LY102

Toyota DYNA-150-TOYOACE-G15 · 1999 · 3,965 parts · 201 categories
LY102 ×
3,965 items
Accelerator Link ([05.1995 - ] (9505- )DSL,LPG) 33
#OEMPart name
78100 78100-25011 Link Assy, Accelerator
78104 78104-22140 Rod Sub-Assy, Accelerator Connecting, No.2
78111 78110-95410 Pedal, Accelerator
78120 78202-95010 Link, Accelerator
78150 78150-25080 Wire Assy, Accelerator Flexible
78183 78183-25050 Clamp, Accelerator Control Cable
78183 78183-25020 Clamp, Accelerator Control Cable
78183 78183-95A12 Clamp, Accelerator Control Cable
78184 78183-95406 Clamp, Accelerator Control Cable
78189 78208-37010 Bolt, Accelerator Pedal Stopper
78189 78208-95404 Bolt, Accelerator Pedal Stopper
78410 78404-37050 Rod Sub-Assy, Throttle
78410 78404-37020 Cable Assy, Throttle Control
78410 78411-22010 Knob, Throttle Cable
78410 78314-95010 Nut, Choke
78411 78411-95J01 Knob, Throttle Cable
78472 78472-25011 Support, Throttle Control Cable
78472 78472-95700-B0 Support, Throttle Control Cable
78472 78472-95700-C0 Support, Throttle Control Cable
7818325030 78183-25030 Clamp, Accelerator Control Cable
9011608039 90116-08039 Bolt(For Manual Transmission Oil Pan Setting)
9017908150 90179-08150 NUT
9046804099 90468-04099 New Genuine Part
9095901216 90959-01216 New Genuine Part
9161160812 91611-60812 Bolt(For Drive Plate & Torque Converter Setting)
9161160812 91611-B0812 Bolt
9161260814 91612-60814 Bolt(For Dust Cover To Steering Knuckle Arm Setting)
9161260814 91611-60814 Bolt
9165140816 91651-40816 BOLT
9165160618 91651-60618 Bolt(For Oil Receiver Pipe)
9165160814 91651-60814 Clamp Or Clip, Hose(for Radiator Outlet No.1)
9165160814 91651-B0814 Bolt with washer
9338526020 93385-26020 New Genuine Part
Air Bag ([05.1995 - ] (9505- )) 6
#OEMPart name
89170 89170-37010 Sensor Assy, Air Bag
89176 89176-37010 Label, Air Bag Sensor Cover Caution
89179 89179-37010-B0 Cover, Air Bag Sensor
9011906327 90119-06327 New Genuine Part
9011906327 90119-06324 Bolt
9014880005 90148-80005 New Genuine Part
Air Cleaner ([10.1996 - ] (9610- )3L,5L..LY10#,11#,12#,13#,15#,16#) 28
#OEMPart name
17700 17700-54790 Cleaner Assy, Air
17700 17700-54791 Cleaner Assy, Air
17700 90175-08008 Nut, Wing(For Air Cleaner)
17705 17705-54260 Cap Sub-Assy, Air Cleaner
17736 90175-06003 Nut, Wing(For Air Cleaner)
17771 17771-54090 Bracket, Air Cleaner Inlet Duct
17801 17801-56020 Element Sub-Assy, Air Cleaner Filter
17805 17805-54142 Pipe Sub-Assy, Air Cleaner, No.1
17805 17805-54260 Resonator Sub-Assy, Intake Air
17807 17807-58010 Plate Sub-Assy, Air Cleaner Filter Set
17841 17841-44030 Gasket, Filter Element
17845 17845-56020 Gasket, Air Cleaner Cap
17881 17881-54530 Hose, Air Cleaner, No.1
17881 96111-10690 Clamp, Hose
17881 96111-10830 Clamp, Hose(For Air Connector)
17882 17882-54220 Hose, Air Cleaner, No.2
17882 96111-10750 Clamp, Hose(For Air Cleaner Duct)
17893 17805-54300 Resonator, Intake Air
53097 53097-25090 Inlet Sub-Assy
53709 53709-25030 Cover Sub-Assy, Air Cleaner Inlet
9011908 90119-08A46 BOLT WWASHER
9162160820 91621-60820 New Genuine Part
9162160820 91651-B0822 BOLT WWASHER
9163260828 91632-60828 New Genuine Part
9163260828 91631-60828 BOLT WWASHER
9165160820 91651-60820 Bolt, Radiator Side Support Plate
9165160820 91651-B0820 Bolt, Radiator Side Support Plate
904670707222 90467-07072-22 Clip (For Roof Side Garnish)
Alternator ([05.1999 - ] 12V 55A (9905- )5L) 33
#OEMPart name
27020 27060-54330 Alternator Assy
27020 90105-10287 Bolt(For Alternator)
27039 27039-16380 Cover, Alternator Rear End
27310 27310-54440 Frame Assy, Drive End, Alternator
27310 27310-54450 Frame Assy, Drive End, Alternator
27310 90099-10165 Bearing(For Alternator Drive End Frame)
27312 27312-64130 Plate, Bearing Retainer, Alternator
27330 27330-64130 Rotor Assy, Alternator
27330 90099-10140 Bearing(For Alternator Rotor)
27357 27357-13360 Holder, Alternator, W/rectifier
27359 27359-16182 Frame, Alternator Rectifier End
27370 27370-58320 Holder Assy, Alternator Brush
27371 27371-70300 Brush, Alternator
27372 27372-63020 Spring, Alternator Brush
27372 27372-87501 Spring, Alternator Brush
27384 27384-16380 Washer
27387 27387-70171 Insulator, Terminal
27389 27389-63020 Insulator, Terminal
27443 27443-63020 Cover, Alternator Bearing
27700 27700-50030 Regulator Assy, Generator
29341 29341-64130 Seal, Alternator Oil
2744554450 27445-54450 New Genuine Part
9009900167 90099-00167 New Genuine Part
9009900197 90099-00197 Screw
9009900243 90099-00243 SCREW WWASHER
9009900269 90099-00269 New Genuine Part
9009900276 90099-00276 New Genuine Part
9009904478 90099-04478 New Genuine Part
9009904966 90099-04966 Bearing(for Alternator Rotor)
9009905119 90099-05119 New Genuine Part
9009905172 90099-05172 New Genuine Part
9011908654 90119-08654 BOLT WWASHER
9017906158 90179-06158 Nut, Rear Wiper Link Pivot, No.2
Alternator ([05.1999 - ] 12V 90A (9905- )5L) 26
#OEMPart name
27020 27060-54330 Alternator Assy
27020 90105-10287 Bolt(For Alternator)
27039 27039-16380 Cover, Alternator Rear End
27310 27310-54440 Frame Assy, Drive End, Alternator
27310 27310-54450 Frame Assy, Drive End, Alternator
27310 90099-10165 Bearing(For Alternator Drive End Frame)
27330 27330-64130 Rotor Assy, Alternator
27330 90099-10140 Bearing(For Alternator Rotor)
27357 27357-13360 Holder, Alternator, W/rectifier
27359 27359-16182 Frame, Alternator Rectifier End
27384 27384-16380 Washer
27387 27387-70171 Insulator, Terminal
27389 27389-63020 Insulator, Terminal
27443 27443-63020 Cover, Alternator Bearing
27700 27700-50030 Regulator Assy, Generator
29341 29341-64130 Seal, Alternator Oil
2744554450 27445-54450 New Genuine Part
9009900167 90099-00167 New Genuine Part
9009900197 90099-00197 Screw
9009900243 90099-00243 SCREW WWASHER
9009900246 90099-00246 New Genuine Part
9009904966 90099-04966 Bearing(for Alternator Rotor)
9009905119 90099-05119 New Genuine Part
9009905172 90099-05172 New Genuine Part
9011908654 90119-08654 BOLT WWASHER
9331914025 93319-14025 Screw W Washer
Antenna ([05.1995 - ] (9505- )) 7
#OEMPart name
86300 86300-37040 Antenna Assy, W/holder
86391 86391-37020 Holder, Antenna
9015740016 90157-40016 New Genuine Part
9017905032 90179-05032 NUT
9017905032 90179-05011 NUT
9090480002 90904-80002 New Genuine Part
9321915020 93219-15020 New Genuine Part
Armrest & Visor ([05.1995 - ] (9505- )) 29
#OEMPart name
61169 61169-95400 Spacer, Antenna Holder
63273 63273-95701 Retainer, Quarter Or Side Window Hinge
63787 63787-95400 Pad, Roof Air Deflector, No.1
74035 74035-95402 Front Visor Set
74306 74306-95400 Support, Sub-Assy, Front Visor
74310 74310-25010-B0 Visor Assy, Rh
74310 74310-37020-B0 Visor Assy, Rh
74318 74318-25010-B0 Cover, Visor Bracket, Lh
74320 74320-25010-B0 Visor Assy, Lh
74321 74321-95402 Visor, Front
74325 74325-95401 Support, Front Visor, No.1
74326 74326-95400 Support, Front Visor, No.2
74327 74327-95400 Pad, Front Visor, No.1
74329 74329-95400 Pad, Front Visor, No.3
74348 74348-25010-B0 Holder, Visor
74356 74356-25010-B0 Cover, Visor Holder Hole
74610 74610-95404-B0 Grip Sub-Assy, Assist
74611 74611-92601-B0 Grip, Assist
74617 74617-95J00-B0 Plug, Assist Grip
74631 74348-12010-B0 Holder, Visor
74811 74811-87001-B0 Pull Assy, Door, Inside
9015260015 90152-60015 SCREW CROSSRECESS
9015480007 90154-80007 New Genuine Part
9015960162 90159-60162 SCREW
9015960243 90159-60243 New Genuine Part
9016750032 90167-50032 New Genuine Part
9038511005 90385-11005 BUSH
9324056012 93240-56012 New Genuine Part
9356054012 93560-54012 Screw
Ash Receptacle ([05.1995 - ] (9505- )) 5
#OEMPart name
74102 74102-12220 Receptacle Assy, Front Ash
74104 74104-37010 Retainer Sub-Assy, Front Ash Receptacle
9323954020 93239-54020 New Genuine Part
9356715016 93567-15016 New Genuine Part
9356715016 93568-55016 Screw
Battery & Battery Cable ([05.1995 - ] (9505- )) 31
#OEMPart name
28800 90982-05050 Terminal, Battery Positive
28800 90982-05068 Terminal, Battery Positive
28800 82021-26112 Cable, Battery To Starter(For Battery To Main Switch)
28800 82021-26153 Cable, Battery To Starter(For Battery To Main Switch)
28800 90982-06031 Terminal, Battery Negative
28800 90982-06060 Terminal, Battery Negative
28800 82021-26131 Cable, Battery To Starter(For Battery To Main Switch)
28897 28897-54030 Plate, Battery Caution
8271195 82711-95A07 Wire, Fuse To Fuse(for Combustion Heater)
8271195 82711-95A08 Wire, Fuse To Fuse(for Combustion Heater)
8271112200 82711-12200 Clamp (For Fuel Lid Lock Control Cable)
8271122270 82711-22270 Clamp(For Transfer Vacuum Tube)
8271137050 82711-37050 Wire, Fuse To Fuse(for Combustion Heater)
8271140020 82711-40020 Wire, Fuse To Fuse(for Combustion Heater)
8271195404 82711-95404 Wire, Fuse To Fuse(for Combustion Heater)
8271195411 82711-95411 Clamp(For Vacuum Tube Connector Hose)
9011908826 90119-08826 BOLT
9011908827 90119-08827 New Genuine Part
9017908144 90179-08144 New Genuine Part
9017908144 90179-08233 NUT
9046110294 90461-10294 Wire, Fuse To Fuse(for Combustion Heater)
9046110294 82711-37290 Wire, Fuse To Fuse(for Combustion Heater)
9046112146 90461-12146 New Genuine Part
9046308121 90463-08121 New Genuine Part
9161160814 91611-60814 Bolt
9165160816 91651-60816 BOLT
9165160816 90080-11396 Bolt
9165160820 91651-60820 Bolt, Radiator Side Support Plate
9165160820 91651-B0820 Bolt, Radiator Side Support Plate
9165160830 91651-60830 Bolt (For Transfer Power Take-Off Cover)
9165161016 91651-61016 Bolt
Battery Carrier ([05.1995 - ] (9505- )LY10#,11#,12#,13#,15#,16#,YY101,121,1 31) 13
#OEMPart name
74411 74401-26040 Bracket, Battery, Front
74412 74402-26040 Bracket, Battery, Rear
74413 74451-36070 Bolt, Battery Clamp
74417 74417-26090 Bracket, Battery Carrier
74421 74421-36091 Carrier, Battery
74453 74453-25100 Bar, Battery Set Plate
74453 74453-36070 Bar, Battery Set Plate
74453 74453-37131 Bar, Battery Set Plate
9011908676 90119-08676 BOLT WWASHER
9011910571 90119-10571 New Genuine Part
9017906158 90179-06158 Nut, Rear Wiper Link Pivot, No.2
9017908141 90179-08141 Nut (For Transmission Control Cable)
9017908141 90179-08038 Nut
Battery Carrier ([10.1996 - ] (9610- )LY10#,11#,12#,13#,15#,16#) 12
#OEMPart name
74042 74042-26010 Bracket Sub-Assy, Battery
74413 74451-36070 Bolt, Battery Clamp
74417 74417-26090 Bracket, Battery Carrier
74453 74453-25100 Bar, Battery Set Plate
74453 74453-36070 Bar, Battery Set Plate
74453 74453-37131 Bar, Battery Set Plate
74461 74461-36100 Cover, Battery
74481 74481-36030 Clamp Sub-Assy, Battery Cover
9011908676 90119-08676 BOLT WWASHER
9011910571 90119-10571 New Genuine Part
9017908141 90179-08141 Nut (For Transmission Control Cable)
9017908141 90179-08038 Nut
Body Stripe ([05.1995 - ] (9505- )) 2
#OEMPart name
75985 75985-37010 Stripe, Front Door, Rh
75986 75986-37010 Stripe, Front Door, Lh
Brake Band & Multiple Disc Clutch (Atm) ([05.1995 - ] A42D,A43D,A44DE,A44DF (9505- )YY211..WT..125 ; (9505- )LY10#,11# ,16#..ATM) 34
#OEMPart name
35601 90301-56007 Ring, O (For Underdrive Clutch Piston)
35602 35602-30042 Piston Sub-Assy, Front Clutch
35603 35603-22030 Spring Sub-Assy, Forward Clutch Return
35604 35603-22010 Spring Sub-Assy, Forward Clutch Return
35605 35605-22011 Drum Sub-Assy, Rear Clutch W/2Nd Sun Gear
35606 35606-22010 Piston Sub-Assy, Rear Clutch
35610 90520-39261 Ring, Shaft Snap (For Front Clutch Piston Return Spring)
35610 90520-99012 Ring, Hole Snap (For Front Multiple Disc Clutch)
35613 90301-99058 Ring, O (For Overdrive Direct Clutch Piston)
35631 35631-30050 Hub, Clutch(For Multiple Disc Clutch)
35631 35631-43010 Hub, Clutch(For Multiple Disc Clutch)
35631 90374-28014 Bearing, Thrust Needle Roller(For Overdrive)
35631 35789-22050 Race, Thrust Bearing (For Rear Planetary Ring Gear Front)
35631 35789-22020 Race, Thrust Bearing (For Rear Planetary Ring Gear Rear)
35631 35789-43010 Race, Thrust Bearing (For Rear Planetary Ring Gear Rear)
35633 35677-22080 Disc, Clutch (For Front Clutch)
35634 35634-22040 Plate, Clutch (For Overdrive)
35634 35634-30070 Plate, Clutch (For Overdrive)
35650 90521-99139 Ring, Hole Snap (For Overdrive Brake Return Spring Seat)
35652 35602-30041 Piston Sub-Assy, Front Clutch
35653 90301-83001 Ring, O (For Rear Clutch Piston)
35654 35654-30010 Hub, Rear Clutch
35654 90521-99146 Ring, Hole Snap, No.1 (For Overdrive)
35674 35634-30090 Plate, Front Clutch
35674 35634-30120 Plate, Front Clutch
35675 35675-22010 Flange, Overdrive Clutch
35675 35675-22140 Flange, Overdrive Clutch
35675 35675-22120 Flange, Rear Clutch
35675 35675-22130 Flange, Rear Clutch
35675 35675-30020 Flange, Rear Clutch
35675 35675-30030 Flange, Rear Clutch
35701 35701-30043 Shaft Sub-Assy, Input
35701 90374-23012 Bearing, Thrust Needle Roller(For Overdrive Planetary Gear)
35701 35789-22010 Race, Thrust Bearing(For Overdrive Planetary Gear)
Brake Booster & Vacuum Tube ([10.1996 - ] (9610- )LY10#,11#,15# ; (9610- )LY16#..T2, T3,TW1..TS) 19
#OEMPart name
44610 44610-25240 Booster Assy, Brake
44704 44704-25100 Reservoir Sub-Assy, Vacuum
44730 44730-60050 Valve Assy, Vacuum Check(For Clutch Vacuum)
44743 90904-05008 Union(For Vacuum Pump)
44743 90904-05009 Union(For Vacuum Pump)
44761 44761-25110 Tube, Intake Manifold Or Vacuum Pump To Connector
44764 90445-17141 Hose, No.2(For Clutch Booster Vacuum)
44768 44768-25030 Tube, Booster Vacuum
44773 44774-25070 Hose, Vacuum, No.2
44776 44776-37020 Hose, Brake Booster
9017908038 90179-08038 Nut
9017908141 90179-08141 Nut (For Transmission Control Cable)
9046110573 90461-10573 New Genuine Part
9046112407 90461-12407 Clamp
9046716002 90467-16002 Clip(Vaccum Transmitting Hose No.1)
9046716002 96133-41500 Clamp Or Clip(For Air Hose, No.5)
9048022022 90480-22022 GROMMET
9094901534 90949-01534 New Genuine Part
9165140816 91651-40816 BOLT
Brake Master Cylinder ([10.1996 - ] (9610- )) 24
#OEMPart name
4493 04493-25080 Cylinder Kit, Brake Master
47201 47201-25200 Cylinder Sub-Assy, Brake Master
47202 47220-37020 Reservoir Sub-Assy, Brake Master Cylinder
47202 47220-37030 Reservoir Sub-Assy, Brake Master Cylinder
47210 90430-06104 Gasket(For Brake Actuator)
47210 90109-06008 Bolt(For Brake Master Cylinder)
47218 47218-30040 Plug, Master Cylinder Fluid Outlet
47218 90430-11001 Gasket(For Fluid Outlet Plug)
47230 47230-37020 Cap Assy, Brake Master Cylinder Reservoir Filler
47234 47234-37060 Tube, Reservoir, No.1
47235 47235-37040 Tube, Brake Master Cyrinder Reservoir, No.2
47264 47264-50010 Clevis, Master Cylinder Push Rod
47281 47281-30020 Valve Assy, Brake Master Cylinder Outlet Check
47281 90501-05012 Spring, Compression
47299 47299-26020 Strainer, Brake Master Cylinder Reservoir
55175 55175-37010 Support Sub-Assy, Brake Master Cylinder
55175 55175-37040 Support Sub-Assy, Brake Master Cylinder
9010506109 90105-06109 New Genuine Part
9017906019 90179-06019 New Genuine Part
9017908146 90179-08146 Nut
9017908146 90179-08204 Nut
9017910065 90179-10065 Nut, Master Cylinder Push Rod Clevis Lock
9046716002 90467-16002 Clip(Vaccum Transmitting Hose No.1)
9046716002 96133-41500 Clamp Or Clip(For Air Hose, No.5)
Brake No.3, 1St & Reverse Brake (Atm) ([10.1996 - ] A44DE,A44DF (9610- )LY10#,11#,16#..ATM) 17
#OEMPart name
35608 35608-20020 Spring Sub-Assy, 2Nd Brake Piston Return
35622 35622-22010 Piston, Brake, No.2
35622 90301-99084 Ring, O (For Underdrive Brake Piston)
35622 90301-56007 Ring, O (For Underdrive Clutch Piston)
35623 35623-22010 Piston, Brake, No.3
35623 90301-99110 Ring, O (For Brake Piston Outer)
35623 90520-52262 Ring, Shaft Snap (For Underdrive Return Spring)
35626 35626-22010 Sleeve, Brake Reaction
35626 90301-99109 Ring (For Brake Reaction Sleeve Outer)
35626 90301-67005 Ring (For Brake Reaction Sleeve Inner)
35629 35629-22010 Spring (1St & Revs Brake Plate Stopper)
35666 35666-26020 Tube, Brake Apply
35666 35647-22010 Plate, Clutch, No.2
35666 35677-26030 Disc, Clutch (For Brake)
35666 35639-22010 Plate, Clutch Pressure (For Brake)
35707 35707-30040 Race Sub-Assy, 1 Way Clutch, Inner
35707 90521-99140 Ring (For Rear Brake)
Brake Pedal & Bracket ([05.1995 - ] (9505- )) 22
#OEMPart name
47101 47101-37040 Pedal Sub-Assy, Brake
47101 90508-35324 Spring(For Brake Pedal Return)
47101 90386-13007 Bush(For Clutch Pedal)
47121 31321-14020 Pad, Clutch Pedal
47124 91121-51070 Shaft, Clutch Pedal
47124 90084-10023 Shaft, Brake Pedal
47124 90387-10004 Collar, Clutch Pedal Shaft
47131 90541-06036 Cushion, No.1(For Clutch Pedal)
47264 90240-10015 Pin(For Push Rod)
55150 55150-37020 Bracket Assy, Pedal
55150 55150-37030 Bracket Assy, Pedal
55159 55159-37010 Stay, Pedal Bracket
9010506109 90105-06109 New Genuine Part
9017908146 90179-08146 Nut
9017908146 90179-08204 Nut
9111261020 91112-61020 New Genuine Part
9164380820 91643-80820 New Genuine Part
9164380820 91641-80818 BOLT WWASHER
9166160825 91661-60825 New Genuine Part
9413061000 94130-61000 Nut(For Clutch Pedal Stopper)
9453101000 94531-01000 WASHER
9538103020 95381-03020 Pin, Cotter(For Reverse Shaft Restrict Pin)
Brake Tube & Clamp ([05.1995 - ] (9505- )) 24
#OEMPart name
47910 47910-25190 Valve Assy, Load Sensing Proportioning
47920 47920-26060 Spring Assy, Load Sensing
47920 90387-08099 Collar(For Load Sensing Spring)
47920 90467-31110 Clip(For Load Sensing Valve Boot)
47920 90202-10103 Washer(For Load Sensing Spring)
47931 47931-26091 Bracket, Load Sensing Valve
47933 47933-26081 Bracket, Load Sensing Shackle, No.1
47935 47935-35010 Shackle, Load Sensing Spring, No.1
47935 90385-10064 Bush(For Load Sensing Spring Shackle)
47935 90201-08062 Retainer(For Load Sensing Spring Shackle)
47936 47936-35010 Shackle, Load Sensing Spring, No.2
47937 47937-60010 Plate, Load Sensing Valve Set
9011908703 90119-08703 New Genuine Part
9020123360 90201-23360 WASHER
9113150840 91131-50840 BOLT
9161160816 91611-60816 Screw Or Bolt(For Valve Rocker Shaft Lock)
9161160816 91611-B0816 Bolt
9411040800 94110-40800 Nut(For Steering Damper)
9411040800 94130-00802 Nut, No.1 (For Center Support Bearing)
9411041000 94110-41000 Nut(For Steering Damper)
9414140800 94141-40800 New Genuine Part
9451200800 94512-00800 Washer, No.1 (For Propeller Shaft & Differential Setting)
9451201000 94512-01000 Washer, No.1 (For Propeller Shaft & Differential Setting)
9538102020 95381-02020 PIN
Brake Tube & Clamp ([05.1999 - ] (9905- )LY102,112,YY101) 53
#OEMPart name
47311 47311-25371 Tube, Front Brake, No.1
47311 90947-02B32 Hose, Flexible(For Brake Tube)
47311 90947-02B33 Hose, Flexible(For Brake Tube)
47312 90904-13058 Way, No.1(For Front Brake Tube)
47313 47313-25161 Tube, Front Brake, No.3
47313 90947-02E77 Hose, Flexible, No.1(For Front)
47313 90904-13023 Way, No.3(For Front Brake Tube)
47314 47314-25201 Tube, Front Brake, No.4
47315 47315-25100 Tube, Front Brake, No.5
47316 47316-25170 Tube, Front Brake, No.6
47316 90947-02F55 Hose, Flexible(For Rear Brake Tube)
47316 90413-10216 Way, 3(For Rear Brake Tube)
47316 90947-02557 Hose, Flexible(For Rear Brake Tube)
47321 47321-25231 Tube, Rear Brake, No.1
47323 47323-25161 Tube, Front Brake, No.6
47324 47324-25290 Tube, Rear Brake, No.2
47325 47325-26281 Tube, Rear Brake, No.5
47326 47326-25250 Tube, Rear Brake, No.6
47326 47326-26191 Tube, Rear Brake, No.6
47327 47327-25210 Tube, Rear Brake, No.7
47327 47327-26071 Tube, Rear Brake, No.7
47341 47341-26060 Tube, Wheel Cylinder, Front Rh No.1
47343 47343-26060 Tube, Wheel Cylinder, Front Lh No.1
47351 47351-26070 Bracket, Flexible Hose(For Front Rh)
47351 47351-25120 Bracket, Flexible Hose, No.1
47352 47352-26070 Bracket, Flexible Hose(For Front Lh)
47353 47353-26030 Bracket, Flexible Hose, No.1
47353 47353-26050 Bracket, Flexible Hose, No.3
47371 47373-25010 Clamp, Brake Tube, No.1
47372 47372-25010 Clamp, Brake Tube, No.1
47373 47373-26010 Clamp, Brake Tube, No.2
9011908 90119-08A46 BOLT WWASHER
9011908164 90119-08164 Bolt
9011908164 90119-08802 BOLT WWASHER
9011908703 90119-08703 New Genuine Part
9046106112 90461-06112 Clamp, Brake Tube, No.6
9046400627 90464-00627 Clamp, Throttle Cable, No.6
9046714006 90467-14006 New Genuine Part
9046808034 90468-08034 CLIP
9046808035 90468-08035 CLIP
9046808035 90468-A0007 New Genuine Part
9048001054 90480-01054 Grommet(For Brake Tube)
9048001274 90480-01274 Grommet, No.2(For Front Brake Tube)
9048001311 90480-01311 Grommet(For Brake Tube)
9094901770 90949-01770 New Genuine Part
9161160812 91611-60812 Bolt(For Drive Plate & Torque Converter Setting)
9161160812 91611-B0812 Bolt
9161160814 91611-60814 Bolt
9161160816 91611-60816 Screw Or Bolt(For Valve Rocker Shaft Lock)
9161160816 91611-B0816 Bolt
9165160816 91651-60816 BOLT
9165160816 90080-11396 Bolt
9622130905 96221-30905 CLAMP
Cab Mounting & Body Mounting ([10.1996 - ] (9610- )LY10#,11#,YY101) 13
#OEMPart name
51735 51735-26020 Reinforcement, Cab Rear Mounting, Rh
51736 51736-26020 Reinforcement, Cab Rear Mounting, Lh
52201 52201-25040 Cushion Sub-Assy, Cab Front Mounting
52202 52202-25040 Cushiion Sub-Assy, Cab Mounting, No.1 Lower
52202 52202-25050 Cushion Sub-Assy, Cab Front Mounting, Lower
57245 57245-25010 Plate, Anchor Side Strength
9010510205 90105-10205 New Genuine Part
9010512107 90105-12107 New Genuine Part
9020112010 90201-12010 Washer(For Front Lateral Control Rod)
9044019027 90440-19027 New Genuine Part
9044019031 90440-19031 New Genuine Part
9413001202 94130-01202 Nut(For Dust Cover To Steering Knuckle Arm Setting)
9418401201 94184-01201 NUT
Camshaft & Valve ([05.1995 - ] (9505- )3L,5L) 48
#OEMPart name
11802 11802-54020 Bearing Set, Camshaft
11802 11802-54021 Bearing Set, Camshaft (STD)
11802 11803-54020 Bearing Set, Camshaft (0.125)
11802 11803-54021 Bearing Set, Camshaft (0.125)
11802 11804-54020 Bearing Set, Camshaft (0.25)
11802 11804-54021 Bearing Set, Camshaft (0.25)
13502 13503-54030 Idler Sub-Assy, Timing Belt, No.2
13505 13505-54021 Idler Sub-Assy, Timing Belt, No.1
13505 90506-18060 Spring, Tension(For Idler)
13511 13501-54070 Camshaft
13523 90280-05004 Key, Woodruff(For Timing Gear)
13523 13523-54040 Pulley, Camshaft Timing
13558 13558-54020 Bracket, Spring(For Idler)
13568 13568-59066 Belt, Timing
13568 13568-59175 Belt, Timing
13613 13603-54030 Pulley, Injection Pump Drive
13711 13711-54030 Valve, Intake
13711 90913-02117 Seal Or Ring, O(For Valve Stem Oil)
13711 90504-49001 Spring, Compression(For Inner)
13711 90201-23003 Washer, Plate(For Valve Spring Seat)
13715 13715-54050 Valve, Exhaust
13741 13741-54020 Retainer, Valve Spring
13741 90913-03014 Lock, Valve Spring Retainer
13751 13751-54010 Lifter, Valve
13753 13753-54010 Shim, Valve Adjusting
13753 13753-54060 Shim, Valve Adjusting
13753 13753-54110 Shim, Valve Adjusting
13753 13753-54160 Shim, Valve Adjusting
13753 13753-54210 Shim, Valve Adjusting
13753 13753-54260 Shim, Valve Adjusting
13753 13753-54310 Shim, Valve Adjusting
13753 13753-54360 Shim, Valve Adjusting
13753 13753-54410 Shim, Valve Adjusting
13753 13753-54420 Shim, Valve Adjusting
13753 13753-54430 Shim, Valve Adjusting
13753 13753-54440 Shim, Valve Adjusting
13753 13753-54450 Shim, Valve Adjusting
13753 13753-54460 Shim, Valve Adjusting
13753 13753-54470 Shim, Valve Adjusting
13753 13753-54480 Shim, Valve Adjusting
13753 13753-54490 Shim, Valve Adjusting
9009905166 90099-05166 Nut, Timer Round
9010508169 90105-08169 BOLT
9010510235 90105-10235 BOLT
9010908171 90109-08171 BOLT
9010908172 90109-08172 BOLT
9011914036 90119-14036 Washer, Plate(For Crankshaft Pulley Set)
9056012041 90560-12041 SPACER
Caution Plate & Name Plate (Engine) ([05.1995 - ] (9505- )) 6
#OEMPart name
11296 11296-54080 Label, Engine Service Information
11296 11296-54081 Label, Engine Service Information
17700 17791-54010 Plate, Air Cleaner Caution (For Engine Model)
17700 17791-64020 Plate, Air Cleaner Caution (For Engine Model)
17791 17791-74040 Label, Maintenance Information
1356410010 13564-10010 Plate, Timing Belt Caution
Caution Plate ([05.1995 - ] (9505- )) 13
#OEMPart name
33621 33621-37020 Plate, Control Lever Caution
74517 74517-26020 Plate, Exhaust Temperature Caution
74539 74539-37010 Plate, Radiator Shutter Caution
74541 74582-25740 Plate, Tire Pressure Caution
74541 74582-25741 Plate, Tire Pressure Caution
74541 74582-25750 Plate, Tire Pressure Caution
74541 74582-25751 Plate, Tire Pressure Caution
74544 74544-36050 Plate, Tire Carrier Caution
74544 74544-37010 Plate, Tire Carrier Caution
74582 74552-2E190 Plate, Safety Caution
74582 74552-37740 Plate, Safety Caution
74585 74585-25010 Plate, Tire Carrier Caution
74586 74586-25010 Plate, Tire Carrier Caution
Center Support & Planetary Sun Gear (Atm) ([10.1996 - ] A44DE,A44DF (9610- )LY10#,11#,16#..ATM) 30
#OEMPart name
35608 35608-30020 Spring Sub-Assy, 2Nd Brake Piston Return
35608 35608-20010 Spring Sub-Assy, 2Nd Brake Piston Return
35620 35677-30140 Disc, Clutch (For Overdrive)
35620 35675-22010 Flange, Overdrive Clutch
35620 35675-22140 Flange, Overdrive Clutch
35620 90521-99139 Ring, Hole Snap (For Overdrive Brake Return Spring Seat)
35620 35648-30020 Plate, Clutch (For Rear Brake)
35620 34625-22010 Flange, Overdrive Brake, No.1
35620 35676-22030 Flange, Overdrive Brake
35621 35624-22010 Piston, Brake, No.1
35621 90301-99110 Ring, O (For Brake Piston Outer)
35621 90301-56007 Ring, O (For Underdrive Clutch Piston)
35621 35621-30010 Piston, Brake, No.1
35621 90301-99107 Ring (For Rear Brake Piston Outer)
35627 90520-52262 Ring, Shaft Snap (For Underdrive Return Spring)
35634 35634-22060 Plate, Clutch (For Overdrive)
35662 35662-30010 Hub, Brake
35677 35677-22070 Disc, Clutch (For Rear Brake)
35706 35706-30050 Gear Sub-Assy, Planetary Sun
35706 90374-21001 Race, Thrust Bearing (For Rear Planetary Ring Gear Front)
35706 90520-34001 Ring, Shaft Snap (For Sun Gear Front)
35706 35789-22030 Race, Thrust Bearing(For Overdrive)
35706 35789-43020 Race, Thrust Bearing (For Planetary Sun Gear Front)
35709 35709-12020 Support Sub-Assy, Center
35709 35617-16010 Ring, Oil Seal (For Overdrive Case)
35719 35719-30050 Gear, Rear Planetary Sun
35749 35749-22010 Ring, Sun Gear Shaft Oil Seal
35790 35791-30020 Clutch, 1Way, No.1(For Overdrive)
35793 35793-22011 Retainer, 1 Way Clutch
9010508141 90105-08141 New Genuine Part
Clutch & Release Fork ([05.1995 - ] (9505- )MTM) 17
#OEMPart name
31126 31126-20070 Boot, Clutch Release Fork
31204 31204-35050 Fork Sub-Assy, Clutch Release
31210 31210-35121 Cover Assy, Clutch
31210 31210-26164 Cover Assy, Clutch
31210 31210-35122 Cover Assy, Clutch
31230 31230-35060 Bearing Assy, Clutch Release
31230 31230-35061 Bearing Assy, Clutch Release
31232 31232-35020 Clip Or Spring, Release Bearing Hub
31232 31232-35030 Clip Or Spring, Release Bearing Hub
31236 31236-30060 Ball, Release Fork
31250 31250-25142 Disc Assy, Clutch
31250 31250-25144 Disc Assy, Clutch
31250 31250-25143 Disc Assy, Clutch
33311 90363-12002 Bearing (For Input Shaft)
33311 90363-12024 Bearing, Radial Ball
9011908026 90119-08026 Bolt(For Transmission Input Damper Cover & Flywheel)
9011908026 90119-08079 Bolt(For Transmission Input Damper Cover & Flywheel)
Clutch Housing & Transmission Case (Mtm) ([05.1995 - ] G54 (9505- )LY102,112,201..MTM..ST..125,1T ; (961 0- )LY101,111..MTM) 26
#OEMPart name
31111 31111-22114 Housing, Clutch
33101 90341-18006 Plug (No magnet)
33101 90430-18008 Gasket
33101 90430-T0021 Gasket(For Manual Transmission Filler Plug)
33101 90930-03085 Plug, Breather
33104 90341-18032 Plug Sub-Assy, Drain(Mtm) - No magnet
33111 33101-35060 Case, Manual Transmission
33111 33101-26060 Case, Manual Transmission
33111 90331-14004 Plug, Manual Transmission Case
33111 90250-12002 Pin, Straight(For Manual Transmission Case)
33111 90253-11001 Pin, Ring(For Camshaft Bearing Cap Setting)
33111 90253-15001 Pin, Straight(For Clutch Housing Set)
33118 33118-25020 Plate, Stiffener, Rh(Mtm)
33119 33119-25020 Plate, Stiffener, Lh(Mtm)
33131 33131-26020 Retainer, Bearing, Front(Mtm)
33131 90311-30014 Seal, Oil(For Transmission Front Bearing Retainer)
33132 33132-28010 Gasket, Front Bearing Retainer(Mtm)
33151 33151-35030 Retainer, Output Shaft Rear Bearing(Mtm)
9011908332 90119-08332 Bolt(For Manual Transmission Oil Pump Cover)
9014980002 90149-80002 BOLT
9161161030 91611-61030 Bolt (For Transmission Control Cable Bracket)
9161161030 91612-61030 Bolt (For Transmission Control Cable Bracket)
9161261045 91612-61045 Bolt(For Transaxle & Engine Setting)
9161961250 91619-61250 Bolt
9161961255 91619-61255 Bolt(For Transaxle & Engine Setting)
9165161032 91651-61032 BOLT
Clutch Master Cylinder ([10.1996 - ] (9505- )LY20#,21#..MTM ; (9610- )LY10#,11# ,12#,13#,15#,16#..MTM..DSL) 10
#OEMPart name
4311 04311-12110 Cylinder Kit, Clutch Master
31410 31420-37040 Cylinder Assy, Clutch Master
31410 91611-60865 Bolt(For Rocker Support Set)
31434 31434-37030 Tube, Clutch Reservoir
31434 96133-41300 Clip(For Air Hose No.6)
31451 31451-36040 Rod, Clutch Master Cylinder Push
31453 31404-28020 Clevis, Clutch Master Cylinder Push Rod
31454 31454-14010 Boot, Clutch Master Cylinder
55165 55107-25020 Support, Clutch Master Cylinder
9412040800 94120-40800 Nut(For Clutch Pedal Stopper)
Clutch Pedal & Flexible Hose ([05.1995 - ] (9505- )MTM..DSL) 22
#OEMPart name
31301 31310-25020 Pedal Sub-Assy, Clutch
31301 90949-03010 Spring(For Clutch Pedal)
31301 90541-06036 Cushion, No.1(For Clutch Pedal)
31301 90386-13007 Bush(For Clutch Pedal)
31301 90101-08052 Bolt(For Clutch Pedal Stopper)
31301 94130-60800 Nut(For Clutch Pedal Stopper)
31301 90170-A0003 New Genuine Part
31301 90386-05017 Bush(For Clutch Pedal Turnover)
31301 90949-03030 Spring, Compression(For Turn Over Spring Seat)
31301 90949-03103 Spring, Compression(For Turn Over Spring Seat)
31321 31321-14020 Pad, Clutch Pedal
31324 91121-51070 Shaft, Clutch Pedal
31324 90084-10023 Shaft, Brake Pedal
31324 90387-10004 Collar, Clutch Pedal Shaft
31353 31353-14010 Holder, Clutch Pedal Spring
31354 90386-13015 Bush(For Clutch Pedal)
31453 90240-08006 Pin, W/hole(For Clutch Master Cylinder Push Rod Clevis)
31453 90386-08002 Bush(For Clutch Pedal Over Center Spring Pin)
9046816142 90468-16142 Clip(For Push Rod Clevis Pin)
9413061000 94130-61000 Nut(For Clutch Pedal Stopper)
9453101000 94531-01000 WASHER
9616000600 96160-00600 Ring, E(For Clutch Pedal Pawl)
Clutch Pedal & Flexible Hose ([05.1999 - ] (9905- )LY102,112,122,132,152,162,YY101..MTM) 20
#OEMPart name
31349 31349-25010 Insulator, Clutch Cable Heat
31481 96817-50310 Hose, Clutch, No.1
31481 31481-25200 Tube, Clutch Master Cylinder To 2 Way
31482 31482-25120 Tube, Clutch Release Cylinder To Flexible Hose
31484 31484-25050 Bracket, Flexible Hose, No.1(For Clutch)
31489 31489-25170 Tube, Tube Connector To Flexible Hose
31495 31495-25010 Way, Clutch Tube
9046108449 90461-08449 New Genuine Part
9046110210 90461-10210 New Genuine Part
9046204007 90462-04007 New Genuine Part
9046808035 90468-08035 CLIP
9046808035 90468-A0007 New Genuine Part
9161160814 91611-60814 Bolt
9161160816 91611-60816 Screw Or Bolt(For Valve Rocker Shaft Lock)
9161160816 91611-B0816 Bolt
9161161014 91611-61014 New Genuine Part
9161161014 91612-B1014 BOLT WWASHER
9165140814 91651-40814 BOLT
9165140814 90080-11228 New Genuine Part
9699110080 96991-10080 CLIP
Clutch Release Cylinder ([05.1995 - ] (9505- )MTM) 8
#OEMPart name
4313 04313-17010 Cylinder Kit, Clutch Release
31470 31470-30222 Cylinder Assy, Clutch Release
31470 91611-60825 Bolt(For Head To Camshaft Bearing Cap)
31470 91611-B0825 Bolt(For Clutch Release Cylinder Setting)
31473 31473-35050 Rod, Clutch Release Cylinder Push, No.1
31476 31476-22010 Boot, Clutch Release Cylinder
31477 47547-12010 Plug, Bleeder(For Release Cylinder)
31478 31478-30010 Bleeder Plug Cap
Console Box & Bracket ([10.1996 - ] (9610- )) 1
#OEMPart name
9046709145 90467-09145-B0 Clip(For Glove Compartment)
Crankshaft & Piston ([05.1995 - ] (9505- )3L,5L) 47
#OEMPart name
11011 11011-54020 Washer Set, Crankshaft Thrust
11011 11012-54020 Washer Set, Crankshaft Thrust
11011 11013-54020 Washer Set, Crankshaft Thrust
11702 11704-54061 Bearing Set, Crankshaft
11702 11704-54081 Bearing Set, Crankshaft (0.25)
11702 11705-54061 Bearing Set, Crankshaft
11702 11705-54081 Bearing Set, Crankshaft (0.50)
11711 11701-54061-01 Bearing, Crankshaft
11711 11701-54081-01 Bearing, Crankshaft
11711 11701-51081-01 Bearing, Crankshaft
11711 11701-54061-02 Bearing, Crankshaft
11711 11701-54081-02 Bearing, Crankshaft
11711 11701-54061-03 Bearing, Crankshaft
11711 11701-54081-03 Bearing, Crankshaft
13011 13011-54130 Piston Ring Set (STD)
13011 13013-54130 Ring Set, Piston
13041 13041-54041-01 Bearing, Connecting Rod
13041 13041-54042-01 Bearing, Connecting Rod
13041 13041-54041-02 Bearing, Connecting Rod
13041 13041-54042-02 Bearing, Connecting Rod
13041 13041-54041-03 Bearing, Connecting Rod
13041 13041-54042-03 Bearing, Connecting Rod
13101 13101-54120-01 Piston Sub-Assy, W/pin
13101 13101-54120-02 Piston Sub-Assy, W/pin
13101 13101-54120-03 Piston Sub-Assy, W/pin
13101 13103-54120 Piston Sub-Assy, W/pin
13101 90521-31001 Ring, Hole Snap(For Piston Pin)
13201 13201-59106 Rod Sub-Assy, Connecting
13201 13201-59216 Rod Sub-Assy, Connecting
13201 90999-73115 Bush(For Connecting Rod Small End)
13202 13204-54041 Bearing Set, Connecting Rod
13202 13204-54042 Bearing Set, Connecting Rod (0.25)
13265 13265-54021 Bolt, Connecting Rod
13265 90179-10123 Nut, Hexagon(For Connecting Rod Bolt)
13405 13405-54080 Flywheel Sub-Assy
13405 90250-08054 Pin, Straight
13405 90105-12109 Bolt, Flywheel Setting
13411 13401-54061 Crankshaft
13411 13401-54100 Crankshaft
13453 13453-54010 Gear, Flywheel Ring
13471 13408-54090 Pulley, Crankshaft
13471 95161-30622 Key, Crankshaft(For Crankshaft Pulley Set)
13471 90901-19028 Bolt(For Crankshaft Pulley Set)
13477 88451-35030 Pulley, Crankshaft, No.2
13521 13521-54030 Pulley, Crankshaft Timing
13566 13566-54040 Guide, Timing Belt
9161160814 91611-60814 Bolt
Cylinder Block ([05.1995 - ] (9505- )3L,5L..LY10#,11#,12#,13#,15#,16#) 29
#OEMPart name
11401 11401-59645 Block Sub-Assy, Cylinder
11401 11401-59818 Block Sub-Assy, Cylinder
11415 90910-09110 Cock Sub-Assy, Water Drain(For Cylinder Block)
11415 90910-09087 Plug, Water Drain Cock(For Cylinder Block)
11416 90910-02061 Bolt(For Cylinder Head Set)
11425 92112-80825 Bolt, Stud(For Oil Filter)
11431 96411-42500 Plug, Tight, No.1
