| 11101-88382 |
Head Sub-Assy, Cylinder |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 11115-88381 |
Gasket, Cylinder Head |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 11115-88382 |
Gasket, Cylinder Head |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 11122-88320 |
Bush, Intake Valve Guide |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 11123-88320 |
Bush, Intake Valve Guide |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 11131-74010 |
Seat, Intake Valve |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 11135-74010 |
Seat, Exhaust Valve |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 11201-88381 |
Cover Sub-Assy, Cylinder Head |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 11213-88360 |
Gasket, Cylinder Head Cover |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 11214-88380 |
Gasket, Cylinder Head Cover |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 12180-13030 |
Cap Sub-Assy, Oil Filler |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 12180-55010 |
Cap Sub-Assy, Oil Filler |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 90110-10010 |
Bolt(For Cylinder Head Set) |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 90119-07001 |
Bolt(For Head To Camshaft Bearing Cap) |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 90119-07002 |
Bolt(For Head To Camshaft Bearing Cap) |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 90119-07003 |
Bolt(For Head To Camshaft Bearing Cap) |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 90201-10060 |
Washer, Plate(For Cylinder Head Set) |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 90210-07001 |
Washer, Seal(For Cylinder Head Cover) |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 90249-06052 |
Pin, Slotted Spring, No.1 |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 90250-06003 |
Pin, Straight |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 90253-10004 |
Pin, Ring W/head |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 90311-35008 |
Seal, Oil(For Camshaft Setting) |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 90311-35040 |
Seal, Oil(For Timing Chain Or Belt Cover) |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 90341-27003 |
Plug, W/head Taper Screw, No.1 |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 90344-52003 |
Plug, W/head Taper Screw, No.1 |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 90430-37140 |
Gasket(For Oil Filler Cap) |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 90520-10004 |
Ring, Shaft Snap (For Valve Guide Bush) |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 93270-26025 |
SCREW |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
| 96411-41800 |
Plug, Tight, No.1 |
Cylinder Head ([10.1987 - ] (8710- )3SGTE) |
