Search › Compare › GC415V × GC416V
GC415V
Suzuki APV — 14 of 3,786 shared
GC416V
Suzuki APV — 14 of 3,786 shared
Gear shift control (TYPE 1:AT) 14 / 14
| # | OEM | GC415V | GC416V |
|---|---|---|---|
| 1 | 28210-61J10-000 | Cable assy, select | Cable assy, select |
| 2 | 28221-61J10-000 | Bracket, select cable | Bracket, select cable |
| 3 | 28230-61J12-000 | LEVER,MANUAL SLT | LEVER,MANUAL SLT |
| 4 | 28393-61J71-000 | Grommet, select cable | Grommet, select cable |
| 4 | 28393-61J11-000 | Grommet, select cable | Grommet, select cable |
| 5 | 28393-61J30-000 | Grommet, clutch cable hole | Grommet, clutch cable hole |
| 6 | 28395-61J00-000 | Plate, select cable grommet | Plate, select cable grommet |
| 7 | 09118-08033-000 | BOLT(8X30) | BOLT(8X30) |
| 8 | 09162-08008-000 | WASHER,LOCK - Lock washer | WASHER,LOCK - Lock washer |
| 9 | 01550-0820A-000 | Bolt - Bolt, funnel bracket | Bolt - Bolt, funnel bracket |
| 10 | 03141-0616A-000 | SCREW | SCREW |
| 11 | 08310-0008A-000 | NUT - Nut, bead stopper | NUT - Nut, bead stopper |
| 12 | 24731-65D10-000 | SWITCH ASSY,SHIFT | SWITCH ASSY,SHIFT |
| 13 | 29993-65D10-000 | BOLT,SHIFT SW | BOLT,SHIFT SW |
| # | OEM | GC415V | GC416V |
|---|---|---|---|
| 16 | 01550-0820A-000 | Bolt - Bolt, funnel bracket | Bolt - Bolt, funnel bracket |
| 10 | 03141-0616A-000 | SCREW | SCREW |
| 9 | 08310-0008A-000 | NUT - Nut, bead stopper | NUT - Nut, bead stopper |
| 7 | 09118-08033-000 | BOLT(8X30) | BOLT(8X30) |
| 8 | 09162-08008-000 | WASHER,LOCK - Lock washer | WASHER,LOCK - Lock washer |
| 12 | 24731-65D10-000 | SWITCH ASSY,SHIFT | SWITCH ASSY,SHIFT |
| 1 | 28210-61J10-000 | Cable assy, select | Cable assy, select |
| 2 | 28221-61J10-000 | Bracket, select cable | Bracket, select cable |
| 3 | 28230-61J12-000 | LEVER,MANUAL SLT | LEVER,MANUAL SLT |
| 4 | 28393-61J11-000 | Grommet, select cable | Grommet, select cable |
| 5 | 28393-61J30-000 | Grommet, clutch cable hole | Grommet, clutch cable hole |
| 4 | 28393-61J71-000 | Grommet, select cable | Grommet, select cable |
| 6 | 28395-61J00-000 | Plate, select cable grommet | Plate, select cable grommet |
| 13 | 29993-65D10-000 | BOLT,SHIFT SW | BOLT,SHIFT SW |
