ES8 × S04

共通 177 / 合計 3,369 · Jaccard 5.3%
ES8 Honda CIVIC — 1,774 中 177 共有
S04 Honda CIVIC — 1,772 中 177 共有
177 件
Air conditioner (COMPRESSOR) 1 / 15
ES8 Air conditioner (COMPRESSOR)
S04 Air conditioner (COMPRESSOR; SANDEN; 1)
# OEM ES8 S04
13 90023-P2A-000 Bolt - FLANGE, 8X100 Bolt - FLANGE, 8X100
Air conditioner (CONDENSER) 2 / 15
ES8 Air conditioner (CONDENSER)
S04 Air conditioner (CONDENSER)
# OEM ES8 S04
10 90041-PAA-A01 Nut - TOOTHED, 5MM Nut - TOOTHED, 5MM
11 90430-PAA-A01 Washer - PLAIN, 8MM Washer - PLAIN, 8MM
Air conditioner (HOSES/PIPES; LH) 4 / 25
ES8 Air conditioner (HOSES/PIPES; LH)
S04 Air conditioner (HOSES/PIPES; LH)
# OEM ES8 S04
24 80871-ST7-000 O-ring - 5/8" O-ring - 5/8"
25 80872-ST7-000 O-ring - 1/2" O-ring - 1/2"
26 80873-ST7-000 O-ring - 8MM O-ring - 8MM
28 90361-SV4-003 Nut - PAINT CUTTING, 6MM Nut - PAINT CUTTING, 6MM
Alternator (MITSUBISHI) 1 / 14
ES8 Alternator (MITSUBISHI)
S04 Alternator (MITSUBISHI)
# OEM ES8 S04
9 31140-P64-902 Brush set Brush set
Antenna/speaker 2 / 12
ES8 Antenna/speaker
S04 Harness band/bracket (LH)
# OEM ES8 S04
10 91531-S04-003 Clip - WIRE HARNESS(NATURAL) (44MM) Clip - WIRE HARNESS(NATURAL) (44MM)
12 91540-S30-003 Clip - HARNESS BAND(NATURAL) (151.5MM) Clip - HARNESS BAND(NATURAL) (151.5MM)
Battery 1 / 11
ES8 Battery
S04 Battery (LH)
# OEM ES8 S04
6 31542-SA5-665 Plug - VENT (MF) (PANASONIC) Plug - VENT (MF) (PANASONIC)
Brake lines (LH) 4 / 26
ES8 Brake lines (LH)
S04 Brake lines (LH)
# OEM ES8 S04
23 46462-SE0-000 Bolt - OIL Bolt - OIL
24 46472-568-000 Packing - OIL BOLT Packing - OIL BOLT
25 90361-SV4-003 Nut - PAINT CUTTING, 6MM Nut - PAINT CUTTING, 6MM
26 90651-538-000 Clip - BRAKE HOSE Clip - BRAKE HOSE
Brake master cylinder/ master power (LH) 3 / 20
ES8 Brake master cylinder/ master power (LH)
S04 Brake master cylinder/ master power
# OEM ES8 S04
4 46120-SD2-013 Piston assy. - PRIMARY Piston assy. - PRIMARY
15 46512-S70-000 Pin - PEDAL Pin - PEDAL
21 46911-S70-003 Pin, LOCK(8MM) Pin, LOCK(8MM)
Bumpers 5 / 24
ES8 Bumpers
S04 Front grille (1)
# OEM ES8 S04
24 90109-SS0-000 Screw - TAPPING, 5X20 Screw - TAPPING, 5X20
25 90126-SR4-000 Screw-washer - 5X16 Screw-washer - 5X16
27 90301-SP0-003 Nut - PAINT CUTTING, 6MM Nut - PAINT CUTTING, 6MM
31 90682-SB0-003 Grommet - SCREW, 5MM Grommet - SCREW, 5MM
33 91503-SZ3-003 Clip A Clip A
Camshaft/timing belt 2 / 19
ES8 Camshaft/timing belt
S04 Camshaft/timing belt (1)
# OEM ES8 S04
5 11832-P08-000 Rubber - R. BACK SEAL Rubber - R. BACK SEAL
