL PIPE	Clamp d - FUEL PIPE
26	90690-SA0-003	Strap - WIRE HARNESS, 25MM (BLACK)	Strap - WIRE HARNESS, 25MM (BLACK)
12	90690-SB0-003	Clip - CABLE (WHITE)	Clip - CABLE (WHITE)
36	90692-SD4-003	Clip b - OPENER CABLE	Clip b - OPENER CABLE
33	90693-SE0-951	Circlip - INTERNAL, 28MM	Circlip - INTERNAL, 28MM
34	90697-SE0-951	Circlip - EXTERNAL, 30MM	Circlip - EXTERNAL, 30MM
28	90700-SB0-003	Clip - AIR BLEED TUBE	Clip - AIR BLEED TUBE
38	90700-SB2-003	Clip - HOOD INSULATOR	Clip - HOOD INSULATOR
26	90701-639-000	Dowel pin - 8X55	Dowel pin - 8X55
22	90701-679-000	Dowel pin - 8X10	Dowel pin - 8X10
19	90703-PA9-003	Roller - 2X19.8	Roller - 2X19.8
10	90704-PH7-000	Key, SPECIAL	Key, SPECIAL
11	90705-PA9-000	Dowel pin - 14X25	Dowel pin - 14X25
12	90705-PF4-000	Dowel pin - 14X20	Dowel pin - 14X20
6	90705-PG2-000	Dowel pin - 14X20	Dowel pin - 14X20
19	90705-SD2-931	Pin - SNAP, 6MM	Pin - SNAP, 6MM
18	90707-PH7-000	Dowel pin - 10X12	Dowel pin - 10X12
23	90715-PH7-000	Dowel pin - 13X37	Dowel pin - 13X37
19	90719-PH7-000	Dowel pin - 13X37	Dowel pin - 13X37
37	90751-SE0-003	Boot - COWL TOP CLIP	Boot - COWL TOP CLIP
11	90801-SB0-000	Plug - CHANGE REINFORCEMENT	Plug - CHANGE REINFORCEMENT
12	90810-SG0-000	Grommet - TIE DOWN	Grommet - TIE DOWN
15	90852-671-003	Plug - HOLE	Plug - HOLE
14	90852-SA5-000	Plug - HOLE, 10MM	Plug - HOLE, 10MM
38	90854-671-000	Collar - OIL PUMP	Collar - OIL PUMP
24	90855-SA5-300	Protector - CORD	Protector - CORD
16	90856-SA0-000	Plug - COATING HOLE, 25MM	Plug - COATING HOLE, 25MM
3	90866-SA0-000	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
18	90871-SG0-010	Valve - RR. DRAIN, 20MM	Valve - RR. DRAIN, 20MM
19	90872-SA5-000	Valve - DRAIN	Valve - DRAIN
13	91001-591-004	Bearing - BALL, 16008 (KOYO)	Bearing - BALL, 16008 (KOYO)
13	91001-PX4-004	Bearing - BALL, 40X68X9 (KOYO)	Bearing - BALL, 40X68X9 (KOYO)
7	91002-PG1-018	Bearing - BALL, 63/28C (TOYO)	Bearing - BALL, 63/28C (TOYO)
15	91002-PG4-003	Bearing - BALL, 26X75X18.2 (SPECIAL)	Bearing - BALL, 26X75X18.2 (SPECIAL)
16	91002-PL5-J01	Bearing - SPECIAL BALL, 28X75X18.2	Bearing - SPECIAL BALL, 28X75X18.2
13	91003-PG2-008	Bearing - SPECIAL BALL (NTN)	Bearing - SPECIAL BALL (NTN)
