| 17308-74070 |
Hose Sub-Assy, Vacuum(For Idle-Up) |
Vacuum Piping ([09.1989 - 08.1991] (8909-9108)3SGE) |
| 17341-74140 |
Hose, No.1(For Idle-Up) |
Vacuum Piping ([09.1989 - 08.1991] (8909-9108)3SGE) |
| 17341-74150 |
Hose, No.1(For Idle-Up) |
Vacuum Piping ([09.1989 - 08.1991] (8909-9108)3SGE) |
| 17341-74240 |
Hose, Air |
Vacuum Piping ([09.1989 - 08.1991] (8909-9108)3SGE) |
| 17342-74050 |
Hose, No.2(For Idle-Up) |
Vacuum Piping ([09.1989 - 08.1991] (8909-9108)3SGE) |
| 17342-74180 |
Hose, No.2(For Idle-Up) |
Vacuum Piping ([09.1989 - 08.1991] (8909-9108)3SGE) |
| 17342-88361 |
Hose, No.2(For Idle-Up) |
Vacuum Piping ([09.1989 - 08.1991] (8909-9108)3SGE) |
| 17361-74040 |
Tube, Air(For Idle-Up) |
Vacuum Piping ([09.1989 - 08.1991] (8909-9108)3SGE) |
| 17630-16040 |
Valve Assy, Air Control |
Vacuum Piping ([09.1989 - 08.1991] (8909-9108)3SGE) |
| 17630-70020 |
Valve Assy, Air Control |
Vacuum Piping ([09.1989 - 08.1991] (8909-9108)3SGE) |
| 25740-74010 |
Valve Assy, Air Control(For Idle Speed Control) |
Vacuum Piping ([09.1989 - 08.1991] (8909-9108)3SGE) |
| 25860-74020 |
Valve Assy, Vacuum Switching, No.1 |
Vacuum Piping ([09.1989 - 08.1991] (8909-9108)3SGE) |
| 44750-20861 |
Hose Assy, Vacuum |
Vacuum Piping ([09.1989 - 08.1991] (8909-9108)3SGE) |
| 90339-07001 |
Plug, Heater Water |
Vacuum Piping ([09.1989 - 08.1991] (8909-9108)3SGE) |
| 90464-00184 |
Clamp, Vacuum Tube |
Vacuum Piping ([09.1989 - 08.1991] (8909-9108)3SGE) |
| 90999-92002 |
Air Hose (300 mm) |
Vacuum Piping ([09.1989 - 08.1991] (8909-9108)3SGE) |
| 91611-60814 |
Bolt |
Vacuum Piping ([09.1989 - 08.1991] (8909-9108)3SGE) |
| 91651-60612 |
BOLT |
Vacuum Piping ([09.1989 - 08.1991] (8909-9108)3SGE) |
| 91651-60814 |
Clamp Or Clip, Hose(for Radiator Outlet No.1) |
Vacuum Piping ([09.1989 - 08.1991] (8909-9108)3SGE) |
| 91651-B0814 |
Bolt with washer |
Vacuum Piping ([09.1989 - 08.1991] (8909-9108)3SGE) |
