Accelerator pedal 15

#	OEM	部品名
1	17800-SB2-670	Pedal assy - ACCELERATOR
2	17800-SB2-711	Pedal assy - ACCELERATOR
3	17805-SB2-000	Pad - ACCELERATOR STOPPER
4	17812-SA7-010	Washer - ACCELERATOR PEDAL
5	17814-SB2-000	Spring - ACCELERATOR PEDAL
6	17816-692-000	Cover - ACCELERATOR PEDAL
7	17826-SB2-981	Hook - THROTTLE WIRE
8	17827-SB2-980	Spring - ACCELERATOR PLATE
9	17910-SB3-732	Wire - THROTTLE
10	17910-SB3-772	Wire - THROTTLE
12	17921-SA4-730	Seal - THROTTLE CABLE
14	17931-SB2-660	Stay - THROTTLE WIRE
15	46590-SB3-670	Bracket - PEDAL
16	46597-SB3-710	Stay - COLUMN HANGER
18	90503-SA0-000	Washer - PLAIN, 9MM

Air cleaner 36

#	OEM	部品名
1	16238-PE0-661	Clamp - FUEL HOSE
2	17115-PE0-300	Label - AIR CLEANER (12-VALVE)
3	17150-PA6-004	Valve - CHECK
4	17210-PE3-603	Cover comp. - AIR CLEANER
5	17212-PC0-000	Washer - AIR CLEANER
6	17217-657-000	Clip b - WIRE (DACRO COATING)
7	17218-PE0-000	Clip A - WIRE
8	17220-PE3-601	Element - AIR CLEANER
9	17221-PD2-300	Packing - ELEMENT
10	17222-PE0-300	Seal - VALVE
11	17226-PE3-000	Grommet - AIR CLEANER CASE
13	17240-PE3-881	Case assy. - AIR CLEANER
14	17242-PE0-903	Pipe - AIR INTAKE
15	17244-PE0-010	Clamp - AIR INTAKE PIPE
16	17245-657-013	Diaphragm - CONTROL VALVE
17	17247-PA0-000	Insulator - SENSOR
18	17250-PE0-003	Sensor comp - AIR IN.
19	17251-PE0-300	Valve - AIR CONTROL
20	17253-689-300	Plug - CONTROL VALVE
21	17255-PE0-010	Stay - CLEANER CASE
22	17257-PE3-730	Pin - PLUG LOCK
23	17258-PE0-300	Packing - AIR CLEANER COVER
24	17261-PE0-660	Clamp comp - CABLE (A)
24	17261-PE0-901	Clamp comp - CABLE (A)
25	17266-PE3-000	Insulator - CLEANER CASE
26	17271-PE3-880	Case - BREATHER ELEMENT
27	17272-PE0-000	Packing - BREATHER
29	17274-PE3-880	Element - BREATHER
30	17275-PE0-000	Supporter - BREATHER ELEMENT
31	17318-PE3-881	Protector - BREATHER ELEMENT
33	17415-PE0-000	Plate - RECTIFY
34	17436-PE0-000	Clamp - CORD
35	17436-PG6-900	Clamp - CENTER CORD
39	60581-SB3-000	Duct - AIR CLEANER
40	90070-PC1-000	Screw - TAPPING, 6X16
41	90203-PB2-000	Nut - AIR CLEANER COVER (DACRO COATING)

Air conditioner (COMPRESSOR) 32

#	OEM	部品名
1	38000-SB3-805	Conditioner kit - AIR
2	38011-PE0-020	Clutch set - COMPRESSOR
3	38800-PE0-063	Compressor assy - CN150L
4	38860-PE0-010	Plate - COMPRESSOR HEAT BAFFLE
5	38871-PC0-005	Seal set - SHAFT
6	38920-PE0-013	Belt - COMPRESSOR (BANDO)
6	38920-PE0-014	Belt - COMPRESSOR (MITSUBOSHI)
7	38924-PE0-000	Solenoid comp.
8	38930-PE0-030	Bracket comp. - COMPRESSOR
10	38934-PE0-000	Rubber comp - STOPPER
11	38941-PB8-610	Shim - CLUTCH (1.0)
11	38944-PB8-000	Shim - CLUTCH (1.5)
11	38940-PB8-610	Shim - CLUTCH (1.25)
11	38943-PB8-000	Shim - CLUTCH (1.75)
11	38942-PB8-000	Shim - CLUTCH (2.0)
11	38939-PB8-000	Shim - CLUTCH (0.1)
12	38942-PG6-010	Pulley comp - IDLE
12	38942-PG6-000	Pulley comp - IDLE
13	38944-PE0-000	Collar - IDLE PULLEY
14	38945-PE0-010	Cover - BEARING
14	38945-PE0-000	Cover - BEARING
15	38946-PE0-010	Bolt - IDLE PULLEY
16	47539-SA5-003	Washer
17	90001-PC0-005	Bolt - SPECIAL, 6X17
18	90017-PE0-000	Washer - 10MM
19	90021-PE0-020	Bolt - FLANGE, 8X90
20	90057-PE0-000	Bolt - COMPRESSOR, 10X115
21	90086-444-000	Bolt - FLANGE, 10X45
22	90201-PB8-000	Nut - COMPRESSOR FLANGE, 12MM
23	90601-PC0-005	Circlip - EXTERNAL, 40MM
24	90741-PB8-610	Key - SPECIAL
25	91308-PB8-610	O-ring - 17.4X1.9

Air conditioner (CONDENSER) 22

#	OEM	部品名
1	38600-SB2-667	Condenser assy
1	38600-SB2-053	Condenser assy
2	38602-SB2-020	Bracket - CONDENSER
3	38607-SA5-000	Washer - SPECIAL, 26MM
4	38608-SA5-000	Rubber - MOUNTING
5	38609-SA5-000	Collar - DISTANCE
7	38611-SB2-013	Fan comp - COOLING
8	38612-SB2-033	Motor - COOLING FAN
9	38613-SB2-000	Rubber - MOTOR MOUNT
10	38613-692-000	Collar - MOTOR MOUNTING
11	38614-SB2-000	Cover - SHROUD
12	38615-SB2-040	Shroud comp.
13	60513-SB2-010	Cover - FR. UNDER CENTER
16	62522-SB3-661	Plate - FR. BUMPER UPPER BAFFLE
18	75522-611-003	Grommet - SCREW, 4MM
19	90041-PD2-004	Nut - SPECIAL, 5MM (MITSUBA)
19	90311-MB6-003	Nut toothed 5mm
20	90107-SA7-003	Screw - TAPPING, 4X10
20	90130-693-000	Screw - TAPPING, 4X10
21	90111-SA5-000	Bolt-washer - 6X30
22	90403-PA0-004	Washer - PLAIN, 7MM (MITSUBA)
24	90675-SA5-003	Nut - CLIP, 6MM

Air conditioner (COOLER UNIT; D,P,Y) 38

#	OEM	部品名
1	35850-SB3-013	Switch assy - AIR CONDITIONER
2	37553-SA0-003	Bulb & socket - 14V 1.4W
3	38620-SB2-672	Cooling unit
3	38620-SB2-662	Cooling unit
4	38621-SB2-660	Case - EVAPORATOR UPPER
5	38622-SB2-661	Case - EVAPORATOR LOWER
6	38623-SB2-660	Insulator - EVAPORATOR UPPER
7	38624-SB2-661	Insulator - EVAPORATOR LOWER
8	38625-SB2-000	Holder - EVAPORATOR PIPE
9	38626-SB2-010	Hose - DRAIN
10	38627-SB2-000	Face - DOUBLE
11	38627-692-000	Grommet - DRAIN HOSE
12	38628-SB2-000	Seal - CAP
13	38629-SB2-000	Pad - EVAPORATOR WATER
14	38632-SB2-661	Pipe - LIQUID
14	38632-SB2-671	Pipe - LIQUID (SHOWA)
15	38638-SB2-000	Seal - EVAPORATOR
16	38639-SB2-000	Band b - AIR CONDITIONER
17	38650-SB2-661	Valve assy. - EXPANSION
17	38650-SA7-003	Valve - EXPANSION (FUJI KOKI)
18	38655-SB2-672	Evaporator sub assy. - SHOWA
18	38655-SB2-662	Evaporator sub assy.
19	38660-SB2-003	Thermostat - AIR CONDITIONER (SHOWA)
19	38660-SB2-661	Thermostat - AIR CONDITIONER
20	38710-SB2-781	Harness - AIR CONDITIONER WIRE
21	38725-SA5-003	Diode assy.
22	39795-SB2-003	Relay assy - POWER (4P) (MITSUBA) (RC-2201)
24	39402-SB2-010	Bracket - AIR CONDITIONER RELAY
26	90650-SB2-003	Clip - WIRE HARNESS, 10MM
27	90650-SB2-670	Holder - WIRE HARNESS
28	90651-SB2-003	Clip - WIRE HARNESS, 13MM (GRAY)
29	90653-SA7-003	Purse - LOCK, 11MM
29	90630-751-000	Clip, purse lock
30	90654-SA4-003	Clip - WIRE HARNESS, 6MM (WHITE)
31	90656-PB1-003	Band - OIL HOSE
32	90659-692-000	Clamp - CASE
33	90669-671-003	Strap b - CABLE, 125MM (BLUE)
34	90674-WA8-003	Band - CABLE, 120MM (BLACK)

Air conditioner (HOSES/PIPES; D,P,Y) 32

#	OEM	部品名
1	38601-SA7-000	Rubber - CONDENSER MOUNTING
2	38640-SB2-661	Receiver assy
2	38640-SB2-003	Receiver assy - SHOWA
3	38645-680-961	Switch - PRESSURE
4	38646-692-660	O-ring - 3/8"
4	80874-SL0-900	O-ring - 3/8"
5	38647-692-660	O-ring - 1/2"
6	38648-692-660	O-ring - 5/8"
7	38666-SB2-770	Bracket - SUCTION HOSE
8	38667-SB2-770	Clamp - SUCTION HOSE
9	38668-SB2-770	Stay - SUCTION HOSE
10	38669-SB2-771	Hose comp. b - SUCTION (NICHIRIN)
11	38670-SB2-665	Hose comp. - SUCTION (NICHIRIN)
12	38670-SB2-673	Hose comp. - SUCTION
13	38671-SB2-665	Hose comp. - DISCHARGE (PARKER)
13	38671-SB2-033	Hose comp. - DISCHARGE (NICHIRIN)
14	38674-SB2-010	Clamp - DISCHARGE HOSE
17	38676-SB2-680	Bracket a - SUCTION HOSE
18	38677-SB2-003	Clamp - SUCTION HOSE
19	38681-SB2-673	Pipe a - RECEIVER (SHOWA)
19	38681-SB2-665	Pipe a - RECEIVER (PARKER)
20	38682-SB2-013	Pipe - CONDENSER (SHOWA)
20	38682-SB2-662	Pipe - CONDENSER
21	38683-SB2-676	Glass assy - SIGHT
22	38684-SB2-670	Bracket - SIGHT GLASS
23	38685-SB2-664	Pipe b - RECEIVER
23	38685-SB2-674	Pipe b - RECEIVER (SHOWA)
24	38686-SB2-670	Bracket - RECEIVER PIPE
25	38687-SB2-003	Clip - RECEIVER PIPE
26	38687-SB2-671	Clip - RECEIVER PIPE
27	38687-SB2-920	Clip - SUCTION PIPE
28	38711-692-010	Protector - PRESSURE SWITCH

Air conditioner (TUBE/VALVE) 14

#	OEM	部品名
5	17205-PC6-000	Clamp - TUBE, 7.5X2
7	17363-PE2-013	Clamp - TUBE, 7.5X2
8	36138-PA0-004	Filter assy - SOLENOID VALVE
10	38771-PE0-004	Valve assy. - AIR CONDITIONER SOLENOID
11	38773-PE0-013	Clip - WIRE HARNESS
12	38774-PE3-600	Stay - TUBE CLAMP
14	38775-PE3-600	Stay - SOLENOID VALVE
15	38776-671-000	Cap - AIR FILTER
18	38781-PE3-601	Diaphragm assy.
19	38787-PE3-601	Clip - SPECIAL
21	38788-PE3-600	Stay - WIRE
22	38789-PE3-601	Plate - SETTING
23	38791-PE2-003	Clamp - TUBE, 3.5
24	90092-657-000	Screw-washer - 5X8

Alternator components 26

#	OEM	部品名
1	31100-PE3-762	Alternator assy - CHA33) (DENSO
2	31101-PE0-023	Rotor assy.
3	31105-PD1-024	Holder assy. - ALTERNATOR BRUSH
4	31109-PE1-662	Frame assy - DRIVE END
5	31111-PD1-014	Bearing - RR. GENERATOR
6	31114-PD1-034	Bearing - FR. GENERATOR
7	31116-PE0-013	Plate - RETAINER
8	31118-PD1-004	Bush - INSULATION
9	31119-PH1-004	Bush - INSULATION
10	31121-PE0-003	Frame - RR. END
11	31127-PD1-004	Rectifier assy.
12	31129-PD1-014	Spring - BRUSH (###)
13	31135-PD1-004	Cover - RR. END
14	31138-PD1-004	Cover - BEARING
15	31141-PH7-004	Pulley - ALTERNATOR
16	31142-PD1-004	Nut - PULLEY LOCK
17	31144-PD1-004	Brush
17	31144-P01-003	Brush
18	31145-PD1-004	Bolt - STUD, 6X68
19	31146-PD1-004	Screw-washer - 4X19
20	31148-PD1-004	Screw-washer - 4X25
21	31149-PD1-004	Screw-washer - 4X8 (###)
22	31150-PE0-003	Regulator assy
23	90231-PD1-004	Nut-washer - 5MM
23	90231-PD1-014	Nut-washer - 5MM
24	91415-PE0-003	Clip - CORD

Auto radio 19

#	OEM	部品名
3	39100-SE3-E41	Tuner assy - AUTO RADIO (MW/SW+CASSETTE) (NATIONAL)
3	39100-SE3-Q41	Tuner assy - AUTO RADIO (AM/FM+CASSETTE) (PIONEER)
3	39100-SE3-W01	Tuner assy - AUTO RADIO (AM/FM) (NATIONAL)
6	39103-SC5-601	Knob - OUTER (NATIONAL) (30MM)
7	39103-SC5-701	Knob - OUTER (NATIONAL) (22MM)
8	39104-693-671	Knob - VOLUME & TUNING CONTROL (PIONEER)
8	39104-SC5-601	Knob - INNER (NATIONAL) (26MM)
9	39104-SC5-701	Knob - INNER (NATIONAL) (23MM)
10	39107-SC5-601	Panel
12	39108-SE3-601	Bolt-washer - 5X8
13	39108-693-004	Bolt-washer - 5X8
14	39110-647-771	Fuse - 1A) (PANASONIC
17	39112-SB3-901	Bracket - FR. SPEAKER SEAL
20	39117-SA5-000	Rubber - RADIO MOUNTING
22	39120-SB2-003	Speaker assy. (120mm - MAX.6.3W) (PANASONIC)
25	39152-594-004	Cap - ROOF SEAL
26	39153-SB6-000	Washer - SEAL CAP
27	90105-SB6-003	Screw - PAN, 4X12
28	90502-SA0-003	Washer - WATER PROOF

Body structure components (1) 3

#	OEM	部品名
42	60871-SB2-000	Plate - TIE DOWN
49	90105-634-000	Bolt-washer (8x20)
50	90127-SB2-000	Bolt-washer - 6X12

Brake hose/brake pipe 29

#	OEM	部品名
1	46210-SB2-013	Valve assy. - PROPORTIONING
2	46310-SB2-671	Pipe comp. a - BRAKE
4	46320-SB2-674	Pipe comp. b - BRAKE
6	46321-SB2-674	Pipe comp. h - BRAKE
7	46330-SB3-000	Pipe comp. c - BRAKE
8	46331-SB3-010	Pipe comp. e - R. BRAKE
9	46340-SB3-000	Pipe comp. d - BRAKE
11	46360-SB2-660	Pipe comp. f - BRAKE
12	46361-SB3-010	Pipe comp. e - L. BRAKE
13	46380-594-300	Grommet a - BRAKE PIPE
14	46381-SA0-300	Grommet b - BRAKE PIPE
15	46381-692-300	Grommet b - BRAKE PIPE
17	46391-692-003	Clip s - BRAKE PIPE
18	46392-SB2-014	Clip b - BRAKE PIPE
19	46392-692-003	Clip d - BRAKE PIPE (WHITE)
20	46393-SB2-673	Clip c - BRAKE PIPE
21	46410-SB2-025	Hose - FR. BRAKE (TOYODA)
21	46410-SB2-044	Hose - FR. BRAKE (MEIJI)
21	46410-SB2-023	Hose - FR. BRAKE (NICHIRIN)
22	46430-SB3-024	Hose - RR. BRAKE (MEIJI)
22	46430-SB3-005	Hose - RR. BRAKE (TOYODA)
22	46430-SB3-003	Hose - RR. BRAKE (NICHIRIN)
23	46462-663-670	Bolt - OIL
24	46472-568-000	Packing - OIL BOLT
25	70273-SB3-000	Bracket - R. RR. BRAKE HOSE
26	70278-SB3-000	Bracket - L. RR. BRAKE HOSE
27	70299-SB3-000	Protector - BRAKE PIPE
29	90105-SB0-003	Bolt-washer - 8X16
30	90651-538-000	Clip - BRAKE HOSE

Bumper 29

#	OEM	部品名
9	62511-SB3-010	Face - FR. BUMPER
10	62512-SB3-010	Bracket - FR. BUMPER
12	62514-SB3-661	Stiffener - FR. BUMPER
14	62551-SB3-000	Beam - FR. BUMPER UPPER
15	62521-SB2-000	Nut - LICENSE PLATE
16	62522-SB2-910	Plate - FR. BUMPER SIDE BAFFLE
17	62523-SB2-000	Stopper - BUMPER MOUNTING
18	62525-SB2-003	Bracket - R. FR. BUMPER
19	62535-SB2-003	Bracket - L. FR. BUMPER
20	62535-SB2-900	Bracket - FR. BUMPER MOUNTING
22	62555-SB2-670	Cushion a - FR. BUMPER
25	62557-SB2-671	Cushion c - FR. BUMPER
26	62572-SB0-660	Holder - FR. CUSHION
29	84111-SB3-660	Face - RR. BUMPER
39	84133-SB3-000	Beam - RR. BUMPER UPPER
40	84134-SB2-660	Support - LICENSE PLATE
41	84134-SB4-000	Rubber - BUMPER BOLT
42	84135-SB3-000	Bracket - LICENSE LIGHT
44	84150-SB3-660	Beam comp - RR. BUMPER
46	90105-SA7-000	Screw-washer - 4X16
49	90108-SB2-000	Screw - TAPPING, 5X12
52	90141-SA7-000	Bolt - BUMPER
56	90540-SA7-000	Washer - BUMPER
60	90679-SB3-013	Clip - BUMPER CORNER
61	90680-SB3-003	Clip - CORNER SLIDE
62	90681-SB2-980	Bolt assy - FR. FENDER (GREEN)
63	90688-SB3-660	Nut - R. CLIP, 6MM
64	90698-SB3-660	Nut - L. CLIP, 6MM
66	90880-SB2-000	Bolt-washer - 8X85

Camshaft/timing belt 13

#	OEM	部品名
1	14110-PE4-000	Camshaft comp.
2	14210-PE0-004	Pulley - TIMING BELT DRIVEN
3	14400-PE3-004	Belt - TIMING (UNITTA)
4	14510-PE0-003	Tensioner comp - TIMING BELT (KOYO SEIKO)
4	14510-PE0-005	Tensioner comp - TIMING BELT (NIPPON SEIKO)
5	14513-PE0-015	Bolt - TENSIONER (M6)
6	14516-PE0-010	Spring - TIMING BELT ADJUSTER
7	14517-PG6-000	Bolt a - TENSIONER
8	90011-PE0-000	Bolt - TIMING BELT ADJUSTER SPRING
9	90031-PC6-000	Bolt - FLANGE, 8X22
10	90435-611-000	Washer - SPECIAL, 28X8.5X4.0
12	91213-PE1-721	Oil seal - 29X45X8 (NOK)
12	91213-P2F-A01	Oil seal - 29X45X8 (ARAI)

