CD3 × CM1

共通 208 / 合計 4,216 · Jaccard 4.9%
CD3 Honda ACCORD — 2,150 中 208 共有
CM1 Honda ACCORD — 2,274 中 208 共有
208 件
Air cleaner 4 / 17
CD3 Air cleaner
CM1 Air cleaner
# OEM CD3 CM1
2 17212-P2J-J00 Rubber, AIR CLEANER MOUNTING Rubber, AIR CLEANER MOUNTING
4 17213-PV0-000 Rubber - AIR CLEANER CASE MOUNTING Rubber - AIR CLEANER CASE MOUNTING
5 17216-PN3-000 Collar - AIR CLEANER MOUNTING Collar - AIR CLEANER MOUNTING
25 90001-P0A-000 Bolt-washer - SPECIAL, 6X35 Bolt-washer - SPECIAL, 6X35
Air conditioner (CONDENSER; RH) 1 / 17
CD3 Air conditioner (CONDENSER; RH)
CM1 Air conditioner (CONDENSE R)
# OEM CD3 CM1
17 80175-SE0-000 Mount - CONDENSER Mount - CONDENSER
Air conditioner (COOLING UNIT; RH) 1 / 21
CD3 Air conditioner (COOLING UNIT; RH)
CM1 Heater blower (LH)
# OEM CD3 CM1
20 90321-SV4-003 Nut-washer - 6MM (PAINT CUTTING) Nut-washer - 6MM (PAINT CUTTING)
Air conditioner (HOSES/PIPES; RH) 3 / 24
CD3 Air conditioner (HOSES/PIPES; RH)
CM1 Air conditioner (HOSES/PI PES; LH)
# OEM CD3 CM1
1 80050-SP0-000 Label - AIR CONDITIONER CAUTION (HFC134A) Label - AIR CONDITIONER CAUTION (HFC134A)
20 80871-ST7-000 O-ring - 5/8" O-ring - 5/8"
22 80872-ST7-000 O-ring - 1/2" O-ring - 1/2"
Alternator (DENSO) 4 / 21
CD3 Alternator (DENSO)
CM1 Alternator (DENSO)
# OEM CD3 CM1
4 31111-PT0-003 Bearing - RR. GENERATOR Bearing - RR. GENERATOR
10 31138-PD1-004 Cover - BEARING Cover - BEARING
12 31142-PD1-004 Nut - PULLEY LOCK Nut - PULLEY LOCK
15 31147-PT0-003 Screw-washer Screw-washer
Battery 4 / 19
CD3 Battery
CM1 Battery
# OEM CD3 CM1
6 31542-SA5-665 Plug - VENT (MF) (PANASONIC) Plug - VENT (MF) (PANASONIC)
12 32601-SK7-900 Bolt - BATTERY TERMINAL Bolt - BATTERY TERMINAL
13 32602-SK7-900 Nut - BATTERY TERMINAL Nut - BATTERY TERMINAL
16 90114-SM4-900 Bolt - 6X15 Bolt - 6X15
Brake lines (RH) 6 / 26
CD3 Brake lines (RH)
CM1 Brake lines (VSA; LH; 1)
# OEM CD3 CM1
16 46380-SB0-000 Grommet a - BRAKE PIPE (BLACK) Grommet a - BRAKE PIPE (BLACK)
22 46393-SM4-951 Clip c Clip c
28 46462-SE0-000 Bolt - OIL Bolt - OIL
29 46472-568-000 Packing - OIL BOLT Packing - OIL BOLT
33 90361-SV4-003 Nut - PAINT CUTTING, 6MM Nut - PAINT CUTTING, 6MM
34 90651-538-000 Clip - BRAKE HOSE Clip - BRAKE HOSE
Brake master cylinder/ master power 1 / 24
CD3 Brake master cylinder/ master power
CM1 Brake master cylinder/ master power (LH)
# OEM CD3 CM1
26 53729-671-003 Clamp d - 15.5MM Clamp d - 15.5MM
Breather tube (SOHC) 3 / 7
CD3 Breather tube (SOHC)
CM1 Cylinder head cover
# OEM CD3 CM1
7 17139-PK1-000 Grommet - PCV VALVE Grommet - PCV VALVE
9 91405-679-004 Clamp - TUBE (D17) Clamp - TUBE (D17)
9 91405-PM5-004 Clamp - TUBE (D17) Clamp - TUBE (D17)
Bumpers (2) 6 / 23
CD3 Bumpers (2)
CM1 Bumpers
# OEM CD3 CM1
21 90110-SE7-000 Bolt-washer - 8X21 Bolt-washer - 8X21
24 90111-SM4-003 Bolt - BUMPER Bolt - BUMPER
25 90301-SP0-003 Nut - PAINT CUTTING, 6MM Nut - PAINT CUTTING, 6MM
28 90305-SM4-000 Nut - AIR SPOILER CLIP Nut - AIR SPOILER CLIP
32 91503-SZ5-003 Clip - BUMPER FACE Clip - BUMPER FACE
33 91503-SZ3-003 Clip A Clip A
Clutch housing 3 / 24
CD3 Clutch housing
CM1 Clutch release
# OEM CD3 CM1
7 22825-P0S-000 Bolt - RELEASE FORK Bolt - RELEASE FORK
