Abs modulator 4

#	OEM	部品名
1	57101-TA0-003	Rubber - MOUNT
2	57110-TM0-T01	Modulator assy - ABS
3	57115-TF0-000	Bracket - MODULATOR (ABS)
4	57376-SNA-A00	Bolt - MOUNTING

Air cleaner 29

#	OEM	部品名
1	17136-REJ-W00	Grommet - BREATHER PIPE
2	17201-RB0-000	Case set - AIR CLEANER
3	17202-RB0-000	Chamber set - AIR CLEANER
4	17210-RB0-000	Cover comp. AIR CLEANER
5	17211-RB1-J60	Stay comp. b - AIR CLEANER
6	17211-RB1-000	Stay comp. b - AIR CLEANER
7	17212-PN3-000	Rubber, AIR CLEANER MOUNTING
7	17212-P2J-J00	Rubber, AIR CLEANER MOUNTING
8	17212-RB0-000	Tube - AIR CLEANER
9	17213-RB0-000	Bracket - AIR CLEANER
10	17214-RB0-000	Stay - AIR CLEANER
11	17215-RB0-000	Stay comp. a - AIR CLEANER
12	17216-PN3-000	Collar - AIR CLEANER MOUNTING
13	17217-PN4-300	Clip - WIRE
14	17217-P2J-300	Clip - AIR CLEANER
15	17218-PN4-300	Collar - CLIP BRACKET
16	17219-P65-000	Clip - AIR CLEANER
17	17220-RB6-Z00	Element assy. - AIR CLEANER
18	17222-RB0-000	Rubber - AIR CLEANER SEAL
19	17228-RB0-000	Joint - THROTTLE RUBBER
20	17243-RB0-000	Tube - AIR INTAKE
21	17315-RAA-A00	Clamp - AIR FLOW (74)
22	37980-RNA-A01	Meter assy - AIR FLOW
23	37985-RAD-L11	Gasket
24	90001-P0A-000	Bolt-washer - SPECIAL, 6X35
25	90006-RB0-003	Nut - INSERT, 6MM
26	90091-RAA-A00	Bolt-washer - 5X28
27	91405-PG7-003	Clip - HOSE (D13)
33	90005-RGA-000	Bolt - CLAMP, 4X25

Air conditioner (COMPRESSOR) 11

#	OEM	部品名
1	38801-PDF-E02	Valve sub assy. - SAFETY
2	38810-RD7-Z01	Compressor comp.
3	38829-PDF-E02	Nut - 9MM
4	38900-RD7-Z01	Clutch set - COMPRESSOR
5	38912-PE1-702	Shim set
6	38913-PP4-E02	Ring - SNAP
7	38913-RD7-Z01	Protector set - THERMAL
8	38914-P07-004	Ring f - SNAP
9	38920-RB0-004	Belt - COMPRESSOR (MITSUBOSHI)
10	38924-RLC-014	Coil set - FIELD
11	90023-PWA-000	Bolt - FLANGE, 8X102

Air conditioner (CONDENSER) 13

#	OEM	部品名
1	38611-RRA-A01	Fan - COOLING
2	38615-RB1-J51	Shroud comp. - AIR CONDITIONER
3	38616-RB0-003	Motor - COOLING FAN
4	80107-S2X-000	Mount - CONDENSER UPPER
5	80110-TM0-H01	Condenser comp.
6	80115-TM0-T00	Bracket - R. CONDENSER UPPER
7	80116-TM0-T00	Bracket - L. CONDENSER UPPER
8	80175-SE0-000	Mount - CONDENSER
9	80351-SDC-A01	Receiver comp
10	80352-SDA-A01	Clamp
11	80873-ST7-000	O-ring - 8MM
12	90041-P3G-003	Screw-washer - 5X11
13	90043-PD2-003	Nut - HEX., 5MM (DENSO)

Air conditioner (HOSES/PIPES) 15

#	OEM	部品名
1	80050-SP0-000	Label - AIR CONDITIONER CAUTION (HFC134A)
2	80311-TM0-T01	Hose comp. - SUCTION
3	80315-TM0-T01	Hose comp. - DISCHARGE
4	80321-TF0-G01	Pipe assy. - AIR CONDITIONER
5	80341-TM0-T01	Pipe comp - RECEIVER
6	80361-TF0-G00	Clamp - AIR CONDITIONER PIPE
7	80365-TF0-003	Clip - RECEIVER PIPE
8	80440-SS0-901	Switch - DUAL PRESSURE (FUJI)
9	80865-ST0-003	Cap h - VALVE (NICHIRIN)
10	80866-ST0-003	Cap l - VALVE (NICHIRIN)
11	80871-ST7-000	O-ring - 5/8"
12	80872-ST7-000	O-ring - 1/2"
13	80873-ST7-000	O-ring - 8MM
14	91536-SLJ-003	Clip - AIR CONDITIONER PIPE
15	91548-S3N-003	Clip - RECEIVER PIPE

Alternator (MITSUBISHI) 14

#	OEM	部品名
1	31100-RB0-004	Alternator assy - AHGA77) (MITSUBISHI
2	31101-RB0-004	Rotor assy.
3	31102-RB0-004	Stator assy.
4	31111-P08-J02	Bearing - RR. GENERATOR
5	31114-P01-014	Bearing - FR. GENERATOR
6	31123-RSH-004	Terminal set
7	31125-P08-J02	Bolt - FLANGE
8	31127-RB0-004	Rectifier assy.
9	31140-RKB-004	Brush set
10	31141-RB0-004	Pulley
11	31142-P08-J02	Nut
12	31146-PE0-004	Screw
13	31147-RKB-004	Screw
14	31150-RB0-004	Regulator set

Antenna/speaker (1) 16

#	OEM	部品名
1	32113-TM0-000	Sub cord - AUX
2	39114-TM0-T00	Cord assy - USB
3	39114-TM0-T01	Cord - USB
4	39120-TC0-T01	Speaker assy - 17CM ND SINGLE) (PP) (PANASONIC
5	39122-SYA-000	Seal - SPEAKER HOLE
6	39152-SYA-003	Mast assy. - ANTENNA
7	39153-TM0-003	Base comp. - ANTENNA
8	39154-SYA-003	Pad
9	39156-TM0-T01	Sub feeder
10	39160-TM0-T11	Feeder assy. - ROOF
11	90109-SLJ-003	Screw - 5X40
12	90309-SLJ-003	Nut assy. - SPEAKER
13	91531-S04-003	Clip - WIRE HARNESS(NATURAL) (44MM)
14	91540-TA0-003	Clip - HARNESS BAND(NATURAL) (100.1MM)
15	91542-SNA-003	Clip - HARNESS BAND(DARK BLUE) (164.5MM)
16	91555-SM4-003	Clip - COUPLER (RED)

Atf pipe 16

#	OEM	部品名
1	24901-RB0-020	Cover - CONTROL WIRE
2	24902-RB0-010	Cover - PROTECTOR(A)
3	24905-RG0-010	Bracket - CONTROL WIRE
4	25212-P24-J01	Hose - ATF, 210MM(BRIDGESTONE)
5	25212-RPC-003	Hose - ATF, 165MM
6	25430-PLR-003	Filter, ATF
7	25431-PLR-000	Stay b - ATF FILTER
8	25432-RMM-000	Stay comp. b - ATF FILTER
9	25910-RMM-000	Pipe comp. a - ATF
10	25920-RMM-000	Pipe comp. b - ATF
11	25930-RG5-000	Pipe comp. c - ATF
12	25950-RMM-000	Bolt comp - JOINT
13	25951-RGR-000	Bolt - JOINT
14	90471-RGR-000	Washer - DRAIN PLUG, 12MM
15	90635-PT0-802	Clip, Oil Pipe
15	90635-RV0-003	CLIP, OIL PIPE

Audio unit 11

#	OEM	部品名
1	39100-TM0-U11	Tuner assy - RADIO (MITSUBISHI)
2	39103-TM0-T01	Knob - VOLUME
3	39104-TM0-T01	Button - VOLUME
4	39106-TM0-U01	Audio assy - GENERAL
5	39107-TM0-U01	Panel assy. - USB/TUNER/CD
7	39108-TM0-U01	Cd assy.
8	39109-TM0-T01	Bracket - L./R.
10	39819-SJD-E01	Bolt-washer - 5X8
11	39819-SJD-E51	Screw - TAPPING PAN, 3X6
12	77259-SLJ-003	Cushion - CLIP
13	90151-SM4-003	Bolt-washer - 5X12

Auto tensioner 5

#	OEM	部品名
1	31170-RB0-J01	Tensioner Assy - AUTO
2	31180-RB0-J01	Pulley comp - IDLER
3	31185-RB0-J01	Cover - BEARING
4	90002-RB0-000	Bolt - SOCKET, 10X30
5	90050-PG7-000	Bolt - FLANGE, 12X65

Battery 18

#	OEM	部品名
1	31500-TF0-Q01	Battery - 34B19L-MF)(PANASONIC
2	31512-TF0-000	Plate - BATTERY SETTING
3	31513-SP0-010	Bolt - BATTERY SETTING (210MM)
4	31521-TF0-000	Box - BATTERY
5	31542-TF0-T01	Plug - VENT(PANASONIC)
6	32115-P64-003	Holder - CORRUGATED (DARK BLUE) (10MM)
7	32132-P8C-A01	Holder - HARNESS (DARK BLUE) (10MM)
8	32410-TF0-000	Cable assy - STARTER
9	32411-TF0-000	Bracket a - STARTER
10	32415-RNA-A01	Nut - M6
11	32416-RNA-A01	Bolt - SQUARE (M6)
12	32418-TF0-003	Cover - BATTERY TERMINAL
13	32600-TM0-000	Cable assy - BATTERY EARTH
14	32601-SK7-900	Bolt - BATTERY TERMINAL
15	32602-SK7-900	Nut - BATTERY TERMINAL
16	38210-TF0-003	Terminal assy - BATTERY FUSE
17	90153-SE0-003	Bolt - EARTH, 6X12
18	90337-SJ4-003	Nut - A.L.B.

Brake lines (ABS; DRUM) 26

#	OEM	部品名
1	01464-TF0-000	Hose set - R. FR. BRAKE
2	01465-TF0-000	Hose set - L. FR. BRAKE
3	01466-TF0-000	Hose set - RR. BRAKE
4	01468-TF0-G00	Hose set - L. RR. BRAKE
5	46330-TM0-P50	Pipe comp. c - BRAKE
6	46331-TF0-Q00	Pipe comp. e - R. BRAKE
7	46340-TM0-P51	Pipe comp. d - BRAKE
8	46361-TF0-Q00	Pipe comp. e - L. BRAKE
9	46374-TF0-G02	Pipe comp. u - BRAKE
10	46375-TF0-G02	Pipe comp. v - BRAKE
11	46376-TF0-000	Pipe comp. w - BRAKE
12	46377-TF0-G00	Pipe comp. x - BRAKE
13	46380-SH3-000	Grommet a - BRAKE PIPE
14	46391-S5A-J01	Clip - BRAKE PIPE
15	46391-TF0-003	Clip - BRAKE PIPE
16	46391-TF0-951	Clip - BRAKE PIPE
17	46392-TF0-003	Clip - BRAKE PIPE
18	46393-SMG-E01	Clip - BRAKE PIPE
19	46393-TF0-G01	Clip - BRAKE PIPE
20	46395-TF0-G01	Clip - BRAKE PIPE
21	46396-TF0-003	Clip - BRAKE PIPE
22	46436-TF0-J00	Bracket - R. RR. BRAKE HOSE
23	46437-TF0-G00	Bracket - L. RR. BRAKE HOSE
24	46462-SE0-000	Bolt - OIL
25	46472-568-000	Packing - OIL BOLT
26	90651-538-000	Clip - BRAKE HOSE

Brake master cylinder/ master power (1) 27

#	OEM	部品名
1	01462-TF0-000	Cylinder set - MASTER (19.05MM)
1	01462-TF0-010	SET,MASTER CYLN (
2	01469-TM0-Y00	POWER SET, MASTER(9")
3	46017-TF0-G50	Hose set - RESERVE TANK
4	46018-TF0-G50	Hose set - RESERVE TANK
5	46100-TF0-Y01	Cylinder assy. - MASTER
6	46120-TF0-003	Piston assy. - PRIMARY
7	46122-TF0-003	Piston assy. - SECONDARY
8	46135-SDA-A01	Guide assy - PISTON
9	46151-SB2-003	Yoke - PUSH ROD (NISSIN)
10	46185-SE0-003	Seal - ROD
11	46191-S2K-000	Packing - MASTER POWER
12	46402-TG0-P01	Tube assy - MASTER POWER
13	46406-TF0-000	Bracket - MASTER POWER TUBE
14	46512-S70-000	Pin - PEDAL
15	46661-TF0-G50	Reservoir set
16	46662-S9A-003	Cap comp. - RESERVE TANK
17	46665-S04-J01	Grommet
18	46666-S2K-003	Filter - BRAKE RESERVOIR
19	46669-S5A-003	Diaphragm
20	46674-TF0-G00	Bracket - RESERVE TANK
21	46680-TF0-G51	Union - RESERVOIR
22	46911-S70-003	Pin, LOCK(8MM)
23	53729-671-003	Clamp d - 15.5MM
24	57173-SB0-801	O-ring - CONNECTOR
25	57562-SF1-003	Circlip
26	90361-SV4-003	Nut - PAINT CUTTING, 6MM

Breather pipe 6

#	OEM	部品名
1	11855-P72-000	Grommet, PCV Valve
2	17130-PWA-003	Valve assy. PCV
3	17131-RB1-000	Tube - PCV
4	17135-RB0-000	Pipe comp - BREATHER
5	17153-RB0-000	Tube - BREATHER
6	91412-SDC-L01	Clamp - FUEL TUBE(D15.5)

Camshaft/cam chain 11

#	OEM	部品名
2	14110-RB7-Z00	Camshaft comp.
3	14211-RB0-003	Sprocket - CAM CHAIN DRIVEN (46T)
4	14221-RB0-003	Plate - TDC PULSER
5	14222-PWA-004	Bolt - TDC PULSER PLATE
6	14401-RB1-003	Chain - 132L
7	14510-PWC-004	Tensioner comp - CAM CHAIN
8	14512-PWC-000	Slider comp. - CAM CHAIN TENSIONER
10	14530-RB1-004	Guide comp - CAM CHAIN
11	90003-PNA-000	Bolt - TENSIONER PIVOT
12	90031-RNA-A01	Bolt-washer - 10X30
13	90703-PWA-003	Dowel pin - 2.5X10

Chain case 9

#	OEM	部品名
1	11410-RB1-000	Case assy. - CHAIN
2	12513-P72-003	Plug - CYLINDER HEAD
3	15302-PE0-300	Washer - SEALING, 14MM
4	90015-PF0-000	Bolt - FLANGE, 8X53
5	90021-PWA-003	Bolt - SPECIAL, 8X41
6	90081-PZA-000	Bolt - SEALING, 14MM
7	90107-P4V-000	Bolt - FLANGE, 8X40
8	90162-RB0-000	Bolt - STUD, 12X72.5
9	91212-PWA-003	Oil seal - 40X55X7 (NOK)

Clutch (2ND-4TH) 30

#	OEM	部品名
1	22530-RPC-004	Piston comp - CLUTCH
2	22536-RCT-014	Spring - CLUTCH WAVE
3	22541-RPC-004	Spring - CLUTCH RETURN
4	22544-RPC-004	Disk - CLUTCH
5	22568-RPC-004	Plate - CLUTCH END (17) (2.8MM)
5	22563-RPC-004	Plate - CLUTCH END (12) (2.3MM)
5	22557-RPC-004	Plate - CLUTCH END (7) (2.7MM)
5	22552-RPC-004	Plate - CLUTCH END (2) (2.2MM)
5	22565-RPC-004	Plate - CLUTCH END (14) (2.5MM)
5	22559-RPC-004	Plate - CLUTCH END (9) (2.9MM)
5	22554-RPC-004	Plate - CLUTCH END (4) (2.4MM)
5	22567-RPC-004	Plate - CLUTCH END (16) (2.7MM)
5	22562-RPC-004	Plate - CLUTCH END (11) (2.2MM)
5	22556-RPC-004	Plate - CLUTCH END (6) (2.6MM)
5	22551-RPC-004	Plate - CLUTCH END (1) (2.1MM)
5	22569-RPC-004	Plate - CLUTCH END (18) (2.9MM)
5	22564-RPC-004	Plate - CLUTCH END (13) (2.4MM)
5	22558-RPC-004	Plate - CLUTCH END (8) (2.8MM)
5	22553-RPC-004	Plate - CLUTCH END (3) (2.3MM)
5	22566-RPC-004	Plate - CLUTCH END (15) (2.6MM)
5	22561-RPC-004	Plate - CLUTCH END (10) (2.1MM)
5	22555-RPC-004	Plate - CLUTCH END (5) (2.5MM)
6	22610-RMM-004	Guide comp - CLUTCH (2-4)
7	22633-RPC-004	Retainer
8	22643-RMM-004	Plate - CLUTCH (2.3MM)
9	22653-RPC-004	Plate - CLUTCH (1.6MM)
10	90603-RPC-004	Circlip - EXTERNAL, 42MM
11	90605-RCT-004	Ring - SNAP, 133MM
12	91302-RCT-004	O-ring - 40.2X2.2
13	91303-RCT-004	O-ring - 111.7X2.2

Clutch (3RD-5TH) 20

#	OEM	部品名
1	22537-RPC-003	Spring - CLUTCH WAVE
2	22542-RPC-003	Spring - CLUTCH RETURN
3	22545-RPC-003	Disk - CLUTCH
4	22568-RPC-003	Plate - CLUTCH END (8) (2.8MM)
4	22563-RPC-003	Plate - CLUTCH END (3) (2.3MM)
4	22565-RPC-003	Plate - CLUTCH END (5) (2.5MM)
4	22567-RPC-003	Plate - CLUTCH END (7) (2.7MM)
4	22562-RPC-003	Plate - CLUTCH END (2) (2.2MM)
4	22569-RPC-003	Plate - CLUTCH END (9) (2.9MM)
4	22564-RPC-003	Plate - CLUTCH END (4) (2.4MM)
4	22566-RPC-003	Plate - CLUTCH END (6) (2.6MM)
4	22561-RPC-003	Plate - CLUTCH END (1) (2.1MM)
5	22633-RPC-003	Seat - RETURN SPRING
6	22643-RMM-003	Plate - CLUTCH WAVE (2.0MM)
7	22651-RMM-003	Guide comp - CLUTCH (3-5)
8	22670-RPC-003	Piston comp - CLUTCH
9	90603-RPC-003	Circlip - EXTERNAL, 45MM
10	90605-PX4-000	Ring - SNAP, 129MM
11	91303-PF4-004	O-ring - 110X2.2 (NOK)
12	91303-P0Z-003	O-ring - 45.1X2.2 (NOK)

Clutch (LOW) 20

#	OEM	部品名
1	22510-RPC-003	Guide comp - LOW CLUTCH
2	22521-RPC-003	Piston - CLUTCH
3	22533-RPC-003	Retainer comp - RETURN SPRING
4	22536-RPC-003	Spring - CLUTCH WAVE
5	22541-RPC-003	Spring - CLUTCH RETURN
6	22543-RPC-003	Plate - CLUTCH WAVE (1.6MM)
7	22544-RPC-003	Disk - CLUTCH
8	22559-RPC-003	Plate - CLUTCH END (9) (2.9MM)
8	22554-RPC-003	Plate - CLUTCH END (4) (2.4MM)
8	22556-RPC-003	Plate - CLUTCH END (6) (2.6MM)
8	22551-RPC-003	Plate - CLUTCH END (1) (2.1MM)
8	22558-RPC-003	Plate - CLUTCH END (8) (2.8MM)
8	22553-RPC-003	Plate - CLUTCH END (3) (2.3MM)
8	22555-RPC-003	Plate - CLUTCH END (5) (2.5MM)
8	22557-RPC-003	Plate - CLUTCH END (7) (2.7MM)
8	22552-RPC-003	Plate - CLUTCH END (2) (2.2MM)
9	90602-RPC-003	Circlip - EXTERNAL, 36MM
10	90605-PA9-000	Ring - SNAP, 114X1.8
11	91302-RPC-003	O-ring - 31.4X2.2
12	91303-PA9-004	O-ring - 100X2.2 (NOK)

