Search › Model › GZ20

GZ20

Toyota SOARER · 1986 · 4,814 parts · 176 categories
GZ20 ×

← Back to categories

4,814 items
Switch & Relay & Computer ([01.1988 - ] (8801- )) 151
#OEMPart name
81980 81980-12070 Flasher Assy, Turn Signal
81980 81980-32010 Flasher Assy, Turn Signal
82600 90982-07011 Fuse, Fuse Block
82600 90982-09002 Fusible Link
82600 90982-09003 Fusible Link
82600 90982-09004 Fusible Link
82600 90982-09005 Fuse, Fuse Block
82600 82683-24030 Plate, Caution(For Fuse)
82616 82616-12020 Puller, Fuse
82641 82641-24020 Relay, Integration No.1
82650 82650-20011 Breaker Assy, Wiring Circuit, No.1
82650 82650-20020 Breaker Assy, Wiring Circuit, No.1
82671 82671-20030 Block Assy, Junction, No.1
82671 82671-24010 Block Assy, Junction, No.1
82671 82671-24030 Block, Junction
82672 82672-24010 Cover, Relay Block, No.1
82672 82672-24050 Cover, Junktion Block
83320 83320-80052 Gage Assy, Fuel Sender
83361 83361-20030 Gasket, Fuel Tank Vent
83420 83420-20020 Gage Assy, Water Temperature Sender
83530 83530-30050 Switch Assy, Oil Pressure (For Engine)
83530 83530-60050 Switch Assy, Oil Pressure (For Engine)
83650 90986-01003 Fusee
84052 84052-10020 Switch Assy, Un-Lock Warning
84052 84052-22030 Switch Assy, Un-Lock Warning
84110 84112-29865 Switch Assy, Light Control, No.1
84110 84112-29875 Switch Assy, Light Control, No.1
84140 84140-20310 Switch Assy, Headlamp Dimmer
84140 84140-20340 Switch Assy, Headlamp Dimmer
84140 84140-20410 Switch Assy, Headlamp Dimmer
84162 84160-24010 Switch, Front Fog Lamp
84210 84210-30060 Switch Assy, Back-Up Lamp
84233 84231-12070 Switch Assy, Courtesy Lamp (For Front Door)
84233 84231-24010 Switch Assy, Courtesy Lamp (For Front Door)
84236 84231-24020 Switch Assy, Courtesy Lamp(For Luggage Compartment Room)
84242 84242-20030 Switch Assy, Courtesy Lamp (For Glove Box)
84310 84310-24210 Switch Assy, Turn Signal
84310 84310-24220 Switch Assy, Turn Signal
84310 84310-24260 Switch Assy, Turn Signal
84312 84312-12040 Plate, Horn Contact
84312 84312-12050 Plate, Horn Contact
84315 84315-24070 Slipring, Horn Contact
84315 84315-24080 Slipring, Horn Contact
84329 84329-20050 Switch, Turn Signal
84330 84332-24020 Switch Assy, Hazard Warning Signal
84340 84340-22100 Switch Assy, Stop Lamp
84340 84340-30030 Switch Assy, Stop Lamp
84340 84340-30050 Switch Assy, Stop Lamp
84450 84450-14060 Switch Assy, Ignition Or Starter
84450 84450-27100 Switch Assy, Ignition Or Starter
84450 84450-14070 Switch Assy, Ignition Or Starter
84540 84540-14130 Switch Assy, Neutral Start
84540 84540-22171 Switch Assy, Neutral Start
84550 84550-24030 Switch Assy, Parking Brake
84650 84652-24080 Switch Assy, Windshield Wiper
84650 84652-24150 Switch Assy, Windshield Wiper
84650 84652-24160 Switch Assy, Windshield Wiper
84650 84652-24170 Switch Assy, Windshield Wiper
84750 84750-24020 Switch Assy, Seat
84790 84790-24030 Switch Assy, Rear Window Defogger
84790 84999-10200 Bulb(For Cruise Control Switch)
84810 84810-32050 Switch Assy, Power Window Regulator
84810 84810-30130 Switch Assy, Power Window Regulator
84820 84820-14180 Master Switch Assy, Power Window Regulator
84870 84870-24020 Switch Assy, Outer Mirror
84870 84870-24030 Switch Assy, Outer Mirror
84931 84931-24020 Switch, Door Control
85432 85432-14010 Solenoid, Key Inter Lock
85500 85500-24020 Lighter Assy, Cigarette