8 22835-P0S-000 Spring - RELEASE FORK SETTING Spring - RELEASE FORK SETTING
16 90705-PG2-000 Dowel pin - 14X20 Dowel pin - 14X20
Clutch master cylinder (RH) 4 / 41
CD3 Clutch master cylinder (RH)
CM1 Clutch master cylinder (LH)
# OEM CD3 CM1
1 43352-567-000 Screw - BLEEDER Screw - BLEEDER
6 46182-500-013 Circlip Circlip
9 46472-568-000 Packing - OIL BOLT Packing - OIL BOLT
40 90651-538-000 Clip - BRAKE HOSE Clip - BRAKE HOSE
Clutch/torque converter 1 / 7
CD3 Clutch/torque converter
CM1 Clutch/torque converter
# OEM CD3 CM1
10 90034-689-000 Bolt - TWELVE POINT, 8MM (TOKAI TRW) Bolt - TWELVE POINT, 8MM (TOKAI TRW)
Combination meter components 2 / 25
CD3 Combination meter components
CM1 Instrument panel garnish (DRIVER SIDE; LH)
# OEM CD3 CM1
6 37115-SA0-601 Packing - NS Packing - NS
27 91640-SM4-003 Grommet - SCREW, 4MM Grommet - SCREW, 4MM
Combination switch (4) 2 / 18
CD3 Combination switch (4)
CM1 Combination switch (LH)
# OEM CD3 CM1
5 35102-SV4-003 Bolt - BREAK HEAD Bolt - BREAK HEAD
26 91551-SF4-003 Band - WIRE HARNESS(BROWN) (110MM) Band - WIRE HARNESS(BROWN) (110MM)
Console (RH) 5 / 19
CD3 Console (RH)
CM1 Console
# OEM CD3 CM1
2 35505-692-003 Bulb - 14V 1.4W Bulb - 14V 1.4W
6 66418-579-000 Stopper - GLOVE BOX LID Stopper - GLOVE BOX LID
34 90144-SP0-000 Screw - TAPPING, 4X16 (PO) Screw - TAPPING, 4X16 (PO)
40 91640-SM4-003 Grommet - SCREW, 4MM Grommet - SCREW, 4MM
41 91641-SM4-003 Grommet - SCREW, 4MM Grommet - SCREW, 4MM
Control unit (CABIN; 2) 3 / 31
CD3 Control unit (CABIN; 2)
CM1 Navigation system (LH)
# OEM CD3 CM1
30 90148-SE0-003 Bolt - EARTH, 6X16 (WASHER 12.5MM) (ZN) Bolt - EARTH, 6X16 (WASHER 12.5MM) (ZN)
31 90301-SP0-003 Nut - PAINT CUTTING, 6MM Nut - PAINT CUTTING, 6MM
33 91555-SM4-003 Clip - COUPLER (RED) Clip - COUPLER (RED)
Control unit (ENGINE ROOM) 1 / 27
CD3 Control unit (ENGINE ROOM)
CM1 Control unit (ENGINE ROOM)
# OEM CD3 CM1
20 90114-SM4-900 Bolt - 6X15 Bolt - 6X15
Cylinder block/oil pan (SOHC) 2 / 32
CD3 Cylinder block/oil pan (SOHC)
CM1 Cylinder block/oil pan
# OEM CD3 CM1
21 90009-PH1-000 Bolt - DRAIN PLUG, 14MM Bolt - DRAIN PLUG, 14MM
24 90041-PA5-000 Bolt - STUD, 6X28 Bolt - STUD, 6X28
Cylinder head (SOHC) 4 / 23
CD3 Cylinder head (SOHC)
CM1 Vtc oil control valve
# OEM CD3 CM1
4 12210-PZ1-004 SEAL A, VALVE STEM (NOK) SEAL A, VALVE STEM (NOK)
4 12210-PZ1-003 Seal a - VALVE STEM(ARAI) Seal a - VALVE STEM(ARAI)
5 12211-PZ1-004 Seal b - VALVE STEM(NOK) Seal b - VALVE STEM(NOK)
5 12211-PZ1-003 Seal b - VALVE STEM(ARAI) Seal b - VALVE STEM(ARAI)
Cylinder head cover (SOHC) 2 / 9
CD3 Cylinder head cover (SOHC)
CM1 Cylinder head cover
# OEM CD3 CM1
10 15613-PC6-000 Packing, Oil Filler Packing, Oil Filler
14 90213-PH3-000 Nut - CAP, 6MM Nut - CAP, 6MM
Emblems 1 / 10
CD3 Emblems
CM1 Molding
# OEM CD3 CM1
28 91512-SR3-004 Clip - TUBULAR Clip - TUBULAR
Engine hood 1 / 22
CD3 Engine hood
CM1 Front door panels
# OEM CD3 CM1
26 91530-SP1-003 Clip A - DOOR WEATHERSTRIP Clip A - DOOR WEATHERSTRIP
Engine wire harness/clamp (SOHC) 4 / 23
CD3 Engine wire harness/clamp (SOHC)
CM1 Cylinder block/oil pan
