Search › Compare › JB416X × JB424X
JB416X
Suzuki GRAND-VITARA — 12 of 4,714 shared
JB424X
Suzuki GRAND-VITARA — 12 of 4,714 shared
Oil pan (JB424X) 12 / 12
| # | OEM | JB416X | JB424X |
|---|---|---|---|
| 1 | 11511-78K01-000 | PAN,OIL | PAN,OIL |
| 2 | 11518-63J10-000 | Plug,Oil Drain | Plug,Oil Drain |
| 3 | 11540-78K00-000 | PLATE,OIL BAFFLE | PLATE,OIL BAFFLE |
| 4 | 09103-08525-000 | BOLT(8X120) | BOLT(8X120) |
| 5 | 09168-14015-000 | GASKET(14X20X1.5) - Gasket, oil hose union | GASKET(14X20X1.5) - Gasket, oil hose union |
| 6 | 01550-0612A-000 | Bolt | Bolt |
| 7 | 01550-0825A-000 | Bolt | Bolt |
| 8 | 04211-13149-000 | PIN | PIN |
| 9 | 16520-78K00-000 | STRAINER,OIL PUMP | STRAINER,OIL PUMP |
| 10 | 09280-22020-000 | O RING(D:2.4,ID:21.8) - O ring (d:2.4,id:21.8) | O RING(D:2.4,ID:21.8) - O ring (d:2.4,id:21.8) |
| 11 | 01550-0616A-000 | Bolt | Bolt |
| 12 | 01550-0645A-000 | Bolt | Bolt |
| # | OEM | JB416X | JB424X |
|---|---|---|---|
| 20 | 01550-0612A-000 | Bolt | Bolt |
| 16 | 01550-0616A-000 | Bolt | Bolt |
| 12 | 01550-0645A-000 | Bolt | Bolt |
| 15 | 01550-0825A-000 | Bolt | Bolt |
| 16 | 04211-13149-000 | PIN | PIN |
| 4 | 09103-08525-000 | BOLT(8X120) | BOLT(8X120) |
| 5 | 09168-14015-000 | GASKET(14X20X1.5) - Gasket, oil hose union | GASKET(14X20X1.5) - Gasket, oil hose union |
| 7 | 09280-22020-000 | O RING(D:2.4,ID:21.8) - O ring (d:2.4,id:21.8) | O RING(D:2.4,ID:21.8) - O ring (d:2.4,id:21.8) |
| 1 | 11511-78K01-000 | PAN,OIL | PAN,OIL |
| 3 | 11518-63J10-000 | Plug,Oil Drain | Plug,Oil Drain |
| 3 | 11540-78K00-000 | PLATE,OIL BAFFLE | PLATE,OIL BAFFLE |
| 9 | 16520-78K00-000 | STRAINER,OIL PUMP | STRAINER,OIL PUMP |
