Air cleaner 4 / 19

#	OEM	ES7	FK2
4	17212-PN3-000	Rubber, AIR CLEANER MOUNTING	Rubber, AIR CLEANER MOUNTING
4	17212-P2J-J00	Rubber, AIR CLEANER MOUNTING	Rubber, AIR CLEANER MOUNTING
6	17216-PN3-000	Collar - AIR CLEANER MOUNTING	Collar - AIR CLEANER MOUNTING
13	90001-P0A-000	Bolt-washer - SPECIAL, 6X35	Bolt-washer - SPECIAL, 6X35

Air conditioner (COMPRESSOR) 5 / 14

#	OEM	ES7	FK2
1	38801-PDF-E02	Valve sub assy. - SAFETY	Valve sub assy. - SAFETY
3	38829-PDF-E02	Nut - 9MM	Nut - 9MM
6	38912-PE1-702	Shim set	Shim set
7	38913-PP4-E02	Ring - SNAP	Ring - SNAP
8	38914-P07-004	Ring f - SNAP	Ring f - SNAP

Air conditioner (HOSES/PIPES; LH) 5 / 29

#	OEM	ES7	FK2
2	80050-SP0-000	Label - AIR CONDITIONER CAUTION (HFC134A)	Label - AIR CONDITIONER CAUTION (HFC134A)
24	80871-ST7-000	O-ring - 5/8"	O-ring - 5/8"
25	80872-ST7-000	O-ring - 1/2"	O-ring - 1/2"
26	80873-ST7-000	O-ring - 8MM	O-ring - 8MM
28	90361-SV4-003	Nut - PAINT CUTTING, 6MM	Nut - PAINT CUTTING, 6MM

Air conditioner (SENSOR) 1 / 5

#	OEM	ES7	FK2
3	80525-S30-941	Sensor assy - AMBIENT	Sensor assy - AMBIENT

Alternator (MITSUBISHI) 5 / 14

#	OEM	ES7	FK2
4	31111-P08-J02	Bearing - RR. GENERATOR	Bearing - RR. GENERATOR
7	31125-P08-J02	Bolt - FLANGE	Bolt - FLANGE
9	31140-P64-902	Brush set	Brush set
11	31142-P08-J02	Nut	Nut
12	31146-PE0-004	Screw	Screw

Antenna/speaker 2 / 13

#	OEM	ES7	FK2
10	91531-S04-003	Clip - WIRE HARNESS(NATURAL) (44MM)	Clip - WIRE HARNESS(NATURAL) (44MM)
11	91540-S0A-003	Clip - HARNESS BAND(NATURAL) (96.9MM)	Clip - HARNESS BAND(NATURAL) (96.9MM)

Atf cooler kit 2 / 16

#	OEM	ES7	FK2
15	90635-PT0-802	Clip, Oil Pipe	Clip, Oil Pipe
15	90635-RV0-003	CLIP, OIL PIPE	CLIP, OIL PIPE

Battery 2 / 12

#	OEM	ES7	FK2
9	32601-SK7-900	Bolt - BATTERY TERMINAL	Bolt - BATTERY TERMINAL
10	32602-SK7-900	Nut - BATTERY TERMINAL	Nut - BATTERY TERMINAL

Brake lines (ABS; LH; 2) 6 / 25

#	OEM	ES7	FK2
14	46380-SH3-000	Grommet a - BRAKE PIPE	Grommet a - BRAKE PIPE
16	46391-S5A-J01	Clip - BRAKE PIPE	Clip - BRAKE PIPE
26	46462-SE0-000	Bolt - OIL	Bolt - OIL
27	46472-568-000	Packing - OIL BOLT	Packing - OIL BOLT
28	90361-SV4-003	Nut - PAINT CUTTING, 6MM	Nut - PAINT CUTTING, 6MM
29	90651-538-000	Clip - BRAKE HOSE	Clip - BRAKE HOSE

Brake master cylinder/ master power (LH) 12 / 22

#	OEM	ES7	FK2
7	46151-SB2-003	Yoke - PUSH ROD (NISSIN)	Yoke - PUSH ROD (NISSIN)
8	46185-SE0-003	Seal - ROD	Seal - ROD
9	46191-S2K-000	Packing - MASTER POWER	Packing - MASTER POWER
15	46512-S70-000	Pin - PEDAL	Pin - PEDAL
18	46665-S04-J01	Grommet	Grommet
19	46666-S2K-003	Filter - BRAKE RESERVOIR	Filter - BRAKE RESERVOIR
20	46669-S5A-003	Diaphragm	Diaphragm
21	46911-S70-003	Pin, LOCK(8MM)	Pin, LOCK(8MM)
22	53729-671-003	Clamp d - 15.5MM	Clamp d - 15.5MM
23	57173-SB0-801	O-ring - CONNECTOR	O-ring - CONNECTOR
24	57515-S30-003	Pin - STOP	Pin - STOP
25	57562-SF1-003	Circlip	Circlip

Bumpers 6 / 26

#	OEM	ES7	FK2
25	90126-SR4-000	Screw-washer - 5X16	Screw-washer - 5X16
27	90301-SP0-003	Nut - PAINT CUTTING, 6MM	Nut - PAINT CUTTING, 6MM
31	90682-SB0-003	Grommet - SCREW, 5MM	Grommet - SCREW, 5MM
33	91503-SZ3-003	Clip A	Clip A
34	91503-SZ5-003	Clip - BUMPER FACE	Clip - BUMPER FACE
36	91512-SX0-003	Clip - INNER FENDER CLIP	Clip - INNER FENDER CLIP