# OEM CD3 CM1
14 37240-PT0-014 Switch - OIL PRESSURE (TEC) Switch - OIL PRESSURE (TEC)
14 37240-PT0-023 Switch - OIL PRESSURE(DENSO) Switch - OIL PRESSURE(DENSO)
19 90114-SM4-900 Bolt - 6X15 Bolt - 6X15
20 90149-SE0-003 Bolt - EARTH, 6X16 Bolt - EARTH, 6X16
Exhaust manifold (1) 3 / 12
CD3 Exhaust manifold (1)
CM1 Exhaust manifold (2.0L)
# OEM CD3 CM1
8 90005-P0A-000 Bolt-washer - 10X22 Bolt-washer - 10X22
9 90010-PE2-900 Bolt - SPECIAL, 10X22 Bolt - SPECIAL, 10X22
13 90451-PE2-000 Washer - SPECIAL, 11X28 Washer - SPECIAL, 11X28
Exhaust pipe (3) 3 / 23
CD3 Exhaust pipe (3)
CM1 Exhaust pipe (2.0L)
# OEM CD3 CM1
18 18393-SH3-S00 Gasket - PRE-CHAMBER (52.5MM-53.5MM) Gasket - PRE-CHAMBER (52.5MM-53.5MM)
27 90212-SA5-003 Nut - SELF-LOCK, 10MM Nut - SELF-LOCK, 10MM
30 91517-SE0-003 Clip - LOWER OUTER DASHBOARD INSULATOR Clip - LOWER OUTER DASHBOARD INSULATOR
Floor mat 2 / 14
CD3 Floor mat
CM1 Pedal (LH)
# OEM CD3 CM1
15 90301-SP0-003 Nut - PAINT CUTTING, 6MM Nut - PAINT CUTTING, 6MM
17 90610-SR3-003 Clip - GARNISH (KATO) Clip - GARNISH (KATO)
Front brake (14") 1 / 23
CD3 Front brake (14")
CM1 Front brake
# OEM CD3 CM1
21 90107-SM4-000 Bolt - CALIPER MOUNTING (12X21) Bolt - CALIPER MOUNTING (12X21)
Front bulkhead 1 / 2
CD3 Front bulkhead
CM1 Front bulkhead/dashboard
# OEM CD3 CM1
32 90105-SV1-000 Bolt-washer - 8X20 Bolt-washer - 8X20
Front combination light 2 / 12
CD3 Front combination light
CM1 Taillight/license light
# OEM CD3 CM1
2 33301-SA0-741 Bulb (12V 5W) - (12V 5W) (STANLEY) Bulb (12V 5W) - (12V 5W) (STANLEY)
4 33303-SL4-003 Bulb - WEDGE (12V 21W) (STANLEY) Bulb - WEDGE (12V 21W) (STANLEY)
Front door lining (RH) 2 / 13
CD3 Front door lining (RH)
CM1 Front door lining (LH)
# OEM CD3 CM1
22 90132-SS0-000 Screw - TAPPING, 4X10 (PO) Screw - TAPPING, 4X10 (PO)
26 91560-S84-A01 CLIP, DOOR LINING (NATURAL) CLIP, DOOR LINING (NATURAL)
Front door locks 4 / 37
CD3 Front door locks
CM1 Front door locks/outer ha ndle
# OEM CD3 CM1
5 72113-SR4-004 Snap - BLACK Snap - BLACK
46 90866-SA0-000 Grommet - SCREW, 4MM Grommet - SCREW, 4MM
47 90120-SV4-000 Bolt - LOCK STRIKER Bolt - LOCK STRIKER
53 91540-SV4-003 Clip - HARNESS BAND (NATURAL) (145.2MM) Clip - HARNESS BAND (NATURAL) (145.2MM)
Front door panels 2 / 20
CD3 Front door panels
CM1 Front door panels
# OEM CD3 CM1
26 91568-SR2-003 Clip - DOOR WEATHERSTRIP Clip - DOOR WEATHERSTRIP
26 91530-SP1-003 Clip A - DOOR WEATHERSTRIP Clip A - DOOR WEATHERSTRIP
Front door windows 1 / 11
CD3 Front door windows
CM1 Harness band/bracket (LH)
# OEM CD3 CM1
1 91540-SV4-003 Clip - HARNESS BAND (NATURAL) (145.2MM) Clip - HARNESS BAND (NATURAL) (145.2MM)
Front driveshaft 7 / 25
CD3 Front driveshaft
CM1 Front driveshaft/half sha ft (1)
# OEM CD3 CM1
7 44319-SE0-000 Set ring - 28X2.0 Set ring - 28X2.0
7 44319-S84-300 Set ring - 28X2.0 Set ring - 28X2.0
8 44327-SV4-305 Band - JOINT BOOT (DOUBLE ROLLED BAND) Band - JOINT BOOT (DOUBLE ROLLED BAND)
15 90102-SF1-000 Bolt - HEX., 10X1.25 Bolt - HEX., 10X1.25
16 90165-SE0-000 Bolt - FLANGE, 10X37 Bolt - FLANGE, 10X37
17 90305-SD4-003 Nut - SPINDLE (24MM) Nut - SPINDLE (24MM)
