ST191

Toyota CALDINA · 1992 · 6,042 parts · 278 categories

6,042 items

Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#) 97

#	OEM	Part name
44510	44510-20110	Actuator Assy, Brake
44510	44510-20901	Actuator Assy, Brake
44510	44050-20010	Actuator Assy, Brake
44510	44510-29025	Actuator Assy, Brake
44543	44543-10010	Cap, Rubber
44545	44545-10010	Holder, Brake Actuator Bolt
44545	44545-12090	Holder, Brake Actuator Bolt
44546	44546-10010	Cushion, Brake Actuator Bolt
44551	44551-20050	Tube, Brake Actuator, No.1
44551	90412-10205	Way, No.1(For Brake Actuator)
44591	44591-20070	Bracket, Brake Actuator, No.1
44591	44591-20090	Bracket, Brake Actuator, No.1
44592	44592-20040	Bracket, Brake Actuator, No.2
44593	44593-20050	Bracket, Brake Actuator, No.3
44595	44595-20020	Bracket, Brake Actuator, No.5
47150	47150-12110	Valve Assy, Proportioning
47150	47150-12250	Valve Assy, Proportioning
47150	47150-20250	Valve Assy, Proportioning
47150	47150-20270	Valve Assy, Proportioning
47311	47311-20840	Tube, Front Brake, No.1
47311	47311-20880	Tube, Front Brake, No.1
47311	47311-2B200	Tube, Front Brake, No.1
47311	90412-10201	Way(For Front Brake Tube)
47313	47313-20610	Tube, Front Brake, No.3
47313	47313-20650	Tube, Front Brake, No.3
47313	47313-20810	Tube, Front Brake, No.3
47313	90947-02695	Hose, Flexible, No.1(For Front)
47313	90947-02821	Hose, Flexible, No.1(For Front)
47313	90947-02696	Hose, Flexible, No.1(For Front)
47313	90947-02820	Hose, Flexible, No.1(For Front)
47313	90947-02742	Hose, Flexible, No.1(For Front)
47313	90947-02743	Hose, Flexible, No.1(For Front)
47313	90401-10045	Bolt, Union(For Front Flexible Hose)
47313	47389-30010	Gasket(For Clutch Master Cylinder To Flexible Hose Tube)
47314	47314-20480	Tube, Front Brake, No.4
47314	47314-20520	Tube, Front Brake, No.4
47315	47315-20540	Tube, Front Brake, No.5
47315	47315-20550	Tube, Front Brake, No.5
47315	47315-20700	Tube, Front Brake, No.5
47317	47317-20180	Tube, Front Brake, No.7
47317	47317-20250	Tube, Front Brake, No.7
47318	47318-20310	Tube, Front Brake, No.8
47318	47318-20380	Tube, Front Brake, No.8
47318	90401-10015	Bolt, Union(For Clutch Mas Cylinder To Flexible Hose Tube)
47318	90947-02668	Hose, Flexible(For Rear Rh)