11431 96411-43500 Plug, Tight, No.1
11431 96411-45000 Plug, Tight, No.1(For Cam Housing)
11432 90345-51006 Plug, W/head Taper Screw, No.2
11434 90253-11021 Pin, Ring
11434 90253-15005 Pin, Ring(For Crankshaft Bearing Cap Set)
11434 90250-10113 Pin, Straight(For Timing Gear Cover Set)
11448 11448-54020 Orifice, Cylinder Block Oil
11452 11452-54090 Guide, Oil Level Gage
11459 90929-01203 Support, Oil Level Gage Guide
12101 12101-54252 Pan Sub-Assy, Oil
12101 90341-12012 Plug(For Oil Pan Drain)
12101 90341-T0004 Plug(For Oil Pan Drain)
12101 90430-12031 Gasket (For Oil Pan Drain Plug)
12584 12584-54040 Insulator, Cylinder Brock, No.4
12585 12585-54050 Insulator, Cylinder Brock, No.5
15301 15301-54140 Gage Sub-Assy, Oil Level
15605 15605-54010 Valve Sub-Assy, Oil Check
15708 15708-54060 Nozzle Sub-Assy, Oil, No.1
9011608404 90116-08404 BOLT STUD
9011908783 90119-08783 BOLT WWASHER
9017908150 90179-08150 NUT
9043027001 90430-27001 Gasket, Engine Oil Level Sensor
Cylinder Head ([05.1995 - ] (9505- )3L,5L) 37
#OEMPart name
11101 11101-54150 Head Sub-Assy, Cylinder
11101 90910-02080 Bolt(For Cylinder Head Set)
11101 90910-02081 Bolt(For Cylinder Head Set)
11101 90440-15003 Tube(For Cylinder Head)
11115 11115-54120-B0 Gasket, Cylinder Head
11115 11115-54130-B0 Gasket, Cylinder Head
11115 11115-54120-D0 Gasket, Cylinder Head
11115 11115-54130-D0 Gasket, Cylinder Head
11115 11115-54120-F0 Gasket, Cylinder Head
11115 11115-54130-F0 Gasket, Cylinder Head
11115 11115-54121-B0 Gasket, Cylinder Head
11115 11115-54121-D0 Gasket, Cylinder Head
11115 11115-54121-F0 Gasket, Cylinder Head
11116 96411-62500 Plug, Tight, No.1
11116 96411-63000 Plug, Tight
11116 96411-64500 Plug, Tight
11122 11122-54020 Bush, Intake Valve Guide
11122 11122-17020 Bush, Intake Valve Guide
11122 11123-54020 Bush, Intake Valve Guide
11151 90253-11021 Pin, Ring
11158 92122-80616 Bolt, Stud(For Head To Cylinder Head Cover)
11159 90105-08166 Bolt(For Head To Camshaft Bearing Cap)
11183 11183-54020 Plug, Semicircular
11201 11210-54032 Cover Sub-Assy, Cylinder Head
11201 90179-06319 Nut, Cap(For Cylinder Head Cover)
11212 11212-54030 Cover, Cylinder Head, No.2
11213 11213-54050 Gasket, Cylinder Head Cover
11213 11213-05010 Gasket, Cylinder Head Cover
11224 11224-54030 Silencer, Cylinder Head Cover
12108 12180-70020 Cap Sub-Assy, Oil Filler
12108 12195-70010 Gasket(For Oil Filler Cap)
9011906787 90119-06787 BOLT WWASHER
9020108466 90201-08466 Washer
9038706045 90387-06045 COLLAR
9038908076 90389-08076 Washer
9048015019 90480-15019 Grommet
9412040800 94120-40800 Nut(For Clutch Pedal Stopper)
Disc Wheel & Wheel Cap ([05.1995 - ] (9505- )) 57
#OEMPart name
42601 42601-26360-03 Wheel, Disc (For Spare)
42601 90942-01051 Nut, Hub (For Axle)
42601 42601-26171-03 Wheel, Disc (For Spare)
42601 42601-26261-03 Wheel, Disc (For Spare)
42603 42603-26070 Ornament Sub-Assy, Wheel Hub
42611 90942-05009 Valve (For Tubeless Tire)
42611 90080-94031 Valve (For Tubeless Tire)
42611 90942-05023 Valve (For Tubeless Tire)
9094203002 90942-03002 Weight, Balance (For Disc Wheel)
9094203002 90942-03362 Weight, Balance (For Disc Wheel)
9094203003 90942-03003 Weight, Balance (For Disc Wheel)
9094203003 90942-03083 Weight, Balance (For Disc Wheel)
9094203004 90942-03004 Weight, Balance (For Disc Wheel)
9094203004 90942-03085 Weight, Balance (For Disc Wheel)
9094203005 90942-03005 Weight, Balance (For Disc Wheel)
9094203005 90942-03366 Weight, Balance (For Disc Wheel)
9094203006 90942-03006 Weight, Balance (For Disc Wheel)
9094203006 90942-03368 Weight, Balance (For Disc Wheel)
9094203006 90942-03084 Weight, Balance (For Disc Wheel)
9094203017 90942-03017 Weight, Balance (For Disc Wheel)
9094203020 90942-03020 Weight, Balance (For Disc Wheel)
9094203022 90942-03022 Weight, Balance (For Disc Wheel)
9094203025 90942-03025 Weight, Balance (For Disc Wheel)
9094203027 90942-03027 Weight, Balance (For Disc Wheel)
9094203029 90942-03029 Weight, Balance (For Disc Wheel)
9094203031 90942-03031 Weight, Balance (For Disc Wheel)
9094203037 90942-03037 Weight, Balance (For Disc Wheel)
9094203041 90942-03041 Weight, Balance (For Disc Wheel)
9094203047 90942-03047 Weight, Balance (For Disc Wheel)
9094203049 90942-03049 Weight, Balance (For Disc Wheel)
9094203051 90942-03051 Weight, Balance (For Disc Wheel)
9094203052 90942-03052 Weight, Balance (For Disc Wheel)
9094203064 90942-03064 Weight, Balance (For Disc Wheel)
9094203076 90942-03076 Weight, Balance (For Disc Wheel)
9094203076 90942-03364 Weight, Balance (For Disc Wheel)
9094203077 90942-03077 Weight, Balance (For Disc Wheel)
9094203078 90942-03078 Weight, Balance (For Disc Wheel)
9094203079 90942-03079 Weight, Balance (For Disc Wheel)
9094203080 90942-03080 Weight, Balance (For Disc Wheel)
9094203081 90942-03081 Weight, Balance (For Disc Wheel)
9094203082 90942-03082 Weight, Balance (For Disc Wheel)
9094203086 90942-03086 Weight, Balance (For Disc Wheel)
9094203107 90942-03107 Weight, Balance (For Disc Wheel)
9094203107 90942-03360 Weight, Balance (For Disc Wheel)
9094203218 90942-03218 Weight, Balance (For Disc Wheel)
9094203218 90942-03369 Weight, Balance (For Disc Wheel)
9094203219 90942-03219 Weight, Balance (For Disc Wheel)
9094203219 90942-03361 Weight, Balance (For Disc Wheel)
9094203220 90942-03220 Weight, Balance (For Disc Wheel)
9094203220 90942-03363 Weight, Balance (For Disc Wheel)
9094203221 90942-03221 Weight, Balance (For Disc Wheel)
9094203221 90942-03365 Weight, Balance (For Disc Wheel)
9094203222 90942-03222 Weight, Balance (For Disc Wheel)
9094203222 90942-03367 Weight, Balance (For Disc Wheel)
9094203223 90942-03223 Weight, Balance (For Disc Wheel)
9094203224 90942-03224 Weight, Balance (For Disc Wheel)
9094203225 90942-03225 Weight, Balance (For Disc Wheel)
Emblem & Name Plate ([05.1995 - ] (9505- )) 14
#OEMPart name
75311 75311-37010 Plate, Front Name, No.1
75311 75311-37020 Plate, Front Name, No.1
75311 75311-37060 Plate, Front Name, No.1
75313 75313-37050 Plate, Front Name, No.3
75315 75315-37010 Ornament, Radiator Grille
75315 75315-37011 Plate Assy, Front Panel
75427 75427-37050 Plate, Front Door Name
75427 75427-37060 Plate, Front Door Name
75455 75455-95404 Mark, Roof Air Deflector
75471 75471-37010 Plate, Rear Body Name, No.1
75471 75471-37020 Plate, Rear Body Name, No.1
75472 75472-95022 Plate, Rear Name, No.6 (Maximum Load)
75473 75473-95400 Plate, Rear Name, No.5 (Mechanism)
75475 75475-95A00 Plate, Rear Name, No.2 (Model Mark)
Engine Oil Cooler ([05.1995 - ] (9505- )3L,5L) 3
#OEMPart name
15710 15710-54050 Cooler Assy, Oil
15710 15785-54010 Gasket(For Oil Cooler)
9017908150 90179-08150 NUT
Engine Oil Pump ([10.1996 - ] (9610- )3L,5L..LY10#,11#,12#,13#,15#,16#) 14
#OEMPart name
15104 15104-54190 Strainer Sub-Assy, Oil
15104 15149-54012 Gasket(For Oil Strainer)
15104 15149-54030 Gasket(For Oil Strainer)
15104 92122-40816 Bolt, Stud(For Oil Strainer)
15115 15115-54022 Cover, Oil Pump
15121 15121-54020 Gear, Oil Pump Drive
15122 15122-54020 Gear, Oil Pump Driven
15131 15131-54010 Valve, Oil Pump Relief
15132 15132-54010 Spring, Oil Pump Relief Valve
15133 15133-54010 Plug, Oil Pump Relief Valve
9011908783 90119-08783 BOLT WWASHER
9015160013 90151-60013 BOLT
9017908150 90179-08150 NUT
9043018002 90430-18002 Gasket
Engine Overhaul Gasket Kit ([05.1999 - ] (9905- )5L) 3
#OEMPart name
4111 04111-54310 Gasket Kit, Engine Overhaul
4111 04111-54311 Gasket Kit, Engine Overhaul
4112 04112-54250 Gasket Kit, Engine Valve Grind
Exhaust Pipe ([10.1996 - ] (9610- )3L,5L..LY10#,11#,12#,13#,15#,16#) 34
#OEMPart name
17410 17410-5B390 Pipe Assy, Exhaust, Front
17410 90179-10070 Nut, Exhaust Pipe Set Stud Bolt
17410 90080-17187 Nut, Exhaust Pipe Set Stud Bolt
17410 90917-06066 Gasket, Exhaust Pipe
17430 17430-5B660 Pipe Assy, Exhaust, Tail
17430 17430-5B661 Pipe Assy, Exhaust, Tail
17451 90917-06045 Gasket, Exhaust Pipe
17451 90080-43028 Gasket, Exhaust Pipe
17505 90917-08009 Cushion, Exhaust Tail Pipe (For Rear)
17505 17505-54130 Support Sub-Assy, Exhaust Pipe
17561 17561-54190 Support, Exhaust Pipe, No.1
17563 17565-54030 Bolt Or Ring, Exhaust Pipe Front (For Center)
17565 17565-63030 Bracket, Catalytic Converter Support
17567 17567-61010 Cushion, Exhaust Tail Pipe(For Center)
17572 17571-54270 Bracket, Exhaust Pipe Front (For Front)
17572 17572-54200 Bracket, Exhaust Pipe Front (For Center)
17573 17575-71050 Bracket, Exhaust Tail Pipe(For Front)
17574 17574-54060 Bracket, Exhaust Tail Pipe (For Rear)
9017906007 90179-06007 Nut
9046123387 90461-23387 Clamp No.2, Exhaust Pipe Center, Front
9046132028 90461-32028 CLAMP
9151261035 91512-61035 Bolt(For Transaxle Case & Engine Setting)
9151261035 90080-10204 New Genuine Part
9151261230 91512-61230 BOLTFLANGE
9162160835 91621-60835 BOLT
9162160835 91651-B0835 BOLT
9163160840 91631-60840 New Genuine Part
9165160825 91651-60825 Bolt, Hexagon(For Steering Column Bracket)
9165160825 91651-B0825 Bolt, Hexagon(For Steering Column Bracket)
9165160835 91651-60835 Bolt(For Front Suspension Control Accumulator)
9413060800 94130-60800 Nut(For Clutch Pedal Stopper)
9413060800 90170-A0003 New Genuine Part
9418560800 94185-60800 NUT
9418561000 94185-61000 NUTLOCK
Extension Housing (Atm) ([10.1996 - ] A44DE (9610- )LY10#,11#..ATM) 11
#OEMPart name
4332 04332-30030 Seal Kit, Oil(For Automatic Extention Housing)
35108 35108-26020 Housing Sub-Assy, Extension (Atm)
35108 90311-38032 Seal, Oil(For Manual Transmission Extension Housing)
35108 33145-30010 Retainer, Extension Housing Dust Seal(Mtm)
35108 90303-38010 Seal, Dust(For Manual Transmission Extension Housing)
35146 33146-30020 Deflector, Extension Housing Dust(Mtm)
35182 35182-28010 Gasket, Extension Housing (Atm)
35189 35189-30010 Gasket, Extension Housing Bush Apply Tube
35847 35847-30020 Tube, Extension Housing Bush Apply
9011910232 90119-10232 Bolt (For Transmission Housing & Case Setting)
9011910233 90119-10233 New Genuine Part
Extension Housing (Mtm) ([05.1995 - ] G54 (9505- )LY10#,11#,201,YY101,201..MTM..ST..125 ,1T) 9
#OEMPart name
33103 33103-28031 Housing Sub-Assy, Extension(Mtm)
33103 90311-38032 Seal, Oil(For Manual Transmission Extension Housing)
33124 33124-28011 Receiver, Case Cover Oil(Mtm)
33124 33124-36010 Pipe, Oil Receiver(Mtm)
33146 33146-30020 Deflector, Extension Housing Dust(Mtm)
33449 33449-26010 Magnet, Transmission
9011908371 90119-08371 New Genuine Part
9011910186 90119-10186 BOLT
9011910337 90119-10337 BOLT
Floor Insulator ([05.1995 - ] (9505- )) 2
#OEMPart name
59258 59258-25010 Insulator, Engine Service Hole Cover Main
59268 59268-25010 Insulator, Engine Sub Cover
Floor Mat & Silencer Pad ([05.1995 - ] (9505- )) 26
#OEMPart name
58510 58510-25020-B0 Mat, Front Floor, Front
58510 58510-25180-B0 Mat, Front Floor, Front
58510 58510-25130-B0 Carpet Assy, Front Floor, Front
58510 58510-25150-B0 Carpet Assy, Front Floor, Front
58510 58510-25210-B0 Carpet Assy, Front Floor, Front
58510 58510-25010-B0 Mat, Front Floor, Front
58510 58510-25200-B0 Mat, Front Floor, Front
58510 58510-25140-B0 Carpet Assy, Front Floor, Front
58510 58510-25230-B0 Carpet Assy, Front Floor, Front
58512 58512-37010 Mat, Floor, Front Lh
58513 58513-25070-B0 Mat, Floor, Front Center
58514 58514-25020-B0 Mat, Floor, Rear Rh
58514 58514-25030-B1 Mat, Floor, Rear Rh
58515 58515-25010-B1 Mat, Floor, Rear Lh
58515 58515-95404-B0 Mat, Front Floor, Rear No.1
58521 58521-25030-B1 Mat, Engine Service Hole Cover
58521 58521-25100-B0 Mat, Engine Service Hole Cover
67913 67913-95403-B0 Plate, Front Door Scuff, Rh
67914 67914-95403-B0 Plate, Front Door Scuff, Lh
9015940041 90159-40041 New Genuine Part
9018904013 90189-04013 New Genuine Part
9018905055 90189-05055 GROMMET
9053004007 90530-04007 Hook, Male, No.1
9053006001 90530-06001 Fastener, Hook
9053018003 90530-18003 New Genuine Part
9356055016 93560-55016 Screw(For Mat Set Plate)
Frame ([10.1996 - ] (9610- )LY102,112 ; (9610- )LY101,111,YY10 1..T2 ; (9805- )LY111..IV5) 43
#OEMPart name
51100 51001-26303 Frame Sub-Assy
51100 90950-01395 Plug, Hole(For Frame)
51100 90950-01420 Plug, Hole(For Frame)
51100 51001-26383 Frame Sub-Assy
51201 51201-25090 Crossmember Sub-Assy, Frame, Front
51203 51203-26112 Crossmember Sub-Assy, Frame, No.2
51204 51203-26120 Crossmember Sub-Assy, Frame, No.3
51205 51204-26031 Crossmember Sub-Assy, Frame, No.4
51205 51205-26060 Bracket Sub-Assy, Differential Support
51209 51209-26030 Crossmember Sub-Assy, Frame, No.5
51225 51225-26010 Bracket, Front Suspension Member, Rh
51341 51342-26012 Gusset, Crossmember, No.4 Lower
51345 51305-26020 Bracket, Rear Spring, Front
51345 51345-26020 Bracket, Rear Spring, Front
51345 51305-25010 Bracket, Rear Spring, Front
51345 51345-26043 Bracket, Rear Spring, Front
51351 51351-26031 Gusset, Crossmember, No.5 Rh
51352 51352-26021 Gusset, Crossmember, No.5 Lh
51355 51301-25010 Bracket, Rear Spring, Rear Rh
51356 51302-25010 Bracket, Rear Spring, Rear Lh
51393 51393-26010 Gusset, Frame Rear Crossmember, Rh
51397 51397-26010 Bracket, Exhaust Pipe Clamp, No.3
51401 51401-26010 Bracket Sub-Assy, Engine Front Mounting, Rh
51505 51505-26904 Support Sub-Assy, Upper Control Arm
51506 51506-26904 Support Sub-Assy, Upper Control Arm
51621 51621-26011 Bracket, Rear Bound Stopper, Rh
51622 51622-26011 Bracket, Rear Bound Stopper, Lh
51701 51711-26080 Bracket Sub-Assy, Cab Mounting, No.1 Rh
51703 51703-26012 Bracket Sub-Assy, Cab Mounting, No.2, Rh
51741 51741-26052 Bracket, Rear Body Mounting, No.1
51741 51742-26022 Bracket, Rear Body Mounting, No.1
51743 51743-26010 Bracket, Rear Body Mounting, No.1
51963 51963-26041 Hook, Transport, Front Rh
51965 51965-26031 Hook, Rear
53901 53901-25010 Duct Sub-Assy, Air
57107 57107-26040 Bracket Sub-Assy, Strut Bar, Rh
57107 57107-26010 Bracket Sub-Assy, Strut Bar, Rh
57108 57108-26040 Bracket Sub-Assy, Strut Bar, Lh
57108 57108-26010 Bracket Sub-Assy, Strut Bar, Lh
9010512233 90105-12233 New Genuine Part
9011910809 90119-10809 New Genuine Part
9017912020 90179-12020 Nut(For Parking Brake Plate To Rear Axle Housing)
9166160816 91661-60816 Bolt
Frame ([10.1996 - ] (9610- )LY102,112,YY101 ; (9610- )LY101,11 1..T1,T3,TW1,TW2) 39
#OEMPart name
51100 51001-26303 Frame Sub-Assy
51100 90950-01395 Plug, Hole(For Frame)
51100 90950-01420 Plug, Hole(For Frame)
51100 51001-26383 Frame Sub-Assy
51201 51201-25090 Crossmember Sub-Assy, Frame, Front
51203 51203-26112 Crossmember Sub-Assy, Frame, No.2
51204 51203-26120 Crossmember Sub-Assy, Frame, No.3
51205 51204-26031 Crossmember Sub-Assy, Frame, No.4
51209 51209-26030 Crossmember Sub-Assy, Frame, No.5
51225 51225-26010 Bracket, Front Suspension Member, Rh
51341 51342-26012 Gusset, Crossmember, No.4 Lower
51345 51305-26020 Bracket, Rear Spring, Front
51345 51345-26020 Bracket, Rear Spring, Front
51345 51305-25010 Bracket, Rear Spring, Front
51345 51345-26043 Bracket, Rear Spring, Front
51355 51301-25010 Bracket, Rear Spring, Rear Rh
51356 51302-25010 Bracket, Rear Spring, Rear Lh
51393 51393-26010 Gusset, Frame Rear Crossmember, Rh
51397 51397-26010 Bracket, Exhaust Pipe Clamp, No.3
51401 51401-26010 Bracket Sub-Assy, Engine Front Mounting, Rh
51505 51505-26904 Support Sub-Assy, Upper Control Arm
51506 51506-26904 Support Sub-Assy, Upper Control Arm
51701 51711-26080 Bracket Sub-Assy, Cab Mounting, No.1 Rh
51703 51703-26012 Bracket Sub-Assy, Cab Mounting, No.2, Rh
51741 51741-26052 Bracket, Rear Body Mounting, No.1
51741 51742-26022 Bracket, Rear Body Mounting, No.1
51743 51743-26010 Bracket, Rear Body Mounting, No.1
51963 51963-26041 Hook, Transport, Front Rh
51965 51965-26031 Hook, Rear
53901 53901-25010 Duct Sub-Assy, Air
57107 57107-26040 Bracket Sub-Assy, Strut Bar, Rh
57107 57107-26010 Bracket Sub-Assy, Strut Bar, Rh
57108 57108-26040 Bracket Sub-Assy, Strut Bar, Lh
57108 57108-26010 Bracket Sub-Assy, Strut Bar, Lh
9010512233 90105-12233 New Genuine Part
9011910454 90119-10454 New Genuine Part
9011910809 90119-10809 New Genuine Part
9017912020 90179-12020 Nut(For Parking Brake Plate To Rear Axle Housing)
9166160816 91661-60816 Bolt
Front Axle Arm & Steering Knuckle ([10.1996 - ] (9610- )LY10#,11#,YY101) 34
#OEMPart name
4485 04485-26050 Shaft Kit, Upper Suspension Arm
4485 04485-26120 Shaft Kit, Upper Suspension Arm - FRONT SUSPENSION UPPER ARM, RH
43211 43211-26051 Knuckle, Steering, Rh
43212 43212-26021 Knuckle, Steering, Lh
43330 43330-29295 Joint Assy, Lower Ball, Front
43330 43330-29515 Joint Assy, Lower Ball, Front
43346 43346-26010 Protector, Lower Ball Joint Dust Cover
43355 43355-26010 Deflector, Lower Arm Ice, Rh
48066 48066-29075 Arm Sub-Assy, Front Suspension, Upper Rh
48067 48067-29075 Arm Sub-Assy, Front Suspension, Upper Lh
48068 48068-26022 Arm Sub-Assy, Front Suspension, Lower No.1 Rh
48069 48069-26022 Arm Sub-Assy, Front Suspension, Lower No.1 Lh
48167 90105-12284 Bolt(For Torque Arm Setting)
48167 90105-12285 Bolt(For Torque Arm Setting)
48167 48106-26050 Arm, Torque
48190 48190-26020 Cam Assy, Camber Adjust
48198 48198-26010 Cam, Camber Adjust, No.2
48332 48332-35020 Bumper, Front Spring, No.2
48631 90948-02142 Retainer, Cushion(For Front Suspension Upper Arm Rh) - REAR (refer to scheme)
48631 90948-02143 Retainer, Cushion(For Front Suspension Upper Arm) - FRONT (refer to scheme)
48632 48632-26010 Bush, Upper Arm - FRONT (refer to scheme)
48632 48635-26010 Bush, Upper Arm
48654 48061-26010 Bush, Lower Arm
9010114024 90101-14024 New Genuine Part
9010514015 90105-14015 Bolt, Upper Arm Set
9017014008 90170-14008 NUT
9017016023 90170-16023 NUT
9017116005 90171-16005 Nut, Castle(For Tie Rod End)
9017908141 90179-08141 Nut (For Transmission Control Cable)
9017908141 90179-08038 Nut
9017918004 90179-18004 Nut
9025204003 90252-04003 PIN
9462111400 94621-11400 WASHER
9462211600 94622-11600 WASHER
Front Axle Hub ([05.1995 - ] (9505- )LY10#,11#,20#,21#,YY101,201,211..T1,T 2,T3,TW1,TW2) 16
#OEMPart name
43501 43502-26050 Hub Sub-Assy, Front Axle
43501 90942-02047 Bolt, Hub
43510 90311-50005 Seal, Oil (For Front Axle Hub)
43510 90368-34001 Bearing
43510 90368-21001 Bearing, Tapered Roller (For Front Axle Outer Bearing)
43510 90214-20007 Washer, Claw (For Front Axle Hub Rh)
43510 90170-19185 Nut (For Axle Shaft)
43512 43512-26070 Disc, Front
43512 43512-35180 Disc, Front
43514 43514-35010 Cap, Front Hub Grease
43525 43525-22010 Cap, Front Wheel Adjusting Lock
9010110462 90101-10462 BOLT
9011910753 90119-10753 New Genuine Part
9025204002 90252-04002 PIN
9025204005 90252-04005 PIN COTTER
9451201000 94512-01000 Washer, No.1 (For Propeller Shaft & Differential Setting)
Front Bumper & Bumper Stay ([05.1995 - ] (9505- )) 5
#OEMPart name
52111 52101-25070-A0 Bar, Front Bumper
52111 52101-25914 Bar, Front Bumper
52111 52101-25070-H0 Bar, Front Bumper
52111 52101-25070-J0 Bar, Front Bumper
9011908530 90119-08530 New Genuine Part
Front Clearance Lamp ([05.1995 - ] (9505- )) 14
#OEMPart name
81610 81610-37010 Lamp Assy, Parking & Clearance, Rh
81610 90981-13036 Bulb(For Headlamp, No.1)
81611 81611-37010 Lens, Parking & Clearance Lamp, Rh
81614 81614-37010 Gasket, Clearance Lamp
81615 81615-37010 Socket And Wire, Clearance Lamp
81620 81620-37010 Lamp Assy, Parking & Clearance, Lh
81621 81621-37010 Lens, Parking & Clearance Lamp, Lh
81624 81624-37010 Gasket, Clearance Lamp, Lh
8155989124 81559-89124 Moulding, Rear Combination Lamp, Rh
9007502001 90075-02001 New Genuine Part
9007510820 90075-10820 SELFLOCKING NUT
9015960008 90159-60008 SCREW
9018906018 90189-06018 GROMMET
9018906111 90189-06111 CLIP
Front Disc Brake Caliper & Dust Cover ([10.1996 - ] (9610- )LY10#,11#,YY101) 32
#OEMPart name
4465 04465-26020 Pad Kit, Disc Brake, Front
4479 04479-35050 Cylinder Kit, Disc Brake, Front
4945 04945-26031 Shim Kit, Anti Squeal, Front
4947 04947-26010 Fitting Kit, Disc Brake, Front
31478 31478-30010 Bleeder Plug Cap
47547 47547-12010 Plug, Bleeder(For Release Cylinder)
47710 90101-12132 Bolt, Hexagon(For Front Disc Brake Caliper)
47716 47716-26040 Plate, Pad Support, No.1(For Front Disc Brake)
47717 47717-26010 Plate, Pad Support, No.2(For Front Disc Brake)
47721 47721-26050 Mounting, Front Disc Brake Cylinder, Rh
47721 90119-10014 Bolt(For Front Disc Brake Cylinder Mounting)
47721 90119-10249 Bolt(For Front Disc Brake Cylinder Mounting)
47721 90387-16004 Collar(For Front Disc Brake Cylinder Mounting)
47721 90387-16005 Collar(For Front Disc Brake Cylinder Mounting)
47730 47730-26080 Cylinder Assy, Front Disc Brake, Rh
47731 47731-40010 Piston, Front Disc Brake
47731 90520-86005 Ring, Set(For Front Disc Brake Piston)
47744 47744-26040 Shim, Anti-Squeal, No.1(For Front Disc Brake)
47745 47745-26020 Shim, Anti-Squeal, No.2(For Front Disc Brake)
47750 47750-26080 Cylinder Assy, Disc Brake, Lh
47769 47769-40010 Bush, Cylinder Slide, No.1(For Front Disc Brake)
47771 47771-26011 Plate, Pad Wear Indicator, No.1
47775 47775-40010 Boot, Bush Dust(For Front Disc Brake)
47779 47779-40010 Bush, Cylinder Slide, No.2(For Front Disc Brake)
47781 47781-26040 Cover, Disc Brake Dust, Front Rh
47781 90102-12005 Bolt(For Backing Plate To Steering Knuckle Arm Setting)
47781 90171-12011 Nut
47782 47782-26040 Cover, Disc Brake Dust, Front Lh
9020112452 90201-12452 Nut(For Backing Plate To Steering Knuckle Setting)
9025203011 90252-03011 PIN
9165160816 91651-60816 BOLT
9165160816 90080-11396 Bolt
Front Door Lock & Handle ([05.1995 - ] (9505- )) 32
#OEMPart name
67239 67239-95401 Weight, Front Door
67787 67787-37020 Silencer, Front Door Locking Button Knob
69120 69120-37020 Actuator Assy, Front Door Lock, Lh
69205 69205-10040-B1 Handle Sub-Assy, Front Door Inside, Rh
69206 69206-10040-B1 Handle Sub-Assy, Front Door Inside, Lh
69210 69210-37010 Handle Assy, Front Door, Outside Rh
69220 69220-37010 Handle Assy, Front Door Outside, Lh
69238 69238-95J00 Pad, Door Outside Handle
69310 69310-37030 Lock Assy, Front Door, Rh
69310 69310-37050 Lock Assy, Front Door, Rh
69320 69320-37020 Lock Assy, Front Door, Lh
69320 69320-37040 Lock Assy, Front Door, Lh
69410 69410-89103 Plate Assy, Front Door Lock Striker
69701 69701-37010-C0 Link Sub-Assy, Front Door Lock Control, Rh
69702 69702-37010-C0 Link Sub-Assy, Front Door Lock Control, Lh
69711 69711-95403 Link Assy, Front Door Open Control, Rh
69712 69712-95401 Link, Front Door Lock Remote Control, Lh
69741 69741-32010-20 Knob, Front Door Lock Control
69749 69749-20010 Clamp, Front Door Lock Link
69759 69759-20060 Snap(For Rear Door Inside Handle)
69759 69759-20070 Snap(For Rear Door Inside Handle)
9011906110 90119-06110 New Genuine Part
9011906110 90119-06442 BOLT WWASHER
9014860049 90148-60049 Screw Hex Lobular
9014880027 90148-80027 Screw Hex Lobular
9015940202 90159-40202 SCREW WWASHER
9016250008 90162-50008 SCREW
9017906070 90179-06070 Nut(For Steering Inter Shaft Dust Seal Cover)
9017906070 90179-06159 Nut, Rear Wiper Link Pivot, No.1
9018905003 90189-05003 CLIP
9038606021 90386-06021 New Genuine Part
9165160612 91651-60612 BOLT
Front Door Panel & Glass ([05.1995 - ] (9505- )) 56
#OEMPart name
62311 62311-37010-B0 Weatherstrip, Front Door Opening Trim, Rh
62312 62312-37010-B0 Weatherstrip, Front Door Opening Trim, Lh
67001 67001-25010 Panel Sub-Assy, Front Door, Rh
67001 67001-37050 Panel Sub-Assy, Front Door, Rh
67002 67002-37060 Panel Sub-Assy, Front Door, Lh
67002 67002-37061 Panel Sub-Assy, Front Door, Lh
67111 67111-37040 Panel, Front Door, Outer Rh
67112 67112-37050 Panel, Front Door, Outer Lh
67403 67403-37010 Frame Sub-Assy, Front Door, Rear Lower Rh
67404 67404-37010 Frame Sub-Assy, Front Door, Rear Lower Lh
67485 67485-95701 Seal, Front Door Bracket, No.1
67491 67491-25010 Garnish, Front Door Lower Frame Bracket, Rh
67491 67491-95010 Garnish, Front Door Lower Frame Bracket, Rh
67491 67491-37010 Garnish, Front Door Lower Frame Bracket, Rh
67491 67491-95400 Garnish, Front Door Lower Frame Bracket, Rh
67492 67492-37010 Garnish, Front Door Lower Frame Bracket, Lh
67492 67492-95400 Garnish, Front Door Lower Frame Bracket, Lh
67601 67610-37010-B0 Board Sub-Assy, Front Door Trim, Rh
67601 67610-95416-B0 Board Sub-Assy, Front Door Trim, Rh
67601 67610-95417-B3 Board Sub-Assy, Front Door Trim, Rh
67601 67771-12050 Clip, Radiator Grille
67601 90467-06017-B0 Clip, Rear Floor Mat Set
67602 67620-37010-B0 Board Sub-Assy, Front Door Trim, Lh
67602 67620-95422-B0 Board Sub-Assy, Front Door Trim, Lh
67602 67620-95423-B3 Board Sub-Assy, Front Door Trim, Lh
67626 67626-95400 Bracket, Door Trim, No.2
67831 67831-95408 Cover, Front Door Service Hole, Rh
67832 67832-95409 Cover, Front Door Service Hole, Lh
67861 67861-37010 Weatherstrip, Front Door, Rh
67862 67862-37010 Weatherstrip, Front Door, Lh
67867 67867-12150 Clip(For Hood Air Intake Duct Seal)
68101 68111-37080 Glass Sub-Assy, Front Door, Rh
68101 68111-37090 Glass Sub-Assy, Front Door, Rh
68102 68112-37110 Glass Sub-Assy, Front Door, Lh
68102 68112-37120 Glass Sub-Assy, Front Door, Lh
68141 68141-95408 Run, Front Door Glass
68160 68161-95403 Weatherstrip Assy, Front Door Glass, Outer Rh
68161 68211-12080 Clip(For Front Door Glass Outer Weatherstrip)
68170 68171-95409 Weatherstrip Assy, Front Door Glass, Inner
68170 68172-95406 Weatherstrip Assy, Front Door Glass, Inner
68210 68162-95402 Weatherstrip Assy, Front Door Glass, Outer Lh
68211 68211-95402 Clip(For Front Door Glass Outer Weatherstrip)
68211 68212-95400 Clip(For Front Door Glass Outer Weatherstrip)
68211 68211-95401 Clip(For Front Door Glass Inner Weatherstrip Set)
68610 68610-95401 Check Assy, Front Door
68617 68617-20011 Pin(For Door Check)
9011906110 90119-06110 New Genuine Part
9011906110 90119-06442 BOLT WWASHER
9015960047 90159-60047 SCREWWWASHER
9017906070 90179-06070 Nut(For Steering Inter Shaft Dust Seal Cover)
9017906070 90179-06159 Nut, Rear Wiper Link Pivot, No.1
9018906018 90189-06018 GROMMET
9033325001 90333-25001 Plug, Hole(For Hood)
9095006057 90950-06057 New Genuine Part
9356815016 93568-15016 Sensor, Automatic Light Control
9356815016 93568-55016 Screw
Front Door Window Regulator & Hinge ([05.1995 - ] (9505- )) 18
#OEMPart name
68171 68173-22010 Weatherstrip, Front Door Glass Channel
68171 69971-90K00 Filler, Front Door Glass Channel
68710 68710-95702 Hinge Assy, Front Door, Upper Rh
68730 68710-25010 Hinge Assy, Front Door, Upper Rh
69260 69260-10040-B1 Handle Assy, Front Door Window Regulator
69260 90520-01274 Ring, Shaft Snap(For Front Door Window Regulator Handle)
69272 69272-30010-08 Escutcheon, Door Regulator Handle(For Front Door)
69801 69801-37010 Regulator Sub-Assy, Front Door Window, Rh
69801 69810-37010 Regulator Sub-Assy, Front Door Window, Rh
69802 69802-37010 Regulator Sub-Assy, Front Door Window, Lh
69802 69820-37010 Regulator Sub-Assy, Front Door Window, Lh
69901 69901-95404 Channel Sub-Assy, Front Door Glass, Rh
85710 85710-37030 Motor Assy, Power Window Regulator, Rh
85720 85720-37040 Motor Assy, Power Window Regulator, Lh
9011908218 90119-08218 BOLT
9016850040 90168-50040 SCREW TAPPING
9165140612 91651-40612 BOLT
9165140612 90080-11225 New Genuine Part
Front Floor Panel & Front Floor Member ([05.1995 - ] (9505- )) 30
#OEMPart name
51772 51771-37020 Plate, Step
51772 51771-37040 Plate, Step
51772 51772-37010 Plate, Step
58213 58201-25010 Panel, Seat Floor, Rh
58214 58202-37010 Panel, Seat Floor, Lh
58407 58407-25020 Cover Sub-Assy, Engine Service Hole Sub
58407 58407-25140 Cover Sub-Assy, Engine Service Hole Sub
58410 59208-25020 Cover, Engine Service Hole
58424 58424-95405 Packing, Engine Service Hole Cover, No.1
58426 58426-95405 Protector, Engine Service Hole
58444 58444-37010 Packing, Engine Sub Cover
58474 58474-95401 Packing, Engine Sub Cover, No.2
58475 58475-95A01 Packing, Engin Sub Cover, No.3
58936 58936-95J02-C0 Band, Engine Service Hole Cover Support
58939 58939-95J00 Screw, Engine Service Hole Cover Support Band
71901 71901-95704-01 Catch, Engine Service Hole Cover
9011908483 90119-08483 New Genuine Part
9012206009 90122-06009 New Genuine Part
9015960366 90159-60366 New Genuine Part
9015980063 90159-80063 New Genuine Part
9020106204 90201-06204 Washer, Plate(For Steering Tilt Lever)
9020505004 90205-05004 New Genuine Part
9054109126 90541-09126 Cushion, No.1
9095001832 90950-01832 Sub-Sheet, Front Door Service Hole
9165160614 91651-60614 Bolt
9165160820 91651-60820 Bolt, Radiator Side Support Plate
9165160820 91651-B0820 Bolt, Radiator Side Support Plate
9165260816 91652-60816 New Genuine Part
9356755016 93567-55016 Screw
9356755016 93568-55016 Screw
Front Floor Panel & Front Floor Member ([10.1996 - ] (9610- )LY10#,11#,12#,13#,15#,16#,YY101,121,1 31..T1,T2,T3) 62
#OEMPart name
53079 53079-25010 Seal Sub-Assy, Front Fender Apron, Lower
53707 53715-95A01 Apron Sub-Assy, Fender Side, Rh
53708 53716-95A02 Apron Sub-Assy, Fender Side, Lh
53711 53711-25010 Apron, Front Fender, Front Rh
53712 53712-25010 Apron, Front Fender, Front Lh
53721 53721-37010 Apron Sub-Assy, Fender Side, Rh
53722 53722-37020 Apron Sub-Assy, Fender Side, Lh
53727 53727-25030 Shutter, Hot Air Side
53736 53736-25040 Seal, Front Fender Apron, Rh
53737 53737-25050 Seal, Front Fender Apron, Lh
53739 53739-25010 Seal, Front Fender Apron To Frame, Rear
53881 53881-25010 Mudguard, Front Rh
53887 53887-95010 Plate, Mudguard Rubber Set, Front
57011 57011-25010 Member Sub-Assy, Floor, Rh
57011 57011-25030 Member Sub-Assy, Floor, Rh
57012 57012-25010 Menber Sub-Assy
57012 57012-25030 Menber Sub-Assy
57107 57107-25010 Bracket Sub-Assy, Cab Front Mounting, Rh
57108 57108-25010 Bracket Sub-Assy, Cab Front Mounting, Lh
57408 57408-25081 Member Sub-Assy, Front Floor Cross
57408 57408-25221 Member Sub-Assy, Front Floor Cross
57408 90333-25001 Plug, Hole(For Hood)
57511 57509-37010 Reinforcement, Front Floor, Center
58025 58271-37011 Panel Sub-Assy, Floor Side Rail, Fr Rh
58026 58272-37010 Panel Sub-Assy, Floor Side Rail, Fr Lh
58101 58101-25014 Pan Sub-Assy, Front Floor
58101 58111-25300 Pan, Front Floor
58101 53724-95010 Bracket, Clamp(For Floor Panel)
58101 58239-25010 Plate, Belt Anchor Nut
58101 58249-95A00 Bracket, Cable Clamp, No.2
58101 58251-37011 Reinforcement, Front Seat, Front Rh
58101 58252-37011 Brace, Floor Panel, Rear
58101 58295-95A00 Reinforcement, Seat Belt Anchor Floor
58101 82715-95J04 Bracket, Wiring Harness Clamp
58101 90174-06002 New Genuine Part
58101 90174-08008 New Genuine Part
58101 90950-01181 Plug, Hole(For Front Fender Apron)
58101 90950-01731 Plug, Hole(For Luggage Compartment Door Panel)
58101 58101-25100 Pan Sub-Assy, Front Floor
58101 58103-37010 Reinforcement Sub-Assy, Front Floor Side, Lh
58101 58101-25034 Pan Sub-Assy, Front Floor
58101 58101-25110 Pan Sub-Assy, Front Floor
58119 58119-95400 Cover, Front Floor Side, Front
58335 58335-37010 Plate, Floor Side, Front Rh
58336 58336-37010 Plate, Floor Side, Front Lh
64018 64018-95413 Bar Sub-Assy, Body
67868 67868-95401 Clip, Front Mudguard
9010508094 90105-08094 New Genuine Part
9010510086 90105-10086 Bolt, Hexagon(For Rear Caliper)
9011906424 90119-06424 New Genuine Part
9033320001 90333-20001 PLUG
9033335002 90333-35002 Plug, Hole(For Rear Door Panel)
9046708027 90467-08027 Clip(For Hood Air Intake Duct Seal)
9046709037 90467-09037 CLIP
9095001759 90950-01759 PLUG
9095001797 90950-01797 New Genuine Part
9095001807 90950-01807 New Genuine Part
9163140614 91631-40614 БОЛТ BOLT
9165160816 91651-60816 BOLT
9165160816 90080-11396 Bolt
9326018014 93260-18014 New Genuine Part
904670504522 90467-05045-22 Clip(For Front Fender Seal)
Front Panel & Windshield Glass ([05.1995 - ] (9505- )) 40
#OEMPart name
53801 53801-37010 Panel Sub-Assy, Front Side, Rh
53802 53802-37010 Panel Sub-Assy, Front Side, Lh
53821 53821-37020 Protector, Front Side Panel, No.1 Rh
53865 53865-37010 Plate, Front Fender Extension, Rh
53866 53866-37010 Plate, Front Fender Extension, Lh
53903 53903-37010 Garnish Sub-Assy, Front Panel, Lower
53951 53951-37010 Support, Front End Panel, Upper
53952 53952-37010 Support, Front End Panel, Lower
53969 53969-37010 Packing, Air Cleaner Inlet, No.4
55078 55078-37010 Cover Sub-Assy, Front Panel
55078 55078-37030 Cover Sub-Assy, Front Panel
55211 55211-37010 Silencer, Front Panel
55211 55211-37020 Silencer, Front Panel
55700 55700-37011 Panel Assy, Front
55700 55700-37030 Panel Assy, Front
55700 55700-37070 Panel Assy, Front
55711 55711-37030 Panel, Front, Lower
55738 55738-37010 Protector, Front Panel Cover, No.1
55738 55738-37020 Protector, Front Panel Cover, No.1
55739 55739-37010 Protector, Front Panel Cover, No.2
55739 55739-37020 Protector, Front Panel Cover, No.2
55739 55739-37030 Protector, Front Panel Cover, No.2
55785 82712-37010 Pad, Front Panel Cover
56111 56111-37021 Glass, Windshield
56111 56111-37080 Glass, Windshield
56121 56121-37010 Weatherstrip, Windshield
8889737010 88897-37010 Valve, Cooler Magnet
8889737020 88897-37020 Valve, Cooler Magnet
9015960076 90159-60076 SCREW, W/WASHER TAPP
9017906298 90179-06298 NUT
9018906006 90189-06006 Grommet
9038607007 90386-07007 Cap, Front Bumper, Side Support
9046711074 90467-11074 CLIP
9046909005 90469-09005 New Genuine Part
9095001181 90950-01181 Plug, Hole(For Front Fender Apron)
9095001807 90950-01807 New Genuine Part
9165160612 91651-60612 BOLT
9165160820 91651-60820 Bolt, Radiator Side Support Plate
9165160820 91651-B0820 Bolt, Radiator Side Support Plate
9165260614 91652-60614 New Genuine Part
Front Spring & Shock Absorber ([10.1996 - ] (9610- )LY10#,11#,YY101) 46
#OEMPart name
48107 48107-26020 Arm Sub-Assy, Anchor, Rh
48108 48108-26020 Arm Sub-Assy, Anchor, Lh
48161 48161-26070 Spring, Torsion Bar, Rh
48162 48162-26070 Spring, Torsion Bar, Lh
48169 48169-26020 Swivel, Anchor Arm
48173 90101-12104 Bolt, Hexagon(For Anchor Arm Adjusting)
48173 48173-27010 Seat, Anchor Arm Adjuster
48174 48174-34010 Cover, Torsion Bar Dust
48331 48331-26030 Bumper, Front Spring, No.1
48331 48331-26040 Bumper, Front Spring, No.1
48510 48511-29366 Absorber Assy, Shock, Front Rh
48510 48511-29416 Absorber Assy, Shock, Front Rh
48510 90948-01003 Rubber Cushion
48510 90948-02017 Retainer, Cushion, No.1(For Front Shock Absorber)
48510 90948-02002 Retainer, Steering Damper Cushion
48510 48511-29486 Absorber Assy, Shock, Front Rh
48660 48660-26011 Bar Assy, Strut, Rh
48670 48670-26011 Bar Assy, Strut, Lh