Carburetor 29

#	OEM	部品名
1	16010-PC3-602	Gasket set
2	16011-PC3-601	Valve set - FLOAT
3	16013-PA1-641	Float set
4	16016-PE4-751	Screw set a
5	16019-PC3-781	Rod set - PUMP
6	16020-PE4-851	Diaphragm assy.
7	16021-PE8-601	Diaphragm set - PUMP
8	16028-PC3-601	Screw set b
9	16032-PE4-771	Rod set - THROTTLE
10	16037-PD3-601	Plate set
12	16041-PE4-772	Economizer set
13	16043-PE4-811	Opener set - THROTTLE
15	16071-PC3-601	Plug
16	16080-PE4-731	Screw-washer
17	16081-PC3-601	Bolt
18	16100-PE4-875	Carburetor assy - DE31A F
18	16100-PE4-885	Carburetor assy - DE31B F
19	16109-PB9-005	Collar - SETTING
21	16134-PC3-601	Clamp
22	16164-PD3-821	Tube - EMULSION SECONDARY
23	16166-PE3-851	Tube - EMULSION PRIMARY
24	16168-634-671	Tube - PRIMARY SLOW EMULSION
26	16181-PC3-781	Pin - SPLIT, 1.2
27	16182-PC3-781	Pin - SPLIT, 1.0
28	16183-PC3-781	Pin - SPLIT, 1.2
29	16199-PC3-601	Tube
30	16230-PE4-732	Valve - FUEL MAGNETIC
31	22415-551-000	Washer - 6.5MM
32	90085-PE3-300	Bolt - STUD, 6X70

Carburetor insulator/ intake manifold 10

#	OEM	部品名
1	16105-PC3-601	Gasket - CARBURETOR INSULATOR
2	16211-PE3-000	Insulator comp. - CARBURETOR
4	16232-PE3-731	Stay - WIRE HARNESS CLIP
5	16237-PE0-010	Clamp - FUEL HOSE
6	17100-PE3-730	Manifold comp - INTAKE
7	17105-PE7-660	Gasket - INTAKE MANIFOLD
8	17132-PE3-000	Stay - INTAKE MANIFOLD
9	17363-PE2-013	Clamp - TUBE, 7.5X2
10	17406-PE4-730	Clamp - CANISTER HOSE
13	90067-PE3-300	Bolt - STUD, 6X41.5

Center console 15

#	OEM	部品名
1	62316-679-003	Grommet - SCREW, 4MM
2	66418-579-000	Stopper - GLOVE BOX LID
9	77703-SB2-000	Bracket - FR. CONSOLE
11	77703-SB3-901	Lid - FR. CONSOLE
14	77704-SB3-901	Frame - FR. CONSOLE
17	77707-SB2-000	Plate - BOOT SETTING
23	77713-SB2-980	Insulator - R. CENTER CONSOLE
25	77714-SB2-980	Insulator - L. CENTER CONSOLE
26	77718-SB3-000	Bracket - FR. CONSOLE
28	77719-SB3-780	Bracket - INSTRUMENT PANEL LOWER
30	77726-SB3-901	Spring - CONSOLE LID
32	77772-SB3-000	Bracket - CENTER CONSOLE
34	90105-SA7-000	Screw-washer - 4X16
35	90662-671-003	Grommet - SCREW, 5MM (WHITE)
36	90683-693-000	Grommet - SCREW, 5MM

Clutch 52

#	OEM	部品名
1	21350-PE0-020	Cover - CLUTCH CASE
1	22500-PF0-902	Clutch assy. - LOW
2	22000-PE1-000	Clutch assy.
2	22510-PF0-000	Guide comp - LOW CLUTCH
3	22100-PE0-000	Flywheel comp.
3	22530-PA9-030	Piston comp - CLUTCH
4	22200-PE0-020	Disk - FRICTION
4	22200-PJ7-000	Disk comp - FRICTION
4	22530-PC9-010	Piston comp - CLUTCH
5	22300-PE1-040	Disk comp - PRESSURE
5	22541-PC9-000	Spring - CLUTCH RETURN
6	90011-PB2-000	Bolt - HEX., 12MM
6	22542-PA9-000	Seat - CLUTCH SPRING
7	90034-689-000	Bolt - TWELVE POINT, 8MM (TOKAI TRW)
8	22543-PA9-000	Plate - CLUTCH (106MM)
9	22543-PC9-000	Plate - CLUTCH (110MM)
10	22544-PA9-020	Disk - CLUTCH
11	22544-PC9-010	Disk - CLUTCH
12	22566-PA9-010	Plate - CLUTCH END (16) (3.65MM)
12	22561-PA9-010	Plate - CLUTCH END (11) (2.15MM)
12	22551-PA9-010	Plate - CLUTCH END (1) (2.3MM)
12	22563-PA9-010	Plate - CLUTCH END (13) (2.75MM)
12	22552-PA9-010	Plate - CLUTCH END (2) (2.6MM)
12	22565-PA9-010	Plate - CLUTCH END (15) (3.35MM)
12	22553-PA9-010	Plate - CLUTCH END (3) (2.9MM)
12	22562-PA9-010	Plate - CLUTCH END (12) (2.45MM)
12	22554-PA9-010	Plate - CLUTCH END (4) (3.2MM)
12	22564-PA9-010	Plate - CLUTCH END (14) (3.05MM)
12	22555-PA9-010	Plate - CLUTCH END (5) (3.5MM)
13	22552-PC9-000	Plate - CLUTCH END (2) (2.5MM)
13	22556-PC9-000	Plate - CLUTCH END (6) (2.9MM)
13	22553-PC9-000	Plate - CLUTCH END (3) (2.6MM)
13	22558-PC9-000	Plate - CLUTCH END (8) (3.1MM)
13	22554-PC9-000	Plate - CLUTCH END (4) (2.7MM)
13	22560-PC9-000	Plate - CLUTCH END (10) (3.3MM)
13	22555-PC9-000	Plate - CLUTCH END (5) (2.8MM)
13	22557-PC9-000	Plate - CLUTCH END (7) (3.0MM)
13	22551-PC9-000	Plate - CLUTCH END (1) (2.4MM)
13	22559-PC9-000	Plate - CLUTCH END (9) (3.2MM)
14	22600-PA9-060	Clutch assy. - SECOND
15	22611-PA9-000	Guide - SECOND CLUTCH
16	22650-PC9-020	Clutch assy. - THIRD
17	22661-PC9-000	Guide comp - THIRD CLUTCH
18	90603-PA9-000	Circlip - EXTERNAL, 40MM
19	90605-PA9-000	Ring - SNAP, 114X1.8
20	90605-PC9-000	Ring - SNAP, 119MM
21	91302-PA9-003	O-ring, 39.8X2.2 (ARAI)
21	91302-PA9-004	O-ring - 39.8X2.2 (NOK)
22	91303-PA9-003	O-ring - 100X2.2(ARAI)
22	91303-PA9-004	O-ring - 100X2.2 (NOK)
23	91303-PC9-004	O-ring - 104X2.2 (NOK)
23	91303-PC9-003	O-ring - 104X2.2 (ARAI)

Clutch housing 18

#	OEM	部品名
1	21000-PE6-040	Case comp. - CLUTCH
2	21101-634-000	Plate - NEEDLE BEARING RETAINING
3	21103-PA0-000	Plate - OIL GUIDE
4	21105-PE6-000	Plate - BREATHER
5	21120-PG2-003	Magnet - TRANSMISSION
8	91005-657-003	Bearing - BALL, 62/22 (FUJIKOSHI)
8	91002-PL0-018	Bearing (62/22)
8	91005-657-004	Bearing - BALL, 62/22 (KOYO)
8	91005-657-008	Bearing - BALL, 62/22(NTN)
8	91002-PL0-008	Bearing - BALL, 62/22C (NTN)
9	91101-PE6-008	Bearing - NEEDLE, 30X47X19
10	91206-PE6-004	Oil seal - 35X56X8 (NOK)
10	91206-PE6-003	Oil seal - 35X56X8 (ARAI)
11	91208-PB6-005	Dust seal - 16X21X4 (NOK)
11	91208-PB6-003	Dust seal - 16X21X4 (ARAI)
12	91215-689-013	Oil seal - 14X25X16
13	91216-PA0-005	Oil seal - 22X35X7 (NOK)
13	91216-PA0-003	Oil seal - 22X35X7 (ARAI)

Clutch pedal/brake pedal 14

#	OEM	部品名
1	22910-SB2-672	Wire comp - CLUTCH
2	22916-SA0-000	Cap c - CUSHION
3	22917-634-000	Seal - CLUTCH WIRE
4	46500-SB3-670	Pedal assy - BRAKE
5	46500-SB3-710	Pedal assy - BRAKE
6	46504-679-300	Bush - PEDAL
7	46505-SA5-000	Pad - PEDAL STOPPER
8	46530-SB2-000	Spring assy - PEDAL RETURN
9	46535-692-000	Collar - PEDAL
10	46540-SB3-000	Spring assy - PEDAL RETURN
11	46545-SA5-000	Cover, Pedal
12	46545-SA5-980	Cover - BRAKE PEDAL
13	46900-SB3-670	Pedal assy - CLUTCH
14	46935-SB2-000	Collar - PEDAL

Clutch release 10

#	OEM	部品名
1	22810-PE6-003	Bearing - CLUTCH RELEASE (FUJIKOSHI)
1	22810-PE6-921	Bearing - CLUTCH RELEASE (NSK)
2	22821-PL0-010	Fork - CLUTCH RELEASE
2	22821-PE6-000	Fork - CLUTCH RELEASE
3	22830-PE6-000	Shaft comp. - CLUTCH RELEASE
4	22851-PE6-000	Spring - RELEASE ARM
5	22871-PE6-010	Stay - CLUTCH WIRE
6	90029-PB6-910	Bolt - SPECIAL, 8X24
7	90081-PB7-000	Screw - SOCKET, 8X20
8	90412-679-000	Washer - CONICAL SPRING, 8MM

Countershaft 45

#	OEM	部品名
1	23220-PA9-671	Countershaft
2	23421-PF0-900	Gear - COUNTERSHAFT LOW
3	23422-PA9-901	Gear - PARKING
4	23441-PF0-910	Gear - COUNTERSHAFT SECOND
5	23451-PF0-910	Gear - COUNTERSHAFT THIRD
6	23531-PA9-000	Gear - COUNTERSHAFT REVERSE
7	23541-PA9-010	Gear - REVERSE IDLE
9	23542-PH0-010	Shaft - REVERSE IDLE GEAR
10	23543-PH0-000	Spring a - IDLE GEAR SHAFT
11	23565-PC9-010	Selector - REVERSE GEAR
11	23565-PC9-000	Selector - REVERSE GEAR
12	23566-PA9-000	Hub - REVERSE SELECTOR
13	90201-689-900	Nut - HEX., 20MM
14	90406-PF0-000	Washer - THRUST, 28X42X2.55
14	90407-PF0-000	Washer - THRUST, 28X42X2.60
14	90401-PF0-000	Washer - THRUST, 28X42X2.30
14	90405-PF0-000	Washer - THRUST, 28X42X2.50
14	90402-PF0-000	Washer - THRUST, 28X42X2.35
14	90403-PF0-000	Washer - THRUST, 28X42X2.40
14	90404-PF0-000	Washer - THRUST, 28X42X2.45
15	90419-PA9-000	Washer - SPLINE, 35X50X3.30
15	90412-PA9-010	Washer - SPLINE, 35X50X3.05
15	90421-PA9-000	Washer - SPLINE, 35X50X3.40
15	90414-PA9-010	Washer - SPLINE, 35X50X3.15
15	90418-PA9-000	Washer - SPLINE, 35X50X3.25
15	90411-PA9-010	Washer - SPLINE, 35X50X3.00
15	90420-PA9-000	Washer - SPLINE, 35X50X3.35
15	90413-PA9-010	Washer - SPLINE, 35X50X3.10
15	90415-PA9-010	Washer - SPLINE, 35X50X3.20
16	90501-PA9-000	Collar - REVERSE GEAR
17	90503-PA9-000	Collar - DISTANCE, 28MM
18	90603-PB6-000	Ring - SNAP, 62MM
19	91004-PA9-003	Bearing - BALL, 6305 (NTN)
20	91011-PG4-003	Bearing - NEEDLE, 32X38X20 (NTN)
20	91011-PA9-004	Bearing - NEEDLE, 32X38X20 (KOYO)
21	91014-PA9-003	Bearing - THRUST NEEDLE, 35X52X2 (NTN)
21	91014-PTD-901	Bearing - THRUST NEEDLE, 35X52X2
22	91016-PA9-003	Bearing - NEEDLE, 28X33X20 (NTN)
22	91016-PG4-003	Bearing - NEEDLE, 28X33X20 (NTN)
22	91016-PA9-004	Bearing - NEEDLE, 28X33X20 (KOYO)
23	91024-PA9-003	Bearing - NEEDLE, 30X36X14 (NTN)
24	91025-639-004	Bearing - NEEDLE, 14X18X15 (KOYO)
24	91025-PJ2-003	Bearing - NEEDLE, 14X18X15 (NTN)
25	91307-PA9-003	O-ring 31.2X1.9 (ARAI)
25	91307-PA9-004	O-ring - 31.2X1.9 (NOK)

Countershaft/ countershaft gear 27

#	OEM	部品名
1	23220-PE6-E00	Countershaft comp.
2	23421-PB7-000	Gear - COUNTERSHAFT LOW
3	23431-PE6-J00	Gear - COUNTERSHAFT SECOND
4	23441-PE6-J00	Gear - COUNTERSHAFT THIRD
5	23451-PE6-J00	Gear - COUNTERSHAFT FOURTH
6	23461-PE6-J00	Gear - COUNTERSHAFT FIFTH
7	23521-PE6-305	Sleeve set - SYNCHRONIZER (1-2)
8	23623-PE6-315	Sleeve set - SYNCHRONIZER (3-4)
9	23914-PE6-000	Collar c - DISTANCE, 25X32X31.8
9	23913-PE6-000	Collar b - DISTANCE, 25X32X31.8
9	23915-PE6-000	Collar d - DISTANCE, 25X32X31.8
9	23912-PE6-000	Collar a - DISTANCE, 25X32X31.8
10	23913-634-008	Spacer - 28MM (+0.04/+0.07)
10	23912-634-000	Spacer - 28MM (+0.07/+0.10)
10	23915-PA0-008	Spacer - 28MM (+0.01/+0.04)
11	23925-634-000	Washer c - THRUST, 32MM (-0.08/-0.11)
11	23921-634-000	Washer a - THRUST, 32MM (-0.02/-0.05)
11	23924-634-000	Washer b - THRUST, 32MM (-0.05/-0.08)
12	23923-671-000	Washer - THRUST, 26MM
13	23926-PB6-000	Washer - SPRING, 22MM
13	23926-PB6-010	Washer - SPRING, 22MM
14	90202-680-000	Nut - HEX., 22MM
15	90603-PE6-000	Ring - SNAP, 65MM
16	91004-PE6-008	Bearing - SPECIAL BALL (NTN)
17	91104-634-006	Bearing - NEEDLE, 32X37X27 (THOMPSON)
17	91104-634-008	Bearing - NEEDLE, 32X37X27 (NTN)
17	91104-634-004	Bearing - NEEDLE, 32X37X27 (KOYO)

Crankshaft 23

#	OEM	部品名
2	13326-634-004	Bearing f - MAIN (PINK) (TAIHO)
2	13324-634-003	Bearing d - MAIN (GREEN) (DAIDO)
2	13321-634-004	BEARING A - MAIN (BLUE) (TAIHO)
2	13327-634-004	Bearing g - MAIN (RED) (TAIHO)
2	13325-634-003	Bearing e - MAIN (YELLOW) (DAIDO)
2	13322-634-004	Bearing b - MAIN (BLACK) (TAIHO)
2	13326-634-003	Bearing f - MAIN (PINK) (DAIDO)
2	13323-634-004	Bearing c - MAIN (BROWN) (TAIHO)
2	13321-634-003	BEARING A - MAIN (BLUE) (DAIDO)
2	13327-634-003	Bearing g - MAIN (RED) (DAIDO)
2	13324-634-004	Bearing d - MAIN (GREEN) (TAIHO)
2	13322-634-003	Bearing b - MAIN (BLACK) (DAIDO)
2	13325-634-004	Bearing e - MAIN (YELLOW) (TAIHO)
2	13323-634-003	Bearing c - MAIN (BROWN) (DAIDO)
3	13331-PD1-004	Washer - THRUST (TAIHO)
3	13331-PD1-003	Washer - THRUST (DAIDO)
4	13621-PE0-003	Pulley - TIMING BELT DRIVE
5	13622-PE0-000	Plate - TIMING BELT GUIDE
6	38921-PE0-670	Pulley - CRANKSHAFT
7	90017-PB2-004	Bolt - SPECIAL, 12MM (SAGA)
7	90017-PB2-003	Bolt - SPECIAL, 12MM (SATO)
8	90402-PB2-000	Washer - 12X30X4.5
9	90704-634-000	Key - 4.5X11.0

Cylinder block/oil pan 33

#	OEM	部品名
1	11000-PE0-040	Block assy - CYLINDER
2	11111-PE0-300	Pipe - OIL LEVEL
3	11200-PE0-020	Pan comp - OIL
4	11251-PE0-004	Gasket - OIL PAN (OTSUKA)
4	11251-P01-004	Packing - OIL PAN (OTSUKA)
4	11251-PE0-003	Gasket - OIL PAN (KOKOKU)
5	11301-PE0-030	Cover - R. SIDE
5	11301-P00-T00	Cover - R. SIDE
6	11810-PE0-020	Cover comp. a - TIMING BELT
7	11812-PE0-300	Grommet - TIMING BELT COVER HOLE
8	11820-PE0-000	Cover comp. b - TIMING BELT
9	11831-PE0-000	Seal a - RUBBER
10	11832-PE0-000	Seal b - RUBBER
11	11840-PE0-000	Cover comp. c - TIMING BELT
12	11910-PE0-030	Bracket - ENGINE MOUNTING
13	11950-PG6-010	Stiffener - ENGINE
14	15140-PE0-000	Orifice - OIL
15	15142-PE0-000	O-ring - 4.8X1.9
16	90008-PE0-003	Bolt-washer - 10X112
16	90007-PE0-003	Bolt - FLANGE, 10X112 (SAGA)
16	90007-PE0-004	Bolt - FLANGE, 10X112 (TOKAI TRW)
17	90009-PC6-000	Bolt - DRAIN PLUG, 14MM
17	90009-PH1-000	Bolt - DRAIN PLUG, 14MM
18	90030-PE0-000	Bolt - STUD, 10X40
19	90031-PE0-000	Bolt - STUD, 10X24,5
20	90041-PA5-000	Bolt - STUD, 6X28
21	90041-PE0-020	Bolt - STUD, 12X30
22	90437-634-000	Washer - SPECIAL, 21X11X2.3
23	90702-PE0-000	Dowel pin - 12X18
24	90703-PE0-000	Dowel pin - 18X22
25	91214-PH1-013	Oil seal - 80X100X10 (NOK)
25	91214-PLE-003	Oil seal
25	91214-PH1-004	Oil seal - 80X100X10 (ARAI)

Cylinder head 17

#	OEM	部品名
1	12100-PE3-020	Head assy - CYLINDER
3	12205-PE0-315	Guide - EX. VALVE
4	12210-PD2-004	Seal a - VALVE STEM (NOK)
4	12210-PD2-003	Seal a - VALVE STEM (ARAI)
5	12211-PE0-004	Seal b - VALVE STEM (NOK)
5	12211-PE0-003	Seal b - VALVE STEM (ARAI)
6	12251-PE3-014	Gasket - CYLINDER HEAD
6	12251-PE0-023	Gasket - CYLINDER HEAD (ISHINO GASKET)
8	14631-PE0-000	Shaft a - VALVE ROCKER ARM
9	14632-PE0-000	Shaft b - VALVE ROCKER ARM
10	90002-PE0-000	Bolt - FLANGE, 8X62
11	90006-PE0-003	Bolt - FLANGE, 10X133
12	90025-PE0-000	Bolt - STUD, 8X35
13	90026-PE0-000	Bolt - STUD, 8X37
13	90026-PT0-000	Bolt - STUD, 8X38
14	90028-PE0-003	Bolt - STUD, 10X132
15	90214-PE0-000	Nut - FLANGE, 10MM

Cylinder head cover 8

#	OEM	部品名
1	12310-PE0-010	Cover comp. - CYLINDER HEAD
3	12341-PE0-000	Gasket - CYLINDER HEAD COVER
4	12345-PE0-300	Emblem - CYLINDER HEAD COVER (H/HONDA MOTOR CO.)
5	15610-PC1-000	Cap assy. - OIL FILLER
6	16239-PE0-000	Clamp - FUEL HOSE
7	90013-PE0-000	Bolt - HEAD COVER
8	90207-PD1-000	Nut - HEAD COVER
9	90441-PD1-000	Washer - HEAD COVER

