Air cleaner 4 / 19

#	OEM	ES8	FD3
4	17212-PN3-000	Rubber, AIR CLEANER MOUNTING	Rubber, AIR CLEANER MOUNTING
4	17212-P2J-J00	Rubber, AIR CLEANER MOUNTING	Rubber, AIR CLEANER MOUNTING
6	17216-PN3-000	Collar - AIR CLEANER MOUNTING	Collar - AIR CLEANER MOUNTING
13	90001-P0A-000	Bolt-washer - SPECIAL, 6X35	Bolt-washer - SPECIAL, 6X35

Air conditioner (COMPRESSOR) 4 / 15

#	OEM	ES8	FD3
3	38829-PDF-E02	Nut - 9MM	Nut - 9MM
6	38912-PE1-702	Shim set	Shim set
7	38913-PP4-E02	Ring - SNAP	Ring - SNAP
8	38914-P07-004	Ring f - SNAP	Ring f - SNAP

Air conditioner (CONDENSER) 1 / 15

#	OEM	ES8	FD3
9	80175-SE0-000	Mount - CONDENSER	Mount - CONDENSER

Air conditioner (HOSES/PIPES; LH) 4 / 25

#	OEM	ES8	FD3
24	80871-ST7-000	O-ring - 5/8"	O-ring - 5/8"
25	80872-ST7-000	O-ring - 1/2"	O-ring - 1/2"
26	80873-ST7-000	O-ring - 8MM	O-ring - 8MM
28	90361-SV4-003	Nut - PAINT CUTTING, 6MM	Nut - PAINT CUTTING, 6MM

Antenna/speaker 5 / 12

#	OEM	ES8	FD3
8	90133-SZ4-003	Screw - ET, 7X16	Screw - ET, 7X16
10	91531-S04-003	Clip - WIRE HARNESS(NATURAL) (44MM)	Clip - WIRE HARNESS(NATURAL) (44MM)
11	91540-S0A-003	Clip - HARNESS BAND(NATURAL) (96.9MM)	Clip - HARNESS BAND(NATURAL) (96.9MM)
12	91540-S30-003	Clip - HARNESS BAND(NATURAL) (151.5MM)	Clip - HARNESS BAND(NATURAL) (151.5MM)
13	91559-ST5-003	Clip - HARNESS BAND OFFSET(30) (NATURAL)	Clip - HARNESS BAND OFFSET(30) (NATURAL)

Battery 2 / 11

#	OEM	ES8	FD3
9	32601-SK7-900	Bolt - BATTERY TERMINAL	Bolt - BATTERY TERMINAL
10	32602-SK7-900	Nut - BATTERY TERMINAL	Nut - BATTERY TERMINAL

Brake lines (LH) 6 / 26

#	OEM	ES8	FD3
13	46380-SH3-000	Grommet a - BRAKE PIPE	Grommet a - BRAKE PIPE
16	46391-S5A-J01	Clip - BRAKE PIPE	Clip - BRAKE PIPE
23	46462-SE0-000	Bolt - OIL	Bolt - OIL
24	46472-568-000	Packing - OIL BOLT	Packing - OIL BOLT
25	90361-SV4-003	Nut - PAINT CUTTING, 6MM	Nut - PAINT CUTTING, 6MM
26	90651-538-000	Clip - BRAKE HOSE	Clip - BRAKE HOSE

Brake master cylinder/ master power (LH) 7 / 20

#	OEM	ES8	FD3
7	46151-SB2-003	Yoke - PUSH ROD (NISSIN)	Yoke - PUSH ROD (NISSIN)
9	46191-S2K-000	Packing - MASTER POWER	Packing - MASTER POWER
15	46512-S70-000	Pin - PEDAL	Pin - PEDAL
18	46665-S04-J01	Grommet	Grommet
19	46666-S2K-003	Filter - BRAKE RESERVOIR	Filter - BRAKE RESERVOIR
21	46911-S70-003	Pin, LOCK(8MM)	Pin, LOCK(8MM)
22	53729-671-003	Clamp d - 15.5MM	Clamp d - 15.5MM

Breather cover 1 / 4

#	OEM	ES8	FD3
2	11855-P72-000	Grommet, PCV Valve	Grommet, PCV Valve

Bumpers 7 / 24

#	OEM	ES8	FD3
27	90301-SP0-003	Nut - PAINT CUTTING, 6MM	Nut - PAINT CUTTING, 6MM
29	90323-SE0-000	Nut - CLIP, 6MM	Nut - CLIP, 6MM
29	90305-SH3-000	Nut - AIR SPOILER CLIP	Nut - AIR SPOILER CLIP
30	90675-SA5-003	Nut - CLIP, 6MM	Nut - CLIP, 6MM
31	90682-SB0-003	Grommet - SCREW, 5MM	Grommet - SCREW, 5MM
33	91503-SZ3-003	Clip A	Clip A
34	91503-SZ5-003	Clip - BUMPER FACE	Clip - BUMPER FACE

Clutch master cylinder (LH) 3 / 36

#	OEM	ES8	FD3
3	43353-SD5-003	Cap - BLEEDER SCREW	Cap - BLEEDER SCREW
6	46911-S70-003	Pin, LOCK(8MM)	Pin, LOCK(8MM)
35	90651-538-000	Clip - BRAKE HOSE	Clip - BRAKE HOSE