Clutch case 1 / 9

#	OEM	ES7	FK2
7	91205-PL3-A01	Oil seal - 35X56X8 (ARAI)	Oil seal - 35X56X8 (ARAI)

Clutch master cylinder (LH) 2 / 36

#	OEM	ES7	FK2
6	46911-S70-003	Pin, LOCK(8MM)	Pin, LOCK(8MM)
35	90651-538-000	Clip - BRAKE HOSE	Clip - BRAKE HOSE

Clutch/torque converter 1 / 15

#	OEM	ES7	FK2
10	90023-PA9-000	Bolt - SPECIAL	Bolt - SPECIAL

Combination switch (LH) 5 / 26

#	OEM	ES7	FK2
4	35102-SV4-003	Bolt - BREAK HEAD	Bolt - BREAK HEAD
5	35103-S04-003	Screw - RECESSED	Screw - RECESSED
6	35108-S30-003	Holder - COLUMN	Holder - COLUMN
15	35400-S5A-013	Switch assy - DOOR (MATSUSHITA)	Switch assy - DOOR (MATSUSHITA)
17	72118-ST7-003	Screw - TAPPING, 3X5	Screw - TAPPING, 3X5

Console (3) 3 / 17

#	OEM	ES7	FK2
28	90666-SDA-A01	Clip, Snap Fitting - SNAP FITTING(PO) (NATURAL)	Clip, Snap Fitting - SNAP FITTING(PO) (NATURAL)
31	91640-SM4-003	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
32	91641-SM4-003	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM

Control unit (CABIN; LH) 1 / 16

#	OEM	ES7	FK2
20	90361-SV4-003	Nut - PAINT CUTTING, 6MM	Nut - PAINT CUTTING, 6MM

Control unit (ENGINE ROOM) 3 / 19

#	OEM	ES7	FK2
3	38100-S6D-E01	Horn assy - LOW(SEGER)	Horn assy - LOW(SEGER)
7	38150-S5L-T01	Horn assy - HIGH(SEGER)	Horn assy - HIGH(SEGER)
24	90150-S84-003	Bolt - EARTH, 8X16	Bolt - EARTH, 8X16

Cylinder block/oil pan 4 / 22

#	OEM	ES7	FK2
13	90001-PM3-003	Bolt - DRAIN PLUG, 28MM	Bolt - DRAIN PLUG, 28MM
17	90009-PY3-000	DRAIN PLUG BOLT, 14MM	DRAIN PLUG BOLT, 14MM
19	90401-PR4-000	Washer - SEALING, 28MM	Washer - SEALING, 28MM
21	90703-PE0-000	Dowel pin - 18X22	Dowel pin - 18X22

Cylinder head (SOHC; VTE C) 4 / 27

#	OEM	ES7	FK2
2	12204-PJ7-305	Guide - IN. VALVE (OS)	Guide - IN. VALVE (OS)
3	12210-PZ1-004	SEAL A, VALVE STEM (NOK)	SEAL A, VALVE STEM (NOK)
4	12211-PZ1-004	Seal b - VALVE STEM(NOK)	Seal b - VALVE STEM(NOK)
7	12513-P72-003	Plug - CYLINDER HEAD	Plug - CYLINDER HEAD

Differential 1 / 33

#	OEM	ES7	FK2
4	90003-PA9-003	Bolt - FLANGE, 10MM	Bolt - FLANGE, 10MM

Emblems/caution labels 1 / 9

#	OEM	ES7	FK2
3	19043-PLA-E00	Label - COOLANT INFORMATION	Label - COOLANT INFORMATION

Engine mounting bracket 1 / 14

#	OEM	ES7	FK2
16	90380-S10-000	Bolt - STUD, 12X83.8	Bolt - STUD, 12X83.8

Engine mounts (AT) 4 / 16

#	OEM	ES7	FK2
9	90161-S5A-000	Bolt - FLANGE, 10X110	Bolt - FLANGE, 10X110
10	90162-S5A-000	Bolt - FLANGE, 10X80	Bolt - FLANGE, 10X80
13	90168-S5A-000	Bolt - FLANGE, 12X35	Bolt - FLANGE, 12X35
15	90177-S5A-000	Bolt - FLANGE, 10X20	Bolt - FLANGE, 10X20

Engine mounts (MT) 3 / 17

#	OEM	ES7	FK2
9	90161-S5A-000	Bolt - FLANGE, 10X110	Bolt - FLANGE, 10X110
10	90162-S5A-000	Bolt - FLANGE, 10X80	Bolt - FLANGE, 10X80
16	90177-S5A-000	Bolt - FLANGE, 10X20	Bolt - FLANGE, 10X20

Engine wire harness (LH) 6 / 28

#	OEM	ES7	FK2
22	90114-SM4-900	Bolt - 6X15	Bolt - 6X15
24	90501-SS8-A01	Retainer	Retainer
25	91501-P8A-A01	Stud	Stud
27	91507-PLC-003	Clip - WIRE HARNESS(DARK BLUE) (132.3MM)	Clip - WIRE HARNESS(DARK BLUE) (132.3MM)
29	91558-ST5-003	Clip - HARNESS BAND(NATURAL) (135MM)(7MM HOLE)	Clip - HARNESS BAND(NATURAL) (135MM)(7MM HOLE)
31	91601-P8A-A01	Receptacle	Receptacle

