Search › Model › RF410
RF410
Throttle body (RF308::W/HEATER) 12
| # | OEM | Part name |
|---|---|---|
| 1 | 13400-M79F4-000 | Body assy, throttle |
| 2 | 13420-M77G0-100 | Sensor, throttle position |
| 3 | 13428-M77G1-V00 | Screw |
| 4 | 18590-M79G0-000 | Sensor, map |
| 6 | 18117-M79F1-100 | Valve, isc |
| 7 | 14139-M70G3-000 | Gasket |
| 9 | 13421-M79F0-000 | Gasket |
| 10 | 01550-0650A-000 | Bolt - Bolt (6x50) |
| 11 | 15910-M79F0-000 | Cable assy, accel |
| 12 | 15918-M79F0-000 | Bracket |
| 13 | 08316-1006A-000 | NUT |
| 14 | 09403-M0531-100 | Clamp |
| OEM | Part name | Category |
|---|---|---|
| 01550-0650A-000 | Bolt - Bolt (6x50) | Throttle body (RF308::W/HEATER) |
| 08316-1006A-000 | NUT | Throttle body (RF308::W/HEATER) |
| 09403-M0531-100 | Clamp | Throttle body (RF308::W/HEATER) |
| 13400-M79F4-000 | Body assy, throttle | Throttle body (RF308::W/HEATER) |
| 13420-M77G0-100 | Sensor, throttle position | Throttle body (RF308::W/HEATER) |
| 13421-M79F0-000 | Gasket | Throttle body (RF308::W/HEATER) |
| 13428-M77G1-V00 | Screw | Throttle body (RF308::W/HEATER) |
| 14139-M70G3-000 | Gasket | Throttle body (RF308::W/HEATER) |
| 15910-M79F0-000 | Cable assy, accel | Throttle body (RF308::W/HEATER) |
| 15918-M79F0-000 | Bracket | Throttle body (RF308::W/HEATER) |
| 18117-M79F1-100 | Valve, isc | Throttle body (RF308::W/HEATER) |
| 18590-M79G0-000 | Sensor, map | Throttle body (RF308::W/HEATER) |
