Abs accumulator 19

#	OEM	部品名
1	46462-SE0-000	Bolt - OIL
2	46472-568-000	Packing - OIL BOLT
3	53729-SP0-003	Clamp - D15.5
4	57070-SR3-013	Accumulator
5	57073-SR3-013	Label - ACCUMULATOR CAUTION
6	57090-SR3-010	Pipe - ACCUMULATOR
7	57310-SR3-023	Pump assy. - ABS
8	57336-SR3-003	Plate - SUCTION
9	57355-SR3-020	Bracket - POWER UNIT
10	57358-SB0-800	Mount a - PUMP BRACKET
11	57371-SR3-000	Hose - PUMP
12	57375-SR3-010	Bracket a - PUMP
13	57376-SF1-800	Bolt-washer - 6X28
14	57376-SR3-000	Bracket b - PUMP
15	57380-SR3-003	Hose - PRESSURE
16	57390-SR3-013	Switch assy - PRESSURE
17	90127-SB0-801	Bolt - SENSOR LOCK, 6X12
17	90118-958-003	Bolt, flange, 6x12
18	91551-SF4-003	Band - WIRE HARNESS(BROWN) (110MM)

Abs modulator 22

#	OEM	部品名
1	46175-671-651	Screw - SOCKET
2	57110-SR3-023	Modulator assy
3	57115-SR3-020	Bracket - MODULATOR
4	57116-SR3-A01	Bracket - MODULATOR UNIT
5	57117-SP0-305	Head set b - MODULATOR
6	57118-SG0-801	O-ring - HEAD
7	57119-SR3-003	Mark - RESERVE TANK (ABS)
8	57120-SG0-805	Piston comp - FR.
9	57121-SG0-801	Spring - FR. MODULATOR
10	57140-SG0-805	Piston comp - RR.
11	57141-SF1-801	Spring - RR. MODULATOR
12	57174-SR3-800	Bracket - COUPLER
13	57174-SR3-820	Bracket - COUPLER
14	57191-SR3-013	Tank comp. - RESERVE
15	57193-SP0-013	Filter - TANK
16	57196-SP0-003	Cap comp. - RESERVE TANK
17	57198-SP0-003	Seal - RESERVE TANK
18	57204-SP0-003	O-ring c - SOLENOID
19	57348-SB0-801	Bleed - AIR
20	57349-SB0-801	Cap - AIR BLEED
21	90105-SG0-003	Bolt-washer - 8X16
22	90361-SV4-003	Nut - PAINT CUTTING, 6MM

Air cleaner (3) 24

#	OEM	部品名
1	17210-P30-000	Cover comp. - AIR CLEANER
2	17212-PN3-000	Rubber, AIR CLEANER MOUNTING
2	17212-P2J-J00	Rubber, AIR CLEANER MOUNTING
3	17212-P07-000	Rubber - AIR CLEANER MOUNTING
4	17216-PN3-000	Collar - AIR CLEANER MOUNTING
5	17220-P07-000	Element assy. - AIR CLEANER
6	17228-P30-010	Tube - AIR FLOW
7	17230-P04-G00	Chamber assy - RESONATOR
8	17232-P04-G00	Seal - RESONATOR RUBBER
10	17241-P07-010	Case comp. - AIR CLEANER
11	17243-PD1-000	Spring - AIR INTAKE TUBE
12	17243-P30-000	Tube a - AIR INTAKE
13	17248-P30-000	Tube assy. b - AIR INTAKE
14	17249-P07-000	Rubber - AIR INTAKE SEAL
15	17254-P08-300	Grommet - AIR CLEANER
16	17273-P30-A00	Label - AIR CLEANER
17	17281-P28-G00	Tube - SIDE BRANCH
18	17284-PT2-003	Clamp - TUBE, 44MM
19	17315-PH3-003	Clamp - AIR FLOW TUBE (74)
20	75353-671-000	Lock - SCREW
21	90001-P0A-000	Bolt-washer - SPECIAL, 6X35
22	90091-P36-000	Bolt-washer - 5X28
22	90091-PE2-000	Bolt-washer - 5X25
23	91405-PG7-003	Clip - HOSE (D13)

Air cleaner (PGM-FI) 24

#	OEM	部品名
1	17210-P30-000	Cover comp. - AIR CLEANER
2	17212-PN3-000	Rubber, AIR CLEANER MOUNTING
2	17212-P2J-J00	Rubber, AIR CLEANER MOUNTING
3	17212-P07-000	Rubber - AIR CLEANER MOUNTING
4	17216-PN3-000	Collar - AIR CLEANER MOUNTING
5	17220-P07-000	Element assy. - AIR CLEANER
7	17228-P30-010	Tube - AIR FLOW
8	17230-P04-G00	Chamber assy - RESONATOR
9	17232-P04-G00	Seal - RESONATOR RUBBER
11	17241-P07-010	Case comp. - AIR CLEANER
12	17243-PD1-000	Spring - AIR INTAKE TUBE
13	17243-P30-000	Tube a - AIR INTAKE
14	17248-P30-000	Tube assy. b - AIR INTAKE
15	17249-P07-000	Rubber - AIR INTAKE SEAL
16	17254-P08-300	Grommet - AIR CLEANER
17	17273-P30-G01	Plate - CAUTION
18	17281-P28-G00	Tube - SIDE BRANCH
19	17284-PT2-003	Clamp - TUBE, 44MM
20	17315-PH3-003	Clamp - AIR FLOW TUBE (74)
21	75353-671-000	Lock - SCREW
22	90001-P0A-000	Bolt-washer - SPECIAL, 6X35
23	90091-PE2-000	Bolt-washer - 5X25
23	90091-P36-000	Bolt-washer - 5X28
24	91405-PG7-003	Clip - HOSE (D13)

Air con (COMPRESSOR; HADSYS) 23

#	OEM	部品名
1	38801-P06-006	Valve sub assy. - SAFETY
2	38810-P76-016	Compressor comp. - HADSYS
2	38810-P76-006	Compressor comp. - HADSYS
3	38829-P06-006	Nut
4	38900-P06-006	Clutch set - COMPRESSOR
5	38908-P06-016	Protector set - THERMAL
5	38908-P06-006	Protector set - THERMAL
6	38912-P06-006	Shim set
7	38913-P06-006	Circlip - EXTERNAL, 45MM
8	38914-P06-006	Circlip - EXTERNAL, 35MM
9	31110-PR4-003	Belt - ALTERNATOR (BANDO)
9	31110-PR4-004	Belt - ALTERNATOR (MITSUBOSHI)
10	38924-P06-006	Coil set - SOLENOID
13	38930-P54-000	Bracket - COMPRESSOR
14	38941-P30-000	Bracket - IDLER
16	38944-PJ7-000	Collar - IDLE PULLEY
18	38945-P30-000	Cover - BEARING
22	90023-P01-000	Bolt - FLANGE, 8X105
23	90054-P30-000	Bolt - SPECIAL, 10X30
24	90086-PR3-000	Bolt - SOCKET, 10X28
25	90087-P30-000	Bolt - HEX., 8X75
26	90279-P30-000	Nut - SPECIAL, 8MM
31	38942-P3F-003	Pulley comp - IDLE

Air con (COMPRESSOR; ND; '93-) 25

#	OEM	部品名
1	38773-PR3-003	Clip - WIRE HARNESS
2	38801-P45-G01	Valve sub assy. - SAFETY
3	38810-PR7-A04	Compressor comp. - DENSO
4	38812-PH1-003	Ring b - SNAP
5	38812-671-003	Ring a - SNAP
6	38816-PR3-003	Clip - LEAD WIRE
7	38827-PH7-003	Screw-washer - 5X8
8	38829-PR3-003	Bolt - WASHER HEAD
10	38838-P72-003	Valve - SUCTION SERVICE
11	38839-PR7-A01	O-ring
12	38840-PC1-003	Bolt b
15	38900-P30-013	Clutch - MAGNETIC
16	38912-PH1-N01	Plate set - WASHER
17	38920-PR3-003	Belt - COMPRESSOR (BANDO)
17	38920-PR3-004	Belt - COMPRESSOR (MITSUBOSHI)
18	38924-P72-003	Stator set
19	38941-P30-000	Bracket - IDLER
20	38942-PM3-000	Pulley comp - IDLE
21	38944-PJ7-000	Collar - IDLE PULLEY
22	38945-P30-000	Cover - BEARING
23	90023-P30-000	Bolt - FLANGE, 8X90
24	90054-P30-000	Bolt - SPECIAL, 10X30
25	90086-PR3-000	Bolt - SOCKET, 10X28
26	90087-P30-000	Bolt - HEX., 8X75
27	90279-P30-000	Nut - SPECIAL, 8MM

Air conditioner (CONDENSER) 22

#	OEM	部品名
2	80107-SR3-000	Bracket - CONDENSER UPPER
3	80110-SR3-023	Condenser comp. - SAK
4	80115-SR3-000	Seal - UPPER CONDENSER
5	80116-SR3-000	Seal - R. CONDENSER
6	80117-SR3-000	Seal - L. CONDENSER
7	80151-SR3-013	Motor - COOLING FAN
8	80152-SR3-013	Fan comp - COOLING (MITSUBA)
9	80161-SR3-000	Shroud comp. - CONDENSER FAN
10	80162-SR3-000	Protector - FAN MOTOR
11	80174-SR3-000	Mount - R. CONDENSER
12	80175-SR3-000	Mount - L. CONDENSER
13	80176-SR3-000	Rubber - CONDENSER MOUNTING
14	80177-SR3-003	Mount - CONDENSER LOWER
15	80373-SR3-000	Bracket - DISCHARGE HOSE
16	80440-SS0-901	Switch - DUAL PRESSURE (FUJI)
16	80440-SK3-901	Switch - DUAL PRESSURE (SAGINOMIYA)
17	90012-PC6-000	Bolt - SPECIAL, 6X12 (+) (DACRO COATING)
18	90041-PD2-004	Nut - SPECIAL, 5MM (MITSUBA)
18	90311-MB6-003	Nut toothed 5mm
19	90078-PR3-000	Screw - PAN, 4X8
20	90403-PM3-004	Washer - PLAIN, 7MM
21	90659-PG6-000	Clip - WIRE HARNESS

Air conditioner (COOLING UNIT; 3) 36

#	OEM	部品名
1	32147-SF1-003	Connector - DIODE(3P)
2	32148-SF1-003	Rubber - SEAL
4	39795-SB2-003	Relay assy - POWER (4P) (MITSUBA) (RC-2201)
6	80201-SR3-A10	Case - EVAPORATOR UPPER
7	80202-SR3-A00	Case - EVAPORATOR LOWER
8	80205-SR3-A00	Insulator - EVAPORATOR UPPER
9	80206-SR3-A00	Insulator - EVAPORATOR LOWER
10	80214-SL5-A01	Insulator - EXPANSION
11	80215-ST7-A01	Evaporator comp. - SAK
12	80220-ST7-A02	Valve assy. - EXPANSION (10N) (FUJI KOKI)
13	80223-ST7-A01	O-ring - FUJI KOKI
14	80225-SR3-000	Clamp
15	80271-SR3-A00	Hose - DRAIN
16	80272-SF4-000	Grommet - DRAIN HOSE
17	80282-SM4-A00	Grommet - THERMOSTAT
18	80286-SR3-000	Seal - EVAPORATOR INNER
19	80287-SR3-000	Seal - EVAPORATOR OUTER
20	80288-SR3-000	Seal - EVAPORATOR JOINT
21	80430-SR3-A02	Thermostat - AIR CONDITIONER
22	80460-SR3-A02	Harness - AIR CONDITIONER WIRE
23	80463-SR3-A00	Bracket - AIR CONDITIONER WIRE HARNESS
24	80464-SR3-000	Grommet - AIR CONDITIONER PIPE
25	80491-SR3-000	Bracket - AIR CONDITIONER RELAY
26	80566-SR3-003	Clip - EVAPORATOR SENSOR
27	80872-ST7-000	O-ring - 1/2"
28	80873-ST7-000	O-ring - 8MM
29	90012-PC6-000	Bolt - SPECIAL, 6X12 (+) (DACRO COATING)
30	90153-SE0-003	Bolt - EARTH, 6X12
31	90155-SE0-003	Screw - TAPPING, 6X20
32	90156-SH3-000	Bolt-washer - 6X24
33	90321-SV4-003	Nut-washer - 6MM (PAINT CUTTING)
34	90659-692-000	Clamp - CASE
35	91546-SR3-003	Clamp - 16.5
36	91547-SF4-003	Band - WIRE HARNESS (BLUE) (123.5MM)
37	91559-SE3-003	Clip - WIRE HARNESS (WHITE) (55MM)
38	91619-SA5-000	Grommet - SCREW, 6MM

Air conditioner (HOSES/PIPES; 1) 27

#	OEM	部品名
1	38608-SA5-000	Rubber - MOUNTING
2	38609-SA5-000	Collar - DISTANCE
4	80871-ST7-000	O-ring - 5/8"
5	80050-SP0-000	Label - AIR CONDITIONER CAUTION (HFC134A)
6	80311-SR3-A02	Hose comp. - SUCTION (NICHIRIN)
7	80315-SR3-911	Hose comp. - DISCHARGE (NICHIRIN)
8	80321-SR3-A02	Pipe a - SUCTION (SAK)
9	80322-SR3-A02	Pipe b - SUCTION (SAK)
10	80331-SR3-013	Pipe - CONDENSER (SAK)
11	80341-SR3-A02	Pipe a - RECEIVER (SAK)
12	80342-SR3-A02	Pipe b - RECEIVER (SAK)
13	80343-SR3-A02	Pipe c - RECEIVER (SAK)
14	80351-ST7-003	Receiver comp
15	80352-SR3-000	Bracket - LIQUID TANK
16	80362-SR3-A00	Clamp - SUCTION HOSE
17	80363-SR3-A00	Stay - SUCTION HOSE
18	80364-SR3-A00	Stay - SUCTION PIPE
19	80367-SR3-A00	Clamp b - SUCTION PIPE
20	80387-SM4-A01	Clip - RECEIVER PIPE
21	90012-PC6-000	Bolt - SPECIAL, 6X12 (+) (DACRO COATING)
22	90126-SM4-000	Bolt-washer - 6X32
23	90308-SD2-A00	Nut - FLANGE, 6MM (DACRO COATING)
24	80873-ST7-000	O-ring - 8MM
25	80872-ST7-000	O-ring - 1/2"
26	91536-SR3-003	Clip - SUCTION PIPE (BLACK)
27	80865-ST0-003	Cap h - VALVE (NICHIRIN)
28	80866-SL0-003	Cap - VALVE(L)

Air conditioner (HOSES/PIPES; LH) 27

#	OEM	部品名
1	38608-SA5-000	Rubber - MOUNTING
2	38609-SA5-000	Collar - DISTANCE
4	80871-ST7-000	O-ring - 5/8"
5	80050-SP0-000	Label - AIR CONDITIONER CAUTION (HFC134A)
6	80311-SR3-G12	Hose comp. - SUCTION (NICHIRIN)
7	80315-SR3-N02	Hose comp. - DISCHARGE (NICHIRIN)
8	80321-SR3-A02	Pipe a - SUCTION (SAK)
9	80322-SR3-A02	Pipe b - SUCTION (SAK)
10	80331-SR3-013	Pipe - CONDENSER (SAK)
11	80341-SR3-A02	Pipe a - RECEIVER (SAK)
12	80342-SR3-A02	Pipe b - RECEIVER (SAK)
13	80343-SR3-A02	Pipe c - RECEIVER (SAK)
14	80351-ST7-003	Receiver comp
15	80352-SR3-000	Bracket - LIQUID TANK
16	80362-SR3-A00	Clamp - SUCTION HOSE
17	80363-SR3-A00	Stay - SUCTION HOSE
18	80364-SR3-A00	Stay - SUCTION PIPE
19	80367-SR3-A00	Clamp b - SUCTION PIPE
20	80387-SM4-A01	Clip - RECEIVER PIPE
21	90012-PC6-000	Bolt - SPECIAL, 6X12 (+) (DACRO COATING)
22	90126-SM4-000	Bolt-washer - 6X32
23	90308-SD2-A00	Nut - FLANGE, 6MM (DACRO COATING)
24	80873-ST7-000	O-ring - 8MM
25	80872-ST7-000	O-ring - 1/2"
26	91536-SR3-003	Clip - SUCTION PIPE (BLACK)
27	80865-ST0-003	Cap h - VALVE (NICHIRIN)
28	80866-SL0-003	Cap - VALVE(L)

Air conditioner (UNIT; LH; '94-) 37

#	OEM	部品名
1	32147-SF1-003	Connector - DIODE(3P)
2	32148-SF1-003	Rubber - SEAL
3	39795-SB2-003	Relay assy - POWER (4P) (MITSUBA) (RC-2201)
5	80201-SR3-A10	Case - EVAPORATOR UPPER
6	80202-SR3-A00	Case - EVAPORATOR LOWER
7	80205-SR3-A00	Insulator - EVAPORATOR UPPER
8	80206-SR3-A00	Insulator - EVAPORATOR LOWER
9	80214-SL5-A01	Insulator - EXPANSION
10	80215-ST7-A01	Evaporator comp. - SAK
11	80220-ST7-A02	Valve assy. - EXPANSION (10N) (FUJI KOKI)
12	80223-ST7-A01	O-ring - FUJI KOKI
13	80225-SR3-000	Clamp
14	80271-SR3-A00	Hose - DRAIN
15	80272-SF4-000	Grommet - DRAIN HOSE
16	80282-SM4-A00	Grommet - THERMOSTAT
17	80286-SR3-000	Seal - EVAPORATOR INNER
18	80287-SR3-000	Seal - EVAPORATOR OUTER
19	80288-SR3-000	Seal - EVAPORATOR JOINT
20	80411-SR3-013	Knob - AIR CONDITIONER SWITCH
21	80430-SR3-A02	Thermostat - AIR CONDITIONER
22	80460-SR3-A02	Harness - AIR CONDITIONER WIRE
23	80463-SR3-A00	Bracket - AIR CONDITIONER WIRE HARNESS
24	80464-SR3-000	Grommet - AIR CONDITIONER PIPE
25	80491-SR3-000	Bracket - AIR CONDITIONER RELAY
26	80566-SR3-003	Clip - EVAPORATOR SENSOR
27	80872-ST7-000	O-ring - 1/2"
28	80873-ST7-000	O-ring - 8MM
29	90012-PC6-000	Bolt - SPECIAL, 6X12 (+) (DACRO COATING)
30	90153-SE0-003	Bolt - EARTH, 6X12
31	90155-SE0-003	Screw - TAPPING, 6X20
32	90156-SH3-000	Bolt-washer - 6X24
33	90321-SV4-003	Nut-washer - 6MM (PAINT CUTTING)
34	90659-692-000	Clamp - CASE
35	91546-SR3-003	Clamp - 16.5
36	91547-SF4-003	Band - WIRE HARNESS (BLUE) (123.5MM)
37	91559-SE3-003	Clip - WIRE HARNESS (WHITE) (55MM)
38	91619-SA5-000	Grommet - SCREW, 6MM

Air conditioner kit 1

#	OEM	部品名
2	80000-SR3-G21	General assy. - AIR CONDITIONER

Alternator (DENSO; 2) 27

#	OEM	部品名
1	31100-P30-G04	Alternator assy - CJP62) (DENSO
2	31101-PV1-A01	Rotor assy.
3	31103-PT0-003	Seal - RING
4	31104-PT0-003	Seal - RING
5	31105-PR7-A01	Holder assy. - BRUSH
6	31111-PT0-003	Bearing - RR. GENERATOR
7	31114-PT0-013	Bearing - FR. GENERATOR
8	31116-PT0-003	Plate - RETAINER
9	31116-P13-003	Plate - TERMINAL
10	31118-PT0-003	Bush - INSULATION
11	31119-PT0-003	Bush - INSULATION
12	31127-PT2-013	Rectifier assy.
13	31135-PT0-013	Cover - RR. END
14	31138-PD1-004	Cover - BEARING
15	31141-PV1-A01	Pulley
16	31142-PD1-004	Nut - PULLEY LOCK
17	31145-PD1-004	Bolt - STUD, 6X68
18	31146-PT0-003	Screw
19	31147-PT0-003	Screw-washer
20	31147-P13-003	Screw
21	31148-PT0-003	Screw - WAVE WASHER
22	31148-P13-003	Screw - WAVE WASHER
23	31150-PE7-662	Regulator assy
24	90231-PD1-014	Nut-washer - 5MM
25	90232-PT0-003	Nut - HEX., 6MM
26	90424-PR7-A01	Washer
27	91415-P30-003	Clip - CORD

Alternator (DENSO; DOHC VTEC) 27

#	OEM	部品名
1	31100-P30-G04	Alternator assy - CJP62) (DENSO
2	31101-PV1-A01	Rotor assy.
3	31103-PT0-003	Seal - RING
4	31104-PT0-003	Seal - RING
5	31105-PR7-A01	Holder assy. - BRUSH
6	31111-PT0-003	Bearing - RR. GENERATOR
7	31114-PT0-013	Bearing - FR. GENERATOR
8	31116-PT0-003	Plate - RETAINER
9	31116-P13-003	Plate - TERMINAL
10	31118-PT0-003	Bush - INSULATION
11	31119-PT0-003	Bush - INSULATION
12	31127-PT2-013	Rectifier assy.
13	31135-PT0-013	Cover - RR. END
14	31138-PD1-004	Cover - BEARING
15	31141-PV1-A01	Pulley
16	31142-PD1-004	Nut - PULLEY LOCK
17	31145-PD1-004	Bolt - STUD, 6X68
18	31146-PT0-003	Screw
19	31147-PT0-003	Screw-washer
20	31147-P13-003	Screw
21	31148-PT0-003	Screw - WAVE WASHER
22	31148-P13-003	Screw - WAVE WASHER
23	31150-PE7-662	Regulator assy
24	90231-PD1-014	Nut-washer - 5MM
25	90232-PT0-003	Nut - HEX., 6MM
26	90424-PR7-A01	Washer
27	91415-P30-003	Clip - CORD

Auto radio ('94-) 2

#	OEM	部品名
15	66849-SH3-G00	Bracket - RADIO
16	91551-SE0-003	Bolt - FLANGE, 5X7

Battery (1) 16

#	OEM	部品名
1	31500-SR3-G04	Battery assy - 55B24L<S>-MF) (YUASA
1	31500-SR3-G05	Battery assy - 55B24L<S>-MF) (PANASONIC
2	31512-SR3-000	Plate - BATTERY SETTING
3	31513-SR3-000	Bolt - BATTERY SETTING
4	31521-SR3-000	Box assy - BATTERY
6	31542-SA5-665	Plug - VENT (MF) (PANASONIC)
6	31542-SA5-664	Plug - VENT (MF) (YUASA)
7	32115-P01-000	Stay - ENGINE WIRE HARNESS CLAMP
8	32410-SR3-A42	Cable assy - STARTER
9	32414-SR3-000	Clamp a - STARTER CABLE
10	32416-SR3-A00	Clamp c - STARTER CABLE
11	32600-SR3-A01	Cable assy - BATTERY EARTH
12	32601-SK7-900	Bolt - BATTERY TERMINAL
13	32602-SK7-900	Nut - BATTERY TERMINAL
14	90153-SE0-003	Bolt - EARTH, 6X12
15	90337-SJ4-003	Nut - A.L.B.

Battery (LH) 17

#	OEM	部品名
1	31500-SR3-G05	Battery assy - 55B24L<S>-MF) (PANASONIC
1	31500-SR3-G04	Battery assy - 55B24L<S>-MF) (YUASA
2	31512-SR3-000	Plate - BATTERY SETTING
3	31513-SR3-000	Bolt - BATTERY SETTING
4	31521-SR3-000	Box assy - BATTERY
5	31542-SA5-665	Plug - VENT (MF) (PANASONIC)
5	31542-SA5-664	Plug - VENT (MF) (YUASA)
6	32115-P01-000	Stay - ENGINE WIRE HARNESS CLAMP
7	32410-SR3-A42	Cable assy - STARTER
8	32414-SR3-000	Clamp a - STARTER CABLE
9	32416-SR3-A00	Clamp c - STARTER CABLE
10	32600-SR3-A01	Cable assy - BATTERY EARTH
11	32601-SK7-900	Bolt - BATTERY TERMINAL
12	32602-SK7-900	Nut - BATTERY TERMINAL
13	90130-SR3-003	Bolt - 5X13
14	90153-SE0-003	Bolt - EARTH, 6X12
15	90337-SJ4-003	Nut - A.L.B.

Body structure components (1) 1

#	OEM	部品名
37	90105-634-000	Bolt-washer (8x20)

Body structure components (3) 5

#	OEM	部品名
28	70494-SE0-000	Spring - FUEL LID OPENER
29	74422-SH3-000	Cushion - FUEL FILLER LID
30	75450-SR3-000	Outlet assy - RR. AIR
31	75451-SP0-000	Clip - RR. AIR OUTLET
32	90147-634-003	Bolt - FENDER, 6X18

Body structure components (FRONT BULKHEAD) 1

#	OEM	部品名
37	90105-634-000	Bolt-washer (8x20)

Body structure components (OUTER PANEL) 5

#	OEM	部品名
27	70494-SE0-000	Spring - FUEL LID OPENER
28	74422-SH3-000	Cushion - FUEL FILLER LID
29	75450-SR3-000	Outlet assy - RR. AIR
30	75451-SP0-000	Clip - RR. AIR OUTLET
31	90147-634-003	Bolt - FENDER, 6X18

Brake line (SRS; LH) 33

#	OEM	部品名
1	01464-SR3-N03	Hose set - R. FR. BRAKE
2	01465-SR3-N02	Hose set - L. FR. BRAKE
3	01466-SR3-903	Hose set - R. RR. BRAKE
4	01468-SR3-902	Hose set - L. RR. BRAKE
5	46330-SR3-N00	Pipe comp. c - BRAKE
6	46340-SR3-N00	Pipe comp. d - BRAKE
7	46374-SR3-A01	Pipe comp. u - BRAKE
8	46375-SR3-A01	Pipe comp. v - BRAKE
9	46376-SR3-A00	Pipe comp. w - BRAKE
10	46377-SR3-A02	Pipe comp. x - BRAKE
11	46378-SR3-A00	Pipe comp. y - BRAKE
12	46379-SR3-A00	Pipe comp. z - BRAKE
13	46380-SH3-000	Grommet a - BRAKE PIPE
14	46391-SR3-J00	Clamp - BRAKE PIPE
15	46391-SR3-J10	Clamp - BRAKE PIPE
16	46391-SR3-922	Clip b - BRAKE PIPE
17	46391-SR3-931	Clip d - BRAKE PIPE
18	46391-SR3-942	Clip e - BRAKE PIPE
19	46392-SR3-000	Clip - BRAKE PIPE
20	46392-SR3-910	Clamp - BRAKE PIPE
21	46392-SR3-931	Clip - BRAKE PIPE
22	46393-SM4-951	Clip c
23	46394-SH3-A01	Clip - BRAKE PIPE
24	46410-SR3-N05	Hose - R. FR. BRAKE (NICHIRIN)
25	46411-SR3-N05	Hose - L. FR. BRAKE (NICHIRIN)
26	46430-SR3-941	Hose - R. RR. BRAKE (NICHIRIN) (DISK)
27	46431-SR3-941	Hose - L. RR. BRAKE (NICHIRIN) (DISK)
28	46460-SR3-801	Joint assy. - FOUR WAY
29	46462-SE0-000	Bolt - OIL
30	46470-SH9-802	Joint - FOUR WAY
31	46472-568-000	Packing - OIL BOLT
34	90651-538-000	Clip - BRAKE HOSE
39	90361-SV4-003	Nut - PAINT CUTTING, 6MM

Brake lines (3) 30

#	OEM	部品名
1	01464-SR3-N03	Hose set - R. FR. BRAKE
2	01465-SR3-N02	Hose set - L. FR. BRAKE
3	01466-SR3-903	Hose set - R. RR. BRAKE
4	01468-SR3-902	Hose set - L. RR. BRAKE
5	46330-SR3-J00	Pipe comp. c - BRAKE
6	46340-SR3-J00	Pipe comp. d - BRAKE
7	46374-SR3-A01	Pipe comp. u - BRAKE
8	46375-SR3-A01	Pipe comp. v - BRAKE
9	46376-SR3-A00	Pipe comp. w - BRAKE
10	46377-SR3-A02	Pipe comp. x - BRAKE
11	46378-SR3-A00	Pipe comp. y - BRAKE
12	46379-SR3-A00	Pipe comp. z - BRAKE
13	46380-SH3-000	Grommet a - BRAKE PIPE
14	46391-SR3-J00	Clamp - BRAKE PIPE
15	46391-SR3-J10	Clamp - BRAKE PIPE
16	46391-SR3-922	Clip b - BRAKE PIPE
17	46391-SR3-931	Clip d - BRAKE PIPE
18	46391-SR3-942	Clip e - BRAKE PIPE
19	46392-SR3-000	Clip - BRAKE PIPE
20	46392-SR3-910	Clamp - BRAKE PIPE
21	46392-SR3-931	Clip - BRAKE PIPE
22	46393-SM4-951	Clip c
23	46394-SH3-A01	Clip - BRAKE PIPE
24	46395-SR3-A01	Clip c - BRAKE PIPE
25	46460-SR3-801	Joint assy. - FOUR WAY
26	46462-SE0-000	Bolt - OIL
27	46470-SH9-802	Joint - FOUR WAY
28	46472-568-000	Packing - OIL BOLT
29	90361-SV4-003	Nut - PAINT CUTTING, 6MM
30	90651-538-000	Clip - BRAKE HOSE

Brake master cylinder/ master power (2) 28

#	OEM	部品名
1	46100-SR3-832	Cylinder assy. - MASTER
1	06464-SM4-000	Power set - MASTER (7"+8")
2	46138-SM4-003	Packing
2	46070-SL0-G01	Plate - SYMBOL MARK
3	46151-SB2-003	Yoke - PUSH ROD (NISSIN)
4	46185-SE0-003	Seal - ROD
5	46191-634-000	Gasket - MASTER CYLINDER BRACKET
6	46400-SM4-003	Power assy. - MASTER (7"+8")
7	46403-SE0-003	Valve comp. - CHECK (NISSIN)
8	46404-ST7-A10	Tube a - MASTER POWER
9	46405-SR3-A20	Tube b - MASTER POWER
10	46406-SR3-000	Stay - MASTER POWER TUBE
11	46512-SB2-000	Pin - PEDAL
12	46660-SE3-013	Tank - RESERVE
13	46662-SK7-003	Cap comp. - RESERVE TANK
14	46665-ST5-003	Band - RESERVE TANK
15	46666-SE3-013	Filter - MASTER CYLINDER
16	46669-SE3-003	Seal - RESERVE TANK
17	53729-671-003	Clamp d - 15.5MM
18	57173-SB0-801	O-ring - CONNECTOR
19	57515-SM4-013	Bolt comp - STOPPER
20	57520-SE0-013	Piston assy. - PRIMARY
20	57520-SE0-023	Piston assy. - PRIMARY
21	57540-SE0-013	Piston assy. - SECONDARY
21	57540-SE0-023	Piston assy. - SECONDARY
22	57560-SE0-003	Guide assy - PISTON
23	57562-SF1-003	Circlip
24	90139-ST7-000	Bolt-washer - 6X20