18 91213-PE1-722 Oil seal - 29X45X8 (NOK) Oil seal - 29X45X8 (NOK)
Clutch case 2 / 9
ES8 Clutch case
S04 Clutch housing (1)
# OEM ES8 S04
5 91002-PS0-003 Bearing - BALL, 26X58X15 (NTN) Bearing - BALL, 26X58X15 (NTN)
7 91205-PL3-A01 Oil seal - 35X56X8 (ARAI) Oil seal - 35X56X8 (ARAI)
Clutch master cylinder (LH) 5 / 36
ES8 Clutch master cylinder (LH)
S04 Clutch master cylinder (LH)
# OEM ES8 S04
2 43352-567-000 Screw - BLEEDER Screw - BLEEDER
3 43353-SD5-003 Cap - BLEEDER SCREW Cap - BLEEDER SCREW
5 46182-500-013 Circlip Circlip
6 46911-S70-003 Pin, LOCK(8MM) Pin, LOCK(8MM)
35 90651-538-000 Clip - BRAKE HOSE Clip - BRAKE HOSE
Clutch release 1 / 11
ES8 Clutch release
S04 Clutch release (1)
# OEM ES8 S04
4 22835-P7N-000 Spring - RELEASE FORK SETTING Spring - RELEASE FORK SETTING
Clutch/torque converter 5 / 7
ES8 Clutch/torque converter
S04 Clutch/torque converter
# OEM ES8 S04
3 22100-P2Y-005 Flywheel comp. Flywheel comp.
5 22300-P2Y-005 Disk comp - PRESSURE Disk comp - PRESSURE
8 90011-PM0-000 Bolt - 12MM Bolt - 12MM
11 90034-689-000 Bolt - TWELVE POINT, 8MM (TOKAI TRW) Bolt - TWELVE POINT, 8MM (TOKAI TRW)
13 91006-634-008 Bearing - CLUTCH PILOT (NTN) Bearing - CLUTCH PILOT (NTN)
Console (2) 2 / 11
ES8 Console (2)
S04 Console
# OEM ES8 S04
19 90137-SH3-000 Screw - TAPPING, 4X16 Screw - TAPPING, 4X16
23 91641-SM4-003 Grommet - SCREW, 4MM Grommet - SCREW, 4MM
Control unit (ENGINE ROOM) 3 / 21
ES8 Control unit (ENGINE ROOM)
S04 Control unit (ENGINE ROOM; LH)
# OEM ES8 S04
21 39794-SE0-003 Relay assy - POWER(4P)(DENSO) (056700-7250) Relay assy - POWER(4P)(DENSO) (056700-7250)
21 39794-SL0-004 Relay assy - POWER(4P) (MITSUBA)(RC-2225)(BLACK) Relay assy - POWER(4P) (MITSUBA)(RC-2225)(BLACK)
24 90150-S84-003 Bolt - EARTH, 8X16 Bolt - EARTH, 8X16
Countershaft 1 / 18
ES8 Countershaft
S04 Countershaft (1)
# OEM ES8 S04
14 91102-PLW-003 Bearing - NEEDLE, 25X52.2X15 Bearing - NEEDLE, 25X52.2X15
Cylinder block/oil pan 6 / 21
ES8 Cylinder block/oil pan
S04 Cylinder block/oil pan (1)
# OEM ES8 S04
7 11251-P2A-014 Packing - OIL PAN (OTSUKA) Packing - OIL PAN (OTSUKA)
12 37240-PT0-023 Switch - OIL PRESSURE(DENSO) Switch - OIL PRESSURE(DENSO)
12 37240-PT0-014 Switch - OIL PRESSURE (TEC) Switch - OIL PRESSURE (TEC)
14 90008-PM0-003 Bolt-washer - 10X112 Bolt-washer - 10X112
16 90009-PH1-000 Bolt - DRAIN PLUG, 14MM Bolt - DRAIN PLUG, 14MM
20 90702-PE0-000 Dowel pin - 12X18 Dowel pin - 12X18