26 44329-SV4-305 Band - SHAFT BOOT (DOUBLE ROLLED BAND) Band - SHAFT BOOT (DOUBLE ROLLED BAND)
Front fenders 4 / 10
CD3 Front fenders
CM1 Front fenders
# OEM CD3 CM1
9 90114-SZ3-000 Screw-washer - 5X20 Screw-washer - 5X20
11 90657-SB0-003 Clip, SPLASH SHIELD Clip, SPLASH SHIELD
12 90682-SB0-003 Grommet - SCREW, 5MM Grommet - SCREW, 5MM
13 91512-SX0-003 Clip - INNER FENDER CLIP Clip - INNER FENDER CLIP
Front grille 1 / 5
CD3 Front grille
CM1 Bumpers
# OEM CD3 CM1
6 90682-SB0-003 Grommet - SCREW, 5MM Grommet - SCREW, 5MM
Front seat 5 / 10
CD3 Front seat
CM1 Front seat (L.; LH; 1)
# OEM CD3 CM1
1 04810-SB3-R00 C clip set - TRIM FASTENER (100 PIECES) C clip set - TRIM FASTENER (100 PIECES)
1 04810-SB3-000 C clip set - TRIM FASTENER (30 PIECES) C clip set - TRIM FASTENER (30 PIECES)
20 81322-SP0-003 Clip - LUMBAR SUPPORT Clip - LUMBAR SUPPORT
31 90134-SE3-003 Screw - TAPPING, 5X10 Screw - TAPPING, 5X10
35 91566-SP0-003 Clip - BACK COVER (NATURAL) Clip - BACK COVER (NATURAL)
Front shock absorber 4 / 24
CD3 Front shock absorber
CM1 Front shock absorber
# OEM CD3 CM1
9 51685-SH3-014 Plate - DUST COVER(SHOWA) Plate - DUST COVER(SHOWA)
12 51689-SH3-004 Plate - BUMP STOP (SHOWA) Plate - BUMP STOP (SHOWA)
14 51728-SB0-004 Collar - SHOCK ABSORBER MOUNTING (SHOWA) Collar - SHOCK ABSORBER MOUNTING (SHOWA)
16 90364-SG0-004 Nut - SELF-LOCK, 10MM (SHOWA) (NYLON) Nut - SELF-LOCK, 10MM (SHOWA) (NYLON)
Front stabilizer/ front lower arm 1 / 27
CD3 Front stabilizer/ front lower arm
CM1 Front stabilizer/ front lower arm
# OEM CD3 CM1
26 90215-SB0-003 Nut - SELF-LOCK, 12MM (SATO RASHI) (CLINCH) Nut - SELF-LOCK, 12MM (SATO RASHI) (CLINCH)
Front windshield wiper (2) 5 / 24
CD3 Front windshield wiper (2)
CM1 Front windshield wiper (LH)
# OEM CD3 CM1
4 76516-SM4-003 Rubber - MOUNTING Rubber - MOUNTING
5 76517-SM4-003 Collar Collar
8 76524-SD4-003 Dust seal Dust seal
9 76524-SE0-013 Dust seal Dust seal
20 90126-SR3-000 Bolt-washer - 6X32 Bolt-washer - 6X32
Fuel pipe (4) 1 / 26
CD3 Fuel pipe (4)
CM1 Brake lines (VSA; LH; 1)
# OEM CD3 CM1
20 90361-SV4-003 Nut - PAINT CUTTING, 6MM Nut - PAINT CUTTING, 6MM
Fuel tank (2) 3 / 38
CD3 Fuel tank (2)
CM1 Fuel tank
# OEM CD3 CM1
7 17525-SM4-000 Bolt-washer - 10X35 Bolt-washer - 10X35
40 90700-SB0-003 Clip - AIR BLEED TUBE Clip - AIR BLEED TUBE
43 91601-SH3-013 Grommet - SCREW, 5MM (BLACK) Grommet - SCREW, 5MM (BLACK)
Grommet 7 / 17
CD3 Grommet
CM1 Grommet (FRONT)
# OEM CD3 CM1
9 82871-671-000 Grommet - DRAIN HOLE, 25MM Grommet - DRAIN HOLE, 25MM
10 85268-SA0-000 Protection - TAILGATE, 20MM (CIRCLE) Protection - TAILGATE, 20MM (CIRCLE)
13 91602-SV4-003 Plug - HOLE, 15MM Plug - HOLE, 15MM
16 91606-SK7-003 Plug - BLIND, 25MM Plug - BLIND, 25MM
18 91611-SM4-003 Plug - FLOOR HOLE, 25MM Plug - FLOOR HOLE, 25MM
19 91611-SS0-003 Plug - HOLE, 25MM Plug - HOLE, 25MM
22 91619-SE0-000 Seal - DOOR HOLE, 30MM(BLACK) Seal - DOOR HOLE, 30MM(BLACK)
Headlight (2) 2 / 19
CD3 Headlight (2)
CM1 Headlight
# OEM CD3 CM1
4 33116-SD4-961 Socket - BULB (OSRAM) (HALOGEN) Socket - BULB (OSRAM) (HALOGEN)
10 33301-SA0-741 Bulb (12V 5W) - (12V 5W) (STANLEY) Bulb (12V 5W) - (12V 5W) (STANLEY)
Heater blower (2) 3 / 13
