| 12601-0L050 |
Protector, Intercooler |
Air Cleaner ([08.2012 - ] (1107- )1KDFTV..KUN51..SUVW..5FC..DCR..IND,LA ,TH ; (1208- )2KDFTV..IDN,PHL ; (1210- )2KDFTV ..KUN50..MA) |
| 12601-0L051 |
Cover Sub-Assy, Engine, No.1 |
Air Cleaner ([08.2012 - ] (1107- )1KDFTV..KUN51..SUVW..5FC..DCR..IND,LA ,TH ; (1208- )2KDFTV..IDN,PHL ; (1210- )2KDFTV ..KUN50..MA) |
| 17116-0L010 |
Gasket, Intake Flange |
Air Cleaner ([08.2012 - ] (1107- )1KDFTV..KUN51..SUVW..5FC..DCR..IND,LA ,TH ; (1208- )2KDFTV..IDN,PHL ; (1210- )2KDFTV ..KUN50..MA) |
| 17341-30060 |
Hose, Air, No.1 |
Air Cleaner ([08.2012 - ] (1107- )1KDFTV..KUN51..SUVW..5FC..DCR..IND,LA ,TH ; (1208- )2KDFTV..IDN,PHL ; (1210- )2KDFTV ..KUN50..MA) |
| 17342-30010 |
Hose, Air, No.2 |
Air Cleaner ([08.2012 - ] (1107- )1KDFTV..KUN51..SUVW..5FC..DCR..IND,LA ,TH ; (1208- )2KDFTV..IDN,PHL ; (1210- )2KDFTV ..KUN50..MA) |
| 17860-0L020 |
Connector, Intake Air |
Air Cleaner ([08.2012 - ] (1107- )1KDFTV..KUN51..SUVW..5FC..DCR..IND,LA ,TH ; (1208- )2KDFTV..IDN,PHL ; (1210- )2KDFTV ..KUN50..MA) |
| 17940-0L060 |
Intercooler Assy |
Air Cleaner ([08.2012 - ] (1107- )1KDFTV..KUN51..SUVW..5FC..DCR..IND,LA ,TH ; (1208- )2KDFTV..IDN,PHL ; (1210- )2KDFTV ..KUN50..MA) |
| 17945-0L020 |
Bracket, Intercooler Support |
Air Cleaner ([08.2012 - ] (1107- )1KDFTV..KUN51..SUVW..5FC..DCR..IND,LA ,TH ; (1208- )2KDFTV..IDN,PHL ; (1210- )2KDFTV ..KUN50..MA) |
| 17945-30080 |
Bracket, Intercooler Support |
Air Cleaner ([08.2012 - ] (1107- )1KDFTV..KUN51..SUVW..5FC..DCR..IND,LA ,TH ; (1208- )2KDFTV..IDN,PHL ; (1210- )2KDFTV ..KUN50..MA) |
| 17946-0L020 |
Bracket, Intercooler Support, No.2 |
Air Cleaner ([08.2012 - ] (1107- )1KDFTV..KUN51..SUVW..5FC..DCR..IND,LA ,TH ; (1208- )2KDFTV..IDN,PHL ; (1210- )2KDFTV ..KUN50..MA) |
| 17946-30040 |
Bracket, Intercooler Support, No.2 |
Air Cleaner ([08.2012 - ] (1107- )1KDFTV..KUN51..SUVW..5FC..DCR..IND,LA ,TH ; (1208- )2KDFTV..IDN,PHL ; (1210- )2KDFTV ..KUN50..MA) |
| 17947-0L010 |
Bracket, Intercooler Support, No.3 |
Air Cleaner ([08.2012 - ] (1107- )1KDFTV..KUN51..SUVW..5FC..DCR..IND,LA ,TH ; (1208- )2KDFTV..IDN,PHL ; (1210- )2KDFTV ..KUN50..MA) |
| 17947-30020 |
Bracket, Intercooler Support, No.3 |
Air Cleaner ([08.2012 - ] (1107- )1KDFTV..KUN51..SUVW..5FC..DCR..IND,LA ,TH ; (1208- )2KDFTV..IDN,PHL ; (1210- )2KDFTV ..KUN50..MA) |
| 90105-08070 |
Bolt (For Pawl Stopper Plate) |
Air Cleaner ([08.2012 - ] (1107- )1KDFTV..KUN51..SUVW..5FC..DCR..IND,LA ,TH ; (1208- )2KDFTV..IDN,PHL ; (1210- )2KDFTV ..KUN50..MA) |
| 90105-T0070 |
New Genuine Part |
Air Cleaner ([08.2012 - ] (1107- )1KDFTV..KUN51..SUVW..5FC..DCR..IND,LA ,TH ; (1208- )2KDFTV..IDN,PHL ; (1210- )2KDFTV ..KUN50..MA) |
| 90119-06830 |
BOLT WWASHER |
Air Cleaner ([08.2012 - ] (1107- )1KDFTV..KUN51..SUVW..5FC..DCR..IND,LA ,TH ; (1208- )2KDFTV..IDN,PHL ; (1210- )2KDFTV ..KUN50..MA) |
| 90119-08C79 |
New Genuine Part |
Air Cleaner ([08.2012 - ] (1107- )1KDFTV..KUN51..SUVW..5FC..DCR..IND,LA ,TH ; (1208- )2KDFTV..IDN,PHL ; (1210- )2KDFTV ..KUN50..MA) |
| 90119-T0429 |
New Genuine Part |
Air Cleaner ([08.2012 - ] (1107- )1KDFTV..KUN51..SUVW..5FC..DCR..IND,LA ,TH ; (1208- )2KDFTV..IDN,PHL ; (1210- )2KDFTV ..KUN50..MA) |
| 90176-06019 |
Nut (For Rear Wiper Arm Setting) |
Air Cleaner ([08.2012 - ] (1107- )1KDFTV..KUN51..SUVW..5FC..DCR..IND,LA ,TH ; (1208- )2KDFTV..IDN,PHL ; (1210- )2KDFTV ..KUN50..MA) |
| 90460-65012 |
Clamp, Hose |
Air Cleaner ([08.2012 - ] (1107- )1KDFTV..KUN51..SUVW..5FC..DCR..IND,LA ,TH ; (1208- )2KDFTV..IDN,PHL ; (1210- )2KDFTV ..KUN50..MA) |
| 90460-80006 |
Clamp, Hose |
Air Cleaner ([08.2012 - ] (1107- )1KDFTV..KUN51..SUVW..5FC..DCR..IND,LA ,TH ; (1208- )2KDFTV..IDN,PHL ; (1210- )2KDFTV ..KUN50..MA) |
| 91671-00816 |
New Genuine Part |
Air Cleaner ([08.2012 - ] (1107- )1KDFTV..KUN51..SUVW..5FC..DCR..IND,LA ,TH ; (1208- )2KDFTV..IDN,PHL ; (1210- )2KDFTV ..KUN50..MA) |