Exhaust pipe/silencer 4 / 30

#	OEM	ES7	FK2
17	18230-SV4-000	Spring - FLEXIBLE JOINT	Spring - FLEXIBLE JOINT
18	18231-SR3-A22	Bolt b - FLEXIBLE JOINT	Bolt b - FLEXIBLE JOINT
30	90212-SA5-003	Nut - SELF-LOCK, 10MM	Nut - SELF-LOCK, 10MM
31	90301-SV7-000	Nut - PAINT CUTTING, 6MM	Nut - PAINT CUTTING, 6MM

Floor mat 3 / 7

#	OEM	ES7	FK2
12	90676-S5A-003	Clip - DASHBOARD INSULATOR	Clip - DASHBOARD INSULATOR
13	91517-SE0-003	Clip - LOWER OUTER DASHBOARD INSULATOR	Clip - LOWER OUTER DASHBOARD INSULATOR
14	91560-S04-003	Clip - SIDE GARNISH (NATURAL)	Clip - SIDE GARNISH (NATURAL)

Front brake (2) 5 / 17

#	OEM	ES7	FK2
12	45353-SN7-G41	Cap - BLEEDER	Cap - BLEEDER
13	90107-SM4-000	Bolt - CALIPER MOUNTING (12X21)	Bolt - CALIPER MOUNTING (12X21)
14	90113-SA0-006	Bolt - WHEEL (SAGA)	Bolt - WHEEL (SAGA)
14	90113-SM1-005	Bolt - WHEEL (ROCKNEL FASTENER)	Bolt - WHEEL (ROCKNEL FASTENER)
14	90113-SA0-025	Bolt - WHEEL (NAGOYA RASHI)	Bolt - WHEEL (NAGOYA RASHI)

Front bulkhead 1 / 3

#	OEM	ES7	FK2
47	90105-634-000	Bolt-washer (8x20)	Bolt-washer (8x20)

Front door lining (LH) 2 / 5

#	OEM	ES7	FK2
18	90662-SB2-003	Grommet - SCREW, 5MM	Grommet - SCREW, 5MM
19	91560-S84-A01	CLIP, DOOR LINING (NATURAL)	CLIP, DOOR LINING (NATURAL)

Front door locks 2 / 36

#	OEM	ES7	FK2
44	90120-SV4-000	Bolt - LOCK STRIKER	Bolt - LOCK STRIKER
48	91531-S04-003	Clip - WIRE HARNESS(NATURAL) (44MM)	Clip - WIRE HARNESS(NATURAL) (44MM)

Front door panels 4 / 20

#	OEM	ES7	FK2
21	90101-SZ3-000	Bolt - FLANGE, 8X22 (8.5MM)	Bolt - FLANGE, 8X22 (8.5MM)
22	90102-S3N-003	Bolt - FLANGE, 8X24.5 (10.5MM)	Bolt - FLANGE, 8X24.5 (10.5MM)
22	90102-SFA-305	Bolt - FLANGE, 8X18 (SERVICE)	Bolt - FLANGE, 8X18 (SERVICE)
23	90141-S04-000	Bolt - FLANGE, 8X22	Bolt - FLANGE, 8X22

Front door windows 1 / 14

#	OEM	ES7	FK2
15	91533-S04-003	Clip - COUPLER (NATURAL)	Clip - COUPLER (NATURAL)

Front driveshaft/ half shaft 4 / 25

#	OEM	ES7	FK2
11	44319-S04-300	Set ring - 26X1.8	Set ring - 26X1.8
11	44319-SR1-003	Set ring - 26X1.8 (GKN)	Set ring - 26X1.8 (GKN)
12	44327-SV4-305	Band - JOINT BOOT (DOUBLE ROLLED BAND)	Band - JOINT BOOT (DOUBLE ROLLED BAND)
13	44329-SV4-305	Band - SHAFT BOOT (DOUBLE ROLLED BAND)	Band - SHAFT BOOT (DOUBLE ROLLED BAND)

Front fenders 7 / 15

#	OEM	ES7	FK2
8	90108-S0A-003	Bolt - FLANGE, 6X15	Bolt - FLANGE, 6X15
9	90114-SE0-000	Screw - TAPPING, 5X20	Screw - TAPPING, 5X20
11	90308-SB2-013	Nut - SUSPENSION, 5MM	Nut - SUSPENSION, 5MM
12	90682-SB0-003	Grommet - SCREW, 5MM	Grommet - SCREW, 5MM
15	91503-SZ3-003	Clip A	Clip A
17	91533-SG0-000	Clip b - FAIRING	Clip b - FAIRING
18	91545-SE0-003	Clip assy. - 8MM	Clip assy. - 8MM

Front grille (2) 2 / 4

#	OEM	ES7	FK2
4	90301-ST0-003	push nut, 3mm	push nut, 3mm
5	91503-SZ3-003	Clip A	Clip A

Front seat (LH; DRIVER SIDE) 3 / 9

#	OEM	ES7	FK2
1	04810-SB3-000	C clip set - TRIM FASTENER (30 PIECES)	C clip set - TRIM FASTENER (30 PIECES)
26	90134-SE3-003	Screw - TAPPING, 5X10	Screw - TAPPING, 5X10
28	90610-SR3-003	Clip - GARNISH (KATO)	Clip - GARNISH (KATO)