Breather chamber 13

#	OEM	部品名
1	11850-PR3-000	Chamber comp - BREATHER
3	11853-PR3-000	Grommet, BREATHER CHAMBER
5	11854-PR3-000	Joint, BREATHER CHAMBER
8	11855-P30-000	Tube A, PCV
10	11856-P30-000	Tube B, PCV
11	11857-PR3-000	Tube C, PCV
13	17130-P72-003	Valve assy. - PCV
13	17130-P0A-003	Valve assy. - PCV
13	17130-PK1-003	Valve assy. - PCV
15	17135-P30-000	Pipe comp - BREATHER
18	91324-PR3-003	O-ring, 29X2.5
21	91405-P05-A01	Clamp - TUBE (D13.8)
22	17153-PR3-000	Tube - BREATHER

Bumper 17

#	OEM	部品名
2	71110-SR3-000	Spoiler, FR. AIR
4	71144-SR3-013	Grommet - BUMPER SIDE
5	71145-SR3-G00	Base - FR. LICENSE PLATE
5	71145-S10-G01	Bracket - FR. LICENSE PLATE
9	71521-SR3-010	Spacer - RR. BUMPER
10	90101-SE0-010	Bolt assy. b - BUMPER
11	90102-SK7-000	Bolt assy - BUMPER
12	90109-SE0-003	Bolt b - BUMPER
13	90111-SM4-003	Bolt - BUMPER
14	90112-SM4-003	Bolt - BUMPER
15	90114-SE0-000	Screw - TAPPING, 5X20
16	90121-SA7-000	Screw - TAPPING, 5X16
17	90130-SB0-010	Bolt assy - BUMPER
18	90305-SH3-000	Nut - AIR SPOILER CLIP
19	90540-SA7-000	Washer - BUMPER
22	91503-SP0-013	Clip A - BUMPER
22	91503-SP0-003	Clip A

Bumpers (1) 13

#	OEM	部品名
4	71110-SR3-000	Spoiler, FR. AIR
5	71113-SH2-000	Nut - LICENSE PLATE
6	71144-SR3-013	Grommet - BUMPER SIDE
9	71521-SR3-010	Spacer - RR. BUMPER
10	90101-SE0-010	Bolt assy. b - BUMPER
11	90102-SK7-000	Bolt assy - BUMPER
12	90109-SE0-003	Bolt b - BUMPER
13	90111-SM4-003	Bolt - BUMPER
14	90112-SM4-003	Bolt - BUMPER
16	90121-SA7-000	Screw - TAPPING, 5X16
17	90130-SB0-010	Bolt assy - BUMPER
18	90305-SH3-000	Nut - AIR SPOILER CLIP
19	90540-SA7-000	Washer - BUMPER

Camshaft/timing belt (4) 25

#	OEM	部品名
1	11810-PR3-010	Cover - TIMING BELT LOWER
2	11812-PJ7-310	Grommet - TIMING BELT COVER
3	11820-PR3-010	Cover - TIMING BELT MIDDLE
4	11831-PR3-000	Rubber, LOWER SEAL
5	11832-PR3-000	Rubber - R. BACK SEAL
6	11840-PR3-010	Cover - TIMING BELT BACK
7	11925-P30-000	Rubber A, ENGINE MOUNTING BRACKET SEAL
8	11926-PR3-000	Rubber B, ENGINE MOUNTING BRACKET SEAL
9	14111-P30-G00	Camshaft - INTAKE
10	14121-P30-G00	Camshaft - EX.
11	14211-PR3-003	Pulley - TIMING BELT DRIVEN
12	14400-PR3-004	Belt - TIMING (UNITTA)
13	14510-P30-003	Tensioner, TIMING BELT (KOYO SEIKO)
14	14513-PK1-000	Bolt - TIMING BELT ADJUSTER BASE
15	14516-PR3-000	Spring comp - TIMING BELT ADJUSTER
16	56999-PR3-000	Insulator - TIMING BELT COVER HEAT
16	56999-P2T-000	Insulator - TIMING BELT COVER HEAT
17	90007-679-000	Bolt a - TIMING BELT COVER
18	90010-PR3-000	Bolt - TIMING BELT COVER
19	90012-PH3-004	Bolt - TIMING BELT ADJUSTER SPRING (NAGOYA RASHI)
20	90026-PR3-003	Bolt - TENSIONER
21	90031-PV0-003	Bolt-washer - 10X30
21	90031-PV0-305	Bolt-washer (10x30)
22	90741-657-000	Key - 25.4X13
23	91213-PR3-004	Oil seal - 29X43X8 (ARAI)

Camshaft/timing belt (DOHC VTEC) 24

#	OEM	部品名
1	11810-PR3-010	Cover - TIMING BELT LOWER
2	11812-PJ7-310	Grommet - TIMING BELT COVER
3	11820-PR3-010	Cover - TIMING BELT MIDDLE
4	11831-PR3-000	Rubber, LOWER SEAL
5	11832-PR3-000	Rubber - R. BACK SEAL
6	11840-PR3-010	Cover - TIMING BELT BACK
7	11925-P30-000	Rubber A, ENGINE MOUNTING BRACKET SEAL
8	11926-PR3-000	Rubber B, ENGINE MOUNTING BRACKET SEAL
9	14111-P30-G00	Camshaft - INTAKE
10	14121-P30-G00	Camshaft - EX.
11	14211-PR3-003	Pulley - TIMING BELT DRIVEN
12	14400-PR3-004	Belt - TIMING (UNITTA)
13	14510-P30-003	Tensioner, TIMING BELT (KOYO SEIKO)
14	14513-PK1-000	Bolt - TIMING BELT ADJUSTER BASE
15	14516-PR3-000	Spring comp - TIMING BELT ADJUSTER
16	56999-PR3-000	Insulator - TIMING BELT COVER HEAT
17	90007-679-000	Bolt a - TIMING BELT COVER
18	90010-PR3-000	Bolt - TIMING BELT COVER
19	90012-PH3-004	Bolt - TIMING BELT ADJUSTER SPRING (NAGOYA RASHI)
20	90026-PR3-003	Bolt - TENSIONER
21	90031-PV0-003	Bolt-washer - 10X30
21	90031-PV0-305	Bolt-washer (10x30)
22	90741-657-000	Key - 25.4X13
23	91213-PR3-004	Oil seal - 29X43X8 (ARAI)

Clutch housing (2) 36

#	OEM	部品名
1	21000-P21-000	Case comp. - CLUTCH
1	21000-P21-020	Case comp. - CLUTCH
1	21000-P21-010	Case comp. - CLUTCH
2	21101-PS1-000	Plate - NEEDLE SET
3	21103-PS1-000	Plate c - OIL GUIDE
4	21106-PS1-000	Plate - OIL CHAMBER
5	21120-PG2-003	Magnet - TRANSMISSION
6	41100-P21-000	Case assy. - DIFFERENTIAL
7	41233-P21-000	Gear - FINAL DRIVEN
8	41452-PL3-B00	Shim m - 80MM(1.25)
8	41447-PL3-B00	Shim g - 80MM(1.6)
8	41442-PL3-B00	Shim b - 80MM(1.1)
8	41454-PL3-B00	Shim p - 80MM(1.45)
8	41449-PL3-B00	Shim j - 80MM(1.8)
8	41444-PL3-B00	Shim d - 80MM(1.3)
8	41456-PL3-B00	Shim r - 80MM(1.65)
8	41451-PL3-B00	Shim l - 80MM(1.15)
8	41446-PL3-B00	Shim f - 80MM(1.5)
8	41441-PL3-B00	Shim a - 80MM(1.0)
8	41453-PL3-B00	Shim n - 80MM(1.35)
8	41448-PL3-B00	Shim h - 80MM(1.7)
8	41443-PL3-B00	Shim c - 80MM(1.2)
8	41455-PL3-B00	Shim q - 80MM(1.55)
8	41450-PL3-B00	Shim k - 80MM(1.05)
8	41445-PL3-B00	Shim e - 80MM(1.4)
8	41457-PL3-B00	Shim s - 80MM(1.75)
9	90017-689-000	Bolt - SPECIAL, 10MM
10	90406-PS1-000	Washer - LOCK
11	91002-PS1-003	Bearing - BALL, 28X60X15
12	91005-PS1-003	Bearing - SEALED BALL, 6208C (NTN)
13	91101-PG1-008	Bearing - NEEDLE, 33X60X20 (TOYO)
14	91205-PL3-A02	Oil seal - 35X56X8(NOK)
14	91205-PL3-A01	Oil seal - 35X56X8 (ARAI)
15	91215-689-013	Oil seal - 14X25X16
16	91216-PH8-003	Oil seal - 28X41X7 (ARAI)
16	91216-PH8-005	Oil seal - 28X41X7 (NOK)

Clutch housing (DOHC VTEC) 36

#	OEM	部品名
1	21000-P21-010	Case comp. - CLUTCH
1	21000-P21-000	Case comp. - CLUTCH
1	21000-P21-020	Case comp. - CLUTCH
2	21101-PS1-000	Plate - NEEDLE SET
3	21103-PS1-000	Plate c - OIL GUIDE
4	21106-PS1-000	Plate - OIL CHAMBER
5	21120-PG2-003	Magnet - TRANSMISSION
6	41100-P21-000	Case assy. - DIFFERENTIAL
7	41233-P21-E00	Gear - FINAL DRIVEN
8	41450-PL3-B00	Shim k - 80MM(1.05)
8	41445-PL3-B00	Shim e - 80MM(1.4)
8	41457-PL3-B00	Shim s - 80MM(1.75)
8	41452-PL3-B00	Shim m - 80MM(1.25)
8	41447-PL3-B00	Shim g - 80MM(1.6)
8	41442-PL3-B00	Shim b - 80MM(1.1)
8	41454-PL3-B00	Shim p - 80MM(1.45)
8	41449-PL3-B00	Shim j - 80MM(1.8)
8	41444-PL3-B00	Shim d - 80MM(1.3)
8	41456-PL3-B00	Shim r - 80MM(1.65)
8	41451-PL3-B00	Shim l - 80MM(1.15)
8	41446-PL3-B00	Shim f - 80MM(1.5)
8	41441-PL3-B00	Shim a - 80MM(1.0)
8	41453-PL3-B00	Shim n - 80MM(1.35)
8	41448-PL3-B00	Shim h - 80MM(1.7)
8	41443-PL3-B00	Shim c - 80MM(1.2)
8	41455-PL3-B00	Shim q - 80MM(1.55)
9	90017-689-000	Bolt - SPECIAL, 10MM
10	90406-PS1-000	Washer - LOCK
11	91002-PS1-003	Bearing - BALL, 28X60X15
12	91005-PS1-003	Bearing - SEALED BALL, 6208C (NTN)
13	91101-PG1-008	Bearing - NEEDLE, 33X60X20 (TOYO)
14	91205-PL3-A02	Oil seal - 35X56X8(NOK)
14	91205-PL3-A01	Oil seal - 35X56X8 (ARAI)
15	91215-689-013	Oil seal - 14X25X16
16	91216-PH8-005	Oil seal - 28X41X7 (NOK)
16	91216-PH8-003	Oil seal - 28X41X7 (ARAI)

Clutch master cylinder (1) 36

#	OEM	部品名
1	43352-567-000	Screw - BLEEDER
2	43353-SD5-003	Cap - BLEEDER SCREW
3	46151-SA5-003	Yoke comp. - NISSIN
4	46164-632-000	Float
5	46182-500-013	Circlip
6	46184-611-000	Dust seal - MASTER CYLINDER
7	46912-SD4-000	Pin - CLUTCH PEDAL
9	46920-SR3-A01	Cylinder assy. - CLUTCH MASTER
11	46926-SF1-003	Piston assy.
12	46928-SF1-000	Seal - CLUTCH MASTER CYLINDER
13	46930-SR3-013	Cylinder assy. - SLAVE
14	46932-SD4-003	Piston - SLAVE CYLINDER
15	46933-SD4-013	Cup a - PISTON
16	46934-SD4-003	Cup b - PISTON
17	46935-SP0-000	Spring - SLAVE CYLINDER
18	46937-SR3-003	Boot - SLAVE CYLINDER
19	46938-SD4-003	Rod - PUSH
20	46939-SR3-A01	Joint - CLUTCH PIPE
21	46950-SL4-003	Rod assy - PUSH
22	46952-SD4-003	Joint - TUBE
23	46953-SD4-003	Packing
24	46960-SR3-A00	Pipe comp - CLUTCH (A)
25	46961-SR2-G01	Hose - CLUTCH (HIGH EXPANSION)
26	46966-SR3-A00	Holder - TANK
27	46970-SR3-N01	Pipe comp. b - CLUTCH
28	46971-SR3-A00	Tube - CLUTCH FLUID
29	46972-SD4-003	Tank - CLUTCH FLUID
30	46973-SD4-003	Cap comp. - RESERVE TANK
31	46975-SD4-003	Seal - RESERVE TANK
32	46980-SR3-A00	Pipe comp - CLUTCH
33	46995-SR3-A00	Bracket a - CLUTCH PIPE
34	46996-SR3-000	Bracket b - CLUTCH PIPE
35	46997-SR3-J01	Clip - CLUTCH PIPE
36	46998-SR3-A00	Clamp - CLUTCH PIPE
37	90651-538-000	Clip - BRAKE HOSE
45	46918-ST7-000	Clamp - TUBE (D10.5)

Clutch master cylinder (LH) 36

#	OEM	部品名
1	43352-567-000	Screw - BLEEDER
2	43353-SD5-003	Cap - BLEEDER SCREW
3	46151-SA5-003	Yoke comp. - NISSIN
4	46164-632-000	Float
5	46182-500-013	Circlip
6	46184-611-000	Dust seal - MASTER CYLINDER
7	46912-SD4-000	Pin - CLUTCH PEDAL
9	46918-ST7-000	Clamp - TUBE (D10.5)
10	46920-SR3-A01	Cylinder assy. - CLUTCH MASTER
12	46926-SF1-003	Piston assy.
13	46928-SF1-000	Seal - CLUTCH MASTER CYLINDER
14	46930-SR3-013	Cylinder assy. - SLAVE
15	46932-SD4-003	Piston - SLAVE CYLINDER
16	46933-SD4-013	Cup a - PISTON
17	46934-SD4-003	Cup b - PISTON
18	46935-SP0-000	Spring - SLAVE CYLINDER
19	46937-SR3-003	Boot - SLAVE CYLINDER
20	46938-SD4-003	Rod - PUSH
21	46939-SR3-A01	Joint - CLUTCH PIPE
22	46950-SL4-003	Rod assy - PUSH
23	46952-SD4-003	Joint - TUBE
24	46953-SD4-003	Packing
25	46960-SR3-A00	Pipe comp - CLUTCH (A)
26	46961-SR2-G01	Hose - CLUTCH (HIGH EXPANSION)
27	46966-SR3-A00	Holder - TANK
28	46970-SR3-N01	Pipe comp. b - CLUTCH
29	46971-SR3-A00	Tube - CLUTCH FLUID
30	46972-SD4-003	Tank - CLUTCH FLUID
31	46973-SD4-003	Cap comp. - RESERVE TANK
32	46975-SD4-003	Seal - RESERVE TANK
33	46980-SR3-A00	Pipe comp - CLUTCH
34	46995-SR3-A00	Bracket a - CLUTCH PIPE
35	46996-SR3-000	Bracket b - CLUTCH PIPE
36	46997-SR3-J01	Clip - CLUTCH PIPE
37	46998-SR3-A00	Clamp - CLUTCH PIPE
38	90651-538-000	Clip - BRAKE HOSE

Clutch release (2) 12

#	OEM	部品名
1	21222-P21-000	Hanger b - TRANSMISSION
2	22810-P21-003	Bearing - CLUTCH RELEASE (FUJIKOSHI)
3	22821-P80-000	Fork - CLUTCH RELEASE
4	22825-P0S-000	Bolt - RELEASE FORK
5	22835-P80-000	Spring - CLUTCH RELEASE SETTING
6	22841-P20-000	Boot - RELEASE FORK
7	23811-P36-000	Holder comp - SPEEDOMETER GEAR
8	23820-P03-000	Gear comp - SPEEDOMETER
9	90003-P03-000	Bolt-washer - 6X26
10	90638-689-000	Clip - SPEEDOMETER GEAR
11	91304-PT0-000	O-ring - 14.8X1.9
12	91313-611-010	O-ring - 23.5X2

Clutch release (DOHC VTEC) 12

#	OEM	部品名
1	21222-P21-000	Hanger b - TRANSMISSION
2	22810-P21-003	Bearing - CLUTCH RELEASE (FUJIKOSHI)
3	22821-P80-000	Fork - CLUTCH RELEASE
4	22825-P0S-000	Bolt - RELEASE FORK
5	22835-P80-000	Spring - CLUTCH RELEASE SETTING
6	22841-P20-000	Boot - RELEASE FORK
7	23811-P36-000	Holder comp - SPEEDOMETER GEAR
8	23820-P03-000	Gear comp - SPEEDOMETER
9	90003-P03-000	Bolt-washer - 6X26
10	90638-689-000	Clip - SPEEDOMETER GEAR
11	91304-PT0-000	O-ring - 14.8X1.9
12	91313-611-010	O-ring - 23.5X2

Clutch/torque converter 8

#	OEM	部品名
1	21351-PR3-010	Cover - CLUTCH CASE
4	22100-P72-000	Flywheel comp.
5	22200-P54-000	Disk comp - FRICTION
6	22300-P30-030	Disk comp - PRESSURE
9	90011-PH3-000	Bolt - FLANGE, 12MM
11	90034-689-000	Bolt - TWELVE POINT, 8MM (TOKAI TRW)
13	91006-634-008	Bearing - CLUTCH PILOT (NTN)
13	91006-634-004	Bearing - CLUTCH PILOT (KOYO)

Combination switch 22

#	OEM	部品名
1	04352-SR3-A00	Shoe set - HORN (SERVICE)
2	35010-SR3-G11	Cylinder set - KEY
2	35010-SR3-G01	Cylinder set - KEY
3	35100-SR3-G12	Lock assy - STEERING
3	35100-SR3-G02	Lock assy - STEERING
4	35102-SG0-003	Bolt - BREAK HEAD
4	35102-SV4-003	Bolt - BREAK HEAD
5	35103-SE3-003	Screw - RECESSED, 3X8
6	35113-SH3-G02	Key - BLANK (MAIN) (MOLD=BLACK)
7	35130-SR3-A01	Switch comp - STEERING
8	35250-SR3-G32	Switch assy - COMBINATION
8	35250-SR3-G13	Switch assy - COMBINATION (###)
9	35251-SR3-A81	Body - SWITCH
9	35251-SR3-003	Body - SWITCH
10	35255-SR3-G02	Switch assy - LIGHTING (B)
11	35256-SR3-G11	Switch assy - WIPER (G)
13	35259-SR3-A02	Shoe - HORN
14	35400-SL4-003	Switch assy - DOOR
15	35401-SL4-003	Cover - DOOR SWITCH
16	35409-692-013	Screw - FLANGE, 4X12
17	53271-SR3-000	Cam - TURN SIGNAL SWITCH CANCEL
18	91547-SF4-003	Band - WIRE HARNESS (BLUE) (123.5MM)

Console 7

#	OEM	部品名
1	77180-SR3-000	Bracket - INSTRUMENT CENTER LOWER
2	77189-SR3-000	Cover - CENTER LOWER BRACKET
12	88324-SB3-950	Cover - RR. ASHTRAY
13	90137-SH3-000	Screw - TAPPING, 4X16
14	90153-SB6-003	Bolt - EARTH, 6X12(ZN)
15	90666-SD4-003	Clip - FITTING
16	91647-SH3-003	Grommet - SCREW, 4MM

Control unit (CABIN; 1) 17

#	OEM	部品名
1	37820-P30-M01	Control module - ENGINE
2	37821-P05-A00	Cover - ELECTRONIC CONTROL UNIT HARNESS
6	38200-SR3-G22	Box assy - JOINT
7	38203-SR3-A00	Bracket - L. FUSE BOX
8	38205-SR3-G02	Label - FUSE
10	38210-SR3-A81	Fuser assy. - SRS (L)
11	38235-SA5-003	Puller - FUSE (SUMITOMO)
12	38300-SE3-003	Relay assy - TURN SIGNAL & HAZARD (FR-3309) (MITSUBA)
12	38300-SE3-004	Relay assy - TURN SIGNAL & HAZARD (166500-0060) (DENSO)
13	38380-SR3-003	Control unit - AUTO DOOR LOCK (MITSUBA)
15	39400-SR3-003	Relay assy - MAIN (RZ-0132) (MITSUBA)
15	39400-S10-003	Relay assy - MAIN (MITSUBA)
16	39790-SR3-A02	Abs control unit
17	39791-SR3-000	Bracket - ABS
18	39793-SR3-A01	Relay assy - POWER (5P) (SUNROOF)
19	39794-SE0-003	Relay assy - POWER(4P)(DENSO) (056700-7250)
23	90670-SG0-003	Grommet - SCREW, 4MM

Control unit (CABIN; LH) 21

#	OEM	部品名
1	37820-P30-G01	Control module - ENGINE
2	37821-P05-A00	Cover - ELECTRONIC CONTROL UNIT HARNESS
3	38200-SR3-G12	Box assy - JOINT
4	38203-SR3-A00	Bracket - L. FUSE BOX
5	38205-SR3-G02	Label - FUSE
8	38235-SA5-003	Puller - FUSE (SUMITOMO)
9	38300-SE3-003	Relay assy - TURN SIGNAL & HAZARD (FR-3309) (MITSUBA)
9	38300-SE3-004	Relay assy - TURN SIGNAL & HAZARD (166500-0060) (DENSO)
10	38310-SR7-003	Relay - CLEANER CONTROL (KOITO)
11	38380-SR3-003	Control unit - AUTO DOOR LOCK (MITSUBA)
12	38600-SH3-G11	Control unit - INTEGRATED (LIGHTING ALARM)
13	39400-SR3-003	Relay assy - MAIN (RZ-0132) (MITSUBA)
13	39400-S10-003	Relay assy - MAIN (MITSUBA)
14	39790-SR3-A02	Abs control unit
15	39791-SR3-000	Bracket - ABS
16	39793-SR3-A01	Relay assy - POWER (5P) (SUNROOF)
17	39794-SE0-003	Relay assy - POWER(4P)(DENSO) (056700-7250)
18	39797-SE0-004	Relay assy - POWER (4P) (MITSUBA) (RC-2201)
18	39797-SE0-003	Relay assy - POWER (4P) (DENSO) (056700-7330)
20	90670-SG0-003	Grommet - SCREW, 4MM
21	91902-SB2-003	Cushion - WIRE HARNESS(50X100)

Control unit (ENGINE ROOM; 1) 18

#	OEM	部品名
1	32133-SM4-003	Band - HARNESS OFFSET (30) (YELLOW) (122.5MM)
3	32230-SR3-A01	Harness - ABS FUSE BOX
5	38150-SR3-003	Horn assy - HIGH (MITSUBA)
6	38211-SM4-003	Fuse - BLOCK (30A)
7	38212-SM4-003	Fuse - BLOCK (40A)
8	38213-SM4-003	Fuse - BLOCK (50A)
9	38216-SM4-003	Fuse - BLOCK (80A)
10	38231-SR3-A00	Bracket - ABS FUSE BOX
11	38232-SR3-A00	Stay - ABS COUPLER
12	38250-SR3-G01	Box assy - MAIN FUSE
13	38251-SR3-A01	Cover - UPPER
14	38252-SR3-003	Cover - LOWER
15	39792-SP0-004	Relay assy - POWER (4P) (MITSUBA) (12V NO)
16	39794-SL0-004	Relay assy - POWER(4P) (MITSUBA)(RC-2225)(BLACK)
16	39794-SE0-003	Relay assy - POWER(4P)(DENSO) (056700-7250)
18	90129-SP0-000	Screw-washer - 5X12
19	90130-SR3-003	Bolt - 5X13
20	90153-SB2-003	Screw-washer - 5X10

Control unit (ENGINE ROOM; LH) 19

#	OEM	部品名
1	32133-SM4-003	Band - HARNESS OFFSET (30) (YELLOW) (122.5MM)
2	32230-SR3-A01	Harness - ABS FUSE BOX
3	38150-SR3-003	Horn assy - HIGH (MITSUBA)
4	38211-SM4-003	Fuse - BLOCK (30A)
5	38212-SM4-003	Fuse - BLOCK (40A)
6	38213-SM4-003	Fuse - BLOCK (50A)
7	38216-SM4-003	Fuse - BLOCK (80A)
8	38231-SR3-A00	Bracket - ABS FUSE BOX
9	38232-SR3-A00	Stay - ABS COUPLER
10	38235-SR3-A00	Cover - UPPER
12	38250-SR3-G01	Box assy - MAIN FUSE
13	38251-SR3-A01	Cover - UPPER
14	38252-SR3-003	Cover - LOWER
15	39792-SP0-004	Relay assy - POWER (4P) (MITSUBA) (12V NO)
16	39794-SE0-003	Relay assy - POWER(4P)(DENSO) (056700-7250)
16	39794-SL0-004	Relay assy - POWER(4P) (MITSUBA)(RC-2225)(BLACK)
18	90129-SP0-000	Screw-washer - 5X12
19	90130-SR3-003	Bolt - 5X13
20	90153-SB2-003	Screw-washer - 5X10

Countershaft (2) 19

#	OEM	部品名
1	23221-P21-020	Countershaft
2	23421-PS1-N00	Gear - COUNTERSHAFT LOW
3	23431-P21-000	Gear - COUNTERSHAFT SECOND
4	23461-P21-F00	Gear - COUNTERSHAFT FIFTH
5	23471-P21-000	Gear - COUNTERSHAFT THIRD
6	23481-P21-000	Gear - COUNTERSHAFT FOURTH
7	23521-P21-315	Sleeve set - SYNCHRONIZER (1-2)
8	23918-P21-010	Collar - DISTANCE, 36.5X42X29 (0.07-0.09)
9	23921-PK5-900	Washer a - 40X54X1.95
10	23926-P21-000	Washer - SPRING, 23MM
11	90202-PH8-000	Nut - HEX., 23MM
12	90603-PL3-000	Ring - SNAP, 52MM
13	91003-P21-003	Bearing - BALL, 25X52X14/15 (NTN)
14	91102-P21-003	Bearing - NEEDLE, 25X52.2X15 (NTN)
14	91102-PLW-003	Bearing - NEEDLE, 25X52.2X15
15	91105-P21-003	Bearing - NEEDLE, 42X47X24
16	91107-P21-003	Bearing - NEEDLE, 37X42X25
17	91211-P21-008	Damper - FRICTION (LOW)
18	91212-P21-008	Damper - FRICTION (SECOND)

Countershaft (DOHC VTEC) 19

#	OEM	部品名
1	23221-P21-E02	Countershaft
2	23421-P21-000	Gear - COUNTERSHAFT LOW
3	23431-P21-000	Gear - COUNTERSHAFT SECOND
4	23461-P21-010	Gear - COUNTERSHAFT FIFTH
5	23471-P21-000	Gear - COUNTERSHAFT THIRD
6	23481-P21-000	Gear - COUNTERSHAFT FOURTH
7	23521-P21-315	Sleeve set - SYNCHRONIZER (1-2)
8	23918-P21-010	Collar - DISTANCE, 36.5X42X29 (0.07-0.09)
9	23921-PK5-900	Washer a - 40X54X1.95
10	23926-P21-000	Washer - SPRING, 23MM
11	90202-PH8-000	Nut - HEX., 23MM
12	90603-PL3-000	Ring - SNAP, 52MM
13	91003-P21-003	Bearing - BALL, 25X52X14/15 (NTN)
14	91102-P21-003	Bearing - NEEDLE, 25X52.2X15 (NTN)
14	91102-PLW-003	Bearing - NEEDLE, 25X52.2X15
15	91105-P21-003	Bearing - NEEDLE, 42X47X24
16	91107-P21-003	Bearing - NEEDLE, 37X42X25
17	91211-P21-008	Damper - FRICTION (LOW)
18	91212-P21-008	Damper - FRICTION (SECOND)

Cylinder block/oil pan (2) 30

#	OEM	部品名
1	11000-PR3-030	Block assy - CYLINDER
2	11105-PR3-000	Joint - PCV
3	11111-PR3-300	Pipe - OIL LEVEL
4	11200-P30-010	Pan comp - OIL
5	11221-PR3-000	Plate comp - BAFFLE
6	11251-P30-004	Oil Pan Packing
7	11300-PR3-000	Cover assy. - R. SIDE
8	11910-P30-000	Bracket - ENGINE MOUNTING
9	11950-PR3-000	Stiffener - RR. ENGINE
10	11960-P30-000	Stiffener - FR. ENGINE
11	15140-PR3-000	Orifice assy - OIL CONTROL
12	15142-PH3-003	O-ring - 10.8X2.4 (ARAI)
13	15280-PR3-000	Body comp - OIL JET
14	15290-PR3-000	Bolt comp - OIL JET
15	15650-P30-000	Gauge comp. - OIL LEVEL
16	90001-PM3-003	Bolt - DRAIN PLUG, 28MM
17	90006-PR3-003	Bolt-washer - 11X104
17	90006-P75-003	Bolt-washer - 11X104
18	90007-PR3-003	Bolt-washer - 11X90
19	90008-PR3-000	Bolt A, ENGINE MOUNT BRACKET (10X60)
20	90009-PH1-000	Bolt - DRAIN PLUG, 14MM
21	90009-PR3-000	Bolt b - ENGINE MOUNT BRACKET (10X40)
22	90041-P01-000	Bolt - STUD, 12X40
23	90042-PR3-000	Bolt - STUD, 6X28
24	90084-657-000	Bolt - SEALING, 16X9.5
25	90401-PR4-000	Washer - SEALING, 28MM
26	90443-PA5-000	Washer - SEALING, 16MM
27	90715-PC6-000	Dowel pin - 13X20
28	91214-PH1-013	Oil seal - 80X100X10 (NOK)
28	91214-PLE-003	Oil seal

Cylinder block/oil pan (DOHC VTEC) 28

#	OEM	部品名
1	11000-PR3-030	Block assy - CYLINDER
2	11105-PR3-000	Joint - PCV
3	11111-PR3-300	Pipe - OIL LEVEL
4	11200-P30-010	Pan comp - OIL
5	11221-PR3-000	Plate comp - BAFFLE
6	11251-P30-004	Oil Pan Packing
7	11300-PR3-000	Cover assy. - R. SIDE
8	11910-P30-000	Bracket - ENGINE MOUNTING
9	11950-PR3-000	Stiffener - RR. ENGINE
10	11960-P30-000	Stiffener - FR. ENGINE
11	15140-PR3-000	Orifice assy - OIL CONTROL
12	15142-PH3-003	O-ring - 10.8X2.4 (ARAI)
13	15280-PR3-000	Body comp - OIL JET
14	15290-PR3-000	Bolt comp - OIL JET
15	15650-P30-000	Gauge comp. - OIL LEVEL
16	90001-PM3-003	Bolt - DRAIN PLUG, 28MM
17	90006-PR3-003	Bolt-washer - 11X104
17	90006-P75-003	Bolt-washer - 11X104
18	90007-PR3-003	Bolt-washer - 11X90
19	90008-PR3-000	Bolt A, ENGINE MOUNT BRACKET (10X60)
20	90009-PH1-000	Bolt - DRAIN PLUG, 14MM
21	90009-PR3-000	Bolt b - ENGINE MOUNT BRACKET (10X40)
22	90041-P01-000	Bolt - STUD, 12X40
23	90042-PR3-000	Bolt - STUD, 6X28
25	90401-PR4-000	Washer - SEALING, 28MM
27	90715-PC6-000	Dowel pin - 13X20
28	91214-PH1-013	Oil seal - 80X100X10 (NOK)
28	91214-PLE-003	Oil seal

