SN413Q

Suzuki JIMNY · 3,595 parts · 183 categories
SN413Q ×

← Back to categories

3,595 items
Emission control (SN413Q, SN413V) 45
#OEMPart name
1 18111-69G00-000 バルブ,EGR
1 18111-69G01-000 VALVE,EGR
2 18529-69G00-000 GASKET,EGR VALVE
3 01550-08553-000 Bolt
3 01550-0855B-000 Bolt
3 01550-0855A-000 Bolt - Bolt, gear holder
4 18117-52G00-000 VALVE ASSY,DUTY FOR PURGE - Valve assy, evap purge
5 18417-54D00-000 BRACKET,PURGE VALVE
6 01550-06123-000 Bolt
6 01550-0612B-000 Bolt - Bolt, clamp
6 01550-0612A-000 Bolt
7 08316-20063-000 Nut
7 08316-2006A-000 NUT
8 18530-54D00-000 PIPE,EGR
9 18533-85C10-000 Gasket
10 01550-06163-000 Bolt
10 01550-0616B-000 Bolt
10 01550-0616A-000 Bolt
11 18565-54D00-000 ホース,パージ(バルブツーマニホールド)
11 09401-11419-000 CLIP
11 18565-54D01-000 HOSE,PURGE VSV TO INMF
12 09355-35753-110 Hose, vac - P-reg to dlvry
12 09355-35754-601 HOSE(3.5X7.5X601) - Hose, vacuum (inmf to check valve)
12 09355-35006-601 Hose(3.5X7.5X601)
13 09355-35753-130 Hose, vac - Dlvry to manf
14 09401-11407-000 CLIP
14 09401-11415-000 CLIP
15 18560-81AA0-000 CANISTER
16 18570-80A01-000 BRACKET,CANISTER
17 01550-08123-000 Bolt - Plug, oil gallery
17 01550-0812B-000 Bolt - Plug, drain
17 01550-0812A-000 Bolt
18 18561-80A00-000 ホース,パージ(キャニスタツーバルブ)
18 18561-80A01-000 HOSE,PURGE CSTR TO VSV
19 18571-65D00-000 CAP,CANISTER
20 09355-54128-170 Hose, evapo - Pipe to pipe
21 18572-80A00-000 HOSE,EVAP PIPE TO CSTR
24 18575-80A00-000 パイプ,エバポ
24 18575-80A01-000 PIPE,EVAP
26 09408-00043-000 CLAMP - Holder, fuse case
27 09408-00050-000 CLAMP
28 18590-72F21-000 SENSOR,PRESSURE
28 18590-68H00-000 SENSOR,PRESSURE - Sensor, pressure
29 07130-05163-000 Bolt - Screw
29 07130-0516A-000 Bolt