Front seat (LH; PASSENGER SIDE) 3 / 8

#	OEM	ES7	FK2
1	04810-SB3-000	C clip set - TRIM FASTENER (30 PIECES)	C clip set - TRIM FASTENER (30 PIECES)
20	90610-SR3-003	Clip - GARNISH (KATO)	Clip - GARNISH (KATO)
21	90610-S10-003	Clip - GARNISH	Clip - GARNISH

Front seat components (L.; MANUAL HEIGHT) 1 / 11

#	OEM	ES7	FK2
8	90135-S5A-003	Bolt-washer - 10X27	Bolt-washer - 10X27

Front seat components (R.) 1 / 6

#	OEM	ES7	FK2
7	90135-S5A-003	Bolt-washer - 10X27	Bolt-washer - 10X27

Front shock absorber 1 / 16

#	OEM	ES7	FK2
12	90002-S10-000	Nut - FLANGE, 10MM	Nut - FLANGE, 10MM

Front windshield wiper (L H) 6 / 21

#	OEM	ES7	FK2
2	76516-SE0-003	Rubber - BRACKETLESS MOUNTING	Rubber - BRACKETLESS MOUNTING
3	76516-SR3-003	Rubber - MOUNTING	Rubber - MOUNTING
4	76517-SE0-003	Collar - BRACKETLESS	Collar - BRACKETLESS
5	76517-SM4-003	Collar	Collar
8	76524-SE0-013	Dust seal	Dust seal
20	90126-SR3-000	Bolt-washer - 6X32	Bolt-washer - 6X32

Fuel pipe (1) 4 / 39

#	OEM	ES7	FK2
13	17711-S0X-A31	Retainer - GREEN)(TOKAI	Retainer - GREEN)(TOKAI
14	17711-S84-004	Retainer - WHITE)(SANOH	Retainer - WHITE)(SANOH
29	90361-SV4-003	Nut - PAINT CUTTING, 6MM	Nut - PAINT CUTTING, 6MM
32	91405-SDA-000	Clamp - TUBE(D10.5)	Clamp - TUBE(D10.5)

Fuel tank (1) 4 / 43

#	OEM	ES7	FK2
21	17525-S0X-A00	Bolt-washer - 10X25	Bolt-washer - 10X25
35	90150-S04-003	Bolt - EARTH, 6X16	Bolt - EARTH, 6X16
38	91404-SDC-000	Clamp - TUBE (D10)	Clamp - TUBE (D10)
42	91601-SH3-013	Grommet - SCREW, 5MM (BLACK)	Grommet - SCREW, 5MM (BLACK)

Grommet (FRONT) 6 / 13

#	OEM	ES7	FK2
2	74144-SR3-000	Cushion - HOOD	Cushion - HOOD
6	82871-671-000	Grommet - DRAIN HOLE, 25MM	Grommet - DRAIN HOLE, 25MM
7	90615-SR3-000	Cap - WELD HOLE, 51X77	Cap - WELD HOLE, 51X77
11	91608-S5A-003	Boot - FLOOR	Boot - FLOOR
12	91615-SH3-000	Cap - FLOOR HOLE, 49MM	Cap - FLOOR HOLE, 49MM
13	91619-SE0-000	Seal - DOOR HOLE, 30MM(BLACK)	Seal - DOOR HOLE, 30MM(BLACK)

Grommet (LOWER) 2 / 2

#	OEM	ES7	FK2
1	85268-SA0-000	Protection - TAILGATE, 20MM (CIRCLE)	Protection - TAILGATE, 20MM (CIRCLE)
2	91606-SK7-003	Plug - BLIND, 25MM	Plug - BLIND, 25MM

Grommet (REAR) 2 / 5

#	OEM	ES7	FK2
1	82871-671-000	Grommet - DRAIN HOLE, 25MM	Grommet - DRAIN HOLE, 25MM
2	85268-SA0-000	Protection - TAILGATE, 20MM (CIRCLE)	Protection - TAILGATE, 20MM (CIRCLE)

Grommet (SIDE) 1 / 5

#	OEM	ES7	FK2
5	91619-SE0-000	Seal - DOOR HOLE, 30MM(BLACK)	Seal - DOOR HOLE, 30MM(BLACK)

Harness band/bracket (LH) 15 / 32

#	OEM	ES7	FK2
3	32132-S6A-003	Band - WIRE HARNESS OFFSET(20) (DARK GREEN)(122.5MM)	Band - WIRE HARNESS OFFSET(20) (DARK GREEN)(122.5MM)
16	91507-693-003	Clip - WIRE HARNESS (BLACK) (50MM) (HARNESS TAPING)	Clip - WIRE HARNESS (BLACK) (50MM) (HARNESS TAPING)
17	91510-SA5-003	Clip - OFFSET(10)(BROWN)(50MM)	Clip - OFFSET(10)(BROWN)(50MM)
18	91531-S04-003	Clip - WIRE HARNESS(NATURAL) (44MM)	Clip - WIRE HARNESS(NATURAL) (44MM)
20	91533-S04-003	Clip - COUPLER (NATURAL)	Clip - COUPLER (NATURAL)
22	91540-SV4-003	Clip - HARNESS BAND (NATURAL) (145.2MM)	Clip - HARNESS BAND (NATURAL) (145.2MM)
23	91540-S0A-003	Clip - HARNESS BAND(NATURAL) (96.9MM)	Clip - HARNESS BAND(NATURAL) (96.9MM)
25	91541-S0A-003	Clip - HARNESS BAND(BLACK) (145MM)	Clip - HARNESS BAND(BLACK) (145MM)
26	91545-SV4-003	Clip - HARNESS BAND (NATURAL) (145.2MM) (WITH SEAL)	Clip - HARNESS BAND (NATURAL) (145.2MM) (WITH SEAL)
28	91547-SH3-003	Clip - BAND(NATURAL)(160MM)	Clip - BAND(NATURAL)(160MM)
31	91552-SS0-003	Clip - WIRE HARNESS (M5) (BROWN) (93.5MM)	Clip - WIRE HARNESS (M5) (BROWN) (93.5MM)
34	91558-SM4-003	Clip - TUBE(BLACK)(135MM)	Clip - TUBE(BLACK)(135MM)
36	91559-S5A-003	Holder - HARNESS (BLACK)	Holder - HARNESS (BLACK)
37	91565-S0X-003	Clip - COUPLER (DARK GREEN)	Clip - COUPLER (DARK GREEN)
38	91571-S10-003	Clip - WIRE HARNESS (NATURAL) (130MM)	Clip - WIRE HARNESS (NATURAL) (130MM)