Differential gear 37

#	OEM	部品名
1	41221-PC8-912	Gear - DRIVE PINION
2	41233-PE6-E00	Gear - FINAL DRIVEN
2	41233-PA9-670	Gear - FINAL DRIVEN
3	41310-PE6-900	Case - DIFFERENTIAL
3	41311-PF0-010	Case - DIFFERENTIAL
3	41311-PF0-020	Case - DIFFERENTIAL
4	41321-PE6-020	Shaft - PINION
4	41312-PA9-000	Gear - SPEEDOMETER DRIVE
4	41312-PA9-010	Gear - SPEEDOMETER DRIVE
5	41341-PC9-000	Gear - DIFFERENTIAL PINION
5	41341-PC9-010	Gear - DIFFERENTIAL PINION
5	41321-PC9-000	Shaft - PINION
6	41353-689-000	Washer c - DIFFERENTIAL PINION (0.9MM)
6	41355-PC8-000	Washer e - DIFFERENTIAL PINION (0.75MM)
6	41357-PC8-000	Washer g - DIFFERENTIAL PINION (0.95MM)
6	41352-689-000	Washer b - DIFFERENTIAL PINION (0.8MM)
6	41354-689-000	Washer d - DIFFERENTIAL PINION (1.0MM)
6	41356-PC8-000	Washer f - DIFFERENTIAL PINION (0.85MM)
6	41351-689-000	Washer a - DIFFERENTIAL PINION (0.7MM)
7	90015-634-010	Bolt - FLANGE, 10MM
8	90416-PE6-000	Set ring - 72MM (3) (2.65)
8	90417-PE6-000	Set ring - 72MM (4) (2.75)
8	90418-PE6-000	Set ring - 72MM (5) (2.85)
8	90419-PE6-000	Set ring - 72MM (6) (2.95)
8	90414-PE6-000	Set ring - 72MM (1) (2.45)
8	90415-PE6-000	Set ring - 72MM (2) (2.55)
8	90003-PA9-003	Bolt - FLANGE, 10MM
9	90425-PF0-000	Washer - THRUST, 26.3X50X1.5
9	90419-634-000	Ring - SNAP, 72MM (2.95MM)
9	90414-634-000	Ring - SNAP, 72MM (2.45MM)
9	90416-634-000	Ring - SNAP, 72MM (2.65MM)
9	90418-634-000	Ring - SNAP, 72MM (2.85MM)
9	90415-634-000	Ring - SNAP, 72MM (2.55MM)
9	90417-634-000	Ring - SNAP, 72MM (2.75MM)
10	91005-PE6-014	Bearing - BALL, 6207 C (KOYO)
10	91005-PE6-008	Bearing - BALL, 6207 C (NTN)
11	90608-PA9-000	Circlip - EXTERNAL, 90MM

Distributor components (TEC) 16

#	OEM	部品名
1	30100-PE3-026	Distributor assy - TD-10I) (TEC
2	30101-PD2-006	Plate assy. - BREAKER
3	30102-PD2-016	Cap assy - TEC
4	30103-PA1-732	Head - ROTOR
5	30104-PE3-016	Control assy. - VACUUM
6	30107-PE1-006	Cover - LEAK
7	30110-PE1-006	O-ring - DISTRIBUTOR (TEC)
8	30111-PA1-733	E-ring - 3.2MM
9	30113-PE1-006	Coupling set - TEC
10	30120-PJ7-003	Igniter unit - OKI
10	30120-PA6-921	Igniter unit - NEC
11	30126-PD2-006	Rotor set - PICK UP
12	30131-PE1-016	Harness assy - DISTRIBUTOR WIRE
13	30132-PA6-921	Gasket - DISTRIBUTOR
14	30148-PA6-921	Screw-washer - 4X11
15	30161-PB1-016	Case - IGNITER UNIT

Door trim (2D) 5

#	OEM	部品名
7	73864-SB3-033	Seal - R. DRIP
9	73869-SB3-033	Seal - L. DRIP
11	90137-SD2-003	Screw - TAPPING, 4X12(SUS)
12	90609-SA6-000	Clip A - PILLAR GARNISH
15	90681-693-000	Grommet - SCREW, 4MM

Driveshaft 19

#	OEM	部品名
1	44010-SB2-962	Driveshaft set - R.
2	44011-SB2-962	Driveshaft set - L.
3	44305-SB2-961	Driveshaft assy. - R.
4	44306-SB2-961	Driveshaft assy. - L.
5	44310-SA5-300	Joint comp - INBOARD
6	44315-SA2-300	Boot b
7	44315-SB2-961	Boot - INBOARD (NOK)
7	44315-SB2-962	Boot - INBOARD (OTSUKA)
8	44316-SA2-310	Band a - BOOT
9	44317-SA2-300	Band b - BOOT
11	44318-SA5-300	Band c - BOOT
12	44318-SA2-300	Band c - BOOT
13	44319-SA2-000	Set ring - 26X1.8
14	44333-SA2-310	Boot a - OTSUKA
15	44333-SB2-962	Boot - OUTBOARD (OTSUKA)
15	44333-SB2-961	Boot - OUTBOARD (NOK)
16	44338-SA2-300	Circlip - 24MM
18	44347-SB2-003	Ring - OUTBOARD
19	90305-692-010	Nut

Emblem 7

#	OEM	部品名
2	19018-PE0-000	Label - FAN CAUTION
3	19043-PH7-750	Mark - RADIATOR CAUTION (130X90)
3	19043-PD3-600	Label - RADIATOR CAUTION (150X115)
4	31511-689-670	Label - BATTERY CAUTION
5	42760-SB3-771	Placard - TIRE PRESSURE
16	87301-SB3-980	Emblem - FR. CENTER (H)
23	87351-SB3-003	Clip - TUBULAR

Engine electrical (1) 13

#	OEM	部品名
1	32722-PE3-600	Cord assy - HIGH TENSION
2	32723-PE0-040	Cord comp - IGNITION CENTER
4	32762-PE1-000	Clamp a - HIGH TENSION CORD
5	32763-PE0-000	Clamp b - HIGH TENSION CORD
6	32764-PE0-000	Clamp c - HIGH TENSION CORD
7	32768-PJ7-000	Clamp - CENTER CORD
7	32765-PA6-000	Clamp - HIGH TENSION CORD
8	32765-PE0-000	Clamp d - HIGH TENSION CORD
11	32777-PE0-000	Clamp - HIGH TENSION CORD
12	90001-PH1-640	Bolt - DISTRIBUTOR (6X20)
12	90001-PD1-000	Bolt - DISTRIBUTOR
14	90482-567-000	Washer - SPECIAL, 6MM
14	90581-831-650	Washer (18mm)

Engine electrical (2) 23

#	OEM	部品名
1	16704-PE0-000	Clamp - TUBE
1	16706-PE0-000	Clamp - TUBE
2	31110-PE0-003	Belt - ALTERNATOR (BANDO)
2	31110-PE0-004	Belt - ALTERNATOR (MITSUBOSHI)
3	31112-PE0-010	Bracket comp. - ALTERNATOR
3	31112-PG6-000	Bracket comp. - ALTERNATOR
4	31113-PE0-000	Stay - ALTERNATOR
5	31117-PE3-730	Plate - CAUTION
6	32110-PE3-753	Sub cord - ENGINE
6	32110-PE3-763	Sub cord - ENGINE
7	32741-PE0-000	Clamp - ENGINE WIRE HARNESS (A)
8	32744-PE0-000	Clamp c - ENGINE WIRE HARNESS
9	32745-PC0-000	Clamp e - ENGINE WIRE HARNESS
10	32745-PE0-000	Clamp - BACK LIGHT HARNESS
11	35600-PE0-013	Switch assy - BACK UP LIGHT (TEC)
12	37240-PD2-003	Switch - OIL PRESSURE (DENSO)
12	37240-PD2-004	Switch - OIL PRESSURE (TEC)
13	37750-PC1-004	Thermo unit - DENSO
16	90016-PE0-000	Bolt - FLANGE, 10X45
17	90050-PE0-000	Bolt - FLANGE, 12X60
18	90051-PE0-000	Bolt - FLANGE, 12X70
19	90057-PG7-003	Bolt - ALTERNATOR
21	90430-657-000	Washer - 23X8.3X3.2

Engine mounts 30

#	OEM	部品名
1	50200-SB2-674	Beam - RR.
2	50210-SB0-000	Grommet - BEAM END
11	50805-SB2-020	Rubber - ENGINE MOUNTING (MT)
11	50805-SB2-982	Rubber - ENGINE MOUNTING (AT)
12	50810-SB2-030	Rubber - ENGINE RR. MOUNTING (MT)
12	50810-SB2-983	Rubber - ENGINE RR. MOUNTING (AT)
13	50811-SB2-000	Bracket - RR. ENGINE MOUNTING STOPPER
14	50820-SB2-934	Rubber assy. - ENGINE SIDE MOUNTING
15	50823-SB2-000	Plate - NUT HOLDER
16	50825-SB2-010	Bracket - ENGINE MOUNTING (MT)
16	50825-SB2-981	Bracket - ENGINE MOUNTING (AT)
17	50827-SB2-010	Bracket - ENGINE RR. MOUNTING
18	91613-SA5-000	Grommet b - CONTROL WIRE
19	90121-SB2-000	Bolt - HEX., 12X95
22	90123-SB2-000	Bolt - FLANGE, 10X78
24	90124-SB2-003	Bolt - HEX., 10X50
25	90125-SB2-000	Bolt - HEX., 12X65
26	90126-SB2-010	Bolt - HEX., 12X53
27	90128-SB2-020	Bolt - FLANGE, 10X53
28	90129-SB2-020	Bolt - FLANGE, 10X41
29	90131-SB2-010	Bolt - HEX., 12X60
30	90132-SB2-000	Screw-washer - NUT PLATE
31	90217-SB2-003	Nut - SELF-LOCK, 12MM
32	90217-SB2-961	Nut - SELF-LOCK, 12MM
33	90350-SB2-000	Nut - TRANSMISSION MOUNTING, 12MM
34	90351-SB2-003	Nut - FLANGE, 8MM
35	90551-SB2-000	Washer - PLAIN, 10MM
36	90504-SB0-000	Washer - PLAIN, 12MM
37	90504-SB2-000	Washer - TRANSMISSION MOUNTING
38	90505-SB2-000	Washer - SIDE MOUNTING

Exhaust manifold (2) 13

#	OEM	部品名
1	11941-PE4-000	Stay - R. EX. MANIFOLD
2	11942-PE4-000	Stay - L. EX. MANIFOLD
3	17302-PE1-003	Pipe - HOT AIR
4	18100-PE4-010	Manifold - EX.
5	18110-PE0-010	Gasket a - EX. MANIFOLD
6	18120-PE1-751	Cover - EX. MANIFOLD
7	18782-PB1-000	Clip - AIR SUCTION TUBE
8	90010-657-010	Bolt - SPECIAL, 8X20
9	90022-PE0-000	Bolt - FLANGE, 8X10
10	90065-PC0-000	Bolt - STUD, 10X35.5
11	90212-PD2-003	Nut - SELF-LOCK, 8MM
11	90212-RCA-A01	Nut - SELF-LOCK, 8MM
12	90451-657-000	Washer - SPECIAL, 9X24X4

Exhaust pipe 23

#	OEM	部品名
6	18210-SB3-602	Pipe a - EX. (FUTABA)
6	18210-SB3-603	Pipe a - EX. (SANKEI)
8	18212-SA5-004	Gasket - EX. PIPE (NIPPON LEAKLESS)
8	18212-671-003	Gasket - EX. PIPE(ISHINO) (59.5MM-60.5MM)
9	18213-SB2-000	Stay - EX. PIPE
11	18214-SB2-020	Bracket - EX. MOUNTING
12	18215-SA7-000	Rubber - SILENCER MOUNTING (70X45X25)
13	18215-SB2-961	Rubber - EX. PIPE MOUNTING
14	18220-SB3-604	Pipe b - EX.
14	18220-SB3-603	Pipe b - EX.
15	18229-SB2-003	Gasket - EX. FLEXIBLE (45MM-59MM)
16	18230-SA0-930	Spring - FLEXIBLE JOINT
17	18231-SB2-000	Bolt - FLEXIBLE JOINT
18	18271-SB3-601	Cover - EX. PIPE HEAT
18	18271-SB3-600	Cover - EX. PIPE HEAT
19	18302-SB2-000	Gasket - SILENCER
20	18307-SB3-602	Silencer comp - EX.
24	72203-SB3-000	Plate - FUEL TANK BAFFLE
25	72209-SB3-020	Plate - SILENCER BAFFLE
27	90115-SB2-003	Nut - SELF-LOCK, 8MM
28	90115-659-003	Nut - SELF-LOCK, 8MM (CLINCH)
29	90117-SB2-000	Nut - SELF-LOCK, 8MM
30	90212-SA5-003	Nut - SELF-LOCK, 10MM

Floor mat/insulator 8

#	OEM	部品名
1	64841-SB3-000	Insulator - R. SIDE COWL
2	64846-SB3-000	Insulator - L. SIDE COWL
3	65841-SB3-670	Insulator - DASHBOARD LOWER
5	83800-SB3-622	Lid comp - SPARE TIRE
10	83863-SA4-000	Cap - TIRE LID
14	90670-SB2-003	Cap - SCREW, 5MM
15	90676-SB2-003	Clip - DASHBOARD INSULATOR
16	90678-SB3-000	Clip - GUIDE INSULATOR

Fresh air vents 13

#	OEM	部品名
1	39385-SA5-000	Stopper - CONTROL LEVER
2	64420-SB3-670	Valve assy. - R. VENT
4	64423-SB3-672	Valve - VENT
5	64424-SB3-670	Plate - R. LEVER BASE
7	64426-SB3-670	Rod - R. SIDE VENT
8	64427-SB3-670	Lever - R. VENT
9	64431-SB3-730	Knob - VENT
10	64440-SB3-670	Valve assy. - L. VENT
11	64442-SB3-670	Seal - VENT VALVE
12	64444-SB3-670	Plate - L. LEVER BASE
13	64446-SB3-670	Rod - L. SIDE VENT
14	64447-SB3-670	Lever - L. VENT
17	90601-SB3-003	Linkage - BUSHING

Front brake caliper 14

#	OEM	部品名
1	45225-579-013	Cap
2	45022-SA0-680	Pad set - FR.
3	45210-SA0-682	Caliper assy - R. (15CL-13ST) (TOKICO)
4	45214-SA0-671	Boot - PISTON
6	45216-SA0-681	Piston
7	45217-SA0-671	Seal - PISTON
8	45224-533-004	Screw - BLEEDER
10	45227-SA0-682	Spring - PAD
11	45228-SA0-681	Shim - BRAKE PAD
12	45230-SA0-682	Caliper assy - L. (15CL-13ST) (TOKICO)
13	45234-SA0-671	Boot - PIN
15	45235-SA0-671	Pin - CALIPER HOLDER
17	45240-SA0-671	Bolt - FLANGE
19	90107-663-670	Bolt - CALIPER MOUNTING

Front combination light 19

#	OEM	部品名
1	33300-SB2-743	Light assy - R. FR. TURN SIGNAL
2	34351-657-921	Bulb - 12V/5W) (STANLEY
3	33301-SB2-003	Lens - R.
4	33303-SB2-003	Packing - STANLEY
5	33350-SB2-743	Light assy - L. FR. TURN SIGNAL
6	33351-SB2-003	Lens - L.
7	33503-506-600	Bulb - 12V 21W) (STANLEY
7	34905-KV7-671	Bulb,winker (12v
7	34908-634-611	Bulb - 12V 21W) (ECE) (STANLEY
10	34352-SB3-023	Cord comp - L.
10	34302-SB3-023	Cord comp - R.
14	34300-SB3-953	Light assy - R. FR. POSITION & SIDE TURN SIGNAL
16	34301-SB3-003	Lens comp - R.
19	34302-693-003	Screw - TAPPING, 4X30
22	34350-SB3-953	Light assy - L. FR. POSITION & SIDE TURN SIGNAL
23	34351-SB3-003	Lens comp - L.
26	75522-611-000	Grommet - SCREW, 4MM
27	90140-SA0-003	Screw - TAPPING, 4X38
28	90303-SA5-003	Nut - FR. COMBINATION LIGHT

Front door lining (2D) 11

#	OEM	部品名
1	73862-672-003	Clip - DOOR WEATHERSTRIP
5	75826-SB3-610	Seal - DOOR HOLE
5	75826-SB3-670	Seal - R. DOOR HOLE
10	75836-SB3-670	Seal - L. DOOR HOLE
13	75851-SB3-660	Weatherstrip - R. DOOR INNER
16	75861-SB3-660	Weatherstrip - L. DOOR INNER
18	75880-SB3-013	Weatherstrip - R. DOOR
19	75885-SB3-013	Weatherstrip - L. DOOR
22	90663-671-003	Clip - LINING
24	90664-671-003	Clip - CANOE
25	90665-SB3-003	Grommet - SCREW, 6MM

Front door locks (2D) 18

#	OEM	部品名
1	72145-SE0-023	Cylinder - R. DOOR
2	72146-SE0-013	Cylinder - L. DOOR
3	75410-SB3-662	Lock assy - R. FR. DOOR
4	75411-634-000	Joint
5	75450-SB3-662	Lock assy - L. FR. DOOR
7	75513-SB2-000	Cushion - LOCK ROD (35MMX58MM)
9	75517-SB3-003	Rod - R. INSIDE LOCK (MITSUI)
10	75518-SB3-003	Rod - R. INSIDE HANDLE (MITSUI)
13	75527-SB3-003	Rod - L. INSIDE LOCK (MITSUI)
14	75528-SB3-003	Rod - L. INSIDE HANDLE (MITSUI)
15	75551-SB2-013	Holder - DOOR LOCK ROD
16	75555-SB2-003	Striker - DOOR LOCK
16	75555-SB2-004	Striker - DOOR LOCK (SHIRAKI)
17	75556-605-010	Bolt - LOCK STRIKER
19	75610-SB3-013	Handle assy - R. OUTSIDE (MITSUI)
20	75611-SB3-003	Ring - OUTSIDE HANDLE (MITSUI)
21	75620-SB3-013	Handle assy - L. OUTSIDE (MITSUI)
22	90111-SA0-000	Screw - TAPPING, 4X8

Front door panels (2D) 9

#	OEM	部品名
12	75750-SB3-014	Checker comp. - DOOR (YANAGISAWA)
12	75750-SB3-003	Checker comp. - DOOR (RIKEN)
13	75760-SB2-003	Pin - DOOR CHECKER
14	75800-SB3-660	Molding assy. - R. DOOR
15	75805-SB3-660	Molding assy. - L. DOOR
16	75864-SB3-000	Clip - DOOR MOLDING
17	75891-SA7-000	Stopper - DOOR
18	90001-SD2-000	Bolt - FLANGE, 8X22
19	90157-SA0-000	Bolt-washer - 8X25

Front door windows/ regulators (2D) 17

#	OEM	部品名
1	75213-SB3-661	Holder - R. FR. SASH
2	75216-SB3-660	Sash - R. DOOR LOWER
3	75223-SB3-661	Holder - L. FR. SASH
4	75226-SB3-660	Sash - L. DOOR LOWER
5	75231-SB3-003	Channel - R. FR. DOOR RUN
6	75236-SB3-003	Channel - L. FR. DOOR RUN
7	75310-SB3-003	Regulator - R. FR. DOOR
8	75320-SB3-003	Regulator - L. FR. DOOR
10	75342-679-000	Pin - WINDOW REGULATOR HANDLE
12	75350-SB3-660	Glass assy - R. FR. DOOR (BLUE)
13	75355-SB3-660	Cushion - DOOR GLASS
14	75360-SB3-660	Glass assy - L. FR. DOOR (BLUE)
15	75839-SB2-660	Seal - R. DOOR MIRROR HOLDER
16	75849-SB2-660	Seal - L. DOOR MIRROR HOLDER
17	90011-896-000	Bolt - FLANGE, 6X8
18	90686-692-003	Cap - LINING MOUNT
24	90105-SA7-000	Screw-washer - 4X16

Front fenders 23

#	OEM	部品名
1	60512-SB2-010	Cover - R. FR. UNDER
2	60513-SB2-010	Cover - FR. UNDER CENTER
3	60515-SB3-020	Cover - R. FR. BUMPER UNDER
4	60522-SB2-020	Cover - L. FR. UNDER
5	60525-SB3-020	Cover - L. FR. BUMPER UNDER
9	61117-SB3-000	Stopper - FR. FENDER
10	61140-SB3-020	Fender - R. FR. INNER
11	61150-SB3-010	Fender - L. FR. INNER
14	61810-SB3-980	Mudguard - R. FR.
15	61815-SA5-013	Clip - FR. MUDGUARD
16	61820-SB3-980	Mudguard - L. FR.
17	81810-SB3-010	Mudguard - R. RR.
18	81820-SB3-010	Mudguard - L. RR.
20	90107-SA0-000	Screw-washer - 5X20
20	90114-SZ3-000	Screw-washer - 5X20
21	90127-SA0-010	Bolt-washer - 6X16
22	90308-SB2-013	Nut - SUSPENSION, 5MM
23	90344-692-003	Nut - CLIP, 6MM
25	90675-SB2-660	Clip - NUT, 6MM
26	90675-SB3-003	Clip - FR. COWL
27	90676-SA7-003	Grommet - SCREW, 5MM (BLACK)
28	90774-SB2-980	Bolt-washer - 6X16(GREEN)
29	90850-SA7-000	Plug - FUSE LID

