RF308
Air cleaner (RF308) 17
| # | OEM | Part name |
|---|---|---|
| 1 | 13700-M79F1-000 | Cleaner assy, air |
| 2 | 13780-M75F0-000 | Element |
| 3 | 13772-M75F0-000 | Spacer |
| 4 | 13723-M75F0-000 | Cushion |
| 6 | 09136-06141-000 | SCREW(6X25) |
| 7 | 13810-M79F0-000 | Bracket, no.1 |
| 8 | 13820-M79G0-000 | Bracket, no.2 |
| 9 | 01550-0612A-000 | Bolt |
| 10 | 13870-M79F0-000 | Pipe, cleaner inlet |
| 11 | 13871-M77G0-000 | Hose, inlet |
| 12 | 18495-M50E0-000 | Bolt |
| 13 | 13881-M79F0-000 | Hose, outlet |
| 14 | 13875-M75F0-000 | Clamp |
| 15 | 09402-M5220-800 | Clamp |
| 16 | 11191-M79F1-000 | Hose, breather |
| 17 | 09401-M1840-200 | Clip |
| 18 | 13650-52G00-000 | SENSOR,INLET AIR TEMP - Sensor, inlet air temp |
| OEM | Part name | Category |
|---|---|---|
| 01550-0612A-000 | Bolt | Air cleaner (RF308) |
| 09136-06141-000 | SCREW(6X25) | Air cleaner (RF308) |
| 09401-M1840-200 | Clip | Air cleaner (RF308) |
| 09402-M5220-800 | Clamp | Air cleaner (RF308) |
| 11191-M79F1-000 | Hose, breather | Air cleaner (RF308) |
| 13650-52G00-000 | SENSOR,INLET AIR TEMP - Sensor, inlet air temp | Air cleaner (RF308) |
| 13700-M79F1-000 | Cleaner assy, air | Air cleaner (RF308) |
| 13723-M75F0-000 | Cushion | Air cleaner (RF308) |
| 13772-M75F0-000 | Spacer | Air cleaner (RF308) |
| 13780-M75F0-000 | Element | Air cleaner (RF308) |
| 13810-M79F0-000 | Bracket, no.1 | Air cleaner (RF308) |
| 13820-M79G0-000 | Bracket, no.2 | Air cleaner (RF308) |
| 13870-M79F0-000 | Pipe, cleaner inlet | Air cleaner (RF308) |
| 13871-M77G0-000 | Hose, inlet | Air cleaner (RF308) |
| 13875-M75F0-000 | Clamp | Air cleaner (RF308) |
| 13881-M79F0-000 | Hose, outlet | Air cleaner (RF308) |
| 18495-M50E0-000 | Bolt | Air cleaner (RF308) |
