Abs modulator 2

#	OEM	部品名
1	57110-S1A-E01	Modulator assy - ABS
2	57115-S1A-E00	Bracket - MODULATOR

Acoustic cover (DIESEL) 8

#	OEM	部品名
1	10001-P5T-316	Engine assy - BARE
2	11911-P5T-G00	Hanger a - ENGINE
3	11912-P5T-G00	Hanger b - ENGINE
4	11915-P5T-G00	Stay - ENGINE COVER
5	17112-PDD-X10	Cover assy. - ACOUSTIC
6	17115-P5T-G00	Grommet - ACOUSTIC COVER
7	17117-P5T-G00	Seal - ACOUSTIC COVER
8	90501-P5T-G00	Insert - ACOUSTIC COVER

Adaptor (DIESEL) 10

#	OEM	部品名
1	21340-P5T-020	Plate - ADAPTOR
2	21341-P5T-000	Pad - BACKPLATE
3	90001-P5T-000	Bolt - 8X20
4	90002-P5T-000	Bolt - 12X55
5	90003-P5T-000	Bolt - 12X120
6	90004-P5T-000	Bolt - 12X45
7	90005-P5T-000	Bolt - 12X50
8	90006-P5T-000	Bolt - 12X80
9	90701-P5T-000	Dowel pin
10	90703-P5T-000	Dowel pin

Air cleaner (DIESEL) 15

#	OEM	部品名
1	17200-PDD-X01	Cleaner assy - AIR
2	17213-P5T-G00	Grommet
2	17213-PDD-E00	Grommet
3	17220-P5T-G00	Element assy. - AIR CLEANER
4	17227-P5T-G01	Hose - AIR FLOW METER
5	17240-PDD-X01	Case comp. - AIR CLEANER
6	17242-PDD-E00	Tube assy. a - AIR INTAKE
7	17243-PDD-E00	Tube b - AIR INTAKE
8	17244-PDD-E00	Rubber - AIR INTAKE SEAL
9	17246-PDD-E00	Ring - SEAL
10	17247-PDD-E01	Clip - TUBE
11	17261-PDD-X00	Stay assy - AIR CLEANER
12	17262-PDD-E00	Insert - AIR CLEANER STAY
12	17262-P5T-G00	Insert - AIR CLEANER STAY
13	90502-P5T-G00	Collar - MOUNTING

Air conditioner (COMPRESSOR; DIESEL) 6

#	OEM	部品名
1	38800-P5T-G20	Compressor assy
2	38805-P5T-G20	O-ring
3	38809-P5T-G20	Tie - HARNESS
4	53745-S1B-E01	Bracket a - POWER STEERING FEED
5	53747-S1B-E01	Bracket comp. b - POWER STEERING FEED
6	56992-P5T-G20	Belt - DRIVE

Air conditioner (CONDENSER; DIESEL) 23

#	OEM	部品名
1	19015-PDD-E01	Shroud assy. - MAIN
2	19020-PDD-E01	Fan - COOLING
3	19030-PDD-E01	Motor - COOLING FAN
4	19033-PDD-E01	Clip - HARNESS
5	80102-S1B-G01	Bracket
6	80103-S1B-G01	Bracket comp. a - LOWER
7	80104-S1B-G01	Bracket comp. b - LOWER
8	80105-S1B-G01	Bracket comp. a - UPPER
9	80106-S1B-G01	Bracket comp. b - UPPER
10	80107-S1B-G01	Packing a
11	80108-S1B-G01	Packing b
12	80109-S1B-G01	Packing c
13	80110-S1B-G01	Condenser comp.
14	80115-S1B-G00	Seal - R. CONDENSER
15	80116-S1B-G00	Seal - L. CONDENSER
16	80117-S1B-G00	Plate - R. BAFFLE
17	80118-S1B-G00	Plate - L. BAFFLE
18	80175-SE0-000	Mount - CONDENSER
19	90041-PDD-E01	Bolt - FLANGE, 6X14
20	90043-P1K-E01	Nut - HEX., 5MM
21	90044-PDD-E01	Nut - FLANGE, 5MM
22	90657-SH3-013	Clip - TWO WAY VALVE COVER
23	91524-SK7-000	Clip - WASHER NOZZLE

Air conditioner (COOLING UNIT; LH) 24

#	OEM	部品名
1	39246-671-003	Clamp - CASE HOLD
2	39794-S01-A01	Relay assy - POWER (4P) (MICRO ISO) (OMRON)
3	79370-S1A-G01	Filter assy
4	80201-S1A-G01	Case - EVAPORATOR UPPER
5	80202-S1A-G01	Case - EVAPORATOR LOWER
6	80203-S1A-G01	Cover - FILTER
7	80205-S1A-G01	Insulator - EVAPORATOR UPPER
8	80206-S1A-G01	Insulator - EVAPORATOR LOWER
9	80208-S1A-G01	Holder - PIPE
10	80210-S1A-G01	Evaporator comp.
11	80211-S1A-G01	Pipe assy.
12	80220-S0X-A01	Valve - EXPANSION
13	80270-S1A-G01	Packing a
14	80286-S1A-G01	Packing - INNER
15	80287-S1A-G01	Packing - OUTER
16	80288-S1A-G01	Packing b
19	80560-S0X-A01	Thermistor - AIR CONDITIONER
20	80566-SW5-003	Clamp - EVAPORATOR SENSOR
21	80871-SN7-003	O-ring - 5/8"
22	80872-SN7-003	O-ring - 1/2"
23	90121-S1A-G01	Bolt - FLANGE
24	90155-SE0-003	Screw - TAPPING, 6X20
25	90321-SV4-003	Nut-washer - 6MM (PAINT CUTTING)
26	91580-SM4-003	Clip - COUPLER(ORANGE)

Air conditioner (HOSES/PIPES; DIESEL) 19

#	OEM	部品名
1	80050-SP0-000	Label - AIR CONDITIONER CAUTION (HFC134A)
2	80311-S1B-G01	Hose comp. - SUCTION
3	80315-S1B-G31	Hose comp. - DISCHARGE
4	80325-S1B-G01	Pipe - DISCHARGE
5	80331-S1B-G01	Pipe - CONDENSER
6	80341-S1B-G01	Pipe - RECEIVER
7	80351-S1B-G30	Receiver comp
8	80352-S1B-G00	Bracket - LIQUID TANK
9	80365-S1B-G00	Stay - DISCHARGE HOSE
10	80381-SV7-A01	Clamp - RECEIVER PIPE
11	80381-S84-E01	Clamp - RECEIVER PIPE
12	80382-S1B-G30	Stay - AIR CONDITIONER PIPE
13	80384-S1B-G00	Clamp a - SUCTION PIPE
14	80440-S1B-G30	Sensor - PRESSURE
15	80865-SS0-A11	Cap h - VALVE(PARKER)
16	80866-ST7-A11	Cap l - VALVE (PARKER)
17	80871-ST7-000	O-ring - 5/8"
18	80872-ST7-000	O-ring - 1/2"
19	80873-ST7-000	O-ring - 8MM

Air flow sensor (DIESEL) 2

#	OEM	部品名
1	16400-PDD-X00	Sensor assy - AIR FLOW
2	91308-P5T-G00	O-ring

Alloy wheel 15 x 6jj 1

#	OEM	部品名
3	42753-SK3-000	Valve - RIM(A.R.G.)

Alloy wheel 15 x 7jj 1

#	OEM	部品名
3	42753-SK3-000	Valve - RIM(A.R.G.)

Alloy wheel 15x6j 5 double spoke 1

#	OEM	部品名
3	42753-SK3-000	Valve - RIM(A.R.G.)

Alloy wheel 15x6j 5-spoke 2

#	OEM	部品名
3	42753-SH3-003	Valve - RIM (US PACIFIC)
3	42753-SB8-661	Valve - RIM (SCHRADER)

Alloy wheel 15x6j 7-spoke 1

#	OEM	部品名
3	42753-SK3-000	Valve - RIM(A.R.G.)

Alloy wheel 15x7j 7-spoke 1

#	OEM	部品名
3	42753-SK3-000	Valve - RIM(A.R.G.)

Alloy wheel 16x6,5j 5 double spoke 1

#	OEM	部品名
3	42753-SK3-000	Valve - RIM(A.R.G.)

Alloy wheel 16x6.5j 6-spoke twisted 2

#	OEM	部品名
3	42753-SH3-003	Valve - RIM (US PACIFIC)
3	42753-SB8-661	Valve - RIM (SCHRADER)

Alloy wheel 16x7j 7-spoke 1

#	OEM	部品名
3	42753-SK3-000	Valve - RIM(A.R.G.)

Alloy wheel 16x7j 9 double spoke 1

#	OEM	部品名
3	42753-SK3-000	Valve - RIM(A.R.G.)

Alternator (DIESEL) 4

#	OEM	部品名
1	31100-P5T-G21	Alternator assy.
2	31160-P5T-G20	Pump assy. - VACUUM
3	31161-P5T-G00	Bolt set - VACUUM PUMP
4	31165-P5T-G21	Bracket - ALTERNATOR SUPPORT

Auto radio 2

#	OEM	部品名
2	39105-S1A-G00	Bracket - R. RADIO
3	39106-S1A-G00	Bracket - L. RADIO

Battery (DIESEL) 17

#	OEM	部品名
1	31500-S1B-G01	Battery assy - YUASA
2	31510-S37-D00	Cover - BATTERY TERMINAL
3	31512-S37-D00	Clamp - BATTERY
4	31521-S1B-000	Box - BATTERY
5	31542-ST3-E01	Plug - VENT (MF) (YUASA)
6	32115-P64-003	Holder - CORRUGATED (DARK BLUE) (10MM)
7	32116-P64-003	Holder - CORRUGATED (DARK GREEN) (13MM)
8	32410-S1B-G00	Cable assy - STARTER
9	32412-S1B-G00	Bracket - STARTER CABLE
10	32415-S1B-000	Bracket a - STARTER CABLE
11	32416-S1B-000	Bracket b - STARTER CABLE
12	32600-S1B-G00	Cable assy - EARTH
13	32601-SK7-900	Bolt - BATTERY TERMINAL
14	32602-SK7-900	Nut - BATTERY TERMINAL
15	90114-SM4-900	Bolt - 6X15
16	90149-SE0-003	Bolt - EARTH, 6X16
17	91540-S30-003	Clip - HARNESS BAND(NATURAL) (151.5MM)

Brake lines (ABS; LH) 25

#	OEM	部品名
1	46330-S1A-E01	Pipe comp. c - BRAKE
3	46340-S1A-E01	Pipe comp. d - BRAKE
5	46376-S1B-G00	Pipe comp. w - BRAKE
6	46375-S1B-G00	Pipe comp. v - BRAKE
7	46374-S1B-G00	Pipe comp. u - BRAKE
8	46377-S1A-E01	Pipe comp. x - BRAKE
9	46378-S1B-E00	Pipe comp. y - BRAKE
10	46379-S1B-E00	Pipe comp. z - BRAKE
11	46380-SB0-000	Grommet a - BRAKE PIPE (BLACK)
12	46391-SX8-T01	Clip - BRAKE PIPE
15	46393-S1A-E00	Clamp - BRAKE PIPE
16	46394-S04-003	Clip A
17	46395-SM4-951	Clip - BRAKE PIPE
19	46396-S1B-003	Clip - BRAKE PIPE
20	46396-S84-A01	Clip - BRAKE PIPE
21	46410-S1A-E01	Hose - R. FR. BRAKE
22	46411-S1A-E01	Hose - L. FR. BRAKE
23	46430-S1A-E01	Hose - R. RR. BRAKE (DISK)
25	46431-S1A-E01	Hose - L. RR. BRAKE (DISK)
26	46435-S1A-E00	Bracket a - R. RR. BRAKE HOSE
27	46436-S1A-E00	Bracket a - L. RR. BRAKE HOSE
29	46462-SE0-000	Bolt - OIL
30	46470-S1A-E01	Joint - 4WAY
31	46472-568-000	Packing - OIL BOLT
32	90651-SN7-003	Clip - BRAKE HOSE

Brake master cylinder/ master power (DIESEL) 21

#	OEM	部品名
1	01469-S1B-E00	Power set - MASTER (7"+8")
2	46070-SL0-G01	Plate - SYMBOL MARK
3	46100-S1A-G01	Cylinder assy. - MASTER
4	46120-S84-A51	Piston assy. - PRIMARY
5	46122-S84-A51	Piston assy. - SECONDARY
6	46151-SB2-003	Yoke - PUSH ROD (NISSIN)
7	46182-S84-A51	Circlip
8	46185-S04-J01	Seal - ROD
9	46191-S50-003	Packing - MASTER POWER
10	46402-S1B-G01	Tube assy - MASTER POWER
11	46403-S1B-E00	Joint - THREE WAY
12	46406-S1A-E00	Stay - MASTER POWER TUBE
13	46407-S84-A01	Clamp - TUBE
14	46512-SB2-000	Pin - PEDAL
15	46660-S1A-003	Reservoir comp.
16	46662-S1A-003	Cap comp. - RESERVE TANK
17	46665-S04-J01	Grommet
18	46666-SE3-013	Filter - MASTER CYLINDER
19	46669-SE3-003	Seal - RESERVE TANK
20	53729-671-003	Clamp d - 15.5MM
21	57515-S30-003	Pin - STOP

Bumpers 15

#	OEM	部品名
2	71111-S1A-E00	Spoiler - FR. AIR
9	71598-SL4-013	Spacer - BUMPER SIDE
10	71598-S30-013	Spacer assy. - RR. BUMPER SIDE
12	90106-SW3-003	Grommet - BUMPER SETTING
13	90108-SW3-003	Clip - BUMPER SETTING
14	90109-SL9-000	Screw - TAPPING, 5X16
15	90109-SS0-000	Screw - TAPPING, 5X20
16	90111-SM4-003	Bolt - BUMPER
19	90301-SP0-003	Nut - PAINT CUTTING, 6MM
20	90302-SD2-003	Nut-washer - 8MM
21	90305-SM4-000	Nut - AIR SPOILER CLIP
22	91501-S1A-E01	Grommet - BUMPER SIDE
23	91502-S1A-E01	Grommet - BUMPER END
24	91503-SZ3-003	Clip A
25	91503-SZ5-003	Clip - BUMPER FACE

Camshaft cover (DIESEL) 6

#	OEM	部品名
1	12310-P5T-G00	Cover - CAMSHAFT
2	12341-P5T-G01	Gasket - CAMSHAFT COVER
3	15610-P5T-G00	Cap assy. - OIL FILLER
4	15611-P5T-G00	Seal - OIL FILLER CAP
5	17137-P5T-G00	Valve - BREATHER
6	17138-P5T-G00	Hose - BREATHER

Center armrest 2

#	OEM	部品名
2	83407-SN7-E00	Hinge assy - RR. CONSOLE
3	83408-SN7-E00	Lock

Clutch (DIESEL) 6

#	OEM	部品名
1	22100-P5T-000	Flywheel comp.
3	22200-P5T-000	Disk comp - FRICTION
4	22300-P5T-000	Disk comp - PRESSURE
5	22810-P6A-000	Bearing - CLUTCH RELEASE
6	90011-P5T-000	Bolt - 12MM
7	90702-P5T-000	Dowel pin

Clutch case (DIESEL) 13

#	OEM	部品名
1	20011-P6A-030	Transmission assy.
2	21000-P6A-010	Case comp. - CLUTCH
3	21101-P6A-000	Plate - NEEDLE SETTING
4	21103-PG1-L60	Plate c - OIL GUIDE
5	21106-P6A-000	Bush kit - CLUTCH
6	21120-PG1-L60	Magnet - TRANSMISSION
7	90701-P6A-000	Dowel pin - 14X20
8	91002-P6A-000	Bearing - BALL, 63/28C
9	91101-P6A-000	Bearing - NEEDLE, 33X60X22
10	91205-P6A-010	Oil seal - 40X62X9
11	91208-P6A-000	Dust seal - 18X23X4
12	91215-P6A-000	Oil seal - 14X25X16
13	91216-P6A-000	Oil seal - 28X43X7

Clutch master cylinder (DIESEL) 28

#	OEM	部品名
1	46151-SA5-003	Yoke comp. - NISSIN
2	46182-500-013	Circlip
3	46912-SD4-000	Pin - CLUTCH PEDAL
4	46918-SM4-020	Clip a13 - TUBE
5	46920-S04-C01	Cylinder assy. - CLUTCH MASTER
6	46926-SF1-003	Piston assy.
7	46928-SF1-000	Seal - CLUTCH MASTER CYLINDER
8	46930-S37-000	Cylinder assy. - SLAVE
9	46950-SL4-003	Rod assy - PUSH
10	46952-SD4-003	Joint - TUBE
11	46953-SD4-003	Packing
12	46960-S1B-D01	Pipe comp - CLUTCH
13	46960-S1B-G02	Pipe comp - CLUTCH
14	46961-S37-000	Hose - CLUTCH
15	46966-S1B-A03	Holder - TANK
16	46970-S1B-000	Pipe comp - CLUTCH
17	46971-S1B-G00	Tube - CLUTCH FLUID
18	46972-SD4-003	Tank - CLUTCH FLUID
19	46973-SD4-003	Cap comp. - RESERVE TANK
20	46985-S37-000	Damper - CLUTCH
21	46993-S1B-D00	Damper assy. - CLUTCH
22	46994-S1B-000	Washer - PLAIN, 6MM
23	46995-S1B-D01	Bracket - DAMPER
24	46997-S04-C01	Clip A - PIPE (BLACK)
25	46998-SM4-000	Clamp - CLUTCH PIPE
26	90100-S37-000	Clip - SPRING
27	90651-SN7-003	Clip - BRAKE HOSE
28	91565-SK7-003	Clip - WASHER TUBE

