YY61

Toyota TOYOACE-DYNA · 1985 · 3,278 parts · 166 categories
YY61 ×

← Back to categories

3,278 items
Switch & Relay & Computer ([08.1987 - ] (8708- )) 110
#OEMPart name
28380 28380-73020 Relay Assy, Fuel Pump
28515 28515-73020 Resistor, Solenoid
74468 74468-95700 Bracket, Relay Block
81980 81980-37040 Flasher Assy, Turn Signal
82600 90982-09002 Fusible Link
82600 90982-09003 Fusible Link
82600 90982-09004 Fusible Link
82600 90982-09005 Fuse, Fuse Block
82611 82611-95013 Cover, Fuse Block
82616 82616-12010 Lever, Fuse
82650 82650-12020 Breaker Assy, Wiring Circuit, No.1
83301 83301-20016 Gage Sub-Assy, Fuel Sender (For Lpg Tank)
83302 83302-36010 Body Sub-Assy, Fuel Sender Gage
83302 83302-36011 Body Sub-Assy, Fuel Sender Gage
83361 90430-42255 Gasket(For Fuel Tank)
83391 83391-25020 Switch, Vacuum
83391 83391-27060 Switch, Vacuum
83420 83420-20020 Gage Assy, Water Temperature Sender
83530 83530-14070 Switch Assy, Oil Pressure (For Engine)
83530 83530-28010 Switch Assy, Oil Pressure (For Engine)
83650 90986-01003 Fusee
83970 83970-16010 Buzzer Assy, Reverse Warning
83970 83970-95401 Buzzer Assy, Reverse Warning
84233 84231-28020 Switch, Courtesy Lamp
84233 84231-28010 Switch Assy, Courtesy Lamp
84340 84340-36050 Switch Assy, Stop Lamp
84540 84540-30290 Switch Assy, Neutral Start
84550 84550-20030 Switch Assy, Courtesy Lamp (For Parking Brake)
84931 84931-37020 Switch, Door Control
85909 85909-95405 Bracket Sub-Assy, Relay Block
85909 85909-95010 Bracket Sub-Assy, Relay, No.1
85909 85907-37010 Bracket Sub-Assy, Relay, No.2
85910 90987-02004 Relay Assy, Starter
85916 90987-01003 Relay, Fuel Lid Opener
85916 90987-02006 Relay
85927 90987-03001 Relay
85930 85930-25010 Relay Assy, Power Window
85933 85933-25010 Computer, Shift Lock Control
85958 85958-25010 Bracket, Main Relay
85980 85980-25010 Relay Assy, Door Control
85985 80590-26010 Relay, Key Reminder
86650 86650-95A04 Buzzer Assy, Reverse Warning
87989 87989-37020 Relay, Mirror Control
89373 89373-26050 Sensor, Lamp Failure Indicator
89425 89425-39315 Sensor, Exhaust Gas Temperature
89465 89465-29665 Sensor, Oxygen
89466 89466-20020 Gasket(For Exhaust Manifold Plate)
89491 89491-26090 Sensor, Engine Oil Level
89491 89491-26091 Sensor, Engine Oil Level
89550 89550-37010 Computer Assy, Emission Control
89590 89590-36140 Computer Assy, Condition Indicator
1987766010 19877-66010 Insulator Sub-Assy, Glow Plug, No.1
2332264010 23322-64010 Drain Plug (For a Level Warning Switch)
2333854020 23338-54020 Gasket(for Warning Switch)
2334454010 23344-54010 O-Ring (For Drain Plug)
2334454030 23344-54030 Gasket, Clamping Nut(for Fuel Filter)
2862254020 28622-54020 Insulator, Glow Plug Resistor, No.1
2862257010 28622-57010 Insulator, Glow Plug Resistor, No.1
2862354010 28623-54010 Insulator, Glow Plug Resistor, No.2
8271112200 82711-12200 Clamp (For Fuel Lid Lock Control Cable)
8271114620 82711-14620 Bracket, Relay, No.3
8271125030 82711-25030 Wire, Fuse To Fuse(for Combustion Heater)
8271195025 82711-95025 Wire, Fuse To Fuse(for Combustion Heater)
9011606041 90116-06041 Bolt, Stud(For Intake Manifold To Glow Plug Connector No.1)
9011606041 90116-06095 Bolt, Stud(For Head To Cylinder Head Cover)
9011606275 90116-06275 Bolt, Stud(For Injection Pipe Clamp)
9011906186 90119-06186 BOLT
9011906186 90119-06420 BOLT WWASHER
9017008204 90170-08204 Nut (For Propeller Shaft)
9017905032 90179-05032 NUT
9017905032 90179-05011 NUT
9017906158 90179-06158 Nut, Rear Wiper Link Pivot, No.2
9017908059 90179-08059 Nut
9017908059 90179-08101 NUT
9017908123 90179-08123 Nut (For Front Wiper Arm Setting)
9017910155 90179-10155 Nut, Heater Blower Switch
9020110008 90201-10008 Washer, No.2 (For Center Support Bearing)
9033325001 90333-25001 Plug, Hole(For Hood)
9043008252 90430-08252 Gasket(For Catalytic Converter Sensor Guide)
9043012221 90430-12221 Gasket
9043018008 90430-18008 Gasket
9043018008 90430-T0021 Gasket(For Manual Transmission Filler Plug)
9043027001 90430-27001 Gasket, Engine Oil Level Sensor
9046106102 90461-06102 New Genuine Part
9046400095 90464-00095 New Genuine Part
9161160612 91611-60612 Bolt(For Dust Cover To Steering Knuckle Arm Setting)
9161160612 91611-G0612 Bolt
9161160820 91611-60820 Bolt(For Transaxle & Engine Setting)
9161160820 91611-G0820 Bolt
9164280822 91642-80822 New Genuine Part
9165140612 91651-40612 BOLT
9165140612 90080-11225 New Genuine Part
9165140820 91651-40820 Bolt
9165160616 91651-60616 BOLT
9165640616 91656-40616 Bolt
9165640616 91651-60614 Bolt
9165640816 91656-40816 New Genuine Part
9165640816 91651-B0814 Bolt with washer
9165640816 90119-A0109 New Genuine Part
9165640818 91656-40818 Clamp Or Clip, Hose(For Radiator Outlet No.1)
9331914010 93319-14010 SCREW
9338516014 93385-16014 New Genuine Part
9338516025 93385-16025 New Genuine Part
9411070800 94110-70800 Nut, No.1 (For Center Support Bearing)
9411070800 94130-00802 Nut, No.1 (For Center Support Bearing)
9412040800 94120-40800 Nut(For Clutch Pedal Stopper)
9412041000 94120-41000 Nut(For Clutch Pedal Stopper)
9412041000 90170-A0002 Nut
9418040600 94180-40600 Retainer, Roof Window Hinge
9461310601 94613-10601 Washer (For Primary Regulator Valve)