Combination switch (LH) 4 / 19

#	OEM	ES8	FD3
4	35102-SV4-003	Bolt - BREAK HEAD	Bolt - BREAK HEAD
5	35103-S04-003	Screw - RECESSED	Screw - RECESSED
6	35108-S30-003	Holder - COLUMN	Holder - COLUMN
15	35400-S5A-013	Switch assy - DOOR (MATSUSHITA)	Switch assy - DOOR (MATSUSHITA)

Console (2) 3 / 11

#	OEM	ES8	FD3
1	77205-S0X-A01	Clip - SNAP FITTING	Clip - SNAP FITTING
20	90666-S84-A01	Clip - SNAP FITTING	Clip - SNAP FITTING
22	91640-SM4-003	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM

Control unit (CABIN; LH) 2 / 12

#	OEM	ES8	FD3
9	39794-S10-003	Relay assy - POWER(5P) (MICRO ISO)(MITSUBA)	Relay assy - POWER(5P) (MICRO ISO)(MITSUBA)
18	90137-SF1-000	Bolt-washer - 6X25	Bolt-washer - 6X25

Control unit (ENGINE ROOM) 1 / 21

#	OEM	ES8	FD3
24	90150-S84-003	Bolt - EARTH, 8X16	Bolt - EARTH, 8X16

Cylinder block/oil pan 4 / 21

#	OEM	ES8	FD3
13	90001-PM3-003	Bolt - DRAIN PLUG, 28MM	Bolt - DRAIN PLUG, 28MM
14	90008-PM0-003	Bolt-washer - 10X112	Bolt-washer - 10X112
19	90401-PR4-000	Washer - SEALING, 28MM	Washer - SEALING, 28MM
20	90702-PE0-000	Dowel pin - 12X18	Dowel pin - 12X18

Cylinder head (SOHC) 6 / 20

#	OEM	ES8	FD3
2	12204-PJ7-305	Guide - IN. VALVE (OS)	Guide - IN. VALVE (OS)
3	12210-PZ1-003	Seal a - VALVE STEM(ARAI)	Seal a - VALVE STEM(ARAI)
3	12210-PZ1-004	SEAL A, VALVE STEM (NOK)	SEAL A, VALVE STEM (NOK)
4	12211-PZ1-004	Seal b - VALVE STEM(NOK)	Seal b - VALVE STEM(NOK)
4	12211-PZ1-003	Seal b - VALVE STEM(ARAI)	Seal b - VALVE STEM(ARAI)
6	12513-P72-003	Plug - CYLINDER HEAD	Plug - CYLINDER HEAD

Cylinder head cover 7 / 16

#	OEM	ES8	FD3
3	12315-PLC-000	Bolt - STUD	Bolt - STUD
4	12316-PLC-000	Washer	Washer
6	12342-P08-004	Seal	Seal
6	12342-RYE-004	Seal,spark plug t	Seal,spark plug t
7	15610-P5G-000	Cap assy. - OIL FILLER	Cap assy. - OIL FILLER
7	15610-RGA-000	Cap assy. - OIL FILLER	Cap assy. - OIL FILLER
8	15613-PC6-000	Packing, Oil Filler	Packing, Oil Filler

Emblems/caution labels 1 / 8

#	OEM	ES8	FD3
20	91512-SR3-004	Clip - TUBULAR	Clip - TUBULAR

Engine wire harness (LH) 4 / 28

#	OEM	ES8	FD3
22	90114-SM4-900	Bolt - 6X15	Bolt - 6X15
26	91506-P01-003	Clip A - HARNESS BAND (DARK GRAY) (129.4MM)	Clip A - HARNESS BAND (DARK GRAY) (129.4MM)
27	91507-PLC-003	Clip - WIRE HARNESS(DARK BLUE) (132.3MM)	Clip - WIRE HARNESS(DARK BLUE) (132.3MM)
29	91558-ST5-003	Clip - HARNESS BAND(NATURAL) (135MM)(7MM HOLE)	Clip - HARNESS BAND(NATURAL) (135MM)(7MM HOLE)

Exhaust manifold (2) 1 / 10

#	OEM	ES8	FD3
9	90004-PLC-000	Bolt-washer - 10X25	Bolt-washer - 10X25

Exhaust pipe/silencer 4 / 14

#	OEM	ES8	FD3
14	18229-SNA-A01	Gasket, EX. FLEXIBLE	Gasket, EX. FLEXIBLE
16	18229-S5A-J11	Gasket - EX. FLEXIBLE	Gasket - EX. FLEXIBLE
17	18230-SV4-000	Spring - FLEXIBLE JOINT	Spring - FLEXIBLE JOINT
31	90301-SV7-000	Nut - PAINT CUTTING, 6MM	Nut - PAINT CUTTING, 6MM

Floor mat 3 / 8

#	OEM	ES8	FD3
13	91517-SE0-003	Clip - LOWER OUTER DASHBOARD INSULATOR	Clip - LOWER OUTER DASHBOARD INSULATOR
14	91560-S04-003	Clip - SIDE GARNISH (NATURAL)	Clip - SIDE GARNISH (NATURAL)
15	91560-S5H-003	Clip - SIDE GARNISH (NATURAL) (SEAL:BLACK)	Clip - SIDE GARNISH (NATURAL) (SEAL:BLACK)

