| 01421-06203-000 |
Stud bolt (l:20)(green) - Stud bolt (6x32) |
water hose (2003-06-01~2005-04-01) |
| 01421-0620A-000 |
BOLT,STUD |
water hose (2003-06-01~2005-04-01) |
| 01421-08253-000 |
Stud bolt, no.2 |
water hose (2003-06-01~2005-04-01) |
| 01421-0825A-000 |
BOLT,STUD |
water hose (2003-06-01~2005-04-01) |
| 01550-06123-000 |
Bolt |
water hose (2003-06-01~2005-04-01) |
| 01550-0612A-000 |
Bolt |
water hose (2003-06-01~2005-04-01) |
| 01550-0612B-000 |
Bolt - Bolt, clamp |
water hose (2003-06-01~2005-04-01) |
| 01550-06203-000 |
Bolt |
water hose (2003-06-01~2005-04-01) |
| 01550-0620B-000 |
Bolt - Bolt, inspection cap |
water hose (2003-06-01~2005-04-01) |
| 07120-10253-000 |
Bolt |
water hose (2003-06-01~2005-04-01) |
| 07120-1025A-000 |
Bolt |
water hose (2003-06-01~2005-04-01) |
| 08316-10063-000 |
Nut |
water hose (2003-06-01~2005-04-01) |
| 08316-1006B-000 |
NUT |
water hose (2003-06-01~2005-04-01) |
| 08316-10083-000 |
Nut |
water hose (2003-06-01~2005-04-01) |
| 08316-1008B-000 |
NUT |
water hose (2003-06-01~2005-04-01) |
| 09280-34005-000 |
O RING(D:3.5,ID:33.7) |
water hose (2003-06-01~2005-04-01) |
| 09280-44008-000 |
O RING(D:2.4,ID:39.5) |
water hose (2003-06-01~2005-04-01) |
| 09401-10409-000 |
CLIP |
water hose (2003-06-01~2005-04-01) |
| 09401-18403-000 |
CLIP - Clip, heater hose |
water hose (2003-06-01~2005-04-01) |
| 09401-21405-000 |
CLIP |
water hose (2003-06-01~2005-04-01) |
| 09401-35403-000 |
CLIP |
water hose (2003-06-01~2005-04-01) |
| 09401-35404-000 |
クリップ |
water hose (2003-06-01~2005-04-01) |
| 13650-50G01-000 |
Sensor,water Temp |
water hose (2003-06-01~2005-04-01) |
| 17550-52D01-000 |
PIPE,WATER INLET |
water hose (2003-06-01~2005-04-01) |
| 17561-67D01-000 |
CAP,WTR THERMOSTAT |
water hose (2003-06-01~2005-04-01) |
| 17570-52D00-000 |
CAP ASSY,WTR OUTLET |
water hose (2003-06-01~2005-04-01) |
| 17570-67D10-000 |
CAP,WTR OUTLET |
water hose (2003-06-01~2005-04-01) |
| 17571-52D00-000 |
CAPWTR OUTLET |
water hose (2003-06-01~2005-04-01) |
| 17579-67D00-000 |
GASKET,WTR OUTLET CAP |
water hose (2003-06-01~2005-04-01) |
| 17579-85FA0-000 |
GASKET,WTR OUTLET CAP |
water hose (2003-06-01~2005-04-01) |
| 17589-77E00-000 |
PIPE,WTR OUTLET |
water hose (2003-06-01~2005-04-01) |
| 17670-77E11-000 |
THERMOSTAT,WATER 82 DEG |
water hose (2003-06-01~2005-04-01) |
| 17690-52D00-000 |
CASE,THERMOSTAT |
water hose (2003-06-01~2005-04-01) |
| 17841-52D00-000 |
HOSE,RADIATOR INLET |
water hose (2003-06-01~2005-04-01) |
| 17851-52D00-000 |
HOSE,RADIATOR OUTLET |
water hose (2003-06-01~2005-04-01) |
| 17857-77E00-000 |
HOSE,WATER HEAD,R |
water hose (2003-06-01~2005-04-01) |
| 17858-77E00-000 |
HOSE,WATER HEAD,L |
water hose (2003-06-01~2005-04-01) |
| 17871-67D20-000 |
HOSE,HEATER INLET |
water hose (2003-06-01~2005-04-01) |
| 17872-67D20-000 |
HOSE,HEATER OUTLET |
water hose (2003-06-01~2005-04-01) |
| 17873-77E01-000 |
HOSE,WATER CIRCULATION |
water hose (2003-06-01~2005-04-01) |
| 17880-67D00-000 |
PIPE,HEATER OUTLET |
water hose (2003-06-01~2005-04-01) |
| 17920-65G50-000 |
CAP,DEGASSING TANK 1.1 |
water hose (2003-06-01~2005-04-01) |