Headlight 1 / 18

#	OEM	ES7	FK2
18	91512-SX0-003	Clip - INNER FENDER CLIP	Clip - INNER FENDER CLIP

Heater blower (LH) 2 / 21

#	OEM	ES7	FK2
16	90156-SH3-000	Bolt-washer - 6X24	Bolt-washer - 6X24
22	90321-SV4-003	Nut-washer - 6MM (PAINT CUTTING)	Nut-washer - 6MM (PAINT CUTTING)

Heater unit (LH) 4 / 36

#	OEM	ES7	FK2
27	80871-ST7-000	O-ring - 5/8"	O-ring - 5/8"
28	80872-ST7-000	O-ring - 1/2"	O-ring - 1/2"
29	90156-SH3-000	Bolt-washer - 6X24	Bolt-washer - 6X24
38	91540-S0A-003	Clip - HARNESS BAND(NATURAL) (96.9MM)	Clip - HARNESS BAND(NATURAL) (96.9MM)

Hood (LH) 1 / 29

#	OEM	ES7	FK2
23	90108-S0A-003	Bolt - FLANGE, 6X15	Bolt - FLANGE, 6X15

Inner panels/floor panel 1 / 1

#	OEM	ES7	FK2
36	90108-S0A-003	Bolt - FLANGE, 6X15	Bolt - FLANGE, 6X15

Instrument panel (LH) 2 / 12

#	OEM	ES7	FK2
3	66844-SA7-000	Cap - INSTRUMENT PANEL STAY	Cap - INSTRUMENT PANEL STAY
21	90321-SP0-A80	Nut-washer - 6MM	Nut-washer - 6MM

Instrument panel garnish (DRIVER SIDE; LH) 1 / 10

#	OEM	ES7	FK2
19	90302-SA4-003	Nut - SPRING, 4MM	Nut - SPRING, 4MM

Instrument panel garnish (PASSENGER SIDE; LH) 4 / 22

#	OEM	ES7	FK2
10	66844-SA7-000	Cap - INSTRUMENT PANEL STAY	Cap - INSTRUMENT PANEL STAY
36	90302-SA4-003	Nut - SPRING, 4MM	Nut - SPRING, 4MM
38	91640-SM4-003	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM
39	91641-SM4-003	Grommet - SCREW, 4MM	Grommet - SCREW, 4MM

Intake manifold 3 / 21

#	OEM	ES7	FK2
3	16451-PLC-000	Clip - INJECTOR	Clip - INJECTOR
17	37835-PGK-A01	O-ring	O-ring
21	91301-PLC-000	O-ring - 7.47X3.6	O-ring - 7.47X3.6

Interior light 4 / 10

#	OEM	ES7	FK2
3	34251-S5A-003	Lens	Lens
6	34253-671-003	Bulb - 12V 8W)(DAIICHI	Bulb - 12V 8W)(DAIICHI
6	04110-SWA-305	BULB T10X318W	BULB T10X318W
9	34351-657-921	Bulb - 12V/5W) (STANLEY	Bulb - 12V/5W) (STANLEY

Knuckle 2 / 19

#	OEM	ES7	FK2
16	90002-S10-000	Nut - FLANGE, 10MM	Nut - FLANGE, 10MM
18	90306-SB2-013	Nut - SELF-LOCK, 10MM (CLINCH)	Nut - SELF-LOCK, 10MM (CLINCH)

Main valve body 1 / 13

#	OEM	ES7	FK2
6	25145-PA9-010	Shaft - OIL PUMP GEAR	Shaft - OIL PUMP GEAR

Meter components (NS; 2) 1 / 6

#	OEM	ES7	FK2
5	90302-SA4-003	Nut - SPRING, 4MM	Nut - SPRING, 4MM

Mirror (BREAK AWAY; ELECTRIC REMOTE CONTROL) 1 / 11

#	OEM	ES7	FK2
18	90615-SK7-003	Clip - MIRROR GARNISH	Clip - MIRROR GARNISH

Oil pump/oil strainer 3 / 23

#	OEM	ES7	FK2
8	15400-PLM-A02	OIL FILTER (HONEYWELL)	OIL FILTER (HONEYWELL)
8	15400-RTA-003	OIL FILTER (MAHLE TENNEX)	OIL FILTER (MAHLE TENNEX)
11	90015-PH1-013	Holder - OIL FILTER	Holder - OIL FILTER