Cylinder head cover 2 / 16
ES8 Cylinder head cover
S04 Cylinder head cover (1)
# OEM ES8 S04
6 12342-P08-004 Seal Seal
6 12342-RYE-004 Seal,spark plug t Seal,spark plug t
Differential 19 / 21
ES8 Differential
S04 Differential gear (1)
# OEM ES8 S04
5 41446-PL3-B00 Shim f - 80MM(1.5) Shim f - 80MM(1.5)
5 41441-PL3-B00 Shim a - 80MM(1.0) Shim a - 80MM(1.0)
5 41457-PL3-B00 Shim s - 80MM(1.75) Shim s - 80MM(1.75)
5 41452-PL3-B00 Shim m - 80MM(1.25) Shim m - 80MM(1.25)
5 41447-PL3-B00 Shim g - 80MM(1.6) Shim g - 80MM(1.6)
5 41442-PL3-B00 Shim b - 80MM(1.1) Shim b - 80MM(1.1)
5 41453-PL3-B00 Shim n - 80MM(1.35) Shim n - 80MM(1.35)
5 41448-PL3-B00 Shim h - 80MM(1.7) Shim h - 80MM(1.7)
5 41443-PL3-B00 Shim c - 80MM(1.2) Shim c - 80MM(1.2)
5 41454-PL3-B00 Shim p - 80MM(1.45) Shim p - 80MM(1.45)
5 41449-PL3-B00 Shim j - 80MM(1.8) Shim j - 80MM(1.8)
5 41444-PL3-B00 Shim d - 80MM(1.3) Shim d - 80MM(1.3)
5 41455-PL3-B00 Shim q - 80MM(1.55) Shim q - 80MM(1.55)
5 41450-PL3-B00 Shim k - 80MM(1.05) Shim k - 80MM(1.05)
5 41445-PL3-B00 Shim e - 80MM(1.4) Shim e - 80MM(1.4)
5 41456-PL3-B00 Shim r - 80MM(1.65) Shim r - 80MM(1.65)
5 41451-PL3-B00 Shim l - 80MM(1.15) Shim l - 80MM(1.15)
6 90015-634-010 Bolt - FLANGE, 10MM Bolt - FLANGE, 10MM
7 91005-PS1-003 Bearing - SEALED BALL, 6208C (NTN) Bearing - SEALED BALL, 6208C (NTN)
Emblems/caution labels 1 / 8
ES8 Emblems/caution labels
S04 Emblems/caution labels
# OEM ES8 S04
2 17669-SA0-670 Label - FUEL FILLER CAUTION (UNLEADED FUEL ONLY) Label - FUEL FILLER CAUTION (UNLEADED FUEL ONLY)
Engine mounting bracket 1 / 10
ES8 Engine mounting bracket
S04 Alternator bracket/ engine stiffener
# OEM ES8 S04
11 90050-PG7-000 Bolt - FLANGE, 12X65 Bolt - FLANGE, 12X65
Engine wire harness (LH) 3 / 28
ES8 Engine wire harness (LH)
S04 Engine wire harness (LH)
# OEM ES8 S04
26 91506-P01-003 Clip A - HARNESS BAND (DARK GRAY) (129.4MM) Clip A - HARNESS BAND (DARK GRAY) (129.4MM)
28 91551-SF4-003 Band - WIRE HARNESS(BROWN) (110MM) Band - WIRE HARNESS(BROWN) (110MM)
29 91558-ST5-003 Clip - HARNESS BAND(NATURAL) (135MM)(7MM HOLE) Clip - HARNESS BAND(NATURAL) (135MM)(7MM HOLE)
Exhaust pipe/silencer 2 / 14
ES8 Exhaust pipe/silencer
S04 Exhaust pipe
# OEM ES8 S04
14 18229-S04-X01 Gasket - EX. FLEXIBLE Gasket - EX. FLEXIBLE
14 18229-SNA-A01 Gasket, EX. FLEXIBLE Gasket, EX. FLEXIBLE
Front brake (1) 6 / 21
ES8 Front brake (1)
S04 Front brake
# OEM ES8 S04
1 01463-S04-V00 Caliper set - FR. Caliper set - FR.
