| 16011-24B00 |
Chamber Assy-Choke |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16023-S5800 |
Stopper |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16033-03B00 |
Jet-Main |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16033-23M20 |
Jet-Main |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16036-11M03 |
Bleed-Main Air |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16036-52A00 |
Bleed-Main Air |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16037-01B22 |
Jet-Mixture |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16055-01B10 |
Jet-Slow |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16055-H8310 |
Jet-Step |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16063-52A02 |
Cover-Gauge Lever |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16066-H7200 |
Shaft-Float |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16069-11M00 |
Spring-Injector |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16098-01B00 |
Filter |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16101-33M12 |
Valve-Needle |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16125-61A04 |
Gauge-Level |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16148-H1000 |
Spring-Return, Piston |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16151-H7260 |
Piston |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16171-11M00 |
Weight-Injector |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16176-24B00 |
Iacv-Ficd Solenoid Valve |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16184-H8900 |
Holder Assy-Adjust Screw |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16196-24B01 |
Iacv-Ficd Solenoid Valve |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16196-24B11 |
Iacv-Ficd Solenoid Valve |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16197-24B00 |
Mixture Control Solenoid Valve |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16198-11M04 |
Pin-Cotter |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16204-01B10 |
Bleed-Slow Air |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16204-H9501 |
Bleed-Slow Air |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16260-31M10 |
Throttle Position Switch |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16260-77A00 |
Throttle Position Switch |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16267-11M08 |
Pipe-Rubber, Carburetor |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16267-25M03 |
Pipe-Rubber, Carburetor |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16273-08B06 |
Plate-Adjust |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16286-H7200 |
Plug |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16307-77A00 |
Cover-Pump |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16313-13B11 |
Diaphragm Assy-Chamber |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16389-01B11 |
Cover-Thermo |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16390-11M07 |
Plate-Stopping |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16390-12M07 |
Plate-Stopping, Rear |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16390-H9061 |
Plate-Thermo Cover |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16391-11M07 |
Wax Kit |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16392-S5800 |
Collar |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16393-S5800 |
Wax |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16394-H9060 |
Ptc |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16396-11M07 |
Cord |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 16399-S5800 |
Nut |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
| 17160-C0610 |
Packing |
Carburetor (1989-01-01 ~ ; 構成部品(1); ALL) |
