Search › Model › NRE161

NRE161

Toyota COROLLA-AXIO-FIELDER · 2015 · 2,382 parts · 182 categories

2,382 items

Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE) 51

#	OEM	Part name
16031	16031-47040	Water Inlet Sub-Assy, W/thermostat
16031	16031-47041	Water Inlet Sub-Assy, W/thermostat
16261	96136-41501	Clamp Or Clip, Hose(For Water By-Pass Hose)
16261	16261-47020	Hose, Water By-Pass, No.1
16261	96136-42901	Clip Or Clamp(For Ventilation Hose)
16261	16261-47100	Hose, Water By-Pass
16261	16261-47110	Hose, Water By-Pass, No.2
16262	16262-47020	Hose, Water Inlet
16264	16264-47050	Hose, Water By-Pass, No.2
16267	16267-47010	Hose, Water By-Pass, No.3
16267	96136-42501	Clip(For Ventilation Hose)
16268	16268-47080	Pipe, Water By-Pass, No.1
16268	16268-47040	Pipe, Water By-Pass, No.1
16278	16270-47020	Pipe, Water By-Pass, No.2
16281	16281-47030	Hose, Water By-Pass, No.4
16281	90466-21001	Clamp Or Clip, Hose(For Water By-Pass Hose)
16283	16283-47030	Hose, Water By-Pass, No.6
16326	16326-47010	Gasket, Water Inlet Housing, No.2
16326	16326-47020	Gasket, Water Inlet Housing, No.2
16361	16361-47040	Fan
16363	16363-47020	Motor, Cooling Fan
16374	16366-47070	Insulator, Cooling Fan Motor
16400	16400-47090	Radiator Assy
16400	16400-47141	RADIATOR ASSY
16400	16417-21280	Cock Sub-Assy, Radiator Drain
16400	16492-21050	Ring, O(For Oil Cooler Drain Cock)
16401	16401-31520	Radiator Cap Sub-Assy (108kPa)
16401	16401-36020	Cap Sub-Assy, Radiator
16431	16431-47090	Inlet, Radiator Water
16431	16492-6A300	Ring, O(For Radiator Water Inlet)
16470	16377-47070	Hose Or Pipe(For Radiator Reserve Tank)
16470	90467-11085	Clamp Or Clip(For Radiator Breather Hose)
16471	16471-23030	Cap Sub-Assy, Reserve Tank
16472	90445-12078	Hose(For Radiator Breather)
16523	16523-21030	Cushion, Radiator Support
16535	90480-22025	Cushion, Intercooler Support
16571	16571-47080	Hose, Radiator, No.1
16571	90467-33006	Clamp Or Clip, Hose(For Radiator Inlet)
16572	16572-47120	Hose, Radiator, No.2
16572	90467-34004	Clamp Or Clip, Hose(For Water By-Pass Hose)
16711	16711-47080	Shroud, Fan
1658147060	16581-47060	Clamp, Hose(for Water Hose)
4754720010	47547-20010	Plug, Bleeder(For Release Cylinder)
9009904119	90099-04119	BOLT WASHER HEAD
9009905164	90099-05164	Nut
9155180616	91551-80616	BOLT FLANGE
9155180625	91551-80625	Bolt(For Camshaft Housing Set)
9167180820	91671-80820	Bolt (For Transmission Control Cable Bracket)
9331514010	93315-14010	SCREW
9338516016	93385-16016	New Genuine Part
9613652201	96136-52201	Clip(For Ventilation Hose No.2)

OEM	Part name	Category
16031-47040	Water Inlet Sub-Assy, W/thermostat	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16031-47041	Water Inlet Sub-Assy, W/thermostat	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16261-47020	Hose, Water By-Pass, No.1	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16261-47100	Hose, Water By-Pass	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16261-47110	Hose, Water By-Pass, No.2	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16262-47020	Hose, Water Inlet	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16264-47050	Hose, Water By-Pass, No.2	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16267-47010	Hose, Water By-Pass, No.3	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16268-47040	Pipe, Water By-Pass, No.1	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16268-47080	Pipe, Water By-Pass, No.1	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16270-47020	Pipe, Water By-Pass, No.2	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16281-47030	Hose, Water By-Pass, No.4	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16283-47030	Hose, Water By-Pass, No.6	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16326-47010	Gasket, Water Inlet Housing, No.2	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16326-47020	Gasket, Water Inlet Housing, No.2	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16361-47040	Fan	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16363-47020	Motor, Cooling Fan	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16366-47070	Insulator, Cooling Fan Motor	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16377-47070	Hose Or Pipe(For Radiator Reserve Tank)	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16400-47090	Radiator Assy	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16400-47141	RADIATOR ASSY	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16401-31520	Radiator Cap Sub-Assy (108kPa)	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16401-36020	Cap Sub-Assy, Radiator	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16417-21280	Cock Sub-Assy, Radiator Drain	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16431-47090	Inlet, Radiator Water	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16471-23030	Cap Sub-Assy, Reserve Tank	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16492-21050	Ring, O(For Oil Cooler Drain Cock)	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16492-6A300	Ring, O(For Radiator Water Inlet)	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16523-21030	Cushion, Radiator Support	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16571-47080	Hose, Radiator, No.1	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16572-47120	Hose, Radiator, No.2	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16581-47060	Clamp, Hose(for Water Hose)	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
16711-47080	Shroud, Fan	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
47547-20010	Plug, Bleeder(For Release Cylinder)	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
90099-04119	BOLT WASHER HEAD	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
90099-05164	Nut	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
90445-12078	Hose(For Radiator Breather)	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
90466-21001	Clamp Or Clip, Hose(For Water By-Pass Hose)	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
90467-11085	Clamp Or Clip(For Radiator Breather Hose)	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
90467-33006	Clamp Or Clip, Hose(For Radiator Inlet)	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
90467-34004	Clamp Or Clip, Hose(For Water By-Pass Hose)	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
90480-22025	Cushion, Intercooler Support	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
91551-80616	BOLT FLANGE	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
91551-80625	Bolt(For Camshaft Housing Set)	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
91671-80820	Bolt (For Transmission Control Cable Bracket)	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
93315-14010	SCREW	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
93385-16016	New Genuine Part	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
96136-41501	Clamp Or Clip, Hose(For Water By-Pass Hose)	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
96136-42501	Clip(For Ventilation Hose)	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
96136-42901	Clip Or Clamp(For Ventilation Hose)	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)
96136-52201	Clip(For Ventilation Hose No.2)	Radiator & Water Outlet ([03.2015 - ] (1503- )2NRFKE)

Source: Public OEM parts-catalog data
Variants: 2 / 7
Category: 182
Collected: 2026-08-02
