Search › Compare › CM21V × CP21S
CM21V
Suzuki ALTO-A-STAR-CELERIO — 40 of 2,719 shared
CP21S
Suzuki ALTO-A-STAR-CELERIO — 40 of 2,837 shared
emission control (V:4V; 1990-01-01~1991-08-01) 40 / 45
| # | OEM | CM21V | CP21S |
|---|---|---|---|
| 1 | 09355-35754-601 | HOSE(3.5X7.5X601) - Hose, vacuum (inmf to check valve) | HOSE(3.5X7.5X601) - Hose, vacuum (inmf to check valve) |
| 1 | 09358-35754-300 | ホース,3.5X7.5X300 | ホース,3.5X7.5X300 |
| 1 | 09355-35006-601 | Hose(3.5X7.5X601) | Hose(3.5X7.5X601) |
| 2 | 18529-78101-000 | ガスケット,EGRバルブ | ガスケット,EGRバルブ |
| 2 | 18529-60A00-000 | GASKET,EGR VALVE | GASKET,EGR VALVE |
| 3 | 01517-06453-000 | ボルト | ボルト |
| 3 | 01550-0645A-000 | Bolt | Bolt |
| 6 | 95551-79640-000 | VSV IDLE UP | VSV IDLE UP |
| 6 | 95160-70B00-000 | VSV,IDLE UP | VSV,IDLE UP |
| 7 | 18571-60D00-000 | BRACKET,SOLENOID VALVE | BRACKET,SOLENOID VALVE |
| 8 | 18565-60D00-000 | 3WAY | 3WAY |
| 9 | 09367-04003-000 | JOINT,4 WAY | JOINT,4 WAY |
| 13 | 18564-63D00-000 | HOSE,VACUUM | HOSE,VACUUM |
| 16 | 09408-00067-000 | CLIP | CLIP |
| 17 | 09408-00116-000 | CLIP | CLIP |
| 20 | 09367-04009-000 | JOINT - Joint, 3 way | JOINT - Joint, 3 way |
| 23 | 95569-78040-000 | VALVE,CHECK - Valve, check | VALVE,CHECK - Valve, check |
| 25 | 18560-72B20-000 | CANISTER | CANISTER |
| 26 | 18570-72B20-000 | ブラケット,キャニスタ | ブラケット,キャニスタ |
| 26 | 18570-72B21-000 | Bracket,canister | Bracket,canister |
| 27 | 09128-06058-000 | SCREW(6X10) | SCREW(6X10) |
| 28 | 09359-54111-300 | ホース,L:300 - 5.4X11.4X300 | ホース,L:300 - 5.4X11.4X300 |
| 28 | 09359-54111-600 | HOSE(5.4X11.4X600) - Hose, canister & carb | HOSE(5.4X11.4X600) - Hose, canister & carb |
| 29 | 89155-70B00-000 | Joint,evapo hose | Joint,evapo hose |
| 29 | 11192-82000-000 | JOINT,PCV HOSE | JOINT,PCV HOSE |
| 30 | 09354-70123-300 | Hose,fuel filter & cock | Hose,fuel filter & cock |
| 30 | 44421-12FR0-000 | HOSE | HOSE |
| 30 | 09355-70125-600 | HOSE(7X12X600) - Hose, fuel (pump to separator) | HOSE(7X12X600) - Hose, fuel (pump to separator) |
| 31 | 09401-12301-000 | CLIP | CLIP |
| 32 | 09408-00033-000 | CLAMP | CLAMP |
| 36 | 18340-63D00-000 | PIPE,CANISTER | PIPE,CANISTER |
| 36 | 18340-63D01-000 | パイプ,キャニスタ | パイプ,キャニスタ |
| 37 | 01517-06123-000 | Bolt | Bolt |
| 37 | 01550-0612B-000 | Bolt - Bolt, clamp | Bolt - Bolt, clamp |
| 37 | 01550-0612A-000 | Bolt | Bolt |
| 40 | 18563-63D00-000 | ホース,キャニスタベント | ホース,キャニスタベント |
| 40 | 18563-60D00-000 | HOSE,CANISTER VENT | HOSE,CANISTER VENT |
| 41 | 09401-11404-000 | クリップ | クリップ |
