SY31
Heater piping (2007-08-01 ~ ; NA20P; S) 9
| # | OEM | Part name |
|---|---|---|
| 27036 | 27036-V5000 | Cover-Grommet |
| 27181 | 27181-10V00 | Door Assy-Vent, No.1 |
| 27181 | 27181-25V00 | Door Assy-Vent, No.1 |
| 92521 | 01555-00231 | CLAMP |
| 92521 | 01558-00191 | CLIP |
| 92521 | 01558-00321 | CLIP |
| 92521 | 01555-00181 | CLIP |
| 92521 | 01555-00791 | CLAMP |
| 92570 | 92570-15V00 | Grommet-Cooler Tube |
| OEM | Part name | Category |
|---|---|---|
| 01555-00181 | CLIP | Heater piping (2007-08-01 ~ ; NA20P; S) |
| 01555-00231 | CLAMP | Heater piping (2007-08-01 ~ ; NA20P; S) |
| 01555-00791 | CLAMP | Heater piping (2007-08-01 ~ ; NA20P; S) |
| 01558-00191 | CLIP | Heater piping (2007-08-01 ~ ; NA20P; S) |
| 01558-00321 | CLIP | Heater piping (2007-08-01 ~ ; NA20P; S) |
| 27036-V5000 | Cover-Grommet | Heater piping (2007-08-01 ~ ; NA20P; S) |
| 27181-10V00 | Door Assy-Vent, No.1 | Heater piping (2007-08-01 ~ ; NA20P; S) |
| 27181-25V00 | Door Assy-Vent, No.1 | Heater piping (2007-08-01 ~ ; NA20P; S) |
| 92570-15V00 | Grommet-Cooler Tube | Heater piping (2007-08-01 ~ ; NA20P; S) |