Clutch case 11

#	OEM	部品名
1	21000-RF0-B00	Case comp. - CLUTCH
3	21103-PLW-000	Plate c - OIL GUIDE
4	21120-PWL-000	Magnet comp. - TRANSMISSION
5	21323-RF0-000	Bracket - BREATHER TUBE
6	24601-PWL-000	Stay - CHANGE WIRE
7	28810-RWE-003	Pick up assy. - MATSUSHITA
8	91002-PS0-013	Bearing - BALL, 26X58X15 (NTN)
9	91101-PHR-003	Bearing - NEEDLE, 34X59X20
10	91206-PHR-003	Oil seal - 35X58X8 (NOK)
11	91216-PHR-003	Oil seal - 26X40X7(NOK)
12	91309-PX4-003	O-ring - 16X2.1 (NOK)

Clutch master cylinder 34

#	OEM	部品名
1	43352-567-000	Screw - BLEEDER
2	43353-SD5-003	Cap - BLEEDER SCREW
3	46151-S5A-A01	Yoke
4	46182-500-013	Circlip
5	46391-SDA-A01	Clip g - BRAKE PIPE
6	46844-SAA-G01	Connector comp
7	46911-S70-003	Pin, LOCK(8MM)
8	46912-S84-A00	Pin - CLUTCH PEDAL
9	46921-S5A-003	Plate - STOPPER
10	46925-TF0-A01	Cylinder assy. - CLUTCH MASTER
11	46926-S5A-013	Piston comp - CLUTCH MASTER CYLINDER
12	46928-S5A-A01	Seal - MASTER CYLINDER
13	46930-SNA-A41	Cylinder assy. - CLUTCH SLAVE
14	46931-S5A-003	Pin - SPRING
15	46932-S5A-003	Piston - SLAVE CYLINDER
16	46937-SS1-003	Boot - SLAVE CYLINDER
17	46941-S5A-003	Connector - CLUTCH MASTER CYLINDER
18	46942-S5A-003	Pin - SNAP
19	46943-S5A-003	Seal - RING
20	46945-S5A-003	O-ring
21	46946-S5A-003	Screw-washer - 4X12
22	46947-S5A-003	Rod - PUSH
23	46948-S5A-003	Rod - PUSH
24	46949-S5A-003	Seal - RING
25	46960-TF0-G01	Pipe comp. a - CLUTCH
26	46961-TF0-003	Hose - CLUTCH
27	46965-S5A-013	Tank assy. - CLUTCH FLUID
28	46966-TF0-G01	Holder - TANK
29	46968-SAA-003	Bracket b - CLUTCH PIPE
30	46970-TF0-003	Pipe comp. b - CLUTCH
31	46971-TF0-G01	Tube - CLUTCH FLUID
32	46995-TF0-003	Bracket a - CLUTCH PIPE
33	90651-538-000	Clip - BRAKE HOSE
34	91594-SM4-013	Clamp - FUEL TUBE

Clutch release 5

#	OEM	部品名
1	22810-RPF-003	BEARING, CLUTCH RELEASE (FUJIKOSHI)
2	22821-RF0-000	Fork - CLUTCH RELEASE
3	22825-P0S-000	Bolt - RELEASE FORK
4	22835-P0S-000	Spring - RELEASE FORK SETTING
5	22841-RPF-000	Boot - RELEASE FORK

Clutch/torque converter 14

#	OEM	部品名
1	21350-PWA-010	Cover - CLUTCH CASE
2	21351-RME-000	Cover - TORQUE CONVERTER CASE
3	22100-RB0-005	Flywheel comp.
4	22200-RB0-005	DISK COMP., FRICTION
5	22300-RB0-005	DISK COMP., PRESSURE
6	26000-RB0-305	Converter assy - TORQUE
7	26251-RME-000	Plate - DRIVE
8	90011-PM0-000	Bolt - 12MM
9	90023-PA9-000	Bolt - SPECIAL
10	90034-689-000	Bolt - TWELVE POINT, 8MM (TOKAI TRW)
11	90429-PLM-000	Washer - 40X85X2
12	90451-RME-000	Collar - 24X28X8.0
13	91006-PWA-008	BEARING, CLUTCH PILOT
14	91302-RNA-003	O-ring - 35.5X1.9

Combination switch 5

#	OEM	部品名
1	35251-TA0-B01	Body comp - SWITCH
2	35255-TA0-A02	Switch assy - LIGHTING & TURN SIGNAL
3	35256-TA0-A02	Switch assy - WIPER
4	35400-S5A-013	Switch assy - DOOR (MATSUSHITA)
5	90132-SFE-003	Screw - EARTH, 5X18

Console (1) 7

#	OEM	部品名
1	39112-TM0-003	Jack assy - AUX IN.
2	77259-SLJ-003	Cushion - CLIP
10	83445-TM0-T00	Bracket comp. - CONSOLE
11	90137-SH3-000	Screw - TAPPING, 4X16
12	90666-SDA-A01	Clip, Snap Fitting - SNAP FITTING(PO) (NATURAL)
13	91560-STK-A01	Clip - GARNISH (SEAL)
15	91641-SM4-003	Grommet - SCREW, 4MM

Control unit (CABIN; 1) 15

#	OEM	部品名
1	38200-TM0-Y01	Box assy - FUSE
2	38211-SNA-A11	Fuse - BLOCK (30A)
4	38221-SNA-A31	Fuse - BLADE(7.5A)
5	38221-SNA-A41	Fuse - BLADE(10A)
6	38221-SNA-A51	Fuse - BLADE(15A)
7	38221-SNA-A61	Fuse - BLADE(20A)
8	38221-SNA-A81	Fuse - BLADE(30A)
9	38232-SDA-A01	Fuse b - MULTI BLOCK (40A/50A)
10	38235-SNA-A01	Puller - MINI FUSE
11	38255-TF0-003	Detector unit - ELECTRONIC LOAD
15	39980-TM0-Y01	Eps unit
15	39980-TM0-Y21	Eps unit
16	90130-TF0-003	Screw-washer - 5X16
17	90137-SF1-000	Bolt-washer - 6X25
18	90361-SV4-003	Nut - PAINT CUTTING, 6MM

Control unit (CABIN; 2) 4

#	OEM	部品名
1	39794-SDA-A03	Relay assy - POWER (MICRO ISO) (OMRON)
9	39794-SDA-003	Relay assy - FUEL PUMP (MITSUBA)
10	39794-SDA-901	Relay assy, ENGINE CONTROL MODULE (MITSUBA)
10	39794-SDA-902	Relay assy, ENGINE CONTROL MODULE (DENSO)

Control unit (ENGINE ROOM) 11

#	OEM	部品名
1	37820-RD7-Y01	Control module - ENGINE (REWRITABLE)
1	37820-RD7-Y51	Control module - ENGINE (REWRITABLE)
2	37821-RB0-000	Bracket comp. - ENGINE CONTROL MODULE
3	37823-RB0-000	Cover - ENGINE CONTROL MODULE
4	38100-TM0-003	Horn assy - LOW
5	38101-TM0-000	Bracket - HORN(LOW)
8	38182-TF0-003	Cover - RELAY BLOCK UPPER(3P)
9	38186-TM0-000	Bracket - MULTI RELAY BOX (L. SIDE)
10	39794-SDA-A03	Relay assy - POWER (MICRO ISO) (OMRON)
13	90113-SLJ-003	Bolt - SPECIAL, 6X14
14	90150-SLJ-003	Bolt - EARTH, 8X16

Converter 7

#	OEM	部品名
1	11941-RB0-000	Stay comp - CONVERTER
2	18115-RB0-004	Gasket - CONVERTER (NIPPON LEAKLESS)
3	18120-RB1-000	Cover - CONVERTER
4	18190-RB7-Z00	Converter comp.
5	36531-RB0-003	Sensor - AIR FUEL RATIO
6	90001-RB0-000	Bolt - FLANGE, 8X22
7	90004-PLC-000	Bolt-washer - 10X25

Cooling duct 2

#	OEM	部品名
1	17245-RD6-G00	Duct - COOLING
2	91512-SX0-003	Clip - INNER FENDER CLIP

Countershaft 42

#	OEM	部品名
1	23221-RF0-A40	Countershaft
1	21215-RG5-000	Holder - IDLE SHAFT
2	23421-RF0-A00	Gear - COUNTERSHAFT LOW
2	23221-RG0-000	Countershaft
3	23431-RF0-A00	Gear - COUNTERSHAFT SECOND
3	23421-RG5-000	Gear - COUNTERSHAFT LOW
4	23461-RF0-B00	Gear - COUNTERSHAFT FIFTH
4	23427-RPC-000	Gear - PARKING
5	23471-RF0-B00	Gear - COUNTERSHAFT THIRD
5	23441-RG5-000	Gear - COUNTERSHAFT SECOND
6	23481-RF0-B00	Gear - COUNTERSHAFT FOURTH
6	23451-RPC-J00	Gear - COUNTERSHAFT THIRD
7	23521-RF0-305	Sleeve set - SYNCHRONIZER(1-2)
7	23491-RG5-000	Gear - COUNTERSHAFT FIFTH
8	23911-RF0-000	Collar - DISTANCE, 36.5X44.5X30.5
8	23531-RPC-000	Gear - COUNTERSHAFT REVERSE
9	23912-PHR-000	Collar - DISTANCE, 34X40X27.5
9	23541-RPC-000	Gear - REVERSE IDLE
10	23926-PB6-010	Washer - SPRING, 22MM
10	23542-P6H-000	Shaft - REVERSE IDLE GEAR
11	90201-PB6-020	Nut - FLANGE, 22MM
11	23565-RPC-000	Selector - REVERSE GEAR
12	90603-PL3-000	Ring - SNAP, 52MM
12	23566-RPC-000	Hub - SELECTOR
13	91003-P21-003	Bearing - BALL, 25X52X14/15 (NTN)
13	90201-PRP-000	Nut - FLANGE, 24MM (LEFT HAND THREAD)
14	91102-PLW-003	Bearing - NEEDLE, 25X52.2X15
14	90402-P0Z-000	Washer - SPRING, 24MM
15	91103-RPF-003	Bearing - NEEDLE, 44.5X48.5X21.5
15	90431-RPC-000	Cotter - 29MM
16	91104-PHR-003	Bearing - NEEDLE, 40X45X22.5
16	90441-RPC-000	Collar - 33.2X40X26
17	91212-PHR-003	Damper - FRICTION (SECOND)
17	91212-PHR-013	Damper
17	90445-RPC-000	Collar - 33X45X7.8
18	91212-RPF-008	Damper, Friction (Second)
18	91212-RPF-018	Damper - FRICTION(SECOND)
18	90616-RPC-000	Ring - SNAP, 33MM
19	91015-RPC-003	Bearing - NEEDLE, 33X39X26.5
20	91017-RPC-004	Bearing - NEEDLE, 36X42X17
21	91018-RPC-003	Bearing - NEEDLE, 15X20X16
22	91306-P0X-003	O-ring - 8.1X4 (NOK)

Cylinder block/oil pan (1.5L) 29

#	OEM	部品名
1	11000-RB1-000	Block assy - CYLINDER
2	11103-RB0-004	Plate - PARTITION
3	11106-PWA-300	Bolt - SEALING, 24MM
4	11107-PWA-300	Washer - SEALING, 24MM
5	11200-RB0-000	Pan assy - OIL
5	11200-RB0-900	Pan assy - OIL
6	11203-PWA-003	O-ring - 17.8X2.4 (NOK)
7	11252-PWA-000	Packing - OIL PAN
8	11850-RB0-000	Cover - BREATHER
9	15200-RB0-000	Pipe comp - OIL LEVEL
10	15650-RB1-000	Gauge comp. - OIL LEVEL
11	30530-RB0-004	Sensor comp - KNOCK
12	32113-RB0-000	Sub harness - CRANK SENSOR
13	32742-RB0-000	Stay - CRANK SENSOR HARNESS
14	32743-RB0-000	Clamp - CRANK SENSOR HARNESS TUBE
15	32744-RB0-000	Stay - COUPLER
16	37241-RNA-A01	Switch assy, OIL PRESSURE
17	37500-RB0-006	Sensor assy - CRANK
18	37501-RB0-000	Cover - CRANK SENSOR
19	90001-PM3-003	Bolt - DRAIN PLUG, 28MM
20	90008-PM0-003	Bolt-washer - 10X112
21	90009-PY3-000	DRAIN PLUG BOLT, 14MM
22	90401-PR4-000	Washer - SEALING, 28MM
23	90702-PE0-000	Dowel pin - 12X18
24	90705-PT0-000	Dowel pin - 16X22
25	91214-PWA-Y01	Oil seal - 80X98X10 (NOK)
26	91308-PH9-000	O-ring - 8.8X1.9
26	91302-GE0-000	O-ring (8.8x1.9)
27	91333-PNC-006	O-ring

Cylinder head 7

#	OEM	部品名
1	12200-RB0-000	Head comp - CYLINDER
2	12204-PJ7-305	Guide - IN. VALVE (OS)
3	12205-PJ7-305	Guide - EX. VALVE (OS)
10	14631-RB1-000	Shaft comp. - ROCKER
11	90003-RB0-000	Bolt - FLANGE, 6X47
12	90011-RB0-000	Bolt - SPECIAL, 6X42
16	04148-RB1-305	Motion set - LOST

Cylinder head cover 5

#	OEM	部品名
1	12310-RB0-003	Cover comp. - CYLINDER HEAD
2	12341-RB0-003	Packing - HEAD COVER
3	15610-PFB-000	Cap assy. - OIL FILLER
4	15613-PC6-000	Packing, Oil Filler
5	90013-RGA-000	Bolt - HEAD COVER

Differential 89

#	OEM	部品名
1	41100-RF0-B00	Differential comp.
1	41100-RPC-010	Differential comp.
2	41233-PWL-A40	Gear - FINAL DRIVEN
2	41233-RG0-000	Gear - FINAL DRIVEN
3	41446-PL3-B00	Shim f - 80MM(1.5)
3	41441-PL3-B00	Shim a - 80MM(1.0)
3	41457-PL3-B00	Shim s - 80MM(1.75)
3	41452-PL3-B00	Shim m - 80MM(1.25)
3	41447-PL3-B00	Shim g - 80MM(1.6)
3	41442-PL3-B00	Shim b - 80MM(1.1)
3	41453-PL3-B00	Shim n - 80MM(1.35)
3	41448-PL3-B00	Shim h - 80MM(1.7)
3	41443-PL3-B00	Shim c - 80MM(1.2)
3	41454-PL3-B00	Shim p - 80MM(1.45)
3	41449-PL3-B00	Shim j - 80MM(1.8)
3	41444-PL3-B00	Shim d - 80MM(1.3)
3	41455-PL3-B00	Shim q - 80MM(1.55)
3	41450-PL3-B00	Shim k - 80MM(1.05)
3	41445-PL3-B00	Shim e - 80MM(1.4)
3	41456-PL3-B00	Shim r - 80MM(1.65)
3	41451-PL3-B00	Shim l - 80MM(1.15)
3	41381-RLM-000	Spacer - 41X80X1
4	90018-PWL-000	Bolt - SPECIAL, 10MM
4	41382-RLM-000	Spacer - 41X76.2X1
5	91005-PPS-003	Bearing - BALL, 40X80X18(NTN)
5	41452-PAX-000	Shim y - 76MM (2.775)
5	41436-PAX-000	Shim i - 76MM (1.975)
5	41449-PK4-000	Shim i - 76MM (2.60)
5	41433-PRP-000	Shim of - 76MM (1.80)
5	41447-PAX-000	Shim t - 76MM (2.525)
5	41431-PAX-000	Shim d - 76MM (1.725)
5	41428-PRP-000	Shim oa - 76MM (1.55)
5	41444-PK4-000	Shim d - 76MM (2.35)
5	41458-PK4-000	Shim r - 76MM (3.05)
5	41442-PAX-000	Shim o - 76MM (2.275)
5	41455-PK4-000	Shim o - 76MM (2.90)
5	41439-PX4-700	Shim t - 76MM (2.10)
5	41453-PAX-000	Shim z - 76MM (2.825)
5	41437-PAX-000	Shim j - 76MM (2.025)
5	41450-PK4-000	Shim j - 76MM (2.65)
5	41434-PRP-000	Shim og - 76MM (1.85)
5	41448-PAX-000	Shim u - 76MM (2.575)
5	41432-PAX-000	Shim e - 76MM (1.775)
5	41429-PRP-000	Shim ob - 76MM (1.60)
5	41445-PK4-000	Shim e - 76MM (2.40)
5	41443-PAX-000	Shim p - 76MM (2.325)
5	41456-PK4-000	Shim p - 76MM (2.95)
5	41440-PX4-700	Shim u - 76MM (2.15)
5	41454-PAX-000	Shim oa - 76MM (2.875)
5	41438-PAX-000	Shim k - 76MM (2.075)
5	41451-PK4-000	Shim k - 76MM (2.70)
5	41435-PRP-000	Shim oh - 76MM (1.90)
5	41449-PAX-000	Shim v - 76MM (2.625)
5	41433-PAX-000	Shim f - 76MM (1.825)
5	41446-PK4-000	Shim f - 76MM (2.45)
5	41430-PRP-000	Shim oc - 76MM (1.65)
5	41428-PAX-000	Shim a - 76MM (1.575)
5	41444-PAX-000	Shim q - 76MM (2.375)
5	41457-PK4-000	Shim q - 76MM (3.00)
5	41441-PK4-000	Shim a - 76MM (2.20)
5	41455-PAX-000	Shim ob - 76MM (2.925)
5	41439-PAX-000	Shim l - 76MM (2.125)
5	41452-PK4-000	Shim l - 76MM (2.75)
5	41436-PRP-000	Shim oi - 76MM (1.95)
5	41450-PAX-000	Shim w - 76MM (2.675)
5	41434-PAX-000	Shim g - 76MM (1.875)
5	41447-PK4-000	Shim g - 76MM (2.50)
5	41431-PRP-000	Shim od - 76MM (1.70)
5	41429-PAX-000	Shim b - 76MM (1.625)
5	41445-PAX-000	Shim r - 76MM (2.425)
5	41442-PK4-000	Shim b - 76MM (2.25)
5	41456-PAX-000	Shim oc - 76MM (2.975)
5	41440-PAX-000	Shim m - 76MM (2.175)
5	41453-PK4-000	Shim m - 76MM (2.80)
5	41437-PRP-000	Shim oj - 76MM (2.00)
5	41451-PAX-000	Shim x - 76MM (2.725)
5	41435-PAX-000	Shim h - 76MM (1.925)
5	41448-PK4-000	Shim h - 76MM (2.55)
5	41432-PRP-000	Shim oe - 76MM (1.75)
5	41430-PAX-000	Shim c - 76MM (1.675)
5	41446-PAX-000	Shim s - 76MM (2.475)
5	41443-PK4-000	Shim c - 76MM (2.30)
5	41457-PAX-000	Shim od - 76MM (3.025)
5	41441-PAX-000	Shim n - 76MM (2.225)
5	41454-PK4-000	Shim n - 76MM (2.85)
5	41438-PX4-700	Shim s - 76MM (2.05)
6	90003-PA9-003	Bolt - FLANGE, 10MM
7	91121-RFK-013	Bearing - SPECIAL TAPER, 40X80X20.25
8	91122-RFK-013	Bearing - SPECIAL TAPER, 40X76.2X19