Front brake (1) 10 / 21

#	OEM	ES8	FD3
3	06455-S5A-J00	Shim set - FR.	Shim set - FR.
4	43352-SM4-951	Screw - BLEEDER	Screw - BLEEDER
5	43353-SD5-003	Cap - BLEEDER SCREW	Cap - BLEEDER SCREW
11	45216-S5A-J01	Piston	Piston
13	45235-S0A-003	Pin a	Pin a
14	45237-SR3-003	Retainer a	Retainer a
15	45240-SC2-003	Bolt - FLANGE, 8X22	Bolt - FLANGE, 8X22
18	45262-S0A-003	Pin b	Pin b
19	90107-SM4-000	Bolt - CALIPER MOUNTING (12X21)	Bolt - CALIPER MOUNTING (12X21)
20	90113-S5H-005	Bolt - WHEEL (THAI MEIRA)	Bolt - WHEEL (THAI MEIRA)

Front bulkhead 2 / 3

#	OEM	ES8	FD3
46	90101-S6A-000	Bolt-washer - 8MM	Bolt-washer - 8MM
47	90105-634-000	Bolt-washer (8x20)	Bolt-washer (8x20)

Front door lining (LH) 3 / 5

#	OEM	ES8	FD3
17	90132-SS0-000	Screw - TAPPING, 4X10 (PO)	Screw - TAPPING, 4X10 (PO)
18	90662-SB2-003	Grommet - SCREW, 5MM	Grommet - SCREW, 5MM
19	91560-S84-A01	CLIP, DOOR LINING (NATURAL)	CLIP, DOOR LINING (NATURAL)

Front door locks 6 / 38

#	OEM	ES8	FD3
21	72141-SD4-004	Bush - R. JOINT	Bush - R. JOINT
38	72181-SD4-004	Bush - L. JOINT	Bush - L. JOINT
44	90120-SV4-000	Bolt - LOCK STRIKER	Bolt - LOCK STRIKER
47	91501-S04-003	Clip - INNER FENDER	Clip - INNER FENDER
48	91531-S04-003	Clip - WIRE HARNESS(NATURAL) (44MM)	Clip - WIRE HARNESS(NATURAL) (44MM)
49	91540-S30-003	Clip - HARNESS BAND(NATURAL) (151.5MM)	Clip - HARNESS BAND(NATURAL) (151.5MM)

Front door panels 3 / 17

#	OEM	ES8	FD3
21	90101-SZ3-000	Bolt - FLANGE, 8X22 (8.5MM)	Bolt - FLANGE, 8X22 (8.5MM)
23	90141-S04-000	Bolt - FLANGE, 8X22	Bolt - FLANGE, 8X22
24	90651-S4N-003	Clip	Clip

Front door windows 2 / 12

#	OEM	ES8	FD3
15	91533-S04-003	Clip - COUPLER (NATURAL)	Clip - COUPLER (NATURAL)
16	91540-S30-003	Clip - HARNESS BAND(NATURAL) (151.5MM)	Clip - HARNESS BAND(NATURAL) (151.5MM)

Front driveshaft/ half shaft 4 / 18

#	OEM	ES8	FD3
11	44319-SR1-003	Set ring - 26X1.8 (GKN)	Set ring - 26X1.8 (GKN)
12	44327-SV4-305	Band - JOINT BOOT (DOUBLE ROLLED BAND)	Band - JOINT BOOT (DOUBLE ROLLED BAND)
13	44329-SV4-305	Band - SHAFT BOOT (DOUBLE ROLLED BAND)	Band - SHAFT BOOT (DOUBLE ROLLED BAND)
23	90305-692-010	Nut	Nut

Front fenders 5 / 15

#	OEM	ES8	FD3
8	90108-S0A-003	Bolt - FLANGE, 6X15	Bolt - FLANGE, 6X15
12	90682-SB0-003	Grommet - SCREW, 5MM	Grommet - SCREW, 5MM
14	91501-S04-003	Clip - INNER FENDER	Clip - INNER FENDER
15	91503-SZ3-003	Clip A	Clip A
18	91545-SE0-003	Clip assy. - 8MM	Clip assy. - 8MM

Front grille (1) 2 / 7

#	OEM	ES8	FD3
7	90301-ST0-003	push nut, 3mm	push nut, 3mm
8	91503-SZ3-003	Clip A	Clip A

Front seat (LH; DRIVER SIDE) 2 / 9

#	OEM	ES8	FD3
1	04810-SB3-000	C clip set - TRIM FASTENER (30 PIECES)	C clip set - TRIM FASTENER (30 PIECES)
26	90134-SE3-003	Screw - TAPPING, 5X10	Screw - TAPPING, 5X10

Front seat (LH; PASSENGER SIDE) 2 / 8

#	OEM	ES8	FD3
1	04810-SB3-000	C clip set - TRIM FASTENER (30 PIECES)	C clip set - TRIM FASTENER (30 PIECES)
21	90610-S10-003	Clip - GARNISH	Clip - GARNISH

