Search › Model › ST185

ST185

Toyota CELICA · 1989 · 5,063 parts · 317 categories

5,063 items

Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185) 40

#	OEM	Part name
42304	42304-20040	Carrier Sub-Assy, Rear Axle, Rh
42304	42304-20290	Carrier Sub-Assy, Rear Axle, Rh
42304	90105-15001	Bolt (For Rear Axle Carrier)
42304	90179-15001	Nut (For Rear Axle Carrier)
42305	42305-20040	Carrier Sub-Assy, Rear Axle, Lh
42305	42305-20290	Carrier Sub-Assy, Rear Axle, Lh
48071	48071-20080	Support Sub-Assy, Rear Suspension, Rh
48072	48072-20020	Support Sub-Assy, Rear Suspension, Lh
48231	48231-2D170	Spring, Coil, Rear
48231	48231-2B350	Spring, Coil, Rear
48258	48258-32010	Insulator, Rear Coil Spring, Lower
48341	48341-20180	Bumper, Rear Spring
48409	48409-20030	Cam Sub-Assy, Rear Suspension Toe Adjust
48452	48452-20010	Plate, Rear Suspension Toe Adjust, No.2
48530	48530-20680	Absorber Assy, Shock, Rear Rh
48540	48540-20680	Absorber Assy, Shock, Rear Lh
48703	90170-14006	Nut
48703	90209-13005	Washer(For Rear Suspension Arm)
48703	90119-12083	Bolt(For Front Suspension Lower Arm)
48703	90119-12126	Bolt(For Rear Suspension Arm)
48703	90119-14024	Bolt(For Rear Suspension Arm)
48710	48710-20180	Arm Assy, Rear Suspension, No.1 Rh
48730	48730-20140	Arm Assy, Rear Suspension, No.2
48750	90179-14015	Nut, Castle (For Front Lower Ball Joint Setting)
48750	90387-15012	Collar(For Rear Support To Rear Shock Absorber)
48750	90387-15027	Collar(For Rear Support To Rear Shock Absorber)
48750	90179-08122	Nut(For Rear Suspension Support)
48753	48753-20030	Cover, Rear Suspension Support
48780	48780-20060	Rod Assy, Strut, Rear
48780	90119-12131	Bolt(For Strut Rod)
48780	90080-11133	Bolt(For Strut Rod)
48780	90179-12062	Nut(For Rear Suspension Arm)
48780	90179-12065	Nut(For Strut Rod)
48812	48812-20640	Bar, Stabilizer, Rear
48818	48818-20250	Bush, Stabilizer, Rear
48830	48830-20010	Link Assy, Rear Stabilizer
48830	90179-10054	Nut, No.1 (For Center Support Bearing)
48832	48832-20030	Bracket, Stabilizer(For Rear)
9161560820	91615-60820	Bolt (For Transmission Control Cable Bracket)
9161560820	91611-B0816	Bolt

OEM	Part name	Category
42304-20040	Carrier Sub-Assy, Rear Axle, Rh	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
42304-20290	Carrier Sub-Assy, Rear Axle, Rh	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
42305-20040	Carrier Sub-Assy, Rear Axle, Lh	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
42305-20290	Carrier Sub-Assy, Rear Axle, Lh	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
48071-20080	Support Sub-Assy, Rear Suspension, Rh	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
48072-20020	Support Sub-Assy, Rear Suspension, Lh	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
48231-2B350	Spring, Coil, Rear	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
48231-2D170	Spring, Coil, Rear	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
48258-32010	Insulator, Rear Coil Spring, Lower	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
48341-20180	Bumper, Rear Spring	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
48409-20030	Cam Sub-Assy, Rear Suspension Toe Adjust	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
48452-20010	Plate, Rear Suspension Toe Adjust, No.2	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
48530-20680	Absorber Assy, Shock, Rear Rh	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
48540-20680	Absorber Assy, Shock, Rear Lh	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
48710-20180	Arm Assy, Rear Suspension, No.1 Rh	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
48730-20140	Arm Assy, Rear Suspension, No.2	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
48753-20030	Cover, Rear Suspension Support	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
48780-20060	Rod Assy, Strut, Rear	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
48812-20640	Bar, Stabilizer, Rear	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
48818-20250	Bush, Stabilizer, Rear	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
48830-20010	Link Assy, Rear Stabilizer	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
48832-20030	Bracket, Stabilizer(For Rear)	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
90080-11133	Bolt(For Strut Rod)	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
90105-15001	Bolt (For Rear Axle Carrier)	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
90119-12083	Bolt(For Front Suspension Lower Arm)	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
90119-12126	Bolt(For Rear Suspension Arm)	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
90119-12131	Bolt(For Strut Rod)	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
90119-14024	Bolt(For Rear Suspension Arm)	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
90170-14006	Nut	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
90179-08122	Nut(For Rear Suspension Support)	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
90179-10054	Nut, No.1 (For Center Support Bearing)	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
90179-12062	Nut(For Rear Suspension Arm)	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
90179-12065	Nut(For Strut Rod)	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
90179-14015	Nut, Castle (For Front Lower Ball Joint Setting)	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
90179-15001	Nut (For Rear Axle Carrier)	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
90209-13005	Washer(For Rear Suspension Arm)	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
90387-15012	Collar(For Rear Support To Rear Shock Absorber)	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
90387-15027	Collar(For Rear Support To Rear Shock Absorber)	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
91611-B0816	Bolt	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)
91615-60820	Bolt (For Transmission Control Cable Bracket)	Rear Spring & Shock Absorber ([10.1989 - ] (8910- )ST185)

Source: Public OEM parts-catalog data
Variants: 2 / 14
Category: 317
Collected: 2026-08-02