Duct 5

#	OEM	部品名
1	77400-TM0-G01	Duct assy - INSTRUMENT
2	83331-TM0-G02	Duct assy - R. RR. HEATER LOWER
3	83332-TM0-G02	Duct assy - L. RR. HEATER LOWER
4	83333-TF0-003	Duct - RR. HEATER UPPER
5	91560-STK-A01	Clip - GARNISH (SEAL)

Emblem/caution label 7

#	OEM	部品名
1	17669-SA0-670	Label - FUEL FILLER CAUTION (UNLEADED FUEL ONLY)
2	19043-PLA-E00	Label - COOLANT INFORMATION
3	42760-TM0-T00	Plate - TIRE PRESSURE CAUTION
4	75701-TM0-000	Emblem - H
5	75722-TM0-T00	Emblem - RR.(CITY)
6	75725-TM0-T00	Emblem - RR.(I-VTEC)
10	91512-SR3-004	Clip - TUBULAR

Engine hood 20

#	OEM	部品名
5	74120-TM0-Y11	Lock assy - HOOD
6	74125-TM0-T00	Cover - HOOD LOCK
7	74130-TM0-G01	Wire assy. - HOOD
9	74141-TM0-T00	Insulator - HOOD
10	74142-TM0-T00	Rubber - R. HOOD SEAL
11	74143-TM0-T00	Rubber - RR. HOOD SEAL
12	74145-TM0-T00	Stay - HOOD OPENER
14	74192-TM0-T00	Rubber - L. HOOD SEAL
15	74200-TM0-G10	Cowl top assy. - FR.
16	74201-TM0-T00	Lip - COWL TOP
17	74212-TM0-T00	Cover - R. HOOD HINGE
18	74222-TM0-T00	Cover - L. HOOD HINGE
19	74231-TM0-T00	Valve - DRAIN
21	90108-S0A-003	Bolt - FLANGE, 6X15
22	90603-SLJ-003	Clip - COWL TOP
24	91501-SL4-003	Clip - FR. COWL
25	91501-STK-003	Clip - ENGINE HOOD INSULATOR
26	91501-S04-003	Clip - INNER FENDER
27	91504-SDA-003	Clip - HOOD OPEN WIRE
29	91520-SCC-003	Clip - HOOD SEAL RUBBER

Engine mount (AT) 20

#	OEM	部品名
1	50620-TG0-T02	Bracket - ENGINE SIDE MOUNTING
2	50621-TF0-901	Mass
3	50650-TF0-980	Bracket - TRANSMISSION MOUNTING
4	50690-TF0-980	Bracket - TORQUE ROD
5	50822-TF0-J02	ENGINE RH SIDE MOUNT
6	50850-TG0-T03	Rubber - TRANSMISSION MOUNTING
7	50890-TF0-981	Rod - TORQUE
8	90164-TF0-000	Bolt - FLANGE, 12X40
9	90165-SDA-A00	Bolt - FLANGE, 12X45
10	90166-TF0-003	Bolt - GUIDE, 14X91
11	90167-TF0-000	Bolt - FLANGE, 12X16
12	90174-STK-A00	Bolt - FLANGE, 12X30
13	90174-TF0-000	Bolt - FLANGE, 10X30
14	90177-TF0-010	Bolt - FLANGE, 12X107
15	90178-TF0-003	Bolt - 10X119
16	90184-TF0-000	Bolt - FLANGE, 14X71
17	90213-SAA-000	Nut - FLANGE, 12MM
18	90371-SAA-010	Nut - FLANGE, 12MM
19	90371-TF0-003	Nut - FLANGE, 14MM
20	90385-SWA-000	Nut - FLANGE, 14MM

Engine mount (MT) 19

#	OEM	部品名
1	50620-TG0-T11	Bracket - ENGINE SIDE MOUNTING
2	50621-TF0-901	Mass
3	50650-TF0-910	Bracket - TRANSMISSION MOUNTING
4	50690-TF0-910	Bracket - TORQUE ROD
5	50695-TF0-910	Guard - TORQUE ROD
6	50822-TF0-J02	ENGINE RH SIDE MOUNT
7	50850-TG0-T12	Rubber - TRANSMISSION MOUNTING
8	50890-TF0-911	Rod - TORQUE
9	90164-TF0-000	Bolt - FLANGE, 12X40
10	90166-TF0-003	Bolt - GUIDE, 14X91
11	90171-TF0-000	Bolt - FLANGE, 10X119
12	90174-STK-A00	Bolt - FLANGE, 12X30
13	90180-TF0-000	Bolt - FLANGE, 14X110
14	90184-TF0-000	Bolt - FLANGE, 14X71
15	90188-TF0-000	Bolt - FLANGE, 14X113
16	90213-SAA-000	Nut - FLANGE, 12MM
17	90371-SAA-010	Nut - FLANGE, 12MM
18	90371-TF0-003	Nut - FLANGE, 14MM
19	90385-SWA-000	Nut - FLANGE, 14MM

Engine wire harness 21

#	OEM	部品名
1	32110-RB0-Z00	Harness - ENGINE WIRE
1	32110-RB0-Z50	Harness - ENGINE WIRE
2	32112-S2K-003	Band - CABLE (90MM)
3	32121-RB0-000	Holder a - ENGINE HARNESS UPPER
4	32127-RB0-000	Holder g - ENGINE WIRE HARNESS UPPER
5	32131-RB0-000	Holder a - ENGINE HARNESS LOWER
6	32132-RB0-000	Holder b - ENGINE HARNESS
7	32133-RB0-000	Holder c - ENGINE HARNESS
8	32134-RB0-000	Holder d - ENGINE HARNESS
9	32136-RB0-J50	Holder f - ENGINE HARNESS
10	32137-RB0-000	Holder g - ENGINE WIRE HARNESS LOWER
11	90051-PNA-000	Bolt - SPECIAL, 6X28
12	90052-RGA-003	Bolt - SPECIAL, 6X17.8
13	91506-RTA-003	Clip A - HARNESS BAND (DARK VIOLET)(129.4MM)
14	91507-RTA-003	Clip b - HARNESS BAND (DARK GREEN) (129.4MM)
15	91507-SL9-003	Clip - WIRE HARNESS (GREEN) (110MM) (7MM HOLE)
16	91540-SV4-003	Clip - HARNESS BAND (NATURAL) (145.2MM)
17	91551-SF4-003	Band - WIRE HARNESS(BROWN) (110MM)
18	91558-ST5-003	Clip - HARNESS BAND(NATURAL) (135MM)(7MM HOLE)
19	91705-RB0-000	Cover - ENGINE CONTROL MODULE COUPLER
20	91727-RB0-003	Cover - WATER PROOF COUPLER

Engine wire harness stay 1

#	OEM	部品名
1	32750-RB0-000	Stay - SHOCK ABSORBER HOUSING (ENGINE HARNESS)

Exhaust pipe/silencer 23

#	OEM	部品名
1	18160-RB6-Z00	Converter comp.
2	18176-PT0-003	Bolt - CONVERTER
3	18181-RB0-000	COVER COMP., LOWER
4	18215-TF0-003	Rubber - EX. MOUNTING
5	18215-TF0-911	Rubber - EX. MOUNTING
6	18220-TM0-T51	Pipe b - EX.
7	18229-SNA-A01	Gasket, EX. FLEXIBLE
8	18229-TF0-013	Gasket - EX. FLEXIBLE
9	18230-SA0-930	Spring - FLEXIBLE JOINT
10	18231-SNA-A00	Bolt b - FLEXIBLE JOINT
11	18307-TM0-T51	Silencer comp - EX.
13	18393-SH3-S00	Gasket - PRE-CHAMBER (52.5MM-53.5MM)
14	36532-RB7-Z01	Sensor - RR. OXYGEN
15	36533-RB0-G00	Clamp - OXYGEN SENSOR
16	36535-TF0-000	Clamp - OXYGEN SENSOR
17	74600-TF0-000	Plate comp - FLOOR HEAT BAFFLE (A)
18	74602-TF0-000	Plate - FLOOR HEAT BAFFLE
19	74603-TM0-T00	Plate c - FLOOR HEAT BAFFLE
20	74605-TF0-000	Plate - SILENCER BAFFLE
21	90023-PR7-A01	BOLT, FLANGE (6X12) - 6X12 (IWATA BOLT)
22	90151-S3N-003	Rivet - BAFFLE PLATE
23	90212-SA5-003	Nut - SELF-LOCK, 10MM
24	90301-SV7-000	Nut - PAINT CUTTING, 6MM

Floor mat 6

#	OEM	部品名
1	74251-TF0-G00	Insulator - DASHBOARD OUTER
2	74260-TM0-G00	Insulator - DASHBOARD
4	83306-TF0-G00	Stopper assy - HEEL
9	90676-SB2-003	Clip - DASHBOARD INSULATOR
10	91517-SE0-003	Clip - LOWER OUTER DASHBOARD INSULATOR
11	91560-SLJ-J01	Clip - DOOR LINING (LIGHT GRAY)

Floor/inner panels 1

#	OEM	部品名
7	64349-TM0-T01	Separator - RR. WHEEL ARCH

Front brake (1) 21

#	OEM	部品名
1	01463-S2A-000	Caliper set
2	06455-S5A-J00	Shim set - FR.
3	43352-SM4-951	Screw - BLEEDER
4	43353-SD5-003	Cap - BLEEDER SCREW
5	44300-TF0-951	Bearing assy - HUB
6	44600-SLN-A00	Hub assy, Front
7	45018-TG0-T00	Caliper sub assy. - R. FR.
8	45019-TG0-T00	Caliper sub assy. - L. FR.
9	45022-TG0-T00	Pad set - FR.
10	45216-S5H-T01	Piston
11	45235-S0A-003	Pin a
12	45237-SR3-003	Retainer a
13	45240-SC2-003	Bolt - FLANGE, 8X22
14	45251-S5H-T10	Disk - FR. BRAKE
15	45255-TF0-950	Guard - SPLASH
16	45262-S0A-003	Pin b
17	90107-SM4-000	Bolt - CALIPER MOUNTING (12X21)
18	90113-S5H-005	Bolt - WHEEL (THAI MEIRA)
18	90113-SA0-006	Bolt - WHEEL (SAGA)
18	90113-SM1-005	Bolt - WHEEL (ROCKNEL FASTENER)
18	90113-SA0-025	Bolt - WHEEL (NAGOYA RASHI)

Front bulkhead/dashboard 5

#	OEM	部品名
39	74181-TM0-T01	Damper - FR. SIDE FRAME DYNAMIC
41	90105-SV1-000	Bolt-washer - 8X20
42	90108-S0A-003	Bolt - FLANGE, 6X15
43	90157-SA0-000	Bolt-washer - 8X25
44	90361-S3C-003	Nut - PAINT CUTTING, 8MM

Front bumper 12

#	OEM	部品名
4	71140-TM0-T00	Beam - R. FR. BUMPER UPPER
5	71145-TM0-Y00	Base - FR. LICENSE PLATE
6	71190-TM0-T00	Beam - L. FR. BUMPER UPPER
7	90101-S5A-003	Tapping - SPECIAL, 5X18
8	90126-SR4-000	Screw-washer - 5X16
9	90144-SA0-020	Bolt - BUMPER SETTING (6X15) (BLACK)
9	90111-SM4-003	Bolt - BUMPER
10	90157-SA0-000	Bolt-washer - 8X25
11	90675-SA5-003	Nut - CLIP, 6MM
12	90682-SB0-003	Grommet - SCREW, 5MM
13	90682-TM0-T01	Grommet - SCREW, 5MM
14	91503-SZ3-003	Clip A

Front door glass/ regulator 12

#	OEM	部品名
1	39885-S5A-G01	Label - IMMOBILIZER
2	72210-TM0-G01	Regulator assy - R. FR. DOOR POWER
3	72230-TM0-T01	Sash - R. FR. DOOR FR. LOWER
4	72231-TM0-T01	Sash - R. FR. DOOR CENTER LOWER
5	72235-TM0-T01	Runchannel - R. FR. DOOR
6	72250-TM0-G01	Regulator assy - L. FR. DOOR POWER
7	72270-TM0-T01	Sash - L. FR. DOOR FR. LOWER
8	72271-TM0-T01	Sash - L. FR. DOOR CENTER LOWER
9	72275-TM0-T01	Runchannel - L. FR. DOOR
10	73300-TM0-Y00	Glass assy - R. FR. DOOR (GREEN)
11	73350-TM0-Y00	Glass assy - L. FR. DOOR (GREEN)
12	90021-SFA-000	Bolt - FLANGE, 6X10

Front door lining 8

#	OEM	部品名
1	35190-TM0-Z01	Switch assy - REMOTE CONTROL MIRROR
2	35750-TM0-F01	Switch assy - POWER WINDOW MASTER
3	35760-TF0-003	Sub switch assy. - POWER WINDOW
4	72335-TM0-T01	Weatherstrip - R. FR. DOOR INNER
5	72375-TM0-T01	Weatherstrip - L. FR. DOOR INNER
20	90132-SS0-000	Screw - TAPPING, 4X10 (PO)
21	90662-SB2-003	Grommet - SCREW, 5MM
22	91560-SLJ-J01	Clip - DOOR LINING (LIGHT GRAY)

Front door lock/ outer handle 26

#	OEM	部品名
1	72110-TM2-P21	Latch assy - R. FR. DOOR POWER
2	72112-SJK-003	Protector - R. DOOR LATCH
3	72118-SJK-003	Screw - TAPPING
5	72130-TM0-T01	Protector - R. OUTER HANDLE
6	72131-TM0-T01	Cable - FR. INSIDE HANDLE
7	72133-TM0-T01	Cable - FR. DOOR LOCK
8	72134-SHJ-003	Clip s - CABLE END (NATURAL)
8	72174-SHJ-003	Clip t - CABLE END (BLACK)
9	72135-SDA-A01	Striker assy - DOOR LOCK
11	72141-SD4-004	Bush - R. JOINT
12	72143-S04-003	Packing
13	72144-SJD-003	Retainer
14	72145-TM0-T01	Cylinder - R. DOOR
15	72146-TM0-T01	Spacer - DOOR OUTSIDE HANDLE
16	72149-SLA-003	Snap - R.(NATURAL)
17	72150-TM2-P21	LATCH ASSY., L. FR. DOOR POWER
18	72152-SJK-003	Protector - L. DOOR LATCH
20	72170-TM0-T01	Protector - L. OUTER HANDLE
22	72181-SD4-004	Bush - L. JOINT
23	72185-TM0-T01	Cylinder - L. DOOR
24	72189-SLA-003	Snap - L.(BLACK)
25	74387-S3C-003	Fastener
26	90101-SJK-003	Screw - TAPPING (ONE WAY)
27	90120-SV4-000	Bolt - LOCK STRIKER
28	90141-SDA-000	Screw - TAPPING, 5X12
29	90662-SB2-003	Grommet - SCREW, 5MM

Front door panel 18

#	OEM	部品名
5	67325-TM0-T01	Tape - R. FR. DOOR SASH UPPER
6	67365-TM0-T01	Tape - L. FR. DOOR SASH UPPER
11	72142-SM4-000	Stopper - DOOR
12	72310-TM0-T01	Weatherstrip - R. FR. DOOR
13	72311-S5S-003	Clip A - DOOR WEATHERSTRIP
14	72321-TM0-T10	Seal - R. FR. DOOR HOLE
15	72340-TG0-T01	Checker comp. - R. FR. DOOR
16	72350-TM0-T01	Weatherstrip - L. FR. DOOR
17	72361-TM0-T10	Seal - L. FR. DOOR HOLE
18	72380-TG0-T01	Checker comp. - L. FR. DOOR
19	75891-SA7-000	Stopper - DOOR
20	90101-SZ3-000	Bolt - FLANGE, 8X22 (8.5MM)
21	90102-S3N-003	Bolt - FLANGE, 8X24.5 (10.5MM)
21	90102-SFA-305	Bolt - FLANGE, 8X18 (SERVICE)
22	90141-S04-000	Bolt - FLANGE, 8X22
23	91561-SZ3-003	Clip
24	91563-SP0-003	Clip - DOOR WEATHERSTRIP OFFSET
25	91563-S4N-003	Clip - DOOR WEATHERSTRIP OFFSET

Front driveshaft (MT) 19

#	OEM	部品名
1	44014-TF0-J01	Joint set - OUTBOARD
2	44017-SEN-P01	Boot set - INBOARD
3	44018-SEN-P01	Boot set - OUTBOARD
4	44305-TF0-J00	Driveshaft assy. - R.
5	44306-TF0-J00	Driveshaft assy. - L.
6	44310-S5A-J00	Joint comp - INBOARD
7	44310-S5A-300	Joint comp - INBOARD
8	44319-S04-300	Set ring - 26X1.8
8	44319-SR1-003	Set ring - 26X1.8 (GKN)
9	44327-SEN-P01	Band b - DRIVESHAFT (OETIKER INDUSTRIES)
10	44327-SV4-305	Band - JOINT BOOT (DOUBLE ROLLED BAND)
11	44329-SEN-P01	Band c - DRIVESHAFT (OETIKER INDUSTRIES)
12	44329-SV4-305	Band - SHAFT BOOT (DOUBLE ROLLED BAND)
13	44337-S04-300	Ring b - STOPPER
14	44338-S04-300	Circlip - 23MM
15	44351-TF0-003	Damper - DYNAMIC
16	44517-TF0-000	Cover comp. - HEAT
17	90165-TF0-J01	Bolt - FLANGE, 8X35
18	90305-692-010	Nut

Front driveshaft/ half shaft (AT) 31

#	OEM	部品名
1	44014-TF6-N02	Joint set - OUTBOARD
1	44014-TF6-N12	Joint set - OUTBOARD
2	44017-TF6-N10	Boot set - INBOARD
2	44017-TF6-N00	Boot set - INBOARD
3	44018-TF6-N02	Boot set - OUTBOARD
3	44018-TF6-N12	Boot set - OUTBOARD
4	44305-TF6-N01	Driveshaft assy. - R.
5	44306-TF6-N01	Driveshaft assy. - L.
6	44310-TF0-300	Joint comp - INBOARD
7	44310-TF6-305	Joint set - INBOARD
8	44319-SE0-000	Set ring - 28X2.0
8	44319-S84-300	Set ring - 28X2.0
9	44319-S04-300	Set ring - 26X1.8
9	44319-SR1-003	Set ring - 26X1.8 (GKN)
10	44327-SV4-305	Band - JOINT BOOT (DOUBLE ROLLED BAND)
11	44327-TG0-T01	Band b - DRIVESHAFT
12	44329-SV4-305	Band - SHAFT BOOT (DOUBLE ROLLED BAND)
13	44329-TG0-T01	Band c - DRIVESHAFT (OETIKER)
14	44337-SA7-300	Ring - OUTBOARD STOPPER
15	44338-SA7-300	Circlip - 22MM
16	44351-TF6-003	Damper - DYNAMIC
17	44351-TF6-901	Damper - DYNAMIC
18	44500-TF0-Y00	Shaft assy - HALF
19	44517-TF6-N00	Cover comp. - HEAT
20	90102-SF1-000	Bolt - HEX., 10X1.25
21	90165-SE0-000	Bolt - FLANGE, 10X37
22	90165-TF0-J01	Bolt - FLANGE, 8X35
23	90305-692-010	Nut
24	90681-SR3-000	Circlip - EXTERNAL, 33MM
25	91057-SR3-008	Bearing - HALF SHAFT(NTN)
26	91260-SWA-A01	Seal - HALF SHAFT OUTER

