Search › Model › LH20
LH20
Radiator Support & Wind Guide ([02.1977 - ] (7702- )) 10
| # | OEM | Part name |
|---|---|---|
| 53167 | 53167-26020 | Rod, Radiator Brace, Rh |
| 53167 | 53167-26040 | Rod, Radiator Brace, Rh |
| 53167 | 90540-10022 | Cushion(For Engine Under Cover Bracket) |
| 53167 | 90440-11043 | Tube(For Radiator Brace Rod) |
| 53168 | 53169-26030 | Rod, Radiator Brace, Lh |
| 9017908146 | 90179-08146 | Nut |
| 9017908146 | 90179-08204 | Nut |
| 9161140816 | 91611-40816 | Screw Or Bolt(For Valve Rocker Shaft Lock) |
| 9161140816 | 91611-B0816 | Bolt |
| 9461310800 | 94613-10800 | Spacer (For Control Select Lever Support) |
| OEM | Part name | Category |
|---|---|---|
| 53167-26020 | Rod, Radiator Brace, Rh | Radiator Support & Wind Guide ([02.1977 - ] (7702- )) |
| 53167-26040 | Rod, Radiator Brace, Rh | Radiator Support & Wind Guide ([02.1977 - ] (7702- )) |
| 53169-26030 | Rod, Radiator Brace, Lh | Radiator Support & Wind Guide ([02.1977 - ] (7702- )) |
| 90179-08146 | Nut | Radiator Support & Wind Guide ([02.1977 - ] (7702- )) |
| 90179-08204 | Nut | Radiator Support & Wind Guide ([02.1977 - ] (7702- )) |
| 90440-11043 | Tube(For Radiator Brace Rod) | Radiator Support & Wind Guide ([02.1977 - ] (7702- )) |
| 90540-10022 | Cushion(For Engine Under Cover Bracket) | Radiator Support & Wind Guide ([02.1977 - ] (7702- )) |
| 91611-40816 | Screw Or Bolt(For Valve Rocker Shaft Lock) | Radiator Support & Wind Guide ([02.1977 - ] (7702- )) |
| 91611-B0816 | Bolt | Radiator Support & Wind Guide ([02.1977 - ] (7702- )) |
| 94613-10800 | Spacer (For Control Select Lever Support) | Radiator Support & Wind Guide ([02.1977 - ] (7702- )) |