Front grille 8

#	OEM	部品名
1	60821-SB3-010	Shelter - WATER
3	62301-SB3-020	Grille assy - FR.
4	62302-SB3-730	Bush a - FR. GRILLE
5	62303-SB3-000	Bush b - FR. GRILLE
8	90114-SB3-000	Bolt-washer - 6X12
10	90676-SB3-003	Clip - NUT, 6MM
11	90661-SB3-003	Grommet - SCREW, 4MM
12	90682-SB0-003	Grommet - SCREW, 5MM

Front seat 1

#	OEM	部品名
15	90161-SB4-003	Screw - FLAT, 4X16

Front seat components 7

#	OEM	部品名
9	77510-SB3-671	Adjuster - FREE SLIDE
10	77512-SB2-672	Cap - SLIDE RAIL END
11	77520-SB3-671	Adjuster - R. SLIDE LOCK
12	77530-SB3-671	Adjuster - L. SLIDE LOCK
13	90110-SB3-003	Bolt - PIVOT, 8X17
14	77208-SA5-003	Bush - NYLON (TS TECH)
15	90112-SB3-003	Washer - NYLON

Front shock absorber 12

#	OEM	部品名
1	51601-SB2-937	Absorber assy - R. FR. SHOCK (SHOWA)
2	51602-SB2-937	Absorber assy - L. FR. SHOCK (SHOWA)
3	51605-SB2-936	Absorber unit - R. FR. SHOCK (SHOWA)
4	51606-SB2-936	Absorber unit - L. FR. SHOCK (SHOWA)
5	51687-SB2-024	Cover - FR. DUST (SHOWA)
6	51722-692-005	Rubber - FR. BUMP STOPPER (NOK)
6	51722-692-006	Rubber - FR. BUMP STOPPER (M.T.P. KASEI)
7	51920-SB2-931	Mount comp - SHOCK ABSORBER (TOKICO)
7	51920-SB2-932	Mount comp - SHOCK ABSORBER (SHOWA)
8	51923-SB2-004	Washer - SHOCK ABSORBER MOUNTING (SHOWA)
10	90213-SB2-004	Nut - SELF-LOCK, 12MM (SHOWA)
11	90304-SB2-003	Nut - SELF-LOCK, 10MM

Front stabilizer spring/ front lower arm 52

#	OEM	部品名
1	51225-671-003	Boot - SUSPENSION BALL
2	51300-SB3-963	Spring - FR. STABILIZER
2	51300-SB3-964	Spring - FR. STABILIZER
3	51301-SB2-035	Arm comp - FR. LOWER (NHK SPRING)
3	51301-SB2-039	Arm comp - FR. LOWER (MITSUBISHI SEIKO)
4	51310-SB2-000	Bracket - FR. STABILIZER
5	51311-SB2-000	Rubber a - STABILIZER END
6	51312-SB2-000	Rubber b - STABILIZER END
7	51315-SB3-961	Bush - FR. STABILIZER
8	51316-SB2-010	Collar - FR. STABILIZER
9	51351-SB2-013	Arm comp - R. FR. RADIUS
9	51351-SB6-931	Arm comp - R. FR. RADIUS
10	51361-SB2-013	Arm comp - L. FR. RADIUS
11	51393-SB2-003	Bush - FR. LOWER ARM
12	51396-SB2-003	Bush - RADIUS ARM
13	51401-SB3-776	Spring - R. TORSION BAR (NIPPON HATSUJO)
13	51401-SB3-773	Spring - R. TORSION BAR (MITSUBISHI SEIKO)
13	51401-SB3-775	Spring - R. TORSION BAR (MITSUBISHI SEIKO)
13	51401-SB3-771	Spring - R. TORSION BAR (NIPPON HATSUJO)
13	51401-SB3-774	Spring - R. TORSION BAR (NIPPON HATSUJO)
13	51401-SB3-777	Spring - R. TORSION BAR (MITSUBISHI SEIKO)
14	51402-SB3-773	Spring - L. TORSION BAR (MITSUBISHI SEIKO)
14	51402-SB3-777	Spring - L. TORSION BAR (MITSUBISHI SEIKO)
14	51402-SB3-775	Spring - L. TORSION BAR (MITSUBISHI SEIKO)
14	51402-SB3-771	Spring - L. TORSION BAR (NIPPON HATSUJO)
14	51402-SB3-776	Spring - L. TORSION BAR (NIPPON HATSUJO)
14	51402-SB3-774	Spring - L. TORSION BAR (NIPPON HATSUJO)
15	51406-SB2-000	Clip - TORSION BAR
16	51407-SB2-010	Cap - TORSION BAR
17	51415-SB3-025	Tube comp - R. TORQUE (NIPPON HATSUJO)
17	51415-SB3-035	Tube comp - R. TORQUE
17	51415-SB3-029	Tube comp - R. TORQUE (MITSUBISHI SEIKO)
17	51415-SB3-039	Tube comp - R. TORQUE
18	51416-SB3-025	Tube comp - L. TORQUE (NIPPON HATSUJO)
18	51416-SB3-035	Tube comp - L. TORQUE
18	51416-SB3-029	Tube comp - L. TORQUE (MITSUBISHI SEIKO)
18	51416-SB3-039	Tube comp - L. TORQUE
19	51423-SB2-020	Seal - TORQUE TUBE
20	51424-SB2-003	Washer - HEIGHT ADJUSTER
21	51425-SB2-010	Holder - TORQUE TUBE
22	51426-SB2-000	Cap - TORQUE TUBE
23	53548-611-003	Circlip - CHUO HATSUJO
24	90109-SB2-000	Bolt a - LOWER ARM
25	90110-SB2-000	Bolt b - LOWER ARM
26	90111-SB2-003	Bolt - HEIGHT ADJUSTING
27	90112-SB2-010	Bolt - FR. STABILIZER
28	90114-SB2-000	Bolt-washer - 8X16
29	90303-SB2-003	Nut - SELF-LOCK, 16MM
30	90312-SB2-000	Nut - SELF-LOCK, 8MM
31	90306-SB2-013	Nut - SELF-LOCK, 10MM (CLINCH)
32	90307-SB2-003	Nut - CASTLE, 12MM
33	90311-SB2-013	Nut - HEIGHT ADJUSTER

Front windshield wiper 27

#	OEM	部品名
1	38400-SB3-675	Wiper assy. - WINDSHIELD
2	38401-SB2-672	Motor comp - FR. WIPER
3	38402-SB3-671	Link comp - FR. WIPER
4	38403-SB2-003	Rubber - MOUNTING
5	38405-SB2-003	Rubber - MOUNTING
6	38406-SB2-003	Collar
7	38407-SB2-671	Link a
8	38408-SB3-671	Link b
9	38409-SB3-003	Link c
11	38411-SB2-003	Collar
12	38412-SB2-003	Cap - PIVOT
13	38413-SB2-003	Seal
14	38413-671-003	Seal - DUST
15	38414-SB3-671	Rod unit a
16	38415-SB3-671	Rod unit b
17	38416-SB3-003	Cap - PIVOT
18	38417-SB2-003	Cover - MOTOR
19	38418-SA5-003	Clip - MOTOR COVER
20	38441-SB3-003	Sleeve
21	38442-693-003	Washer
22	38443-SB0-003	Ring c - STOPPER
24	38460-SB3-673	Arm - WINDSHIELD WIPER
25	38461-SB0-671	Nut - WIPER ARM CAP, 8MM
26	38470-SB2-672	Blade - WINDSHIELD WIPER (DRIVER SIDE)
27	38472-SB2-003	Rubber - BLADE (450MM)
27	76632-S5H-T01	Rubber - BLADE (450MM)
28	38480-SB2-672	Blade - WINDSHIELD WIPER (PASSENGER SIDE)

Front windshield/ rear windshield 15

#	OEM	部品名
1	67201-SB3-772	Glass - FR. WINDSHIELD (BLUE) (HALF SHADE GREEN)
2	67205-SB3-020	Rubber - FR. WINDSHIELD DAM
3	67206-SB3-000	Rubber b - WINDSHIELD DAM
4	67210-SB3-010	Bracket - FR. WINDSHIELD
6	67801-SB3-030	Molding - FR. WINDSHIELD
8	67811-SB3-003	Molding comp. - R. FR. SIDE
9	67812-SB3-013	End - R. SIDE MOLDING
10	67816-SB3-003	Molding comp. - L. FR. SIDE
11	67817-SB3-013	End - L. SIDE MOLDING
23	74807-SB3-000	Spacer b - RR. WINDSHIELD
23	74807-SB4-000	Spacer b - RR. WINDSHIELD
24	90115-SB3-003	Clip - FR. SIDE MOLDING
27	90662-693-003	Grommet - SCREW, 4MM (BLUE)
28	90664-SB3-003	Grommet - SCREW, 5MM
30	90854-SB3-000	Screw-washer - 3X7

Fuel Pump 11

#	OEM	部品名
1	16700-PE0-023	Pump assy. - FUEL
2	16701-PE0-000	Insulator comp. - FUEL PUMP
3	16702-PE0-900	Stay - FUEL PUMP COVER
4	16703-PE0-010	Cover - FUEL PUMP
5	16874-PE3-010	Hose comp. - FUEL
6	17262-PE0-660	Clamp comp. b - CABLE
6	17262-PE0-030	Clamp comp. b - CABLE
7	17303-PE1-670	Clamp - HOT AIR PIPE
7	17303-PE0-670	Clamp - HOT AIR PIPE
8	30151-PE0-010	Holder - DISTRIBUTOR
10	91304-PE0-000	O-ring - 60X2.4

Fuel pipe/canister 13

#	OEM	部品名
1	16704-PE0-662	Valve - ONE WAY
2	17300-SA5-711	Canister assy
3	17700-SB3-040	Pipe comp - FUEL FEED
5	17711-SA7-930	Grommet - FUEL PIPE
6	17710-SB3-000	Grommet - FUEL PIPE
7	17712-SA0-000	Grommet - FUEL PIPE
8	17720-SB3-675	Pipe comp. a - VENT
9	17725-SB2-661	Holder - FUEL PIPE
12	17740-SB3-030	Pipe comp - FUEL RETURN
13	17742-SB2-671	Joint - DRAIN TUBE (CANISTER)
15	90664-SB2-003	Clamp - FUEL PIPE
17	90780-SB2-003	Clip - FUEL PIPE
18	90781-SB2-000	Holder - FUEL HOSE

Fuel strainer 11

#	OEM	部品名
1	16900-SA5-004	Strainer comp. - FUEL (TOYO ROKI)
1	16900-SA5-003	Strainer comp. - FUEL (TOKYO ROKI)
3	16903-SB3-020	Bracket - FUEL STRAINER
4	16911-SB3-000	Cover - FUEL FILLER NECK
6	17371-SA5-003	Valve - TWO WAY
7	17663-SB3-000	Stopper - FUEL PIPE
8	17717-SB3-003	Clamp b - FUEL TANK
9	17726-SB3-000	Bracket - TWO WAY VALVE
13	90347-SB3-010	Nut - FLOATING, 6MM
15	90684-SB3-003	Clip - FUEL TUBE
24	16876-SB3-000	Tube assy - FUEL

Fuel tank 36

#	OEM	部品名
1	17500-SB3-040	Tank comp. - FUEL
3	17517-SB2-003	Filter comp - FUEL PIPE
4	17521-SB3-000	Band - R. FUEL TANK MOUNTING
5	17522-SB3-000	Band - L. FUEL TANK MOUNTING
6	17525-SB3-000	Bolt - FUEL TANK MOUNTING
7	17526-SB3-023	Valve - FILLER NECK
9	17651-SB3-000	Tube - FILLER NECK CONNECTING
11	17652-SA5-000	Clip - FILLER TUBE
12	17653-SB3-010	Tube a - BREATHER
14	17654-SB3-000	Tube b - BREATHER
15	17655-SB3-600	Pipe - FUEL BREATHER
16	17657-SB3-010	Cover - FUEL PIPE CONNECTING
18	17659-SB3-010	Connector - FUEL FILLER PIPE
19	17660-SB3-030	Pipe - FUEL FILLER
19	17660-SB3-020	Pipe - FUEL FILLER
22	17662-SB3-000	Packing - FUEL FILLER
24	17664-SB3-670	Plate - FUEL FILLER SETTING
26	17670-SA5-013	Cap comp. - FUEL FILLER
27	17682-679-013	Packing - FUEL FILLER CAP
28	17709-SB3-010	Pipe unit - FUEL
30	37800-SB3-014	Meter unit - FUEL (DENSO)
30	37800-SB3-013	Meter unit - FUEL (NS)
32	37801-689-000	Packing - BASE
33	37802-689-000	Retainer - FUEL UNIT
33	37802-SD2-000	Retainer - FUEL UNIT
36	70495-689-000	Cushion - FUEL FILLER LID
37	73010-SB3-305	Key set - FILLER LID CYLINDER
39	73215-693-003	Striker - FUEL FILLER
40	73220-SB2-003	Lock - FILLER LID
40	73220-SB2-013	Lock - FILLER LID
41	75581-673-000	Spring - LOCK KEY SETTING
41	75581-SB3-000	Spring - LOCK KEY SETTING
43	90602-SA7-931	Clamp - FUEL HOSE, 18.5MM
45	90684-693-013	Clip - FUEL HOSE
46	90691-SB3-000	Clip - WIRE HARNESS (BLACK)
52	90103-SB0-000	Nut - FLANGE, 5MM

Fuel tubing 6

#	OEM	部品名
2	17267-PE0-661	Clamp - CANISTER HOSE
3	17321-PE3-730	Joint - FOUR WAY
4	38778-671-671	Clip - PURSE LOCK
5	36061-PB1-000	Clamp b - TUBE (BLACK)
6	17716-SB3-710	Joint - FUEL TUBE
8	90634-PA0-000	Cap - SEALING

Gasket kit 3

#	OEM	部品名
4	10002-PE4-752	Engine assy - BLOCK (EW2)
5	10003-PE4-731	General assy. - CYLINDER HEAD
6	20011-PE6-J40	Transmission assy - GW-020

Glove box 9

#	OEM	部品名
2	66402-SB3-670	Frame - GLOVE BOX
3	66405-693-000	Stay - GLOVE BOX HINGE
4	66417-SB3-670	Rubber - GLOVE BOX STOPPER
5	66418-SB2-000	Stopper - GLOVE BOX LID
6	66418-579-000	Stopper - GLOVE BOX LID
7	66430-SB2-000	Striker assy - GLOVE BOX
8	66450-SB2-023	Lock assy - GLOVE BOX
9	90103-SA4-000	Screw-washer - 5X18
10	90305-SA0-000	Nut - FLOATING, 4MM

Governor 31

#	OEM	部品名
1	27122-PC9-000	Cover - SHIFT VALVE
2	27300-PF0-903	Governor assy.
2	27300-PF0-902	Governor assy.
2	27300-PF0-904	Governor assy.
3	27310-680-901	Holder comp - GOVERNOR
4	27312-PA9-000	Pipe - 5X65
5	27313-PF4-000	Filter - GOVERNOR
5	27313-PC9-003	Filter - GOVERNOR
6	27314-PC9-000	Plate - GOVERNOR
7	27315-PC9-010	Body assy - GOVERNOR
7	27315-PC9-020	Body assy - GOVERNOR
8	27341-PF0-010	Shaft - GOVERNOR
8	27341-PF0-020	Shaft - GOVERNOR
9	27342-PA9-670	Gear - GOVERNOR
10	27370-PF4-000	Filter assy - EX.
11	27413-PF0-000	Cover - THROTTLE VALVE
12	27414-PF0-900	Plate - THROTTLE SEPARATING
13	27600-PF0-902	Body assy - LOCK UP VALVE
14	27611-PF0-840	Body - LOCK UP VALVE
15	27612-PF0-840	Plate - LOCK UP SEPARATING
16	27621-PF0-020	Valve - LOCK UP SHIFT
17	27623-PF0-902	Spring - LOCK UP SHIFT VALVE
18	27648-PF0-000	Pipe - 6X119
19	90003-PC9-000	Bolt - FLANGE, 6X96
21	90011-PF0-000	Bolt - FLANGE, 6X108
22	90024-612-000	Bolt - SEALING, 8MM
23	90433-PF4-000	Washer - LOCK, 6MM
24	90433-639-000	Washer - LOCK, 6MM
25	90451-PC9-000	Washer - THRUST, 14MM
26	90471-580-000	Packing - 8MM
27	90741-PA9-000	Key - WOODRUFF, 3MM

Grommet 22

#	OEM	部品名
1	32169-647-010	Grommet - WASHER TUBE (18MM)
3	60625-SB3-000	Valve - DRAIN
5	60675-SB3-000	Seal - FR. PILLAR INNER LOWER (70X100)
6	60676-SB3-000	Seal b - FR. PILLAR INNER LOWER
7	60677-SB3-000	Seal c - FR. PILLAR INNER LOWER
9	61109-623-670	Grommet - FR. FENDER
10	70225-SB2-000	Seal - HOLE
15	72206-SA5-000	Cap - FLOOR HOLE, 53MM
17	72827-601-000	Plug - SEATBELT ANCHORAGE
18	75826-SB3-300	Seal - DASHBOARD UPPER HOLE, 30MM
19	75826-605-300	Seal - DOOR HOLE, 30MM (CIRCLE) (BLACK)
20	75826-634-300	Seal - INSIDE PANEL, 15MM
21	76841-672-000	Seal - RR. DOOR LOCK HOLE
22	82871-671-000	Grommet - DRAIN HOLE, 25MM
24	90651-SB3-003	Clip - DRAIN VALVE
28	90684-SB2-000	Plug - HOLE, 40X90
29	90694-SA5-000	Grommet - WASHER TUBE HOLE
31	90851-SA0-000	Plug - WASHER HOLE
33	90851-SB2-000	Plug - AIR CONDITIONER HOLE
35	90852-671-003	Plug - HOLE
42	91617-SB6-000	Grommet - WASHER HOSE, 32MM
43	91610-SB2-003	Plug - HOLE, 16.7MM (BLACK)

Headlight 19

#	OEM	部品名
2	33100-SB3-723	Headlight assy - R.
3	33101-SB3-722	Housing comp - R.
5	33102-SB3-951	Stay comp - R. (1)
6	33103-SB3-951	Stay comp - R. (2)
9	33104-SB3-951	Stay comp - R. (3) (HELLA)
10	33105-SB3-952	Garnish - R. HEADLIGHT
11	33106-SB2-731	Screw - TAPPING, 6X20
13	33113-SB2-751	Screw - TAPPING, 4X20
15	33126-SB3-003	Cover - RUBBER
16	33127-SA5-951	Tube - DRAIN
16	39127-SB2-305	Cap - HEADLIGHT DRAIN
20	33150-SB3-723	Headlight assy - L.
21	33151-SB3-722	Housing comp - L.
21	33151-SB3-622	Housing comp - L.
22	33152-SB3-951	Stay comp - L. (1)
23	33153-SB3-951	Stay comp - L. (2)
24	33154-SB3-951	Stay comp - L. (3) (HELLA)
25	33155-SB3-952	Garnish - L. HEADLIGHT
26	34901-390-611	Bulb - HEADLIGHT (12V 45/40W) (LOCAL PROCUREMENT PART)

Heater blower 9

#	OEM	部品名
2	39242-671-000	Fan - HEATER
3	39246-671-003	Clamp - CASE HOLD
4	39410-SB3-676	Blower assy
5	39430-SA5-003	Motor assy.
6	39432-SA5-003	Packing
7	39473-SB2-043	Resistor - BLOWER (4P)
8	39480-SB2-671	Duct - HEATER
9	90307-SA0-003	Nut - FLANGE, 5MM
10	90501-671-003	Washer - SPECIAL

Heater duct 3

#	OEM	部品名
2	64482-SB3-670	Duct a - INSTRUMENT JOINT
4	70382-SB3-000	Duct - R. RR. OUTLET
5	70482-SB3-000	Duct - L. RR. OUTLET

