RW419D
Injection pump (RW420D) 16
| # | OEM | Part name |
|---|---|---|
| 1 | 15200-79J80-000 | Pump assy, fuel injection |
| 2 | 15251-79J80-000 | Collector, fuel |
| 3 | 15254-79J80-000 | Hose, fuel |
| 4 | 15250-79J80-000 | Tube |
| 5 | 15255-79J80-000 | Clamp |
| 6 | 15256-79J80-000 | Clamp |
| 7 | 15252-79J80-000 | Bolt - 6x35 |
| 8 | 12813-79J80-000 | Bracket, inj pump |
| 9 | 12826-79J51-000 | Bush |
| 10 | 12829-79J80-000 | Stud bolt |
| 11 | 12827-79J80-000 | Bracket |
| 12 | 12828-79J80-000 | Bolt - 6x16 |
| 13 | 12821-79J50-002 | Bolt |
| 14 | 12821-79J80-000 | Bolt |
| 15 | 12824-79J50-000 | Washer |
| 16 | 14143-79J51-000 | Nut |
| OEM | Part name | Category |
|---|---|---|
| 12813-79J80-000 | Bracket, inj pump | Injection pump (RW420D) |
| 12821-79J50-002 | Bolt | Injection pump (RW420D) |
| 12821-79J80-000 | Bolt | Injection pump (RW420D) |
| 12824-79J50-000 | Washer | Injection pump (RW420D) |
| 12826-79J51-000 | Bush | Injection pump (RW420D) |
| 12827-79J80-000 | Bracket | Injection pump (RW420D) |
| 12828-79J80-000 | Bolt - 6x16 | Injection pump (RW420D) |
| 12829-79J80-000 | Stud bolt | Injection pump (RW420D) |
| 14143-79J51-000 | Nut | Injection pump (RW420D) |
| 15200-79J80-000 | Pump assy, fuel injection | Injection pump (RW420D) |
| 15250-79J80-000 | Tube | Injection pump (RW420D) |
| 15251-79J80-000 | Collector, fuel | Injection pump (RW420D) |
| 15252-79J80-000 | Bolt - 6x35 | Injection pump (RW420D) |
| 15254-79J80-000 | Hose, fuel | Injection pump (RW420D) |
| 15255-79J80-000 | Clamp | Injection pump (RW420D) |
| 15256-79J80-000 | Clamp | Injection pump (RW420D) |