Clutch release (DIESEL) 4

#	OEM	部品名
1	22821-P6A-000	Fork - CLUTCH RELEASE
2	22830-P6A-000	Shaft comp. - RELEASE
3	90029-PG1-L60	Bolt - SPECIAL, 8X28
4	90412-PG1-L60	Washer - CONICAL SPRING, 8MM

Combination meter components 17

#	OEM	部品名
1	35505-SA5-003	Socket assy, BULB(14V 1.4W) (NS)(BASE:BLACK)
2	35505-SJ4-003	Socket assy - BULB (14V 3W)
4	37115-SA0-601	Packing - NS
5	78110-S1A-E01	Case assy.
6	78120-S1B-G01	Speedometer assy
7	78125-S1B-E01	Tachometer assy.
8	78130-S1B-E01	Meter assy - FUEL & TEMPERATURE
9	78145-S1A-003	Knob - ILLUMINATION CONTROL
10	78146-S1B-G01	Panel - COMBINATION PRINT
11	78150-S0A-003	Shaft - TRIP RESET
12	78151-S1A-E01	Pipe - SHAFT
13	78155-S1A-E01	Visor
14	78166-S1A-E01	Cover
15	78170-S1A-E01	Lens - METER
17	78181-SS0-003	Socket assy - BULB (14V 1.12W)
18	78181-S1A-E01	Socket assy - BULB (9.5V)
22	78150-S1A-E01	Shaft - TRIP RESET

Combination switch 29

#	OEM	部品名
1	04809-S37-D00	Key & unit assy. - IMMOBILIZER (SERVICE)
2	06350-S1B-G10	Cylinder set - KEY
2	06350-S1B-G00	Cylinder set - KEY
3	35100-S1B-G11	Lock assy - STEERING
3	35100-S1B-G01	Lock assy - STEERING
4	35102-SN7-G01	Bolt - BREAK HEAD
5	35103-SE3-003	Screw - RECESSED, 3X8
6	35103-SN7-G01	Screw - FIXING
8	35107-S1A-G01	Holder - BULB
9	35108-S1A-003	Holder - COLUMN
11	35110-S1B-G01	Receiver comp - IMMOBILISER
12	35113-SN7-G00	Key - BLANK (IMMOBILIZER) (MAIN)
15	35130-S1A-G01	Switch comp - STEERING
16	35132-SN7-G01	Clip
17	35135-S1A-G11	Cord assy - SWITCH
17	35135-S1A-G01	Cord assy - SWITCH
18	35251-S1A-E01	Body - SWITCH
19	35255-S1A-E01	Switch assy - LIGHTING
20	35256-SN7-E01	Switch assy - WIPER
21	35400-S0A-003	Switch assy - DOOR
22	35409-S0A-003	Screw - FLANGE, 4X12
23	35505-SN7-G11	Bulb - 14V 1.4W
25	39731-ST3-E00	Bracket - IMMOBILIZER
27	72146-S1A-G01	Cover - BATTERY
28	72147-S1A-G01	Transmitter assy - KEYLESS (2BUTTONS)
28	72147-S1A-307	Transmitter assy - KEYLESS (2BUTTONS) (FRANCE)
29	72148-S10-003	Battery - CR2025
29	72148-S84-A10	Battery - CR2025
30	72149-S10-003	O-ring

Console (1) 16

#	OEM	部品名
1	35505-ST3-E01	Bulb - T5 1.2W
2	39600-S1A-E01	Lighter assy - CIGARETTE
3	39610-ST3-E01	Knob comp. - CIGARETTE LIGHTER
4	39613-S1A-E01	Harness comp.
5	39614-S1A-E01	Ring assy - ILLUMINATION
7	77286-S1A-E21	Fabric - NON WOVEN
8	77287-S1A-E01	Stopper - CLOSE
15	83405-S1A-E00	Mat - PEN SPACE TRAY
16	83406-S1A-E00	Mat - CUP HOLDER TRAY (1)
17	83407-S1A-E00	Mat - CUP HOLDER TRAY (2)
18	83408-S1A-E00	Mat - TRAY BOX
22	88324-ST3-E00	Cover - RR. ASHTRAY
23	90606-SN7-E00	Spring - FR. ASHTRAY
24	90666-S84-A01	Clip - SNAP FITTING
25	91640-SM4-003	Grommet - SCREW, 4MM
26	91641-SM4-003	Grommet - SCREW, 4MM

Control unit (CABIN; LH) 15

#	OEM	部品名
1	30505-SL5-003	Condenser comp. - TEC) (N-1691/250-0.47
8	37820-PDD-X00	Control module - ENGINE (EU2000)
9	37822-PDD-X00	Bracket comp. - ENGINE CONTROL MODULE
10	37825-PDD-X00	Bracket c - ENGINE CONTROL MODULE
13	38200-S1A-G01	Box assy - FUSE (DRIVER SIDE)
14	38210-S1B-G01	Box assy - FUSE (PASSENGER SIDE)
15	38211-S1A-G00	Bracket - FUSE BOX (AS)
16	38300-SK3-G01	Relay assy - TURN SIGNAL & HAZARD
19	38385-S84-G01	Keyless unit
20	38800-S1A-G01	System unit - MULTIPLEX CONTROL (DRIVER SIDE)
21	38850-S1A-G02	System unit - MULTIPLEX CONTROL (PASSENGER SIDE)
23	39792-SM4-004	Relay assy - POWER (4P) (OMRON) (G4R-1A21T-49H)
24	39794-S1A-G01	Relay assy - POWER (4P) (MICRO ISO) (BOSCH)
24	39794-S01-A01	Relay assy - POWER (4P) (MICRO ISO) (OMRON)
28	91755-SX0-010	Bracket - RELAY BLOCK (ISO)

Control unit (ENGINE ROOM; LH) 29

#	OEM	部品名
1	32743-PDD-E00	Stay c - ENGINE WIRE HARNESS
6	38150-S0A-003	Horn assy - HIGH (MITSUBA)
7	38213-SM4-003	Fuse - BLOCK (50A)
8	38214-SS1-003	Fuse - BLOCK (60A)
9	38218-SM4-003	Fuse - BLOCK (100A)
10	38231-S04-003	Fuse - BLOCK (30A)
11	38231-S04-961	Fuse - BLOCK (40A)
12	38235-S04-003	Puller - MINI FUSE (SUMITOMO)
13	38244-S1B-G01	Case - SUB FUSE (1P)
14	38246-S1B-G01	Cover - UPPER
15	38247-S0A-003	Cover - LOWER
16	38250-S1B-G01	Box assy - RELAY
17	38251-S1B-G01	Cover - UPPER
18	38251-S1B-G10	Bracket - RELAY BOX
19	38252-S1A-G01	Cover - LOWER
20	38252-S1A-G02	Bracket - RELAY BOX
21	39420-S37-D00	Control unit - RADIATOR FAN
22	39421-S1B-G00	Bracket - RADIATOR FAN UNIT
23	39792-SE0-003	Relay assy - POWER(4P)(DENSO) (056700-7410)
23	39792-SE0-004	Relay assy - POWER (4P) (OMRON) (G4R-1A21T-H22)
24	39792-S37-D01	Relay - NORMAL OPEN (GLOW PLUG)
25	39793-SV4-003	Relay assy - POWER (5P) (MITSUBA)
26	39794-S1A-G01	Relay assy - POWER (4P) (MICRO ISO) (BOSCH)
26	39794-S01-A01	Relay assy - POWER (4P) (MICRO ISO) (OMRON)
27	90114-SM4-900	Bolt - 6X15
28	90129-SP0-000	Screw-washer - 5X12
29	90129-S84-000	Screw-washer - 5X14
30	90150-S84-003	Bolt - EARTH, 8X16
31	91551-SV4-003	Clip - BRACKET

Countershaft (DIESEL) 21

#	OEM	部品名
1	23220-P6A-000	Countershaft comp.
2	23421-PG1-G60	Gear - COUNTERSHAFT LOW
3	23431-P6A-000	Gear - COUNTERSHAFT SECOND
4	23461-P6A-000	Gear - COUNTERSHAFT FIFTH
5	23471-PG1-K60	Gear - COUNTERSHAFT THIRD
6	23481-PG1-L60	Gear - COUNTERSHAFT FOURTH
7	23521-P6A-315	Sleeve set - SYNCHRONIZER (1-2)
8	23912-P6A-000	Collar a - DISTANCE, 36X44X29
8	23913-P6A-000	Collar b - DISTANCE, 36X44X29
9	23922-PG1-L60	Washer b - 40X54X1.99
9	23924-PG1-L60	Washer d - 40X54X2.05
9	23921-PG1-L60	Washer a - 40X54X1.96
9	23923-PG1-L60	Washer c - 40X54X2.02
9	23925-PG1-L60	Washer e - 40X54X2.08
10	23926-PG1-L60	Washer - SPRING, 23MM
11	90201-PG1-L60	Nut - HEX., 23MM (L)
12	90602-PG1-K30	Ring - SNAP, 56MM
13	91003-P6A-000	Bearing - SPECIAL BALL
14	91102-P6A-000	Bearing - NEEDLE, 25X56.4X19
15	91105-PG1-L60	Bearing - NEEDLE, 40X46X29
16	91106-PG1-L60	Bearing - NEEDLE, 44X50X29

Cylinder block/piston/ crankshaft (DIESEL) 28

#	OEM	部品名
1	06133-P5T-G01	Crankshaft kit
2	10002-P5T-G00	General assy. - CYLINDER BLOCK
3	11000-P5T-G00	Block assy - CYLINDER
4	11300-P5T-G00	Cover assy. - R. SIDE
5	11301-P5T-G01	Plug - OIL PRESSURE
6	13000-P5T-G00	Piston assy.
7	13011-P5T-G00	Ring set - PISTON
8	13205-P5T-G00	Nut - CONNECTING ROD
9	13210-P5T-G01	Rod comp - CONNECTING
10	13213-P5T-G01	Bolt - CONNECTING ROD
11	13220-P5T-G01	Bearing set - CONNECTING ROD
12	13312-P5T-G00	Circlip - PISTON
13	13320-P5T-G00	Bearing set - MAIN
14	13330-P5T-G00	Bearing set - THRUST
15	15140-P5T-G00	Orifice assy - OIL CONTROL
16	15141-P5T-G00	Orifice assy - OIL CONTROL
17	15280-P5T-G00	Jet assy - OIL
18	19517-P5T-G01	Joint - TUBE
19	90001-P5T-G00	Bolt
20	90004-P5T-G00	Bolt
21	90701-P5T-G00	Dowel pin
22	90702-P5T-G00	Dowel pin
23	90703-P5T-G00	Dowel pin
24	90704-P5T-G00	Dowel pin
25	90705-P5T-G00	Dowel pin
26	90707-P5T-G00	Ring - DOWEL
27	90801-P5T-G00	Plug - CORE WATER
29	90001-PDD-X00	Plug - COOLANT DRAIN

Cylinder head (DIESEL) 24

#	OEM	部品名
1	10003-P5T-G00	General assy. - CYLINDER HEAD
2	12100-P5T-G01	Head assy - CYLINDER
3	12202-P5T-G00	Seat - IN. VALVE
4	12203-P5T-G00	Seat - EX. VALVE
5	12204-P5T-G00	Guide - VALVE
6	12251-P5T-G00	Gasket - CYLINDER HEAD (1.05MM)
6	12251-P5T-G20	Gasket - CYLINDER HEAD (1.35MM)
6	12251-P5T-G10	Gasket - CYLINDER HEAD (1.25MM)
7	14410-P5T-G00	Camshaft
8	14711-P5T-G01	Valve - IN.
9	14721-P5T-G01	Valve - EX.
10	14751-P5T-G00	Tappet - VALVE
11	14761-P5T-G00	Spring - IN. VALVE
12	14765-P5T-G00	Retainer - VALVE SPRING
13	14775-P5T-G00	Seat - VALVE SPRING
14	14781-P5T-G00	Cotter - VALVE
15	90003-P5T-G00	Bolt - CYLINDER HEAD
16	90005-P5T-G00	Bolt - STUD
17	90016-P5T-G00	Bolt - PLUG, 14MM
18	90402-P5T-G00	Washer - OIL DRAIN PLUG
19	90706-P5T-G00	Dowel pin
20	90803-P5T-G00	Plug - CORE
21	91201-P5T-G00	Oil seal - CAMSHAFT
23	14411-PDD-X00	Pin - SPIRAL

Differential gear (DIESEL) 25

#	OEM	部品名
1	41100-P6A-000	Differential comp.
2	41221-P6A-000	Gear - DIFFERENTIAL SIDE
3	41233-P6A-000	Gear - FINAL DRIVEN
4	41311-P6A-010	Case - DIFFERENTIAL
5	41312-P6A-000	Gear - SPEEDOMETER DRIVE
6	41321-P6A-000	Shaft - PINION
7	41341-P6A-000	Pinion - DIFFERENTIAL
8	41354-PG1-L60	Washer d - DIFFERENTIAL PINION THRUST (0.85MM)
8	41356-PG1-L60	Washer f - DIFFERENTIAL PINION THRUST (0.95MM)
8	41351-PG1-L60	Washer a - DIFFERENTIAL PINION THRUST (0.7MM)
8	41358-PG1-L60	Washer h - DIFFERENTIAL PINION THRUST (1.05MM)
8	41353-PG1-L60	Washer c - DIFFERENTIAL PINION THRUST (0.8MM)
8	41355-PG1-L60	Washer e - DIFFERENTIAL PINION THRUST (0.9MM)
8	41357-PG1-L60	Washer g - DIFFERENTIAL PINION THRUST (1.0MM)
8	41352-PG1-L60	Washer b - DIFFERENTIAL PINION THRUST (0.75MM)
9	41371-PG1-L60	Washer - THRUST, 30.5X53X1.5
10	90017-PG1-K30	Bolt - SPECIAL, 11MM
11	90417-PG1-L60	Ring - SET, 80X2.8
11	90419-PG1-L60	Ring - SET, 80X3.0
11	90414-PG1-L60	Ring - SET, 80X2.5
11	90416-PG1-L60	Ring - SET, 80X2.7
11	90418-PG1-L60	Ring - SET, 80X2.9
11	90415-PG1-L60	Ring - SET, 80X2.6
12	90703-P6A-F00	Pin - SPRING, 4X32
13	91005-P6A-000	Bearing - BALL, 6208C

Duct (LH) 11

#	OEM	部品名
1	77410-S1A-G01	Duct assy - AIR CONDITIONER CENTER (LH)
2	77412-S1A-E01	Seal a
3	77413-S1A-E01	Seal b
4	77420-S1A-G01	Duct assy - DRIVER SIDE AIR CONDITIONER (LH)
5	77422-S1A-E01	Seal a
6	77430-S1A-G01	Duct assy - PASSENGER SIDE AIR CONDITIONER (LH)
7	77432-S1A-E01	Seal a
8	77433-S1A-E01	Seal b
10	77468-S1A-E01	Seal
11	83331-S1A-E00	Duct - RR. HEATER
12	91560-SK3-E00	Clip - ROOF LINING, 8MM

Egr valve pipe (DIESEL) 3

#	OEM	部品名
1	17343-PDD-X00	Pipe assy. - EGR VALVE
2	17349-PDD-X00	Pipe assy. - VACUUM SOLENOID
3	17417-PDD-X00	Pipe assy. - BOOST SENSOR

Emblems 12

#	OEM	部品名
1	17275-PDD-X00	Label - SMOKE
3	17669-S37-E30	Label - FUEL FILLER CAUTION
4	19018-P42-G00	Mark - FAN CAUTION
5	42760-S1B-E00	Plate - TIRE PRESSURE CAUTION
6	75701-S1A-E10	Emblem - RR. CENTER (H)
7	75711-S1A-E00	Emblem - RR. (HONDA)
9	75722-S1A-E00	Emblem - RR. (ACCORD)
12	75731-S1A-E20	Emblem - RR. (2.0I)
16	75733-S1B-E30	Emblem - RR. (TD)
18	77875-S84-G80	Label - SRS CAUTION
20	78527-S04-G80	Label - SRS CAUTION (CHILD SEAT)
21	81459-S84-G00	Label - PRETENSIONER CAUTION