Cylinder head (4) 32

#	OEM	部品名
1	12100-P30-010	Head assy - CYLINDER
2	12204-PR3-305	Guide - IN. VALVE (OS)
3	12205-PR3-305	Guide - EX. VALVE (OS)
4	12210-PZ1-004	SEAL A, VALVE STEM (NOK)
4	12210-PZ1-003	Seal a - VALVE STEM(ARAI)
5	12211-PZ1-003	Seal b - VALVE STEM(ARAI)
5	12211-PZ1-004	Seal b - VALVE STEM(NOK)
6	12237-P30-000	Pipe comp - CAM HOLDER
7	12251-P30-004	Gasket comp - CYLINDER HEAD (NIPPON LEAKLESS)
7	12251-P30-014	Gasket, Cylinder Head - (NIPPON LEAKLESS)
8	12513-P30-000	Rubber comp - CYLINDER HEAD SEAL
9	15810-P30-005	Valve assy. - SPOOL
10	15815-PR3-000	Filter, SPOOL VALVE
10	15815-PR3-004	Filter comp - SPOOL VALVE
11	15816-PR3-000	Stay - COUPLER HOLD
12	15825-P08-005	Filter and Gasket, SPOOL VALVE
13	36171-P08-005	Solenoid assy.
14	36172-P08-015	Packing, SOLENOID BASE
15	37250-PR3-003	Switch assy - VALVE TIMING OIL PRESSURE
16	90002-PJ7-010	Bolt - FLANGE, 6X45
17	90002-PR3-000	Bolt - FLANGE, 6X55
18	90004-PE2-005	Bolt - SEALING, 10MM
19	90006-PG6-003	Bolt-washer - 11X155
20	90014-PR3-000	Bolt A, HEAD COVER
21	90026-PE0-000	Bolt - STUD, 8X37
21	90026-PT0-000	Bolt - STUD, 8X38
22	90401-PE2-003	Washer - SEALING, 10MM
23	90701-679-000	Dowel pin - 8X10
24	91308-PH9-000	O-ring - 8.8X1.9
24	91302-GE0-000	O-ring (8.8x1.9)
25	91319-PR3-000	O-ring - 13X1.5
25	91319-PR3-003	O-ring - 13X1.5 (ARAI)

Cylinder head (DOHC VTEC) 32

#	OEM	部品名
1	12100-P30-010	Head assy - CYLINDER
2	12204-PR3-305	Guide - IN. VALVE (OS)
3	12205-PR3-305	Guide - EX. VALVE (OS)
4	12210-PZ1-004	SEAL A, VALVE STEM (NOK)
4	12210-PZ1-003	Seal a - VALVE STEM(ARAI)
5	12211-PZ1-003	Seal b - VALVE STEM(ARAI)
5	12211-PZ1-004	Seal b - VALVE STEM(NOK)
6	12237-P30-000	Pipe comp - CAM HOLDER
7	12251-P30-004	Gasket comp - CYLINDER HEAD (NIPPON LEAKLESS)
7	12251-P30-014	Gasket, Cylinder Head - (NIPPON LEAKLESS)
8	12513-P30-000	Rubber comp - CYLINDER HEAD SEAL
9	15810-P30-005	Valve assy. - SPOOL
10	15815-PR3-000	Filter, SPOOL VALVE
10	15815-PR3-004	Filter comp - SPOOL VALVE
11	15816-PR3-000	Stay - COUPLER HOLD
12	15825-P08-005	Filter and Gasket, SPOOL VALVE
13	36171-P08-005	Solenoid assy.
14	36172-P08-015	Packing, SOLENOID BASE
15	37250-PR3-003	Switch assy - VALVE TIMING OIL PRESSURE
16	90002-PJ7-010	Bolt - FLANGE, 6X45
17	90002-PR3-000	Bolt - FLANGE, 6X55
18	90004-PE2-005	Bolt - SEALING, 10MM
19	90006-PG6-003	Bolt-washer - 11X155
20	90014-PR3-000	Bolt A, HEAD COVER
21	90026-PE0-000	Bolt - STUD, 8X37
21	90026-PT0-000	Bolt - STUD, 8X38
22	90401-PE2-003	Washer - SEALING, 10MM
23	90701-679-000	Dowel pin - 8X10
25	91308-PH9-000	O-ring - 8.8X1.9
25	91302-GE0-000	O-ring (8.8x1.9)
26	91319-PR3-000	O-ring - 13X1.5
26	91319-PR3-003	O-ring - 13X1.5 (ARAI)

Cylinder head cover (2) 14

#	OEM	部品名
2	12030-P30-000	Packing set - HEAD COVER
4	12310-P30-000	Cover comp. - CYLINDER HEAD
5	12341-PR3-000	Packing - CYLINDER HEAD COVER
7	12342-PG6-000	Packing b - HEAD COVER
7	12342-PT2-000	Packing b - HEAD COVER
9	12500-PR3-000	Cover - HIGH TENSION CORD
10	15610-PC6-000	Cap assy. - OIL FILLER
11	15613-PC6-000	Packing, Oil Filler
13	32762-PR3-000	HIGH TENSION CORD CLAMP STAY B
14	32770-PR3-000	Stay c - HIGH TENSION CORD CLAMP
15	90012-PM7-000	Bolt B, Head Cover
18	90212-PR3-000	Nut - HEAD COVER
19	90213-PH3-000	Nut - CAP, 6MM
21	90442-P30-000	Washer - HEAD COVER

Cylinder head cover (VTEC) 14

#	OEM	部品名
2	12030-P30-000	Packing set - HEAD COVER
4	12310-P30-000	Cover comp. - CYLINDER HEAD
5	12341-PR3-000	Packing - CYLINDER HEAD COVER
7	12342-PG6-000	Packing b - HEAD COVER
7	12342-PT2-000	Packing b - HEAD COVER
9	12500-PR3-000	Cover - HIGH TENSION CORD
10	15610-PC6-000	Cap assy. - OIL FILLER
11	15613-PC6-000	Packing, Oil Filler
14	32762-PR3-000	HIGH TENSION CORD CLAMP STAY B
15	32770-PR3-000	Stay c - HIGH TENSION CORD CLAMP
16	90012-PM7-000	Bolt B, Head Cover
19	90212-PR3-000	Nut - HEAD COVER
20	90213-PH3-000	Nut - CAP, 6MM
22	90442-P30-000	Washer - HEAD COVER

Distributor (TEC) 12

#	OEM	部品名
1	30100-P30-006	Distributor assy - TD-44U) (TEC
2	30102-PT2-026	Distributor Cap
2	30102-P54-006	Cap assy.
3	30103-P08-003	Distributor Rotor Head Assembly
4	30105-P30-006	Housing comp - DISTRIBUTOR (TEC)
5	30107-P08-006	Cover - LEAK
6	30110-PA1-732	O-ring - 26.4X3.1 (TEC)
9	30130-P06-006	Igniter unit - E12-303) (HITACHI
10	30132-PT2-006	Packing - CAP
11	30135-P08-006	Screw-washer - 5X12
11	30135-P73-004	Screw-washer - 5X12
12	30510-PT2-006	Ignition Coil

Door lining 6

#	OEM	部品名
3	72335-SR3-003	Weatherstrip - DOOR INNER
8	83508-SR3-000	Bracket assy - PULL POCKET
16	90662-SB2-003	Grommet - SCREW, 5MM
17	90678-SK7-003	Clip - SPEAKER
19	91560-SP0-003	Clip - DOOR LINING (GRAY)
19	91560-S84-A01	CLIP, DOOR LINING (NATURAL)

Door locks 30

#	OEM	部品名
1	72110-SR3-J11	Lock assy - R. FR. POWER DOOR
2	72110-SR3-G01	Lock assy - R. FR. DOOR
3	72115-SR3-J11	Actuator - R. DOOR LOCK
6	72123-SR0-003	Ring - OUTSIDE HANDLE
8	72131-SR3-003	Rod - R. INSIDE HANDLE
8	72130-SR3-A01	Protector - R. DOOR CYLINDER
9	72132-SR3-003	Rod - R. INSIDE LOCK
10	72134-SM1-003	Bush - OUTSIDE HANDLE JOINT
11	72135-SR3-003	Striker assy - DOOR LOCK
12	72136-SR3-003	Joint
13	72139-SR3-003	Fastener - NATURAL
14	72140-SR3-013	Handle assy - R. FR. DOOR OUTSIDE
15	72145-SR3-003	Cylinder - R. DOOR
16	72146-SR3-003	Cylinder - L. DOOR
18	72150-SR3-J01	Lock assy - L. FR. POWER DOOR (###)
19	72150-SR3-G01	Lock assy - L. FR. DOOR
20	72156-SR3-J01	Switch assy - L. DOOR LOCK
24	72171-SR3-003	Rod - L. INSIDE HANDLE
25	72172-SR3-003	Rod - L. INSIDE LOCK
25	72170-SR3-A01	Protector - L. DOOR CYLINDER
26	72175-SH3-901	Holder - DOOR LOCK ROD
27	72180-SR3-013	Handle assy - L. FR. OUTSIDE
28	75513-SB2-000	Cushion - LOCK ROD (35MMX58MM)
29	90120-SV4-000	Bolt - LOCK STRIKER
30	35103-SE3-003	Screw - RECESSED, 3X8
31	90102-SR3-003	Screw - TAPPING, 3X14
32	90120-SM4-000	Screw - TAPPING
33	90662-SB2-003	Grommet - SCREW, 5MM
34	91540-SV4-003	Clip - HARNESS BAND (NATURAL) (145.2MM)
35	91580-SM4-003	Clip - COUPLER(ORANGE)

Door panels 17

#	OEM	部品名
11	72310-SR3-003	Weatherstrip - R. FR. DOOR
12	72321-SR3-J00	Seal - R. FR. DOOR HOLE
13	72325-SR3-004	Sub seal - R. FR. DOOR
14	72340-SH3-003	Checker comp. - DOOR
15	72350-SR3-003	Weatherstrip - L. FR. DOOR
16	72361-SR3-J10	Seal - L. FR. DOOR HOLE
17	72365-SR3-004	Sub seal - L. FR. DOOR
17	72325-SR3-014	Sub seal - R. FR. DOOR
18	75760-SB2-003	Pin - DOOR CHECKER
19	75891-SA7-000	Stopper - DOOR
20	90001-SD2-000	Bolt - FLANGE, 8X22
21	90157-SA0-000	Bolt-washer - 8X25
21	72365-SR3-014	Sub seal - L. FR. DOOR
22	90686-692-003	Cap - LINING MOUNT
23	90755-SB2-000	E-ring - 6MM
24	91530-SP1-003	Clip A - DOOR WEATHERSTRIP
25	91534-SR3-003	Clip - DOOR SUB SEAL

Door windows 19

#	OEM	部品名
2	72211-SR3-J01	Regulator - R. FR. DOOR POWER
5	72215-SR3-A01	Motor assy. - R. WINDOW
6	72231-SR3-003	Sash - R. DOOR CENTER LOWER
7	72235-SR3-004	Runchannel - R. FR. DOOR
8	72246-SR3-003	Stopper - DOOR GLASS
10	72251-SR3-J01	Regulator - L. FR. DOOR POWER
11	72255-SR3-A01	Motor assy. - L. WINDOW
11	72255-SR3-505	MOTOR ASSY., L. FR. WINDOW
12	72271-SR3-003	Sash - L. DOOR CENTER LOWER
13	72275-SR3-004	Runchannel - L. FR. DOOR
14	73300-SR0-A00	Glass assy - R. DOOR (GREEN)
14	73300-SR3-000	Glass assy - R. FR. DOOR (BLUE)
15	73350-SR0-A00	Glass assy - L. DOOR (GREEN)
15	73350-SR3-000	Glass assy - L. FR. DOOR (BLUE)
18	90011-896-000	Bolt - FLANGE, 6X8
19	90115-SG0-003	Bolt - FLANGE, 6MM
20	90120-SE3-003	Bolt - FLANGE, 6X12
21	91555-SM4-003	Clip - COUPLER (RED)
22	91540-SV4-003	Clip - HARNESS BAND (NATURAL) (145.2MM)

Driveshaft/half shaft 31

#	OEM	部品名
1	44010-ST7-N50	Driveshaft set - R.
2	44011-ST7-N50	Driveshaft set - L.
3	44017-SR3-900	Boot set - INBOARD
3	44017-SR3-901	Boot set
5	44310-SH3-J00	Joint comp - INBOARD
6	44310-ST7-900	Joint comp - INBOARD
6	44310-SL5-N00	Joint comp - INBOARD
7	44328-SB0-300	Band - INBOARD BOOT
8	44329-SB0-300	Band - DRIVESHAFT BOOT
8	44352-SA2-300	Band - DAMPER WEIGHT
9	44319-S0A-300	Set ring - 28X2.0
9	44319-S84-300	Set ring - 28X2.0
10	44327-SV4-305	Band - JOINT BOOT (DOUBLE ROLLED BAND)
11	44336-SB0-300	Ring a - STOPPER
12	44338-SB0-300	Circlip - 26MM
13	44347-SF1-003	Ring - OUTBOARD
14	44351-SR3-A11	Damper - DYNAMIC (HOKUSHIN)
15	44351-SR3-J01	Damper - DYNAMIC (HOKUSHIN)
17	44500-SR3-J01	Shaft assy - HALF
18	44502-SR3-J00	Support comp - HALF SHAFT (###)
19	90102-SF1-000	Bolt - HEX., 10X1.25
20	90305-692-010	Nut
21	90681-SR3-000	Circlip - EXTERNAL, 33MM
22	91057-SR3-008	Bearing - HALF SHAFT(NTN)
23	91260-SR3-003	Seal - HALF SHAFT OUTER(NOK)
23	91260-SR3-004	Seal - HALF SHAFT OUTER (ARAI)
25	44014-SR3-N50	Joint set - OUTBOARD
26	44018-SR3-C53	Boot set - OUTBOARD
26	44018-SR3-C56	Boot set
27	44329-SV4-305	Band - SHAFT BOOT (DOUBLE ROLLED BAND)
28	44337-SB0-300	Ring b - STOPPER

Emblem 8

#	OEM	部品名
1	17669-SM4-G31	Label - FUEL FILLER CAUTION
2	19043-P01-E01	Label - COOLANT CAUTION
3	42760-SR3-G42	Placard - TIRE PRESSURE SPECIFICATION
4	57079-SR3-E00	Plate - ABS CAUTION
5	75700-SR3-000	Emblem - CENTER (H)
6	75701-SR3-000	Emblem - RR. CENTER (H)
21	87125-041-680	Honda Motor Co., Made In Japan, Sticker
22	91512-SR3-004	Clip - TUBULAR

Emblems 7

#	OEM	部品名
1	17669-SH3-P30	Label - FUEL FILLER CAUTION (PORTUGAL)
3	42760-SR3-G42	Placard - TIRE PRESSURE SPECIFICATION
4	57079-SR3-E00	Plate - ABS CAUTION
5	75700-SR3-000	Emblem - CENTER (H)
6	75701-SR3-000	Emblem - RR. CENTER (H)
16	77871-SM4-A70	Label - SRS CAUTION
17	91512-SR3-004	Clip - TUBULAR

Engine mounts 31

#	OEM	部品名
1	50200-SR3-H50	Beam - RR. (POWER STEERING)
2	50203-SR3-010	Collar - RR. BEAM
3	50205-SR3-N11	Rod - RR. BEAM PERFORMANCE
4	50803-SR3-A01	Rubber - TRANSMISSION MOUNTING (MT)
5	50807-SR3-A01	Damper - MISSION MOUNT DYNAMIC (MT)
6	50805-SR3-010	Rubber - TRANSMISSION MOUNTING (MT)
11	50810-SR3-030	Rubber - RR. ENGINE MOUNTING INSULATOR (MT)
13	50820-SR3-J11	RUBBER ASSY., ENGINE SIDE MOUNTING (HYDRO)
16	50827-SR3-N12	Bracket - ENGINE RR. MOUNTING
17	50841-SR3-N10	Rubber - R. FR. STOPPER INSULATOR (MT)
18	50842-SR3-N10	Rubber - L. FR. STOPPER INSULATOR (MT)
20	50843-SR3-N11	Bracket - R. FR. STOPPER (MT)
24	90131-ST7-000	Bolt - L. FR. STOPPER
25	90133-SR3-010	Bolt - R. FR. STOPPER
26	90161-SR3-000	Bolt - FLANGE, 14X107
27	90186-SL4-000	Bolt - FLANGE, 12X67
28	90162-SR3-000	Bolt - FLANGE, 14X60
29	90165-SM4-020	Bolt - FLANGE, 12X101
30	90166-SR3-000	Bolt - FLANGE, 10X30
31	90167-SR3-000	Bolt - FLANGE, 14X120
33	90176-SK7-013	Bolt - FLANGE, 10X31
34	90182-SR3-000	Bolt - FLANGE, 12X112
35	90183-SR3-000	Bolt - FLANGE, 12X100
38	90188-SR3-010	Bolt - FLANGE, 14X67
39	90190-SR3-000	Bolt - FLANGE, 12X64
41	90371-SR3-000	Nut - FLANGE, 12MM
42	90372-SR3-003	Nut - FLANGE, 12MM
43	90380-SR3-000	Bolt - STUD, 12X57.6
44	90504-SR3-010	Washer - FR. STOPPER
45	90505-SB2-000	Washer - SIDE MOUNTING
46	90505-SR3-000	Washer - RR. BRACKET, 14MM

Engine mounts (MT) 33

#	OEM	部品名
1	38930-P30-000	Bracket - COMPRESSOR
2	50200-SR3-H50	Beam - RR. (POWER STEERING)
3	50203-SR3-010	Collar - RR. BEAM
4	50205-SR3-N11	Rod - RR. BEAM PERFORMANCE
5	50803-SR3-A01	Rubber - TRANSMISSION MOUNTING (MT)
8	50807-SR3-A01	Damper - MISSION MOUNT DYNAMIC (MT)
9	50810-SR3-030	Rubber - RR. ENGINE MOUNTING INSULATOR (MT)
10	50820-SR3-J11	RUBBER ASSY., ENGINE SIDE MOUNTING (HYDRO)
12	50827-SR3-N12	Bracket - ENGINE RR. MOUNTING
13	50841-SR3-N10	Rubber - R. FR. STOPPER INSULATOR (MT)
14	50842-SR3-N10	Rubber - L. FR. STOPPER INSULATOR (MT)
15	50843-SR3-N11	Bracket - R. FR. STOPPER (MT)
19	90131-ST7-000	Bolt - L. FR. STOPPER
20	90133-SR3-010	Bolt - R. FR. STOPPER
21	90161-S04-000	Bolt - FLANGE, 14X100
21	90161-SR3-000	Bolt - FLANGE, 14X107
22	90186-SL4-000	Bolt - FLANGE, 12X67
23	90162-SR3-000	Bolt - FLANGE, 14X60
24	90165-SM4-020	Bolt - FLANGE, 12X101
25	90166-SR3-000	Bolt - FLANGE, 10X30
26	90167-SR3-000	Bolt - FLANGE, 14X120
28	90176-S04-000	Bolt-washer - 10X32.5
28	90176-SK7-013	Bolt - FLANGE, 10X31
29	90182-SR3-000	Bolt - FLANGE, 12X112
30	90183-SR3-000	Bolt - FLANGE, 12X100
32	90188-SR3-010	Bolt - FLANGE, 14X67
33	90190-SR3-000	Bolt - FLANGE, 12X64
35	90371-SR3-000	Nut - FLANGE, 12MM
36	90372-SR3-003	Nut - FLANGE, 12MM
37	90380-SR3-000	Bolt - STUD, 12X57.6
38	90504-SR3-010	Washer - FR. STOPPER
39	90505-SB2-000	Washer - SIDE MOUNTING
41	90505-SR3-000	Washer - RR. BRACKET, 14MM

Engine wire harness/clamp (3) 37

#	OEM	部品名
1	17274-P30-A00	Label - SPARK PLUG
2	30530-PV1-A01	Sensor assy - KNOCK
3	31110-PR4-A05	Belt - ALTERNATOR (BANDO)
3	31110-PR4-A06	Belt - ALTERNATOR (MITSUBOSHI)
4	31112-PR3-000	Bracket comp. a - ALTERNATOR
5	31113-PR3-000	Bracket b - ALTERNATOR
6	32110-P30-A00	Harness - ENGINE WIRE
7	32113-P01-000	Stay comp - R. COUPLER
8	32115-P01-000	Stay - ENGINE WIRE HARNESS CLAMP
9	32127-P05-A00	Holder comp - HARNESS
10	32741-P01-000	Clamp a - ENGINE HARNESS (GREEN)
11	32744-P01-000	Clamp d - ENGINE HARNESS (GREEN)
12	32744-P05-A01	Clamp d - ENGINE HARNESS (BLACK)
13	32746-P05-A00	Clamp f - ENGINE HARNESS (GRAY)
14	32748-PR3-000	Stay c - ENGINE WIRE HARNESS
15	32752-P01-000	Stay b - ENGINE WIRE HARNESS
16	37240-PT0-013	Switch - OIL PRESSURE (DENSO)
16	37240-PT0-004	Switch - OIL PRESSURE (TEC)
17	37750-PH2-014	Thermo unit - DENSO
18	37760-P00-004	Switch assy - THERMO (A-93) (UCHIYA THERMOSTAT)
18	37760-P00-003	Switch assy, THERMO (A-93) (NIPPON THERMOSTAT)
19	37870-PJ7-003	Sensor assy, WATER TEMP (TW5) (MATSUSHITA)
20	75353-671-000	Lock - SCREW
21	90050-PG7-000	Bolt - FLANGE, 12X65
22	90051-PE0-000	Bolt - FLANGE, 12X70
23	90057-PG7-003	Bolt - ALTERNATOR
24	90058-PR3-003	Bolt - ALTERNATOR UPPER
25	90059-PR3-000	Bolt - KNOCK, 10X35
26	90130-SR3-003	Bolt - 5X13
27	91307-PJ7-003	O-ring - 9.5X1.5 (MATSUSHITA)
27	91307-PK2-005	O-ring - 9.5X1.5(HONDA KIKAKI)
28	91307-PN4-000	O-ring - 17.5X1.4
28	91307-PN3-000	O-ring,17.8x1.4
29	91506-P01-003	Clip A - HARNESS BAND (DARK GRAY) (129.4MM)
30	91507-P01-003	Clip b - HARNESS BAND (DARK BROWN) (129.4MM)
31	91540-SV4-003	Clip - HARNESS BAND (NATURAL) (145.2MM)
32	91547-SF4-003	Band - WIRE HARNESS (BLUE) (123.5MM)

Engine wire harness/clamp (DOHC VTEC) 36

#	OEM	部品名
1	17274-P29-E01	Label - PLUG CAUTION
2	31110-PR4-A05	Belt - ALTERNATOR (BANDO)
2	31110-PR4-A06	Belt - ALTERNATOR (MITSUBOSHI)
3	31112-PR3-000	Bracket comp. a - ALTERNATOR
4	31113-PR3-000	Bracket b - ALTERNATOR
5	32110-P30-G02	Harness - ENGINE WIRE
6	32113-P01-000	Stay comp - R. COUPLER
7	32115-P01-000	Stay - ENGINE WIRE HARNESS CLAMP
8	32127-P05-A00	Holder comp - HARNESS
9	32741-P01-000	Clamp a - ENGINE HARNESS (GREEN)
10	32744-P01-000	Clamp d - ENGINE HARNESS (GREEN)
11	32744-P05-A01	Clamp d - ENGINE HARNESS (BLACK)
12	32746-P05-A00	Clamp f - ENGINE HARNESS (GRAY)
13	32748-PR3-000	Stay c - ENGINE WIRE HARNESS
14	32752-P01-000	Stay b - ENGINE WIRE HARNESS
15	37240-PT0-013	Switch - OIL PRESSURE (DENSO)
15	37240-PT0-004	Switch - OIL PRESSURE (TEC)
16	37750-PH2-014	Thermo unit - DENSO
17	37760-P00-004	Switch assy - THERMO (A-93) (UCHIYA THERMOSTAT)
17	37760-P00-003	Switch assy, THERMO (A-93) (NIPPON THERMOSTAT)
18	37870-PJ7-003	Sensor assy, WATER TEMP (TW5) (MATSUSHITA)
19	75353-671-000	Lock - SCREW
20	90050-PG7-000	Bolt - FLANGE, 12X65
21	90051-PE0-000	Bolt - FLANGE, 12X70
22	90057-PG7-003	Bolt - ALTERNATOR
23	90058-PR3-003	Bolt - ALTERNATOR UPPER
24	90059-PR3-000	Bolt - KNOCK, 10X35
25	90130-SR3-003	Bolt - 5X13
26	91307-PJ7-003	O-ring - 9.5X1.5 (MATSUSHITA)
26	91307-PK2-005	O-ring - 9.5X1.5(HONDA KIKAKI)
27	91307-PN4-000	O-ring - 17.5X1.4
27	91307-PN3-000	O-ring,17.8x1.4
28	91506-P01-003	Clip A - HARNESS BAND (DARK GRAY) (129.4MM)
29	91507-P01-003	Clip b - HARNESS BAND (DARK BROWN) (129.4MM)
30	91540-SV4-003	Clip - HARNESS BAND (NATURAL) (145.2MM)
31	91547-SF4-003	Band - WIRE HARNESS (BLUE) (123.5MM)

Exhaust manifold (4) 13

#	OEM	部品名
1	11942-P30-000	Stay - EX. MANIFOLD
2	18100-P30-000	Manifold assy - EX.
3	18115-P30-003	Gasket - EX. MANIFOLD (NIPPON LEAKLESS)
3	18115-P30-013	Gasket - EX. MANIFOLD (NIPPON LEAKLESS)
4	18120-P30-J01	Cover a - EX. MANIFOLD
5	18121-P30-000	Cover b - EX. MANIFOLD
6	90010-PE2-900	Bolt - SPECIAL, 10X22
7	90015-PT0-J00	Bolt-washer - 8X14
8	90022-PE0-000	Bolt - FLANGE, 8X10
9	90065-PG6-000	Bolt, STUD, 10X24
10	90212-PD2-003	Nut - SELF-LOCK, 8MM
10	90212-RCA-A01	Nut - SELF-LOCK, 8MM
11	90451-PE2-000	Washer - SPECIAL, 11X28

Exhaust pipe 32

#	OEM	部品名
1	18020-SR3-X90	Insulator set - EX. PIPE B FR.
4	18030-SR3-X90	Silencer set - EX.
5	18160-P30-A00	Converter comp. - HEE/HPJ382
5	18160-P30-G00	Converter comp. - MNE935
6	18176-P08-003	Bolt - CONVERTER
7	18181-P28-A00	Cover
8	18182-P28-A00	Cover - UPPER
10	18210-SR3-X93	Pipe a - EX.
12	18212-SA7-003	Gasket - EX. PIPE (ISHINO)
19	18213-SR3-J91	Stay - EX. MOUNTING
21	18215-SH3-J01	Rubber - EX. MOUNTING (70X55X30)
22	18215-SR3-000	Rubber - EX. MOUNTING
23	18215-671-000	Rubber - SILENCER MOUNTING (74X53X22)
24	18220-SR3-X94	Pipe b - EX.
27	18222-SR3-A20	Bracket - EX. PIPE MOUNTING
28	18229-SH3-X30	Gasket - EX. FLEXIBLE (50.8MM-64MM)
30	18230-SA0-930	Spring - FLEXIBLE JOINT
31	18231-SR3-A22	Bolt b - FLEXIBLE JOINT
32	18231-SR3-J01	Bolt a - FLEXIBLE JOINT
34	18310-SR3-X91	Finisher - EX. PIPE (48.6MM)
35	18393-SH3-S00	Gasket - PRE-CHAMBER (52.5MM-53.5MM)
36	36531-P54-003	Sensor - OXYGEN
37	74601-SR3-000	Plate - FLOOR HEAT BAFFLE
38	74651-SR3-000	Plate - FUEL TANK BAFFLE
39	74653-SR3-000	Sensor assy - VENT PRESSURE
40	90023-PK1-000	Bolt - FLANGE, 6X10
40	90023-PR7-A01	BOLT, FLANGE (6X12) - 6X12 (IWATA BOLT)
41	90110-679-003	Nut - SELF-LOCK, 8MM
44	90115-SL5-A00	Nut - FLANGE, 6MM
45	90115-SR3-A71	Nut - PREVAILING TORQUE, 8MM
47	90117-SB2-000	Nut - SELF-LOCK, 8MM
48	90212-SA5-003	Nut - SELF-LOCK, 10MM

Floor mat 10

#	OEM	部品名
1	64436-692-000	Clip - GUIDE
2	83101-SR3-A11	Insulator - DASHBOARD
4	83107-ST7-000	Insulator - DASHBOARD WINDSHIELD LOWER
4	83103-SR3-C01	Insulator - DASHBOARD UPPER
5	83108-ST7-000	Insulator - DASHBOARD UPPER CENTER
12	90668-SH3-003	Clip - SIDE LINING
13	91532-SR3-003	Clip - DASHBOARD INSULATOR (BLACK)
14	91533-SR3-003	Clip - INSULATOR (NATURAL)
15	91535-SR3-003	Clip - DASHBOARD INSULATOR LOCK (BLACK)
17	91641-SH3-013	Grommet assy, GARNISH

Front brake (2) 24

#	OEM	部品名
1	01463-SR3-V00	Caliper set - FR.
2	43352-SM4-951	Screw - BLEEDER
3	43353-SD5-003	Cap - BLEEDER SCREW
4	44300-SR3-A04	Bearing assy - FR. HUB (KOYO SEIKO)
4	44300-SR3-A02	Bearing assy - FR. HUB (NTN)
5	44600-SR3-A01	Hub assy - FR.
6	45018-SR3-V00	Caliper sub assy. - R. FR.
7	45019-SR3-V00	Caliper sub assy. - L. FR.
8	45022-SR3-V12	Pad set - FR.
11	45216-SR3-V01	Piston - 54MM
11	45216-S5A-J01	Piston
16	45235-SR3-003	Pin a
17	45237-SR3-003	Retainer a
18	45238-SR3-003	Retainer b
19	45240-SA7-003	Bolt - FLANGE, 8X22
20	45251-SK7-J00	Disk - FR. BRAKE
21	45255-SR3-V00	Guard - FR. BRAKE SPLASH
21	45255-SR3-V01	Guard - FR. BRAKE SPLASH
23	45262-SR3-003	Pin b
24	90107-SM4-000	Bolt - CALIPER MOUNTING (12X21)
25	90113-SA0-025	Bolt - WHEEL (NAGOYA RASHI)
25	90113-SM1-005	Bolt - WHEEL (ROCKNEL FASTENER)
25	90113-SA0-023	Bolt - WHEEL (TOKAI TRW)
26	90681-SR3-A00	Circlip, SPECIAL INTERNAL, 79MM