Front fender 15

#	OEM	部品名
3	74101-TM0-T00	Fender - R. FR. INNER
4	74105-TM0-T00	Enclosure - R. FR. FENDER
5	74111-TM0-T00	Guard - CENTER SPLASH
6	74112-TM0-T00	Garnish - AIR SCREEN
7	74115-TM0-T00	Guard - R. FR. SPLASH
8	74151-TM0-T00	Fender - L. FR. INNER
9	74155-TM0-T00	Enclosure - L. FR. FENDER
10	74165-TM0-T00	Guard - L. FR. SPLASH
11	90114-SE0-000	Screw - TAPPING, 5X20
12	90308-SB2-013	Nut - SUSPENSION, 5MM
13	90682-SEA-003	Clip - TAPPING SCREW, 5MM
14	91501-S04-003	Clip - INNER FENDER
15	91503-SZ3-003	Clip A
16	91505-S9A-003	Clip A - BUMPER
17	91545-SE0-003	Clip assy. - 8MM

Front grille 6

#	OEM	部品名
1	71121-TM0-T01	Base - FR. GRILLE
3	74175-SJA-000	Cushion - HOOD
4	75700-TM0-000	Emblem - H
5	90301-ST0-003	push nut, 3mm
6	91503-SZ3-003	Clip A
7	91503-SZ5-003	Clip - BUMPER FACE

Front lower arm 20

#	OEM	部品名
1	42533-SMG-E01	Grommet - HARNESS
2	51211-TF0-G00	Knuckle - R. FR.
3	51216-TF0-G00	Knuckle - L. FR.
4	51225-TG0-T01	Boot - FR. LOWER ARM
5	51300-TM0-T11	Spring - FR. STABILIZER
6	51306-TM0-003	Bush - FR. STABILIZER HOLDER
7	51308-TF0-010	Bracket - FR. STABILIZER
8	51320-TG0-T01	Link comp - FR. STABILIZER
9	51350-TG0-T02	Arm assy. - R. FR. LOWER
9	51350-TF0-030	Arm assy. - R. FR. LOWER
10	51360-TG0-T02	Arm assy. - L. FR. LOWER
10	51360-TF0-030	Arm assy. - L. FR. LOWER
11	57450-TF0-003	SENSOR ASSY., RH FRONT
12	57455-TF0-003	SENSOR ASSY., LH FRONT
13	90002-S10-000	Nut - FLANGE, 10MM
14	90118-S5A-000	Bolt - FLANGE, 14X91
15	90119-TF0-000	Bolt - FLANGE, 14X65
16	90306-SB2-013	Nut - SELF-LOCK, 10MM (CLINCH)
17	90363-S3V-A01	Nut - CASTLE, 14MM
18	90701-SKC-003	Pin - SPLIT(M14)

Front seat (L.) 5

#	OEM	部品名
1	04810-SB3-000	C clip set - TRIM FASTENER (30 PIECES)
9	81527-TM0-T01	Pad comp - L. FR. SEATBACK
11	81537-TM0-T21	Pad comp - L. FR. SEAT CUSHION
20	90134-SE3-003	Screw - TAPPING, 5X10
22	90610-S10-003	Clip - GARNISH

Front seat (R.) 5

#	OEM	部品名
1	04810-SB3-000	C clip set - TRIM FASTENER (30 PIECES)
4	81127-TM0-T01	Pad comp - R. FR. SEATBACK
6	81137-TM0-T21	Pad comp - R. FR. SEAT CUSHION
17	90134-SE3-003	Screw - TAPPING, 5X10
19	90610-S10-003	Clip - GARNISH

Front seat components (L.) 4

#	OEM	部品名
1	81139-TM0-T01	Lever comp - FR. SEAT CUSHION SLIDE
2	81262-SNA-A01	Cap - SLIDE ADJUSTER UPPER END
7	81526-TM0-T21	Frame assy - L. FR. SEAT
10	90135-S5A-003	Bolt-washer - 10X27

Front seat components (R.) 4

#	OEM	部品名
5	81126-TM0-T01	Frame assy - R. FR. SEAT
6	81139-TM0-T01	Lever comp - FR. SEAT CUSHION SLIDE
7	81262-SNA-A01	Cap - SLIDE ADJUSTER UPPER END
8	90135-S5A-003	Bolt-washer - 10X27

Front shock absorber 22

#	OEM	部品名
1	51401-TM0-T21	Spring - FR.
1	51401-TM0-T31	Spring - FR.
2	51402-SLA-003	Seat - FR. SPRING UPPER CLIP
3	51608-SLJ-000	Cap - FR. DAMPER
4	51610-TM0-T62	Absorber assy - R. FR. SHOCK
4	51610-TM0-T72	Absorber assy - R. FR. SHOCK
5	51611-TM0-T31	Absorber unit - R. FR. SHOCK
6	51620-TM0-T62	Absorber assy - L. FR. SHOCK
6	51620-TM0-T72	Absorber assy - L. FR. SHOCK
7	51621-TM0-T31	Absorber unit - L. FR. SHOCK
8	51684-TG0-T01	Rubber - SPRING SEAT
9	51686-TG0-T01	Sleeve - FR. DUST COVER
10	51688-SCC-004	Seat comp - SPRING UPPER
11	51722-TF0-014	Rubber - FR. BUMP STOPPER
12	51726-SFA-005	Bearing, Shock Absorber Mounting
13	51920-TG0-T01	Rubber comp - FR. SHOCK ABSORBER MOUNTING
14	51925-TG0-T01	Damper comp - REBOUND STOP
15	90188-SCC-000	Bolt - FLANGE, 14X57.3
15	90188-SCC-A00	Bolt - FLANGE, 14X57.3
16	90213-SMA-003	Nut - SELF-LOCK, 14MM (CLINCH)
17	90215-TF0-000	Nut - HEX., 22MM
18	90551-SAA-000	Washer - WAVE, 12MM

Front sub frame 8

#	OEM	部品名
1	50200-TM0-G02	Sub frame comp. - FR.
2	50290-TF0-000	Stay - R. GEAR BOX
3	50295-TF0-G00	Stay - L. GEAR BOX
4	50400-TM0-003	Damper assy. - FR. SUB FRAME DYNAMIC
5	90160-SAA-000	Bolt - FLANGE, 14X67
6	90162-TF0-000	Bolt - FLANGE, 14X28
7	90163-S5A-000	Bolt - FLANGE, 10X20
8	90165-TF0-000	Bolt - FLANGE, 14X82

Front windshield 6

#	OEM	部品名
1	73111-TM0-Y00	Glass - FR. WINDSHIELD(GREEN)
2	73125-TM0-000	Rubber a - FR. WINDSHIELD DAM
3	73126-TM0-000	Rubber b - FR. WINDSHIELD DAM
4	73127-TM0-000	Rubber c - FR. WINDSHIELD DAM
7	73150-TM0-003	Molding - FR. WINDSHIELD
8	91568-TF0-003	Clip - FR. WINDSHIELD UPPER

Front windshield wiper 20

#	OEM	部品名
1	76505-TM0-Y01	Motor comp - FR. WIPER(LH)
2	76516-SEL-T01	Rubber - MOUNTING
3	76516-SR3-003	Rubber - MOUNTING
4	76517-SEL-T01	Collar
5	76517-SM4-003	Collar
6	76520-TM0-T01	Link assy. a
7	76524-SD4-003	Dust seal
8	76524-SE0-013	Dust seal
9	76530-TM0-Y01	Link comp - FR. WIPER(LH)
10	76540-TM0-T01	Rod unit a
11	76550-TM0-T01	Rod unit b
12	76561-SEL-T01	Cap - PIVOT
13	76600-TM0-G01	Arm - WINDSHIELD WIPER (LH) (DRIVER SIDE)
14	76610-TM0-G01	Arm - WINDSHIELD WIPER (LH) (PASSENGER SIDE)
15	76620-TM0-G01	Blade - WINDSHIELD WIPER (LH) (600MM)
16	76622-TM0-T01	Rubber - BLADE(600MM)
17	76630-TM0-G01	Blade - WINDSHIELD WIPER (LH) (375MM)
18	76632-TM0-T01	Rubber - BLADE(375MM)
19	90126-SR3-000	Bolt-washer - 6X32
20	91611-S5A-000	Cap - FR. WIPER

Fuel pipe 60

#	OEM	部品名
1	16050-TF0-G01	Pipe assy. - FUEL
2	16720-RB0-003	Hose comp. - FUEL FEED
3	16723-RB0-G00	Bracket comp. - FUEL FEED HOSE (A)
4	16724-RB0-G00	Bracket comp. - FUEL FEED HOSE (B)
5	16725-RAA-004	Cover a - FUEL CONNECTOR (LIGHT GRAY)
6	16725-RAC-003	Clamp - FUEL HOSE (NATURAL)
7	16726-PWA-004	Cover b - FUEL CONNECTOR (BLACK)
8	16727-PWA-004	Clamp - FUEL HOSE
9	16727-RB0-000	Clamp - FUEL FEED PIPE
10	17300-TF0-G02	Canister assy
11	17315-TF0-G01	Separator - DUST
12	17357-TF0-G00	Tube - SUB DRAIN
13	17358-TF0-G00	Bracket - CANISTER
14	17371-SLJ-003	Valve - TWO WAY
15	17372-TM0-G00	Tube comp. c - CANISTER DRAIN
16	17374-TF0-G00	Tube comp - CANISTER DRAIN (D)
17	17377-TF0-G00	Tube g - DRAIN
18	17379-TF0-G00	Tube j - DRAIN
19	17389-TF0-G01	Clamp k - FUEL PIPE
20	17700-TF0-G01	Pipe comp - FUEL FEED
21	17710-TF0-000	Tube assy. a - FUEL VENT
22	17711-S0X-A31	Retainer - GREEN)(TOKAI
23	17711-S0X-931	Retainer - BLUE GREEN) (TOKAI
24	17711-S84-004	Retainer - WHITE)(SANOH
25	17720-TM0-G01	Pipe - FUEL PURGE
26	17721-TF0-G00	Tube assy. b - FUEL VENT
27	17722-TF0-000	Tube assy. c - FUEL VENT
28	17725-TF0-G00	Tube assy - FUEL PURGE
29	17726-TF0-G00	Hose assy - FUEL PURGE
30	17730-TM0-G01	Pipe - FUEL VENT
31	17741-TF0-G00	Tube h - DRAIN
32	17742-S1A-E01	Joint - DRAIN TUBE
33	17743-TF0-G00	Tube a - DRAIN
34	17748-TF0-G00	Tube d - DRAIN
35	17759-SM4-000	Stopper - VENT PIPE
36	17761-TF0-G01	Stay a - FUEL PIPE
37	17762-TF0-G00	Stay b - FUEL PIPE
38	17763-TF0-G00	Stay c - FUEL PIPE
39	17763-TF0-000	Stay c - FUEL PIPE
40	17767-TF0-G00	Stay d - FUEL PIPE
41	90120-PZA-000	Bolt - FLANGE, 6X12
42	90301-SV7-000	Nut - PAINT CUTTING, 6MM
43	90361-SV4-003	Nut - PAINT CUTTING, 6MM
44	91402-SDC-000	Clip - TUBE(B12)
45	91404-SDC-000	Clamp - TUBE (D10)
46	91404-TA0-G01	Clamp - FUEL TUBE (D10)
47	91406-SAA-J00	Clamp - TUBE (D12)
48	91407-SDB-000	Clamp - TUBE (D12.5)
49	91503-SP0-013	Clip A - BUMPER
49	91503-SP0-003	Clip A
50	91592-TF0-G01	Clamp b - FUEL PIPE
51	91593-SDE-T01	Clip - DRAIN TUBE
52	91593-TF0-G01	Clamp c - FUEL PIPE
53	91594-TF0-G01	Clamp d - FUEL PIPE
54	91595-TF0-G01	Clamp e - FUEL PIPE
55	91596-SAA-931	Clamp - FUEL TUBE
56	91597-TF0-G01	Clip - SUB DRAIN TUBE
57	91598-S9A-A00	Rubber - FUEL PIPE INSULATOR
58	91598-TF0-G01	Clamp g - FUEL PIPE
59	91599-TF0-G01	Clamp h - FUEL PIPE

Fuel tank 31

#	OEM	部品名
1	17044-TG0-010	Tank set - FUEL
2	17045-TG0-000	Module set - FUEL PUMP
3	17046-TG0-000	Nut & packing set - FUEL LOCK
4	17047-TG0-000	Meter set
5	17048-TG0-000	Strainer set - FUEL
6	17052-TG0-000	Regulator set - PRESSURE
7	17513-TF0-000	Stopper - FUEL TANK
8	17518-TF0-000	Bracket - TANK GUARD
9	17519-TF0-000	Protector - FUEL TANK
10	17520-TF0-000	Band comp - FUEL TANK MOUNTING
11	17525-SAA-003	Bolt-washer - 10X45
12	17645-TF0-000	Cover - FILLER NECK TUBE
13	17651-TF0-003	Tube - FILLER NECK
14	17652-SDA-A31	Clip - FILLER TUBE
15	17652-SEL-003	Clip - FILLER TUBE (39MM)
16	17653-TF0-003	Tube a - BREATHER
17	17655-TF0-003	Tube - SUCTION
18	17656-TF0-003	Tube b - BREATHER
19	17659-TF0-003	Tube assy - SUCTION
20	17660-TM0-Y01	Pipe comp - FUEL FILLER
21	17670-SJA-013	Cap comp. FUEL FILLER
21	17670-T3W-003	CAP, FUEL FILLER
22	74615-TF0-003	Protector - FILLER NECK
23	74660-TF0-000	Cap assy. - FUEL MAINTENANCE HOLE
24	90150-S04-003	Bolt - EARTH, 6X16
25	90301-SV7-000	Nut - PAINT CUTTING, 6MM
26	91404-SDC-000	Clamp - TUBE (D10)
27	91414-SEL-003	Clamp - TUBE (D11.5)
28	91417-SEL-003	Clamp - FUEL TUBE(D20) (TOPY FASTENERS)
29	91417-SZ3-003	Clamp - FUEL TUBE (D20) (CHUO HATSUJO)
30	91601-TA0-003	Clip - FUEL MAINTENANCE HOLE CAP

Gasket kit 4

#	OEM	部品名
1	06110-RB0-010	Gasket kit - CYLINDER HEAD
2	06111-RB1-Y00	Gasket kit - CYLINDER BLOCK
3	06112-RMM-000	Gasket kit - AT TRANSMISSION
4	06114-RB0-000	Gasket kit - CHAIN CASE

Grommet (FRONT) 13

#	OEM	部品名
1	72207-SB2-000	Cap - FLOOR HOLE, 24MM
2	74144-SE0-000	Cushion - HOOD
3	82871-671-000	Grommet - DRAIN HOLE, 25MM
4	90602-TM0-T01	Holder - HOOD OPENER STAY
5	90615-SM4-000	Cap - WELD HOLE, 46X72
6	90820-SNA-003	Grommet - 20MM
7	91604-SNA-A01	Grommet - HOOD STAY
8	91615-SH3-000	Cap - FLOOR HOLE, 49MM
9	91616-SAA-000	Block - FR. PILLAR INNER LOWER
10	91616-S04-000	Block - FR. PILLAR INNER LOWER
11	91618-SE3-010	Seal - RR. PILLAR UPPER
12	91618-TM0-000	Seal - 65X120
13	91619-SE0-000	Seal - DOOR HOLE, 30MM(BLACK)

Grommet (LOWER) 4

#	OEM	部品名
1	82871-671-000	Grommet - DRAIN HOLE, 25MM
2	85268-SA0-000	Protection - TAILGATE, 20MM (CIRCLE)
3	90810-SB2-660	Grommet - TIE DOWN, 20X35
4	91606-SK7-003	Plug - BLIND, 25MM

Grommet (REAR) 6

#	OEM	部品名
1	82871-671-000	Grommet - DRAIN HOLE, 25MM
2	85268-SA0-000	Protection - TAILGATE, 20MM (CIRCLE)
3	90665-SS0-003	Grommet - RR. COMBINATION
4	91610-SD4-000	Plug - HOLE, 28MM
5	91619-TM0-000	Seal - RR. PILLAR INNER
6	91657-SP0-000	Seal c - DOOR PANEL HOLE (25MM)

Harness band/bracket 33

#	OEM	部品名
1	32101-TF0-G00	Bracket - HARNESS CLAMP (LH)
2	32118-P72-003	Holder - CORRUGATED(DARK GREEN) (19MM)
3	32124-TF0-000	Bracket - L. CABIN WIRE HARNESS
4	32133-SLA-003	Band - HARNESS OFFSET(30) (DARK GRAY)(145MM)
5	32134-SM4-003	Band - HARNESS OFFSET (10) (BROWN) (122.5MM)
6	90361-SV4-003	Nut - PAINT CUTTING, 6MM
7	90652-SM5-003	Band - HARNESS OFFSET (122.5MM) (DARK GRAY)(WITH SEAL)
8	91507-RTA-003	Clip b - HARNESS BAND (DARK GREEN) (129.4MM)
9	91507-SNA-003	Clip - HARNESS BAND(BROWN) (164.5MM)
10	91507-693-003	Clip - WIRE HARNESS (BLACK) (50MM) (HARNESS TAPING)
11	91531-SDA-003	Clip - HARNESS BAND (NATURAL) (145MM)
12	91531-S04-003	Clip - WIRE HARNESS(NATURAL) (44MM)
13	91531-S84-003	Clip - WIRE HARNESS(NATURAL) (44MM)(WITH SEAL)
14	91533-STK-003	Clip - COUPLER(NATURAL)
15	91533-SYA-003	Clip - COUPLER (10MM OFFSET)
16	91534-STK-003	Clip - COUPLER(NATURAL) (WITH SEAL)
18	91540-STK-003	Clip - HARNESS BAND (BLACK) (155.3MM)
19	91540-TA0-003	Clip - HARNESS BAND(NATURAL) (100.1MM)
20	91542-SNA-003	Clip - HARNESS BAND(DARK BLUE) (164.5MM)
21	91542-TF0-003	Band - HARNESS OFFSET(20) (DARK BLUE)(145MM)
22	91545-SNA-003	Clip - HARNESS BAND(DARK BLUE) (164.5MM)(WITH SEAL)
23	91545-SV4-003	Clip - HARNESS BAND (NATURAL) (145.2MM) (WITH SEAL)
24	91545-S2A-003	Clip - HARNESS BAND (BROWN) (151MM) (WITH SEAL)
25	91545-TA0-003	Clip - HARNESS BAND(NATURAL) (100.1MM)(WITH SEAL)
26	91547-SH3-003	Clip - BAND(NATURAL)(160MM)
27	91556-SVA-A01	Clip - BAND(HARNESS & CABLE) (BLACK)
28	91558-SAA-003	Clip - HARNESS BAND(30)(BLACK) (151.5MM)
29	91559-S47-003	Clip - HARNESS BAND(NATURAL) (167MM)
30	91619-SE0-000	Seal - DOOR HOLE, 30MM(BLACK)
31	91705-TF0-300	Cover - COUPLER
32	91902-S2X-003	Plaster - WIRE HARNESS(50X100)
33	91902-S3N-003	Plaster - WIRE HARNESS (50X50)
35	32119-R40-003	Holder - CORRUGATED (BLACK) (19MM)