Front seat components (L.; MANUAL HEIGHT) 1 / 11

#	OEM	ES8	FD3
8	90135-S5A-003	Bolt-washer - 10X27	Bolt-washer - 10X27

Front seat components (R.) 1 / 6

#	OEM	ES8	FD3
7	90135-S5A-003	Bolt-washer - 10X27	Bolt-washer - 10X27

Front shock absorber 1 / 16

#	OEM	ES8	FD3
12	90002-S10-000	Nut - FLANGE, 10MM	Nut - FLANGE, 10MM

Front sub frame 1 / 5

#	OEM	ES8	FD3
7	90175-S5A-000	Bolt - FLANGE, 14X115	Bolt - FLANGE, 14X115

Front windshield wiper (L H) 3 / 21

#	OEM	ES8	FD3
4	76517-SE0-003	Collar - BRACKETLESS	Collar - BRACKETLESS
5	76517-SM4-003	Collar	Collar
20	90126-SR3-000	Bolt-washer - 6X32	Bolt-washer - 6X32

Fuel pipe (2) 4 / 37

#	OEM	ES8	FD3
23	17711-S84-004	Retainer - WHITE)(SANOH	Retainer - WHITE)(SANOH
40	90361-SV4-003	Nut - PAINT CUTTING, 6MM	Nut - PAINT CUTTING, 6MM
43	91402-SDC-000	Clip - TUBE(B12)	Clip - TUBE(B12)
44	91405-SDA-000	Clamp - TUBE(D10.5)	Clamp - TUBE(D10.5)

Fuel tank (2) 6 / 43

#	OEM	ES8	FD3
18	17525-SM4-000	Bolt-washer - 10X35	Bolt-washer - 10X35
19	17525-S0X-A00	Bolt-washer - 10X25	Bolt-washer - 10X25
32	17711-S84-004	Retainer - WHITE)(SANOH	Retainer - WHITE)(SANOH
39	90150-S04-003	Bolt - EARTH, 6X16	Bolt - EARTH, 6X16
44	91413-S5A-003	Clamp - FUEL TUBE (D17)	Clamp - FUEL TUBE (D17)
45	91601-SH3-013	Grommet - SCREW, 5MM (BLACK)	Grommet - SCREW, 5MM (BLACK)

Grommet (FRONT) 7 / 12

#	OEM	ES8	FD3
2	74144-SR3-000	Cushion - HOOD	Cushion - HOOD
6	82871-671-000	Grommet - DRAIN HOLE, 25MM	Grommet - DRAIN HOLE, 25MM
7	90615-SR3-000	Cap - WELD HOLE, 51X77	Cap - WELD HOLE, 51X77
10	91604-SD2-013	Grommet - HOOD STAY	Grommet - HOOD STAY
11	91608-S5A-003	Boot - FLOOR	Boot - FLOOR
12	91615-SH3-000	Cap - FLOOR HOLE, 49MM	Cap - FLOOR HOLE, 49MM
13	91619-SE0-000	Seal - DOOR HOLE, 30MM(BLACK)	Seal - DOOR HOLE, 30MM(BLACK)

Grommet (LOWER) 1 / 1

#	OEM	ES8	FD3
2	91606-SK7-003	Plug - BLIND, 25MM	Plug - BLIND, 25MM

Grommet (REAR) 1 / 4

#	OEM	ES8	FD3
1	91603-SK7-000	Grommet - WAX HOLE, 25MM	Grommet - WAX HOLE, 25MM

Grommet (SIDE) 1 / 6

#	OEM	ES8	FD3
5	91619-SE0-000	Seal - DOOR HOLE, 30MM(BLACK)	Seal - DOOR HOLE, 30MM(BLACK)

Harness band/bracket (LH) 15 / 26

#	OEM	ES8	FD3
3	32132-S6A-003	Band - WIRE HARNESS OFFSET(20) (DARK GREEN)(122.5MM)	Band - WIRE HARNESS OFFSET(20) (DARK GREEN)(122.5MM)
15	91507-SL9-003	Clip - WIRE HARNESS (GREEN) (110MM) (7MM HOLE)	Clip - WIRE HARNESS (GREEN) (110MM) (7MM HOLE)
17	91510-SA5-003	Clip - OFFSET(10)(BROWN)(50MM)	Clip - OFFSET(10)(BROWN)(50MM)
18	91531-S04-003	Clip - WIRE HARNESS(NATURAL) (44MM)	Clip - WIRE HARNESS(NATURAL) (44MM)
20	91533-S04-003	Clip - COUPLER (NATURAL)	Clip - COUPLER (NATURAL)
22	91540-SV4-003	Clip - HARNESS BAND (NATURAL) (145.2MM)	Clip - HARNESS BAND (NATURAL) (145.2MM)
23	91540-S0A-003	Clip - HARNESS BAND(NATURAL) (96.9MM)	Clip - HARNESS BAND(NATURAL) (96.9MM)
25	91541-S0A-003	Clip - HARNESS BAND(BLACK) (145MM)	Clip - HARNESS BAND(BLACK) (145MM)
26	91545-SV4-003	Clip - HARNESS BAND (NATURAL) (145.2MM) (WITH SEAL)	Clip - HARNESS BAND (NATURAL) (145.2MM) (WITH SEAL)
27	91545-S2A-003	Clip - HARNESS BAND (BROWN) (151MM) (WITH SEAL)	Clip - HARNESS BAND (BROWN) (151MM) (WITH SEAL)
28	91547-SH3-003	Clip - BAND(NATURAL)(160MM)	Clip - BAND(NATURAL)(160MM)
31	91552-SS0-003	Clip - WIRE HARNESS (M5) (BROWN) (93.5MM)	Clip - WIRE HARNESS (M5) (BROWN) (93.5MM)
33	91556-SM4-003	Clip - BAND (BLACK) (100MM)	Clip - BAND (BLACK) (100MM)
36	91559-S5A-003	Holder - HARNESS (BLACK)	Holder - HARNESS (BLACK)
40	91619-SE0-000	Seal - DOOR HOLE, 30MM(BLACK)	Seal - DOOR HOLE, 30MM(BLACK)