48674 48674-26010 Cushion, Strut Bar
48674 90948-02062 Retainer, Cushion(For Strut Bar Cushion)
48674 90387-18005 Collar(For Strut Bar Cushion)
48811 48811-26050 Bar, Stabilizer, Front
48815 48815-26040 Bush, Front Stabilizer Bar, No.1
48817 90948-01002 Cushion
48817 90948-02004 Cushion Retainer
48817 90948-02005 Retainer No.2
48817 90440-14004 Collar(For Stabilizer Bar)
48817 90101-10090 Bolt(For Front Stabilizer)
48817 94184-61001 Nut(For Front Stabilizer Bar)
48823 48823-26050 Cover, Front Stabilizer Bracket
48823 48823-26120 Cover, Stabilizer Link(For Rear)
9011908 90119-08A46 BOLT WWASHER
9010112010 90101-12010 Bolt, Hexagon(For Front Disc Brake Caliper)
9010112157 90101-12157 New Genuine Part
9010510166 90105-10166 BOLT
9017010021 90170-10021 Nut(For Steering Center Arm)
9017012004 90170-12004 NUT
9017012008 90170-12008 NUT
9017012016 90170-12016 New Genuine Part
9017018001 90170-18001 NUT
9020118011 90201-18011 WASHER
9020618001 90206-18001 WASHER
9165160825 91651-60825 Bolt, Hexagon(For Steering Column Bracket)
9165160825 91651-B0825 Bolt, Hexagon(For Steering Column Bracket)
9462111200 94621-11200 New Genuine Part
9462211000 94622-11000 WASHER
Front Steering Gear & Link ([10.1996 - ] (9610- )LY10#,11#,YY101) 80
#OEMPart name
4445 04445-25060 Gasket Kit, Power Steering Gear(For Recirculating Ball)
4455 04455-25040 Gasket Kit, Power Steering Cross Shaft Overhole
40110 40110-26050 Gear Assy,power Steering,rebuilt
44105 90410-06006 Seat, Union(Pressure Control Valve Assy)
44107 44107-26030 Housing Sub-Assy, Power Steering Gear
44107 90364-32001 Bearing, Needle Roller(For Power Steering Gear Housing)
44107 90301-33007 Ring, O(For Power Steering Gear Housing)
44107 90301-65145 Ring, O(For Power Steering Gear Housing)
44107 96711-19010 Ring, O(For Oil Level Gage Guide)
44107 90562-31003 Ring(For Power Steering Gear Housing)
44107 90562-32001 Ring(For Power Steering Gear Housing)
44107 90521-46125 Ring, Hole Snap(For Power Steering Gear Housing)
44107 90312-32001 Seal, Oil(For Power Steering Gear Housing)
44108 44108-60010 Cover Sub-Assy, Side
44108 90301-64002 Ring, O(For Side Cover)
44110 44110-26050 Gear Assy, Power Steering
44111 90170-22058 Nut, Hexagon(For Cross Shaft To Pitman Arm Setting)
44111 44111-60010 Shaft, Cross
44114 90562-67002 Ring(For Power Piston Nut)
44114 90301-64005 Ring, O(For Power Piston Nut)
44120 44120-26040 Valve Assy, W/ball Nut
44142 44142-22020 Nut, Lock
44251 45411-26100 Arm, Pitman
44257 45357-60030 Screw, Cross Shaft Adjusting
44257 90210-10001 Washer, Seal(For Cross Shaft Adjusting Screw)
44457 44457-26050 Bracket, Tube Support, No.1
45046 45046-39235 End Sub-Assy, Tie Rod
45046 45046-39385 End Sub-Assy, Tie Rod
45046 90171-14042 Nut, Castle(For Pitman Arm)
45312 45312-26160 Bracket, Steering Gear Housing
45403 45403-26081 Bracket Sub-Assy, Center Arm
45403 90311-25004 Seal, Oil(For Center Arm Bracket)
45403 90501-30369 Spring, Compression(For Center Arm Shaft Set)
45403 90345-06014 Plug (For Ball Joint)
45406 45406-29175 Rod Sub-Assy, Tie, Rh
45409 90201-14519 Washer, Plate(For Idler Arm Rubber Bush)
45409 94184-61401 Nut(For Idler Arm Support)
45409 90385-18068 Bush(For Idler Arm)
45409 90304-31012 Seal, Dust(For Idler Arm Support)
45421 45421-26061 Arm, Steering Center
45422 45422-26010 Shaft, Center Arm
45434 45434-26011 Cap, Center Arm Bracket
45436 45436-26010 Seat, Center Arm Shaft
45436 45436-28010 Seat, Center Arm Shaft
45440 45440-29255 Link Assy, Steering Drag
45450 45450-29185 Rod Assy, Steering Relay
45460 45460-29415 Rod Assy, Tie, Rh
45461 45465-35020 Rod, Steering Tie
45466 45466-30020 Clamp, Tie Rod End
45490 45490-29515 Arm Assy, Steering Idler
45490 90171-12028 Nut, Castle(For Pitman Arm)
45611 45611-26040 Arm, Steering Knuckle, Rh
45611 90106-12005 Bolt, Round Hexagon (For Steering Knuckle Stopper Bolt)
45612 45612-26040 Arm, Steering Knuckle, Lh
45619 45619-26020 Cover, Knuckle Stopper
9010108057 90101-08057 BOLT
9010512118 90105-12118 New Genuine Part
9010512234 90105-12234 New Genuine Part
9010514085 90105-14085 New Genuine Part
9010514086 90105-14086 New Genuine Part
9010514143 90105-14143 New Genuine Part
9011910070 90119-10070 New Genuine Part
9017010208 90170-10208 NUT
9017012018 90170-12018 Nut (For Propeller Shaft)
9017014012 90170-14012 Nut, Rack End Lock
9017912025 90179-12025 Nut (For Rear Axle Carrier)
9017914019 90179-14019 Nut
9111150816 91111-50816 Bolt
9413000802 94130-00802 Nut, No.1 (For Center Support Bearing)
9413000802 90170-A0001 New Genuine Part
9413061600 94130-61600 Nut, Hexagon(for Sector Shaft To Pitman Arm Setting)
9451102200 94511-02200 WASHER
9451200800 94512-00800 Washer, No.1 (For Propeller Shaft & Differential Setting)
9453100800 94531-00800 Washer (For Transfer Shift Outer Lever)
9453101200 94531-01200 WASHER
9453101600 94531-01600 WASHER
9461311600 94613-11600 New Genuine Part
9462111200 94621-11200 New Genuine Part
9462111400 94621-11400 WASHER
9538103025 95381-03025 PIN
Front Turn Signal Lamp ([05.1995 - ] (9505- )) 8
#OEMPart name
81510 81510-37050 Lamp Assy, Front Turn Signal, Rh
81510 81511-37050 Lens, Front Turn Signal Lamp, Rh
81510 99132-11210 Bulb (12V 21W)
81515 90075-99092 Fog Lamp Socket Plug Assy
81520 81520-37050 Lamp Assy, Front Turn Signal, Lh
81520 81521-37050 Lens, Front Turn Signal Lamp, Lh
9007502024 90075-02024 New Genuine Part
9018905019 90189-05019 New Genuine Part
Fuel Filter ([05.1995 - ] (9505- )3L,5L..LY10#,11#,12#,13#,15#,16#..CBU ,IV3) 18
#OEMPart name
19529 19529-54010 Clamp
23303 23303-64010 Element Sub-Assy, Fuel Filter
23303 23303-64010-00 233036401000
23322 23322-64010 Drain Plug (For a Level Warning Switch)
23322 23344-54010 O-Ring (For Drain Plug)
23338 23344-64010 O-Ring (For Level Warning Switch)
23380 23380-54790 Cap Assy, Fuel Filter
23380 23380-54800 Cap Assy, Fuel Filter
23910 23910-54080 Heater Assy, Fuel
23921 23921-54360 Support, Fuel Filter
84461 84461-60040 Switch, Level Warning
2334754010 23347-54010 Clip, Cord
9017908038 90179-08038 Nut
9162140820 91621-40820 Bolt
9162140840 91621-40840 New Genuine Part
9162161020 91621-61020 Bolt(For Transaxle & Engine Setting)
9162161020 91622-B1020 Bolt(For Transaxle & Engine Setting)
9331915008 93319-15008 SCREW
Fuel Tank & Tube ([10.1996 - ] (9610- )LY10#,11#,12#,13#,15#,16#..CBU,IV3) 39
#OEMPart name
77017 77017-26121 Tube Sub-Assy, Fuel And Evaporation Vent
77017 77169-14020 Gasket, Fuel Tank Vent
77018 77018-26140 Valve Sub-Assy, Fuel Vapour Separate
77018 77018-37140 Valve Sub-Assy, Fuel Vapour Separate
77018 90977-02001 Orifice, Fuel Vapour
77022 95333-06030 Hose, Fuel
77022 95338-06030 HOSE, FUEL
77022 95333-08020 Hose, Lpg Injector
77022 95337-08020 Hose, Fuel(For Fuel Evaporative Separator) - FUEL, NO.1(FOR RETURN TUBE, NO.1)
77023 77023-32010 Filter Sub-Assy, Fuel Suction Tube
77100 77001-26410 Tank Assy, Fuel
77100 77001-26420 Tank Assy, Fuel
77100 90105-12116 Plug(For Fuel Tank)
77100 90430-12245 Gasket(For Fuel Tank)
77100 77001-26560 Tank Assy, Fuel
77251 77205-26040 Tube, Fuel Main
77251 90447-14045 Hose Or Pipe, Fuel(For Injection Pump To Fuel Filter)
77255 95333-06020 Hose, Fuel(For Injection Pump To Fuel Pipe)
77255 95337-06020 Hose, Differential Pressure Control
77277 90447-12109 Hose, Fuel, No.1(For Return Tube, No.1)
77295 77295-27010 Grommet, Fuel Tube
77601 77601-26060 Band Sub-Assy, Fuel Tank, No.1
77603 77603-26030 Band Sub-Assy, Fuel Tank, No.2
77611 77653-25010 Pin (For Fuel Tank Band)
77633 77501-25091 Bracket Sub-Assy, Fuel Tank
77651 77651-26040 Packing, Fuel Tank Bracket
77701 90917-10067 Valve, Check (For Main Fuel Tank)
9011908 90119-08A46 BOLT WWASHER
9011910571 90119-10571 New Genuine Part
9015940155 90159-40155 SCREW WWASHER
9017910016 90179-10016 Nut(For Counter Gear Shaft)
9017910016 90179-10132 Nut
9046713007 90467-13007 Clamp Or Clip(For Water By-Pass Hose No.2)
9046713007 96132-51300 Clip(For Ventilation Hose No.2)
9162640616 91626-40616 New Genuine Part
9413001002 94130-01002 Nut, Booster Sleeve Cylinder
9461211001 94612-11001 Washer, Plate (For Center Support Bearing Housing)
9613230600 96132-30600 Clip(For Actuator Hose)
9613230600 96132-51100 Clip (For Hose)
Gear Shift Fork & Lever Shaft (Mtm) ([05.1995 - ] G54 (9505- )LY10#,11#,201,YY101,201..MTM..ST..125 ,1T) 52
#OEMPart name
33027 90254-05001 Pin, Slotted Spring(For Shift Lever Shaft Set)
33203 90311-18002 Seal, Oil(For Extension Housing Rear)
33205 33262-28020 Shaft Sub-Assy, Select Lever
33205 90313-13001 Seal, Oil(For Shift Lever Shaft)
33205 90201-13029 Washer(For Outer Lever Oil Setting)
33205 90501-18044 Spring, Compression(For Select Return)
33208 33271-28010 Housing Sub-Assy, Shift Lever Shaft
33208 96411-41200 Plug, Tight, No.1
33211 33211-28010 Fork, Reverse Shift
33212 33212-26030 Fork, Gear Shift, No.1
33213 90105-06143 Bolt(For Shift Fork Set)
33213 33220-26010 Fork, Gear Shift, No.2
33214 33214-26020 Fork, 5Th Shift
33221 33221-28010 Arm, Reverse Shift
33221 96160-01000 Ring, E(For Clutch Booster Air Valve)
33225 33225-35030 Shoe, Shift Arm
33225 96160-00800 Ring, E(For Counter Weight)
33228 33228-28010 Bracket, Reverse Shift Arm
33228 90253-11001 Pin, Ring(For Camshaft Bearing Cap Setting)
33231 33231-28020 Head, Reverse Shift
33231 90360-10003 Ball(For Transmission Oil Pump Cover)
33231 90520-12006 Ring(For Reverse Shift Head)
33232 33232-28020 Head, 1St & 2Nd Shift
33241 33244-28011 Shaft, Reverse Shift Fork
33242 33242-26020 Shaft, Gear Shift Fork, No.1
33243 33243-35051 Shaft, Gear Shift Fork, No.2
33245 33245-26010 Shaft, 5Th Shift Fork
33251 33251-28030 Lever, Shift & Select
33253 33253-26040 Lever, Shift Outer, No.1
33253 33281-16020 Pin, Lever Lock (For Shift Outer Lever)
33257 33257-26050 Lever, Select Outer
33261 33261-28030 Shaft, Shift & Select Lever
33264 90361-10002 Pin, Or Ball, Shift Inter Lock, No.1
33264 90361-10003 Pin, Or Ball, Shift Inter Lock, No.1
33265 90250-05020 Pin, Straight (For Shift & Select Lever Shaft)
33272 33272-28010 Gasket, Shift Lever Shaft Housing
33275 90341-12008 Plug, W/head Straight Screw(For Transfer Adapter)
33275 90501-14132 Spring, Compression (For Shift Detent Ball Low Side)
33276 90501-14123 Spring, Compression (For Shift Detent Ball Low Side)
33276 33276-28011 Seat(For Select Return Spring)
33282 33282-35010 Pin, Lever Lock (For Shift Outer Lever)
33283 33283-27010 Pin, Reverse Restrict, No.1
33283 90504-10008 Spring, Compression (For Reverse Restrict Pin)
33283 90254-04015 Pin, Slotted Spring (For Reverse Restrict Pin)
33555 33555-28010 Boot, Shift Lever
9011908333 90119-08333 BOLT
9161160850 91611-60850 Bolt(For Rocker Support Set)
9413060600 94130-60600 Nut, Wire Adjusting, No.1
9413060800 94130-60800 Nut(For Clutch Pedal Stopper)
9413060800 90170-A0003 New Genuine Part
9451200800 94512-00800 Washer, No.1 (For Propeller Shaft & Differential Setting)
9453100600 94531-00600 Washer(For Outer Lever Oil Setting)
Headlamp ([05.1995 - ] (9505- )) 10
#OEMPart name
81105 81105-37011 Housing Sub-Assy, Headlamp, Rh
81106 81106-37011 Housing Sub-Assy, Headlamp, Lh
81110 81110-37011 Headlamp Assy, Rh
81110 90981-22003 Bulb(For Headlamp, No.1)
81110 90981-13058 Bulb(For Headlamp, No.1) (HB2, 12V, 60W 55W)
81139 81139-87641 Ring, Sealed Beam Mounting, No.2 Rh
81150 81150-37011 Headlamp Assy, Lh
81210 99132-11270 Bulb, Fog Lamp
81515 81515-12520 Wire Sub-Assy, Front Turn Signal Lamp Body
9015960339 90159-60339 New Genuine Part
Heating & Air Conditioning - Compressor ([05.1995 - ] (9505- )) 41
#OEMPart name
88301 88412-30430 Rotor Sub-Assy, Magnet Clutch
88301 88412-2A060 Rotor Sub-Assy, Magnet Clutch
88302 88411-22280 Stator Sub-Assy, Magnet Clutch
88320 88320-26480 Compressor Assy, Cooler
88320 88320-35H92 Compressor Assy, Cooler
88330 88335-14020 Washer
88403 88403-30290 Hub Sub-Assy, Magnet Clutch
88410 88410-25090 Clutch Assy, Magnet
88431 88431-25210 Bracket, Compressor Mounting, No.1
88440 88440-26070 Pulley Assy, Idle
88440 88440-35030 Pulley Assy, Idle
88444 88444-60070 Bracket, Idle Pulley
88446 88446-35030 Bolt, Idle Pulley
88469 88469-30280 Collar, Adjusting
88595 90099-10015 Bearing(For Alternator Rotor)
88688 88569-60070 Bracket, Cooler Compressor
8844660020 88446-60020 Bolt, Idle Pulley
8868825200 88688-25200 Bracket, Cooler
8868837320 88688-37320 Bracket, Cooler Compressor
8868850250 88688-50250 Bracket, Cooler Diaphragm
9009904306 90099-04306 Bolt, Idle Pulley
9009904321 90099-04321 Bolt, Idle Pulley
9009904349 90099-04349 Bolt, Magnet Clutch Setting
9009904950 90099-04950 BOLT
9009907053 90099-07053 Ring, Snap (For Cooler Idle Pulley)
9009907087 90099-07087 Bearing, Magnet Clutch
9009907114 90099-07114 Ring, Snap (For Magnet Clutch)
9009907125 90099-07125 Ring, Snap
9011908225 90119-08225 BOLT
9011908474 90119-08474 Bolt, Compressor, No.1
9011908474 91671-80835 Bolt, Compressor, No.1
9011908720 90119-08720 BOLT WWASHER
9011910367 90119-10367 BOLT
9011912160 90119-12160 BOLT WWASHER
9017910016 90179-10016 Nut(For Counter Gear Shaft)
9017910016 90179-10132 Nut
9165161025 91651-61025 Bolt with washer
9331915008 93319-15008 SCREW
9411040800 94110-40800 Nut(For Steering Damper)
9411040800 94130-00802 Nut, No.1 (For Center Support Bearing)
9451100800 94511-00800 WASHERSPRING
Heating & Air Conditioning - Compressor ([05.1995 - ] ﾚｲﾄｳｼﾔ (9505- )LY10#,11#,15#,16#,20#,21#) 12
#OEMPart name
88431 88431-25210 Bracket, Compressor Mounting, No.1
8857825050 88578-25050 Paking, Cooler Air Duct
9009140605 90091-40605 New Genuine Part
9009301301 90093-01301 New Genuine Part
9009904208 90099-04208 New Genuine Part
9009904553 90099-04553 New Genuine Part
9010508101 90105-08101 New Genuine Part
9011910367 90119-10367 BOLT
9161160835 91611-60835 Bolt(For Clutch Release Cylinder Setting)
9162161022 91621-61022 New Genuine Part
9162161022 91622-61022 BOLT WWASHER
9451101000 94511-01000 Washer(For Rear Drive Shaft)
Heating & Air Conditioning - Control & Air Duct ([05.1995 - ] CONTROL (9505- )) 10
#OEMPart name
55519 55519-37010 Plate, Heater Control Name
55519 55519-37020 Plate, Heater Control Name
55905 55905-89115 Knob, Heater Control
55906 55906-37020 Cable Sub-Assy, Heater Control
55907 55907-37020 Cable Sub-Assy, Water Valve Control
55908 55908-37010 Cable Sub-Assy, Air Inlet Damper Control
55909 55909-37010 Cable Sub-Assy, Airmix Damper Control
55910 55910-37020 Control Assy, Heater Or Boost Ventilator
5594237010 55942-37010 Guard, Heater Control
9356015016 93560-15016 New Genuine Part
Heating & Air Conditioning - Control & Air Duct ([05.1995 - ] DUCT (9505- )) 16
#OEMPart name
55843 55843-37010 Duct, Heater To Register, No.1
55845 55845-37010 Duct, Heater To Register, No.3
55846 55846-37010 Duct, Heater To Register, No.4
55847 55847-37010 Duct, Heater To Register, No.5
87201 87201-37010 Duct Sub-Assy, Air, No.1
87211 87211-37020 Duct, Air, No.1
87211 87211-37070 Duct, Air, No.2
88539 88539-37020 Hose, Cooler Unit Drain, No.1
8868837020 88688-37020 Bracket, Cooler Diaphragm
9011906056 90119-06056 New Genuine Part
9011906056 90119-06442 BOLT WWASHER
9015960096 90159-60096 New Genuine Part
9046708150 90467-08150 Clip(For Luggage Compartment Trim Cover)
9046709145 90467-09145-B0 Clip(For Glove Compartment)
9356715016 93567-15016 New Genuine Part
9356715016 93568-55016 Screw
Heating & Air Conditioning - Cooler Piping ([05.1995 - ] ﾚｲﾄｳｼﾔ (9505- )LY10#,111,12#,13#,151,161,YY101,121,1 31) 66
#OEMPart name
87138 87138-37020 Resistor, Blower
88374 88374-30010 Valve, Service, No.1
88375 88375-30280 Cap, Service Valve (For Cooler Pipe)
88453 88453-95A01 Fan, Cooling (For Condenser)
88454 88454-25050 Shroud, Fan
88460 88460-25160 Condenser Assy, Cooler
88471 88471-20050 Receiver & Dryer Assy, Cooler
88471 88471-34010 Receiver & Dryer Assy, Cooler
88472 88472-25070 Bracket, Receiver Tank, No.1
88479 90986-02007 Freon Gas, Air Conditioner (Drum, Cooler Refrigerant)
88479 90986-02008 Freon Gas, Air Conditioner (Drum, Cooler Refrigerant)
88550 87104-25620 Motor Assy, Blower (For Condenser)
88590 88590-25050 Blower Assy, W/shroud
88648 88648-25120 Wiring, Cooler
88711 88711-25290 Hose, Cooler Refrigerant Discharge, No.1
88712 88712-25360 Hose, Cooler Refrigerant Suction, No.1
88721 88721-25170 Hose, Liquid, A
88721 88721-25180 Hose, Liquid, B
88723 88723-20030 Plate, Caution, No.1
88723 88733-30040 Label, Cooler Service Caution
887182 88718-2B290 Clamp(For Cooler Refrigerant Pipe), No.4
8868895 88688-95A57 Bracket, Cooler Condenser, No.2
8868895 88688-95A60 Bracket, Cooler Condenser, No.1
8837530290 88375-30290 Cap, Service Valve (For Cooler Pipe)
8846712030 88467-12030 Cushion, Cooler Condenser, No.1
8856912190 88569-12190 Clamp (for Cooler Relay)
8859287002 88592-87002 Packing, Cooling Unit, No.1
8868825080 88688-25080 Bracket, Cooler Diaphragm
8868825090 88688-25090 Bracket, Cooler Diaphragm
8868825150 88688-25150 Bracket, Cooler Diaphragm
8868825170 88688-25170 Bracket, Cooler Diaphragm
8868836120 88688-36120 Bracket, Cooler Diaphragm
8871410040 88714-10040 Insulator, Cooler Refrigerant Pipe, No.1
8871426030 88714-26030 Hose, Cooler Refrigerant Liquid, No.1
8871812790 88718-12790 Pipe, Cooler Refrigerant Suction, No.2
8871814450 88718-14450 Clamp(For Cooler Refrigerant Pipe), No.1
8871825040 88718-25040 Pipe, Cooler Refrigerant Suction, No.2
8871825110 88718-25110 Pipe, Cooler Refrigerant Suction, No.2
8871825130 88718-25130 Pipe, Cooler Refrigerant Suction, No.2
8871836190 88718-36190 Pipe, Cooler Refrigerant Suction, No.2
9004464009 90044-64009 CLAMP
9009902133 90099-02133 New Genuine Part
9009904957 90099-04957 New Genuine Part
9009905164 90099-05164 Nut
9009914119 90099-14119 Ring, O(For Cooler Refrigerant Liquid Pipe)
9009914119 90099-14119-TH O RING
9009914120 90099-14120 O-Ring, Cooler Evaporator No.1(Discharge)
9009914121 90099-14121 O-Ring, Cooler Evaporator No.1(Suction)
9009914122 90099-14122 O-RING
9017906115 90179-06115 Nut (For Rear Wiper Arm Setting)
9017908123 90179-08123 Nut (For Front Wiper Arm Setting)
9095001011 90950-01011 Grommet(For Upper Back Panel)
9095001401 90950-01401 New Genuine Part
9151160630 91511-60630 BOLT
9165160620 91651-60620 BOLTWWASHER
9165160820 91651-60820 Bolt, Radiator Side Support Plate
9165160820 91651-B0820 Bolt, Radiator Side Support Plate
9165160825 91651-60825 Bolt, Hexagon(For Steering Column Bracket)
9165160825 91651-B0825 Bolt, Hexagon(For Steering Column Bracket)
9338516016 93385-16016 New Genuine Part
9338516020 93385-16020 New Genuine Part
9338516020 93385-26020 New Genuine Part
9338516025 93385-16025 New Genuine Part
9338516030 93385-16030 Lever, Cooler Control, No.1
9338518016 93385-18016 New Genuine Part
9354014012 93540-14012 Screw
Heating & Air Conditioning - Cooler Piping ([05.1999 - ] (9905- )LY102,112,122,132,152,162,YY101,121,1 31) 61
#OEMPart name
87138 87138-37020 Resistor, Blower
88374 88374-30010 Valve, Service, No.1
88375 88375-30280 Cap, Service Valve (For Cooler Pipe)
88453 88453-95A01 Fan, Cooling (For Condenser)
88454 88454-25050 Shroud, Fan
88460 88460-25160 Condenser Assy, Cooler
88461 88461-25030 Core, Cooler Condenser
88471 88471-20050 Receiver & Dryer Assy, Cooler
88471 88471-34010 Receiver & Dryer Assy, Cooler
88472 88472-25070 Bracket, Receiver Tank, No.1
88479 90986-02007 Freon Gas, Air Conditioner (Drum, Cooler Refrigerant)
88479 90986-02008 Freon Gas, Air Conditioner (Drum, Cooler Refrigerant)
88550 87104-25620 Motor Assy, Blower (For Condenser)
88590 88590-25050 Blower Assy, W/shroud
88648 88648-25120 Wiring, Cooler
88711 88711-25290 Hose, Cooler Refrigerant Discharge, No.1
88712 88712-25360 Hose, Cooler Refrigerant Suction, No.1
88716 88716-25210 Pipe, Cooler Refrigerant Liquid, A
88721 88721-25170 Hose, Liquid, A
88721 88721-25180 Hose, Liquid, B
88723 88723-20030 Plate, Caution, No.1
88723 88733-30040 Label, Cooler Service Caution
88897 88897-25020 Grommet, Cooler
8837530290 88375-30290 Cap, Service Valve (For Cooler Pipe)
8868825210 88688-25210 Bracket, Cooler Diaphragm
8868825220 88688-25220 Bracket, Cooler Diaphragm
8868825230 88688-25230 Bracket, Cooler Diaphragm
8868825270 88688-25270 Bracket, Cooler Diaphragm
8868825280 88688-25280 Bracket, Cooler Diaphragm
8871814450 88718-14450 Clamp(For Cooler Refrigerant Pipe), No.1
8871825170 88718-25170 Pipe, Cooler Refrigerant Suction, No.2
8871825180 88718-25180 Pipe, Cooler Refrigerant Suction, No.2
8871825190 88718-25190 Pipe, Cooler Refrigerant Suction, No.2
8871837340 88718-37340 Pipe, Cooler Refrigerant Suction, No.2
8888825010 88888-25010 Band (for Cooler Compressor)
8888825020 88888-25020 Band (for Cooler Compressor)
8889725030 88897-25030 Valve, Cooler Magnet
9009902133 90099-02133 New Genuine Part
9009904957 90099-04957 New Genuine Part
9009905164 90099-05164 Nut
9009914119 90099-14119 Ring, O(For Cooler Refrigerant Liquid Pipe)
9009914119 90099-14119-TH O RING
9009914120 90099-14120 O-Ring, Cooler Evaporator No.1(Discharge)
9009914121 90099-14121 O-Ring, Cooler Evaporator No.1(Suction)
9009914122 90099-14122 O-RING
9010506165 90105-06165 New Genuine Part
9010506165 91511-60635 Bolt
9017908123 90179-08123 Nut (For Front Wiper Arm Setting)
9046400772 90464-00772 New Genuine Part
9095901532 90959-01532 New Genuine Part
9151160625 91511-60625 Bolt(For Cylinder Head Cover)
9151160625 91511-J0625 Bolt(For Cylinder Head Cover)
9151160630 91511-60630 BOLT
9165140625 91651-40625 New Genuine Part
9165140816 91651-40816 BOLT
9165160820 91651-60820 Bolt, Radiator Side Support Plate
9165160820 91651-B0820 Bolt, Radiator Side Support Plate
9165160825 91651-60825 Bolt, Hexagon(For Steering Column Bracket)
9165160825 91651-B0825 Bolt, Hexagon(For Steering Column Bracket)
9338516016 93385-16016 New Genuine Part
9354014012 93540-14012 Screw
Heating & Air Conditioning - Cooler Unit ([05.1995 - ] (9505- )) 41
#OEMPart name
82650 82650-12020 Breaker Assy, Wiring Circuit, No.1
87116 87116-14010 Spring, Heater Case Fastening
88501 88501-35021 Evaporator Sub-Assy, Cooler, No.1
88508 88508-37020 Filter Sub-Assy, Clean Air
88510 88510-25060 Unit Assy, Cooler
88510 88510-25070 Unit Assy, Cooler
88515 88515-20100 Valve, Cooler Expansion
88515 88515-22240 Valve, Cooler Expansion
88539 88539-37020 Hose, Cooler Unit Drain, No.1
88578 88578-20470 Packing, Cooling Unit, No.1
88625 88625-3A020 Thermistor, Cooler, No.1
88625 88625-3A090 Thermistor, Cooler, No.1
88626 88626-28010 Holder, Thermistor
88630 88630-95702 Relay, Heater Radiator
88648 88648-25150 Wiring, Cooler, No.1
88650 88650-25080 Amplifier Assy, Cooler Stabilizer
88710 88710-25160 Tube Assy, Air Conditioner
8271112200 82711-12200 Clamp (For Fuel Lid Lock Control Cable)
8271114890 82711-14890 Wire, Fuse To Fuse(for Combustion Heater)
8851837010 88518-37010 Holder, Cooling Unit Door
8868837230 88688-37230 Bracket, Cooler Diaphragm
8868837240 88688-37240 Bracket, Cooling Unit, No.1
8889737010 88897-37010 Valve, Cooler Magnet
8889737020 88897-37020 Valve, Cooler Magnet
9009900968 90099-00968 Screw(For Air Conditioner Unit)
9009904381 90099-04381 BOLT
9009914119 90099-14119 Ring, O(For Cooler Refrigerant Liquid Pipe)
9009914119 90099-14119-TH O RING
9009914121 90099-14121 O-Ring, Cooler Evaporator No.1(Suction)
9011906056 90119-06056 New Genuine Part
9011906056 90119-06442 BOLT WWASHER
9015950322 90159-50322 SCREW WWASHER
9015960096 90159-60096 New Genuine Part
9017906115 90179-06115 Nut (For Rear Wiper Arm Setting)
9046320473 90463-20473 New Genuine Part
9338515012 93385-15012 SCREW
9338516016 93385-16016 New Genuine Part
9356615512 93566-15512 New Genuine Part
9356615512 93568-55012 SCREW
9358015012 93580-15012 New Genuine Part
9358015012 90099-00324 New Genuine Part
Heating & Air Conditioning - Heater Unit & Blower ([05.1995 - ] ﾌﾛﾝﾄ (9505- )) 17
#OEMPart name
55076 55076-37010 Net Sub-Assy, Air Duct
55076 55076-37050 Net Sub-Assy, Air Duct
87104 87104-37070 Motor Sub-Assy, Heater Blower
87105 87105-37010 Fan Sub-Assy, Heater Blower
87116 87116-37010 Spring, Heater Case Fastening
87130 87130-37061 Blower Assy, Heater, Front
87138 87138-37080 Resistor, Heater Blower
87150 87150-37031 Radiator Assy, Heater
87150 87150-37051 Radiator Assy, Heater
87150 87150-37130 Radiator Assy, Heater
87150 87150-37140 Radiator Assy, Heater
8271537300 82715-37300 Bracket,wiring Harness Clamp
8712837010 87128-37010 Grommet, Heater
9017908057 90179-08057 NUT
9165160618 91651-60618 Bolt(For Oil Receiver Pipe)
9165160820 91651-60820 Bolt, Radiator Side Support Plate
9165160820 91651-B0820 Bolt, Radiator Side Support Plate
Heating & Air Conditioning - Vacuum Piping ([05.1999 - ] (9905- )LY102,112,122,132,152,162,202,212) 8
#OEMPart name
88691 25860-54230 Valve Assy, Vacuum Switching, No.1
9017908146 90179-08146 Nut
9017908146 90179-08204 Nut
9033903002 90339-03002 PLUG
9041304005 90413-04005 Way, 3, No.1 (For Front Drive Shift)
9046400082 90464-00082 Clamp(For Resistive Cord)
9046400604 90464-00604 New Genuine Part
9099992002 90999-92002 Air Hose (300 mm)
Heating & Air Conditioning - Water Piping ([05.1995 - ] (9505- )DSL) 16
#OEMPart name
87208 87208-25170 Pipe Sub-Assy, Heater Water
87240 87240-37010 Valve Assy, Heater Water
87245 99556-30300 Hose, Heater Water, Inlet A
87245 99556-30500 Hose, Heater Water, Inlet A
87245 99556-30100 Hose, Water Inlet
8712425010 87124-25010 Clamp, Heater
8712437010 87124-37010 Clamp, Heater
8712495400 87124-95400 Clamp, Heater
9046022073 90460-22073 Clip(For Ventilation Hose No.2)
9046022073 90467-19022 Clip(For Ventilation Hose No.2)
9046024039 90460-24039 Clamp Or Clip, Hose(For Oil Cooler Hose)
9046024039 90467-21010 Clip(For Ventilation Hose No.2)
9046722004 90467-22004 Clip(For Ventilation Hose No.2)
9165140816 91651-40816 BOLT
9611210250 96112-10250 Clamp Or Clip, Hose(For Oil Cooler Hose)
9613442100 96134-42100 Clip(For Water By-Pass Hose Assy)
Horn ([05.1995 - ] (9505- )) 7
#OEMPart name
86520 86520-25100 Horn Assy, Low Pitched
86520 86520-25110 Horn Assy, Low Pitched
86522 86522-25100 Protector, Horn
86591 86591-25020 Bracket, Horn
9011908300 90119-08300 New Genuine Part
9011908827 90119-08827 New Genuine Part
9017908191 90179-08191 New Genuine Part
Ignition Coil & Spark Plug ([05.1995 - ] (9505- )3L,5L) 12
#OEMPart name
19850 19850-05010 Plug Assy, Glow
19850 19850-54120 Plug Assy, Glow
19856 90179-04030 Nut, Connecting(For Glow Plug)
19856 90189-04024 Grommet, Screw(For Glow Plug)
19871 19871-54020 Connector, Glow Plug No.1
19871 19871-05010 Connector, Glow Plug No.1
2862257010 28622-57010 Insulator, Glow Plug Resistor, No.1
2862354010 28623-54010 Insulator, Glow Plug Resistor, No.2
9011606041 90116-06041 Bolt, Stud(For Intake Manifold To Glow Plug Connector No.1)
9011606041 90116-06095 Bolt, Stud(For Head To Cylinder Head Cover)
9017906158 90179-06158 Nut, Rear Wiper Link Pivot, No.2
9461310601 94613-10601 Washer (For Primary Regulator Valve)
Indicator ([05.1995 - ] (9505- )) 2
#OEMPart name
81850 81850-37040 Lamp Sub-Assy, Ash Receptacle
81850 90981-11014 Bulb, Position Indicator Lamp
Injection Nozzle ([05.1995 - ] (9505- )3L,5L) 43
#OEMPart name
11106 11106-54170 Chamber Sub-Assy, Combustion
11106 11106-54171 Chamber Sub-Assy, Combustion
11106 11165-54030 Shim(For Combustion Chamber)
11161 90250-02046 Pin, Straight(For Combustion Chamber)
11176 11176-64010 Seat, Injection Nozzle
11177 11177-54020 Gasket, Injection Nozzle Seat
23600 23600-59266 Holder & Nozzle Set, Nozzle
23600 23600-59315 Holder & Nozzle Set, Nozzle
23618 23618-54730 Spring, Nozzle Holder Pressure
23619 23619-64010 Pin, Nozzle Holder Pressure
23620 23620-59115 Nozzle Assy
23624 23624-64040 Nut, Nozzle Retaining
23624 23624-64041 Nut, Nozzle Retaining
23628 23628-64010 Nut(For Ring Packing Setting)
23629 23629-54080 Piece, Distance(For Nozzle)
23631 23631-64010 Washer(For Nozzle Holder Pressure Spring)
23631 23631-64012 Washer(For Nozzle Holder Pressure Spring)
23631 23631-64014 Washer(For Nozzle Holder Pressure Spring)
23631 23631-64016 Washer(For Nozzle Holder Pressure Spring)
23631 23631-64018 Washer(For Nozzle Holder Pressure Spring)
23631 23632-64010 Washer(For Nozzle Holder Pressure Spring)
23631 23632-64012 Washer(For Nozzle Holder Pressure Spring)
23631 23632-64014 Washer(For Nozzle Holder Pressure Spring)
23631 23632-64016 Washer(For Nozzle Holder Pressure Spring)
23631 23632-64018 Washer(For Nozzle Holder Pressure Spring)
23631 23633-64010 Washer(For Nozzle Holder Pressure Spring)
23631 23633-64012 Washer(For Nozzle Holder Pressure Spring)
23631 23633-64014 Washer(For Nozzle Holder Pressure Spring)
23631 23633-64016 Washer(For Nozzle Holder Pressure Spring)
23631 23633-64018 Washer(For Nozzle Holder Pressure Spring)
23631 23634-64010 Washer(For Nozzle Holder Pressure Spring)
23631 23634-64012 Washer(For Nozzle Holder Pressure Spring)
23631 23634-64014 Washer(For Nozzle Holder Pressure Spring)
23631 23634-64016 Washer(For Nozzle Holder Pressure Spring)
23631 23634-64018 Washer(For Nozzle Holder Pressure Spring)
23631 23635-64010 Washer(For Nozzle Holder Pressure Spring)
23631 23635-64012 Washer(For Nozzle Holder Pressure Spring)
23654 23654-64010 Washer(For Ring Packing)
23760 23760-54030 Pipe Assy, Nozzle Leakage
23770 23764-54090 Pipe, Nozzle Leakage, No.4
23770 95333-04020 Hose, Lpg Injector
23770 96133-41000 Clip, No.2(For Idle-Up Hose)
23770 96132-51000 Clip Or Clamp(For Ventilation Hose)
Injection Pump Assembly ([10.1996 - ] (9610- )3L,5L..LY10#,11#,12#,13#,15#,16#) 28
#OEMPart name
22100 22100-5D040 Pump Assy, Injection Or Supply
22100 90447-14023 Hose Or Pipe, Fuel(For Injection Pump To Fuel Filter)
22100 90447-14059 Hose Or Pipe, Fuel(For Injection Pump To Fuel Filter)
22100 22100-5D100 Pump Assy, Injection Or Supply
22811 22811-54042 Stay, Injection Pump, No.1
23701 23701-54140 Pipe Sub-Assy, Injection, No.1
23702 23702-54140 Pipe Sub-Assy, Injection, No.2
23703 23703-54100 Pipe Sub-Assy, Injection, No.3
23703 23703-05011 Pipe Sub-Assy, Injection, No.3
23704 23704-54100 Pipe Sub-Assy, Injection, No.4
23704 23704-05010 Pipe Sub-Assy, Injection, No.4
23741 23741-54030 Clamp, Injection Pipe, No.1
23741 90116-06095 Bolt, Stud(For Head To Cylinder Head Cover)
23741 23741-56010 Clamp, Injection Pipe, No.1
23801 23801-54050 Pipe Sub-Assy, Fuel(For Fuel Filter To Injection Pump)
23811 23811-54160 Pipe, Fuel(For Fuel Filter To Injection Pump)
9011906454 90119-06454 Bolt
9011910699 90119-10699 BOLT WWASHER
9017906100 90179-06100 New Genuine Part
9017906100 90179-06204 NUT
9017908022 90179-08022 NUT
9046713007 90467-13007 Clamp Or Clip(For Water By-Pass Hose No.2)
9046713007 96132-51300 Clip(For Ventilation Hose No.2)
9046713013 90467-13013 New Genuine Part
9092901205 90929-01205 CLAMP
9162160820 91621-60820 New Genuine Part
9162160820 91651-B0822 BOLT WWASHER
9165160818 91651-60818 BOLTWWASHER
Injection Pump Body ([05.1999 - 07.2000] (9905-0007)5L..LY102,112,132,162,212..ATM) 154
#OEMPart name
22019 22390-6A511 Solenoid Assy, Fuel Cut
22101 22101-5B580 Housing Sub-Assy, Injection Pump
22101 90099-14053 Ring, O(For Injection Pump Housing)
22104 22104-5B640 Valve Sub-Assy, Injection Pump Delivery
22108 22108-54180 Ring Sub-Assy, Roller
22119 90201-12109 Washer, Air Bleeder Nipple
22128 22128-54010 Bolt, Distributive Head
22130 22130-5B640 Camplate Sub-Assy, Face
22140 22140-5B640 Head Sub-Assy, Distributive Pump
22140 22140-5B810 Head Sub-Assy, Distributive Pump
22143 22143-54010 Seat, Spring Upper
22144 22144-54190 Spring, Pump Plunger
22145 22145-54010 Seat, Spring, Lower
22146 90099-13018 Key(For Drive Gear)
22146 22544-64740 Seal, Oil, Injection Pump Camshaft
22147 22161-54010 Washer, Drive Shaft
22147 22147-54290 Ring, Governor Sleeve
22148 22148-54010 Spring, Delivery Valve
22149 22149-56351 Gasket, Delivery Valve
22160 22160-64010 Screw Sub-Assy, Overflow
22160 22160-5B320 Screw Sub-Assy, Over Flow, No.2
22162 22162-54010 Plate, Plunger Upper
22163 22163-54010 Plate, Plunger Lower
22169 22169-54180 Joint, Rubber
22170 22170-5D200 Shaft Sub-Assy, Drive
22170 22170-6A510 Shaft Sub-Assy, Drive
22170 90099-13017 Key(For Drive Gear)
22172 22172-5B324 Clip, Connector Support, Solenoid
22172 22172-5B327 Clip, Connector Support, Solenoid
22172 22172-64160 Clip, Connector Support, Solenoid
22176 22176-54020 Plug, Distributive Head
22176 22193-54772 Ring, O(For Distributive Head Plug)
22178 22178-5B840 Bracket(For Injection Pump Assy)
22179 22179-54010 Shim, Plunger Adjusting
22179 22179-54011 Shim, Plunger Adjusting
22179 22179-54012 Shim, Plunger Adjusting
22179 22179-54013 Shim, Plunger Adjusting
22179 22179-54014 Shim, Plunger Adjusting
22179 22179-54015 Shim, Plunger Adjusting
22179 22179-54016 Shim, Plunger Adjusting
22179 22179-54017 Shim, Plunger Adjusting
22179 22179-54018 Shim, Plunger Adjusting
22179 22179-54019 Shim, Plunger Adjusting
22179 22179-54020 Shim, Plunger Adjusting
22180 22180-55050 Valve Sub-Assy, Regulator
22182 22182-54010 Plate, Tappet Adjusting Shim
22182 22183-54010 Plate, Tappet Adjusting Shim
22182 22184-54010 Plate, Tappet Adjusting Shim
22182 22185-54010 Plate, Tappet Adjusting Shim
22182 22186-54010 Plate, Tappet Adjusting Shim
22182 22187-54010 Plate, Tappet Adjusting Shim
22182 22188-54010 Plate, Tappet Adjusting Shim
22190 22190-5B640 Valve Sub-Assy, Snubber
22192 22192-54010 Plate, Tappet Adjusting Shim
22193 22193-17020 Ring, O(For Lever Connecting Pin)
22193 22193-64750 Ring, O(For Lever Connecting Pin)
22193 22193-5B320 Ring, O(For Fuel Injection Pump Filter)
22302 22302-5D070 Shaft Sub-Assy, Speed Control
22305 22305-5B640 Idle-Up Sub-Assy
22314 22314-54010 Spring, Lever Support
22316 22316-6E070 Sleeve, Governor
22316 22316-6E101 Sleeve, Governor
22316 22316-6E102 Sleeve, Governor
22316 22316-6E103 Sleeve, Governor
22316 22316-6E104 Sleeve, Governor
22316 90099-10148 Bearing, Ball(For Governor Sleeve)
22322 22322-54630 Spring, Return
22341 22341-54010 Gear, Governor Drive
22350 22350-5B880 Governor Assy, Torque Control
22378 22378-64010 Washer, Governor Thrust
22384 22380-54020 Shaft, Governor
22384 90099-14049 Ring, O(For Governor Main Shaft)
22390 22390-5B320 Solenoid Assy, Fuel Cut
22505 22505-54010 Pump Sub-Assy, Fuel Feed
22505 90099-00723 Screw(For Fuel Feed Pump)
22511 22511-54020 Cover, Feed Pump
22545 22545-5B321 Nipple, Swivel(For Injection Pump Inlet)
