Search › Model › RW420D
RW420D
Oil pump (RW420D) 26
| # | OEM | Part name |
|---|---|---|
| 1 | 16100-79J80-000 | Pump assy, oil |
| 2 | 16119-79J50-000 | Gasket, oil pump |
| 3 | 16124-79J80-000 | Seal, oil |
| 4 | 16124-79J50-000 | Seal oil - 30x41x7 |
| 5 | 16520-79J80-000 | Strainer, oil pump |
| 6 | 16529-79J80-000 | Gasket, strainer |
| 7 | 11165-79J80-000 | Bolt |
| 8 | 11165-79J50-001 | Bolt - 6x22 |
| 9 | 11165-79J50-002 | Bolt - 6x35 |
| 10 | 16600-79J80-000 | Cooler assy, oil |
| 11 | 16582-79J50-000 | Switch, oil pressure |
| 12 | 16510-79J60-000 | Filter assy, oil - Ufi |
| 13 | 16539-79J80-000 | Gasket, Oil Filter |
| 14 | 16533-79J80-000 | Cover, oil filter |
| 16 | 15423-79J50-000 | Bolt |
| 17 | 16925-79J80-000 | Adapter, oil filler cap |
| 18 | 16920-79J80-000 | Cap, oil filler |
| 19 | 16922-79J80-000 | Gasket, oil filler |
| 20 | 16927-79J80-000 | Bolt - 6x50 |
| 21 | 16926-79J80-000 | Gasket, oil filler cap adapter |
| 22 | 11180-79J80-000 | Separator assy, oil |
| 23 | 11186-79J80-000 | Bolt |
| 24 | 11187-79J80-000 | Bolt |
| 25 | 11188-79J80-000 | Pipe, breather |
| 26 | 11184-79J80-000 | Clip |
| 27 | 18424-79J50-000 | Bolt - 6x14 |
| OEM | Part name | Category |
|---|---|---|
| 11165-79J50-001 | Bolt - 6x22 | Oil pump (RW420D) |
| 11165-79J50-002 | Bolt - 6x35 | Oil pump (RW420D) |
| 11165-79J80-000 | Bolt | Oil pump (RW420D) |
| 11180-79J80-000 | Separator assy, oil | Oil pump (RW420D) |
| 11184-79J80-000 | Clip | Oil pump (RW420D) |
| 11186-79J80-000 | Bolt | Oil pump (RW420D) |
| 11187-79J80-000 | Bolt | Oil pump (RW420D) |
| 11188-79J80-000 | Pipe, breather | Oil pump (RW420D) |
| 15423-79J50-000 | Bolt | Oil pump (RW420D) |
| 16100-79J80-000 | Pump assy, oil | Oil pump (RW420D) |
| 16119-79J50-000 | Gasket, oil pump | Oil pump (RW420D) |
| 16124-79J50-000 | Seal oil - 30x41x7 | Oil pump (RW420D) |
| 16124-79J80-000 | Seal, oil | Oil pump (RW420D) |
| 16510-79J60-000 | Filter assy, oil - Ufi | Oil pump (RW420D) |
| 16520-79J80-000 | Strainer, oil pump | Oil pump (RW420D) |
| 16529-79J80-000 | Gasket, strainer | Oil pump (RW420D) |
| 16533-79J80-000 | Cover, oil filter | Oil pump (RW420D) |
| 16539-79J80-000 | Gasket, Oil Filter | Oil pump (RW420D) |
| 16582-79J50-000 | Switch, oil pressure | Oil pump (RW420D) |
| 16600-79J80-000 | Cooler assy, oil | Oil pump (RW420D) |
| 16920-79J80-000 | Cap, oil filler | Oil pump (RW420D) |
| 16922-79J80-000 | Gasket, oil filler | Oil pump (RW420D) |
| 16925-79J80-000 | Adapter, oil filler cap | Oil pump (RW420D) |
| 16926-79J80-000 | Gasket, oil filler cap adapter | Oil pump (RW420D) |
| 16927-79J80-000 | Bolt - 6x50 | Oil pump (RW420D) |
| 18424-79J50-000 | Bolt - 6x14 | Oil pump (RW420D) |