21	91004-PG1-771	Bearing - BALL, 28X78 (TOYO)	Bearing - BALL, 28X78 (TOYO)
11	91005-PG2-004	Bearing - TAPER, 40X75X21 (KOYO)	Bearing - TAPER, 40X75X21 (KOYO)
11	91005-PG2-008	Bearing - TAPER, 40X75X21 (NTN)	Bearing - TAPER, 40X75X21 (NTN)
12	91006-PG2-004	Bearing - TAPER, 40X68X19 (KOYO)	Bearing - TAPER, 40X68X19 (KOYO)
12	91006-PG2-008	Bearing - TAPER, 40X68X19 (TOYO)	Bearing - TAPER, 40X68X19 (TOYO)
10	91006-PG4-003	Bearing - SPECIAL TAPER, 40X80X19.75	Bearing - SPECIAL TAPER, 40X80X19.75
17	91011-PA9-004	Bearing - NEEDLE, 32X38X20 (KOYO)	Bearing - NEEDLE, 32X38X20 (KOYO)
18	91011-PG4-003	Bearing - NEEDLE, 32X38X20 (NTN)	Bearing - NEEDLE, 32X38X20 (NTN)
18	91012-PN6-701	Bearing - NEEDLE, 31X36X18.5	Bearing - NEEDLE, 31X36X18.5
19	91017-PL5-Z01	Bearing - NEEDLE, 23X29X25	Bearing - NEEDLE, 23X29X25
20	91018-P56-003	Bearing - THRUST NEEDLE, 32X44X2 (NTN)	Bearing - THRUST NEEDLE, 32X44X2 (NTN)
20	91018-PA9-003	Bearing - THRUST NEEDLE, 32X44X2 (NTN)	Bearing - THRUST NEEDLE, 32X44X2 (NTN)
21	91019-PG4-003	Bearing - THRUST NEEDLE, 31X47X2	Bearing - THRUST NEEDLE, 31X47X2
22	91023-PG4-013	Bearing - THRUST NEEDLE, 36X56X2.5 (NTN)	Bearing - THRUST NEEDLE, 36X56X2.5 (NTN)
19	91024-PL5-J01	Bearing - NEEDLE, 33X39X14	Bearing - NEEDLE, 33X39X14
20	91025-639-004	Bearing - NEEDLE, 14X18X15 (KOYO)	Bearing - NEEDLE, 14X18X15 (KOYO)
20	91025-PJ2-003	Bearing - NEEDLE, 14X18X15 (NTN)	Bearing - NEEDLE, 14X18X15 (NTN)
21	91028-PL5-003	Bearing - THRUST NEEDLE, 44X49X24	Bearing - THRUST NEEDLE, 44X49X24
23	91031-PC9-003	Bearing - THRUST NEEDLE, 39X54X2 (NTN)	Bearing - THRUST NEEDLE, 39X54X2 (NTN)
23	91031-PC9-005	Bearing - THRUST NEEDLE, 39X54X2 (KOYO)	Bearing - THRUST NEEDLE, 39X54X2 (KOYO)
23	91031-PC9-006	Bearing - THRUST NEEDLE, 39X54X2 (NIPPON SEIKO)	Bearing - THRUST NEEDLE, 39X54X2 (NIPPON SEIKO)
22	91031-PL5-003	Bearing - THRUST NEEDLE, 50X66X2.5	Bearing - THRUST NEEDLE, 50X66X2.5
35	91052-SD4-J62	Bearing - 6906Z	Bearing - 6906Z
36	91053-SD4-J61	Bearing - 6001Z	Bearing - 6001Z
7	91057-SD2-004	Bearing - HALF SHAFT (KOYO SEIKO)	Bearing - HALF SHAFT (KOYO SEIKO)
7	91057-SD9-008	Bearing - HALF SHAFT (TOYO SEIKO)	Bearing - HALF SHAFT (TOYO SEIKO)
28	91101-PF4-003	Roller - 3.5X21.8	Roller - 3.5X21.8
