RW420D
Oil pump (RW419D) 22
| # | OEM | Part name |
|---|---|---|
| 1 | 16100-79J52-000 | Pump assy, oil |
| 2 | 16119-79J50-000 | Gasket, oil pump |
| 2 | 16119-79J60-000 | Gasket, oil pump |
| 3 | 16124-79J50-000 | Seal oil - 30x41x7 |
| 3 | 16124-79J61-000 | Seal oil |
| 4 | 16520-79J51-000 | Strainer assy, oil pump |
| 4 | 16520-79J60-000 | Strainer assy, oil pump |
| 5 | 16529-79J50-000 | O ring |
| 5 | 16529-79J60-000 | O ring |
| 6 | 11165-79J50-003 | Bolt - 6x18 |
| 6 | 11165-79J60-000 | Bolt |
| 7 | 11165-79J50-001 | Bolt - 6x22 |
| 8 | 11165-79J50-002 | Bolt - 6x35 |
| 10 | 16600-79J51-000 | Cooler assy, oil - Mann |
| 10 | 16600-79J60-000 | Cooler assy, oil - Ufi |
| 11 | 16510-79J50-000 | Filter assy, oil - Mann |
| 11 | 16510-79J60-000 | Filter assy, oil - Ufi |
| 12 | 16539-79J50-000 | Gasket set |
| 13 | 16533-79J50-000 | Cover assy, oil filter - Mann |
| 13 | 16533-79J60-000 | Cover assy, oil filter - Ufi |
| 14 | 16582-79J50-000 | Switch, oil pressure |
| 15 | 15422-79J50-000 | Bolt - 10x55 |
| OEM | Part name | Category |
|---|---|---|
| 11165-79J50-001 | Bolt - 6x22 | Oil pump (RW419D) |
| 11165-79J50-002 | Bolt - 6x35 | Oil pump (RW419D) |
| 11165-79J50-003 | Bolt - 6x18 | Oil pump (RW419D) |
| 11165-79J60-000 | Bolt | Oil pump (RW419D) |
| 15422-79J50-000 | Bolt - 10x55 | Oil pump (RW419D) |
| 16100-79J52-000 | Pump assy, oil | Oil pump (RW419D) |
| 16119-79J50-000 | Gasket, oil pump | Oil pump (RW419D) |
| 16119-79J60-000 | Gasket, oil pump | Oil pump (RW419D) |
| 16124-79J50-000 | Seal oil - 30x41x7 | Oil pump (RW419D) |
| 16124-79J61-000 | Seal oil | Oil pump (RW419D) |
| 16510-79J50-000 | Filter assy, oil - Mann | Oil pump (RW419D) |
| 16510-79J60-000 | Filter assy, oil - Ufi | Oil pump (RW419D) |
| 16520-79J51-000 | Strainer assy, oil pump | Oil pump (RW419D) |
| 16520-79J60-000 | Strainer assy, oil pump | Oil pump (RW419D) |
| 16529-79J50-000 | O ring | Oil pump (RW419D) |
| 16529-79J60-000 | O ring | Oil pump (RW419D) |
| 16533-79J50-000 | Cover assy, oil filter - Mann | Oil pump (RW419D) |
| 16533-79J60-000 | Cover assy, oil filter - Ufi | Oil pump (RW419D) |
| 16539-79J50-000 | Gasket set | Oil pump (RW419D) |
| 16582-79J50-000 | Switch, oil pressure | Oil pump (RW419D) |
| 16600-79J51-000 | Cooler assy, oil - Mann | Oil pump (RW419D) |
| 16600-79J60-000 | Cooler assy, oil - Ufi | Oil pump (RW419D) |
