RW420D
Engine assy (RW420D) 6
| # | OEM | Part name |
|---|---|---|
| 1 | 11000-79J80-000 | Engine assy, stripped |
| 2 | 36670-55LU0-000 | Harness assy, engine |
| 3 | 11312-79J50-000 | Bolt - 6x16 |
| 4 | 33220-55L00-000 | Sensor, crank angle |
| 5 | 11186-79J80-000 | Bolt |
| 6 | 33220-55L10-000 | Sensor |
| OEM | Part name | Category |
|---|---|---|
| 11000-79J80-000 | Engine assy, stripped | Engine assy (RW420D) |
| 11186-79J80-000 | Bolt | Engine assy (RW420D) |
| 11312-79J50-000 | Bolt - 6x16 | Engine assy (RW420D) |
| 33220-55L00-000 | Sensor, crank angle | Engine assy (RW420D) |
| 33220-55L10-000 | Sensor | Engine assy (RW420D) |
| 36670-55LU0-000 | Harness assy, engine | Engine assy (RW420D) |
