RW419D
Radiator (RW419D) 20
| # | OEM | Part name |
|---|---|---|
| 1 | 17111-79J50-000 | Fan, cooling |
| 2 | 17120-79J50-000 | Motor assy, fan |
| 3 | 17760-79J50-000 | Shroud |
| 4 | 02142-0510A-000 | SCREW - Bolt, oil pump rotor plate |
| 4 | 02142-0510B-000 | SCREW - Bolt |
| 5 | 08316-2005A-000 | NUT |
| 6 | 17111-79J60-000 | Fan, cooling - Sub |
| 7 | 17120-79J60-000 | Motor, cooling fan - Sub |
| 8 | 17760-79J61-000 | Shroud |
| 10 | 17761-60B00-000 | CLIP(BLACK) |
| 11 | 02162-0616B-000 | SCREW - Bolt, adjust |
| 12 | 17700-79J50-000 | Radiator assy |
| 13 | 17751-61A00-000 | PLUG,DRAIN |
| 14 | 17759-72010-000 | O-RING |
| 15 | 17793-79J50-000 | Seal, radiator |
| 16 | 17812-54G00-000 | MOUNT,RDTR SUPPORT UPR |
| 17 | 17861-79J50-000 | Bracket, upper |
| 18 | 17861-79J60-000 | Bracket, upper |
| 19 | 17878-75F00-000 | MOUNT,RDTR SUPPORT LWR |
| 20 | 09103-08382-000 | BOLT(8X12) |
| OEM | Part name | Category |
|---|---|---|
| 02142-0510A-000 | SCREW - Bolt, oil pump rotor plate | Radiator (RW419D) |
| 02142-0510B-000 | SCREW - Bolt | Radiator (RW419D) |
| 02162-0616B-000 | SCREW - Bolt, adjust | Radiator (RW419D) |
| 08316-2005A-000 | NUT | Radiator (RW419D) |
| 09103-08382-000 | BOLT(8X12) | Radiator (RW419D) |
| 17111-79J50-000 | Fan, cooling | Radiator (RW419D) |
| 17111-79J60-000 | Fan, cooling - Sub | Radiator (RW419D) |
| 17120-79J50-000 | Motor assy, fan | Radiator (RW419D) |
| 17120-79J60-000 | Motor, cooling fan - Sub | Radiator (RW419D) |
| 17700-79J50-000 | Radiator assy | Radiator (RW419D) |
| 17751-61A00-000 | PLUG,DRAIN | Radiator (RW419D) |
| 17759-72010-000 | O-RING | Radiator (RW419D) |
| 17760-79J50-000 | Shroud | Radiator (RW419D) |
| 17760-79J61-000 | Shroud | Radiator (RW419D) |
| 17761-60B00-000 | CLIP(BLACK) | Radiator (RW419D) |
| 17793-79J50-000 | Seal, radiator | Radiator (RW419D) |
| 17812-54G00-000 | MOUNT,RDTR SUPPORT UPR | Radiator (RW419D) |
| 17861-79J50-000 | Bracket, upper | Radiator (RW419D) |
| 17861-79J60-000 | Bracket, upper | Radiator (RW419D) |
| 17878-75F00-000 | MOUNT,RDTR SUPPORT LWR | Radiator (RW419D) |