22569 22569-5B320 Screw, Overflow
22582 22582-5B520 Piston Assy, Timer
22601 22601-5B360 Bracket Sub-Assy, Idle Up
22602 22602-56350 Filter Sub-Assy, Fuel Injection Pump
22602 22602-5B320 Filter Sub-Assy, Fuel Injection Pump, No.2
22612 22612-56350 Cover, Timer
22612 22612-17020 Cover, Timer
22612 22193-17840 Ring, O(For Timer Cover)
22615 22615-17030 Spring, Timer Outer
22615 22615-18020 Spring, Timer Outer
22615 22615-5B371 Spring, Timer Outer
22615 22615-5B372 Spring, Timer Outer
22615 22615-5B373 Spring, Timer Outer
22615 22615-5B374 Spring, Timer Outer
22625 22625-17020 Washer, Timer Adjusting
22632 22632-54010 Coupling, Injection Pump
22632 22632-5B170 Coupling, Injection Pump
22655 22655-54010 Pin, Timer Slide
22656 22656-17840 Clip, Timer
22657 22657-54010 Clip, Timer
22658 22658-17020 Stopper, Timer
22658 22658-17840 Stopper, Timer
22659 22659-64150 Spring, Coupling
22689 22689-56350 Washer(For Swivel Nipple)
22701 22701-5B020 Lever Sub-Assy, Adjusting
22701 22701-5B021 Lever Sub-Assy, Adjusting
22701 26126-54390 Joint, Ball(For Adjusting Lever)
22712 22775-77121 Nut, Rock
22713 22713-54010 Washer, Governor Gear Adjusting
22713 22714-54010 Washer, Governor Gear Adjusting
22713 22715-54010 Washer, Governor Gear Adjusting
22713 22716-54010 Washer, Governor Gear Adjusting
22713 22717-54010 Washer, Governor Gear Adjusting
22722 22722-54470 Nut, Governor Shaft Rock
22739 22739-54020 Bolt, Governor Link Support
22740 22193-54770 Ring, O(For Governor Adjusting Shaft)
22741 22741-54020 Holder Sub-Assy, Flyweight
22745 22745-5B640 Flyweight, Distributive Pump
22751 22751-5B320 Wire Sub-Assy, Fuel Cut Solenoid
22753 22753-54010 Washer, Flyweight, No.1
22753 22753-54020 Washer, Flyweight, No.2
22774 22774-54270 Gasket, Governor Cover
22776 22776-54110 Screw, Smoke Set Adjusting
22776 22193-54771 Ring, O(For Smoke Set Screw)
22787 22787-54027 Plug, Governor Sleeve
22787 22787-54029 Plug, Governor Sleeve
22787 22787-54031 Plug, Governor Sleeve
22787 22787-54033 Plug, Governor Sleeve
22787 22787-64640 Plug, Governor Sleeve
22787 22787-64641 Plug, Governor Sleeve
22787 22787-64643 Plug, Governor Sleeve
22787 22787-64680 Plug, Governor Sleeve
22790 22790-5B640 Cover Sub-Assy, Timer
26133 26133-5B640 Actuator Set, Idle-Up
221495 22149-5B320 Gasket, Delivery Valve
221725 22172-5B325 Clip, Connector Support, Solenoid
221725 22172-5B326 Clip, Connector Support, Solenoid
223785 22378-5C430 Washer, Governor Thrust
223955 22395-5B320 Bolt, Socket(for Injection Pump Governor Cover)
223955 22395-5B321 Bolt, Socket(for Injection Pump Governor Cover)
2214954771 22149-54771 Gasket, Delivery Valve
2214956200 22149-56200 Gasket, Delivery Valve
2239554010 22395-54010 Bolt, Socket(For Injection Pump Governor Cover)
2239556351 22395-56351 Bolt, Socket(for Injection Pump Governor Cover)
2239556352 22395-56352 Bolt, Socket(for Injection Pump Governor Cover)
2239558200 22395-58200 Bolt, Socket(For Injection Pump Governor Cover)
9009210608 90092-10608 New Genuine Part
9009690024 90096-90024 Ring, O(For Stopper Lever)
9009902211 90099-02211 New Genuine Part
9009904954 90099-04954 BOLT
9009905161 90099-05161 Nut, Timer Round
9009905225 90099-05225 NUT
9009905252 90099-05252 NUT HEXAGON
9009918022 90099-18022 SCREW
9017906009 90179-06009 Nut (For Transmission Control Cable)
9017906009 90179-06156 Nut (For Transmission Control Cable)
9331514012 93315-14012 Screw with washer
Injection Pump Body ([05.1999 - 07.2000] (9905-0007)5L..MTM) 155
#OEMPart name
22019 22390-6A511 Solenoid Assy, Fuel Cut
22101 22101-5B580 Housing Sub-Assy, Injection Pump
22101 90099-14053 Ring, O(For Injection Pump Housing)
22104 22104-5B640 Valve Sub-Assy, Injection Pump Delivery
22108 22108-54180 Ring Sub-Assy, Roller
22119 90201-12109 Washer, Air Bleeder Nipple
22128 22128-54010 Bolt, Distributive Head
22130 22130-5B640 Camplate Sub-Assy, Face
22140 22140-5B640 Head Sub-Assy, Distributive Pump
22140 22140-5B810 Head Sub-Assy, Distributive Pump
22143 22143-54010 Seat, Spring Upper
22144 22144-54190 Spring, Pump Plunger
22145 22145-54010 Seat, Spring, Lower
22146 90099-13018 Key(For Drive Gear)
22146 22544-64740 Seal, Oil, Injection Pump Camshaft
22147 22161-54010 Washer, Drive Shaft
22147 22147-54290 Ring, Governor Sleeve
22148 22148-54010 Spring, Delivery Valve
22149 22149-56351 Gasket, Delivery Valve
22160 22160-64010 Screw Sub-Assy, Overflow
22160 22160-5B320 Screw Sub-Assy, Over Flow, No.2
22162 22162-54010 Plate, Plunger Upper
22163 22163-54010 Plate, Plunger Lower
22169 22169-54180 Joint, Rubber
22170 22170-5D200 Shaft Sub-Assy, Drive
22170 22170-6A510 Shaft Sub-Assy, Drive
22170 90099-13017 Key(For Drive Gear)
22172 22172-5B324 Clip, Connector Support, Solenoid
22172 22172-5B327 Clip, Connector Support, Solenoid
22172 22172-64160 Clip, Connector Support, Solenoid
22176 22176-54020 Plug, Distributive Head
22176 22193-54772 Ring, O(For Distributive Head Plug)
22179 22179-54010 Shim, Plunger Adjusting
22179 22179-54011 Shim, Plunger Adjusting
22179 22179-54012 Shim, Plunger Adjusting
22179 22179-54013 Shim, Plunger Adjusting
22179 22179-54014 Shim, Plunger Adjusting
22179 22179-54015 Shim, Plunger Adjusting
22179 22179-54016 Shim, Plunger Adjusting
22179 22179-54017 Shim, Plunger Adjusting
22179 22179-54018 Shim, Plunger Adjusting
22179 22179-54019 Shim, Plunger Adjusting
22179 22179-54020 Shim, Plunger Adjusting
22180 22180-55050 Valve Sub-Assy, Regulator
22182 22182-54010 Plate, Tappet Adjusting Shim
22182 22183-54010 Plate, Tappet Adjusting Shim
22182 22184-54010 Plate, Tappet Adjusting Shim
22182 22185-54010 Plate, Tappet Adjusting Shim
22182 22186-54010 Plate, Tappet Adjusting Shim
22182 22187-54010 Plate, Tappet Adjusting Shim
22182 22188-54010 Plate, Tappet Adjusting Shim
22190 22190-5B640 Valve Sub-Assy, Snubber
22192 22192-54010 Plate, Tappet Adjusting Shim
22193 22193-17020 Ring, O(For Lever Connecting Pin)
22193 22193-64750 Ring, O(For Lever Connecting Pin)
22193 22193-5B320 Ring, O(For Fuel Injection Pump Filter)
22305 22305-5B640 Idle-Up Sub-Assy
22314 22314-54010 Spring, Lever Support
22316 22316-6E070 Sleeve, Governor
22316 22316-6E101 Sleeve, Governor
22316 22316-6E102 Sleeve, Governor
22316 22316-6E103 Sleeve, Governor
22316 22316-6E104 Sleeve, Governor
22316 90099-10148 Bearing, Ball(For Governor Sleeve)
22317 22317-54470 Spring, Governor Domper
22317 22317-54870 Spring, Governor Domper
22317 22317-5B790 Spring, Governor Domper
22322 22322-54730 Spring, Return
22341 22341-54010 Gear, Governor Drive
22350 22350-67080 Governor Assy, Torque Control
22369 22369-54010 Seat, Governor Spring
22378 22378-64010 Washer, Governor Thrust
22384 22380-54020 Shaft, Governor
22384 90099-14049 Ring, O(For Governor Main Shaft)
22390 22390-5B320 Solenoid Assy, Fuel Cut
22505 22505-54010 Pump Sub-Assy, Fuel Feed
22505 90099-00723 Screw(For Fuel Feed Pump)
22511 22511-54020 Cover, Feed Pump
22545 22545-5B321 Nipple, Swivel(For Injection Pump Inlet)
22569 22569-5B320 Screw, Overflow
22582 22582-5B520 Piston Assy, Timer
22601 22601-5B360 Bracket Sub-Assy, Idle Up
22602 22602-56350 Filter Sub-Assy, Fuel Injection Pump
22602 22602-5B320 Filter Sub-Assy, Fuel Injection Pump, No.2
22612 22612-56350 Cover, Timer
22612 22612-17020 Cover, Timer
22612 22193-17840 Ring, O(For Timer Cover)
22615 22615-17030 Spring, Timer Outer
22615 22615-18020 Spring, Timer Outer
22615 22615-5B371 Spring, Timer Outer
22615 22615-5B373 Spring, Timer Outer
22615 22615-5B374 Spring, Timer Outer
22615 22615-5C153 Spring, Timer Outer
22625 22625-17020 Washer, Timer Adjusting
22632 22632-54010 Coupling, Injection Pump
22632 22632-5B170 Coupling, Injection Pump
22655 22655-54010 Pin, Timer Slide
22656 22656-17840 Clip, Timer
22657 22657-54010 Clip, Timer
22658 22658-17020 Stopper, Timer
22658 22658-17840 Stopper, Timer
22659 22659-64150 Spring, Coupling
22689 22689-56350 Washer(For Swivel Nipple)
22701 22701-5B640 Lever Sub-Assy, Adjusting
22701 22701-5B641 Lever Sub-Assy, Adjusting
22712 22775-77121 Nut, Rock
22713 22713-54010 Washer, Governor Gear Adjusting
22713 22714-54010 Washer, Governor Gear Adjusting
22713 22715-54010 Washer, Governor Gear Adjusting
22713 22716-54010 Washer, Governor Gear Adjusting
22713 22717-54010 Washer, Governor Gear Adjusting
22722 22722-54470 Nut, Governor Shaft Rock
22726 22726-5B710 Spring, Speed Control
22739 22739-54020 Bolt, Governor Link Support
22740 22740-64820 Shaft Sub-Assy, Governor Adjusting
22740 22193-54770 Ring, O(For Governor Adjusting Shaft)
22741 22741-54020 Holder Sub-Assy, Flyweight
22745 22745-5B640 Flyweight, Distributive Pump
22751 22751-5B320 Wire Sub-Assy, Fuel Cut Solenoid
22753 22753-54010 Washer, Flyweight, No.1
22753 22753-54020 Washer, Flyweight, No.2
22774 22774-54270 Gasket, Governor Cover
22776 22776-54110 Screw, Smoke Set Adjusting
22776 22193-54771 Ring, O(For Smoke Set Screw)
22787 22787-54027 Plug, Governor Sleeve
22787 22787-54029 Plug, Governor Sleeve
22787 22787-54031 Plug, Governor Sleeve
22787 22787-54033 Plug, Governor Sleeve
22787 22787-64640 Plug, Governor Sleeve
22787 22787-64641 Plug, Governor Sleeve
22787 22787-64643 Plug, Governor Sleeve
22787 22787-64680 Plug, Governor Sleeve
22790 22790-5B640 Cover Sub-Assy, Timer
26133 26133-5B640 Actuator Set, Idle-Up
221495 22149-5B320 Gasket, Delivery Valve
221725 22172-5B325 Clip, Connector Support, Solenoid
221725 22172-5B326 Clip, Connector Support, Solenoid
223785 22378-5C430 Washer, Governor Thrust
223955 22395-5B320 Bolt, Socket(for Injection Pump Governor Cover)
223955 22395-5B321 Bolt, Socket(for Injection Pump Governor Cover)
2214954771 22149-54771 Gasket, Delivery Valve
2214956200 22149-56200 Gasket, Delivery Valve
2239554010 22395-54010 Bolt, Socket(For Injection Pump Governor Cover)
2239556351 22395-56351 Bolt, Socket(for Injection Pump Governor Cover)
2239556352 22395-56352 Bolt, Socket(for Injection Pump Governor Cover)
2239558200 22395-58200 Bolt, Socket(For Injection Pump Governor Cover)
9009210608 90092-10608 New Genuine Part
9009690024 90096-90024 Ring, O(For Stopper Lever)
9009904954 90099-04954 BOLT
9009905161 90099-05161 Nut, Timer Round
9009905225 90099-05225 NUT
9009905252 90099-05252 NUT HEXAGON
9009918022 90099-18022 SCREW
9017906009 90179-06009 Nut (For Transmission Control Cable)
9017906009 90179-06156 Nut (For Transmission Control Cable)
Injection Pump Body ([05.1999 - ] (9905- )5L) 31
#OEMPart name
22129 22129-55110 Plug, Screw
22129 22149-54800 Washer, Air Bleeder Nipple
22193 22193-55031 Ring, O(For Lever Connecting Pin)
22301 22301-5B581 Rod Sub-Assy, Push
22308 22308-5B650 Lever Sub-Assy, Control
22327 22327-54800 Spring(For Bellows)
22327 22327-64400 Spring(For Bellows)
22338 22338-54120 Pin, Lever Connecting
22348 22348-64400 Bushing, Guide
22348 22348-54121 Bushing, Guide
22526 22526-54120 Pin, Lever Support
22621 22621-54010 Washer, Timer Adjusting
22621 22622-54010 Washer, Timer Adjusting
22621 22624-54010 Washer, Timer Adjusting
22621 22624-54800 Washer, Timer Adjusting
22621 22624-54803 Washer, Timer Adjusting
22621 22624-54804 Washer, Timer Adjusting
22621 22624-54805 Washer, Timer Adjusting
22621 22624-54806 Washer, Timer Adjusting
22680 90099-01473 Washer(For Guide Bushing)
22681 22681-6A570 Bellows Sub-Assy, Pneumatic
22686 22682-54351 Cover, Pneumatic Bellows
22686 90099-14057 Ring, O(For Bellows Cover)
22703 22703-5B121 Cover Sub-Assy, Governor
22739 22739-54120 Bolt, Governor Link Support
22739 22149-6D450 Gasket, Delivery Valve
22777 22777-54120 Cap, Rubber(For Bellows)
22777 22777-64410 Cap, Rubber(For Bellows)
2239554263 22395-54263 Bolt, Socket(for Injection Pump Governor Cover)
2272254120 22722-54120 Nut, Governor Shaft Rock
9009905156 90099-05156 New Genuine Part
Injection Pump Body ([07.2000 - ] (0007- )5L..LY102,112,132,162,212..ATM) 155
#OEMPart name
22019 22390-6A511 Solenoid Assy, Fuel Cut
22101 22101-5B580 Housing Sub-Assy, Injection Pump
22101 90099-14053 Ring, O(For Injection Pump Housing)
22104 22104-5B640 Valve Sub-Assy, Injection Pump Delivery
22108 22108-54180 Ring Sub-Assy, Roller
22119 90201-12109 Washer, Air Bleeder Nipple
22128 22128-54010 Bolt, Distributive Head
22130 22130-5B640 Camplate Sub-Assy, Face
22140 22140-5B640 Head Sub-Assy, Distributive Pump
22140 22140-5B810 Head Sub-Assy, Distributive Pump
22143 22143-54010 Seat, Spring Upper
22144 22144-54190 Spring, Pump Plunger
22145 22145-54010 Seat, Spring, Lower
22146 90099-13018 Key(For Drive Gear)
22146 22544-64740 Seal, Oil, Injection Pump Camshaft
22147 22161-54010 Washer, Drive Shaft
22147 22147-54290 Ring, Governor Sleeve
22148 22148-54010 Spring, Delivery Valve
22149 22149-56351 Gasket, Delivery Valve
22160 22160-64010 Screw Sub-Assy, Overflow
22160 22160-5B320 Screw Sub-Assy, Over Flow, No.2
22162 22162-54010 Plate, Plunger Upper
22163 22163-54010 Plate, Plunger Lower
22169 22169-54180 Joint, Rubber
22170 22170-5D200 Shaft Sub-Assy, Drive
22170 22170-6A510 Shaft Sub-Assy, Drive
22170 90099-13017 Key(For Drive Gear)
22172 22172-5B324 Clip, Connector Support, Solenoid
22172 22172-5B327 Clip, Connector Support, Solenoid
22172 22172-64160 Clip, Connector Support, Solenoid
22176 22176-54020 Plug, Distributive Head
22176 22193-54772 Ring, O(For Distributive Head Plug)
22178 22178-5B840 Bracket(For Injection Pump Assy)
22179 22179-54010 Shim, Plunger Adjusting
22179 22179-54011 Shim, Plunger Adjusting
22179 22179-54012 Shim, Plunger Adjusting
22179 22179-54013 Shim, Plunger Adjusting
22179 22179-54014 Shim, Plunger Adjusting
22179 22179-54015 Shim, Plunger Adjusting
22179 22179-54016 Shim, Plunger Adjusting
22179 22179-54017 Shim, Plunger Adjusting
22179 22179-54018 Shim, Plunger Adjusting
22179 22179-54019 Shim, Plunger Adjusting
22179 22179-54020 Shim, Plunger Adjusting
22180 22180-55050 Valve Sub-Assy, Regulator
22182 22182-54010 Plate, Tappet Adjusting Shim
22182 22183-54010 Plate, Tappet Adjusting Shim
22182 22184-54010 Plate, Tappet Adjusting Shim
22182 22185-54010 Plate, Tappet Adjusting Shim
22182 22186-54010 Plate, Tappet Adjusting Shim
22182 22187-54010 Plate, Tappet Adjusting Shim
22182 22188-54010 Plate, Tappet Adjusting Shim
22190 22190-5B640 Valve Sub-Assy, Snubber
22192 22192-54010 Plate, Tappet Adjusting Shim
22193 22193-17020 Ring, O(For Lever Connecting Pin)
22193 22193-64750 Ring, O(For Lever Connecting Pin)
22193 22193-5B320 Ring, O(For Fuel Injection Pump Filter)
22302 22302-5D070 Shaft Sub-Assy, Speed Control
22305 22305-5B640 Idle-Up Sub-Assy
22314 22314-54010 Spring, Lever Support
22316 22316-6E070 Sleeve, Governor
22316 22316-6E101 Sleeve, Governor
22316 22316-6E102 Sleeve, Governor
22316 22316-6E103 Sleeve, Governor
22316 22316-6E104 Sleeve, Governor
22316 90099-10148 Bearing, Ball(For Governor Sleeve)
22322 22322-54630 Spring, Return
22341 22341-54010 Gear, Governor Drive
22350 22350-5B880 Governor Assy, Torque Control
22378 22378-64010 Washer, Governor Thrust
22384 22380-54020 Shaft, Governor
22384 90099-14049 Ring, O(For Governor Main Shaft)
22390 22390-5B320 Solenoid Assy, Fuel Cut
22505 22505-54010 Pump Sub-Assy, Fuel Feed
22505 90099-00723 Screw(For Fuel Feed Pump)
22511 22511-54020 Cover, Feed Pump
22545 22545-5B321 Nipple, Swivel(For Injection Pump Inlet)
22569 22569-5B320 Screw, Overflow
22582 22582-5B520 Piston Assy, Timer
22601 22601-5B360 Bracket Sub-Assy, Idle Up
22602 22602-56350 Filter Sub-Assy, Fuel Injection Pump
22602 22602-5B320 Filter Sub-Assy, Fuel Injection Pump, No.2
22612 22612-56350 Cover, Timer
22612 22612-17020 Cover, Timer
22612 22193-17840 Ring, O(For Timer Cover)
22615 22615-17030 Spring, Timer Outer
22615 22615-18020 Spring, Timer Outer
22615 22615-5B371 Spring, Timer Outer
22615 22615-5B372 Spring, Timer Outer
22615 22615-5B373 Spring, Timer Outer
22615 22615-5B374 Spring, Timer Outer
22625 22625-17020 Washer, Timer Adjusting
22632 22632-54010 Coupling, Injection Pump
22632 22632-5B170 Coupling, Injection Pump
22632 90099-70002 Spacer, Injection Pump Coupling
22655 22655-54010 Pin, Timer Slide
22656 22656-17840 Clip, Timer
22657 22657-54010 Clip, Timer
22658 22658-17020 Stopper, Timer
22658 22658-17840 Stopper, Timer
22689 22689-56350 Washer(For Swivel Nipple)
22689 22689-5B170 Spacer, Injection Pump Coupling
22701 22701-5B020 Lever Sub-Assy, Adjusting
22701 22701-5B021 Lever Sub-Assy, Adjusting
22701 26126-54390 Joint, Ball(For Adjusting Lever)
22712 22775-77121 Nut, Rock
22713 22713-54010 Washer, Governor Gear Adjusting
22713 22714-54010 Washer, Governor Gear Adjusting
22713 22715-54010 Washer, Governor Gear Adjusting
22713 22716-54010 Washer, Governor Gear Adjusting
22713 22717-54010 Washer, Governor Gear Adjusting
22722 22722-54470 Nut, Governor Shaft Rock
22739 22739-54020 Bolt, Governor Link Support
22740 22193-54770 Ring, O(For Governor Adjusting Shaft)
22741 22741-54020 Holder Sub-Assy, Flyweight
22745 22745-5B640 Flyweight, Distributive Pump
22751 22751-5B320 Wire Sub-Assy, Fuel Cut Solenoid
22753 22753-54010 Washer, Flyweight, No.1
22753 22753-54020 Washer, Flyweight, No.2
22774 22774-54270 Gasket, Governor Cover
22776 22776-54110 Screw, Smoke Set Adjusting
22776 22193-54771 Ring, O(For Smoke Set Screw)
22787 22787-54027 Plug, Governor Sleeve
22787 22787-54029 Plug, Governor Sleeve
22787 22787-54031 Plug, Governor Sleeve
22787 22787-54033 Plug, Governor Sleeve
22787 22787-64640 Plug, Governor Sleeve
22787 22787-64641 Plug, Governor Sleeve
22787 22787-64643 Plug, Governor Sleeve
22787 22787-64680 Plug, Governor Sleeve
22790 22790-5B640 Cover Sub-Assy, Timer
26133 26133-5B640 Actuator Set, Idle-Up
221495 22149-5B320 Gasket, Delivery Valve
221725 22172-5B325 Clip, Connector Support, Solenoid
221725 22172-5B326 Clip, Connector Support, Solenoid
223785 22378-5C430 Washer, Governor Thrust
223955 22395-5B320 Bolt, Socket(for Injection Pump Governor Cover)
223955 22395-5B321 Bolt, Socket(for Injection Pump Governor Cover)
2214954771 22149-54771 Gasket, Delivery Valve
2214956200 22149-56200 Gasket, Delivery Valve
2239554010 22395-54010 Bolt, Socket(For Injection Pump Governor Cover)
2239556351 22395-56351 Bolt, Socket(for Injection Pump Governor Cover)
2239556352 22395-56352 Bolt, Socket(for Injection Pump Governor Cover)
2239558200 22395-58200 Bolt, Socket(For Injection Pump Governor Cover)
9009210608 90092-10608 New Genuine Part
9009690024 90096-90024 Ring, O(For Stopper Lever)
9009902211 90099-02211 New Genuine Part
9009904954 90099-04954 BOLT
9009905161 90099-05161 Nut, Timer Round
9009905225 90099-05225 NUT
9009905252 90099-05252 NUT HEXAGON
9009918022 90099-18022 SCREW
9017906009 90179-06009 Nut (For Transmission Control Cable)
9017906009 90179-06156 Nut (For Transmission Control Cable)
9331514012 93315-14012 Screw with washer
Injection Pump Body ([07.2000 - ] (0007- )5L..MTM) 156
#OEMPart name
22019 22390-6A511 Solenoid Assy, Fuel Cut
22101 22101-5B580 Housing Sub-Assy, Injection Pump
22101 90099-14053 Ring, O(For Injection Pump Housing)
22104 22104-5B640 Valve Sub-Assy, Injection Pump Delivery
22108 22108-54180 Ring Sub-Assy, Roller
22119 90201-12109 Washer, Air Bleeder Nipple
22128 22128-54010 Bolt, Distributive Head
22130 22130-5B640 Camplate Sub-Assy, Face
22140 22140-5B640 Head Sub-Assy, Distributive Pump
22140 22140-5B810 Head Sub-Assy, Distributive Pump
22143 22143-54010 Seat, Spring Upper
22144 22144-54190 Spring, Pump Plunger
22145 22145-54010 Seat, Spring, Lower
22146 90099-13018 Key(For Drive Gear)
22146 22544-64740 Seal, Oil, Injection Pump Camshaft
22147 22161-54010 Washer, Drive Shaft
22147 22147-54290 Ring, Governor Sleeve
22148 22148-54010 Spring, Delivery Valve
22149 22149-56351 Gasket, Delivery Valve
22160 22160-64010 Screw Sub-Assy, Overflow
22160 22160-5B320 Screw Sub-Assy, Over Flow, No.2
22162 22162-54010 Plate, Plunger Upper
22163 22163-54010 Plate, Plunger Lower
22169 22169-54180 Joint, Rubber
22170 22170-5D200 Shaft Sub-Assy, Drive
22170 22170-6A510 Shaft Sub-Assy, Drive
22170 90099-13017 Key(For Drive Gear)
22172 22172-5B324 Clip, Connector Support, Solenoid
22172 22172-5B327 Clip, Connector Support, Solenoid
22172 22172-64160 Clip, Connector Support, Solenoid
22176 22176-54020 Plug, Distributive Head
22176 22193-54772 Ring, O(For Distributive Head Plug)
22179 22179-54010 Shim, Plunger Adjusting
22179 22179-54011 Shim, Plunger Adjusting
22179 22179-54012 Shim, Plunger Adjusting
22179 22179-54013 Shim, Plunger Adjusting
22179 22179-54014 Shim, Plunger Adjusting
22179 22179-54015 Shim, Plunger Adjusting
22179 22179-54016 Shim, Plunger Adjusting
22179 22179-54017 Shim, Plunger Adjusting
22179 22179-54018 Shim, Plunger Adjusting
22179 22179-54019 Shim, Plunger Adjusting
22179 22179-54020 Shim, Plunger Adjusting
22180 22180-55050 Valve Sub-Assy, Regulator
22182 22182-54010 Plate, Tappet Adjusting Shim
22182 22183-54010 Plate, Tappet Adjusting Shim
22182 22184-54010 Plate, Tappet Adjusting Shim
22182 22185-54010 Plate, Tappet Adjusting Shim
22182 22186-54010 Plate, Tappet Adjusting Shim
22182 22187-54010 Plate, Tappet Adjusting Shim
22182 22188-54010 Plate, Tappet Adjusting Shim
22190 22190-5B640 Valve Sub-Assy, Snubber
22192 22192-54010 Plate, Tappet Adjusting Shim
22193 22193-17020 Ring, O(For Lever Connecting Pin)
22193 22193-64750 Ring, O(For Lever Connecting Pin)
22193 22193-5B320 Ring, O(For Fuel Injection Pump Filter)
22305 22305-5B640 Idle-Up Sub-Assy
22314 22314-54010 Spring, Lever Support
22316 22316-6E070 Sleeve, Governor
22316 22316-6E101 Sleeve, Governor
22316 22316-6E102 Sleeve, Governor
22316 22316-6E103 Sleeve, Governor
22316 22316-6E104 Sleeve, Governor
22316 90099-10148 Bearing, Ball(For Governor Sleeve)
22317 22317-54470 Spring, Governor Domper
22317 22317-54870 Spring, Governor Domper
22317 22317-5B790 Spring, Governor Domper
22322 22322-54730 Spring, Return
22341 22341-54010 Gear, Governor Drive
22350 22350-67080 Governor Assy, Torque Control
22369 22369-54010 Seat, Governor Spring
22378 22378-64010 Washer, Governor Thrust
22384 22380-54020 Shaft, Governor
22384 90099-14049 Ring, O(For Governor Main Shaft)
22390 22390-5B320 Solenoid Assy, Fuel Cut
22505 22505-54010 Pump Sub-Assy, Fuel Feed
22505 90099-00723 Screw(For Fuel Feed Pump)
22511 22511-54020 Cover, Feed Pump
22545 22545-5B321 Nipple, Swivel(For Injection Pump Inlet)
22569 22569-5B320 Screw, Overflow
22582 22582-5B520 Piston Assy, Timer
22601 22601-5B360 Bracket Sub-Assy, Idle Up
22602 22602-56350 Filter Sub-Assy, Fuel Injection Pump
22602 22602-5B320 Filter Sub-Assy, Fuel Injection Pump, No.2
22612 22612-56350 Cover, Timer
22612 22612-17020 Cover, Timer
22612 22193-17840 Ring, O(For Timer Cover)
22615 22615-17030 Spring, Timer Outer
22615 22615-18020 Spring, Timer Outer
22615 22615-5B371 Spring, Timer Outer
22615 22615-5B373 Spring, Timer Outer
22615 22615-5B374 Spring, Timer Outer
22615 22615-5C153 Spring, Timer Outer
22625 22625-17020 Washer, Timer Adjusting
22632 22632-54010 Coupling, Injection Pump
22632 22632-5B170 Coupling, Injection Pump
22632 90099-70002 Spacer, Injection Pump Coupling
22655 22655-54010 Pin, Timer Slide
22656 22656-17840 Clip, Timer
22657 22657-54010 Clip, Timer
22658 22658-17020 Stopper, Timer
22658 22658-17840 Stopper, Timer
22689 22689-56350 Washer(For Swivel Nipple)
22689 22689-5B170 Spacer, Injection Pump Coupling
22701 22701-5B640 Lever Sub-Assy, Adjusting
22701 22701-5B641 Lever Sub-Assy, Adjusting
22712 22775-77121 Nut, Rock
22713 22713-54010 Washer, Governor Gear Adjusting
22713 22714-54010 Washer, Governor Gear Adjusting
22713 22715-54010 Washer, Governor Gear Adjusting
22713 22716-54010 Washer, Governor Gear Adjusting
22713 22717-54010 Washer, Governor Gear Adjusting
22722 22722-54470 Nut, Governor Shaft Rock
22726 22726-5B710 Spring, Speed Control
22739 22739-54020 Bolt, Governor Link Support
22740 22740-64820 Shaft Sub-Assy, Governor Adjusting
22740 22193-54770 Ring, O(For Governor Adjusting Shaft)
22741 22741-54020 Holder Sub-Assy, Flyweight
22745 22745-5B640 Flyweight, Distributive Pump
22751 22751-5B320 Wire Sub-Assy, Fuel Cut Solenoid
22753 22753-54010 Washer, Flyweight, No.1
22753 22753-54020 Washer, Flyweight, No.2
22774 22774-54270 Gasket, Governor Cover
22776 22776-54110 Screw, Smoke Set Adjusting
22776 22193-54771 Ring, O(For Smoke Set Screw)
22787 22787-54027 Plug, Governor Sleeve
22787 22787-54029 Plug, Governor Sleeve
22787 22787-54031 Plug, Governor Sleeve
22787 22787-54033 Plug, Governor Sleeve
22787 22787-64640 Plug, Governor Sleeve
22787 22787-64641 Plug, Governor Sleeve
22787 22787-64643 Plug, Governor Sleeve
22787 22787-64680 Plug, Governor Sleeve
22790 22790-5B640 Cover Sub-Assy, Timer
26133 26133-5B640 Actuator Set, Idle-Up
221495 22149-5B320 Gasket, Delivery Valve
221725 22172-5B325 Clip, Connector Support, Solenoid
221725 22172-5B326 Clip, Connector Support, Solenoid
223785 22378-5C430 Washer, Governor Thrust
223955 22395-5B320 Bolt, Socket(for Injection Pump Governor Cover)
223955 22395-5B321 Bolt, Socket(for Injection Pump Governor Cover)
2214954771 22149-54771 Gasket, Delivery Valve
2214956200 22149-56200 Gasket, Delivery Valve
2239554010 22395-54010 Bolt, Socket(For Injection Pump Governor Cover)
2239556351 22395-56351 Bolt, Socket(for Injection Pump Governor Cover)
2239556352 22395-56352 Bolt, Socket(for Injection Pump Governor Cover)
2239558200 22395-58200 Bolt, Socket(For Injection Pump Governor Cover)
9009210608 90092-10608 New Genuine Part
9009690024 90096-90024 Ring, O(For Stopper Lever)
9009904954 90099-04954 BOLT
9009905161 90099-05161 Nut, Timer Round
9009905225 90099-05225 NUT
9009905252 90099-05252 NUT HEXAGON
9009918022 90099-18022 SCREW
9017906009 90179-06009 Nut (For Transmission Control Cable)
9017906009 90179-06156 Nut (For Transmission Control Cable)
Inside Trim Board ([05.1995 - ] (9505- )) 13
#OEMPart name
62211 62211-25010-B0 Garnish, Front Pillar, Rh
62212 62212-25010-B0 Garnish, Front Pillar, Lh
62313 62313-37020-B0 Trim, Front Door Opening, Rh
62471 62471-25010-B0 Garnish, Rear Pillar, Upper Rh
62471 90467-07043-B1 Clip
62471 90467-07043-C0 Clip(For Rear Bumper Retainer)
62472 62472-25010-B0 Garnish, Rear Pillar, Upper Lh
62571 62571-25010-B0 Garnish, Rear Pillar, Lower Rh
62572 62572-25010-B0 Garnish, Rear Pillar, Lower Lh
6777116080 67771-16080 Retainer (For Quarter Inside Trim Board)
6777132150 67771-32150 Clip, Cowl Top Ventilator Louver
9046711079 90467-11079 New Genuine Part
9046805047 90468-05047 CLIP
Instrument Panel & Glove Compartment ([05.1995 - ] (9505- )) 52
#OEMPart name
55301 55311-37021-B0 Panel Sub-Assy, Instrument
55307 55307-37010 Reinforcement Sub-Assy, Instrument Panel, Lower
55307 55307-37050 Reinforcement Sub-Assy, Instrument Panel, Lower
55330 55330-25010 Reinforcement Assy, Instrument Panel
55341 55341-37010 Brace, Instrument Panel, No.1
55341 55341-37020 Brace, Instrument Panel, No.1
55351 55351-37010 Brace, Instrument Panel To Floor
55352 55352-37030 Brace, Instrument Panel To Floor, No.2
55381 55381-37010 Bracket, Finish Panel Mounting, No.1
55405 55405-37010-C0 Panel Sub-Assy, Instrument Cluster Finish, Center
55410 55410-37010-B0 Panel Assy, Instrument Cluster Finish
55411 55411-37020-C0 Panel, Instrument Cluster Finish, No.1
55448 55448-37010-B0 Cover, Oil Reservoir Tank, Rh
55477 55477-37010 Bezel, Cigarette Lighter Hole
55479 55479-37010-B0 Cover, Instrument, Lower Center
55501 55501-37010-B0 Door Sub-Assy, Glove Compartment
55521 55521-16030 Cover, Radio Tuner Opening
55539 55539-95J00-B0 Cover, Choke Knob Hole
55539 55539-95J00-C0 Cover, Spare Switch Hole
55539 55539-37010-C0 Cover, Spare Switch Hole
55541 55541-37010 Retainer, Radio Tuner Opening, No.1
55541 55541-37020 Retainer, Radio Tuner Opening, No.1
55557 55557-28010 Stopper, Glove Compertment Door Check
55562 55562-95J00 Pin, Glove Compartment Door Lock
55565 55565-37010 Knob, Glove Compartment Door Lock
55565 55565-37010-B0 Knob, Glove Compartment Door Lock
55573 55573-37010 Hinge, Glove Compartment Door
55581 55581-37010 Compartment, Glove
55604 55604-37020 Holder Sub-Assy, Instrument Panel Cup
55650 55650-37020-B0 Register Assy, Instrument Panel, No.1
55950 55950-37010 Nozzle Assy, Defroster
55961 55961-37010-B0 Nozzle, Side Defroster, No.1
55971 55971-37010 Duct, Side Defroster Nozzle, No.1
55972 55972-37010 Duct, Side Defroster Nozzle, No.2
55990 55990-37010 Nozzle Assy, Defroster, Lower
82715 82715-37671 Bracket, Wiring Harness Clamp
9010506109 90105-06109 New Genuine Part
9011906327 90119-06327 New Genuine Part
9011906327 90119-06324 Bolt
9018305103 90183-05103 NUT
9024904002 90249-04002 New Genuine Part
9046709145 90467-09145-B0 Clip(For Glove Compartment)
9046714014 90467-14014 New Genuine Part
9164380820 91643-80820 New Genuine Part
9164380820 91641-80818 BOLT WWASHER
9356715014 93567-15014 Direct
9356715016 93567-15016 New Genuine Part
9356715016 93568-55016 Screw
9356755014 93567-55014 Direct
9356755014 93568-55014 Screw
9356755018 93567-55018 New Genuine Part
9356755018 93568-55018 SCREW
Interior Lamp ([05.1995 - ] (9505- )) 9
#OEMPart name
81240 81240-37030-B0 Lamp Assy, Room, No.1
81240 81240-37030-B1 Lamp Assy, Room, No.1
81240 90981-11053 Bulb, Room Lamp, No.1
81241 81241-37020 Lens, Room Lamp, No.1
81241 81241-37021 Lens, Room Lamp, No.1
81952 81952-37020 Cover, Rear Lamp
9015950087 90159-50087 New Genuine Part
9321016016 93210-16016 SCREW
9322944030 93229-44030 New Genuine Part
Lock Cylinder Set ([05.1995 - ] (9505- )) 11
#OEMPart name
69503 69503-37020 Cylinder Set, Lock
69503 69503-37130 Cylinder Set, Lock
69503 90999-00185 Key, Blank
69503 90999-00186 Key, Blank
69510 69510-37010 Cylinder Assy, Front Door Lock, Rh
69511 69511-95400 Retainer, Front Door Lock Cylinder
69513 69513-32010 Pad, Lock Cylinder
69520 69520-37010 Cylinder Assy, Front Door Lock, Lh
69570 69570-37010 Cylinder Assy, Ignition Switch Lock
69570 69570-36011 Cylinder Assy, Ignition Switch Lock
77310 77310-37020 Cap Assy, Fuel Tank
Manifold ([05.1995 - ] (9505- )3L,5L) 15
#OEMPart name
17111 17101-54110 Manifold, Intake
17141 17141-54111 Manifold, Exhaust
17152 90116-10088 Bolt, Stud(For Manifold To Exhaust Pipe)
17159 90116-08220 Bolt, Stud(For Intake Manifold To Cylinder Head)
17159 90116-10141 Bolt, Stud(For Exhaust Manifold To Cylinder Head)
17167 17167-54110 Insulator, Exhaust Manifold Heat, No.1
17173 17173-54030 Gasket, Exhaust Manifold To Head
17173 17173-05010 Gasket, Exhaust Manifold To Head
17177 17177-54021 Gasket, Intake Manifold To Head, No.1
9011908 90119-08A96 BOLT WWASHER
9011910367 90119-10367 BOLT
9017908150 90179-08150 NUT
9017910070 90179-10070 Nut, Exhaust Pipe Set Stud Bolt
9017910070 90080-17187 Nut, Exhaust Pipe Set Stud Bolt
9161160822 91611-60822 Bolt
Meter ([05.1995 - ] (9505- )) 32
#OEMPart name
83100 83120-24010 Bulb, Combination Meter, No.1
83100 83120-60020 Bulb, Combination Meter, No.1
83100 90010-06006 Bulb, Combination Meter, No.1
83110 83110-25110 Speedometer Assy
83132 83132-37020 Case, Combination Meter
83134 83134-37020 Cover, Combination Meter, No.1
83138 83137-37020 Glass, Speedometer
83145 83146-37340 Lens, Meter, No.1
83145 83146-37240 Lens, Meter, No.2
83145 83146-37140 Lens, Meter, No.3
83145 83145-25070 Lens, Meter, No.1
83149 83247-25070 Plate, Meter Circuit
83149 83149-26860 Plate, Meter Circuit
83180 83180-35020 Detector Assy, Revolution
83189 83189-20020 Bracket, Meter
83248 86650-16020 Chime, Speed Warning
83248 86650-16030 Chime, Speed Warning
83270 83243-37260 Tachometer Assy, Engine
83710 83710-25120 Cable Assy, Speedometer Drive, No.1
83710 83710-25130 Cable Assy, Speedometer Drive, No.1
83770 83770-22100 Adapter Assy, Speedometer Cable
83910 83910-37050 Clock Assy
8316120440 83161-20440 Case, Combination Meter Mirror, No.1
8316120720 83161-20720 Case, Combination Meter Mirror, No.1
8316120800 83161-20800 Case, Combination Meter Mirror, No.1
8316120860 83161-20860 Case, Combination Meter Mirror, No.1
8316165020 83161-65020 Case, Combination Meter Mirror, No.1
8316220100 83162-20100 Case, Combination Meter Mirror, No.2
8316220120 83162-20120 Case, Combination Meter Mirror, No.2
9015940027 90159-40027 New Genuine Part
9356755016 93567-55016 Screw
9356755016 93568-55016 Screw
Meter ([05.1995 - ] 1/2 (9505- )) 19
#OEMPart name
9011908 90119-08A46 BOLT WWASHER
9094901 90949-01A11 New Genuine Part
9094901 90949-01A97 New Genuine Part
8379125040 83791-25040 New Genuine Part
8379125050 83791-25050 New Genuine Part
8379195019 83791-95019 New Genuine Part
8379195020 83791-95020 New Genuine Part
8379195021 83791-95021 New Genuine Part
8379195024 83791-95024 New Genuine Part
8379195025 83791-95025 New Genuine Part
8379195026 83791-95026 New Genuine Part
8379195027 83791-95027 New Genuine Part
9011908469 90119-08469 Bolt(for Dust Cover To Steering Knuckle Arm Setting)
9015970070 90159-70070 New Genuine Part
9017008204 90170-08204 Nut (For Propeller Shaft)
9095901218 90959-01218 New Genuine Part
9161160814 91611-60814 Bolt
9161160816 91611-60816 Screw Or Bolt(For Valve Rocker Shaft Lock)
9161160816 91611-B0816 Bolt
Meter ([05.1995 - ] 2/2 (9505- )) 15
#OEMPart name
8379195 83791-95A00 New Genuine Part
8379195 83791-95A02 New Genuine Part
8379195 83791-95A03 New Genuine Part
9011908 90119-08A46 BOLT WWASHER
9161108 91611-08A46 New Genuine Part
8379125030 83791-25030 New Genuine Part
8379125060 83791-25060 New Genuine Part
8379125070 83791-25070 New Genuine Part
8379125080 83791-25080 New Genuine Part
8379125090 83791-25090 New Genuine Part
9046400165 90464-00165 Clamp, No.2(For Luggage Door Lock Control Cable)
9095901221 90959-01221 New Genuine Part
9161160814 91611-60814 Bolt
9165160820 91651-60820 Bolt, Radiator Side Support Plate
9165160820 91651-B0820 Bolt, Radiator Side Support Plate
Mirror ([05.1995 - ] (9505- )) 20
#OEMPart name
87093 87093-37110 Stay Sub-Assy, Outer Rear View Mirror, Upper Rh
87093 87093-25030 Stay Sub-Assy, Outer Rear View Mirror, Upper Rh
87094 87094-25010 Stay Sub-Assy, Outer Rear View Mirror, Upper Lh
87094 87094-37260 Stay Sub-Assy, Outer Rear View Mirror, Upper Lh
87094 87094-25030 Stay Sub-Assy, Outer Rear View Mirror, Upper Lh
87094 87094-37240 Stay Sub-Assy, Outer Rear View Mirror, Upper Lh
87810 87810-25020-C0 Mirror Assy, Inner Rear View
87810 90981-11027 Bulb(For Map Lamp)