Heater lever 27

#	OEM	部品名
1	35455-512-003	Nut
2	35505-692-003	Bulb - 14V 1.4W
3	35650-SB3-013	Switch assy - HEATER FAN
4	35651-SB3-003	Knob - FAN SWITCH
5	39330-SB3-672	Control assy. - HEATER
6	39342-SB3-670	Panel - HEATER CONTROL
7	39343-SB3-670	Guide - SLIDER
8	39344-SB3-000	Slider
9	39351-SB3-671	Lever a
10	39352-SB3-671	Lever b
11	39353-SB3-670	Lever - FRESH & RECIRCULAR CONTROL
12	39371-SB3-670	Cable - TEMPERATURE CONTROL
13	39372-SB3-670	Cable - MODE CONTROL
14	39373-SB3-000	Cable - FRESH RECIRCULAR
15	39381-SB3-020	Knob - HEATER CONTROL
16	39381-SB3-621	Knob - HEATER CONTROL
17	39382-680-000	Collar - CONTROL LEVER
18	39383-SA5-000	Clamp - CONTROL CABLE
19	39384-SB3-000	Shaft - CONTROL LEVER
20	39385-SA5-000	Stopper - CONTROL LEVER
21	39386-SB3-000	Clamp - HEATER CONTROL
22	39387-SB3-790	Spacer - HEATER CONTROL
23	39388-SB3-000	Spring - CONTROL LEVER
24	39390-SB3-623	Illumination assy. - HEATER
25	39395-SB3-003	Lid - AIR CONDITIONER SWITCH HOLE
26	90130-693-000	Screw - TAPPING, 4X10
27	90657-SB3-000	Spring b - HEATER CONTROL

Heater unit 8

#	OEM	部品名
1	39210-SB3-675	Heater unit
4	39228-SB2-671	Holder - PIPE
5	39233-692-003	Nut - INSTRUMENT PANEL
6	39245-SB2-003	Core comp - HEATER
7	39246-671-003	Clamp - CASE HOLD
8	39248-692-003	Packing - HEATER
9	39282-SB2-003	Bolt - HEATER SETTING
10	39297-SB3-003	Cover - HEATER CORE

Hood 28

#	OEM	部品名
1	38405-SB3-000	Cap - AIRSCOOP SEAL
3	60637-SB3-661	Flap - AIR IN.
5	60642-SB3-003	Grommet - SCREW, 4MM (WHITE)
8	60644-SB3-000	Seal - AIRSCOOP LOWER
12	60651-SB3-664	Garnish assy - AIRSCOOP
14	60652-SB3-660	Garnish assy - R. AIRSCOOP
17	60657-SB3-003	Rubber - RR. HOOD SEAL
19	60658-SB3-000	Cap - AIRSCOOP
19	60658-SD2-000	Cap - AIRSCOOP GARNISH
21	60659-SB3-660	Garnish assy - L. AIRSCOOP
23	63117-SB3-000	Protection - HOOD
27	63413-SB3-000	Stopper - HOOD HINGE
29	63415-SB4-000	Shim - HOOD HINGE
30	63415-SB3-300	Cover - HOOD HINGE
32	63441-SB2-010	Stay - HOOD OPENER
33	63450-SB3-662	Wire comp - HOOD
35	63455-SA0-000	Grommet - HOOD WIRE
36	63510-SB3-013	Lock assy - HOOD
37	63511-SA5-003	Cushion - HOOD
38	70576-688-000	Grommet a - SIDE PANEL, 23MM
39	90102-SB3-000	Bolt - HINGE STOPPER
41	90651-692-731	Nut - NYLON, 3MM
43	90659-SB2-003	Clip - SEAL, 6MM
45	90670-SA0-000	Grommet - HOOD STAY
46	90670-SA7-003	Clip - CABLE HOLDER
47	90671-SA0-003	Holder - ROD
48	90697-SB2-003	Clip - HOOD WIRE
50	90127-SA0-010	Bolt-washer - 6X16

Ignition coil/battery 10

#	OEM	部品名
1	30500-PE0-006	Coil assy - IGNITION (TEC)
4	30501-PE0-000	Bracket - IGNITION COIL
5	30510-SB2-682	Condenser comp. - PANASONIC
5	30510-SB2-683	Condenser comp. - SHOWA
6	31500-507-671	Battery - 32C 24R) (YUASA
7	31512-SB2-010	Plate - BATTERY SETTING
8	31513-SB2-000	Bolt - BATTERY SETTING
9	31521-SB2-010	Box assy - BATTERY
9	31521-SR3-000	Box assy - BATTERY
10	31542-SA0-612	Plug - VENT (YUASA)

Instrument lower panel (D,P,Y) 9

#	OEM	部品名
1	64410-SB3-620	Outlet assy - R. FRESH AIR
6	66161-SB2-000	Label - COIN
8	66162-SB3-000	Spring - COIN POCKET
9	66188-SB3-000	Label - FUSE
13	66418-579-000	Stopper - GLOVE BOX LID
16	66843-SA5-670	Clip - RADIO PANEL
18	66844-SB3-000	Clip - INSTRUMENT PANEL LOWER
19	66846-SB3-670	Bracket a - LOWER COVER
24	90651-692-731	Nut - NYLON, 3MM

Instrument panel (D,P,Y) 35

#	OEM	部品名
1	60647-SB3-660	Stay - STEERING HANGER
2	60679-SB3-660	Bracket - R. INSTRUMENT PANEL
3	62316-679-003	Grommet - SCREW, 4MM
7	64475-SB3-000	Hinge - CENTER OUTLET
9	64499-SB3-000	Bush - FRESH AIR
10	64521-SB3-670	Panel - WIDE FLOW
12	64524-SB3-670	Spring - WIDE FLOW
13	64525-SB3-000	Link - WIDE FLOW
14	64526-SB3-000	Valve - WIDE FLOW
15	64527-SB3-000	Shaft - WIDE FLOW
16	64529-SB3-000	Seal - WIDE FLOW
17	64530-SB3-000	Stopper - WIDE FLOW KNOB
19	64539-SB3-000	Pin - WIDE FLOW
25	66241-SB3-670	Bracket - METER FRAME
26	66242-SB3-670	Stay - METER FRAME
29	66831-SB3-000	Guide assy - R. DEFROSTER
30	66836-SB3-000	Guide assy - L. DEFROSTER
31	66838-SB3-670	Bracket - INSTRUMENT PANEL HANGER (LH)
32	66839-SB3-671	Stay - INSTRUMENT LOWER
33	66840-SB3-670	Box assy - CLOCK
34	66844-SA7-000	Cap - INSTRUMENT PANEL STAY
35	66847-SB3-671	Frame - INSTRUMENT LOWER
36	66848-SB3-671	Stay - INSTRUMENT PIPE
37	66849-SB3-670	Bracket - RADIO
38	66886-SB3-000	Bracket - R. INSTRUMENT PANEL SIDE
39	66887-SB3-000	Bracket - L. INSTRUMENT PANEL SIDE
40	90101-SA4-000	Screw - TAPPING, 4X12
41	90102-SA4-000	Screw - TAPPING, 4X16
42	90105-SA7-000	Screw-washer - 4X16
43	90107-693-000	Nut - FLOATING, 5MM
44	90128-SA7-000	Bolt-washer - 6X25
45	90128-SB0-000	Bolt-washer - 6X30
47	90302-SA4-003	Nut - SPRING, 4MM
48	90454-SB3-000	Circlip - 6MM
49	90651-692-731	Nut - NYLON, 3MM

Interior light 6

#	OEM	部品名
2	34252-SB2-003	Lens - DAIICHI
4	34260-SA0-013	Light assy - TRUNK ROOM
5	34262-SA0-003	Lens
6	34295-SA5-003	Bulb - 12V 3.4W) (DAIICHI
7	34295-538-003	Bulb - 12V 5W) (DAIICHI
7	34295-SD4-003	Bulb - 12V 5W.K

Knuckle 16

#	OEM	部品名
1	44300-SB2-965	Bearing assy - FR. HUB (TOYO SEIKO)
1	44300-SB2-966	Bearing assy - FR. HUB (TOYO SEIKO)
1	44300-SB2-963	Bearing assy - FR. HUB (KOYO SEIKO)
1	44300-SX8-004	Bearing assy - HUB
1	44300-SB2-962	Bearing assy - FR. HUB (FUJIKOSHI)
1	44300-SB2-964	Bearing assy - FR. HUB (NSK)
2	44610-SB2-960	Hub - FR.
3	45251-SB2-730	Disk - FR. BRAKE
4	45255-SA7-980	Guard - SPLASH
5	51211-SB2-930	Knuckle - R.
6	51216-SB2-930	Knuckle - L.
7	90113-SA0-023	Bolt - WHEEL (TOKAI TRW)
7	90113-SM1-005	Bolt - WHEEL (ROCKNEL FASTENER)
7	90113-SA0-015	Bolt - WHEEL (NAGOYA RASHI)
8	90120-SB2-003	Bolt - SHOCK ABSORBER LOCK
9	91055-SB2-960	Circlip - INTERNAL, 72MM

Main fuse/horn 19

#	OEM	部品名
1	38100-SA5-003	Horn assy - LOW
3	38200-SB3-674	Box assy - FUSE (FURUKAWA)
3	38200-SB3-673	Box assy - FUSE (SUMITOMO)
4	38205-SB3-741	Label - FUSE
4	38205-SB3-721	Label - FUSE
5	38207-SA0-004	Terminal - SHORT
6	38230-SA5-003	Fuse b - 10A) (FURUKAWA
7	38235-SA5-003	Puller - FUSE (SUMITOMO)
7	38235-SB0-003	Puller - FUSE (FURUKAWA)
8	38250-SB2-901	Box assy - MAIN FUSE
9	38251-SB2-000	Bracket - FUSE BOX
11	38300-SE3-003	Relay assy - TURN SIGNAL & HAZARD (FR-3309) (MITSUBA)
11	38300-SE3-004	Relay assy - TURN SIGNAL & HAZARD (166500-0060) (DENSO)
12	38310-SB3-030	Bracket - RELAY
15	38965-SB2-681	Alarm assy - BELT & KEY (DENSHI GIKEN)
16	39797-SE0-003	Relay assy - POWER (4P) (DENSO) (056700-7330)
16	39797-SE0-004	Relay assy - POWER (4P) (MITSUBA) (RC-2201)
19	90101-SA4-000	Screw - TAPPING, 4X12
26	90153-SB2-003	Screw-washer - 5X10

Main valve body/regulator 36

#	OEM	部品名
1	22741-PF0-000	Pipe - LOW CLUTCH
2	24461-PA9-000	Spring - ROLLER
2	24461-PA9-010	Spring - ROLLER
3	24471-612-000	Roller - 6X16
4	25145-PA9-010	Shaft - OIL PUMP GEAR
5	27000-PF0-900	Body assy - MAIN VALVE
6	27105-PF0-910	Body sub assy. - MAIN VALVE
7	27112-PF0-901	Plate - MAIN SEPARATING
8	27122-PC9-000	Cover - SHIFT VALVE
9	27122-PF0-900	Cover - TIMING VALVE
10	27200-PF0-010	Regulator assy
11	27211-PF0-840	Body - REGULATOR VALVE
12	27221-PC9-000	Valve - REGULATOR
13	27231-PC9-911	Spring a - REGULATOR VALVE
14	27232-PF4-000	Spring b - REGULATOR VALVE
15	27233-PA9-000	Spring - REACTION STATOR
16	27246-PA9-000	Cap - REGULATOR SPRING
17	27247-PA9-000	Seat - REACTION SPRING
18	27255-PC9-710	Spring - TORQUE CONVERTER CHECK VALVE
19	27256-PA9-000	Valve - RELIEF
20	27256-639-000	Valve - TORQUE CONVERTER CHECK
21	27257-PA9-000	Spring - RELIEF VALVE
22	27258-680-900	Seat - RELIEF VALVE SPRING
23	27419-PC9-010	SEAT, VALVE SPRING
24	27421-PF0-901	Valve - MANUAL
25	27521-PF0-900	Valve - REVERSE SHIFT
26	27522-PF0-900	Spring - REVERSE SHIFT
27	27631-PC9-810	Valve - LOCK UP TIMING
28	27631-PF0-900	Valve - LOCK UP TIMING
29	27632-PF0-810	Spring - GOVERNOR CUT
30	27633-PF0-900	Spring - LOCK UP TIMING VALVE
31	27634-PF0-000	Valve - CONTROL
32	27635-PF0-000	Spring - CONTROL VALVE
33	27637-PF0-000	Cover - CONTROL VALVE
34	27644-PF0-900	Spring - LOCK UP CUT VALVE
36	90089-PC9-000	Bolt - STOPPER, 6MM

Mainshaft 36

#	OEM	部品名
1	22814-PA9-023	Ring - SEALING, 32MM
2	23210-PF0-910	Mainshaft comp.
3	23411-PF0-900	Gear - MAINSHAFT LOW
4	23431-PF0-910	Gear - MAINSHAFT THIRD
5	90201-PA9-000	Nut - FLANGE, 19MM
6	90420-PA9-000	Washer - SPLINE, 35X50X3.35
6	90414-PA9-010	Washer - SPLINE, 35X50X3.15
6	90411-PA9-010	Washer - SPLINE, 35X50X3.00
6	90419-PA9-000	Washer - SPLINE, 35X50X3.30
6	90413-PA9-010	Washer - SPLINE, 35X50X3.10
6	90421-PA9-000	Washer - SPLINE, 35X50X3.40
6	90415-PA9-010	Washer - SPLINE, 35X50X3.20
6	90418-PA9-000	Washer - SPLINE, 35X50X3.25
6	90412-PA9-010	Washer - SPLINE, 35X50X3.05
7	90417-PA9-000	Washer - 26 X 45 X 4
8	90422-PA9-000	Washer - THRUST, 26MM
9	90506-PC9-000	Collar - DISTANCE, 20MM
10	90508-PA9-000	Collar - 26MM
11	90603-689-900	Circlip - EXTERNAL, 20MM
12	90609-PA9-000	Ring - SNAP, 68MM
13	90613-PA9-000	Ring - SNAP, 26MM
14	91002-PA9-003	Bearing - BALL, 63/26 (NTN)
15	91011-PG4-003	Bearing - NEEDLE, 32X38X20 (NTN)
15	91011-PA9-004	Bearing - NEEDLE, 32X38X20 (KOYO)
16	91011-428-008	Bearing - NEEDLE, 20X26X20
16	91011-P48-008	Bearing - NEEDLE, 20X26X20
17	91012-PA9-003	Bearing - NEEDLE, 31X36X18.5
18	91014-PA9-003	Bearing - THRUST NEEDLE, 35X52X2 (NTN)
18	91014-PTD-901	Bearing - THRUST NEEDLE, 35X52X2
19	91018-PA9-003	Bearing - THRUST NEEDLE, 32X44X2 (NTN)
19	91018-P56-003	Bearing - THRUST NEEDLE, 32X44X2 (NTN)
20	91019-PA9-013	Bearing - THRUST NEEDLE, 31X47X2
21	91307-PA9-003	O-ring 31.2X1.9 (ARAI)
21	91307-PA9-004	O-ring - 31.2X1.9 (NOK)
22	91308-PA9-003	O-ring - 19.8X1.9 (ARAI)
22	91308-PA9-004	O-ring - 19.8X1.9 (NOK)

Mainshaft/mainshaft gears 31

#	OEM	部品名
1	23211-PE6-J00	Mainshaft
2	23261-PB7-000	Shaft - REVERSE IDLE GEAR
3	23540-PE6-000	Gear - REVERSE IDLE
4	23581-PE6-J00	Gear - MAINSHAFT FIFTH
5	23626-PE6-900	Sleeve set - SYNCHRONIZER (5)
7	23951-PE6-000	Shim u - 1.575
7	23946-PE6-000	Shim p - 1.325
7	23941-PE6-000	Shim k - 1.55
7	23936-PE6-000	Shim f - 1.3
7	23948-PE6-000	Shim r - 1.425
7	23943-PE6-000	Shim m - 1.175
7	23938-PE6-000	Shim h - 1.4
7	23933-PE6-000	Shim c - 1.15
7	23950-PE6-000	Shim t - 1.525
7	23945-PE6-000	Shim o - 1.275
7	23940-PE6-000	Shim j - 1.5
7	23935-PE6-000	Shim e - 1.25
7	23931-PE6-000	Shim a - 0.5
7	23947-PE6-000	Shim q - 1.375
7	23942-PE6-000	Shim l - 1.125
7	23937-PE6-000	Shim g - 1.35
7	23932-PE6-000	Shim b - 1.1
7	23949-PE6-000	Shim s - 1.475
7	23944-PE6-000	Shim n - 1.225
7	23939-PE6-000	Shim i - 1.45
7	23934-PE6-000	Shim d - 1.2
8	23931-634-960	Plate - THRUST, 25MM
9	90602-PE6-000	Ring - SNAP, 45MM
10	91003-PE6-018	Bearing - RADIAL BALL, 6304
11	91102-PE6-008	Bearing - NEEDLE, 28X45X20
12	91108-PE6-008	Bearing - NEEDLE, 25X30X23

Master cylinder 17

#	OEM	部品名
1	31185-PE0-660	Guard comp - ALTERNATOR
2	46100-SA5-023	Cylinder assy. - MASTER
3	46120-SF4-003	Piston assy. - PRIMARY
3	46120-SA5-003	Piston assy. - PRIMARY
4	46122-SA5-013	Piston assy. - SECONDARY
5	46126-SA5-013	Cup - SECONDARY
6	46138-568-671	Packing
7	46139-632-000	Bolt - STOPPER
9	46181-SA5-013	Plate - RETURN STOPPER
10	46182-SA5-013	Circlip
11	46183-SA5-013	Bush
12	46185-SA5-003	Seal - VACUUM
13	46660-SC2-003	Tank - RESERVE
14	46662-692-023	Cap comp. - RESERVE TANK
15	46665-671-651	Band - RESERVE TANK
16	46666-692-013	Filter - MASTER CYLINDER
17	46669-692-003	Seal - RESERVE TANK

Master power 27

#	OEM	部品名
1	06464-SB2-000	Power set - MASTER (7")
4	46151-SB2-003	Yoke - PUSH ROD (NISSIN)
5	46191-634-000	Gasket - MASTER CYLINDER BRACKET
6	46400-SB2-003	Power assy. - MASTER (7") (NISSIN)
7	46401-SA5-013	Valve assy. - CHECK
9	46404-SB3-733	Tube a - MASTER POWER
11	46405-SB2-662	Tube b - MASTER POWER
12	46407-SB2-670	Clamp - MASTER POWER TUBE
17	46411-692-003	Seal - PISTON
18	46412-671-003	Bush
19	46413-671-003	Bush - STOPPER
20	46417-692-003	E-ring
21	46418-671-003	Element a
22	46419-692-003	Element b
23	46425-SA0-003	Ring - SNAP
24	46426-SA0-003	Rubber - REACTION
25	46431-692-003	Spring - VALVE
26	46432-SA0-003	Spring - POPPET
27	46433-SB2-003	Rod comp - PUSH
28	46443-692-003	Adjuster - PUSH ROD
29	46446-SA5-003	Seal - TIE ROD
30	46447-SA5-003	Boot - TIE ROD
31	46448-SA5-003	Stopper - ROD
32	46451-SA5-003	O-ring
33	46452-SA5-003	E-ring
34	46512-SB2-000	Pin - PEDAL
35	53729-671-003	Clamp d - 15.5MM

Mirror/sunvisor 22

#	OEM	部品名
1	34267-693-003	Socket
2	35505-692-003	Bulb - 14V 1.4W
10	88011-SB3-010	Holder set - FR. ASHTRAY
12	88141-SB3-000	Holder - RR. VIEW MIRROR
14	88145-SB2-953	Base - STAY (MURAKAMI)
16	88147-SB2-952	Plate - SPRING (MURAKAMI)
17	88148-SB2-952	Bolt - LOCK, 6X7 (MURAKAMI)
18	88150-SB3-743	Mirror assy - R. DOOR
19	88153-SB3-742	Mirror - R. (MATSUYAMA)
20	88154-SA7-003	Knob - DOOR MIRROR (MATSUYAMA)
21	88155-SB3-743	Mirror assy - L. DOOR
22	88158-SB3-742	Mirror - L. (MATSUYAMA)
23	88159-SA7-003	Cap - DOOR MIRROR KNOB (MATSUYAMA)
24	88171-SB3-670	Garnish - R. DOOR MIRROR
26	88176-SB3-670	Garnish - L. DOOR MIRROR
33	88324-SA0-000	Cover - RR. ASHTRAY
34	90102-SA4-000	Screw - TAPPING, 4X16
35	90110-SA7-003	Screw-washer - 3X16 (MATSUYAMA)
36	90116-SA0-000	Screw - TAPPING, 4X12
38	90302-SA4-003	Nut - SPRING, 4MM
39	90670-SB0-003	Clip - DOOR SASH GARNISH
40	90686-692-003	Cap - LINING MOUNT

