Search › Model › NCP96

NCP96

Toyota BELTA · 2005 · 3,781 parts · 181 categories

3,781 items

Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE) 47

#	OEM	Part name
16261	16261-21090	Hose, Water By-Pass
16261	90467-13054	Clamp Or Clip, Hose(For Water By-Pass Hose)
16261	96135-51300	Clamp, Hose
16261	96136-41501	Clamp Or Clip, Hose(For Water By-Pass Hose)
16264	16264-21070	Hose, Water By-Pass, No.2
16268	16268-21022	Pipe, Water By-Pass, No.1
16268	16258-21020	Gasket(For Water By-Pass Pipe)
16268	16258-21021	Gasket(For Water By-Pass Pipe)
16321	16321-21020	Inlet, Water
16325	16325-62010	Gasket, Water Inlet Housing, No.1
16331	90916-03093	Thermostat
16361	16361-21090	Fan
16363	16363-28160	Motor, Cooling Fan
16381	16381-21020	Bar, Fan Belt Adjusting
16400	16400-21300	Radiator Assy
16400	16400-21371	RADIATOR ASSY
16400	16417-21280	Cock Sub-Assy, Radiator Drain
16400	16492-21050	Ring, O(For Oil Cooler Drain Cock)
16470	16377-21200	Hose Or Pipe(For Radiator Reserve Tank)
16470	90467-11085	Clamp Or Clip(For Radiator Breather Hose)
16471	16471-23030	Cap Sub-Assy, Reserve Tank
16502	16502-21060	Filler Sub-Assy, Water
16502	16502-21080	Filler Sub-Assy, Water
16520	16401-31480	Cap Sub-Assy, Radiator
16520	16401-31520	Radiator Cap Sub-Assy (108kPa)
16520	16401-36020	Cap Sub-Assy, Radiator
16520	16401-62100	Cap Sub-Assy, Radiator
16522	16522-21010	Bracket, Water Filler
16523	16523-21030	Cushion, Radiator Support
16535	90480-22025	Cushion, Intercooler Support
16553	16581-21010	Clamp, Hose
16571	90467-33006	Clamp Or Clip, Hose(For Radiator Inlet)
16571	16571-21120	Hose, Radiator, No.1
16572	90467-34004	Clamp Or Clip, Hose(For Water By-Pass Hose)
16572	16572-21090	Hose, Radiator, No.2
16573	16573-21040	Hose, Radiator, No.3
16711	16711-21110	Shroud, Fan
91631	91631-B0616	BOLT WWASHER
9011908	90119-08A53	BOLT WWASHER
9009904119	90099-04119	BOLT WASHER HEAD
9009905164	90099-05164	Nut
9011606127	90116-06127	Bolt, Stud(For Oil Pan)
9012606019	90126-06019	New Genuine Part
9017906299	90179-06299	Nut, Wire Adjusting, No.1
9167180614	91671-80614	Bolt (For Transmission Control Cable Bracket)
9415180600	94151-80600	Nut, Cap(For Cylinder Head Cover)
9415180801	94151-80801	NUT FLANGE

OEM	Part name	Category
16258-21020	Gasket(For Water By-Pass Pipe)	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16258-21021	Gasket(For Water By-Pass Pipe)	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16261-21090	Hose, Water By-Pass	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16264-21070	Hose, Water By-Pass, No.2	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16268-21022	Pipe, Water By-Pass, No.1	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16321-21020	Inlet, Water	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16325-62010	Gasket, Water Inlet Housing, No.1	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16361-21090	Fan	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16363-28160	Motor, Cooling Fan	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16377-21200	Hose Or Pipe(For Radiator Reserve Tank)	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16381-21020	Bar, Fan Belt Adjusting	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16400-21300	Radiator Assy	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16400-21371	RADIATOR ASSY	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16401-31480	Cap Sub-Assy, Radiator	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16401-31520	Radiator Cap Sub-Assy (108kPa)	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16401-36020	Cap Sub-Assy, Radiator	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16401-62100	Cap Sub-Assy, Radiator	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16417-21280	Cock Sub-Assy, Radiator Drain	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16471-23030	Cap Sub-Assy, Reserve Tank	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16492-21050	Ring, O(For Oil Cooler Drain Cock)	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16502-21060	Filler Sub-Assy, Water	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16502-21080	Filler Sub-Assy, Water	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16522-21010	Bracket, Water Filler	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16523-21030	Cushion, Radiator Support	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16571-21120	Hose, Radiator, No.1	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16572-21090	Hose, Radiator, No.2	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16573-21040	Hose, Radiator, No.3	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16581-21010	Clamp, Hose	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
16711-21110	Shroud, Fan	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
90099-04119	BOLT WASHER HEAD	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
90099-05164	Nut	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
90116-06127	Bolt, Stud(For Oil Pan)	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
90119-08A53	BOLT WWASHER	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
90126-06019	New Genuine Part	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
90179-06299	Nut, Wire Adjusting, No.1	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
90467-11085	Clamp Or Clip(For Radiator Breather Hose)	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
90467-13054	Clamp Or Clip, Hose(For Water By-Pass Hose)	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
90467-33006	Clamp Or Clip, Hose(For Radiator Inlet)	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
90467-34004	Clamp Or Clip, Hose(For Water By-Pass Hose)	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
90480-22025	Cushion, Intercooler Support	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
90916-03093	Thermostat	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
91631-B0616	BOLT WWASHER	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
91671-80614	Bolt (For Transmission Control Cable Bracket)	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
94151-80600	Nut, Cap(For Cylinder Head Cover)	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
94151-80801	NUT FLANGE	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
96135-51300	Clamp, Hose	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
96136-41501	Clamp Or Clip, Hose(For Water By-Pass Hose)	Radiator & Water Outlet ([11.2005 - ] (0511- )2NZFE)
