Search › Compare › CP22S × CV51S
CP22S
Suzuki CERVO-MODE — 31 of 2,173 shared
CV51S
Suzuki WAGON-R-PLUS-SOLIO-WIDE — 31 of 2,210 shared
front suspension (1997-05-01~1998-06-01) 31 / 39
| # | OEM | CP22S | CV51S |
|---|---|---|---|
| 1 | 46111-69D00-000 | KNUCKLE,RR SUSPENSION,R | KNUCKLE,RR SUSPENSION,R |
| 2 | 46151-69D00-000 | KNUCKLE,RR SUSPENSION,L | KNUCKLE,RR SUSPENSION,L |
| 5 | 09103-12501-000 | BOLT(12X55) | BOLT(12X55) |
| 6 | 08316-10123-000 | Nut | Nut |
| 6 | 08316-1012A-000 | NUT | NUT |
| 7 | 08310-00123-000 | Nut | Nut |
| 7 | 08310-0012A-000 | NUT | NUT |
| 8 | 08321-01123-000 | Washer - Lock washer | Washer - Lock washer |
| 8 | 08321-0112A-000 | WASHER,LOCK | WASHER,LOCK |
| 9 | 41714-82000-000 | SUPPORT,FRONT STRUT INNER | SUPPORT,FRONT STRUT INNER |
| 10 | 41713-82000-000 | STOPPER,FRONT STRUT REBOUND | STOPPER,FRONT STRUT REBOUND |
| 11 | 41710-82000-000 | SUPPORT,FRONT STRUT | SUPPORT,FRONT STRUT |
| 12 | 08316-10083-000 | Nut | Nut |
| 12 | 08316-1008B-000 | NUT | NUT |
| 13 | 41712-82000-000 | MOUNT,FR STRUT | MOUNT,FR STRUT |
| 14 | 41720-82000-000 | SEAT,STRUT MOUNT | SEAT,STRUT MOUNT |
| 18 | 41230-50E00-000 | SEAT,FRONT SPRING UPPER | SEAT,FRONT SPRING UPPER |
| 19 | 41211-70B00-000 | SEAT,FRONT COIL SPRING | SEAT,FRONT COIL SPRING |
| 21 | 42111-70B11-000 | STOPPER,BUMP | STOPPER,BUMP |
| 22 | 45200-69D00-000 | アームアッシ,サスペンションコントロール | アームアッシ,サスペンションコントロール |
| 22 | 45200-69DV1-000 | ARM ASSY,FR SPNSN | ARM ASSY,FR SPNSN |
| 23 | 45723-70B00-000 | SEAL SET,DUST | SEAL SET,DUST |
| 23 | 45723-70B01-000 | Seal Set,dust | Seal Set,dust |
| 23 | 45700-70810-000 | Seal Set,dust | Seal Set,dust |
| 24 | 09319-10030-000 | BUSH(10.2X25.5X52.2) - Bushing | BUSH(10.2X25.5X52.2) - Bushing |
| 25 | 09100-10184-000 | BOLT(10X40) | BOLT(10X40) |
| 26 | 08321-01103-000 | Washer - Lock washer | Washer - Lock washer |
| 26 | 08321-0110B-000 | WASHER,LOCK - Washer, knuckle end | WASHER,LOCK - Washer, knuckle end |
| 26 | 08321-0110A-000 | WASHER,LOCK | WASHER,LOCK |
| 27 | 09117-10025-000 | Bolt (10x89.5) | Bolt (10x89.5) |
| 27 | 45215-72J10-000 | BOLT,SPNSN ARM FR BUSHING | BOLT,SPNSN ARM FR BUSHING |
| # | OEM | CP22S | CV51S |
|---|---|---|---|
| 7 | 08310-00123-000 | Nut | Nut |
| 7 | 08310-0012A-000 | NUT | NUT |
| 18 | 08316-10083-000 | Nut | Nut |
| 18 | 08316-1008B-000 | NUT | NUT |
| 6 | 08316-10123-000 | Nut | Nut |
| 6 | 08316-1012A-000 | NUT | NUT |
| 4 | 08321-01103-000 | Washer - Lock washer | Washer - Lock washer |
| 4 | 08321-0110A-000 | WASHER,LOCK | WASHER,LOCK |
| 4 | 08321-0110B-000 | WASHER,LOCK - Washer, knuckle end | WASHER,LOCK - Washer, knuckle end |
| 8 | 08321-01123-000 | Washer - Lock washer | Washer - Lock washer |
| 8 | 08321-0112A-000 | WASHER,LOCK | WASHER,LOCK |
| 25 | 09100-10184-000 | BOLT(10X40) | BOLT(10X40) |
| 5 | 09103-12501-000 | BOLT(12X55) | BOLT(12X55) |
| 27 | 09117-10025-000 | Bolt (10x89.5) | Bolt (10x89.5) |
| 24 | 09319-10030-000 | BUSH(10.2X25.5X52.2) - Bushing | BUSH(10.2X25.5X52.2) - Bushing |
| 19 | 41211-70B00-000 | SEAT,FRONT COIL SPRING | SEAT,FRONT COIL SPRING |
| 18 | 41230-50E00-000 | SEAT,FRONT SPRING UPPER | SEAT,FRONT SPRING UPPER |
| 11 | 41710-82000-000 | SUPPORT,FRONT STRUT | SUPPORT,FRONT STRUT |
| 13 | 41712-82000-000 | MOUNT,FR STRUT | MOUNT,FR STRUT |
| 10 | 41713-82000-000 | STOPPER,FRONT STRUT REBOUND | STOPPER,FRONT STRUT REBOUND |
| 9 | 41714-82000-000 | SUPPORT,FRONT STRUT INNER | SUPPORT,FRONT STRUT INNER |
| 14 | 41720-82000-000 | SEAT,STRUT MOUNT | SEAT,STRUT MOUNT |
| 21 | 42111-70B11-000 | STOPPER,BUMP | STOPPER,BUMP |
| 22 | 45200-69D00-000 | アームアッシ,サスペンションコントロール | アームアッシ,サスペンションコントロール |
| 22 | 45200-69DV1-000 | ARM ASSY,FR SPNSN | ARM ASSY,FR SPNSN |
| 27 | 45215-72J10-000 | BOLT,SPNSN ARM FR BUSHING | BOLT,SPNSN ARM FR BUSHING |
| 23 | 45700-70810-000 | Seal Set,dust | Seal Set,dust |
| 23 | 45723-70B00-000 | SEAL SET,DUST | SEAL SET,DUST |
| 23 | 45723-70B01-000 | Seal Set,dust | Seal Set,dust |
| 1 | 46111-69D00-000 | KNUCKLE,RR SUSPENSION,R | KNUCKLE,RR SUSPENSION,R |
| 2 | 46151-69D00-000 | KNUCKLE,RR SUSPENSION,L | KNUCKLE,RR SUSPENSION,L |
