Search › Compare › JB416X × JB424X
JB416X
Suzuki GRAND-VITARA — 13 of 4,714 shared
JB424X
Suzuki GRAND-VITARA — 13 of 4,714 shared
Turbo charger (TYPE 5:JB419XD) 13 / 13
| # | OEM | JB416X | JB424X |
|---|---|---|---|
| 1 | 13900-80KA0-000 | Charger assy, turbo | Charger assy, turbo |
| 2 | 13917-80KA0-000 | Stud bolt set | Stud bolt set |
| 3 | 13918-67JG1-000 | NUT | NUT |
| 4 | 13919-80KA0-000 | Gasket | Gasket |
| 5 | 13930-80KA0-000 | Tube set, feed | Tube set, feed |
| 6 | 13943-80KA0-000 | Bolt - 6x20 | Bolt - 6x20 |
| 7 | 13933-80KA0-000 | Clip | Clip |
| 8 | 13936-80KA0-000 | Gasket | Gasket |
| 9 | 19924-67JG0-000 | BOLT,6X15 | BOLT,6X15 |
| 10 | 13935-80KA0-000 | Tube, turbo oil | Tube, turbo oil |
| 11 | 13934-80KA0-000 | Bolt - 10x25 | Bolt - 10x25 |
| 12 | 13937-80KA0-000 | Clip | Clip |
| 13 | 13938-80KA0-000 | O ring | O ring |
| # | OEM | JB416X | JB424X |
|---|---|---|---|
| 1 | 13900-80KA0-000 | Charger assy, turbo | Charger assy, turbo |
| 2 | 13917-80KA0-000 | Stud bolt set | Stud bolt set |
| 3 | 13918-67JG1-000 | NUT | NUT |
| 4 | 13919-80KA0-000 | Gasket | Gasket |
| 5 | 13930-80KA0-000 | Tube set, feed | Tube set, feed |
| 7 | 13933-80KA0-000 | Clip | Clip |
| 11 | 13934-80KA0-000 | Bolt - 10x25 | Bolt - 10x25 |
| 10 | 13935-80KA0-000 | Tube, turbo oil | Tube, turbo oil |
| 8 | 13936-80KA0-000 | Gasket | Gasket |
| 12 | 13937-80KA0-000 | Clip | Clip |
| 13 | 13938-80KA0-000 | O ring | O ring |
| 6 | 13943-80KA0-000 | Bolt - 6x20 | Bolt - 6x20 |
| 9 | 19924-67JG0-000 | BOLT,6X15 | BOLT,6X15 |