Headlight 8 / 15

#	OEM	ES8	FD3
4	33105-S5N-C01	Nut - SPECIAL	Nut - SPECIAL
5	33115-S84-A01	Bulb - HEADLIGHT (HB3) (12V 60W) (SYLVANIA)	Bulb - HEADLIGHT (HB3) (12V 60W) (SYLVANIA)
6	33116-S84-A01	Bulb - HEADLIGHT (HB4) (12V 51W) (SYLVANIA)	Bulb - HEADLIGHT (HB4) (12V 51W) (SYLVANIA)
11	33301-SA0-741	Bulb (12V 5W) - (12V 5W) (STANLEY)	Bulb (12V 5W) - (12V 5W) (STANLEY)
13	33303-SAA-003	Socket comp - T20 S) (AMBER	Socket comp - T20 S) (AMBER
14	33303-S2R-003	Bulb - WEDGE (12V 21W) (STANLEY) (AMBER)	Bulb - WEDGE (12V 21W) (STANLEY) (AMBER)
15	33304-S5A-003	Socket comp - T10	Socket comp - T10
18	91512-SX0-003	Clip - INNER FENDER CLIP	Clip - INNER FENDER CLIP

Heater blower (LH) 3 / 19

#	OEM	ES8	FD3
19	90127-SX0-003	Screw - TAPPING, 4X16	Screw - TAPPING, 4X16
20	90132-SR3-003	Screw - TAPPING, 5X16	Screw - TAPPING, 5X16
22	90321-SV4-003	Nut-washer - 6MM (PAINT CUTTING)	Nut-washer - 6MM (PAINT CUTTING)

Heater control (LH) 1 / 3

#	OEM	ES8	FD3
12	79609-S5A-003	Bulb - NEO WEDGE (14V 100MA)	Bulb - NEO WEDGE (14V 100MA)

Heater unit (LH) 4 / 29

#	OEM	ES8	FD3
1	39248-692-003	Packing - HEATER	Packing - HEATER
33	90126-S5A-003	Bolt - SOCKET, 5X40	Bolt - SOCKET, 5X40
34	90127-SX0-003	Screw - TAPPING, 4X16	Screw - TAPPING, 4X16
38	91540-S0A-003	Clip - HARNESS BAND(NATURAL) (96.9MM)	Clip - HARNESS BAND(NATURAL) (96.9MM)

Hood (LH) 4 / 27

#	OEM	ES8	FD3
23	90108-S0A-003	Bolt - FLANGE, 6X15	Bolt - FLANGE, 6X15
27	90602-S5A-003	Clip - COWL TOP	Clip - COWL TOP
30	91501-SL4-003	Clip - FR. COWL	Clip - FR. COWL
33	91518-SM4-003	Clip - TRUNK MOLDING	Clip - TRUNK MOLDING

Ignition coil/plug 1 / 4

#	OEM	ES8	FD3
3	90207-PG6-010	Nut - CAP, 6MM (BLACK)	Nut - CAP, 6MM (BLACK)

Inner panels/floor panel 1 / 1

#	OEM	ES8	FD3
36	90108-S0A-003	Bolt - FLANGE, 6X15	Bolt - FLANGE, 6X15

Instrument panel (LH) 5 / 13

#	OEM	ES8	FD3
3	66844-SA7-000	Cap - INSTRUMENT PANEL STAY	Cap - INSTRUMENT PANEL STAY
16	90101-S6A-000	Bolt-washer - 8MM	Bolt-washer - 8MM
19	90140-SH3-003	Bolt-washer - 5X18	Bolt-washer - 5X18
21	90321-SP0-A80	Nut-washer - 6MM	Nut-washer - 6MM
22	90666-S84-A01	Clip - SNAP FITTING	Clip - SNAP FITTING

Instrument panel garnish (DRIVER SIDE; LH) 3 / 10

#	OEM	ES8	FD3
18	90101-S2K-000	Screw - TAPPING, 4X16(IT)	Screw - TAPPING, 4X16(IT)
19	90302-SA4-003	Nut - SPRING, 4MM	Nut - SPRING, 4MM
20	90666-S84-A01	Clip - SNAP FITTING	Clip - SNAP FITTING

Instrument panel garnish (PASSENGER SIDE; LH) 8 / 25

#	OEM	ES8	FD3
4	39610-S2H-G01	Knob assy	Knob assy
5	39620-S0X-003	Socket assy	Socket assy
9	66418-SB2-000	Stopper - GLOVE BOX LID	Stopper - GLOVE BOX LID
10	66844-SA7-000	Cap - INSTRUMENT PANEL STAY	Cap - INSTRUMENT PANEL STAY
35	90140-SH3-003	Bolt-washer - 5X18	Bolt-washer - 5X18
36	90302-SA4-003	Nut - SPRING, 4MM	Nut - SPRING, 4MM
37	90666-S84-A01	Clip - SNAP FITTING	Clip - SNAP FITTING
38	91640-SM4-003	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM

