Search › Model › ZZE172
ZZE172
Heating & Air Conditioning - Control & Air Duct ([10.2013 - ] SENSOR (1310- )LHD) 5
| # | OEM | Part name |
|---|---|---|
| 88505 | 88505-02100 | Duct Sub-Assy,air Conditioner |
| 88625 | 88625-47031 | Thermistor, Cooler (Solar Sensor) |
| 88625 | 88625-47021 | Thermistor, Cooler No.3 |
| 88688 | 88688-0Z340 | Bracket (For Cooler Thermistor) |
| 88790 | 88790-22131 | Thermistor, Cooler |
| OEM | Part name | Category |
|---|---|---|
| 88505-02100 | Duct Sub-Assy,air Conditioner | Heating & Air Conditioning - Control & Air Duct ([10.2013 - ] SENSOR (1310- )LHD) |
| 88625-47021 | Thermistor, Cooler No.3 | Heating & Air Conditioning - Control & Air Duct ([10.2013 - ] SENSOR (1310- )LHD) |
| 88625-47031 | Thermistor, Cooler (Solar Sensor) | Heating & Air Conditioning - Control & Air Duct ([10.2013 - ] SENSOR (1310- )LHD) |
| 88688-0Z340 | Bracket (For Cooler Thermistor) | Heating & Air Conditioning - Control & Air Duct ([10.2013 - ] SENSOR (1310- )LHD) |
| 88790-22131 | Thermistor, Cooler | Heating & Air Conditioning - Control & Air Duct ([10.2013 - ] SENSOR (1310- )LHD) |