87819 87819-25010 Lens, Inner Rr View Mirror Room Lamp
87827 87828-23010 Absorber, Inner Rear View Mirror
87827 87828-30010 Absorber, Inner Rear View Mirror
87901 87901-37080 Mirror Sub-Assy, Outer Rear View
87901 87901-37130 Mirror Sub-Assy, Outer Rear View
87906 87901-95A00 Mirror Sub-Assy, Outer Rear View
87907 87907-37050 Mirror Sub-Assy, Outer Under View
87910 87910-95A15 Mirror Assy, Outer Rear View, Rh
9014860057 90148-60057 Screw
9015260015 90152-60015 SCREW CROSSRECESS
9356815016 93568-15016 Sensor, Automatic Light Control
9356815016 93568-55016 Screw
Moulding ([05.1995 - ] (9505- )) 2
#OEMPart name
75595 75595-37010 Cover, Roof Drip Side Moulding, Front Rh
75596 75596-37010 Cover, Roof Drip Side Moulding, Front Lh
Mounting ([10.1996 - ] (9610- )3L,5L..LY10#,11#) 24
#OEMPart name
12303 12303-67021 Bracket Sub-Assy, Engine Mounting, Rear
12303 12303-67031 Bracket Sub-Assy, Engine Mounting, Rear
12311 12311-54260 Bracket, Engine Mounting, Front No.1 Rh
12322 12322-54050 Bracket, Engine Mounting, Rear No.2
12322 12322-54060 Bracket, Engine Mounting, Rear No.2
12361 12361-54200 Insulator, Engine Mounting, Front
12381 12381-54050 Stabilizer, Engine Mounting
12381 12381-54052 Stabilizer, Engine Mounting
12581 12581-54010 Insulator, Cylinder Block, No.1
12582 12582-54021 Insulator, Cylinder Block, No.2
12583 12583-54030 Insulator, Cylinder Block, No.3
9010113003 90101-13003 BOLTHEXAGON
9010508384 90105-08384 New Genuine Part
9011910220 90119-10220 New Genuine Part
9011910220 91642-81025 BOLT WWASHER
9011910274 90119-10274 New Genuine Part
9011910274 90119-10038 New Genuine Part
9011910881 90119-10881 New Genuine Part
9017910015 90179-10015 NUT
9017912024 90179-12024 NUT
9161161025 91611-61025 Bolt(For Transaxle & Engine Setting)
9161161025 91612-61025 Bolt (For Control Shaft Cover)
9411041300 94110-41300 NUT
9461211300 94612-11300 Washer(For Outer Lever Oil Setting)
Oil Cooler & Tube (Atm) ([10.1996 - ] A44DE (9610- )LY10#,11#..ATM) 29
#OEMPart name
32907 32907-25020 Tube Sub-Assy, Oil Cooler Outlet, No.2
32910 32910-25011 Cooler Assy, Oil
32913 32913-25010 Bracket, Oil Cooler
32914 32914-25010 Stay, Transmission Oil Cooler
32921 32921-25022 Tube, Oil Cooler Inlet, No.1
32921 90407-16010 Union(For Oil Cooler Tube)
32921 90407-16028 Union(For Oil Cooler Tube)
32921 32941-22181 Hose(For Oil Cooler Inlet)
32921 90301-10189 Ring, O(For Oil Cooler Tube Union)
32922 32922-25022 Tube, Oil Cooler Outlet, No.1
32922 32942-25040 Hose(For Oil Cooler Outlet)
32924 32924-26061 Clamp, Oil Cooler Tube, No.2
32924 90462-12044 Clamp, Automatic Transmission Oil Cooler Tube
32926 32926-30020 Cushion, Oil Cooler Tube(Atm)
32928 32928-26021 Clamp, Oil Cooler Tube, No.2
32941 32941-25020 Hose, Oil Cooler Inlet, No.1
32942 32942-25020 Hose, Oil Cooler Outlet, No.1
32943 32943-25010 Hose, Transmission Oil Cooler, No.1
32943 32943-25020 Hose, Transmission Oil Cooler, No.2
91611 91611-G0614 New Genuine Part
9011906477 90119-06477 New Genuine Part
9046400166 90464-00166 Clamp, Automatic Transmission Oil Cooler Tube, No.7
9046716013 90467-16013 Clip(For Oil Return Hose)
9046716013 90467-16022 Clip(For Water Inlet Hose)
9046810034 90468-10034 CLIP
9161160814 91611-60814 Bolt
9161161020 91611-61020 Bolt(For Transaxle & Engine Setting)
9161161020 91612-B1020 Bolt (For Transfer Case)Cover No.2
9165160620 91651-60620 BOLTWWASHER
Oil Filter ([05.1999 - ] (9905- )5L) 13
#OEMPart name
15600 15116-54021 Union(For Oil Filter)
15600 90341-18015 Plug, W/head Straight Screw(For Timing Gear Case)
15600 90344-51005 Plug, W/head Taper Screw, No.1
15600 90430-18029 Washer(For Oil Filter)
15600 90501-16026 Spring, Compression(For Oil Filter)
15601 90915-30002 Filter Sub-Assy, Oil
15601 90915-30002-8T Oil Filter (Thailand)
15604 15131-54010 Valve, Oil Pump Relief
15609 15609-54072 Bracket Sub-Assy, Oil Filter
15691 15692-54050 Gasket, Oil Filter
9011908 90119-08B32 New Genuine Part
9017908150 90179-08150 NUT
9151180825 91511-80825 BOLTFLANGE
Overdrive & Electronic Controlled Transmission ([10.1996 - ] (9610- )LY10#,11#,16#..ATM) 24
#OEMPart name
33485 33485-30020 Plate, Speedometer Sleeve Lock (For Atm)
35478 35478-30010 Gasket, Accumulator Cover
82125 82125-28010 Wire, Transmission
84722 84722-25010-B0 Switch, Transmission Control
84722 84722-14080-01 Transmission Control Switch (Black color)
85420 85420-30050 Solenoid Assy, Transmission
85420 85420-30070 Solenoid Assy, Transmission
85420 90301-06004 Ring, O No.3(For Transmission Solenoid)
89411 89411-28020 Sensor, Speed
89414 89414-30011 Rotor, Sensor
89530 89530-25050 Computer Assy, Transmission Control
9010505004 90105-05004 New Genuine Part
9011906189 90119-06189 New Genuine Part
9015930121 90159-30121 New Genuine Part
9015960025 90159-60025 SCREW W-WASHER
9028003005 90280-03005 Key, Oil Pump Drive Shaft
9161160610 91611-60610 Bolt (For Transfer Oil Receiver No.1)
9161160610 91611-B0610 Bolt (For Transfer Oil Receiver No.1)
9161160814 91611-60814 Bolt
9161160816 91611-60816 Screw Or Bolt(For Valve Rocker Shaft Lock)
9161160816 91611-B0816 Bolt
9672119009 96721-19009 Ring, O(For Oil Level Gage)
9672124011 96721-24011 Ring, O(For Oil Pipe)
9672124018 96721-24018 Ring, O
Overdrive Gear (Atm) ([10.1996 - ] A44DE,A44DF (9610- )LY10#,11#,16#..ATM) 48
#OEMPart name
34101 34101-22020 Case Sub-Assy, Overdrive
34601 34601-30022 Drum Sub-Assy, Overdrive Direct Clutch
34601 90520-52262 Ring, Shaft Snap (For Underdrive Return Spring)
34601 35634-22040 Plate, Clutch (For Overdrive)
34601 35677-30160 Disc, Clutch (For Overdrive)
34601 90521-99146 Ring, Hole Snap, No.1 (For Overdrive)
34601 90521-99001 Ring, Hole Snap, No.2 (For Overdrive)
34602 34602-30011 Piston Sub-Assy, Overdrive Direct Clutch
34602 90301-56007 Ring, O (For Underdrive Clutch Piston)
34602 90301-57188 Ring, O (For Underdrive Clutch Piston)
34602 90301-99016 Ring, O (For Overdrive Direct Clutch Piston)
34602 90301-99058 Ring, O (For Overdrive Direct Clutch Piston)
34604 34604-22010 Spring Sub-Assy, Overdrive Clutch Return
34622 34622-30040 Piston, Overdrive Brake
34622 90301-99008 Ring, O (For Overdrive Brake Piston)
34622 90301-99103 Ring, O (For Overdrive Brake Piston)
34622 90301-99009 Ring, O (For Overdrive Brake Piston)
34622 90301-99111 Ring, O (For Overdrive Brake Piston)
34623 34623-30020 Seat, Overdrive Brake Return Spring
34623 90501-11023 Spring, Compression (For Overdrive Direct Clutch)
34623 90521-99004 Ring, Hole Snap (For Overdrive Brake Return Spring Seat)
34624 34624-26010 Hub, Overdrive Brake
34625 34625-22020 Flange, Overdrive Brake, No.1
34625 34625-26010 Flange, Overdrive Brake, No.1
34626 34626-30050 Plate, Overdrive Brake Cushion
34705 34705-30021 Gear Sub-Assy, Overdrive Planetary Ring
34710 34710-14011 Gear Assy, Overdrive Planetary
34710 90521-99003 Ring, Hole Snap(For Overdrive Planetary Gear)
34710 34739-30031 Race, Thrust Bearing(For Overdrive Planetary Gear)
34710 34739-30041 Race, Thrust Bearing(For Overdrive Planetary Gear)
34710 35789-22010 Race, Thrust Bearing(For Overdrive Planetary Gear)
34710 90374-23012 Bearing, Thrust Needle Roller(For Overdrive Planetary Gear)
34710 90374-24001 Bearing, Thrust Needle Roller(For Overdrive Planetary Gear)
34710 90334-03001 Plug, Straight(For Overdrive Planetary Gear)
34710 90250-03024 Pin, Straight(For Overdrive Planetary Gear)
34713 34713-30020 Race, 1 Way Clutch Outer (For Overdrive)
34714 35791-30030 Clutch, 1Way, No.1(For Overdrive)
34735 34735-30020 Washer, Overdrive Planetary Gear Thrust, No.1
34736 34736-30010 Washer, Overdrive Planetary Gear Thrust, No.2
34737 34737-30020 Washer, Overdrive Planetary Gear Thrust, No.3
34738 34738-30020 Washer, Overdrive Planetary Gear Thrust, No.4
34739 34739-30020 Race, Thrust Bearing(For Overdrive)
34739 35789-22030 Race, Thrust Bearing(For Overdrive)
34739 90374-28014 Bearing, Thrust Needle Roller(For Overdrive)
35617 35617-43010 Ring, Clutch Drum Oil Seal (For Overdrive)
35634 34634-30010 Plate, Clutch (For Overdrive)
35634 35634-30080 Flange, Overdrive Brake, No.1
35677 35677-43010 Disc, Clutch (For Overdrive)
Parking Brake & Cable ([10.1996 - ] (9610- )LY10#,11#,15#,16#,YY101..ST) 53
#OEMPart name
46103 46103-25081 Guide Sub-Assy, Parking Brake Plunger
46104 46104-25071 Handle Sub-Assy, Parking Brake Control
46110 90386-12048 Bush Or Ring, O (For Parking Brake Plunger)
46114 46114-20010 Pin(For Parking Brake Handle Set)
46144 46144-20010 Anti-Rattle, Parking Brake Plunger
46301 46301-26030 Lever Sub-Assy, Parking Brake Intermediate
46301 90386-13007 Bush(For Clutch Pedal)
46301 90387-10003 Collar, Clutch Pedal Shaft
46301 90101-10039 Shaft, Clutch Pedal
46304 90385-12029 Bush(For Parking Brake Equalizer)
46311 46311-26010 Pawl, Parking Brake
46311 90508-08106 Spring, Torsion(For Parking Brake Plunger)
46313 46313-40010 Pin, Parking Brake Pawl
46321 90506-18058 Spring, Tensiion(For Parking Brake Intermediate Lever)
46341 46341-35020 Equalizer Sub-Assy, Parking Brake
46356 46356-26090 Bracket, Intermediate Lever(For Parking Brake)
46410 46410-26371 Cable Assy, Parking Brake, No.1
46420 46420-25220 Cable Assy, Parking Brake, No.2
46420 90240-08042 Pin, W/hole(For Gear Selecting Rod No.2)
46420 46420-26211 Cable Assy, Parking Brake, No.2
46441 46441-30041 Nut, Wire Adjusting, No.1
46454 46454-26051 Bracket, Cable Retainer, Front
46458 46458-28010 Retainer, Cable
46469 46469-25010 Lever, Cable Guide Support
46469 46469-60020 Lever, Cable Guide Support
46471 46471-20010 Pulley, Wire
46471 90240-08017 Pin, W/hole(For Parking Brake Cable)
9011908 90119-08A46 BOLT WWASHER
9094901 90949-01A11 New Genuine Part
9094901 90949-01A14 New Genuine Part
9094901 90949-01B72 New Genuine Part
9010506109 90105-06109 New Genuine Part
9010908206 90109-08206 BOLT
9046108645 90461-08645 New Genuine Part
9046400677 90464-00677 New Genuine Part
9046803016 90468-03016 New Genuine Part
9046806076 90468-06076 New Genuine Part
9046808001 90468-08001 CLIP
9046814004 90468-14004 Union, Auxiliary Fuel Band
9046816012 90468-16012 Pin, Sub Seat Cushion Pin
9094901252 90949-01252 New Genuine Part
9161160612 91611-60612 Bolt(For Dust Cover To Steering Knuckle Arm Setting)
9161160612 91611-G0612 Bolt
9161160814 91611-60814 Bolt
9161160816 91611-60816 Screw Or Bolt(For Valve Rocker Shaft Lock)
9161160816 91611-B0816 Bolt
9161160820 91611-60820 Bolt(For Transaxle & Engine Setting)
9161160820 91611-G0820 Bolt
9165140820 91651-40820 Bolt
9165160616 91651-60616 BOLT
9413060600 94130-60600 Nut, Wire Adjusting, No.1
9413061000 94130-61000 Nut(For Clutch Pedal Stopper)
9453101000 94531-01000 WASHER
Partial Engine Assembly ([05.1995 - ] (9505- )) 1
#OEMPart name
11000 19000-5B660 Engine Assy, Partial
Planetary Gear, Reverse Piston & Counter Gear(Atm) ([10.1996 - ] A44DE,A44DF (9610- )LY10#,11#,16#..ATM) 24
#OEMPart name
33481 33481-26011 Gear, Speedometer Drive (Atm)
33481 90360-06004 Ball, Detent(For Gear Shift Head No.4)
33481 90080-36191 Ball, Check Valve
35074 35074-30030 Gear Sub-Assy, Rear Planetary Ring
35074 90522-20037 Ring, Set (For Rear Planetary Ring Gear)
35074 35789-22020 Race, Thrust Bearing (For Rear Planetary Ring Gear Rear)
35074 90374-28014 Bearing, Thrust Needle Roller(For Overdrive)
35481 90520-28009 Ring Or Spacer (For Mtm Speedometer Drive Gear)
35481 90520-29004 Ring, Shaft Snap (For Atm Speedmeter Drive Gear)
35704 35704-30040 Carrier Sub-Assy, Planetary W/lock Gear
35708 35708-30041 Shaft Sub-Assy, Planetary Intermediate
35735 35735-22010 Ring, Planetary Output Snap
35737 35737-22010 Washer, Planetary Carrier Thrust
35738 35738-30030 Washer, Planetary Carrier Thrust, No.2
35739 35739-30020 Washer, Planetary Carrier Thrust, No.3
35743 35743-30010 Gear, Front Planetary Ring
35743 90520-99121 Ring, Shaft Snap (For Front Planetary Ring Gear)
35748 35748-30010 Ring, Intermediate Shaft Sleeve Oil Seal
35760 35760-30040 Gear Assy, Rear Planetary
35770 35770-53010 Shaft Assy, Output
35770 90374-38013 Bearing, Thrust (For Output Shaft)
35770 35789-22040 Race, Thrust Bearing (For Output Shaft)
35792 35792-30030 Clutch, 1 Way, No.2
35792 90521-79148 Ring, Hole Snap(For Overdrive Planetary Gear)
Power Steering Tube ([10.1996 - ] (9610- )LY10#,11#) 25
#OEMPart name
44318 44318-26010 Spacer, Vane Pump Drive Pulley
44319 44319-26010 Pulley, Vane Pump Drive
44348 44348-26060 Hose, Oil Reservoir To Pump, No.1
44410 44410-25070 Tube Assy, Pressure Feed
44411 44411-26021 Hose, Pressure Feed
44411 90401-16027 Bolt, Union(For Pressure Feed Tube)
44411 90430-16168 Gasket(For Pressure Feed Tube)
44443 44443-25010 Bracket, Pump
44446 44446-30070 Strut, Adjusting
9010510042 90105-10042 Bolt, Flywheel Setting
9010510152 90105-10152 New Genuine Part
9010512109 90105-12109 Bolt, Flywheel Setting
9011910049 90119-10049 Bolt, Center Support Bearing Bracket
9046110678 90461-10678 New Genuine Part
9046716008 90467-16008 Clip(For Oil Return Hose)
9046716008 90467-16019 Clip(For Return No.1)
9046721005 90467-21005 Clip(For Suction Hose No.1)
9046721005 90467-21010 Clip(For Ventilation Hose No.2)
9161160816 91611-60816 Screw Or Bolt(For Valve Rocker Shaft Lock)
9161160816 91611-B0816 Bolt
9161161025 91611-61025 Bolt(For Transaxle & Engine Setting)
9161161025 91612-61025 Bolt (For Control Shaft Cover)
9165160820 91651-60820 Bolt, Radiator Side Support Plate
9165160820 91651-B0820 Bolt, Radiator Side Support Plate
9165160828 91651-60828 Bolt
Propeller Shaft & Universal Joint ([10.1996 - ] (9505- )125..LPG ; (9505- )LY201,YY201..TS ..ST ; (9610- )LY10#,11#,YY101 ; (9610- )YY211 ..WT..125..CBR) 71
#OEMPart name
4371 04371-30040 Spider Kit, Universal Joint(For Propeller Shaft)
4371 04371-60100 Spider Kit, Universal Joint(For Propeller Shaft)
4371 04371-30041 Spider Kit, Universal Joint(For Propeller Shaft)
37101 90937-01132 Piece, Balance, No.1 (For Propeller Shaft)
37101 90937-01136 Piece, Balance, No.1 (For Propeller Shaft)
37101 90937-01140 Piece, Balance, No.1 (For Propeller Shaft)
37101 90937-01147 Piece, Balance, No.1 (For Propeller Shaft)
37101 90937-01148 Piece, Balance, No.1 (For Propeller Shaft)
37101 90937-01149 Piece, Balance, No.1 (For Propeller Shaft)
37101 90937-01150 Piece, Balance, No.1 (For Propeller Shaft)
37101 90937-01151 Piece, Balance, No.1 (For Propeller Shaft)
37101 90937-01152 Piece, Balance, No.1 (For Propeller Shaft)
37101 90937-01153 Piece, Balance, No.1 (For Propeller Shaft)
37101 90937-01154 Piece, Balance, No.1 (For Propeller Shaft)
37101 90937-01155 Piece, Balance, No.1 (For Propeller Shaft)
37101 90937-01156 Piece, Balance, No.1 (For Propeller Shaft)
37101 90937-01157 Piece, Balance, No.1 (For Propeller Shaft)
37101 90937-01158 Piece, Balance, No.1 (For Propeller Shaft)
37110 37110-25460 Shaft Assy, Propeller
37110 90105-10085 Bolt, No.1 (For Propeller Shaft & Differential Setting)
37110 90080-10294 Bolt, No.1 (For Propeller Shaft & Differential Setting)
37110 90179-10059 Nut, No.1 (For Propeller Shaft & Differential Setting)
37110 90080-17239 Nut, No.2 (For Propeller Shaft & Differential Setting)
37110 90204-10002 Washer, No.1 (For Propeller Shaft & Differential Setting)
37110 90560-10H00 Washer, No.1 (For Propeller Shaft & Differential Setting)
37110 37110-25450 Shaft Assy, Propeller
37302 37302-35030 Yoke Sub-Assy, Universal Joint Sleeve
37315 37315-35040 Yoke, Universal Joint Flange
37315 37315-35070 Yoke, Universal Joint Flange
37331 37331-30010 Cover, Sliding Shaft Dust
37401 90520-25039 Ring, Hole Snap (For Spider Bearing)
37401 90520-25040 Ring, Hole Snap (For Spider Bearing)
37401 90520-25041 Ring, Hole Snap (For Spider Bearing)
37401 90520-25042 Ring, Hole Snap (For Spider Bearing)
37401 90520-25043 Ring, Hole Snap (For Spider Bearing)
37401 90520-25044 Ring, Hole Snap (For Spider Bearing)
37401 90520-25045 Ring, Hole Snap (For Spider Bearing)
37401 90520-25046 Ring, Hole Snap (For Spider Bearing)
37401 90520-25047 Ring, Hole Snap (For Spider Bearing)
37401 90520-25048 Ring, Hole Snap (For Spider Bearing)
37401 90520-25049 Ring, Hole Snap (For Spider Bearing)
37401 90520-25050 Ring, Hole Snap (For Spider Bearing)
37401 90520-25051 Ring, Hole Snap (For Spider Bearing)
37401 90520-25052 Ring, Hole Snap (For Spider Bearing)
37401 90520-25053 Ring, Hole Snap (For Spider Bearing)
37401 90520-25054 Ring, Hole Snap (For Spider Bearing)
37401 90520-25055 Ring, Hole Snap (For Spider Bearing)
37401 90520-25056 Ring, Hole Snap (For Spider Bearing)
37401 90520-25057 Ring, Hole Snap (For Spider Bearing)
37401 90520-25058 Ring, Hole Snap (For Spider Bearing)
37401 90520-26050 Ring, Hole Snap (For Spider Bearing)
37401 90520-26051 Ring, Hole Snap (For Spider Bearing)
37401 90520-26052 Ring, Hole Snap (For Spider Bearing)
37401 90520-26053 Ring, Hole Snap (For Spider Bearing)
37401 90520-26054 Ring, Hole Snap (For Spider Bearing)
37401 90520-26055 Ring, Hole Snap (For Spider Bearing)
37401 90520-26056 Ring, Hole Snap (For Spider Bearing)
37401 90520-26057 Ring, Hole Snap (For Spider Bearing)
37401 90520-26058 Ring, Hole Snap (For Spider Bearing)
37401 90520-26059 Ring, Hole Snap (For Spider Bearing)
37401 90520-26062 Ring, Hole Snap (For Spider Bearing)
37401 90520-26063 Ring, Hole Snap (For Spider Bearing)
37401 90520-26064 Ring, Hole Snap (For Spider Bearing)
37401 90520-26065 Ring, Hole Snap (For Spider Bearing)
37401 90520-26066 Ring, Hole Snap (For Spider Bearing)
37401 90520-26067 Ring, Hole Snap (For Spider Bearing)
37401 90520-26068 Ring, Hole Snap (For Spider Bearing)
37401 90520-26069 Ring, Hole Snap (For Spider Bearing)
37402 37402-30011 Bearing Sub-Assy, Universal Joint Spider
37402 04371-60070 Spider Kit, Propeller Shaft Universal Joint
37402 37402-30021 Bearing Sub-Assy, Universal Joint Spider
Radiator & Water Outlet ([05.1995 - ] (9505- )3L,5L) 19
#OEMPart name
16400 16400-5B191 Radiator Assy
16400 16417-15210 Plug, Radiator Drain Cock
16400 16418-15520 Packing(For Radiator Drain Cock)
16400 16400-5B572 Radiator Assy
16401 16401-67150 Cap Sub-Assy(For Water Outlet)
16403 16403-5B191 Core Sub-Assy, Radiator
16403 16403-5B572 Core Sub-Assy, Radiator
16442 16442-58420 Ring, O(For Radiator Upper Tank)
16443 16443-58420 Plate, Radiator Tank, Lock, Upper
16453 16453-5B190 Plate, Radiator Side
16453 16453-5B570 Plate, Radiator Side
16454 16454-5B190 Plate, Radiator Side
16455 16455-67020 Bolt, Radiator Side Support Plate
16491 16491-5B570 Cooler, Oil(For Atm)
16491 16492-61170 Ring, O(For Atm Oil Cooler)
16491 16493-61170 Washer, Plate(For Atm Oil Cooler)
16491 16494-61170 Washer, Spring(For Atm Oil Cooler)
16491 16496-15580 Nut(For Atm Oil Cooler)
16495 16497-17030 Nut, Flare(For Atm Oil Cooler)
Radiator & Water Outlet ([05.1995 - ] ﾚｲﾄｳｼﾔ (9505- )3L,5L) 13
#OEMPart name
16400 16400-5B191 Radiator Assy
16400 16417-15210 Plug, Radiator Drain Cock
16400 16418-15520 Packing(For Radiator Drain Cock)
16400 16400-5B572 Radiator Assy
16403 16403-5B191 Core Sub-Assy, Radiator
16403 16403-5B572 Core Sub-Assy, Radiator
16442 16442-58420 Ring, O(For Radiator Upper Tank)
16443 16443-58420 Plate, Radiator Tank, Lock, Upper
16453 16453-5B190 Plate, Radiator Side
16453 16453-5B570 Plate, Radiator Side
16454 16454-5B190 Plate, Radiator Side
16455 16455-67020 Bolt, Radiator Side Support Plate
9165160612 91651-60612 BOLT
Radiator & Water Outlet ([10.1996 - ] (9610- )3L,5L..LY10#,11#) 66
#OEMPart name
16261 16261-54090 Hose, Water By-Pass
16261 90467-15022 Clip Or Clamp(For Ventilation Hose)
16261 90404-54037 Union(For Water By-Pass Hose)
16264 16264-54080 Hose, Water By-Pass, No.2
16331 16331-54090 Outlet, Water
16331 16340-54010 Thermostat
16333 16333-54113 Housing, Water Outlet
16333 16333-54210 Housing, Water Outlet
16341 16341-35010 Gasket, Water Outlet
16343 16343-54040 Gasket, Water Outlet Housing
16361 16361-54070 Fan
16361 16361-67030 Fan
16381 16381-54121 Bar, Fan Belt Adjusting
16400 16400-5B191 Radiator Assy
16400 16400-5B572 Radiator Assy
16470 16470-54280 Tank Assy, Radiator Reserve
16470 16567-58010 Hose Or Pipe(For Radiator Reserve Tank)
16470 90467-11085 Clamp Or Clip(For Radiator Breather Hose)
16470 90445-12078 Hose(For Radiator Breather)
16471 16405-54250 Cap Sub-Assy, Reserve Tank
16505 16505-54020 Support Sub-Assy, Radiator, Rh
16506 16506-54010 Support Sub-Assy, Radiator, Lh
16523 53210-36010 Cushion, Radiator Support
16561 16561-71010 Seal, Radiator To Support, No.1
16571 16571-54390 Hose, Radiator, Inlet
16571 90467-37001 Clip(For Water Inlet Hose)
16571 90467-37003 Clamp Or Clip, Hose(For Radiator Inlet)
16572 16572-54430 Hose, Radiator, Outlet
16572 90467-37002 Clip(For Water Inlet Hose)
16572 90467-37005 Clip(For Water Inlet Hose)
16572 90467-41005 Clamp Or Clip, Sub Radiator Hose
16573 16573-54110 Hose, Radiator, No.3
16577 16577-54160 Pipe, Radiator, No.7
16582 16582-54030 Bracket, Radiator, No.1
16592 16592-54070 Guide, Radiator Air, No.3
16593 16593-54070 Guide, Radiator Air, No.1
16593 16593-54090 Guide, Radiator Air, No.1
16594 16594-54090 Guide, Radiator Air, No.2
16611 16611-54130 Bracket, Radiator Reserve Tank
16711 16711-54470 Shroud, Fan
9011908 90119-08A46 BOLT WWASHER
9094901 90949-01A45 New Genuine Part
9011906144 90119-06144 Bolt, Hexagon (For Shift Lever Plate)
9011908689 90119-08689 Bolt(For Clutch Release Cylinder Setting)
9011908689 91611-G0820 Bolt
9011908694 90119-08694 BOLT
9011912224 90119-12224 BOLT WWASHER
9017906293 90179-06293 NUT
9046912009 90469-12009 Clamp Or Clip(For Radiator Reserve Tank Hose)
9046912010 90469-12010 Clamp Or Clip(For Radiator Reserve Tank Hose No.3)
9054011008 90540-11008 Insulator, Radiator Mounting
9092901220 90929-01220 Clamp Or Clip(For Water By-Pass Hose)
9162140812 91621-40812 BOLT
9162140814 91621-40814 Bolt
9162140820 91621-40820 Bolt
9162140855 91621-40855 New Genuine Part
9162160612 91621-60612 BOLTWWASHER
9162160612 91621-J0612 BOLT W-WASHER
9162160825 91621-60825 BOLT
9162160825 91651-B0825 Bolt, Hexagon(For Steering Column Bracket)
9163140828 91631-40828 New Genuine Part
9165140616 91651-40616 BOLT
9165140616 91621-60614 Bolt(For Transaxle & Engine Setting)
9165140616 90080-11395 New Genuine Part
9413000802 94130-00802 Nut, No.1 (For Center Support Bearing)
9413000802 90170-A0001 New Genuine Part
Radiator & Water Outlet ([10.1996 - ] ﾚｲﾄｳｼﾔ (9610- )3L,5L..LY10#) 67
#OEMPart name
16261 16261-54090 Hose, Water By-Pass
16261 90467-15022 Clip Or Clamp(For Ventilation Hose)
16261 90404-54037 Union(For Water By-Pass Hose)
16264 16264-54080 Hose, Water By-Pass, No.2
16331 16331-54090 Outlet, Water
16331 16340-54010 Thermostat
16333 16333-54113 Housing, Water Outlet
16333 16333-54210 Housing, Water Outlet
16341 16341-35010 Gasket, Water Outlet
16343 16343-54040 Gasket, Water Outlet Housing
16361 16361-54070 Fan
16361 16361-67030 Fan
16381 16381-54121 Bar, Fan Belt Adjusting
16400 16400-5B191 Radiator Assy
16400 16400-5B572 Radiator Assy
16401 16401-67150 Cap Sub-Assy(For Water Outlet)
16470 16470-54280 Tank Assy, Radiator Reserve
16470 16567-58010 Hose Or Pipe(For Radiator Reserve Tank)
16470 90467-11085 Clamp Or Clip(For Radiator Breather Hose)
16470 90445-12078 Hose(For Radiator Breather)
16471 16405-54250 Cap Sub-Assy, Reserve Tank
16505 16505-54020 Support Sub-Assy, Radiator, Rh
16506 16506-54010 Support Sub-Assy, Radiator, Lh
16523 53210-36010 Cushion, Radiator Support
16561 16561-71010 Seal, Radiator To Support, No.1
16571 16571-54390 Hose, Radiator, Inlet
16571 90467-37001 Clip(For Water Inlet Hose)
16571 90467-37003 Clamp Or Clip, Hose(For Radiator Inlet)
16572 16572-54430 Hose, Radiator, Outlet
16572 90467-37002 Clip(For Water Inlet Hose)
16572 90467-37005 Clip(For Water Inlet Hose)
16572 90467-41005 Clamp Or Clip, Sub Radiator Hose
16573 16573-54110 Hose, Radiator, No.3
16577 16577-54160 Pipe, Radiator, No.7
16582 16582-54030 Bracket, Radiator, No.1
16593 16593-54070 Guide, Radiator Air, No.1
16593 16593-54090 Guide, Radiator Air, No.1
16594 16594-54090 Guide, Radiator Air, No.2
16611 16611-54130 Bracket, Radiator Reserve Tank
16711 16711-54470 Shroud, Fan
9011908 90119-08A46 BOLT WWASHER
9094901 90949-01A45 New Genuine Part
9011906144 90119-06144 Bolt, Hexagon (For Shift Lever Plate)
9011908689 90119-08689 Bolt(For Clutch Release Cylinder Setting)
9011908689 91611-G0820 Bolt
9011908694 90119-08694 BOLT
9011912224 90119-12224 BOLT WWASHER
9017906293 90179-06293 NUT
9046912009 90469-12009 Clamp Or Clip(For Radiator Reserve Tank Hose)
9046912010 90469-12010 Clamp Or Clip(For Radiator Reserve Tank Hose No.3)
9054011008 90540-11008 Insulator, Radiator Mounting
9092901220 90929-01220 Clamp Or Clip(For Water By-Pass Hose)
9151261230 91512-61230 BOLTFLANGE
9162140812 91621-40812 BOLT
9162140814 91621-40814 Bolt
9162140820 91621-40820 Bolt
9162140855 91621-40855 New Genuine Part
9162160612 91621-60612 BOLTWWASHER
9162160612 91621-J0612 BOLT W-WASHER
9162160825 91621-60825 BOLT
9162160825 91651-B0825 Bolt, Hexagon(For Steering Column Bracket)
9163140828 91631-40828 New Genuine Part
9165140616 91651-40616 BOLT
9165140616 91621-60614 Bolt(For Transaxle & Engine Setting)
9165140616 90080-11395 New Genuine Part
9413000802 94130-00802 Nut, No.1 (For Center Support Bearing)
9413000802 90170-A0001 New Genuine Part
Radiator Grille ([05.1995 - ] (9505- )) 8
#OEMPart name
53111 53101-37010-B0 Grille, Radiator
53111 53101-37040-B0 Grille, Radiator
53115 53115-37020 Bracket, Radiator Grille
53145 53145-26010 Clip, Radiator Grille Garnish
9011906595 90119-06595 BOLT WWASHER
9018906174 90189-06174 GROMMET SCREW
9046719020 90467-19020 CLIP
9356056020 93560-56020 SCREW
Radiator Support & Wind Guide ([05.1995 - ] (9505- )) 12
#OEMPart name
53180 53180-25010 Shutter Assy, Radiator
53188 53188-37010 Bracket, Radiator Shutter Support, Rh
53189 53189-37010 Bracket, Radiator Shutter Support, Lh
59193 59193-25030 Guard, Noise Shutter
59195 59195-25030 Insulator, Noise Shutter
9162160612 91621-60612 BOLTWWASHER
9162160612 91621-J0612 BOLT W-WASHER
9163260612 91632-60612 BOLT WWASHER
9163260612 91631-J0612 BRACKET
9165540820 91655-40820 New Genuine Part
9165540820 91653-40820 BOLT, W/WASHER
904671000501 90467-10005-01 Clip(For Front Fender Apron Seal)
Radio Receiver & Amplifier & Condenser ([05.1995 - ] (9505- )) 11
#OEMPart name
86011 90980-04040 Condenser, Radio Setting
86120 86120-2B530 Receiver Assy, Radio
86120 86120-37010 Receiver Assy, Radio
86120 86120-37060 Receiver Assy, Radio
86211 86211-37030 Bracket, Radio, No.1
86212 86212-37020 Bracket, Radio, No.2
9014950032 90149-50032 Screw
9015350010 90153-50010 BOLT
9015960025 90159-60025 SCREW W-WASHER
9017905021 90179-05021 NUT
9165160614 91651-60614 Bolt
Rear Axle Housing & Differential ([05.1995 - ] (9505- )LY10#,11#,15#,YY101 ; (9505- )LY16 #..T2,T3,TW1..TS ; (9505- )LY201 ,YY201..T1,T2,TW2) 13
#OEMPart name
41110 90116-08329 Bolt, No.1 (For Rear Differential Carrier Set)
41110 90116-08334 Bolt, No.1 (For Rear Differential Carrier Set)
41991 41991-22010 Caution Plate, Rear Differential (LSD)
42110 42110-26192 Housing Assy, Rear Axle
42110 90341-18006 Plug (No magnet)
42110 12157-10010 Gasket (For Drain Plug)
42110 90930-03031 Plug, Breather(For Parking Cover)
42110 90341-18040 Plug (For Rear Axle Housing Drain)
42110 42110-26212 Housing Assy, Rear Axle
42181 42181-60020 Gasket, Rear Differential Carrier
42181 42181-0K030 Gasket, Rear Differential Carrier
9017008204 90170-08204 Nut (For Propeller Shaft)
9453100800 94531-00800 Washer (For Transfer Shift Outer Lever)
Rear Axle Housing & Differential ([10.1996 - ] (9505- )LY16#,201..T2..ST..125 ; (9610- )L Y10#,11#,YY101 ; (9708- )LY16#.. T3,TW1..ATM) 66
#OEMPart name
41101 41101-35031 Carrier Sub-Assy, Differential, Rear
41110 41110-35481 Carrier Assy, Differential, Rear
41110 41110-3D251 Carrier Assy, Differential, Rear
41110 41110-25240 Carrier Assy, Differential, Rear
41110 41110-3D241 Carrier Assy, Differential, Rear
41114 90105-12053 Bolt (For Rear Differential Carrier)
41201 41201-29655 Final Gear Kit, Differential, Rear
41201 41201-80189 Final Gear Kit, Differential, Rear
41201 41204-35082 Flange Sub-Assy, Rear Drive Pinion Companion, Rear
41201 41214-26011 Slinger, Rear Differential Drive Pinion Oil
41201 41201-29675 Final Gear Kit, Differential, Rear
41201 90366-35044 Bearing (For Rear Drive Pinion Rear)
41201 90366-30022 Bearing (For Rear Drive Pinion Front)
41201 90366-30078 Bearing (For Rear Drive Pinion Front)
41201 90311-38047 Seal, Oil (For Differential Carrier)
41201 90201-35497 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35498 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35499 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35500 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35501 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35502 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35503 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35504 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35505 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35506 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35507 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35508 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35509 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35510 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35511 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35512 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35513 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35514 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35515 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35516 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35517 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35518 Washer, Plate (For Rear Differential Drive Pinion)
41204 41204-35040 Flange Sub-Assy, Rear Drive Pinion Companion, Rear
41204 90179-20018 Nut (For Rear Drive Pinion)
41214 41214-26010 Slinger, Rear Differential Drive Pinion Oil
41222 41222-35020 Plate, Rear Differential Ring Gear Set Bolt Lock
41222 90101-11353 Bolt (For Rear Differential Ring Gear Set)
41231 41231-40011 Spacer, Rear Differential Drive Pinion Bearing
41252 41252-35020 Deflector, Dust (For Rear Differential)
41301 90368-45066 Bearing(For Rear Differential Case)
41301 90368-50024 Bearing(For Rear Differential Case)
41302 41311-40020 Case Sub-Assy, Rear Differential
41302 41302-35040 Case Sub-Assy, Rear Differential
41302 41302-35041 CASE SUBASSY
41302 90105-11063 Bolt (For Rear Differential Ring Gear Set)
41315 41315-35010 Nut, Rear Differential Bearing Adjusting
41316 41316-35010 Lock, Rear Differential Bearing Adjusting Nut
41331 41331-35011 Gear, Rear Differential Side
41331 41331-35030 Gear, Rear Differential Side
41331 41039-34070 Gear Kit, Differential, Rear
41341 41341-35020 Pinion, Rear Differential
41341 41341-30020 Pinion, Rear Differential
41341 41341-30050 Pinion, Rear Differential
41342 41342-39610 Shaft, Rear Differential Pinion
41343 90250-06085 Pin, Straight (For Differential Pinion Shaft)
41351 41351-30052 Washer, Rear Differential Pinion Thrust
41351 41351-30060 Washer, Rear Differential Pinion Thrust
41361 41361-40021 Washer, Rear Differential Side Gear Thrust, No.1
41361 41362-40021 Washer, Rear Differential Side Gear Thrust, No.1
41361 41363-40021 Washer, Rear Differential Side Gear Thrust, No.1
9161160814 91611-60814 Bolt
Rear Axle Housing & Differential ([10.1996 - ] ﾘﾐﾃﾂﾄﾞ ｽﾘﾂﾌﾟ ﾃﾞｲﾌｱﾚﾝｼﾔﾙ (9610- )) 77
#OEMPart name
41039 41039-34070 Gear Kit, Differential, Rear
41101 41101-35031 Carrier Sub-Assy, Differential, Rear
41110 41110-35481 Carrier Assy, Differential, Rear
41110 41110-3D251 Carrier Assy, Differential, Rear
41110 41110-25240 Carrier Assy, Differential, Rear
41110 41110-3D241 Carrier Assy, Differential, Rear
41114 90105-12053 Bolt (For Rear Differential Carrier)
41201 41201-29655 Final Gear Kit, Differential, Rear
41201 41201-80189 Final Gear Kit, Differential, Rear
41201 41204-35082 Flange Sub-Assy, Rear Drive Pinion Companion, Rear
41201 41214-26011 Slinger, Rear Differential Drive Pinion Oil
41201 41201-29675 Final Gear Kit, Differential, Rear
41201 90366-35044 Bearing (For Rear Drive Pinion Rear)
41201 90366-30022 Bearing (For Rear Drive Pinion Front)
41201 90366-30078 Bearing (For Rear Drive Pinion Front)
41201 90311-38047 Seal, Oil (For Differential Carrier)
41201 90201-35497 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35498 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35499 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35500 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35501 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35502 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35503 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35504 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35505 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35506 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35507 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35508 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35509 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35510 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35511 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35512 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35513 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35514 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35515 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35516 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35517 Washer, Plate (For Rear Differential Drive Pinion)
41201 90201-35518 Washer, Plate (For Rear Differential Drive Pinion)
41204 41204-35040 Flange Sub-Assy, Rear Drive Pinion Companion, Rear
41204 90179-20018 Nut (For Rear Drive Pinion)
41214 41214-26010 Slinger, Rear Differential Drive Pinion Oil
41222 41222-35020 Plate, Rear Differential Ring Gear Set Bolt Lock
41222 90101-11353 Bolt (For Rear Differential Ring Gear Set)
41231 41231-40011 Spacer, Rear Differential Drive Pinion Bearing
41252 41252-35020 Deflector, Dust (For Rear Differential)
41301 90368-45066 Bearing(For Rear Differential Case)
41301 90368-50024 Bearing(For Rear Differential Case)
41302 41311-40020 Case Sub-Assy, Rear Differential
