Search › Model › ST191

ST191

Toyota CALDINA · 1992 · 6,042 parts · 278 categories

6,042 items

Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191) 78

#	OEM	Part name
42304	42304-20150	Carrier Sub-Assy, Rear Axle, Rh
42304	42304-20360	Carrier Sub-Assy, Rear Axle, Rh
42304	42304-20170	Carrier Sub-Assy, Rear Axle, Rh
42304	42304-20370	Carrier Sub-Assy, Rear Axle, Rh
42304	42304-20300	Carrier Sub-Assy, Rear Axle, Rh
42304	90105-15001	Bolt (For Rear Axle Carrier)
42304	90179-15001	Nut (For Rear Axle Carrier)
42305	42305-20150	Carrier Sub-Assy, Rear Axle, Lh
42305	42305-20360	Carrier Sub-Assy, Rear Axle, Lh
42305	42305-20170	Carrier Sub-Assy, Rear Axle, Lh
42305	42305-20370	Carrier Sub-Assy, Rear Axle, Lh
42305	42305-20300	Carrier Sub-Assy, Rear Axle, Lh
48231	48231-21031	Spring, Coil, Rear Rh
48231	48231-32500	Spring, Coil, Rear Rh
48231	48231-21060	Spring, Coil, Rear Rh
48231	48231-2D660	Spring, Coil, Rear Rh
48231	48231-2D610	Spring, Coil, Rear Rh
48231	48231-2G060	Spring, Coil, Rear Rh
48231	48231-2G250	Spring, Coil, Rear Rh
48258	48258-32010	Insulator, Rear Coil Spring, Lower
48341	48341-20280	Bumper, Rear Spring, No.1 Rh
48341	48341-32051	Bumper, Rear Spring, No.1 Rh
48341	48341-32052	Bumper, Rear Spring, No.1 Rh
48530	48530-29455	Absorber Assy, Shock, Rear Rh
48530	48530-29765	Absorber Assy, Shock, Rear Rh
48530	48530-29515	Absorber Assy, Shock, Rear Rh
48530	48530-2B010	Absorber Assy, Shock, Rear Rh
48530	48530-2B340	Absorber Assy, Shock, Rear Rh
48540	48540-29155	Absorber Assy, Shock, Rear Lh
48540	48540-29315	Absorber Assy, Shock, Rear Lh
48540	48540-29195	Absorber Assy, Shock, Rear Lh
48540	48540-2B010	Absorber Assy, Shock, Rear Lh
48540	48540-2B340	Absorber Assy, Shock, Rear Lh
48559	48559-20040	Cover, Rear Shock Absober Dust, Rh No.1
48703	90179-14019	Nut
48703	90901-09001	Bolt(For Rear Suspension Arm)
48703	90901-19001	Bolt(For Rear Suspension Arm)
48703	90201-14017	Washer(For Rear Suspension Arm)
48703	48715-20030	Washer, No.2(For Rear Suspension Arm)
48703	48715-32010	Washer, No.2(For Rear Suspension Arm)
48710	48710-20190	Arm Assy, Rear Suspension, No.1 Rh
48710	48710-20230	Arm Assy, Rear Suspension, No.1 Rh
48710	48710-20241	Arm Assy, Rear Suspension, No.1 Rh
48730	48730-20160	Arm Assy, Rear Suspension, No.2 Rh
48730	48730-20220	Arm Assy, Rear Suspension, No.2 Rh
48730	90179-16022	Nut, No.1(For Rear Suspension Arm No.2)
48730	90179-16021	Nut, No.2(For Arm Assy, Rear Suspension, No.2)
48740	48740-20050	Arm Assy, Rear Suspension, No.2 Lh
48740	48740-20080	Arm Assy, Rear Suspension, No.2 Lh
48750	90179-08122	Nut(For Rear Suspension Support)
48750	48750-20100	Support Assy, Rear Suspension, Rh
48750	48750-21020	Support Assy, Rear Suspension, Rh
48750	48750-20150	Support Assy, Rear Suspension, Rh
48750	90179-14015	Nut, Castle (For Front Lower Ball Joint Setting)
48750	94184-61400	Nut(For Idler Arm Support)
48750	90387-15012	Collar(For Rear Support To Rear Shock Absorber)
48750	90387-15027	Collar(For Rear Support To Rear Shock Absorber)
48753	48753-20040	Cover, Rear Suspension Supoport, No.1 Rh
48753	48753-20060	Cover, Rear Suspension Supoport, No.2 Rh
48753	48753-20070	Cover, Rear Suspension Supoport, No.2 Rh
48780	48780-20080	Rod Assy, Strut, Rear
48780	48780-20160	Rod Assy, Strut, Rear
48780	48780-20190	Rod Assy, Strut, Rear
48780	90119-12131	Bolt(For Strut Rod)
48780	90080-11133	Bolt(For Strut Rod)
48780	90179-12062	Nut(For Rear Suspension Arm)
48780	90179-12091	Nut(For Front Suspension Lower Arm)
48780	90179-12114	Nut(For Strut Rod)
48812	48812-05030	Bar, Stabilizer, Rear
48812	48812-20700	Bar, Stabilizer, Rear
48818	48818-20260	Bush, Stabilizer, Rear
48830	48830-32010	Link Assy, Rear Stabilizer
48830	48830-20010	Link Assy, Rear Stabilizer
48830	90179-10054	Nut, No.1 (For Center Support Bearing)
48832	48832-20080	Bracket, Rear Stabilizer Bar, No.1
91611	91611-B0816	Bolt
9046400480	90464-00480	New Genuine Part
9095001453	90950-01453	New Genuine Part