Front brake (EXCEPT DX) 30

#	OEM	部品名
1	01463-SR3-V00	Caliper set - FR.
2	43352-SM4-951	Screw - BLEEDER
3	43353-SD5-003	Cap - BLEEDER SCREW
4	44300-SR3-A02	Bearing assy - FR. HUB (NTN)
4	44300-S04-A01	Bearing assy - FR. HUB (NTN)
4	44300-S5A-008	FR HUB Bearing assy (NTN)
4	44300-S04-A02	Bearing assy - FR. HUB (KOYO SEIKO)
4	44300-S5A-004	FR HUB Bearing assy (KOYO SEIKO)
4	44300-SR3-A04	Bearing assy - FR. HUB (KOYO SEIKO)
5	44600-SR3-A01	Hub assy - FR.
6	45018-SR3-V00	Caliper sub assy. - R. FR.
7	45019-SR3-V00	Caliper sub assy. - L. FR.
8	45022-SR3-V11	Pad set - FR.
8	45022-SR3-V12	Pad set - FR.
11	45216-SR3-V01	Piston - 54MM
11	45216-S5A-J01	Piston
16	45235-SR3-003	Pin a
17	45237-SR3-003	Retainer a
18	45238-SR3-003	Retainer b
19	45240-SA7-003	Bolt - FLANGE, 8X22
20	45251-SK7-J00	Disk - FR. BRAKE
21	45255-SR3-V00	Guard - FR. BRAKE SPLASH
21	45255-SR3-V01	Guard - FR. BRAKE SPLASH
23	45262-SR3-003	Pin b
24	90107-SM4-000	Bolt - CALIPER MOUNTING (12X21)
25	90113-SA0-025	Bolt - WHEEL (NAGOYA RASHI)
25	90113-SM1-005	Bolt - WHEEL (ROCKNEL FASTENER)
25	90113-SA0-006	Bolt - WHEEL (SAGA)
25	90113-SA0-023	Bolt - WHEEL (TOKAI TRW)
26	90681-SR3-A00	Circlip, SPECIAL INTERNAL, 79MM

Front door lining 6

#	OEM	部品名
3	72335-SR3-003	Weatherstrip - DOOR INNER
8	83508-SR3-000	Bracket assy - PULL POCKET
16	90662-SB2-003	Grommet - SCREW, 5MM
17	90678-SK7-003	Clip - SPEAKER
19	91560-SP0-003	Clip - DOOR LINING (GRAY)
19	91560-S84-A01	CLIP, DOOR LINING (NATURAL)

Front driveshaft/ half shaft 31

#	OEM	部品名
1	44010-ST7-N50	Driveshaft set - R.
2	44011-ST7-N50	Driveshaft set - L.
3	44017-SR3-900	Boot set - INBOARD
3	44017-SR3-901	Boot set
5	44310-SH3-J00	Joint comp - INBOARD
6	44310-SL5-N00	Joint comp - INBOARD
6	44310-ST7-900	Joint comp - INBOARD
7	44328-SB0-300	Band - INBOARD BOOT
8	44329-SB0-300	Band - DRIVESHAFT BOOT
8	44352-SA2-300	Band - DAMPER WEIGHT
9	44319-S0A-300	Set ring - 28X2.0
9	44319-S84-300	Set ring - 28X2.0
10	44327-SV4-305	Band - JOINT BOOT (DOUBLE ROLLED BAND)
11	44336-SB0-300	Ring a - STOPPER
12	44338-SB0-300	Circlip - 26MM
13	44347-SF1-003	Ring - OUTBOARD
14	44351-SR3-A11	Damper - DYNAMIC (HOKUSHIN)
15	44351-SR3-J01	Damper - DYNAMIC (HOKUSHIN)
17	44500-SR3-J01	Shaft assy - HALF
18	44502-SR3-J00	Support comp - HALF SHAFT (###)
19	90102-SF1-000	Bolt - HEX., 10X1.25
20	90305-692-010	Nut
21	90681-SR3-000	Circlip - EXTERNAL, 33MM
22	91057-SR3-008	Bearing - HALF SHAFT(NTN)
23	91260-SR3-003	Seal - HALF SHAFT OUTER(NOK)
23	91260-SR3-004	Seal - HALF SHAFT OUTER (ARAI)
25	44014-SR3-N50	Joint set - OUTBOARD
26	44018-SR3-C53	Boot set - OUTBOARD
26	44018-SR3-C56	Boot set
27	44337-SB0-300	Ring b - STOPPER
28	44329-SV4-305	Band - SHAFT BOOT (DOUBLE ROLLED BAND)

Front fenders 8

#	OEM	部品名
7	74101-SR3-000	RH FR. INNER Fender
10	74111-SR3-A00	Shield - FR. SPLASH
12	74151-SR3-000	LH FR. INNER Fender
14	90126-SR4-000	Screw-washer - 5X16
15	90146-SA7-000	Bolt-washer - 6X16 (DACRO COATING)
16	90682-SB0-003	Grommet - SCREW, 5MM
17	91512-SM4-003	Clip - INNER FENDER
18	91516-SK7-013	Clip - UNDER COVER

Front seat ('94-) 1

#	OEM	部品名
18	90134-SE3-003	Screw - TAPPING, 5X10

Front seat (2) 1

#	OEM	部品名
16	90134-SE3-003	Screw - TAPPING, 5X10

Front seat components (2) 14

#	OEM	部品名
1	77517-SA5-014	Cap - SLIDE ADJUSTER
2	81108-SE3-J02	Bush - NYLON (TACHI-S) (BLACK)
3	81230-SR3-C01	Adjuster - R. RECLINING
5	81235-SR3-J01	Cable comp - WALK-IN
6	81236-SR3-003	Knob a - R. RECLINING
7	81260-SR3-J02	Adjuster - OUTER SLIDE
8	81270-SR3-G01	Adjuster - R. INNER SLIDE
9	81630-SR3-G02	Adjuster - L. RECLINING
10	81636-SR3-003	Knob a - L. RECLINING
11	81670-SR3-G01	Adjuster - L. INNER SLIDE
12	90128-SR4-003	Bolt-washer - 8X19
13	90135-SK7-A01	Bolt-washer - 10X27
14	90155-SH3-000	Bolt-washer - 8X25
15	90203-SB2-003	Washer

Front seat components (LH; '94-) 15

#	OEM	部品名
3	81108-SE3-J02	Bush - NYLON (TACHI-S) (BLACK)
4	90203-SB2-003	Washer
5	77517-SA5-014	Cap - SLIDE ADJUSTER
6	81230-SR3-C01	Adjuster - R. RECLINING
8	81235-SR3-J01	Cable comp - WALK-IN
9	81236-SR3-003	Knob a - R. RECLINING
10	81260-SR3-J02	Adjuster - OUTER SLIDE
11	81270-SR3-G01	Adjuster - R. INNER SLIDE
12	81630-SR3-G02	Adjuster - L. RECLINING
13	81636-SR3-003	Knob a - L. RECLINING
14	81670-SR3-G01	Adjuster - L. INNER SLIDE
15	90128-SR4-003	Bolt-washer - 8X19
15	90128-SR3-004	Bolt-washer - 8X16 (TACHI-S)
17	90135-SK7-A01	Bolt-washer - 10X27
19	90155-SH3-000	Bolt-washer - 8X25

Front shock absorber 21

#	OEM	部品名
1	51401-SR3-N02	Spring - FR. (MITSUBISHI)
1	51401-SR3-N01	Spring - FR. (SHOWA)
2	51601-SR3-C04	Absorber assy - R. FR. SHOCK (SHOWA)
3	51602-SR3-C04	Absorber assy - L. FR. SHOCK (SHOWA) (###)
4	51605-SR3-N03	Absorber unit - R. FR. SHOCK (SHOWA)
5	51606-SR3-N03	Absorber unit - L. FR. SHOCK (SHOWA)
6	51621-SB0-004	Washer - FR. SHOCK ABSORBER MOUNTING (SHOWA)
6	51621-SB0-003	Washer - SHOCK ABSORBER MOUNTING (TOKICO)
7	51631-SB0-004	Rubber - SHOCK ABSORBER MOUNTING (YAMASHITA)
7	51631-S7S-J01	RUBBER DAMPER M
7	51631-SB0-003	Rubber - SHOCK ABSORBER MOUNTING (INOUE M.T.P.)
8	51675-SH3-024	Base - SHOCK ABSORBER MOUNTING (SHOWA)
9	51685-SH3-014	Plate - DUST COVER(SHOWA)
10	51686-SR3-003	Rubber - SPRING MOUNTING (SHOWA)
11	51687-SR3-003	Cover - FR. SLEEVE DUST (SHOWA)
12	51728-SB0-004	Collar - SHOCK ABSORBER MOUNTING (SHOWA)
12	51728-SB0-003	Collar - SHOCK ABSORBER MOUNTING(TOKICO)
13	52690-SG0-000	Plate - BUMP STOP
14	52722-SE0-006	Rubber - BUMP STOPPER (POLYURETHAN KASEI)
15	90304-SR3-014	Nut - FLANGE, 10MM (OHASHI)
16	90364-SG0-004	Nut - SELF-LOCK, 10MM (SHOWA) (NYLON)

Front stabilizer/ front lower arm 27

#	OEM	部品名
1	51300-SR3-N02	Spring - FR. STABILIZER
2	51306-SR3-N01	Bush - STABILIZER HOLDER
3	51308-SR3-000	Holder - R. FR. STABILIZER
4	51312-SD4-020	Rubber - STABILIZER END
5	51350-SR3-020	Arm assy. - R. FR. LOWER
6	51360-SR3-020	Arm assy. - L. FR. LOWER
7	51392-SR3-024	Bush - FR. LOWER ARM
8	51395-SR3-N03	Bush comp - R. FR. COMPLIANCE (YAMASHITA)
9	51396-SR3-N03	Bush comp - L. FR. COMPLIANCE (YAMASHITA)
10	51398-SR3-000	Washer b - FR. RADIUS ARM (14MM)
11	51399-SR3-010	Washer a - FR. RADIUS ARM (18MM)
12	51810-SH3-003	Bush - SHOCK ABSORBER FORK (HOKUSHIN)
12	51810-SH3-004	Bush - SHOCK ABSORBER FORK (YAMASHITA)
12	51810-SK7-004	Bush - SHOCK ABSORBER FORK
13	51811-SR3-010	Fork - R. FR. SHOCK ABSORBER
14	51821-SR3-010	Fork - L. FR. SHOCK ABSORBER
15	74300-SR3-010	BAR, FR. TOWER
16	90112-SE0-000	Bolt - FR. STABILIZER
17	90118-SR3-003	Bolt - SELF-LOCK, 12X76
18	90120-SB0-003	Bolt - SHOCK ABSORBER LOCK, 10X42
19	90162-SR3-000	Bolt - FLANGE, 14X60
20	90164-SR3-013	Bolt - SELF-LOCK, 14X34
21	90168-SR3-000	Bolt - FLANGE, 14X35
22	90175-SH3-005	Bolt - SHOCK ABSORBER FORK
23	90213-SR3-013	Nut - SELF-LOCK, 14MM
24	90215-SB0-003	Nut - SELF-LOCK, 12MM (SATO RASHI) (CLINCH)
25	90362-SF1-003	Nut - SELF-LOCK, 8MM

Front windshield 23

#	OEM	部品名
1	73111-SR0-E00	Glass - FR. WINDSHIELD (GREEN)
1	73111-SR3-000	Glass - FR. WINDSHIELD (BLUE)
2	73125-SR3-000	Rubber a - FR. WINDSHIELD DAM
3	73126-SR3-000	Rubber b - FR. WINDSHIELD DAM
4	73127-SR3-003	Holder - FR. WINDSHIELD GLASS
5	73151-SR3-013	Molding - FR. WINDSHIELD UPPER
6	73152-SR3-003	Molding assy. - R. FR. WINDSHIELD SIDE
7	73162-SR3-003	Molding assy. - L. FR. WINDSHIELD SIDE
8	73511-SR0-A10	Glass - R. QUARTER (GREEN)
8	73511-SR3-000	Glass - R. QUARTER (BLUE)
9	73561-SR0-A10	Glass - L. QUARTER (GREEN)
9	73561-SR3-000	Glass - L. QUARTER (BLUE)
10	73810-SR3-000	Molding - R. QUARTER
11	73860-SR3-000	Molding - L. QUARTER
12	91501-SR3-003	Clip A - R. QUARTER WINDOW (BLUE)
13	91502-SR3-003	Clip b - QUARTER WINDOW (NATURAL)
14	91505-SR3-003	Clip A - L. QUARTER WINDOW (NATURAL)
15	91511-SR3-003	Clip d - FR. WINDSHIELD SIDE MOLDING (ORANGE)
16	91518-SR3-003	Clip A - FR. WINDSHIELD SIDE MOLDING (YELLOW)
17	91519-SR3-003	Clip b - FR. WINDSHIELD SIDE MOLDING (GREEN)
18	91520-SR3-003	Clip c - FR. WINDSHIELD SIDE MOLDING (RED)
19	91521-SR3-003	Clip f - FR. WINDSHIELD SIDE MOLDING (PURPLE)
20	91534-ST0-003	Clip c - FR. WINDSHIELD SIDE MOLDING (BLUE)

Front windshield wiper (1) 25

#	OEM	部品名
1	38472-SB2-003	Rubber - BLADE (450MM)
1	76632-S5H-T01	Rubber - BLADE (450MM)
2	76505-SR3-A01	Motor comp - FR. WIPER
3	76515-SR3-003	Seal a
4	76516-SE0-003	Rubber - BRACKETLESS MOUNTING
5	76516-SR3-003	Rubber - MOUNTING
6	76517-SE0-003	Collar - BRACKETLESS
7	76517-SM4-003	Collar
8	76520-SR3-A01	Link unit a
9	76524-SD4-003	Dust seal
10	76524-SE0-013	Dust seal
11	76530-SR3-A01	Link comp - FR. WIPER
12	76540-SR3-003	Rod unit a
13	76550-SM4-003	Rod unit b
14	76561-SD4-003	Cap - PIVOT
15	76600-SR3-G01	Arm - WINDSHIELD WIPER (DRIVER SIDE)
16	76610-SR3-G01	Arm - WINDSHIELD WIPER (PASSENGER SIDE)
17	76620-SH2-A02	Blade - WINDSHIELD WIPER (500MM) (DRIVER SIDE)
18	76622-SF4-003	Rubber - BLADE (500MM)
18	76632-S6M-003	Rubber - BLADE (500MM)
19	76630-SH3-G11	Blade - WINDSHIELD WIPER (450MM) (PASSENGER SIDE)
19	76630-SH3-305	Blade,windshield
20	90126-SR3-000	Bolt-washer - 6X32
21	90201-SK7-000	Nut - HEX. CAP, 10MM
22	91556-SR3-003	Clip - COUPLER

Front windshield wiper (LH) 25

#	OEM	部品名
1	38472-SB2-003	Rubber - BLADE (450MM)
1	76632-S5H-T01	Rubber - BLADE (450MM)
2	76505-SR3-A01	Motor comp - FR. WIPER
3	76515-SR3-003	Seal a
4	76516-SE0-003	Rubber - BRACKETLESS MOUNTING
5	76516-SR3-003	Rubber - MOUNTING
6	76517-SE0-003	Collar - BRACKETLESS
7	76517-SM4-003	Collar
8	76520-SR3-A01	Link unit a
9	76524-SD4-003	Dust seal
10	76524-SE0-013	Dust seal
11	76530-SR3-A01	Link comp - FR. WIPER
12	76540-SR3-003	Rod unit a
13	76550-SM4-003	Rod unit b
14	76561-SD4-003	Cap - PIVOT
15	76600-SR3-G01	Arm - WINDSHIELD WIPER (DRIVER SIDE)
16	76610-SR3-G01	Arm - WINDSHIELD WIPER (PASSENGER SIDE)
17	76620-SH2-A02	Blade - WINDSHIELD WIPER (500MM) (DRIVER SIDE)
18	76622-SF4-003	Rubber - BLADE (500MM)
18	76632-S6M-003	Rubber - BLADE (500MM)
19	76630-SH3-G11	Blade - WINDSHIELD WIPER (450MM) (PASSENGER SIDE)
19	76630-SH3-305	Blade,windshield
20	90126-SR3-000	Bolt-washer - 6X32
21	90201-SK7-000	Nut - HEX. CAP, 10MM
22	91556-SR3-003	Clip - COUPLER

Fuel pipe (3) 42

#	OEM	部品名
1	16010-ST5-931	Strainer set - FUEL (TOYO ROKI)
2	16680-PE7-661	Damper assy. - PULSATION
2	16680-PCX-003	Damper assy. - PULSATION
3	16705-PD1-003	Gasket - SILENCER
4	16722-P30-A02	Hose comp. - FUEL FEED
5	16913-SR3-000	Cover - FR. FUEL PIPE
6	16914-SR3-000	Cover - RR. FUEL PIPE
7	16918-ST7-A30	Stay - FUEL STRAINER
9	16919-ST5-930	Band - FUEL STRAINER
14	17300-SR3-E31	Canister assy - 29PCV
16	17358-ST0-000	Bracket - CANISTER
18	17700-ST7-930	Pipe comp - FUEL FEED
19	17720-SR3-J30	Pipe comp - VENT
20	17723-SR3-J82	Hose - PRESSURE REGULATOR RETURN
21	17740-SR3-J30	Pipe comp - FUEL RETURN
22	17742-ST0-003	Pipe - CANISTER DRAIN JOINT
23	17743-SR3-A00	Tube - CANISTER DRAIN
24	17745-ST0-003	Joint - CANISTER DRAIN
26	17749-SR3-J92	Clamp - RETURN HOSE
27	17761-SR3-010	Stay a - FUEL PIPE
28	17762-SR3-J00	Stay b - FUEL PIPE
29	17763-SR3-000	Stay c - FUEL PIPE
30	17764-SR3-J00	Stay d - FUEL PIPE
31	17765-SM4-000	Stay e - FUEL PIPE
32	90008-PP4-E02	Bolt - BANJO, 12MM
33	90009-PP4-E01	Bolt - SEALING, 6MM
35	90301-SP0-003	Nut - PAINT CUTTING, 6MM
36	90361-SV4-003	Nut - PAINT CUTTING, 6MM
37	90428-PD6-003	Washer - SEALING, 12MM
38	90430-PD6-003	Washer - SEALING, 6MM
39	91406-SL4-931	Clamp - FUEL HOSE (D10.5)
40	91590-SR3-J31	CLAMP J, FUEL PIPE
41	91591-SR3-010	Clip A - BRAKE
42	91592-SR3-J32	Clamp h - FUEL PIPE (SANOU)
43	91593-SR3-J31	Clamp g - FUEL PIPE
44	91594-SR3-J32	Clamp f - FUEL PIPE (SANOU)
45	91595-SR3-003	Clamp a - FUEL PIPE
46	91596-SR3-J31	Clamp b - FUEL PIPE
47	91597-SH3-Y01	Clamp - VENT TUBE (BLACK)
48	91597-SR3-003	Clamp c - FUEL PIPE
49	91598-SR3-J32	Clamp d - FUEL PIPE (SANOU)
50	91599-SR3-J32	Clamp e - FUEL PIPE

Fuel pipe (PGM-FI; '95) 52

#	OEM	部品名
1	16010-ST5-931	Strainer set - FUEL (TOYO ROKI)
2	16680-PE7-661	Damper assy. - PULSATION
2	16680-PCX-003	Damper assy. - PULSATION
3	16705-PD1-003	Gasket - SILENCER
4	16722-P30-A02	Hose comp. - FUEL FEED
5	16913-SR3-000	Cover - FR. FUEL PIPE
6	16914-SR3-000	Cover - RR. FUEL PIPE
7	16918-ST7-A30	Stay - FUEL STRAINER
7	16918-SR3-A32	Stay - FUEL STRAINER
9	16919-ST5-930	Band - FUEL STRAINER
10	16922-SH3-930	Rubber - MOUNTING
11	16922-SR3-931	Rubber - MOUNTING
12	16923-SP0-930	Collar - DISTANCE
13	16923-SR3-930	Collar - DISTANCE
14	17300-SR3-E31	Canister assy - 29PCV
16	17358-ST0-000	Bracket - CANISTER
17	17700-SR3-N30	Pipe comp - FUEL FEED
18	17720-SR3-J30	Pipe comp - VENT
19	17723-SR3-J82	Hose - PRESSURE REGULATOR RETURN
21	17740-SR3-N30	Pipe comp - FUEL RETURN
22	17742-ST0-003	Pipe - CANISTER DRAIN JOINT
23	17743-SR3-A00	Tube - CANISTER DRAIN
24	17745-ST0-003	Joint - CANISTER DRAIN
26	17749-SR3-J92	Clamp - RETURN HOSE
27	17761-SR3-010	Stay a - FUEL PIPE
28	17762-SR3-J00	Stay b - FUEL PIPE
29	17763-SR3-000	Stay c - FUEL PIPE
30	17764-SR3-J00	Stay d - FUEL PIPE
31	17765-SM4-000	Stay e - FUEL PIPE
32	90008-PP4-E02	Bolt - BANJO, 12MM
33	90009-PP4-E01	Bolt - SEALING, 6MM
34	90156-SH3-000	Bolt-washer - 6X24
36	90301-SP0-003	Nut - PAINT CUTTING, 6MM
36	90321-SV4-003	Nut-washer - 6MM (PAINT CUTTING)
37	90361-SV4-003	Nut - PAINT CUTTING, 6MM
38	90428-PD6-003	Washer - SEALING, 12MM
39	90430-PD6-003	Washer - SEALING, 6MM
40	91406-SL4-931	Clamp - FUEL HOSE (D10.5)
41	91590-SR3-J31	CLAMP J, FUEL PIPE
42	91591-SR3-010	Clip A - BRAKE
43	91592-SR3-J32	Clamp h - FUEL PIPE (SANOU)
43	91592-SR3-J31	Clamp h - FUEL PIPE (NIFCO)
45	91593-SR3-J31	Clamp g - FUEL PIPE
46	91594-SR3-J32	Clamp f - FUEL PIPE (SANOU)
46	91594-SR3-J31	Clamp f - FUEL PIPE (NIFCO)
47	91595-SR3-003	Clamp a - FUEL PIPE
48	91596-SR3-J31	Clamp b - FUEL PIPE
49	91597-SH3-Y01	Clamp - VENT TUBE (BLACK)
50	91597-SR3-003	Clamp c - FUEL PIPE
51	91598-SR3-J32	Clamp d - FUEL PIPE (SANOU)
51	91598-SR3-J31	Clamp d - FUEL PIPE (NIFCO)
52	91599-SR3-J32	Clamp e - FUEL PIPE

Fuel tank (2) 39

#	OEM	部品名
1	17040-SR3-M30	Pump set - FUEL
3	17371-SR3-003	Valve - TWO WAY
5	17372-SR3-010	Cover - TWO WAY VALVE
6	17500-SR3-A30	Tank comp. - FUEL
7	17521-SR3-000	Band assy. - R. FUEL TANK MOUNTING
8	17522-SR3-000	Band assy. - L. FUEL TANK MOUNTING
9	17525-SM4-000	Bolt-washer - 10X35
10	17525-SR3-000	Bolt - FUEL TANK MOUNTING
10	17525-SR3-305	Bolt
11	17574-SE0-000	Packing - BASE
12	17651-SR3-000	Tube - FILLER NECK
13	17652-SA5-000	Clip - FILLER TUBE
14	17653-SH7-000	Tube - BREATHER
15	17656-SR3-003	Bolt - FILLER PIPE MOUNTING
16	17660-SR3-B00	Pipe comp - FUEL FILLER
16	06170-S04-B00	Pipe comp
17	17662-SR3-000	Packing - FUEL FILLER
18	17670-SM1-A03	Cap comp. - FUEL FILLER (STANT)
18	17670-S3N-003	Cap comp. - FUEL FILLER (TOYODA)
18	17670-SM4-014	Cap comp. - FUEL FILLER (TOYODA)
19	17704-SR3-930	Hose - FUEL PIPE RETURN
20	17707-SR3-A31	Hose comp. - FUEL JOINT
25	17733-SR3-010	Protector - FUEL FILLER PIPE
26	37800-SR3-981	Meter unit - FUEL (NS)
26	37800-S04-305	(meter)unit assy
27	37801-SJ4-003	Packing - BASE
28	37802-SD2-000	Retainer - FUEL UNIT
29	74559-SR3-010	Cover - FUEL FILLER PIPE
30	74661-SR3-000	Cap - FLOOR MAINTENANCE HOLE
31	74662-SR3-000	Rubber - SEAL
32	90020-PD6-000	Bolt - SEALING, 12MM
34	90164-SD4-000	Bolt-washer - 6X16
35	90347-SR3-000	Nut - SPRING, 6MM
36	90428-PD6-003	Washer - SEALING, 12MM
37	90602-SA7-931	Clamp - FUEL HOSE, 18.5MM
38	90657-SA5-003	Clip - SIDE APRON MOLDING
39	90657-SH3-013	Clip - TWO WAY VALVE COVER
40	91406-SL4-931	Clamp - FUEL HOSE (D10.5)
41	91601-SH3-013	Grommet - SCREW, 5MM (BLACK)

Fuel tank (PGM-FI) 36

#	OEM	部品名
2	17040-SR3-G30	Pump set - FUEL
3	17371-SR3-A01	Valve - TWO WAY
4	17372-SR3-010	Cover - TWO WAY VALVE
5	17500-SR3-A30	Tank comp. - FUEL
6	17521-SR3-000	Band assy. - R. FUEL TANK MOUNTING
7	17522-SR3-000	Band assy. - L. FUEL TANK MOUNTING
8	17525-SM4-000	Bolt-washer - 10X35
9	17525-SR3-000	Bolt - FUEL TANK MOUNTING
9	17525-SR3-305	Bolt
10	17574-SE0-000	Packing - BASE
11	17651-SR3-000	Tube - FILLER NECK
12	17652-SA5-000	Clip - FILLER TUBE
13	17653-SH7-000	Tube - BREATHER
14	17656-SR3-003	Bolt - FILLER PIPE MOUNTING
15	17660-S04-A00	Pipe comp - FUEL FILLER
15	17660-SR3-A00	Pipe comp - FUEL FILLER
16	17662-SR3-000	Packing - FUEL FILLER
17	17670-SM4-014	Cap comp. - FUEL FILLER (TOYODA)
17	17670-SM4-004	Cap comp. - FUEL FILLER (TOYODA)
18	17704-SR3-930	Hose - FUEL PIPE RETURN
20	17710-SR3-A31	Tube comp - FUEL JOINT (TOKAI)
21	17711-ST0-003	Retainer - YELLOW) (TOKAI
22	17733-SR3-010	Protector - FUEL FILLER PIPE
23	37800-SR3-981	Meter unit - FUEL (NS)
23	37800-S04-305	(meter)unit assy
24	37801-SJ4-003	Packing - BASE
25	37802-SD2-000	Retainer - FUEL UNIT
26	74559-SR3-010	Cover - FUEL FILLER PIPE
27	74661-SR3-000	Cap - FLOOR MAINTENANCE HOLE
28	74662-SR3-000	Rubber - SEAL
32	90347-SR3-000	Nut - SPRING, 6MM
34	90602-SA7-931	Clamp - FUEL HOSE, 18.5MM
35	90657-SA5-003	Clip - SIDE APRON MOLDING
36	90657-SH3-013	Clip - TWO WAY VALVE COVER
37	91406-SL4-931	Clamp - FUEL HOSE (D10.5)
38	91601-SH3-013	Grommet - SCREW, 5MM (BLACK)

Gasket kit/ transmission assy. 5

#	OEM	部品名
1	06110-P30-020	Gasket kit - CYLINDER HEAD
2	06111-P30-010	Gasket kit - CYLINDER BLOCK
4	10002-P30-E10	General assy. - CYLINDER BLOCK (B16A2)
5	10003-P30-A00	General assy. - CYLINDER HEAD
6	20011-P21-K52	Transmission assy - Y21

Gasket kit/engine assy./ transmission assy. 5

#	OEM	部品名
1	06110-P30-020	Gasket kit - CYLINDER HEAD
2	06111-P30-000	Gasket kit - CYLINDER BLOCK
4	10002-P30-A00	General assy. - CYLINDER BLOCK (B16A2)
5	10003-P30-A00	General assy. - CYLINDER HEAD
6	20011-P21-A40	Transmission assy - Y21

Grommet 17

#	OEM	部品名
1	72207-SB2-000	Cap - FLOOR HOLE, 24MM
2	75826-605-300	Seal - DOOR HOLE, 30MM (CIRCLE) (BLACK)
3	75826-634-300	Seal - INSIDE PANEL, 15MM
4	83431-SA4-000	Cushion - FR. TRUNK
5	85268-SA0-000	Protection - TAILGATE, 20MM (CIRCLE)
6	90615-SR3-000	Cap - WELD HOLE, 51X77
7	90851-SJ4-000	Seal - DOOR HOLE, 20MM
8	90852-671-003	Plug - HOLE
9	90855-SA0-000	Plug - VENTILATION HOLE, 20MM
11	90860-SA5-003	Plug - HOLE, 16MM
13	82871-671-000	Grommet - DRAIN HOLE, 25MM
15	91610-SB2-003	Plug - HOLE, 16.7MM (BLACK)
16	91615-SH3-000	Cap - FLOOR HOLE, 49MM
17	91616-SR3-000	Seal - FR. INNER LOWER (110X110) (BLACK)
18	91617-SB6-000	Grommet - WASHER HOSE, 32MM
18	91631-SR3-000	Plug - AIR CONDITIONER HOLE
19	91617-SH3-000	Seal - HOLE

Headlight 26

#	OEM	部品名
2	33100-SR3-G01	Headlight assy - R. (GERMANY) (HEADLIGHT ADJUSTER)
3	33101-SR3-G01	Headlight unit - R. (GERMANY) (HEADLIGHT ADJUSTER)
4	33102-SR3-G01	Plate - R.
5	33104-SR3-G01	Nut - SPECIAL (3)
6	33109-SR3-A01	Nut e - SPECIAL
7	33115-SM3-003	Bulb - HEADLIGHT (H4) (12V 60/55W) (STANLEY)
7	33115-SV4-G01	Bulb - HEADLIGHT (H4/HB2) (12V 60/55W) (PHILIPS)
7	33115-SM4-003	Bulb
8	33126-SH3-003	Cover - RUBBER
9	33150-SR3-G01	Headlight assy - L. (GERMANY) (HEADLIGHT ADJUSTER)(###)
10	33151-SR3-G01	Headlight unit - L. (GERMANY) (HEADLIGHT ADJUSTER)
11	33152-SR3-G01	Plate - L.
12	33300-SR3-013	Light assy - R. FR. TURN
13	33301-SA0-741	Bulb (12V 5W) - (12V 5W) (STANLEY)
14	33301-SR3-013	Lamp unit - R.
15	33305-SH3-A01	Socket comp - GRAY
16	33350-SR3-013	Light assy - L. FR. TURN
17	33351-SR3-013	Lamp unit - L.
18	33800-SR3-G01	Light assy - R. SIDE TURN
19	33801-SR3-G01	Housing comp - R.
20	33802-SR3-G01	Housing comp - L.
21	33850-SR3-G01	Light assy - L. SIDE TURN
22	34303-SS1-003	Socket comp - 2P
23	34304-SH3-A01	Socket comp.
24	34908-634-611	Bulb - 12V 21W) (ECE) (STANLEY
25	90146-SA7-000	Bolt-washer - 6X16 (DACRO COATING)