Headlight 15

#	OEM	部品名
1	33100-TM0-Y01	Headlight assy - R.
2	33105-S5N-C01	Nut - SPECIAL
3	33115-SM4-003	Bulb
3	33115-SV4-G01	Bulb - HEADLIGHT (H4/HB2) (12V 60/55W) (PHILIPS)
3	33115-SV4-003	Bulb - HEADLIGHT (H4) (12V 60/55W) (TUNGSRAM)
4	33126-S05-003	Cover - RUBBER
5	33130-SJK-J01	Adjuster unit - HEADLIGHT
6	33150-TM0-Y01	Headlight assy - L.
7	33301-SA0-741	Bulb (12V 5W) - (12V 5W) (STANLEY)
8	33301-S5H-T01	Bulb - WEDGE BASE (WY 12V 5W) (STANLEY) (AMBER)
9	33303-SAA-003	Socket comp - T20 S) (AMBER
10	33303-S2R-003	Bulb - WEDGE (12V 21W) (STANLEY) (AMBER)
11	33304-S5A-003	Socket comp - T10
12	34301-S5H-T02	Lamp unit
13	34303-SX0-003	Socket comp. - 2P

Heater blower 13

#	OEM	部品名
1	79305-TG0-P01	Blower sub assy.
2	79306-TG0-T01	Seal - BLOWER OUTER
3	79307-TG0-T01	Packing - AIR INTAKE
4	79310-TM0-G01	Motor assy. - FAN
6	79810-TM0-G01	Duct - INTAKE
7	80292-TF0-G01	Element - FILTER
7	80292-TGL-E01	ELEMENT FILTER KEI
8	80293-TF0-G01	Seal - FILTER
9	80297-TF0-G01	Frame set - FILTER
11	90132-SFA-003	Screw - TAPPING, 5X16
12	90155-SFA-003	Screw - TAPPING, 6X20
13	90321-SV4-003	Nut-washer - 6MM (PAINT CUTTING)
14	90665-SM4-000	Grommet - SCREW, 4MM (YELLOW)

Heater control 12

#	OEM	部品名
1	35854-TM0-T01	Bulb comp. - 14V 60MA
2	35857-TM0-T01	Bulb comp. - 14V 80MA
4	79502-TM0-G01	Base comp. - HEATER CONTROL
6	79555-TM0-T01	Bulb - T6.5
7	79555-TM0-T11	Bulb - T5
8	79570-TM0-T01	Switch assy - HEATER FAN
9	79575-TM0-T00	Sub cord - FAN SWITCH
13	79675-TM2-P01	Cable - FRESH & RECIRCULAR
14	79680-TM0-G01	Cable - TEMPERATURE
15	79685-TM2-P01	Cable - MODE
17	80460-TM0-T00	Sub cord - ILLUMINATION
18	91540-TA0-003	Clip - HARNESS BAND(NATURAL) (100.1MM)

Heater unit 27

#	OEM	部品名
2	39248-692-003	Packing - HEATER
3	79021-SNA-A01	Seal a
4	79023-TF0-G01	Seal c
5	79102-TF0-G01	Duct assy - PASSENGER HEATER
6	79103-TF0-G01	Packing set - VENT
7	79105-TF0-G01	Duct - DRIVER HEATER
8	79106-TM0-G01	Heater sub assy.
9	79107-TF0-G01	Cover - HEATER CORE
10	79110-TF0-G01	Core sub assy. - HEATER
11	79111-TF0-G01	Stay - HEATER PIPE
14	79308-TM0-G01	Joint set - DUCT
16	79335-TF0-G01	Resistor assy.
17	79336-TG0-T00	Sub cord - RESISTOR
18	80211-TF0-G01	Evaporator comp.
19	80213-TF0-G01	Valve assy. - EXPANSION
20	80271-TF0-G00	Hose - DRAIN
21	80381-TF0-G01	Clip - DRAIN HOSE
23	80560-TA0-A01	Thermistor - AIR CONDITIONER
24	80566-SMA-003	Clip - EVAPORATOR SENSOR
25	80871-ST7-000	O-ring - 5/8"
26	80872-ST7-000	O-ring - 1/2"
27	90121-SFA-003	Screw - TAPPING, 4X16
28	90121-SFA-941	Screw - TAPPING, 4X16
29	90126-S5A-003	Bolt - SOCKET, 5X40
30	90127-SFA-003	Screw - TAPPING, 4X16
31	90321-SV4-003	Nut-washer - 6MM (PAINT CUTTING)
32	91533-STK-003	Clip - COUPLER(NATURAL)

Idle shaft 4

#	OEM	部品名
1	23515-RPC-020	Gear - IDLE
2	23516-RG5-000	Shaft - IDLE
3	90431-PRP-000	Cotter - 17MM
4	90432-PRP-000	Retainer - COTTER

Instrument panel 18

#	OEM	部品名
2	66844-SA7-000	Cap - INSTRUMENT PANEL STAY
4	77104-TM0-000	Felt - INSTRUMENT
8	77370-TM0-G00	Pad - DRIVER INSIDE
9	77375-TM0-G00	Pad - DRIVER OUTSIDE
10	77466-S2G-000	Seal - FR. INSTRUMENT
13	77550-TM0-T00	Frame - GLOVE BOX
16	90107-S7S-000	Bolt-washer - 8X50
17	90108-SF1-000	Bolt-washer - 6X15
18	90111-SLJ-000	Bolt-washer - 8X80
19	90111-SWA-A01	Bolt-washer - 8X62
20	90112-SMA-003	Bolt-washer - 8X103.5
21	90113-SAA-003	Bolt - SPECIAL, 6X14
22	90134-SFA-N81	Bolt - FLANGE, 6X20 (ADHESIVE)
23	90140-SH3-003	Bolt-washer - 5X18
24	90140-TF0-000	Bolt - FLANGE, 6X30
25	90302-SA4-003	Nut - SPRING, 4MM
26	90666-SDA-A01	Clip, Snap Fitting - SNAP FITTING(PO) (NATURAL)
27	91640-SM4-003	Grommet - SCREW, 4MM

Instrument panel garnish (DRIVER SIDE) 9

#	OEM	部品名
1	66418-579-000	Stopper - GLOVE BOX LID
2	66844-SA7-000	Cap - INSTRUMENT PANEL STAY
4	77285-SLA-003	Rubber - STOPPER
8	77355-TM0-T00	Blind - COLUMN
11	77752-SF4-000	Spring - COIN POCKET
13	90101-S2K-000	Screw - TAPPING, 4X16(IT)
14	90666-SDA-A01	Clip, Snap Fitting - SNAP FITTING(PO) (NATURAL)
15	90666-TA0-A21	Clip - SNAP FITTING (PO) (ORANGE)
16	90669-SHJ-A01	Clip - SNAP FITTING

Instrument panel garnish (PASSENGER SIDE) 11

#	OEM	部品名
1	39610-SEL-003	Knob assy
2	39620-S2K-003	Socket assy
3	39624-S2K-003	Ring
4	66417-SB3-670	Rubber - GLOVE BOX STOPPER
5	66418-SB2-000	Stopper - GLOVE BOX LID
6	66844-SA7-000	Cap - INSTRUMENT PANEL STAY
13	77515-SZ3-A02	Hinge - GLOVE BOX
14	77541-TM0-G00	Striker comp. - GLOVE BOX
17	90140-SH3-003	Bolt-washer - 5X18
18	90666-SDA-A01	Clip, Snap Fitting - SNAP FITTING(PO) (NATURAL)
19	90669-SHJ-A01	Clip - SNAP FITTING

Intake manifold 18

#	OEM	部品名
1	16450-RNA-A01	Injector assy - FUEL
2	16451-PLC-000	Clip - INJECTOR
3	16620-RB0-003	Pipe comp - FUEL
4	16638-PT2-000	Insulator - FUEL PIPE
5	17100-RB7-Z00	Manifold comp - INTAKE
6	17105-RB0-004	Gasket - INTAKE MANIFOLD
7	17107-RB0-007	Packing - THROTTLE BODY
8	17110-RB1-000	Chamber comp - INTAKE MANIFOLD
9	17115-RB0-007	Packing - INTAKE PORT
10	17116-RB0-000	Plate - THROTTLE FLANGE
11	17117-RB0-000	Plate - INTAKE MANIFOLD FLANGE
12	17132-RB0-000	Stay comp. a - INTAKE MANIFOLD
13	17134-RB1-000	Stay comp. b - INTAKE MANIFOLD
14	32741-RB7-Z00	Stay - ENGINE HARNESS
15	37830-RNA-A01	Sensor assy - MAP
16	37835-PGK-A01	O-ring
17	91301-PLC-000	O-ring - 7.47X3.6
18	91302-PNA-003	O-ring - 7.45X3.61(NOK)

Interior light 6

#	OEM	部品名
1	34251-S6A-003	Lens
3	34253-S6A-003	Bulb - 12V 8W)(T10)(ICHIMITSU
5	34261-S5A-003	Lens comp
6	34295-SJ8-003	Bulb - 12V 5W) (DAIICHI
6	34351-657-921	Bulb - 12V/5W) (STANLEY
10	90148-S6A-013	Bolt - EARTH, 5X14

Key cylinder components 10

#	OEM	部品名
1	35102-SV4-003	Bolt - BREAK HEAD
2	35103-S04-003	Screw - RECESSED
3	35108-S30-003	Holder - COLUMN
4	35111-SWA-A01	Key comp. - IMMOBILIZER (MAIN) (H-MARK:SILVER)
4	35111-SNB-A01	Key comp. - IMMOBILIZER (MAIN) (BLACK)
5	35111-SWA-305	KEY COMP., IMMOBILIZER (MAIN) (BLANK) (H-MARK:SILVER) - IMMOBILIZER (MAIN) (BLANK)(H-MARK:SILVER)
5	35118-SNB-A00	Key comp. - IMMOBILIZER (MAIN) (BLANK)(BLACK)
12	35130-SAA-J51	Switch comp - STEERING
13	39730-SWC-P01	Immobilizer & keyless unit
14	72118-ST7-003	Screw - TAPPING, 3X5

Key cylinder set 4

#	OEM	部品名
3	06350-TM0-Y01	Cylinder set - KEY
3	06350-TM0-Y11	Cylinder set - KEY
4	06351-TF0-A01	Lock assy - STEERING
4	06351-TF0-A11	Lock assy - STEERING

L. side cover 42

#	OEM	部品名
1	21240-RMM-000	Cover comp. - L. SIDE
2	21515-RPC-000	Stay c - HARNESS
3	21720-RPC-000	Cover comp. - POSITION SENSOR
4	21722-RPC-000	Stopper - POSITION SENSOR
5	21724-RCT-000	Rubber - POSITION SENSOR COVER
6	21725-RCT-000	Collar - POSITION SENSOR COVER
7	21812-RMM-000	Packing - L. SIDE COVER
8	22713-PW4-000	Guide a - FEED PIPE
9	22713-RPC-000	Guide a - FEED PIPE
10	22715-PRP-000	Pipe comp. b - FEED
11	24282-634-000	Bolt - SHAFT FORK SETTING
12	24532-PX4-000	Lever - PARKING BRAKE
13	24535-RPC-000	Spring - PARKING BRAKE
14	24539-PA9-003	Stopper - PARKING BRAKE (3)
14	24538-PA9-003	Stopper - PARKING BRAKE (2)
14	24537-PA9-003	Stopper - PARKING BRAKE (1)
15	24552-PRP-000	Spring - PARKING PAWL
16	24553-PN6-000	Roller - PARKING BRAKE
17	24555-RDK-000	Pin - ROLLER, 6MM
18	24561-RG0-000	Pawl - PARKING BRAKE
19	24562-PRP-000	Shaft - PARKING
20	27430-RPC-003	Bolt comp - AIR CHECK
21	28900-RCT-024	Sensor assy - POSITION
22	28950-RR4-000	Harness - POSITION SENSOR
23	90024-RPC-000	Bolt - SEALING, 10MM
24	90024-612-000	Bolt - SEALING, 8MM
25	90433-639-000	Washer - LOCK, 6MM
26	90471-PW7-A00	PACKING, 10MM
27	90471-580-000	Packing - 8MM
28	90472-RPC-000	Packing - 10MM
29	90602-PX4-000	Circlip b - INTERNAL, 47MM
30	90702-PL4-000	Dowel pin - 8X44
31	91006-P1B-003	Bearing - BALL, 9X20X6
32	91102-RPC-003	Bearing - NEEDLE, 30X52X19
33	91201-PA9-004	Oil seal - 9X18X7 (ARAI)
34	91301-PC9-003	O-ring - 7.7X2.3 (ARAI)
35	91304-RPC-003	O-ring - 39X1.9
36	91305-PC9-003	O-ring - 34X1.9 (ARAI)
37	91311-PA9-004	O-ring - 7.7X1.9 (NOK)
38	91314-PW4-003	O-ring - 11X1.9 (NOK)
39	91506-RTA-003	Clip A - HARNESS BAND (DARK VIOLET)(129.4MM)
44	90001-RLJ-000	Bolt - FLANGE, 6X18

Main valve body 11

#	OEM	部品名
1	22771-RPC-000	Pipe a - JOINT
2	22772-RPC-000	Pipe b - JOINT
3	25145-PA9-010	Shaft - OIL PUMP GEAR
4	27000-RPC-000	Body assy - MAIN VALVE
5	27112-RPC-000	Plate - MAIN SEPARATING
6	27122-RGC-000	Cap - 11MM
7	27132-P6H-000	Cap - 14MM
8	27142-P6H-000	Cap - 15MM
9	27263-PX3-000	Seat - VALVE SPRING
10	27524-P6H-000	Clip - CAP
11	91108-PRP-003	Roller - 4X23.8

Mainshaft 42

#	OEM	部品名
1	23211-RF0-A00	Mainshaft
1	22814-PRP-003	Ring - SEALING, 29MM
2	23261-PL3-000	Shaft - REVERSE GEAR
2	23210-RPC-000	Mainshaft comp.
3	23440-RF0-B00	Gear comp - MAINSHAFT THIRD
3	23455-RPC-J00	Gear - MAINSHAFT THIRD
4	23450-RF0-B00	Gear comp - MAINSHAFT FOURTH
4	23481-RG5-000	Gear - MAINSHAFT FIFTH
5	23540-PLW-000	Gear - REVERSE IDLE
5	23511-RPC-000	Gear - MAINSHAFT IDLE
6	23581-RF0-B00	Gear - MAINSHAFT FIFTH
6	90203-RPC-000	Nut - FLANGE, 22MM
7	23623-RF0-305	Sleeve set - SYNCHRONIZER(3-4)
7	90402-RPC-000	Washer - SPRING, 22MM
8	23626-REM-305	Sleeve set - SYNCHRONIZER (5)
8	90422-RG0-000	Washer - THRUST, 40X63X3.950
8	90417-RG0-000	Washer - THRUST, 40X63X3.825
8	90424-RG0-000	Washer - THRUST, 40X63X4.000
8	90419-RG0-000	Washer - THRUST, 40X63X3.875
8	90414-RG0-000	Washer - THRUST, 40X63X3.750
8	90421-RG0-000	Washer - THRUST, 40X63X3.925
8	90416-RG0-000	Washer - THRUST, 40X63X3.800
8	90423-RG0-000	Washer - THRUST, 40X63X3.975
8	90418-RG0-000	Washer - THRUST, 40X63X3.850
8	90420-RG0-000	Washer - THRUST, 40X63X3.900
8	90415-RG0-000	Washer - THRUST, 40X63X3.775
9	23647-PLW-000	Ring - TAPER CONE
9	90501-RPC-000	Collar - 27X32X60.5
10	23915-PHR-010	Collar - DISTANCE, 29X35X52
10	90603-P0X-000	Set ring - 23MM
11	23916-PLW-000	Collar - DISTANCE, 26X35X12
11	91014-RPC-003	Bearing - NEEDLE, 32X37X24
12	23927-PL3-000	Washer - SPRING, 36MM
12	91016-RPC-003	Bearing - NEEDLE, 47X52X15.5
13	23928-PL3-000	Washer - 26MM
13	91017-PZK-003	Bearing - NEEDLE, 23X29X18
14	91004-PLW-B01	Bearing - ANGULAR BALL
14	91022-RPC-003	Needle - THRUST, 32X44X2
15	91105-PHR-003	Bearing - NEEDLE, 35X39X24
15	91023-RPC-003	Needle - THRUST, 32X51.5X2.5
16	91024-RPC-003	Needle - THRUST, 52.5X66.5X2
17	91316-PR9-003	O-ring - 33X1.9 (ARAI)

Meter (NS) 6

#	OEM	部品名
1	37115-SA0-601	Packing - NS
2	78100-TM0-Y02	Meter assy - COMBINATION
2	78100-TM0-Y12	Meter assy - COMBINATION
3	78156-TM0-G31	Lens
4	90302-SA4-003	Nut - SPRING, 4MM
5	91640-SM4-003	Grommet - SCREW, 4MM

Mirror (1) 22

#	OEM	部品名
2	76203-TM0-T01	Mirror comp - R.(1400)
3	76205-TM0-T01	Housing set - R.
4	76207-TM0-Y01	Bracket comp. - R.(R.C.)
5	76208-TM0-Y31	Mirror assy - R. DOOR(R.C.)
6	76210-TM0-T01	Actuator comp. - R.(R.C.)
7	76215-TM0-T01	Actuator comp. - L.(R.C.)
8	76220-TM0-T01	Garnish - R. DOOR MIRROR
10	76253-TM0-T01	Mirror comp - L.(1400)
11	76255-TM0-T01	Housing set - L.
12	76257-TM0-Y01	Bracket comp. - L.(R.C.)
13	76258-TM0-Y31	Mirror assy - L. DOOR(R.C.)
14	76270-TM0-T01	Garnish - L. DOOR MIRROR
15	76401-S5H-003	Base
16	76403-SAA-000	Holder - RR. VIEW MIRROR
17	76409-SX8-T01	Catch
18	76410-SX8-T01	Screw - PAN, 6X8
20	90107-SFA-003	Screw - TAPPING, 3X12
21	90109-SDF-003	Screw - TAPPING, 4X14
22	90109-SFA-003	Screw-washer - 5X12
23	90109-SHJ-003	Screw - TAPPING, 4X16(TRUSS)
24	90615-SK7-003	Clip - MIRROR GARNISH
25	91565-SEA-003	Clamp - HARNESS

Molding 22

#	OEM	部品名
1	72410-TM0-T01	Molding assy. - R. FR. DOOR
2	72430-TM0-T01	Garnish - R. FR. DOOR SASH
3	72450-TM0-T01	Molding assy. - L. FR. DOOR
4	72470-TM0-T01	Garnish - L. FR. DOOR SASH
5	72721-TM0-T01	Garnish - R. RR. DOOR RR. PILLAR
6	72761-TM0-T01	Garnish - L. RR. DOOR RR. PILLAR
7	72910-TM0-T01	Molding assy. - R. RR. DOOR
8	72930-TM0-T01	Garnish - R. RR. DOOR SASH
9	72950-TM0-T01	Molding assy. - L. RR. DOOR
10	72970-TM0-T01	Garnish - L. RR. DOOR SASH
11	74306-TM0-T01	Molding assy. - R. ROOF
12	74316-TM0-T01	Molding assy. - L. ROOF
13	74551-TM0-T00	Cover - R. RR. FENDER
14	74556-TM0-T00	Cover - L. RR. FENDER
20	75490-TM0-Y01	Garnish assy - R. FR. CORNER PILLAR
21	75495-TM0-Y01	Garnish assy - L. FR. CORNER PILLAR
26	76222-SP1-003	Clip - DOOR MIRROR COVER
27	90103-SDA-A00	Screw - TAPPING, 5X20
28	90126-SR4-000	Screw-washer - 5X16
30	90142-S04-000	Screw - TAPPING, 4X10
32	90331-679-003	Nut - SPRING, 5MM
33	91503-SZ3-003	Clip A