Engine mounts (DIESEL) 19

#	OEM	部品名
1	50805-S1B-E01	Rubber assy. - TRANSMISSION MOUNTING
2	50806-S1B-E00	Rubber - MISSION STOPPER INSULATOR
3	50807-S1B-E01	Mass - WEIGHT
4	50807-S74-E00	Stopper b - MOUNTING RUBBER
5	50820-S1B-E01	Rubber - ENGINE SIDE MOUNTING
6	50821-S1B-E00	Bracket assy - SIDE MOUNTING
7	50822-S1B-E00	Damper - ENGINE SIDE DYNAMIC
8	50822-S1B-E10	Damper - MISSION MOUNT DYNAMIC
9	50823-S1B-E00	Rubber assy. - SIDE MOUNTING
10	50825-S1B-E00	Bracket - TRANSMISSION MOUNTING
11	50826-S1B-E00	Rubber - SIDE MOUNTING
12	50830-S1B-E00	Rod assy - FR. TORQUE
13	50831-S1B-E00	Bracket - FR. TORQUE ROD
14	50833-S37-000	Insulator a - TORQUE ROD
15	50834-S37-000	Insulator b - TORQUE ROD
16	50835-S1B-E00	Mass - TORQUE ROD UPPER
17	50838-S1B-E00	Mass - SIDE ENGINE MOUNTING
18	50850-S1B-E00	Rod assy - ENGINE SIDE TORQUE
19	90166-SR3-000	Bolt - FLANGE, 10X30

Engine wire harness (DIESEL) 17

#	OEM	部品名
1	32110-PDD-X20	Harness - ENGINE WIRE
2	32115-P64-003	Holder - CORRUGATED (DARK BLUE) (10MM)
3	32118-P72-003	Holder - CORRUGATED(DARK GREEN) (19MM)
4	32121-PAA-A01	Plate - WIRE HARNESS GROMMET
5	32132-SM4-003	Band - WIRE HARNESS OFFSET (20) (BLACK) (122.5MM)
6	32134-SM4-003	Band - HARNESS OFFSET (10) (BROWN) (122.5MM)
7	32741-PCA-000	Clamp a - ENGINE WIRE HARNESS
8	32741-PDA-G00	Clamp a - ENGINE WIRE HARNESS
9	32742-PDD-X00	Stay b - ENGINE WIRE HARNESS
10	90361-SV4-003	Nut - PAINT CUTTING, 6MM
11	90674-SL0-003	Band - INSERT WIRE
12	91506-P01-003	Clip A - HARNESS BAND (DARK GRAY) (129.4MM)
13	91540-SV4-003	Clip - HARNESS BAND (NATURAL) (145.2MM)
14	91547-SF4-003	Band - WIRE HARNESS (BLUE) (123.5MM)
15	91558-SJ6-003	Strap - HARNESS (30) (BLACK) (107.5MM)
16	91559-PAA-A01	Clip - HARNESS BAND(GRAY) (150MM)
17	91567-SE0-003	Band - WIRE HARNESS(WHITE) (93.5MM)

Exhaust pipe (DIESEL) 16

#	OEM	部品名
1	18030-S1B-E00	Silencer set - R. EX.
2	18035-S1B-E00	Silencer set - L. EX.
3	18160-PDD-X00	Converter comp.
4	18210-S1B-X02	Pipe a - EX.
5	18393-S37-G00	Gasket - EX. PIPE
6	18215-S84-A20	Rubber - EX. MOUNTING
7	18215-S1B-X00	Rubber - EX. MOUNTING
8	18220-S1B-X01	Pipe b - EX.
9	18282-S1B-E00	Bracket b - FLEXIBLE MOUNTING
10	18303-SM4-020	Gasket - SILENCER
11	18212-S1B-E01	Gasket - EX. PIPE
12	74601-S1B-E00	Plate - FLOOR HEAT BAFFLE
13	74651-S1A-E00	Plate - FUEL TANK BAFFLE
14	90212-S37-G00	Nut - SELF-LOCK
15	90212-671-005	Nut - SELF-LOCK, 10MM
16	90301-SV7-000	Nut - PAINT CUTTING, 6MM

Floor mat 12

#	OEM	部品名
1	46992-SV4-003	Clip - FOOTREST
2	74251-S1B-G00	Insulator - DASHBOARD LOWER OUTER
4	74255-S1A-G00	Stopper - FOOTREST
5	74256-S1A-G00	Stopper - TOE
6	74260-S1A-G00	Insulator - DASHBOARD
6	74260-S1A-G10	Insulator - DASHBOARD
15	90121-SJ6-003	Bolt - FLANGE, 6X14
19	90676-SE0-003	Clip - JOINT COVER PLATE
20	91517-SE0-003	Clip - LOWER OUTER DASHBOARD INSULATOR
21	91546-SM4-003	Plug - DASHBOARD INSULATOR BLIND (12MM)
22	91547-SM4-003	Cap - INSULATOR
23	91560-S04-003	Clip - SIDE GARNISH (NATURAL)

Fr fog light 6

#	OEM	部品名
2	33901-S1A-G00	Light unit - R. FOG
3	33951-S1A-G00	Light unit - L. FOG
4	33905-S1A-G00	Bracket - R. FR. FOG LIGHT
5	33955-S1A-G00	Bracket - L. FR. FOG LIGHT
8	35180-S1A-E01	Switch assy - FR. FOG
9	39797-SE0-004	Relay assy - POWER (4P) (MITSUBA) (RC-2201)

Front brake 21

#	OEM	部品名
1	01463-S1A-E02	Caliper set - FR. (LUCAS57MM)
2	44300-S1A-E01	Bearing assy - FR. HUB
3	44600-S1A-E00	Hub assy - FR.
4	45010-S1A-E01	Pin set - FR.
5	45012-S1A-E01	Body set - R. FR. CALIPER
6	45013-S1A-E01	Body set - L. FR. CALIPER
7	45014-S1A-E02	Bracket comp. - R. FR. CALIPER
8	45015-S1A-E02	Bracket comp. - L. FR. CALIPER
9	45017-S1A-E01	Boot set - FR. PIN
10	45022-S1A-E50	Pad set - FR. (LUCAS,J632)
11	45216-S1A-E01	Piston
12	45240-SK3-E00	Bolt
13	45251-S1A-G00	Disk - FR. BRAKE (15")
14	45255-S1A-E00	Guard - R. FR. BRAKE SPLASH (15")
15	45256-S1A-E00	Guard - L. FR. BRAKE SPLASH (15")
16	45352-SN7-G41	Screw - BLEEDER
17	45353-SN7-G41	Cap - BLEEDER
18	90107-SM4-000	Bolt - CALIPER MOUNTING (12X21)
19	90113-SD4-901	Bolt - WHEEL (MEIRA)
19	90113-SD4-902	Bolt - WHEEL (SAGA)
20	90681-SG0-000	Circlip - INTERNAL, 84MM

Front bulkhead 1

#	OEM	部品名
29	90105-634-000	Bolt-washer (8x20)

Front combination light 4

#	OEM	部品名
1	33802-S1A-E01	Housing comp - R.
2	33852-S1A-E01	Housing comp - L.
7	34304-SH3-A01	Socket comp.
8	34351-S1A-G01	Bulb - WEDGE (12V 5W)

Front door lining 11

#	OEM	部品名
2	35750-S1A-G01	Switch assy - POWER WINDOW MASTER
3	35750-S1A-G11	Switch assy - POWER WINDOW MASTER
4	35760-S1A-E01	Sub switch assy. - POWER WINDOW
5	72225-S1A-E00	Bracket assy - R. FR. DOOR LINING
6	72265-S1A-E00	Bracket assy - L. FR. DOOR LINING
7	72335-S1A-E00	Weatherstrip - R. FR. DOOR INNER
8	72375-S1A-E00	Weatherstrip - L. FR. DOOR INNER
12	83512-S1A-E00	Nut - SPEED, 5MM
21	90116-ST3-E00	Bolt - FLANGE, 6X12
23	91560-S84-A01	CLIP, DOOR LINING (NATURAL)
24	91626-SP0-003	Grommet - SCREW, 5MM

Front door locks 40

#	OEM	部品名
1	72152-S1A-G11	Lock assy - R. FR. DOOR
1	72112-S1A-G01	Lock assy - R. FR. DOOR
2	72112-SR4-004	Snap - BROWN
3	72113-SR4-004	Snap - BLACK
5	72115-S84-A01	Actuator assy - DOOR LOCK
6	72116-SM4-003	Snap d - VIOLET
7	72116-SV4-003	Snap - ORANGE
8	72116-S04-003	Holder - ROD(SKY BLUE)
9	72117-S04-003	Holder - ROD (YELLOW)
10	72117-S1A-E01	Protector - R. FR. DOOR LOCK
13	72119-S1A-E01	Stopper
15	72123-S1A-E01	Clip - R. DOOR KEY CYLINDER
17	72130-S1A-E02	Protector - R. FR. DOOR HANDLE
18	72131-S1A-E01	Rod - R. FR. INSIDE HANDLE
19	72134-SM4-003	Snap - R. (VIOLET)
20	72134-SN7-G01	Bush - JOINT
21	72135-SR3-003	Striker assy - DOOR LOCK
22	72136-SM4-003	Holder - ROD, 4MM
24	72138-S1A-E00	Protector - R. FR. DOOR KEY ROD
25	72139-S1A-E00	Protector - R. FR. DOOR KNOB ROD
26	72140-S1A-E32	Handle assy - R. FR. OUTSIDE
26	72140-S1A-E22	Handle assy - R. FR. OUTSIDE
29	72145-S1A-E01	Cylinder - R. DOOR
31	72146-S1A-E01	Cylinder - L. DOOR
33	72152-S1A-E11	Lock assy - L. FR. DOOR
35	72155-S84-A11	Actuator assy - L. FR. DOOR LOCK
36	72157-S1A-E01	Protector - L. FR. DOOR LOCK
39	72163-S1A-E01	Clip - L. DOOR KEY CYLINDER
40	72170-S1A-E02	Protector - L. FR. DOOR OUTER HANDLE
41	72171-S1A-E01	Rod - L. FR. INSIDE HANDLE
42	72174-SM4-003	Snap - L. (YELLOW)
43	72178-S1A-E00	Protector - L. FR. DOOR KEY ROD
44	72179-S1A-E00	Protector - L. FR. DOOR KNOB ROD
45	72180-S1A-E22	Handle assy - L. FR. OUTSIDE
46	75411-634-000	Joint
47	90120-SM4-000	Screw - TAPPING
48	90120-SV4-000	Bolt - LOCK STRIKER
49	90141-S84-003	Screw - 3X10
50	90662-SB2-003	Grommet - SCREW, 5MM
51	90866-SA0-000	Grommet - SCREW, 4MM

Front door panels 26

#	OEM	部品名
5	67325-S1A-E01	Tape - R. FR. DOOR LOWER INNER
6	67326-S1A-E01	Tape - R. FR. DOOR UPPER INNER
7	67327-S1A-E01	Tape - R. FR. DOOR CENTER INNER
8	67365-S1A-E01	Tape - L. FR. DOOR LOWER INNER
9	67366-S1A-E01	Tape - L. FR. DOOR UPPER INNER
10	67367-S1A-E01	Tape - L. FR. DOOR CENTER INNER
15	72142-SM4-000	Stopper - DOOR
16	72310-S1A-E01	Weatherstrip - R. FR. DOOR
17	72321-S1A-E00	Seal - R. FR. DOOR HOLE
18	72325-S1A-E01	Sub seal - R. FR. DOOR
19	72326-S1A-E01	Weatherstrip - FR. LOWER
20	72340-S1A-E00	Checker comp. - R. FR. DOOR
21	72350-S1A-E01	Weatherstrip - L. FR. DOOR
22	72361-S1A-E00	Seal - L. FR. DOOR HOLE
23	72365-S1A-E01	Sub seal - L. FR. DOOR
24	72380-S1A-E00	Checker comp. - L. FR. DOOR
25	75891-SA7-000	Stopper - DOOR
26	90102-SZ3-000	Bolt - FLANGE, 8X22 (10.5MM)
26	90101-SZ3-000	Bolt - FLANGE, 8X22 (8.5MM)
27	90141-S04-000	Bolt - FLANGE, 8X22
28	90686-692-003	Cap - LINING MOUNT
29	91530-SH4-003	Clip - DOOR WEATHERSTRIP
30	91530-S0A-003	Clip - SUB SEAL
31	91568-SR2-003	Clip - DOOR WEATHERSTRIP
31	91530-SP1-003	Clip A - DOOR WEATHERSTRIP
32	91657-SP0-000	Seal c - DOOR PANEL HOLE (25MM)

Front door windows 15

#	OEM	部品名
1	35118-SX0-G00	Label - IMMOBILIZER
2	72210-S1A-G01	Regulator assy - R. FR. DOOR (POWER)
3	72230-S1A-E00	Sash - R. FR. DOOR FR. LOWER
4	72231-S1A-E00	Sash - R. FR. DOOR CENTER LOWER
5	72235-S1A-E01	Runchannel - R. FR. DOOR
6	72237-S84-G01	Clip - FR. DOOR GLASS GUIDE
7	72250-S1A-G21	Regulator assy - L. FR. DOOR (ANTI TRAP)
8	72270-S1A-E00	Sash - L. FR. DOOR FR. LOWER
9	72271-S1A-E00	Sash - L. FR. DOOR CENTER LOWER
10	72275-S1A-E01	Runchannel - L. FR. DOOR
11	73300-S1A-E01	Glass assy - R. FR. DOOR (GREEN)(SAINT-GOBAIN)
13	73350-S1A-E01	Glass assy - L. FR. DOOR (GREEN)(SAINT-GOBAIN)
15	90116-ST3-E00	Bolt - FLANGE, 6X12
16	91540-SV4-003	Clip - HARNESS BAND (NATURAL) (145.2MM)
17	91580-SM4-003	Clip - COUPLER(ORANGE)

Front driveshaft/ half shaft 16

#	OEM	部品名
1	44014-S1B-E01	Joint set - OUTBOARD
2	44017-S1B-E01	Boot set - INBOARD
3	44018-S1B-E01	Boot set - OUTBOARD
4	44305-S1B-E01	Driveshaft assy. - R.
5	44306-S1B-E01	Driveshaft assy. - L.
6	44310-S1B-951	Joint comp - INBOARD
8	44318-S1A-E01	Band r - BOOT (GKN)
9	44319-S37-300	Set ring - 30X2.0
10	44327-SV4-305	Band - JOINT BOOT (DOUBLE ROLLED BAND)
11	44327-S1A-E01	Band - OUTBOARD BOOT (GKN)
12	44329-SV4-305	Band - SHAFT BOOT (DOUBLE ROLLED BAND)
13	44337-S1A-E01	Ring b - STOPPER
14	44338-S1A-E01	Circlip
15	44351-S37-950	Damper - DYNAMIC
16	44351-S47-901	Damper - DYNAMIC (TOKAI)
21	90305-SD4-003	Nut - SPINDLE (24MM)

Front fenders 18

#	OEM	部品名
3	74101-S1A-E00	Fender - R. FR. INNER
5	74112-S1B-E00	Tray - UNDER COVER
6	74113-S1B-E00	Insulator - UNDER COVER
7	74114-S1B-E00	Lid - OIL DRAIN
8	74151-S1A-E00	Fender - L. FR. INNER
9	90102-SK3-E00	Screw-washer - TAPPING, 5X20
10	90102-S1A-E00	Bolt - BUMPER BEAM UPPER
11	90106-SE1-000	Bolt-washer - 6X15
12	90111-SM4-003	Bolt - BUMPER
13	90112-SS0-000	Bolt - FLANGE, 6X12
14	90144-SA0-020	Bolt - BUMPER SETTING (6X15) (BLACK)
15	90305-SM4-000	Nut - AIR SPOILER CLIP
16	90652-SL9-003	Clip - BUMPER
17	90657-SB0-003	Clip, SPLASH SHIELD
18	90673-SG4-U01	Nut - CLIP, 6MM
19	90676-SA7-003	Grommet - SCREW, 5MM (BLACK)
20	91503-SZ5-003	Clip - BUMPER FACE
21	91512-SM4-003	Clip - INNER FENDER

Front grille ('00) 10

#	OEM	部品名
1	75105-ST3-000	Bolt - SPECIAL
2	75114-S1A-E00	Grille & lip set
4	75120-S1A-E00	Molding - FR. GRILLE
5	75133-S1A-E00	Stopper - FR. GRILLE
6	75135-S1A-E01	Stiffener - FR. GRILLE
7	75307-SN7-000	Nut - SIDE PROTECTOR
8	75700-ST3-E00	Emblem - FR. (H) (LARGE TYPE)
10	90155-ST3-000	Washer
11	90157-SP0-901	Clip - FR. GRILLE
12	90301-ST0-003	push nut, 3mm

