Search › Model › SY419
SY419
Throttle body (SY419:TYPE 6) 12
| # | OEM | Part name |
|---|---|---|
| 1 | 13953-65GA0-000 | Pipe, throt body outlet |
| 2 | 13954-65GA0-000 | Hose, thb to manf |
| 3 | 13959-65GA0-000 | Bracket, throt body |
| 4 | 13968-66GA0-000 | Gasket, throt body |
| 5 | 13969-66GA0-000 | Body, throttle |
| 6 | 09402-57511-000 | CLAMP |
| 7 | 01550-06123-000 | Bolt |
| 7 | 01550-0612B-000 | Bolt - Bolt, clamp |
| 7 | 01550-0612A-000 | Bolt |
| 8 | 01550-06253-000 | Bolt (6x25) |
| 8 | 01550-0625B-000 | Bolt - Bolt, head cover |
| 8 | 01550-0625A-000 | Bolt |
| OEM | Part name | Category |
|---|---|---|
| 01550-06123-000 | Bolt | Throttle body (SY419:TYPE 6) |
| 01550-0612A-000 | Bolt | Throttle body (SY419:TYPE 6) |
| 01550-0612B-000 | Bolt - Bolt, clamp | Throttle body (SY419:TYPE 6) |
| 01550-06253-000 | Bolt (6x25) | Throttle body (SY419:TYPE 6) |
| 01550-0625A-000 | Bolt | Throttle body (SY419:TYPE 6) |
| 01550-0625B-000 | Bolt - Bolt, head cover | Throttle body (SY419:TYPE 6) |
| 09402-57511-000 | CLAMP | Throttle body (SY419:TYPE 6) |
| 13953-65GA0-000 | Pipe, throt body outlet | Throttle body (SY419:TYPE 6) |
| 13954-65GA0-000 | Hose, thb to manf | Throttle body (SY419:TYPE 6) |
| 13959-65GA0-000 | Bracket, throt body | Throttle body (SY419:TYPE 6) |
| 13968-66GA0-000 | Gasket, throt body | Throttle body (SY419:TYPE 6) |
| 13969-66GA0-000 | Body, throttle | Throttle body (SY419:TYPE 6) |
