Search › Compare › A5B310 × A5B412
A5B310
Suzuki SPLASH — 31 of 3,419 shared
A5B412
Suzuki SPLASH — 31 of 3,419 shared
Muffler (A5B413D:W/DPF) 31 / 31
| # | OEM | A5B310 | A5B412 |
|---|---|---|---|
| 1 | 14182-53K00-000 | Gasket, dpf | Gasket, dpf |
| 2 | 14190-53K10-000 | Pipe, exh no.1 | Pipe, exh no.1 |
| 3 | 14195-53K00-000 | Pipe, dpf pressure sensor | Pipe, dpf pressure sensor |
| 4 | 14220-53K00-H02 | Case, dpf | Case, dpf |
| 5 | 14231-53K00-000 | Insulator, catalyst heat | Insulator, catalyst heat |
| 6 | 14271-84E50-000 | Brace, catalytic conv | Brace, catalytic conv |
| 7 | 14281-71C01-000 | MOUNTING,MUF | MOUNTING,MUF |
| 8 | 14357-72J00-000 | NUT | NUT |
| 9 | 09159-08083-000 | NUT | NUT |
| 10 | 01550-1025A-000 | Bolt - Bolt, drive gear | Bolt - Bolt, drive gear |
| 11 | 14182-53K10-000 | GASKET,EXH PIPE | GASKET,EXH PIPE |
| 12 | 14231-63J00-000 | INSULATOR,HEAT | INSULATOR,HEAT |
| 13 | 14250-53K10-000 | Pipe, exh center | Pipe, exh center |
| 14 | 14281-80JA0-000 | MOUNTING,MUF | MOUNTING,MUF |
| 15 | 14283-53K00-000 | Bracket, exh pipe mtg | Bracket, exh pipe mtg |
| 16 | 14300-53K00-000 | Muffler | Muffler |
| 18 | 09159-10049-000 | Nut | Nut |
| 18 | 09159-10102-000 | NUT | NUT |
| 19 | 01550-0816A-000 | Bolt - Bolt, rear | Bolt - Bolt, rear |
| 20 | 18213-53K10-000 | Sensor, exh gas temp | Sensor, exh gas temp |
| 21 | 18215-53K00-000 | Hose, dpf pressure no.1 | Hose, dpf pressure no.1 |
| 21 | 18215-53K10-000 | Hose, dpf pressure no.1 | Hose, dpf pressure no.1 |
| 22 | 18216-53K00-000 | Pipe, dpf pressure | Pipe, dpf pressure |
| 23 | 18217-53K00-000 | Hose, dpf pressure no.2 | Hose, dpf pressure no.2 |
| 24 | 18218-53K00-000 | Hose, dpf pressure no.3 | Hose, dpf pressure no.3 |
| 25 | 18590-79J50-000 | Sensor, dpf pressure | Sensor, dpf pressure |
| 26 | 18595-53K00-000 | Pipe, dpf pressure sensor | Pipe, dpf pressure sensor |
| 27 | 18596-53K10-000 | Bracket, dpf pressure snsr | Bracket, dpf pressure snsr |
| 28 | 09401-13419-000 | CLIP | CLIP |
| 29 | 01550-0616A-000 | Bolt | Bolt |
| 30 | 08316-1006A-000 | NUT | NUT |
| # | OEM | A5B310 | A5B412 |
|---|---|---|---|
| 20 | 01550-0616A-000 | Bolt | Bolt |
| 14 | 01550-0816A-000 | Bolt - Bolt, rear | Bolt - Bolt, rear |
| 46 | 01550-1025A-000 | Bolt - Bolt, drive gear | Bolt - Bolt, drive gear |
| 31 | 08316-1006A-000 | NUT | NUT |
| 5 | 09159-08083-000 | NUT | NUT |
| 13 | 09159-10049-000 | Nut | Nut |
| 13 | 09159-10102-000 | NUT | NUT |
| 8 | 09401-13419-000 | CLIP | CLIP |
| 1 | 14182-53K00-000 | Gasket, dpf | Gasket, dpf |
| 8 | 14182-53K10-000 | GASKET,EXH PIPE | GASKET,EXH PIPE |
| 2 | 14190-53K10-000 | Pipe, exh no.1 | Pipe, exh no.1 |
| 3 | 14195-53K00-000 | Pipe, dpf pressure sensor | Pipe, dpf pressure sensor |
| 4 | 14220-53K00-H02 | Case, dpf | Case, dpf |
| 5 | 14231-53K00-000 | Insulator, catalyst heat | Insulator, catalyst heat |
| 9 | 14231-63J00-000 | INSULATOR,HEAT | INSULATOR,HEAT |
| 13 | 14250-53K10-000 | Pipe, exh center | Pipe, exh center |
| 3 | 14271-84E50-000 | Brace, catalytic conv | Brace, catalytic conv |
| 4 | 14281-71C01-000 | MOUNTING,MUF | MOUNTING,MUF |
| 10 | 14281-80JA0-000 | MOUNTING,MUF | MOUNTING,MUF |
| 15 | 14283-53K00-000 | Bracket, exh pipe mtg | Bracket, exh pipe mtg |
| 11 | 14300-53K00-000 | Muffler | Muffler |
| 12 | 14357-72J00-000 | NUT | NUT |
| 20 | 18213-53K10-000 | Sensor, exh gas temp | Sensor, exh gas temp |
| 21 | 18215-53K00-000 | Hose, dpf pressure no.1 | Hose, dpf pressure no.1 |
| 21 | 18215-53K10-000 | Hose, dpf pressure no.1 | Hose, dpf pressure no.1 |
| 22 | 18216-53K00-000 | Pipe, dpf pressure | Pipe, dpf pressure |
| 23 | 18217-53K00-000 | Hose, dpf pressure no.2 | Hose, dpf pressure no.2 |
| 24 | 18218-53K00-000 | Hose, dpf pressure no.3 | Hose, dpf pressure no.3 |
| 25 | 18590-79J50-000 | Sensor, dpf pressure | Sensor, dpf pressure |
| 26 | 18595-53K00-000 | Pipe, dpf pressure sensor | Pipe, dpf pressure sensor |
| 27 | 18596-53K10-000 | Bracket, dpf pressure snsr | Bracket, dpf pressure snsr |