Front seat (L.) 24

#	OEM	部品名
1	04810-SB3-R00	C clip set - TRIM FASTENER (100 PIECES)
1	04810-SB3-000	C clip set - TRIM FASTENER (30 PIECES)
8	81118-S1A-E01	Cable - HEIGHT ADJUSTER
9	81133-S1A-E01	Cushion - ANTI NOISE FABRIC
11	81144-SN7-E02	Guide - HEADREST
12	81146-SN7-E01	Lock - SPRING
13	81241-S1A-E01	Nut - 4MM
14	81242-S1A-E01	Clip - LOCK
15	81243-S1A-E01	Rod - CONNECTING
16	81244-S1A-E01	Clip - ROD HOLDER
17	81245-S1A-E01	Back - ANTI NOISE FABRIC
20	81323-S1A-E01	Spring a
21	81324-S1A-E01	Spring b
22	81325-S1A-E01	Spring c
23	81326-S1A-E01	Absorber - NOISE
24	81516-S1A-E21	Frame comp - L. FR. SEAT
24	81516-S1A-E11	Frame comp - L. FR. SEAT
25	81522-S1A-E01	Pad comp - L. FR. SEATBACK
27	81532-S1A-E01	Pad comp - L. FR. SEAT CUSHION
32	81639-S1A-E11	Clip - HEIGHT CABLE
33	81820-S1A-E01	Lumbar comp. - L. FR. BACK
34	90184-SN7-003	Screw - 4.2X9.5
35	90184-S1A-003	Screw - TAPPING, 4.2
38	91551-SF4-003	Band - WIRE HARNESS(BROWN) (110MM)

Front seat (R.) 15

#	OEM	部品名
1	04810-SB3-R00	C clip set - TRIM FASTENER (100 PIECES)
1	04810-SB3-000	C clip set - TRIM FASTENER (30 PIECES)
7	81116-S1A-E01	Frame comp - R. FR. SEAT
10	81122-S1A-E01	Pad comp - FR. SEATBACK
12	81132-S1A-E01	Pad comp - R. FR. SEAT CUSHION
13	81133-S1A-E01	Cushion - ANTI NOISE FABRIC
15	81144-SN7-E02	Guide - HEADREST
16	81146-SN7-E01	Lock - SPRING
21	81241-S1A-E01	Nut - 4MM
22	81242-S1A-E01	Clip - LOCK
23	81243-S1A-E01	Rod - CONNECTING
24	81244-S1A-E01	Clip - ROD HOLDER
25	81245-S1A-E01	Back - ANTI NOISE FABRIC
34	90184-SN7-003	Screw - 4.2X9.5
38	91551-SF4-003	Band - WIRE HARNESS(BROWN) (110MM)

Front seat components (L.; 2) 3

#	OEM	部品名
2	81550-S1A-E11	Device comp. - L. FR. SEAT
4	81637-S1A-E11	Bushing
5	90183-S1A-003	Bolt - TORX, 8X11

Front seat components (R.; 1) 2

#	OEM	部品名
1	81150-S1A-E01	Device comp. - R. FR. SEAT
4	90182-SN7-013	Bolt - TORX, 8X16

Front shock absorber 14

#	OEM	部品名
1	51401-S1A-Y02	Spring - FR. (SHOWA)
2	51605-S1A-E03	Absorber unit - R. FR. SHOCK
3	51621-S84-A01	Washer - SHOCK ABSORBER MOUNTING
5	51631-SV7-004	Rubber - SHOCK ABSORBER MOUNTING(SHOWA)
6	51675-S1A-E01	Base - DAMPER MOUNT
7	51685-SH3-014	Plate - DUST COVER(SHOWA)
8	51686-S0A-003	Rubber - SPRING MOUNTING
10	51689-SH3-004	Plate - BUMP STOP (SHOWA)
11	51689-SP0-004	Cover - DUST (SHOWA)
12	51722-S0A-004	Rubber - FR. BUMP STOPPER
14	51728-SR0-003	Collar - SHOCK ABSORBER MOUNTING(DUFFY STEEL PARTS)
14	51728-SB0-004	Collar - SHOCK ABSORBER MOUNTING (SHOWA)
15	90304-S1A-E00	Nut - FR. SHOCK ABSORBER FLANGE
16	90364-SG0-004	Nut - SELF-LOCK, 10MM (SHOWA) (NYLON)

Front stabilizer/ front lower arm 26

#	OEM	部品名
1	51300-S1A-E01	Spring - FR. STABILIZER
2	51306-S84-A01	Bush - STABILIZER HOLDER
3	51308-S1A-E00	Bracket - FR. STABILIZER
4	51320-S84-A01	Link comp - R. FR. STABILIZER
5	51321-S84-A01	Link comp - L. FR. STABILIZER
6	51352-S1A-E00	Rod - FR. RADIUS
7	51355-S1A-E00	Arm comp - R. FR. LOWER
8	51362-S1A-E00	Rod - L. FR. RADIUS
9	51365-S1A-E00	Arm comp - L. FR. LOWER
10	51381-S1A-E01	Bush - FR. RADIUS ROD (RR.)
11	51391-S1A-E01	Bush - FR. RADIUS ROD (FR.)
12	51393-S1A-E01	Bush - FR. LOWER ARM
13	51394-S84-000	Washer - CASTER ADJUSTER
14	51398-SM4-000	Collar - RADIUS ROD
15	51399-S0A-000	Washer - FR. RADIUS ROD
16	51810-S1A-E01	Bush - SHOCK ABSORBER FORK
17	51811-S1B-E00	Fork - R. FR. SHOCK ABSORBER
18	51821-S1B-E00	Fork - L. FR. SHOCK ABSORBER
21	90002-S10-000	Nut - FLANGE, 10MM
22	90117-S0A-000	Bolt - DAMPER LOCK(10X44)
23	90118-S0A-000	Bolt - FR. LOWER ARM (12X84)
24	90121-S0A-000	Bolt - DAMPER FORK(12X98)
25	90178-S84-A00	Bolt - FR. RADIUS ROD (14X37)
26	90215-SB0-003	Nut - SELF-LOCK, 12MM (SATO RASHI) (CLINCH)
27	90303-SF1-003	Nut - SELF-LOCK, 12MM
28	90306-SB2-013	Nut - SELF-LOCK, 10MM (CLINCH)

Front windshield 10

#	OEM	部品名
1	73111-S1A-E20	Glass set - FR. WINDSHIELD (GREEN)(SAINT-GOBAIN)
1	73111-S1A-E30	Glass set - FR. WINDSHIELD (GREEN)(SPLINTEX)
3	73125-S1A-E00	Rubber - FR. WINDSHIELD DAM
4	73127-S1A-000	Seal - FR. WINDSHIELD
5	73128-S1A-000	Seal - FR. WINDSHIELD
6	73129-S1A-000	Fabric - NON WOVEN
7	73150-S1A-E01	Molding - FR. WINDSHIELD
8	78527-S04-E80	Label - SRS CAUTION (CHILD SEAT)
9	91568-SX0-003	Fastener a - WINDSHIELD
10	91569-SZ3-013	Fastener b - WINDSHIELD

Front windshield wiper (LH) 26

#	OEM	部品名
1	76505-S1A-G01	Motor comp - FR. WIPER (LH)
2	76506-SN7-G05	Cover - MOTOR
3	76510-SN7-E05	Rubber - MOUNTING
4	76515-SN7-E05	Seal a
5	76516-SN7-E05	Rubber - MOUNTING
6	76517-SN7-E05	Collar
7	76520-SN7-E05	Link unit a
8	76522-S1A-G01	Rubber - BLADE (550MM)
9	76524-SN7-E05	Dust seal
10	76530-S1A-G11	Link comp - FR. WIPER
11	76532-S1A-G01	Rubber - BLADE (475MM)
12	76540-S1A-G01	Rod unit a
13	76550-S1A-G01	Rod unit b
14	76558-S1A-G01	Cap - PIVOT (PASSENGER SIDE)
15	76561-S1A-G01	Cap - PIVOT (DRIVER SIDE)
16	76600-S1A-G01	Arm - WINDSHIELD WIPER (DRIVER SIDE)
17	76610-S1A-G01	Arm - WINDSHIELD WIPER (PASSENGER SIDE)
18	76620-S1A-G01	Blade - WINDSHIELD WIPER (550MM) (DRIVER SIDE)
19	76630-S1A-G01	Blade - WINDSHIELD WIPER (475MM) (PASSENGER SIDE)
20	90116-SN7-E05	Bolt - 6X15
21	90126-SR3-000	Bolt-washer - 6X32
22	90166-SN7-E05	Screw - SELF-TAPPING, 3X10
23	90201-SK7-000	Nut - HEX. CAP, 10MM
24	90317-SN7-E05	Nut - HEX., 8MM
25	90545-SN7-E05	Washer - SPRING, 8MM
26	91555-SL0-A01	Clip - COUPLER

Fuel injector (DIESEL) 13

#	OEM	部品名
1	16450-P5T-G01	Injector - FUEL MAIN
2	16450-P5T-G11	Sub injector - FUEL
3	16472-P5T-G00	Washer - INJECTOR SEAL
4	16474-P5T-G00	Clamp - INJECTOR
5	16610-P5T-G01	Pipe comp - FUEL
6	16611-P5T-G00	Clip A - FUEL PIPE
7	16750-P5T-G01	Pipe assy. - FUEL RETURN
8	16751-P5T-G00	Hose a - FUEL RETURN
9	16752-P5T-G00	Hose b - FUEL RETURN
10	16756-P5T-G00	Hose c - FUEL RETURN
11	90404-P5T-G00	Washer
12	90405-P5T-G00	Washer
13	90602-P5T-G00	Clip - FUEL RETURN HOSE

Fuel injector pump (DIESEL) 17

#	OEM	部品名
1	16300-P5T-G01	Pump assy. - FUEL INJECTOR
2	16340-P5T-G00	Solenoid - SHUT OFF
3	16361-P5T-G00	Plate - INTERMEDIATE
4	16390-P5T-G01	Bracket a - FUEL INJECTOR MOUNT
5	16391-P5T-G00	Bracket b - FUEL INJECTOR MOUNT
6	16392-P5T-G01	Stay - FUEL INJECTOR PUMP HARNESS
7	16721-P5T-G00	Hose b - FUEL FEED
8	16724-P5T-G00	Joint - FLANGE
9	16725-P5T-G00	Clip - FUEL FEED
10	90010-P5T-G00	Bolt
11	90011-P5T-G00	Bolt
12	90205-P5T-G00	Nut - PULLEY
13	90404-P5T-G00	Washer
14	90412-P5T-G00	Washer - SPRING
15	91303-P5T-G00	O-ring
21	90009-PDD-X00	Screw - BLEED
21	90008-PDD-X00	Bolt - BANJO

Fuel injector pump drive cover (DIESEL) 15

#	OEM	部品名
1	14310-P5T-G00	Pulley assy - CAMSHAFT RR.
2	14311-P5T-G00	Pulley - CAMSHAFT RR. DRIVE
3	14312-P5T-G01	Hub - CAMSHAFT RR. PULLEY
4	14315-P5T-G01	Pulley - FUEL INJECTOR PUMP DRIVE
5	14320-P5T-G01	Belt - FUEL INJECTOR PUMP DRIVE
6	14325-P5T-G00	Tensioner - FUEL INJECTOR PUMP DRIVE
7	14330-P5T-G01	Cover assy. - FUEL INJECTOR PUMP DRIVE
8	14332-P5T-G00	Seal - FUEL INJECTOR PUMP DRIVE COVER
9	14335-P5T-G00	Plate - FUEL INJECTOR PUMP DRIVE COVER BACK
10	90206-P5T-G00	Nut - PULLEY
11	90413-P5T-G00	Washer - PULLEY
12	90503-P5T-G00	Collar - TIMING BELT BACK COVER
13	90601-P5T-G00	Grommet - TIMING BELT BACK COVER
18	14316-PDD-X00	Damper - FUEL INJECTION PUMP/ FLY WHEEL MASS
19	14317-PDD-X00	Screw - TORX COUNTERSUNK

Fuel pipe (DIESEL) 19

#	OEM	部品名
1	16901-S1B-E00	Hose - FUEL FEED
2	16901-S37-E30	Filter - FUEL (BOSCH)
3	16902-S37-E30	Primer - HAND
4	16903-S1B-E00	Tube - OUTLET
5	16904-S1B-E00	Tube - INLET
6	16917-S1B-E00	Stay a - FUEL STRAINER
7	16918-S1B-E00	Stay - FUEL STRAINER
8	17700-S1B-E00	Pipe - FUEL FEED
9	17740-S1A-G00	Pipe - FUEL RETURN
10	17752-S1A-E01	Cover - FR. FUEL PIPE
11	17753-S1A-E01	Cover - RR. FUEL PIPE
12	17761-S1A-G00	Bracket - CLIP A
13	17762-S0A-000	Stay b - FUEL PIPE
14	17762-S1A-E00	Stay a - FUEL PIPE
15	91594-S84-A01	Clip c - FUEL PIPE
16	91597-S30-L01	Clip A - FUEL PIPE
17	91598-S84-A01	Clip - FUEL PIPE
18	91599-ST3-E31	Clamp e - FUEL PIPE
19	91599-S0A-003	Clamp - FUEL PIPE

Fuel tank 35

#	OEM	部品名
1	17040-S1B-E00	Set - FUEL MODULE
2	17371-S04-003	Valve - TWO WAY (TOYO)
3	17373-S1B-E00	Stay - TWO WAY VALVE
4	17500-S1A-E01	Tank comp. - FUEL
5	17521-S1A-E00	Band - R. FUEL TANK MOUNTING
6	17522-S1A-E00	Band - L. FUEL TANK MOUNTING
7	17525-SM4-000	Bolt-washer - 10X35
8	17574-S1A-E01	Packing - BASE
8	17574-S0X-A01	Packing - BASE
9	17630-S1A-E00	Meter comp - FUEL
10	17651-S1A-E11	Tube - FILLER NECK
11	17652-SN7-000	Clip - FILLER TUBE
12	17652-S0E-003	Clip - FILLER TUBE
13	17653-S1A-E00	Tube - BREATHER
14	17660-S1A-Y01	Pipe comp - FUEL FILLER
15	17662-S1A-E01	Packing - FUEL FILLER
16	17668-S1A-E01	Cover - FUEL FILLER PIPE
17	17670-S1A-E02	Cap comp. - FUEL FILLER
18	17707-S1B-E01	Tube comp - FEED
19	17710-S1B-E01	Tube comp - VENT
20	17711-ST0-003	Retainer - YELLOW) (TOKAI
21	17711-S84-003	Retainer - YELLOW) (TOKAI
22	17713-S1A-E01	Tube comp - RETURN
23	17718-S1A-E00	Stay - FUEL TUBE CLAMP
24	17719-S1A-E01	Nut - FUEL PUMP MODULE LOCK
25	17721-S1B-E00	Tube assy - FUEL
26	74660-S84-A00	Cap assy. - FLOOR MAINTENANCE HOLE
27	90150-S04-003	Bolt - EARTH, 6X16
28	91462-SA5-950	Clamp d - 19MM
29	91512-SX0-003	Clip - INNER FENDER CLIP
30	91591-S1A-E01	Cap - FUEL PIPE CLAMP
31	91592-S1A-E01	Clamp - FUEL PIPE
32	91594-S1A-E01	Clip - FUEL FILLER CAP
33	91594-S84-G01	Clip - JOINT TUBE
34	91601-SH3-013	Grommet - SCREW, 5MM (BLACK)

Gasket kit (DIESEL) 2

#	OEM	部品名
1	06125-P5T-G00	Gasket set - CYLINDER HEAD
2	06129-P5T-G01	Gasket kit - CYLINDER BLOCK

Grommet 17

#	OEM	部品名
1	32170-647-000	Grommet - WINDOW DEFROSTER
2	72206-SA5-000	Cap - FLOOR HOLE, 53MM
3	74175-SD4-000	Cushion - HOOD
4	74416-SF1-000	Insulator - PILLAR LOWER
5	75826-634-300	Seal - INSIDE PANEL, 15MM
6	82871-671-000	Grommet - DRAIN HOLE, 25MM
7	85268-SN7-000	Protection - TAILGATE
8	90615-SR3-000	Cap - WELD HOLE, 51X77
11	90852-671-003	Plug - HOLE
12	91606-SE0-000	Seal - 20X20
13	91606-SK7-003	Plug - BLIND, 25MM
14	91610-SD4-000	Plug - HOLE, 28MM
15	91611-SM4-003	Plug - FLOOR HOLE, 25MM
16	91613-SR3-003	Grommet - SUB FRAME, 15MM
17	91615-SA5-000	Grommet - HOLE, 25MM
18	91619-SE0-000	Seal - DOOR HOLE, 30MM(BLACK)
19	91634-SE3-000	Grommet - 6MM

Harn trailer 1

#	OEM	部品名
4	39797-SE0-004	Relay assy - POWER (4P) (MITSUBA) (RC-2201)

Harness band/bracket 14

#	OEM	部品名
2	32133-SM4-003	Band - HARNESS OFFSET (30) (YELLOW) (122.5MM)
3	32134-SM4-003	Band - HARNESS OFFSET (10) (BROWN) (122.5MM)
4	32146-SH3-003	Connector - DIODE(2P)
6	32210-S1A-G00	Protector - TRUNK HINGE
7	32312-SM4-013	Holder - COUPLER
9	32756-S1A-G00	Guide - FR. DOOR WIRE HARNESS (GRAY)
10	77963-SV4-A01	Clip - SRS HARNESS (BLUE) (153MM)
12	91533-S04-003	Clip - COUPLER (NATURAL)
13	91534-S03-003	Clip - COUPLER (NATURAL) (SEAL)
14	91540-S30-003	Clip - HARNESS BAND(NATURAL) (151.5MM)
15	91545-SV4-003	Clip - HARNESS BAND (NATURAL) (145.2MM) (WITH SEAL)
16	91545-S30-003	Clip - HARNESS BAND (NATURAL) (151.5MM) (WITH SEAL)
18	91571-S10-003	Clip - WIRE HARNESS (NATURAL) (130MM)
19	91582-SM4-003	Clip - WIRE HARNESS

