Search › Model › RT135

RT135

Toyota CORONA · 1980 · 4,288 parts · 171 categories

4,288 items

Center Support & Planetary Sun Gear (Atm) ([08.1980 - ] (8008- )4FC) 21

#	OEM	Part name
35620	35634-22060	Plate, Clutch (For Overdrive)
35620	35648-30010	Plate, Clutch (For Brake)
35620	35677-22020	Disc, Clutch (For Overdrive)
35620	35677-30160	Disc, Clutch (For Overdrive)
35620	34625-22010	Flange, Overdrive Brake, No.1
35620	35676-22030	Flange, Overdrive Brake
35620	90521-99139	Ring, Hole Snap (For Overdrive Brake Return Spring Seat)
35621	35621-30010	Piston, Brake, No.1
35621	90301-99007	Ring, O (For Brake Piston Outer)
35621	90301-99107	Ring (For Rear Brake Piston Outer)
35621	90301-57188	Ring, O (For Underdrive Clutch Piston)
35621	90301-56007	Ring, O (For Underdrive Clutch Piston)
35621	90501-10671	Spring, Compression (For Overdrive Direct Clutch)
35627	35627-22010	Seat, Brake Return Spring
35627	90520-52262	Ring, Shaft Snap (For Underdrive Return Spring)
35709	35709-22040	Support Sub-Assy, Center
35709	35709-22041	Support Sub-Assy, Center
35709	35617-16010	Ring, Oil Seal (For Overdrive Case)
35709	35617-22020	Ring, Oil Seal (For Overdrive Case)
9010908073	90109-08073	Bolt (For Front Oil Pump Setting)
9454200800	94542-00800	New Genuine Part

OEM	Part name	Category
34625-22010	Flange, Overdrive Brake, No.1	Center Support & Planetary Sun Gear (Atm) ([08.1980 - ] (8008- )4FC)
35617-16010	Ring, Oil Seal (For Overdrive Case)	Center Support & Planetary Sun Gear (Atm) ([08.1980 - ] (8008- )4FC)
35617-22020	Ring, Oil Seal (For Overdrive Case)	Center Support & Planetary Sun Gear (Atm) ([08.1980 - ] (8008- )4FC)
35621-30010	Piston, Brake, No.1	Center Support & Planetary Sun Gear (Atm) ([08.1980 - ] (8008- )4FC)
35627-22010	Seat, Brake Return Spring	Center Support & Planetary Sun Gear (Atm) ([08.1980 - ] (8008- )4FC)
35634-22060	Plate, Clutch (For Overdrive)	Center Support & Planetary Sun Gear (Atm) ([08.1980 - ] (8008- )4FC)
35648-30010	Plate, Clutch (For Brake)	Center Support & Planetary Sun Gear (Atm) ([08.1980 - ] (8008- )4FC)
35676-22030	Flange, Overdrive Brake	Center Support & Planetary Sun Gear (Atm) ([08.1980 - ] (8008- )4FC)
35677-22020	Disc, Clutch (For Overdrive)	Center Support & Planetary Sun Gear (Atm) ([08.1980 - ] (8008- )4FC)
35677-30160	Disc, Clutch (For Overdrive)	Center Support & Planetary Sun Gear (Atm) ([08.1980 - ] (8008- )4FC)
35709-22040	Support Sub-Assy, Center	Center Support & Planetary Sun Gear (Atm) ([08.1980 - ] (8008- )4FC)
35709-22041	Support Sub-Assy, Center	Center Support & Planetary Sun Gear (Atm) ([08.1980 - ] (8008- )4FC)
90109-08073	Bolt (For Front Oil Pump Setting)	Center Support & Planetary Sun Gear (Atm) ([08.1980 - ] (8008- )4FC)
90301-56007	Ring, O (For Underdrive Clutch Piston)	Center Support & Planetary Sun Gear (Atm) ([08.1980 - ] (8008- )4FC)
90301-57188	Ring, O (For Underdrive Clutch Piston)	Center Support & Planetary Sun Gear (Atm) ([08.1980 - ] (8008- )4FC)
90301-99007	Ring, O (For Brake Piston Outer)	Center Support & Planetary Sun Gear (Atm) ([08.1980 - ] (8008- )4FC)
90301-99107	Ring (For Rear Brake Piston Outer)	Center Support & Planetary Sun Gear (Atm) ([08.1980 - ] (8008- )4FC)
90501-10671	Spring, Compression (For Overdrive Direct Clutch)	Center Support & Planetary Sun Gear (Atm) ([08.1980 - ] (8008- )4FC)
90520-52262	Ring, Shaft Snap (For Underdrive Return Spring)	Center Support & Planetary Sun Gear (Atm) ([08.1980 - ] (8008- )4FC)
90521-99139	Ring, Hole Snap (For Overdrive Brake Return Spring Seat)	Center Support & Planetary Sun Gear (Atm) ([08.1980 - ] (8008- )4FC)
94542-00800	New Genuine Part	Center Support & Planetary Sun Gear (Atm) ([08.1980 - ] (8008- )4FC)