41302 41302-35040 Case Sub-Assy, Rear Differential
41302 41302-35041 CASE SUBASSY
41302 90105-11063 Bolt (For Rear Differential Ring Gear Set)
41302 90105-10084 Bolt(For Rear Differential Case)
41302 90105-10570 Bolt(For Rear Differential Case)
41315 41315-35010 Nut, Rear Differential Bearing Adjusting
41316 41316-35010 Lock, Rear Differential Bearing Adjusting Nut
41331 41331-35011 Gear, Rear Differential Side
41331 41331-35030 Gear, Rear Differential Side
41331 90501-65003 Spring, Compression
41341 41341-35020 Pinion, Rear Differential
41341 41341-30020 Pinion, Rear Differential
41341 41341-30050 Pinion, Rear Differential
41351 41351-30052 Washer, Rear Differential Pinion Thrust
41351 41351-30060 Washer, Rear Differential Pinion Thrust
41361 90564-50001 Washer, Plate (For Rear Differential Side Gear Shaft)
41361 90564-50002 Washer, Plate (For Rear Differential Side Gear Shaft)
41361 90564-50003 Washer, Plate (For Rear Differential Side Gear Shaft)
41361 90564-50004 Washer, Plate (For Rear Differential Side Gear Shaft)
41361 90564-50005 Washer, Plate (For Rear Differential Side Gear Shaft)
41362 41361-35160 Washer, Rear Differential Side Gear Thrust, No.1
41362 41361-35161 Washer, Rear Differential Side Gear Thrust, No.1
41362 41361-35290 Washer, Rear Differential Side Gear Thrust, No.1
41362 41361-35291 Washer, Rear Differential Side Gear Thrust, No.1
41371 41306-35040 Spider Sub-Assy, Front Differential
41385 41385-22020 Plate, clutch
41387 41308-35010 Member Kit, Clutch
41388 41388-35020 Retainer Sub-Assy, Spring
9161160814 91611-60814 Bolt
Rear Axle Shaft & Hub ([10.1996 - ] (9505- )LY201,YY201..TS..ST ; (9610- )LY10 #,11#,15#,YY101 ; (9610- )LY16#. .T2,T3,TW1..TS) 26
#OEMPart name
42311 90310-50001 Seal, Oil (For Rear Axle Shaft)
42311 90310-50006 Seal, Oil (For Rear Axle Shaft)
42311 90363-40041 Bearing (For Rear Axle Shaft)
42311 90363-40068 Bearing (For Axle Shaft)
42311 90363-40072 Bearing (For Rear Axle Shaft)
42311 90313-48001 Seal, Oil (For Rear Axle Shaft Outer)
42311 90313-54001 Seal, Oil (For Rear Axle Shaft Outer)
42311 42311-26011 Shaft, Rear Axle
42311 42311-26012 Shaft, Rear Axle, Rh
42311 42421-35050 Case, Rear Axle Bearing
42311 90520-36045 Ring, Snap (For Rear Axle Shaft)
42311 90942-02049 Bolt, Hub
42311 90942-02082 Bolt, Hub
42311 42311-26051 Shaft, Rear Axle
42311 42311-26052 Shaft, Rear Axle
42403 42431-35190 Drum Sub-Assy, Rear Brake
42403 90937-01100 Piece, Balance (For Rear Brake Drum)
42403 90937-01287 Piece, Balance (For Rear Brake Drum)
42403 90937-01288 Piece, Balance (For Rear Brake Drum)
42403 90937-01289 Piece, Balance (For Rear Brake Drum)
42421 42421-35030 Case, Rear Axle Bearing
42423 42423-20010 Retainer, Rear Axle Bearing, Inner
42424 90301-88077 Ring, O (For Rear Axle Bearing Case)
42441 42441-26010 Deflector, Brake Drum Oil
42443 42443-30010 Gasket, Brake Drum Oil Deflector
42444 42444-35060 Gasket, Brake Drum (For Rear Axle)
Rear Body Assembly ([05.1995 - ] (9505- )) 2
#OEMPart name
65000 66000-25670 Body Assy, Rear
65000 60500-25280 Body Assy, Rear
Rear Body Floor & Fender ([05.1995 - ] (9505- )T2..TS) 2
#OEMPart name
9165140820 91651-40820 Bolt
9166160616 91661-60616 BOLT
Rear Body Floor & Fender ([10.1996 - ] (9505- )LY10#,11#,12#,13#,15#,201,21#,YY121,1 31,201,211..T2..TB ; (9610- )LY1 0#,YY101..T2..IV3) 34
#OEMPart name
65026 65026-37020 Bracket Sub-Assy, Gate Rubber Bumper, Rh
65027 65027-37020 Bracket Sub-Assy, Gate Rubber Bumper, Lh
65100 65100-25340 Floor Assy, Rear Body
65207 65413-37050 Bracket Sub-Assy, Guard Frame, Rh
65208 65415-37030 Bracket Sub-Assy, Guard Frame, Lh
65307 65307-25030 Frame Sub-Assy, Floor, Rear
65635 65635-92830 Bolt, Counter Sunk Head Square Neck
66010 66010-25020 Fender Assy, Rear No.2 Rh
66020 66020-25020 Fender Assy, Rear No.2 Lh
66210 66210-25020 Fender Assy, Rear No.1 Rh
66220 66220-25020 Fender Assy, Rear No.1 Lh
66231 66231-25020 Retainer, Rear Fender, Front Rh
66241 66241-25040 Baffle, Rubber
66241 66241-25041 Baffle, Rubber
66242 66242-37070 Support, Baffle Rubber
66259 66259-37010 Cover, Rear Body Floor, Rear
66271 66271-25010 Step, Rear Body
66311 66311-37020 Hook, Rope
66312 66312-37020 Hook, Rope, No.2
66313 66235-25010 Support, Rear Fender
66313 66236-25020 Support, Rear Fender
66321 66321-92803 Bumper, Gate Rubber
66321 66321-92805 Bumper, Gate Rubber
66441 66441-37010 Shim, Mounting, No.1
9004463020 90044-63020 New Genuine Part
9015150004 90151-50004 Screw(for Floor Board)
9015150006 90151-50006 New Genuine Part
9017906070 90179-06070 Nut(For Steering Inter Shaft Dust Seal Cover)
9017906070 90179-06159 Nut, Rear Wiper Link Pivot, No.1
9162660616 91626-60616 New Genuine Part
9162660616 91621-J0612 BOLT W-WASHER
9165660616 91656-60616 BOLT
9165660616 91651-60616 BOLT
9321016016 93210-16016 SCREW
Rear Body Floor & Fender ([10.1996 - ] (9610- )T1) 18
#OEMPart name
64311 58426-95700 Protector, Engine Sub Cover
65100 65100-26090 Floor Assy, Rear Body
65241 65240-26010 Sill, Rear Cross
65311 65311-26010 Panel, Floor, Center
66210 66205-95A01 Fender Assy, Rear No.1 Rh
66210 66205-25010 Fender Assy, Rear No.1 Rh
66241 76625-37010 Baffle, Rubber
66241 76625-25041 Baffle, Rubber
66242 66242-95012 Plate, Rear Mudguard Set Retainer
66321 66321-95406 Bumper, Gate Rubber
66321 66321-37010 Bumper, Gate Rubber
9015050005 90150-50005 SCREW
9017905095 90179-05095 NUT
9017905095 90179-05004 NUT
9162140614 91621-40614 BOLT
9165140616 91651-40616 BOLT
9165140616 91621-60614 Bolt(For Transaxle & Engine Setting)
9165140616 90080-11395 New Genuine Part
Rear Body Guard Frame & Tail Gate ([05.1995 - ] (9505- )T1,TW2..ST) 10
#OEMPart name
65400 65400-25420 Guard Assy, Rear Body
65700 65700-25010 Gate Assy, Rear Body Tail
66110 66110-95014 Hinge Assy, Tail Gate
66121 66121-95012 Bolt(For Tail Gate)
66170 66170-95402 Latch Assy, Rear Body Tail Gate
66280 66280-37010 Chain Assy, Tail Gate
66311 66311-90K00 Hook, Rope
9161160816 91611-60816 Screw Or Bolt(For Valve Rocker Shaft Lock)
9161160816 91611-B0816 Bolt
9326018014 93260-18014 New Genuine Part
Rear Body Guard Frame & Tail Gate ([05.1995 - ] (9505- )T2,T3,TW1..TS) 23
#OEMPart name
65400 65400-25290 Guard Assy, Rear Body
65491 65491-37010 Stop, Guard Frame Load Slide, Rh
65492 65492-37010 Stop, Guard Frame Load Slide, Lh
65700 65700-25030 Gate Assy, Rear Body Tail
65700 65700-37110 Gate Assy, Rear Body Tail
66110 66110-37010 Hinge Assy, Tail Gate
66110 66110-37012 Hinge Assy, Tail Gate
66161 65080-92701 Handle Assy, Side Gate Latch
66161 65080-92702 Handle Assy, Side Gate Latch
66165 66165-92701 Cap, Gate Latch Handle
66264 66264-37010 Handle, Tail Gate Latch, Rh
66265 66265-37010 Handle, Tail Gate Latch, Lh
66280 66280-37020 Chain Assy, Tail Gate
9011908 90119-08A09 New Genuine Part
9011908657 90119-08657 New Genuine Part
9011908905 90119-08905 New Genuine Part
9015880005 90158-80005 New Genuine Part
9017908123 90179-08123 Nut (For Front Wiper Arm Setting)
9050145024 90501-45024 New Genuine Part
9050145024 90501-45042 SPRING COMPRESSION
9326018016 93260-18016 SCREW
9418561000 94185-61000 NUTLOCK
9461211001 94612-11001 Washer, Plate (For Center Support Bearing Housing)
Rear Body Guard Frame & Tail Gate ([10.1996 - ] (9505- )YY201,211..T2,T4..TB ; (9610- )TB ; (9610- )LY10#,YY101..T2..IV3) 41
#OEMPart name
65400 65400-25290 Guard Assy, Rear Body
65491 65491-37010 Stop, Guard Frame Load Slide, Rh
65492 65492-37010 Stop, Guard Frame Load Slide, Lh
65507 65507-37040 Support Sub-Assy, Corner, Rh
65508 65508-37040 Support Sub-Assy, Corner, Lh
65700 65700-25030 Gate Assy, Rear Body Tail
65700 65700-37110 Gate Assy, Rear Body Tail
66109 66193-37010 Handle Sub-Assy, Side Gate Support Corner
66110 66110-37010 Hinge Assy, Tail Gate
66110 66110-37012 Hinge Assy, Tail Gate
66161 65080-92701 Handle Assy, Side Gate Latch
66161 65080-92702 Handle Assy, Side Gate Latch
66165 66165-92701 Cap, Gate Latch Handle
66264 66264-37010 Handle, Tail Gate Latch, Rh
66265 66265-37010 Handle, Tail Gate Latch, Lh
66280 66280-37020 Chain Assy, Tail Gate
9011510016 90115-10016 New Genuine Part
9011908464 90119-08464 Bolt, W/washer(For Side Gate, Rh)
9011908913 90119-08913 Stopper, Guard Frame
9014880008 90148-80008 Bolt
9016680001 90166-80001 New Genuine Part
9017908024 90179-08024 NUT
9017908245 90179-08245 New Genuine Part
9017910036 90179-10036 NUT
9020110180 90201-10180 Washer, Plate(For Shift Lever Sub-Assy)
9050107041 90501-07041 SPRING
9050145024 90501-45024 New Genuine Part
9050145024 90501-45042 SPRING COMPRESSION
9054106028 90541-06028 New Genuine Part
9054107018 90541-07018 Cushion, Tail Gate Side
9095001430 90950-01430 Plug, Hole(For Tail Gate)
9151160814 91511-60814 New Genuine Part
9151160814 91511-B0814 BOLT
9164281025 91642-81025 BOLT WWASHER
9356014008 93560-14008 New Genuine Part
9418401001 94184-01001 Nut
9418560800 94185-60800 NUT
9418561000 94185-61000 NUTLOCK
9461310800 94613-10800 Spacer (For Control Select Lever Support)
9462211000 94622-11000 WASHER
9616000600 96160-00600 Ring, E(For Clutch Pedal Pawl)
Rear Body Mounting ([05.1995 - ] (9505- )LY10#,11#,YY101..T1,T2..TS) 5
#OEMPart name
66418 90119-10102 Bolt, Mounting
66418 90109-10156 Bolt, Mounting
66441 90564-15142 Shim, Mounting
9020110203 90201-10203 Washer, Plate
9413061000 94130-61000 Nut(For Clutch Pedal Stopper)
Rear Body Mounting ([10.1996 - ] (9505- )LY13#,YY131..WT..125..CBU ; (9505- )LY201,21#,YY201,211..T2,T4,TW2..T B ; (9610- )LY 10#,YY101..T2..IV3) 4
#OEMPart name
66418 90109-10156 Bolt, Mounting
66441 90564-15142 Shim, Mounting
9020110203 90201-10203 Washer, Plate
9413001002 94130-01002 Nut, Booster Sleeve Cylinder
Rear Body Side Panel ([05.1995 - ] (9505- )T1,TW2..ST) 17
#OEMPart name
65313 65313-26020 Panel, Floor Front Corner, Rh
65314 65314-25020 Panel, Floor Front Corner, Lh
65315 65315-25010 Panel, Floor Rear Corner, Rh
65316 65316-25010 Panel, Floor Rear Corner, Lh
65500 65500-26091 Panel Assy, Rear Body Side, Rh
65577 65577-95012 Retainer, Tail Gate Latch Female
65600 65600-26090 Panel Assy, Rear Body Side, Lh
66153 66153-95012 Latch, Tail Gate Female, Rh
66311 66311-90K00 Hook, Rope
66332 66332-95A00 Cushion, Rubber
9017908123 90179-08123 Nut (For Front Wiper Arm Setting)
9017908146 90179-08146 Nut
9017908146 90179-08204 Nut
9326018016 93260-18016 SCREW
9326018020 93260-18020 SCREW
9326018030 93260-18030 SCREW
9461210800 94612-10800 Washer, Plate(For Repair Actuator Set)
Rear Body Side Panel ([05.1995 - ] (9505- )T2,T3,TW1..TS) 25
#OEMPart name
65500 65500-25090 Panel Assy, Rear Body Side, Rh
65500 65500-37860 Panel Assy, Rear Body Side, Rh
65500 90950-01753 Plug, Hole(For Rear Body Side Panel)
65600 65600-25090 Panel Assy, Rear Body Side, Lh
65600 65600-3V060 Panel Assy, Rear Body Side, Lh
65679 65679-37010 Seal, Side Gate
65679 65679-37011 Seal, Side Gate
66110 65010-37040 Hinge Assy, Side Gate, No.1 Rh
66110 65050-37080 Hinge Assy, Side Gate, N0.2 Rh
66187 66187-37010 Handle, Side Gate Latch, Center No.2
66187 66187-37011 Handle, Side Gate Latch, Center No.2
9011908657 90119-08657 New Genuine Part
9011908957 90119-08957 New Genuine Part
9017908123 90179-08123 Nut (For Front Wiper Arm Setting)
9046708011 90467-08011 Clip(For Headlamp Cover Seal)
9046708011 90467-08011-TH CLIP
9046708011 90467-08011-83 Clip(For Headlamp Cover Seal)
9050107041 90501-07041 SPRING
9054106021 90541-06021 New Genuine Part
9166140620 91661-40620 New Genuine Part
9166160825 91661-60825 New Genuine Part
9322018020 93220-18020 New Genuine Part
9322018020 93230-18020 New Genuine Part
9326018025 93260-18025 New Genuine Part
9616000600 96160-00600 Ring, E(For Clutch Pedal Pawl)
Rear Body Side Panel ([05.1995 - ] (9505- )TB ; (9505- )LY10#,YY101..T2..IV3) 19
#OEMPart name
65500 65500-25090 Panel Assy, Rear Body Side, Rh
65500 65500-37860 Panel Assy, Rear Body Side, Rh
65500 90950-01753 Plug, Hole(For Rear Body Side Panel)
65500 90119-08464 Bolt, W/washer(For Side Gate, Rh)
65600 65600-25090 Panel Assy, Rear Body Side, Lh
65600 65600-3V060 Panel Assy, Rear Body Side, Lh
65679 65679-37010 Seal, Side Gate
65679 65679-37011 Seal, Side Gate
66110 65010-37040 Hinge Assy, Side Gate, No.1 Rh
66110 65050-37080 Hinge Assy, Side Gate, N0.2 Rh
66187 66187-37010 Handle, Side Gate Latch, Center No.2
66187 66187-37011 Handle, Side Gate Latch, Center No.2
9014880007 90148-80007 New Genuine Part
9014880008 90148-80008 Bolt
9014880024 90148-80024 New Genuine Part
9014880025 90148-80025 New Genuine Part
9017908245 90179-08245 New Genuine Part
9046708008 90467-08008 Clip, Step Plate Cover
9054106021 90541-06021 New Genuine Part
Rear Combination Lamp ([05.1995 - ] (9505- )) 19
#OEMPart name
81550 81550-25100 Lamp Assy, Rear Combination, Rh
81550 99132-11210 Bulb (12V 21W)
81550 99132-21210 Bulb, Cornering Lamp
81551 81551-25060 Lens, Rear Combination Lamp, Rh
81553 75135-25030 Bracket, Combination Rear Lamp, Rh
81553 75136-25020 Bracket, Combination Rear Lamp, Rh
81554 81552-25060 Gasket, Rear Combination Lamp Lens, Rh
81558 81557-25060 Shade, Rear Combination Lamp, No.1 Rh
81560 81560-25090 Lamp Assy, Rear Combination, Lh
81561 81561-25040 Lens, Rear Combination Lamp, Lh
81564 81562-25040 Gasket, Rear Combination Lamp Lens, Lh
9017905095 90179-05095 NUT
9017905095 90179-05004 NUT
9017910125 90179-10125 Nut(For Counter Gear Shaft)
9017910125 90179-10132 Nut
9162140818 91621-40818 New Genuine Part
9166161020 91661-61020 New Genuine Part
9321964020 93219-64020 Screw
9321964020 81559-10050 Screw
Rear Door Lock & Handle ([05.1995 - ] (9505- )) 8
#OEMPart name
9014880027 90148-80027 Screw Hex Lobular
9015960270 90159-60270 New Genuine Part
9016250008 90162-50008 SCREW
9017906070 90179-06070 Nut(For Steering Inter Shaft Dust Seal Cover)
9017906070 90179-06159 Nut, Rear Wiper Link Pivot, No.1
9018905003 90189-05003 CLIP
9020610018 90206-10018 Washer, Wave(For Gear Selecting Rod, No.2)
9152140610 91521-40610 New Genuine Part
Rear Door Panel & Glass ([05.1995 - ] (9505- )) 5
#OEMPart name
68103 68113-37020 Glass Sub-Assy, Rear Door, Rh
9095001011 90950-01011 Grommet(For Upper Back Panel)
9152140610 91521-40610 New Genuine Part
9166140614 91661-40614 New Genuine Part
9166140614 91661-A0614 New Genuine Part
Rear Door Window Regulator & Hinge ([05.1995 - ] (9505- )) 3
#OEMPart name
9011908056 90119-08056 New Genuine Part
9011908091 90119-08091 New Genuine Part
9152140610 91521-40610 New Genuine Part
Rear Drum Brake Wheel Cylinder & Backing Plate ([05.1995 - ] (9505- )LY15#,16#..T2..125 ; (9505- )LY10# ,11#,201,YY101,201..ST..125,1T) 56
#OEMPart name
4495 04495-35122 Shoe Kit, Rear Brake
4906 04906-35080 Cup Kit, Rear Wheel Cylinder
4906 04906-31010 Cup Kit, Rear Wheel Cylinder
47043 47043-25150 Plate Sub-Assy, Brake Backing, Rear Rh
47043 90179-10041 Nut(For Backing Plate To Rear Axle Housing Setting)
47043 90114-10002 Bolt, Serration (For Rear Axle Flange)
47043 90114-10016 Bolt(For Backing Plate To Rear Axle Housing Setting)
47044 47044-25120 Plate Sub-Assy, Brake Backing, Rear Lh
47430 90506-26331 Spring, Tension(For Rear Brake Shoe Return)
47430 90501-20604 Spring(For Rear Brake Shoe Hold Down)
47430 90506-12412 Spring, Tension(For Rear Brake Shoe Return)
47430 90506-16343 Spring, Tension(For Rear Brake Shoe Return)
47430 90508-20261 Spring, Tension(For Rear Brake Automatic Adjust Lever)
47430 90508-20262 Spring, Tension(For Rear Brake Automatic Adjust Lever)
47430 90504-18012 Spring, Compression(For Parking Brake Shoe Strut)
47430 90506-18004 Spring, Tension(For Parking Brake Shoe Strut)
47447 47447-20010 Pin, Shoe Hold Down Spring(For Front Brake)
47449 47449-30020 Cup, Shoe Hold Down Spring(For Front Brake)
47456 47456-20010 Plate, Rear Brake Shoe Guide
47458 47457-35020 Bracket, Rear Brake Shoe Return Spring, Rh
47458 47458-35020 Bracket, Rear Brake Shoe Return Spring
47460 47405-30020 Adjuster Assy, Shoe, Rh(For Rear Brake)
47470 47406-30020 Adjuster Assy, Shoe, Lh(For Rear Brake)
47492 47492-28010 Plug, Shoe Inspection(For Rear Brake)
47492 47492-06010 Plug, Shoe Inspection(For Rear Brake)
47496 47491-35040 Plug, Hole(For Rear Brake)
47536 47531-26070 Piston, Wheel Brake Cylinder(For Rear Brake)
47536 47531-26080 Piston, Wheel Brake Cylinder(For Rear Brake)
47538 47538-35010 Rod, Rear Wheel Cylinder
47547 47547-26010 Plug, Bleeder (For Deceleration Sensing Proportionin)
47548 31478-30010 Bleeder Plug Cap
47550 47550-26090 Cylinder Assy, Rear Wheel Brake(For Rh, Front Or Upper)
47550 47509-20010 Spring Sub-Assy, Rear Wheel Cylinder Piston
47550 47550-26100 Cylinder Assy, Rear Wheel Brake(For Rh, Front Or Upper)
47550 47509-22010 Spring, Compression(For Rear Wheel Brake Cylinder)
47601 47601-26020 Lever Sub-Assy, Parking Brake Shoe, Rh(For Rear Brake)
47601 90213-07010 Washer, Type C(For Parking Brake Shoe)
47601 90206-10059 Washer, Wave(For Rear Brake)
47602 47602-26020 Lever Sub-Assy, Parking Brake Shoe, Lh (For Rear Brake)
47603 90213-06013 Washer, Type C(For Parking Brake Shoe)
47607 47607-30010 Cable Sub-Assy, Rear Beake Automatic Adjust
47613 47613-35020 Strut, Parking Brake Shoe (For Rear Brake)
47613 47614-35020 Strut, Parking Brake Shoe (For Rear Brake)
47616 47616-26030 Wire, Parking Brake, Rh
47623 90249-08075 Pin, Parking Brake Bellcrank
47624 47624-26040 Bellcrank Sub-Assy, Parking Brake, Rh(For Rear Brake)
47625 47625-26040 Bellcrank Sub-Assy, Parking Brake, Lh (For Rear Brake)
47628 47628-26010 Bracket Sub-Assy, Bell Crank, Rh (For Rear Brake)
47633 47633-26010 Boot, Parking Brake Bellcrank
47642 47642-20010 Guide, Rear Brake Automatic Adjust Cable
47643 47643-20011 Lever, Rear Brake Automatic Adjust, Rh
9010108043 90101-08043 New Genuine Part
9011908838 90119-08838 New Genuine Part
9014360002 90143-60002 Bolt, Bellcrank Stopper(For Parking Brake)
9411040600 94110-40600 Nut, Rock
9453100800 94531-00800 Washer (For Transfer Shift Outer Lever)
Rear License Plate Lamp ([05.1995 - ] (9505- )) 10
#OEMPart name
81270 81270-25030 Lamp Assy, License Plate
81270 81270-25031 Lamp Assy, License Plate
81270 99132-12050 Bulb (12V 5W)
81270 90080-81053 Bulb(For Clearance Lamp)
81271 81271-89110 Lens, License Plate Lamp
81271 81271-25031 LENS, LICENSE LAMP
81272 81272-89110 Gasket, License Plate Lamp Lens
8127930020 81279-30020 Washer, Side Turn Signal Lamp
8161914050 81619-14050 New Genuine Part
9018904014 90189-04014 CLIP
Rear Spring & Shock Absorber ([05.1995 - ] (9505- )) 21
#OEMPart name
48210 48210-2E080 Spring Assy, Rear Rh
48210 48299-26540 Bush(For Rear Spring Leaf)
48210 48210-2E090 Spring Assy, Rear Rh
48211 48201-2E080 Leaf, Rear Spring, No.1
48211 48201-2E090 Leaf, Rear Spring, No.1
48212 48212-2E080 Leaf, Rear Spring, No.2
48212 48212-2E090 Leaf, Rear Spring, No.2
48213 48213-2E080 Leaf, Rear Spring, No.3
48213 48202-2E090 Leaf, Rear Spring, No.3
48214 48202-2E080 Leaf, Rear Spring, No.4
48214 48214-2E090 Leaf, Rear Spring, No.4
48215 48215-2E080 Leaf, Rear Spring, No.5
48215 48203-2E090 Leaf, Rear Spring, No.5
48216 48203-2E080 Leaf, Rear Spring, No.6
48216 48216-2E090 Leaf, Rear Spring, No.6
48247 48247-60172 Bolt, Rear Spring, Center
48247 48247-36052 Bolt, Rear Spring, Center
4828437130 48284-37130 Nut, Front Spring Center Bolt
9411040800 94110-40800 Nut(For Steering Damper)
9411040800 94130-00802 Nut, No.1 (For Center Support Bearing)
9411051000 94110-51000 Nut(For Steering Center Arm)
Rear Spring & Shock Absorber ([05.1998 - ] (9805- )) 11
#OEMPart name
48210 48210-2E080 Spring Assy, Rear Rh
48210 48299-26540 Bush(For Rear Spring Leaf)
48210 48210-2E090 Spring Assy, Rear Rh
48211 48201-2E080 Leaf, Rear Spring, No.1
48211 48201-2E090 Leaf, Rear Spring, No.1
48212 48212-2E080 Leaf, Rear Spring, No.2
48212 48212-2E090 Leaf, Rear Spring, No.2
48247 48247-60172 Bolt, Rear Spring, Center
48247 48247-36052 Bolt, Rear Spring, Center
4829927620 48299-27620 Nut, Front Spring Center Bolt
4829927620 48284-0W060 Nut, Front Spring Center Bolt
Rear Spring & Shock Absorber ([05.1999 - ] (9905- )) 15
#OEMPart name
48210 48210-2E080 Spring Assy, Rear Rh
48210 48299-26540 Bush(For Rear Spring Leaf)
48210 48210-2E090 Spring Assy, Rear Rh
48211 48201-2E080 Leaf, Rear Spring, No.1
48211 48201-2E090 Leaf, Rear Spring, No.1
48212 48212-2E080 Leaf, Rear Spring, No.2
48212 48212-2E090 Leaf, Rear Spring, No.2
48213 48213-2E080 Leaf, Rear Spring, No.3
48213 48202-2E090 Leaf, Rear Spring, No.3
48214 48202-2E080 Leaf, Rear Spring, No.4
48214 48214-2E090 Leaf, Rear Spring, No.4
48247 48247-60172 Bolt, Rear Spring, Center
48247 48247-36052 Bolt, Rear Spring, Center
4829927620 48299-27620 Nut, Front Spring Center Bolt
4829927620 48284-0W060 Nut, Front Spring Center Bolt
Rear Spring & Shock Absorber ([08.2000 - ] (0008- )) 17
#OEMPart name
48210 48210-2E080 Spring Assy, Rear Rh
48210 48299-26540 Bush(For Rear Spring Leaf)
48210 48210-2E090 Spring Assy, Rear Rh
48211 48201-2E080 Leaf, Rear Spring, No.1
48211 48201-2E090 Leaf, Rear Spring, No.1
48212 48212-2E080 Leaf, Rear Spring, No.2
48212 48212-2E090 Leaf, Rear Spring, No.2
48213 48213-2E080 Leaf, Rear Spring, No.3
48213 48202-2E090 Leaf, Rear Spring, No.3
48214 48202-2E080 Leaf, Rear Spring, No.4
48214 48214-2E090 Leaf, Rear Spring, No.4
48247 48247-60172 Bolt, Rear Spring, Center
48247 48247-36052 Bolt, Rear Spring, Center
4824237130 48242-37130 Clip, Rear Spring, No.2
4828437130 48284-37130 Nut, Front Spring Center Bolt
9411040800 94110-40800 Nut(For Steering Damper)
9411040800 94130-00802 Nut, No.1 (For Center Support Bearing)
Rear Spring & Shock Absorber ([10.1996 - ] (9610- )) 21
#OEMPart name
48210 48210-2E080 Spring Assy, Rear Rh
48210 48299-26540 Bush(For Rear Spring Leaf)
48210 48210-2E090 Spring Assy, Rear Rh
48211 48201-2E080 Leaf, Rear Spring, No.1
48211 48201-2E090 Leaf, Rear Spring, No.1
48212 48212-2E080 Leaf, Rear Spring, No.2
48212 48212-2E090 Leaf, Rear Spring, No.2
48213 48213-2E080 Leaf, Rear Spring, No.3
48213 48202-2E090 Leaf, Rear Spring, No.3
48214 48202-2E080 Leaf, Rear Spring, No.4
48214 48214-2E090 Leaf, Rear Spring, No.4
48215 48215-2E080 Leaf, Rear Spring, No.5
48215 48203-2E090 Leaf, Rear Spring, No.5
48216 48203-2E080 Leaf, Rear Spring, No.6
48216 48216-2E090 Leaf, Rear Spring, No.6
48217 48217-2E080 Leaf, Rear Spring, No.7
48247 48247-60172 Bolt, Rear Spring, Center
48247 48247-36052 Bolt, Rear Spring, Center
4828437130 48284-37130 Nut, Front Spring Center Bolt
4829927620 48299-27620 Nut, Front Spring Center Bolt
4829927620 48284-0W060 Nut, Front Spring Center Bolt
Rear Spring & Shock Absorber ([10.1996 - ] (9610- )LY10#,11#,YY101..T2 ; (9610- )LY12 #,13#,15#,16#,YY121,131..ST) 20
#OEMPart name
4483 04483-26010 Shackle Kit, Rear Spring
4483 04483-35040 Shackle Kit, Rear Spring
4484 04484-26030 Pin Kit, Rear Spring
48046 90117-14031 Bolt, U(For Rear Spring)
48210 90385-18046 Bush(For Front Spring Shackle)
48341 48341-26210 Bumper, Rear Spring
48473 48473-26080 Seat Sub-Assy, Spring U Bolt, Rh
48516 48505-26010 Bracket, Rear Shock Absorber, Upper Rh
48530 48531-80549 Absorber Assy, Shock, Rear Rh
48530 90385-16010 Bush(For Front Shock Absorber Rh)
48530 90948-03004 Retainer, Cushion, No.1(For Front Shock Absorber)
9010512152 90105-12152 New Genuine Part
9011910355 90119-10355 Washer, Rear Shock Absorber Cushion, No.2
9017014026 90170-14026 Nut(For Front Support To Front Shock Absorber Rh)
9017914023 90179-14023 Nut(For Rear Spring U Bolt)
9161160818 91611-60818 Bolt(For Oil Receiver Pipe)
9161160818 90119-08830 Bolt(For Oil Receiver Pipe)
9413001202 94130-01202 Nut(For Dust Cover To Steering Knuckle Arm Setting)
9451201200 94512-01200 Washer
9462111400 94621-11400 WASHER
Rear Spring & Shock Absorber ([10.1996 - ] (9610- )LY12#,13#,162,YY121,131..WT ; (9610- )LY10#,11#,YY101..T1,T3,TW1,TW2) 22
#OEMPart name
4483 04483-26010 Shackle Kit, Rear Spring
4483 04483-35040 Shackle Kit, Rear Spring
4484 04484-26030 Pin Kit, Rear Spring
48046 90117-14031 Bolt, U(For Rear Spring)
48210 90385-18046 Bush(For Front Spring Shackle)
48341 48341-26040 Bumper, Rear Spring
48473 48473-26080 Seat Sub-Assy, Spring U Bolt, Rh
48481 48481-26011 Seat, Rear Spring, Upper
48516 48505-26010 Bracket, Rear Shock Absorber, Upper Rh
48530 48531-80488 Absorber Assy, Shock, Rear Rh
48530 90385-16010 Bush(For Front Shock Absorber Rh)
48530 90948-03004 Retainer, Cushion, No.1(For Front Shock Absorber)
9010512152 90105-12152 New Genuine Part
9011908676 90119-08676 BOLT WWASHER
9011910355 90119-10355 Washer, Rear Shock Absorber Cushion, No.2
9017014026 90170-14026 Nut(For Front Support To Front Shock Absorber Rh)
9017914023 90179-14023 Nut(For Rear Spring U Bolt)
9161160818 91611-60818 Bolt(For Oil Receiver Pipe)
9161160818 90119-08830 Bolt(For Oil Receiver Pipe)
9413001202 94130-01202 Nut(For Dust Cover To Steering Knuckle Arm Setting)
9451201200 94512-01200 Washer
9462111400 94621-11400 WASHER
Roof Headlining & Silencer Pad ([05.1995 - ] (9505- )) 4
#OEMPart name
63341 63341-95409-B0 Silencer, Roof, No.1
63391 63391-25010-B0 Trim, Roof Headlining, Front
63391 90467-07043-B1 Clip
63391 90467-07043-C0 Clip(For Rear Bumper Retainer)
Roof Panel & Back Panel ([05.1995 - 05.2001] (9505-0105)T1,T2,T3,T4) 41
#OEMPart name
53701 53717-25010 Apron Sub-Assy, Front Fender, Rh
53702 53718-25010 Apron Sub-Assy, Front Fender, Lh
58183 58102-25010 Reinforcement, Rear Mounting, Rh
58183 58102-25020 Reinforcement, Rear Mounting, Rh
58184 58103-25010 Reinforcement, Rear Mounting, Lh
58236 58236-25010 Bracket, Clutch Tube
63102 63132-37010 Panel Sub-Assy, Windshield Header
63111 63111-37010 Panel, Roof
63141 63141-37010 Reinforcement, Roof Panel, No.1
64107 64107-25032 Frame Sub-Assy, Back
64107 64107-25150 Frame Sub-Assy, Back
64111 64100-37251 Panel, Back
64111 64105-37030 Reinforcement, Back, Upper
64111 63218-95400 Channel, Roof Drip, Rear
64111 64111-37052 Panel, Quarter Outer, Upper Rh
64111 65613-37010 Strip, Side Gate Hinge, Inside
64111 71962-95400 Bracket, Front Seat Headrest
64111 64100-37470 Panel, Back
64111 63172-37010 Base, Room Lamp, No.1
64111 64111-37210 Panel, Quarter Outer, Upper Rh
64111 90333-15002 PLUG
64111 64100-37490 Panel, Back
64122 64122-25011 Baffle, Dust Rear Body
64160 64160-37060-B0 Silencer Assy, Back Panel, Upper
64160 90467-06171-B0 Clip
64160 90467-06171-C0 Clip
64171 64025-25011 Bracket Sub-Assy, Rear Mounting
64186 64186-95A00 Retainer, Rear Mounting Bracket
64190 64190-25010 Silencer Assy, Back Panel
64190 64190-25030-B0 Silencer Assy, Back Panel
64219 64219-25010 Stay, Back Panel
64811 64811-37020 Glass, Back Window
64811 64811-37070 Glass, Back Window
64831 64831-37050 Weatherstrip, Back Window Glass
64831 64831-37051 Weatherstrip, Back Window Glass
64832 64832-37040 Key, Back Window Weatherstrip
75299 75209-25010 Base, Jack Holder
9011908837 90119-08837 New Genuine Part
9033320001 90333-20001 PLUG
9046705156 90467-05156 New Genuine Part
9053006001 90530-06001 Fastener, Hook
Roof Panel & Back Panel ([05.1995 - ] ｱﾘ(ﾙ-ﾌ ｴｱ ﾃﾞﾌﾚｸﾀ) (9505- )T1,T2,T3,T4) 24
#OEMPart name
63072 63072-37121 Deflector Set, Roof Air
63701 63701-95400 Bracket Sub-Assy, Roof Air Deflector, Front
63701 63702-95400 Bracket Sub-Assy, Roof Air Deflector, Front
63706 63706-95400 Bracket Sub-Assy, Roof Air Deflector, Rear
63707 63707-95400 Holder Sub-Assy, Roof Deflector, Front
63708 63708-95400 Holder Sub-Assy, Roof Deflector, Front
63709 63709-95400 Holder Sub-Assy, Roof Deflector, Rear
63760 63760-37120 Panel Assy, Roof Air Deflector
63781 63781-95400 Stay, Roof Air Deflector
63785 63785-95400 Pad, Roof Air Deflector, Front
63786 63786-95400 Pad, Roof Air Deflector, Front
63787 63787-95400 Pad, Roof Air Deflector, No.1
63788 63788-95400 Pad, Roof Air Deflector, No.2
63789 63789-95400 Pad, Roof Air Deflector, No.3
9010108078 90101-08078 New Genuine Part
9010108106 90101-08106 New Genuine Part
9017008026 90170-08026 New Genuine Part
9017606040 90176-06040 New Genuine Part
9017906091 90179-06091 New Genuine Part
9020108055 90201-08055 New Genuine Part
9026903025 90269-03025 RIVET
9095001258 90950-01258 Plug, Hole(For Rear Suspension Arm)
9095001258 90950-01478 Plug, Hole(For Front Suspension Lower Arm)
9095901214 90959-01214 New Genuine Part
Roof Panel & Back Panel ([05.2001 - ] (0105- )T1,T2,T3,T4) 43
#OEMPart name
53701 53717-25010 Apron Sub-Assy, Front Fender, Rh
53702 53718-25010 Apron Sub-Assy, Front Fender, Lh
58183 58102-25010 Reinforcement, Rear Mounting, Rh
58183 58102-25020 Reinforcement, Rear Mounting, Rh
58184 58103-25010 Reinforcement, Rear Mounting, Lh
58236 58236-25010 Bracket, Clutch Tube
63102 63132-37010 Panel Sub-Assy, Windshield Header
63111 63111-37010 Panel, Roof
63141 63141-37010 Reinforcement, Roof Panel, No.1
63172 63172-37010 Base, Room Lamp, No.1
63218 63218-95400 Channel, Roof Drip, Rear
64107 64107-25032 Frame Sub-Assy, Back
64107 64107-25150 Frame Sub-Assy, Back
64111 64100-37251 Panel, Back
64111 64105-37030 Reinforcement, Back, Upper
64111 64111-37052 Panel, Quarter Outer, Upper Rh
64111 65613-37010 Strip, Side Gate Hinge, Inside
64111 71962-95400 Bracket, Front Seat Headrest
64111 64100-37470 Panel, Back
64111 64111-37210 Panel, Quarter Outer, Upper Rh
64111 90333-15002 PLUG
64111 64100-37490 Panel, Back
64115 64105-37050 Reinforcement, Back, Upper
64115 64115-37030 Reinforcement, Back Panel
64122 64122-25011 Baffle, Dust Rear Body
64160 64160-37060-B0 Silencer Assy, Back Panel, Upper
64160 90467-06171-B0 Clip
64160 90467-06171-C0 Clip
64171 64025-25011 Bracket Sub-Assy, Rear Mounting
64186 64186-95A00 Retainer, Rear Mounting Bracket
64190 64190-25010 Silencer Assy, Back Panel
64190 64190-25030-B0 Silencer Assy, Back Panel
64219 64219-25010 Stay, Back Panel
64811 64811-37020 Glass, Back Window
64811 64811-37070 Glass, Back Window
64831 64831-37050 Weatherstrip, Back Window Glass
64831 64831-37051 Weatherstrip, Back Window Glass
64832 64832-37040 Key, Back Window Weatherstrip
75299 75209-25010 Base, Jack Holder
9011908837 90119-08837 New Genuine Part
9033320001 90333-20001 PLUG
9046705156 90467-05156 New Genuine Part
9053006001 90530-06001 Fastener, Hook
Seat & Seat Track ([05.1995 - ] (9505- )T1,T2,T3,T4..CBU,IV3) 64
#OEMPart name
58839 58839-95400-C0 Cover, Console Box Hole
71011 71011-37020 Frame Sub-Assy, Front Seat Cushion, Rh
71011 71011-37060 Frame Sub-Assy, Front Seat Cushion, Rh
71013 71013-37080 Frame Sub-Assy, Front Seat Back, Rh
71014 71014-95417-01 Frame Sub-Assy, Front Seat Back, Lh
71035 71095-25020-B1 Cover, Front Seat Back, Center
71035 71095-25030-B1 Cover, Front Seat Back, Center
71071 71071-25040-B1 Cover, Front Seat Cushion, Rh(For Separate Type)
71071 71071-25050-B1 Cover, Front Seat Cushion, Rh(For Separate Type)
71072 71072-25040-B1 Cover, Front Seat Cushion, Lh(For Separate Type)
71072 71072-25050-B1 Cover, Front Seat Cushion, Lh(For Separate Type)
71073 71073-25080-B1 Cover, Front Seat Back, Rh(For Separate Type)
71073 71073-25090-B1 Cover, Front Seat Back, Rh(For Separate Type)
71074 71074-25020-B1 Cover, Front Seat Back, Lh(For Separate Type)
71074 71074-25030-B1 Cover, Front Seat Back, Lh(For Separate Type)
71305 71305-95400-01 Frame Sub-Assy, Center Seat Back
71319 71319-95402 Striker, Front Seat Back
71350 71350-25020-B1 Back Assy, Front Seat, Center
71350 71350-25030-B1 Back Assy, Front Seat, Center
71365 71365-95400 Pad, Center Seat Back
71373 71373-95400-B0 Cover, Front Seat Back Lock
71410 71410-25040-B1 Cushion Assy, Front Seat, Rh(For Separate Type)
71410 71410-25050-B1 Cushion Assy, Front Seat, Rh(For Separate Type)
71420 71420-25040-B1 Cushion Assy, Front Seat, Lh (For Separate Type)
71420 71420-25050-B1 Cushion Assy, Front Seat, Lh (For Separate Type)
71430 71430-25100-B1 Back Assy, Front Seat, Rh(For Separate Type)
71430 71430-25110-B1 Back Assy, Front Seat, Rh(For Separate Type)
71440 71440-25020-B1 Back Assy, Front Seat, Lh(For Separate Type)
71440 71440-25030-B1 Back Assy, Front Seat, Lh(For Separate Type)
71511 71511-37020 Pad, Front Seat Cushion, Rh(For Separate Type)
71512 71502-37020 Pad, Front Seat Cushion, Lh (For Separate Type)
71551 71551-37070 Pad, Front Seat Back, Rh(For Separate Type)
71552 71552-95407 Pad, Front Seat Back, Lh(For Separate Type)
71587 71587-95J00 Protector, Front Seat Back Edge
71811 71811-95J00-B0 Cover, Reclining Adjuster, Rh
71815 71815-95J00-B0 Cover, Front Seat Cushion Hinge, Rh
71910 71910-25030-B0 Headrest Assy, Front Seat
71910 71910-25050-B0 Headrest Assy, Front Seat
72090 72090-95400-B0 Lock Assy, Front Seat Back
72110 72110-37010 Track Assy, Front Seat, Outer Rh
72130 72130-37010 Track Assy, Front Seat, Inner Rh
72510 72510-37010-B0 Adjuster Assy, Reclining Seat Back, Rh
72525 72525-95J01-B0 Handle, Reclining Adjuster Release, Rh
9011906214 90119-06214 New Genuine Part
9011908079 90119-08079 Bolt(For Transmission Input Damper Cover & Flywheel)
9011908134 90119-08134 BOLT
9011910116 90119-10116 New Genuine Part
9011910116 90119-10229 BOLT
9011910185 90119-10185 Bolt
9016840043 90168-40043 SCREW
9017908039 90179-08039 New Genuine Part
9017910073 90179-10073 New Genuine Part
9018304048 90183-04048 New Genuine Part
9033320001 90333-20001 PLUG
9038612051 90386-12051 Bush (For Front Seat Hinge Pin)
9052001274 90520-01274 Ring, Shaft Snap(For Front Door Window Regulator Handle)
9053018003 90530-18003 New Genuine Part
9054006006 90540-06006 New Genuine Part
9161161020 91611-61020 Bolt(For Transaxle & Engine Setting)
9161161020 91612-B1020 Bolt (For Transfer Case)Cover No.2
9161560816 91615-60816 Bolt(For Oil Receiver Pipe)
9161560816 91611-60814 Bolt
9166260614 91662-60614 New Genuine Part
9356015016 93560-15016 New Genuine Part
Seat & Seat Track ([05.1995 - ] ｳｵ-ｸｽﾙ- ﾊﾞﾝ (9505- )) 36
#OEMPart name
71011 71011-37020 Frame Sub-Assy, Front Seat Cushion, Rh
71011 71011-37060 Frame Sub-Assy, Front Seat Cushion, Rh
71013 71013-37080 Frame Sub-Assy, Front Seat Back, Rh
71071 71071-25040-B1 Cover, Front Seat Cushion, Rh(For Separate Type)
71071 71071-25050-B1 Cover, Front Seat Cushion, Rh(For Separate Type)
71073 71073-25080-B1 Cover, Front Seat Back, Rh(For Separate Type)
71073 71073-25090-B1 Cover, Front Seat Back, Rh(For Separate Type)
71410 71410-25040-B1 Cushion Assy, Front Seat, Rh(For Separate Type)
71410 71410-25050-B1 Cushion Assy, Front Seat, Rh(For Separate Type)