Headlight 10

#	OEM	部品名
1	33101-S1A-G01	Headlight unit - R.
2	33110-S1A-G01	Bulb - H7) (12V 55W
3	33121-S1A-G01	Cover - LOW
4	33121-S1A-G11	Cover - HIGH
5	33130-S1A-G11	Motor unit - HEADLIGHT LEVELING
6	33151-S1A-G01	Headlight unit - L.
7	33305-S1A-G01	Socket - TURN BULB (PY 21W)
8	34351-SN7-G00	Bulb - POSITION (12V 5W)
9	34901-SN7-G00	Bulb - HEADLIGHT (HI) (12V 55W)
10	34903-SN7-G10	Bulb - 12V 21W) (AMBER

Heater blower (LH) 12

#	OEM	部品名
1	39246-671-003	Clamp - CASE HOLD
2	79191-SZ3-A01	Nut - HOLDER
3	79192-SR3-003	Bush - LINK
4	79305-S1A-G11	Blower sub assy.
5	79310-S1A-G21	Motor assy. - FAN
7	79330-S1A-G01	Resistor - BLOWER
8	79350-S1A-G01	Motor assy. - FRESH & RECIRCULAR
9	90121-SR3-003	Screw - TAPPING, 5X12
10	90122-SR3-003	Screw - TAPPING, 5X12
11	90132-SR3-003	Screw - TAPPING, 5X16
12	90133-SR3-003	Screw-washer - 4X16
13	90321-SV4-003	Nut-washer - 6MM (PAINT CUTTING)

Heater control 12

#	OEM	部品名
2	79541-S1A-G00	Cable - MODE CONTROL
3	79542-S1A-G00	Cable - TEMPERATURE CONTROL
4	79555-S1A-G01	Clip - CABLE
5	79558-S1A-G01	Bulb
6	79570-ST3-G01	Switch assy - HEATER FAN
7	79581-S1A-G01	Knob - HEATER CONTROL
8	79582-S1A-G01	Knob - MODE SELECT
9	79583-S1A-G01	Knob
10	79584-S1A-G01	Button
11	79585-S1A-G01	Button
13	79691-SN7-E01	Screw - TAPPING, 4X12
14	80411-S1A-G01	Button

Heater unit (LH) 9

#	OEM	部品名
1	39246-671-003	Clamp - CASE HOLD
2	79100-S1A-G11	Heater unit
3	79110-S1A-G11	Core comp - HEATER
6	79191-SZ3-A01	Nut - HOLDER
7	79544-S1A-G00	Cable - WATER VALVE CONTROL
8	79770-SE0-000	Grommet - WATER VALVE CABLE
11	90122-SR3-003	Screw - TAPPING, 5X12
12	90133-SR3-003	Screw-washer - 4X16
13	90321-SV4-003	Nut-washer - 6MM (PAINT CUTTING)

Hood (LH) 35

#	OEM	部品名
4	73862-672-003	Clip - DOOR WEATHERSTRIP
6	74120-S1A-G00	Lock assy - HOOD
7	74125-S1A-E00	Cover - HOOD LOCK
8	74130-S1A-G00	Wire assy. - HOOD
9	74134-SM4-000	Grommet - HOOD WIRE
11	74141-S1B-E00	Insulator - HOOD
12	74142-S1A-E00	Rubber - R. HOOD SEAL
13	74143-S1A-E00	Rubber - RR. HOOD SEAL
14	74145-S1A-E00	Stay - HOOD OPENER
15	74146-S1A-E00	Rubber - HOOD CENTER SEAL
16	74192-S1A-E00	Rubber - L. HOOD SEAL
17	74200-S1A-G00	Cowl top assy.
18	74202-S1A-G00	Lid - DRIVER COWL TOP
19	74207-S1A-G00	Lid - PASSENGER COWL TOP
20	74208-S1A-E00	Rubber - COWL TOP SIDE
21	74231-S1A-E00	Valve - DRAIN
22	90106-SE1-000	Bolt-washer - 6X15
23	90107-S84-A00	Bolt - FLANGE, 6X18
24	90112-SS0-000	Bolt - FLANGE, 6X12
25	90601-S1A-E00	Grommet - HOOD OPEN STAY
26	90652-S1A-E01	Clip - COWL TOP
27	90851-SD2-000	Plug - HOLE, 8MM
28	91501-SF1-003	Clip - HOOD INSULATOR
28	90700-SB2-003	Clip - HOOD INSULATOR
29	91502-S84-A01	Clip - SEAL RUBBER (ORANGE)
29	91502-S84-A11	Clip - SEAL RUBBER (BLACK)
31	91503-SS0-003	Holder - ROD
32	91504-SL0-003	Clip - HOOD OPEN WIRE
33	91512-SM4-003	Clip - INNER FENDER
34	91522-SM4-003	Clip - TUBE & INSULATOR
35	91530-SP1-003	Clip A - DOOR WEATHERSTRIP
36	91558-SE3-003	Clip - HOOD WIRE
37	91564-SP0-003	Clip - DOOR CHECKER COVER
40	91602-SZ5-000	Cushion - HOOD (11.6MM)
41	91603-SZ5-000	Cushion - HOOD (25MM)

Inner panels 2

#	OEM	部品名
39	90106-SE1-000	Bolt-washer - 6X15
40	90302-SD2-003	Nut-washer - 8MM

Instrument panel (LH) 22

#	OEM	部品名
2	38205-S1A-P00	Label - FUSE (PORTUGAL)
2	38205-S1A-G00	Label - FUSE (GERMANY)
4	66844-SA7-000	Cap - INSTRUMENT PANEL STAY
7	77105-S1C-G00	Insulator - INSTRUMENT PAD
20	77222-S1A-E01	Seal
21	77223-S1A-E01	Felt
23	77463-S1A-E01	Seal a
24	77464-S1A-E01	Seal b
25	77466-S1A-E01	Seal c
26	77467-S1A-E01	Seal d
32	77982-S04-N81	Holder - COUPLER (2P)
33	90104-SV4-000	Bolt-washer - 8X25
34	90106-S84-A00	Bolt-washer - 8X40
35	90108-S84-A00	Bolt-washer - 8MM(SRS)
36	90110-S84-A00	Bolt-washer - 8X20
37	90302-SN7-E00	Nut - SPRING, 4MM
38	90321-SP0-A80	Nut-washer - 6MM
39	90651-S0A-003	Cap - BOLT, 8MM
40	90666-SD4-003	Clip - FITTING
41	90666-S84-A01	Clip - SNAP FITTING
42	91640-SM4-003	Grommet - SCREW, 4MM
43	91641-SM4-003	Grommet - SCREW, 4MM

Instrument panel garnish (LH) 28

#	OEM	部品名
1	38215-S1B-G00	Label - FUSE (PASSENGER SIDE) (GERMANY)
1	38215-S1B-P00	Label - FUSE (PASSENGER SIDE) (PORTUGAL)
3	66417-SA0-000	Rubber - GLOVE BOX STOPPER
5	77240-S1A-E01	Lid assy - AUDIO HOLE
10	77308-S1B-G01	Insulator a - DRIVER LOWER COVER
11	77309-S1B-G01	Insulator b - DRIVER LOWER COVER
15	77329-S1B-G01	Insulator - PASSENGER LOWER COVER
18	77371-S1A-E00	Ring - COLUMN COVER
20	77503-S1A-G01	Cover - GLOVE BOX LID
21	77504-S1A-G01	Arm a - GLOVE BOX
22	77505-S1A-G01	Arm b - GLOVE BOX
23	77506-SM4-900	Stopper - GLOVE BOX LID
24	77509-S1B-E01	Insulator - GLOVE BOX
25	77510-S1A-E01	Hinge comp - GLOVE BOX
26	77520-S1A-E01	Cover - LAMP
27	77530-S1A-E00	Cylinder - GLOVE BOX
29	77542-S1A-E01	Striker - GLOVE BOX
32	77560-S1B-G01	Box set - GLOVE
37	77755-S1A-E01	Spring - POCKET
38	90140-SH3-003	Bolt-washer - 5X18
39	90144-S84-A00	Screw 4x12 - PO
40	90151-SM4-003	Bolt-washer - 5X12
41	90302-SN7-E00	Nut - SPRING, 4MM
42	90601-SW3-003	Washer - CONSOLE PUSH
43	90650-SE3-000	Clip - RADIO PANEL
44	90666-SD4-003	Clip - FITTING
45	90666-S84-A01	Clip - SNAP FITTING
46	91637-SD4-000	Stopper - CASSETTE BOX

Intercooler (DIESEL) 9

#	OEM	部品名
1	17225-PDD-E01	Hose a - INTERCOOLER
2	17227-PDD-E02	Hose b - INTERCOOLER
3	17228-PDD-E02	Hose c - INTERCOOLER
4	17229-PDD-E02	Joint - INTERCOOLER HOSE
5	17315-PDD-E01	Clamp - INTERCOOLER HOSE
6	19700-PDD-E01	Intercooler comp.
7	19701-PDD-E01	Seal - INTERCOOLER
8	90042-PDD-E01	Screw - PAN, 8X30
9	90043-PDD-E01	Nut - FLANGE, 6MM

Interior light 6

#	OEM	部品名
2	34251-SN7-G01	Lens
3	34252-SN7-G00	Lid - INTERIOR LIGHT
4	34260-S84-A01	Light assy - TRUNK ROOM
5	34261-S84-A00	Bulb - T10 3CP) (12V 5W
7	34295-SN7-G01	Bulb - 12V 5W
11	90134-S30-003	Screw - EARTH, 5X18

Knuckle 17

#	OEM	部品名
1	51210-S1A-E00	Knuckle comp - R. FR.
2	51215-S1A-E00	Knuckle comp - L. FR.
3	51225-S84-A01	Boot - LOWER BALL DUST
4	51450-S1A-E01	Arm assy. - R. FR. UPPER
5	51460-S1A-E01	Arm assy. - L. FR. UPPER
6	51464-S1A-E01	Boot - UPPER BALL JOINT
6	51464-S04-013	Boot, UPPER BALL JOINT
7	52226-SL0-003	Circlip - LOWER BALL(MUSASHI)
8	52338-SL0-003	Circlip - CONTROL ARM
9	57450-S1A-E02	Sensor assy - R. FR.
10	57451-SM4-950	Bracket - COUPLER (L.)
11	57451-S1A-E00	Bracket - COUPLER
12	57455-S1A-E02	Sensor assy - L. FR.
13	90114-SB0-000	Bolt-washer - 6X12
14	90172-S0A-000	Bolt - FLANGE, 10X68
15	90321-SE0-000	Nut - UPPER BALL PIN, 10MM
16	90363-SF1-000	Nut - CASTLE, 12MM

Mainshaft (DIESEL) 12

#	OEM	部品名
1	23210-P6A-010	Shaft comp. - MAIN
2	23261-PG1-L60	Shaft - REVERSE IDLE GEAR
3	23441-PG1-K30	Gear - MAINSHAFT THIRD
4	23451-PG1-L60	Gear - MAINSHAFT FOURTH
5	23540-P6A-010	Gear comp - REVERSE IDLE
6	23543-PG1-L60	Washer - 20X30X4
7	23581-PG1-L60	Gear - MAINSHAFT FIFTH
8	23623-P6A-315	Sleeve set - SYNCHRONIZER (3-4)
9	23626-P6A-315	Sleeve set - SYNCHRONIZER (5)
10	23915-P6A-000	Collar - DISTANCE, 31X38X56
11	90702-P6A-000	Pin - SPRING, 4X8
12	91104-P6A-000	Bearing - NEEDLE, 38X43X26

Manifold (DIESEL) 14

#	OEM	部品名
1	17000-P5T-G01	Manifold a - INTAKE
2	17010-P5T-G01	Manifold b - INTAKE
3	17120-P5T-G00	Gasket - IN. MANIFOLD
4	17125-P5T-G00	Stay - IN. MANIFOLD
5	18000-P5T-G01	Manifold - EX.
6	18110-P5T-G00	Valve assy. - EGR
7	18115-P5T-G00	Gasket - MANIFOLD
8	18715-P5T-G01	Gasket a - EGR VALVE
10	18721-P5T-G00	Gasket b - EGR VALVE
11	90012-P5T-G00	Bolt - STUD
12	90406-P5T-G00	Washer
20	18717-PDD-X00	Pipe comp - EGR
21	18718-PDD-X00	Cooler - EX. GAS RECIRCULATION
22	18716-PDD-X00	Bracket - EGR VALVE

Mirror 9

#	OEM	部品名
1	76200-S1A-G21	Mirror assy - R. DOOR (R.C.)
2	76203-S1A-G20	Mirror comp - R.
3	76210-S1A-G20	Actuator comp. - R.
4	76215-S1A-G20	Actuator comp. - L.
6	76250-S1A-G21	Mirror assy - L. DOOR (R.C.)
7	76253-S1A-G20	Mirror comp - L.
9	76400-SN7-G10	Mirror assy - RR. VIEW
10	90615-SK7-003	Clip - MIRROR GARNISH
11	91540-S30-003	Clip - HARNESS BAND(NATURAL) (151.5MM)

Molding 19

#	OEM	部品名
1	72410-S1A-E01	Molding assy. - R. FR. DOOR
2	72411-S1A-E01	Cap - R. FR. DOOR END
3	72430-S1A-E00	Garnish - R. FR. DOOR SASH
4	72450-S1A-E01	Molding assy. - L. FR. DOOR
5	72451-S1A-E01	Cap - L. FR. DOOR END
6	72470-S1A-E00	Garnish - L. FR. DOOR SASH
7	72910-S1A-E01	Molding assy. - R. RR. DOOR
8	72913-S1A-E01	Cap - R. RR. DOOR MOLDING CENTER END
9	72914-S1A-E01	Cap - R. RR. DOOR MOLDING END
10	72930-S1A-E00	Garnish - R. RR. DOOR SASH
11	72950-S1A-E01	Molding assy. - L. RR. DOOR
12	72953-S1A-E01	Cap - L. RR. DOOR MOLDING CENTER END
13	72954-S1A-E01	Cap - L. RR. DOOR MOLDING END
14	72970-S1A-E00	Garnish - L. RR. DOOR SASH
15	74306-S1A-E01	Molding assy. - R. ROOF
17	74316-S1A-E01	Molding assy. - L. ROOF
18	90142-S04-000	Screw - TAPPING, 4X10
19	91588-S1A-E01	Clip - DOOR MOLDING
20	91589-S1A-E01	Clip - CAP END

Oil cooler (DIESEL) 12

#	OEM	部品名
2	15511-P5T-G02	Pipe comp. c - OIL COOLER
3	15512-P5T-G02	Pipe comp. d - OIL COOLER
4	15542-P5T-G00	Stay - CLAMP
5	15544-P5T-G00	Bracket - OIL COOLER PIPE
6	15545-P5T-G00	Clip
7	15546-P5T-G00	Bracket - OIL COOLER PIPE
8	91305-P5T-G00	O-ring
13	15500-P5T-G01	Cooler comp - ENGINE OIL
14	15501-PDD-X00	Thermostat - ENGINE
15	15502-PDD-X00	O-ring - ENGINE OIL COOLER
16	15503-PDD-X00	Housing - OIL COOLER END CAP
17	15504-PDD-X00	Housing - OIL COOLER END CAP

Oil pan (DIESEL) 13

#	OEM	部品名
1	11200-P5T-G00	Pan comp - OIL
2	11222-P5T-G00	Pipe - VACUUM PUMP JOINT
3	11251-P5T-G01	Packing - OIL PAN
4	15200-P5T-G00	Pipe comp - OIL LEVEL
5	15220-P5T-G00	Strainer comp. - OIL
6	15650-P5T-G00	Gauge comp. - OIL LEVEL
7	15702-P5T-G02	Pipe assy. - OIL DRAIN
8	15703-P5T-G00	Hose - VACUUM PUMP
9	15704-P5T-G00	Hose - OIL DRAIN
10	90002-P5T-G00	Bolt - SEALING
11	90402-P5T-G00	Washer - OIL DRAIN PLUG
12	90608-P5T-G00	Clip - HOSE
13	91302-P5T-G00	O-ring