1 01463-S04-V01 SET, FR CALIPER SET, FR CALIPER
5 43353-SD5-003 Cap - BLEEDER SCREW Cap - BLEEDER SCREW
11 45216-S5A-J01 Piston Piston
17 45255-SR3-V01 Guard - FR. BRAKE SPLASH Guard - FR. BRAKE SPLASH
21 90681-SR3-A00 Circlip, SPECIAL INTERNAL, 79MM Circlip, SPECIAL INTERNAL, 79MM
Front door lining (LH) 1 / 5
ES8 Front door lining (LH)
S04 Front door lining (LH)
# OEM ES8 S04
17 90132-SS0-000 Screw - TAPPING, 4X10 (PO) Screw - TAPPING, 4X10 (PO)
Front door locks 3 / 38
ES8 Front door locks
S04 Harness band/bracket (LH)
# OEM ES8 S04
18 72139-SR0-A01 Snap - VIOLET Snap - VIOLET
48 91531-S04-003 Clip - WIRE HARNESS(NATURAL) (44MM) Clip - WIRE HARNESS(NATURAL) (44MM)
49 91540-S30-003 Clip - HARNESS BAND(NATURAL) (151.5MM) Clip - HARNESS BAND(NATURAL) (151.5MM)
Front door windows 2 / 12
ES8 Front door windows
S04 Harness band/bracket (LH)
# OEM ES8 S04
15 91533-S04-003 Clip - COUPLER (NATURAL) Clip - COUPLER (NATURAL)
16 91540-S30-003 Clip - HARNESS BAND(NATURAL) (151.5MM) Clip - HARNESS BAND(NATURAL) (151.5MM)
Front driveshaft/ half shaft 3 / 18
ES8 Front driveshaft/ half shaft
S04 Driveshaft/half shaft
# OEM ES8 S04
11 44319-SR1-003 Set ring - 26X1.8 (GKN) Set ring - 26X1.8 (GKN)
12 44327-SV4-305 Band - JOINT BOOT (DOUBLE ROLLED BAND) Band - JOINT BOOT (DOUBLE ROLLED BAND)
13 44329-SV4-305 Band - SHAFT BOOT (DOUBLE ROLLED BAND) Band - SHAFT BOOT (DOUBLE ROLLED BAND)
Front fenders 5 / 15
ES8 Front fenders
S04 Front fenders
# OEM ES8 S04
9 90114-SE0-000 Screw - TAPPING, 5X20 Screw - TAPPING, 5X20
11 90308-SB2-000 Nut - SUSPENSION, 5MM Nut - SUSPENSION, 5MM
11 90308-SB2-013 Nut - SUSPENSION, 5MM Nut - SUSPENSION, 5MM
12 90682-SB0-003 Grommet - SCREW, 5MM Grommet - SCREW, 5MM
15 91503-SZ3-003 Clip A Clip A
Front grille (1) 2 / 7
ES8 Front grille (1)
S04 Front grille (1)
# OEM ES8 S04
7 90301-ST0-003 push nut, 3mm push nut, 3mm
8 91503-SZ3-003 Clip A Clip A
Front seat (LH; DRIVER SIDE) 1 / 9
ES8 Front seat (LH; DRIVER SIDE)
S04 Front seat
# OEM ES8 S04
12 81223-S04-000 Clip - SHAFT, 8MM Clip - SHAFT, 8MM
Front seat components (L.; MANUAL HEIGHT) 1 / 11
ES8 Front seat components (L.; MANUAL HEIGHT)
S04 Front seat components (L.; 1)
# OEM ES8 S04
9 90143-SR3-000 Bolt-washer - 10X22 Bolt-washer - 10X22
Front seat components (R.) 1 / 6
ES8 Front seat components (R.)