Intake manifold 3 / 21

#	OEM	ES8	FD3
3	16451-PLC-000	Clip - INJECTOR	Clip - INJECTOR
17	37835-PGK-A01	O-ring	O-ring
21	91301-PLC-000	O-ring - 7.47X3.6	O-ring - 7.47X3.6

Interior light 6 / 8

#	OEM	ES8	FD3
3	34251-S5A-003	Lens	Lens
7	34253-671-003	Bulb - 12V 8W)(DAIICHI	Bulb - 12V 8W)(DAIICHI
7	04110-SWA-305	BULB T10X318W	BULB T10X318W
8	34261-S5A-003	Lens comp	Lens comp
9	34295-SJ8-003	Bulb - 12V 5W) (DAIICHI	Bulb - 12V 5W) (DAIICHI
9	34351-657-921	Bulb - 12V/5W) (STANLEY	Bulb - 12V/5W) (STANLEY

Knuckle 2 / 17

#	OEM	ES8	FD3
16	90002-S10-000	Nut - FLANGE, 10MM	Nut - FLANGE, 10MM
18	90306-SB2-013	Nut - SELF-LOCK, 10MM (CLINCH)	Nut - SELF-LOCK, 10MM (CLINCH)

Meter components (NS; 1) 2 / 7

#	OEM	ES8	FD3
2	37115-SA0-601	Packing - NS	Packing - NS
7	90302-SA4-003	Nut - SPRING, 4MM	Nut - SPRING, 4MM

Oil pump/oil strainer 5 / 23

#	OEM	ES8	FD3
3	15221-PZ1-000	Packing - OIL STRAINER	Packing - OIL STRAINER
7	15302-PE0-300	Washer - SEALING, 14MM	Washer - SEALING, 14MM
8	15400-PLM-A02	OIL FILTER (HONEYWELL)	OIL FILTER (HONEYWELL)
8	15400-RTA-003	OIL FILTER (MAHLE TENNEX)	OIL FILTER (MAHLE TENNEX)
11	90015-PH1-013	Holder - OIL FILTER	Holder - OIL FILTER

Outer panels 1 / 4

#	OEM	ES8	FD3
20	90147-634-003	Bolt - FENDER, 6X18	Bolt - FENDER, 6X18

P.s. lines (LH) 1 / 21

#	OEM	ES8	FD3
6	53729-671-003	Clamp d - 15.5MM	Clamp d - 15.5MM

Pedal (LH) 3 / 25

#	OEM	ES8	FD3
11	46505-SA5-000	Pad - PEDAL STOPPER	Pad - PEDAL STOPPER
25	90207-PG6-010	Nut - CAP, 6MM (BLACK)	Nut - CAP, 6MM (BLACK)
26	90301-SP0-003	Nut - PAINT CUTTING, 6MM	Nut - PAINT CUTTING, 6MM

Pillar garnish 2 / 4

#	OEM	ES8	FD3
19	91560-S84-A01	CLIP, DOOR LINING (NATURAL)	CLIP, DOOR LINING (NATURAL)
20	91560-S84-A11	Clip - PILLAR GARNISH(BLACK)	Clip - PILLAR GARNISH(BLACK)

Radiator (DENSO) 5 / 14

#	OEM	ES8	FD3
2	19011-PH1-621	Bolt - DRAIN (DENSO)	Bolt - DRAIN (DENSO)
3	19012-671-300	Packing - DRAIN (DENSO)	Packing - DRAIN (DENSO)
11	19047-PLC-003	Cover - RADIATOR CAP (DENSO)	Cover - RADIATOR CAP (DENSO)
13	90042-PAA-A01	Bolt-washer - 6X16 (DENSO)	Bolt-washer - 6X16 (DENSO)
14	90043-PD2-003	Nut - HEX., 5MM (DENSO)	Nut - HEX., 5MM (DENSO)

Radiator hose/reserve tan k 3 / 13

#	OEM	ES8	FD3
10	19511-PA6-003	Clip - WATER HOSE(CHUO SPRING)	Clip - WATER HOSE(CHUO SPRING)
17	74172-S5A-000	Cushion - RADIATOR MOUNTING LOWER	Cushion - RADIATOR MOUNTING LOWER
18	74173-SJ4-000	Cushion - RADIATOR MOUNTING UPPER	Cushion - RADIATOR MOUNTING UPPER

Rear brake (DRUM) 4 / 39

#	OEM	ES8	FD3
18	43353-SD5-003	Cap - BLEEDER SCREW	Cap - BLEEDER SCREW
36	90113-SA0-025	Bolt - WHEEL (NAGOYA RASHI)	Bolt - WHEEL (NAGOYA RASHI)
36	90113-SM1-005	Bolt - WHEEL (ROCKNEL FASTENER)	Bolt - WHEEL (ROCKNEL FASTENER)
36	90113-SA0-006	Bolt - WHEEL (SAGA)	Bolt - WHEEL (SAGA)

Rear door lining 3 / 4

#	OEM	ES8	FD3
14	90132-SS0-000	Screw - TAPPING, 4X10 (PO)	Screw - TAPPING, 4X10 (PO)
15	90662-SB2-003	Grommet - SCREW, 5MM	Grommet - SCREW, 5MM
16	91560-S84-A01	CLIP, DOOR LINING (NATURAL)	CLIP, DOOR LINING (NATURAL)