P.s. gear box components (EPS; LH) 3 / 19

#	OEM	ES7	FK2
1	53413-SCC-003	Spring - RACK GUIDE PRESSURE	Spring - RACK GUIDE PRESSURE
2	53414-S5A-003	Screw - RACK GUIDE	Screw - RACK GUIDE
4	53418-S5A-003	Washer - DISK	Washer - DISK

Pedal (LH) 2 / 27

#	OEM	ES7	FK2
11	46505-SA5-000	Pad - PEDAL STOPPER	Pad - PEDAL STOPPER
26	90301-SP0-003	Nut - PAINT CUTTING, 6MM	Nut - PAINT CUTTING, 6MM

Pillar garnish 2 / 4

#	OEM	ES7	FK2
19	91560-S84-A01	CLIP, DOOR LINING (NATURAL)	CLIP, DOOR LINING (NATURAL)
20	91560-S84-A11	Clip - PILLAR GARNISH(BLACK)	Clip - PILLAR GARNISH(BLACK)

Protector 2 / 10

#	OEM	ES7	FK2
12	90114-SE0-000	Screw - TAPPING, 5X20	Screw - TAPPING, 5X20
15	91503-SZ3-003	Clip A	Clip A

R. side cover 14 / 41

#	OEM	ES7	FK2
8	24282-634-000	Bolt - SHAFT FORK SETTING	Bolt - SHAFT FORK SETTING
11	24538-PA9-003	Stopper - PARKING BRAKE (2)	Stopper - PARKING BRAKE (2)
11	24537-PA9-003	Stopper - PARKING BRAKE (1)	Stopper - PARKING BRAKE (1)
11	24539-PA9-003	Stopper - PARKING BRAKE (3)	Stopper - PARKING BRAKE (3)
13	24553-PN6-000	Roller - PARKING BRAKE	Roller - PARKING BRAKE
23	90024-612-000	Bolt - SEALING, 8MM	Bolt - SEALING, 8MM
24	90433-639-000	Washer - LOCK, 6MM	Washer - LOCK, 6MM
25	90471-580-000	Packing - 8MM	Packing - 8MM
29	91006-P1B-003	Bearing - BALL, 9X20X6	Bearing - BALL, 9X20X6
30	91201-PA9-004	Oil seal - 9X18X7 (ARAI)	Oil seal - 9X18X7 (ARAI)
31	91301-PC9-003	O-ring - 7.7X2.3 (ARAI)	O-ring - 7.7X2.3 (ARAI)
32	91305-PC9-003	O-ring - 34X1.9 (ARAI)	O-ring - 34X1.9 (ARAI)
34	91309-PX4-003	O-ring - 16X2.1 (NOK)	O-ring - 16X2.1 (NOK)
35	91311-PA9-004	O-ring - 7.7X1.9 (NOK)	O-ring - 7.7X1.9 (NOK)

Radiator hose/reserve tan k 4 / 21

#	OEM	ES7	FK2
17	74172-S5A-000	Cushion - RADIATOR MOUNTING LOWER	Cushion - RADIATOR MOUNTING LOWER
18	74173-SJ4-000	Cushion - RADIATOR MOUNTING UPPER	Cushion - RADIATOR MOUNTING UPPER
19	90635-PT0-802	Clip, Oil Pipe	Clip, Oil Pipe
19	90635-RV0-003	CLIP, OIL PIPE	CLIP, OIL PIPE

Rear brake (DRUM) 4 / 39

#	OEM	ES7	FK2
36	90113-SA0-025	Bolt - WHEEL (NAGOYA RASHI)	Bolt - WHEEL (NAGOYA RASHI)
36	90113-SM1-005	Bolt - WHEEL (ROCKNEL FASTENER)	Bolt - WHEEL (ROCKNEL FASTENER)
36	90113-SA0-006	Bolt - WHEEL (SAGA)	Bolt - WHEEL (SAGA)
37	90305-S30-003	Nut - SPINDLE	Nut - SPINDLE

Rear door lining 2 / 4

#	OEM	ES7	FK2
15	90662-SB2-003	Grommet - SCREW, 5MM	Grommet - SCREW, 5MM
16	91560-S84-A01	CLIP, DOOR LINING (NATURAL)	CLIP, DOOR LINING (NATURAL)

Rear door locks 2 / 32

#	OEM	ES7	FK2
35	90120-SV4-000	Bolt - LOCK STRIKER	Bolt - LOCK STRIKER
36	90662-SB2-003	Grommet - SCREW, 5MM	Grommet - SCREW, 5MM

Rear door panels 5 / 19

#	OEM	ES7	FK2
19	75891-SA7-000	Stopper - DOOR	Stopper - DOOR
20	90102-S3N-003	Bolt - FLANGE, 8X24.5 (10.5MM)	Bolt - FLANGE, 8X24.5 (10.5MM)
20	90102-SFA-305	Bolt - FLANGE, 8X18 (SERVICE)	Bolt - FLANGE, 8X18 (SERVICE)
21	90141-S04-000	Bolt - FLANGE, 8X22	Bolt - FLANGE, 8X22
22	90361-SR3-000	Nut - FLANGE, 8MM	Nut - FLANGE, 8MM