24	91101-PL5-003	Bearing - THRUST NEEDLE, 36X42X18.5	Bearing - THRUST NEEDLE, 36X42X18.5
28	91102-PF4-000	Roller - 3.5X19.8	Roller - 3.5X19.8
14	91102-PG2-008	Bearing - NEEDLE, 25X56.4X19	Bearing - NEEDLE, 25X56.4X19
14	91102-PL5-003	Bearing - NEEDLE, 38.5X67X19	Bearing - NEEDLE, 38.5X67X19
37	91103-429-000	Dowel pin - 8X10	Dowel pin - 8X10
8	91103-PG2-004	Bearing - NEEDLE, 33X62X22 (KOYO)	Bearing - NEEDLE, 33X62X22 (KOYO)
8	91103-PG2-008	Bearing - NEEDLE, 33X62X22 (TOYO)	Bearing - NEEDLE, 33X62X22 (TOYO)
12	91104-PG1-771	Bearing - NEEDLE, 38X43X26 (NTN)	Bearing - NEEDLE, 38X43X26 (NTN)
12	91104-PG2-004	Bearing - NEEDLE, 38X43X26 (KOYO)	Bearing - NEEDLE, 38X43X26 (KOYO)
12	91104-PK5-008	Bearing - NEEDLE, 38X43X26 (NTN)	Bearing - NEEDLE, 38X43X26 (NTN)
15	91105-PG1-008	Bearing - NEEDLE, 40X46X29 (NTN)	Bearing - NEEDLE, 40X46X29 (NTN)
15	91105-PG2-004	Bearing - NEEDLE, 40X46X29 (KOYO)	Bearing - NEEDLE, 40X46X29 (KOYO)
15	91105-PK5-008	Bearing - NEEDLE, 40X46X29 (NTN)	Bearing - NEEDLE, 40X46X29 (NTN)
16	91106-PG1-008	Bearing - NEEDLE, 44X50X29 (NTN)	Bearing - NEEDLE, 44X50X29 (NTN)
16	91106-PG2-004	Bearing - NEEDLE, 44X50X29 (KOYO)	Bearing - NEEDLE, 44X50X29 (KOYO)
16	91106-PK5-008	Bearing - NEEDLE, 44X50X29 (NTN)	Bearing - NEEDLE, 44X50X29 (NTN)
38	91154-SA5-952	Roller - 3.5X29.8	Roller - 3.5X29.8
17	91201-PA9-003	Oil seal - 9X18X7 (NOK)	Oil seal - 9X18X7 (NOK)
17	91201-PA9-004	Oil seal - 9X18X7 (ARAI)	Oil seal - 9X18X7 (ARAI)
9	91201-PE0-003	Oil seal - 16X30X7 (NOK)	Oil seal - 16X30X7 (NOK)
9	91201-PE0-004	Oil seal - 16X30X7 (ARAI)	Oil seal - 16X30X7 (ARAI)
39	91202-SD4-951	Ring - BACK UP	Ring - BACK UP
9	91206-PG2-005	Oil seal - 40X56X9 (NOK)	Oil seal - 40X56X9 (NOK)
16	91207-PG4-005	Oil seal - 44X68X8	Oil seal - 44X68X8
17	91209-612-000	Oil seal - 12X22X7	Oil seal - 12X22X7
17	91209-612-003	Oil seal - 12X22X7 (ARAI)	Oil seal - 12X22X7 (ARAI)
19	91212-PH7-013	Oil seal - 41X56X8	Oil seal - 41X56X8
15	91213-PH7-004	Oil seal - 35X50X8 (ARAI)	Oil seal - 35X50X8 (ARAI)
15	91213-PL2-003	Oil seal - 35X50X8 (NOK)	Oil seal - 35X50X8 (NOK)
24	91214-PL2-003	Oil seal	Oil seal
24	91214-PL2-004	Oil seal - 80X98X10 (ARAI)	Oil seal - 80X98X10 (ARAI)
24	91214-PNA-014	Oil seal - 80X98X10 (ARAI)	Oil seal - 80X98X10 (ARAI)