Oil pump/oil strainer 11

#	OEM	部品名
1	15100-RB0-003	Pump assy. - OIL
3	15220-RB1-000	Strainer comp. - OIL
4	15221-PZ1-000	Packing - OIL STRAINER
5	15231-413-020	Valve - RELIEF
6	15232-PHM-003	Spring - RELIEF VALVE
7	15233-PFB-003	Bolt - SEALING, 18MM
8	15400-RAF-T01	Cartridge - OIL FILTER (MAHLE TENNEX)
9	90015-PH1-013	Holder - OIL FILTER
10	90042-PR3-000	Bolt - STUD, 6X28
10	90041-PA5-000	Bolt - STUD, 6X28
11	91326-PF4-004	O-ring - 24.4X2.4 (NOK)

Outer panels/rear panel 17

#	OEM	部品名
9	63136-TG0-Z01	Separator - R. FR. PILLAR INSIDE
10	63139-TM0-T01	Separator - R. FR. PILLAR OUTSIDE
12	63219-TM0-T01	Separator - R. CENTER PILLAR OUTSIDE
14	63223-TM0-T01	Separator - R. CENTER PILLAR INSIDE
17	63536-TG0-Z01	Separator - L. FR. PILLAR INSIDE
18	63539-TM0-T01	Separator - L. FR. PILLAR OUTSIDE
20	63619-TM0-T01	Separator - L. CENTER PILLAR OUTSIDE
22	63623-TM0-T01	Separator - L. CENTER PILLAR INSIDE
28	74470-SAA-003	Packing - FUEL LID LOCK
29	74480-TM0-T00	Adapter assy - FUEL FILLER
30	74486-TF0-003	Lifter - FUEL LID PUSH
31	74490-TM0-T00	Grommet - FUEL LID
32	74494-TM0-T01	Spring - FUEL LID OPEN
33	74700-TF0-003	Actuator assy - FUEL LID
34	75450-SDE-T00	Outlet assy - RR. AIR
35	90113-TM0-T00	Bolt - HEX., 5X8
36	90853-SJA-A00	Rivet - 4.8MM

P.s. gear box (EPS) 29

#	OEM	部品名
1	53010-TF0-003	End comp - RACK
2	53413-SCC-003	Spring - RACK GUIDE PRESSURE
3	53414-S04-003	Screw - RACK GUIDE
4	53416-TF0-003	Guide comp - STEERING RACK
5	53417-SCC-003	O-ring - RACK GUIDE
6	53418-S04-G51	Washer - DISK
7	53434-TF0-003	Clip - STEERING TIE ROD
8	53449-S5A-J01	Band a - BELLOWS
9	53458-S50-003	Nut - LOCK
10	53501-TF0-G00	Grommet - STEERING
11	53429-TF0-003	Seal set - TIE ROD DUST
12	53536-SDA-A02	Washer - TIE ROD LOCK
13	53537-S84-A01	Rubber - STOPPER
14	53540-TF0-003	End comp - R. TIE ROD
15	53546-S84-003	Boot - TIE ROD END (NOK)
16	53560-TF0-003	End comp - L. TIE ROD
17	53601-TF0-G96	BOX, STEERING GEAR
18	53602-TF0-G03	Motor comp
19	53684-TF0-003	Bush - STEERING GEAR BOX MOUNTING
20	53685-TF0-003	Bush - STEERING GEAR BOX MOUNTING
21	53686-TF0-003	Bush - STEERING GEAR BOX MOUNTING
22	53692-TF0-G01	Guard - HEAT
23	53752-TF0-G01	Stay b
24	90103-S0A-N01	Screw - PAN, 5X8
25	90167-ST7-000	Bolt - FLANGE, 10X60
26	90428-S0A-003	Washer - DRAIN
27	90505-TF0-000	Washer - PLAIN, 10MM
28	91411-S84-A01	Nut - HEX., 14MM
33	91351-S5A-003	O-ring - MOTOR

Parking brake 10

#	OEM	部品名
1	42514-SEL-T01	Clamp - WIRE
2	43115-ST5-004	Clip - WIRE
4	47342-TG0-T01	Switch - PARKING BRAKE
5	47360-SX8-T00	Equalizer
6	47365-SX8-T00	Pin - PARKING BRAKE EQUALIZER
7	47370-TG0-T01	Guide - EQUALIZER
8	47510-TM0-T01	Wire b - R. PARKING BRAKE
10	47538-S2R-000	Nut - ADJUSTER
11	47560-TM0-T01	Wire b - L. PARKING BRAKE
13	47572-SAA-000	Base - WIRE GUIDE

Pedal 15

#	OEM	部品名
1	17800-TF0-G01	Pedal assy - ACCELERATOR
2	35350-SMA-003	Switch assy - STOP (PANASONIC)
4	46505-SA5-000	Pad - PEDAL STOPPER
5	46530-TF0-981	Spring assy - PEDAL RETURN
6	46545-S1F-981	Cover - PEDAL
7	46545-538-010	Cover - PEDAL
8	46600-TF0-G01	Pedal assy - BRAKE
8	46600-TF0-G81	Pedal assy - BRAKE
9	46910-TF0-G51	Pedal comp - CLUTCH
10	46911-SD4-930	Bush - PEDAL PIN
11	46991-TF0-G00	Bracket - FOOTREST
12	46992-TF0-G01	Plate - FOOTREST
13	75891-611-000	Cover - DOOR SWITCH
14	90361-SV4-003	Nut - PAINT CUTTING, 6MM
15	90361-S3C-003	Nut - PAINT CUTTING, 8MM

Pillar garnish 9

#	OEM	部品名
1	38205-TM0-T00	Label - FUSE
2	72315-TM0-T02	Seal - FR. DOOR OPENING
3	72815-TM0-T02	Seal - R. RR. DOOR OPENING
4	72855-TM0-T02	Seal - L. RR. DOOR OPENING
19	90669-SHJ-A01	Clip - SNAP FITTING
20	91560-SLJ-J01	Clip - DOOR LINING (LIGHT GRAY)
21	91560-SLJ-003	Clip - PILLAR GARNISH
22	91560-SYA-J01	Clip - PILLAR GARNISH (DARK GREEN)
23	91560-SYY-003	Clip - PILLAR GARNISH

Piston/crankshaft 37

#	OEM	部品名
1	13020-RB7-Z00	Piston set - OS 0.25
1	13010-RB1-000	Piston set - STD.
2	13021-RB7-Z02	Ring set - PISTON(OS 0.25) (NIPPON)
2	13021-RB7-Z01	Ring set - PISTON(OS 0.25) (RIKEN)
2	13011-RB1-004	Ring set - PISTON (STD.) (RIKEN)
3	13111-PWA-000	Pin - PISTON
4	13204-PWA-003	Bolt - CONNECTING ROD
5	13210-RB1-000	Rod comp - CONNECTING
6	13217-REA-Z01	Bearing g - CONNECTING ROD (RED) (DYNA)
6	13212-REA-Z01	Bearing b - CONNECTING ROD (BLACK) (DYNA)
6	13214-REA-Z01	Bearing d - CONNECTING ROD (GREEN) (DYNA)
6	13216-REA-Z01	Bearing f - CONNECTING ROD (PINK) (DYNA)
6	13211-REA-Z01	BEARING A - CONNECTING ROD (BLUE) (DYNA)
6	13213-REA-Z01	Bearing c - CONNECTING ROD (BROWN) (DYNA)
6	13215-REA-Z01	Bearing e - CONNECTING ROD (YELLOW) (DYNA)
8	13310-RB1-000	Crankshaft comp.
9	13324-REA-Z01	Bearing d - MAIN UPPER (GREEN) (DYNA)
9	13326-REA-Z01	Bearing f - MAIN UPPER (PINK) (DYNA)
9	13328-REA-Z01	Bearing h - MAIN UPPER (WHITE) (DYNA)
9	13323-REA-Z01	Bearing c - MAIN UPPER (BROWN) (DYNA)
9	13325-REA-Z01	Bearing e - MAIN UPPER (YELLOW) (DYNA)
9	13327-REA-Z01	Bearing g - MAIN UPPER (RED) (DYNA)
9	13322-REA-Z01	Bearing b - MAIN UPPER (BLACK) (DYNA)
10	13331-REA-Z01	Washer - THRUST (DYNA)
11	13345-REA-Z01	Bearing e - MAIN LOWER (YELLOW) (DYNA)
11	13347-REA-Z01	Bearing g - MAIN LOWER (RED) (DYNA)
11	13342-REA-Z01	Bearing b - MAIN LOWER (BLACK) (DYNA)
11	13344-REA-Z01	Bearing d - MAIN LOWER (GREEN) (DYNA)
11	13346-REA-Z01	Bearing f - MAIN LOWER (PINK) (DYNA)
11	13348-REA-Z01	Bearing h - MAIN LOWER (WHITE) (DYNA)
11	13343-REA-Z01	Bearing c - MAIN LOWER (BROWN) (DYNA)
12	13621-RB0-003	Sprocket - CAM CHAIN DRIVE
13	13623-RB0-000	Plate - CRANK PULSER
14	13810-RB0-003	Pulley comp - CRANKSHAFT
15	90013-RB0-003	Bolt - SPECIAL, 8X9
16	90017-PWA-G02	Bolt-washer - 14X36
17	90704-PH7-000	Key, SPECIAL

Plug top coil/plug 4

#	OEM	部品名
1	12290-RB1-003	Plug - SPARK (IZFR6K13) (NGK)
2	30511-RB0-000	Insulator - PLUG TOP COIL HEAT
3	30520-RB0-003	Coil assy - PLUG TOP
4	90015-PWA-000	Bolt-washer - 6X14

Radiator (T.RAD) 16

#	OEM	部品名
1	19010-RB7-Z01	Radiator comp. - T.RAD
1	19010-RB7-Z51	Radiator comp. - T.RAD
2	19011-PH2-004	Cock - DRAIN (T.RAD)
3	19012-PD2-004	Packing - DRAIN (T.RAD)
4	19015-RB0-004	Shroud comp.
5	19020-RB0-004	Fan comp - COOLING
6	19030-RB0-004	Motor - COOLING FAN
7	19045-PWA-004	Cap comp. - RADIATOR (T.RAD)
9	19046-RAA-A00	Label - RADIATOR CAP
10	19047-RB0-004	Cover - RADIATOR CAP
11	37870-RWC-A01	Water Temp Sensor assy - (PANASONIC)
12	90041-PAA-A01	Nut - TOOTHED, 5MM
13	90042-PZ1-004	Bolt-washer - 6X20
14	90050-R40-A01	Screw - WASHER (5X12)
15	90403-P5M-004	Spacer - FAN, 8MM (MITSUBA)
16	91307-PLC-004	O-ring - 9.5X1.9 (MATSUSHITA)

Radiator hose/reserve tan k 18

#	OEM	部品名
1	19101-RB0-000	Tank comp. - RESERVE
2	19102-RNA-A00	Cap - RESERVE TANK
3	19103-PLC-000	Hose a - RESERVE TANK
4	19104-RB0-000	Hose b - RESERVE TANK
5	19106-RSA-G00	Joint - RESERVE TANK
6	19501-RD7-Z00	Hose - WATER UPPER
7	19502-RD7-Z00	Hose - WATER LOWER
8	19511-P08-004	Clip - WATER HOSE (KATO HATSUJO)
8	19511-PA6-003	Clip - WATER HOSE(CHUO SPRING)
9	19511-P3S-T01	Clip - WATER HOSE (TOPY FASTENERS)
10	25213-P5P-003	Hose - ATF, 390MM
11	25214-RBA-013	Hose - ATF, 320MM
12	74171-TM0-T00	Bracket - R. RADIATOR UPPER MOUNTING
13	74172-SS0-000	Cushion - RADIATOR MOUNTING LOWER
14	74173-SJ4-000	Cushion - RADIATOR MOUNTING UPPER
15	74176-TM0-T00	Bracket - L. RADIATOR UPPER MOUNTING
16	90635-PT0-802	Clip, Oil Pipe
16	90635-RV0-003	CLIP, OIL PIPE

Rear axle 13

#	OEM	部品名
1	42100-TM0-T02	Beam assy - RR. AXLE
2	42115-TG0-T03	Damper - RR. AXLE DYNAMIC
3	46428-TF0-000	Bracket - R. RR. BRAKE HOSE
4	46429-TF0-000	Bracket - L. RR. BRAKE HOSE
5	52315-TM0-T01	Rubber - RR. STABILIZER
6	52745-TG0-T02	Cover - R. RR. SPRING SEAT LOWER
7	52746-TG0-T02	Cover - L. RR. SPRING SEAT LOWER
8	52748-TF0-020	Rubber - RR. SPRING MOUNTING LOWER
9	57470-TF0-013	Sensor assy - R. RR.
10	57475-TF0-003	Sensor assy - L. RR.
11	90115-659-003	Nut - SELF-LOCK, 8MM (CLINCH)
12	90164-SMG-E00	Bolt - FLANGE, 14X128
13	91503-SZ3-003	Clip A

Rear brake (DRUM) 39

#	OEM	部品名
1	01433-SJ8-000	Cylinder set - RR. WHEEL
2	42200-TF0-Z51	Bearing assy - RR. HUB UNIT
3	42326-SLA-000	Cap - HUB UNIT
4	42610-S5A-000	Drum - RR. BRAKE
5	43110-TF0-Q01	Plate comp - R. RR. BRAKE BACKING
6	43120-TF0-Q01	Plate comp - L. RR. BRAKE BACKING
7	43153-SNA-A01	Shoe comp - RR. BRAKE
7	43153-SNA-A02	Shoe, RR. Brake
8	43171-S04-013	Spring a - BRAKE SHOE RETURN
9	43172-S04-003	Spring b - BRAKE SHOE RETURN
10	43300-SEN-003	Cylinder assy. - RR. WHEEL
11	43321-SH2-G01	Piston - WHEEL CYLINDER
12	43323-663-003	Spring - RR. WHEEL CYLINDER
13	43345-S04-003	Plug - ADJUSTER
14	43345-S5A-003	Plug - ADJUSTER
15	43352-568-003	SCREW, BLEEDER (NISSIN)
16	43353-SD5-003	Cap - BLEEDER SCREW
17	43361-SNA-A02	Lever - R. PARKING BRAKE
18	43362-S5A-013	Rod a - R. CONNECTING
19	43363-S5A-013	Bolt - R. ADJUSTER
20	43364-S5A-003	Rod b - CONNECTING
21	43365-SNA-A01	Pin - PARKING LEVER
22	43366-SH5-003	Lever comp - R. ADJUSTER
23	43367-SH5-003	Spring - R. ADJUSTER
24	43371-SNA-A02	Lever - L. PARKING BRAKE
25	43372-S5A-013	Rod a - L. CONNECTING
26	43373-S5A-013	Bolt - L. ADJUSTER
27	43375-SA0-003	U-clip
28	43376-SH5-003	Lever comp - L. ADJUSTER
29	43377-SH5-003	Spring - L. ADJUSTER
30	43379-SA5-003	Washer - WAVE
31	45172-S04-003	Spring - SHOE CLAMP
32	45175-SA0-013	Pin - TENSIONER
33	90113-SA0-006	Bolt - WHEEL (SAGA)
33	90113-SM1-005	Bolt - WHEEL (ROCKNEL FASTENER)
33	90113-SA0-025	Bolt - WHEEL (NAGOYA RASHI)
33	90113-S5H-005	Bolt - WHEEL (THAI MEIRA)
34	90162-TF0-J00	Bolt - FLANGE, 12X18
35	90305-S30-003	Nut - SPINDLE

Rear bumper 9

#	OEM	部品名
2	71592-S6A-000	Clip assy. - BUMPER SPACER
3	71593-TM0-T00	Spacer - R. RR. BUMPER SIDE
4	71594-TM0-T00	Spacer - R. RR. BUMPER UPPER
5	71598-TM0-T00	Spacer - L. RR. BUMPER SIDE
6	71599-TM0-T00	Spacer - L. RR. BUMPER UPPER
7	90103-SDA-A00	Screw - TAPPING, 5X20
8	90126-SR4-000	Screw-washer - 5X16
9	90149-SAA-003	Bolt - BUMPER
10	91503-SZ3-003	Clip A

Rear door glass/ regulator 14

#	OEM	部品名
1	72710-TM0-T01	Regulator assy - R. RR. DOOR POWER
2	72731-TM0-T01	Sash - R. RR. DOOR QUARTER
3	72735-TM0-T01	Runchannel - R. RR. DOOR
4	72750-TM0-T01	Regulator assy - L. RR. DOOR POWER
5	72771-TM0-T01	Sash - L. RR. DOOR QUARTER
6	72775-TM0-T01	Runchannel - L. RR. DOOR
7	73400-TM0-Q00	Glass assy - R. RR. DOOR (GREEN)
8	73405-TM0-Q00	Glass - R. RR. DOOR QUARTER (GREEN)
9	73441-TM0-T01	Seal - R. RR. DOOR QUARTER
10	73450-TM0-Q00	Glass assy - L. RR. DOOR (GREEN)
11	73455-TM0-Q00	Glass - L. RR. DOOR QUARTER (GREEN)
12	73491-TM0-T01	Seal - L. RR. DOOR QUARTER
13	76218-SB4-000	Collar b - RR. DOOR PANEL LOWER
14	90021-SFA-000	Bolt - FLANGE, 6X10

Rear door lining 6

#	OEM	部品名
1	35760-TF0-003	Sub switch assy. - POWER WINDOW
2	72835-TM0-T01	Weatherstrip - R. RR. DOOR INNER
3	72875-TM0-T01	Weatherstrip - L. RR. DOOR INNER
18	90132-SS0-000	Screw - TAPPING, 4X10 (PO)
19	90662-SB2-003	Grommet - SCREW, 5MM
20	91560-SLJ-J01	Clip - DOOR LINING (LIGHT GRAY)

Rear door lock/ outer handle 23

#	OEM	部品名
1	72112-SJK-003	Protector - R. DOOR LATCH
3	72130-TM0-T01	Protector - R. OUTER HANDLE
4	72174-SHJ-003	Clip t - CABLE END (BLACK)
4	72134-SHJ-003	Clip s - CABLE END (NATURAL)
5	72135-SDA-A01	Striker assy - DOOR LOCK
6	72141-SD4-004	Bush - R. JOINT
7	72143-S04-003	Packing
8	72146-TM0-T01	Spacer - DOOR OUTSIDE HANDLE
9	72149-SLA-003	Snap - R.(NATURAL)
10	72152-SJK-003	Protector - L. DOOR LATCH
12	72170-TM0-T01	Protector - L. OUTER HANDLE
13	72181-SD4-004	Bush - L. JOINT
14	72189-SLA-003	Snap - L.(BLACK)
15	72610-TM0-T11	Latch assy - R. RR. DOOR POWER
16	72612-SFA-000	Cap - CHILD LOCK
17	72613-SNA-003	Seal
18	72631-TM0-T01	Cable - RR. INSIDE HANDLE
19	72633-TM0-T01	Cable - RR. DOOR LOCK
21	72650-TM0-T11	Latch assy - L. RR. DOOR POWER
23	74387-S3C-003	Fastener
24	90120-SV4-000	Bolt - LOCK STRIKER
25	90141-SDA-000	Screw - TAPPING, 5X12
26	90662-SB2-003	Grommet - SCREW, 5MM