CD3 Heater blower (2)
CM1 Heater blower (LH)
# OEM CD3 CM1
12 90132-SR3-003 Screw - TAPPING, 5X16 Screw - TAPPING, 5X16
13 90133-SR3-003 Screw-washer - 4X16 Screw-washer - 4X16
15 90321-SV4-003 Nut-washer - 6MM (PAINT CUTTING) Nut-washer - 6MM (PAINT CUTTING)
Heater unit (2) 2 / 14
CD3 Heater unit (2)
CM1 Heater unit (LH)
# OEM CD3 CM1
11 79770-SE0-000 Grommet - WATER VALVE CABLE Grommet - WATER VALVE CABLE
15 90133-SR3-003 Screw-washer - 4X16 Screw-washer - 4X16
Instrument panel (RH) 5 / 13
CD3 Instrument panel (RH)
CM1 Instrument panel (LH)
# OEM CD3 CM1
5 66844-SA7-000 Cap - INSTRUMENT PANEL STAY Cap - INSTRUMENT PANEL STAY
25 90104-SV4-000 Bolt-washer - 8X25 Bolt-washer - 8X25
29 90361-SR3-000 Nut - FLANGE, 8MM Nut - FLANGE, 8MM
31 91640-SM4-003 Grommet - SCREW, 4MM Grommet - SCREW, 4MM
32 91641-SM4-003 Grommet - SCREW, 4MM Grommet - SCREW, 4MM
Instrument panel garnish (RH) 4 / 32
CD3 Instrument panel garnish (RH)
CM1 Instrument panel (LH)
# OEM CD3 CM1
8 66418-579-000 Stopper - GLOVE BOX LID Stopper - GLOVE BOX LID
38 90302-SA4-003 Nut - SPRING, 4MM Nut - SPRING, 4MM
40 90321-SP0-A80 Nut-washer - 6MM Nut-washer - 6MM
46 91641-SM4-003 Grommet - SCREW, 4MM Grommet - SCREW, 4MM
Interior light 2 / 8
CD3 Interior light
CM1 Interior light
# OEM CD3 CM1
5 34253-671-003 Bulb - 12V 8W)(DAIICHI Bulb - 12V 8W)(DAIICHI
5 04110-SWA-305 BULB T10X318W BULB T10X318W
Knuckle 2 / 12
CD3 Knuckle
CM1 Front knuckle/upper arm
# OEM CD3 CM1
8 52226-SL0-003 Circlip - LOWER BALL(MUSASHI) Circlip - LOWER BALL(MUSASHI)
15 90215-SB0-003 Nut - SELF-LOCK, 12MM (SATO RASHI) (CLINCH) Nut - SELF-LOCK, 12MM (SATO RASHI) (CLINCH)
Mainshaft 3 / 19
CD3 Mainshaft
CM1 Mainshaft (2.0L; 5MT)
# OEM CD3 CM1
16 23927-PG2-A00 Washer - SPRING, 28MM Washer - SPRING, 28MM
17 23928-PS1-000 Washer - 28MM Washer - 28MM
19 90401-PG1-000 Washer - DRAIN PLUG, 10MM Washer - DRAIN PLUG, 10MM
Mirror 1 / 15
CD3 Mirror
CM1 Mirror
# OEM CD3 CM1
28 90615-SK7-003 Clip - MIRROR GARNISH Clip - MIRROR GARNISH
Oil pump/oil strainer 2 / 28
CD3 Oil pump/oil strainer
CM1 Oil pump (2.0L)
# OEM CD3 CM1
13 15400-RTA-003 OIL FILTER (MAHLE TENNEX) OIL FILTER (MAHLE TENNEX)
17 90015-PH1-013 Holder - OIL FILTER Holder - OIL FILTER
Parking brake 4 / 11
CD3 Parking brake
CM1 Parking brake (LH)
# OEM CD3 CM1
6 47360-SB2-000 Equalizer Equalizer
7 47365-538-000 Pin - EQUALIZER Pin - EQUALIZER
10 47522-594-000 Nut - PARKING BRAKE ADJUSTING Nut - PARKING BRAKE ADJUSTING
11 47537-671-670 Spring - PARKING BRAKE ROD Spring - PARKING BRAKE ROD
Pedal 5 / 28
CD3 Pedal
CM1 Pedal (LH)
# OEM CD3 CM1
21 46505-SA5-000 Pad - PEDAL STOPPER Pad - PEDAL STOPPER
22 46505-SA7-000 Pad - PEDAL STOPPER Pad - PEDAL STOPPER
25 46545-SA5-000 Cover, Pedal Cover, Pedal
30 46911-SD4-930 Bush - PEDAL PIN Bush - PEDAL PIN
38 75891-611-000 Cover - DOOR SWITCH Cover - DOOR SWITCH
Pillar garnish (RH) 2 / 4
CD3 Pillar garnish (RH)
CM1 Seatbelts
# OEM CD3 CM1
22 90610-SR3-003 Clip - GARNISH (KATO) Clip - GARNISH (KATO)
23 90666-SM4-003 Clip - SNAP FITTING Clip - SNAP FITTING
Power steering lines (RH) 6 / 26
CD3 Power steering lines (RH)
CM1 P.s. lines (LH)