Rear door locks 2 / 27

#	OEM	ES8	FD3
35	90120-SV4-000	Bolt - LOCK STRIKER	Bolt - LOCK STRIKER
36	90662-SB2-003	Grommet - SCREW, 5MM	Grommet - SCREW, 5MM

Rear door panels 5 / 18

#	OEM	ES8	FD3
19	75891-SA7-000	Stopper - DOOR	Stopper - DOOR
20	90101-SZ3-000	Bolt - FLANGE, 8X22 (8.5MM)	Bolt - FLANGE, 8X22 (8.5MM)
21	90141-S04-000	Bolt - FLANGE, 8X22	Bolt - FLANGE, 8X22
22	90361-SR3-000	Nut - FLANGE, 8MM	Nut - FLANGE, 8MM
23	90651-S4N-003	Clip	Clip

Rear door windows 1 / 14

#	OEM	ES8	FD3
15	91533-S04-003	Clip - COUPLER (NATURAL)	Clip - COUPLER (NATURAL)

Rear lower arm 2 / 26

#	OEM	ES8	FD3
22	90002-S10-000	Nut - FLANGE, 10MM	Nut - FLANGE, 10MM
23	90306-SB2-013	Nut - SELF-LOCK, 10MM (CLINCH)	Nut - SELF-LOCK, 10MM (CLINCH)

Rear seat (1) 1 / 7

#	OEM	ES8	FD3
1	04810-SB3-000	C clip set - TRIM FASTENER (30 PIECES)	C clip set - TRIM FASTENER (30 PIECES)

Rear tray/trunk lining 4 / 9

#	OEM	ES8	FD3
1	33303-SL4-003	Bulb - WEDGE (12V 21W) (STANLEY)	Bulb - WEDGE (12V 21W) (STANLEY)
2	33513-S50-003	Socket - T20W S2	Socket - T20W S2
3	34271-S5A-A01	Lamp unit	Lamp unit
20	91560-S84-A01	CLIP, DOOR LINING (NATURAL)	CLIP, DOOR LINING (NATURAL)

Resonator chamber 4 / 18

#	OEM	ES8	FD3
2	17212-P2J-J00	Rubber, AIR CLEANER MOUNTING	Rubber, AIR CLEANER MOUNTING
3	17213-P8A-A00	Rubber - INTAKE MANIFOLD COVER MOUNTING	Rubber - INTAKE MANIFOLD COVER MOUNTING
4	17216-PN3-000	Collar - AIR CLEANER MOUNTING	Collar - AIR CLEANER MOUNTING
18	90001-P0A-000	Bolt-washer - SPECIAL, 6X35	Bolt-washer - SPECIAL, 6X35

Roof lining 1 / 6

#	OEM	ES8	FD3
18	91560-S84-A01	CLIP, DOOR LINING (NATURAL)	CLIP, DOOR LINING (NATURAL)

Seatbelts 3 / 5

#	OEM	ES8	FD3
17	90101-S84-A00	Screw - ET, 6X16	Screw - ET, 6X16
17	90133-SZ4-003	Screw - ET, 7X16	Screw - ET, 7X16
18	90135-S1F-003	Bolt - FLANGE, 7/16"	Bolt - FLANGE, 7/16"

Shift arm/shift lever 1 / 16

#	OEM	ES8	FD3
1	21396-P20-000	Cap - BREATHER	Cap - BREATHER

Shift lever 1 / 12

#	OEM	ES8	FD3
9	90361-SV4-003	Nut - PAINT CUTTING, 6MM	Nut - PAINT CUTTING, 6MM

Srs unit (LH) 1 / 5

#	OEM	ES8	FD3
6	90137-S84-A01	Bolt - TORX EARTH, 6X20	Bolt - TORX EARTH, 6X20

Steering column 2 / 5

#	OEM	ES8	FD3
4	90361-SR3-000	Nut - FLANGE, 8MM	Nut - FLANGE, 8MM
5	90511-671-003	Washer - TOOTHED LOCK	Washer - TOOTHED LOCK

Steering wheel 1 / 11

#	OEM	ES8	FD3
12	90161-SV4-003	Bolt - STEERING HANDLE	Bolt - STEERING HANDLE

Steering wheel (SRS) 1 / 9

#	OEM	ES8	FD3
14	90161-SV4-003	Bolt - STEERING HANDLE	Bolt - STEERING HANDLE

Switch (LH) 1 / 2

#	OEM	ES8	FD3
11	90666-SD4-003	Clip - FITTING	Clip - FITTING

Taillight/license light 7 / 23

#	OEM	ES8	FD3
1	33301-SA0-741	Bulb (12V 5W) - (12V 5W) (STANLEY)	Bulb (12V 5W) - (12V 5W) (STANLEY)
2	33303-SL4-003	Bulb - WEDGE (12V 21W) (STANLEY)	Bulb - WEDGE (12V 21W) (STANLEY)
3	33303-S2R-003	Bulb - WEDGE (12V 21W) (STANLEY) (AMBER)	Bulb - WEDGE (12V 21W) (STANLEY) (AMBER)
8	33514-S2R-003	Socket - T20W SY	Socket - T20W SY
11	33515-S50-003	Socket - T20W W	Socket - T20W W
21	34906-ST5-003	Bulb - 12V 21W/5W) (STANLEY	Bulb - 12V 21W/5W) (STANLEY
26	90321-S06-000	Nut - HEX. CAP, 5MM	Nut - HEX. CAP, 5MM