10	91215-PG2-005	Oil seal - 16X27X16 (NOK)	Oil seal - 16X27X16 (NOK)
11	91216-PG1-003	Oil seal - 28X43X7 (ARAI)	Oil seal - 28X43X7 (ARAI)
11	91216-PG1-005	Oil seal - 28X43X7 (NOK)	Oil seal - 28X43X7 (NOK)
8	91260-SD9-014	Seal - HALF SHAFT OUTER (ARAI)	Seal - HALF SHAFT OUTER (ARAI)
8	91260-SD9-023	Seal - HALF SHAFT OUTER (NOK)	Seal - HALF SHAFT OUTER (NOK)
9	91262-SE0-003	Seal - HALF SHAFT INNER (NOK)	Seal - HALF SHAFT INNER (NOK)
9	91262-SE0-004	Seal - HALF SHAFT INNER (ARAI)	Seal - HALF SHAFT INNER (ARAI)
28	91301-671-671	O-ring - 1.9X11	O-ring - 1.9X11
14	91301-706-000	O-ring - 12X2.5	O-ring - 12X2.5
32	91301-P2F-A01	O-ring - 7.3X2.2 (NOK)	O-ring - 7.3X2.2 (NOK)
20	91301-PC9-003	O-ring - 7.7X2.3 (ARAI)	O-ring - 7.7X2.3 (ARAI)
20	91301-PC9-004	O-ring - 7.7X2.3 (NOK)	O-ring - 7.7X2.3 (NOK)
32	91301-PD6-003	O-ring - 7.3X2.2 (ARAI)	O-ring - 7.3X2.2 (ARAI)
25	91301-PH3-003	O-ring - 28.7X3.5	O-ring - 28.7X3.5
6	91302-639-000	O-ring - 32X1.9	O-ring - 32X1.9
20	91302-GE0-000	O-ring (8.8x1.9)	O-ring (8.8x1.9)
24	91302-PA9-003	O-ring, 39.8X2.2 (ARAI)	O-ring, 39.8X2.2 (ARAI)
24	91302-PA9-004	O-ring - 39.8X2.2 (NOK)	O-ring - 39.8X2.2 (NOK)
25	91302-PG4-003	O-ring - 42.8X2.2 (ARAI)	O-ring - 42.8X2.2 (ARAI)
28	91303-HA0-004	O-ring, 11x1.9 (nok)	O-ring, 11x1.9 (nok)
11	91303-PD1-910	O-ring - 7.5X1.5	O-ring - 7.5X1.5
26	91303-PF4-004	O-ring - 110X2.2 (NOK)	O-ring - 110X2.2 (NOK)
10	91303-PH1-003	Seal - HOUSING (NOK)	Seal - HOUSING (NOK)
10	91303-PH1-004	Seal - HOUSING (ARAI)	Seal - HOUSING (ARAI)
11	91303-PK2-005	O-ring (7.5X1.5)	O-ring (7.5X1.5)
39	91304-PA6-003	O-ring - 7.8X1.9	O-ring - 7.8X1.9
22	91304-PE2-005	O-ring - 15.8X1.9	O-ring - 15.8X1.9
40	91305-MCJ-751	O-ring (3.2x1.1)	O-ring (3.2x1.1)
21	91305-PC9-003	O-ring - 34X1.9 (ARAI)	O-ring - 34X1.9 (ARAI)
21	91305-PC9-004	O-ring - 34X1.9 (NOK)	O-ring - 34X1.9 (NOK)
26	91305-PH7-003	O-ring - 12.5X2.4	O-ring - 12.5X2.4
22	91307-425-003	O-ring - 21.5X3.2	O-ring - 21.5X3.2
27	91307-611-000	O-ring (13.5X1.4)	O-ring (13.5X1.4)
25	91307-PA9-003	O-ring 31.2X1.9 (ARAI)	O-ring 31.2X1.9 (ARAI)
25	91307-PA9-004	O-ring - 31.2X1.9 (NOK)	O-ring - 31.2X1.9 (NOK)
11	91307-PH1-004	Seal - PLUNGER	Seal - PLUNGER