Oil filter/ oil level gauge 13

#	OEM	部品名
1	11311-PG6-000	Cover - BREATHING PORT
2	11855-PC6-000	Grommet - PCV VALVE
3	11856-PE3-010	Tube comp - PCV
4	11850-PG6-000	Chamber - BREATHER
5	15220-PE0-010	Strainer comp. - OIL
6	15221-PE0-010	Packing - OIL STRAINER
7	15400-PA6-004	Filter - OIL (TOYO ROKI)
7	15400-PA6-003	Filter - OIL (TOKYO ROKI)
7	15400-PA6-506	OILFILTER CARTRID
10	15650-PE0-030	Gauge comp. - OIL LEVEL
11	17130-PE0-003	Valve assy. - PCV
15	90015-689-000	Holder - OIL FILTER
17	91324-PC6-000	O-ring - 20.6X2.6

Oil pump 14

#	OEM	部品名
1	15100-PE1-730	Pump assy. - OIL
2	15110-PE0-030	Body - OIL PUMP
3	15112-PE0-010	Cover - OIL PUMP
4	15131-PE0-013	Rotor - PUMP INNER (SUMITOMO)
5	15132-PE0-003	Rotor - PUMP OUTER (SUMITOMO)
6	15231-PE0-000	Valve - RELIEF
7	15232-PB2-000	Spring - RELIEF VALVE
8	15233-634-000	Seat - RELIEF VALVE SPRING
9	15301-PE0-300	Bolt - SEALING, 14MM
10	15302-PE0-300	Washer - SEALING, 14MM
11	90020-PE0-000	Bolt - STUD, 8X28
12	90041-PA5-000	Bolt - STUD, 6X28
13	91212-PE0-662	Oil seal - 31X46X8
14	91307-PE0-010	O-ring - 25X2.4

Oil strainer/ speedometer gear 16

#	OEM	部品名
1	23811-689-020	Holder comp - SPEEDOMETER GEAR
2	23813-689-000	Plate - SPEEDOMETER GEAR HOLDER
3	23814-689-000	Seal - GEAR HOLDER
4	23820-PF0-920	Gear - SPEEDOMETER DRIVEN
5	25155-PF0-010	Shaft assy - STATOR
6	25420-PA9-000	Strainer - TRANSMISSION
7	25610-PF0-850	Gauge comp. - ATF
8	25910-639-000	Joint a - OIL HOSE
9	25951-639-000	Bolt - JOINT
10	25960-PA9-020	Joint - OIL HOSE
14	90637-689-000	Clip - SPEEDOMETER CABLE
15	90638-689-000	Clip - SPEEDOMETER GEAR
16	91301-250-000	O-ring - 21.5MM
16	91307-425-003	O-ring - 21.5X3.2
17	91313-611-010	O-ring - 23.5X2
18	91316-612-000	O-ring - 27.5X1.7

Parking brake 13

#	OEM	部品名
1	47105-SB3-000	Lever assy. - PARKING BRAKE
2	47142-659-310	Knob - PARKING BRAKE PUSH ROD
3	47143-671-310	Spring - PUSH ROD
4	47342-SA5-013	Switch - PARKING BRAKE
5	47360-SB2-000	Equalizer
6	47365-538-000	Pin - EQUALIZER
7	47510-SB3-073	Wire a - R. PARKING BRAKE
8	47522-594-000	Nut - PARKING BRAKE ADJUSTING
9	47530-SB3-000	Stay - PARKING BRAKE WIRE
10	47537-671-670	Spring - PARKING BRAKE ROD
11	47560-SB3-073	Wire a - L. PARKING BRAKE
12	47570-SB2-000	Guide - PARKING BRAKE WIRE A
14	90125-679-003	Bolt - LOCK, 8MM

Piston/connecting rod 23

#	OEM	部品名
1	13011-PE3-004	Ring set - PISTON (STD.)
1	13021-PE3-004	Ring set - PISTON (OS 0.25)
2	13102-PE4-000	Piston - OS 0.25
2	13101-PE4-000	Piston - STD
3	13112-PE0-000	Pin - PISTON
4	13204-PE1-003	Bolt
5	13205-689-004	Nut - CONNECTING ROD (NAGOYA RASHI)
5	13205-634-010	Nut
6	13210-PE1-000	Rod assy - CONNECTING
7	13215-PE1-004	Bearing e - CONNECTING ROD (YELLOW) (TAIHO)
7	13214-PE1-003	Bearing d - CONNECTING ROD (GREEN) (DAIDO)
7	13217-PE1-003	Bearing g - CONNECTING ROD (RED) (DAIDO)
7	13213-PE1-004	Bearing c - CONNECTING ROD (BROWN) (TAIHO)
7	13212-PE1-003	Bearing b - CONNECTING ROD (BLACK) (DAIDO)
7	13216-PE1-004	Bearing f - CONNECTING ROD (PINK) (TAIHO)
7	13215-PE1-003	Bearing e - CONNECTING ROD (YELLOW) (DAIDO)
7	13211-PE1-004	BEARING A - CONNECTING ROD (BLUE) (TAIHO)
7	13214-PE1-004	Bearing d - CONNECTING ROD (GREEN) (TAIHO)
7	13213-PE1-003	Bearing c - CONNECTING ROD (BROWN) (DAIDO)
7	13217-PE1-004	Bearing g - CONNECTING ROD (RED) (TAIHO)
7	13216-PE1-003	Bearing f - CONNECTING ROD (PINK) (DAIDO)
7	13212-PE1-004	Bearing b - CONNECTING ROD (BLACK) (TAIHO)
7	13211-PE1-003	BEARING A - CONNECTING ROD (BLUE) (DAIDO)

Quarter window (2D) 28

#	OEM	部品名
1	73100-SB3-305	Glass assy - R. QUARTER
2	73141-SB3-000	Pin - QUARTER WINDOW LOCK
3	73145-SB3-000	Seal - QUARTER WINDOW PIN
4	73146-671-000	E-clip
5	73200-SB3-305	Glass assy - L. QUARTER
7	73612-SB3-000	Stay a - QUARTER WINDOW
9	73614-SB3-003	Grommet - QUARTER WINDOW HINGE
10	73615-SB3-000	Grommet - QUARTER WINDOW HINGE UPPER
11	73622-SB3-000	Stay b - QUARTER WINDOW HINGE
13	73803-SB3-010	Garnish - R. RR. PILLAR
14	73805-SB3-000	Molding - QUARTER WINDOW LOWER
15	73808-SB3-010	Garnish - L. RR. PILLAR
16	73810-SB3-010	Garnish - R. CENTER PILLAR
17	73815-SB3-010	Garnish - L. CENTER PILLAR
20	73860-SB3-921	Seal - QUARTER (BLACK) (TOKAI KOGYO)
22	74200-SB3-315	Glass assy - RR. WINDSHIELD (BLUE/DEFOGGER)
22	74200-SB3-791	Glass assy - RR. WINDSHIELD (BLUE)
23	74205-SB3-000	Rubber - RR. WINDSHIELD DAM
24	74206-SB3-000	Trim - RR. WINDSHIELD
25	74801-SB3-000	Molding - RR. WINDSHIELD
26	74802-SB3-003	Molding assy. - TAILGATE
27	74803-SB3-003	Spacer - RR. WINDSHIELD
28	74808-SB3-000	Spacer c - RR. WINDSHIELD
29	75522-611-000	Grommet - SCREW, 4MM
31	90656-SB3-003	Clip - RR. PILLAR GARNISH
32	90668-SA7-000	Grommet - ADJUST SCREW
34	90673-SB3-003	Clip - TAILGATE MOLDING
36	90853-SB3-000	Screw - PAN, 4X10

Radiator (DENSO) 12

#	OEM	部品名
1	19010-PE1-665	Radiator comp - DENSO
1	19010-PE1-675	Radiator comp - DENSO
2	19011-PA0-003	Cock - DRAIN (DENSO)
3	19012-PA0-003	Packing - DRAIN (DENSO)
3	19012-ZB5-003	Packing, drain
4	19015-PE0-023	Shroud comp - DENSO
5	19020-PE0-003	Fan - COOLING (DENSO)
6	19030-PE0-023	Motor - COOLING FAN (DENSO)
7	19045-692-003	Cap comp. - RADIATOR (DENSO)
8	90041-PE0-003	Screw-washer - 4X10 (DENSO)
9	90042-PA6-003	Bolt-washer - 6X10 (DENSO)
10	90043-PD2-003	Nut - HEX., 5MM (DENSO)

Radiator (TOYO) 16

#	OEM	部品名
1	19010-PE1-666	Radiator comp - TOYO
1	19010-PE1-676	Radiator comp - TOYO
2	19011-PA0-004	Cock - DRAIN (TOYO)
3	19012-PA0-004	Packing - DRAIN (TOYO)
4	19015-PE0-024	Shroud comp - TOYO
5	19020-PE0-004	Fan comp - COOLING (MITSUBA)
6	19030-PE0-024	Motor - COOLING FAN (MITSUBA)
7	19045-PA0-014	Cap comp. - RADIATOR (TOYO)
7	19045-692-003	Cap comp. - RADIATOR (DENSO)
8	32175-647-920	Clip - WIRE HARNESS
8	30701-883-000	Clip, high tension cord (8mm)
9	90041-PA6-004	Screw-washer - 4X18 (TOYO)
10	90041-PD2-004	Nut - SPECIAL, 5MM (MITSUBA)
10	90311-MB6-003	Nut toothed 5mm
11	90042-PE0-004	Bolt-washer - 6X12 (TOYO)
12	90403-PA0-004	Washer - PLAIN, 7MM (MITSUBA)

Radiator hose/ reserve tank 31

#	OEM	部品名
1	17724-102-700	Clip - SUB TANK HOSE
2	19021-PE0-020	Rubber - RADIATOR MOUNTING
3	19025-PE0-010	Bush - RADIATOR MOUNTING
4	19028-PE0-000	Plate - RUBBER SETTING
6	19101-PE2-010	Tank comp. - RESERVE
8	19102-692-010	Cap - RESERVE TANK
10	19103-PA0-660	Hose - RESERVE TANK
10	19103-671-000	Hose - RESERVE TANK
12	19104-PE2-000	Tube - RESERVE TANK
14	19105-PE2-010	Mark - RESERVE TANK
16	19106-689-000	Joint - RESERVE TANK
17	19107-PA0-000	Clip - RESERVE TANK JOINT
18	19108-PE2-000	Filler - COOLANT
19	19109-PE2-000	Cap - FILLER
20	19110-PE2-000	Stay - FILLER
21	19111-PE2-010	Tube - FILLER
22	19114-PE0-003	Clamp - RESERVE TANK TUBE
23	19501-PE0-010	Hose - WATER UPPER
24	19502-PE0-020	Hose - LOWER WATER
24	19502-PE0-900	Hose - LOWER WATER
25	19511-PA6-003	Clip - WATER HOSE(CHUO SPRING)
26	25213-PE0-900	Hose - OIL COOLER, 750
27	25213-639-902	Hose - OIL COOLER, 400MM (YAMASHITA)
27	25213-639-900	Hose - OIL COOLER, 400MM (MEIJI)
29	37760-PB2-003	Switch assy - THERMOSTAT (A-90) (NIPPON THERMOSTAT)
30	60785-SB2-000	Cushion a - RADIATOR MOUNTING
31	90635-671-000	Clip - OIL HOSE
32	39228-PA0-901	Band - HOSE, 220MM
33	91307-611-000	O-ring (13.5X1.4)
33	91307-PH7-660	O-ring (13.5X1.4)
34	90003-PG7-660	Bolt-washer - 6X16 (DACRO COATING)

Rear brake drum 21

#	OEM	部品名
1	42200-SB2-018	Bearing assy - HUB UNIT (TOYO SEIKO)
1	42200-SB2-015	Bearing assy - HUB UNIT (FUJIKOSHI)
2	42324-SB2-020	Washer - HUB UNIT
3	42326-SB2-000	Cap - HUB UNIT
3	42326-SFA-000	Cap - HUB UNIT
4	42400-SB2-015	Housing unit - SWING BEARING (FUJIKOSHI)
4	42400-SB2-018	Housing unit - SWING BEARING (TOYO SEIKO)
5	42411-SB2-000	Ring - HOUSING UNIT
6	42610-SB2-010	Drum - RR. BRAKE
7	52210-SB2-020	Spindle assy - R. RR. WHEEL
8	52211-SB2-020	Spindle assy - L. RR. WHEEL
9	90113-SA0-015	Bolt - WHEEL (NAGOYA RASHI)
9	90113-SM1-005	Bolt - WHEEL (ROCKNEL FASTENER)
9	90113-SA0-023	Bolt - WHEEL (TOKAI TRW)
10	90116-SB2-003	Bolt - HOUSING UNIT, 11X27
11	90210-SB2-003	Bolt - AXLE BEAM, 11X66
12	90214-SB2-023	Bolt - AXLE BEAM, 11X33
13	90215-SB2-004	Nut - SELF-LOCK (FUSE RASHI)
14	90402-SB2-000	Nut - HUB
14	90305-692-010	Nut
15	91252-SB2-013	Seal - HUB UNIT (NOK)

Rear brake shoe 39

#	OEM	部品名
1	43110-SB2-033	Plate comp - R. RR. BRAKE BACKING
1	43110-SB2-043	Plate comp - R. RR. BRAKE BACKING
2	43120-SB2-043	Plate comp - L. RR. BRAKE BACKING
2	43120-SB2-033	Plate comp - L. RR. BRAKE BACKING
3	43153-SB2-602	Shoe comp - RR. BRAKE
3	43153-SB2-601	Shoe comp - RR. BRAKE
4	43171-SC2-003	Spring a - R. BRAKE
5	43172-SA5-003	Spring b - BRAKE SHOE RETURN
6	43172-SC2-003	Spring a - L. BRAKE
7	43300-SB2-003	Cylinder assy. - R. RR. WHEEL
8	43301-SB2-003	Cylinder assy. - L. RR. WHEEL
9	43315-671-631	Cover - DUST
9	43315-SN4-003	Cover - DUST
10	43321-SA3-681	Piston - WHEEL CYLINDER
11	43322-663-003	Cup - PISTON
12	43323-663-003	Spring - RR. WHEEL CYLINDER
13	43345-SA5-013	Plug - ADJUSTER
14	43352-568-003	SCREW, BLEEDER (NISSIN)
14	43352-567-000	Screw - BLEEDER
15	43353-548-003	Cap - BLEEDER SCREW
16	43361-SC2-003	Lever - R. PARKING BRAKE
17	43362-SC2-003	Rod a - R. CONNECTING
18	43363-SA5-003	Bolt - R. ADJUSTER
19	43364-SA5-003	Rod b - CONNECTING
19	43364-S5A-003	Rod b - CONNECTING
20	43365-SA5-003	Pin - PARKING BRAKE LEVER
21	43366-SC2-013	Lever comp - R. ADJUSTER
22	43367-SC2-003	Spring - R. ADJUSTER
23	43371-SC2-003	Lever - L. PARKING BRAKE
24	43372-SC2-003	Rod a - L. CONNECTING
25	43373-SA5-003	Bolt - L. ADJUSTER
26	43375-SA0-003	U-clip
27	43376-SC2-013	Lever comp - L. ADJUSTER
28	43377-SC2-003	Spring - L. ADJUSTER
29	43379-SC2-013	Washer - WAVE
30	45172-SA0-003	Spring - SHOE CLAMP
30	45172-S04-003	Spring - SHOE CLAMP
31	45175-SA0-003	Pin - TENSIONER
32	90215-SB2-004	Nut - SELF-LOCK (FUSE RASHI)

Rear seat (1; 2D) 6

#	OEM	部品名
7	78152-SB3-013	Knob - R. RR. SEAT
8	78154-SB3-003	Cover - R. LOCK
10	78159-SB3-013	Damper
13	78162-SB3-013	Knob - L. RR. SEAT
14	78164-SB3-003	Cover - L. LOCK
19	78185-SB3-003	Striker - RR. SEAT

Rear shelf 9

#	OEM	部品名
1	75353-671-000	Lock - SCREW
3	83826-SB3-920	Holder - CENTER SHELF
8	83885-SB3-921	Retractor assy - RR. SHELF
9	83886-SB3-920	Hook - RR. SHELF
11	83892-693-930	Slider - SHELF LOCK
12	83893-693-930	Plate - SHELF LOCK
13	83894-SB3-920	Knob - RR. SHELF
15	83898-SB3-921	Cover - RR. SHELF PIVOT
16	85822-SB3-921	Stopper - RR. SHELF

Rear shock absorber 15

#	OEM	部品名
1	42107-SB2-020	Protector - RR. SHOCK ABSORBER
2	52441-SB3-772	Spring - RR.
3	52610-SB3-024	Absorber assy - RR. SHOCK
4	52611-SB3-024	Absorber unit - RR. SHOCK (SHOWA)
5	52621-SB3-000	Washer - RR. SHOCK ABSORBER MOUNTING
6	52622-SB2-004	Bush - RR. SHOCK ABSORBER LOWER (HOKUSHIN)
7	52687-SB2-004	Cover comp. - RR. SHOCK ABSORBER DUST (SHOWA)
8	52691-SB2-007	Rubber - RR. SPRING SEAT UPPER
9	52722-SB2-005	Rubber - RR. BUMP STOPPER (NOK)
9	52722-SB2-006	Rubber - RR. BUMP STOPPER (POLYURETHAN KASEI)
10	52725-SB2-013	Rubber - RR. SHOCK ABSORBER MOUNTING (YAMASHITA)
10	52725-SB2-016	Rubber - RR. SHOCK ABSORBER MOUNTING (INOUE)
11	52728-SB2-004	Collar - RR. SHOCK ABSORBER MOUNTING(SHOWA)
12	72208-SB3-000	Cap - RR. SHOCK ABSORBER MOUNTING
13	90213-SB0-004	Nut - SELF-LOCK, 10MM (SHOWA)

Rear side lining (2D) 5

#	OEM	部品名
15	83863-671-000	Cap - RR. LINING
16	90609-SA6-000	Clip A - PILLAR GARNISH
19	90669-SB3-010	Holder - SIDE LINING
21	90681-693-000	Grommet - SCREW, 4MM
22	90691-SB2-003	Clip - LINING

Rear stabilizer/ rear lower arm 16

#	OEM	部品名
1	42100-SB2-010	Beam assy - RR. AXLE
3	42120-SB2-000	Cap - BEAM, 58MM
9	52350-SB2-010	Rod comp - PANHARD
10	52357-SB2-010	Bush b - INNER PIPE
11	52361-SB2-007	Bush a - PANHARD ROD
12	52362-SB2-007	Bush b - PANHARD ROD
13	52364-SB2-000	Washer - PANHARD ROD
14	52371-SB3-794	Arm comp - R. RR. TRAILING
15	52372-SB3-793	Arm comp - L. RR. TRAILING
16	52384-SB2-605	Bush comp - TRAILING ARM
18	90020-SB2-023	Bolt - SELF-LOCK, 12X87
19	90021-SB2-003	Bolt - SELF-LOCK, 10X68
20	90210-SB2-003	Bolt - AXLE BEAM, 11X66
21	90211-SB2-003	Bolt - AXLE BEAM, 11X37
23	90345-SB2-003	Nut - SELF-LOCK, 12MM (CAP)
24	90439-SB2-010	Washer - SPECIAL, 24X12X2.3

Roof lining 4

#	OEM	部品名
5	71851-SB3-000	Molding comp. - R. ROOF
6	71856-SB3-000	Molding comp. - L. ROOF
7	90666-SB3-003	Clip - ROOF MOLDING
8	90667-692-003	Clip - ROOF LINING

Seatbelt 1

#	OEM	部品名
8	77690-SB3-750	Bag - PROTECTOR

Select lever (AT) 19

#	OEM	部品名
1	30158-700-010	E-clip - 3MM
2	35505-692-003	Bulb - 14V 1.4W
3	37700-SB2-772	Lamp assy. - INDICATOR (AT)
4	54110-SB2-980	Stopper comp - SELECT LEVER
5	54113-692-980	Collar - LOCK PIN
6	54115-SB2-980	Bolt - SELECTOR STOPPER
7	54117-692-980	Spring - LOCK PIN
8	54119-689-981	Pin - LOCK
9	54120-SB2-980	Spring - SELECT STOPPER
10	54123-SA0-980	Collar - SELECT LEVER
12	54132-SA5-982	Knob - PUSH
13	54133-SA5-981	Spring - PUSH KNOB
14	54135-SB3-980	Lever - SELECT
15	54136-SB3-980	Rod comp - LOCK PIN
16	54204-SB2-980	Guide - WIRE HARNESS
17	54211-SA0-713	Case - INDICATOR LAMP
18	54222-689-980	Cover - SELECT LEVER
19	54710-SB3-720	Escutcheon comp. - CONSOLE
20	90114-SA0-000	Nut - SELF-LOCK, 6MM