S04 Front seat components (L.; 1)
# OEM ES8 S04
8 90143-SR3-000 Bolt-washer - 10X22 Bolt-washer - 10X22
Front shock absorber 1 / 16
ES8 Front shock absorber
S04 Front stabilizer/ front lower arm
# OEM ES8 S04
12 90002-S10-000 Nut - FLANGE, 10MM Nut - FLANGE, 10MM
Fuel pipe (2) 1 / 37
ES8 Fuel pipe (2)
S04 Clutch master cylinder (LH)
# OEM ES8 S04
40 90361-SV4-003 Nut - PAINT CUTTING, 6MM Nut - PAINT CUTTING, 6MM
Fuel tank (2) 2 / 43
ES8 Fuel tank (2)
S04 Fuel tank
# OEM ES8 S04
39 90150-S04-003 Bolt - EARTH, 6X16 Bolt - EARTH, 6X16
40 90301-SE0-J00 Nut - FLANGE, 6MM Nut - FLANGE, 6MM
Grommet (FRONT) 1 / 12
ES8 Grommet (FRONT)
S04 Grommet
# OEM ES8 S04
1 72207-SB2-000 Cap - FLOOR HOLE, 24MM Cap - FLOOR HOLE, 24MM
Harness band/bracket (LH) 8 / 26
ES8 Harness band/bracket (LH)
S04 Harness band/bracket (LH)
# OEM ES8 S04
15 91507-SL9-003 Clip - WIRE HARNESS (GREEN) (110MM) (7MM HOLE) Clip - WIRE HARNESS (GREEN) (110MM) (7MM HOLE)
18 91531-S04-003 Clip - WIRE HARNESS(NATURAL) (44MM) Clip - WIRE HARNESS(NATURAL) (44MM)
20 91533-S04-003 Clip - COUPLER (NATURAL) Clip - COUPLER (NATURAL)
22 91540-SV4-003 Clip - HARNESS BAND (NATURAL) (145.2MM) Clip - HARNESS BAND (NATURAL) (145.2MM)
26 91545-SV4-003 Clip - HARNESS BAND (NATURAL) (145.2MM) (WITH SEAL) Clip - HARNESS BAND (NATURAL) (145.2MM) (WITH SEAL)
28 91547-SH3-003 Clip - BAND(NATURAL)(160MM) Clip - BAND(NATURAL)(160MM)
30 91551-SF4-003 Band - WIRE HARNESS(BROWN) (110MM) Band - WIRE HARNESS(BROWN) (110MM)
38 91571-S10-003 Clip - WIRE HARNESS (NATURAL) (130MM) Clip - WIRE HARNESS (NATURAL) (130MM)
Headlight 1 / 15
ES8 Headlight
S04 Headlight
# OEM ES8 S04
11 33301-SA0-741 Bulb (12V 5W) - (12V 5W) (STANLEY) Bulb (12V 5W) - (12V 5W) (STANLEY)
Heater blower (LH) 1 / 19
ES8 Heater blower (LH)
S04 Heater unit (RH)
# OEM ES8 S04
21 90133-SR3-003 Screw-washer - 4X16 Screw-washer - 4X16
Heater unit (LH) 1 / 29
ES8 Heater unit (LH)
S04 Heater unit (RH)
# OEM ES8 S04
35 90133-SR3-003 Screw-washer - 4X16 Screw-washer - 4X16
Hood (LH) 1 / 27
ES8 Hood (LH)
S04 Trunk lid (RH)
# OEM ES8 S04
1 17706-SC3-003 Clip - FUEL PIPE Clip - FUEL PIPE
Instrument panel (LH) 2 / 13
ES8 Instrument panel (LH)
S04 Instrument panel (LH)
# OEM ES8 S04
15 77982-S04-N81 Holder - COUPLER (2P) Holder - COUPLER (2P)
21 90321-SP0-A80 Nut-washer - 6MM Nut-washer - 6MM
Instrument panel garnish (DRIVER SIDE; LH) 2 / 10
ES8 Instrument panel garnish (DRIVER SIDE; LH)
S04 Console
# OEM ES8 S04
2 66418-SA5-000 Stopper - GLOVE BOX LID Stopper - GLOVE BOX LID
15 77873-SP0-A80 Label - STEERING COLUMN CAUTION (ENGLISH/FRENCH) Label - STEERING COLUMN CAUTION (ENGLISH/FRENCH)
