Search › Model › KDJ125

KDJ125

Toyota LAND-CRUISER-PRADO · 2002 · 5,584 parts · 246 categories

5,584 items

Air Cleaner ([08.2006 - ] (0608- )1KDFTV) 25

#	OEM	Part name
17116	17116-67021	Gasket, Intake Flange
17341	17341-30050	Hose, Air, No.1
17341	17341-30060	Hose, Air, No.1
17341	90460-80006	Clamp, Hose
17342	17342-30010	Hose, Air, No.2
17861	17860-30020	Connector, Intake Air
17861	17860-30070	Connector, Intake Air
17940	17940-30070	Intercooler Assy
17940	17940-30080	Intercooler Assy
17943	12602-30011	Protector, Intercooler
17943	17943-30021	Protector, Intercooler
17943	17943-30022	Protector, Intercooler
17943	17943-30030	Protector, Intercooler
17945	17945-30060	Bracket, Intercooler Support
17945	17945-30080	Bracket, Intercooler Support
17946	17946-30020	Bracket, Intercooler Support, No.2
17946	17946-30050	Bracket, Intercooler Support, No.2
17947	17947-30010	Bracket, Intercooler Support, No.3
17947	17947-30020	Bracket, Intercooler Support, No.3
9011908	90119-08C79	New Genuine Part
9010508070	90105-08070	Bolt (For Pawl Stopper Plate)
9011906830	90119-06830	BOLT WWASHER
9046065012	90460-65012	Clamp, Hose
9155180614	91551-80614	Bolt(For Vacuum Transmitting Pipe)
9167100816	91671-00816	New Genuine Part

OEM	Part name	Category
12602-30011	Protector, Intercooler	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
17116-67021	Gasket, Intake Flange	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
17341-30050	Hose, Air, No.1	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
17341-30060	Hose, Air, No.1	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
17342-30010	Hose, Air, No.2	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
17860-30020	Connector, Intake Air	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
17860-30070	Connector, Intake Air	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
17940-30070	Intercooler Assy	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
17940-30080	Intercooler Assy	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
17943-30021	Protector, Intercooler	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
17943-30022	Protector, Intercooler	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
17943-30030	Protector, Intercooler	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
17945-30060	Bracket, Intercooler Support	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
17945-30080	Bracket, Intercooler Support	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
17946-30020	Bracket, Intercooler Support, No.2	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
17946-30050	Bracket, Intercooler Support, No.2	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
17947-30010	Bracket, Intercooler Support, No.3	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
17947-30020	Bracket, Intercooler Support, No.3	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
90105-08070	Bolt (For Pawl Stopper Plate)	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
90119-06830	BOLT WWASHER	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
90119-08C79	New Genuine Part	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
90460-65012	Clamp, Hose	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
90460-80006	Clamp, Hose	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
91551-80614	Bolt(For Vacuum Transmitting Pipe)	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)
91671-00816	New Genuine Part	Air Cleaner ([08.2006 - ] (0608- )1KDFTV)

Source: Public OEM parts-catalog data
Variants: 2 / 10
Category: 246
Collected: 2026-08-02