71430 71430-25100-B1 Back Assy, Front Seat, Rh(For Separate Type)
71430 71430-25110-B1 Back Assy, Front Seat, Rh(For Separate Type)
71511 71511-37020 Pad, Front Seat Cushion, Rh(For Separate Type)
71551 71551-37070 Pad, Front Seat Back, Rh(For Separate Type)
71587 71587-95J00 Protector, Front Seat Back Edge
71811 71811-95J00-B0 Cover, Reclining Adjuster, Rh
71815 71815-95J00-B0 Cover, Front Seat Cushion Hinge, Rh
72110 72110-37010 Track Assy, Front Seat, Outer Rh
72130 72130-37010 Track Assy, Front Seat, Inner Rh
72510 72510-37010-B0 Adjuster Assy, Reclining Seat Back, Rh
72525 72525-95J01-B0 Handle, Reclining Adjuster Release, Rh
9011908134 90119-08134 BOLT
9011910116 90119-10116 New Genuine Part
9011910116 90119-10229 BOLT
9011910185 90119-10185 Bolt
9014950039 90149-50039 SCREW
9016840043 90168-40043 SCREW
9017910073 90179-10073 New Genuine Part
9033320001 90333-20001 PLUG
9038612041 90386-12041 Bush (For Front Seat Hinge Pin)
9038612051 90386-12051 Bush (For Front Seat Hinge Pin)
9052001274 90520-01274 Ring, Shaft Snap(For Front Door Window Regulator Handle)
9052308001 90523-08001 E Ring (For Tilt Motor Shaft, Lower)
9053018003 90530-18003 New Genuine Part
9161161020 91611-61020 Bolt(For Transaxle & Engine Setting)
9161161020 91612-B1020 Bolt (For Transfer Case)Cover No.2
9166260614 91662-60614 New Genuine Part
Seat & Seat Track ([05.1995 - ] ﾎｸﾞﾘﾝｸﾞ (9505- )) 2
#OEMPart name
9046816019 90468-16019 Clip (For Rear Seat Back)
9046818008 90468-18008 Clip (For Rear Seat Back)
Seat Belt ([05.1995 - ] (9505- )) 4
#OEMPart name
73210 73210-37070-B0 Belt Assy, Front Seat Outer, Rh
73230 73230-37050-B0 Belt Assy, Front Seat Inner, Rh
73240 73240-37061-B0 Belt Assy, Front Seat Inner, Lh
9011906443 90119-06443 New Genuine Part
Seat Belt ([05.1995 - ] ｳｵ-ｸｽﾙ- ﾊﾞﾝ (9505- )) 4
#OEMPart name
73210 73210-37070-B0 Belt Assy, Front Seat Outer, Rh
73230 73230-37050-B0 Belt Assy, Front Seat Inner, Rh
73240 73240-37061-B0 Belt Assy, Front Seat Inner, Lh
9011906443 90119-06443 New Genuine Part
Separator & Separator Curtain ([05.1995 - ] (9505- )) 1
#OEMPart name
9015960072 90159-60072 SCREW
Shift Lever & Retainer ([05.1995 - ] (9505- )LY10#,11#,13#,21#,YY211..ATM) 64
#OEMPart name
33058 33058-26021 Bracket Sub-Assy, Shift Lock Solenoid
33502 33502-26080 Housing Sub-Assy, Shift Lever (For Floor Shift)
33503 90387-08089 Collar (For Floor Shift Control Shaft)
33503 33503-36110 Lever Sub-Assy, Shift(For Floor Shift)
33503 90385-11003 Bush(For Control Shaft)
33503 91111-40855 Bolt(For Shift Lever Sub-Assy)
33504 33504-36070-B0 Knob Sub-Assy, Shift Lever
33504 33504-36070-C0 Knob Sub-Assy, Shift Lever
33505 33505-26010 Seal Sub-Assy, Control Shaft Dust (For Floor Shift)
33506 33570-26020 Retainer Sub-Assy, Control Shift Lever (For Floor Shift)
33523 90249-05071 Pin, Shift Lever (For Floor Shift)
33555 33555-26020 Boot, Shift Lever
33563 33563-26020 Button, Shift Lock Release
33580 33580-36060 Bellcrank Assy, Shifting (For Floor Shift)
33621 33621-26040 Label, Control Lever Information
33623 33623-36020-B0 Button, Shift Lever Knob
33653 33653-36030 Guide, Shift Lever Wire
33653 90508-16113 Spring, Torsion (For Floor Shift Lever Guide)
33653 96160-00500 Ring, E(For Over Center Lever)
33653 90386-08014 Bush(For Over Center Adjusting Rod)
33663 33663-26012 Lever, Control
33663 91111-40880 Bolt (For Floor Shift Control Lever)
33663 90385-11006 Bush(For Shift Lever)
33663 90387-08096 Collar (For Floor Shift Control Lever)
33663 90508-25003 Spring, Torsion (For Floor Shift Control Lever)
33820 33820-26041 Cable Assy, Transmission Control
33820 90386-10025 Bush (For Floor Shift Control Shaft)
33821 90560-08366 Spacer (For Floor Shift Control Cable)
33821 90201-09019 Washer, Plate (For Transmission Control Cable)
33821 90949-01489 Clamp, No.1 (For Transmission Control Cable)
33821 90179-08141 Nut (For Transmission Control Cable)
33821 90179-08038 Nut
33823 33823-26030 Bracket, Transmission Control Cable, No.1
33866 33866-36010 Spring, Shift Lock Release
33878 33878-36010 Label, Shift Lock Information, No.2
35902 35902-26021-B0 Cover Sub-Assy, Position Indicator Housing
35906 35906-26021 Wire Sub-Assy, Indicator Lamp
35921 35921-26060 Plate, Control Position Indicator
35973 35973-36010 Attachment, Position Indicator Housing Cover
35975 35975-36020 Cover, Slide (For Position Indicator)
35976 35976-36010-B0 Cover, Slide, No.2 (For Position Indicator)
35976 90508-10045 Spring, Torsion (For Position Indicater Slide Cover)
9011910774 90119-10774 New Genuine Part
9015950193 90159-50193 New Genuine Part
9020209001 90202-09001 New Genuine Part
9025402021 90254-02021 Pin, Slotted Spring (For Control Shaft)
9038605011 90386-05011 New Genuine Part
9046312008 90463-12008 New Genuine Part
9046814004 90468-14004 Union, Auxiliary Fuel Band
9046814007 90468-14007 New Genuine Part
9046814016 90468-14016 CLIP
9052005002 90520-05002 New Genuine Part
9161160612 91611-60612 Bolt(For Dust Cover To Steering Knuckle Arm Setting)
9161160612 91611-G0612 Bolt
9161160814 91611-60814 Bolt
9161160820 91611-60820 Bolt(For Transaxle & Engine Setting)
9161160820 91611-G0820 Bolt
9338115010 93381-15010 SCREW
9413060400 94130-60400 New Genuine Part
9413060800 94130-60800 Nut(For Clutch Pedal Stopper)
9413060800 90170-A0003 New Genuine Part
9453100800 94531-00800 Washer (For Transfer Shift Outer Lever)
9461310800 94613-10800 Spacer (For Control Select Lever Support)
9538102015 95381-02015 New Genuine Part
Shift Lever & Retainer ([05.1995 - ] (9505- )MTM) 29
#OEMPart name
33502 33502-25010 Plate Sub-Assy, Shift Lever
33502 90387-10081 Collar (For Floor Shift Setting)
33502 90480-17018 Grommet (For Shift Lever Plate)
33502 90386-13192 Bush(For Over Center Plate)
33502 90101-08107 Bolt, Hexagon (For Shift Lever Plate)
33502 90508-23094 Spring, Torsion (For Shift Lever Plate)
33502 90387-08064 Collar (For Shift Lever Plate)
33503 90387-08063 Collar(For Shift Lever)
33503 90387-08065 Collar(For Shift Lever)
33503 33501-25091 Lever Sub-Assy, Shift(For Floor Shift)
33503 90389-11002 Bush(For Shift Lever)
33503 96711-24018 Ring, O
33504 33504-35030-B1 Knob Sub-Assy, Shift Lever (For Column Shift)
33504 33504-35030-B3 Knob Sub-Assy, Shift Lever
33506 33506-25010 Retainer Sub-Assy, Control Shift Lever (For Floor Shift)
33531 33531-25020 Boot, Dust (For Control Shift Lever)
33542 33542-25010 Knob, Spring Back Shift Lever
33555 33555-25031 Boot, Shift Lever
33710 33710-25143 Rod Assy, Gear Shifting, No.1
9015940109 90159-40109 Bolt Or Pin (For Shift Lever Knob Setting)
9017908141 90179-08141 Nut (For Transmission Control Cable)
9017908141 90179-08038 Nut
9111140855 91111-40855 Bolt(For Shift Lever Sub-Assy)
9111260850 91112-60850 New Genuine Part
9161160814 91611-60814 Bolt
9166160825 91661-60825 New Genuine Part
9413060800 94130-60800 Nut(For Clutch Pedal Stopper)
9413060800 90170-A0003 New Genuine Part
9453100800 94531-00800 Washer (For Transfer Shift Outer Lever)
Shift Lever & Retainer ([10.1996 - ] (9610- )LY10#,11#,YY101..MTM) 43
#OEMPart name
33607 33607-26220 Support Sub-Assy, Control Rod (For Column Shift)
33643 33643-25020 Lever, Gear Selecting, No.3
33643 90386-13192 Bush(For Over Center Plate)
33709 33709-25142 Shaft Sub-Assy, Cross, No.1 (For Floor Shift)
33709 90386-13020 Bush(For Clutch Pedal)
33709 90105-10103 Bolt, Hexagon
33709 90387-10075 Collar (For Cross Shaft)
33727 33727-25020 Insulator, Connecting Rod Bush Heat
33736 33790-25181 Rod, Gear Selecting, No.2(For Floor Shift)
33737 33701-25190 Rod, Gear Selecting, No.3 (For Column Shift)
33740 33740-26010 End Assy, Connecting Rod, No.1(For Column Shift)
33741 90389-08005 Bushing(For Gear Selecting Rod)
33741 90480-17177 Grommet (For Transmission Control Rod)
33742 33742-25140 Rod, Gear Shifting, No.2(For Floor Shift)
33742 90240-08028 Pin, W/hole (For Column Shift Gear Selecting Rod)
33742 90240-08042 Pin, W/hole(For Gear Selecting Rod No.2)
33743 33743-25130 Rod, Gear Shifting, No.3 (For Column Shift)
33749 33749-25020 Lever, Gear Shift, No.3 (For Floor Shift)
33770 90387-09021 Coller (For Cross Shaft)
33772 33772-25010 Bush, Cross Shaft Support, No.1 (For Floor Shift)
33773 33773-25020 Support, Cross Shaft, No.1
33774 33774-25010 Support, Cross Shaft, No.2
9017908141 90179-08141 Nut (For Transmission Control Cable)
9017908141 90179-08038 Nut
9020608016 90206-08016 Washer, Wave (For Low Speed Connecting Rod)
9020613003 90206-13003 Washer, Wave (For Power Take-Off Shift Lever)
9024008068 90240-08068 Pin, W/hose (For Gear Selecting Rod No.3)
9046803011 90468-03011 CLIP
9046814004 90468-14004 Union, Auxiliary Fuel Band
9161160816 91611-60816 Screw Or Bolt(For Valve Rocker Shaft Lock)
9161160816 91611-B0816 Bolt
9165160610 91651-60610 BOLT
9165160610 91651-B0610 BOLTWWASHER
9165160820 91651-60820 Bolt, Radiator Side Support Plate
9165160820 91651-B0820 Bolt, Radiator Side Support Plate
9165160830 91651-60830 Bolt (For Transfer Power Take-Off Cover)
9412040800 94120-40800 Nut(For Clutch Pedal Stopper)
9413060800 94130-60800 Nut(For Clutch Pedal Stopper)
9413060800 90170-A0003 New Genuine Part
9413061000 94130-61000 Nut(For Clutch Pedal Stopper)
9453100800 94531-00800 Washer (For Transfer Shift Outer Lever)
9453101000 94531-01000 WASHER
9461310800 94613-10800 Spacer (For Control Select Lever Support)
Short Block Assembly ([05.1995 - ] (9505- )) 1
#OEMPart name
11400 11400-54160 Block Assy, Short
Side Member ([05.1995 - ] (9505- )T1,T2,T3,T4) 34
#OEMPart name
58011 58011-25010 Panel Sub-Assy, Front Floor Side, Rh
58011 58011-25020 Panel Sub-Assy, Front Floor Side, Rh
58012 58012-25020 Panel Sub-Assy, Front Floor Side, Lh
58012 58012-25030 Panel Sub-Assy, Front Floor Side, Lh
61023 61023-37011 Pillar Sub-Assy, Front Body, Inner Rh
61024 61024-37031 Pillar Sub-Assy, Front Body, Inner Lh
61027 61027-37031 Pillar Sub-Assy, Front Body, Outer Rh
61028 61028-37031 Pillar Sub-Assy, Front Body, Outer Lh
61036 61036-37011 Bracket Sub-Assy, Instrument Panel To Cowl Side, Lh
61107 61107-37010 Cover Sub-Assy, Front Pillar Door Hinge, Rh
61133 61133-37010 Bracket, Front Body Pillar ,outer Rh
61181 61181-37011 Bracket, Instrument Side, Rh
61211 61211-95403 Rail, Roof Side, Outer Rh
61212 61212-95403 Rail, Roof Side, Outer Lh
61231 61231-37010 Rail, Roof Side, Inner Rh
61231 61231-37020 Rail, Roof Side, Inner Rh
61232 61232-37010 Rail, Roof Side, Inner Lh
61232 61232-37020 Rail, Roof Side, Inner Lh
61261 61261-37020 Channel, Roof Drip, Rh
61262 61262-37020 Channel, Roof Drip, Lh
61267 61267-95400 Channel, Roof Drip Side, Rear Rh
61268 61268-95400 Channel, Roof Drip Side, Rear Lh
61579 61579-37010 Silencer, Cab Rear Pillar
64015 64015-37050 Panel Sub-Assy, Back Corner, Inner Rh
64016 64016-37050 Panel Sub-Assy, Back Corner, Inner Lh
64103 64103-95403 Panel Sub-Assy, Back Corner, Outer Rh
64104 64104-95403 Panel Sub-Assy, Back Corner, Outer Lh
9010508341 90105-08341 BOLT WASHER BASED
9010906139 90109-06139 New Genuine Part
9016260005 90162-60005 SCREW
9017908123 90179-08123 Nut (For Front Wiper Arm Setting)
9018906006 90189-06006 Grommet
9046706017 90467-06017-B0 Clip, Rear Floor Mat Set
9165260614 91652-60614 New Genuine Part
Spare Wheel Carrier ([10.1996 - ] (9610- )LY10#,11#,12#,15#,16#,YY101,121,131.. T1,T3,TW1,TW2) 4
#OEMPart name
51900 51900-35101 Carrier Assy, Spare Wheel
64778 64778-26010 Protector, Spare Wheel
9161160816 91611-60816 Screw Or Bolt(For Valve Rocker Shaft Lock)
9161160816 91611-B0816 Bolt
Spare Wheel Carrier ([10.1996 - ] (9610- )LY10#,11#,13#,15#,16#,YY101,121,131.. T2) 8
#OEMPart name
51900 51900-35101 Carrier Assy, Spare Wheel
64778 64778-26010 Protector, Spare Wheel
9161160816 91611-60816 Screw Or Bolt(For Valve Rocker Shaft Lock)
9161160816 91611-B0816 Bolt
9161161030 91611-61030 Bolt (For Transmission Control Cable Bracket)
9161161030 91612-61030 Bolt (For Transmission Control Cable Bracket)
9165160820 91651-60820 Bolt, Radiator Side Support Plate
9165160820 91651-B0820 Bolt, Radiator Side Support Plate
Speaker ([05.1995 - ] (9505- )) 6
#OEMPart name
86160 86160-37050 Speaker Assy, Front No.1
86160 86160-37070 Speaker Assy, Front No.1
86160 86160-37080 Speaker Assy, Front No.1
86202 86202-37020 Wire, Speaker, No.1
9356715016 93567-15016 New Genuine Part
9356715016 93568-55016 Screw
Speedometer Driven Gear (Atm) ([10.1996 - ] A44DE (9610- )LY10#,11#..ATM) 6
#OEMPart name
33403 33403-69135 Gear Sub-Assy, Speedometer Driven (Atm)
33404 33404-30040 Sleeve Sub-Assy, Speedometer Shaft (Mtm)
33404 90301-18004 Ring, O (For Atm Speedometer Driven Hole Cover)
33404 90310-09001 Seal, Oil (For Mtm Speedometer Shaft Sleeve)
33485 33485-25010 Plate, Speedometer Sleeve Lock (Atm)
9161160814 91611-60814 Bolt
Speedometer Driven Gear (Mtm) ([05.1995 - ] G54,R451,R452,R453 (9505- )LY10#,11#,12#,13#,20#,21#,YY101,121,1 31,201,211..MTM) 7
#OEMPart name
33403 33482-39065 Gear Sub-Assy, Speedometer Driven (Mtm)
33404 33404-35010 Sleeve Sub-Assy, Speedometer Shaft (Mtm)
33404 90301-18018 Ring, O (For Atm Speedometer Driven Hole Cover)
33404 90310-09001 Seal, Oil (For Mtm Speedometer Shaft Sleeve)
33404 90468-12005 Clip (For Mtm Speedometer Shaft Sleeve)
33485 33485-30020 Plate, Speedometer Sleeve Lock (For Atm)
9161160814 91611-60814 Bolt
Standard Tool ([05.1995 - ] (9505- )) 16
#OEMPart name
9110 09111-25082 Jack Assy
9114 09114-28010 Extension Sub-Assy, Jack Handle
9115 09115-35070 Rod Sub-Assy, Jack Handle
9116 09116-35041 Lever, Jack Handle
9120 09120-26021 Bag, Tool
9120 09120-35170 Bag, Tool (Black)
9130 99913-11500 Pliers (China) - No Toyota stamp
9135 99915-10700 Driver, Screw - No Toyota stamp
9135 90089-99009 Driver, Screw (ATC) (Thailand) - Screw Driver (ATC)
9141 99914-10810 Spanner (China) - No Toyota stamp
9141 09141-0K030 Spanner (ATC) (Thailand) - 8x10
9141 99914-11214 Spanner (China) - No Toyota stamp
9141 09141-0K040 Spanner (Thailand)
9145 99911-11200 Monkey Wrench (China) No Toyota Stamp
9150 09150-26030 Wrench, Hub Nut Box
9184 09184-00010 Stopper, Wheel
Starter ([05.1995 - ] 12V 1.0KW (9505- )) 51
#OEMPart name
28011 28011-54010 Clutch Sub-Assy, Starter
28011 28011-54260 Clutch Sub-Assy, Starter
28100 28100-54460 Starter Assy
28100 28100-54470 Starter Assy
28100 28100-54481 Starter Assy
28110 28115-54011 Housing Assy, Starter Drive
28110 28115-54260 Housing Assy, Starter Drive
28120 28120-56081 Yoke Assy, Starter
28120 28120-64040 Yoke Assy, Starter
28130 28130-54430 Frame Assy, Starter Commutator End
28140 28140-64040 Holder Assy, Starter Brush
28140 28140-77090 Holder Assy, Starter Brush
28143 90099-17115 Spring, Starter Brush
28150 28150-54260 Switch Assy, Magnet Starter
28150 28150-54430 Switch Assy, Magnet Starter
28159 28159-10040 Cover, Magnet Switch
28159 28159-56310 Cover, Magnet Switch
28160 28160-54140 Armature Assy, Starter
28160 28160-64041 Armature Assy, Starter
28160 28253-54070 Bearing, Starter Armature
28160 90099-10107 Bearing, Starter Armature
28160 90099-10119 Bearing, Starter Armature
28160 90099-10143 Bearing, Starter Armature
28165 28165-26040 Spring, Starter Magnet Switch Return
28165 28165-77090 Spring, Starter Magnet Switch Return
28169 28169-54260 Clamp, Starter Motor Lead Wire
28175 28175-10040 Gasket, Magnet Switch Cover
28175 28175-56310 Gasket, Magnet Switch Cover
28226 28226-17030 Starter Kit, Battery Terminal
28226 28226-54320 Starter Kit, Battery Terminal
28226 28226-54330 Starter Kit, Battery Terminal
28226 28226-54220 Starter Kit, Motor Terminal
28226 28226-72010 Starter Kit, Motor Terminal
28228 28228-26040 Roller, Starter Idle Gear Clutch
28228 28228-56080 Roller, Starter Idle Gear Clutch
28229 28229-26040 Retainer, Starter Idle Gear
28229 28229-56080 Retainer, Starter Idle Gear
28235 28235-17030 Plunger, Magnet Switch
28235 28235-35080 Plunger, Magnet Switch
28252 28254-64040 Pinion, Starter Drive
28252 28254-77090 Pinion, Starter Drive
9009900902 90099-00902 Screw, W/washer(For Bearing Cover Setting)
9009900907 90099-00907 New Genuine Part
9009904473 90099-04473 New Genuine Part
9009904562 90099-04562 BOLT
9009905129 90099-05129 Nut (For Front Wiper Arm Setting)
9009905251 90099-05251 New Genuine Part
9009912009 90099-12009 Ball, Starter Clutch
9017908146 90179-08146 Nut
9017908146 90179-08204 Nut
9161261055 91612-61055 Bolt (For Transfer Case)
Starter ([05.1995 - ] 12V 1.4KW (9505- )) 53
#OEMPart name
28011 28011-54010 Clutch Sub-Assy, Starter
28011 28011-54260 Clutch Sub-Assy, Starter
28100 28100-54460 Starter Assy
28100 28100-54470 Starter Assy
28100 28100-54481 Starter Assy
28110 28115-54011 Housing Assy, Starter Drive
28110 28115-54260 Housing Assy, Starter Drive
28119 28199-46080 Cover, Starter End Frame
28120 28120-56081 Yoke Assy, Starter
28120 28120-64040 Yoke Assy, Starter
28120 90099-64040 Rubber(For Starter Yoke)
28130 28130-54430 Frame Assy, Starter Commutator End
28140 28140-64040 Holder Assy, Starter Brush
28140 28140-77090 Holder Assy, Starter Brush
28143 90099-17115 Spring, Starter Brush
28150 28150-54260 Switch Assy, Magnet Starter
28150 28150-54430 Switch Assy, Magnet Starter
28159 28159-10040 Cover, Magnet Switch
28159 28159-56310 Cover, Magnet Switch
28160 28160-54140 Armature Assy, Starter
28160 28160-64041 Armature Assy, Starter
28160 28253-54070 Bearing, Starter Armature
28160 90099-10107 Bearing, Starter Armature
28160 90099-10119 Bearing, Starter Armature
28160 90099-10143 Bearing, Starter Armature
28165 28165-26040 Spring, Starter Magnet Switch Return
28165 28165-77090 Spring, Starter Magnet Switch Return
28169 28169-54260 Clamp, Starter Motor Lead Wire
28175 28175-10040 Gasket, Magnet Switch Cover
28175 28175-56310 Gasket, Magnet Switch Cover
28226 28226-17030 Starter Kit, Battery Terminal
28226 28226-54320 Starter Kit, Battery Terminal
28226 28226-54330 Starter Kit, Battery Terminal
28226 28226-54220 Starter Kit, Motor Terminal
28226 28226-72010 Starter Kit, Motor Terminal
28228 28228-26040 Roller, Starter Idle Gear Clutch
28228 28228-56080 Roller, Starter Idle Gear Clutch
28229 28229-26040 Retainer, Starter Idle Gear
28229 28229-56080 Retainer, Starter Idle Gear
28235 28235-17030 Plunger, Magnet Switch
28235 28235-35080 Plunger, Magnet Switch
2817615090 28176-15090 Screw, Starter
2817615090 28176-87701 Screw, Starter
9009900270 90099-00270 Screw, Starter
9009904448 90099-04448 Bolt, Starter
9009904449 90099-04449 New Genuine Part
9009904474 90099-04474 New Genuine Part
9009905129 90099-05129 Nut (For Front Wiper Arm Setting)
9009905251 90099-05251 New Genuine Part
9009912009 90099-12009 Ball, Starter Clutch
9017908146 90179-08146 Nut
9017908146 90179-08204 Nut
9161261055 91612-61055 Bolt (For Transfer Case)
Starter ([05.1995 - ] 12V 2.0KW (9505- )) 61
#OEMPart name
28011 28011-54010 Clutch Sub-Assy, Starter
28011 28011-54260 Clutch Sub-Assy, Starter
28100 28100-54460 Starter Assy
28100 28100-54470 Starter Assy
28100 28100-54481 Starter Assy
28110 28115-54011 Housing Assy, Starter Drive
28110 28115-54260 Housing Assy, Starter Drive
28119 28199-46080 Cover, Starter End Frame
28120 28120-56081 Yoke Assy, Starter
28120 28120-64040 Yoke Assy, Starter
28120 90099-64040 Rubber(For Starter Yoke)
28130 28130-54430 Frame Assy, Starter Commutator End
28139 28139-54251 Wire, Lead, No.1(For Starter)
28139 28139-56290 Wire, Lead, No.1(For Starter)
28140 28140-64040 Holder Assy, Starter Brush
28140 28140-77090 Holder Assy, Starter Brush
28143 90099-17115 Spring, Starter Brush
28150 28150-54260 Switch Assy, Magnet Starter
28150 28150-54430 Switch Assy, Magnet Starter
28159 28159-10040 Cover, Magnet Switch
28159 28159-56310 Cover, Magnet Switch
28160 28160-54140 Armature Assy, Starter
28160 28160-64041 Armature Assy, Starter
28160 28253-54070 Bearing, Starter Armature
28160 90099-10107 Bearing, Starter Armature
28160 90099-10119 Bearing, Starter Armature
28160 90099-10143 Bearing, Starter Armature
28165 28165-26040 Spring, Starter Magnet Switch Return
28165 28165-77090 Spring, Starter Magnet Switch Return
28169 28169-54260 Clamp, Starter Motor Lead Wire
28175 28175-10040 Gasket, Magnet Switch Cover
28175 28175-56310 Gasket, Magnet Switch Cover
28226 28226-17030 Starter Kit, Battery Terminal
28226 28226-54320 Starter Kit, Battery Terminal
28226 28226-54330 Starter Kit, Battery Terminal
28226 28226-54220 Starter Kit, Motor Terminal
28226 28226-72010 Starter Kit, Motor Terminal
28228 28228-26040 Roller, Starter Idle Gear Clutch
28228 28228-56080 Roller, Starter Idle Gear Clutch
28229 28229-26040 Retainer, Starter Idle Gear
28229 28229-56080 Retainer, Starter Idle Gear
28235 28235-17030 Plunger, Magnet Switch
28235 28235-35080 Plunger, Magnet Switch
28251 28251-54070 Plate, Lead, Switch Connecting
28252 28254-64040 Pinion, Starter Drive
28252 28254-77090 Pinion, Starter Drive
2817654380 28176-54380 Screw, Starter
9009900253 90099-00253 New Genuine Part
9009900271 90099-00271 Screw, Starter
9009904453 90099-04453 New Genuine Part
9009904475 90099-04475 New Genuine Part
9009905129 90099-05129 Nut (For Front Wiper Arm Setting)
9009905251 90099-05251 New Genuine Part
9009912009 90099-12009 Ball, Starter Clutch
9011912019 90119-12019 Bolt(For Transaxle & Engine Setting)
9017908146 90179-08146 Nut
9017908146 90179-08204 Nut
9321915008 93219-15008 New Genuine Part
9411551200 94115-51200 Nut(For Backing Plate To Steering Knuckle Setting)
9413061200 94130-61200 Nut
9453100500 94531-00500 WASHER,WAVE
Starter ([05.1995 - ] 12V 2.7KW (9505- )) 61
#OEMPart name
28011 28011-54010 Clutch Sub-Assy, Starter
28011 28011-54260 Clutch Sub-Assy, Starter
28100 28100-54460 Starter Assy
28100 28100-54470 Starter Assy
28100 28100-54481 Starter Assy
28110 28115-54011 Housing Assy, Starter Drive
28110 28115-54260 Housing Assy, Starter Drive
28118 28118-77090 Plate(For Starter Yoke)
28119 28199-46080 Cover, Starter End Frame
28120 28120-56081 Yoke Assy, Starter
28120 28120-64040 Yoke Assy, Starter
28130 28130-54430 Frame Assy, Starter Commutator End
28139 28139-54251 Wire, Lead, No.1(For Starter)
28139 28139-56290 Wire, Lead, No.1(For Starter)
28140 28140-64040 Holder Assy, Starter Brush
28140 28140-77090 Holder Assy, Starter Brush
28150 28150-54260 Switch Assy, Magnet Starter
28150 28150-54430 Switch Assy, Magnet Starter
28159 28159-10040 Cover, Magnet Switch
28159 28159-56310 Cover, Magnet Switch
28160 28160-54140 Armature Assy, Starter
28160 28160-64041 Armature Assy, Starter
28160 28253-54070 Bearing, Starter Armature
28160 90099-10107 Bearing, Starter Armature
28160 90099-10119 Bearing, Starter Armature
28160 90099-10143 Bearing, Starter Armature
28165 28165-26040 Spring, Starter Magnet Switch Return
28165 28165-77090 Spring, Starter Magnet Switch Return
28175 28175-10040 Gasket, Magnet Switch Cover
28175 28175-56310 Gasket, Magnet Switch Cover
28191 28191-54010 Stay, Starter
28199 28199-54190 Cover, Starter End Frame
28222 28222-77090 Washer, Starter Idle Gear Clutch
28226 28226-17030 Starter Kit, Battery Terminal
28226 28226-54320 Starter Kit, Battery Terminal
28226 28226-54330 Starter Kit, Battery Terminal
28226 28226-54220 Starter Kit, Motor Terminal
28226 28226-72010 Starter Kit, Motor Terminal
28228 28228-26040 Roller, Starter Idle Gear Clutch
28228 28228-56080 Roller, Starter Idle Gear Clutch
28229 28229-26040 Retainer, Starter Idle Gear
28229 28229-56080 Retainer, Starter Idle Gear
28235 28235-17030 Plunger, Magnet Switch
28235 28235-35080 Plunger, Magnet Switch
28252 28254-64040 Pinion, Starter Drive
28252 28254-77090 Pinion, Starter Drive
9009221001 90092-21001 NUT
9009900158 90099-00158 SCREW
9009900254 90099-00254 New Genuine Part
9009902205 90099-02205 Washer, Felt, Starter
9009902325 90099-02325 WASHER
9009904207 90099-04207 New Genuine Part
9009904473 90099-04473 New Genuine Part
9009912009 90099-12009 Ball, Starter Clutch
9011912019 90119-12019 Bolt(For Transaxle & Engine Setting)
9017908068 90179-08068 NUT
9017910195 90179-10195 NUT WWASHER
9411551200 94115-51200 Nut(For Backing Plate To Steering Knuckle Setting)
9413061200 94130-61200 Nut
9451100600 94511-00600 Washer, Lock, No.2
9451101000 94511-01000 Washer(For Rear Drive Shaft)
Starter ([05.1999 - ] 12V 2.2KW (9905- )) 59
#OEMPart name
28011 28011-54010 Clutch Sub-Assy, Starter
28011 28011-54260 Clutch Sub-Assy, Starter
28100 28100-54460 Starter Assy
28100 28100-54470 Starter Assy
28100 28100-54481 Starter Assy
28110 28115-54011 Housing Assy, Starter Drive
28110 28115-54260 Housing Assy, Starter Drive
28119 28199-46080 Cover, Starter End Frame
28120 28120-56081 Yoke Assy, Starter
28120 28120-64040 Yoke Assy, Starter
28120 90099-64040 Rubber(For Starter Yoke)
28139 28139-54171 Wire, Lead, No.1(For Starter)
28140 28140-64040 Holder Assy, Starter Brush
28140 28140-77090 Holder Assy, Starter Brush
28143 90099-17115 Spring, Starter Brush
28150 28150-54260 Switch Assy, Magnet Starter
28150 28150-54430 Switch Assy, Magnet Starter
28159 28159-10040 Cover, Magnet Switch
28159 28159-56310 Cover, Magnet Switch
28160 28160-54140 Armature Assy, Starter
28160 28160-64041 Armature Assy, Starter
28160 28253-54070 Bearing, Starter Armature
28160 90099-10107 Bearing, Starter Armature
28160 90099-10119 Bearing, Starter Armature
28160 90099-10143 Bearing, Starter Armature
28165 28165-26040 Spring, Starter Magnet Switch Return
28165 28165-77090 Spring, Starter Magnet Switch Return
28169 28169-54260 Clamp, Starter Motor Lead Wire
28175 28175-10040 Gasket, Magnet Switch Cover
28175 28175-56310 Gasket, Magnet Switch Cover
28226 28226-17030 Starter Kit, Battery Terminal
28226 28226-54320 Starter Kit, Battery Terminal
28226 28226-54330 Starter Kit, Battery Terminal
28226 28226-54220 Starter Kit, Motor Terminal
28226 28226-72010 Starter Kit, Motor Terminal
28228 28228-26040 Roller, Starter Idle Gear Clutch
28228 28228-56080 Roller, Starter Idle Gear Clutch
28229 28229-26040 Retainer, Starter Idle Gear
28229 28229-56080 Retainer, Starter Idle Gear
28235 28235-17030 Plunger, Magnet Switch
28235 28235-35080 Plunger, Magnet Switch
28251 28251-54070 Plate, Lead, Switch Connecting
28252 28254-64040 Pinion, Starter Drive
28252 28254-77090 Pinion, Starter Drive
2817187702 28171-87702 Bolt, Starter
2936287701 29362-87701 Bolt, Starter
9009904473 90099-04473 New Genuine Part
9009905129 90099-05129 Nut (For Front Wiper Arm Setting)
9009912009 90099-12009 Ball, Starter Clutch
9011912019 90119-12019 Bolt(For Transaxle & Engine Setting)
9017908146 90179-08146 Nut
9017908146 90179-08204 Nut
9321915008 93219-15008 New Genuine Part
9411040800 94110-40800 Nut(For Steering Damper)
9411040800 94130-00802 Nut, No.1 (For Center Support Bearing)
9413061200 94130-61200 Nut
9451100500 94511-00500 Washer, Cover Set, No.2
9451100800 94511-00800 WASHERSPRING
9671119006 96711-19006 Packing(For Radiator Drain Cock)
Steering Column & Shaft ([05.1995 - ] (9505- )LY10#,11#,20#,21#,YY101,201,211) 55
#OEMPart name
45201 45210-25010 Shaft Sub-Assy, Steering Main
45201 90520-17042 Ring, Shaft Snap(For Steering Main Shaft)
45201 90520-17269 Ring, Shaft Snap(For Steering Main Shaft)
45201 96152-00300 Ring, Hole Snap (For Differential Side Gear Shaft)
45204 45204-25010 Tube Assy, Steering Column, Lower
45204 45204-25020 Tube Assy, Steering Column, Lower
45205 45205-37030 Tube Sub-Assy, Steering Column, Upper
45207 45207-25040 Cover Sub-Assy, Main Shaft Joint
45207 45207-25050 Cover Sub-Assy, Main Shaft Joint
45225 45225-26010 Ring, Shaft Snap(For Steering Main Shaft)
45230 45230-25022 Coupling Assy, Flexible
45254 45254-36090 Shield, Steering Column Hole
45263 45263-32010 Ring, Steering Column, No.1
45280 45307-37020 Bracket, Steering Column, Upper
45280 45307-37010 Bracket, Steering Column, Upper
45286 45286-37040-B0 Cover, Steering Column
45286 45286-37040-C0 Cover, Steering Column
45286 45286-37070-B0 Cover, Steering Column, Upr
45287 45287-37030-B0 Cover, Steering Column
45287 45287-37070-B0 Cover, Steering Column, Lwr
45804 45804-36010-B0 Lever Sub-Assy, Steering Tilt
45804 45804-36010-C0 Lever Sub-Assy, Steering Tilt
45804 90105-10204 Bolt(For Steering Tilt Lever)
45804 90201-10489 Washer, Plate(For Timing Gear)
45804 90339-28001-B0 Plug(For Steering Tilt Lever)
45819 90386-19004 Collar(For Tilt Lever Retainer)
45819 90387-06037 Collar(For Tilt Lever Retainer)
45826 90507-18018 Spring, Tension(For Steering Tilt Lever)
45826 90386-10024 Bush(For Steering Tilt Lever)
45831 45831-36010 Bolt, Tilt Lever Lock, No.1
45833 45833-36010 Nut, Tilt Steering Adjusting, No.1
45872 45872-36040 Cover, Steering Column Tube
45890 90389-12009 Collar(For Tilt Steering Pawl)
9011408027 90114-08027 Bolt, Flexible Attaching(For Steering Main Shaft)
9011908560 90119-08560 Bolt, Hexagon
9011908560 90080-11555 Bolt w-washer
9011908843 90119-08843 New Genuine Part
9011908843 90119-08856 BOLT W-WASHER
9011910322 90119-10322 BOLT
9020111313 90201-11313 Spacer, Heater Blower Switch
9020618002 90206-18002 RING
9112140665 91121-40665 New Genuine Part
9161160616 91611-60616 Bolt(For Transaxle Case Receiver)
9161160616 91611-B0616 Bolt(For Transaxle Case Receiver)
9166160616 91661-60616 BOLT
9331514012 93315-14012 Screw with washer
9356615514 93566-15514 Direct
9356615514 93568-55014 Screw
9413060600 94130-60600 Nut, Wire Adjusting, No.1
9413060800 94130-60800 Nut(For Clutch Pedal Stopper)
9413060800 90170-A0003 New Genuine Part
9451200800 94512-00800 Washer, No.1 (For Propeller Shaft & Differential Setting)
9453100600 94531-00600 Washer(For Outer Lever Oil Setting)
9453100800 94531-00800 Washer (For Transfer Shift Outer Lever)
9461310601 94613-10601 Washer (For Primary Regulator Valve)
Steering Column & Shaft ([08.1997 - ] ｱﾘ(*80) (9708- )LY10#,11#,20#,21#,YY101,201,211) 57
#OEMPart name
45201 90520-17042 Ring, Shaft Snap(For Steering Main Shaft)
45201 90520-17269 Ring, Shaft Snap(For Steering Main Shaft)
45201 96152-00300 Ring, Hole Snap (For Differential Side Gear Shaft)
45204 45204-25010 Tube Assy, Steering Column, Lower
45204 45204-25020 Tube Assy, Steering Column, Lower
45205 45205-37030 Tube Sub-Assy, Steering Column, Upper
45207 45207-25040 Cover Sub-Assy, Main Shaft Joint
45207 45207-25050 Cover Sub-Assy, Main Shaft Joint
45210 45210-25020 Shaft Assy, Steering Main
45225 45225-26010 Ring, Shaft Snap(For Steering Main Shaft)
45230 45230-25022 Coupling Assy, Flexible
45263 45263-32010 Ring, Steering Column, No.1
45275 45307-36230 Bracket, Steering Column, Upper
45275 45307-36220 Bracket, Steering Column, Upper
45286 45286-37040-B0 Cover, Steering Column
45286 45286-37040-C0 Cover, Steering Column
45286 45286-37070-B0 Cover, Steering Column, Upr
45287 45287-37030-B0 Cover, Steering Column
45287 45287-37070-B0 Cover, Steering Column, Lwr
45804 45804-36010-B0 Lever Sub-Assy, Steering Tilt
45804 45804-36010-C0 Lever Sub-Assy, Steering Tilt
45804 90105-10204 Bolt(For Steering Tilt Lever)
45804 90201-10489 Washer, Plate(For Timing Gear)
45804 90339-28001-B0 Plug(For Steering Tilt Lever)
45819 90386-19004 Collar(For Tilt Lever Retainer)
45819 90387-06037 Collar(For Tilt Lever Retainer)
45826 90507-18018 Spring, Tension(For Steering Tilt Lever)
45826 90386-10024 Bush(For Steering Tilt Lever)
45831 45831-36010 Bolt, Tilt Lever Lock, No.1
45833 45833-36010 Nut, Tilt Steering Adjusting, No.1
45872 45872-36040 Cover, Steering Column Tube
45890 90389-12009 Collar(For Tilt Steering Pawl)
51735 51735-25040 Plate, Cab Mounting Bracket
51751 51751-25010 Bracket, Body Support, No.1
9011908560 90119-08560 Bolt, Hexagon
9011908560 90080-11555 Bolt w-washer
9011908843 90119-08843 New Genuine Part
9011908843 90119-08856 BOLT W-WASHER
9011910841 90119-10841 New Genuine Part
9020111313 90201-11313 Spacer, Heater Blower Switch
9020618002 90206-18002 RING
9112140665 91121-40665 New Genuine Part
9161160616 91611-60616 Bolt(For Transaxle Case Receiver)
9161160616 91611-B0616 Bolt(For Transaxle Case Receiver)
9163560616 91635-60616 BOLT WWASHER
9163560616 91631-J0612 BRACKET
9166160616 91661-60616 BOLT
9331514012 93315-14012 Screw with washer
9356615514 93566-15514 Direct
9356615514 93568-55014 Screw
9413060600 94130-60600 Nut, Wire Adjusting, No.1
9413060800 94130-60800 Nut(For Clutch Pedal Stopper)
9413060800 90170-A0003 New Genuine Part
9451200800 94512-00800 Washer, No.1 (For Propeller Shaft & Differential Setting)
9453100600 94531-00600 Washer(For Outer Lever Oil Setting)
9453100800 94531-00800 Washer (For Transfer Shift Outer Lever)
9461310601 94613-10601 Washer (For Primary Regulator Valve)
Steering Wheel ([05.1995 - ] (9505- )) 10
#OEMPart name
45100 45100-36130-B0 Wheel Assy, Steering
45100 45100-37040-B0 Wheel Assy, Steering
45100 45100-37040-B1 Wheel Assy, Steering
45105 45105-36020 Plate Sub-Assy, Horn Button Contact, No.1
45130 45130-36110-B0 Button Assy, Horn
45130 45130-37140-B1 Button Assy, Horn
45130 45130-37140-B0 Button Assy, Horn
45176 45176-36010 Ring, Horn Contact
45180 45180-36020-B0 Cover Sub-Assy, Steering Wheel
45201 90179-12071 Nut, Steering Wheel Set
Steering Wheel ([08.1997 - ] W(*80) (9708- )) 8
#OEMPart name
45100 45100-36130-B0 Wheel Assy, Steering
45100 45100-37040-B0 Wheel Assy, Steering
45100 45100-37040-B1 Wheel Assy, Steering
45130 45130-36110-B0 Button Assy, Horn
45130 45130-37140-B1 Button Assy, Horn
45130 45130-37140-B0 Button Assy, Horn
45188 90148-60011 Screw, Steering Wheel Pad Attaching
45201 90179-12071 Nut, Steering Wheel Set
Suspension Crossmember & Under Cover ([10.1996 - ] (9610- )LY10#,11#,YY101) 10
#OEMPart name
51405 51405-25050 Cover Sub-Assy, Engine Under, No.1
51405 51405-25060 Cover Sub-Assy, Engine Under, No.1
51409 51409-25040 Guide, Engine Under Air
51436 51436-25020 Protector, Engine Front Support
51473 51473-25030 Cover Sub-Assy, Engine Side, Rh
51474 51474-25030 Cover Sub-Assy, Engine Side, Lh
9163160830 91631-60830 New Genuine Part
9163160830 91631-G0830 BOLT WWASHER
9165160816 91651-60816 BOLT
9165160816 90080-11396 Bolt
Switch & Relay & Computer ([05.1995 - ] ｴﾝｼﾞﾝ & ﾄﾗﾝｽﾐｯｼｮﾝ (9505- )) 29
#OEMPart name
83420 83420-16040 Gage Assy, Water Temperature Sender
83530 83530-60030 Switch Assy, Oil Pressure (For Engine)
84210 84210-12040 Switch Assy, Back-Up Lamp
84210 84210-52050 Switch Assy, Back-Up Lamp
84540 84540-30290 Switch Assy, Neutral Start
84540 84540-30300 Switch Assy, Neutral Start
89422 89422-20010 Sensor, Water Temperature (For E.f.i.)
