| 35602-30041 |
Piston Sub-Assy, Front Clutch |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 35602-30042 |
Piston Sub-Assy, Front Clutch |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 35603-22030 |
Spring Sub-Assy, Forward Clutch Return |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 35605-30021 |
Drum Sub-Assy, Rear Clutch W/2Nd Sun Gear |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 35606-22010 |
Piston Sub-Assy, Rear Clutch |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 35615-30020 |
Seat, Clutch Piston Return Spring |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 35631-30050 |
Hub, Clutch(For Multiple Disc Clutch) |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 35634-22040 |
Plate, Clutch (For Overdrive) |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 35634-30070 |
Plate, Clutch (For Overdrive) |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 35654-30010 |
Hub, Rear Clutch |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 35675-22010 |
Flange, Overdrive Clutch |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 35675-22140 |
Flange, Overdrive Clutch |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 35677-30030 |
Disc, Clutch (For Overdrive) |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 35677-30160 |
Disc, Clutch (For Overdrive) |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 35701-30042 |
Shaft Sub-Assy, Input |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 35701-30043 |
Shaft Sub-Assy, Input |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 35789-22010 |
Race, Thrust Bearing(For Overdrive Planetary Gear) |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 35789-22020 |
Race, Thrust Bearing (For Rear Planetary Ring Gear Rear) |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 35789-22050 |
Race, Thrust Bearing (For Rear Planetary Ring Gear Front) |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 90301-56007 |
Ring, O (For Underdrive Clutch Piston) |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 90301-57188 |
Ring, O (For Underdrive Clutch Piston) |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 90301-83001 |
Ring, O (For Rear Clutch Piston) |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 90301-84184 |
Ring, O (For Transfer Low Speed Brake Piston) |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 90301-99016 |
Ring, O (For Overdrive Direct Clutch Piston) |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 90374-23012 |
Bearing, Thrust Needle Roller(For Overdrive Planetary Gear) |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 90374-28014 |
Bearing, Thrust Needle Roller(For Overdrive) |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 90501-10671 |
Spring, Compression (For Overdrive Direct Clutch) |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 90501-11023 |
Spring, Compression (For Overdrive Direct Clutch) |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 90520-39261 |
Ring, Shaft Snap (For Front Clutch Piston Return Spring) |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 90520-99012 |
Ring, Hole Snap (For Front Multiple Disc Clutch) |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 90521-99139 |
Ring, Hole Snap (For Overdrive Brake Return Spring Seat) |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
| 90521-99146 |
Ring, Hole Snap, No.1 (For Overdrive) |
Brake Band & Multiple Disc Clutch (Atm) ([01.1988 - ] A42DL (8801- )4FC..VX) |