Headlight (1) 27

#	OEM	部品名
1	32102-SM4-970	Cap - HEADLIGHT ADJUSTER (NON HEADLIGHT ADJUSTER)
2	33100-SR3-B01	Headlight assy - R.
3	33101-SR3-B01	Headlight unit - R.
4	33102-SR3-G01	Plate - R.
5	33104-SR3-G01	Nut - SPECIAL (3)
6	33109-SR3-A01	Nut e - SPECIAL
7	33115-SV4-G01	Bulb - HEADLIGHT (H4/HB2) (12V 60/55W) (PHILIPS)
7	33115-SM4-003	Bulb
7	33115-SM3-003	Bulb - HEADLIGHT (H4) (12V 60/55W) (STANLEY)
8	33126-SH3-003	Cover - RUBBER
9	33150-SR3-B01	Headlight assy - L.
10	33151-SR3-B01	Headlight unit - L.
11	33152-SR3-G01	Plate - L.
12	33300-SR3-013	Light assy - R. FR. TURN
13	33301-SA0-741	Bulb (12V 5W) - (12V 5W) (STANLEY)
14	33301-SR3-013	Lamp unit - R.
15	33305-SH3-A01	Socket comp - GRAY
16	33350-SR3-013	Light assy - L. FR. TURN
17	33351-SR3-013	Lamp unit - L.
18	33800-SR3-G01	Light assy - R. SIDE TURN
19	33801-SR3-G01	Housing comp - R.
20	33802-SR3-G01	Housing comp - L.
21	33850-SR3-G01	Light assy - L. SIDE TURN
22	34303-SS1-003	Socket comp - 2P
23	34304-SH3-A01	Socket comp.
24	34908-634-611	Bulb - 12V 21W) (ECE) (STANLEY
25	90146-SA7-000	Bolt-washer - 6X16 (DACRO COATING)

Heater blower 14

#	OEM	部品名
1	39246-671-003	Clamp - CASE HOLD
2	79192-SR3-003	Bush - LINK
3	79305-SR3-A01	Blower sub assy. - DENSO
4	79310-SR3-A01	Motor assy. - BLOWER (DENSO)
5	79330-SR3-A01	Resistor - BLOWER
6	79350-SR3-A01	Motor assy. - FRESH & RECIRCULAR
8	90121-SR3-003	Screw - TAPPING, 5X12
8	79810-SR3-A01	Duct - HEATER
9	90123-SR3-003	Screw - TAPPING, 4X16
10	90132-SR3-003	Screw - TAPPING, 5X16
11	90133-SR3-003	Screw-washer - 4X16
13	90156-SH3-000	Bolt-washer - 6X24
13	90155-SE0-003	Screw - TAPPING, 6X20
14	90321-SV4-003	Nut-washer - 6MM (PAINT CUTTING)

Heater control 24

#	OEM	部品名
1	32133-SM4-003	Band - HARNESS OFFSET (30) (YELLOW) (122.5MM)
2	32157-SR3-A01	Sub cord a - HEATER
4	32257-SR3-000	Sub cord b - HEATER
5	79500-SR3-A52	Control assy. - HEATER (AIR CONDITIONER)
5	79500-SR3-A02	Control assy. - HEATER
6	79512-SR3-003	Lever
7	79514-SR3-003	Slider
8	79529-SR3-003	Stopper - CONTROL LEVER
9	79542-SR3-A00	Cable - TEMPERATURE CONTROL (TSK)
10	79550-SR3-013	Garnish
11	79551-SR3-013	Display - MODE CONTROL
12	79570-SR3-003	Switch assy - HEATER FAN
13	79601-SR3-013	Knob a
14	79602-SR3-013	Knob b
15	79603-SR3-013	Knob c
16	79604-SR3-013	Knob d
17	79612-SR3-013	Lid - AIR CONDITIONER SWITCH
18	79629-SR3-003	Bulb assy - BLUE) (14V 14W
19	80411-SR3-013	Knob - AIR CONDITIONER SWITCH
20	91540-SV4-003	Clip - HARNESS BAND (NATURAL) (145.2MM)
21	91551-SF4-003	Band - WIRE HARNESS(BROWN) (110MM)
22	91580-SM4-003	Clip - COUPLER(ORANGE)
23	91902-SB2-003	Cushion - WIRE HARNESS(50X100)
23	91641-SM4-003	Grommet - SCREW, 4MM

Heater unit 11

#	OEM	部品名
1	39246-671-003	Clamp - CASE HOLD
2	79100-SR3-G01	Heater unit
3	79110-SR3-A01	Core comp - HEATER
4	79140-SR3-A01	Motor assy. - MODE
5	79192-SR3-003	Bush - LINK
6	79195-SF1-003	Holder - ROD
7	79544-SR3-A00	Cable - WATER VALVE CONTROL
8	90122-SR3-003	Screw - TAPPING, 5X12
9	90125-SR3-003	Screw - TAPPING, 5X15
10	90133-SR3-003	Screw-washer - 4X16
11	90321-SV4-003	Nut-washer - 6MM (PAINT CUTTING)

High tension cord/ spark plug 12

#	OEM	部品名
1	32701-P30-010	Cord comp - RESISTANCE (NO.1) (SUMITOMO)
2	32702-P30-010	Cord comp - RESISTANCE (NO.2) (SUMITOMO)
3	32703-P30-010	Cord comp - RESISTANCE (NO.3) (SUMITOMO)
4	32704-P30-010	Cord comp - RESISTANCE (NO.4) (SUMITOMO)
5	32722-P30-000	Cord comp - HIGH TENSION (SUMITOMO)(###)
6	32763-PM3-000	Clamp c - HIGH TENSION CORD
9	32764-PR3-000	Clamp c - HIGH TENSION CORD
14	32766-PR3-000	Clamp d - HIGH TENSION CORD
18	32777-PG7-J00	Grommet - HIGH TENSION CORD
19	32777-PR3-010	Clamp e - HIGH TENSION CORD
21	90003-P01-000	Bolt-washer - 8X28
23	32722-P30-405	CORD, HIGH TENSION (SUMITOMO)

High tension cord/plug 12

#	OEM	部品名
1	32701-P30-010	Cord comp - RESISTANCE (NO.1) (SUMITOMO)
2	32702-P30-010	Cord comp - RESISTANCE (NO.2) (SUMITOMO)
3	32703-P30-010	Cord comp - RESISTANCE (NO.3) (SUMITOMO)
4	32704-P30-010	Cord comp - RESISTANCE (NO.4) (SUMITOMO)
5	32722-P30-000	Cord comp - HIGH TENSION (SUMITOMO)(###)
6	32763-PM3-000	Clamp c - HIGH TENSION CORD
8	32764-PR3-000	Clamp c - HIGH TENSION CORD
13	32766-PR3-000	Clamp d - HIGH TENSION CORD
17	32777-PG7-J00	Grommet - HIGH TENSION CORD
18	32777-PR3-010	Clamp e - HIGH TENSION CORD
20	90003-P01-000	Bolt-washer - 8X28
22	32722-P30-405	CORD, HIGH TENSION (SUMITOMO)

Hood 26

#	OEM	部品名
1	17706-SC3-003	Clip - FUEL PIPE
5	61210-SR3-A00	Cowl top assy.
6	74120-SR3-A01	Lock assy - HOOD
7	74130-SR3-A00	Wire assy. - HOOD
8	74131-SH3-A01	Cover - HOOD WIRE
9	74132-SR3-A00	Lever assy. - HOOD WIRE
10	74134-SH3-003	Grommet - HOOD WIRE
11	74141-SR3-000	Hood Insulator
12	74142-SR3-010	Rubber - HOOD SEAL
13	74143-SR3-000	Rubber - RR. HOOD SEAL
14	74145-SR3-000	Stay - HOOD OPENER
15	74149-SR3-000	Cover - CONDENSER
16	74177-SD4-000	Cushion a - HOOD
17	74213-SR3-300	Cover - R. HOOD HINGE
18	74214-SR3-300	Cover - L. HOOD HINGE
19	74144-SR3-000	Cushion - HOOD
20	90127-SA0-000	Bolt-washer - 6X16
21	90146-SA7-000	Bolt-washer - 6X16 (DACRO COATING)
22	90672-SJ4-013	Holder - ROD
23	90700-SJ4-000	Clip - ENGINE HOOD INSULATOR
24	91508-SR3-000	Clip - COWL TOP (BLACK)
24	91508-SX8-003	Clip - COWL TOP
25	91512-SM4-003	Clip - INNER FENDER
26	91515-SR3-000	Clip - RR. HOOD
27	91520-SM4-C01	Clip - HOOD SEAL RUBBER
29	91604-SD2-013	Grommet - HOOD STAY

Instrument panel (1) 20

#	OEM	部品名
3	75513-SR3-000	Cushion - SIDE
4	77106-SR3-A80	Plate a
5	77107-SR3-A80	Frame - INSTRUMENT PASSENGER MODULE INNER
6	77108-SR3-A80	Frame - INSTRUMENT PASSENGER MODULE OUTER
9	77140-SR3-C00	Bracket comp. - INSTRUMENT DRIVER SIDE
10	77145-SR3-C00	Bracket comp. - INSTRUMENT PASSENGER SIDE
12	77212-SR3-003	Blind - COLUMN
18	77411-SR3-C01	Duct - CENTER AIR CONDITIONER
19	77466-SR3-000	Seal - FR. INSTRUMENT
24	77623-SR3-000	Bush - UPPER VENT KNOB
27	77852-SL5-N81	Holder - SHORT CONNECTOR (3P)
29	77887-SS0-A90	Label - MODULE CAUTION
30	90106-SD2-000	Nut - SPRING
31	90128-SA7-000	Bolt-washer - 6X25
32	90301-634-670	Nut - FLANGE, 6MM
33	90302-SA4-003	Nut - SPRING, 4MM
34	90321-SP0-A80	Nut-washer - 6MM
36	90666-SD4-003	Clip - FITTING
37	91641-SM4-003	Grommet - SCREW, 4MM
38	91902-SB2-003	Cushion - WIRE HARNESS(50X100)

Instrument panel (LH) 14

#	OEM	部品名
3	75513-SR3-000	Cushion - SIDE
9	77140-SR3-C00	Bracket comp. - INSTRUMENT DRIVER SIDE
10	77145-SR3-C00	Bracket comp. - INSTRUMENT PASSENGER SIDE
12	77212-SR3-003	Blind - COLUMN
14	77230-SM4-G00	Lid assy - AUDIO HOLE
18	77411-SR3-C01	Duct - CENTER AIR CONDITIONER
19	77466-SR3-000	Seal - FR. INSTRUMENT
24	77623-SR3-000	Bush - UPPER VENT KNOB
30	90106-SD2-000	Nut - SPRING
31	90128-SA7-000	Bolt-washer - 6X25
33	90302-SA4-003	Nut - SPRING, 4MM
35	90650-SE3-000	Clip - RADIO PANEL
36	90666-SD4-003	Clip - FITTING
37	91641-SM4-003	Grommet - SCREW, 4MM

Instrument panel garnish (3) 31

#	OEM	部品名
2	35505-692-003	Bulb - 14V 1.4W
8	66418-579-000	Stopper - GLOVE BOX LID
9	75353-671-000	Lock - SCREW
10	77160-SR3-C02	Frame comp - INSTRUMENT CENTER
16	77504-SR3-A80	Cover - GLOVE BOX
17	77505-SR8-A90	Plate - R.
18	77508-SP0-000	Rubber - GLOVE BOX STOPPER
19	77509-SR3-000	Stopper - GLOVE BOX
20	77512-SR8-A90	Hinge comp - GLOVE BOX
21	77515-SR8-A91	Plate - L.
22	77518-SR8-A90	Stopper - GLOVE BOX
24	77530-SR8-A00	Damper assy. - GLOVE BOX
25	77542-SR3-000	Striker - GLOVE BOX
26	77551-ST7-A90	Frame - GLOVE BOX
29	77730-SR3-003	Holder comp - FR. ASHTRAY
30	77755-SH3-010	Spring - COIN POCKET
31	90101-692-000	Screw - GLOVE BOX
32	90104-MR4-900	Screw - SPECIAL, 4X12
33	90105-SA7-000	Screw-washer - 4X16
34	90137-SH3-000	Screw - TAPPING, 4X16
35	90140-SH3-003	Bolt-washer - 5X18
36	90157-SA0-000	Bolt-washer - 8X25
37	90302-SA4-003	Nut - SPRING, 4MM
38	90305-SA0-000	Nut - FLOATING, 4MM
39	90665-SM4-003	Grommet - SCREW, 4MM (YELLOW)
40	90666-SD4-003	Clip - FITTING
42	91555-SM4-003	Clip - COUPLER (RED)
43	91640-SM4-003	Grommet - SCREW, 4MM
53	39600-SW3-305	Lighter unit - CIGARETTE
53	39600-SW3-505	LIGHTER ASSYCIGA
54	39628-S04-305	Cord assy

Instrument panel garnish (LH; 1) 23

#	OEM	部品名
2	35505-692-003	Bulb - 14V 1.4W
7	66405-SD4-000	Stay - GLOVE BOX HINGE
8	66417-SB3-670	Rubber - GLOVE BOX STOPPER
9	66418-579-000	Stopper - GLOVE BOX LID
10	77160-SR3-C02	Frame comp - INSTRUMENT CENTER
15	77509-SR3-000	Stopper - GLOVE BOX
17	77542-SR3-000	Striker - GLOVE BOX
18	77551-SR3-C00	Frame - GLOVE BOX
21	77730-SR3-003	Holder comp - FR. ASHTRAY
22	77755-SH3-010	Spring - COIN POCKET
23	90137-SH3-000	Screw - TAPPING, 4X16
24	90140-SH3-003	Bolt-washer - 5X18
25	90144-SP0-000	Screw - TAPPING, 4X16 (PO)
26	90157-SA0-000	Bolt-washer - 8X25
27	90302-SA4-003	Nut - SPRING, 4MM
28	90305-SA0-000	Nut - FLOATING, 4MM
29	90665-SM4-003	Grommet - SCREW, 4MM (YELLOW)
30	90666-SD4-003	Clip - FITTING
31	91555-SM4-003	Clip - COUPLER (RED)
32	91640-SM4-003	Grommet - SCREW, 4MM
40	39600-SW3-305	Lighter unit - CIGARETTE
40	39600-SW3-505	LIGHTER ASSYCIGA
41	39628-S04-305	Cord assy

Intake manifold (PGM-FI; 3) 19

#	OEM	部品名
1	06164-P06-A02	Packing set - INJECTOR
2	16472-PD6-000	Seal ring - INJECTOR (OTSUKA)
3	16473-PD6-000	Cushion ring - INJECTOR (OTSUKA)
3	16473-P10-A01	Cushion ring - INJECTOR (NOK)
4	16620-P30-A00	Pipe assy. - FUEL
5	16638-PH3-S00	Insulator - FUEL PIPE
6	16740-P05-A01	Regulator assy - PRESSURE
7	16741-PG7-005	O-ring - PRESSURE REGULATOR
8	17100-P30-G00	Manifold comp - INTAKE
9	17105-P30-004	Gasket - INTAKE MANIFOLD (NIPPON LEAKLESS)
10	17132-P30-G00	Stay comp - INTAKE MANIFOLD
11	19509-PR3-003	Clamp - ELECTRONIC AIR CONTROL VALVE
12	32754-P30-000	Stay d - ENGINE WIRE HARNESS
13	37880-P05-A00	Sensor assy - AIR TEMP
14	90033-PR3-000	Bolt - INTAKE MANIFOLD STAY
15	91301-PM7-003	O-ring - 7.3X2.2 (ARAI)
15	91301-P2F-A01	O-ring - 7.3X2.2 (NOK)
15	16074-ZY3-000	O-ring
16	91303-PK2-005	O-ring (7.5X1.5)

Intake manifold (PGM-FI; DOHC VTEC) 19

#	OEM	部品名
1	06164-P06-A02	Packing set - INJECTOR
2	16472-PD6-000	Seal ring - INJECTOR (OTSUKA)
3	16473-PD6-000	Cushion ring - INJECTOR (OTSUKA)
3	16473-P10-A01	Cushion ring - INJECTOR (NOK)
4	16620-P30-A00	Pipe assy. - FUEL
5	16638-PH3-S00	Insulator - FUEL PIPE
6	16740-P05-A01	Regulator assy - PRESSURE
7	16741-PG7-005	O-ring - PRESSURE REGULATOR
8	17100-P30-G00	Manifold comp - INTAKE
9	17105-P30-004	Gasket - INTAKE MANIFOLD (NIPPON LEAKLESS)
10	17132-P30-G00	Stay comp - INTAKE MANIFOLD
11	19509-PR3-003	Clamp - ELECTRONIC AIR CONTROL VALVE
12	32754-P30-000	Stay d - ENGINE WIRE HARNESS
13	37880-P05-A00	Sensor assy - AIR TEMP
14	90033-PR3-000	Bolt - INTAKE MANIFOLD STAY
15	91301-PM7-003	O-ring - 7.3X2.2 (ARAI)
15	91301-P2F-A01	O-ring - 7.3X2.2 (NOK)
15	16074-ZY3-000	O-ring
16	91303-PK2-005	O-ring (7.5X1.5)

Interior light 3

#	OEM	部品名
2	34252-692-003	Lens - DAIICHI) (SUNROOF
3	34253-671-003	Bulb - 12V 8W)(DAIICHI
3	04110-SWA-305	BULB T10X318W

Knuckle 18

#	OEM	部品名
1	44348-SR3-000	Ring - FR. KNUCKLE
2	51210-SR3-N10	Knuckle comp - R. FR. (ABS)
3	51215-SR3-N10	Knuckle comp - L. FR. (ABS)
4	51220-SR3-003	Joint comp - LOWER BALL (MUSASHI)
5	51225-SR3-003	Boot - LOWER BALL DUST (MUSASHI)
6	51450-SR3-013	Arm assy. - R. FR. UPPER
7	51455-SR3-004	Bush - FR. UPPER ARM (SUMITOMO)
7	51455-SR3-003	Bush - FR. UPPER ARM (YAMASHITA)
8	51460-SR3-013	Arm assy. - L. FR. UPPER
9	51464-SK7-003	Boot - UPPER BALL JOINT
10	52338-SL0-003	Circlip - CONTROL ARM
11	57450-SR3-801	Sensor assy - R. FR.
12	57455-SR3-801	Sensor assy - L. FR.
13	90185-SR3-013	Bolt - FR. ARM UPPER (10X58)
14	90215-SB0-003	Nut - SELF-LOCK, 12MM (SATO RASHI) (CLINCH)
15	90306-SB2-013	Nut - SELF-LOCK, 10MM (CLINCH)
16	90321-SE0-000	Nut - UPPER BALL PIN, 10MM
17	90363-SF1-000	Nut - CASTLE, 12MM

Lower gate 30

#	OEM	部品名
3	72116-SM4-003	Snap d - VIOLET
4	72616-SM4-003	Snap - NATURAL
5	73219-693-951	Seal - FUEL LID OPENER (GREEN)
6	74411-SR3-A01	Cable - FUEL LID OPENER
7	74440-SR3-003	Weatherstrip - TAILGATE
8	74441-SR3-003	Weatherstrip - STEP GATE
9	74442-SR3-003	Clip - R. LOWER GATE WEATHERSTRIP
10	74443-SR3-003	Clip - L. LOWER GATE WEATHERSTRIP
11	74790-SR3-003	Handle assy - LOWER GATE
12	74810-SR3-003	Lock assy - TAILGATE
13	74812-SR3-003	Cylinder - TAILGATE
14	74814-SR3-003	Rod - TAILGATE OPENER
15	74815-SK8-000	Grommet - KEY CYLINDER(BLACK)
16	74830-SR3-A01	Cable - TAILGATE OPENER
17	74851-SR3-003	Rod - R. LOWER GATE LOCK
18	74852-SR3-003	Rod - L. LOWER GATE LOCK
21	74860-SR3-003	Lock assy - R. LOWER GATE
22	74862-SR3-003	Striker - LOWER GATE
23	74870-SR3-003	Lock assy - L. LOWER GATE
26	74910-SR3-003	Cable comp - LOWER GATE SUPPORT
27	74911-SR3-000	Guide - SUPPORT CABLE
28	75513-SB4-000	Cushion - LOCK ROD (15MMX40MM)
31	90113-SR3-003	Bolt b - FLANGE
32	90504-SR3-003	Washer - BOLT HOLD
34	90662-SB2-003	Grommet - SCREW, 5MM
35	90691-SC5-003	Clip A - OPENER CABLE
36	90692-SK8-003	Clip - TRUNK OPENER CABLE
37	91513-SR3-003	Snap
38	91514-SR3-003	Snap - BLACK
43	90105-634-000	Bolt-washer (8x20)

Mainshaft (2) 17

#	OEM	部品名
1	23210-PS1-N01	Mainshaft comp.
2	23261-PS1-010	Shaft - REVERSE IDLE GEAR
3	23440-P21-000	Gear comp - MAINSHAFT THIRD
4	23451-P21-000	Gear - MAINSHAFT FOURTH
5	23540-PF5-010	Gear comp - REVERSE IDLE
6	23581-P21-F00	Gear - MAINSHAFT FIFTH
7	23623-P21-315	Sleeve set - SYNCHRONIZER (3-4)
8	23626-P21-335	Sleeve set - SYNCHRONIZER (5-R)
9	23646-P21-000	Stopper - RING BRAKE
10	23647-P21-000	Ring - TAPER CONE
11	23915-P21-000	Collar - DISTANCE, 31X38X56.5
12	23916-P21-M00	Collar - DISTANCE, 28X37X15
13	23927-PG2-A00	Washer - SPRING, 28MM
14	23928-PS1-000	Washer - 28MM
15	91004-P21-003	Bearing - ANGULAR BALL, 28X72X18
16	91104-P21-008	Bearing - NEEDLE, 38X43X26 (NTN)
17	91108-P21-008	Bearing - NEEDLE, 37X42X14.8 (NTN)

Mainshaft (DOHC VTEC) 17

#	OEM	部品名
1	23210-P21-020	Mainshaft comp.
2	23261-PS1-010	Shaft - REVERSE IDLE GEAR
3	23440-P21-000	Gear comp - MAINSHAFT THIRD
4	23451-P21-000	Gear - MAINSHAFT FOURTH
5	23540-PF5-010	Gear comp - REVERSE IDLE
6	23581-P21-010	Gear - MAINSHAFT FIFTH
7	23623-P21-315	Sleeve set - SYNCHRONIZER (3-4)
8	23626-P21-335	Sleeve set - SYNCHRONIZER (5-R)
9	23646-P21-000	Stopper - RING BRAKE
10	23647-P21-000	Ring - TAPER CONE
11	23915-P21-000	Collar - DISTANCE, 31X38X56.5
12	23916-P21-M00	Collar - DISTANCE, 28X37X15
13	23927-PG2-A00	Washer - SPRING, 28MM
14	23928-PS1-000	Washer - 28MM
15	91004-P21-003	Bearing - ANGULAR BALL, 28X72X18
16	91104-P21-008	Bearing - NEEDLE, 38X43X26 (NTN)
18	91108-P21-008	Bearing - NEEDLE, 37X42X14.8 (NTN)

Mirror 19

#	OEM	部品名
1	04762-SR3-J11	Mirror sub assy. - R. REMOTE CONTROL
2	04764-SR3-J11	Mirror sub assy. - L. REMOTE CONTROL
3	04769-SM4-J01	Holder set - ACTUATOR
4	76200-SR3-G15	Mirror assy - R. DOOR (R.C.)
6	76201-SR3-003	Housing - R.
11	76213-SR3-003	Pin - STOPPER
13	76220-SR3-900	Sub garnish - R. DOOR MIRROR
14	76250-SR3-G15	Mirror assy - L. DOOR (R.C.)
16	76251-SR3-003	Housing - L.
20	76270-SR3-900	Sub garnish - L. DOOR MIRROR
23	76409-SL0-003	Washer - TOOTHED
24	76410-SL4-003	Bolt - LOCK
25	76419-SL4-003	Spring - HOLDER
26	76420-SL4-003	Plate - HOOK
27	76290-SR3-003	Screw - TAPPING, 4X10 (TRUSS) (###)
28	76291-SR3-003	Screw - TAPPING, 4X16 (TRUSS)
29	90615-SK7-003	Clip - MIRROR GARNISH
32	04763-SR3-000	Actuator set - R. DOOR MIRROR
33	04766-SR3-000	Actuator set - L. DOOR MIRROR

Oil pump (DOHC VTEC) 21

#	OEM	部品名
2	15100-PR3-024	Pump assy. - OIL
2	15100-PR3-014	Pump assy. - OIL
3	15220-P30-003	Strainer comp. - OIL
4	15221-PW0-S01	Packing - OIL STRAINER
5	15231-PE0-000	Valve - RELIEF
6	15232-PG6-000	Spring - RELIEF VALVE
7	15233-PC6-000	Bolt - SEALING, 18MM
8	15234-PC6-000	Washer - SEALING, 18MM
9	15400-PH1-F03	Cartridge - OIL FILTER (LABINAL-PURFLUX)
10	15400-PR3-004	Cartridge - OIL FILTER (TOYO ROKI)
10	15400-RTA-003	OIL FILTER (MAHLE TENNEX)
10	15400-PR3-003	Cartridge - OIL FILTER (TSUCHIYA)
11	15400-PR3-305	Cartridge set - OIL FILTER (TOYO ROKI)
12	15500-PR3-013	Cooler - ENGINE OIL
13	15560-PT6-003	Bolt - OIL COOLER CENTER
14	90042-PR3-000	Bolt - STUD, 6X28
15	91212-PR3-003	Oil seal - 38X50X7.4 (NOK)
16	91308-PK1-003	O-ring - 26.2X2.4 (NOK)
16	91302-PF0-003	O-ring - 26.9X2.4 (NOK)
17	91316-PT6-003	O-ring - 62.4X3.1
17	91316-PE7-730	O-ring - 62.4X3.1

Oil pump/oil strainer (2) 19

#	OEM	部品名
2	15100-PR3-014	Pump assy. - OIL
2	15100-PR3-024	Pump assy. - OIL
3	15220-P30-003	Strainer comp. - OIL
4	15221-PW0-S01	Packing - OIL STRAINER
5	15231-PE0-000	Valve - RELIEF
6	15232-PG6-000	Spring - RELIEF VALVE
7	15233-PC6-000	Bolt - SEALING, 18MM
8	15234-PC6-000	Washer - SEALING, 18MM
9	15400-PR3-004	Cartridge - OIL FILTER (TOYO ROKI)
9	15400-RTA-003	OIL FILTER (MAHLE TENNEX)
9	15400-PR3-405	Cartridge - OIL FILTER (TOYO ROKI)
9	15400-PR3-003	Cartridge - OIL FILTER (TSUCHIYA)
10	15400-PR3-305	Cartridge set - OIL FILTER (TOYO ROKI)
10	15400-PR3-406	Cartridge set - OIL FILTER (TOYO ROKI)
11	90015-PH1-013	Holder - OIL FILTER
12	90042-PR3-000	Bolt - STUD, 6X28
13	91212-PR3-003	Oil seal - 38X50X7.4 (NOK)
14	91308-PK1-003	O-ring - 26.2X2.4 (NOK)
14	91302-PF0-003	O-ring - 26.9X2.4 (NOK)

P.s. gear box (1) 28

#	OEM	部品名
1	53010-SR3-010	End set - RACK
2	53411-SH3-950	Tube - AIR TRANSFER
3	53434-SD9-000	Clip - TIE ROD
3	53434-S04-J51	CLIP, TIE ROD
4	53436-SH3-950	Cushion b - POWER STEERING GEAR BOX
5	53438-SR3-950	Bracket - POWER STEERING GEAR BOX
6	53446-SK7-950	Rubber - BAND (T)
7	53447-SH3-950	Band - TRANSFER TUBE
8	53448-SH3-950	Clip - TRANSFER TUBE
9	53449-SL0-A00	Band b - BELLOWS
9	53449-S04-J51	Band b - BELLOWS
10	53449-SM4-000	Band - BELLOWS
11	53459-SR3-A51	Stay - TRANSFER TUBE
12	53501-SR3-000	Grommet a - STEERING
13	53502-SR3-A51	Grommet b - STEERING
14	53534-SR3-A52	Dust seal comp. - TIE ROD
15	53534-SR3-N52	Dust seal comp. - TIE ROD
16	53536-SR3-000	Washer - TIE ROD LOCK
17	53540-SR3-003	End comp - R. TIE ROD
18	53546-SA0-003	Boot - TIE ROD END (MUSASHI)
19	53548-SL0-A01	Circlip - TIE ROD
20	53560-SR3-003	End comp - L. TIE ROD
21	53601-SR3-G53	Box assy - POWER STEERING GEAR
22	53685-SH3-000	Bush - STEERING GEAR BOX MOUNTING
23	53686-SH3-010	Collar - STEERING GEAR BOX MOUNTING
24	90108-SR3-951	Bolt - GEAR BOX MOUNTING (10X65)
25	90320-SF1-000	Nut - CASTLE, 10MM
26	90325-SM4-J00	Washer - PLAIN, 10MM

P.s. gear box (LH) 28

#	OEM	部品名
1	53010-SR3-010	End set - RACK
2	53411-SH3-950	Tube - AIR TRANSFER
3	53434-SD9-000	Clip - TIE ROD
3	53434-S04-J51	CLIP, TIE ROD
4	53436-SH3-950	Cushion b - POWER STEERING GEAR BOX
5	53438-SR3-950	Bracket - POWER STEERING GEAR BOX
6	53446-SK7-950	Rubber - BAND (T)
7	53447-SH3-950	Band - TRANSFER TUBE
8	53448-SH3-950	Clip - TRANSFER TUBE
9	53449-SL0-A00	Band b - BELLOWS
9	53449-S04-J51	Band b - BELLOWS
10	53449-SM4-000	Band - BELLOWS
11	53459-SR3-A51	Stay - TRANSFER TUBE
12	53501-SR3-000	Grommet a - STEERING
13	53502-SR3-A51	Grommet b - STEERING
14	53534-SR3-A52	Dust seal comp. - TIE ROD
15	53534-SR3-N52	Dust seal comp. - TIE ROD
16	53536-SR3-000	Washer - TIE ROD LOCK
17	53540-SR3-003	End comp - R. TIE ROD
18	53546-SA0-003	Boot - TIE ROD END (MUSASHI)
19	53548-SL0-A01	Circlip - TIE ROD
20	53560-SR3-003	End comp - L. TIE ROD
21	53601-SR3-G53	Box assy - POWER STEERING GEAR
22	53685-SH3-000	Bush - STEERING GEAR BOX MOUNTING
23	53686-SH3-010	Collar - STEERING GEAR BOX MOUNTING
24	90108-SR3-951	Bolt - GEAR BOX MOUNTING (10X65)
25	90320-SF1-000	Nut - CASTLE, 10MM
26	90325-SM4-J00	Washer - PLAIN, 10MM

