| 01550-06303-000 |
Bolt (6x30) - Bolt, head cover l:30 |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 01550-0630A-000 |
Bolt |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 01550-06403-000 |
Bolt (green) - Bolt, engine controlunit |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 01550-0640A-000 |
Bolt - Bolt (l:40) |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 01550-0640B-000 |
Bolt |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 01570-06123-000 |
Bolt |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 01570-0612A-000 |
Bolt |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 01570-0612B-000 |
Bolt - Bolt, upper |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 02162-06123-000 |
Bolt (6x12) |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 02162-0612A-000 |
SCREW - Bolt, bracket |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 02162-0612B-000 |
SCREW - Bolt |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 09132-06006-000 |
SCREW(6X12) |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 09161-10009-000 |
WASHER(10X15X1.5) - Lock washer |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 09360-10026-000 |
Union bolt |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 09383-13001-000 |
E RING |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 09383-13003-000 |
E-RING |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 09403-06401-000 |
CLAMP |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 09403-06404-000 |
CLAMP |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 09403-07312-000 |
CLAMP |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 51340-60A60-000 |
PIPE,JOINT TO RR BK HOSE |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 51410-77E60-000 |
PIPE,MA PRIMARY TO PV |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 51420-77E10-000 |
PIPE,JOINT TO FR BK HOSE |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 51430-77E60-000 |
PIPE,HU TO FL BK HOSE |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 51435-60A00-000 |
CLAMP,BRAKE PIPE SIDE |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 51440-77E60-000 |
PIPE,HU TO JOINT FRONT |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 51450-77E60-000 |
PIPE,HU TO JOINT REAR |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 51465-60A00-000 |
CLAMP,BRAKE PIPE FRAME |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 51470-77E00-000 |
PIPE,RR BK HOSE TO R BK ASSY |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 51480-77E00-000 |
PIPE,R BK ASSY TO L BK ASSY |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 51490-77E60-000 |
PIPE,PV FRONT TO HU |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 51510-77E60-000 |
PIPE,PV REAR TO HU |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 51520-77E50-000 |
PIPE,MA SECONDARY TO PV |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 51540-60A31-000 |
HOSE,FR BRAKE FLEXIBLE,R |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 51550-60A31-000 |
HOSE,FR BRAKE FLEXIBLE,L |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 51560-83031-000 |
HOSE,RR BRAKE FLEXIBLE |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 51570-77E00-000 |
HOSE,MA CYL FLEXIBLE |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 51640-60A60-000 |
JOINT,4WAY BRAKE |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 51751-77E00-000 |
CLAMP,BRAKE PIPE |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 51752-70B00-000 |
CLAMP,BK PIPE |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 51753-60G00-000 |
CLAMP,PIPE HU |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 51920-60A10-000 |
VALVE ASSY,P&DIFFERENTIAL |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
| 51925-77E10-000 |
BRACKET,P&B VALVE |
brakes piping (ABS; (2DR,4DR):XD; 1994-11-01~) |