Rear door windows 1 / 14

#	OEM	ES7	FK2
15	91533-S04-003	Clip - COUPLER (NATURAL)	Clip - COUPLER (NATURAL)

Rear lower arm 2 / 28

#	OEM	ES7	FK2
22	90002-S10-000	Nut - FLANGE, 10MM	Nut - FLANGE, 10MM
23	90306-SB2-013	Nut - SELF-LOCK, 10MM (CLINCH)	Nut - SELF-LOCK, 10MM (CLINCH)

Rear seat (2) 1 / 21

#	OEM	ES7	FK2
1	04810-SB3-000	C clip set - TRIM FASTENER (30 PIECES)	C clip set - TRIM FASTENER (30 PIECES)

Rear tray/trunk lining 2 / 10

#	OEM	ES7	FK2
17	90610-SR3-003	Clip - GARNISH (KATO)	Clip - GARNISH (KATO)
20	91560-S84-A01	CLIP, DOOR LINING (NATURAL)	CLIP, DOOR LINING (NATURAL)

Regulator body 3 / 14

#	OEM	ES7	FK2
3	27246-PN6-800	Cap - REGULATOR SPRING	Cap - REGULATOR SPRING
10	90089-PK4-000	Bolt - STOPPER, 6MM	Bolt - STOPPER, 6MM
14	91316-PF4-003	O-ring - 31X1.7 (ARAI)	O-ring - 31X1.7 (ARAI)

Resonator chamber 5 / 18

#	OEM	ES7	FK2
2	17212-P2J-J00	Rubber, AIR CLEANER MOUNTING	Rubber, AIR CLEANER MOUNTING
3	17213-P8A-A00	Rubber - INTAKE MANIFOLD COVER MOUNTING	Rubber - INTAKE MANIFOLD COVER MOUNTING
4	17216-PN3-000	Collar - AIR CLEANER MOUNTING	Collar - AIR CLEANER MOUNTING
17	75353-671-000	Lock - SCREW	Lock - SCREW
18	90001-P0A-000	Bolt-washer - SPECIAL, 6X35	Bolt-washer - SPECIAL, 6X35

Roof lining 3 / 6

#	OEM	ES7	FK2
16	90137-S30-003	Screw - ET, 6X18	Screw - ET, 6X18
16	90136-S30-003	Screw - ET, 5X18	Screw - ET, 5X18
18	91560-S84-A01	CLIP, DOOR LINING (NATURAL)	CLIP, DOOR LINING (NATURAL)

Seatbelts 1 / 6

#	OEM	ES7	FK2
18	90135-S1F-003	Bolt - FLANGE, 7/16"	Bolt - FLANGE, 7/16"

Secondary body 1 / 14

#	OEM	ES7	FK2
2	22743-P4R-000	Pipe - 8X192.5	Pipe - 8X192.5

Select lever 3 / 14

#	OEM	ES7	FK2
1	35505-692-003	Bulb - 14V 1.4W	Bulb - 14V 1.4W
15	90351-SB2-003	Nut - FLANGE, 8MM	Nut - FLANGE, 8MM
16	90361-SV4-003	Nut - PAINT CUTTING, 6MM	Nut - PAINT CUTTING, 6MM

Servo body 4 / 27

#	OEM	ES7	FK2
20	91321-PF4-004	O-ring - 18.3X2.4(NOK)	O-ring - 18.3X2.4(NOK)
23	91331-PC9-003	O-ring	O-ring
24	91331-PL5-J00	O-ring - 20.2X2.4 (NOK)	O-ring - 20.2X2.4 (NOK)
26	91344-580-000	O-ring - 31X2.7 (ARAI)	O-ring - 31X2.7 (ARAI)

Shift arm/shift lever 1 / 16

#	OEM	ES7	FK2
1	21396-P20-000	Cap - BREATHER	Cap - BREATHER

Shift fork/control shaft 4 / 10

#	OEM	ES7	FK2
3	24282-634-000	Bolt - SHAFT FORK SETTING	Bolt - SHAFT FORK SETTING
7	90001-PA9-000	Bolt - HEX., 6MM	Bolt - HEX., 6MM
9	90433-639-000	Washer - LOCK, 6MM	Washer - LOCK, 6MM
10	91209-612-003	Oil seal - 12X22X7 (ARAI)	Oil seal - 12X22X7 (ARAI)

Shift lever 1 / 12

#	OEM	ES7	FK2
9	90361-SV4-003	Nut - PAINT CUTTING, 6MM	Nut - PAINT CUTTING, 6MM

Srs unit (LH) 1 / 5

#	OEM	ES7	FK2
6	90137-S84-A01	Bolt - TORX EARTH, 6X20	Bolt - TORX EARTH, 6X20

Starter motor (DENSO; 1) 17 / 33

#	OEM	ES7	FK2
1	30201-PH9-004	Ring - SNAP (DENSO)	Ring - SNAP (DENSO)
2	30202-P3F-003	Collar - CLUTCH STOP	Collar - CLUTCH STOP
7	31202-PM3-J01	Bolt - THROUGH (DENSO)	Bolt - THROUGH (DENSO)
8	31203-PCA-003	Lever - PINION DRIVE	Lever - PINION DRIVE
13	31208-P3F-003	Screw - PAN, 4MM	Screw - PAN, 4MM
15	31214-P3F-003	Gear assy. - INTERNAL	Gear assy. - INTERNAL
16	31215-P3F-003	Gear comp - PLANETARY	Gear comp - PLANETARY
17	31216-RAA-003	Absorber comp - SHOCK	Absorber comp - SHOCK
18	31217-P3F-003	Plate - SEAL	Plate - SEAL
19	31218-P3F-003	Washer a	Washer a
20	31219-P3F-003	Washer b	Washer b
21	31220-PH9-004	Nut - HEX., 8MM	Nut - HEX., 8MM
22	31220-P3F-003	Washer c	Washer c
23	31223-PA0-006	Nut - HEX.	Nut - HEX.
24	31228-PLR-A01	O-ring	O-ring
25	31231-P3F-003	Plate comp - BRUSH HOLDER	Plate comp - BRUSH HOLDER
29	31292-PLR-A01	Bolt-washer	Bolt-washer