OEM	Part name	Category
42304-20150	Carrier Sub-Assy, Rear Axle, Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
42304-20170	Carrier Sub-Assy, Rear Axle, Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
42304-20300	Carrier Sub-Assy, Rear Axle, Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
42304-20360	Carrier Sub-Assy, Rear Axle, Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
42304-20370	Carrier Sub-Assy, Rear Axle, Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
42305-20150	Carrier Sub-Assy, Rear Axle, Lh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
42305-20170	Carrier Sub-Assy, Rear Axle, Lh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
42305-20300	Carrier Sub-Assy, Rear Axle, Lh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
42305-20360	Carrier Sub-Assy, Rear Axle, Lh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
42305-20370	Carrier Sub-Assy, Rear Axle, Lh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48231-21031	Spring, Coil, Rear Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48231-21060	Spring, Coil, Rear Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48231-2D610	Spring, Coil, Rear Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48231-2D660	Spring, Coil, Rear Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48231-2G060	Spring, Coil, Rear Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48231-2G250	Spring, Coil, Rear Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48231-32500	Spring, Coil, Rear Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48258-32010	Insulator, Rear Coil Spring, Lower	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48341-20280	Bumper, Rear Spring, No.1 Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48341-32051	Bumper, Rear Spring, No.1 Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48341-32052	Bumper, Rear Spring, No.1 Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48530-29455	Absorber Assy, Shock, Rear Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48530-29515	Absorber Assy, Shock, Rear Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48530-29765	Absorber Assy, Shock, Rear Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48530-2B010	Absorber Assy, Shock, Rear Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48530-2B340	Absorber Assy, Shock, Rear Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48540-29155	Absorber Assy, Shock, Rear Lh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48540-29195	Absorber Assy, Shock, Rear Lh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48540-29315	Absorber Assy, Shock, Rear Lh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48540-2B010	Absorber Assy, Shock, Rear Lh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48540-2B340	Absorber Assy, Shock, Rear Lh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48559-20040	Cover, Rear Shock Absober Dust, Rh No.1	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48710-20190	Arm Assy, Rear Suspension, No.1 Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48710-20230	Arm Assy, Rear Suspension, No.1 Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48710-20241	Arm Assy, Rear Suspension, No.1 Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48715-20030	Washer, No.2(For Rear Suspension Arm)	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48715-32010	Washer, No.2(For Rear Suspension Arm)	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48730-20160	Arm Assy, Rear Suspension, No.2 Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48730-20220	Arm Assy, Rear Suspension, No.2 Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48740-20050	Arm Assy, Rear Suspension, No.2 Lh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48740-20080	Arm Assy, Rear Suspension, No.2 Lh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48750-20100	Support Assy, Rear Suspension, Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48750-20150	Support Assy, Rear Suspension, Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48750-21020	Support Assy, Rear Suspension, Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48753-20040	Cover, Rear Suspension Supoport, No.1 Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48753-20060	Cover, Rear Suspension Supoport, No.2 Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48753-20070	Cover, Rear Suspension Supoport, No.2 Rh	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48780-20080	Rod Assy, Strut, Rear	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48780-20160	Rod Assy, Strut, Rear	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48780-20190	Rod Assy, Strut, Rear	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48812-05030	Bar, Stabilizer, Rear	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48812-20700	Bar, Stabilizer, Rear	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48818-20260	Bush, Stabilizer, Rear	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48830-20010	Link Assy, Rear Stabilizer	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48830-32010	Link Assy, Rear Stabilizer	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
48832-20080	Bracket, Rear Stabilizer Bar, No.1	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
90080-11133	Bolt(For Strut Rod)	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
90105-15001	Bolt (For Rear Axle Carrier)	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
90119-12131	Bolt(For Strut Rod)	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
90179-08122	Nut(For Rear Suspension Support)	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
90179-10054	Nut, No.1 (For Center Support Bearing)	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
90179-12062	Nut(For Rear Suspension Arm)	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
90179-12091	Nut(For Front Suspension Lower Arm)	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
90179-12114	Nut(For Strut Rod)	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
90179-14015	Nut, Castle (For Front Lower Ball Joint Setting)	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
90179-14019	Nut	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
90179-15001	Nut (For Rear Axle Carrier)	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
90179-16021	Nut, No.2(For Arm Assy, Rear Suspension, No.2)	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
90179-16022	Nut, No.1(For Rear Suspension Arm No.2)	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
90201-14017	Washer(For Rear Suspension Arm)	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
90387-15012	Collar(For Rear Support To Rear Shock Absorber)	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
90387-15027	Collar(For Rear Support To Rear Shock Absorber)	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
90464-00480	New Genuine Part	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
90901-09001	Bolt(For Rear Suspension Arm)	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
90901-19001	Bolt(For Rear Suspension Arm)	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
90950-01453	New Genuine Part	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
91611-B0816	Bolt	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
94184-61400	Nut(For Idler Arm Support)	Rear Spring & Shock Absorber ([11.1992 - 01.1996] (9211-9601)CT190,ST190,191)