Rear door panel 18

#	OEM	部品名
5	67825-TM0-T01	Tape - R. RR. DOOR SASH UPPER
6	67865-TM0-T01	Tape - L. RR. DOOR SASH UPPER
11	72311-S5S-003	Clip A - DOOR WEATHERSTRIP
12	72367-SDA-A00	Seal - OUTER HANDLE HOLE
13	72810-TM0-T01	Weatherstrip - R. RR. DOOR
14	72821-TM0-T00	Seal - R. RR. DOOR HOLE
15	72840-TG0-T01	Checker comp. - R. RR. DOOR
16	72850-TM0-T01	Weatherstrip - L. RR. DOOR
17	72861-TM0-T00	Seal - L. RR. DOOR HOLE
18	72880-TG0-T01	Checker comp. - L. RR. DOOR
19	75891-SA7-000	Stopper - DOOR
20	90102-SFA-305	Bolt - FLANGE, 8X18 (SERVICE)
20	90102-S3N-003	Bolt - FLANGE, 8X24.5 (10.5MM)
21	90103-SLA-000	Bolt - FLANGE, 8X22 (TORX)
22	90141-S04-000	Bolt - FLANGE, 8X22
23	91561-SZ3-003	Clip
24	91563-S4N-003	Clip - DOOR WEATHERSTRIP OFFSET
25	91568-S9V-003	Clip - DOOR WEATHERSTRIP

Rear seat (FIXED) 11

#	OEM	部品名
1	04810-SB3-000	C clip set - TRIM FASTENER (30 PIECES)
4	82122-TM0-T01	Clip - TRIM(5MM)
5	82126-TM0-T01	Frame comp - RR. SEATBACK
6	82127-TM0-T01	Pad comp - RR. SEATBACK
8	82137-S84-A01	Clip - RR. SEAT CUSHION
9	82137-TM0-T01	Pad comp - RR. SEAT CUSHION
10	82212-TM0-T11	Foot comp. - RR. SEAT
11	82214-TM0-000	Bracket - RR. SEATBACK(FIX)
12	90101-SAA-000	Bolt-washer - 8X22
13	90128-SA7-000	Bolt-washer - 6X25
14	90135-S5A-003	Bolt-washer - 10X27

Rear shock absorber 9

#	OEM	部品名
1	52441-TM0-T22	Spring - RR.
2	52610-TM0-T11	Absorber assy - RR. SHOCK
3	52621-SB2-004	Washer - RR. SHOCK ABSORBER MOUNTING (SHOWA)
4	52622-TG0-T01	Bush - RR. DAMPER LOWER
5	52691-SAA-000	Rubber - RR. SPRING UPPER MOUNTING
6	52725-TG0-T01	Rubber - RR. SHOCK ABSORBER MOUNTING
8	52727-TM0-T00	Weight - RR. SHOCK ABSORBER
9	90172-S04-003	Bolt - FLANGE, 10X68
10	90364-SG0-004	Nut - SELF-LOCK, 10MM (SHOWA) (NYLON)

Rear windshield 7

#	OEM	部品名
1	73211-TM0-900	Glass set - RR. WINDSHIELD (GREEN)
2	73225-TM0-000	Rubber a - WINDSHIELD DAM
3	73226-TM0-000	Rubber b - WINDSHIELD DAM
4	73227-TM0-T00	Rubber c - WINDSHIELD DAM
5	91501-S70-003	Fastener b - WINDSHIELD
6	91536-SS0-J01	Fastener a - WINDSHIELD
7	91568-TF0-003	Clip - FR. WINDSHIELD UPPER

Regulator body 23

#	OEM	部品名
1	22743-PG4-000	Pipe - THIRD CLUTCH
2	22753-RG5-000	Pipe - 6X196.5
3	25155-RPC-000	Shaft assy - STATOR
4	27132-P6H-000	Cap - 14MM
5	27200-RPC-000	Body assy - REGULATOR
6	27212-RPC-000	Plate - REGULATOR SEPARATING
7	27246-PN6-800	Cap - REGULATOR SPRING
8	27263-PX3-000	Seat - VALVE SPRING
9	27430-RPC-003	Bolt comp - AIR CHECK
10	27524-P6H-000	Clip - CAP
11	27561-PRP-000	Piston - LOW ACCUMULATOR
12	27562-RPC-000	Spring a - LOW ACCUMULATOR
13	27564-RPC-000	Spring b - LOW ACCUMULATOR
14	27574-PRP-000	Piston - THIRD ACCUMULATOR
15	27583-PRP-000	Spring - THIRD ACCUMULATOR
16	27591-RPC-000	Cover - REGULATOR ACCUMULATOR
17	90001-PRP-000	Bolt - FLANGE, 6X30
18	90089-PK4-000	Bolt - STOPPER, 6MM
19	90472-RPC-000	Packing - 10MM
20	90701-PK4-000	Dowel pin - 8X80
21	91316-PF4-003	O-ring - 31X1.7 (ARAI)
22	91321-PF4-004	O-ring - 18.3X2.4(NOK)
23	91331-PC9-003	O-ring

Roof lining 8

#	OEM	部品名
3	83203-TM0-T01	Pad assy - R. FR. ROOF SIDE
4	83204-TM0-T01	Pad assy - R. RR. ROOF SIDE
9	83241-TM0-000	Bracket - FR. GRAB RAIL
10	83242-TM0-000	Bracket - RR. GRAB RAIL
13	83247-SNA-A01	Clip - GRAB RAIL
14	83253-TM0-T01	Pad assy - L. FR. ROOF SIDE
15	83254-TM0-T01	Pad assy - L. RR. ROOF SIDE
21	90133-SDC-003	Bolt-washer - 5X16

Seatbelts 23

#	OEM	部品名
1	81441-S2G-N31	Collar - 3.5H
2	81441-S4N-J01	Collar - 6.5H
3	81441-S50-J22	Collar - 2H
4	81441-S50-J51	Collar - 5H
11	82424-TM0-Z01	Collar - 5H
14	82491-TM0-000	Protector - R. RR. SEATBELT
18	82891-TM0-000	Protector - L. RR. SEATBELT
19	90123-S04-J30	Washer - WAVE
20	90135-S1F-003	Bolt - FLANGE, 7/16"
21	90142-SAA-J01	Bolt - 7/16"X38
22	90142-SEL-T01	Bolt - 7/16"X28
23	90142-S04-J32	Bolt - 7/16"X23.4
24	90142-S3C-B01	Bolt - 7/16"X40
25	90142-TF0-004	Bolt - 7/16"X28.5
26	90142-TM0-Z01	Bolt - 7/16"X22
27	90541-SEL-T21	Washer - PLANE
28	90543-S2G-K31	Washer - PLAIN
29	90543-S2G-004	Nut - PUSH
30	90543-S4R-005	Washer - SPRING
31	90543-TF0-J01	Washer - SPRING
35	91507-SDA-003	Clip - HARNESS BAND
36	91533-STK-003	Clip - COUPLER(NATURAL)
37	91541-S0A-003	Clip - HARNESS BAND(BLACK) (145MM)

Secondary shaft 53

#	OEM	部品名
1	22814-RGC-003	Seal - RING (21.2MM)
2	23230-RG5-000	Shaft comp. - SECONDARY
3	23411-RG5-000	Gear - SECONDARY SHAFT LOW
4	23431-RG5-000	Gear - SECONDARY SHAFT SECOND
5	23461-RG5-000	Gear - SECONDARY SHAFT FOURTH
6	23521-RPC-010	Gear - SECONDARY SHAFT IDLE
7	90201-PRP-000	Nut - FLANGE, 24MM (LEFT HAND THREAD)
8	90402-P0Z-000	Washer - SPRING, 24MM
9	90432-RPC-000	Cotter - 39MM
10	90433-RDK-000	Retainer - COTTER
11	90443-RPC-000	Collar - 29X35X33
12	90511-RPC-000	Washer - THRUST, 43X54.5X3.125
12	90506-RPC-000	Washer - THRUST, 43X54.5X3.000
12	90513-RPC-000	Washer - THRUST, 43X54.5X3.175
12	90508-RPC-000	Washer - THRUST, 43X54.5X3.050
12	90503-RPC-000	Washer - THRUST, 43X54.5X2.925
12	90510-RPC-000	Washer - THRUST, 43X54.5X3.100
12	90505-RPC-000	Washer - THRUST, 43X54.5X2.975
12	90512-RPC-000	Washer - THRUST, 43X54.5X3.150
12	90507-RPC-000	Washer - THRUST, 43X54.5X3.025
12	90502-RPC-000	Washer - THRUST, 43X54.5X2.900
12	90514-RPC-000	Washer - THRUST, 43X54.5X3.200
12	90509-RPC-000	Washer - THRUST, 43X54.5X3.075
12	90504-RPC-000	Washer - THRUST, 43X54.5X2.950
13	90534-RG5-000	Washer - THRUST, 31X50X4.250
13	90529-RG5-000	Washer - THRUST, 31X50X4.125
13	90524-RG5-000	Washer - THRUST, 31X50X4.000
13	90536-RG5-000	Washer - THRUST, 31X50X4.300
13	90531-RG5-000	Washer - THRUST, 31X50X4.175
13	90526-RG5-000	Washer - THRUST, 31X50X4.050
13	90521-RG5-000	Washer - THRUST, 31X50X3.925
13	90533-RG5-000	Washer - THRUST, 31X50X4.225
13	90528-RG5-000	Washer - THRUST, 31X50X4.100
13	90523-RG5-000	Washer - THRUST, 31X50X3.975
13	90535-RG5-000	Washer - THRUST, 31X50X4.275
13	90530-RG5-000	Washer - THRUST, 31X50X4.150
13	90525-RG5-000	Washer - THRUST, 31X50X4.025
13	90537-RG5-000	Washer - THRUST, 31X50X4.325
13	90532-RG5-000	Washer - THRUST, 31X50X4.200
13	90527-RG5-000	Washer - THRUST, 31X50X4.075
13	90522-RG5-000	Washer - THRUST, 31X50X3.950
14	90608-RDK-000	Circlip - EXTERNAL, 43MM
15	90621-RPC-000	Circlip - EXTERNAL, 26MM
16	91011-RG5-005	Bearing - NEEDLE, 31X38X18
17	91012-RPC-005	Bearing - NEEDLE, 43X49X20.5
18	91013-RPC-003	Bearing - NEEDLE, 35X41X24
19	91021-RPC-003	Needle - THRUST, 35X53X2.5
20	91025-RPC-003	Needle - THRUST, 31X44X2.5
21	91026-RPC-003	Needle - THRUST, 38.5X51.5X2.5
22	91027-RPC-003	Needle - THRUST, 49.5X64X2.5
23	91028-RPC-003	Needle - THRUST, 43X55.5X2.5
24	91307-RPC-000	O-ring - 22.5X1.9
25	91316-PR9-003	O-ring - 33X1.9 (ARAI)

Select lever 14

#	OEM	部品名
1	35505-692-003	Bulb - 14V 1.4W
2	37700-TF0-A81	Lamp assy. - SOLENOID & INDICATOR (AT)
3	54030-SAA-982	Release - SHIFT LOCK
4	54031-SAA-981	Spring - RELEASE SHIFT LOCK
5	54123-SLN-A82	Stopper comp - SHIFT LOCK
7	54132-TM0-A71	Knob assy - PUSH
8	54133-SFA-981	Spring - PUSH KNOB
9	54200-TM0-A81	Bracket set - BASE
10	54222-TF0-981	Cover - SELECT LEVER
11	54315-TK6-A51	Wire - CONTROL
14	54903-SYA-981	SCREW, FLAT 5x8
15	90351-SB2-003	Nut - FLANGE, 8MM
16	90361-SV4-003	Nut - PAINT CUTTING, 6MM
17	91533-S04-003	Clip - COUPLER (NATURAL)

Servo body 29

#	OEM	部品名
1	22743-PG4-000	Pipe - THIRD CLUTCH
2	22743-P4R-000	Pipe - 8X192.5
3	24271-PRP-000	Shaft - SHIFT FORK
4	24630-PRP-000	Arm comp - CHANGE DETENT
5	24635-PRP-000	Collar - CHANGE DETENT ARM
6	27142-P6H-000	Cap - 15MM
7	27263-PX3-000	Seat - VALVE SPRING
8	27400-RPC-000	Body assy - SERVO
9	27412-RPC-000	Plate - SERVO SEPARATING
10	27524-P6H-000	Clip - CAP
11	27572-PRP-000	Piston - SECOND ACCUMULATOR
12	27574-PRP-000	Piston - THIRD ACCUMULATOR
13	27575-RPC-000	Spring b - TOP ACCUMULATOR
14	27577-RPC-000	Spring a - TOP ACCUMULATOR
15	27580-RPC-000	Cover - SERVO ACCUMULATOR
16	27581-RPC-000	Spring a - SECOND ACCUMULATOR
17	27584-RPC-000	Spring b - SECOND ACCUMULATOR
18	28400-RPC-003	Solenoid assy. a
19	28500-RPC-003	Solenoid assy. b
20	90001-PRP-000	Bolt - FLANGE, 6X30
21	90024-612-000	Bolt - SEALING, 8MM
22	90433-PRP-000	Washer - LOCK, 6MM
23	90471-580-000	Packing - 8MM
24	91301-P6H-003	O-ring - 7.6X1.9 (KEIHIN)
25	91302-P6H-003	O-ring - 9.6X1.9 (KEIHIN)
25	91302-P7W-A00	O-ring - 9.6X1.9
26	91321-PF4-004	O-ring - 18.3X2.4(NOK)
27	91331-PL5-J00	O-ring - 20.2X2.4 (NOK)
28	91344-580-000	O-ring - 31X2.7 (ARAI)

Shift fork 11

#	OEM	部品名
1	24111-RPC-000	Fork - REVERSE SHIFT
2	24282-634-000	Bolt - SHAFT FORK SETTING
3	24410-RMM-000	Shaft comp. - CONTROL
4	24634-PRP-060	Spring - DETENT LEVER
5	25420-RPC-003	Strainer assy - ATF
6	25421-RMM-000	Plate comp - BAFFLE
7	90001-PA9-000	Bolt - HEX., 6MM
8	90433-639-000	Washer - LOCK, 6MM
9	90511-TG0-000	Washer - LOCK, 6MM
10	91209-612-003	Oil seal - 12X22X7 (ARAI)
11	91308-PW4-003	O-ring - 21.8X1.9

Shift fork/shift holder 9

#	OEM	部品名
1	24201-PWL-000	Fork comp - GEARSHIFT(5TH)
2	24210-PWL-010	Fork comp - GEARSHIFT(3-4)
3	24220-PWL-010	Fork comp - GEARSHIFT(1-2)
4	24230-PWL-010	Holder comp - REVERSE SHIFT
5	24240-PWL-010	Piece comp. - SHIFT(5-R)
6	24440-PWL-000	Cam comp - REVERSE LOCK
7	90028-PB6-010	Bolt - SPECIAL, 6X22.5
8	90029-611-010	Bolt - HEX., 8X24
9	90412-679-000	Washer - CONICAL SPRING, 8MM

Shift lever 13

#	OEM	部品名
1	54100-TG0-023	Lever sub assy. - CHANGE
3	54117-S3A-N01	Rubber - FLOATING
4	54118-SC2-000	Washer assy. - WIRE
5	54119-SEL-T01	Collar - FLOATING
6	54310-TF0-003	Wire comp - CHANGE
7	54322-SWA-T01	Washer - SELECT
8	54323-SWA-T01	Bush - SHIFT
9	54324-SWA-T01	Washer - SHIFT
10	54325-SWA-T01	Bush - SELECT
11	54357-SF1-003	Plate - CHANGE WIRE
12	90175-SEL-T81	Pin - LOCK, 8MM
13	90361-SV4-003	Nut - PAINT CUTTING, 6MM
14	90715-SDA-000	Pin - SNAP, 8MM

Shift lever/shift arm 18

#	OEM	部品名
1	21320-RF0-000	Tube assy - BREATHER
2	21321-689-000	Plug - BREATHER TUBE
3	21500-RF0-000	Cover comp. - SHIFT ARM
4	24411-PWL-010	Arm - SHIFT
5	24430-PWL-000	Interlock comp.
6	24460-RF0-000	Lever comp - SELECT
7	24464-PLW-000	Spring - SELECT
8	24466-PHR-000	Collar - SELECT SPRING
9	24467-PLW-000	Plate - SELECT SPRING
10	24470-RF0-000	Lever comp - SHIFT
11	24475-PWL-000	Cover - DUST
12	24479-PWL-000	Cover - SHIFT LEVER
13	41936-PDZ-003	Clamp - BREATHER TUBE
14	41936-PFM-F01	Clamp - BREATHER TUBE
15	90029-611-010	Bolt - HEX., 8X24
16	90412-679-000	Washer - CONICAL SPRING, 8MM
17	91209-PE9-005	Dust seal - 16X23X5(NOK)
18	91215-PHR-003	Oil seal - 18X30X7(NOK)

Solenoid 16

#	OEM	部品名
1	22749-PW4-000	Pipe - 35MM
2	22760-PPW-000	Pipe comp - JOINT
3	22775-RPC-000	Pipe - 50MM
4	28250-R90-003	Solenoid assy. a - LINEAR
5	28252-RPC-000	Packing a - LINEAR SOLENOID
6	28260-RG5-004	Solenoid assy. b - LINEAR
7	28262-RPC-000	Packing b - LINEAR SOLENOID
8	28360-RMM-003	Harness - SOLENOID WIRE
9	28600-RG5-003	Switch assy - AT OIL PRESSURE
10	28600-RG5-004	Switch assy - AT OIL PRESSURE
11	28810-RPC-003	Pick up assy.
12	28820-RPC-003	Pick up assy.
13	90471-PW7-A00	PACKING, 10MM
14	91301-PC9-003	O-ring - 7.7X2.3 (ARAI)
15	91309-PX4-003	O-ring - 16X2.1 (NOK)
16	91329-PRP-003	O-ring - 23.3X2.4

Spool valve 13

#	OEM	部品名
1	12210-PZ1-004	SEAL A, VALVE STEM (NOK)
2	12211-PZ1-004	Seal b - VALVE STEM(NOK)
3	12230-RB0-000	Cover - CAM THRUST
4	12251-RB0-004	Gasket comp - CYLINDER HEAD (NIPPON LEAKLESS)
5	15810-RB0-003	Valve assy. - SPOOL
6	15825-RB0-003	Filter assy, SPOOL VALVE
7	37510-RB0-003	Sensor assy - TDC
8	90001-P70-000	Bolt - FLANGE, 10X10.5
9	90003-RME-A10	Bolt - STUD, 8X25
10	90008-PWA-003	Bolt-washer - 9X155
11	91302-PX4-004	O-ring - 46.8X2.2 (NOK)
12	91319-PAA-A01	O-ring - 13X1.5
13	91333-PNA-003	O-ring - 15X1.9

Srs unit 6

#	OEM	部品名
2	77900-TF0-E91	Reel assy - CABLE(FURUKAWA)
3	77901-SNA-C00	Sub cord - CABLE REEL
4	77930-TF0-J21	Sensor assy - FR. CRASH
5	77960-TM0-Y42	Srs unit - REWRITABLE
14	90137-S84-A01	Bolt - TORX EARTH, 6X20
16	91533-STK-003	Clip - COUPLER(NATURAL)

Starter motor (DENSO; 1.5L) 19

#	OEM	部品名
1	30201-PH9-004	Ring - SNAP (DENSO)
2	30202-PZ1-003	Collar set - CLUTCH STOP
3	31200-RB6-Z52	Motor assy. - STARTER (DV4DY) (DENSO)
4	31203-PH9-004	Lever - PINION DRIVE
5	31204-RB0-J01	Switch assy - MAGNET
6	31206-PH9-004	Armature comp.
7	31207-PWA-003	Clutch assy. - OVERRUNNING
8	31210-PH9-004	Bearing b
9	31211-PH9-004	Brush
10	31212-PH9-004	Spring - BRUSH
11	31213-PWA-G01	Cover
12	31214-PH9-004	Bolt - THROUGH
13	31218-PWA-G51	Yoke comp.
14	31220-PH9-004	Nut - HEX., 8MM
15	31223-PA0-006	Nut - HEX.
16	31228-PC2-661	O-ring - YOKE BODY
17	31231-PH9-004	Holder - BRUSH
18	31233-PH9-004	Insulator - BRUSH HOLDER
19	91002-ZG4-801	BEARING A