25	91307-PH7-660	O-ring (13.5X1.4)	O-ring (13.5X1.4)
23	91307-PL5-003	O-ring - 34.2X1.9	O-ring - 34.2X1.9
22	91308-PA9-003	O-ring - 19.8X1.9 (ARAI)	O-ring - 19.8X1.9 (ARAI)
22	91308-PA9-004	O-ring - 19.8X1.9 (NOK)	O-ring - 19.8X1.9 (NOK)
20	91308-PH7-003	O-ring - OIL JOINT	O-ring - OIL JOINT
20	91308-PH9-000	O-ring - 8.8X1.9	O-ring - 8.8X1.9
21	91309-PH7-000	O-ring - 17.4X3.5	O-ring - 17.4X3.5
23	91309-PX4-003	O-ring - 16X2.1 (NOK)	O-ring - 16X2.1 (NOK)
22	91310-PH7-000	O-ring - 19.8X2.4	O-ring - 19.8X2.4
24	91311-PA9-003	O-ring - 7.7X1.9 (ARAI)	O-ring - 7.7X1.9 (ARAI)
24	91311-PA9-004	O-ring - 7.7X1.9 (NOK)	O-ring - 7.7X1.9 (NOK)
17	91311-PH7-003	O-ring - 13.8X2.4 (NOK)	O-ring - 13.8X2.4 (NOK)
17	91311-PH7-004	O-ring - 13.8X2.4 (ARAI)	O-ring - 13.8X2.4 (ARAI)
19	91312-PH7-000	O-ring - 8.8X1.5	O-ring - 8.8X1.5
7	91313-611-010	O-ring - 23.5X2	O-ring - 23.5X2
11	91313-PH7-003	O-ring - 28.2X2.4	O-ring - 28.2X2.4
25	91314-PC9-003	O-ring - 8.5X1.9 (ARAI)	O-ring - 8.5X1.9 (ARAI)
25	91314-PC9-004	O-ring - 8.5X1.9 (NOK)	O-ring - 8.5X1.9 (NOK)
40	91314-PE0-000	O-ring - 19.8X1.9	O-ring - 19.8X1.9
12	91314-PH7-003	O-ring 31.2X4.1 (NOK)	O-ring 31.2X4.1 (NOK)
15	91316-PE7-730	O-ring - 62.4X3.1	O-ring - 62.4X3.1
29	91316-PF4-003	O-ring - 31X1.7 (ARAI)	O-ring - 31X1.7 (ARAI)
30	91318-PA9-003	O-ring - 23.5X2.1 (ARAI)	O-ring - 23.5X2.1 (ARAI)
30	91318-PA9-004	O-ring - 23.5X2.1 (NOK)	O-ring - 23.5X2.1 (NOK)
16	91318-PH7-003	O-ring - OIL FILTER CASE (ARAI)	O-ring - OIL FILTER CASE (ARAI)
16	91318-PH7-004	O-ring - OIL FILTER CASE (NOK)	O-ring - OIL FILTER CASE (NOK)
16	91318-PY3-000	Packing - OIL PUMP	Packing - OIL PUMP
12	91322-PH1-003	O-ring - 18.3X1.9 (NOK)	O-ring - 18.3X1.9 (NOK)
12	91322-PH1-004	O-ring - 18.3X1.9 (ARAI)	O-ring - 18.3X1.9 (ARAI)
27	91323-PH7-003	Packing - BEARING CAP BRIDGE (ARAI)	Packing - BEARING CAP BRIDGE (ARAI)
27	91323-PH7-004	Packing - BEARING CAP BRIDGE (NOK)	Packing - BEARING CAP BRIDGE (NOK)
28	91326-PL5-003	O-ring - 26X2.4(NOK)	O-ring - 26X2.4(NOK)
17	91327-PH7-003	O-ring - 29X2.4 (NOK)	O-ring - 29X2.4 (NOK)
17	91327-PH7-004	O-ring - 29X2.4 (ARAI)	O-ring - 29X2.4 (ARAI)
29	91331-PC9-003	O-ring	O-ring
29	91331-PC9-004	O-ring - 21.2X2.4 (NOK)	O-ring - 21.2X2.4 (NOK)