89428 89428-36030 Switch, Temperature Detect, No.2
89491 89491-25021 Sensor, Engine Oil Level
89491 89493-60010 Gasket, Engine Oil Level Sensor
1987766010 19877-66010 Insulator Sub-Assy, Glow Plug, No.1
2862257010 28622-57010 Insulator, Glow Plug Resistor, No.1
2862354010 28623-54010 Insulator, Glow Plug Resistor, No.2
8271112200 82711-12200 Clamp (For Fuel Lid Lock Control Cable)
8271126040 82711-26040 Wire, Fuse To Fuse(for Combustion Heater)
9011606041 90116-06041 Bolt, Stud(For Intake Manifold To Glow Plug Connector No.1)
9011606041 90116-06095 Bolt, Stud(For Head To Cylinder Head Cover)
9017905032 90179-05032 NUT
9017905032 90179-05011 NUT
9017906158 90179-06158 Nut, Rear Wiper Link Pivot, No.2
9017908059 90179-08059 Nut
9017908059 90179-08101 NUT
9043012221 90430-12221 Gasket
9043018008 90430-18008 Gasket
9043018008 90430-T0021 Gasket(For Manual Transmission Filler Plug)
9165140825 91651-40825 Bolt(For Clutch Release Cylinder Setting)
9165160614 91651-60614 Bolt
9338516025 93385-16025 New Genuine Part
9461310601 94613-10601 Washer (For Primary Regulator Valve)
Switch & Relay & Computer ([05.1995 - ] ｴﾝｼﾞﾝﾙｰﾑ (9505- )) 15
#OEMPart name
28610 28610-54360 Relay Assy, Glow Plug
83390 83390-12340 Switch Assy, Vacuum Warning
85958 85909-25030 Bracket, Main Relay
85958 85958-25080 Bracket, Main Relay
8271125110 82711-25110 Wire, Fuse To Fuse(for Combustion Heater)
8271125180 82711-25180 Wire, Fuse To Fuse(for Combustion Heater)
8271525170 82715-25170 Bracket,wiring Harness Clamp
9011906186 90119-06186 BOLT
9011906186 90119-06420 BOLT WWASHER
9164280822 91642-80822 New Genuine Part
9165140814 91651-40814 BOLT
9165140814 90080-11228 New Genuine Part
9165140820 91651-40820 Bolt
9165160614 91651-60614 Bolt
9165160616 91651-60616 BOLT
Switch & Relay & Computer ([05.1995 - ] ｶｳﾙ (9505- )) 10
#OEMPart name
84330 84332-37050 Switch Assy, Hazard Warning Signal
84660 84660-35010 Switch, Cooler
84660 88607-16010 Bulb(For Cooler Switch)
84730 84732-42010 Switch Assy, Heater Blower
84730 90981-11014 Bulb, Position Indicator Lamp
84730 84998-10050 Cap, Satellite Switch
84873 84873-37010 Switch Assy, Outer Mirror
85500 85500-37040 Lighter Assy, Cigarette
85520 85520-17020 Knob And Element Assy, Cigarette Lighter
8499910320 84999-10320 Bulb, Satellite Switch
Switch & Relay & Computer ([05.1995 - ] ｽﾃｱﾘﾝｸﾞ (9505- )) 35
#OEMPart name
84110 84112-80190 Switch Assy, Light Control, No.1
84110 84112-80228 Switch Assy, Light Control, No.1
84110 84112-80219 Switch Assy, Light Control, No.1
84140 84140-37010 Switch Assy, Headlamp Dimmer
84306 84306-25010 Cable Sub-Assy, Spiral
84310 84310-25230 Switch Assy, Turn Signal
84310 84310-25240 Switch Assy, Turn Signal
84310 84310-37020 Switch Assy, Turn Signal
84310 84310-37030 Switch Assy, Turn Signal
84312 84312-20011 Plate, Horn Contact
84329 84329-37010 Switch, Turn Signal
84329 84329-37050 Switch, Turn Signal
84450 84450-37040 Switch Assy, Ignition Or Starter
84450 84450-37110 Switch Assy, Ignition Or Starter
84450 84450-37050 Switch Assy, Ignition Or Starter
84450 84450-37070 Switch Assy, Ignition Or Starter
84450 84450-37090 Switch Assy, Ignition Or Starter
84650 84652-25100 Switch Assy, Windshield Wiper
84650 84652-25110 Switch Assy, Windshield Wiper
84650 84652-37020 Switch Assy, Windshield Wiper
84650 84652-37030 Switch Assy, Windshield Wiper
85432 85432-25010 Solenoid, Key Inter Lock
8271130070 82711-30070 Wire, Fuse To Fuse(for Combustion Heater)
8271130130 82711-30130 Wire, Fuse To Fuse(for Combustion Heater)
8271137181 82711-37181 Wire, Fuse To Fuse(for Combustion Heater)
8271137200 82711-37200 Wire, Fuse To Fuse(for Combustion Heater)
9008046104 90080-46104 New Genuine Part
9046400232 90464-00232 New Genuine Part
9165140616 91651-40616 BOLT
9165140616 91621-60614 Bolt(For Transaxle & Engine Setting)
9165140616 90080-11395 New Genuine Part
9331913008 93319-13008 New Genuine Part
9331913012 93319-13012 New Genuine Part
9331914012 93319-14012 New Genuine Part
9331915012 93319-15012 Screw
Switch & Relay & Computer ([05.1995 - ] ﾄﾞｱ,ﾙｰﾌ,ﾌﾛｱ (9505- )) 24
#OEMPart name
83650 90986-01005 Fusee
83790 83970-37040 Buzzer Assy, Reverse Warning
84233 84231-28020 Switch, Courtesy Lamp
84233 84231-28010 Switch Assy, Courtesy Lamp
84340 84340-36070 Switch Assy, Stop Lamp
84340 84340-36071 Switch Assy, Stop Lamp
84550 84550-37010 Switch Assy, Parking Brake
84810 84810-37030-B0 Switch Assy, Power Window Regulator
84820 84820-37020-B4 Master Switch Assy, Power Window Regulator
84931 84931-37020 Switch, Door Control
85431 85431-26010 Solenoid, Shift Lock
85933 85933-25020 Computer, Shift Lock Control
86650 86650-37020 Buzzer Assy, Vacuum Warning
9015940009 90159-40009 New Genuine Part
9016740024 90167-40024 New Genuine Part
9017910155 90179-10155 Nut, Heater Blower Switch
9020110008 90201-10008 Washer, No.2 (For Center Support Bearing)
9020110041 90201-10041 New Genuine Part
9033325001 90333-25001 Plug, Hole(For Hood)
9162640616 91626-40616 New Genuine Part
9165140614 91651-40614 Bolt
9331314008 93313-14008 New Genuine Part
9412040800 94120-40800 Nut(For Clutch Pedal Stopper)
9413061000 94130-61000 Nut(For Clutch Pedal Stopper)
Switch & Relay & Computer ([05.1995 - ] ﾘﾔﾎﾞﾃﾞｰ (9505- )) 12
#OEMPart name
83320 83320-80316 Gage Assy, Fuel Sender
83361 83361-20030 Gasket, Fuel Tank Vent
86650 86650-95A08 Buzzer Assy, Reverse Warning
9011908 90119-08A46 BOLT WWASHER
2332264010 23322-64010 Drain Plug (For a Level Warning Switch)
2334454010 23344-54010 O-Ring (For Drain Plug)
9015940155 90159-40155 SCREW WWASHER
9043008252 90430-08252 Gasket(For Catalytic Converter Sensor Guide)
9165660616 91656-60616 BOLT
9165660616 91651-60616 BOLT
9413000802 94130-00802 Nut, No.1 (For Center Support Bearing)
9413000802 90170-A0001 New Genuine Part
Switch & Relay & Computer ([05.1999 - ] ｲﾝｽﾄﾙﾒﾝﾄﾊﾟﾈﾙ (9905- )) 32
#OEMPart name
28300 28300-46010 Relay Assy, Starter
28521 28521-54591 Timer, Preheating
28529 28529-54380 Bracket, Preheating Timer, No.1
28610 28610-54360 Relay Assy, Glow Plug
81980 81980-25090 Flasher Assy, Turn Signal
82600 90982-09007 Fusible Link
82600 90982-09008 Fusible Link
82600 90982-09009 Fusible Link
82600 90982-09010 Fusible Link
82600 90982-09011 Fusible Link
82600 90982-09013 Fusible Link
82600 82683-25100 Plate, Caution(For Fuse)
82616 82616-20010 Puller, Fuse
85913 90987-04002 Relay, Ignition, No.1
85915 90987-02004 Relay Assy, Starter
85916 90987-02006 Relay
85930 85930-25011 Relay Assy, Power Window
85980 85980-25011 Relay Assy, Door Control
85985 80590-26011 Relay, Key Reminder
89373 89370-37010 Sensor, Lamp Failure Indicator
89390 89390-25020 Relay, Brake Warning
9011906620 90119-06620 BOLT WWASHER
9015960025 90159-60025 SCREW W-WASHER
9015960081 90159-60081 SCREW
9018906066 90189-06066 CLIP
9161160612 91611-60612 Bolt(For Dust Cover To Steering Knuckle Arm Setting)
9161160612 91611-G0612 Bolt
9161260816 91612-60816 Bolt, Exhaust Valve Cover
9161260816 91611-B0816 Bolt
9164280822 91642-80822 New Genuine Part
9165140814 91651-40814 BOLT
9165140814 90080-11228 New Genuine Part
Throttle Link & Valve Lever (Atm) ([10.1996 - ] A44DE (9610- )LY10#,11#..ATM) 17
#OEMPart name
35501 35501-26020 Rod Sub-Assy, Parking Lock
35505 35505-22020 Lever Sub-Assy, Manual Valve
35506 90254-04011 Pin, Slotted Spring (For Transfer Manual Valve Lever)
35506 90311-11003 Seal, Oil (For Manual Valve Lever Shaft)
35506 90560-20003 Spacer (For Transfer Manual Valve Lever)
35506 90560-20025 Spacer (For Manual Valve Lever)
35556 35556-26010 Shaft, Parking Lock Pawl
35556 90523-08021 Ring, E (For Parking Lock Pawl Shaft)
35557 35557-26040 Pawl, Parking Lock
35557 90508-21001 Spring, Torsion (For Parking Lock Pawl)
35561 35561-30060 Shaft Sub-Assy, Manual Valve Lever
35573 35573-26020 Lever, Transmission Control Shaft, Lh
35595 35595-26010 Bracket, Parking Lock Pawl
9010106024 90101-06024 New Genuine Part
9411050800 94110-50800 Nut(For Repair Actuator Set)
9451200800 94512-00800 Washer, No.1 (For Propeller Shaft & Differential Setting)
9454200600 94542-00600 New Genuine Part
Throttle Link & Valve Lever (Atm) ([10.1996 - ] A44DE,A44DF (9610- )LY10#,11#,16#..ATM) 8
#OEMPart name
35520 35520-25021 Cable Assy, Throttle
35523 35523-26021 Clamp, Throttle Cable
35525 35525-35031 Bracket, Throttle Cable
9046400535 90464-00535 Clamp, Throttle Cable, No.1
9161160816 91611-60816 Screw Or Bolt(For Valve Rocker Shaft Lock)
9161160816 91611-B0816 Bolt
9165140610 91651-40610 RIVET
9622110710 96221-10710 Clamp, Throttle Cable, No.2
Timing Gear Cover & Rear End Plate ([05.1995 - ] (9505- )3L,5L) 42
#OEMPart name
11301 11311-54052 Case Sub-Assy, Timing Gear
11301 92132-60828 Bolt,stud(For Timing Gear Case)
11301 90311-42031 Seal, Oil
11302 11321-54020 Cover Sub-Assy, Timing Chain Or Belt
11302 11321-54021 Cover Sub-Assy, Timing Chain Or Belt
11302 90341-18004 Plug, Straight(For Timing Gear Cover)
11305 90311-32019 Seal, Oil(For Camshaft Setting)
11305 90253-11021 Pin, Ring
11312 11312-54021 Gasket, Front End Plate
11312 11312-54040 Gasket, Front End Plate
11322 11322-54021 Cover, Timing Belt, No.2
11322 11322-54022 Cover, Timing Belt, No.2
11328 11328-54021 Gasket, Timing Gear Or Chain Cover
11329 11329-05010 Gasket, Timing Gear Rear Cover
11329 11329-54021 Gasket, Timing Gear Rear Cover
11354 11354-54010 Seal, Flywheel Housing Dust
11355 11355-54030 Plate, Rear End
11355 11355-54140 Plate, Rear End
11355 90950-01686 Plug, Hole(For Rear End Plate)
11381 11381-54020 Retainer, Engine Rear Oil Seal
11381 11381-54030 Retainer, Engine Rear Oil Seal
11381 90116-08404 BOLT STUD
11381 90311-85008 Seal, Engine Rear Oil
11383 11383-54030 Gasket, Engine Rear Oil Seal Retainer
11384 11384-54030 Gasket, Oil Seal Retainer, No.2
11385 11382-54020 Retainer, Camshaft Oil Seal
11391 11391-54020 Pointer, Timing
9010508175 90105-08175 Bolt(For Crankshaft Bearing Cap Set)
9010906017 90109-06017 BOLT
9011908689 90119-08689 Bolt(For Clutch Release Cylinder Setting)
9011908689 91611-G0820 Bolt
9011910736 90119-10736 BOLT WWASHER
9021008019 90210-08019 WASHER
9021008019 90080-21002 WASHER
9161160818 91611-60818 Bolt(For Oil Receiver Pipe)
9161160818 90119-08830 Bolt(For Oil Receiver Pipe)
9161160822 91611-60822 Bolt
9161160828 91611-60828 Bolt(For Clutch Release Cylinder Setting)
9162160814 91621-60814 Bolt (For Transmission Control Cable Bracket)
9162160814 91621-J0814 Bolt (For Transmission Control Cable Bracket)
9162261022 91622-61022 BOLT WWASHER
9671119015 96711-19015 Ring, O(For Power Steering Pump Tight Plug)
Tool Box & License Plate Bracket ([05.1995 - ] (9505- )) 28
#OEMPart name
58794 58794-37020 Support, Jack Handle
58797 58797-37020 Band, Jack Clamp
66407 66407-95017 Stay Sub-Assy, License Plate Bracket
66407 66407-25050 Stay Sub-Assy, License Plate Bracket
66407 66493-25020 Stay Sub-Assy, License Plate Bracket
66407 66495-25010 Stay Sub-Assy, License Plate Bracket
66407 66495-25012 Stay Sub-Assy, License Plate Bracket
75102 66490-95019 Bracket Sub-Assy, Rear License Plate
75102 66490-25050 Bracket Sub-Assy, Rear License Plate
75135 75135-25040 Bracket, Combination Rear Lamp, Rh
75135 75136-25030 Bracket, Combination Rear Lamp, Lh
75201 75210-25030 Box Sub-Assy, Tool W/stay
75204 75204-25020 Stay Sub-Assy, Tool Box
9011910087 90119-10087 New Genuine Part
9026903001 90269-03001 New Genuine Part
9026903025 90269-03025 RIVET
9151160820 91511-60820 Bolt, Washer Based Head Hexagon (For Transfer Case Cover)
9151160820 91511-J0820 Bolt, Washer Based Head Hexagon (For Transfer Case Cover)
9162140616 91621-40616 Step Cover Bolt
9162140818 91621-40818 New Genuine Part
9165140616 91651-40616 BOLT
9165140616 91621-60614 Bolt(For Transaxle & Engine Setting)
9165140616 90080-11395 New Genuine Part
9166160816 91661-60816 Bolt
9413001001 94130-01001 Nut(For Clutch Pedal Stopper)
9418561000 94185-61000 NUTLOCK
9453101000 94531-01000 WASHER
9461311001 94613-11001 WASHER
Torque Converter, Front Oil Pump & Chain (Atm) ([05.1995 - ] A42D,A43D,A44DE,A44DF (9505- )YY211..WT..125 ; (9505- )LY10#,11# ,16#..ATM) 27
#OEMPart name
30250 30250-26060 Converter Assy, Torque, Rebuilt
32000 32000-26060 Converter Assy, Torque
32101 32101-35020 Gear Sub-Assy, Drive Plate & Ring
32101 90119-09026 Bolt(For Drive Plate & Torque Converter Setting)
32101 90119-09027 Bolt(For Drive Plate & Torque Converter Setting)
32101 90105-12014 Bolt, Hexagon(For Drive Plate Setting)
32116 32116-35010 Spacer, Drive Plate, Front
32117 32117-35010 Spacer, Drive Plate, Rear
35301 35301-14010 Body Sub-Assy, Front Oil Pump
35301 90311-38020 Seal, Oil (For Front Oil Pump)
35301 90311-38064 Seal, Oil (For Front Oil Pump)
35301 90301-99010 Ring, O (For Front Oil Pump Body)
35301 90105-08137 Bolt (For Front Oil Pump Setting)
35321 35321-22020 Gear Sub-Assy, Front Oil Pump Drive
35321 35321-22030 Gear Sub-Assy, Front Oil Pump Drive
35321 35321-22040 Gear Sub-Assy, Front Oil Pump Drive
35321 35321-22050 Gear Sub-Assy, Front Oil Pump Drive
35321 35321-22060 Gear Sub-Assy, Front Oil Pump Drive
35322 35322-22020 Gear, Front Oil Pump Driven
35322 35322-22030 Gear, Front Oil Pump Driven
35322 35322-22040 Gear, Front Oil Pump Driven
35322 35322-22050 Gear, Front Oil Pump Driven
35322 35322-22060 Gear, Front Oil Pump Driven
35370 35370-14012 Shaft Sub-Assy, Stator
35617 35617-32010 Ring, Clutch Drum Oil Seal
35701 90374-25003 Bearing, Thrust (For Input Shaft Front)
9010506126 90105-06126 Bolt (For Stator Shaft)
Transaxle Or Transmission Assy & Gasket Kit (Atm) ([10.1996 - ] A42D,A44DE,A443E (9610- )LY10#,11#,132,212,YY211..ATM..CBR,DSL) 4
#OEMPart name
4351 04351-25020 Gasket Kit, Automatic Transmission Overhaul
4351 04351-25050 Gasket Kit, Automatic Transmission Overhaul
30030 30030-25100 Transmission Assy, Rebuilt
35000 35000-25100 Transmission Assy, Automatic
Transaxle Or Transmission Assy & Gasket Kit (Mtm) ([05.1995 - ] G54 (9505- )LY10#,11#,201,YY101,201..MTM..ST..125 ,1T) 2
#OEMPart name
4331 04331-28010 Gasket Kit, Manual Transmission Overhaul
33030 33030-25130 Transmission Unit Assy, Manual
Transmission Case & Oil Pan (Atm) ([10.1996 - ] A44DE,A44DF (9610- )LY10#,11#,16#..ATM) 36
#OEMPart name
33118 33118-25020 Plate, Stiffener, Rh(Mtm)
33119 33119-25020 Plate, Stiffener, Lh(Mtm)
35013 35013-25030 Tube Sub-Assy, Transmission Oil Filler
35103 35103-25030 Gage Sub-Assy, Transmission Oil Level
35104 35104-30101 Case Sub-Assy, Automatic Transmission
35104 90341-08001 Plug, Transaxle Case, No.1
35104 90930-03098 Plug, Breather, No.1 (Atm)
35104 90930-03099 Plug, Breather, No.1 (Atm)
35104 90445-11096 Hose (For Breather Plug)
35106 35106-28030 Pan Sub-Assy, Automatic Transmission Oil
35106 35106-30051 Pan Sub-Assy, Automatic Transmission Oil
35106 90341-10006 Plug (For Transfer Oil Pan)
35106 90341-10011 Drain Plug (No Type)
35106 35178-30010 Drain Plug Gasket
35106 90119-06117 Bolt (For Automatic Transmission Oil Pan)
35106 90119-06173 Bolt, Stud (For Automatic Transmission Oil Pan Setting)
35111 35111-26030 Housing, Automatic Transmission
35111 90301-99054 Ring, O (For Automatic Transmission Housing)
35111 90301-06196 O Ring, Transaxle Case, No.1
35143 35143-22010 Cover, Transmission Case, Rear
35144 35144-28010 Gasket, Transmission Case Rear Cover
35168 35168-22011 Gasket, Automatic Transmission Oil Pan
35336 90301-09173 Ring, O(For Transmission Oil Filler Tube)
35394 35394-30011 Magnet, Oil Cleaner (For Transmission)
9010510190 90105-10190 New Genuine Part
9010512144 90105-12144 New Genuine Part
9161160814 91611-60814 Bolt
9161161030 91611-61030 Bolt (For Transmission Control Cable Bracket)
9161161030 91612-61030 Bolt (For Transmission Control Cable Bracket)
9161261045 91612-61045 Bolt(For Transaxle & Engine Setting)
9161961250 91619-61250 Bolt
9161961255 91619-61255 Bolt(For Transaxle & Engine Setting)
9165161032 91651-61032 BOLT
9322016012 93220-16012 SCREW
9613230400 96132-30400 Clip Or Clamp(For Ventilation Hose)
9613230400 96132-51000 Clip Or Clamp(For Ventilation Hose)
Transmission Gear (Mtm) ([05.1995 - ] G54 (9505- )LY10#,11#,201,YY101,201..MTM..ST..125 ,1T) 87
#OEMPart name
33311 33301-35071 Shaft, Input
33311 90363-32024 Bearing (For Input Shaft Front)
33311 90520-30214 Ring, Shaft Snap (For Front Bearing)
33311 90520-30215 Ring, Shaft Snap (For Front Bearing)
33311 90520-30216 Ring, Shaft Snap (For Front Bearing)
33311 90520-30217 Ring, Shaft Snap (For Front Bearing)
33311 90520-30218 Ring, Shaft Snap (For Front Bearing)
33311 90520-30219 Ring, Shaft Snap (For Front Bearing)
33311 90361-06002 Bearing, Input Shaft
33311 90520-76002 Ring, Shaft Snap (For Front Bearing)
33318 33318-35030 Piece, Gear Spline, No.5
33321 33321-26050 Shaft, Output
33321 90363-30059 Bearing (For Input Shaft Front)
33321 90520-25005 Ring, Shaft Snap (For Output Shaft Bearing)
33321 90520-25006 Ring, Shaft Snap (For Output Shaft Bearing)
33321 90520-25009 Ring, Shaft Snap (For Output Shaft Bearing)
33321 90520-25010 Ring, Shaft Snap (For Output Shaft Bearing)
33321 90520-25011 Ring, Shaft Snap (For Output Shaft Bearing)
33321 90520-25012 Ring, Shaft Snap (For Output Shaft Bearing)
33321 90520-25013 Ring, Shaft Snap (For Output Shaft Bearing)
33321 90520-25014 Ring, Shaft Snap (For Output Shaft Bearing)
33321 90520-25015 Ring, Shaft Snap (For Output Shaft Bearing)
33321 90520-25016 Ring, Shaft Snap (For Output Shaft Bearing)
33321 90520-25017 Ring, Shaft Snap (For Output Shaft Bearing)
33321 90520-71221 Ring, Shaft Snap (For Front Bearing)
33321 90520-28010 Ring, Shaft Snap (For Clutch Hub Set)
33321 90520-28011 Ring, Shaft Snap (For Clutch Hub Set)
33321 90520-28012 Ring, Shaft Snap (For Clutch Hub Set)
33321 90520-28013 Ring, Shaft Snap (For Clutch Hub Set)
33321 90520-28245 Ring, Shaft Snap (For Output Shaft Bearing)
33321 90520-28246 Ring, Shaft Snap (For Output Shaft Bearing)
33321 90520-28248 Ring, Shaft Snap (For Output Shaft Bearing)
33331 33331-35061 Gear, Reverse
33331 33331-71010 Gear, Reverse
33332 33033-26021 Gear, 2Nd
33332 90364-38002 Bearing, Needle Roller (For 2Nd Gear)
33333 33034-35050 Gear, 3Rd
33333 90364-35005 Bearing, Needle Roller (For 2Nd Gear)
33335 33032-26030 Gear, 1St
33335 90364-39011 Bearing, Needle Roller(For 1St Gear)
33336 33336-28020 Gear, 4Th
33349 33349-35010 Washer, 5Th Gear Thrust
33355 33355-35020 Race, 1St Gear Bearing Inner
33355 90360-06004 Ball, Detent(For Gear Shift Head No.4)
33355 90080-36191 Ball, Check Valve
33361 33361-35020 Hub, Transmission Clutch, No.1
33362 33362-35040 Hub, Transmission Clutch, No.2
33364 33364-26020 Sleeve, Transmission Hub, No.2
33365 33365-35020 Key, Synchromesh Shifting, No.1
33365 33365-35021 Key, Synchromesh Shifting, No.1
33366 33366-35040 Key, Synchromesh Shifting, No.2
33366 33366-35041 Key, Synchromesh Shifting, No.2
33367 33367-14010 Ring, Synchronizer, No.1
33368 33368-20012 Ring, Synchronizer, No.1
33371 33371-14031 Spring, Synchromesh Shifting Key, No.1
33377 33394-30011 Key, Synchromesh Shifting (For No.3 Clutch Hub)
33391 33371-14010 Spring, Synchromesh Shifting Key, No.1
33395 33395-35020 Sleeve, Transmission Hub, No.3
33395 33395-35060 Sleeve, Transmission Hub, No.3
33402 33402-35050 Gear Sub-Assy, Reverse Idler
33402 33402-60040 Gear Sub-Assy, Reverse Idler
33411 90365-25023 Bearing Or Roller(For Counter Gear Front)
33411 90520-49222 Ring, Counter Gear Front Bearing Snap, No.1
33411 90365-31006 Bearing, Counter Shaft Center
33411 90520-23089 Ring, Shaft Snap (For Input Shaft)
33411 90520-23090 Ring, Shaft Snap (For Output Shaft Bearing)
33411 90520-23115 Ring, Shaft Snap (For Output Shaft Bearing)
33411 90520-23143 Ring, Shaft Snap (For Output Shaft Bearing)
33411 90520-23144 Ring, Shaft Snap (For Input Shaft)
33411 90520-23145 Ring, Shaft Snap (For Output Shaft Bearing)
33421 33421-26140 Gear, Counter
33421 90520-19008 Ring, Shaft Snap
33421 90520-19009 Ring, Shaft Snap
33421 90520-19010 Ring, Shaft Snap
33421 90520-19011 Ring, Shaft Snap
33421 90520-19012 Ring, Shaft Snap
33421 90520-19013 Ring, Shaft Snap
33421 90520-19014 Ring, Snap, Counter Gear Rear Bearing
33428 33046-35062 Gear Sub-Assy, Countershaft, 4Th
33428 90364-26002 Bearing(For Countershaft 4Th Gear)
33451 33451-28010 Shaft, Reverse Idler Gear
33451 33451-28011 Shaft, Reverse Idler Gear
33452 33452-36030 Stopper, Reverse Idler Gear Shaft
33481 33481-20090 Gear, Speedometer Drive (Mtm)
33481 90520-26061 Ring Or Spacer (For Mtm Speedometer Drive Gear)
9161160820 91611-60820 Bolt(For Transaxle & Engine Setting)
9161160820 91611-G0820 Bolt
V-Belt ([05.1995 - ] (9505- )) 3
#OEMPart name
16361 90916-02211 Belt, V(For Fan & Alternator)
44310 99332-00850 Belt, V(For Vane Pump)
88310 99332-11265 Belt, V (Cooler Compressor To Crankshaft Pulley), No.1
Vacuum Pump ([05.1999 - ] (9905- )5L) 27
#OEMPart name
29300 29300-54180 Pump Assy, Vacuum
29300 90923-02118 Hose, Vacuum Pump Oil Inlet
29300 29611-54050 Hose, Vacuum Pump Oil Outlet
29314 29314-64030 Ring, Stop
29322 90099-10199 Bearing(For Alternator Drive End Frame)
29331 29331-54130 Blade, Vacuum Pump, A
29336 29336-64031 Shaft, Vacuum Pump
29341 29341-64030 Seal, Vacuum Pump Oil
29342 29342-64030 Packing, Vacuum Pump
29364 29364-66010 Washer, Vacuum Pump
29366 29366-54110 Pulley, Vacuum Pump
29369 29369-64030 Valve Sub-Assy, Check
2932164030 29321-64030 Ring, Oil Seal Stop, Vacuum Pump
9009900166 90099-00166 New Genuine Part
9009904577 90099-04577 New Genuine Part
9009905171 90099-05171 Nut(For Alternator Pulley)
9020114099 90201-14099 Gasket(For Vacuum Pump Union)
9040109001 90401-09001 Bolt, Union(For Vacuum Pump Union)
9040109001 90401-09003 Bolt, Union(For Vacuum Pump Union)
9040414016 90404-14016 New Genuine Part
9040451012 90404-51012 UNION VACCUM HOSE
9043010020 90430-10020 GASKETROUND TYPE
9046716016 90467-16016 Clamp Or Crip, Hose
9046716016 90467-15018 Clamp Or Crip, Hose
9331914012 93319-14012 New Genuine Part
9331915012 93319-15012 Screw
9634111000 96341-11000 Bolt, Union(For Turbo Oil Inlet Pipe)
Valve Body & Oil Strainer (Atm) ([10.1996 - ] A44DE,A44DF (9610- )LY10#,11#,16#..ATM) 103
#OEMPart name
35151 35151-30020 Cover, Transmission Case, Lower
35153 35153-30010 Gasket, Transmission Case Lower Cover
35208 35208-26010 Spring Sub-Assy, B-2 Accumulator
35208 90521-22004 Ring, Hole Snap (For B-3 Accumulator Spring)
35212 35202-30010 Valve, Lock Up Relay
35212 90501-10113 Spring, Compression (For Lock Up Signal Valve)
35215 90250-04027 Pin, Straight (For Lock Up Signal Valve)
35215 35215-30013 Sleeve, Lock Up Relay Valve
35222 35222-30010 Plate, Lock Up Relay Valve Body
35223 35223-30010 Gasket, Lock Up Relay Valve Body
35303 35303-30060 Strainer Sub-Assy, Oil
35339 35339-28030 Gasket, Oil Strainer
35408 35408-22040 Plug Sub-Assy, Primary Down Shift
35408 90501-11011 Spring, Compression (For Primary Down Shift Plug)
35409 35409-30010 Spring Sub-Assy, Manual Detent
35415 35203-30011 Valve, Pressure Regulator
35415 90501-17031 Spring, Compression (For Pressure Regulator Valve)
35416 35416-14010 Plunger, Primary Regulator Valve, No.1
35417 35417-14010 Sleeve, Pressure Regulator Valve
35418 35418-30060 Valve, Manual
35419 35419-22010 Valve, Check, No.1
35419 90501-16083 Spring, Compression (For Check Valve)
35420 35496-22030 Ball (For Lower Valve Body)
35420 90501-04727 Spring (For Lower Valve Body)
35420 35420-25010 Body Assy, Lower Valve
35420 90360-13024 Ball (For Pressure Relief)
35420 90501-18677 Spring (For Pressure Relief)
35421 35421-26010 Piston, Accumulator, No.1
35421 90301-29011 Ring (For Accumulator Piston No.1)
35421 90301-23010 Ring (For Accumulator Piston No.1)
35421 35441-30010 Piston, Accumulator, No.2
35421 90301-26012 Ring (For Accumulator Piston No.1)
35421 90301-18010 Ring (For Accumulator Piston No.2)
35421 35421-22030 Piston, Accumulator, No.3
35421 90301-21012 Ring (For Accumulator Piston No.3)
35422 35422-22010 Stopper, Valve Vibrating
35423 90501-25033 Spring, Compression (For Accumulator Piston No.1)
35424 90501-20063 Spring Sub-Assy, C-1 Accumulator
35425 90501-27013 Spring, Compression (For Accumulator Piston No.2)
35425 35425-14010 Seat, Pressure Regulator Valve Sleeve
35427 35427-30020 Seat (For Pressure Relief)
35430 35430-30120 Body Assy, Rear Upper Valve
35430 90360-06023 Ball (For Rear Upper Valve Body)
35432 35432-25030 Plate, Valve Body, No.1
35433 35433-22041 Gasket, Valve Body, No.1
35434 35434-22041 Gasket, Valve Body, No.2
35435 35435-30040 Gasket, Valve Body Plate, No.3
35436 35436-30050 Gasket, Valve Body Plate, No.4
35440 35440-28120 Body Assy, Front Upper Valve
35443 35443-22010 Sleeve, Down Shift Plug
35443 90250-03034 Pin (For Down Shift Plug Sleeve)
35444 35444-22010 Valve, Intermediate Modulator
35444 90501-09686 Spring, Compression (For Intermediate Modulator Valve)
35445 90501-11009 Spring, Compression (For Intermediate Modulator Valve)
35447 35447-30010 Valve, Reverse Clutch Sequence
35447 90501-12726 Spring, Compression (For Reverse Clutch Sequence Valve)
35456 35456-30050 Valve, 2-3 Shift
35456 90501-09028 Spring, Compression (For 2-3 Shift Valve)
35456 90339-05014 Plug, Low-High Signal Valve
35458 35458-30020 Valve, Cut Back
35458 35459-22010 Plug (For Cut Back Valve)
35458 35493-22010 Seat (For Cut Back Valve)
35458 90501-06022 Spring, Compression (For Cut Back Valve)
35462 35462-22011 Valve, Throttle
35462 90501-07129 Spring, Compression (For Throttle Valve)
35462 90523-06023 Ring, E (For Throttle Valve)
35464 35464-30030 Valve, 1-2 Shift
35468 35204-30010 Valve, Secondary Regulator
35468 90501-19001 Spring, Compression (For Secondary Regulator Valve)
35469 35469-30020 Plug, 3-2 Kick Down Orifice Control Valve
35469 90361-02051 Seat, Shift Valve Plug
35472 35472-30010 Cover, Valve Body, No.2
35473 35473-22010 Cover, Transmission Valve Body
35475 35475-30040 Cover, Valve Body, No.5
35487 35487-30010 Ball, Check, No.4
35487 90504-05006 Spring, Compression (For Check Ball)
35493 35493-30030 Seat(For Center Differential Clutch Control Valve Plug)
35497 35497-30030 Valve, 3-4 Shift
35521 35521-22051 Cam, Throttle Valve
35521 90508-12331 Spring (For Throttle Valve Cam Return)
35521 90201-06472 Washer (For Throttle Valve Cam Set)
35522 35522-22010 Pin, Throttle Valve Cam
35599 35599-30010 Cover, Manual Detent Spring
35847 35847-30010 Tube, Transmission Lube Apply
35892 35892-26010 Tube, Overdrive Brake
35895 35895-30030 Tube, Front Clutch Apply
35897 35897-30010 Tube, 1St & Reverse Brake, No.1
9010505001 90105-05001 New Genuine Part
9010505002 90105-05002 New Genuine Part
9010505003 90105-05003 Bolt (For Pressure Regulator Valve No.2)
9010505003 90119-05035 Bolt (For Pressure Regulator Valve No.2)
9010505004 90105-05004 New Genuine Part
9010505005 90105-05005 Bolt (For Transfer Relief Valve Plate)
9010505009 90105-05009 New Genuine Part
9010505033 90105-05033 New Genuine Part
9010506014 90105-06014 New Genuine Part
9010506015 90105-06015 New Genuine Part
9010506017 90105-06017 Bolt(for Cylinder Head Cover)
9010506017 91551-A0625 Bolt(For Cylinder Head Cover)
9010506018 90105-06018 Bolt (For Throttle Valve Cam Set)
9010506020 90105-06020 New Genuine Part
9010506020 91511-C0630 New Genuine Part
9011905023 90119-05023 New Genuine Part
Vane Pump & Reservoir (Power Steering) ([05.1995 - ] (9505- )LY10#,11#,20#,21#) 63
#OEMPart name
4446 04446-26030 Gasket Kit, Power Steering Pump
40140 40140-30151 Pump Assy,vane Rebuilt
40140 44320-30151 Pump Assy, Vane
44039 44039-25010 Bracket Sub-Assy, Oil Reservoir
44302 44302-30110 Housing Sub-Assy, Vane Pump, Front
44302 90301-60001 Ring, O, No.1(For Vane Pump Housing)
44302 96711-19016 Ring, O (For 5Th Shift Arm Shaft)
44302 90311-17004 Seal, Oil, No.2(For Vane Pump Housing)
44302 90521-51003 Ring, Snap, No.1(For Vane Pump Housing)
44302 90313-23001 Seal, Oil, No.3(For Vane Pump Housing)
44304 44304-30051 Housing Sub-Assy, Vane Pump, Rear
44305 44305-32010 Cap Sub-Assy, Vane Pump Oil Reservoir
44308 44308-30060 Union Sub-Assy, Pressure Port
44311 44311-30150 Pulley, Vane Pump
44311 90178-12003 Nut(For Vane Pump Pulley)
44312 44312-28010 Shaft, Vane Pump
44312 90363-17011 Bearing(For Vane Pump Shaft)
44312 90363-17017 Bearing(For Vane Pump Shaft)
44312 90520-15005 Ring, Snap, No.1(For Vane Pump Shaft)
44313 44313-22040 Rotor, Vane Pump
44313 44313-22050 Rotor, Vane Pump
44313 44313-22060 Rotor, Vane Pump
44313 44313-22070 Rotor, Vane Pump
44313 44313-22080 Rotor, Vane Pump
44326 44325-12010 Ring, Cam(For Vane Pump)
44326 44325-12020 Ring, Cam(For Vane Pump)
44326 44325-12030 Ring, Cam(For Vane Pump)
44326 44325-12040 Ring, Cam(For Vane Pump)
44326 44325-12050 Ring, Cam(For Vane Pump)
44326 90250-05008 Pin, Straight(For Vane Pump Cam Ring)
44330 44330-32130 Valve Assy, Flow Control
44330 44330-32670 Valve Assy, Flow Control
44330 44330-32140 Valve Assy, Flow Control
44330 44330-32680 Valve Assy, Flow Control
44330 44330-32150 Valve Assy, Flow Control
44330 44330-32690 Valve Assy, Flow Control
44330 44330-32160 Valve Assy, Flow Control
44330 44330-32700 Valve Assy, Flow Control
44330 44330-32170 Valve Assy, Flow Control
44330 44330-32710 Valve Assy, Flow Control
44330 44330-32180 Valve Assy, Flow Control
44330 44330-32720 Valve Assy, Flow Control
44330 90501-12103 Spring, Compression(For Flow Control Valve)
44330 96151-01700 Ring, Snap(For Flow Control Valve)
44337 44337-30010 Union, Power Steering Suction Port
44337 96711-19013 Ring, O(For Power Steering Suction Port)
44338 90301-22001 Ring, O(For Pressure Port Union)
44338 96711-19014 O-Ring
44342 44341-12010 Plate, Vane Pump Side, Front
44342 90301-53002 Ring, O(For Vane Pump Side Plate Rear)
44342 90501-23014 Spring, Compression(For Vane Pump Side Plate Rear)
44343 44343-12040 Seat, Flow Control Spring
44345 44345-12010 Plate, Vane Pump
44345 44345-12020 Plate, Vane Pump
44345 44345-12030 Plate, Vane Pump
44345 44345-12040 Plate, Vane Pump
44345 44345-12050 Plate, Vane Pump
44360 44360-26030 Reservoir Assy, Vane Pump Oil
9011910072 90119-10072 New Genuine Part
9161160814 91611-60814 Bolt
9161160816 91611-60816 Screw Or Bolt(For Valve Rocker Shaft Lock)
9161160816 91611-B0816 Bolt
9165140614 91651-40614 Bolt
Ventilation Hose ([05.1995 - ] (9505- )3L,5L) 2
#OEMPart name
12261 12261-54100 Hose, Ventilation
12261 90467-18003 Clip Or Clamp(For Ventilation Hose)
Water Pump ([05.1995 - ] (9505- )3L,5L) 13
#OEMPart name
16100 16100-59255 Pump Assy, Engine Water
16100 16100-59257 Pump Assy, Engine Water
16171 16171-75020 Seat, Water Pump Pulley
16210 16210-54220 Coupling Assy, Fluid
16210 16210-54150 Coupling Assy, Fluid
16241 92122-60818 Bolt, Stud(For Water Pump Pulley Seat)
16271 16271-54020 Gasket, Water Pump
16271 16271-54030 Gasket, Water Pump
16371 16371-54030 Pulley, Fan
9010508176 90105-08176 BOLT
9017908123 90179-08123 Nut (For Front Wiper Arm Setting)
9017908150 90179-08150 NUT
9025311001 90253-11001 Pin, Ring(For Camshaft Bearing Cap Setting)
Windshield Washer ([05.1995 - ] (9505- )) 21
#OEMPart name
85301 85301-17010 Inlet Sub-Assy, Washer
85310 85310-22080 Motor And Pump Assy, Windshield Washer
85330 85315-37030 Jar Assy, Windshield Washer
85330 90099-32089 Bush, Headlamp Cleaner Washer Jar
85330 90068-32002 Bush, Windshield Washer Jar
85336 85336-20340 Packing, Windshield Washer Jar
85342 85342-95J01 Holder, Washer Nozzle
85345 85381-37020 Nozzle Sub-Assy, Washer
85348 85349-89122 Valve Sub-Assy, Washer
85348 85375-20800 Joint, Windshield Washer Hose, No.1
85348 85378-33030 Joint, Windshield Washer Hose, No.1
85355 85355-14481 Joint, Windshield Washer Elbow, No.1
85371 90446-07001 Hose, Windshield Washer (From Motor To Joint)
85372 90099-59135 Hose, Windshield Washer (From Joint To Joint), No.1
85372 90446-06013 Hose, Windshield Washer (From Motor To Joint)
85373 90099-33080 Hose, Windshield Washer (From Motor To Joint)
85373 90099-33299 Joint, Windshield Washer Elbow, No.2
85383 85383-37010 Holder, Front Washer Nozzle
827111 82711-1A240 Wire, Fuse To Fuse(for Combustion Heater)
9015960413 90159-60413 SCREW WWASHER
9017906110 90179-06110 New Genuine Part
Windshield Wiper ([05.1995 - ] (9505- )) 22
#OEMPart name
85070 85070-37010 Motor & Bracket Assy, Front Wiper
85070 85070-37060 Motor & Bracket Assy, Front Wiper
85154 85154-37010 Packing, Front Wiper Shaft
85160 85150-37030 Link Assy, Wiper
85211 85211-37050 Arm, Front Wiper, Rh
85212 85212-37050 Blade, Fr Wiper, Rh
85212 85212-37051 Blade, Fr Wiper, Rh
85214 85214-10120 Rubber, Wiper, Rh
85214 85214-12301 Rubber, Wiper, Rh
85221 85221-37080 Arm, Front Wiper, Lh
85222 85222-37080 Blade, Fr Wiper, Lh
85222 85222-37081 Blade, Fr Wiper, Lh
85224 85224-35050 Plate, Wiper Rubber Backing, No.1
85224 85224-35060 Plate, Wiper Rubber Backing, No.3
85224 85224-10190 Plate, Wiper Rubber Backing, No.1
85291 85291-60060 Blade Assy, Windshield Wiper
85291 85291-44080 Blade Assy, Windshield Wiper
85291 85291-60070 Blade Assy, Windshield Wiper
85292 85292-37010 Cover, Windshield Wiper Arm
9017908209 90179-08209 Nut (For Front Wiper Arm Setting)
9163560618 91635-60618 New Genuine Part
9163560618 91631-B0614 BOLT WWASHER
Wiring & Clamp ([05.1995 - ] ｴﾝｼﾞﾝ ﾜｲﾔ (9505- )LY10#,11#,12#,13#,15#,16#) 12
#OEMPart name
82060 82060-26015 Wire Assy, Engine, No.2
82060 82060-25052 Wire Assy, Engine, No.2
82121 82121-26314 Wire, Engine
82121 82121-26304 Wire, Engine
82210 90982-08189 Fusible Link
82210 90982-08202 Fusible Link
82210 90982-08203 Fusible Link
82261 82261-25021 Wire, Alternator
82823 82823-22050 Cap, Terminal, No.1
9011908827 90119-08827 New Genuine Part
9017906158 90179-06158 Nut, Rear Wiper Link Pivot, No.2
9165160616 91651-60616 BOLT
Wiring & Clamp ([05.1995 - ] ｴﾝｼﾞﾝ ﾜｲﾔ ｸﾗﾝﾌﾟ & ﾌﾞﾗｹﾂﾄ (9505- )LY10#,11#,12#,13#,15#,16#) 43
#OEMPart name
827112 82711-2A620 Wire, Fuse To Fuse(for Combustion Heater)
827112 82711-2B660 Clamp, Wiring Harness
827113 82711-3A740 Clamp, Headlamp Cleaner, No.1
827113 82711-16830 Clamp, Headlamp Cleaner, No.1
8271195 82711-95A07 Wire, Fuse To Fuse(for Combustion Heater)
8271195 82711-95A08 Wire, Fuse To Fuse(for Combustion Heater)
8271195 82711-95A09 Wire, Fuse To Fuse(for Combustion Heater)
8271195 82711-95J26 Wire, Fuse To Fuse(for Combustion Heater)
8271114110 82711-14110 Clamp(For Hood Lock Control Cable)
8271122270 82711-22270 Clamp(For Transfer Vacuum Tube)
8271125060 82711-25060 Wire, Fuse To Fuse(for Combustion Heater)
8271125140 82711-25140 Wire, Fuse To Fuse(for Combustion Heater)
8271130130 82711-30130 Wire, Fuse To Fuse(for Combustion Heater)
8271130370 82711-30370 Wire, Fuse To Fuse(for Combustion Heater)
8271137050 82711-37050 Wire, Fuse To Fuse(for Combustion Heater)
8271140020 82711-40020 Wire, Fuse To Fuse(for Combustion Heater)
8271195410 82711-95410 Clamp, Choke Cable
8271195411 82711-95411 Clamp(For Vacuum Tube Connector Hose)
8271195422 82711-95422 Wire, Fuse To Fuse(for Combustion Heater)
8271525040 82715-25040 Bracket,wiring Harness Clamp
8271525070 82715-25070 Bracket,wiring Harness Clamp
8271525150 82715-25150 Bracket,wiring Harness Clamp
8271525160 82715-25160 Bracket,wiring Harness Clamp
8271525190 82715-25190 Bracket,wiring Harness Clamp
8271525200 82715-25200 Bracket,wiring Harness Clamp
8271525220 82715-25220 Bracket,wiring Harness Clamp
8271530500 82715-30500 Bracket,wiring Harness Clamp
8271537300 82715-37300 Bracket,wiring Harness Clamp
8271589107 82715-89107 Bracket,wiring Harness Clamp
9011908826 90119-08826 BOLT
9017908144 90179-08144 New Genuine Part
9017908144 90179-08233 NUT
9046110294 90461-10294 Wire, Fuse To Fuse(for Combustion Heater)
9046110294 82711-37290 Wire, Fuse To Fuse(for Combustion Heater)
9162140812 91621-40812 BOLT
9165140814 91651-40814 BOLT
9165140814 90080-11228 New Genuine Part
9165160616 91651-60616 BOLT
9165160816 91651-60816 BOLT
9165160816 90080-11396 Bolt
9165160820 91651-60820 Bolt, Radiator Side Support Plate
9165160820 91651-B0820 Bolt, Radiator Side Support Plate
9165260816 91652-60816 New Genuine Part
Wiring & Clamp ([05.1995 - ] ｶｳﾙ & ｲﾝﾊﾟﾈ ﾜｲﾔ (9505- )) 26
#OEMPart name
82131 82131-25641 Wire, Cowl
82131 82131-25651 Wire, Cowl
82131 82131-25701 Wire, Cowl
82131 82131-25711 Wire, Cowl
82141 82141-25011 Wire, Instrument Panel
82141 82141-37211 Wire, Instrument Panel
827112 82711-2B640 Wire, Fuse To Fuse(for Combustion Heater)
8266637040 82666-37040 Holder, Connector No.2
8266637070 82666-37070 Holder, Connector No.3
8271132610 82711-32610 Wire, Fuse To Fuse(for Combustion Heater)
8271137080 82711-37080 Wire, Fuse To Fuse(for Combustion Heater)
8271137090 82711-37090 Wire, Fuse To Fuse(for Combustion Heater)
8271237010 82712-37010 Pad, Front Panel Cover
8271537300 82715-37300 Bracket,wiring Harness Clamp
8271537350 82715-37350 Bracket,wiring Harness Clamp
8271537470 82715-37470 Bracket,wiring Harness Clamp
8281995402 82819-95402 Grommet, Wiring Harness
9011906390 90119-06390 BOLT WWASHER
9011906595 90119-06595 BOLT WWASHER
9015960437 90159-60437 New Genuine Part
9046706121 90467-06121 Clip, Rear Bumper Side
9095006001 90950-06001 Protector, Front Side Panel, No.3
9162140616 91621-40616 Step Cover Bolt
9356715016 93567-15016 New Genuine Part
9356715016 93568-55016 Screw
9359056014 93590-56014 New Genuine Part
Wiring & Clamp ([05.1995 - ] ｹ-ﾌﾞﾙ ﾎﾞﾝﾄﾞ (9505- )DSL) 6
#OEMPart name
82001 90980-07299 Cable, Bond, No.1
82001 90980-07353 Cable, Bond, No.1
8271112200 82711-12200 Clamp (For Fuel Lid Lock Control Cable)
9011908103 90119-08103 New Genuine Part
9165160816 91651-60816 BOLT
9165160816 90080-11396 Bolt
Wiring & Clamp ([05.1995 - ] ﾄﾞｱ, ﾙ-ﾌ & ﾌﾛｱ ﾜｲﾔ (9505- )) 18
#OEMPart name
82151 82151-25080 Wire, Front Door, Rh
82151 82151-37080 Wire, Front Door, Rh
82151 82151-37090 Wire, Front Door, Rh
82152 82152-25060 Wire, Front Door, Lh
82152 82152-37130 Wire, Front Door, Lh
82152 82152-37140 Wire, Front Door, Lh
82171 82171-37062 Wire, Roof, No.1
82171 82171-37081 Wire, Roof, No.1
82817 82817-28640 Protector, Wiring Harness, No.1
82821 82821-37020 Cover, Connector
82821 82821-37030 Cover, Connector
827112 82711-2B660 Clamp, Wiring Harness
827113 82711-3H370 Clamp, Headlamp Cleaner, No.1
827113 82711-16830 Clamp, Headlamp Cleaner, No.1
8271122270 82711-22270 Clamp(For Transfer Vacuum Tube)
8271237010 82712-37010 Pad, Front Panel Cover
9046308124 90463-08124 Clamp(For Oil Pipe)
9048030320 90480-30320 New Genuine Part
Wiring & Clamp ([05.1995 - ] ﾎﾞﾃﾞ- ﾜｲﾔ (9505- )) 26
#OEMPart name
82164 82164-26123 Wire, Frame
82164 82164-26053 Wire, Frame
8271195 82711-95A06 Wire, Fuse To Fuse(for Combustion Heater)
9011908 90119-08A46 BOLT WWASHER
8271112200 82711-12200 Clamp (For Fuel Lid Lock Control Cable)
8271122270 82711-22270 Clamp(For Transfer Vacuum Tube)
8271125030 82711-25030 Wire, Fuse To Fuse(for Combustion Heater)
8271125100 82711-25100 Wire, Fuse To Fuse(for Combustion Heater)
8271137050 82711-37050 Wire, Fuse To Fuse(for Combustion Heater)
8271195015 82711-95015 Wire, Fuse To Fuse(for Combustion Heater)
8271195020 82711-95020 Wire, Fuse To Fuse(for Combustion Heater)
8271195422 82711-95422 Wire, Fuse To Fuse(for Combustion Heater)
8271528430 82715-28430 Bracket,wiring Harness Clamp
8271625010 82716-25010 Bracket, Wiring Harness Clamp, Lh
9011908827 90119-08827 New Genuine Part
9046108202 90461-08202 Clamp(For Brake Master Cylinder)
9046310012 90463-10012 New Genuine Part
9046310032 90463-10032 New Genuine Part
9046315003 90463-15003 New Genuine Part
9046400052 90464-00052 New Genuine Part
9161160820 91611-60820 Bolt(For Transaxle & Engine Setting)
9161160820 91611-G0820 Bolt
9165160816 91651-60816 BOLT
9165160816 90080-11396 Bolt
9165160820 91651-60820 Bolt, Radiator Side Support Plate
9165160820 91651-B0820 Bolt, Radiator Side Support Plate
Source
Public OEM parts-catalog data
Variants
2 / 13
Category
201
Collected
2026-08-03