# OEM CD3 CM1
1 53697-SB3-952 Cap - OIL TANK Cap - OIL TANK
11 53729-671-003 Clamp d - 15.5MM Clamp d - 15.5MM
17 53736-SH3-950 Holder b - POWER STEERING PIPE Holder b - POWER STEERING PIPE
23 90635-SM4-A02 Clip - OIL HOSE (MEIJI) Clip - OIL HOSE (MEIJI)
25 91370-SV4-000 O-ring - 14.4X1.9 O-ring - 14.4X1.9
26 91405-SS0-003 Clamp - TUBE (D21) Clamp - TUBE (D21)
Power steering pump 1 / 18
CD3 Power steering pump
CM1 Power steering pump
# OEM CD3 CM1
12 91345-PY3-000 O-ring - 13.0X1.9 O-ring - 13.0X1.9
Protector 4 / 19
CD3 Protector
CM1 Bumpers
# OEM CD3 CM1
18 90114-SZ3-000 Screw-washer - 5X20 Screw-washer - 5X20
23 90682-SB0-003 Grommet - SCREW, 5MM Grommet - SCREW, 5MM
24 91512-SX0-003 Clip - INNER FENDER CLIP Clip - INNER FENDER CLIP
25 91513-SM4-000 Clip - SIDE SILL UPPER GARNISH Clip - SIDE SILL UPPER GARNISH
Radiator (TOYO) 5 / 18
CD3 Radiator (TOYO)
CM1 Radiator (2.0L)
# OEM CD3 CM1
2 19011-PH2-004 Cock - DRAIN (T.RAD) Cock - DRAIN (T.RAD)
3 19012-PD2-004 Packing - DRAIN (T.RAD) Packing - DRAIN (T.RAD)
14 90041-PG6-004 Nut - HEX., 5MM(MITSUBA) Nut - HEX., 5MM(MITSUBA)
15 90042-PZ1-004 Bolt-washer - 6X20 Bolt-washer - 6X20
16 90050-PK1-004 Screw-washer - 4X12(T.RAD) Screw-washer - 4X12(T.RAD)
Radiator hose 4 / 15
CD3 Radiator hose
CM1 Radiator hose/reserve tan k
# OEM CD3 CM1
3 19102-PM5-A00 Cap - RESERVE TANK Cap - RESERVE TANK
10 19511-PH7-003 Clip, HOSE(36.5MM) (CHUO SPRING) Clip, HOSE(36.5MM) (CHUO SPRING)
11 19511-PT0-004 Clip - WATER HOSE (36.5MM) (KEIHIN) Clip - WATER HOSE (36.5MM) (KEIHIN)
23 74173-SJ4-000 Cushion - RADIATOR MOUNTING UPPER Cushion - RADIATOR MOUNTING UPPER
Radio antenna/speaker 1 / 18
CD3 Radio antenna/speaker
CM1 Harness band/bracket (LH)
# OEM CD3 CM1
2 32134-SM4-003 Band - HARNESS OFFSET (10) (BROWN) (122.5MM) Band - HARNESS OFFSET (10) (BROWN) (122.5MM)
Rear brake (DRUM) 4 / 39
CD3 Rear brake (DRUM)
CM1 Parking brake shoe
# OEM CD3 CM1
29 43375-SA0-003 U-clip U-clip
32 43379-SA5-003 Washer - WAVE Washer - WAVE
36 90113-SA0-025 Bolt - WHEEL (NAGOYA RASHI) Bolt - WHEEL (NAGOYA RASHI)
36 90113-SM1-005 Bolt - WHEEL (ROCKNEL FASTENER) Bolt - WHEEL (ROCKNEL FASTENER)
Rear door lining 3 / 14
CD3 Rear door lining
CM1 Front door lining (LH)
# OEM CD3 CM1
16 90132-SS0-000 Screw - TAPPING, 4X10 (PO) Screw - TAPPING, 4X10 (PO)
18 90615-SK7-003 Clip - MIRROR GARNISH Clip - MIRROR GARNISH
21 91560-S84-A01 CLIP, DOOR LINING (NATURAL) CLIP, DOOR LINING (NATURAL)
Rear door locks 5 / 33
CD3 Rear door locks
CM1 Front door locks/outer ha ndle
# OEM CD3 CM1
1 32132-SM4-003 Band - WIRE HARNESS OFFSET (20) (BLACK) (122.5MM) Band - WIRE HARNESS OFFSET (20) (BLACK) (122.5MM)
11 72139-SR0-A01 Snap - VIOLET Snap - VIOLET
33 90866-SA0-000 Grommet - SCREW, 4MM Grommet - SCREW, 4MM
34 90120-SV4-000 Bolt - LOCK STRIKER Bolt - LOCK STRIKER
38 91545-SV4-003 Clip - HARNESS BAND (NATURAL) (145.2MM) (WITH SEAL) Clip - HARNESS BAND (NATURAL) (145.2MM) (WITH SEAL)
Rear door panels 3 / 17
CD3 Rear door panels
CM1 Front door panels
# OEM CD3 CM1
22 75891-SA7-000 Stopper - DOOR Stopper - DOOR
25 91568-SR2-003 Clip - DOOR WEATHERSTRIP Clip - DOOR WEATHERSTRIP