32	91344-580-000	O-ring - 31X2.7 (ARAI)	O-ring - 31X2.7 (ARAI)
31	91344-PC9-003	O-ring - 29X2.4 (ARAI)	O-ring - 29X2.4 (ARAI)
31	91344-PC9-004	O-ring - 29X2.4 (NOK)	O-ring - 29X2.4 (NOK)
26	91344-PN1-003	O-ring - 30.7X2.4 (NOK)	O-ring - 30.7X2.4 (NOK)
40	91350-671-003	O-ring - 3.4MM (ARAI)	O-ring - 3.4MM (ARAI)
40	91350-671-004	O-ring - 3.4MM (NOK)	O-ring - 3.4MM (NOK)
29	91351-SD4-000	O-ring - 40X3MM	O-ring - 40X3MM
41	91352-SA5-951	O-ring - 7.8X1.9(ARAI)	O-ring - 7.8X1.9(ARAI)
41	91352-SA5-952	O-ring - 7.8X1.9 (NOK)	O-ring - 7.8X1.9 (NOK)
42	91353-SA5-951	O-ring - 11X1.9 (ARAI)	O-ring - 11X1.9 (ARAI)
43	91354-SD4-951	O-ring - 27.5X2 (NOK)	O-ring - 27.5X2 (NOK)
43	91354-SD4-952	O-ring - 27.5X2 (ARAI)	O-ring - 27.5X2 (ARAI)
44	91355-SD4-953	O-ring - 37X1.5 (NOK)	O-ring - 37X1.5 (NOK)
44	91355-SD4-954	O-ring - 37X1.5 (ARAI)	O-ring - 37X1.5 (ARAI)
45	91356-SD4-953	O-ring - 31.5X2.4 (NOK)	O-ring - 31.5X2.4 (NOK)
46	91360-SD4-951	O-ring - 50X2.4 (NOK)	O-ring - 50X2.4 (NOK)
46	91360-SD4-952	O-ring - 50X2.4 (ARAI)	O-ring - 50X2.4 (ARAI)
47	91361-SA5-951	O-ring - 46X1.5 (ARAI)	O-ring - 46X1.5 (ARAI)
47	91361-SA5-952	O-ring - 46X1.5 (NOK)	O-ring - 46X1.5 (NOK)
48	91362-SE0-951	O-ring - 45.5X2 (ARAI)	O-ring - 45.5X2 (ARAI)
48	91362-SE0-952	O-ring - 45.5X2 (NOK)	O-ring - 45.5X2 (NOK)
41	91370-SB3-950	O-ring - 8.8X1.9	O-ring - 8.8X1.9
18	91405-679-004	Clamp - TUBE (D17)	Clamp - TUBE (D17)
18	91405-PD1-004	Clamp - TUBE(D12)	Clamp - TUBE(D12)
25	91405-PH7-003	Clamp - TUBE (D15)	Clamp - TUBE (D15)
15	91405-PK1-003	Clip, WATER HOSE, 24MM	Clip, WATER HOSE, 24MM
18	91405-PM5-004	Clamp - TUBE (D17)	Clamp - TUBE (D17)
17	91406-SA7-931	Clamp - FUEL HOSE, 15.5MM	Clamp - FUEL HOSE, 15.5MM
17	91406-SL0-931	Clamp - FUEL HOSE, 15.5MM	Clamp - FUEL HOSE, 15.5MM
20	91451-688-000	Grommet - TRUNK LID	Grommet - TRUNK LID
43	91462-SA5-950	Clamp d - 19MM	Clamp d - 19MM
72	91501-S04-003	Clip - INNER FENDER	Clip - INNER FENDER
38	91501-SF1-003	Clip - HOOD INSULATOR	Clip - HOOD INSULATOR
31	91502-SG0-003	Clip - FR. WINDSHIELD UPPER MOLDING	Clip - FR. WINDSHIELD UPPER MOLDING
32	91505-SG0-003	Clip A - FR. WINDSHIELD UPPER MOLDING (ORANGE)	Clip A - FR. WINDSHIELD UPPER MOLDING (ORANGE)
