MX63

Toyota MARK-2 · 1980 · 5,046 parts · 186 categories

5,046 items

Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#) 42

#	OEM	Part name
44101	90201-30003	Washer, Plate(For Steering Worm)
44101	90301-44001	Ring, O(For Steering Worm)
44101	90374-30003	Bearing, Thrust Needle Roller(For Steering Worm)
44101	90562-47002	Ring(For Steering Worm)
44105	44105-22040	Housing Sub-Assy, Valve
44105	90301-32002	Ring, O(For Valve Housing)
44105	90562-30002	Ring(For Valve Housing)
44105	90410-05035	Seat, Union(For Valve Body Housing)
44105	90410-06030	Seat, Union(For Valve Body Housing)
44107	44107-22030	Housing Sub-Assy, Power Steering Gear
44107	90364-30002	Bearing, Needle Roller(For Power Steering Gear Housing)
44107	90301-32001	Ring, 0 (For Hoist Cylinder Delivery)
44107	90301-62002	Ring, O(For Power Steering Gear Housing)
44107	96710-01010	Ring, O(For Oil Pump)
44107	96711-19010	Ring, O(For Oil Level Gage Guide)
44107	90562-29001	Ring(For Power Steering Gear Housing)
44107	90562-30001	Ring(For Power Steering Gear Housing)
44107	90521-41001	Ring, Hole Snap(For Power Steering Gear Housing)
44107	90312-30001	Seal, Oil(For Power Steering Gear Housing)
44108	44108-22020	Cover Sub-Assy, Side
44108	90301-58001	Ring, O(For Side Cover)
44111	44111-22030	Shaft, Cross
44114	90562-58001	Ring(For Power Piston Nut)
44114	90301-53001	Ring, O(For Power Piston Nut)
44114	90360-06021	Ball(For Power Piston Nut)
44115	44115-22010	Guide, Ball
44116	44116-22010	Clamp, Ball Guide
44141	44104-22011	Plug Sub-Assy, Adjuster
44141	90301-51001	Ring, O(For Adjuster Plug)
44141	90311-19002	Seal, Oil(For Adjuster Plug)
44141	90369-22001	Bearing(For Adjuster Plug)
44141	90369-22004	Bearing(For Adjuster Plug)
44142	44142-22010	Nut, Lock
44142	44142-22020	Nut, Lock
44210	44120-22110	Valve Assy, Power Steering Control
44257	45357-22010	Screw, Cross Shaft Adjusting
44257	45357-60030	Screw, Cross Shaft Adjusting
44257	90210-10001	Washer, Seal(For Cross Shaft Adjusting Screw)
9011910054	90119-10054	BOLT
9017010208	90170-10208	NUT
9331915008	93319-15008	SCREW
9452100500	94521-00500	New Genuine Part

OEM	Part name	Category
44104-22011	Plug Sub-Assy, Adjuster	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
44105-22040	Housing Sub-Assy, Valve	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
44107-22030	Housing Sub-Assy, Power Steering Gear	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
44108-22020	Cover Sub-Assy, Side	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
44111-22030	Shaft, Cross	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
44115-22010	Guide, Ball	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
44116-22010	Clamp, Ball Guide	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
44120-22110	Valve Assy, Power Steering Control	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
44142-22010	Nut, Lock	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
44142-22020	Nut, Lock	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
45357-22010	Screw, Cross Shaft Adjusting	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
45357-60030	Screw, Cross Shaft Adjusting	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90119-10054	BOLT	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90170-10208	NUT	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90201-30003	Washer, Plate(For Steering Worm)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90210-10001	Washer, Seal(For Cross Shaft Adjusting Screw)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90301-32001	Ring, 0 (For Hoist Cylinder Delivery)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90301-32002	Ring, O(For Valve Housing)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90301-44001	Ring, O(For Steering Worm)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90301-51001	Ring, O(For Adjuster Plug)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90301-53001	Ring, O(For Power Piston Nut)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90301-58001	Ring, O(For Side Cover)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90301-62002	Ring, O(For Power Steering Gear Housing)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90311-19002	Seal, Oil(For Adjuster Plug)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90312-30001	Seal, Oil(For Power Steering Gear Housing)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90360-06021	Ball(For Power Piston Nut)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90364-30002	Bearing, Needle Roller(For Power Steering Gear Housing)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90369-22001	Bearing(For Adjuster Plug)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90369-22004	Bearing(For Adjuster Plug)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90374-30003	Bearing, Thrust Needle Roller(For Steering Worm)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90410-05035	Seat, Union(For Valve Body Housing)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90410-06030	Seat, Union(For Valve Body Housing)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90521-41001	Ring, Hole Snap(For Power Steering Gear Housing)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90562-29001	Ring(For Power Steering Gear Housing)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90562-30001	Ring(For Power Steering Gear Housing)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90562-30002	Ring(For Valve Housing)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90562-47002	Ring(For Steering Worm)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
90562-58001	Ring(For Power Piston Nut)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
93319-15008	SCREW	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
94521-00500	New Genuine Part	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
96710-01010	Ring, O(For Oil Pump)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
96711-19010	Ring, O(For Oil Level Gage Guide)	Steering Column & Shaft ([09.1980 - 08.1982] (8009-8208)GX6#,LX6#,MX6#,RX60 ; (8009-8209)TX60 ..GL ; (8208- )SX60..GL,GR,STD ; (8208- )GX6#, LX60,65,MX6#)