Steering column 2 / 5

#	OEM	ES7	FK2
4	90361-SR3-000	Nut - FLANGE, 8MM	Nut - FLANGE, 8MM
5	90511-671-003	Washer - TOOTHED LOCK	Washer - TOOTHED LOCK

Steering wheel (SRS) 1 / 9

#	OEM	ES7	FK2
14	90161-SV4-003	Bolt - STEERING HANDLE	Bolt - STEERING HANDLE

Taillight/license light 1 / 28

#	OEM	ES7	FK2
28	91512-S50-003	Clip - LICENSE GARNISH	Clip - LICENSE GARNISH

Tire/wheel disks 2 / 15

#	OEM	ES7	FK2
9	42753-SK3-000	Valve - RIM(A.R.G.)	Valve - RIM(A.R.G.)
18	83853-SX0-000	Bolt - ANCHOR	Bolt - ANCHOR

Torque converter case 7 / 19

#	OEM	ES7	FK2
5	90024-612-000	Bolt - SEALING, 8MM	Bolt - SEALING, 8MM
6	90471-580-000	Packing - 8MM	Packing - 8MM
7	90705-PA9-000	Dowel pin - 14X25	Dowel pin - 14X25
10	91205-PL3-A01	Oil seal - 35X56X8 (ARAI)	Oil seal - 35X56X8 (ARAI)
12	91301-P6H-003	O-ring - 7.6X1.9 (KEIHIN)	O-ring - 7.6X1.9 (KEIHIN)
13	91302-P6H-003	O-ring - 9.6X1.9 (KEIHIN)	O-ring - 9.6X1.9 (KEIHIN)
13	91302-P7W-A00	O-ring - 9.6X1.9	O-ring - 9.6X1.9

Transmission case 8 / 82

#	OEM	ES7	FK2
3	21396-P20-000	Cap - BREATHER	Cap - BREATHER
5	25422-PN6-801	Magnet comp. - TRANSMISSION	Magnet comp. - TRANSMISSION
18	90081-PX4-003	Bolt - PLUG, 18MM	Bolt - PLUG, 18MM
20	90471-PX4-000	Washer - DRAIN PLUG, 18MM	Washer - DRAIN PLUG, 18MM
21	90603-PB6-000	Ring - SNAP, 62MM	Ring - SNAP, 62MM
22	90609-PC8-000	Ring - SNAP, 68MM	Ring - SNAP, 68MM
23	90615-PF4-000	Ring - SNAP, 75MM	Ring - SNAP, 75MM
28	91309-PX4-003	O-ring - 16X2.1 (NOK)	O-ring - 16X2.1 (NOK)

Trunk lid 2 / 26

#	OEM	ES7	FK2
8	73219-693-951	Seal - FUEL LID OPENER (GREEN)	Seal - FUEL LID OPENER (GREEN)
31	90108-S0A-003	Bolt - FLANGE, 6X15	Bolt - FLANGE, 6X15

Valve/rocker arm (SOHC; VTEC; 1) 1 / 18

#	OEM	ES7	FK2
12	14775-P08-000	Seat - VALVE SPRING	Seat - VALVE SPRING

Water pump/sensor 4 / 27

#	OEM	ES7	FK2
2	18715-PB2-000	GASKET, EGR VALVE (ISHINO GASKET)	GASKET, EGR VALVE (ISHINO GASKET)
6	19305-PLC-A00	Rubber - THERMOSTAT MOUNTING	Rubber - THERMOSTAT MOUNTING
17	37870-PLC-004	Sensor assy, WATER TEMP (MATSUSHITA)	Sensor assy, WATER TEMP (MATSUSHITA)
19	91307-PLC-004	O-ring - 9.5X1.9 (MATSUSHITA)	O-ring - 9.5X1.9 (MATSUSHITA)

Water valve (LH) 3 / 10

#	OEM	ES7	FK2
8	79746-S5A-003	Clamp - HEATER HOSE (NATURAL)	Clamp - HEATER HOSE (NATURAL)
9	91405-PK1-003	Clip, WATER HOSE, 24MM	Clip, WATER HOSE, 24MM
9	19513-PE0-003	Clamp - WATER HOSE (21.7MM) (CHUO SPRING)	Clamp - WATER HOSE (21.7MM) (CHUO SPRING)

Wire harness (LH) 4 / 19

#	OEM	ES7	FK2
15	35505-692-003	Bulb - 14V 1.4W	Bulb - 14V 1.4W
16	90137-S84-A01	Bolt - TORX EARTH, 6X20	Bolt - TORX EARTH, 6X20
17	90148-SE0-003	Bolt - EARTH, 6X16 (WASHER 12.5MM) (ZN)	Bolt - EARTH, 6X16 (WASHER 12.5MM) (ZN)
18	90149-SE0-003	Bolt - EARTH, 6X16	Bolt - EARTH, 6X16