Select lever bracket (AT) 11

#	OEM	部品名
1	54201-SA0-980	Bracket - SELECT LEVER
2	54202-SB2-980	Bracket - CONTROL
3	54205-SB2-980	Clamp - WIRE HARNESS
4	54317-SB2-980	Holder - CONTROL WIRE
5	54318-SB2-980	Seal - CONTROL
6	54319-SB3-980	Seal - CONTROL WIRE BRACKET
7	54347-SA0-980	Pin a - CONTROL ROD
8	54351-SB3-980	Bracket - CONTROL WIRE
9	54360-689-981	Adjuster assy - CONTROL WIRE
10	54363-689-981	Pin - CONTROL WIRE ADJUSTER
11	90308-SA0-981	Nut - SELF-LOCK, 6MM

Servo body 14

#	OEM	部品名
1	22743-PF0-000	Pipe - THIRD CLUTCH
2	24272-PF0-010	Shaft b - SHIFT FORK
2	24271-PF0-010	Shaft a - SHIFT FORK
2	24273-PF0-900	Shaft c - SHIFT FORK
2	24272-PF0-900	Shaft b - SHIFT FORK
2	24273-PF0-010	Shaft c - SHIFT FORK
2	24271-PF0-900	Shaft a - SHIFT FORK
3	25422-PC9-000	Magnet - TRANSMISSION
4	25423-PC9-010	Spring - MAGNET HOLDER
5	27405-PF0-912	Body set - SERVO
5	27405-PF0-911	Body set - SERVO
6	27412-PF0-900	Plate - SERVO SEPARATING
7	27861-PF0-000	Spring - SERVO RETURN
10	91344-580-000	O-ring - 31X2.7 (ARAI)

Shift fork/fork shaft 15

#	OEM	部品名
1	24201-PB7-940	Fork - FIFTH GEARSHIFT
2	24211-PB7-000	Fork - TOP GEARSHIFT
3	24221-PE6-600	Fork - LOW GEARSHIFT
4	24242-PB7-000	Piece - TOP SHIFT
5	24243-PE6-910	Piece - REVERSE SHIFT
6	24251-PE6-600	Shaft - TOP FORK
7	24261-PE6-600	Shaft - LOW FORK
8	24271-PE6-610	Shaft - FIFTH & REVERSE FORK SHIFT
9	24282-634-000	Bolt - SHAFT FORK SETTING
10	24452-PB6-020	Spring a - BALL SETTING
11	24519-PB6-000	Screw - BALL SPRING SETTING
12	90432-634-020	Plate - LOCK, 6MM
13	90439-634-000	Plate - LOCK, 6MM
13	90439-PH8-000	Washer - LOCK, 6MM
13	90439-634-010	Plate - LOCK, 6MM

Shift lever (MT) 25

#	OEM	部品名
1	54101-SB3-000	Lever - CHANGE
2	54102-SB3-913	Knob comp. - CHANGE LEVER (5MT)
3	54104-SB2-000	Dust seal a - CHANGE
4	54105-692-010	Washer - THRUST
5	54107-SA0-010	Bush, RR. JOINT
6	54108-SA7-000	Boot - CHANGE LEVER
7	54108-SB2-000	Boot - CHANGE LEVER
8	54110-692-020	Seat - CHANGE LEVER BALL
9	54113-611-000	Clip - CHANGE JOINT PIN
9	54113-611-010	Clip - SHIFT JOINT PIN
10	54114-SB2-000	Collar - PIPE MOUNTING
11	54114-692-020	Dust seal b - CHANGE
12	54117-692-000	Collar - RR. JOINT
13	54119-692-010	Stopper - CHANGE LEVER BALL
14	54201-SB3-911	Rod comp - CHANGE
15	54301-SB3-000	Extension
16	54303-SB2-010	Rubber, EXTENSION END
17	54304-689-000	Washer a - EXTENSION END
18	54305-SA0-000	Washer b - EXTENSION END
19	54306-SB2-000	Rubber - EXTENSION MOUNTING
20	54307-SB2-000	Stopper - EXTENSION MOUNTING
21	90115-659-003	Nut - SELF-LOCK, 8MM (CLINCH)
23	91301-671-671	O-ring - 1.9X11
23	91303-HA0-004	O-ring, 11x1.9 (nok)
24	91351-689-000	O-ring - 35X3

Shift lever shaft 29

#	OEM	部品名
1	24111-PA9-010	Fork - REVERSE SHIFT
2	24282-634-000	Bolt - SHAFT FORK SETTING
3	24411-PA9-900	Shaft - CONTROL
4	24412-PC9-000	Lever - CONTROL
5	24414-PA9-010	Pin - CONTROL
6	24415-PA9-000	Roller - CONTROL LEVER
7	24421-PA9-300	Lever - MANUAL VALVE
8	24423-PA9-000	Pin - MANUAL VALVE
9	24425-639-000	Roller - MANUAL VALVE
10	24532-689-900	Lever - PARKING BRAKE
11	24535-PA9-010	Spring - PARKING BRAKE
12	24538-PA9-003	Stopper - PARKING BRAKE (2)
12	24537-PA9-003	Stopper - PARKING BRAKE (1)
12	24539-PA9-003	Stopper - PARKING BRAKE (3)
13	24552-PA9-000	Spring - PARKING BRAKE PAWL
14	24553-612-000	Roller - PARKING BRAKE
15	24555-PA9-000	Pin - ROLLER, 6MM
16	24561-PA9-030	Pawl - PARKING BRAKE
17	24562-PA9-000	Shaft - PARKING BRAKE
18	24901-PA9-000	Holder - CONTROL WIRE
19	27490-PC9-000	Shaft - THROTTLE VALVE
20	27494-PF0-000	Lever - THROTTLE CONTROL
21	27495-PA9-000	Spring - THROTTLE LEVER
22	90001-PA9-000	Bolt - HEX., 6MM
23	90010-PA9-000	Bolt - SPECIAL, 5X12
24	90433-639-000	Washer - LOCK, 6MM
25	90436-PA9-000	Washer - LOCK, 5MM
26	90607-081-000	Circlip - 7MM
27	90701-639-000	Dowel pin - 8X55

Shift rod/shift arm 24

#	OEM	部品名
1	24231-PB7-961	Fork - REVERSE SHIFT
2	24311-PE6-000	Rod - GEARSHIFT
3	24316-679-000	Boot
4	24342-PB7-960	Shaft b - SHIFT ARM
5	24411-PB7-000	Arm - GEARSHIFT
6	24420-PB7-961	Arm comp. b - GEARSHIFT
7	24425-PB7-960	Holder comp - ARM B
8	24428-PA0-960	Plate - ARM B HOLDER
9	24429-634-000	Bar - INTERLOCK
10	24431-PA0-000	Retainer - SELECT SPRING
11	24432-PA0-000	Retainer - REVERSE SELECT
12	24453-PB7-000	Spring - REVERSE STOPPER
13	24454-PB6-000	Spring b - BALL SETTING
14	24454-PB7-000	Spring - REVERSE SELECT
15	24455-PB7-010	Spring b - REVERSE STOPPER
16	24461-PB6-000	Collar - SPRING
17	24461-679-000	Collar - SPRING
18	24621-PB7-000	Spring - SHIFT SELECT
19	90028-PB6-010	Bolt - SPECIAL, 6X22.5
20	90029-611-000	Bolt - HEX., 8X24
20	90029-611-010	Bolt - HEX., 8X24
21	90406-611-000	Washer - LOCK, 8MM
21	90406-PS1-000	Washer - LOCK
22	90435-634-000	Washer - 8MM

Side protector (2D) 20

#	OEM	部品名
1	75802-SB3-660	Molding - R. FR. DOOR CORNER
2	75803-SB3-672	Fitting - SIDE PROTECTOR
3	75807-SB3-660	Molding - L. FR. DOOR CORNER
4	75807-671-000	Nut - SIDE PROTECTOR (BLACK)
5	75810-SB3-672	Protector assy - R. SIDE
6	75811-SB3-671	Protector - R. FR. FENDER
7	75812-SB3-672	Protector - R. DOOR
8	75813-SB3-671	Protector - R. RR. FENDER
10	75815-SB3-672	Protector assy - L. SIDE
11	75816-SB3-671	Protector - L. FR. FENDER
12	75817-SB3-672	Protector - L. DOOR
13	75818-SB3-671	Protector - L. RR. FENDER
15	75824-SB3-010	Garnish - R. DOOR SASH
18	75834-SB3-010	Garnish - L. DOOR SASH
19	75865-SB3-000	Molding - R. DOOR SASH
24	75875-SB3-000	Molding - L. DOOR SASH
29	90660-SB3-671	Clip A - SIDE PROTECTOR
30	90663-SB3-671	Clip b - R. SIDE PROTECTOR
31	90668-SB3-671	Clip b - L. SIDE PROTECTOR
32	90161-SB3-000	Screw - TAPPING, 4X8

Speedometer 5

#	OEM	部品名
2	37230-SB3-672	Cable assy - SPEEDOMETER
3	37233-SB3-671	Cable - INNER
4	37236-SB2-600	Clamp - SPEEDOMETER CABLE
5	39700-SB4-003	Clock assy - DIGITAL (JECO)
5	39700-SB4-005	Clock assy - DIGITAL (CITIZEN)

Speedometer component (ND) 24

#	OEM	部品名
1	35505-SA5-004	Bulb & socket - 14V 1.4W) (DENSO) (BASE:BLACK
3	37251-SB3-004	Bulb & socket - 14V 1.4W) (GREEN
3	37255-SB3-004	Bulb & socket - 14V 3.4W) (GREEN
4	37106-SB2-004	Knob - TRIP (DENSO)
5	37109-SB3-762	Panel - PRINT (DENSO)
6	37110-SB3-902	Case - METER (DENSO)
7	37112-SB3-902	Visor assy - METER (DENSO)
8	37113-SB3-004	Lens - ILLUMINATION
9	37114-SA5-004	Grommet - DENSO
10	37114-SB3-004	Panel - ILLUMINATION PRINT (DENSO)
11	37114-671-005	Grommet - TRIP KNOB (NS)
12	37116-SB3-004	Rubber - SPEEDOMETER (DENSO)
13	37120-SB3-004	Buzzer - SPEED ALARM (DENSO)
14	37121-SB3-932	Case assy. - AUTOMATIC
15	37124-SB3-004	Case - ILLUMINATION (DENSO)
16	37150-SB3-702	Meter assy - FUEL & TEMPERATURE (DENSO)
20	37195-SB3-902	Lens - SMOKE (DENSO)
22	37200-SB3-662	Speedometer assy - DENSO
22	37200-SB3-762	Speedometer assy - DENSO
23	37220-SB3-664	Amplifier assy - DENSO
26	37500-SB3-662	Plate assy. - WINDOW
27	37570-SB3-914	Indicator assy. - AUTOMATIC (DENSO)
28	90101-SB2-004	Screw - TAPPING, 3X15
29	90102-SB2-004	Screw - TAPPING, 4X14 (DENSO)

Speedometer component (NS) 30

#	OEM	部品名
1	35505-SA5-003	Socket assy, BULB(14V 1.4W) (NS)(BASE:BLACK)
3	35509-SA5-003	Bulb & socket - 8V 1.2W) (NS
4	37102-SA5-003	Socket assy - BULB (14V 3.4W) (NS) (BASE:BLACK)
5	37106-SB2-003	Knob - TRIP (NS)
6	37109-SB3-661	Panel - PRINT (NS)
6	37109-SB3-761	Panel - PRINT (NS)
7	37110-SB3-903	Case assy - NS
7	37110-SB3-901	Case assy - NS
8	37112-SB3-901	Visor assy - METER (NS)
8	37112-SB3-911	Visor assy - METER (NS)
9	37114-671-005	Grommet - TRIP KNOB (NS)
10	37115-SA0-601	Packing - NS
11	37116-SB3-003	Rubber - SPEEDOMETER (NS)
12	37122-SB3-003	Amplifier & buzzer assy.
13	37124-SB3-013	Illumination assy.
13	37124-SB3-003	Illumination assy. - NS
14	37150-SB3-703	Meter assy - FUEL & TEMPERATURE (NS)
18	37195-SB3-661	Lens - SMOKE (NS)
19	37195-SB3-731	Lens - SMOKE (NS) (L)
20	37195-SB3-901	Lens - SMOKE (NS) (TURN)
22	37200-SB3-661	Speedometer assy - NS
22	37200-SB3-761	Speedometer assy - NS
23	37220-SB3-663	Amplifier & buzzer assy. - NS
25	37237-SB3-003	Bulb - 14V 3.4W CAP
26	37238-SB3-003	Bulb & socket - 14V 3.4W CAP
27	37238-SB3-961	Bulb & socket - 14V 1.4W CAP
29	37570-SB3-913	Indicator assy. - AUTOMATIC
30	90102-SB2-003	Screw - TAPPING, 4X14
30	90131-SD2-003	Screw-washer - 4X12 (NS)
31	90131-SB3-003	Screw-washer - 3X12

Speedometer gear 7

#	OEM	部品名
1	23811-PC1-000	Holder comp - SPEEDOMETER GEAR
2	23813-689-000	Plate - SPEEDOMETER GEAR HOLDER
3	23814-689-000	Seal - GEAR HOLDER
4	23820-PE4-700	Gear - SPEEDOMETER DRIVEN
5	90637-689-000	Clip - SPEEDOMETER CABLE
6	90638-689-000	Clip - SPEEDOMETER GEAR
7	91313-611-010	O-ring - 23.5X2

Starter motor component (DENSO) 16

#	OEM	部品名
1	31200-PE0-661	Motor assy. - STARTER (DRDFE) (DENSO)
2	31201-657-671	Screw - DENSO) (###
3	31202-657-671	Bolt - THROUGH (###)
4	31203-PE0-661	Housing - DRIVE SIDE (###)
5	31204-657-671	Clutch comp. - OVERRUNNING(###)
6	31205-657-671	Ball - STEEL (DENSO)
7	31206-PE0-662	Yoke comp - DENSO) (###
8	31207-657-671	Armature comp - DENSO
9	31208-657-671	Plate comp - BRUSH HOLDER (DENSO)(###)
10	31209-PD1-004	Frame - STARTER END (DENSO) (###)
11	31210-PE0-662	Switch assy - MAGNETIC (DENSO) (###)
13	31222-657-671	Gear - IDLE (DENSO)(###)
14	31225-PB2-006	Roller - BEARING (DENSO)
15	31226-PB2-006	Retainer - BEARING (DENSO)(###)
16	31235-PE0-662	Cover - TERMINAL (DENSO)
17	31291-PE0-661	Stay - ENGINE WIRE HARNESS

Starter motor component (MITSUBA) 17

#	OEM	部品名
1	31200-PE0-665	Motor assy. - STARTER (MITSUBA) (SM-302-07)
2	31202-PC2-006	Bolt - THROUGH (MITSUBA)
3	31203-PE0-664	Cover - GEAR
4	31204-PD1-013	Gear assy. - PINION
6	31207-PC2-006	Armature comp - MITSUBA
8	31209-PG6-006	Cover - RR. (MITSUBA)(###)
9	31210-PC2-026	Switch assy - MAGNETIC
10	31211-PC2-006	Ring - SQUARE (MITSUBA)
11	31215-PC2-006	Washer - THRUST, 1.2 (MITSUBA)
12	31216-PC2-006	Washer - THRUST, 0.2 (MITSUBA)
13	31217-PC2-006	Screw-washer - 4X28 (MITSUBA)
14	31251-PD2-016	Tube - LABYRINTH
15	31219-PC2-006	Rubber - BUSH
16	31229-PC2-016	Case comp. - FR.
17	31235-PC2-016	Cover - TERMINAL
18	31291-PE0-663	Stay - ENGINE WIRE HARNESS
20	31260-PC2-006	Stator set

Steering column 36

#	OEM	部品名
1	53210-SB3-000	Column - STEERING (TILT)
1	53210-SD2-900	Column - STEERING
3	53211-SB3-900	Holder - COLUMN UPPER
4	53212-SB3-000	Plate comp - BENDING
6	53216-SB3-000	Holder b - COLUMN
7	53217-SB3-000	Collar - STEERING RETAINER
9	53221-SA0-003	Bush - STEERING COLUMN
10	53224-SA5-003	Ring - COLUMN THRUST
11	53225-SB3-000	Band - RUBBER
12	53231-SB2-000	Label - IGNITION SWITCH
15	53235-SA5-000	Ring - COLUMN COVER
16	53239-SB2-000	Clip - COLUMN COVER
18	53271-692-003	Cam - TURN SIGNAL SWITCH CANCEL (TEC) (WHITE)
19	53275-SB2-013	Contact assy. - HORN
20	53300-SB2-730	Joint assy. - STEERING
21	53310-SB3-000	Shaft a - STEERING
22	53311-692-000	Washer - STEERING SHAFT
23	53312-SA0-660	Washer a - STEERING SHAFT
24	53313-SA7-003	Washer b - STEERING SHAFT
25	53320-SB3-731	Cover - STEERING JOINT
27	53322-SB2-672	Insulator - JOINT HOLE
28	53323-SB2-000	Joint b - STEERING COLUMN
30	53335-SB3-013	Bush - COLUMN HANGER
31	53336-SB3-000	Ring - COLUMN BUSH
36	53363-SB3-670	Pivot - COLUMN
37	53364-SA0-960	Collar - PIVOT
38	53365-SA0-961	Bush - PIVOT
44	53326-SB0-000	Clip b - JOINT COVER
47	66221-SB3-670	Blind - COLUMN
48	66225-SB3-000	Clip - COLUMN BLIND
49	90102-SA4-000	Screw - TAPPING, 4X16
50	90130-SB3-003	Bolt - PIVOT
51	90131-SB3-000	Bolt - STEERING HANGER
52	90135-579-010	Bolt - STEERING YOKE, 8X22
53	90136-SA0-660	Bolt-washer - 8X32
54	90505-SA0-660	Washer - PLAIN, 20MM

Steering gear box 20

#	OEM	部品名
1	53040-SB2-738	Box comp - STEERING GEAR (YAMADA)
2	53413-SA0-670	Spring - RACK GUIDE PRESSURE
3	53414-679-013	Screw - RACK GUIDE
4	53416-SB2-013	Guide - STEERING RACK
5	53422-SB2-732	Pinion - STEERING
6	53426-671-003	Dust seal - STEERING PINION (ARAI)
6	53426-671-004	Dust seal - STEERING PINION (NOK)
7	53427-SB2-735	Rack - STEERING
8	53430-SA0-003	Bush - RACK END
9	53435-SB2-000	Cushion a - STEERING GEAR BOX
9	53435-SD2-000	Cushion a - STEERING GEAR BOX
10	53436-SA5-000	Cushion b - GEAR BOX MOUNTING
11	53437-SB2-000	Bracket a - STEERING GEAR BOX
12	53438-SB2-000	Bracket b - STEERING GEAR BOX
13	53458-SE0-003	Nut - RACK SCREW LOCK
13	53458-S01-A51	Nut - LOCK
14	53501-SB2-000	Grommet a - STEERING GEAR BOX
15	53502-SB2-000	Grommet b - STEERING GEAR BOX
16	53503-SB2-010	Grommet c - STEERING GEAR BOX
17	53504-SB2-010	Spacer - JOINT HOLE

Steering wheel (2) 4

#	OEM	部品名
5	53154-SB3-004	Screw - SLIDE (TS TECH)
6	53155-SB3-004	Spring - COIL (TS TECH)
7	53164-SB4-004	Cord - HORN (TS TECH)
8	90380-SB2-003	Nut - SELF-LOCK (OHASHI)

Steering wheel (5) 8

#	OEM	部品名
4	53138-SB2-003	Bush - NIPPON PURASUTO
6	53154-SB2-003	Screw - SLIDE (NIPPON PURASUTO)
7	53154-SB3-951	Screw - SLIDE (NIPPON PURASUTO)
8	53155-SB2-003	Spring - HORN (NIPPON PURASUTO)
9	53156-SB3-003	Bush - NIPPON PURASUTO
10	53162-692-003	Bolt - CONTACT (NIPPON PURASUTO)
11	53164-SB3-951	Cord - HORN (NIPPON PURASUTO)
12	90380-SB2-003	Nut - SELF-LOCK (OHASHI)