25 91530-SP1-003 Clip A - DOOR WEATHERSTRIP Clip A - DOOR WEATHERSTRIP
Rear seat (2) 2 / 10
CD3 Rear seat (2)
CM1 Front seat (L.; LH; 1)
# OEM CD3 CM1
1 04810-SB3-R00 C clip set - TRIM FASTENER (100 PIECES) C clip set - TRIM FASTENER (100 PIECES)
1 04810-SB3-000 C clip set - TRIM FASTENER (30 PIECES) C clip set - TRIM FASTENER (30 PIECES)
Rear shock absorber 2 / 23
CD3 Rear shock absorber
CM1 Rear shock absorber
# OEM CD3 CM1
5 52621-SB2-004 Washer - RR. SHOCK ABSORBER MOUNTING (SHOWA) Washer - RR. SHOCK ABSORBER MOUNTING (SHOWA)
16 90364-SG0-004 Nut - SELF-LOCK, 10MM (SHOWA) (NYLON) Nut - SELF-LOCK, 10MM (SHOWA) (NYLON)
Rear stabilizer/ rear lower arm 5 / 55
CD3 Rear stabilizer/ rear lower arm
CM1 Rear lower arm
# OEM CD3 CM1
1 51464-S04-013 Boot, UPPER BALL JOINT Boot, UPPER BALL JOINT
19 52338-SL0-003 Circlip - CONTROL ARM Circlip - CONTROL ARM
44 90026-SM4-000 Bolt b - TRAILING ARM (10X45) Bolt b - TRAILING ARM (10X45)
45 90028-SM4-000 Bolt - TRAILING, 8X19 Bolt - TRAILING, 8X19
50 90215-SB0-003 Nut - SELF-LOCK, 12MM (SATO RASHI) (CLINCH) Nut - SELF-LOCK, 12MM (SATO RASHI) (CLINCH)
Rear tray/side lining 1 / 3
CD3 Rear tray/side lining
CM1 Seatbelts
# OEM CD3 CM1
20 90610-SR3-003 Clip - GARNISH (KATO) Clip - GARNISH (KATO)
Resonator chamber 4 / 11
CD3 Resonator chamber
CM1 Air cleaner
# OEM CD3 CM1
1 17212-P2J-J00 Rubber, AIR CLEANER MOUNTING Rubber, AIR CLEANER MOUNTING
2 17213-PV0-000 Rubber - AIR CLEANER CASE MOUNTING Rubber - AIR CLEANER CASE MOUNTING
3 17216-PN3-000 Collar - AIR CLEANER MOUNTING Collar - AIR CLEANER MOUNTING
10 90001-P0A-000 Bolt-washer - SPECIAL, 6X35 Bolt-washer - SPECIAL, 6X35
Roof lining (RH) 2 / 13
CD3 Roof lining (RH)
CM1 Side lining
# OEM CD3 CM1
3 75353-671-000 Lock - SCREW Lock - SCREW
22 90133-SM4-003 Bolt-washer - 5X16 Bolt-washer - 5X16
Roof slide components 1 / 26
CD3 Roof slide components
CM1 Harness band/bracket (LH)
# OEM CD3 CM1
27 91555-SM4-003 Clip - COUPLER (RED) Clip - COUPLER (RED)
Shift arm/shift lever 1 / 17
CD3 Shift arm/shift lever
CM1 Shift fork (2.0L; 5MT)
# OEM CD3 CM1
12 90028-PB6-010 Bolt - SPECIAL, 6X22.5 Bolt - SPECIAL, 6X22.5
Shift fork 2 / 8
CD3 Shift fork
CM1 Shift fork (2.0L; 5MT)
# OEM CD3 CM1
7 24519-PB6-000 Screw - BALL SPRING SETTING Screw - BALL SPRING SETTING
8 90028-PB6-010 Bolt - SPECIAL, 6X22.5 Bolt - SPECIAL, 6X22.5
Shift lever 5 / 27
CD3 Shift lever
CM1 Shift lever (LH)
# OEM CD3 CM1
22 54357-SF1-003 Plate - CHANGE WIRE Plate - CHANGE WIRE
27 90555-SF1-000 Washer a - SHIFT WIRE(1.6MM) Washer a - SHIFT WIRE(1.6MM)
28 90556-SF1-000 Washer b - SHIFT WIRE (0.5MM) Washer b - SHIFT WIRE (0.5MM)
29 90557-SF1-000 Washer a - SELECT WIRE (1.6MM) Washer a - SELECT WIRE (1.6MM)
30 90558-SF1-000 Washer b - SELECT WIRE (0.5MM) Washer b - SELECT WIRE (0.5MM)
Steering column 1 / 10
CD3 Steering column
CM1 Steering column
# OEM CD3 CM1
15 90511-671-003 Washer - TOOTHED LOCK Washer - TOOTHED LOCK
Taillight (2) 2 / 26
CD3 Taillight (2)
CM1 Taillight/license light
# OEM CD3 CM1
1 33301-SA0-741 Bulb (12V 5W) - (12V 5W) (STANLEY) Bulb (12V 5W) - (12V 5W) (STANLEY)
3 33303-SL4-003 Bulb - WEDGE (12V 21W) (STANLEY) Bulb - WEDGE (12V 21W) (STANLEY)