| 41 | 09401-11415-000 | CLIP | CLIP |
| 41 | 09401-11407-000 | CLIP | CLIP |
| # | OEM | CM21V | CP21S |
|---|---|---|---|
| 17 | 01517-06123-000 | Bolt | Bolt |
| 21 | 01517-06453-000 | ボルト | ボルト |
| 17 | 01550-0612A-000 | Bolt | Bolt |
| 17 | 01550-0612B-000 | Bolt - Bolt, clamp | Bolt - Bolt, clamp |
| 21 | 01550-0645A-000 | Bolt | Bolt |
| 27 | 09128-06058-000 | SCREW(6X10) | SCREW(6X10) |
| 30 | 09354-70123-300 | Hose,fuel filter & cock | Hose,fuel filter & cock |
| 54 | 09355-35006-601 | Hose(3.5X7.5X601) | Hose(3.5X7.5X601) |
| 54 | 09355-35754-601 | HOSE(3.5X7.5X601) - Hose, vacuum (inmf to check valve) | HOSE(3.5X7.5X601) - Hose, vacuum (inmf to check valve) |
| 30 | 09355-70125-600 | HOSE(7X12X600) - Hose, fuel (pump to separator) | HOSE(7X12X600) - Hose, fuel (pump to separator) |
| 54 | 09358-35754-300 | ホース,3.5X7.5X300 | ホース,3.5X7.5X300 |
| 28 | 09359-54111-300 | ホース,L:300 - 5.4X11.4X300 | ホース,L:300 - 5.4X11.4X300 |
| 28 | 09359-54111-600 | HOSE(5.4X11.4X600) - Hose, canister & carb | HOSE(5.4X11.4X600) - Hose, canister & carb |
| 9 | 09367-04003-000 | JOINT,4 WAY | JOINT,4 WAY |
| 74 | 09367-04009-000 | JOINT - Joint, 3 way | JOINT - Joint, 3 way |
| 41 | 09401-11404-000 | クリップ | クリップ |
| 41 | 09401-11407-000 | CLIP | CLIP |
| 41 | 09401-11415-000 | CLIP | CLIP |
| 31 | 09401-12301-000 | CLIP | CLIP |
| 25 | 09408-00033-000 | CLAMP | CLAMP |
| 16 | 09408-00067-000 | CLIP | CLIP |
| 17 | 09408-00116-000 | CLIP | CLIP |
| 29 | 11192-82000-000 | JOINT,PCV HOSE | JOINT,PCV HOSE |
| 36 | 18340-63D00-000 | PIPE,CANISTER | PIPE,CANISTER |
| 36 | 18340-63D01-000 | パイプ,キャニスタ | パイプ,キャニスタ |
| 2 | 18529-60A00-000 | GASKET,EGR VALVE | GASKET,EGR VALVE |
| 2 | 18529-78101-000 | ガスケット,EGRバルブ | ガスケット,EGRバルブ |
| 25 | 18560-72B20-000 | CANISTER | CANISTER |
| 40 | 18563-60D00-000 | HOSE,CANISTER VENT | HOSE,CANISTER VENT |
| 40 | 18563-63D00-000 | ホース,キャニスタベント | ホース,キャニスタベント |
| 13 | 18564-63D00-000 | HOSE,VACUUM | HOSE,VACUUM |
| 8 | 18565-60D00-000 | 3WAY | 3WAY |
| 26 | 18570-72B20-000 | ブラケット,キャニスタ | ブラケット,キャニスタ |
| 26 | 18570-72B21-000 | Bracket,canister | Bracket,canister |
| 7 | 18571-60D00-000 | BRACKET,SOLENOID VALVE | BRACKET,SOLENOID VALVE |
| 30 | 44421-12FR0-000 | HOSE | HOSE |
| 29 | 89155-70B00-000 | Joint,evapo hose | Joint,evapo hose |
| 6 | 95160-70B00-000 | VSV,IDLE UP | VSV,IDLE UP |
| 6 | 95551-79640-000 | VSV IDLE UP | VSV IDLE UP |
| 23 | 95569-78040-000 | VALVE,CHECK - Valve, check | VALVE,CHECK - Valve, check |