Steering wheel (6) 8

#	OEM	部品名
4	53138-SB3-004	Grommet - TS TECH
6	53154-SB3-004	Screw - SLIDE (TS TECH)
7	53154-SB3-952	Screw - SLIDE (TS TECH)
8	53155-SB3-004	Spring - COIL (TS TECH)
9	53156-SB3-004	Bush - TS TECH
10	53158-SB3-004	Plate - HORN (TS TECH)
11	53164-SB3-004	Cord - HORN (TS TECH)
12	90380-SB2-003	Nut - SELF-LOCK (OHASHI)

Switch (1) 11

#	OEM	部品名
2	17950-SB3-663	Wire comp - CHOKE
3	17951-SB3-000	Knob - CHOKE WIRE
4	17957-659-003	Nut - 14MM
8	35500-SB2-013	Switch assy - RR. DEFOGGER (TEC)
9	37553-SA0-003	Bulb & socket - 14V 1.4W
12	66219-SB3-602	Bracket - CHOKE
13	90130-SA0-003	Screw - PAN, 2.6X6
15	90679-671-621	Band - VENT TUBE
17	39620-SB3-305	Socket assy - CIGARETTE LIGHTER
18	39600-S84-G01	Lighter assy - CIGARETTE
18	39600-SW3-505	LIGHTER ASSYCIGA

Switch (2) 16

#	OEM	部品名
1	35010-SB3-712	Cylinder set - KEY
2	35100-SB3-722	Lock assy - STEERING (HONDA LOCK)
3	35102-SA5-003	Bolt - BREAK HEAD
3	35102-SV4-003	Bolt - BREAK HEAD
4	35103-SA5-003	Screw - RECESSED, 3X8
5	35111-SA5-922	Key - BLANK (MAIN)
6	35130-SB2-003	Switch comp - STEERING (HONDA LOCK)
7	35131-SA5-671	Cylinder comp - STEERING
8	35250-SB3-674	Switch assy - COMBINATION
9	35350-SE0-003	Switch assy - STOP (TEC)
10	35400-692-033	Switch assy - DOOR
10	35400-SE3-003	Switch assy - DOOR
11	35409-692-013	Screw - FLANGE, 4X12
12	35417-SE3-003	Cover - DOOR SWITCH
12	35410-692-003	Cover - DOOR SWITCH
13	35700-SB2-982	Switch assy - INHIBITOR & BACK UP LIGHT (TEC)

Tailgate (2D) 30

#	OEM	部品名
3	74800-SB3-000	Holder assy. - RR. GLASS
4	74809-SB3-010	Mount - TAILGATE UPPER GARNISH CENTER
6	83300-SB3-023	Lock assy - TAILGATE
7	83303-SB3-003	Cylinder - TAILGATE
7	83303-SB3-013	Cylinder - TAILGATE
8	83305-SB3-003	Striker - TAILGATE
9	83307-SB3-000	Shim - TAILGATE STRIKER
11	83312-SB3-000	Cushion - TAILGATE LOCK
15	85254-SB3-000	Shim - TAILGATE HINGE
16	85256-SB3-010	Seal - TAILGATE HINGE
17	85257-SB3-901	Clip A - TAILGATE HINGE COVER
18	85259-SB3-900	Seal - R. TAILGATE HINGE COVER
20	85262-SB3-010	Cushion - TAILGATE SIDE
21	85263-SB3-000	Spring - TAILGATE CUSHION
22	85268-SB3-000	Stopper - TAILGATE
23	85269-SH3-003	Stud - BALL
23	85269-SA0-013	Stud - BALL (SHOWA)
24	85270-SB3-902	Stay assy - TAILGATE OPEN
25	85277-SB3-000	Stopper - R. TAILGATE CUSHION
26	85278-SB3-010	Stopper - L. TAILGATE CUSHION
27	85279-SA0-003	Clip - BALL JOINT (SHOWA)
28	85279-SB3-010	Seal - TAILGATE STOPPER
32	85359-SB3-900	Seal - L. TAILGATE HINGE COVER
33	85522-SB3-003	Opener assy - L. TAILGATE
37	85525-SB3-003	Cable - TAILGATE OPENER
39	90106-SB3-010	Screw - SPECIAL TAPPING, 6X12
40	90107-SB3-000	Bolt - TAILGATE STRIKER
41	90108-SB3-000	Bolt - 6X12 (GREEN)
42	90109-SB3-000	Bolt - 6X10 (GREEN)
43	90140-SB3-000	Bolt - TAILGATE STOPPER

Tailgate lining (2D) 6

#	OEM	部品名
4	83863-SA4-000	Cap - TIRE LID
6	85861-SB3-003	Weatherstrip - TAILGATE
7	90103-693-000	Screw - FLANGE TAPPING, 4X12
8	90612-SB3-013	Clip - WIRE HARNESS
9	90662-SB3-000	Clip - TAILGATE LINING
13	90681-693-000	Grommet - SCREW, 4MM

Taillight (3D) 17

#	OEM	部品名
1	33310-594-601	Bulb - 12V5W
1	34910-504-003	Bulb (12v5w)
2	33500-SB3-613	Taillight assy. - R.
3	33501-SB3-611	Housing - R.
4	33502-SB3-003	Packing - BASE
5	33503-SB3-612	Cord comp
6	33503-506-600	Bulb - 12V 21W) (STANLEY
6	34905-KV7-671	Bulb,winker (12v
6	34908-634-611	Bulb - 12V 21W) (ECE) (STANLEY
7	33550-SB3-613	Taillight assy. - L.
8	33551-SB3-611	Housing - L.
10	34100-SB2-741	Light assy - LICENSE
11	34101-SB2-003	Lens - STANLEY
12	34103-SB2-003	Packing - LENS
17	34154-SB3-671	Packing - BASE
22	34906-594-622	Bulb - 12V 21/5W
23	83200-SB3-000	Garnish - RR. PANEL

Taillight (4D) 2

#	OEM	部品名
24	34101-SB2-003	Lens - STANLEY
25	34103-SB2-003	Packing - LENS

Tie rod 11

#	OEM	部品名
2	53434-SA0-000	Clip - BOOT
4	53449-579-000	Band - BELLOWS
5	53521-SB2-013	End comp - RACK
8	53535-SB3-000	Washer - TIE ROD STOPPER
9	53536-SB2-000	Washer - TIE ROD LOCK
10	53537-SA5-000	Dust seal - TIE ROD
11	53537-SB2-020	Dust seal - TIE ROD
13	53540-SB2-003	End comp - TIE ROD (MUSASHI)
14	53546-SA0-003	Boot - TIE ROD END (MUSASHI)
15	53548-SA0-003	Circlip - MUSASHI
16	90320-601-000	Nut - CASTLE, 10MM

Tire/wheel disk 32

#	OEM	部品名
3	42700-SB2-921	Disk - WHEEL (13X5J) (KANAI) (STOUT SILVER)
3	42700-SB2-922	Disk - WHEEL (13X5J) (YUNO) (STOUT SILVER)
7	42750-SA5-621	Tire assy - 165SR13) (TUBELESS) (BRIDGESTONE
7	42750-SA5-625	Tire assy - 165SR13) (DUNLOP) (TUBELESS
7	42750-SA5-986	Tire assy - 165SR13) (YOKOHAMA) (TUBELESS
13	42753-634-003	Valve - RIM (BRIDGESTONE)
13	42753-SB8-661	Valve - RIM (SCHRADER)
13	42753-634-006	Valve - RIM (YOKOHAMA)
13	42753-671-962	Valve - RIM (DUNLOP)
15	44730-SB2-013	Weight - BALANCE (45G) (YAMATE)
15	44726-693-000	Weight - BALANCE (5G)
15	44725-SB2-003	Weight - BALANCE (50G) (YAMATE)
15	44729-SB2-003	Weight - BALANCE (35G) (YAMATE)
15	44721-SB2-003	Weight - BALANCE (10G) (YAMATE)
15	44725-693-000	Weight - BALANCE (50G)
15	44724-SB2-003	Weight - BALANCE (40G) (YAMATE)
15	44729-693-000	Weight - BALANCE (35G)
15	44728-SB2-003	Weight - BALANCE (25G) (YAMATE)
15	44724-693-000	Weight - BALANCE (40G)
15	44723-SB2-003	Weight - BALANCE (30G) (YAMATE)
15	44721-693-000	Weight - BALANCE (10G)
15	44728-693-000	Weight - BALANCE (25G)
15	44727-SB2-003	Weight - BALANCE (15G) (YAMATE)
15	44723-693-000	Weight - BALANCE (30G)
15	44730-693-000	Weight - BALANCE (45G)
15	44722-SB2-003	Weight - BALANCE (20G) (YAMATE)
15	44727-693-000	Weight - BALANCE (15G)
15	44726-SB2-003	Weight - BALANCE (5G) (YAMATE)
15	44722-693-000	Weight - BALANCE (20G)
17	44732-SB2-000	Cap - WHEEL CENTER (56MM) (BLACK)
22	83853-SA7-980	Bolt - ANCHOR (79MM)
25	90304-SA5-013	Nut - WHEEL (CHROME PLATED) (FUSE RASHI)

Tools/jack 12

#	OEM	部品名
1	89000-SB2-601	Tool set
2	89101-SB2-601	Bag - TOOL
2	89101-SB2-600	Bag - TOOL
4	89216-642-810	Wrench - SPARK PLUG
5	89218-611-003	Shaft - WRENCH (RIKEN)
5	89218-611-004	Shaft - WRENCH (KOWA)
6	89310-SB0-013	Jack assy - PANTOGRAPH
7	89320-SA0-003	Bar comp - JACK
10	89600-SE3-Y01	Extinguisher - FIRE
11	89610-SE3-Y00	Bracket - FIRE EXTINGUISHER
12	90156-SE3-003	Blind - FASTENER
13	90663-688-000	Clamp - JACK BAR

Torque converter 6

#	OEM	部品名
1	21351-PE0-900	Cover - TORQUE CONVERTER CASE
2	26000-PF0-934	Converter assy - TORQUE
3	26251-PE1-900	Plate - DRIVE
4	90023-PA9-000	Bolt - SPECIAL
5	90429-PE0-000	Washer - 40X85X2
6	91302-639-000	O-ring - 32X1.9

Torque converter housing 13

#	OEM	部品名
1	21110-PF0-010	Case comp. - TORQUE CONVERTER
2	21811-PC9-000	Gasket - TORQUE CONVERTER CASE
3	23225-PA9-000	Plate - OIL GUIDE
4	25425-PF0-000	Pipe - SUCTION
5	90024-612-000	Bolt - SEALING, 8MM
6	90471-580-000	Packing - 8MM
7	91001-591-004	Bearing - BALL, 16008 (KOYO)
7	91001-PX4-004	Bearing - BALL, 40X68X9 (KOYO)
8	91101-PB6-008	Bearing - NEEDLE, 33X55X17
9	91206-639-005	Oil seal - 35X68X9
10	91207-639-015	Oil seal - 44X68X8 (NOK)
11	91209-612-000	Oil seal - 12X22X7
11	91209-612-003	Oil seal - 12X22X7 (ARAI)

Transmission housing 38

#	OEM	部品名
1	21104-PE6-000	Plate - OIL GUIDE
1	21211-PF0-010	Case - TRANSMISSION
2	21200-PE6-900	Case - TRANSMISSION
2	21215-PF4-000	Holder - REVERSE IDLE SHAFT
3	21310-PE6-901	Cover comp. - TRANSMISSION
3	21232-PC9-950	Hanger - TRANSMISSION
4	21321-689-000	Plug - BREATHER TUBE
4	21240-PF0-010	Cover comp. - R. SIDE
5	21398-PE6-010	Clamp - BREATHER TUBE
5	21396-611-010	Cap - BREATHER
6	90081-PB6-000	Bolt - PLUG, 14MM
6	21812-PF0-000	Gasket - R. SIDE COVER
7	91205-PE6-004	Oil seal - 35X68X9 (NOK)
7	91205-PE6-003	Oil seal - 35X68X9 (ARAI)
7	22712-PA9-000	Pipe a - FEED
8	22721-PA9-003	Flange - FEED PIPE
9	22722-PA9-010	Pipe b - FEED
11	23544-PC9-810	Spring b - IDLE GEAR SHAFT
12	27496-PC9-000	Stay - THROTTLE CABLE
13	90007-PC9-810	Bolt - REVERSE HOLDER
14	90024-612-000	Bolt - SEALING, 8MM
16	90437-PA9-000	Washer - TONGUED, 6MM
17	90471-580-000	Packing - 8MM
18	90507-PA9-000	Collar - 8X11
19	90701-639-000	Dowel pin - 8X55
20	90703-PA9-003	Roller - 2X19.8
21	90705-PA9-000	Dowel pin - 14X25
22	91201-PA9-004	Oil seal - 9X18X7 (ARAI)
22	91201-PA9-003	Oil seal - 9X18X7 (NOK)
23	91205-639-005	Oil seal - 35X56X9
24	91301-PC9-004	O-ring - 7.7X2.3 (NOK)
24	91301-PC9-003	O-ring - 7.7X2.3 (ARAI)
25	91308-PA9-004	O-ring - 19.8X1.9 (NOK)
25	91308-PA9-003	O-ring - 19.8X1.9 (ARAI)
26	91311-PA9-004	O-ring - 7.7X1.9 (NOK)
26	91311-PA9-003	O-ring - 7.7X1.9 (ARAI)
36	90015-PF0-000	Bolt - FLANGE, 8X53
38	90016-PF0-000	Bolt - FLANGE, 8X70

Valve/rocker arm 14

#	OEM	部品名
1	14621-PE2-000	Arm a - VALVE ROCKER
2	14622-PE2-000	Arm b - VALVE ROCKER
3	14645-PE0-000	Spring a - VALVE ROCKER ARM
4	14651-PE0-000	Collar - VALVE ROCKER ARM
5	14711-PE0-000	Valve - IN.
6	14721-PE0-000	Valve - EX.
7	14745-657-000	Screw - TAPPET ADJUSTING
9	14761-PE1-004	Spring - VALVE (CHUO HATSUJO)
9	14761-PE1-003	Spring - VALVE (NIPPON HATSUJO)
10	14765-PE0-000	Retainer - VALVE SPRING
11	14775-PE0-000	Seat - VALVE SPRING
12	14781-PE0-003	Valve Cotter - (FUJI VALVE)
12	14781-MB9-000	Cotter - VALVE
13	90206-657-000	Nut - TAPPET ADJUSTING

Water hose 10

#	OEM	部品名
1	39214-SB2-000	Grommet - HEATER PIPE
2	39223-SB2-003	Clamp - WATER HOSE, 24MM
3	39270-SB2-003	Valve assy. - WATER
4	39271-SB2-000	Cover - WATER VALVE
5	39272-SB2-003	Clamp - HEATER HOSE
6	39273-SB2-000	Cable - WATER VALVE
7	39274-SB2-000	Grommet - WATER VALVE CABLE
8	39311-SB2-040	Hose a - WATER IN.
9	39312-SB2-000	Hose - WATER OUTLET
10	39313-SB2-000	Hose b - WATER IN.

Water pump/thermostat 15

#	OEM	部品名
1	19200-PE0-660	Pump comp - WATER
2	19222-PE0-000	Gasket - WATER PUMP
3	19300-PE0-024	Thermostat unit - 78) (NIPPON THERMOSTAT
3	19300-PE0-013	Thermostat unit - 78) (FUJI SEIKO
4	19305-PC6-000	Rubber - THERMOSTAT MOUNTING
5	19311-PE0-000	Cover - THERMOSTAT
6	19315-PE0-010	Cover - WATER OUTLET
7	19320-PE0-660	Case comp. - THERMOSTAT
11	19500-PE0-000	Joint, Tube
12	19504-PE3-000	Hose - IN. BYPASS
13	19505-PE0-000	Pipe - CONNECTING
15	19508-PE3-000	Hose - BYPASS OUTLET
16	19513-PE0-003	Clamp - WATER HOSE (21.7MM) (CHUO SPRING)
17	19516-PC1-000	Bolt - BREATHING WATER
25	91314-634-000	O-ring

Windshield washer 13

#	OEM	部品名
2	38510-SB2-673	Washer comp - FR. WINDSHIELD
4	38512-SB0-921	Motor - WASHER
5	38513-SD7-003	Cap - WASHER MOUTH (BLUE)
6	38516-SA0-671	Packing - PARALLEL TYPE) (MITSUBA
7	38516-SA5-671	Packing - T-TYPE) (MITSUBA
8	38519-SB0-003	Bush - WASHER TANK (MITSUBA)
9	38540-SB3-003	Nozzle - WINDSHIELD WASHER (PASSENGER SIDE)
10	38550-SB3-003	Nozzle - WINDSHIELD WASHER (DRIVER SIDE)
13	38562-663-920	Joint b - WASHER TUBE (MITSUBA)
20	38581-SB2-003	Joint y - TUBE (MITSUBA)
25	90652-SB2-023	Clip - TUBE, 7MM
26	90653-SB3-003	Clip - WASHER TUBE
27	90683-SA0-003	Clip - WIRE HARNESS, 25MM

Wire harness/ battery cable 54

#	OEM	部品名
1	32101-SB3-813	Harness - CABIN WIRE (RR. DEF)
1	32100-SB3-813	Harness - CABIN WIRE
1	32101-SB4-823	Harness - CABIN WIRE
1	32100-SB3-Y00	Harness - CABIN WIRE
3	32108-SB3-772	Cord - TRUNK ROOM (RR. DEF)
3	32108-SB3-752	Cord - TRUNK ROOM
4	32109-SB3-901	Cord - TAILGATE (RR. DEF)
5	32112-SB3-010	Sub cord - LICENSE
8	32117-SB3-791	Harness - INSTRUMENT WIRE
8	32117-SB3-891	Harness - INSTRUMENT WIRE (RR. DEF)
8	32117-SB4-851	Harness - INSTRUMENT WIRE
8	32117-SB3-Y00	Harness - INSTRUMENT WIRE
9	32120-SB3-010	Sub cord - SPEAKER
10	32155-SB3-010	Cord assy - INTERIOR
11	32165-SA5-003	Clip - HARNESS, 9MM(WHITE)
11	90674-769-000	Clamp, p.t.o. cable (b)
12	32170-SB3-010	Cord - FUEL UNIT
14	32410-SB2-687	Cable assy - STARTER (SUMITOMO)
15	32600-SA0-682	Cable assy - EARTH (FURUKAWA)
15	32600-SA0-681	Cable assy - EARTH (SUMITOMO)
16	32601-SA5-004	Bolt - BATTERY TERMINAL (FURUKAWA)
16	32601-SA5-003	Bolt - BATTERY TERMINAL (SUMITOMO)
17	32602-SA5-004	Nut - BATTERY TERMINAL (FURUKAWA)
17	32602-SA5-003	Nut - BATTERY TERMINAL (SUMITOMO)
18	32610-SA7-000	Cable - SUB EARTH
25	38210-SB2-683	Fuser - HAZARD (RED)
27	74804-SB3-000	Holder - WIRE HARNESS
32	90111-SA7-003	Strap - CABLE, 120MM (WHITE)
33	90114-SA7-003	Clamp - CABLE, 20MM (GREEN)
35	90602-SB2-003	Clip - PROTECTOR
37	90618-SA0-003	Clip - WIRE HARNESS
38	90622-SA0-003	Clip - WIRE HARNESS (BLACK)
39	90622-SA7-930	Clip - WIRE HARNESS
42	90650-SB2-003	Clip - WIRE HARNESS, 10MM
43	90651-SB2-003	Clip - WIRE HARNESS, 13MM (GRAY)
44	90653-SB2-003	Clip - PROTECTOR
45	90657-SA7-013	Holder - DEFROSTER CORD
46	90657-671-631	Clip - TRIM (BLACK)
48	90659-170-000	Clip - CABLE, 6MM (WHITE)
49	90660-SB2-000	Clip - CORD
51	90672-SB2-003	Strap - CABLE, 105MM (BLACK)
52	90653-SA7-003	Purse - LOCK, 11MM
52	90630-751-000	Clip, purse lock
53	90676-SA8-003	Band - WIRE HARNESS, 150MM (BLUE)
54	90677-692-003	Clip - WIRE HARNESS (HARNESS TAPING)
55	90682-SB3-003	Clip - WIRE HARNESS
57	90683-SB3-003	Clip - WIRE HARNESS
58	90686-SB3-003	Clip - WIRE HARNESS (7MM X 2)
59	90690-SA0-003	Strap - WIRE HARNESS, 25MM (BLACK)
61	90695-SB2-003	Band - WIRE HARNESS
62	91476-SB6-003	Clip - ROOF ARCH(NATURAL) (HARNESS TAPING)(60MM)
65	91507-693-003	Clip - WIRE HARNESS (BLACK) (50MM) (HARNESS TAPING)
66	91508-SA4-003	Clip - WIRE HARNESS (BLACK)
69	91552-SD2-003	Clip - WIRE HARNESS
