Search › Model › SCP12

SCP12

Toyota YARIS-ECHO-VIOS-LIMO · 2002 · 3,034 parts · 169 categories

3,034 items

Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D) 24

#	OEM	Part name
82151	82151-0D010	Wire, Front Door, Rh
82151	82151-0D020	Wire, Front Door, Rh
82151	82151-0D030	Wire, Front Door, Rh
82151	82151-0D040	Wire, Front Door, Rh
82151	82151-0D050	Wire, Front Door, Rh
82151	82151-0D060	Wire, Front Door, Rh
82151	82151-0D070	Wire, Front Door, Rh
82151	82151-0D080	Wire, Front Door, Rh
82151	82151-0D090	Wire, Front Door, Rh
82151	82151-0D100	Wire, Front Door, Rh
82152	82152-0D010	Wire, Front Door, Lh
82152	82152-0D020	Wire, Front Door, Lh
82152	82152-0D030	Wire, Front Door, Lh
82152	82152-0D040	Wire, Front Door, Lh
82152	82152-0D050	Wire, Front Door, Lh
82152	82152-0D060	Wire, Front Door, Lh
82152	82152-0D070	Wire, Front Door, Lh
82152	82152-0D080	Wire, Front Door, Lh
82152	82152-0D100	Wire, Front Door, Lh
82184	82184-0D020	Wire, Back Door, No.1
82184	82184-0D030	Wire, Back Door, No.1
82185	82185-0D040	Wire, Back Door, No.2
82185	82185-0D060	Wire, Back Door, No.2
82186	82186-0D010	Wire, Rear Window, No.1

OEM	Part name	Category
82151-0D010	Wire, Front Door, Rh	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)
82151-0D020	Wire, Front Door, Rh	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)
82151-0D030	Wire, Front Door, Rh	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)
82151-0D040	Wire, Front Door, Rh	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)
82151-0D050	Wire, Front Door, Rh	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)
82151-0D060	Wire, Front Door, Rh	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)
82151-0D070	Wire, Front Door, Rh	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)
82151-0D080	Wire, Front Door, Rh	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)
82151-0D090	Wire, Front Door, Rh	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)
82151-0D100	Wire, Front Door, Rh	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)
82152-0D010	Wire, Front Door, Lh	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)
82152-0D020	Wire, Front Door, Lh	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)
82152-0D030	Wire, Front Door, Lh	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)
82152-0D040	Wire, Front Door, Lh	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)
82152-0D050	Wire, Front Door, Lh	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)
82152-0D060	Wire, Front Door, Lh	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)
82152-0D070	Wire, Front Door, Lh	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)
82152-0D080	Wire, Front Door, Lh	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)
82152-0D100	Wire, Front Door, Lh	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)
82184-0D020	Wire, Back Door, No.1	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)
82184-0D030	Wire, Back Door, No.1	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)
82185-0D040	Wire, Back Door, No.2	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)
82185-0D060	Wire, Back Door, No.2	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)
82186-0D010	Wire, Rear Window, No.1	Wiring & Clamp ([01.2001 - ] DOOR (0101- )FRP..3D)

Source: Public OEM parts-catalog data
Variants: 2 / 32
Category: 169
Collected: 2026-08-04