Instrument panel garnish (PASSENGER SIDE; LH) 1 / 25
ES8 Instrument panel garnish (PASSENGER SIDE; LH)
S04 Console
# OEM ES8 S04
39 91641-SM4-003 Grommet - SCREW, 4MM Grommet - SCREW, 4MM
Interior light 2 / 8
ES8 Interior light
S04 Interior light
# OEM ES8 S04
9 34295-SJ8-003 Bulb - 12V 5W) (DAIICHI Bulb - 12V 5W) (DAIICHI
9 34351-657-921 Bulb - 12V/5W) (STANLEY Bulb - 12V/5W) (STANLEY
Knuckle 2 / 17
ES8 Knuckle
S04 Front stabilizer/ front lower arm
# OEM ES8 S04
16 90002-S10-000 Nut - FLANGE, 10MM Nut - FLANGE, 10MM
18 90306-SB2-013 Nut - SELF-LOCK, 10MM (CLINCH) Nut - SELF-LOCK, 10MM (CLINCH)
Oil pump/oil strainer 1 / 23
ES8 Oil pump/oil strainer
S04 Oil pump/oil strainer (1)
# OEM ES8 S04
8 15400-RTA-003 OIL FILTER (MAHLE TENNEX) OIL FILTER (MAHLE TENNEX)
Outer panels 1 / 4
ES8 Outer panels
S04 Outer panels
# OEM ES8 S04
19 75450-S04-000 Outlet assy - RR. AIR Outlet assy - RR. AIR
P.s. gear box (HPS; LH) 1 / 21
ES8 P.s. gear box (HPS; LH)
S04 P.s. gear box (LH)
# OEM ES8 S04
9 53546-S84-003 Boot - TIE ROD END (NOK) Boot - TIE ROD END (NOK)
P.s. gear box components (HPS; LH) 8 / 36
ES8 P.s. gear box components (HPS; LH)
S04 P.s. gear box components (LH)
# OEM ES8 S04
3 06534-S84-A01 Ring set - POWER STEERING SEAL (ROTARY VALVE) Ring set - POWER STEERING SEAL (ROTARY VALVE)
4 06535-S50-003 Ring set - POWER STEERING SEAL (ROTARY VALVE) Ring set - POWER STEERING SEAL (ROTARY VALVE)
9 53414-S04-003 Screw - RACK GUIDE Screw - RACK GUIDE
26 53660-S50-003 Oil seal - 27X38X5.5 (SHOWA) Oil seal - 27X38X5.5 (SHOWA)
27 53661-S50-003 Washer - WAVE (SHOWA) Washer - WAVE (SHOWA)
31 53666-S50-003 O-ring - 41.5X2 (SHOWA) O-ring - 41.5X2 (SHOWA)
34 90105-S50-003 Bolt - FLANGE, 8X28 Bolt - FLANGE, 8X28
36 90601-S50-003 Circlip - EXTERNAL, 20MM Circlip - EXTERNAL, 20MM
Parking brake (1) 1 / 9
ES8 Parking brake (1)
S04 Parking brake
# OEM ES8 S04
11 47572-ST0-000 Base - WIRE GUIDE Base - WIRE GUIDE
Pedal (LH) 4 / 25
ES8 Pedal (LH)
S04 Pedal (LH)
# OEM ES8 S04
11 46505-SA5-000 Pad - PEDAL STOPPER Pad - PEDAL STOPPER
18 46905-SK7-000 Stopper - CLUTCH PEDAL Stopper - CLUTCH PEDAL
20 46911-SD4-930 Bush - PEDAL PIN Bush - PEDAL PIN
26 90301-SP0-003 Nut - PAINT CUTTING, 6MM Nut - PAINT CUTTING, 6MM
Piston/crankshaft 3 / 31
ES8 Piston/crankshaft
S04 Piston/crankshaft
# OEM ES8 S04
3 13112-PE0-000 Pin - PISTON Pin - PISTON
4 13204-PE1-003 Bolt Bolt
5 13205-634-010 Nut Nut
Power steering pump /bracket 7 / 30
ES8 Power steering pump /bracket
S04 P.s. pump
# OEM ES8 S04
14 90305-PAA-A01 Nut - POWER STEERING PULLEY Nut - POWER STEERING PULLEY
15 90693-P2A-003 Circlip - INTERNAL, 40MM Circlip - INTERNAL, 40MM
