RW420D
Muffler (RW420D) 19
| # | OEM | Part name |
|---|---|---|
| 1 | 14181-79J80-000 | Gasket |
| 2 | 14184-65J00-000 | GASKET,EXH PIPE |
| 3 | 14190-79J80-000 | Pipe, exh no.1 |
| 4 | 14271-79J80-000 | Brace, exh pipe |
| 5 | 14281-80JA0-000 | MOUNTING,MUF |
| 6 | 09159-08083-000 | NUT |
| 7 | 01550-1020A-000 | Bolt - Bolt, bal sprocket |
| 8 | 01550-1025A-000 | Bolt - Bolt, drive gear |
| 9 | 14184-67D00-000 | GASKET,MUFFLER |
| 10 | 14230-79J50-000 | Pipe, exh center |
| 13 | 14281-80J00-000 | MOUNTING,MUF |
| 14 | 14283-79J50-000 | Bracket, exh pipe mtg no.1 |
| 15 | 14300-79J50-000 | Muffler |
| 16 | 09159-10049-000 | Nut |
| 16 | 09159-10102-000 | NUT |
| 17 | 09180-08057-000 | Spacer |
| 17 | 09180-08227-000 | SPACER(8.2X12.5X23.5) |
| 18 | 01550-0840A-000 | Bolt |
| 19 | 02162-0612A-000 | SCREW - Bolt, bracket |
| OEM | Part name | Category |
|---|---|---|
| 01550-0840A-000 | Bolt | Muffler (RW420D) |
| 01550-1020A-000 | Bolt - Bolt, bal sprocket | Muffler (RW420D) |
| 01550-1025A-000 | Bolt - Bolt, drive gear | Muffler (RW420D) |
| 02162-0612A-000 | SCREW - Bolt, bracket | Muffler (RW420D) |
| 09159-08083-000 | NUT | Muffler (RW420D) |
| 09159-10049-000 | Nut | Muffler (RW420D) |
| 09159-10102-000 | NUT | Muffler (RW420D) |
| 09180-08057-000 | Spacer | Muffler (RW420D) |
| 09180-08227-000 | SPACER(8.2X12.5X23.5) | Muffler (RW420D) |
| 14181-79J80-000 | Gasket | Muffler (RW420D) |
| 14184-65J00-000 | GASKET,EXH PIPE | Muffler (RW420D) |
| 14184-67D00-000 | GASKET,MUFFLER | Muffler (RW420D) |
| 14190-79J80-000 | Pipe, exh no.1 | Muffler (RW420D) |
| 14230-79J50-000 | Pipe, exh center | Muffler (RW420D) |
| 14271-79J80-000 | Brace, exh pipe | Muffler (RW420D) |
| 14281-80J00-000 | MOUNTING,MUF | Muffler (RW420D) |
| 14281-80JA0-000 | MOUNTING,MUF | Muffler (RW420D) |
| 14283-79J50-000 | Bracket, exh pipe mtg no.1 | Muffler (RW420D) |
| 14300-79J50-000 | Muffler | Muffler (RW420D) |