26	91506-PH7-003	Clip - WIRE HARNESS (BLACK)	Clip - WIRE HARNESS (BLACK)
30	91512-SE0-003	Clip - WASHER TUBE	Clip - WASHER TUBE
26	91512-SR3-004	Clip - TUBULAR	Clip - TUBULAR
31	91519-SE0-000	Clip - WASHER TUBE	Clip - WASHER TUBE
14	91530-SD4-003	Clip - DASHBOARD INSULATOR OUTER	Clip - DASHBOARD INSULATOR OUTER
59	91530-SE0-003	Clip A - DOOR WEATHERSTRIP	Clip A - DOOR WEATHERSTRIP
27	91532-SG0-003	Clip - FAIRING	Clip - FAIRING
28	91533-SG0-000	Clip b - FAIRING	Clip b - FAIRING
26	91547-SE0-000	Washer - LINK	Washer - LINK
16	91547-SF4-003	Band - WIRE HARNESS (BLUE) (123.5MM)	Band - WIRE HARNESS (BLUE) (123.5MM)
19	91549-SE0-003	Holder - DRAIN HOSE	Holder - DRAIN HOSE
18	91551-SF4-003	Band - WIRE HARNESS(BROWN) (110MM)	Band - WIRE HARNESS(BROWN) (110MM)
11	91553-SD4-A00	Joint - VACUUM TUBE	Joint - VACUUM TUBE
39	91558-SE3-003	Clip - HOOD WIRE	Clip - HOOD WIRE
20	91559-SE3-003	Clip - WIRE HARNESS (WHITE) (55MM)	Clip - WIRE HARNESS (WHITE) (55MM)
21	91567-SE0-003	Band - WIRE HARNESS(WHITE) (93.5MM)	Band - WIRE HARNESS(WHITE) (93.5MM)
39	91588-SD4-004	Grommet - CABIN WIRE HARNESS	Grommet - CABIN WIRE HARNESS
34	91592-SG0-003	Clamp	Clamp
22	91602-SD4-000	Grommet - 32MM	Grommet - 32MM
23	91603-SD4-000	Grommet - WAX HOLE, 25MM	Grommet - WAX HOLE, 25MM
40	91605-SD4-000	Grommet - HOOD HINGE	Grommet - HOOD HINGE
26	91606-SE0-000	Seal - 20X20	Seal - 20X20
41	91610-SD4-000	Plug - HOLE, 28MM	Plug - HOLE, 28MM
28	91611-SG0-003	Plug - FLOOR HOLE, 25MM	Plug - FLOOR HOLE, 25MM
21	91613-SE0-003	Grommet - SUB FRAME, 15MM	Grommet - SUB FRAME, 15MM
30	91613-SG0-003	Plug - FLOOR HOLE, 50MM	Plug - FLOOR HOLE, 50MM
31	91614-SA5-000	Grommet - HEATER LEVER HOLE (20MM)	Grommet - HEATER LEVER HOLE (20MM)
33	91617-SB6-000	Grommet - WASHER HOSE, 32MM	Grommet - WASHER HOSE, 32MM
25	91619-SA5-000	Grommet - SCREW, 6MM	Grommet - SCREW, 6MM
29	91620-SA5-000	Plug - CONSOLE	Plug - CONSOLE
34	91624-SE0-000	Seal - DASHBOARD UPPER	Seal - DASHBOARD UPPER
27	91633-SE0-003	Plug - HOLE, 20MM	Plug - HOLE, 20MM
40	91637-SF1-003	Cap - 090 2P	Cap - 090 2P
26	91640-SD4-003	Cap - VALVE	Cap - VALVE
28	91704-PF4-000	Dowel pin - 8X40	Dowel pin - 8X40

この比較のURL: https://xparts.kbsr.co.jp/compare/KA3/KA4