Oil pump (DIESEL) 20

#	OEM	部品名
1	15100-P5T-G01	Pump assy. - OIL
2	15115-P5T-G00	Gasket - OIL PUMP
3	15231-P5T-G01	Valve - RELIEF
4	15235-P5T-G00	Case - OIL PRESSURE
6	15400-PDD-E00	Cartridge - OIL FILTER
7	15560-P5T-G00	Bolt - OIL FILER SETTING
8	37860-P5T-G00	Sensor - OIL TEMPERATURE
9	90008-P5T-G00	Bolt - PATCH
10	90401-P5T-G01	Washer
11	90605-P5T-G00	Clip
12	90707-P5T-G00	Ring - DOWEL
13	90741-P5T-G00	Key - OIL PUMP
14	90802-P5T-G00	Cap - SEALING
15	91202-P5T-G00	Oil seal
16	91301-P5T-G00	O-ring
19	15232-PDD-X00	Valve kit - RELIEF
20	15233-PDD-X00	Thermostat kit - OIL PUMP
21	15234-PDD-X00	Plug kit - OIL PUMP DISCHARGE
22	15236-P5T-G31	Pipe - OIL FEED
23	15237-PDD-X00	Plug - OIL PUMP RELIEF VALVE

Outer panels 7

#	OEM	部品名
22	70494-SE0-000	Spring - FUEL LID OPENER
23	70495-692-000	Cushion - FUEL FILLER LID
24	74423-S1A-E01	Holder - FUEL CAP
25	75450-SN7-000	Outlet assy - RR. AIR
26	90103-SM4-010	Bolt - FLANGE, 6X18
27	90106-SE1-000	Bolt-washer - 6X15
28	90664-SB3-003	Grommet - SCREW, 5MM

Parking brake 9

#	OEM	部品名
2	47342-SN7-003	Switch assy - BRAKE LEVER
3	47360-S1A-E01	Equalizer
4	47365-SN7-003	Pin - EQUALIZER
5	47510-S1A-E03	Wire - PARKING BRAKE (R.) (DISK)
7	47522-SN7-003	Nut - PARKING BRAKE ADJUSTING
8	47537-S1A-E01	Spring - PARKING BRAKE ROD
9	47560-S1A-E03	Wire - PARKING BRAKE (L.) (DISK)
11	47572-SN7-000	Base - WIRE GUIDE
12	90651-SN7-003	Clip - BRAKE HOSE

Pedal (LH) 28

#	OEM	部品名
1	17256-PD6-000	Rubber - RESONATOR MOUNTING
2	17800-S1A-E01	Pedal comp - ACCELERATOR
3	17805-SK3-000	Pad - PEDAL STOPPER
4	17910-S1B-G01	Wire - THROTTLE
5	17924-S1B-G00	Clamp - THROTTLE WIRE
11	36750-S04-003	Switch assy - STOP & CRUISE
12	36641-PP8-000	Collar - ACTUATOR MOUNT
14	37972-PDD-E00	Stay comp - ACCELERATOR PEDAL SENSOR
15	37975-PDD-X00	Sensor comp - ACCELERATION
16	37996-PDD-E00	Cover - ACCELERATOR PEDAL SENSOR
17	46504-679-300	Bush - PEDAL
18	46505-SK3-000	Pad - PEDAL STOPPER
19	46530-S1A-E01	Spring assy - PEDAL RETURN
20	46535-S1A-000	Collar - PEDAL
21	46545-SA5-000	Cover, Pedal
22	46545-SK3-000	Cover - PEDAL
24	46600-S1A-G72	Pedal assy - BRAKE
25	46907-SR3-010	Spring - CLUTCH ASSISTANT
26	46910-S1A-E01	Pedal comp - CLUTCH
27	46911-SN7-000	Bush - PEDAL PIN
28	46981-ST3-E00	Bush a - CLUTCH ASSISTANT
29	46982-ST3-E00	Bush b - CLUTCH ASSISTANT
30	46990-S1A-E01	Bracket - CLUTCH PEDAL
31	46991-S1A-G00	Bracket - FOOTREST
32	46992-S1A-E00	Plate - FOOTREST BRACKET
33	75891-611-000	Cover - DOOR SWITCH
34	90301-SP0-003	Nut - PAINT CUTTING, 6MM
35	90361-SV4-003	Nut - PAINT CUTTING, 6MM

Pillar garnish 4

#	OEM	部品名
17	91560-SP0-003	Clip - DOOR LINING (GRAY)
17	91560-S84-A01	CLIP, DOOR LINING (NATURAL)
18	91560-S04-003	Clip - SIDE GARNISH (NATURAL)
19	91560-S84-A11	Clip - PILLAR GARNISH(BLACK)

Power steering gear box (LH) 16

#	OEM	部品名
3	53415-S1A-E01	Yoke set
5	53434-S1A-E01	Clip - RETAINER
6	53436-S1A-E01	Cushion b - GEAR BOX
7	53438-S84-A00	Bracket b - GEAR BOX
10	53501-S84-A00	Grommet a - STEERING
11	53502-S1A-E00	Grommet b - STEERING
12	53535-S1A-E01	Tube - BELLOW
13	53536-S1A-E01	Housing - BELLOW
14	53540-S1A-E01	End comp - R. TIE ROD
15	53546-S84-003	Boot - TIE ROD END (NOK)
16	53560-S1A-E01	End comp - L. TIE ROD
17	53600-S1A-G05	Box assy - POWER STEERING GEAR
17	53600-S1A-G03	Box assy - POWER STEERING GEAR
18	53669-S1A-G01	Pipe set
21	53685-S1A-E01	Bush - FOOT MOUNTING
22	90108-SH3-003	Bolt - GEAR BOX MOUNTING (10X55)

Power steering lines (LH; DIESEL) 29

#	OEM	部品名
1	53697-SK3-E01	Cap - OIL TANK
2	53701-S1A-E00	Tank comp. - POWER STEERING OIL
3	53711-S1B-E00	Bracket - OIL TANK
4	53713-S1B-X02	Hose comp. - FEED
7	53728-S0X-A01	Clip - RETURN PIPE
8	53729-SN7-000	Clamp - D15.5
9	53729-SS0-003	Clip - RETURN HOSE
10	53729-ST3-E01	Clip - RETURN PIPE, 10MM
11	53729-S1A-E01	Clip - RETURN HOSE (BLACK)
12	53729-S1A-003	Clip - RETURN HOSE (NATURAL)
13	53730-S1B-E01	Pipe comp - POWER STEERING
14	53731-S1B-E01	Tube - SUCTION
16	53733-S1B-E00	Hose - OIL TANK
18	53735-S1B-E01	Hose b - RETURN, 10MM
19	53736-SH3-950	Holder b - POWER STEERING PIPE
20	53736-S1B-E01	Bolt - SEALING, 16MM
21	53737-S1B-R01	Hose comp. - RETURN
22	53738-ST5-J21	Washer - POWER STEERING SEALING, 16MM
23	53739-S1B-E01	Hose - POWER STEERING OIL COOLER OUTLET
24	53740-S1B-E00	Stay - FEED PIPE
25	53742-S1B-X01	Stay c - FEED HOSE
26	53743-S1B-E01	Hose - POWER STEERING OIL COOLER IN.
27	53748-S1A-E60	Clamp - RETURN PIPE
28	53765-S1B-E00	Cooler comp - POWER STEERING OIL
30	90635-SM4-A01	Clip - OIL HOSE (MEIJI)
30	90635-SM4-A02	Clip - OIL HOSE (MEIJI)
31	91405-PE0-003	Clamp - TUBE (D20)
31	91417-SZ3-003	Clamp - FUEL TUBE (D20) (CHUO HATSUJO)
32	91405-SS0-003	Clamp - TUBE (D21)

Power steering pump (DIESEL) 9

#	OEM	部品名
1	06569-P5T-G20	Bracket kit - POWER STEERING SUPPORT
2	56100-P5T-G21	Pump assy. - POWER STEERING
3	56483-P5T-G21	Pulley - POWER STEERING PUMP
4	56900-P5T-G00	Tensioner comp - DRIVE BELT
5	56915-P5T-G00	Washer - FIT PLATE TENSIONER
6	56992-P5T-G20	Belt - DRIVE
7	90015-P5T-G01	Bolt - POWER STEERING FEED HOSE
8	90020-P5T-G01	Bolt
9	90409-P5T-G01	Washer - SEALING

Protector 14

#	OEM	部品名
1	71800-S1A-E00	Garnish assy - R. SIDE SILL
2	71850-S1A-E00	Garnish assy - L. SIDE SILL
3	74430-S1A-E01	Protector - RR. WHEEL ARCH
4	75301-S1A-E01	Protector comp - R. FR. FENDER
5	75302-S1A-E01	Protector comp - R. FR. DOOR
6	75303-S1A-E01	Protector comp - R. RR. DOOR
7	75305-S1A-E00	Clip - FR. FENDER PROTECTOR
8	75313-ST3-E00	Clip - SIDE PROTECTOR
9	75321-S1A-E01	Protector comp - L. FR. FENDER
10	75322-S1A-E01	Protector comp - L. FR. DOOR
11	75323-S1A-E01	Protector comp - L. RR. DOOR
12	90331-SD5-003	Nut - SPRING, 5MM
13	91503-SZ3-003	Clip A
14	91513-SM4-000	Clip - SIDE SILL UPPER GARNISH

Radiator (DIESEL) 13

#	OEM	部品名
1	19010-PDD-X01	Radiator comp - CALSONIC
2	19011-P1K-E01	Plug - DRAIN (CALSONIC)
3	19012-P1K-E01	O-ring - CALSONIC
4	19013-P1K-E01	Seal
5	19015-PDD-E01	Shroud assy. - MAIN
6	19020-PDD-E01	Fan - COOLING
7	19030-PDD-E01	Motor - COOLING FAN
8	19033-PDD-E01	Clip - HARNESS
9	19705-PDD-E01	Stay - INTERCOOLER HOSE CLAMP
10	32175-PDD-E01	Clip - HARNESS
15	90041-PDD-E01	Bolt - FLANGE, 6X14
16	90043-P1K-E01	Nut - HEX., 5MM
17	90044-PDD-E01	Nut - FLANGE, 5MM

Radiator hose (DIESEL) 39

#	OEM	部品名
1	19045-P1K-E01	Cap comp. - RADIATOR (CALSONIC)
2	19046-PT5-P00	Seal - CAP (PORTUGAL)
3	19101-PDD-E01	Tank comp. - EXPANSION
4	19103-PDD-X01	Hose a - EXPANSION TANK
5	19105-PDD-E00	Hose - EXPANSION TANK
6	19106-PDD-E00	Pipe comp - EXPANSION TANK
7	19107-PDD-E00	Hose b - EXPANSION TANK
8	19108-PDD-E00	Hose c - EXPANSION TANK
9	19115-PDD-E00	Bracket - EXPANSION TANK
10	19302-P5T-G01	Thermostat
11	19500-P5T-G00	Pipe comp - COOLANT & FUEL
12	19502-PDD-X03	Hose - WATER LOWER
13	19504-P5T-G00	Hose - THERMOSTAT
14	19505-P5T-G20	Hose - THERMOSTAT BODY OUTLET
15	19506-P5T-G00	Hose - WATER OUTLET
16	19507-PDD-E00	Joint - UPPER WATER HOSE
17	19508-PDD-X01	Hose a - UPPER WATER
18	19509-PDD-X00	Hose b - UPPER WATER
19	19511-PH7-003	Clip, HOSE(36.5MM) (CHUO SPRING)
21	19511-PT0-004	Clip - WATER HOSE (36.5MM) (KEIHIN)
22	19512-PH7-003	Clip - BYPASS HOSE (28MM)
23	19513-PE0-003	Clamp - WATER HOSE (21.7MM) (CHUO SPRING)
24	19525-PDD-X01	Joint - SIX WAY DUAL
25	19527-PDD-X00	Hose - RETURN CONNECTING
26	19531-PDD-X01	Hose c - WATER UPPER
27	19532-PDD-X01	Hose d - WATER UPPER
28	19533-PDD-X03	Hose - HEATER IN.
29	19534-PDD-X01	Joint - THREE WAY SINGLE
30	19535-PDD-X01	Joint - HEATER IN.
31	19536-PDD-X02	Hose - EGR FEED
32	19537-PDD-X02	Hose - EGR RETURN
33	19538-PDD-X01	Hose - COOLANT FUEL RAIL RETURN
34	19539-PDD-X03	Hose - COOLANT FUEL RAIL FEED
35	74171-S1B-E00	Bracket - RADIATOR MOUNT UPPER
36	74172-S10-970	Cushion - RADIATOR MOUNTING LOWER
37	74173-SK3-E00	Cushion - RADIATOR MOUNTING UPPER
38	90601-PDD-X00	Clip - WATER HOSE
39	90607-P5T-G00	Clip - HOSE
40	90609-P5T-G00	Clip - HOUE

Radio antenna 15

#	OEM	部品名
1	39150-S1A-G01	Antenna assy - AUTO RADIO
2	39151-S1A-G01	Bracket
3	39152-S1A-G01	Mast assy. - ANTENNA
4	39154-S1A-G01	Nut - MOUNTING
5	39155-S1A-G01	Motor assy.
6	39156-S1A-G01	Mounting comp. - INSULATOR
7	39157-S1A-G01	Guide comp
10	39168-S1A-G01	Base comp. - GROUND
11	39170-SJ4-000	Valve - RR. MOTOR ANTENNA DRAIN
15	91507-SL9-003	Clip - WIRE HARNESS (GREEN) (110MM) (7MM HOLE)
16	91531-S04-003	Clip - WIRE HARNESS(NATURAL) (44MM)
18	91540-S30-003	Clip - HARNESS BAND(NATURAL) (151.5MM)
19	91902-SB2-003	Cushion - WIRE HARNESS(50X100)
30	39160-S1A-G01	Feeder - ANTENNA
31	91582-SM4-003	Clip - WIRE HARNESS

Rear beam/cross beam 11

#	OEM	部品名
2	50200-S1B-G00	Beam - RR.
4	50205-S1B-E00	Damper - RR. BEAM DYNAMIC
5	50210-S84-A00	Stiffener - RR. BEAM
6	50220-S1A-G00	Stiffener - STEERING GEAR BOX
13	50250-S1B-E00	Beam - FR.
17	50310-S1A-E01	Sub frame comp. - RR. SUSPENSION
18	90161-S84-A00	Bolt - FLANGE, 14X125
19	90162-S84-A00	Bolt - FLANGE, 14X90
20	90164-S1A-E00	Bolt - FLANGE, 12X30
21	91613-SE0-003	Grommet - SUB FRAME, 15MM
22	91613-S84-A01	Grommet - RR. SUB FRAME

Rear brake (DISK) 22

#	OEM	部品名
1	42200-S1A-E01	Bearing assy - RR. HUB UNIT
1	42200-S1A-E02	Bearing assy - RR. HUB UNIT
3	42326-SG0-000	Cap - HUB UNIT
4	42510-S1A-E00	Disk - RR. BRAKE
6	43010-S1A-E00	Pin set - RR.
7	43012-S1A-E01	Body set - R. RR. CALIPER
8	43013-S1A-E01	Body set - L. RR. CALIPER
9	43014-S1A-E01	Bracket set - R. RR. CALIPER
10	43015-S1A-E01	Bracket set - L. RR. CALIPER
11	43017-S1A-E00	Boot set - RR. PIN
12	43018-S1A-E01	Excluder set - RR
13	43022-S1A-E50	Pad set - RR. (LUCAS,D6272)
14	43249-S1A-E01	Bolt
15	43253-S1A-E00	Guard - R. RR. SPLASH
16	43254-S1A-E00	Guard - L. RR. SPLASH
17	45352-SN7-G41	Screw - BLEEDER
18	45353-SN7-G41	Cap - BLEEDER
19	90103-SV4-003	Bolt - FLANGE, 10X30
20	90113-SA0-006	Bolt - WHEEL (SAGA)
20	90113-SM1-005	Bolt - WHEEL (ROCKNEL FASTENER)
20	90113-SA0-025	Bolt - WHEEL (NAGOYA RASHI)
21	90305-S30-003	Nut - SPINDLE

Rear door lining 6

#	OEM	部品名
1	35760-S1A-E01	Sub switch assy. - POWER WINDOW
2	72835-S1A-E00	Weatherstrip - R. RR. DOOR INNER
3	72875-S1A-E00	Weatherstrip - L. RR. DOOR INNER
6	83512-S1A-E00	Nut - SPEED, 5MM
12	91560-S84-A01	CLIP, DOOR LINING (NATURAL)
13	91626-SP0-003	Grommet - SCREW, 5MM