85910 90987-04002 Relay, Ignition, No.1
85916 90987-02002 Relay, Ignition, No.1
85916 90987-02004 Relay Assy, Starter
85916 90987-02006 Relay
85933 85933-24010 Computer, Shift Lock Control
85980 85980-24040 Relay Assy, Door Control
85999 85999-24020 Bracket, Relay, No.2
85999 85999-24030 Bracket, Relay, No.3
87989 87989-24010 Relay, Mirror Control
88630 88630-24060 Relay Assy, Cooler
89373 89373-24060 Sensor, Lamp Failure Indicator
89425 89425-29425 Sensor, Exhaust Gas Temperature
89428 89428-22050 Switch, Temperature
89439 89439-24010 Bracket, Sensor
89465 89465-29175 Sensor, Oxygen
89465 89465-29176 Sensor, Oxygen
89466 89466-30030 Gasket, Oxygen Sensor
89466 89466-32010 Gasket, Oxygen Sensor
89615 89615-30020 Sensor, Knock Control
89620 89620-14410 Igniter Assy
89620 89620-22420 Igniter Assy
89629 89629-14050 Bracket, Igniter Assy
89650 89650-24030 Computer Assy, Power Steering
827111 82711-1B030 Wire, Fuse To Fuse(for Combustion Heater)
4561914010 45619-14010 Cover, Knuckle Stopper
8271114110 82711-14110 Clamp(For Hood Lock Control Cable)
8271114280 82711-14280 Wire, Fuse To Fuse(for Combustion Heater)
8271114750 82711-14750 Wire, Fuse To Fuse(for Combustion Heater)
8271124120 82711-24120 Wire, Fuse To Fuse(for Combustion Heater)
8271124190 82711-24190 Wire, Fuse To Fuse(for Combustion Heater)
8499910110 84999-10110 Bulb, Indicator Lamp
9011906005 90119-06005 New Genuine Part
9011906033 90119-06033 Bolt
9011906033 90119-06157 Bolt
9011906067 90119-06067 BOLT
9011906601 90119-06601 New Genuine Part
9015960081 90159-60081 SCREW
9016720002 90167-20002 New Genuine Part
9017906069 90179-06069 Direct
9017906069 90179-06274 Nut
9017908059 90179-08059 Nut
9017908059 90179-08101 NUT
9018906018 90189-06018 GROMMET
9043008252 90430-08252 Gasket(For Catalytic Converter Sensor Guide)
9043018007 90430-18007 Gasket(For Water Hole)
9043018007 90430-18008 Gasket
9046108312 90461-08312 New Genuine Part
9046108365 90461-08365 New Genuine Part
9046208008 90462-08008 New Genuine Part
9046312570 90463-12570 CLAMP
9046315402 90463-15402 New Genuine Part
9161160612 91611-60612 Bolt(For Dust Cover To Steering Knuckle Arm Setting)
9161160612 91611-G0612 Bolt
9161160812 91611-60812 Bolt(For Drive Plate & Torque Converter Setting)
9161160812 91611-B0812 Bolt
9161160814 91611-60814 Bolt
9161160816 91611-60816 Screw Or Bolt(For Valve Rocker Shaft Lock)
9161160816 91611-B0816 Bolt
9165140612 91651-40612 BOLT
9165140612 90080-11225 New Genuine Part
9165140614 91651-40614 Bolt
9165140830 91651-40830 Bolt, Radiator Side Support Plate
9165160616 91651-60616 BOLT
9165540614 91655-40614 Bolt (For Rear Differential Breather Plug Oil Deflector)
9165540614 91651-60614 Bolt
9165540616 91655-40616 Bolt
9165540620 91655-40620 Bolt(For Oil Receiver Pipe)
9165540620 91651-60618 Bolt(For Oil Receiver Pipe)
9166140612 91661-40612 New Genuine Part
9331514010 93315-14010 SCREW
9331514014 93315-14014 SCREW
9331913008 93319-13008 New Genuine Part
9331914010 93319-14010 SCREW
9331914012 93319-14012 New Genuine Part
9331915012 93319-15012 Screw
9338516025 93385-16025 New Genuine Part
9354044012 93540-44012 Screw, Front Body Pillar Garnish
9354054012 93540-54012 Screw, Headlamp
9356755014 93567-55014 Direct
9356755014 93568-55014 Screw
9412041000 94120-41000 Nut(For Clutch Pedal Stopper)
9412041000 90170-A0002 Nut