15 90693-PAA-A01 Circlip - INTERNAL, 40MM Circlip - INTERNAL, 40MM
20 91345-PAA-A01 O-ring - 13.0X1.9 O-ring - 13.0X1.9
20 91345-PY3-000 O-ring - 13.0X1.9 O-ring - 13.0X1.9
22 91347-PAA-A01 O-ring - 16.7X1.8 O-ring - 16.7X1.8
27 91350-P8C-A01 Bolt - FLANGE, 6X20 Bolt - FLANGE, 6X20
Protector 2 / 11
ES8 Protector
S04 Bumpers (1)
# OEM ES8 S04
12 90114-SE0-000 Screw - TAPPING, 5X20 Screw - TAPPING, 5X20
13 90345-S04-000 Nut - SUSPENSION, 5MM Nut - SUSPENSION, 5MM
Radiator (DENSO) 6 / 14
ES8 Radiator (DENSO)
S04 Radiator (DENSO)
# OEM ES8 S04
2 19011-PH1-621 Bolt - DRAIN (DENSO) Bolt - DRAIN (DENSO)
3 19012-671-300 Packing - DRAIN (DENSO) Packing - DRAIN (DENSO)
8 19045-PAA-A01 Cap comp. - RADIATOR (DENSO) Cap comp. - RADIATOR (DENSO)
12 90041-P5A-003 Screw-washer - 4X11 Screw-washer - 4X11
13 90042-PAA-A01 Bolt-washer - 6X16 (DENSO) Bolt-washer - 6X16 (DENSO)
14 90043-PD2-003 Nut - HEX., 5MM (DENSO) Nut - HEX., 5MM (DENSO)
Radiator hose/reserve tan k 2 / 13
ES8 Radiator hose/reserve tan k
S04 Radiator hose
# OEM ES8 S04
10 19511-P08-003 Clip - WATER HOSE (CHUO SPRING) Clip - WATER HOSE (CHUO SPRING)
10 19511-PA6-003 Clip - WATER HOSE(CHUO SPRING) Clip - WATER HOSE(CHUO SPRING)
Rear brake (DRUM) 11 / 39
ES8 Rear brake (DRUM)
S04 Rear brake (DRUM)
# OEM ES8 S04
9 43171-S04-003 Spring a - BRAKE SHOE RETURN Spring a - BRAKE SHOE RETURN
18 43353-SD5-003 Cap - BLEEDER SCREW Cap - BLEEDER SCREW
19 43361-SH5-003 Lever - R. PARKING BRAKE Lever - R. PARKING BRAKE
24 43366-SH5-003 Lever comp - R. ADJUSTER Lever comp - R. ADJUSTER
25 43367-SH5-003 Spring - R. ADJUSTER Spring - R. ADJUSTER
26 43371-SH5-003 Lever - L. PARKING BRAKE Lever - L. PARKING BRAKE
30 43376-SH5-003 Lever comp - L. ADJUSTER Lever comp - L. ADJUSTER
31 43377-SH5-003 Spring - L. ADJUSTER Spring - L. ADJUSTER
32 43379-SA5-003 Washer - WAVE Washer - WAVE
33 45172-S04-003 Spring - SHOE CLAMP Spring - SHOE CLAMP
36 90113-SM1-005 Bolt - WHEEL (ROCKNEL FASTENER) Bolt - WHEEL (ROCKNEL FASTENER)
Rear door lining 1 / 4
ES8 Rear door lining
S04 Front door lining (LH)
# OEM ES8 S04
14 90132-SS0-000 Screw - TAPPING, 4X10 (PO) Screw - TAPPING, 4X10 (PO)
Rear door locks 1 / 27
ES8 Rear door locks
S04 Rear door locks
# OEM ES8 S04
5 72139-SR0-A01 Snap - VIOLET Snap - VIOLET
Rear door windows 1 / 14
ES8 Rear door windows
S04 Harness band/bracket (LH)
# OEM ES8 S04
15 91533-S04-003 Clip - COUPLER (NATURAL) Clip - COUPLER (NATURAL)
Rear lower arm 2 / 26
ES8 Rear lower arm
S04 Front stabilizer/ front lower arm
# OEM ES8 S04
22 90002-S10-000 Nut - FLANGE, 10MM Nut - FLANGE, 10MM
23 90306-SB2-013 Nut - SELF-LOCK, 10MM (CLINCH) Nut - SELF-LOCK, 10MM (CLINCH)