Tire/wheel disk 1 / 36
CD3 Tire/wheel disk
CM1 Tire/wheel disks
# OEM CD3 CM1
10 42753-SB8-661 Valve - RIM (SCHRADER) Valve - RIM (SCHRADER)
Tools/jack 2 / 10
CD3 Tools/jack
CM1 Tools/jack
# OEM CD3 CM1
5 89211-S05-003 Wrench - WHEEL Wrench - WHEEL
10 89320-S05-003 Bar - JACK Bar - JACK
Transmission housing 1 / 53
CD3 Transmission housing
CM1 Transmission case
# OEM CD3 CM1
11 90081-PB6-000 Bolt - PLUG, 14MM Bolt - PLUG, 14MM
Trunk lid ('96/'97) 2 / 31
CD3 Trunk lid ('96/'97)
CM1 Engine hood (LH)
# OEM CD3 CM1
1 17706-SC3-003 Clip - FUEL PIPE Clip - FUEL PIPE
30 85268-SA0-000 Protection - TAILGATE, 20MM (CIRCLE) Protection - TAILGATE, 20MM (CIRCLE)
Valve/rocker arm (SOHC) 3 / 17
CD3 Valve/rocker arm (SOHC)
CM1 Valve/rocker arm (2.0L)
# OEM CD3 CM1
9 14744-PT0-004 Screw - TAPPET ADJUSTING Screw - TAPPET ADJUSTING
13 14775-PT0-000 Seat - VALVE SPRING Seat - VALVE SPRING
15 90206-PT0-004 Nut - TAPPET ADJUSTING Nut - TAPPET ADJUSTING
Water pump/sensor (SOHC) 4 / 30
CD3 Water pump/sensor (SOHC)
CM1 Radiator (2.0L)
# OEM CD3 CM1
16 37760-P00-003 Switch assy, THERMO (A-93) (NIPPON THERMOSTAT) Switch assy, THERMO (A-93) (NIPPON THERMOSTAT)
16 37760-P00-004 Switch assy - THERMO (A-93) (UCHIYA THERMOSTAT) Switch assy - THERMO (A-93) (UCHIYA THERMOSTAT)
23 91307-PN4-000 O-ring - 17.5X1.4 O-ring - 17.5X1.4
23 91307-PN3-000 O-ring,17.8x1.4 O-ring,17.8x1.4
Water valve 2 / 7
CD3 Water valve
CM1 Water valve (LH)
# OEM CD3 CM1
6 91405-PK1-003 Clip, WATER HOSE, 24MM Clip, WATER HOSE, 24MM
6 19513-PE0-003 Clamp - WATER HOSE (21.7MM) (CHUO SPRING) Clamp - WATER HOSE (21.7MM) (CHUO SPRING)
Windshield washer 4 / 18
CD3 Windshield washer
CM1 Windshield washer (1)
# OEM CD3 CM1
5 38562-SA0-003 Joint l - WASHER TUBE(MITSUBA) Joint l - WASHER TUBE(MITSUBA)
8 76809-SE0-003 Grommet - WASHER TANK Grommet - WASHER TANK
15 38519-SB0-003 Bush - WASHER TANK (MITSUBA) Bush - WASHER TANK (MITSUBA)
16 90652-SB2-023 Clip - TUBE, 7MM Clip - TUBE, 7MM
Wire harness (2) 12 / 37
CD3 Wire harness (2)
CM1 Harness band/bracket (LH)
# OEM CD3 CM1
10 32134-SM4-003 Band - HARNESS OFFSET (10) (BROWN) (122.5MM) Band - HARNESS OFFSET (10) (BROWN) (122.5MM)
12 32146-SH3-003 Connector - DIODE(2P) Connector - DIODE(2P)
23 90148-SE0-003 Bolt - EARTH, 6X16 (WASHER 12.5MM) (ZN) Bolt - EARTH, 6X16 (WASHER 12.5MM) (ZN)
24 90149-SE0-003 Bolt - EARTH, 6X16 Bolt - EARTH, 6X16
26 91507-693-003 Clip - WIRE HARNESS (BLACK) (50MM) (HARNESS TAPING) Clip - WIRE HARNESS (BLACK) (50MM) (HARNESS TAPING)
27 91533-S04-003 Clip - COUPLER (NATURAL) Clip - COUPLER (NATURAL)
29 91545-SV4-003 Clip - HARNESS BAND (NATURAL) (145.2MM) (WITH SEAL) Clip - HARNESS BAND (NATURAL) (145.2MM) (WITH SEAL)
34 91551-SF4-003 Band - WIRE HARNESS(BROWN) (110MM) Band - WIRE HARNESS(BROWN) (110MM)
35 91551-SW5-003 Clip - HARNESS BAND (BROWN) (151MM) Clip - HARNESS BAND (BROWN) (151MM)
38 91555-SM4-003 Clip - COUPLER (RED) Clip - COUPLER (RED)
40 91559-SE3-003 Clip - WIRE HARNESS (WHITE) (55MM) Clip - WIRE HARNESS (WHITE) (55MM)
48 91540-S30-003 Clip - HARNESS BAND(NATURAL) (151.5MM) Clip - HARNESS BAND(NATURAL) (151.5MM)