Steering column 6

#	OEM	部品名
1	53200-TM0-F02	Column assy - STEERING
2	53320-TF0-G00	Cover - STEERING JOINT
3	90135-SDA-000	Bolt - STEERING JOINT YOKE
3	90135-SZT-000	Bolt - STEERING JOINT YOKE
4	90361-SR3-000	Nut - FLANGE, 8MM
5	90511-671-003	Washer - TOOTHED LOCK

Steering wheel (SRS) 6

#	OEM	部品名
8	78520-TM0-N81	Damper comp - STEERING
9	78525-SNB-N81	Guide - CORD
15	90134-S6A-A80	Bolt - HEX., 6X23
16	90161-SV4-003	Bolt - STEERING HANDLE
17	90172-SL4-003	Screw-washer - 5X12
18	90178-SNB-A81	Screw - TAPPING, 3X16(PO)

Switch 8

#	OEM	部品名
1	35500-TM0-T11	Switch assy - RR. DEFOGGER
2	35510-TM0-T01	Switch assy - HAZARD
3	35820-TM0-T01	Switch assy - HEADLIGHT ADJUST
4	35850-TM0-T01	Bulb comp. a - 14V 80MA
5	35851-TM0-T01	Bulb comp. b - 14V 80MA
6	35853-TM0-T01	Bulb comp. - 14V 80MA
7	35854-TM0-T01	Bulb comp. - 14V 60MA
8	35855-TM0-T01	Bulb comp. - 14V 80MA

Taillight/license light 18

#	OEM	部品名
1	33301-SA0-741	Bulb (12V 5W) - (12V 5W) (STANLEY)
2	33303-SL4-003	Bulb - WEDGE (12V 21W) (STANLEY)
4	33303-S2R-003	Bulb - WEDGE (12V 21W) (STANLEY) (AMBER)
5	33500-TM0-T01	Taillight assy. - R.
6	33502-TM0-T01	Gasket - BASE
7	33513-S50-003	Socket - T20W S2
8	33513-S84-A01	Socket - T10
9	33514-S2R-003	Socket - T20W SY
10	33514-S50-003	Socket - T20W S3
12	33550-TM0-T01	Taillight assy. - L.
13	34101-S5A-A01	Lens comp
14	34102-S60-003	Housing comp
15	34103-S5A-A01	Gasket
16	74890-TM0-T01	Garnish assy - RR. LICENSE
17	74895-S5A-000	Bolt - SPECIAL, 5MM
18	75523-SS0-000	Packing - SEAL
19	90665-SS0-003	Grommet - RR. COMBINATION
20	91513-SJK-003	Clip - TAILGATE GARNISH

Throttle body 7

#	OEM	部品名
1	16400-RB7-Z01	Throttle body - ELECTRONIC CONTROL(GMD5C)
2	16896-ZY9-003	Clamp b - FUEL TUBE
3	36162-RK8-005	Valve assy. - PURGE CONTROL SOLENOID
4	36163-RB0-000	Guard - PURGE CONTROL SOLENOID VALVE
5	36167-RB0-000	Tube - PURGE
6	36168-RB0-G00	Pipe comp - PURGE
7	36221-PNC-005	O-ring

Tire/wheel disks 18

#	OEM	部品名
1	42700-TF0-N01	Disk - WHEEL (15X5 1/2J) (CHUO SEIKI) (BLACK)
4	42751-TG0-P01	Tire - 175/65R15 84T) (BRIDGESTONE
6	42753-SH3-003	Valve - RIM (US PACIFIC)
6	42753-SB8-661	Valve - RIM (SCHRADER)
6	42753-SE0-A02	Valve - RIM (SCHRADER)
6	42753-671-003	Valve - RIM (TAIHEIYO)
11	44729-SEA-003	Weight - BALANCE (35G) (YAMATE)
11	44727-SEA-003	Weight - BALANCE (15G) (YAMATE)
11	44723-SEA-003	Weight - BALANCE (30G) (YAMATE)
11	44721-SEA-003	Weight - BALANCE (10G) (YAMATE)
11	44728-SEA-003	Weight - BALANCE (25G) (YAMATE)
11	44726-SEA-003	Weight - BALANCE (5G) (YAMATE)
11	44722-SEA-003	Weight - BALANCE (20G) (YAMATE)
13	44733-TG0-T00	Trim - WHEEL(15X5 1/2J)
14	44737-SEL-T01	Washer - WHEEL NUT(OHASHI)
15	74654-SH5-000	Bolt - ANCHOR
16	83850-SK3-E00	Plate - ANCHOR BOLT
17	90304-SEL-T01	Nut comp. - WHEEL(OHASHI)

Tool/jack 7

#	OEM	部品名
1	74717-TM0-T00	Eyebolt - M22
2	89000-TM0-F00	Tool set
3	89101-S5H-T00	Bag - TOOL
4	89211-SEL-T01	Wrench - WHEEL
5	89310-S5A-Y02	Jack assy - PANTOGRAPH
6	89311-S5A-Y02	Plate - JACK CAUTION
7	89320-SEL-T01	Bar - JACK

Torque converter case 21

#	OEM	部品名
1	21101-RG0-A00	Plate - BEARING SETTING
2	21111-RG0-000	Case - TORQUE CONVERTER
3	23225-RPC-000	Plate - OIL GUIDE
4	23235-RPC-000	Collar - OIL GUIDE
5	25422-PN6-801	Magnet comp. - TRANSMISSION
6	27251-RPC-000	Valve - LUBRICATION CHECK
7	90024-612-000	Bolt - SEALING, 8MM
8	90025-RPC-000	Bolt - SEALING, 16MM
9	90081-PX4-003	Bolt - PLUG, 18MM
10	90433-639-000	Washer - LOCK, 6MM
11	90471-PX4-000	Washer - DRAIN PLUG, 18MM
12	90471-RPC-000	Washer - DRAIN PLUG, 16MM
13	90471-580-000	Packing - 8MM
14	90701-PW8-000	Dowel pin - 14X15
15	90705-PA9-000	Dowel pin - 14X25
16	91001-PRP-004	Bearing - BALL, 40X68X7.5
17	91003-RPC-003	Bearing - BALL, 26X62X11
18	91101-RPC-003	Bearing - NEEDLE, 33.5X59X19
19	91206-PHR-003	Oil seal - 35X58X8 (NOK)
20	91207-P7Z-003	Oil seal - 44X68X8 (NOK)
21	91326-P4V-003	O-ring - 26.7X1.9(NOK)

Transmission assy. 2

#	OEM	部品名
2	20011-RS0-L41	Transmission assy - MT
2	20021-RR4-020	Transmission assy - AT

Transmission case 78

#	OEM	部品名
1	21104-PHR-000	Plate m - OIL GUIDE
1	21210-RG0-000	Case comp. - TRANSMISSION
2	21210-PWL-B00	Case - TRANSMISSION
2	21231-RG5-010	Hanger comp. - TRANSMISSION
3	21211-RF0-000	Plate - OIL GUTTER
3	21321-689-000	Plug - BREATHER TUBE
4	21220-PWL-000	Hanger comp. - TRANSMISSION
4	21391-RG5-000	Stay - BREATHER TUBE
5	23946-P21-000	Shim p - 72MM(1.05)
5	23941-P21-000	Shim k - 72MM(0.90)
5	23968-P21-000	Shim al - 72MM(1.71)
5	23936-P21-000	Shim f - 72MM(0.75)
5	23931-P21-000	Shim a - 72MM(0.60)
5	23963-P21-000	Shim ag - 72MM(1.56)
5	23958-P21-000	Shim ab - 72MM(1.41)
5	23953-P21-000	Shim w - 72MM(1.26)
5	23948-P21-000	Shim r - 72MM(1.11)
5	23943-P21-000	Shim m - 72MM(0.96)
5	23970-P21-000	Shim an - 72MM(1.77)
5	23938-P21-000	Shim h - 72MM(0.81)
5	23933-P21-000	Shim c - 72MM(0.66)
5	23965-P21-000	Shim ai - 72MM(1.62)
5	23960-P21-000	Shim ad - 72MM(1.47)
5	23955-P21-000	Shim y - 72MM(1.32)
5	23950-P21-000	Shim t - 72MM(1.17)
5	23945-P21-000	Shim o - 72MM(1.02)
5	23940-P21-000	Shim j - 72MM(0.87)
5	23967-P21-000	Shim ak - 72MM(1.68)
5	23935-P21-000	Shim e - 72MM(0.72)
5	23962-P21-000	Shim af - 72MM(1.53)
5	23957-P21-000	Shim aa - 72MM(1.38)
5	23952-P21-000	Shim v - 72MM(1.23)
5	23947-P21-000	Shim q - 72MM(1.08)
5	23942-P21-000	Shim l - 72MM(0.93)
5	23969-P21-000	Shim am - 72MM(1.74)
5	23937-P21-000	Shim g - 72MM(0.78)
5	23932-P21-000	Shim b - 72MM(0.63)
5	23964-P21-000	Shim ah - 72MM(1.59)
5	23959-P21-000	Shim ac - 72MM(1.44)
5	23954-P21-000	Shim x - 72MM(1.29)
5	23949-P21-000	Shim s - 72MM(1.14)
5	23944-P21-000	Shim n - 72MM(0.99)
5	23971-P21-000	Shim ao - 72MM(1.80)
5	23939-P21-000	Shim i - 72MM(0.84)
5	23934-P21-000	Shim d - 72MM(0.69)
5	23966-P21-000	Shim aj - 72MM(1.65)
5	23961-P21-000	Shim ae - 72MM(1.50)
5	23956-P21-000	Shim z - 72MM(1.35)
5	23951-P21-000	Shim u - 72MM(1.20)
5	21514-RMM-000	Stay b - HARNESS
6	24455-PHR-000	Spring - BALL SETTING
6	21811-RMM-000	Packing - TORQUE CONVERTER CASE
7	24519-PB6-000	Screw - BALL SPRING SETTING
7	25610-RG5-003	Gauge comp. - ATF
8	28700-PWL-013	Switch assy - BACK LIGHT (U-SHIN)(BLACK)
8	25614-PK4-000	Bolt - FILLER (ATF)
9	90081-PB6-000	Bolt - PLUG, 14MM
9	28450-RG5-000	Cover - SOLENOID
10	90081-PX5-000	Screw - SEALING, 32MM
10	28451-RMM-000	Packing - SOLENOID COVER
11	90381-TF0-000	Bolt - STUD, 10X73
11	32746-RME-A70	Stay f - ENGINE WIRE HARNESS
12	90382-TF0-000	Bolt - STUD, 10X49
12	41936-PDZ-003	Clamp - BREATHER TUBE
13	90401-P8A-A00	Washer - DRAIN, 18MM
13	90380-S5A-000	Bolt - STUD, 12X99.8
14	91205-PL3-A02	Oil seal - 35X56X8(NOK)
14	91205-PL3-A01	Oil seal - 35X56X8 (ARAI)
14	90383-TF0-000	Bolt - STUD, 12X50
15	90441-PK4-000	Washer - SEALING, 24MM
16	90603-PB6-000	Ring - SNAP, 62MM
17	90609-PC8-000	Ring - SNAP, 68MM
18	90612-RPC-000	Ring - SNAP, 78MM
19	90615-PF4-000	Ring - SNAP, 75MM
20	91001-RPC-006	Bearing - BALL, 27X75X18.5
21	91002-RPC-005	Bearing - BALL, 29X78X19/16
22	91004-RPC-016	Bearing - BALL, 29X68X13
23	91005-RPC-016	Bearing - BALL, 20X62X16.5

Trunk lid 25

#	OEM	部品名
5	71704-SL3-000	Seal - GASKET
6	74815-SK8-000	Grommet - KEY CYLINDER(BLACK)
7	74822-SW5-003	Cushion - TRUNK HINGE
8	74829-SDA-A01	Stopper - TRUNK LID
9	74829-SEL-T00	Stopper - TRUNK LID LOWER
10	74851-SNA-003	Lock - TRUNK(MANUAL)
12	74852-SDA-A21	Snap
13	74853-SDA-A21	Washer
14	74854-SNA-A01	Washer
15	74854-SNA-003	Cover
16	74855-SNA-A01	Silencer
18	74861-TM0-T11	Cylinder - TRUNK
19	74862-SE3-003	Striker - TRUNK
20	74863-TM0-T11	Rod - TRUNK
21	74865-TM0-T00	Weatherstrip - TRUNK LID
23	74867-TM0-003	Holder - ROD
24	74871-TM0-T00	Spring - R. TRUNK OPENER
25	74872-TM0-T00	Spring - L. TRUNK OPENER
26	74873-S30-013	Clip - TRUNK OPENER SPRING
27	74880-TM0-G01	Cable - TRUNK OPENER(LH)
28	74882-TM0-G01	Opener assy - TRUNK LID(LH)
30	90109-SNA-000	Bolt - SPECIAL, 6X35
31	90856-TM0-T00	Flap - TAILGATE SEAL
32	91507-S5A-003	Clip - TRUNK OPENER CABLE
33	91902-SB2-003	Cushion - WIRE HARNESS(50X100)

Trunk lining 7

#	OEM	部品名
1	33303-SL4-003	Bulb - WEDGE (12V 21W) (STANLEY)
2	33513-S50-003	Socket - T20W S2
3	34271-S5A-A01	Lamp unit
11	84513-TM0-T30	Spacer - RR. TRAY SIDE
12	84521-TM0-T00	Lid comp - SPARE TIRE
20	90140-SH3-003	Bolt-washer - 5X18
24	91560-SLJ-J01	Clip - DOOR LINING (LIGHT GRAY)

Valve/rocker arm 10

#	OEM	部品名
2	14620-RD7-Z00	Arm assy. - ROCKER
3	14711-RB0-000	Valve - IN.
4	14721-RB0-000	Valve, Exhaust
5	14744-PNA-004	Screw - TAPPET ADJUSTING
6	14761-RB1-003	Spring - IN. VALVE (GREEN) (NIPPON HATSUJO)
7	14762-RB1-007	Spring - EX. VALVE (BROWN) (SANKORU)
8	14765-RGA-000	Retainer - VALVE SPRING
9	14775-P08-000	Seat - VALVE SPRING
10	14781-RGM-A01	Cotter - VALVE (FUJI VALVE)
12	90206-PM3-004	Nut - TAPPET ADJUSTING (TOKAI TRW)

Water hose 14

#	OEM	部品名
1	79721-TF0-000	Hose - WATER IN.
1	19506-RB0-000	Hose - THROTTLE BODY IN.
2	79725-TF0-900	Hose - WATER OUTLET
2	19508-RB1-000	Hose - BYPASS
3	79731-S5A-000	Grommet - HEATER PIPE
3	19509-P72-003	Clamp - ELECTRONIC AIR CONTROL VALVE HOSE
4	79746-TF0-003	Clip - HEATER HOSE
4	19512-PK2-003	Clip - HOSE, 18.7MM
5	79754-TF0-000	Bracket - HEATER HOSE
5	19527-RB0-000	Hose a - BREATHER HEATER
6	91405-PK1-003	Clip, WATER HOSE, 24MM
6	19513-PE0-003	Clamp - WATER HOSE (21.7MM) (CHUO SPRING)
6	19528-RB1-000	Hose b - BREATHER HEATER
7	91405-TF0-G01	Clip - WATER HOSE (24MM)

Water pump 15

#	OEM	部品名
1	19200-RB0-003	Pump comp - WATER
2	19222-RB0-003	Packing - WATER PUMP
3	19224-RB0-000	Pulley - WATER PUMP
4	19301-PAA-306	Thermostat assy - NIPPON THERMOSTAT
5	19305-PT0-000	Rubber - THERMOSTAT MOUNTING
5	19305-PLC-A00	Rubber - THERMOSTAT MOUNTING
6	19311-RB0-000	Cover - THERMOSTAT
7	19315-RB0-000	Cover comp. - WATER OUTLET
8	19320-RB0-000	Case comp. - THERMOSTAT
9	19500-PE0-000	Joint, Tube
10	19505-RB0-000	Pipe comp - CONNECTING
11	37870-RWC-A01	Water Temp Sensor assy - (PANASONIC)
12	90013-PCX-000	Bolt - SPECIAL, 6X12
13	91307-PLC-004	O-ring - 9.5X1.9 (MATSUSHITA)
14	91314-PH7-003	O-ring 31.2X4.1 (NOK)

Windshield washer 18

#	OEM	部品名
1	38562-SA0-003	Joint l - WASHER TUBE(MITSUBA)
2	76802-SX0-003	Cap unit - MOUTH
3	76810-TM0-T01	Nozzle assy. - WASHER
4	76813-TM0-T01	Tube - 590MM
5	76829-SM4-003	Joint i - WASHER
6	76830-SM4-003	Joint y - WASHER
7	76837-TM0-T01	Tube - 1040MM
8	76838-TM0-T01	Tube - 400MM
9	76839-SFJ-W01	Tube - 140MM
10	76839-TM0-T01	Tube - 210MM
11	76841-TM0-T01	Tank - WASHER(2.5L FR.)
12	76842-S2K-J11	Bush - WASHER TANK
13	76846-TA0-A01	Pump set - WASHER (FR.)
14	90686-SD5-003	Clamp - METER CABLE
15	90815-SNA-003	Grommet - 15MM
16	91512-SX0-003	Clip - INNER FENDER CLIP
17	91523-SM4-003	Clip - WASHER TUBE
18	91659-SP0-003	Clip - TUBE, 7MM(DARK GRAY)

Wire harness (1) 10

#	OEM	部品名
1	32100-TM0-Y00	Harness - R. CABIN WIRE
2	32120-TM0-Y00	Harness - L. CABIN WIRE
2	32120-TM0-Y10	Harness - L. CABIN WIRE
3	32601-TF0-910	Cable assy - EARTH (MISSION)
3	32601-TF0-920	Cable assy - EARTH (MISSION)
4	32610-TM0-000	Cable - SUB EARTH
5	90115-TF0-003	Bolt - SPECIAL, 6X33
6	90148-SE0-003	Bolt - EARTH, 6X16 (WASHER 12.5MM) (ZN)
7	90149-SE0-003	Bolt - EARTH, 6X16
8	90153-SE0-003	Bolt - EARTH, 6X12

Wire harness (2) 4

#	OEM	部品名
1	32117-TM0-Y00	Harness - INSTRUMENT WIRE
1	32117-TM0-Y10	Harness - INSTRUMENT WIRE
2	90137-S84-A01	Bolt - TORX EARTH, 6X20
3	90148-SE0-003	Bolt - EARTH, 6X16 (WASHER 12.5MM) (ZN)

Wire harness (3) 3

#	OEM	部品名
1	32107-TM0-Y00	Harness - FLOOR WIRE
2	32202-TM0-T00	Cord - DEFROSTER EARTH
3	90148-SE0-003	Bolt - EARTH, 6X16 (WASHER 12.5MM) (ZN)

Wire harness (4) 7

#	OEM	部品名
1	32108-TM0-P00	Harness - RR. WIRE
2	32155-TM0-P00	Cord - INTERIOR
3	32751-TM0-P41	Harness - DRIVER DOOR WIRE
4	32752-TM0-P41	Harness - PASSENGER DOOR WIRE
5	32753-TM0-P00	Harness - R. RR. DOOR WIRE
6	32754-TM0-P00	Harness - L. RR. DOOR WIRE
7	90148-SE0-003	Bolt - EARTH, 6X16 (WASHER 12.5MM) (ZN)
