RF410
Cylinder head (RF308) 21
| # | OEM | Part name |
|---|---|---|
| 1 | 11100-M79G0-100 | Head assy, cylinder |
| 2 | 11115-M77G1-000 | Guide, valve |
| 3 | 11112-M8440-000 | Plug, venturi |
| 4 | 09206-M0800-100 | Pin - 6.2x8x11 |
| 5 | 09241-M2000-600 | Plug - Od:20 |
| 6 | 09246-M0500-600 | Plug, oil gallery - 1/8 |
| 7 | 09248-M1800-700 | Plug |
| 8 | 11216-M77E4-000 | Gasket |
| 9 | 11128-69G01-000 | BOLT,CAMSHAFT HOUSING 6X39 |
| 10 | 11117-M52E2-000 | Bolt, cylinder head |
| 11 | 11141-M8441-000 | Gasket, cylinder head |
| 12 | 04211-M1318-900 | Pin |
| 13 | 11170-M79G1-000 | Cover, cylinder head |
| 14 | 11189-M79G3-000 | Gasket |
| 15 | 01550-M0625-A00 | Bolt, discharge hose |
| 16 | 11179-M79F0-100 | O ring |
| 17 | 09482-M0056-700 | Plug, spark - Champion,ra7yc |
| 18 | 16920-M8650-200 | Cap, oil filler |
| 19 | 11145-M79G0-000 | Plate, cylinder head |
| 20 | 11146-M79G1-000 | Gasket |
| 21 | 01550-M0616-A00 | Bolt, expansion cover |
| OEM | Part name | Category |
|---|---|---|
| 01550-M0616-A00 | Bolt, expansion cover | Cylinder head (RF308) |
| 01550-M0625-A00 | Bolt, discharge hose | Cylinder head (RF308) |
| 04211-M1318-900 | Pin | Cylinder head (RF308) |
| 09206-M0800-100 | Pin - 6.2x8x11 | Cylinder head (RF308) |
| 09241-M2000-600 | Plug - Od:20 | Cylinder head (RF308) |
| 09246-M0500-600 | Plug, oil gallery - 1/8 | Cylinder head (RF308) |
| 09248-M1800-700 | Plug | Cylinder head (RF308) |
| 09482-M0056-700 | Plug, spark - Champion,ra7yc | Cylinder head (RF308) |
| 11100-M79G0-100 | Head assy, cylinder | Cylinder head (RF308) |
| 11112-M8440-000 | Plug, venturi | Cylinder head (RF308) |
| 11115-M77G1-000 | Guide, valve | Cylinder head (RF308) |
| 11117-M52E2-000 | Bolt, cylinder head | Cylinder head (RF308) |
| 11128-69G01-000 | BOLT,CAMSHAFT HOUSING 6X39 | Cylinder head (RF308) |
| 11141-M8441-000 | Gasket, cylinder head | Cylinder head (RF308) |
| 11145-M79G0-000 | Plate, cylinder head | Cylinder head (RF308) |
| 11146-M79G1-000 | Gasket | Cylinder head (RF308) |
| 11170-M79G1-000 | Cover, cylinder head | Cylinder head (RF308) |
| 11179-M79F0-100 | O ring | Cylinder head (RF308) |
| 11189-M79G3-000 | Gasket | Cylinder head (RF308) |
| 11216-M77E4-000 | Gasket | Cylinder head (RF308) |
| 16920-M8650-200 | Cap, oil filler | Cylinder head (RF308) |