P.s. gear box components (1) 51

#	OEM	部品名
1	06531-SR3-A51	Seal kit a - POWER STEERING
2	06532-SR3-A50	Seal kit b - POWER STEERING
3	53412-SR0-003	O-ring - RACK GUIDE (SHOWA)
3	53412-634-000	O-ring - RACK GUIDE (YAMADA)
4	53413-SD4-951	Spring - RACK GUIDE PRESSURE
5	53414-634-010	Screw - RACK GUIDE
5	53414-634-020	Screw
6	53416-SR3-A01	Guide - STEERING RACK
7	53426-SE0-951	Dust seal - STEERING PINION
8	53449-SL0-A00	Band b - BELLOWS
8	53449-S04-J51	Band b - BELLOWS
9	53449-SM4-000	Band - BELLOWS
10	53458-SE0-003	Nut - RACK SCREW LOCK
10	53458-S01-A51	Nut - LOCK
11	53536-SR3-000	Washer - TIE ROD LOCK
12	53608-SR3-A51	Housing sub assy. - STEERING GEAR BOX (###)
13	53611-SR3-A51	Cylinder comp
14	53612-SH3-950	Barrel - CYLINDER
15	53613-SK7-950	Retainer - PACKING
16	53614-SH3-N51	Cap - CYLINDER (SGN)
17	53615-SD4-950	Washer - RETAINER
18	53617-SF1-950	Port - ORIFICE
19	53622-SR3-G52	Pinion - STEERING
20	53625-SR3-A50	Cap - GEAR BOX HOUSING
21	53626-SR3-G52	Rack comp - STEERING
22	53629-SB3-950	Orifice - SENSOR
23	53630-SD4-950	Spring - CYLINDER
24	53631-SD4-951	Bush a - STEERING RACK
25	53632-SF1-950	Bush b - STEERING RACK
26	53634-SF1-951	Clip - BUSH STOPPER
27	53640-SR3-G51	Body comp - VALVE (###)
28	53643-SR3-A50	Port comp. - VALVE
29	53645-SR3-A50	Cap comp. - VALVE
30	53646-SR3-A50	Spool - FOUR WAY
31	53651-SB4-950	Spool comp. b - CUT-OFF (-0.005 / 0)
32	53653-SR3-G51	Spring - CUT-OFF
33	53659-SR3-A50	Orifice comp. - DAMPING
34	53666-SA5-671	Plunger - DIAMETER=8MM
35	53667-SR3-A50	Spring - RETURN
36	90103-SB4-950	Bolt - POWER STEERING
37	90684-SD4-950	Ring - SNAP, 31MM
38	90693-SC5-003	Circlip - INTERNAL, 32MM
39	90697-SA5-003	Circlip - EXTERNAL, 31MM
40	91052-SL5-A01	Bearing - RADIAL BALL, 6906/31ZZ
41	91053-SL5-A01	Bearing - RADIAL BALL, 600
42	91103-429-000	Dowel pin - 8X10
43	91154-SA5-952	Roller - 3.5X29.8
44	91352-SF4-951	O-ring - 9.8X1.9 (NOK)
44	91318-PT0-003	O-ring - 9.8X1.9 (NOK)
45	91360-SD4-951	O-ring - 50X2.4 (NOK)
45	91360-SD4-952	O-ring - 50X2.4 (ARAI)

P.s. gear box components (LH) 51

#	OEM	部品名
1	06531-SR3-A51	Seal kit a - POWER STEERING
2	06532-SR3-A50	Seal kit b - POWER STEERING
3	53412-SR0-003	O-ring - RACK GUIDE (SHOWA)
3	53412-634-000	O-ring - RACK GUIDE (YAMADA)
4	53413-SD4-951	Spring - RACK GUIDE PRESSURE
5	53414-634-010	Screw - RACK GUIDE
5	53414-634-020	Screw
6	53416-SR3-A01	Guide - STEERING RACK
7	53426-SE0-951	Dust seal - STEERING PINION
8	53449-SL0-A00	Band b - BELLOWS
8	53449-S04-J51	Band b - BELLOWS
9	53449-SM4-000	Band - BELLOWS
10	53458-SE0-003	Nut - RACK SCREW LOCK
10	53458-S01-A51	Nut - LOCK
11	53536-SR3-000	Washer - TIE ROD LOCK
12	53608-SR3-A51	Housing sub assy. - STEERING GEAR BOX (###)
13	53611-SR3-A51	Cylinder comp
14	53612-SH3-950	Barrel - CYLINDER
15	53613-SK7-950	Retainer - PACKING
16	53614-SH3-N51	Cap - CYLINDER (SGN)
17	53615-SD4-950	Washer - RETAINER
18	53617-SF1-950	Port - ORIFICE
19	53622-SR3-G52	Pinion - STEERING
20	53625-SR3-A50	Cap - GEAR BOX HOUSING
21	53626-SR3-G52	Rack comp - STEERING
22	53629-SB3-950	Orifice - SENSOR
23	53630-SD4-950	Spring - CYLINDER
24	53631-SD4-951	Bush a - STEERING RACK
25	53632-SF1-950	Bush b - STEERING RACK
26	53634-SF1-951	Clip - BUSH STOPPER
27	53640-SR3-G51	Body comp - VALVE (###)
28	53643-SR3-A50	Port comp. - VALVE
29	53645-SR3-A50	Cap comp. - VALVE
30	53646-SR3-A50	Spool - FOUR WAY
31	53651-SB4-950	Spool comp. b - CUT-OFF (-0.005 / 0)
32	53653-SR3-G51	Spring - CUT-OFF
33	53659-SR3-A50	Orifice comp. - DAMPING
34	53666-SA5-671	Plunger - DIAMETER=8MM
35	53667-SR3-A50	Spring - RETURN
36	90103-SB4-950	Bolt - POWER STEERING
37	90684-SD4-950	Ring - SNAP, 31MM
38	90693-SC5-003	Circlip - INTERNAL, 32MM
39	90697-SA5-003	Circlip - EXTERNAL, 31MM
40	91052-SL5-A01	Bearing - RADIAL BALL, 6906/31ZZ
41	91053-SL5-A01	Bearing - RADIAL BALL, 600
42	91103-429-000	Dowel pin - 8X10
43	91154-SA5-952	Roller - 3.5X29.8
44	91352-SF4-951	O-ring - 9.8X1.9 (NOK)
44	91318-PT0-003	O-ring - 9.8X1.9 (NOK)
45	91360-SD4-951	O-ring - 50X2.4 (NOK)
45	91360-SD4-952	O-ring - 50X2.4 (ARAI)

P.s. line (LH) 22

#	OEM	部品名
1	53697-SB3-952	Cap - OIL TANK
2	53701-SR3-A51	Tank comp. - POWER STEERING OIL
3	53711-SR3-951	Bracket assy - OIL TANK
4	53713-SR3-G96	Hose comp. - POWER STEERING FEED
5	53720-SR3-A51	Pipe comp - RETURN, 10MM
6	53724-SR3-A53	Pipe comp - RETURN, 6MM
7	53728-SR3-A51	Clip - RETURN PIPE
8	53729-671-003	Clamp d - 15.5MM
9	53730-SR3-A51	Pipe comp - POWER STEERING COMBINATION RETURN
10	53731-SR3-990	Tube - POWER STEERING SUCTION
11	53732-SR3-A52	Hose - POWER STEERING RETURN
12	53733-SR3-A50	Tube - POWER STEERING OIL TANK
15	53735-SR3-960	Hose - OIL COOLER RETURN
16	53736-SR3-950	Holder - POWER STEERING PIPE
17	53737-SR3-A90	Bracket - POWER STEERING PIPE
22	53775-SR3-981	Stay b - FEED HOSE
24	90635-SM4-A01	Clip - OIL HOSE (MEIJI)
24	90635-SM4-A02	Clip - OIL HOSE (MEIJI)
26	91370-SM4-003	O-ring - 11X1.9 (NOK)
26	91370-SM4-004	O-ring - 11X1.9 (ARAI)
27	91405-PE0-003	Clamp - TUBE (D20)
27	91417-SZ3-003	Clamp - FUEL TUBE (D20) (CHUO HATSUJO)

P.s. lines (1) 22

#	OEM	部品名
1	53697-SB3-952	Cap - OIL TANK
2	53701-SR3-A51	Tank comp. - POWER STEERING OIL
3	53711-SR3-951	Bracket assy - OIL TANK
4	53713-SR3-G96	Hose comp. - POWER STEERING FEED
5	53720-SR3-A51	Pipe comp - RETURN, 10MM
6	53724-SR3-A53	Pipe comp - RETURN, 6MM
7	53728-SR3-A51	Clip - RETURN PIPE
8	53729-671-003	Clamp d - 15.5MM
9	53730-SR3-A51	Pipe comp - POWER STEERING COMBINATION RETURN
10	53731-SR3-990	Tube - POWER STEERING SUCTION
11	53732-SR3-A52	Hose - POWER STEERING RETURN
12	53733-SR3-A50	Tube - POWER STEERING OIL TANK
15	53735-SR3-960	Hose - OIL COOLER RETURN
16	53736-SR3-950	Holder - POWER STEERING PIPE
17	53737-SR3-A90	Bracket - POWER STEERING PIPE
21	53775-SR3-981	Stay b - FEED HOSE
22	90635-SM4-A01	Clip - OIL HOSE (MEIJI)
22	90635-SM4-A02	Clip - OIL HOSE (MEIJI)
23	91370-SM4-003	O-ring - 11X1.9 (NOK)
23	91370-SM4-004	O-ring - 11X1.9 (ARAI)
24	91405-PE0-003	Clamp - TUBE (D20)
24	91417-SZ3-003	Clamp - FUEL TUBE (D20) (CHUO HATSUJO)

P.s. pump 19

#	OEM	部品名
1	56110-P30-A02	Pump sub assy - POWER STEERING
2	56123-P30-000	Joint comp - IN. (###)
3	56141-P02-000	Shaft - POWER STEERING PUMP DRIVE
4	56167-PY3-000	Spacer - PUMP SEAL
5	56483-P30-000	Pulley - POWER STEERING PUMP
7	56992-P30-004	Belt - POWER STEERING PUMP (MITSUBOSHI)
7	56992-P30-003	Belt - POWER STEERING PUMP (BANDO)
7	38920-P08-003	Belt - COMPRESSOR (BANDO)
8	90305-PT0-000	Nut - POWER STEERING PULLEY
9	91048-PY3-003	Bearing - RADIAL BALL, 15X38X12
10	91148-PY3-003	Roller - 5X26.8
11	91149-PY3-003	Roller - 4.5X49.8
12	91249-P02-003	Seal - POWER STEERING PUMP
13	91317-P02-003	O-ring - 5.8X1.9 (NOK)
14	91345-PY3-000	O-ring - 13.0X1.9
15	91346-PY3-000	O-ring - 22.1X1.9
16	91347-PY3-000	O-ring - 16.8X1.9
17	91348-PY3-000	O-ring - 54.0X1.9
18	91349-PY3-000	O-ring - 68.5X1.9

P.s. pump bracket 5

#	OEM	部品名
2	56994-P30-000	Bracket - POWER STEERING PUMP LOWER
4	56996-P01-000	Bolt - POWER STEERING PUMP ADJUSTING WING
7	56997-P30-010	Bracket - POWER STEERING PUMP UPPER
10	90004-P30-000	Bolt - SPECIAL, 8MM
11	90601-P01-003	Clip - ADJUST BOLT

Parking brake 13

#	OEM	部品名
1	43471-SD2-930	Pin - BRAKE WIRE END
3	47142-659-310	Knob - PARKING BRAKE PUSH ROD
4	47143-SD4-300	Spring - PUSH ROD
5	47342-SM4-000	Switch - PARKING BRAKE
6	47360-SB2-000	Equalizer
7	47365-538-000	Pin - EQUALIZER
9	47510-SR3-933	Wire a - R. PARKING BRAKE
10	47522-594-000	Nut - PARKING BRAKE ADJUSTING
11	47537-671-670	Spring - PARKING BRAKE ROD
13	47560-SR3-933	Wire a - L. PARKING BRAKE
14	47572-SR3-010	Base - WIRE GUIDE
16	90651-538-000	Clip - BRAKE HOSE
17	90705-SD2-931	Pin - SNAP, 6MM

Pedal (1) 24

#	OEM	部品名
1	17800-SR3-000	Pedal comp - ACCELERATOR
3	17812-SA7-010	Washer - ACCELERATOR PEDAL
4	17814-SR3-000	Spring - ACCELERATOR RETURN
5	17816-SK7-000	Cover - ACCELERATOR PEDAL
6	17910-SR3-L01	Wire - THROTTLE
8	17921-SA4-730	Seal - THROTTLE CABLE
11	17931-SR3-A10	Clamp - THROTTLE WIRE
13	35350-SE0-A03	Switch assy - STOP (TEC)
14	46500-SR3-A10	Pedal assy - BRAKE
16	46504-ST5-300	Bush - PEDAL
17	46505-SA5-000	Pad - PEDAL STOPPER
18	46530-SR3-000	Spring assy - PEDAL RETURN
19	46535-SM4-000	Collar - PEDAL
21	46545-SH3-000	Cover - PEDAL
22	46590-SR3-A11	Bracket - PEDAL
23	46904-SM4-300	Pad - ACCELERATOR STOPPER
24	46905-SK7-000	Stopper - CLUTCH PEDAL
26	46907-SR3-000	Spring - CLUTCH ASSISTANT
27	46910-SR3-J00	Pedal comp - CLUTCH
28	46911-SD4-930	Bush - PEDAL PIN
29	46981-SR3-930	Bush a - CLUTCH ASSISTANT
30	46982-SR3-930	Bush b - CLUTCH ASSISTANT
31	46990-SR3-000	Bracket - CLUTCH PEDAL
32	46991-SR3-010	Bracket - FOOTREST

Pedal (LH) 24

#	OEM	部品名
1	17800-SR3-000	Pedal comp - ACCELERATOR
3	17812-SA7-010	Washer - ACCELERATOR PEDAL
4	17814-SR3-000	Spring - ACCELERATOR RETURN
5	17816-SK7-000	Cover - ACCELERATOR PEDAL
7	17910-SR3-L01	Wire - THROTTLE
8	17921-SA4-730	Seal - THROTTLE CABLE
11	17931-SR3-A10	Clamp - THROTTLE WIRE
13	35350-SE0-A03	Switch assy - STOP (TEC)
15	46500-SR3-A10	Pedal assy - BRAKE
17	46504-ST5-300	Bush - PEDAL
18	46505-SA5-000	Pad - PEDAL STOPPER
19	46530-SR3-000	Spring assy - PEDAL RETURN
20	46535-SM4-000	Collar - PEDAL
22	46545-SH3-000	Cover - PEDAL
23	46590-SR3-A11	Bracket - PEDAL
24	46904-SM4-300	Pad - ACCELERATOR STOPPER
25	46905-SK7-000	Stopper - CLUTCH PEDAL
27	46907-SR3-000	Spring - CLUTCH ASSISTANT
28	46910-SR3-J00	Pedal comp - CLUTCH
29	46911-SD4-930	Bush - PEDAL PIN
30	46981-SR3-930	Bush a - CLUTCH ASSISTANT
31	46982-SR3-930	Bush b - CLUTCH ASSISTANT
32	46990-SR3-000	Bracket - CLUTCH PEDAL
33	46991-SR3-000	Bracket - FOOTREST

Pillar garnish 2

#	OEM	部品名
6	90609-SG0-003	Clip - PILLAR GARNISH
7	90611-SR3-003	Clip - PILLAR GARNISH

Piston/crankshaft 53

#	OEM	部品名
1	13020-P30-G00	Piston set - OS 0.25
1	13010-P30-G00	Piston set - STD.
2	13021-PR3-004	Ring set - PISTON (OS 0.25) (RIKEN)
2	13011-PR3-004	Ring set - PISTON (STD.) (RIKEN)
2	13011-PR3-003	Ring set - PISTON (STD.) (TEIKOKU)
2	13021-PR3-003	Ring set - PISTON (OS 0.25) (TEIKOKU)
3	13014-PR3-S10	Washer set - THRUST (DAIDO)
3	13014-PR3-S20	Washer set - THRUST (TAIHO)
6	13112-PR3-000	Pin - PISTON
7	13204-PR3-004	Bolt - CONNECTING ROD
8	13205-PH7-000	Nut - CONNECTING ROD
9	13210-PR3-000	Rod comp - CONNECTING
10	13310-PR3-000	Crankshaft comp.
11	13621-PR3-003	Pulley - TIMING BELT DRIVE (HITACHI)
12	13622-PR3-000	Plate - TIMING BELT GUIDE
13	13810-P30-003	Pulley comp - CRANKSHAFT
16	90017-PR3-003	Bolt-washer - 14X31
17	90704-634-000	Key - 4.5X11.0
19	13216-PR3-004	Bearing f - CONNECTING ROD (PINK) (TAIHO)
19	13211-PR3-004	BEARING A - CONNECTING ROD (BLUE) (TAIHO)
19	13214-PR3-004	Bearing d - CONNECTING ROD (GREEN) (TAIHO)
19	13212-PR3-004	Bearing b - CONNECTING ROD (BLACK) (TAIHO)
19	13215-PR3-004	Bearing e - CONNECTING ROD (YELLOW) (TAIHO)
19	13217-PR3-004	Bearing g - CONNECTING ROD (RED) (TAIHO)
19	13213-PR3-004	Bearing c - CONNECTING ROD (BROWN) (TAIHO)
20	13325-PR3-003	Bearing e - MAIN UPPER (YELLOW) (DAIDO)
20	13325-PR3-004	Bearing e - MAIN UPPER (YELLOW) (TAIHO)
20	13323-PR3-004	Bearing c - MAIN UPPER (BROWN) (TAIHO)
20	13324-PR3-003	Bearing d - MAIN UPPER (GREEN) (DAIDO)
20	13324-PR3-004	Bearing d - MAIN UPPER (GREEN) (TAIHO)
20	13322-PR3-004	Bearing b - MAIN UPPER (BLACK) (TAIHO)
20	13321-PR3-004	BEARING A - MAIN UPPER (BLUE) (TAIHO)
20	13327-PR3-004	Bearing g - MAIN UPPER (RED)(TAIHO)
20	13323-PR3-003	Bearing c - MAIN UPPER (BROWN) (DAIDO)
20	13326-PR3-004	Bearing f - MAIN UPPER (PINK) (TAIHO)
20	13322-PR3-003	Bearing b - MAIN UPPER (BLACK) (DAIDO)
20	13321-PR3-003	BEARING A - MAIN UPPER (BLUE) (DAIDO)
20	13327-PR3-003	Bearing g - MAIN UPPER (RED)(DAIDO)
20	13326-PR3-003	Bearing f - MAIN UPPER (PINK) (DAIDO)
21	13346-PR3-004	Bearing f - MAIN LOWER (PINK) (TAIHO)
21	13344-PR3-003	Bearing d - MAIN LOWER (GREEN) (DAIDO)
21	13341-PR3-004	BEARING A - MAIN LOWER (BLUE) (TAIHO)
21	13347-PR3-004	Bearing g - MAIN LOWER (RED) (TAIHO)
21	13345-PR3-003	Bearing e - MAIN LOWER (YELLOW) (DAIDO)
21	13342-PR3-004	Bearing b - MAIN LOWER (BLACK) (TAIHO)
21	13341-PR3-003	BEARING A - MAIN LOWER (BLUE) (DAIDO)
21	13346-PR3-003	Bearing f - MAIN LOWER (PINK) (DAIDO)
21	13343-PR3-004	Bearing c - MAIN LOWER (BROWN) (TAIHO)
21	13347-PR3-003	Bearing g - MAIN LOWER (RED) (DAIDO)
21	13344-PR3-004	Bearing d, MAIN LOWER (GREEN) (TAIHO)
21	13342-PR3-003	Bearing b - MAIN LOWER (BLACK) (DAIDO)
21	13345-PR3-004	Bearing e - MAIN LOWER (YELLOW) (TAIHO)
21	13343-PR3-003	Bearing c - MAIN LOWER (BROWN) (DAIDO)

Radiator (DENSO) 15

#	OEM	部品名
1	19010-P30-G02	Radiator comp - DENSO
2	19011-PH1-621	Bolt - DRAIN (DENSO)
3	19012-671-300	Packing - DRAIN (DENSO)
4	19014-PK1-003	Clip - HARNESS
5	19015-P08-013	Shroud comp - DENSO
7	19020-P08-003	Fan, COOLING (DENSO)
8	19030-P08-013	Motor - COOLING FAN (DENSO)
9	19033-P08-003	Stay - COUPLER (DENSO)
10	19045-P08-013	Cap comp. - RADIATOR (DENSO)
10	19045-PAA-A01	Cap comp. - RADIATOR (DENSO)
11	19046-PV1-000	Seal - CAP
12	90041-P08-003	Screw-washer - 4X11
13	90042-PH2-003	Bolt-washer - 6X16 (DENSO)
13	90042-PAA-A01	Bolt-washer - 6X16 (DENSO)
14	90043-PD2-003	Nut - HEX., 5MM (DENSO)

Radiator hose 16

#	OEM	部品名
1	19101-P08-J00	Tank - RESERVE
2	19102-PM5-A00	Cap - RESERVE TANK
3	19104-PZ3-010	Tube a - RESERVE TANK (220MM)
4	19104-P08-000	Tube - RESERVE TANK
5	19106-PA0-020	Joint - RESERVE TANK
8	19115-P08-000	Bracket - RESERVE TANK
9	19501-P30-000	Hose - WATER UPPER
10	19502-P30-000	Hose - WATER LOWER
12	19511-PR3-003	Clip, WATER HOSE (CHUO SPRING)
12	19511-PH7-003	Clip, HOSE(36.5MM) (CHUO SPRING)
13	19511-P30-003	Clip, WATER HOSE (CHUO SPRING)
20	74172-SR3-000	Cushion - RADIATOR MOUNTING LOWER
21	74173-SJ4-000	Cushion - RADIATOR MOUNTING UPPER
22	74176-SR3-000	Bracket - RADIATOR MOUNT UPPER
23	90146-SA7-000	Bolt-washer - 6X16 (DACRO COATING)
27	19519-P54-003	Clamp - WATER HOSE

Radio antenna/speaker 10

#	OEM	部品名
1	39112-SH3-000	Bracket - FR. SPEAKER SEAL (12CM)
4	39120-SM4-901	Speaker assy - 120MM DUAL) (PIONEER
8	39150-SR3-G01	Antenna assy - AUTO RADIO (MATSUSHITA)
9	39154-SR3-G01	Packing - ANTENNA BASE (MATSUSHITA)
10	39156-SR3-C02	Sub feeder
11	90105-SB6-003	Screw - PAN, 4X12
13	90502-SA0-003	Washer - WATER PROOF
14	90670-SG0-003	Grommet - SCREW, 4MM
15	90683-SB3-003	Clip - WIRE HARNESS
16	91570-SH3-003	Band - WIRE HARNESS (NATURAL)

Rear brake (DISK) 47

#	OEM	部品名
1	01473-SD2-932	Caliper set - RR.
1	01473-ST7-010	Caliper set
2	42200-SR3-A53	Bearing assy - HUB UNIT (NTN) (ABS)
3	42324-SB2-020	Washer - HUB UNIT
4	42326-SB2-000	Cap - HUB UNIT
4	42326-SFA-000	Cap - HUB UNIT
5	42510-SR3-J00	Disk - RR. BRAKE
6	43018-SR3-000	Caliper sub assy. - R. RR.
7	43019-SR3-000	Caliper sub assy. - L. RR.
8	43022-SR3-G01	Pad set - RR.
11	43215-SH3-931	Piston assy.
13	43223-SD2-932	BEARING A
14	43224-SD2-931	Spring b - ADJUSTING
15	43227-SF1-003	Spring - PAD
16	43228-SD2-933	Shaft a
17	43229-SD2-931	Rod
20	43233-SD2-931	Piston comp - SLEEVE
22	43235-SD2-931	Pin a
23	43236-SD2-931	Spacer
23	43236-S04-003	Spacer
24	43238-SD2-931	Ring - RETAINING
25	43241-SD2-931	Guide - SPRING
27	43243-SD2-931	Nut - PARKING
28	43244-SD2-931	Retainer
29	43245-SH3-931	Lever - R.
30	43246-SD2-931	Spring - R. RETURN
31	43247-SH3-931	Arm - R.
32	43248-SD2-933	Shaft b
33	43249-SM4-951	Bolt - ADJUSTER
34	43253-SK7-950	Guard - R. RR. SPLASH (ABS)
35	43254-SK7-950	Guard - L. RR. SPLASH (ABS)
36	43255-SR3-932	Protector - R. RR. CALIPER
37	43256-SR3-932	Protector - L. RR. CALIPER
38	43262-SD2-931	Pin b
38	43262-S84-A51	Pin b
39	43265-SH3-931	Lever - L.
40	43266-SD2-931	Spring - L. RETURN
41	43267-SH3-931	Arm - L.
42	43352-SM4-951	Screw - BLEEDER
43	43353-SD5-003	Cap - BLEEDER SCREW
45	45240-SC2-003	Bolt - FLANGE, 8X22
46	90113-SA0-025	Bolt - WHEEL (NAGOYA RASHI)
46	90113-SM1-005	Bolt - WHEEL (ROCKNEL FASTENER)
46	90113-SA0-023	Bolt - WHEEL (TOKAI TRW)
46	90113-SA0-006	Bolt - WHEEL (SAGA)
47	90305-692-010	Nut
53	43227-SD2-305	Shim - OUTER PAD

Rear seat (2) 10

#	OEM	部品名
1	78178-SR3-004	Collar - PIVOT
6	82230-SR3-003	Adjuster - R. RR. RECLINING
8	82231-SR3-003	Cover - R. RR. SEAT RECLINING
9	82232-SR3-J22	Rod - R. RR. RECLINING
10	82295-SR3-003	Bracket - RR. SEAT PIVOT CENTER
13	82630-SR3-003	Adjuster - L. RR. RECLINING
15	82631-SR3-003	Cover - L. RR. SEAT RECLINING
16	82632-SR3-J22	Rod - L. RR. RECLINING
17	90155-SH3-000	Bolt-washer - 8X25
18	91554-SR3-003	Clip - RR. RECLINING

Rear seat (VTI) 10

#	OEM	部品名
1	78178-SR3-004	Collar - PIVOT
6	82230-SR3-003	Adjuster - R. RR. RECLINING
8	82231-SR3-003	Cover - R. RR. SEAT RECLINING
9	82232-SR3-J22	Rod - R. RR. RECLINING
10	82295-SR3-003	Bracket - RR. SEAT PIVOT CENTER
13	82630-SR3-003	Adjuster - L. RR. RECLINING
15	82631-SR3-003	Cover - L. RR. SEAT RECLINING
16	82632-SR3-J22	Rod - L. RR. RECLINING
17	90155-SH3-000	Bolt-washer - 8X25
19	91554-SR3-003	Clip - RR. RECLINING

Rear shock absorber 18

#	OEM	部品名
1	51621-SB0-003	Washer - SHOCK ABSORBER MOUNTING (TOKICO)
2	51685-SH3-014	Plate - DUST COVER(SHOWA)
3	51728-SB0-003	Collar - SHOCK ABSORBER MOUNTING(TOKICO)
4	52441-SR3-902	Spring - RR. (MITSUBISHI)
4	52441-SR3-901	Spring - RR. (SHOWA)
4	52441-SR3-903	Spring - RR. (NHK SPRING)
5	52610-SR3-Y12	Absorber assy - RR. SHOCK (###)
6	52611-SR3-A02	Absorber unit - RR. SHOCK (SHOWA)
9	52675-SH3-024	Base - RR. SHOCK ABSORBER MOUNTING (SHOWA)
10	52686-SR3-003	Rubber - RR. SPRING MOUNTING (SHOWA)
11	52687-SR3-003	Cover - RR. DUST (SHOWA)
12	52688-SR3-003	End - RR. DUST COVER (SHOWA)
13	52690-SG0-000	Plate - BUMP STOP
14	52722-SR3-003	Rubber - RR. BUMP STOPPER (SHOWA)
15	52725-SJ4-000	Rubber - RR. SHOCK ABSORBER MOUNTING (SHOWA)
17	90172-SK7-A01	Bolt - SHOCK ABSORBER LOWER (10X84)
18	90304-SR3-014	Nut - FLANGE, 10MM (OHASHI)
19	90364-SG0-004	Nut - SELF-LOCK, 10MM (SHOWA) (NYLON)

Rear stabilizer/rear lower arm 38

#	OEM	部品名
1	42534-SK7-A00	Cover - R. RR. (ABS)
2	42535-SK7-A00	Cover - L. RR. (ABS)
3	46438-SR3-010	Bracket - R. RR. BRAKE HOSE (DISK)
4	46439-SR3-010	Bracket - L. RR. BRAKE HOSE (DISK)
5	52300-SR3-901	Spring - RR. STABILIZER
6	52303-SH3-020	Link comp - STABILIZER
7	52308-SR3-000	Holder - RR. STABILIZER
8	52312-SE0-000	Collar - STABILIZER INNER BUSH END
9	52314-SH3-000	Bush - STABILIZER LINKAGE
10	52315-SR3-900	Bush - RR. STABILIZER
11	52316-SA5-000	Bush - STABILIZER END
12	52317-SR3-010	Bracket - R. RR. STABILIZER
13	52318-SR3-010	Bracket - L. RR. STABILIZER
14	52341-SR3-000	Arm comp - RR. COMPENSATOR
15	52343-SR3-004	Bush - COMPENSATOR (YAMASHITA)
15	52343-SK7-003	Bush - COMPENSATOR (HOKUSHIN)
16	52350-SH3-G31	Arm comp - R. RR. LOWER (ABS)
18	52354-SR3-000	Protector - R. RR. LOWER ARM
19	52360-SH3-G31	Arm comp - L. RR. LOWER (ABS)
21	52364-SR3-000	Protector - L. RR. LOWER ARM
22	52365-SK7-A02	Bush - RR. LOWER ARM (HOKUSHIN)
24	52370-SR3-A80	Arm comp - R. RR. TRAILING (DISK)
25	52371-SR3-A80	Arm comp - L. RR. TRAILING (DISK)
26	52390-SR3-000	Arm comp
27	52393-SR3-004	Bush - UPPER ARM INNER (YAMASHITA)
28	52395-SH3-004	Bush - RR. UPPER ARM (YAMASHITA)
29	52400-SR3-000	Arm comp
30	52622-SK7-A02	Bush - RR. SHOCK ABSORBER LOWER (YAMASHITA)
31	57470-SR3-A02	Sensor assy - R. RR.
32	57475-SR3-A03	Sensor assy - L. RR.
34	90117-SH3-004	Bolt - UPPER ARM, 10X30
35	90120-SB0-003	Bolt - SHOCK ABSORBER LOCK, 10X42
36	90171-SR3-003	Bolt - TORQUE COMPENSATOR, 10X59
37	90172-SK7-003	Bolt - UPPER ARM, 10X68
37	90172-S04-003	Bolt - FLANGE, 10X68
38	90173-SR3-003	Bolt - LOWER ARM, 10X80
39	90174-SJ4-003	Bolt - TRAILING ARM BUSH, 12X60
41	90551-SH3-000	Washer - 24X10X2.3