Rear door locks 31

#	OEM	部品名
1	72119-S1A-E01	Stopper
3	72135-SR3-003	Striker assy - DOOR LOCK
5	72139-SR0-A01	Snap - VIOLET
6	72149-SR4-000	Snap - R.
7	72175-SH3-901	Holder - DOOR LOCK ROD
8	72189-SR4-000	Snap - L.
9	72610-S84-A01	Lock assy - R. RR. DOOR
10	72612-S84-A00	Cap - R. CHILD LOCK
12	72615-S84-A01	R. RR. DOOR LOCK ACTUATOR ASSY
13	72139-S0A-003	Snap - PINK
14	72616-SM4-003	Snap - NATURAL
17	72630-S84-A01	Crank assy - LOCK ROD
18	72631-S1A-E01	Rod - R. RR. INSIDE HANDLE
19	72632-S1A-E01	Rod - R. RR. DOOR LOCK
20	72633-S1A-E01	Rod - RR. DOOR LOCK KNOB
21	72634-S1A-E01	Rod - RR. DOOR LOCK
22	72638-S1A-E00	Protector - R. RR. DOOR ROD
23	72640-S1A-E12	Handle assy - R. RR. DOOR OUTSIDE
24	72645-S1A-E00	Protector - R. RR. DOOR OUTSIDE HANDLE
25	72650-S84-A01	Lock assy - L. RR. DOOR
26	72652-S84-A00	Cap - L. CHILD LOCK
28	72655-S84-A01	L. RR. DOOR LOCK ACTUATOR ASSY
31	72671-S1A-E01	Rod - L. RR. INSIDE HANDLE
32	72672-S1A-E01	Rod - L. RR. DOOR LOCK
33	72678-S1A-E00	Protector - L. RR. DOOR ROD
34	72680-S1A-E12	Handle assy - L. RR. OUTSIDE
35	72685-S1A-E00	Protector - L. RR. DOOR OUTSIDE HANDLE
36	90120-SM4-000	Screw - TAPPING
37	90120-SV4-000	Bolt - LOCK STRIKER
39	90662-SB2-003	Grommet - SCREW, 5MM
40	90866-SA0-000	Grommet - SCREW, 4MM

Rear door panels 27

#	OEM	部品名
5	67825-S1A-E01	Tape - R. RR. DOOR LOWER INNER
6	67826-S1A-E01	Tape - R. RR. DOOR UPPER INNER
7	67827-S1A-E01	Tape - R. RR. DOOR CENTER INNER
8	67865-S1A-E01	Tape - L. RR. DOOR LOWER INNER
9	67866-S1A-E01	Tape - L. RR. DOOR UPPER INNER
10	67867-S1A-E01	Tape - L. RR. DOOR CENTER INNER
15	72810-S1A-E01	Weatherstrip - R. RR. DOOR
16	72821-S1A-E10	Seal - R. RR. DOOR HOLE
16	72821-S1A-E00	Seal - RR. DOOR HOLE
17	72825-S1A-E01	Sub seal - R. RR. DOOR
18	72826-S1A-E01	Weatherstrip - RR. LOWER
19	72840-S1A-E00	Checker comp. - R. RR. DOOR
20	72850-S1A-E01	Weatherstrip - L. RR. DOOR
21	72861-S1A-E10	Seal - L. RR. DOOR HOLE
21	72861-S1A-E00	Seal - L. RR. DOOR HOLE
22	72865-S1A-E01	Sub seal - L. RR. DOOR
23	72880-S1A-E00	Checker comp. - L. RR. DOOR
24	75891-SA7-000	Stopper - DOOR
25	90101-SZ3-000	Bolt - FLANGE, 8X22 (8.5MM)
25	90102-SZ3-000	Bolt - FLANGE, 8X22 (10.5MM)
26	90141-S04-000	Bolt - FLANGE, 8X22
27	90686-692-003	Cap - LINING MOUNT
28	91530-SH4-003	Clip - DOOR WEATHERSTRIP
29	91530-S0A-003	Clip - SUB SEAL
30	91568-SR2-003	Clip - DOOR WEATHERSTRIP
30	91530-SP1-003	Clip A - DOOR WEATHERSTRIP
31	91657-SP0-000	Seal c - DOOR PANEL HOLE (25MM)

Rear door windows 20

#	OEM	部品名
1	72220-SN7-G00	Handle assy - REGULATOR
2	72222-SN7-G00	Pin - REGULATOR HANDLE
3	72710-S1A-E01	Regulator assy - R. RR. DOOR (POWER)
4	72710-S1A-E11	Regulator assy - R. RR. DOOR (MANUAL)
5	72730-S1A-E00	Sash - R. RR. DOOR FR. LOWER
6	72731-S1A-E00	Sash - R. RR. DOOR CENTER
7	72735-S1A-E01	Runchannel - R. RR. DOOR
8	72737-SR4-000	Collar a - RR. DOOR PANEL LOWER
9	72750-S1A-E01	Regulator - L. RR. DOOR (POWER)
10	72750-S1A-E11	Regulator - L. RR. DOOR (MANUAL)
11	72770-S1A-E00	Sash - L. RR. DOOR FR. LOWER
12	72771-S1A-E00	Sash - L. RR. DOOR CENTER
13	72775-S1A-E01	Runchannel - L. RR. DOOR
14	73400-S1A-E00	Glass assy - R. RR. DOOR (GREEN)
15	73410-S1A-E01	Glass assy - R. RR. DOOR QUARTER (GREEN)
16	73450-S1A-E00	Glass assy - L. RR. DOOR (GREEN)
17	73460-S1A-E01	Glass assy - L. RR. DOOR QUARTER (GREEN)
19	90116-ST3-E00	Bolt - FLANGE, 6X12
20	91540-SV4-003	Clip - HARNESS BAND (NATURAL) (145.2MM)
21	91580-SM4-003	Clip - COUPLER(ORANGE)

Rear seat 19

#	OEM	部品名
1	04810-SB3-R00	C clip set - TRIM FASTENER (100 PIECES)
1	04810-SB3-000	C clip set - TRIM FASTENER (30 PIECES)
3	82122-S1A-E11	Pad comp - R. RR. SEATBACK
4	82126-S1A-E02	Frame comp - R. RR. SEAT
5	82127-SM4-J01	Collar - RR. SEATBACK SETTING (A) (TS TECH)
7	82132-S1A-E01	Pad & frame comp. - RR. SEAT CUSHION
8	82137-S84-A01	Clip - RR. SEAT CUSHION
13	82152-S1A-E01	Pad & frame comp. - R. RR. SEATBACK SIDE
15	82290-S1A-E11	Bracket comp. - R. SEAT PIVOT
16	82291-S1A-E10	Cover - CENTER PIVOT
17	82295-SN7-E21	Bracket - CENTER SEAT PIVOT
19	82522-S1A-E11	Pad comp - L. RR. SEATBACK
20	82526-S1A-E02	Frame comp - L. RR. SEAT
22	82552-S1A-E01	Pad & frame comp. - L. RR. SEATBACK SIDE
23	82620-SN7-E22	Lock assy - L. RR. SEAT
24	82690-S1A-E11	Bracket comp. - L. SEAT PIVOT
25	90003-692-000	Bolt - FLANGE, 6X16
26	90139-SH3-003	Bolt-washer - 6X20
27	90186-S1A-003	Bolt - ARMREST

Rear shock absorber 17

#	OEM	部品名
1	51621-S84-A01	Washer - SHOCK ABSORBER MOUNTING
3	51631-SV7-004	Rubber - SHOCK ABSORBER MOUNTING(SHOWA)
4	51728-SR0-003	Collar - SHOCK ABSORBER MOUNTING(DUFFY STEEL PARTS)
4	51728-SB0-004	Collar - SHOCK ABSORBER MOUNTING (SHOWA)
5	52441-S1A-E01	Spring - RR. (SHOWA)
6	52611-S1A-E02	Absorber unit - RR. SHOCK
7	52622-S84-A01	Bush - RR. SHOCK ABSORBER LOWER
8	52675-S0A-003	Base - RR. SHOCK ABSORBER MOUNTING (SHOWA)
9	52686-S84-A01	Rubber - RR. SPRING MOUNTING
10	52688-S0A-004	Sleeve - RR. DUST COVER
11	52689-SG0-014	End - DUST COVER
12	52690-SG0-000	Plate - BUMP STOP
13	52722-SM4-013	Rubber - BUMPER STOPPER (POLYURETHAN KASEI)
14	52748-S0A-004	Cover - RR. LOWER MOUNT DUST
15	90182-S84-A00	Bolt - RR. DAMPER, (10X81)
16	90304-SR3-014	Nut - FLANGE, 10MM (OHASHI)
17	90364-SG0-004	Nut - SELF-LOCK, 10MM (SHOWA) (NYLON)

Rear stabilizer/ rear lower arm 36

#	OEM	部品名
1	52113-S1A-E01	Bush - RR. KNUCKLE
2	52210-S1A-E50	Knuckle comp - R. RR. (DISK)
3	52215-S1A-E50	Knuckle comp - L. RR. (DISK)
4	52300-S1A-E00	Spring - RR. STABILIZER
5	52306-S0A-015	RR. STABILIZER HOLDER Bush
6	52308-SZ5-000	Holder - STABILIZER BUSH
7	52320-S84-A01	Link comp - R. RR. STABILIZER
8	52325-S84-A01	Link comp - L. RR. STABILIZER
9	52338-SL0-003	Circlip - CONTROL ARM
10	52340-S1A-E00	Bracket - R. RR. LINK STABILIZER
11	52345-S1A-E00	Bracket - L. RR. LINK STABILIZER
12	52350-S1A-E00	Arm comp - RR. LOWER
13	52360-S1A-E00	Arm comp - RR. CONTROL
14	52364-634-020	Washer - LOWER ARM
15	52370-S1A-E00	Arm comp - R. RR. TRAILING (200)
16	52375-S1A-E00	Arm comp - L. RR. TRAILING (200)
17	52380-S1A-E20	Arm comp - RR. LEADING (200)
18	52387-S84-A00	Bolt - CONTROL ADJUSTING
19	52388-S84-A00	Plate - CAM
20	52390-S1A-E01	Arm comp - RR. UPPER (900)
21	52454-S84-A01	Boot - UPPER DUST
21	06511-TY2-A01	Boot
21	52454-S1A-E01	Boot - RR. UPPER DUST
22	57452-S84-A50	Bracket - RR. COUPLER
23	57470-S1A-E02	Sensor assy - R. RR.
24	57475-S1A-E02	Sensor assy - L. RR.
25	90002-S10-000	Nut - FLANGE, 10MM
26	90114-SB0-000	Bolt-washer - 6X12
27	90121-S0A-000	Bolt - DAMPER FORK(12X98)
28	90173-S84-A00	Bolt - RR. UPPER ARM
29	90181-S84-A00	Bolt - TRAILING ARM, 12X68
30	90215-SB0-003	Nut - SELF-LOCK, 12MM (SATO RASHI) (CLINCH)
31	90216-SE0-010	Nut
31	90216-SE0-305	NUT, LWR ARM
32	90306-SB2-013	Nut - SELF-LOCK, 10MM (CLINCH)
33	90363-SF1-000	Nut - CASTLE, 12MM

Rear tray/trunk lining 3

#	OEM	部品名
21	90610-SR3-003	Clip - GARNISH (KATO)
24	90683-693-000	Grommet - SCREW, 5MM
26	91560-S04-003	Clip - SIDE GARNISH (NATURAL)

Rear windshield 6

#	OEM	部品名
1	73211-S1A-E00	Glass set - RR. WINDSHIELD (GREEN)
2	73250-S1A-E01	Molding - RR. WINDSHIELD
4	91563-SV4-003	Fastener a - RR. WINDSHIELD
5	91568-SV4-003	Fastener b - RR. WINDSHIELD
6	91568-SX0-003	Fastener a - WINDSHIELD
7	91569-SZ3-013	Fastener b - WINDSHIELD

Roof lining 6

#	OEM	部品名
5	83202-SZ3-000	Clip - ROOF LINING
11	90137-S1A-E01	Screw - ET, 6X18
11	90136-S1A-E01	Screw - ET, 5X18
12	90136-S30-003	Screw - ET, 5X18
12	90137-S30-003	Screw - ET, 6X18
13	90673-SE0-003	Clip - ROOF LINING

Seatbelts 4

#	OEM	部品名
5	81491-S1A-010	Protector - R. FR. SEATBELT
8	81891-S1A-010	Protector - L. FR. SEATBELT
11	82456-S1A-000	Protector - RR. CENTER SEATBELT
14	90101-S84-A00	Screw - ET, 6X16

Sensor (DIESEL) 15

#	OEM	部品名
1	12291-P5T-G02	Plug - HEATER
3	32741-P5T-G00	Stay - HARNESS
4	36033-PDD-X00	Stay comp - DEVICE
5	36166-P5T-G01	Valve assy. - EGR SOLENOID
6	37240-P5T-G01	Switch - OIL PRESSURE
7	37776-P5T-G00	Sensor - THERMO
8	37830-PDD-X01	Sensor assy - BOOST
9	37870-P5T-G00	Sensor - TW
10	37880-P5T-G00	Sensor - TA
11	78420-P5T-G00	Sensor assy - SPEED
12	90203-P5T-G00	Nut
13	90410-P5T-G00	Spacer - SPEED SENSOR
17	90403-PDD-X00	Washer - SEALING
18	39792-S1B-D00	Relay - NORMAL OPEN (HEATER PLUG)
18	12296-P5T-G01	Cable - HEATER PLUG

Shift fork (DIESEL) 6

#	OEM	部品名
1	24200-P6A-000	Fork comp - FIFTH GEARSHIFT
2	24210-P6A-010	Fork comp - GEARSHIFT (3-4)
3	24220-P6A-000	Fork comp - GEARSHIFT (1-2)
4	24261-P6A-010	Shaft - GEARSHIFT FORK (1-2)
5	24270-P6A-020	Shaft - FIFTH & REVERSE SHIFT
6	90704-P6A-000	Pin - SPRING, 5X22

Shift lever (DIESEL) 29

#	OEM	部品名
1	24313-PF5-000	Clip - CHANGE JOINT PIN
1	54113-611-505	CLIP, SHIFT JOINT
2	44329-S71-300	Band - SHAFT BOOT
3	54101-S1B-003	Lever - CHANGE
4	54102-SK3-900	Knob comp. - CHANGE LEVER
5	54105-692-010	Washer - THRUST
6	54107-SA0-010	Bush, RR. JOINT
7	54108-S1B-003	Boot - CHANGE LEVER
8	54109-S1B-E00	Seal a - CHANGE DUST
9	54110-SD4-003	Seat - CHANGE LEVER BALL
10	54110-S1A-E60	Seat - CHANGE EXTENSION MOUNTING
11	54114-SB2-000	Collar - PIPE MOUNTING
12	54114-SL4-900	Seal b - CHANGE DUST
13	54117-SD4-000	Collar - RR. JOINT
14	54119-SD4-003	Stopper - CHANGE BALL
15	54145-S1B-000	Damper - CHANGE LEVER
16	54146-SD4-000	Spacer - BALL SEAT
17	54201-S1B-003	Rod comp - CHANGE
18	54301-S1B-003	Extension - CHANGE
19	54303-SB2-010	Rubber, EXTENSION END
20	54304-SG4-U00	Washer a - EXTENSION END
21	54305-SG4-U00	Washer b - EXTENSION END
22	54307-S1A-E60	Stopper - EXTENSION MOUNTING
23	90105-S37-000	Bolt-washer - 6X20
24	90115-659-003	Nut - SELF-LOCK, 8MM (CLINCH)
25	90751-S04-000	PIN, SPRING, 8X22
26	91301-671-671	O-ring - 1.9X11
26	91303-HA0-004	O-ring, 11x1.9 (nok)
27	91351-SD4-000	O-ring - 40X3MM

Shift rod/shift holder (DIESEL) 15

#	OEM	部品名
1	24230-P6A-010	Holder comp - REVERSE CHANGE
2	24311-PG1-L60	Rod - GEARSHIFT
3	24316-PG1-L60	Boot - SHIFT ROD
4	24351-P6A-000	Shaft - SHIFT PIECE
5	24400-P6A-010	Holder assy. - CHANGE
6	24411-P6A-010	Piece - CHANGE
7	24432-P6A-030	Interlock assy.
8	24440-P6A-010	Piece comp. - GEARSHIFT
9	24451-PG1-L60	Spring - BALL SETTING
10	24519-PG1-L60	Screw - BALL SPRING SETTING
11	90011-P6A-000	Bolt - FLANGE, 6X18MM
12	90027-PG1-L60	Bolt - SPECIAL, 6X22.5
13	90028-PG1-L60	Bolt - SPECIAL, 8X61.5
14	90030-PG1-L60	Bolt - SPECIAL, 8X24
15	90412-PG1-L60	Washer - CONICAL SPRING, 8MM

Speaker 4

#	OEM	部品名
1	39112-S0A-000	Bracket - DOOR SPEAKER SEAL
3	39120-S1A-G03	Speaker assy - 16CM SINGLE) (MATSUSHITA
7	90131-S30-003	Screw-washer - ET, 6X16
8	90670-SG0-003	Grommet - SCREW, 4MM

Speed sensor (DIESEL) 4

#	OEM	部品名
1	23810-P6A-306	Gear assy. - SPEEDOMETER
2	23817-P6A-305	O-ring
3	23818-P6A-305	Bolt
4	78410-S37-D00	Sensor assy - SPEED

Srs unit (LH) 10

#	OEM	部品名
1	32132-SM4-003	Band - WIRE HARNESS OFFSET (20) (BLACK) (122.5MM)
2	77900-S1A-E01	Reel assy - CABLE
3	77907-S04-003	Holder - CONNECTOR (2P)
4	77960-S1A-G82	Srs unit
5	77961-S1A-G80	Harness - SRS MAIN
6	77962-S1A-G80	Harness - SRS FLOOR WIRE
9	90101-SA4-000	Screw - TAPPING, 4X12
10	90137-S84-A01	Bolt - TORX EARTH, 6X20
11	91507-SL9-003	Clip - WIRE HARNESS (GREEN) (110MM) (7MM HOLE)
12	91540-S30-003	Clip - HARNESS BAND(NATURAL) (151.5MM)