Rear seat (1) 1 / 7
ES8 Rear seat (1)
S04 Rear seat (3)
# OEM ES8 S04
6 82127-SM4-J01 Collar - RR. SEATBACK SETTING (A) (TS TECH) Collar - RR. SEATBACK SETTING (A) (TS TECH)
Rear shock absorber 1 / 19
ES8 Rear shock absorber
S04 Front shock absorber
# OEM ES8 S04
2 51728-SB0-004 Collar - SHOCK ABSORBER MOUNTING (SHOWA) Collar - SHOCK ABSORBER MOUNTING (SHOWA)
Shift lever 1 / 12
ES8 Shift lever
S04 Clutch master cylinder (LH)
# OEM ES8 S04
9 90361-SV4-003 Nut - PAINT CUTTING, 6MM Nut - PAINT CUTTING, 6MM
Srs unit (LH) 1 / 5
ES8 Srs unit (LH)
S04 Srs unit (LH)
# OEM ES8 S04
6 90137-S84-A01 Bolt - TORX EARTH, 6X20 Bolt - TORX EARTH, 6X20
Switch (LH) 1 / 2
ES8 Switch (LH)
S04 Console
# OEM ES8 S04
11 90666-SD4-003 Clip - FITTING Clip - FITTING
Taillight/license light 1 / 23
ES8 Taillight/license light
S04 Headlight
# OEM ES8 S04
1 33301-SA0-741 Bulb (12V 5W) - (12V 5W) (STANLEY) Bulb (12V 5W) - (12V 5W) (STANLEY)
Tire/wheel disks 6 / 26
ES8 Tire/wheel disks
S04 Tire/wheel disks
# OEM ES8 S04
9 42753-SE0-A02 Valve - RIM (SCHRADER) Valve - RIM (SCHRADER)
9 42753-SB8-661 Valve - RIM (SCHRADER) Valve - RIM (SCHRADER)
9 42753-671-003 Valve - RIM (TAIHEIYO) Valve - RIM (TAIHEIYO)
9 42753-SH3-003 Valve - RIM (US PACIFIC) Valve - RIM (US PACIFIC)
17 83850-SH3-000 Plate - ANCHOR BOLT Plate - ANCHOR BOLT
20 90304-SA5-013 Nut - WHEEL (CHROME PLATED) (FUSE RASHI) Nut - WHEEL (CHROME PLATED) (FUSE RASHI)
Tools/jack 3 / 6
ES8 Tools/jack
S04 Tools/jack
# OEM ES8 S04
4 89000-SR3-020 Tool set Tool set
7 89211-S05-003 Wrench - WHEEL Wrench - WHEEL
10 89320-S05-003 Bar - JACK Bar - JACK
Trunk lid 3 / 27
ES8 Trunk lid
S04 Trunk lid (LH)
# OEM ES8 S04
9 74815-SK8-000 Grommet - KEY CYLINDER(BLACK) Grommet - KEY CYLINDER(BLACK)
23 74867-SW5-003 Holder - ROD Holder - ROD
37 91555-SM4-003 Clip - COUPLER (RED) Clip - COUPLER (RED)
Valve/rocker arm (SOHC) 3 / 16
ES8 Valve/rocker arm (SOHC)
S04 Valve/rocker arm (1)
# OEM ES8 S04
8 14711-P2A-000 Valve - IN. Valve - IN.
9 14721-P2A-000 Valve - EX. Valve - EX.
11 14761-P2A-003 Spring - VALVE (SKY BLUE) (NIPPON HATSUJO) Spring - VALVE (SKY BLUE) (NIPPON HATSUJO)
Water pump/sensor 2 / 24
ES8 Water pump/sensor
S04 Water pump/sensor (1)
# OEM ES8 S04
16 37760-P00-003 Switch assy, THERMO (A-93) (NIPPON THERMOSTAT) Switch assy, THERMO (A-93) (NIPPON THERMOSTAT)
16 37760-P00-004 Switch assy - THERMO (A-93) (UCHIYA THERMOSTAT) Switch assy - THERMO (A-93) (UCHIYA THERMOSTAT)
Wire harness (LH) 2 / 19
ES8 Wire harness (LH)
S04 Instrument panel garnish (LH)
# OEM ES8 S04
15 35505-692-003 Bulb - 14V 1.4W Bulb - 14V 1.4W
16 90137-S84-A01 Bolt - TORX EARTH, 6X20 Bolt - TORX EARTH, 6X20