Rear wiper 17

#	OEM	部品名
1	68135-SR3-020	Plate - RR. WIPER MOTOR BASE
2	76700-SR3-003	Motor assy. - RR. WIPER (MITSUBA)
3	76705-SR3-003	Cover - UPPER MOTOR
4	76707-SR3-000	Seal a
5	76708-SE1-003	Washer b - SPECIAL
6	76709-SE0-A01	Nut - SPECIAL, 18MM
7	76711-SF1-003	Cap - PIVOT
8	76721-SR3-003	Cover - HEAD
9	76725-SR3-003	Cover - LOWER MOTOR
10	76732-SR3-003	Rubber - BLADE (275MM)
10	76732-SR3-305	Blade rubber 275m
11	76740-SR3-003	Arm & blade, RR. WINDSHIELD WIPER
12	90105-SR3-000	Seal - TAILGATE OPENER STAY & WIPER MOTOR
14	90108-SR3-901	Bolt - RR. WIPER MOTOR BASE PLATE, 6MM
14	90108-SR3-900	Bolt - RR. WIPER MOTOR BASE PLATE, 6MM
15	90109-SR3-000	Seal - RR. WIPER MOTOR BASE PLATE
16	90410-SD3-660	Washer - PLAIN, 8MM

Roof lining 7

#	OEM	部品名
3	75353-671-000	Lock - SCREW
16	83241-SR3-000	Bracket - R. FR. GRAB RAIL (SUNROOF)
17	83243-SK8-A40	Cover - GRAB RAIL
18	83248-SG0-003	Spacer - GRAB RAIL
33	90131-SH3-A12	Screw - PAN, 5X16
34	90195-SA0-000	Screw-washer - 6X20
35	90662-SB2-003	Grommet - SCREW, 5MM

Roof lining (LH) 7

#	OEM	部品名
3	75353-671-000	Lock - SCREW
13	83241-SR3-000	Bracket - R. FR. GRAB RAIL (SUNROOF)
14	83243-SK8-A40	Cover - GRAB RAIL
15	83248-SG0-003	Spacer - GRAB RAIL
25	90131-SH3-A12	Screw - PAN, 5X16
26	90195-SA0-000	Screw-washer - 6X20
27	90662-SB2-003	Grommet - SCREW, 5MM

Seatbelt 5

#	OEM	部品名
3	81481-SF1-G02	Cap - SEATBELT ANCHOR
4	81490-ST7-000	Bag - R. PROTECTOR
8	81890-ST7-000	Bag - L. PROTECTOR
11	82490-SR3-000	Bag - PROTECTOR
13	90688-SR3-003	Clip - BAG PROTECTOR

Seatbelts 5

#	OEM	部品名
6	81481-SF1-G02	Cap - SEATBELT ANCHOR
7	81490-ST7-000	Bag - R. PROTECTOR
13	81890-ST7-000	Bag - L. PROTECTOR
18	82490-SR3-000	Bag - PROTECTOR
22	90688-SR3-003	Clip - BAG PROTECTOR

Shift fork (2) 6

#	OEM	部品名
1	24201-P80-000	Fork sub comp. - FIFTH-REVERSE SHIFT
2	24210-P80-V00	Fork comp - GEARSHIFT (3-4)
3	24220-P80-000	Fork comp - GEARSHIFT (1-2)
4	24230-P21-010	Holder comp - REVERSE CHANGE
5	24243-P21-000	Piece - FIFTH & REVERSE SHIFT
6	90028-PB6-010	Bolt - SPECIAL, 6X22.5

Shift fork (DOHC VTEC; 1051163-) 6

#	OEM	部品名
1	24201-P80-000	Fork sub comp. - FIFTH-REVERSE SHIFT
2	24210-P80-V00	Fork comp - GEARSHIFT (3-4)
3	24220-P80-000	Fork comp - GEARSHIFT (1-2)
4	24230-P21-010	Holder comp - REVERSE CHANGE
5	24243-P21-000	Piece - FIFTH & REVERSE SHIFT
6	90028-PB6-010	Bolt - SPECIAL, 6X22.5

Shift lever 24

#	OEM	部品名
1	24313-PF5-000	Clip - CHANGE JOINT PIN
1	54113-611-505	CLIP, SHIFT JOINT
2	54101-SH3-010	Lever - CHANGE
3	54102-SH3-901	Knob comp,change
4	54105-692-010	Washer - THRUST
5	54107-SA0-010	Bush, RR. JOINT
7	54109-SA7-000	Seal A, CHANGE LEVER DUST
8	54110-SH3-003	Seat - CHANGE LEVER BALL
9	54111-SH3-000	Holder - CHANGE BALL
10	54114-SB2-000	Collar - PIPE MOUNTING
11	54115-SH3-000	Dust seal B, Change
12	54117-SH3-000	Collar - RR. JOINT
13	54201-SR3-G01	Rod comp - CHANGE
14	54301-SR3-G00	Extension - CHANGE
15	54303-SB2-010	Rubber, EXTENSION END
17	54304-SK7-000	Washer a - EXTENSION END
18	54305-SA0-000	Washer b - EXTENSION END
19	54306-SH3-000	Rubber, EXTENSION MOUNTING
20	54307-SH3-010	Stopper - EXTENSION MOUNTING
21	54308-SH3-000	Bolt - EXTENSION
23	90114-SA0-000	Nut - SELF-LOCK, 6MM
24	90115-659-003	Nut - SELF-LOCK, 8MM (CLINCH)
26	91301-671-671	O-ring - 1.9X11
26	91303-HA0-004	O-ring, 11x1.9 (nok)

Shift rod/shift holder (2) 20

#	OEM	部品名
1	24311-PS1-000	Rod - GEARSHIFT
2	24316-PS1-000	Boot - SHIFT ROD
3	24351-PS1-000	Shaft - SHIFT PIECE
4	24400-P21-020	Holder assy. - CHANGE
5	24411-PB6-010	Piece - CHANGE
6	24432-P21-000	Interlock comp.
7	24439-689-000	Shim e - SELECT ARM, 10.1X16X1.6
7	24436-689-000	Shim b - SELECT ARM, 10.1X16X1.0
7	24438-689-000	Shim d - SELECT ARM, 10.1X16X1.4
7	24435-689-000	Shim a - SELECT ARM, 10.1X16X0.8
7	24437-689-000	Shim c - SELECT ARM, 10.1X16X1.2
8	24440-P21-000	Piece comp. - GEARSHIFT
9	24452-P20-000	Spring - BALL SETTING
10	24457-PB6-020	Spring - SELECT RETURN
11	24519-PB6-000	Screw - BALL SPRING SETTING
12	90028-PB6-010	Bolt - SPECIAL, 6X22.5
13	90029-611-010	Bolt - HEX., 8X24
14	90401-689-010	Washer - 10MM
15	90403-689-000	Collar - LOCK
16	90412-679-000	Washer - CONICAL SPRING, 8MM

Shift rod/shift holder (DOHC VTEC) 20

#	OEM	部品名
1	24311-PS1-000	Rod - GEARSHIFT
2	24316-PS1-000	Boot - SHIFT ROD
3	24351-PS1-000	Shaft - SHIFT PIECE
4	24400-P21-020	Holder assy. - CHANGE
5	24411-PB6-010	Piece - CHANGE
6	24432-P21-000	Interlock comp.
7	24436-689-000	Shim b - SELECT ARM, 10.1X16X1.0
7	24438-689-000	Shim d - SELECT ARM, 10.1X16X1.4
7	24435-689-000	Shim a - SELECT ARM, 10.1X16X0.8
7	24437-689-000	Shim c - SELECT ARM, 10.1X16X1.2
7	24439-689-000	Shim e - SELECT ARM, 10.1X16X1.6
8	24440-P21-000	Piece comp. - GEARSHIFT
9	24452-P20-000	Spring - BALL SETTING
10	24457-PB6-020	Spring - SELECT RETURN
11	24519-PB6-000	Screw - BALL SPRING SETTING
12	90028-PB6-010	Bolt - SPECIAL, 6X22.5
13	90029-611-010	Bolt - HEX., 8X24
14	90401-689-010	Washer - 10MM
15	90403-689-000	Collar - LOCK
16	90412-679-000	Washer - CONICAL SPRING, 8MM

Side lining (2) 10

#	OEM	部品名
2	66418-579-000	Stopper - GLOVE BOX LID
9	83740-SR3-000	Lid - STOPPER
10	83742-SR3-000	Spacer
17	90302-SA4-003	Nut - SPRING, 4MM
18	90601-SD4-003	Grommet - PILLAR MOLDING
19	90609-SG0-003	Clip - PILLAR GARNISH
20	90668-SH3-003	Clip - SIDE LINING
21	90674-SK7-000	Clip - SNAP FITTING
22	90678-SK7-003	Clip - SPEAKER
23	90678-SR3-003	Clip - SNAP FITTING

Side lining (VTI) 10

#	OEM	部品名
2	66418-579-000	Stopper - GLOVE BOX LID
9	83740-SR3-000	Lid - STOPPER
10	83742-SR3-000	Spacer
18	90302-SA4-003	Nut - SPRING, 4MM
19	90601-SD4-003	Grommet - PILLAR MOLDING
20	90609-SG0-003	Clip - PILLAR GARNISH
21	90668-SH3-003	Clip - SIDE LINING
22	90674-SK7-000	Clip - SNAP FITTING
23	90678-SK7-003	Clip - SPEAKER
24	90678-SR3-003	Clip - SNAP FITTING

Side protector 35

#	OEM	部品名
2	71800-SR3-000	Garnish assy - R. SIDE SILL
3	71850-SR3-000	Garnish assy - L. SIDE SILL
4	72410-SR3-003	Molding assy. - R. FR. DOOR
5	72430-SR3-003	Garnish - R. DOOR SASH
6	72450-SR3-003	Molding assy. - L. FR. DOOR
7	72470-SR3-003	Garnish - L. DOOR SASH
8	74306-SR3-003	Molding assy. R. ROOF
9	74307-SR3-003	Clip - ROOF MOLDING
10	74316-SR3-003	Molding assy. L. ROOF
11	74430-SR3-A00	Protector - RR. WHEEL ARCH
11	74430-SM4-A00	Protector - RR. WHEEL ARCH
15	75301-SR3-003	Protector comp - R. FR. FENDER
16	75302-SR3-003	Protector comp - R. DOOR
17	75304-SR3-003	Protector comp - R. RR. FENDER
18	75305-SH2-003	Clip - SIDE PROTECTOR
19	75305-SR3-003	Clip - FR. FENDER PROTECTOR
20	75321-SR3-003	Protector comp - L. FR. FENDER
21	75322-SR3-003	Protector comp - L. DOOR
22	75324-SR3-003	Protector comp - L. RR. FENDER
23	75328-SR3-003	Clip - SIDE PROTECTOR
25	75807-671-010	Nut - SIDE PROTECTOR (BLACK)
27	75820-SR3-003	Mudguard - R. RR.
28	75830-SR3-003	Mudguard - L. RR.
30	90119-SR3-000	Screw - TAPPING, 4X10
30	90116-SE0-000	Screw - TAPPING, 4X12
32	90126-SA7-000	Screw-washer - 5X20
32	90114-SZ3-000	Screw-washer - 5X20
33	90308-SB2-013	Nut - SUSPENSION, 5MM
34	90331-SD5-003	Nut - SPRING, 5MM
37	90682-SB0-003	Grommet - SCREW, 5MM
38	90688-SB0-013	Clip b
38	90668-SC5-003	Clip A - AIRSCOOP GRILLE
39	91509-SR3-003	Clip - SASH GARNISH (NATURAL)
40	91510-SR3-003	Clip - DOOR MOLDING (NATURAL)
41	91513-SM4-000	Clip - SIDE SILL UPPER GARNISH

Side protectors 29

#	OEM	部品名
1	71800-SR3-000	Garnish assy - R. SIDE SILL
2	71850-SR3-000	Garnish assy - L. SIDE SILL
3	72410-SR3-003	Molding assy. - R. FR. DOOR
4	72430-SR3-003	Garnish - R. DOOR SASH
5	72450-SR3-003	Molding assy. - L. FR. DOOR
6	72470-SR3-003	Garnish - L. DOOR SASH
7	74306-SR3-003	Molding assy. R. ROOF
8	74307-SR3-003	Clip - ROOF MOLDING
9	74316-SR3-003	Molding assy. L. ROOF
10	74430-SR3-A00	Protector - RR. WHEEL ARCH
10	74430-SM4-A00	Protector - RR. WHEEL ARCH
13	75301-SR3-003	Protector comp - R. FR. FENDER
14	75302-SR3-003	Protector comp - R. DOOR
15	75304-SR3-003	Protector comp - R. RR. FENDER
16	75305-SH2-003	Clip - SIDE PROTECTOR
17	75305-SR3-003	Clip - FR. FENDER PROTECTOR
18	75321-SR3-003	Protector comp - L. FR. FENDER
19	75322-SR3-003	Protector comp - L. DOOR
20	75324-SR3-003	Protector comp - L. RR. FENDER
21	75328-SR3-003	Clip - SIDE PROTECTOR
22	75807-671-010	Nut - SIDE PROTECTOR (BLACK)
25	90119-SR3-000	Screw - TAPPING, 4X10
25	90116-SE0-000	Screw - TAPPING, 4X12
28	90331-SD5-003	Nut - SPRING, 5MM
30	90688-SB0-013	Clip b
30	90668-SC5-003	Clip A - AIRSCOOP GRILLE
31	91509-SR3-003	Clip - SASH GARNISH (NATURAL)
32	91510-SR3-003	Clip - DOOR MOLDING (NATURAL)
33	91513-SM4-000	Clip - SIDE SILL UPPER GARNISH

Sliding roof (1) 24

#	OEM	部品名
1	15707-634-000	Clip - OIL DRAIN TUBE
2	18534-634-670	Clip - AIR HOSE, 16MM
3	70052-SH3-000	Valve - FR. DRAIN (SUNROOF)
4	70060-SR3-000	Tube - RR. DRAIN VINYL (SUNROOF)
5	70062-SH3-000	Valve - RR. DRAIN (SUNROOF)
6	70080-SR3-003	Seal - SUNROOF FRAME
7	70100-SR3-G01	Frame comp - SUNROOF
8	70205-SR3-G01	Seal - SUNROOF PANEL
10	70271-SR3-G01	Holder - FR. SEAL
11	70272-SR3-G01	Holder - R. SEAL
12	70273-SR3-G01	Holder - RR. SEAL
13	70277-SR3-G01	Holder - L. SEAL
14	70291-SR3-003	Bolt - STAY, 6MM
17	70331-SR3-003	Stay - R. ROOF GLASS
18	70333-SR3-013	Slider - R.
19	70334-SR3-003	Slider b - GLASS LIFTER
20	70336-SR3-003	Stay - L. ROOF GLASS
21	70338-SR3-013	Slider - L.
23	70605-SR3-G02	Clip - LINING
24	70609-SR3-G01	Cover - SPRING
25	70615-SR3-G01	Spring - LINING
26	70621-SR3-G02	Lifter - R. LINING
27	70622-SR3-G01	Holder - CLIP
28	70626-SR3-G02	Lifter - L. LINING

Sliding roof (3) 29

#	OEM	部品名
1	70011-SR3-003	Hinge - TIE
2	70081-SR3-003	Sub seal - FRAME
3	70231-SR3-003	Channel - R. FR. DRAIN
4	70236-SR3-003	Channel - L. FR. DRAIN
5	70240-SR3-G01	Channel comp. - DRAIN
6	70242-SR3-003	Seal - RR. DRAIN CHANNEL MAIN
7	70245-SR3-003	Clip - DRAIN CHANNEL
9	70302-SR3-003	Stopper - FR.
10	70308-SR3-003	Stopper - RR.
11	70310-SR3-003	Rail - R. GUIDE
12	70312-SR3-003	Holder - R. FR. RAIL
13	70313-SR3-003	Holder - R. RR. RAIL
14	70314-SR3-003	Guide - FR. RAIL HOLDER
15	70315-SR3-003	Rail - L. GUIDE
16	70317-SR3-003	Holder - L. FR. RAIL
17	70318-SR3-003	Holder - L. RR. RAIL
18	70319-SR3-003	Cover - SPRING HOOK
21	70332-SR3-003	Slider a - GLASS LIFTER
22	70340-SR3-003	Anchor comp. - R.
23	70345-SR3-003	Anchor comp. - L.
24	70347-SR3-003	Spring - ANCHOR
25	70361-SR3-003	Link - R. SLIDE STOPPER
26	70366-SR3-003	Link - L. SLIDE STOPPER
27	70372-SR3-003	Lifter - R.
28	70377-SR3-003	Lifter - L.
29	70391-SR3-003	Screw - PAN, 5X10
30	70400-SR3-003	Cable assy - SUNROOF
31	70450-SR3-003	Motor assy. - SUNROOF
33	91555-SM4-003	Clip - COUPLER (RED)

Sliding roof (FRAME) 24

#	OEM	部品名
1	15707-634-000	Clip - OIL DRAIN TUBE
2	18534-634-670	Clip - AIR HOSE, 16MM
3	70052-SH3-000	Valve - FR. DRAIN (SUNROOF)
4	70060-SR3-000	Tube - RR. DRAIN VINYL (SUNROOF)
5	70062-SH3-000	Valve - RR. DRAIN (SUNROOF)
6	70080-SR3-003	Seal - SUNROOF FRAME
7	70100-SR3-G01	Frame comp - SUNROOF
8	70205-SR3-G01	Seal - SUNROOF PANEL
10	70271-SR3-G01	Holder - FR. SEAL
11	70272-SR3-G01	Holder - R. SEAL
12	70273-SR3-G01	Holder - RR. SEAL
13	70277-SR3-G01	Holder - L. SEAL
14	70291-SR3-003	Bolt - STAY, 6MM
17	70331-SR3-003	Stay - R. ROOF GLASS
18	70333-SR3-013	Slider - R.
19	70334-SR3-003	Slider b - GLASS LIFTER
20	70336-SR3-003	Stay - L. ROOF GLASS
21	70338-SR3-013	Slider - L.
23	70605-SR3-G02	Clip - LINING
24	70609-SR3-G01	Cover - SPRING
25	70615-SR3-G01	Spring - LINING
26	70621-SR3-G02	Lifter - R. LINING
27	70622-SR3-G01	Holder - CLIP
28	70626-SR3-G02	Lifter - L. LINING

Sliding roof (MOTOR) 29

#	OEM	部品名
1	70011-SR3-003	Hinge - TIE
2	70081-SR3-003	Sub seal - FRAME
3	70231-SR3-003	Channel - R. FR. DRAIN
4	70236-SR3-003	Channel - L. FR. DRAIN
5	70240-SR3-G01	Channel comp. - DRAIN
6	70242-SR3-003	Seal - RR. DRAIN CHANNEL MAIN
7	70245-SR3-003	Clip - DRAIN CHANNEL
8	70302-SR3-003	Stopper - FR.
9	70308-SR3-003	Stopper - RR.
10	70310-SR3-003	Rail - R. GUIDE
11	70312-SR3-003	Holder - R. FR. RAIL
12	70313-SR3-003	Holder - R. RR. RAIL
13	70314-SR3-003	Guide - FR. RAIL HOLDER
14	70315-SR3-003	Rail - L. GUIDE
15	70317-SR3-003	Holder - L. FR. RAIL
16	70318-SR3-003	Holder - L. RR. RAIL
17	70319-SR3-003	Cover - SPRING HOOK
18	70332-SR3-003	Slider a - GLASS LIFTER
19	70340-SR3-003	Anchor comp. - R.
20	70345-SR3-003	Anchor comp. - L.
21	70347-SR3-003	Spring - ANCHOR
22	70361-SR3-003	Link - R. SLIDE STOPPER
23	70366-SR3-003	Link - L. SLIDE STOPPER
24	70372-SR3-003	Lifter - R.
25	70377-SR3-003	Lifter - L.
26	70391-SR3-003	Screw - PAN, 5X10
27	70400-SR3-003	Cable assy - SUNROOF
28	70450-SR3-003	Motor assy. - SUNROOF
29	91555-SM4-003	Clip - COUPLER (RED)

Speed sensor 4

#	OEM	部品名
1	78410-SR3-004	Sensor assy - SPEED (NS)
1	78410-SV4-003	Sensor assy - SPEED (MATSUSHITA)
2	78411-SM4-003	Joint - SPEED SENSOR (MATSUSHITA)
3	90302-SA4-003	Nut - SPRING, 4MM

Speedometer component 14

#	OEM	部品名
1	35505-SA5-003	Socket assy, BULB(14V 1.4W) (NS)(BASE:BLACK)
2	35506-SA5-003	Bulb - 14V 1.4W
3	37103-SD2-003	Bulb & socket
4	37106-SJ4-J00	Knob - TRIP
5	37238-SD2-A00	Bulb & socket - T6.5 CAP) (NS) (BASE:BROWN
6	78108-SR3-G01	Panel - PRINT
7	78110-SR3-J03	Case assy.
8	78115-SR3-G12	Speedometer assy
9	78125-SR3-841	Tachometer assy.
10	78130-SR3-E02	Meter assy - FUEL & TEMPERATURE
13	78155-SR3-G12	Visor assy - METER
17	90131-SF4-003	Screw-washer - 3X16 (NS)
18	90132-SM4-003	Screw-washer - 3X16
20	91547-SR3-003	Clamp - WIRE HARNESS

Speedometer components 15

#	OEM	部品名
1	35505-SA5-003	Socket assy, BULB(14V 1.4W) (NS)(BASE:BLACK)
2	35506-SA5-003	Bulb - 14V 1.4W
3	37103-SD2-003	Bulb & socket
4	37106-SJ4-J00	Knob - TRIP
5	37238-SD2-A00	Bulb & socket - T6.5 CAP) (NS) (BASE:BROWN
6	78108-SR3-G01	Panel - PRINT
7	78110-SR3-J03	Case assy.
8	78115-SR3-G12	Speedometer assy
9	78125-SR3-841	Tachometer assy.
10	78130-SR3-E02	Meter assy - FUEL & TEMPERATURE
13	78155-SR3-G32	Visor assy - METER
15	78190-SR3-J03	Srs unit
17	90131-SF4-003	Screw-washer - 3X16 (NS)
18	90132-SM4-003	Screw-washer - 3X16
20	91547-SR3-003	Clamp - WIRE HARNESS

Srs unit 10

#	OEM	部品名
1	77900-SR3-A01	Reel assy - CABLE
2	77907-SL4-N81	Holder - CONNECTOR (5P) (SKY BLUE)
3	77960-SR3-L81	Srs unit
4	77961-SR3-N80	Harness - MAIN (SRS)
5	77963-SR3-L80	Cover - R. SRS UNIT
6	77964-SR3-L80	Cover - L. SRS UNIT
7	77969-SR3-003	Case - CONNECTOR
8	77982-SP0-A81	Holder - COUPLER (3P) (SKY BLUE)
9	90137-SR3-003	Bolt - TORX EARTH, 6X25
10	91540-SV4-003	Clip - HARNESS BAND (NATURAL) (145.2MM)

Starter motor (MITSUBA; 2) 15

#	OEM	部品名
1	31200-P30-005	Motor assy. - STARTER (SM-402-16 N) (MITSUBA)
1	31200-P30-015	Motor assy. - STARTER (SM-402-16 N) (MITSUBA)
2	31202-PR3-004	Bolt - THROUGH (###)
3	31204-P01-305	Gear assy - ###
3	31204-PJ7-903	Gear assy. - PINION (MITSUBA)
4	31206-PR3-004	Yoke assy.
5	31207-PR3-014	Armature assy - ###
6	31208-PT0-005	Plate comp - BRUSH HOLDER
7	31210-P30-005	Switch assy - ###
8	31211-PC2-006	Ring - SQUARE (MITSUBA)
11	31217-PC2-006	Screw-washer - 4X28 (MITSUBA)
12	31235-PT0-005	Cover - TERMINAL (###)
13	31251-PD2-026	Tube - LABYRINTH
14	31252-PD2-006	Rubber - BUSH (MITSUBA)
15	31291-P01-902	Stay assy - ENGINE WIRE HARNESS (###)

Steering column 18

#	OEM	部品名
1	53200-SR3-G00	Column assy - STEERING
1	53200-SR3-020	Column assy - STEERING (TILT)
2	53201-SL4-003	Guide - ABSORBING PLATE
3	53202-SR3-J00	Plate - ABSORBING
4	53216-SR3-000	Holder b - STEERING COLUMN
5	53217-SR3-000	Collar - STEERING RETAINER
6	53320-SR3-A81	Cover - STEERING JOINT
6	53320-SR3-A01	Cover - STEERING JOINT
7	53323-SM4-013	Joint comp. b - STEERING
8	53325-SH3-000	Clip A - JOINT COVER
9	53326-SB0-000	Clip b - JOINT COVER
10	53363-SR3-A01	Pivot comp - COLUMN
11	77873-SP0-A80	Label - STEERING COLUMN CAUTION (ENGLISH/FRENCH)
12	90135-SB0-003	Bolt - STEERING YOKE, 8X28 (NIPPON SEIKO)
13	90361-SR3-000	Nut - FLANGE, 8MM
13	53371-SB3-000	Spring - COLUMN HANGER
14	90511-671-003	Washer - TOOTHED LOCK
15	90654-SR3-003	Clip - STEERING JOINT COVER

Steering wheel 11

#	OEM	部品名
4	78505-SK8-003	Washer a
5	78505-SR3-902	Spacer
6	78506-SK8-003	Washer b
7	78506-SR3-902	Ring - SLIP
8	78507-SR3-902	Plate - CONTACT
9	78508-SR3-902	Plate - HORN
10	78509-SR3-902	Cover - NUT
12	78519-SH3-003	Spring - COIL (TS TECH)
14	90136-SF1-A01	Screw - TAPPING, 4X18 (TS TECH)
15	90171-SK7-003	Screw-washer - 4X10
16	90380-SB2-003	Nut - SELF-LOCK (OHASHI)

Steering wheel (3) 9

#	OEM	部品名
2	77804-SP0-A80	Label - DRIVER MODULE WARNING
3	77894-SP0-A80	Label - DRIVER MODULE DANGER
7	78515-SR4-A81	Plate - CRUISE SWITCH SET
8	78516-SR4-A81	Bracket - CRUISE SWITCH
10	78519-SR3-A02	Lid - CASE
14	78527-SP0-A80	Label - SRS WHEEL NOTICE
15	90123-SR4-003	Screw-washer - 3X8
16	90134-SG0-A81	Bolt - TORX, 6X16
17	90380-SB2-003	Nut - SELF-LOCK (OHASHI)

Switch (1) 6

#	OEM	部品名
1	35145-SR3-901	Frame - TWO KEY
2	35145-SR3-911	Frame - THREE KEY
10	35510-SR3-003	Switch assy - HAZARD
12	35851-SM4-003	Bulb - NEO WEDGE (14V 60MA) (TEC)
13	39700-SR3-003	Clock assy - DIGITAL (NS)
13	39700-SR3-004	Clock assy - DIGITAL (JECO)

Switch (LH) 7

#	OEM	部品名
1	35145-SR3-901	Frame - TWO KEY
2	35145-SR3-911	Frame - THREE KEY
10	35510-SR3-003	Switch assy - HAZARD
11	35820-SR3-G01	Switch assy - HEADLIGHT ADJUSTER (GERMANY)
13	35851-SM4-003	Bulb - NEO WEDGE (14V 60MA) (TEC)
15	39700-SR3-004	Clock assy - DIGITAL (JECO)
15	39700-SR3-003	Clock assy - DIGITAL (NS)

Tailgate 24

#	OEM	部品名
5	62316-679-003	Grommet - SCREW, 4MM
7	68215-SR3-000	Plate - HINGE SET
8	68217-SR3-000	Seal - TAILGATE HINGE
12	73201-SR3-E00	Glass - RR. WINDSHIELD
13	73220-SR3-J00	Garnish - RR. WIPER HARNESS
14	73221-SR3-J00	Garnish - RR. WIPER HARNESS (B)
15	73222-SR3-J00	Garnish - RR. WIPER HARNESS (C)
16	74813-SR3-003	Striker - TAILGATE
17	74820-SR3-003	Stay assy - TAILGATE OPENER
18	74820-SR3-305	Stay assy - TAILGATE OPENER
20	74990-SR3-G10	Garnish - TAILGATE SPOILER CENTER
22	74992-SR3-910	Garnish - R. TAILGATE SPOILER CORNER
24	74993-SR3-910	Garnish - L. TAILGATE SPOILER CORNER
25	74994-SH3-003	Clip - TAILGATE SPOILER
26	74998-SR3-J00	Spacer - TAILGATE SPOILER CORNER
28	90101-SR3-000	Nut - OPENER STAY LOWER PIVOT, 8MM
29	90105-SR3-000	Seal - TAILGATE OPENER STAY & WIPER MOTOR
30	90106-SR3-000	Spacer - TAILGATE OPENER STAY
31	90111-SR3-000	Plate - HINGE & WINDOW ATTACHMENT
32	90112-SR3-000	Bolt - TAILGATE STRIKER, 6MM
33	90114-SR3-000	Spacer - HINGE & WINDOW ATTACHMENT
34	90222-SB4-000	Nut-washer - 6MM
35	90307-SH3-000	Nut - SPOILER CAP, 6MM
37	90502-SR3-000	Plate - HINGE & WINDOW ATTACHMENT

Taillight 30

#	OEM	部品名
1	33301-SA0-741	Bulb (12V 5W) - (12V 5W) (STANLEY)
2	34901-SE3-003	Bulb - 12V 8W
3	33500-SR3-G01	Taillight assy. - R.
4	33501-SR3-G01	Lamp unit - R.
5	33502-SR3-G01	Socket - COUPLER
6	33503-SR3-A01	Gasket - BASE
7	33550-SR3-G01	Taillight assy. - L.
8	33551-SR3-G01	Lamp unit - L.
8	34100-SR3-G01	Light assy - LICENSE (###)
9	34100-SR3-A01	Light assy - LICENSE
10	34101-SR3-A01	Lens
11	34102-SR3-A01	Housing
12	34103-SR3-A01	Packing - LENS
13	34104-SE3-A01	Screw - TAPPING, 4X20
14	34104-SR3-A01	Shade
15	34150-SR3-G01	Light assy - R. LID (###)
16	34151-SR3-G01	Lamp unit - R.
17	34152-SR3-G01	Cord - COUPLER (2)
19	34153-SR3-A01	Gasket - R. BASE
20	34154-SR3-A01	Seal - PACKING
21	34155-SR3-G01	Light assy - L. LID (###)
22	34156-SR3-G01	Lamp unit - L.
23	34157-SR3-G01	Cord - COUPLER (1)
24	34158-SR3-A01	Gasket - L. BASE
25	34304-SH3-A01	Socket comp.
26	34908-634-611	Bulb - 12V 21W) (ECE) (STANLEY
27	34911-634-611	Bulb - 12V 21/5W) (ECE) (STANLEY
28	90301-SE0-902	Nut - SPECIAL, 5MM
29	90521-SE3-003	Grommet - SCREW, 4MM
30	91555-SM4-003	Clip - COUPLER (RED)