47318	90947-02750	Hose, Flexible(For Rear Rh)
47318	90947-02775	Hose, Flexible(For Rear Rh)
47318	90947-02823	Hose, Flexible(For Rear Rh)
47319	90947-02669	Hose, Flexible(For Rear Lh)
47319	90947-02751	Hose, Flexible(For Rear Lh)
47319	90947-02776	Hose, Flexible(For Rear Lh)
47319	90947-02822	Hose, Flexible(For Rear Lh)
47321	47321-20340	Tube, Rear Brake, No.1
47321	47321-20420	Tube, Rear Brake, No.1
47322	47322-20460	Tube, Rear Brake, No.2
47322	47322-20520	Tube, Rear Brake, No.2
47323	47323-20180	Tube, Rear Brake, No.3
47324	47324-20180	Tube, Rear Brake, No.4
47361	47361-20010	Tube, Front Brake, No.10
47371	47371-20301	Clamp, Brake Tube, No.1
47371	47371-20311	Clamp, Brake Tube, No.1
47371	47371-20660	Clamp, Brake Tube, No.1
47371	47371-20411	Clamp, Brake Tube, No.6
47371	47371-20500	Clamp, Brake Tube, No.6
47371	47371-20380	Clamp, Brake Tube, No.7
47371	47371-20700	Clamp, Brake Tube, No.7
47372	47371-20200	Clamp, Brake Tube, No.1
47372	47371-20320	Clamp, Brake Tube, No.2
47372	47371-20370	Clamp, Brake Tube, No.1
47372	47371-20670	Clamp, Brake Tube, No.2
47373	47371-20330	Clamp, Brake Tube, No.3
47373	47371-20680	Clamp, Brake Tube, No.6
47374	47371-20291	Clamp, Brake Tube, No.4
47375	47371-20351	Clamp, Brake Tube, No.5
47375	47371-20690	Clamp, Brake Tube, No.8
91651	91651-B0614	BOLT WWASHER
91656	91656-B0625	New Genuine Part
91656	91651-B0622	New Genuine Part
9011906746	90119-06746	New Genuine Part
9011906746	91631-J0612	BRACKET
9012908007	90129-08007	New Genuine Part
9017906074	90179-06074	Nut(For Suspension Control Oil Cooler)
9017906158	90179-06158	Nut, Rear Wiper Link Pivot, No.2
9017908177	90179-08177	New Genuine Part
9046106055	90461-06055	Clamp, Brake Tube, No.1
9046400657	90464-00657	CLAMP
9046808035	90468-08035	CLIP
9046808035	90468-A0007	New Genuine Part
9048001556	90480-01556	Grommet, No.2(For Front Brake Tube)
9048001628	90480-01628	Grommet(For Brake Tube)
9094901806	90949-01806	Clamp, Brake Tube, No.8
9161160640	91611-60640	New Genuine Part
9165140610	91651-40610	RIVET
9165160616	91651-60616	BOLT
9166160816	91661-60816	Bolt
9461410600	94614-10600	Washer (For Primary Regulator Valve)
9461410600	94613-10601	Washer (For Primary Regulator Valve)