Throttle body 1 / 10

#	OEM	ES8	FD3
7	36166-PAA-A01	Joint - PURGE	Joint - PURGE

Tire/wheel disks 17 / 26

#	OEM	ES8	FD3
9	42753-SB8-661	Valve - RIM (SCHRADER)	Valve - RIM (SCHRADER)
9	42753-671-003	Valve - RIM (TAIHEIYO)	Valve - RIM (TAIHEIYO)
10	44729-SEA-J01	Weight - BALANCE (35G) (TOHO)	Weight - BALANCE (35G) (TOHO)
10	44721-SEA-J01	Weight - BALANCE (10G) (TOHO)	Weight - BALANCE (10G) (TOHO)
10	44726-SEA-J01	Weight - BALANCE (5G) (TOHO)	Weight - BALANCE (5G) (TOHO)
10	44723-SEA-J01	Weight - BALANCE (30G) (TOHO)	Weight - BALANCE (30G) (TOHO)
10	44722-SEA-J02	Weight - BALANCE (20G) (YAMATE)	Weight - BALANCE (20G) (YAMATE)
10	44728-SEA-J01	Weight - BALANCE (25G) (TOHO)	Weight - BALANCE (25G) (TOHO)
10	44727-SEA-J02	Weight - BALANCE (15G) (YAMATE)	Weight - BALANCE (15G) (YAMATE)
10	44729-SEA-J02	Weight - BALANCE (35G) (YAMATE)	Weight - BALANCE (35G) (YAMATE)
10	44722-SEA-J01	Weight - BALANCE (20G) (TOHO)	Weight - BALANCE (20G) (TOHO)
10	44721-SEA-J02	Weight - BALANCE (10G) (YAMATE)	Weight - BALANCE (10G) (YAMATE)
10	44727-SEA-J01	Weight - BALANCE (15G) (TOHO)	Weight - BALANCE (15G) (TOHO)
10	44726-SEA-J02	Weight - BALANCE (5G) (YAMATE)	Weight - BALANCE (5G) (YAMATE)
10	44723-SEA-J02	Weight - BALANCE (30G) (YAMATE)	Weight - BALANCE (30G) (YAMATE)
10	44728-SEA-J02	Weight - BALANCE (25G) (YAMATE)	Weight - BALANCE (25G) (YAMATE)
20	90304-SA5-013	Nut - WHEEL (CHROME PLATED) (FUSE RASHI)	Nut - WHEEL (CHROME PLATED) (FUSE RASHI)

Tools/jack 1 / 6

#	OEM	ES8	FD3
7	89211-S05-003	Wrench - WHEEL	Wrench - WHEEL

Transmission case 2 / 53

#	OEM	ES8	FD3
11	90380-S04-000	Bolt - STUD, 12X73	Bolt - STUD, 12X73
13	91206-PHR-003	Oil seal - 35X58X8 (NOK)	Oil seal - 35X58X8 (NOK)

Trunk lid 4 / 27

#	OEM	ES8	FD3
10	74822-SW5-003	Cushion - TRUNK HINGE	Cushion - TRUNK HINGE
31	90108-S0A-003	Bolt - FLANGE, 6X15	Bolt - FLANGE, 6X15
34	90684-SD4-003	Clip - FUEL LID OPENER	Clip - FUEL LID OPENER
37	91555-SM4-003	Clip - COUPLER (RED)	Clip - COUPLER (RED)

Valve/rocker arm (SOHC) 1 / 16

#	OEM	ES8	FD3
13	14775-P08-000	Seat - VALVE SPRING	Seat - VALVE SPRING

Water pump/sensor 4 / 24

#	OEM	ES8	FD3
6	19305-PLC-A00	Rubber - THERMOSTAT MOUNTING	Rubber - THERMOSTAT MOUNTING
17	37870-PLC-004	Sensor assy, WATER TEMP (MATSUSHITA)	Sensor assy, WATER TEMP (MATSUSHITA)
19	91307-PLC-004	O-ring - 9.5X1.9 (MATSUSHITA)	O-ring - 9.5X1.9 (MATSUSHITA)
21	91314-634-000	O-ring	O-ring

Windshield washer (1) 4 / 19

#	OEM	ES8	FD3
1	38516-SA5-671	Packing - T-TYPE) (MITSUBA	Packing - T-TYPE) (MITSUBA
2	38519-SB0-003	Bush - WASHER TANK (MITSUBA)	Bush - WASHER TANK (MITSUBA)
5	76806-SL0-E11	Motor - WASHER (HIGH) (MITSUBA)	Motor - WASHER (HIGH) (MITSUBA)
18	91512-SX0-003	Clip - INNER FENDER CLIP	Clip - INNER FENDER CLIP

Wire harness (LH) 3 / 19

#	OEM	ES8	FD3
16	90137-S84-A01	Bolt - TORX EARTH, 6X20	Bolt - TORX EARTH, 6X20
17	90148-SE0-003	Bolt - EARTH, 6X16 (WASHER 12.5MM) (ZN)	Bolt - EARTH, 6X16 (WASHER 12.5MM) (ZN)
18	90149-SE0-003	Bolt - EARTH, 6X16	Bolt - EARTH, 6X16
