Search › Model › RW419D
RW419D
Cam shaft/valve (RW420D) 18
| # | OEM | Part name |
|---|---|---|
| 1 | 12711-79J80-000 | Camshaft, intk |
| 2 | 12721-79J80-000 | Camshaft, exh |
| 3 | 12741-79J80-000 | Gear, intk camshaft |
| 4 | 12742-79J80-000 | Gear, exh camshaft |
| 5 | 12743-79J50-000 | Bolt |
| 6 | 12746-79J80-000 | Seal, camshaft oil |
| 7 | 12840-79J80-000 | Arm, rocker |
| 8 | 12845-79J80-000 | Spring, rocker arm |
| 9 | 12850-79J80-000 | Adjuster, hydr valve lash |
| 10 | 12911-79J80-000 | Valve, Intake |
| 11 | 12915-79J80-000 | Valve, Exhaust |
| 12 | 12919-79J80-000 | Seal valve stem |
| 13 | 11115-79J80-005 | Guide, valve - +0.05 |
| 13 | 11115-79J80-010 | Guide, valve - +0.10 |
| 13 | 11115-79J80-025 | Guide, valve - +0.25 |
| 14 | 12921-79J80-000 | Spring, valve |
| 15 | 12931-79J80-000 | Retainer, valve spring |
| 16 | 12932-79J80-000 | Cotter, valve |
| OEM | Part name | Category |
|---|---|---|
| 11115-79J80-005 | Guide, valve - +0.05 | Cam shaft/valve (RW420D) |
| 11115-79J80-010 | Guide, valve - +0.10 | Cam shaft/valve (RW420D) |
| 11115-79J80-025 | Guide, valve - +0.25 | Cam shaft/valve (RW420D) |
| 12711-79J80-000 | Camshaft, intk | Cam shaft/valve (RW420D) |
| 12721-79J80-000 | Camshaft, exh | Cam shaft/valve (RW420D) |
| 12741-79J80-000 | Gear, intk camshaft | Cam shaft/valve (RW420D) |
| 12742-79J80-000 | Gear, exh camshaft | Cam shaft/valve (RW420D) |
| 12743-79J50-000 | Bolt | Cam shaft/valve (RW420D) |
| 12746-79J80-000 | Seal, camshaft oil | Cam shaft/valve (RW420D) |
| 12840-79J80-000 | Arm, rocker | Cam shaft/valve (RW420D) |
| 12845-79J80-000 | Spring, rocker arm | Cam shaft/valve (RW420D) |
| 12850-79J80-000 | Adjuster, hydr valve lash | Cam shaft/valve (RW420D) |
| 12911-79J80-000 | Valve, Intake | Cam shaft/valve (RW420D) |
| 12915-79J80-000 | Valve, Exhaust | Cam shaft/valve (RW420D) |
| 12919-79J80-000 | Seal valve stem | Cam shaft/valve (RW420D) |
| 12921-79J80-000 | Spring, valve | Cam shaft/valve (RW420D) |
| 12931-79J80-000 | Retainer, valve spring | Cam shaft/valve (RW420D) |
| 12932-79J80-000 | Cotter, valve | Cam shaft/valve (RW420D) |