OEM	Part name	Category
44050-20010	Actuator Assy, Brake	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
44510-20110	Actuator Assy, Brake	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
44510-20901	Actuator Assy, Brake	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
44510-29025	Actuator Assy, Brake	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
44543-10010	Cap, Rubber	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
44545-10010	Holder, Brake Actuator Bolt	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
44545-12090	Holder, Brake Actuator Bolt	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
44546-10010	Cushion, Brake Actuator Bolt	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
44551-20050	Tube, Brake Actuator, No.1	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
44591-20070	Bracket, Brake Actuator, No.1	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
44591-20090	Bracket, Brake Actuator, No.1	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
44592-20040	Bracket, Brake Actuator, No.2	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
44593-20050	Bracket, Brake Actuator, No.3	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
44595-20020	Bracket, Brake Actuator, No.5	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47150-12110	Valve Assy, Proportioning	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47150-12250	Valve Assy, Proportioning	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47150-20250	Valve Assy, Proportioning	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47150-20270	Valve Assy, Proportioning	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47311-20840	Tube, Front Brake, No.1	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47311-20880	Tube, Front Brake, No.1	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47311-2B200	Tube, Front Brake, No.1	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47313-20610	Tube, Front Brake, No.3	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47313-20650	Tube, Front Brake, No.3	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47313-20810	Tube, Front Brake, No.3	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47314-20480	Tube, Front Brake, No.4	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47314-20520	Tube, Front Brake, No.4	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47315-20540	Tube, Front Brake, No.5	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47315-20550	Tube, Front Brake, No.5	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47315-20700	Tube, Front Brake, No.5	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47317-20180	Tube, Front Brake, No.7	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47317-20250	Tube, Front Brake, No.7	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47318-20310	Tube, Front Brake, No.8	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47318-20380	Tube, Front Brake, No.8	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47321-20340	Tube, Rear Brake, No.1	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47321-20420	Tube, Rear Brake, No.1	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47322-20460	Tube, Rear Brake, No.2	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47322-20520	Tube, Rear Brake, No.2	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47323-20180	Tube, Rear Brake, No.3	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47324-20180	Tube, Rear Brake, No.4	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47361-20010	Tube, Front Brake, No.10	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47371-20200	Clamp, Brake Tube, No.1	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47371-20291	Clamp, Brake Tube, No.4	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47371-20301	Clamp, Brake Tube, No.1	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47371-20311	Clamp, Brake Tube, No.1	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47371-20320	Clamp, Brake Tube, No.2	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47371-20330	Clamp, Brake Tube, No.3	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47371-20351	Clamp, Brake Tube, No.5	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47371-20370	Clamp, Brake Tube, No.1	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47371-20380	Clamp, Brake Tube, No.7	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47371-20411	Clamp, Brake Tube, No.6	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47371-20500	Clamp, Brake Tube, No.6	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47371-20660	Clamp, Brake Tube, No.1	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47371-20670	Clamp, Brake Tube, No.2	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47371-20680	Clamp, Brake Tube, No.6	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47371-20690	Clamp, Brake Tube, No.8	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47371-20700	Clamp, Brake Tube, No.7	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
47389-30010	Gasket(For Clutch Master Cylinder To Flexible Hose Tube)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90119-06746	New Genuine Part	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90129-08007	New Genuine Part	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90179-06074	Nut(For Suspension Control Oil Cooler)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90179-06158	Nut, Rear Wiper Link Pivot, No.2	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90179-08177	New Genuine Part	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90401-10015	Bolt, Union(For Clutch Mas Cylinder To Flexible Hose Tube)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90401-10045	Bolt, Union(For Front Flexible Hose)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90412-10201	Way(For Front Brake Tube)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90412-10205	Way, No.1(For Brake Actuator)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90461-06055	Clamp, Brake Tube, No.1	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90464-00657	CLAMP	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90468-08035	CLIP	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90468-A0007	New Genuine Part	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90480-01556	Grommet, No.2(For Front Brake Tube)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90480-01628	Grommet(For Brake Tube)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90947-02668	Hose, Flexible(For Rear Rh)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90947-02669	Hose, Flexible(For Rear Lh)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90947-02695	Hose, Flexible, No.1(For Front)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90947-02696	Hose, Flexible, No.1(For Front)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90947-02742	Hose, Flexible, No.1(For Front)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90947-02743	Hose, Flexible, No.1(For Front)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90947-02750	Hose, Flexible(For Rear Rh)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90947-02751	Hose, Flexible(For Rear Lh)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90947-02775	Hose, Flexible(For Rear Rh)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90947-02776	Hose, Flexible(For Rear Lh)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90947-02820	Hose, Flexible, No.1(For Front)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90947-02821	Hose, Flexible, No.1(For Front)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90947-02822	Hose, Flexible(For Rear Lh)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90947-02823	Hose, Flexible(For Rear Rh)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
90949-01806	Clamp, Brake Tube, No.8	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
91611-60640	New Genuine Part	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
91631-J0612	BRACKET	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
91651-40610	RIVET	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
91651-60616	BOLT	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
91651-B0614	BOLT WWASHER	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
91651-B0622	New Genuine Part	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
91656-B0625	New Genuine Part	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
91661-60816	Bolt	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
94613-10601	Washer (For Primary Regulator Valve)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)
94614-10600	Washer (For Primary Regulator Valve)	Brake Tube & Clamp ([11.1992 - 01.1996] ｱﾘ(ABS) (9211-9601)CT190,ST19#)

Source: Public OEM parts-catalog data
Variants: 1 / 2
Category: 278
Collected: 2026-08-02