Starter motor (DIESEL) 2

#	OEM	部品名
1	31200-P9M-E00	Motor assy. - STARTER
2	90014-P5T-G00	Bolt - SPECIAL STARTER

Steering column 12

#	OEM	部品名
1	53200-S1A-G04	Column assy - STEERING (LH)
2	53216-ST3-E00	Holder b - STEERING COLUMN
3	53320-S1A-G00	Cover - STEERING JOINT (LH)
4	53323-ST3-E01	Joint comp. b - STEERING
5	53325-SV4-000	Clip A - JOINT COVER
6	53326-SN7-000	Clip b - JOINT COVER
7	77873-S04-G80	Label - STEERING COLUMN CAUTION (ENGLISH/FRENCH/GERMAN/DUTCH)
8	90135-SF1-000	Bolt - CENTER SHAFT YOKE
9	90361-SM4-003	Nut - FLANGE, 8MM
9	90361-SR3-000	Nut - FLANGE, 8MM
10	90511-671-003	Washer - TOOTHED LOCK
11	90676-SB2-003	Clip - DASHBOARD INSULATOR

Steering wheel (SRS; 1) 6

#	OEM	部品名
5	78502-S1A-E61	Sleeve assy
9	78520-S1A-E61	Damper - STEERING DYNAMIC
10	78521-S1A-E81	Button - L. HORN
11	78522-S1A-E81	Button - R. HORN
12	90140-S1A-E61	Screw - SCHRAUBE TAPPING (M5)
13	90161-SV4-003	Bolt - STEERING HANDLE

Switch (LH) 8

#	OEM	部品名
1	35170-S1A-E01	Switch assy - RR. FOG
5	35505-SN7-G01	Bulb comp. - NEO-WEDGE (12V 1.2W)
6	35510-S1A-E01	Switch assy - HAZARD
7	35820-S1A-E01	Switch assy - HEADLIGHT ADJUSTER
9	35851-S1A-E02	Bulb comp. - 14V 40MA
11	35852-S1A-E02	Bulb comp. - 14V 60MA
14	35871-S84-T01	Bulb - NEO WEDGE (T3) (14V 60MA) (TOYO)
18	39700-S1A-E01	Clock assy - DIGITAL

Taillight 19

#	OEM	部品名
1	33301-SA0-741	Bulb (12V 5W) - (12V 5W) (STANLEY)
2	33501-S1A-G02	Lamp unit - R. TAIL
3	33503-S1A-G01	Socket comp - RR. FOG SIDE
4	33504-S1A-G01	Socket comp.
5	33551-S1A-G02	Lamp unit - L. TAIL
6	34100-S84-G01	Light assy - LICENSE
7	34102-S60-003	Housing comp
8	34102-S84-A01	Lens comp
10	34271-S1A-G01	Light comp. - HIGH MOUNT STOP
12	34351-SN7-G00	Bulb - POSITION (12V 5W)
13	34903-SN7-G10	Bulb - 12V 21W) (AMBER
14	34906-SN7-G00	Bulb - 12V 21W/5W
16	74892-S1A-E00	Molding - RR. LICENSE
17	90102-SN7-010	Bolt assy - LICENSE GARNISH
18	90501-SL9-003	Clip - LICENSE GARNISH
19	90650-SL9-003	Grommet - R. RR. COMBINATION (WHITE)
20	90655-SL9-003	Grommet - L. RR. COMBINATION (GRAY)
21	91524-SE0-003	Clip - COWL TOP
22	91533-S04-003	Clip - COUPLER (NATURAL)

Timing belt (DIESEL) 13

#	OEM	部品名
1	11910-P5T-G00	Bracket - ENGINE MOUNTING
2	13621-P5T-G00	Pulley - TIMING BELT DRIVE
3	13622-P5T-G00	Plate - TIMING BELT
4	14210-P5T-G00	Pulley - TIMING BELT DRIVEN
5	14400-P5T-G00	Belt - TIMING
6	14510-P5T-G01	Adjuster comp - TIMING BELT (A)
7	14520-P5T-G00	Adjuster comp - TIMING BELT (B)
8	14525-P5T-G00	Spring - TIMING BELT ADJUSTER
9	14526-P5T-G00	Sleeve - TIMING BELT ADJUSTER
10	90006-P5T-G00	Bolt - STUD
11	90018-P5T-G00	Bolt - STUD
12	90201-P5T-G00	Nut - SPECIAL
13	90202-P5T-G00	Nut - TIMING BELT IDLER SPECIAL

Timing belt cover (DIESEL) 16

#	OEM	部品名
1	11810-P5T-G00	Cover - TIMING BELT LOWER
2	11811-P5T-G00	Rubber a - TIMING BELT LOWER SEAL
3	11812-P5T-G01	Rubber b-f - TIMING BELT LOWER SEAL
4	11820-P5T-G00	Cover assy. - TIMING BELT
5	11821-P5T-G00	Rubber assy. - TIMING BELT UPPER SEAL
6	11830-P5T-G00	Cover assy. - TIMING BELT BACK UPPER
7	11831-P5T-G00	Rubber a - TIMING BELT BACK SEAL
8	11832-P5T-G00	Rubber b - TIMING BELT BACK SEAL
9	11833-P5T-G00	Rubber c - TIMING BELT BACK SEAL
10	11840-P5T-G00	Cover assy. - TIMING BELT BACK
11	13810-P5T-G01	Pulley comp - CRANKSHAFT
12	90007-P5T-G00	Bolt-washer
13	90503-P5T-G00	Collar - TIMING BELT BACK COVER
14	90601-P5T-G00	Grommet - TIMING BELT BACK COVER
15	90804-P5T-G00	Cap - CORE PLUG
16	90805-P5T-G00	Plug - BLANKING

Tire/wheel disk 34

#	OEM	部品名
2	42700-S1A-E01	Disk - WHEEL (15X6J) (DUNLOP)
6	42751-S1C-E02	Tire - 195/60R15 88V) (PIRELLI
6	42751-S1A-E02	Tire - 195/60R15 88V) (BRIDGESTONE
6	42751-S1A-E01	Tire - 195/60R15 88V) (DUNLOP
7	42753-SH3-003	Valve - RIM (US PACIFIC)
7	42753-SB8-661	Valve - RIM (SCHRADER)
7	42753-SN8-E00	Valve - RIM
7	42753-SG9-000	Valve - RIM(A.R.G.)
7	42753-SK3-000	Valve - RIM(A.R.G.)
7	42753-SE0-A02	Valve - RIM (SCHRADER)
11	44729-SN7-004	Weight - BALANCE (35G)
11	44728-SN7-004	Weight - BALANCE (25G)
11	44721-SN7-003	Weight - BALANCE (10G)
11	44725-SN7-003	Weight - BALANCE (50G)
11	44730-SN7-003	Weight - BALANCE (45G)
11	44723-SN7-003	Weight - BALANCE (30G)
11	44722-SN7-004	Weight - BALANCE (20G)
11	44727-SN7-003	Weight - BALANCE (15G)
11	44726-SN7-004	Weight - BALANCE (5G)
11	44724-SN7-004	Weight - BALANCE (40G)
11	44729-SN7-003	Weight - BALANCE (35G)
11	44728-SN7-003	Weight - BALANCE (25G)
11	44722-SN7-003	Weight - BALANCE (20G)
11	44721-SN7-004	Weight - BALANCE (10G)
11	44726-SN7-003	Weight - BALANCE (5G)
11	44725-SN7-004	Weight - BALANCE (50G)
11	44730-SN7-004	Weight - BALANCE (45G)
11	44724-SN7-003	Weight - BALANCE (40G)
11	44723-SN7-004	Weight - BALANCE (30G)
11	44727-SN7-004	Weight - BALANCE (15G)
15	44733-S1A-E00	Trim - WHEEL (15")
17	83853-S84-A00	Bolt - ANCHOR
18	74666-SX0-000	Adapter - ANCHOR BOLT
20	90381-SV1-981	Nut comp. - WHEEL (SATO RASHI)

Tools/jack 3

#	OEM	部品名
2	89101-S1A-E00	Box - TOOL
3	89104-SG9-000	Wrench - WHEEL NUT
4	89310-S1A-E00	Jack assy - PANTOGRAPH

Transmission case (DIESEL) 30

#	OEM	部品名
1	21104-PG1-K30	Plate m - OIL GUIDE
2	21200-P6A-010	Case comp. - TRANSMISSION
3	21216-P6A-000	Strut
4	21320-P6A-000	Breather assy
5	23927-PG1-K30	Washer - SPRING, 78MM
6	23941-PG1-K30	Shim k - 78MM (1.0)
6	23936-PG1-K30	Shim f - 78MM (0.75)
6	23931-PG1-K30	Shim a - 78MM (0.5)
6	23943-PG1-K30	Shim m - 78MM (1.1)
6	23938-PG1-K30	Shim h - 78MM (0.85)
6	23933-PG1-K30	Shim c - 78MM (0.6)
6	23940-PG1-K30	Shim j - 78MM (0.95)
6	23935-PG1-K30	Shim e - 78MM (0.7)
6	23942-PG1-K30	Shim l - 78MM (1.05)
6	23937-PG1-K30	Shim g - 78MM (0.8)
6	23932-PG1-K30	Shim b - 78MM (0.55)
6	23944-PG1-K30	Shim n - 78MM (1.15)
6	23939-PG1-K30	Shim i - 78MM (0.9)
6	23934-PG1-K30	Shim d - 78MM (0.65)
7	35600-PG1-L60	Switch assy - BACK UP LIGHT (TEC)
8	90010-P6A-000	Bolt - STUD
9	90012-PG1-L60	Bolt - SPECIAL, 10X1.25
10	90013-PG1-L60	Bolt - SPECIAL, 10X42
11	90014-PG1-L60	Bolt - SPECIAL, 10X92
12	90080-PG1-L60	Bolt - PLUG, 14MM
13	90081-PG1-305	Bolt - SEALING, 32MM
14	90083-PG1-305	Bolt - SEALING, 16MM
15	90401-PG1-L60	Washer - DRAIN PLUG, 10MM
16	91004-P6A-000	Bearing - BALL, 28X78
17	91206-P6A-010	Oil seal - 40X76X9

Trunk lid 24

#	OEM	部品名
5	72134-SM4-003	Snap - R. (VIOLET)
6	73219-693-951	Seal - FUEL LID OPENER (GREEN)
7	74411-S1A-G00	Cable - FUEL LID OPENER
8	74815-S1A-305	Garnish - TRUNK CYLINDER (CHROME PLATED)
9	74822-S1A-E00	Cushion - TRUNK HINGE
10	74826-S84-A00	Protector - RR. COMBINATION
11	74827-SH2-003	Stopper - TAILGATE
13	74851-S30-003	Lock - TRUNK
14	74861-S1A-E01	Cylinder - TRUNK
16	74862-SE3-003	Striker - TRUNK
17	74863-S1A-E61	Rod - TRUNK LOCK
18	74864-S30-003	Cover
19	74865-S1A-003	Weatherstrip - TRUNK LID
21	74867-S1A-E01	Rod - BUSH
22	74871-S1A-E00	Spring - R. TRUNK OPENER
23	74872-S1A-E00	Spring - L. TRUNK OPENER
24	74873-SM4-003	Clip - TRUNK OPENER SPRING
25	74880-S1A-G00	Cable - TRUNK OPENER
30	74886-SN7-003	Cylinder - TRUNK RELEASE
31	90106-SE1-000	Bolt-washer - 6X15
32	90109-SM4-000	Bolt - SPECIAL, 6X35
34	90691-SF1-003	Clip c - OPENER CABLE
35	91516-SM4-013	Clip - RR. COMBINATION PROTECTOR
38	91902-SB2-003	Cushion - WIRE HARNESS(50X100)

Trunk opener 2

#	OEM	部品名
4	72147-S1A-F01	New Genuine Part
6	72147-S1A-G11	Transmitter assy - KEYLESS (3BUTTONS)

Trunk spoiler high wing 2

#	OEM	部品名
2	74871-S1A-E50	Spring - R. TRUNK OPENER
3	74872-S1A-E50	Spring - L. TRUNK OPENER

Turbocharger (DIESEL) 14

#	OEM	部品名
1	15580-P5T-G00	Hose assy - TURBOCHARGER BRACKET
2	15581-P5T-G01	Hose comp. - TURBOCHARGER OIL IN.
3	15585-P5T-G00	Bolt - TURBOCHARGER OIL HOSE
4	15590-P9M-E00	Pipe comp - TURBOCHARGER OIL OUTLET
5	15596-P5T-G00	Gasket - TURBOCHARGER OIL PIPE
6	17228-P5T-G00	Hose - TURBOCHARGER OUTLET
7	17229-P5T-G00	Pipe - TURBOCHARGER OUTLET
8	18131-P5T-G01	Pipe - EX. JOINT
9	18135-P5T-G00	Bracket - TURBOCHARGER
10	18900-P5T-G01	Turbocharger assy
11	90204-P5T-G00	Nut - TURBOCHARGER
12	90408-P5T-G00	Washer - SEALING
13	90607-P5T-G00	Clip - HOSE
14	91304-P5T-G00	O-ring

Water pump (DIESEL) 8

#	OEM	部品名
1	19200-P5T-G01	Pump comp - WATER
2	19210-P5T-G01	Cover - WATER PUMP
3	19222-P5T-G01	Packing set - WATER PUMP
4	19223-P5T-G00	O-ring
5	19230-P5T-G20	Bracket - WATER PUMP
6	19231-P5T-G00	Bush - WATER PIPE BRACKET
7	19350-P5T-G02	Cover assy. - WATER OUTLET
8	19351-P5T-G00	Packing - WATER OUTLET COVER

Water valve (DIESEL) 11

#	OEM	部品名
1	19512-PH7-003	Clip - BYPASS HOSE (28MM)
2	19513-PE0-003	Clamp - WATER HOSE (21.7MM) (CHUO SPRING)
3	79710-S1A-G01	Valve assy. - WATER
4	79721-S1B-G30	Hose a - WATER IN.
5	79722-S1B-G30	Hose b - WATER IN.
6	79725-S1B-G30	Hose a - WATER OUTLET
7	79726-S1B-G30	Hose b - WATER OUTLET
8	79727-S1B-G00	Joint - HOSE
9	79760-SE0-000	Grommet - HEATER PIPE
10	90361-SV4-003	Nut - PAINT CUTTING, 6MM
11	91405-PK1-003	Clip, WATER HOSE, 24MM

Wheel disk al 14x 1

#	OEM	部品名
3	42753-SK3-000	Valve - RIM(A.R.G.)

Windshield washer 16

#	OEM	部品名
2	76806-ST3-E01	Motor - FR. WASHER
4	76807-ST3-E01	Packing - T-TYPE
5	76810-S1A-E01	Nozzle assy. - R. WINDSHIELD WASHER
6	76812-ST3-E01	Cap assy. - MOUTH
7	76815-S1A-E01	Nozzle assy. - L. WINDSHIELD WASHER
8	76820-S1A-E01	Grommet - TUBE WASHER
9	76826-ST3-E01	Valve - ONE WAY
10	76828-ST3-E01	Joint l - WASHER
12	76829-ST3-E01	Joint - RR. WASHER TUBE
13	76830-SN7-G05	Joint y - WASHER
14	76841-S1A-E01	Tank set - WASHER
15	76842-SN7-G05	Bush - WASHER TANK
16	76851-S1A-E01	Bellows - FR. WASHER
24	90652-SN7-G00	Clip - TUBE, 7MM
25	91511-SJ8-003	Clip - WASHER TUBE
26	91539-S1A-E01	Clip - TUBE WASHER

Wire harness (LH) 19

#	OEM	部品名
1	32100-S1B-X10	Harness - R. CABIN WIRE
2	32108-S1A-G31	Harness - RR. WIRE
3	32117-S1B-L10	Harness - INSTRUMENT WIRE
4	32120-S1B-L10	Harness - L. CABIN WIRE
6	32140-S1A-G40	Harness - DRIVER SIDE WIRE
6	32140-S1A-G30	Harness - DRIVER SIDE WIRE
7	32150-S1B-L00	Harness - DASHBOARD WIRE
8	32155-S1A-G30	Cord assy - INTERIOR
10	32160-S1A-G40	Harness - PASSENGER SIDE WIRE
10	32160-S1A-G30	Harness - PASSENGER SIDE WIRE
11	32202-S1A-G00	Cord - RR. DEFROSTER
12	32601-S1B-G00	Cable assy - MISSION EARTH
13	32751-S1A-G30	Harness - DRIVER DOOR WIRE
14	32752-S1A-G30	Harness - PASSENGER DOOR WIRE
14	32752-S1A-G20	Harness - PASSENGER DOOR WIRE
15	32755-S1A-G40	Harness - RR. DOOR WIRE
15	32755-S1A-G30	Harness - RR. DOOR WIRE
17	35505-692-003	Bulb - 14V 1.4W
18	90149-SE0-003	Bolt - EARTH, 6X16
