Search › Compare › JB416X × JB424X
JB416X
Suzuki GRAND-VITARA — 22 of 4,714 shared
JB424X
Suzuki GRAND-VITARA — 22 of 4,714 shared
Generator (JB424X) 22 / 22
| # | OEM | JB416X | JB424X |
|---|---|---|---|
| 1 | 31400-78K01-000 | Generator assy | Generator assy |
| 1 | 31400-78K13-000 | GENERATOR ASSY | GENERATOR ASSY |
| 1 | 31400-78K10-000 | Generator assy | Generator assy |
| 2 | 31171-78K00-000 | Pulley | Pulley |
| 3 | 31410-65J10-000 | STATOR ASSY | STATOR ASSY |
| 3 | 31410-54L00-000 | STATOR ASSY | STATOR ASSY |
| 4 | 31471-84A00-000 | INSULATOR | INSULATOR |
| 5 | 31582-50F20-000 | Bearing,front | Bearing,front |
| 5 | 31582-50F30-000 | BEARING,FRONT | BEARING,FRONT |
| 6 | 31585-65J10-000 | RETAINER | RETAINER |
| 7 | 31586-86520-000 | SCREW SET | SCREW SET |
| 8 | 31512-84A00-000 | NUT | NUT |
| 9 | 31621-78K00-000 | RECTIFIER | RECTIFIER |
| 10 | 31651-86520-000 | SCREW SET | SCREW SET |
| 11 | 31710-78K00-000 | ROTOR ASSY | ROTOR ASSY |
| 11 | 31710-78K01-000 | ROTOR ASSY | ROTOR ASSY |
| 11 | 31710-78K10-000 | ROTOR ASSY | ROTOR ASSY |
| 12 | 31612-60A10-000 | Bearing,rr | Bearing,rr |
| 12 | 31612-60A11-000 | BEARING,REAR | BEARING,REAR |
| 13 | 31775-50F20-000 | NUT | NUT |
| 14 | 32500-80J10-000 | REGULATOR ASSY | REGULATOR ASSY |
| 15 | 31631-60F30-000 | BRUSH SET | BRUSH SET |
| # | OEM | JB416X | JB424X |
|---|---|---|---|
| 2 | 31171-78K00-000 | Pulley | Pulley |
| 4 | 31400-78K01-000 | Generator assy | Generator assy |
| 4 | 31400-78K10-000 | Generator assy | Generator assy |
| 4 | 31400-78K13-000 | GENERATOR ASSY | GENERATOR ASSY |
| 3 | 31410-54L00-000 | STATOR ASSY | STATOR ASSY |
| 3 | 31410-65J10-000 | STATOR ASSY | STATOR ASSY |
| 4 | 31471-84A00-000 | INSULATOR | INSULATOR |
| 8 | 31512-84A00-000 | NUT | NUT |
| 5 | 31582-50F20-000 | Bearing,front | Bearing,front |
| 5 | 31582-50F30-000 | BEARING,FRONT | BEARING,FRONT |
| 6 | 31585-65J10-000 | RETAINER | RETAINER |
| 7 | 31586-86520-000 | SCREW SET | SCREW SET |
| 12 | 31612-60A10-000 | Bearing,rr | Bearing,rr |
| 12 | 31612-60A11-000 | BEARING,REAR | BEARING,REAR |
| 9 | 31621-78K00-000 | RECTIFIER | RECTIFIER |
| 15 | 31631-60F30-000 | BRUSH SET | BRUSH SET |
| 10 | 31651-86520-000 | SCREW SET | SCREW SET |
| 11 | 31710-78K00-000 | ROTOR ASSY | ROTOR ASSY |
| 11 | 31710-78K01-000 | ROTOR ASSY | ROTOR ASSY |
| 11 | 31710-78K10-000 | ROTOR ASSY | ROTOR ASSY |
| 13 | 31775-50F20-000 | NUT | NUT |
| 14 | 32500-80J10-000 | REGULATOR ASSY | REGULATOR ASSY |