Throttle body 21

#	OEM	部品名
1	16016-PM6-005	Screw set
2	16075-PE2-005	O-ring - 31.2X1.9
3	16075-P07-000	O-ring
4	16076-P64-000	O-ring
5	16077-P06-A00	O-ring
6	16078-P06-A00	O-ring - 15.8X1.9
7	16080-P07-000	Screw-washer - 4X16
8	16081-P06-A00	Bolt - FLANGE, 6X40
9	16176-P30-003	Gasket - THROTTLE BODY (ISHINO GASKET)
9	16176-P30-004	Gasket - THROTTLE BODY (NIPPON LEAKLESS)
10	16179-P06-A00	Binder
11	16400-P30-G01	Throttle Body Assy - GR06B
13	16411-P30-000	Stay - THROTTLE WIRE
14	16500-P75-000	Valve assy. - FAST IDLE (AF42C)
15	36138-PM1-G01	Filter assy - SOLENOID VALVE
16	36151-P05-A00	Stay - PURGE CONTROL TUBE
17	36162-PT3-Q01	Valve assy. - PURGE CUT SOLENOID
18	36450-P30-000	Valve assy. - ELECTRONIC AIR CONTROL (KEIHIN)
20	36454-PS4-003	Filter comp - ELECTRONIC AIR CONTROL VALVE (TOYO ROKI)
21	36455-PV0-000	Packing - ELECTRONIC AIR CONTROL VALVE (KEIHIN)
22	37830-P05-A01	Sensor assy - MAP

Throttle body (DOHC VTEC; 1.6L SOHC VTEC) 21

#	OEM	部品名
1	16016-PM6-005	Screw set
2	16075-PE2-005	O-ring - 31.2X1.9
3	16075-P07-000	O-ring
4	16076-P64-000	O-ring
5	16077-P06-A00	O-ring
6	16078-P06-A00	O-ring - 15.8X1.9
7	16080-P07-000	Screw-washer - 4X16
8	16081-P06-A00	Bolt - FLANGE, 6X40
9	16176-P30-003	Gasket - THROTTLE BODY (ISHINO GASKET)
9	16176-P30-004	Gasket - THROTTLE BODY (NIPPON LEAKLESS)
10	16179-P06-A00	Binder
11	16400-P30-G01	Throttle Body Assy - GR06B
14	16411-P30-000	Stay - THROTTLE WIRE
15	16500-P75-000	Valve assy. - FAST IDLE (AF42C)
16	36138-PM1-G01	Filter assy - SOLENOID VALVE
17	36151-P05-A00	Stay - PURGE CONTROL TUBE
18	36162-PT3-Q01	Valve assy. - PURGE CUT SOLENOID
19	36450-P30-000	Valve assy. - ELECTRONIC AIR CONTROL (KEIHIN)
20	36454-PS4-003	Filter comp - ELECTRONIC AIR CONTROL VALVE (TOYO ROKI)
21	36455-PV0-000	Packing - ELECTRONIC AIR CONTROL VALVE (KEIHIN)
22	37830-P05-A01	Sensor assy - MAP

Tire/wheel disk 39

#	OEM	部品名
1	42700-SR3-A51	Disk - WHEEL (15X4T)
3	42700-SR3-N55	Disk - WHEEL (15X5 1/2JJ) (YUNO) (BLACK)
3	42700-SR3-N54	Disk - WHEEL (15X5 1/2JJ) (KANAI) (BLACK)
3	42700-SR3-J51	Disk - WHEEL (15X4T)
4	42751-SR3-B15	Tire - 195/55R15 84V) (DUNLOP
4	42751-SR3-B14	Tire - 195/55R15 84V) (BRIDGESTONE
5	42751-SR3-A52	Tire - T135/70D15) (DUNLOP
5	42751-SF1-601	Tire - T135/70D15) (BRIDGESTONE
6	42753-SH3-003	Valve - RIM (US PACIFIC)
6	42753-SB8-661	Valve - RIM (SCHRADER)
7	42767-SR3-P10	Plate - SPARE TIRE CAUTION (T-TYPE) (PORTUGAL)
8	44727-SH0-A01	Weight - BALANCE (15G) (THOS. SALMON)
8	44724-SH0-A01	Weight - BALANCE (40G) (THOS. SALMON)
8	44726-SH0-A01	Weight - BALANCE (5G) (THOS. SALMON)
8	44723-SH0-A01	Weight - BALANCE (30G) (THOS. SALMON)
8	44722-SH0-A01	Weight - BALANCE (20G) (THOS. SALMON)
8	44730-SH0-A01	Weight - BALANCE (45G) (THOS. SALMON)
8	44725-SH0-A01	Weight - BALANCE (50G) (THOS. SALMON)
8	44721-SH0-A01	Weight - BALANCE (10G) (THOS. SALMON)
8	44728-SH0-A01	Weight - BALANCE (25G) (THOS. SALMON)
8	44729-SH0-A01	Weight - BALANCE (35G) (THOS. SALMON)
8	42767-SH3-E00	Plate - SPARE TIRE CAUTION (T-TYPE)
9	42767-SR3-E10	Plate - SPARE TIRE CAUTION (T-TYPE) (ENGLISH)
10	44728-SB2-003	Weight - BALANCE (25G) (YAMATE)
10	44725-SB2-003	Weight - BALANCE (50G) (YAMATE)
10	44729-SB2-003	Weight - BALANCE (35G) (YAMATE)
10	44730-SB2-013	Weight - BALANCE (45G) (YAMATE)
10	44726-SB2-003	Weight - BALANCE (5G) (YAMATE)
10	44721-SB2-003	Weight - BALANCE (10G) (YAMATE)
10	44722-SB2-003	Weight - BALANCE (20G) (YAMATE)
10	44723-SB2-003	Weight - BALANCE (30G) (YAMATE)
10	44727-SB2-003	Weight - BALANCE (15G) (YAMATE)
10	44724-SB2-003	Weight - BALANCE (40G) (YAMATE)
14	44733-SR3-Z60	Trim - WHEEL (15")
20	44736-SA0-981	Nut - WHEEL (FUSE RASHI)
21	44737-SA0-981	Washer - WHEEL NUT (FUSE RASHI)
22	83850-SD2-000	Plate - ANCHOR BOLT
23	83853-SA7-980	Bolt - ANCHOR (79MM)
24	90304-SA0-981	Nut comp. - WHEEL (FUSE RASHI)

Tools/jack 9

#	OEM	部品名
1	71969-SA7-890	Wrench - SUNROOF
2	89000-SR3-961	Tool set - SUNROOF
3	89101-SH3-000	Bag - TOOL
3	89101-SW5-003	Bag - TOOL
4	89211-SE3-003	Wrench - WHEEL
6	89217-355-000	Wrench - BOX (10MM)
7	89310-SE3-013	Jack assy - PANTOGRAPH
9	89320-SE3-003	Bar - JACK
9	89320-S50-003	Bar - JACK

Transmission housing (2) 59

#	OEM	部品名
1	21104-PS1-020	Plate m - OIL GUIDE
2	21200-P21-040	Case comp. Transmission
2	21200-P21-030	Case comp. - TRANSMISSION
3	21211-P21-300	Plate - OIL GUTTER
4	21221-P21-000	Hanger a - TRANSMISSION
5	21396-P20-000	Cap - BREATHER
5	21396-P80-000	Cap - BREATHER
6	23944-P21-000	Shim n - 72MM(0.99)
6	23971-P21-000	Shim ao - 72MM(1.80)
6	23939-P21-000	Shim i - 72MM(0.84)
6	23966-P21-000	Shim aj - 72MM(1.65)
6	23934-P21-000	Shim d - 72MM(0.69)
6	23961-P21-000	Shim ae - 72MM(1.50)
6	23956-P21-000	Shim z - 72MM(1.35)
6	23951-P21-000	Shim u - 72MM(1.20)
6	23946-P21-000	Shim p - 72MM(1.05)
6	23941-P21-000	Shim k - 72MM(0.90)
6	23968-P21-000	Shim al - 72MM(1.71)
6	23936-P21-000	Shim f - 72MM(0.75)
6	23931-P21-000	Shim a - 72MM(0.60)
6	23963-P21-000	Shim ag - 72MM(1.56)
6	23958-P21-000	Shim ab - 72MM(1.41)
6	23953-P21-000	Shim w - 72MM(1.26)
6	23948-P21-000	Shim r - 72MM(1.11)
6	23943-P21-000	Shim m - 72MM(0.96)
6	23970-P21-000	Shim an - 72MM(1.77)
6	23938-P21-000	Shim h - 72MM(0.81)
6	23965-P21-000	Shim ai - 72MM(1.62)
6	23933-P21-000	Shim c - 72MM(0.66)
6	23960-P21-000	Shim ad - 72MM(1.47)
6	23955-P21-000	Shim y - 72MM(1.32)
6	23950-P21-000	Shim t - 72MM(1.17)
6	23945-P21-000	Shim o - 72MM(1.02)
6	23940-P21-000	Shim j - 72MM(0.87)
6	23967-P21-000	Shim ak - 72MM(1.68)
6	23935-P21-000	Shim e - 72MM(0.72)
6	23962-P21-000	Shim af - 72MM(1.53)
6	23957-P21-000	Shim aa - 72MM(1.38)
6	23952-P21-000	Shim v - 72MM(1.23)
6	23947-P21-000	Shim q - 72MM(1.08)
6	23942-P21-000	Shim l - 72MM(0.93)
6	23969-P21-000	Shim am - 72MM(1.74)
6	23937-P21-000	Shim g - 72MM(0.78)
6	23932-P21-000	Shim b - 72MM(0.63)
6	23964-P21-000	Shim ah - 72MM(1.59)
6	23959-P21-000	Shim ac - 72MM(1.44)
6	23954-P21-000	Shim x - 72MM(1.29)
6	23949-P21-000	Shim s - 72MM(1.14)
7	24452-PB6-020	Spring a - BALL SETTING
8	24519-PB6-000	Screw - BALL SPRING SETTING
9	32746-P21-000	Stay - BACK LIGHT HARNESS
10	35600-P21-003	Switch assy - BACK LIGHT
11	90081-PB6-000	Bolt - PLUG, 14MM
12	90081-PX5-000	Screw - SEALING, 32MM
13	90083-PG1-305	Bolt - SEALING, 16MM
14	90401-PG1-000	Washer - DRAIN PLUG, 10MM
15	91205-PC9-711	Oil seal - 40X62X8 (NOK)
15	91205-PG1-003	Oil seal - 40X62X8 (ARAI)
16	91507-P01-003	Clip b - HARNESS BAND (DARK BROWN) (129.4MM)

Transmission housing (DOHC VTEC) 59

#	OEM	部品名
1	21104-PS1-020	Plate m - OIL GUIDE
2	21200-P21-030	Case comp. - TRANSMISSION
2	21200-P21-040	Case comp. Transmission
3	21211-P21-300	Plate - OIL GUTTER
4	21221-P21-000	Hanger a - TRANSMISSION
5	21396-P20-000	Cap - BREATHER
5	21396-P80-000	Cap - BREATHER
6	23967-P21-000	Shim ak - 72MM(1.68)
6	23935-P21-000	Shim e - 72MM(0.72)
6	23962-P21-000	Shim af - 72MM(1.53)
6	23957-P21-000	Shim aa - 72MM(1.38)
6	23952-P21-000	Shim v - 72MM(1.23)
6	23947-P21-000	Shim q - 72MM(1.08)
6	23942-P21-000	Shim l - 72MM(0.93)
6	23969-P21-000	Shim am - 72MM(1.74)
6	23937-P21-000	Shim g - 72MM(0.78)
6	23964-P21-000	Shim ah - 72MM(1.59)
6	23932-P21-000	Shim b - 72MM(0.63)
6	23959-P21-000	Shim ac - 72MM(1.44)
6	23954-P21-000	Shim x - 72MM(1.29)
6	23949-P21-000	Shim s - 72MM(1.14)
6	23944-P21-000	Shim n - 72MM(0.99)
6	23971-P21-000	Shim ao - 72MM(1.80)
6	23939-P21-000	Shim i - 72MM(0.84)
6	23966-P21-000	Shim aj - 72MM(1.65)
6	23934-P21-000	Shim d - 72MM(0.69)
6	23961-P21-000	Shim ae - 72MM(1.50)
6	23956-P21-000	Shim z - 72MM(1.35)
6	23951-P21-000	Shim u - 72MM(1.20)
6	23946-P21-000	Shim p - 72MM(1.05)
6	23941-P21-000	Shim k - 72MM(0.90)
6	23968-P21-000	Shim al - 72MM(1.71)
6	23936-P21-000	Shim f - 72MM(0.75)
6	23963-P21-000	Shim ag - 72MM(1.56)
6	23931-P21-000	Shim a - 72MM(0.60)
6	23958-P21-000	Shim ab - 72MM(1.41)
6	23953-P21-000	Shim w - 72MM(1.26)
6	23948-P21-000	Shim r - 72MM(1.11)
6	23943-P21-000	Shim m - 72MM(0.96)
6	23970-P21-000	Shim an - 72MM(1.77)
6	23938-P21-000	Shim h - 72MM(0.81)
6	23965-P21-000	Shim ai - 72MM(1.62)
6	23933-P21-000	Shim c - 72MM(0.66)
6	23960-P21-000	Shim ad - 72MM(1.47)
6	23955-P21-000	Shim y - 72MM(1.32)
6	23950-P21-000	Shim t - 72MM(1.17)
6	23945-P21-000	Shim o - 72MM(1.02)
6	23940-P21-000	Shim j - 72MM(0.87)
7	24452-PB6-020	Spring a - BALL SETTING
8	24519-PB6-000	Screw - BALL SPRING SETTING
9	32746-P21-000	Stay - BACK LIGHT HARNESS
10	35600-P21-003	Switch assy - BACK LIGHT
12	90081-PB6-000	Bolt - PLUG, 14MM
13	90081-PX5-000	Screw - SEALING, 32MM
14	90083-PG1-305	Bolt - SEALING, 16MM
15	90401-PG1-000	Washer - DRAIN PLUG, 10MM
16	91205-PG1-003	Oil seal - 40X62X8 (ARAI)
16	91205-PC9-711	Oil seal - 40X62X8 (NOK)
17	91507-P01-003	Clip b - HARNESS BAND (DARK BROWN) (129.4MM)

Trunk box 11

#	OEM	部品名
1	75353-671-000	Lock - SCREW
6	84523-SR3-000	Strap - R. RR. BAGGAGE NET
11	84573-SR3-000	Strap - L. RR. BAGGAGE NET
15	84625-SR3-000	Hinge
16	84629-SR3-000	Stopper - TRUNK BOX
17	84633-SR3-010	Caution - RR. TRUNK BOX
22	90302-SA4-003	Nut - SPRING, 4MM
23	90609-SG0-003	Clip - PILLAR GARNISH
24	90610-SR3-003	Clip - GARNISH (KATO)
25	90674-SK7-000	Clip - SNAP FITTING
26	90683-693-000	Grommet - SCREW, 5MM

Valve/rocker arm (4) 22

#	OEM	部品名
1	12208-PR3-000	Bolt - SEALING, 20MM
2	12209-PR3-000	Washer - SEALING, 20MM
3	12250-PR3-000	Orifice assy - IN. ROCKER SHAFT
4	12260-PR3-000	Orifice assy - EX. ROCKER SHAFT
5	14620-P30-000	Arm assy. - ROCKER
6	14631-PR3-000	Shaft - VALVE ROCKER ARM
7	14711-PR3-000	Valve - IN.
8	14721-PR3-000	Valve - EX.
9	14744-PR3-003	Screw - TAPPET ADJUSTING
10	14751-P30-004	Spring - IN. VALVE INNER (PINK) (CHUO SPRING)
10	14751-P30-003	Spring - IN. VALVE INNER (PINK) (NIPPON HATSUJO)
11	14761-P30-004	Spring - IN. VALVE OUTER (GREEN) (CHUO SPRING)
11	14761-P30-003	Spring - IN. VALVE OUTER (GREEN) (NIPPON HATSUJO)
12	14762-P30-004	Spring - EX. VALVE (PURPLE) (CHUO SPRING)
12	14762-P30-003	Spring - EX. VALVE (PURPLE) (NIPPON HATSUJO)
13	14765-P30-000	Retainer - VALVE SPRING
14	14775-PR3-000	Seat - VALVE SPRING
15	14781-PR7-A01	Valve Cotter
16	14820-P30-000	Motion assy. - LOST
17	90206-590-000	Nut - TAPPET ADJUSTING
17	90206-PT0-004	Nut - TAPPET ADJUSTING
18	91306-PJ4-000	O-ring - 6.8X1.9

Valve/rocker arm (DOHC VTEC) 22

#	OEM	部品名
1	12208-PR3-000	Bolt - SEALING, 20MM
2	12209-PR3-000	Washer - SEALING, 20MM
3	12250-PR3-000	Orifice assy - IN. ROCKER SHAFT
4	12260-PR3-000	Orifice assy - EX. ROCKER SHAFT
5	14620-P30-000	Arm assy. - ROCKER
6	14631-PR3-000	Shaft - VALVE ROCKER ARM
7	14711-PR3-000	Valve - IN.
8	14721-PR3-000	Valve - EX.
9	14744-PR3-003	Screw - TAPPET ADJUSTING
10	14751-P30-004	Spring - IN. VALVE INNER (PINK) (CHUO SPRING)
10	14751-P30-003	Spring - IN. VALVE INNER (PINK) (NIPPON HATSUJO)
11	14761-P30-004	Spring - IN. VALVE OUTER (GREEN) (CHUO SPRING)
11	14761-P30-003	Spring - IN. VALVE OUTER (GREEN) (NIPPON HATSUJO)
12	14762-P30-004	Spring - EX. VALVE (PURPLE) (CHUO SPRING)
12	14762-P30-003	Spring - EX. VALVE (PURPLE) (NIPPON HATSUJO)
13	14765-P30-000	Retainer - VALVE SPRING
14	14775-PR3-000	Seat - VALVE SPRING
15	14781-PR7-A01	Valve Cotter
16	14820-P30-000	Motion assy. - LOST
17	90206-590-000	Nut - TAPPET ADJUSTING
17	90206-PT0-004	Nut - TAPPET ADJUSTING
18	91306-PJ4-000	O-ring - 6.8X1.9

Water hose (4) 6

#	OEM	部品名
1	19506-P75-000	Hose, ELECTRONIC AIR CONTROL VALVE IN.
2	19507-PR3-000	Hose - ELECTRONIC AIR CONTROL VALVE OUTLET
3	19508-P08-000	Hose, BY-PASS OUTLET
4	19513-PE0-003	Clamp - WATER HOSE (21.7MM) (CHUO SPRING)
5	19527-P30-J00	Hose a - BREATHER HEATER
6	19528-P30-J00	Hose b - BREATHER HEATER

Water hose (DOHC VTEC) 10

#	OEM	部品名
1	11108-PR3-010	Joint - OIL COOLER
2	19422-PR3-000	Hose, OIL COOLER IN.
3	19423-PR3-000	Hose, Oil Cooler Outlet
4	19506-P75-000	Hose, ELECTRONIC AIR CONTROL VALVE IN.
5	19507-PR3-000	Hose - ELECTRONIC AIR CONTROL VALVE OUTLET
6	19508-P08-000	Hose, BY-PASS OUTLET
7	19512-PC6-003	Clip - HOSE, 18.7MM
8	19513-PE0-003	Clamp - WATER HOSE (21.7MM) (CHUO SPRING)
11	19527-P30-J00	Hose a - BREATHER HEATER
12	19528-P30-J00	Hose b - BREATHER HEATER

Water pump 16

#	OEM	部品名
2	19200-P30-003	Pump comp - WATER (KEIHIN)
4	19222-P30-003	O-ring - WATER PUMP (KEIHIN)
5	19301-P08-316	Thermostat assy - NIPPON THERMOSTAT
5	19301-PAA-306	Thermostat assy - NIPPON THERMOSTAT
5	19301-P08-305	Thermostat assy - FUJI THOMSON
6	19305-PT0-000	Rubber - THERMOSTAT MOUNTING
6	19305-PLC-A00	Rubber - THERMOSTAT MOUNTING
8	19311-P30-000	Cover - THERMOSTAT
11	19315-P30-J01	Cover - WATER OUTLET
11	19315-P30-J00	Cover - WATER OUTLET
13	19320-P30-J00	Case comp. - THERMOSTAT
14	19500-PE0-000	Joint, Tube
14	19505-PW0-G00	Pipe - CONNECTING
15	19505-PR4-A00	Pipe - CONNECTING
17	19516-PC1-000	Bolt - BREATHING WATER
19	91314-PH7-003	O-ring 31.2X4.1 (NOK)

Water valve 10

#	OEM	部品名
2	79710-SR3-003	Valve assy. - WATER
2	79710-SR3-A01	Valve assy. Water
3	79721-SR3-J30	Hose a - WATER IN.
4	79722-SR3-000	Hose b, WATER IN.
5	79725-SR3-J30	Hose - WATER OUTLET
6	79731-SR3-000	Grommet - HEATER PIPE
7	91405-PK1-003	Clip, WATER HOSE, 24MM
7	19513-PE0-003	Clamp - WATER HOSE (21.7MM) (CHUO SPRING)
9	91553-SK7-003	Clamp - 24X39
10	90361-SV4-003	Nut - PAINT CUTTING, 6MM

Windshield washer 25

#	OEM	部品名
1	38511-SD2-003	Adapter - NOZZLE (MITSUBA)
2	38512-SB0-922	Motor - WASHER (MITSUBA)
3	38512-SF0-013	Motor - WASHER (MITSUBA)
4	38513-SB0-961	Cap - WASHER MOUTH(MITSUBA)
4	76802-SS0-003	Cap - MOUTH
5	38516-SA0-671	Packing - PARALLEL TYPE) (MITSUBA
6	38516-SA5-671	Packing - T-TYPE) (MITSUBA
7	38519-SB0-003	Bush - WASHER TANK (MITSUBA)
8	38562-SA0-003	Joint l - WASHER TUBE(MITSUBA)
9	38562-663-920	Joint b - WASHER TUBE (MITSUBA)
10	38564-SA7-013	Grommet - WASHER TUBE (MITSUBA)
11	76815-SD5-003	Valve - ONE WAY (RR.) (MITSUBA)
12	66427-SA7-000	Cushion - WIRE HARNESS (45X70) (GRAY)
13	76810-SR3-003	Nozzle assy. - R. FR. WASHER
14	76815-SR3-003	Nozzle assy. - L. FR. WASHER
15	76825-SH3-003	Tube a - RR. WASHER
16	76830-SL0-003	Joint y - TUBE (MITSUBA)
18	76841-SR3-C11	Tank
19	76850-SR3-003	Nozzle assy. - RR. WINDSHIELD WASHER
20	76854-SR3-003	Tube - R., 4X8X200
21	90652-SB2-023	Clip - TUBE, 7MM
22	91504-SR3-003	Clip - WASHER TUBE
23	91506-SR3-003	Clip - TUBE WASHER (NATURAL)
24	91512-SE0-003	Clip - WASHER TUBE
25	91531-SL4-J01	Clamp - TUBE, 3.5

Windshield washer/ headlight washer 44

#	OEM	部品名
1	38511-SD2-003	Adapter - NOZZLE (MITSUBA)
2	38512-SB0-922	Motor - WASHER (MITSUBA)
3	38512-SF0-013	Motor - WASHER (MITSUBA)
4	38514-692-731	Bush
5	38516-SA0-671	Packing - PARALLEL TYPE) (MITSUBA
6	38516-SA5-671	Packing - T-TYPE) (MITSUBA
7	76809-SH3-005	Grommet - WASHER TANK
8	38562-SA0-003	Joint l - WASHER TUBE(MITSUBA)
9	38562-663-920	Joint b - WASHER TUBE (MITSUBA)
10	38564-SA7-013	Grommet - WASHER TUBE (MITSUBA)
11	76815-SD5-003	Valve - ONE WAY (RR.) (MITSUBA)
12	38581-671-631	Joint - TUBE
13	76802-SR3-S03	Cap - MOUTH
14	76803-SE1-S03	Clip - WASHER HOSE
15	76806-SM4-E03	Pump - HEADLIGHT WASHER
16	76807-SE1-S01	Cover - MOTOR
17	76810-SR3-003	Nozzle assy. - R. FR. WASHER
18	76815-SR3-003	Nozzle assy. - L. FR. WASHER
19	76825-SH3-003	Tube a - RR. WASHER
20	76826-SH3-S00	Valve - ONE WAY
21	76828-SH3-S03	Joint l
22	76830-SM4-003	Joint y - WASHER
23	76841-SR3-S13	Tank
24	76844-SR3-S03	Bracket
25	76845-SR3-S03	Bracket b
26	76848-SR3-S03	Bracket - PUMP
27	76849-SR3-S03	Stay - COUPLER
28	76850-SR3-003	Nozzle assy. - RR. WINDSHIELD WASHER
29	76854-SR3-003	Tube - R., 4X8X200
30	76871-SR3-S13	Tank assy. - HEADLIGHT WASHER (FR.-RR. H/L 6.5L)
31	76880-SR3-S03	Nozzle assy. - HEADLIGHT WASHER
32	76882-SL0-G03	Clamp - HEADLIGHT WASHER NOZZLE
33	76891-SR3-S03	Hose a
34	76892-SM4-E03	Hose b
35	76893-SR3-S03	Hose c
36	76894-SR3-S03	Hose d
37	76895-SR3-S03	Hose
38	90118-SM5-G03	Bolt-washer - 6MM
39	90316-SM5-G03	Nut - HEX., 6MM
40	90652-SB2-023	Clip - TUBE, 7MM
41	91504-SR3-003	Clip - WASHER TUBE
42	91506-SR3-003	Clip - TUBE WASHER (NATURAL)
43	91512-SE0-003	Clip - WASHER TUBE
44	91561-SR3-003	Clip - HEADLIGHT WASHER HOSE

Wire harness (1) 40

#	OEM	部品名
1	32100-SR3-X03	Harness - CABIN WIRE
2	32108-SR3-G32	Harness - RR. WIRE
3	32113-SR3-A00	Stay - L. COUPLER
4	32114-SR3-000	Bracket - RADIO EARTH
5	32117-SR3-G64	Harness - INSTRUMENT WIRE
6	32119-SR3-G00	Sub cord - TAILGATE
7	32129-SR3-000	Sub cord - RR. WIPER
8	32132-SM4-003	Band - WIRE HARNESS OFFSET (20) (BLACK) (122.5MM)
9	32133-SM4-003	Band - HARNESS OFFSET (30) (YELLOW) (122.5MM)
10	32134-SM4-003	Band - HARNESS OFFSET (10) (BROWN) (122.5MM)
11	32155-SR3-A11	Cord - SUNROOF
12	32200-SR3-B13	Harness - ENGINE ROOM WIRE
13	32601-SR3-003	Cable assy - MISSION EARTH (SUMITOMO)
14	32610-SR3-960	Cable, SUB EARTH (260MM)
15	32751-SR3-G12	Harness - DRIVER DOOR WIRE (R.C. MIRROR)
16	32752-SR3-902	Harness - PASSENGER DOOR WIRE (R.C. MIRROR)
17	72327-SD5-000	Seal b - FR. DOOR HOLE (30X50)
19	90153-SE0-003	Bolt - EARTH, 6X12
20	90154-SD4-003	Bolt - EARTH, 6X20
22	91540-SR3-003	Holder - COUPLER(YELLOW)
23	91540-SV4-003	Clip - HARNESS BAND (NATURAL) (145.2MM)
24	91545-SV4-003	Clip - HARNESS BAND (NATURAL) (145.2MM) (WITH SEAL)
25	91547-SF4-003	Band - WIRE HARNESS (BLUE) (123.5MM)
26	91547-SH3-003	Clip - BAND(NATURAL)(160MM)
28	91549-SD2-003	Clip - WIRE HARNESS (BLACK)
29	91550-SH5-003	Band - HARNESS (NATURAL) (90.4MM)(WITH SEAL)
30	91550-SM4-003	Clip - WIRE HARNESS
31	91551-SF4-003	Band - WIRE HARNESS(BROWN) (110MM)
32	91554-SH3-003	Band - WIRE HARNESS (NATURAL) (100.5MM)
33	91557-SR3-003	Clip - WIRE HARNESS PROTECTOR (RED)
34	91560-SR3-003	Band - HARNESS (NATURAL)(113MM)
37	91570-SH3-003	Band - WIRE HARNESS (NATURAL)
38	91571-SR3-004	Holder - COUPLER
39	91580-SR3-003	Holder - COUPLER (WITH SEAL)
40	91582-SM4-003	Clip - WIRE HARNESS
41	91626-SR3-003	Ring - WIRE HARNESS
42	91637-SF1-003	Cap - 090 2P
43	91763-SH3-003	Bar - JOINT (6P)
44	91786-SR3-003	Bar - JOINT (10P)
45	91902-SB2-003	Cushion - WIRE HARNESS(50X100)

Wire harness (LH) 41

#	OEM	部品名
1	32100-SR4-G11	Harness - CABIN WIRE
2	32108-SR3-G32	Harness - RR. WIRE
3	32113-SR3-A00	Stay - L. COUPLER
4	32114-SR3-000	Bracket - RADIO EARTH
5	32117-SR3-G20	Harness - INSTRUMENT WIRE
5	32117-SR3-G21	Harness - INSTRUMENT WIRE
6	32119-SR3-G00	Sub cord - TAILGATE
7	32129-SR3-000	Sub cord - RR. WIPER
8	32132-SM4-003	Band - WIRE HARNESS OFFSET (20) (BLACK) (122.5MM)
9	32133-SM4-003	Band - HARNESS OFFSET (30) (YELLOW) (122.5MM)
10	32134-SM4-003	Band - HARNESS OFFSET (10) (BROWN) (122.5MM)
11	32155-SR3-A11	Cord - SUNROOF
12	32200-SR3-B32	Harness - ENGINE ROOM WIRE
13	32601-SR3-003	Cable assy - MISSION EARTH (SUMITOMO)
14	32610-SR3-960	Cable, SUB EARTH (260MM)
15	32751-SR3-G12	Harness - DRIVER DOOR WIRE (R.C. MIRROR)
16	32752-SR3-902	Harness - PASSENGER DOOR WIRE (R.C. MIRROR)
17	66427-SA7-000	Cushion - WIRE HARNESS (45X70) (GRAY)
18	72327-SD5-000	Seal b - FR. DOOR HOLE (30X50)
20	90153-SB6-003	Bolt - EARTH, 6X12(ZN)
21	90153-SE0-003	Bolt - EARTH, 6X12
22	90154-SD4-003	Bolt - EARTH, 6X20
24	91540-SR3-003	Holder - COUPLER(YELLOW)
25	91540-SV4-003	Clip - HARNESS BAND (NATURAL) (145.2MM)
26	91545-SV4-003	Clip - HARNESS BAND (NATURAL) (145.2MM) (WITH SEAL)
27	91547-SF4-003	Band - WIRE HARNESS (BLUE) (123.5MM)
28	91547-SH3-003	Clip - BAND(NATURAL)(160MM)
30	91549-SD2-003	Clip - WIRE HARNESS (BLACK)
31	91550-SH5-003	Band - HARNESS (NATURAL) (90.4MM)(WITH SEAL)
32	91550-SM4-003	Clip - WIRE HARNESS
33	91551-SF4-003	Band - WIRE HARNESS(BROWN) (110MM)
34	91554-SH3-003	Band - WIRE HARNESS (NATURAL) (100.5MM)
35	91557-SR3-003	Clip - WIRE HARNESS PROTECTOR (RED)
39	91570-SH3-003	Band - WIRE HARNESS (NATURAL)
40	91571-SR3-004	Holder - COUPLER
41	91582-SM4-003	Clip - WIRE HARNESS
42	91626-SR3-003	Ring - WIRE HARNESS
43	91637-SF1-003	Cap - 090 2P
44	91763-SH3-003	Bar - JOINT (6P)
45	91786-SR3-003	Bar - JOINT (10P)
46	91902-SB2-003	Cushion - WIRE HARNESS(50X100)
